DoCoMo SH-03B User guide

’10.1

DOCOMO

SH-03B
terminal
(includes
warranty and
Back Cover
SH36)

Battery Pack
SH21

Manual SH-03B

CD-ROM

The explanations in this manual are based on the case when

Kisekae tool is set for the handset color “White”.

The screens and illustrations in this manual are shown as

examples. The actual screens and illustrations may differ.

Note that “SH-03B” is referred to as the “FOMA terminal” in this

manual.

Reproduction of this manual in part or in whole is prohibited.
The contents of this manual are subject to change without prior

notice.

W-CDMA and GSM/GPRS System

Thank you for purchasing “docomo PRO series SH-03B”.
Before use of SH-03B, make sure that you read this
manual to ensure proper operation.

Explanation for operation of

SH-03B

Other than this manual, “Support Book” (contained in the
FOMA terminal) or “Manual (detailed edition)” (PDF file)
explains how to operate SH-03B.

 “Manual” (this manual)

Explanation for contents displayed on the screen or
operation of basic function

 “Support Book” (in Japanese only)

(contained in the FOMA terminal)

Explanation for the outline and operation of
frequently-used function

From SH-03B }[Quick search]/[Support
Book]/select a menu or an item

 “Manual (detailed edition)” (in Japanese

only) (PDF file)

Explanation for the detailed information and operation
of all functions

From a PC Download from the DOCOMO website
http://www.nttdocomo.co.jp/support/trouble/manual/
download/index.html

※ The URL and contents are subject to change without

prior notice.

Basic package

Manual

For details on optional parts compatible with the FOMA terminal

nP.95

Introduction

Contents

Introduction

P.1

FOMA Terminal nP.2 What You Can Do with SH-03B nP.3 Part Names and

Functions

n

P.4 Position nP.7 Precautions nP.9 Handling Precautions nP.17

More
Convenient

P.80

Others

P.89

Enjoy

P.68

Search

P.62

Basic
Operation

P.21

Connect

P.50

Support nP.89 Appendix nP.96 Index nP.114

Before Use nP.21 Screen Explanation nP.25 Character Entry nP.34
Sound/Screen Setting nP.39 Lock/Security nP.45

Call nP.50 Mail nP.57 Phonebook nP.61

i-mode/Full Browser nP.62 i-Channel nP.65 Map/GPS nP.66

Camera nP.68 1Seg nP.71 Music nP.74 i-appli/i-Widget nP.78
i-motion/Movie nP.79

Wellness nP.80 Osaifu-Keitai nP.81 i-concier nP.82
Convenient Tools nP.83 Data Management nP.85

1

FOMA Terminal

Because the FOMA terminal relies on radio signals, it

Introduction

cannot be used in places with no signal (such as tunnels,
underground, or in buildings), in places with a weak signal
or outside the FOMA service area. You may not use the
FOMA terminal in the upper floors of a building even with
no obstructions in sight. There may also be times when
the signal is strong and you are not moving but the call is
interrupted.

Make sure not to disturb others when using the FOMA

terminal in public places, places with many people or quiet
places.

Because the FOMA terminal uses electrical signals, it is

possible for a third party to listen in on a conversation.
However, since the W-CDMA and GSM/GPRS system
automatically applies privacy to every call, a third party
that tries to listen in only hears static.

The FOMA terminal converts conversations into a digital

signal and sends it to the other party over the radio. If the
signal cannot be reconverted properly by such as moving
to an area with a weak signal, the voice may not be heard
correctly.

Keep a separate memo and note information (e.g.

phonebook, schedule, text memo, record message, voice
memo) stored in the FOMA terminal. DOCOMO shall not
be liable for any loss of content due to a failure, repair,
upgrade or other handling of the FOMA terminal.

It is recommended to save the important data to the

microSD Card. If you own a PC, you can also transfer and
store the information such as a phonebook, mail and
schedule to your PC using DOCOMO keitai datalink.

The user hereby agrees that the user shall be solely

responsible for the result of the use of SSL/TLS. Neither
DOCOMO nor the certifier as listed herein makes any
representation and warranty as for the security in the use
of SSL/TLS. In the event that the user shall sustain
damage or loss due to the use of SSL/TLS, neither
DOCOMO nor the certifier shall be liable for any such
damage or loss.

Certifier: VeriSign Japan K.K.,

Cybertrust Japan Co.,Ltd.,
GlobalSign K.K.,
RSA Security Japan Ltd.,
SECOM Trust Systems Co., Ltd.,
Comodo CA Ltd, Entrust, Inc.

The FOMA terminal supports the FOMA Plus-Area and

the FOMA HIGH-SPEED area.

The FOMA terminal can be used only via the FOMA

network provided by DOCOMO and DOCOMO’s roaming
area.

2

What You Can Do with SH-03B

Support book (in Japanese only)

Support book is a convenient function which allows you
to check an operation method of function on the FOMA
terminal. You can search immediately without a manual.

}[Quick search]/[Support Book]/select a menu

or an item

i-concier (in Japanese only) nP.82

i-concier is a service that a character in the stand-by
display (Machi-chara) notifies you of useful information
and that can be used conveniently by downloading a
schedule (i-schedule) from sites.

International roaming nP.55

The same FOMA terminal, phone number and mail
address as those used in Japan are available overseas
(supporting 3G and GSM areas).

Touch panel nP.27

You can operate by putting your finger on the touch panel
(screen).

Multifunctional camera nP.68

The FOMA terminal has built-in multifunctional camera
offering approximately 5.3 million effective pixels.

Wellness nP.80

Supports daily walking using the pedometer. You can
display the number of steps, burned calories, etc. in the
stand-by display.

AUTO-GPS (in Japanese only) nP.67

By the AUTO-GPS function, you can receive convenient
services, such as providing surrounding information
including weather information, store information, etc., or
sight-seeing information.

Full keyboard nP.6

You can enter numbers or characters in the Romaji
method using a keyboard of the FOMA terminal.

Introduction

3

Part Names and Functions

2

41

5

6

7

2

3

2

2

d

e

8

c

b98

a

Introduction

1 Keyboard (nP.6, P.36)
2 Called/Charging LED

Illuminates/Flashes while receiving a call/charging/

activating the camera/shooting.

3 Earpiece
4 Brightness sensor

Sensor detects brightness of the surrounding area. Do

not cover the sensor area with your hand or a sticker.

5 Display/Touch panel (nP.25, P.27)
6 H: Power/End key (nP.23)

Use to end the function being activated and return to

stand-by display.

7 s: Start/Hands-free key (nP.50)
8 Speaker
9 1Seg antenna

Use to receive 1Seg.

a Camera

Use to shoot still pictures or moving pictures.

b Infrared port (nP.88)
c b mark (nP.81, P.88)
d Back cover (nP.21)
e Picture Light

Illuminates while shooting.

4

i

h

f

g

k

j

l

Using earphone

When you use an earphone which does not support
external connector terminal, connect with a plug adapter
(sold separately).

Connection example for flat-plug earphone/
microphone with switch (sold separately)

Connector

Flat-plug connector of
flat-plug earphone/
microphone with switch
(sold separately)

Flat-plug earphone
terminal

f &: Side/Camera key (nP.48)

Use to return to the previous screen or delete entered

numbers or characters.

Use to shoot still pictures or moving pictures.

g Charger terminal

Use for charging with the desktop holder.

h FOMA antenna

FOMA antenna is built in.

i Mouthpiece/Microphone
j Strap hole
k External connector terminal

Use for charging and connecting the earphone, etc.

l microSD Card slot (nP.86)

Introduction

5

Keyboard

12

3

45

5

4

67

x + 1x + 2x + 3x + 4

For details on operation when entering characters nP.36

Introduction

1 1 to 9, 0: Numeric keys

Enter a phone number or number.

2 c: Clear key

Return to the previous screen.
Delete entered characters or phone numbers.

3 w&t&: Multi-guide key

Move the cursor to select an item and execute or set.

4 z: Shift key

Press z and press another key with [ ] displayed in

the upper part of the screen to operate.

Combined operation is described as “z + key” in this

manual.

5 x: Function key

Press x and press another key with [ ] displayed in

the upper part of the screen to operate.

Combined operation is described as “x + key” in this

manual.

6

Press x + 1 to x + 4 to execute functions of the

operation guidance.

Press x + 6 to activate Quick search.
Press x + 7 to use Multi Assistant.
Press x + 8 to set/disable VeilView.
Press x + c to end the function being activated and

return to stand-by display.

6 #: D key

Press x + # to enter “#”.

7 *: S key

Pre

ss x +

* to enter “b”.

Operation guidance

In the open position, the operation guidance appears in the
lower part of the screen. Press an assigned key to select/
execute a menu of the operation guidance. If the operation
guidance does not appear, press x + 5 to display.

Close position/Open position

Close position

Open position

Rotate 90° left

Rotate 90° right

Longways

Sideways

To open the FOMA terminal, hold the FOMA terminal with
both hands and push its display side up in the direction
of the arrow.

When making a videophone call in the open position, use the
earphone/microphone (sold separately) or use hands-free.

Opening the FOMA terminal to display compose
message screen/bookmark list screen

You can display the compose message screen and bookmark
list screen just by setting the handset to the open position in
the stand-by display.

1

][Settings]/[Disp/LED/Power

saver]/[Stand-by settings]/[Stdby slide
link]

Position

Select the setting

2

Switching vertical/horizontal
view

The display is automatically switched between the
vertical view and the horizontal view just by tilting the
FOMA terminal as shown. You can use the FOMA
terminal with closed and turned longways or sideways. In
the open position, the screen is displayed in the
horizontal view regardless of direction of the FOMA
terminal.

Vertical/Horizontal view is not switched if the FOMA

terminal is turned in the place parallel to the ground.

You can set the display not to automatically switch

(nP.8).

Screens or keys which can be displayed differ depending

on the function or position.

Introduction

7

Introduction

Horizontal view

Vertical view

4

1

3 2

15

2

6

4 3

1

6

3

1 1

7

5

41 32

2

1 Operation guidance

Select/Execute a menu of the operation guidance.

2 HOLD switch view key

Set the FOMA terminal not to temporarily switch

vertical/horizontal view when you tilt the FOMA
terminal.

When Auto Switch vertical/horizontal is set to [OFF],

switch view key appears. Vertical/Horizontal view is
switched.

3 CLR key

Return to the previous screen or delete entered

numbers or characters. Touch for a while to end the
function being activated and return to stand-by display.

4 MULTI key

Touch to use Multi Assistant.

5 Multi-guide key

Move the cursor to select an item and execute or set.

6 Button switch key

Display/Hide the dial/character entry keys.

7 Dial/Character entry keys

Enter numbers or characters.

Setting whether to automatically switch
vertical/horizontal view

Set whether to automatically switch the vertical/horizontal
view according to the direction of the FOMA terminal in the
close position.

][Settings]/[Disp/LED/Power

1

saver]/[Stand-by settings]/[Auto SW
vert/horiz]

Select the setting

2

8

Precautions

Before use, read these “Precautions” carefully and use your FOMA

terminal properly.
Keep this manual in a safe place for future reference.

These precautions contain information intended to prevent bodily

injury to the user and to surrounding people, as well as damage to
property, and must be observed at all times.

The following symbols indicate the different degrees of injury or
damage that may occur if information provided is not observed
and the FOMA terminal is used improperly.

This symbol indicates that “death or

Danger

Warning

Caution

serious bodily injury may directly and
immediately result from improper
use”.

This symbol indicates that “death or
serious bodily injury may result from
improper use”.

This symbol indicates that “bodily
injury and/or property damage may
result from improper use”.

The following symbols indicate specific directions.

Indicates a prohibited action.

Indicates not to disassemble the device.

Indicates not to handle the device with wet hands.

Indicates not to use the device near water or get it wet.

Indicates that instructions specified are
compulsory (must be followed).

Indicates that the power cord must be unplugged from
the outlet.

“Precautions” is explained in the following six sections.

