Docomo User Manua, F-04F User Manual
F-04F
INSTRUCTION MANUAL
’13.12
Thank you for purchasing "F-04F" mobile terminal.
Introduction
Before using your terminal, or when necessary, read this
manual to ensure safe use and handling.
Learning operations
"Quick start guide" (in Japanese only)
This manual provides information about screens and
operations of basic functions.
"Instruction Manual" application (e-manual)
(installed in the terminal) (in Japanese only)
This manual provides detailed information and operations of
the functions.
〈
Operation steps
From the Home screen, [MENU]→[Apps]→[Instruction
Manual]
･
For "NX!Home", from the Home screen, →Tap
[Instruction Manual].
This manual provides detailed information and operations of
the functions.
〈
From PC〉 http://www.nttdocomo.co.jp/english/support/
trouble/manual/download/index.html
*You can download the latest information.
〉
"INSTRUCTION MANUAL" (PDF file)
･
Viewing this manual
In this manual, "F-04F" mobile terminal is usually referred to
as "the terminal".
･
The images or illustration used in this manual are examples.
They may differ from the actual displays.
･
In this manual, basic explanations and screen images for
"Telephone Home" as Home application are provided. If
operation steps are different in "NX!Home", explanations in
"NX!Home" are also provided.
･
In this manual, "authenticate" indicates the operating
procedure for entering security code or performing
fingerprint authentication depending on functions.
･
Unauthorized copying of parts of or this entire manual is
prohibited.
･
The contents in this manual, URL and contents are subject to
change without prior notice.
Basic package
■F-04
F (including warranty)■Back Cover F
Quick start guide (Japanese)
■
■
Battery Pack F
81
■
Desktop Holder F
□
Other options→P153
31
45
1
Contents/Precautions
Contents
■
Basic package .......................................................... 1
■
Before using the terminal ....................................... 5
■
Precautions (Always follow these directions) ......6
■
Handling precautions ............................................ 15
■
Waterproofness/Dustproofness .......................... 21
Before using the terminal ........... 26
Part names and functions ................................................ 26
docomo mini UIM card ....................................................27
Battery pack ......................................................................29
Charging ............................................................................31
Turning power on/off .......................................................34
Basic operation ................................................................. 35
Character entry .................................................................37
Initial settings ...................................................................43
Indicator LED ....................................................................44
Screen/Icon .......................................................................44
Home screen (Telephone Home) ....................................49
Menu screen (Telephone Home) .....................................50
Home screen (NX!Home) ................................................53
Application list (NX!Home) .............................................55
Task manager ...................................................................57
Switching the home applications ...................................57
Calling .........................................58
Making a call ..................................................................... 58
Receiving a call ................................................................. 60
Operation during a call .................................................... 60
Recent calls ....................................................................... 61
Phone memo .................................................................... 62
Voice memo ...................................................................... 63
Call settings ......................................................................64
Phonebook ........................................................................ 65
Mail/Browser ................................69
docomo mail ..................................................................... 69
SMS ................................................................................... 69
Email ................................................................................. 71
NX! Mail ............................................................................ 75
Early warning "Area Mail" ............................................... 77
Browser ............................................................................. 78
2
Contents/Precautions
Applications ................................ 83
Applications ......................................................................83
dmenu ...............................................................................83
ToruCa ...............................................................................83
Camera ..............................................................................84
Gallery ...............................................................................90
Media Player .....................................................................91
GPS/Navigation ................................................................92
Schedule ...........................................................................94
AlarmClock ........................................................................95
Calculator ..........................................................................95
Search ...............................................................................96
Document Viewer ............................................................. 96
docomo backup ................................................................97
Settings ....................................... 99
Setting menu ....................................................................99
WIRELESS & NETWORKS .............................................103
Sound & Vibration settings ...........................................109
Display .............................................................................112
Multimedia ......................................................................115
Storage ............................................................................115
Battery .............................................................................116
NX! eco ...........................................................................116
Apps ................................................................................117
docomo service ..............................................................118
Lock/Security ..................................................................118
Encryption settings ........................................................127
My physical profile ......................................................... 128
Slide-in function .............................................................129
Language & input ........................................................... 130
Adding an account ......................................................... 131
Date & time ..................................................................... 131
Accessibility .................................................................... 132
About phone ................................................................... 132
File management .......................133
Storage (Internal storage) ............................................. 133
microSD card (External storage) ................................... 133
File operations ................................................................ 135
Data communication .................136
Infrared communication ................................................ 136
Bluetooth
Using Osaifu-Keitai function ......................................... 141
communication .......................................... 138
External device connection .......144
Connecting with a PC ..................................................... 144
Connecting with other devices .....................................145
International roaming ................ 146
Outline of international roaming (WORLD WING) ...... 146
Available service overseas ............................................ 146
Before using the terminal overseas .............................. 146
Settings for overseas use .............................................. 148
Making/Receiving a call in the country you stay ......... 149
Setting international roaming ....................................... 151
After returning to Japan ................................................ 152
3
Contents/Precautions
Appendix/Index ......................... 153
Options and related devices .......................................... 153
Troubleshooting (FAQ) ..................................................153
Smartphone Anshin Remote Support ..........................161
Resetting the terminal .................................................... 162
Warranty and After-Sales Service ................................. 162
Software update .............................................................165
Main specifications ........................................................168
Specific Absorption Rate (SAR) of Mobile Phones ...... 170
Export Administration Regulations ..............................175
Intellectual Property Right .............................................175
SIM unlock ......................................................................178
Index ................................................................................179
4
Contents/Precautions
Before using the terminal
･
This terminal supports LTE, W-CDMA, GSM/GPRS, Wireless
LAN System.
･
Because your terminal uses wireless transmission, it may
not function in locations where it is difficult for radio waves
to penetrate, such as tunnels, underground passages and
some buildings, in areas where radio waves are weak, or out
of Xi and FOMA service area. Even when you are high up in
a tall building or condominium and nothing blocks your
view outside, your terminal may not be able to receive or
transmit signals. Also, communication may be interrupted
even when there are strong radio waves with 4 signal status
icons on the terminal and you are not moving (traveling).
･
Because your terminal uses radio waves to communicate, it
is possible that a third party may attempt to tap your calls.