Handling the FOMA terminal, battery pack, adapters, and FOMA

card (general) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P.10

Handling the FOMA terminal . . . . . . . . . . . . . . . . . . . . . . . . . . P.11

Handling battery pack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P.14

Handling adapters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P.15

Handling FOMA card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P.16

Handling mobile phones near electronic medical equipment

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P.16

Introduction

9

Handling the FOMA terminal,

Danger

Warning

battery pack, adapters, and
FOMA card (general)

Introduction

Do not use, store, or leave the
FOMA terminal, battery pack,
adapters or FOMA card in locations
subject to high temperatures, such
as near a fire, in direct sunlight, or

The FOMA terminal may become deformed or
malfunction. In addition, the battery pack may
leak, overheat, explode, catch fire or suffer
performance loss and a reduced service life.
Part of the casing may also become hot and
cause burns.

May cause accidents such as fire, bodily
injury, electric shock or malfunction.
In addition, the battery pack may leak,
overheat, explode or catch fire.

Contact with water, pet urine, and other
liquids may cause overheating, electric shock,
fire, malfunction or bodily injury. Be attentive
to where and how you use the handset.

10

inside a car on a hot day.

Do not attempt to disassemble
or modify. In addition, do not
attempt to solder.

Do not get the FOMA terminal,
battery pack, adapters or FOMA
card wet.

Use only the battery packs and
adapters specified by NTT
DOCOMO for use with the
FOMA terminal.

The use of devices other than those specified
may cause the FOMA terminal, battery pack
or other devices to leak, overheat, explode,
catch fire or malfunction.

Do not place the battery pack,
FOMA terminal, adapters, or
FOMA card inside cooking
appliances such as microwave
ovens or pressure cookers.

The battery pack may leak, overheat,
explode or catch fire, and the FOMA terminal
and adapters may overheat, emit smoke or
catch fire. The internal circuitry may also be
damaged.

Do not subject the FOMA
terminal to strong impacts or
throw it.

The battery pack may leak, overheat,
explode or catch fire. Other devices may also
be damaged or cause a fire.

Do not allow conductive materials
(such as metal objects and pencil
lead) to come into contact with
the charger terminal or external
device terminal. In addition, do
not insert such objects.

The battery pack may short-circuit and cause
a fire or malfunction.

Make sure to turn off the mobile
phone in locations such as gas
stations where flammable gas
is generated.
In addition, do not charge the
battery. It may cause a gas
explosion or fire.

To use Osaifu-Keitai in locations such as gas
stations, make sure to turn off the power in
advance (If the IC card lock is set, disable the
lock before turning off the power).

If you notice anything unusual,
such as an unusual odor,
overheating, discoloration or
deformation during use,
charging or storage, immediately
follow the instructions below.

1. Unplug the power cord from
the outlet or cigarette lighter
socket.

2. Turn off the FOMA terminal.

3. Remove the battery pack
from the FOMA terminal.

Continued use may cause overheating,
explosion, or fire. In addition, the battery pack
may leak.

Do not leave the FOMA terminal

Caution

Warning

Picture Light

on unstable surfaces, such as
on a wobbling table or sloped
surface.

The FOMA terminal may fall and cause injury
or be damaged.

Do not store the FOMA terminal
in locations that are subject to
humidity, dust or high
temperatures.

May cause a malfunction.

If being used by a child, have a
guardian teach him/her the
proper handling procedures. In
addition, check that the child is
using the FOMA terminal as
directed.

May result in bodily injury.

Keep the FOMA terminal out of
the reach of young children.

A young child may swallow components or
suffer other bodily injury.

Be very careful when using the
FOMA terminal connected to
adapters repeatedly or for long
periods of time.

The FOMA terminal, battery pack or adapters
may become warm if i-appli, videophone, or
1Seg is used for a long time while charging.
Touch high temperature areas for a
prolonged period of time may cause skin
irritations, itchiness, or low-temperature burn
in some people.

Handling the FOMA
terminal

Do not aim the infrared port
towards the eyes.

May cause eye injury. In addition, do not aim
or direct the infrared port towards another Ir
device as this may cause the device to
malfunction.

Do not point the illuminated
light directly at someone’s

Do not use Picture Light near people’s faces.
Eyesight may be temporarily affected leading
to accidents.
Precautions:
The picture light source used for this product
may emit the light over the safety level for
eyes when operations such as undirected
adjustments are intentionally made.
Therefore, do not disassemble the terminal.

CAUTION:

Use of controls, adjustments or performance
of procedure other than those specified
herein may result in hazardous radiation
exposure. As the emission level from Picture
Light LED used in this product is harmful to
the eyes, do not attempt to disassemble the
cabinet. Servicing is limited to qualified
servicing station only.

eyes.

EN60825-1:1994 A1:2002 & A2:2001

CLASS1
LED Product

Introduction

11

Do not put the FOMA terminal
in the place where it could be
affected by an expanded airbag,

Introduction

If the air bag inflates, the FOMA terminal may
hit you or others around you, resulting in
bodily injury or damage to the FOMA terminal
or other property.

Using the FOMA terminal in close proximity
to electronic medical equipment may cause
the equipment to malfunction.

May cause a fire, electric shock or other
malfunctions.

This may prevent a driver from driving safely
and cause a traffic accident.

e.g., on the dashboard.

If you are using electronic
medical equipment, do not put
the FOMA terminal in your
breast pocket or in the inside
pocket of your jacket.

Do not allow water or other
liquids, metal, flammable
material, or other foreign
objects to enter the FOMA card
or microSD Card port on the
FOMA terminal.

Do not shine the light at anyone
driving a car or other vehicles.

12

Turn off the FOMA terminal in
areas where the use of mobile
phones is prohibited, such as
in aircraft or hospitals.

The FOMA terminal may interfere with the
operation of electronic devices and electronic
medical equipment. In addition, if auto power
on function is set to on, disable this function
before turning off your mobile phone.
Follow the instructions given by the
respective medical facilities regarding the
use of mobile phones on their premises.
In addition, actions such as using on a mobile
phone aboard aircraft are prohibited and may
be punishable by law.

During a call in which hands-free
is set, keep the FOMA terminal
away from the ears.
When you attach the earphone/
microphone to the FOMA
terminal to play games or
music, do not make the volume
too loud.

Excessive high volume may damage your
hearing.
Also it may prevent you from hearing the
ambient sounds and cause an accident.

If you have a weak heart, take
extra precautions when setting
functions such as the vibrator
and ring tone volume for
incoming calls.

Various settings may have effects on your
heart.

If you hear thunder while using
the FOMA terminal outdoors, put
the antenna back into the FOMA
terminal and immediately turn it
off and move to a safe location.

There is a risk of being struck by lightning
and suffering electric shock.

Turn the FOMA terminal off
near high-precision electronic
devices or devices that use
weak electronic signals.

The FOMA terminal may interfere with the
operation of electronic devices.

Take particular care with the following devices

Hearing aids, implanted cardiac pacemakers,
implanted cardioverter-defibrillators, or other
electronic medical equipment. Fire alarms,
automatic doors, and other equipment controlled by
electronic signals. If you use an implanted cardiac
pacemaker, implanted cardioverter-defibrillator or
other electronic medical equipment, contact the
respective manufacturer or vendor to check whether
the operation of the equipment is affected by signals.

In case that the display part or
camera lens is damaged, make
sure to pay attention to a
broken glass and the exposed
inside of the FOMA terminal.

The surface of the display is covered by a
protective film or the surface of camera lens
are covered by a plastic panel so as to
minimize the possibility of glass scattering.
However, touching the broken or exposed
parts may cause injury.

Do not swing the FOMA

Caution

terminal by its antenna, strap,

The FOMA terminal may hit you or others
around you, resulting in bodily injury or damage
to the FOMA terminal or other property.

The antenna may hit others, resulting in an
accident such as bodily injury.

Touching the antenna may cause an
accident such as burn or other injuries.

Use motion tracking to operate by tilting and
shaking (or swinging) the FOMA terminal.
The FOMA terminal may hit people or
objects, if shaken (or swung) too much, and
cause a serious accident or damage, etc.

May result in bodily injury or damage to the
FOMA terminal or other property.

etc.

Do not use the FOMA terminal
in area with many people.

Do not use the FOMA terminal
with the damaged antenna.

When using motion tracking,
confirm the safety of
surroundings, hold the FOMA
terminal securely and do not swing
it around more than necessary.

If using motion tracking with the
FOMA terminal to which metallic
straps or others are attached, be
careful not to hit people or
objects with the straps.

If the display is broken and the
liquid crystal then leaks, do not
lick or inhale the liquid or get
the liquid on your skin.
If the liquid comes into contact
with your eyes or mouth,
immediately rinse your eyes or
mouth with clean water and see
a doctor.
If the liquid comes into contact with
your skin or clothes, immediately
wipe it off with alcohol, and wash

May result in loss of eyesight and harm to
your skin.

This may cause hearing loss.

Using the FOMA terminal with the film
removed may cause a bodily injury when the
display is damaged.

In such cases, stop using the FOMA terminal,
as this could impede safe driving.

with water and soap.

While the ring tone is ringing or
a melody is played on the
FOMA terminal, do not put the
ears closer to the speaker.

On the surface of the display,
there is a protective film for
securing the safety (for
preventing the reinforced glass
panel from shattering) in case of
the damage caused by a drop,
impact, etc. Do not forcibly peel
off or scratch this film.

Using the FOMA terminal in an
automobile may sometimes
affect the electronic equipment
in some vehicle models.

Use of the FOMA terminal may
cause skin irritations such as
itchiness, rashes or eczema in
some people. If this occurs,
immediately stop using the
FOMA terminal and seek

The following parts contain metals.

Surface of FOMA
terminal (back of
display side)

Surface of FOMA
terminal (slide hinge
section on the back
of display side)

Metal section of
1Seg antenna

External connector
terminal

Card slot

Charger terminal

Connector terminal
with battery pack

May result in bodily injury or cause a
malfunction.

medical treatment.

Part Material

Magnesium

SUS

Brass

SUSInside microSD

Brass

Do not close the FOMA terminal
on your fingers or objects such
as the strap.

Introduction

Surface

treatment

Coating

Nickel
plating

Gold
plating

13

Watch 1Seg in a well-lit place,

Danger

Warning

Caution

keeping a certain distance from

Otherwise, eyesight may be decreased.

the screen.

Introduction

Handling battery pack

Check the type of battery using the
information printed on the battery pack
label.

Label Battery type

Li-ion00 Lithium-ion

Do not touch terminals with
metallic objects such as wires.
In addition, do not carry or
store the battery pack with

The battery pack may leak, overheat,
explode or catch fire.

The battery pack may leak, overheat,
explode or catch fire.

14

metallic necklaces, etc.

If you are having difficulty
fitting the battery pack to the
FOMA terminal, do not use
excessive pressure to force the
battery into place. Check that
the battery pack is facing the
correct direction before you
attach it.

Do not throw the battery pack
into a fire.

The battery pack may leak, overheat,
explode or catch fire.

Do not puncture, hit with a
hammer or step on the battery
pack.

The battery pack may leak, overheat,
explode or catch fire.

If the battery fluid comes into
contact with your eyes, do not
rub your eyes but immediately
rinse your eyes with clean
water. Then seek prompt
medical treatment.

May result in loss of eyesight.

If any trouble is found on the
battery pack due to an external
impact such as a deformation
or scratches caused by a drop,
immediately stop using it.

The battery pack may leak, overheat,
explode or catch fire. Other equipment may
also be damaged or catch fire.

If the battery pack is not fully
charged after the specified time
has elapsed, stop charging.

The battery pack may leak, overheat,
explode or catch fire.

If the battery pack leaks or
emits an unusual odor,
immediately stop use and move
it away from any flame or fire.

The battery fluid is flammable and could
ignite, causing a fire or explosion.

Prevent your pet from biting the
battery pack.

The battery pack may leak, overheat,
explode or catch fire. Other equipment may
also be damaged or catch fire.

Do not dispose of used battery
packs in ordinary garbage.

May cause fires or damage to the
environment. Place tape over the terminals to
insulate unnecessary battery packs, and take
them to a docomo Shop, retailer or institution
that handles used batteries in your area.

Do not charge a wet battery
pack.

The battery pack may overheat, catch fire or
explode.

If the battery fluid comes into

Warning

contact with your skin or
clothing, stop using the FOMA
terminal immediately and rinse
it off thoroughly with clean
water.

May cause injuries to your skin.

Handling adapters

Do not use if the adapter’s cord
or power cord is damaged.

May cause electric shock, overheating or fire.

Never use the AC adapter or
desktop holder in humid
locations such as a bathroom.

May result in electric shock.

The DC adapter should only be
used in negative grounded
vehicles. Never use this adapter
in positive grounded vehicles.

May cause a fire.

Do not touch the FOMA
terminal or adapters if you hear
thunder.

There is a risk of being struck by lightning
and suffering electric shock.

Take care not to short-circuit
the charging terminal when
connected to an outlet or
cigarette lighter socket. Also,
take care not to allow any part
of your body (hands, fingers,
etc.) to come into contact with
the charging terminal.

May result in a fire, malfunction, electric
shock or bodily injury.

Place the adapter and desktop
holder on stable surfaces when
charging. In addition, do not
cover or wrap the adapter or
desktop holder with clothing or
bedding.

The FOMA terminal may detach, overheat, or
cause a fire or malfunction.

Do not place heavy objects on
the adapter’s cord or power
cord.

May cause an electric shock or fire.

Do not handle the cord and
plug of the adapters with wet
hands.

May result in electric shock.

Always use the specified power
supply and voltage.

Using the incorrect voltage may cause a fire
or malfunction.
When using overseas, use the AC adapter
that is available overseas.
AC adapter: 100V AC
DC adapter: 12/24V DC (for negative
grounded vehicles only)
AC adapter available overseas: 100 to 240V
AC (Connect only with household AC outlet)

If the fuse in the DC adapter
blows, always replace it with a
fuse of the specified type.

Using the fuse other than the specified one
may cause a fire or malfunction. Refer to the
respective manuals for information on the
correct fuse specifications.

Wipe off any dust on the power
plug.

May cause a fire.

When plugging the AC adapter
into the outlet, make sure that
no metallic straps or other
metallic objects are caught
between the plug and the
socket.

May cause electric shock, short-circuiting or
fire.

Introduction

15

Always grasp the power plug

Caution

Warning

when unplugging the adapters
from the outlet or cigarette

Introduction

Pulling on the cord may damage the cord and
cause an electric shock or fire.

May cause an electric shock, fire, or malfunction.

May cause an electric shock, smoke
emission or fire.

May result in electric shock.

lighter socket. Do not forcibly
pull by the adapter’s cord or
power cord.

Unplug the power plug from the
outlet when not using for a long
time.

Should water or other liquids enter
the adapters, remove the power
plug from the outlet or cigarette
lighter socket immediately.

Always unplug the power plug
from the outlet or cigarette
lighter socket before cleaning
the adapters.

Handling FOMA card

Be careful with the cutting
surface when detaching the

May cause injuries to your hands or fingers.

16

FOMA card (IC).

Handling mobile phones
near electronic medical
equipment

The precautions detailed here conform to
the guidelines drawn up by the
Electromagnetic Compatibility
Conference Japan, regarding the
protection of electronic medical
equipment from signals emitted by mobile
phones.

Observe the following in
hospitals or other medical
facilities.

Do not take your FOMA terminal into

operating rooms, ICUs (Intensive Care
Units) or CCUs (Coronary Care Units).

Turn off your FOMA terminal inside

hospital wards.

Turn off your FOMA terminal even when

you are in an area outside hospital wards,
such as a hospital lobby, since electronic
medical equipment may be in use nearby.

Where a medical facility has specific

instructions prohibiting the carrying and
use of mobile phones, observe those
instructions strictly.

If auto power on function is set to on,

disable this function before turning off your
mobile phone.

Turn off your FOMA terminal in
crowded places such as
rush-hour trains in case
somebody nearby is using an
implanted cardiac pacemaker
or implanted
cardioverter-defibrillator.

Electromagnetic signals may affect the
operation of implanted cardiac pacemakers
and implanted cardioverter-defibrillators.

If you have an implanted
cardiac pacemaker or an
implanted
cardioverter-defibrillator,
always carry or use your FOMA
terminal at least 22 cm away
from your implant.

Electromagnetic signals may affect the
operation of implanted cardiac pacemakers
and implanted cardioverter-defibrillators.

Patients receiving medical
treatment away from a hospital
or medical facility (e.g. home
treatment) who are using
electronic medical equipment
other than implanted cardiac
pacemakers or implanted
cardioverter-defibrillators
should consult the respective
manufacturers for information
regarding the effects of signals
on the equipment.

Electromagnetic signals may affect the
operation of electronic medical equipment.

Handling Precautions

General notes

Do not expose to water.

The FOMA terminal, battery pack, adapter
and FOMA card are not waterproof. Do not
use in humid or steamy areas such as
bathrooms and avoid exposing to rain and
other forms of moisture. If the FOMA
terminal is carried close to skin,
perspiration may cause internal
components to corrode and result in
malfunction. Note that if problem is found
to be due to moisture, handset and parts
are not covered by warranty and in some
cases may be irreparable. Even where
repairs are possible, repair charges will be
incurred since damage is not covered by
warranty.

Clean only with a soft and dry cloth

(such as the type used for eyeglasses).

The surface of the handset’s LCD has a
special coating to improve the visibility of
the color display. Forceful rubbing of LCD
with a dry cloth may scratch LCD surface.
Handle the handset carefully and clean
with a soft and dry cloth (such as the type
used for eyeglasses). Note also that LCD
coating may peel off or stain if moisture or
soiling is left on the surface for a long
period.
Never use chemicals such as alcohol,
thinners, benzene or detergents, as these
agents may erase the printing on the
handset or cause discoloration.

Occasionally clean terminals with a dry

cotton swab, etc.

Unclean terminals may result in poor
connections and loss of power. Keep
terminal clean with a dry cotton swab, etc.
Take care of the terminal while cleaning it.

Do not place the handset near an air

conditioning vent.

Condensation formed due to rapid
changes in temperature may cause
internal corrosion and lead to malfunction.

Do not apply excessive force to the

FOMA terminal and battery pack when
using them.

Carrying the handset in a tightly packed
bag, or sitting on the handset in your
pocket may cause a damage to display,
other internal components or battery pack,
or result in malfunction. Keeping an
external connector device plugged into the
external connector terminal (earphone/
microphone terminal) may cause a
damage to the connector or result in
malfunction.

Read the respective manuals supplied

with the FOMA terminal, adapters, and
desktop holder carefully.

Do not rub or scratch the display with

metal, etc.

May scratch the handset and cause
malfunction or damage.

Notes about the FOMA
terminal

Do not forcefully press a surface of the

touch panel, or operate with a pointed
object such as a fingernail, ballpoint
pen, pin, etc.

May damage the touch panel.

Introduction

17

Avoid using the handset in extremely

high or low temperatures.

Use the FOMA terminal within the range of
a temperature between 5°C and 35°C and

Introduction

a humidity between 45% and 85%.

Using the handset close to landline

phones, TVs or radios may affect the
operation of such equipment. Move as
far away as possible from such items
before use.

Keep a separate memo and note

information stored in the FOMA
terminal.

DOCOMO shall not be liable for any loss
of content.

Do not drop or otherwise subject the

FOMA terminal to severe impact.

May damage the handset and cause
malfunction.

When connecting an external

connector device to the external
connector terminal (earphone/
microphone terminal), do not put it in
obliquely or do not pull it while it is
plugged in.

May damage the handset and cause
malfunction.

Do not close the FOMA terminal on

strap, etc.

May damage the handset and cause
malfunction.

The FOMA terminal becomes warm

during using or charging but this is not
a malfunction.

Do not leave the camera in direct

sunlight.

May cause discoloration or burn-in.

Use the FOMA terminal with the

external connector terminal cover and
microSD Card slot cover on.

Dust, water and others enter inside and
cause a malfunction.

Do not use the FOMA terminal without

the back cover.

May detach the battery pack or cause
malfunction or damage.

Do not paste a label or sticker on the

back of the FOMA terminal display.

The FOMA terminal is caught by the label
or sticker when opened or closed, and it
may cause malfunction or damage.

While using a microSD Card, do not

remove the card or turn off the FOMA
terminal.

May cause data loss or malfunction.

Never place a magnetic card near or in

the FOMA terminal.

The stored magnetic data in cash cards,
credit cards, telephone cards, floppy disks,
etc. may be erased.

Never place magnetized items near the

FOMA terminal.

Putting highly magnetized items closer
may cause a malfunction.

Notes about battery pack

Battery pack is a consumable product.

Though usage time varies with use,
change battery if battery level is extremely
low even after fully charged. Purchase a
specified new battery pack.

Charge battery in areas where ambient

temperature is between 5°C and 35°C.

Always charge the battery before the

first use or after not using battery for a
long time.

The usage time for a battery pack

depends on the usage and
deterioration of battery pack.

Depending on usage, the battery pack

may swell as it approaches the end of
its service life but this will not cause
problems.

Note the followings when the battery

pack is stored for a long term.

 The storage with the battery pack fully

charged (immediately after charging is
completed)

 The storage with no battery level

(cannot turn the FOMA terminal on)
May lower the performance or shorten the
life of the battery pack. The second or third
level of the battery pack icon is
recommended as the battery level for
long-term storage.

18

Notes about adapters

Charge battery in areas where ambient

temperature is between 5°C and 35°C.

Do not charge battery pack in the

following locations.

 Areas with high humidity or dust, or in

areas exposed to strong vibrations

 Close to landline phones, TVs, radios,

etc.

Adapters may become warm during

charging but this is not a malfunction.

Do not use DC adapter to charge

battery when the car engine is not
running.

May cause car battery to run down.

When using an outlet with a feature to

prevent the plug from being removed
accidentally, follow instructions in the
outlet user’s guide.

Do not subject to strong force or

impacts. Also, do not disfigure the
charger terminals.

May cause a malfunction.

When folding the stand of the desktop

holder, prevent the cord for the
adapters and your fingers from being
caught.

May result in bodily injury or damage.

Notes about FOMA card

Do not apply unnecessary force when

inserting/removing the FOMA card.

FOMA card may become warm during

using but this is not a malfunction.

Customer is responsible for

malfunctions arising from inserting
FOMA card into a different IC card
reader/writer.

Always keep IC area clean.
Clean only with a soft and dry cloth

(such as the type used for eyeglasses).

Keep a separate memo and note

information stored in the FOMA card.

DOCOMO shall not be liable for any loss
of content.

To protect the environment, please take

any unnecessary FOMA cards to a
docomo Shop or retailer.

Avoid using in extremely high or low

temperatures.

Do not damage, touch haphazardly or

short-circuit the IC.

May cause data loss or malfunction.

Do not drop or otherwise subject the

FOMA card to severe impact.

May cause a malfunction.

Never bend the FOMA card or place

heavy objects on it.

May cause a malfunction.

Do not insert the FOMA card to the

FOMA terminal with a label or sticker
attached on the card.

May cause a malfunction.

Notes on using

®

Bluetooth

The FOMA terminal supports the

security function that meets the
Bluetooth specification for the security
during communication using Bluetooth
function. However, the security may
not be sufficient depending on the
configuration. Take care of the security
while making communication using
Bluetooth function.

Even if any leak of data or information

occurs while making communication
using Bluetooth function, DOCOMO
shall not be liable for any loss of
content.

With the FOMA terminal, use headset,

hands-free, audio, keyboard, dial-up
communication, object push and serial
port. Also, the audio/video
remote-control may be available
depending on the audio (only with
compatible Bluetooth devices).

Radio frequencies

The radio frequencies the Bluetooth
function of the FOMA terminal uses are
as follows.

function

Introduction

19

This wireless device uses 2.4 GHz band.
The modulation system is the FH-SS
system and a coverage distance is 10 m or
less. All radio frequencies are used and

Introduction

the frequencies for mobile object
identifiers shall not be avoided.