However, the LTE, W-CDMA, GSM/GPRS automatically
applies a confidential communication function to all calls, so
even if a third party could somehow tap a call, they only hear
noise.
･
Your terminal encodes voice communication as digital data.
When you are operating your terminal while moving to a
location subject to weaker radio wave conditions, the
transmitted digital data may not be correctly decoded and as
a result the decoded voice may differ somewhat from the
actual voice.
･
Maintain a separate record of the data you saved in the
terminal. Note that DOCOMO assumes no responsibility for
any loss of saved contents of data resulting from
malfunction, repair, changing of the model or other
handling of the terminal.
･
In the terminal, as it is for a PC, some applications that you
install may give instability of the operation, or may send
your location information or personal information
registered to the terminal to outside via the Internet and the
information may be used improperly. Please thoroughly
check a provider and operation status of the application etc.
which you want to use beforehand and then use it.
･
You are recommended to save important data to microSD
card or a PC.
･
This terminal supports FOMA Plus-Area and FOMA HIGHSPEED Area.
･
The terminal does not support i-mode sites (programs) or
i-αppli.
･
You can use the terminal only with docomo mini UIM card.
If you have a UIM or FOMA card, bring it to a docomo Shop
to replace.
･
Even in Manner mode, screen capturing sound when
activating the camera, capturing sound for Capture & Draw,
shutter sound, auto focus lock sound, count down sound for
self timer, and Find Me Ringtone sound for Bluetooth Low
Energy setting are emitted.
･
You can check your own phone number in the following
step.
From the Home screen, →[Settings]→[My profile]
･
The terminal automatically performs communication for
some functions, for example, to synchronize data, check the
latest software or maintain connection with the server. If you
transmit a large amount of data such as downloading
applications or watching video, a packet communication
charge becomes high. Subscription of packet flat-rate
service is highly recommended.
5
Contents/Precautions
･
Depending on the applications or service you use, packet
communication charge may be applied even in Wi-Fi
communication.
･
The software on the terminal can be updated with the latest
information.→P165
･
Display is manufactured by taking advantage of highly
advanced technology but some dots may be always or never
lit. Note that, this shows characteristics of liquid crystal
displays and not defects in the terminals.
･
For commercially available option devices, DOCOMO is not
liable to any failures or the malfunctions.
･
When the memory space of the microSD card or the terminal
is low, running applications may not operate normally. In
this case, delete the saved data.
･
You can use pre-installed applications and applications that
can be downloaded from "
support)" in dmenu on the terminal.
Downloading applications from browser or Google Play is
not available.
･
If your terminal is lost, change or disable passwords for PCmail account on a PC to prevent other persons from using.
･
Set the screen lock to ensure the security of your terminal for
its loss.→P121
･
The terminal supports only sp-mode, mopera U and
Business mopera Internet. Other providers are not
supported.
･
For details on usage fee, refer to http://
www.nttdocomo.co.jp/english/.
お客様サポート
(Customer
Precautions (Always follow these directions)
・
Before using your terminal, or when necessary, read the
precautions below to ensure safe use and handling. After
reading this manual, keep it carefully.
・
These precautions are intended to protect you and others
around you. Read and follow them carefully to avoid injury,
damage to the product or damage to property.
・
The signs below differentiate between the levels of danger
that can occur if the product is not used within the specified
guidelines.
This sign denotes that death
DANGER
WARNING
CAUTION
or serious injury may directly
result from improper use.
This sign denotes that death
or serious injury may result
from improper use.
This sign denotes that minor
injury or damage to property
may result from improper
use.
6
Contents/Precautions
・
The symbols below show specific directions.
This symbol denotes that the action is
prohibited.
Don’t
This symbol denotes that disassembling the
phone or its components is not allowed.
No disassembl y
This symbol denotes that using the phone or its
components in a bathroom or other highly
No liquids
humid area is not allowed.
This symbol denotes that using the phone or its
components with wet hands is not allowed.
No wet hands
This symbol denote s that an instruction must be
obeyed at all times.
Do
This symbol denotes that the equipment should
be unplugged.
Unplug
■
Precautions contain the description below.
Handling the terminal, battery pack, adapter, desktop holder
and docomo mini UIM card (common)..................................7
Handling the terminal..................................................................9
Handling battery pack ...............................................................11
Handling adapter and desktop holder .....................................12
Handling docomo mini UIM card.............................................13
Handling mobile phones near electronic medical equipment
.................................................................................................13
Material list.................................................................................14
◆
Handling the terminal, battery pack,
adapter, desktop holder and docomo mini
UIM card (common)
DANGER
Do not use, store or leave the terminal in hot
places (e.g. by the fire, near a heater, under a
kotatsu, in direct sunlight, in a car in the hot sun).
Don’t
May cause fire, burns or injuries.
Do not put the terminal into heating cooking
device such as microwave oven or high-pressure
container.
Don’t
May cause fire, burns, injuries, electric shock.
Do not disassemble or remodel the equipment.
May cause fire, burns, injuries, electric shock.
No disassembl y
7
Contents/Precautions
Do not let the terminal get wet with water,
drinking water, urine of pet animals,
No liquids
perspiration, etc.
May cause fire, burns, injuries, electric shock.
For waterproofness, refer to the page.
"Waterproofness/Dustproofness"
Do not allow liquid (water, drinking water, urine
of pet animals, perspiration, etc.) to come into
No liquids
the charging jack or the external connection jack.
May cause fire, burns, injuries, electric shock.
Use the optional devices specified by NTT
DOCOMO for your terminal.
May cause fire, burns, injuries, electric shock.
Do
WARNING
Do not throw the equipment or give a strong
force or hard shock to it.
May cause fire, burns, injuries, electric shock.
Don’t
Do not allow conductive materials (metal pieces,
pencil lead, etc.) to come in contact with the
charging jack or external connection jack or
Don’t
stereo earphone jack. Do not put those materials
inside the terminal.
May cause fire, burns, injuries, electric shock.
Do not cover or wrap the terminal with a blanket
etc. while using or charging.
May cause fire or burns.
Don’t
Turn the terminal OFF and stop charging before
entering a place such as a gas station where
Do
flammable gases are generated.
→
P21
The gas may catch fire.