Cautions on using Bluetooth devices

Bluetooth operates at radio
frequencies assigned to the in-house
radio stations for a mobile object
identifier that have to be licensed and
is used in production lines of a
factory, specific unlicensed low power
radio stations, and amateur radio
stations (hereafter, referred to
“another radio station”) in addition to
industrial, scientific, medical devices,
or home electric appliances such as
microwave ovens.

1. Before using this product, make
sure that “another radio station” is
not operating nearby.

2. If radio interference between this
product and “another radio station”
occurs, avoid interference by
moving immediately to another
place or “turning off the power”.

3. Contact the number listed in
“General Inquiries” on the back of
this manual for further details.

FeliCa reader/writer

The FeliCa reader/writer function in the

FOMA terminal uses weak electric
waves in the handling of which does
not require a license of radio station.

The frequency in use is the 13.56 MHz

band. When another reader/writer is
being used nearby, keep enough
distance from it. Make sure that there is
no radio station using the same
frequency band in the nearby area.

Caution

Never use the FOMA terminal that is

modified. Using a modified device
violates the Radio Law.

The FOMA terminal has acquired the
certification of conformity with technical
regulations for the specified radio station
based on the Radio Law, and the
“Technical Conformity Mark ” is printed
on the model nameplate of the FOMA
terminal as a proof. If the screws of FOMA
terminal are removed and a modification is
given to the inside, the certification of
conformity with technical regulations will
become invalid. Never use the FOMA
terminal without the valid certification.
Doing so violates the Radio Law.

Be careful when using the FOMA

terminal while driving a motor vehicle.

While driving, using a mobile phone in
hand is regarded as a punishable act. If
there is no choice but to receive a call, use
hands-free and tell the caller that you will
“call back” and then pull over to a safe
place to make a call.

Use the Bluetooth function only in

Japan.

The Bluetooth function in the FOMA
terminal conforms to the domestic radio
wave standards and is authorized. Using
the function overseas may result in
punishment.

Use the FeliCa reader/writer function

only in Japan.

The FeliCa reader/writer function in the
FOMA terminal conforms to the domestic
radio wave standards. Using the function
overseas may result in punishment.

20

Before Use

Basic Operation

1

2

3

IC (gold)

Notch

123

Tray

Notch

Tabs

Inserting FOMA card and
battery pack

A FOMA card is an IC card that records personal

information, such as phone numbers, etc.

The FOMA terminal does not support the FOMA card

(blue). Change the FOMA card (blue) at a docomo Shop.

Push the back cover in

1

the direction of the
arrow (1), slide
approximately 3 mm
(2) and remove the
back cover (3)

Pull out the tray straight (1).

2

Set the FOMA card on the tray
with the IC (gold) side turned
down (2) and push the tray all
the way in (3)

Turn a recycle mark

3

side up, match tabs
and attach the battery
pack

Place the back cover

4

to the FOMA terminal
slot with the back
cover open
approximately 3 mm,
push it (1) and slide it
to the direction of arrow to insert (2)

Turn off the power and insert the FOMA card/battery

pack while holding the FOMA terminal with your both
hands. Note that excessive force may damage the FOMA
terminal, FOMA card and battery pack.

Securely close the back cover. If not closed securely, the

back cover may come off and the battery pack may fall
out due to vibration.

Basic Operation

21

Charging

External
connector
terminal

External connector terminal cover

Connector (Turn the side with the arrows up)

Charging LED

Release buttons

1

2

1

Charging by using AC adapter

Read the user’s guide of FOMA AC Adapter 01/02 (sold

separately).

Open the external connector terminal

1

Basic Operation

22

cover and insert the AC adapter connector
horizontally into the external connector
terminal

Insert the AC adapter power plug into an

2

outlet

Charge start sound is heard, charging LED

illuminates, and charging starts.

Hold the release buttons (1) and

3

horizontally remove the connector (2)
when charging is complete

Charge end sound is heard and charging LED turns

off when charging is complete.

Note that excessive force may damage the FOMA

terminal and AC adapter.

Charging by using desktop holder

1

Charging LED

Connector
(Turn the side
with the
arrows up)

FOMA AC
Adapter 01/02

2

Read the user’s guide of Desktop Holder SH30 (sold

separately).

Use in the close position.

Insert the AC adapter connector into the

1

connector terminal of the desktop holder

Insert the AC adapter power plug into an

2

outlet

Place the FOMA terminal in the desktop

3

holder in the direction of the arrow until it
clicks (1)

Charge start sound is heard, charging LED

illuminates, and charging starts.

Hold the desktop holder and lift the FOMA

4

terminal out in the direction of the arrow
when charging is complete (2)

Charge end sound is heard and charging LED turns

off when charging is complete.

Pull the AC adapter out of the outlet when left unused for

a long period of time.

When charge start sound is not heard or when charging

LED does not illuminate, check that the FOMA terminal is
placed securely in the desktop holder (except when
terminal is turned off, manner mode is set or charge start
sound is silent).

When placing the FOMA terminal in the desktop holder,

be careful not to catch a strap.

Turning power on

H (for at least 2 seconds)

1

Stand-by display appears when initial settings are

complete (Stand-by Display Touch Launcher may
appear according to Stand-by Display Touch
Launcher set).

Press H for at least 2 seconds to turn the power off.

Basic Operation

23

Changing screen display to

Alternatively, ]
[Settings]/[Initial setting] to
display the setting screen.

English

Checking your own phone
number

][設定]/[一般設定]/[Bilingual]/

1

[English]

Making initial setting

Basic Operation

If initial settings are not complete, the setting screen

appears every time the power is turned on.

Set the date and time

1

Register a terminal security code

2

Set the key/touch sound

3

Set GPS location provision on/off

4

Set the font size collectively

5

24

][Phone]/[Own number]

1

Saving your own name and image

][Phone]/[Own number]/[Details]

1

Enter the terminal security code/[OK]/

2

[Submenu]/[Edit]
Save owner information/[Complete]

3

Changing mail address or configuring spam
mail prevention

You can connect to the i-mode site for changing mail address
or configuring spam mail prevention, etc. Refer to “Mobile
Phone User’s Guide [i-mode] FOMA version” for details on
setting method.

][Mail]/[Mail setting]/[Address/

1

Spam Mail Settings]/[Yes]

Screen Explanation

Icon display area

Viewing display/icon

Main icons

Signal status

b bbb (Strong b Weak)

When [ ] appears, the handset is

outside the service area or in a place with
no signal.

Battery level

bbbbb

(High b Low)

i-mode/Full Browser
i-appli

GPS

Ir communication/Bluetooth communication

i-mode mail/SMS/Area Mail received

microSD Card

1Seg being recorded

Record message

Silent

Vibrator

Manner mode

Public mode (Drive mode)

IC card lock

Restriction

Hands-free

Alarm

Music&Video Channel program reservation

FOMA card error

Self mode

Bluetooth

VeilView

3G/GSM

ToruCa

Information received

Basic Operation

25

Checking stock icon details

Number of entries

Message

Stock icon

Area where Widget Appli is
attached

Setting status icons for Widget
Appli

Operation guidance

Stock icons appear in the stand-by display when a call is
missed or a new mail is received.

Basic Operation

Main stock icon type

B
F
E

C

6

t
g

G

* The displayed message differs depending on the menu

screen or direction of the FOMA terminal.

A stock icon appears in the stand-by

1

display

Select the stock icon

2

The stock icon and message disappear after you

26

xx missed call

xx/ xx message

xx voice mail

xx mail message

Update required

Download successful (Music&Video Channel)

Download failed (Music&Video Channel)

Custom menu/Basic menu/Menu

check the details.

Displaying and operating i-Widget

In the i-Widget screen, you can simultaneously activate
multiple Widget Appli and display them as a list.
For details on operation of i-Widget nP.78

*

Using touch panel

Cautions when using the touch panel

The touch panel is designed to lightly touch with your finger. Do not forcefully press with your finger, or press with a

pointed object (fingernail, ballpoint pen, pin, etc.).

In the following cases, the touch panel may not work even if you touch it. May cause a malfunction.

 Operation with a gloved finger  Operation with foreign objects placed on the operation pad
 Operation with a fingernail  Operation on the touch panel on which a protective sheet or a sticker is put

Operate by touching the touch panel (screen) directly with your finger.

When the screen is off, you cannot perform the touch panel operation.

Locking touch panel

Lock the touch panel to prevent errors by turning the screen off.

^&

1

You can operate the touch panel if you perform the following operations according to Panel unlock set. Regardless of

the setting, touch panel operation is available if you set the handset to the open position.

 Two-step unlock: Press any key and touch [w] or press & to unlock.

 Simple unlock: Press any key to unlock.

Setting unlock method of touch panel lock

][Settings]/[General settings]/[Panel unlock set]

1

Select the setting

2

Locking for voice/videophone call

The touch panel is automatically locked while making a voice/videophone call, calling, receiving a call, or during a call to
prevent from errors. Press & to temporarily unlock. Press & to lock again.

Basic Operation

27

Basic operation of touch panel

Operation Main purpose

Touch Put your finger on the touch panel and

put it off.

For a list screen, etc., touch the object to

point the cursor and touch again.

Basic Operation

Touch for a while Keep your finger on the touch panel. Continuous operation such as adjusting

Slide Keep your finger on the touch panel and

Quickly slide Quickly slide your finger and put it off. Switch pages in a list screen, etc.

slide it.

When you touch a menu or item by

mistake, slide away from the menu or
item.

Select/OK
Move the cursor and select

volume, fast reverse/forward, etc.

Scroll the screen while viewing sites, etc.
Cancel the selection

Display previous/next data while displaying

images or mails

Put a distance between
two fingers apart/closer

Touch “CLR” – Cancel/End

Put two fingers on the touch panel and

slide them with putting a distance
between two fingers apart/closer.

Zoom in/out while displaying an image

28

Main operation while using function

Operating with control key

Control key appears in the lower part of the screen while using a function.
When control key does not appear, touch/touch and hold the screen to display during using a function.

Switching pages

When a list screen, etc. contains multiple pages, quickly slide to the left/right to switch pages.
When [\]/[]] or [F]/[G], etc. appears on the screen, switch pages by touching a key.

Adjusting volume

When the volume bar appears, keep touching the volume bar and slide up/down to adjust the volume.

Number entry

When numbers such as the phone number, terminal security code, or PIN code is required to be entered, the
numeric panel appears. Touch the numeric part. Touch the number in the input field to enter numbers for
date and time setting, etc.

Character entry

For details on entering characters nP.34

Basic Operation

29

Viewing main menu

Custom menu

Stand-by display

Touch wall paper

*

Basic menu

[]

[]

Stand-by Display Touch

Launcher appears

Touch shaded

area

Quick Settings appears

Quickly slide down

Touch icon

display area

[]

The explanations in this manual are based
on the method for retrieving a function from
the custom menu. If functions can be
retrieved from the Stand-by Display Touch
Launcher and the Quick Settings, retrieving
methods from these menus are explained.
In this manual, the touch panel operation

in vertical view is mainly explained.

Functions and designs of the custom

menu differ depending on the Kisekae
tool set.

TOP MENU

* TOP MENU appears when Stand-by Display

Touch Launcher set is [OFF].

Touch shaded

area

H

H

Set, change or register functions from the menu screens.

Basic Operation

30

Setting whether to display Stand-by Display Touch Launcher

Set whether to display the Stand-by Display Touch Launcher in the stand-by display when the power is turned on or a function
is ended.

ON (full-time) Display the Stand-by Display Touch Launcher. The Stand-by Display Touch Launcher disappears if you

touch other than the Stand-by Display Touch Launcher.