When using Osaifu-Keitai in a place as a gas station, turn
OFF the terminal before using it.
(When Osaifu-Keitai lock is activated, deactivate it before
turning OFF the terminal.)
If the equipment starts giving off a strange smell,
overheats, becomes discolored or deformed
Do
during use, charging or in storage, immediately
perform the following operations.
･
Remove the power plug from the wall outlet or
cigarette lighter socket.
･
Turn the terminal OFF.
･
Remove battery pack from the terminal.
May cause fire, burns, injuries, electric shock.
CAUTION
Do not leave the equipment on unstable or
sloping surfaces.
The equipment may fall and cause injuries.
Don’t
Do not store the equipment in extremely humid,
dusty or hot areas.
May cause fire, burns, electric shock.
Don’t
Children using the equipment should be
instructed in proper operation by an adult. Do
Do
not allow them to use the equipment without
adult supervision.
May cause inju ries.
8
Contents/Precautions
Store the equipment out of reach of infant.
Equipment may be accidentally swallowed or cause
injuries.
Do
Be careful especially when using the terminal
connected to the adapter continuously for a long
Do
time.
If you use applications or call for a long time while
charging the batter y, the terminal, battery pa ck and
adapter may be heated.
Directly touching a hot part for a long time, you may have
redness, itching or rash on your skin, or it may result in
low-temperature burns depending on your constitution
and/or health condition.
◆
Handling the terminal
WARNING
Do not direct the infrared data port toward your
eye and transmit signals.
May cause harmful effect on eyes.
Don’t
Do not direct the infrared data port toward home
electric appliances etc. equipped with infrared
device when using infrared communication.
Don’t
May cause an accident because of malfunction of infrared
device.
Do not turn on the light by getting the lighting
part closer to other person's eyes. When
shooting infants, keep at least 1 m away from the
Don’t
object.
May impair eyesight. And may cause accidents like injury
etc., by dazzling or astounding other people.
Do not put foreign objects such as liquid like
water, metal pieces or burnable things into
docomo mini UIM card slot or microSD card slot.
Don’t
May cause fire, burns, injuries, electric shock.
Do not turn on the light aiming directly at the
driver of the car etc.
May disturb driving and cause an accident.
Don’t
Turn the terminal OFF in areas where use is
prohibited, such as in airplanes and hospitals.
May cause electronic equipment or electronic medical
Do
equipment to fail or malfunction.
When using the phone in a medical facility, be sure to
observe the regulations of the facility.
If you do prohibited act such as using the phone in an
airplane, you will be punished according to law.
If usage of the terminal in an aircraft is admitted by setting
airplane mode, etc., use the terminal under the direction of
the airline.
When you talk by setting handsfree or ring alert
is sounding, keep the terminal away from your
Do
ear.
And, when connecting the earphone/
microphone etc. to the terminal and play a game
or music, adjust the volume moderately.
Too loud volume may cause a hearing loss.
And, if you cannot hear the sound around you clearly, it
may cause an accident.
If you have weak heart, be careful when setting
the incoming vibrate alert (vibration) or alert
Do
volume setting.
May cause harmful effect on heart.
9
Contents/Precautions
When you use electronic medical equipment,
check with the equipment manufacturer to
Do
determine how the device is affected by radio
waves before using.
May cause harmful effect on electronic medical equipment
etc.
Turn the terminal OFF near high-precision
electronic control equipment or electronic
Do
equipment using low-power signals.
May cause the equipment to fail or malfunction.
Examples of electronic equipment to avoid
*
Hearing aids, implanted pacemakers or d efibrillators, other
electronic medical equipment, fire alar ms, automatic doors and
other automatic control equipment.
Users wearing implanted pacemakers or def ibrillators or other
electronic medical equipment should check with the
manufacturer or sales outlet about the effect of radio freq uencies
on the equipment.
When the display or camera lens is accidentally
broken, be careful of broken glass or exposed
Do
internal parts of the terminal.
Surface of display is made of hardened glass and camera
lens is made of plastic panel so that they are not to be
shattered, however, if you mistakenly touch broken or
exposed parts, you may be injured.
CAUTION
Do not swing the terminal by the strap etc.
May cause accident such as injury to yourself or others by
hitting.
Don’t
Do not use the damaged terminal.
May cause fire, burns, injuries, electric shock.
Don’t
When using the motion sensor, check the safety
around you, hold the terminal firmly, and do not
shake it unnecessarily.
Don’t
May cause accident such as injuries.
If the display part is accidentally broken and the
liquid crystal leaks out, do not make the
substance contact with your skin of face or
Don’t
hands.
May cause loss of sight or skin problems.
If the liquid crystal gets into your eyes or mouth, rinse it
with clean water and see a doctor immediately.
And, if the liquid adheres to skin or clothing, use alcohol
etc. to wipe it off, then wash with soap.
To use the terminal in car, check with automobile
manufacturer or dealer to determine how the
Do
device is affected by radio waves before using.
In rare cases, using the phone in some vehicle models can
cause the vehicle's electronic equipment to malfunction. In
that case, stop using the terminal immediately.
The use of the terminal may cause itching,
rashes, eczema, or other symptoms depending
Do
on the user's physical condition. If you develop
skin problems, stop using the phone
immediately, and see a doctor.
For material of each part →P14 "Material list"
When watching the display, take a certain
distance from the display in a fully bright place.
May reduce visual ac uity.
Do
10
Contents/Precautions
◆
Handling battery pack
■
Check that battery type with indication on the battery pack
label.
Display Battery type
Li-ion 00 Li-ion battery
DANGER
Do not connect a wire or other metal objects to
the contacts. And, do not carry or store the
terminal with objects like a metal necklace.
Don’t
May cause battery pack to ignite, burst, heat or leak.
Check the orientation of the battery pack to
attach to the terminal, and do not try to force the
battery pack onto the terminal if you are having
Don’t
trouble attaching it.
May cause battery pack to ignite, burst, heat or leak.
Do not throw the terminal into the fire.
May cause battery pack to ignite, burst, heat or leak.
Don’t
Do not nail the terminal, hit with a hammer or
step on it.
May cause battery pack to ignite, burst, heat or leak.
Don’t
If the battery pack's fluid etc. contacts eyes,
immediately flush the eyes with clean water and
Do
see a doctor right away. Do not rub the eyes.
May cause loss of sight.
WARNING
If the battery pack seems to have abnormalities
such as deformation or scratches due to falling,
never use it.
Don’t
May cause battery pack to ignite, burst, heat or leak.
If the battery pack leaks or gives off a strange
smell, immediately remove it from the vicinity of
Do
open flames.
The vapors from leaking battery fluid may ignite, fire or
explode.
Be careful not to let your pet bite the battery
pack.
May cause battery pack to ignite, burst, heat or leak.
Do
CAUTION
Do not discard the old terminal together with
other garbage.
May cause igniting or environmental destruction. Tape the
Don’t
terminals of old battery packs to insulate them, and then
bring them into a sales outlet such as docomo Shop. If
your local municipality has a battery recycling program,
dispose of them as provided for.
Do not use or charge a wet battery pack.
May cause battery pack to ignite, burst, heat or leak.
Don’t
11
Contents/Precautions
If fluid etc. leaks out from the battery pack, avoid
making the fluid contact with your skin of face or
Do
hands.
May cause loss of sight or skin problems. If the fluid etc.
put into your eyes or mouth, or contacts skin or clothes,
immediately flush the contacted area with clean water.
If the fluid etc. put into the eyes or mouth, immediately see
a doctor after flushing.
◆
Handling adapter and desktop holder
WARNING
Do not use the adapter cord if it gets damaged.
May cause fire, burns, electric shock.
Don’t
Do not use the AC adapter and the desktop
holder in a bathroom or other highly humid area.
May cause fire, burns, electric shock.
Don’t
Always use the DC adapter with a negativeground vehicle. Do not plug it into a positiveground vehicle.
Don’t
May cause fire, burns, electric shock.
When it starts to thunder, do not touch adapter.
May cause electric shock.
Don’t
Do not short the charging terminal while it is
connected to the outlet or cigarette lighter
socket. Do not touch the charging terminal with
Don’t
a part of your body such as your hand or finger.
May cause fire, burns, electric shock.
Don’t
Don’t
Don’t
No wet hands
Do
Do
Do
12
Do not place heavy objects on the adapter cord.
May cause fire, burns, electric shock.
When you insert and remove the AC adapter
from power outlet, do not contact a metal strap
or other metal objects with the jack.
May cause fire, burns, electric shock.
Do not put an excessive force up, down, left or
right to the adapter connected to the terminal.
May cause fire, burns, injuries, electric shock.
Do not touch the adapter cord, charging
terminal, desktop holder or outlet with wet
hands.
May cause fire, burns, electric shock.
Only use with the specified power source and
voltage. When charging the terminal overseas,
use AC adapter for global use.
If incorrect voltage is used, this may cause fire, burns or
electric shock.
AC adapter : 100V AC
DC adapter : 12V or 24V DC (spe cific for negative ground
vehicle)
AC adapter for global use : Between 100V and 240V AC
(Connect to the AC outlet for internal household use)
If the DC adapter's fuse blows, replace it only
with the specified fuse.
May cause fire, burns, electric shock. For the specified
fuse, see the instructions that come with the DC adapter.
Wipe off any dust that accumulates on the power
plug.
May cause fire, burns, electric shock.
Contents/Precautions
When you connect the AC adapter to an outlet,
firmly connect to the outlet.
May cause fire, burns, electric shock.
Do
When you disconnect the power plug from the
outlet or cigarette lighter socket, do not pull the
Do
adapter cord with excessive force. Instead, hold
the adapter to disconnect.
May cause fire, burns, electric shock.
Remove or insert the adapter to the terminal
evenly without applying excessive force.
May cause fire, burns, injuries, electric shock.
Do
Always remove the power plug from the outlet
or cigarette lighter when not using the adapter
Unplug
for an extended period.
May cause fire, burns, electric shock.
Immediately remove the power plug from the
outlet or cigarette lighter socket if water or other
Unplug
fluids get into the adapter.
May cause fire, burns, electric shock.
Always remove the power plug from the
cigarette lighter socket when cleaning the
Unplug
equipment.
May cause fire, burns, electric shock.
◆
Handling docomo mini UIM card
CAUTION
Be careful of the cut surface when removing
docomo mini UIM card.
May cause inju ries.
Do
◆
Handling mobile phones near electronic
medical equipment
WARNING
Wearers of medical equipment such as
implanted pacemakers or defibrillators must
Do
carry and use the terminal at least 15 cm away
from the implanted device.
The terminal's signals may affect the performance of
electronic medical equipment.
When electronic medical equipment other than
implanted pacemakers or defibrillators are in use
Do
outside of medical facilities (such as in home care
settings), check with the device manufacturer to
determine how the device is affected by
electrical signals.
The terminal's signals may affect the performance of
electronic medical equipment.
13
Contents/Precautions
When you are in a crowd etc. and you have
difficulties to keep a distance of 15 cm or more
Do
from others, turn the airplane mode on or power
off the terminal not to transmit signals.
There may be wearers of medical equipment such as
implanted pacemakers or defibrillators around you. The
terminal's signals may affect the performance of electronic
medical equipment.
When using the terminal in a medical facility, be
sure to observe the regulations of the facility.
Do
◆
Material list
Part Material/Surface treatment
Display panel Hardened glass/AF coating
Exterior case Front case PA-GF resin/Acrylic UV curable
Rear case PC + ABS-GF resin/Acrylic UV
Back cover PC-GF resin + Polyester
Receiver panel Acrylic resin/Acrylic UV curable
Home key PC resin/discontinuous
coating
curable coating
elastomer resin/Acrylic UV
curable coating
coating
evaporation + Acrylic UV
curable coating
Part Material/Surface treatment
Out-camera/
Infrared data
port
Side button (Power key) Aluminum alloy/Alumite
Side button (Camera key/
Volume key)
External connection jack
cap
Charging terminal PC resin + ABS resin/Gold
Fingerprint
sensor
■
Battery Pack F31
Body PC resin
Contacts Beryllium copper/Gold plating
Label Polyethylene/Black print letter
■
Desktop Holder F45
Top and bottom case ABS resin
Panel Acrylic resin/Acrylic UV curable
Sensor Epoxy resin
Top and
bottom
outer
periphery
Part Material/Surface treatment
Part Material/Surface treatment
coating
treatment
PC resin/Acrylic UV curable
coating
PC resin + Polyester elastomer
resin/Acrylic UV curable coating
plating
Stainless steel/Titanium coating
14
Contents/Precautions
Part Material/Surface treatment
Spacer (L/R), front hook,
side lever, charging
terminal (lever)
Charging terminal
(Contacts)
External connection jack Stainless steel/Tin plating
Rubber foot Polyurethane
Label (top case) Polyethylene
Label (bottom case front) PP resin
Label (bottom case back) Art paper
POM resin
Phosphor bronze/Gold plating
Handling precautions
◆
General
・
F-04F is waterproof/dustproof, however, do not allow
water or dust to seep into the terminal and do not allow
accessories or optional devices to get wet or attached with
dust.