ON (temporary) The Stand-by Display Touch Launcher does not appear. The Stand-by Display Touch Launcher appears if

OFF The Stand-by Display Touch Launcher does not appear. The Stand-by Display Touch Launcher does not

][Settings]/[Disp/LED/Power saver]/[Stand-by settings]/[Stdby toch lnch]

1

Select the setting

2

Setting TOP MENU

}[TOP MENU]/[Settings]/[Disp/LED/Power saver]/[Menu priority]

1

Select a menu/[Yes]

2

you touch the wall paper on the stand-by display.

appear even if you touch the wall paper on the stand-by display (TOP MENU appears).

Basic Operation

31

Menu operation

Operation procedure

Operation procedures are expressed in the following
symbols in this manual.

Symbol Meaning

}

Operation from Stand-by Display Touch Launcher

{ Operation from Quick Settings
] Operation from custom menu
^ Operation from stand-by display

[6]

Stand-by Display

Touch Launcher

Phonebook

appears

Basic Operation

Registering a function on the Stand-by
Display Touch Launcher

You can register up to 12 functions on the following part of

the Stand-by Display Touch Launcher.

Retrieving a function from Stand-by Display
Touch Launcher

Icons which retrieve functions such as the phonebook, redials or
received calls appear in the stand-by display. You can quickly
activate functions and also register frequently-used functions.

Example: Display the phonebook

32

}touch an icon to change for a

1

while/[Register icon]

Point the cursor to the function to

2

register/[Save]/[Yes]

Retrieving a function from Quick Settings

[Public mode]

Quick Settings Set Public mode

(Drive mode)

[Camera]

[Shoot
movie]

Custom menu [Camera] appears

Camera (shooting

moving pictures)

is activated

Setting menus of functions related to icons displayed in the
upper part of the screen appear in the stand-by display and
you can quickly perform settings.

Example: Set the Public mode (Drive mode)

Retrieving a function from TOP MENU

TOP MENU is a menu from which you can retrieve all
functions.
Menus are classified by function. For details on menu

contents nP.96

The method for selecting functions may differ depending

on the Kisekae tool set for the custom menu.

When the custom menu screen is changed by the Kisekae

tool, the operation may differ from the description in this
manual.

Example: Retrieve camera (shooting moving pictures)

from the custom menu

Basic Operation

Selecting a function from submenu

Submenu appears if you slide from the upper right to the
lower left (or from the upper left to the lower right) while using
a function.
Slide an area where the submenu is displayed up/down to

scroll the submenu.

Touch [Q] to return to the previous screen.
Touch other than the submenu or touch [B] to hide the

submenu.

33

Character Entry

Entry mode switch palette

Conversion candidates
field

Entering characters with touch
panel

Switching entry modes

Basic Operation

Switch entry modes to enter various types of characters.

In the character entry screen, [Chara]

1

Select the entry mode

2

Kanji/Hiragana

あ

Double-byte katakana

ア

Single-byte katakana

ｱ

Double-byte alphanumeric characters

aA

(lower case b upper case)
Single-byte alphanumeric characters

aA

(lower case b upper case)

1 Single-byte numbers

Double-byte alphanumeric characters

Ａａ

Aa

Kuten Kuten code

34

(upper case b lower case)
Single-byte alphanumeric characters

(upper case b lower case)

Entering characters

Example: When entering “電話”

In the character entry screen, enter “

1

でんわ: [た] (four times)/[YZA/a] (once)/[わをん－]

(three times)/[b]/[わをん－] (once)

To enter multiple characters assigned to the same

key: Enter a character/[b]/enter a character

[Conv]

2

Select “電話”

3

でんわ

”

Entering pictograms/symbols

In the character entry screen, [Pict/Sym]

1

To switch to Deco-mail pictogram: [Pict-D]
To switch to pictogram: [Pict]
To switch to symbol: [Symbol]
To switch to double-byte symbol: [Fulpitch]
To switch to single-byte symbol: [Hlfpitch]

Select a pictogram/symbol

2

Using phrases

In the character entry screen,

1

[Submenu]/[Phrase(Hold F4)]
Select a phrase/confirm the phrase/

2

[OK]

Entering emoticons

In the character entry screen,

1

[Submenu]/[Emoticon(Hold F3)]

Select an emoticon

2

Copying characters

In the character entry screen,

1

[Submenu]/[Copy]/move the cursor to
the start position/[Start]

Move the cursor to the end position/

2

[Copy]

Cutting characters

In the character entry screen,

1

[Submenu]/[Cut]/move the cursor to
the start position/[Start]

Move the cursor to the end position/

2

[Cut]

Pasting characters

Example: When entering a message

In the character entry screen,

1

[Submenu]/[Paste]
Move the cursor to the paste position/

2

[Paste]

Example: When entering other than message

In the character entry screen, move the

1

cursor to the paste position/
[Submenu]/[Paste]

Basic Operation

35

Entering characters with

132

8 856

7

b

4

7

9a

keyboard

Keyboard for entering characters

Basic Operation

Entered character/Action

Key

1 1

2 2

1

3 3

Press

individually

Press after

z

Press after x

Operation guidance
F1

Operation guidance
F2

Operation guidance
F3
Press for at least

1 second to
display emoticon
selection screen.

Entered character/Action

Key

4 4

5 5
6 6

1

7 7
8 8 Set VeilView

9 9

0 0

2 $

3 c
4 ­5 o&

Press

individually

Display
Deco-mail
pictogram
selection screen

Delete character right after
the cursor

－＝

Move the
cursor up

Press after

*1

Select area

*2

(up)

z

Press after x

Operation guidance
F4
Press for at least

Activate Quick
search

Activate Multi
Assistant

Display single-byte
symbol selection
screen

Display emoticon
selection screen

Display pictogram
selection screen

End function being
activated

Move the cursor up

1 second to
display phrase
selection screen.

36

Entered character/Action

5

Key

q&

p&

r&

Press

individually

Move the
cursor to the
left (Change
selection area
for character
conversion)

Move the
cursor down

Move the
cursor to the
right (Change
selection area
for character
conversion)

Press after

z

Select area

*2

(left)

Select area

*2

(down)
Select area

*2

(right)

Press after x

Move the cursor to
the left (Change
selection area for
character
conversion)

Move the cursor
down

Move the cursor to
the right (Change
selection area for
character
conversion)

6 t& OK (Confirm for character conversion)
7 z Use in combination with another key.
8 x Use in combination with another key.

K

9 +

Insert line break (Confirm for character conversion).

Space (Move the cursor in

a _

conversion candidate field for

. 。

character conversion)

Q qQ /
W wW @

b

E eE _
R rR "
T tT (

Entered character/Action

Key

Press

individually

Press after

z

Press after x

Y yY )
U uU <
I iI >
O oO
P pP

「

」

A aA :
S sS b
D dD #
F fF %
G gG &

b

H hH '
J jJ +
K kK !
L lL ?
Z z Z Cancel operation
X xXCut
C cCCopy

*3

*3

V vVPaste
B bB E
N nN
M mM

・

, 、

*1 Press $ to switch the pictogram selection screen and

Deco-mail pictogram selection screen.

*2 Press with z.
*3 Operate after selecting an area.

Basic Operation

37

Switching entry modes

Entry mode switch palette

Conversion
candidates
field

Switch entry modes to enter various types of characters.

In the character entry screen, x + 4

1

Entering characters

Example: When entering “メール”

In the character entry screen, enter “めー

1

る”

めーる: ME-RU

Basic Operation

38

Select the entry mode with w&/t&

2

Kanji/Hiragana

あ

Double-byte katakana

ア

Single-byte katakana

ｱ

Double-byte alphanumeric characters

ａ

Ａ

aASingle-byte alphanumeric characters

Kuten Kuten code

Move the cursor to the conversion

2

candidates field with p&
Select “メール” with w&/t&

3

Sound/Screen Setting

Point the cursor to any pattern
from [Pattern1] to [Pattern3] to
sample the vibration pattern.

Changing ring tone

][Settings]/[Snd/Vibrator/

1

Manner]/[Select sound]

Select an item

2

Point the cursor to the ring tone/[OK]

3

Adjusting volume

You can change the mobile phone sound volume such as
ring tone, etc.

][Settings]/[Snd/Vibrator/

1

Manner]/[Select volume]

Select an item

2

Keep touching the volume bar and slide

3

up/down/[OK]

Setting keypad sound off

][Settings]/[Snd/Vibrator/

1

Manner]/[Select volume]/[Key/Touch
sound]

Keep touching the volume bar and slide

2

down to set [Silent]/[OK]

Setting vibrator

You can set the vibrator to notify you of incoming calls,
mails, alarms, GPS function and touching the touch
panel.

][Settings]/[Snd/Vibrator/

1

Manner]/[Vibrator]

Select an item

2

Select the vibrator

3

Note that if you set the vibrator and put the FOMA

terminal on a table, it may fall due to vibration.

Basic Operation

39

Using manner mode

Alternatively, press x + # (for
at least 1 second) to set/disable
manner mode while in stand-by/
receiving a call.

You can set the FOMA terminal on mute.

Camera shutter sound and record start/end sound are

heard even while the manner mode is set.

Normal The sound is not heard and vibrator is activated for

receiving a call, etc.

Silent The sound is not heard and vibrator is not

Basic Operation

Original You can change settings for each ring tone, alarm

1

activated.

tone, vibrator, etc.

}[/]

The screen for selecting manner mode appears. The

selected manner mode is set if you do not operate for
approximately 2 seconds.

Changing original manner mode setting

][Settings]/[Snd/Vibrator/

1

Manner]/[Manner mode]/[ON]/
[Original]

Select an item

2

Select the setting

3

To adjust the volume: Keep touching the volume bar

and slide up/down/[OK]

Setting to stop ring tone by
turning the FOMA terminal back

Even if manner mode is not set, you can stop the ring
tone, alarm tone, timer sound, or vibrator temporarily by
turning the FOMA terminal back.

][Settings]/[Snd/Vibrator/

1

Manner]/[Quick silent]/[ON]

40

Changing screen display

Changing stand-by display

][Settings]/[Disp/LED/Power

1

saver]/[Stand-by settings]/[Stand-by
display]

Select the screen to set

2

Point the cursor to the image/[OK]/

3

[Yes]

Setting display of background image

You can display the background image in each screen such
as phonebook, mail, data box, etc.

][Settings]/[Disp/LED/Power

1

saver]/[Color/Graphic set]/[Set
background]/[Show image]

Select the setting

2

Setting Machi-chara

You can display a character in the stand-by display.

][Settings]/[Disp/LED/Power

1

saver]/[Color/Graphic set]/
[Machi-chara]/[ON]

Point the cursor to Machi-chara/[OK]

2

Machi-chara being set does not appear.

Changing menu item

For some of Kisekae tool, you can change the custom menu
items to other functions.

]point the cursor to the item/

1

[Submenu]/[Assign function]
Select a function to assign/[Yes]

2

Basic Operation

41

Changing font setting

Small Normal Maximum

Alternatively, ^5 (for
at least 1 second) to set the
font size.
Font size is switched from
[Normal] b [Maximum] b
[Small].

][Settings]/[Disp/LED/Power

1

saver]/[Font style]/[Font style setting]

Select the font style

2

Changing font size

Basic Operation

][Settings]/[Disp/LED/Power

1

saver]/[Font style]/[Font size setting]
[Collective setting]/select the font size

2

When a confirmation screen asking whether to

change the menu appears, select [Yes] to change the
font size and menu. Select [No] to change the font
size only.

Setting VeilView

You can prevent others from seeing your display.

]touch [MULTI/a] for a while

1

Alternatively, touch [MULTI/a]/[h] for a while to

set during using a function.

; To disable: ]touch [MULTI/a] for a

while

Alternatively, touch [MULTI/a]/[h] for a while to

disable during using a function.

Changing Kisekae tool

You can change the custom menu screen, stand-by
display, menu icon, ring tone, etc. collectively.

][Data box]/[Kisekae Tool]

1

][Settings]/[Disp/LED/Power saver]/[Color/

Graphic set]/[Kisekae Tool] to operate.