- Battery pack, adapter, desktop holder, docomo mini UIM
card are not waterproof/dustproof. Do not use in a
bathroom or other highly humid area or do not let rain
touch. Or putting the terminal on your body, humidity of
perspiration may cause internal corrosion and
malfunction. Note that malfunctions, which are
determined to be caused by water as result of inspections,
are not covered by the warranty. Since these conditions
are outside the scope of the warranty, a repair, if at all
possible, is charged.
・
Clean the terminal with a dry soft cloth (such as a cloth for
eyeglasses).
- Rubbing it roughly with a dry cloth may scratch the
display.
- Drops of water or dirt left on the display may cause stains.
- If the terminal is wiped with alcohol, paint thinner, benzine
or detergent, the printing may disappear or color may
fade.
・
Clean the jack occasionally with a dry cotton swab etc.
- If the jack is soiled, connection gets worse and it may
cause power to be turned off or insufficient battery charge,
so clean the jack with a dry cotton swab etc.
Also, be careful never to damage the jack when cleaning it.
15
Contents/Precautions
・
Do not place the terminal near an air-conditioner outlet.
- The rapid change in temperature may cause condensation,
causing internal corrosion and malfunction.
・
When using, be careful not to subject excessive force to the
terminal or the battery.
- If the terminal is crammed into a brimming bag or placed
in a pocket and sat on, display, internal PCBs or battery
pack may be damaged or malfunction. And, if external
devices are plugged into the external connection jack or
the stereo earphone jack, the breakage of the connector or
malfunction may result.
・
Do not rub or scrape the display with a metal piece etc.
- May scratch the display, causing malfunction or damage.
・
Carefully read the separate instructions that come with
optional devices.
◆
The terminal
・
Do not press the surface of the touch panel strongly or
operate it with sharp objects such as a nail, a ballpoint pen
and a pin.
- It may damage the touch panel.
・
Avoid extreme temperature.
- Use the terminal where the temperature ranges between 5
and 40℃ (limited to the temporary use in a bathroom etc.
when temperature is above 36℃) and humidity ranges
between 45 and 85%.
・
The terminal may affect land-line phones, TVs or radios in
use nearby, so use it as far as possible from these
appliances.
・
Maintain a separate record of the data you saved in the
terminal.
- If the data is deleted, DOCOMO assumes no responsibility
for the loss of any data.
・
Do not drop the terminal or subject it to shocks.
- May cause malfunction or damage.
・
Do not plug external devices into the external connection
jack or stereo earphone jack at a slant, or do not pull it
forcibly while it is plugged.
- May cause malfunction or damage.
・
It is normal for the terminal to become warm during use or
charging. Continue to use it.
・
Do not leave the terminal with the camera in areas under
strong direct sunlight.
- May cause discoloring or burn-in of elements.
・
Use the terminal with the external connection jack cap
closed.
- Dust and/or water brought into the terminal cause
malfunction.
・
Do not use the terminal with the back cover removed.
- May cause removal of battery pack, malfunction or
damage.
・
Do not give a strong impact on the fingerprint sensor or
scratch the surface.
- It may cause not only malfunction of the fingerprint sensor
but also disabling authentication.
・
Clean the fingerprint sensor with a dry soft cloth (such as a
cloth for eyeglasses).
- When the fingerprint sensor is dirty or gets wet on the
surface, it cannot read the fingerprint and may cause
decrease the authentication performance or erroneous
operation.
・
While microSD card is being used, do not take the card out
or do not turn off the terminal.
- May cause data loss or malfunction.
16
Contents/Precautions
・
Do not bring magnetic cards etc. close to the terminal.
- Magnetic data in cash cards, credit cards, telephone cards,
floppy disks, etc. may be erased.
・
Do not bring magnetized objects close to the terminal.
- Bringing strong magnetism close may cause a
malfunction.
◆
Battery pack
・
The battery pack is a consumable part.
- Replace the battery pack if the terminal has extremely
short operation time on a full charge, though it may vary
by operating conditions. Purchase a new battery pack of
the specified type.
・
Charge the battery in an area within the proper ambient
temperature range (5-35℃).
・
The operation time provided by the battery pack varies by
the operating environment and battery pack's
deterioration.
・
The battery pack may swell out as it comes to near the end
of its lifetime depending on the usage conditions, but it is
not a problem.
・
Be careful especially about the following points when
preserving the battery pack.
- Storing under the state of the full charge (right after
charging ends)
- Storing under the state of the empty charge (too
exhausted to turn on the terminal)
They may cause the battery pack performance to be
degraded or its lifetime to be shortened.
A recommended battery level to store the terminal is
approximately 40% of remaining battery level as a guide.
◆
Adapter
・
Charge the battery in an area within the proper ambient
temperature range (5-35℃).
・
Do not charge the battery in the areas below.
- In areas of excessive humidity, dust or vibrations
- Near land-line phones or TV/radio
・
It is normal for the adapter to become hot while charging.
Continue to use it.
・
When using the DC adapter for charging, keep the vehicle
engine running.
- The vehicle's battery could become flat.
・
When using an outlet with a mechanism preventing
unplugging, follow the handling instructions for that outlet.
・
Do not give strong shock. Do not deform the charging
terminal.
- May cause malfunction.
17
Contents/Precautions
◆
docomo mini UIM card
・
Do not use excessive force to install/remove docomo mini
UIM card.
・
Note that DOCOMO assumes no responsibility for
malfunctions occurring as the result of inserting and using
docomo mini UIM card with another IC card reader/writer.
・
Always keep UIM ICs clean.
・
Clean docomo mini UIM card with a soft, dry cloth (such as
a cloth for eyeglasses).
・
Maintain a separate record of the data you saved in docomo
mini UIM card.
- If the data is deleted, DOCOMO assumes no responsibility
for the loss of any data.
・
To preserve the environment, bring the old docomo mini
UIM card to a sales outlet such as docomo Shop.
・
Take care not to scratch, touch accidentally or short IC.
- May cause data loss or malfunction.
・
Do not drop docomo mini UIM card or subject it to shocks.
- May cause malfunction.
・
Do not bend docomo mini UIM card or place heavy objects
on it.
- May cause malfunction.
・
Do not install docomo mini UIM card into the terminal with
a label or sticker put on.
- May cause malfunction.
◆
Bluetooth devices
・
This terminal is equipped with the security features, that
are compliant with Bluetooth standards for communication
via Bluetooth. However, depending on the settings, there
may not be enough security. Be aware of security risks
when using Bluetooth.
・
DOCOMO assumes no responsibility for any information
which may be leaked during communication via Bluetooth.
・
Frequency bands
Frequency bands used by the terminal Bluetooth function
are as below.
abdc
2.4FH/XX1
a
2.4 : Radio equipment that uses the 2400 MHz band.
b
FH/XX : The modulation is the FH-SS method or other
method (method other than DS-SS method/DS-FH
method/FH-OFDM composite method/OFDM method).
c
1 : The expected interference distance is 10 m or shorter.
d
2483.5 MHz are used, and the bandwidth used by mobile
object identification devices cannot be avoided.
Available channels vary by countries.
Use of Bluetooth function is limited in some countries.
Confirm regulations of the country/region to use it.
To use in airplane, confirm with airline company in advance.
: All bandwidths between 2400 MHz and
18
Contents/Precautions
Cautions on using Bluetooth devices
In the bandwidth used by this terminal, in addition to
home electric appliances such as a microwave oven and
industrial/scientific/medical devices, in-plant radio
stations used to identify mobile objects used in
production lines of a factory that require a license,
specified low power radio stations, or amateur radio
stations that do not require a license (hereafter "other
radio stations") can be in operation.
1. Before using the terminal, check whether "other radio
stations" are in operation in your neighborhood.
2. If radio wave interference occurs between the terminal
and "other radio stations", use the terminal in a
different location or "Turn the power OFF" to avoid the
radio wave interference.
3. For details, contact "General Inquiries" on the last page
of this manual.
◆
Wireless LAN (WLAN)
・
Wireless LAN (WLAN) exchanges information using radio
waves, and allows you to freely establish LAN connection if
you are within an area where radio wave reaches. On the
other side, if you communicate without appropriate
security settings, communications may be intercepted or
hacked by malicious parties. It is recommended to make
necessary security settings on your judgement and
responsibility.
・
Wireless LAN
Do not use wireless LAN in a place where magnetized by
electric products, AV, OA equipment, etc. or where
electromagnetic wave is generated.
- If magnetism or electrostatic noise affects the terminal,
noise may be increased or communication may not be
available (especially when using microwave oven, it may
affect the terminal).
- Using near TV or radio may cause poor reception or TV
screen may be blurred.
- When multiple wireless LAN access points exist near the
terminal and they use the same channel, search may not
be performed correctly.
・
Frequency bands
Frequency band used for wireless LAN function of the
terminal is described on the battery pack recess in the
terminal. Label description are as follows.
a bc
d
2.4DS/OF4
a
2.4 : Radio equipment that uses the 2400 MHz band.
b
DS : The modulation is the DS-SS method.
c
OF : The modulation is the OFDM method.
d
4 : The expected interference distance is 40 m or shorter.
e
2483.5 MHz are used, and the bandwidth used by mobile
object identification devices can be avoided.
Available channels vary by countries. To use WLAN
overseas, check the conditions such as available frequency,
regulation, etc. for the country.
19
e
: All bandwidths between 2400 MHz and
Contents/Precautions
To use in airplane, confirm with airline company in advance.
When docomo mini UIM card is not inserted or when you
are out of service area, channels 12, 13 of 2.4 GHz band and
channels between 120 and 128 of 5 GHz band are not
available regardless of whether you are in Japan or abroad.
Cautions on using 2.4 GHz devices
In the frequency band used by WLAN devices, in addition
to home electric appliances such as a microwave oven
and industrial/scientific/medical devices, in-plant radio
stations for identification of mobile objects used in
production lines of a factory (a license is required),
specified low power radio stations (a license is not
required), or amateur radio stations (a license is required)
can be in operation.
1. Before using this device, confirm that in-plant radio
stations for identification of mobile objects, specified
low power radio stations or amateur radio stations are
not in operation in your neighborhood.
2. If this device generates harmful radio wave
interference against in-plant radio stations for
identification of mobile objects, change the using
frequency promptly or stop using wireless LAN
function, and contact "General Inquiries" on the last
page of this manual, then consult about treatment for
prevention of the interference (for example, installation
of partitions etc.).
3. If this device generates harmful radio wave
interference against in-plant radio stations for
identification of mobile objects or amateur radio
stations, or if any trouble, contact "General Inquiries"
on the last page of this manual.
Cautions on using 5 GHz devices
Using wireless LAN built-into the terminal in 5.2/5.3 GHz
outside is prohibited by the Radio Law.
Channel numbers and frequency bands available in Japan
are as follows.
･
5.2 GHz band : 5,180 to 5,240 MHz (36, 38, 40, 42*, 44, 46,
48 Ch)
･
5.3 GHz band : 5,260 to 5,320 MHz (52, 54, 56, 58*, 60, 62,
64 Ch)
･
5.6 GHz band : 5,500 to 5,700 MHz (100, 102, 104, 106*,
108, 110, 112, 116, 118, 120, 122
134, 136, 140 Ch)
* It is compatible with draft IEEE802.11ac version. The
terminal may not be able to communicate with officialversion-compatible devices or draft-versioncompatible devices from other companies. For
information on compatible merchandise, visit the
following website.
http://www.fmworld.net/product/phone/wifi/ (In
Japanese only)
◆
FeliCa reader/writer
・
FeliCa reader/writer, P2P function of the terminal uses
weak waves requiring no licenses for radio stations.