Point the cursor to the Kisekae tool/

2

[Kisekae]/[Yes]

To check data: Select Kisekae tool (to display data list

screen in Kisekae tool)/select data

42

Changing LED for incoming

{[Eco mode]/[Yes]

to set the eco mode (Power
saver).

calls

][Settings]/[Disp/LED/Power

1

saver]/[LED settings]/[Called LED]

Select an item

2

[LED color settings]/select the LED color

3

[LED pattern settings]/select the LED

4

pattern

Checking missed calls or new
mails with LED

LED flashes at approximately 4-second intervals and
notify you of missed calls and new mails.

][Settings]/[Disp/LED/Power

1

saver]/[LED settings]/[Notice LED]
Select an item/[ON]

2

Saving power consumption

Norm
(auto bright)

Norm
(fixed bright)

Eco mode
(Pwr saver)

Original
Eco mode

][Settings]/[Disp/LED/Power

1

saver]/[Light/Power saver]

Select the type

2

This is normal light setting. Brightness is
automatically adjusted.

This is normal light setting. Brightness is
fixed.

You can save power consumption.

You can change settings for light
duration, brightness, etc. of display.

Basic Operation

43

Changing original eco mode
setting

Setting light time of display and keypad

You can set the length of backlight time by functions when the
FOMA terminal is not in use for a set length of time.

Basic Operation

][Settings]/[Disp/LED/Power

1

saver]/[Light/Power saver]/[Original
Eco mode]/[Display light time]

Select an item

2

Select the setting

3

To change the setting of [Normal]: Enter the light

duration/[OK]

Setting screen display time

Display is turned off when the FOMA terminal is not in use for
a set length of time.

][Settings]/[Disp/LED/Power

1

saver]/[Light/Power saver]/[Original
Eco mode]/[Screen dsp time]

Select the time

2

Adjusting display brightness

Automatic The display brightness is automatically adjusted

Manual You can select from 16 display brightness levels.

1

2

Setting keypad backlight

Set whether to turn on or off the keypad backlight.

1

2

Setting light time of display after FOMA
terminal is closed

1

2

according to the surrounding light.

][Settings]/[Disp/LED/Power

saver]/[Light/Power saver]/[Original
Eco mode]/[Brightness]

Select the adjusting method

][Settings]/[Disp/LED/Power

saver]/[Light/Power saver]/[Original
Eco mode]/[Keypad light setting]

Select the setting

][Settings]/[Disp/LED/Power

saver]/[Light/Power saver]/[Original
Eco mode]/[Light time aft cls]

Select the setting

44

Lock/Security

Precautions for various security codes

Do not use easily estimated numbers for security

codes to be set such as “birthday”, “part of a phone
number”, “address or room number”, “1111” or “1234”.
Keep a separate memo of security codes.

Keep security codes private. If the security codes are

found and improperly used by others, DOCOMO shall
not be liable for any loss of the users.

If you forget your security codes, you are required to

bring your identification (a driver’s license, etc.), your
FOMA terminal and your FOMA card to a docomo
Shop.
For further details, contact the number listed in
“General Inquiries” on the back of this manual.

PUK is described in the agreement form (customer

copy) you received at the time of subscription at a
docomo Shop. If you made a subscription outside a
docomo Shop, bring your identification (a driver’s
license, etc.) and your FOMA card to a docomo Shop
or contact the number listed in “General Inquiries” on
the back of this manual.

[0000] is set by default but you can change the code.

Various security codes

Some functions for convenient use of the FOMA terminal
require security codes.

Terminal security code (for various
functions)

If you enter the wrong terminal security code five times

continuously, the power is turned off.

Changing terminal security code

][Settings]/[Security]/[Change

1

security code]/enter the current terminal
security code/[OK]

Enter the new terminal security code/

2

[OK]/enter the new terminal security
code again/[OK]

Basic Operation

45

Network security code

You set arbitrary code at the time of subscription but you
can change the code.

[0000] is set at the time of subscription but you can
change the password.

i-mode password

Network security code is a four-digit code required for
confirming the subscriber’s identity when an order is received

at a docomo Shop, docomo Information Center or “お客様サ

Basic Operation

ポート (user support)” (in Japanese only), or used for
accessing various network services.

Changing network security code

][i-mode]/[iMenu/Search]/[お客様

1

サポート]/[各種設定 (確 認・変 更・利 用 )]/
[ネットワーク暗証番号変更]

46

A four-digit “i-mode password” is required to register/delete
sites in マイメニュー (My menu), or subscribe/cancel

message services and charged i-mode services (Additionally,
information providers may set their own passwords).

Changing i-mode password

][i-mode]/[iMenu/Search]/

1

[English]/[Options]/[Change i-mode
Password]

PIN1 code/PIN2 code

[0000] is set at the time of subscription but you can
change the code.

You cannot change the code.

You can set two security codes, PIN1 code and PIN2 code,
on the FOMA card.
The PIN1 code is a four- to eight-digit security code that is
entered when a FOMA card is inserted or when the FOMA
terminal is turned on to prevent unauthorized use by a third
party. Enter the PIN1 code to enable making/receiving calls
and operating the handset. The PIN2 code is four- to
eight-digit security code that is entered for performing
operations such as resetting total cost or using client
certificates, or applying for.
If you enter the wrong PIN1 code or PIN2 code three times
continuously, it is locked.

Setting handset to require PIN1 code entry at
power on

][Settings]/[Security]/[UIM

1

Settings]/enter the terminal security
code/[OK]

[PIN1 code input set]/[ON]

2

Enter the PIN1 code/[OK]

3

Changing

When the PIN1 code input set is set to [OFF], you cannot

change the PIN1 code.

][Settings]/[Security]/[UIM

1

Settings]/enter the terminal security
code/[OK]

Select the PIN1 or PIN2 code

2

Enter the current PIN code/[OK]

3

Enter the new PIN code/[OK]/enter the

4

new PIN code again/[OK]

PUK

PUK is an eight-digit number used to disable the PIN1/PIN2
code lock.
If you enter the wrong code ten times continuously, the

FOMA card is completely locked. In this case, contact a
docomo Shop.

PIN1 code/PIN2 code

Basic Operation

47

Various lock functions

Lock function Operation/Restriction Lock function Operation/Restriction

All lock Prevents all operations other than power

on/off and answering calls.

Enable:

]

[Lock settings]/enter the terminal

Basic Operation

Keypad dial lock Prevents calling to numbers not saved in

Function lock

Self mode Prevents communication.

* This is a paid service. Refer to “Mobile Phone User’s Guide [i-mode] FOMA version” for details on Omakase Lock.

security code

Disable: ^[All lock]/enter the

terminal security code/[OK]

the phonebook.
Enable/Disable: ][Settings]/

[Security]/[Lock settings]/enter the
terminal security code/[OK]/
[Keypad dial lock]/select the setting

Prevents access of each function individually.
Enable/Disable: ][Settings]/

[Security]/[Lock settings]/enter the
terminal security code/[OK]/
[Function lock]/select an item to lock/
disable/[Complete]

Enable/Disable: {[Self

mode]/select the setting/[Yes]

[Settings]/[Security]

/

[OK]/[All lock]/[Yes]

48

Multi lock Keypad dial lock, IC card lock and

/

IC card lock Prevents the use of IC card functions.

Touch panel/Key
lock

Omakase Lock*Omakase Lock is a service to lock the

Function lock can be set collectively.
Enable: {[Lock select]/[Multi

lock]/[Yes]

Disable: {[Lock select]/

[Multi lock]/enter the terminal security
code/[OK]

Enable: {[Lock select]/[IC

card lock]/[Yes]

Disable: {[Lock select]/[IC

card lock]/enter the terminal security
code/[OK]

Prevents the operation of touch panel,
front key, or side key in the close position.
Enable/Disable: & (for at least 1

second)

personal data and IC card functions in
case of loss, etc. by only your request to
DOCOMO via phone.

Enable/Disable Omakase Lock

s 0120-524-360 Office hours: 24 hours
(in Japanese only)

Incoming call restriction

Rejecting a call with no caller ID

You can set the handset to reject calls with no caller ID
depending on reason (User unset, Payphone, Unavailable).

][Settings]/[Security]/[Accept/

1

Reject calls]/enter the terminal security
code/[OK]

Select the reason

2

Select the setting

3

Rejecting a call from a caller unset in
phonebook

][Settings]/[Security]/[Accept/

1

Reject calls]/enter the terminal security
code/[OK]/[Reject unknown]

Select the setting

2

Resetting to default

Resetting various functions

For items return to default by reset settings nP.96

][Settings]/[General settings]/

1

[Reset settings]

Enter the terminal security code/[OK]

2

[Yes]/[Agree]

3

Deleting saved data all at once

You can delete all saved data and reset the settings of each
function to default.
Protected data is also deleted.

][Settings]/[Security]/[Delete all

1

data]/[Delete user data]
[Agree]/enter the terminal security

2

code/[OK]/[Yes]

Resetting data by remote
control

You can initialize various data (memory in the handset/
microSD Card/FOMA card) in the specified FOMA
terminal by manager’s request with the subscription of
this function (Business mopera anshin manager).
Refer to the DOCOMO website for corporations (in
Japanese only) for details.
docomo Business Online
From a PC http://www.docomo.biz

※ You may not be able to access some site services due to

system maintenance, etc.

Remote reset is a service that requires subscription.

Basic Operation

49

Call

Connect

If you make a call, [Submenu]/
[Switch to v.phone]/[chg to
voice call]/[Yes] during a call
to switch a voice call and a
videophone call.

Making a voice/videophone call

DOCOMO videophones comply with “3G-324M as defined

by the international 3GPP standard”. Connection is not
available with videophones using other standards.

^s/enter a phone number

1

Start with the area code.

[B] (Phone)/[V.phone]

2

Connect

50

To enable/disable hands-free (voice call): s (for at

least 1 second)

To enable/disable hands-free (videophone call): s

H to end the call

3

Making a call from phonebook

}[6]

1

Point the cursor to the name

2

Make a call

3

Voice call: [B]
Videophone call: [Submenu]/[V.phone]

Making a call with redials/received calls

^quickly slide to the right (Redial)/

1

left (Received calls)

Select a phone number

2

[B] (Phone)/[V.phone]

3

Notifying the other party of your phone
number

You can display your number on the other party’s phone
when you make a call.

][Settings]/[NW Services]/[Notify

1

caller ID]/[Activate/Deactivate]/[Yes]

Making an international call

WORLD CALL is an international calling service available
from DOCOMO mobile phones.
WORLD CALL is registered when FOMA services are
registered (excluding users who did not apply for WORLD
CALL).
WORLD CALL charges are billed with the monthly mobile

phone charges.

Commission and monthly usage fees are free.
For details on WORLD CALL, contact the number listed in

“General Inquiries” on the back of this manual.

To make an international call through a company other

than DOCOMO, contact the representative companies
directly for instructions.

Some payment plans may not be available.

^s/touch [0(+)] for a while/

1

enter the country code, area code (city
code) and other party’s phone number

For area codes (city codes) that begin with “0”, omit

the “0” when entering (Include the “0” when making a
call to some countries or regions such as Italy).

[B] (Phone)/[V.phone]/[Call]

2

Receiving a voice/videophone
call

A call is received

1

The ring tone sounds and the called LED flashes.
When the caller does not send a caller ID, a

non-disclosure reason message appears.

• [User unset]: When the caller purposely withholds
caller ID

• [Payphone]: When the call is received from a
payphone

• [Unavailable]: When the caller cannot send a caller
ID, such as when the call is received from overseas
or ordinary (landline) telephones via various
transfer services

s to answer a call

2

H to end a call

3

Adjusting earpiece volume

During a call, [Volume]

1

Keep touching the volume bar and slide

2

up/down

Sending touch-tone signal

During a call, [Keypad]/enter a number

1

[Close]

2

Connect

51

When you cannot answer call

Alternatively, touch [Rec msg]
during an incoming call to record.

Public mode (Drive mode)

The FOMA terminal plays the message stating you cannot
answer the phone without the ring tone.

{[Public mode]

1

; To disable: {[Public mode]

Public mode (Power off)

The FOMA terminal plays the message stating you cannot

Connect

answer the phone when the power is off.