・
It uses 13.56 MHz frequency band. When using other
reader/writers, P2P function in your surroundings, keep the
terminal away sufficiently from them. Before using the
FeliCa reader/writer, confirm that there are no radio
stations using the same frequency band nearby.
・
To use in airplane, confirm with airline company in advance.
Use is limited in some countries.
Confirm regulations of the country/region to use it.
20
*
, 124, 126, 128, 132,
Contents/Precautions
◆
CAUTION
・
Do not use a remodeled terminal. Using a remodeled
terminal violates the Radio Law/Telecommunications
Business Act.
The terminal is compliant with rules on the technical
standard conformance of specified wireless equipment
based on the Radio Law/Telecommunications Business Act,
and as a proof of it, the "Technical Compliance Mark " is
depicted on the electronic nameplate of the terminal.
If you remodel the terminal by removing its screws, your
certification of technical standard conformance becomes
invalid.
Do not use the terminal with its certification of technical
standard conformance invalid as it violates the Radio Law/
Telecommunications Business Act.
・
Be careful when you use the terminal while driving a car etc.
Using a mobile phone while driving is subject to penal
regulations.
However, absolutely necessary cases such as rescue of a
sick person or maintaining public's safety are exempted.
・
Do not alter the basic software.
Repairs may be refused as a modification of software.
Waterproofness/Dustproofness
F-04F provides waterproofness of IPX5*1, IPX8*2 and
dustproofness of IP5X*3 with firmly closing the external
connection jack and steadily installing the back cover.
*1
IPX5 means that a phone keeps functioning after applying a jet
flow of 12.5 L/min. from every direction from a distance of
approximately 3 m for at least 3 minutes using water nozzle in 6.3
mm inner diameter.
*2
For F-04F, IPX8 means that a phone keeps functioning after F-04F
is slowly submerged to depth of 1.5 m in static tap water at room
temperature, left there for 30 minutes and then taken out. (Camera
function cannot be used under water.)
*3
IP5X means a protection degree that a phone keeps functioning
and safety after it is placed in a device with dust in diameter 75μ
or less for 8 hours, agitated and then taken out.
❖
What you can do with waterproofness of
F-04F
・
You can talk without an umbrella in the rain (for rainfall of
20 mm or less per hour).
- When your hands or the terminal are wet, avoid installing/
removing the back cover or opening/closing the external
connection jack cap.
21
Contents/Precautions
・
The terminal can be washed with tap water at room
temperature.
- With pressing and holding the external connection jack
cap not to open, wash the terminal without rubbing hard.
- Do not apply water flow stronger than allowed (
- Do not use brush, sponge, soap, detergent, etc.
- If mud or soil is adhered to the terminal, eliminate the dirt
first by shaking several times in tap water of wash-basin
and then wash the terminal with running water.
- Drain water in the specified steps (
・
You can use the terminal in a bathroom.
- Do not immerse the terminal into a bathtub. Also, do not
use the terminal in hot water. May cause malfunction. If
you should fall the terminal into the bathtub, immediately
pick it up to drain water in specified procedure (→P24).
- Never put the terminal in hot spring water or water
containing soap, detergent or bath powder. In case the
terminal gets wet with water other than tap water, wash it
in the procedure above.
- You can use the terminal within 2 hours in a bathroom
where the temperature ranges between 5 and 45℃ and
humidity ranges between 45 and 99%.
- Rapid temperature change may cause condensation. If you
bring the terminal from a cold place to warm place such as
a bathroom, wait until the terminal reaches the room
temperature.
- Do not put hot water from a faucet or shower.
→
→
P21).
P24) after washing.
◆
To ensure waterproofness/dustproofness
To avoid water/dust ingress, be sure to observe the
following points.
・
For using the external connection jack, pull the external
connection jack cap with your fingertip by the groove to
open in the direction of arrow (a), or after using, close the
external connection jack cap firmly and press it in the
direction of arrow and then ensure that there are no gaps
between the cap and the terminal (b).
a
Groove
b
・
Attaching the back cover is explained in "■Attaching" in
"Attaching/Removing battery pack".→P29
22
Contents/Precautions
・
Steadily attach the back cover without any space between
and firmly close the external connection jack. Even a fine
obstacle (one hair, one grain of sand, tiny fiber, etc.) put
between contact surfaces may allow water to enter.
・
Do not poke the stereo earphone jack, microphone,
earpiece/speaker, back side microphone, etc. with a sharp
object.
・
Do not let the terminal fall. It may be scratched and cause the
waterproof/dustproof performance to degrade.
・
The external connection jack cap and the rubber gasket of
the rear side of the back cover play important roles for
keeping waterproof/dustproof performance. Do not deform
the back cover by twisting etc. or peel off or damage the
rubber gasket. Also, prevent dust from adhering to them.
To keep the terminal waterproofness/dustproofness,
replacement of parts is required every 2 years regardless
of whether the terminal appears normal or abnormal.
DOCOMO takes the terminal to replace the parts as a
chargeable service. Bring the terminal to a sales outlet
such as a DOCOMO-specified repair office.
◆
Important precautions
Do not perform actions shown in the illustrations below.
<Example>
Using Soap/
Detergent/Bath powder
Applying strong
Observe the following precautions to use the terminal
properly.
・
Accessories and optional devices are not waterproof/
dustproof.
・
Do not apply water flow stronger than allowed (→P21). Even
if the F-04F is waterproof in IPX5 waterproof, water may
enter inside from a damaged section and cause troubles
such as electric shocks or corrosion of the battery.
・
If the terminal gets wet with salt water, sea water, refreshing
beverage, etc. or mud or soil adhered, wash it immediately.
If they dry out, it is hard to remove the dirt and it may cause
damage or malfunction.
・
Do not put the terminal in hot water, use it in a sauna or
apply hot airflow (from a hair dryer etc.) to it.
・
Do not move the terminal in water or slam the terminal
against the surface of water.