^s/enter “b25251”/[B]

1

; To disable: ^s/enter “b25250”/

[B]

Placing a call on hold when you cannot
answer call immediately

During an incoming call, H

1

The call is disconnected when you press H while on

hold, or when the other party disconnects the call
(The call is saved in received calls).

[B] when ready to answer

2

Setting record message (voice/videophone
calls)

If you set record message, the FOMA terminal answers a call
and records the caller’s message when you cannot answer.

][Settings]/[Phone settings]/

1

[Record message]/[Record message]

Select the setting

2

; To play record message: {[Rec

msg]/[Play]/select a message

Recorded contents may be lost due to malfunctions,

repairs or other handling of the FOMA terminal.
DOCOMO shall not be liable for any loss of content. It is
recommended that a memo be kept of contents for
record message (voice/videophone calls).

52

Using various network services

Service name Subscription Monthly fee

Voice Mail Service Necessary Fees apply
Call Waiting Necessary Fees apply
Call Forwarding Service Necessary Free
Nuisance Call Blocking

Service
Notify Caller ID Service Not necessary Free
Caller ID Request Service Not necessary Free
2in1 Necessary Fees apply
Public mode (Drive mode) Not necessary Free
Public mode (Power off) Not necessary Free
Dual Network Service Necessary Fees apply
English Guidance Not necessary Free
Multi Number Necessary Fees apply
OFFICEED Necessary Fees apply
Melody Call Necessary Fees apply

Network services are not available outside the service

area or in a place with no signal.

“OFFICEED” is a service that requires a subscription.

Refer to the DOCOMO website for corporations (in
Japanese only) (http://www.docomo.biz/html/product/
officeed/) for further information.

Refer to “Mobile Phone User’s Guide [Network Services]”

for details on each network service.

For subscription and inquiries, contact the number listed in

“General Inquiries” on the back of this manual.

Not necessary Free

Using Voice Mail Service

][Settings]/[NW Services]/[Voice

1

Mail]
[Activate VoiceMail]/[Activate

2

VoiceMail]/[Yes]

Using Call Waiting

][Settings]/[NW Services]/[Call

1

waiting]
[Activate]/[Yes]

2

Using Call Forwarding Service

][Settings]/[NW Services]/[Call

1

Forwarding]
[Activate]/[Activate]/[Yes]

2

Connect

53

Services available for the
FOMA terminal

For weather forecast, enter the number, starting with the

area code of the area you want to know the weather. For
other services, dial without area code.

Available services

Directory assistance service (fees apply:
assistance fee + call fee)

Telegrams (fees apply: telegram fee) 115
Time tone service (fees apply) 117

Connect

Weather forecast (fees apply) 177
Police emergencies 110
Fire department/Medical assistance 119
Emergencies and accidents at sea 118
Disaster message (fees apply) 171
Collect call (fees apply: assistance fee + call fee) 106

* We do not provide directory assistance service to

customers who do not want to have it.

If landline phones subscribed to “Call Forwarding” are set

to forward calls to mobile phones, callers may hear the
phone ringing even if the mobile phone is busy, outside
the service area, in self mode or turned off depending on
the settings for the landline/mobile phones.

*

Phone

number

104

The FOMA terminal supports “Location notification of

emergency call”. When dialing an emergency number
such as 110, 119, and 118, the information of your
location (location information) is automatically notified to
the agency that receives the emergency call (e.g. the
police station). Depending on your location and the
reception status of the signal, the agency that received the
emergency call may not be able to confirm the exact
location. If the location information is notified, the name of
the agency that received the emergency call is displayed
in the stand-by display. If you are not sending your caller
ID by calling with “184” added or other means, your
location information and phone number are not notified.
However, if the agency that received the emergency call
considers your location information and phone number
necessary for important purposes, such as life saving, the
agency can retrieve them regardless of your settings. In
addition, the area/timing to introduce “Location notification
of emergency call” depends on the state of preparation in
each agency that receives emergency calls.

When calling 110, 119, and 118 from your FOMA terminal,

the police or fire stations may return your call for
verification purposes. State that you are calling from a
mobile phone, and give your phone number and exact
location. Remain stationary to ensure that you are not
disconnected while making an emergency call, and keep
handset turned on to receive calls for approximately 10
minutes afterwards.

Depending on the region, calls to the police or fire station

may not be connected. In such cases, use the nearest
payphone or landline phone.

54

Using overseas

International roaming (WORLD WING) is a service that
enables you, using overseas telecommunications
carrier’s networks, to make calls and use i-mode.
You can use your mobile phone number and mail
address overseas for voice/videophone calls, i-mode and
SMS as you do in Japan. Also, you can use network
services such as Voice Mail and Call Forwarding
Services.

Check the status of a subscription for WORLD WING

when using the service.

The FOMA terminal is available in the 3G network and

GSM/GPRS network service areas. In addition, this
service is available in countries and regions supporting
3G850MHz.

By default, the FOMA terminal is set to automatically

switch networks.

When you received a call during international roaming, the

call is forwarded from Japan. Call charges to Japan are
incurred by the caller and receiving charges by the
receiver.

Refer to the following before using the FOMA terminal

overseas.

 “Mobile Phone User’s Guide [International Services]”
 “Mobile Phone User’s Guide [Network Services]”
 DOCOMO International Services website

 PDF file “海外ご利用ガイド” (in Japanese only)

pre-installed in [My Documents] of data box

WORLD WING

If you have subscribed to the FOMA service after

September 1, 2005, subscription for WORLD WING is not
required. However, if subscription for WORLD WING is
canceled at or after subscription for the FOMA service,
subscription for WORLD WING is required again.

If you have subscribed to the FOMA service before August

31, 2005 but not subscribed to WORLD WING,
subscription for WORLD WING is required.

For lost, stolen, and cost settlement, or malfunction of the

FOMA terminal overseas, refer to “Loss or theft FOMA
terminal or payment of cumulative cost overseas” or
“Failures encountered overseas” on the back of this
manual. Note that any call or transmission charges
incurred after the FOMA terminal is lost or stolen are
charged to the subscriber.

Connect

55

Available services overseas

Communication service 3G GSM

Voice call AAA
Videophone ABB
i-mode mail ABA

*1

i-mode
i-Channel
i-concier
i-Widget
SMS AAA
GPS position location

Connect

Packet transmission by connecting a
PC, etc.

*1 Overseas use settings for i-mode is required.
*2 i-Channel setting is required. Packet transmission

*3 Overseas use settings for i-concier is required. Packet

*4 Setting for i-Widget roaming is required. Multiple Widget

*5 Transmission charges are not incurred when you

Overseas charges (call charges, packet transmission

*1, 2

*3

*4

*5

charges are incurred for each i-Channel reception
(including Basic channel).

transmission charges are incurred for each information
reception.

Appli may attempt transmission when i-Widget screen
appears. In such case, packet transmission charges are
incurred for each transmission.

position the present location. However, packet
transmission charges are incurred such as when you
display a map based on the location information.

charges) differ from those in Japan.

ABA
ABA
ABA
ABA

ABA
ABA

56

GPRS

Making a call outside your country of stay
(including Japan)

Make a call from your country of stay to Japan or other countries.

^s/touch [0(+)] for a while/

1

enter country code, area code (city code)
and other party’s phone number

When the area code (city code) begins with “0”, omit

the “0” when dialing (Include “0” when making a call to
some countries or regions such as Italy).

[B] (Phone)/[V.phone]

2

Making a call in your country of stay

You can make a domestic call at your country of stay in the
same way as you do in Japan.

^s/enter a phone number

1

[B] (Phone)/[V.phone]

2

Making a call to a WORLD WING subscriber
overseas

When you make a call to a WORLD WING subscriber
overseas, you make a call as an international call to Japan
regardless of your country of stay.

^s/touch [0(+)] for a while/

1

enter country code “81” (Japan) and the
other party’s mobile phone number
excluding the first “0”

[B] (Phone)/[V.phone]

2

Mail

Select an attachment file

Enter an address

Enter a subject

Enter a message

You can display the compose
message screen just by setting
the handset to the open
position in the stand-by display
(nP.7).
If you select [EmojiPlus] or
[Decome-Anime] after entering
a message, you can enter
pictograms/Deco-mail
pictograms or compose
Decome-Anime easily.

You can exchange mails with other i-mode terminals and
e-mail via Internet by subscribing to i-mode service.
You can attach up to ten files (pictures, moving picture
files, etc.) in total of 2 MB to a message. Also, Deco-mail
is available. You can send an expressive mail by
changing character color and size, or background color
and inserting Deco-mail pictograms.
Moreover, Flash movie Decome-Anime with a message
or image inserted is available.

Refer to “Mobile Phone User’s Guide [i-mode] FOMA

version” for details on i-mode mail.

Sending i-mode mail

}[Compose message]

1

Compose a mail

2

[Send]

3

Connect

57

Composing and sending

Palette

Editing items list

Deco-mail/Decome-Anime

Composing and sending Deco-mail

You can decorate a message or its
background when composing i-mode mail.

Connect

In the message entry screen,

1

[Submenu]/[Decorate mail]

Decorate

2

Select the decoration method from the palette, set

contents of decorating and enter messages.

[OK]/[Send]

3

Composing and sending Decome-Anime

You can compose an expressive mail with
Flash movies using templates.

][Mail]/[Compose

1

Decome-Anime]/[Edit]
Point the cursor to the template/[OK]

2

Select an edit item/edit

3

[Quit]/enter an address and a subject/

4

[Send]

58

Checking received i-mode mail

Receive i-mode mail

1

The receive complete screen appears and the mail

ring tone sounds.

If you do not operate for approximately 15 seconds,

the screen before reception reappears.

[Mail]/select a mail

2

[- END -] appears at the end of the message. When

receiving limit is exceeded, [/] or [//] appears and the
exceeding portion is automatically deleted.

Checking a mail in Inbox

}[Inbox]

1

Select a mail

2

Checking new i-mode mail

Received i-mode mail or Message R/F are stored at the
i-mode center while the handset is outside the service area,
in the self mode or when the power is turned off. You can
check and receive mails from the i-mode center.

][Mail]/[Check new messages]

1

Replying to i-mode mail

In the received mail details screen,

1

[Submenu]/[Reply/Forward]

To reply referring to the received mail in the open

position: x + 2/[Reference reply]

[Reply]/[i-mode mail]/[Decome-Anime]

2

Compose and send a mail

3

Sorting mail to folder automatically

If you set sort rules for user folders in Inbox/Outbox, you can
sort i-mode mail and SMS automatically.
Multiple sort rules can be set for one folder.

Point the cursor to the folder/

1

[Submenu]/[Sort rules]

Select a save destination

2

Set the sort rules/[Complete]

3

Connect

59

Receiving Early Warning “Area

Basic operation for SMS is same as
that for i-mode mail.

Mail”

Area Mail is a service to receive the earthquake early
warning, etc. provided from the Japan Meteorological
Agency.

Receive Area Mail

1

Dedicated alarm tone (beep sound) or Area Mail

dedicated ring tone sounds and called LED flashes
red.

After receptions, some Area Mail automatically

Connect

display a message, while others display [Area mail
received]. When [Area mail received] appears, the
screen before reception automatically reappears in
approximately 30 seconds.

Setting whether to receive Area Mail

][Mail]/[Mail setting]/[Area Mail

1
2

setting]/[Receive setting]

Select the setting

Using SMS

You can use SMS entering mobile phone number in the
[To] field.

Sending SMS

][Mail]/[Compose SMS]

1

Compose and send SMS

2

Checking received SMS

Receive SMS

1

[Mail]/select SMS

2

60

Phonebook

You can use the FOMA terminal phonebook and FOMA
card phonebook.

Adding entries to phonebook

Main entry items

Icon Item Details

Name

Reading

Group

*

/
/

* Icons displayed in the FOMA card phonebook
You can add address, birthday and other items to the

FOMA terminal phonebook.