・
When you use the terminal in swimming pool, obey rules of
the facility.
water flow
Washing with
brush/sponge
Soaking in
ocean water
23
Machine-washing
hot spring
Contents/Precautions
Using in
・
The terminal does not float on water.
・
Do not leave water on the terminal. May short-circuit the
power jacks, or in a cold region, water may freeze causing
malfunction.
・
Do not leave water on the stereo earphone jack,
microphone, earpiece/speaker, back side microphone. Such
water may interfere with talking.
・
If the back cover is damaged, replace it. Water may enter
inside from a damaged section causing troubles such as
electric shocks or corrosion of the battery.
・
If the terminal gets wet with water or other liquids with the
external connection jack cap or the back cover open, the
liquid may get inside the terminal causing electric shocks or
malfunction. Stop using the terminal, turn the power OFF,
remove the battery pack and contact a DOCOMO-specified
repair office.
・
If the external connection jack cap, or the rubber gasket on
the rear side of the back cover is damaged or deformed,
replace it at DOCOMO-specified repair office.
DOCOMO does not guarantee actual operations under all
states. Malfunctions deemed to be caused by
inappropriate operation by the customer are not covered
by the warranty.
◆
Draining water
When the terminal is wet, water may flow out after wiping it
off. Drain the water in the following steps.
a
Hold the terminal firmly and wipe off moisture on the
terminal surface and back side with dry, clean cloth etc.
b
Shake the terminal approximately 20 times, firmly holding
it, until there is no more water splattering.
24
Contents/Precautions
c
Swing the terminal in about 10 times against a dry, clean
cloth etc. to wipe off water remaining in the stereo
earphone jack, microphone, earpiece/speaker, back side
microphone, keypad, charging terminal, strap hole, etc.
d
Wipe off water drained from the terminal with dry, clean
cloth etc., and dry naturally.
･
Water, if any, remaining in the terminal may ooze up after
wiping off.
･
Do not wipe off water remaining in gaps directly with a
cotton swab etc.
◆
Charging
Check the following during and after charging.
・
Never try to charge the battery when the terminal is wet.
・
When charging the battery after the terminal gets wet,
adequately drain water and wipe off water with a dry, clean
cloth etc. then insert to the included desktop holder or open
the external connection jack cap.
・
When the external connection jack cap is opened for
charging, close the cap firmly after charging. You are
recommended to use the desktop holder for charging to
prevent water from seeping inside from the external
connection jack.
・
Do not use the AC adapter or desktop holder in a bathroom,
shower room, kitchen, lavatory or other highly humid area.
May cause fire or electric shock.
・
Do not touch the AC adapter or desktop holder with wet
hands. May cause electric shock.
25
Contents/Precautions
Before using the terminal
Part names and functions
a
b jc e fd
g h
i
k nlm
ts
o
u
p
v
q
w
r
x
a
Stereo earphone jack (waterproof)
b
Display (Touch panel)
c
In-camera
d
Earpiece/Speaker
e
Proximity sensor/RGB sensor
Proximity sensor prevents erroneous operation of the
touch panel during a call. RGB sensor senses ambient light
and brightness and automatically adjusts the display
backlight.
f
Indicator LED
g
Home key
B
Display Home screen, or touch and hold to display recentlyused applications.
h
Microphone
i
External connection jack
j
k
l
m
n
o
p
q
r
s
t
u
*2
Back cover
Out-camera
Infrared data port
mark
Flash/Light
GPS/Xi antenna section
Fingerprint sensor
Authenticate with fingerprint, cancel the screen lock, or set/
cancel sleep mode.
Bluetooth/Wi-Fi antenna section
Xi/FOMA antenna section
Back side microphone
Use for reducing noise during a call. Do not cover it.
Charging terminal
Volume key
Adjust sound volume, or set/cancel Manner mode by
pressing and holding
UD
*1
*3
*3
*3
D
for 1 second or more.
26
Before using the terminal
v
Power key
P
Power on/off and set/cancel sleep mode. Press and hold P
until the phone options menu appears to restart or set/
cancel Public mode, Airplane mode, Manner mode.
w
Camera key
Press and hold this key with the Home screen displayed to
activate Camera. Or press and hold for 1 second or more to
start/end phone memo recording.
x
Strap hole
*1
*2
*3
C
Putting a protective sheet or sticker on the sensor or covering the
sensor with fingers may cause erroneous operation or incorrect
sensing result. If you cover the proximity sensor, deactivating
Sleep mode by pressing the Home key is not available.
Removing the back cover and the battery pack reveals docomo
mini UIM card slot and the microSD card slot. Rubber gasket is
attached on the rear side of the back cover to resist water.
It is built-in the terminal. Covering around the antenna by the hand
may affect the quality.
docomo mini UIM card
The docomo mini UIM card is an IC card in which user
information such as your phone number etc. is saved.
･
You can use the terminal only with docomo mini UIM card.
If you have a UIM or FOMA card, bring it to a docomo Shop
to replace.
･
If docomo mini UIM card is not inserted to the terminal,
some functions such as making/receiving calls and sending/
receiving SMS are not available.
･
For details on docomo mini UIM card, refer to the docomo
mini UIM card manual.
◆
Installing/Removing docomo mini UIM
card
･
Turn the terminal OFF, remove the back cover and the
battery pack before installing/removing.→P29
27
Before using the terminal
■
Installing
a
Insert the docomo mini UIM card with IC side facing up into
docomo mini UIM card slot
･
Check the orientation of docomo mini UIM card corner
cut.
Corner cut
docomo mini UIM card
■
Removing
a
Put your fingertip on the tab of the tray and pull it straight
out
b
With lightly pressing the docomo mini UIM card, pull it out
in the direction of the arrow
･
Do not press the docomo mini UIM card toward down
strongly.
Tab
IC
Tray
c
Insert the tray straight and horizontally
✔
INFORMATION
･
When handling docomo mini UIM card, take care not to touch
or scratch the IC. Note that inserting or removing docomo
mini UIM card forcibly into or from the terminal may damage
docomo mini UIM card.
･
The tray is structured not to be removed. When pulling the
tray out, stop pulling out at the pullout limit. Do not pull out
with excessive force. Doing so may damage the tray.
28
Before using the terminal
Loading...