}[6]/[Submenu]/[New]/

1

[Phone]/[UIM]
Enter/Select an item/[Complete]

2

You can set a memory number for the FOMA terminal

Phone number

*

Mail address

phonebook. If you touch [OK] without entering a
memory number, the entry is added to an available
memory number.

Enter a name.

Reading is entered
automatically.

Entries can be sorted in
groups.

Add phone numbers.

Add mail addresses.

Adding entries from redials/received calls

}[I] (Redial)/[M] (Received call)

1

Select a phone number/[Submenu]/

2

[Add to phonebook]
Add to phonebook

3

Editing phonebook

}[6]/point the cursor to the

1

name/[Submenu]/[Edit data]/[Edit]
Edit the phonebook/[Complete]

2

You can set a memory number for the FOMA terminal

phonebook. If you touch [OK]/[Yes] without
changing a memory number, original phonebook is
overwritten.

Deleting phonebook

}[6]/point the cursor to the

1

name/[Submenu]/[Delete]/[Delete
one]/[Yes]

Connect

61

i-mode/Full Browser

Search

i-mode enables you to use online services, such as
connection to sites and Internet.
You can view sites that are not supported by i-mode as
they appear on PCs using Full Browser.

i-mode is a paid service that requires a subscription.
Refer to “Mobile Phone User’s Guide [i-mode] FOMA

version” for details on i-mode.

Note that making a transmission with large-volume data,

such as viewing a web page with many images and
downloading data during Full Browser will lead to higher
transmission charges.

Using i-mode

Sites and Internet web pages are generally protected by

Search

copyright law. Selling and redistributing whole or a part of
downloaded text, images or other data from sites and web
pages for non-personal use as they are or a part changed
without author’s permission is prohibited.

Some models cannot display/play data downloaded from

sites, etc. if a different FOMA card is inserted or the
handset is turned on without a FOMA card.

If files with access restrictions by a FOMA card are set as

the stand-by display or ring tone, etc. and a different
FOMA card is inserted or the handset is turned on without
a FOMA card, settings are reset to default.

Connecting to i-mode site

}[8]/select an item

1

Viewing web pages designed
for PC

}[Full Browser Home]

1

Some sites with large amounts of information do not

appear properly.

Switching browsers

Note that different transmission charges are incurred

when switching between i-mode and Full Browser.

Switching from i-mode to Full Browser

While viewing sites with i-mode,

1

[Submenu]/[Full Browser]/[Switch to
FB]

Switching from Full Browser to i-mode

While viewing sites with Full Browser,

1

[Submenu]/[i-mode Browser]/[Switch
to i-mode]

62

Viewing and operating sites

i-mode and Full Browser may
be switched depending on
the link. Select [Yes] in the
confirmation screen asking
whether to switch.

Quickly slide to

the right

*

Quickly slide to

the left

*

Selecting a link and moving to a new screen

While viewing sites, select a link

1

A selected link is highlighted.
Some links may be images. If you select, the image is

outlined.

Moving to previous/next page

The FOMA terminal saves sites you viewed. You can view the
previous/next page without transmission. This memory is
called the “cache”.

* Touch [Back]/[Next] in Full Browser.

Information such as previously entered character,

setting, etc. is not viewed when you view pages saved in
the cache.

The cache is reset by ending i-mode/Full Browser.
When switching from i-mode to Full Browser, you can

return to the page displayed with i-mode by touching
[Back]. Likewise, when switching from Full Browser to
i-mode, you can return to the page displayed with Full
Browser by quickly sliding to the left.

Search

63

Bookmark/Screen memo

You can display the
bookmark list screen just by
setting the handset to the
open position in the stand-by
display (nP.7).

Saving frequently viewed sites

You can save frequently viewed sites and Internet web pages
as bookmarks for convenient access.

While viewing sites, [Submenu]/

1

[Bookmark]/[Add bookmark]/[OK]

Select a folder

2

; To view sites from bookmarks:

}[Bookmark]/select a bookmark

Search

Saving site contents

You can add (save) screens from your favorite sites, etc. as
screen memos to the FOMA terminal or microSD Card.

While viewing sites, [Submenu]/[Screen

1

Memo]/[Add screen memo]
Select a save destination/[Yes]

2

The screen memo is added.
To add the screen capture only: Select a save

destination/[Only displayed]

; To display screen memos:

][i-mode]/[Screen Memo]/select

a screen memo

If you select a link in the screen memo, connection is

made with i-mode for the screen memo of i-mode, while it
is made with Full Browser for the screen memo of Full
Browser.

Bookmarks are listed in the order of use.
Connection is made with i-mode from i-mode bookmarks,

while it is made with Full Browser from Full Browser
bookmarks.

64

i-Channel

※ The i-Channel service is provided in Japanese.

i-Channel is a service that sends news and other
information. The latest information received
automatically is displayed in the stand-by display using a
ticker. Additionally, touch the i-Channel ticker to display
the latest information in a list of channels. i-Channel is a
paid service that requires a subscription (i-mode
subscription is required).
There are two types of i-Channel as follows.

 “ベーシックチャネル” (Basic channel): This is

i-Channel provided by DOCOMO. Packet transmission
charges are not incurred for automatically updating
information.

 “おこのみチャネル” (Favorite channel): This is

i-Channel provided by IP (Information Providers).
Packet transmission charges are incurred for

automatically updating information.
Note that packet transmission charges are incurred for
when detailed information are viewed in both channels.
Packet transmission charges are incurred for
automatically updating information and viewing detailed
information during international roaming.
Refer to “Mobile Phone User’s Guide [i-mode] FOMA
version” for details on i-Channel.

Displaying i-Channel

{[i-Channel list]

1

Select a channel

2

Displaying i-Channel in stand-by display

Set whether to display i-Channel ticker in the stand-by
display.

][i-mode]/[i-Channel]/[i-Channel

1

ticker]/[ON]

The operation is completed if you set to [OFF].

Select the [Ticker font size] field/select

2

the size
Select the [Ticker color] field/select the

3

color
Select the [Ticker speed] field/select the

4

speed/[Complete]

Search

65

Map/GPS

Note that DOCOMO shall not be liable for the pure

economic loss if you cannot confirm the positioning

(communication) result with the FOMA terminal failure,

malfunction, error or external factors such as power failure

(including battery exhaustion).
You cannot use the FOMA terminal as navigation system

for professional use of aircrafts, vehicles, person, etc.

Therefore, note that DOCOMO shall not be liable for the

loss caused by the navigation system to use location

information.
You cannot use the FOMA terminal as surveying GPS of

high accuracy. Therefore, note that DOCOMO shall not be

liable for the loss caused by the error of location

information.
GPS is the service in charge of Department of Defense of

Search

USA, therefore, GPS radio wave condition may be

controlled (accuracy degradation, radio wave abort, etc.)

for the US national security reason.
For the use of location provision or location notification,

check the information of an information provider and

DOCOMO website. Charges may be incurred for these

functions.
GPS function of the FOMA terminal is not available

outside the service area.

66

Checking your location

You can check your location by positioning the present
location. You can use this function for more convenient use
such as displaying a map from positioning location
information.
Transmission charges are not incurred when you check

the present location. However, packet transmission
charges are incurred when you display a map based on
the location information.

][LifeKit]/[Map/GPS]/[Position

1

location]

Select a usage

2

Viewing map

You can activate GPS compatible i-appli and view the
present location or specified location.

][LifeKit]/[Map/GPS]/[Map]

1

GPS compatible i-appli is activated after positioning

the present location.

Using AUTO-GPS

※ The AUTO-GPS service is provided in Japanese.

According to your present location, you can receive
various services, such as providing surrounding
information including weather information, store
information, etc., or sight-seeing information.

If you use AUTO-GPS function, your present location is

automatically measured based on your movement and

location information is sent to a service provider (Present

location is measured approximately once every 5 minutes

according to your movement).
Set AUTO-GPS service information from AUTO-GPS

compatible i-appli of each service to use services

supporting AUTO-GPS function.
You can register up to three AUTO-GPS services other

than those provided by DOCOMO.
For the use of AUTO-GPS function, check the information

of GPS service provider or DOCOMO website. Charges

may be incurred for using these services.
Packet transmission charges may be incurred for sending

location information.
Communication may be performed on a regular basis and

power consumption of the FOMA terminal may increase

depending on your status of use.

Setting whether to use AUTO-GPS function

][LifeKit]/[Map/GPS]/

1

[AUTO-GPS]/[AUTO-GPS setting]

Select the setting

2

Using services provided by DOCOMO

If you use DOCOMO AUTO-GPS service, location
information of the FOMA terminal is automatically sent to
DOCOMO, and you can receive services related to i-concier
or various services provided by DOCOMO.
Separate subscription and the settings are required to use

various services.

][LifeKit]/[Map/GPS]/

1

[AUTO-GPS]/[DOCOMO service
setting]/[ON]/[OK]

Search

67

Camera

Enjoy

1

2

3

4
5

Still picture

Moving picture

Enjoy

68

Screen layout and operations
for shooting screen

Shooting screen layout

1 Focus frame 4 Zoom bar
2 Shooting status 5 Shooting time
3 Icon display position

Meaning of main icons

Focus lock Image quality

Picture Light Size

Brightness Fix camera shake

Auto timer White balance

Shoot by scene

Touch panel operations for shooting screen

Still picture

The following operations are available with keys displayed.

[Settings] Change settings collectively
[A] Shoot
[Egao] Switch to Egao focus shutter mode
[Turn] Switch to Furimuki shutter mode
[Normal] Return to normal shooting
[Face reg] Face registration

The following touch operations are available.

Adjust brightness Quickly slide up/down
Adjust zoom Quickly slide to the left/right

Moving picture

The following operations are available with keys displayed.

[Settings] Change settings

collectively
[Rec] Start shooting [Normal]
[Stop] Stop shooting
[Scenes] Shoot by scene

As well as still picture, touch operations are available for

adjusting brightness/zoom.

[C replay]

Switch to common
replay mode

Switch to normal
shooting

Shooting still/moving pictures

If the camera lens is exposed to direct sunlight for a long

time, the internal color filter may discolor, creating a
discoloration of shot images. In addition, shooting the sun
directly may damage the performance of the CMOS.

Although the cameras are made with high-precision

technology, some pixels or lines look constantly dark or
bright. Further, white lines and other noise may appear in
images especially when shooting images in dimly lit
surroundings.

Images shot in shooting conditions which include the sun,

a light or other strong light source may appear dark and
distorted.

Shot still pictures or moving pictures may not be saved

when the battery level is low.

Shooting still pictures

}[Shoot still pic]

1

When still pictures shooting activates, the called LED

illuminates.

[A]

2

[Save]

3

Shooting moving pictures

][Camera]/[Shoot movie]

1

When moving pictures shooting activates, the called

LED flashes. The called LED illuminates while
shooting.

[Rec]

2

[Stop]

3

[Save]

4

Confirming shot still/moving
pictures

Displaying shot still pictures

][Data box]/[My picture]

1

[Camera] folder/select an image

2

To set as stand-by display, etc.: Point the cursor to

the image/[Submenu]/[Set screen]/select an
item

Playing shot moving pictures

][Data box]/[i-motion/Movie]

1

[Camera] folder/select i-motion

2

To set as stand-by display, etc.: Point the cursor to

i-motion/[Submenu]/[AV settings]/select an item

Enjoy

69

Convenient functions for shooting

Function Details Setting/Starting method

Best select photo*1Shoot continuously just before shutter operation. You can

select and save your favorite picture.

Strobophoto

Face registration*1You can save a shot face image as face information, and

Pretty arrange

Enjoy

camera

*1 Available for still picture shooting.
*2 Respect personal rights and portrait rights when editing face images, to avert any legal issues.

*1

Shoot continuously and compose the combined image. In the still picture shooting screen,

display the saved face information in the still picture
shooting screen.

*2

You can arrange a picture after shooting, by making a
face smaller or making eyes bigger, etc.

In the still picture shooting screen,
[Submenu]/[Shooting menu]/[Continuous
mode]/[Best select photo]

[Submenu]/[Shooting menu]/[Continuous
mode]/[Strobophoto]

In the still picture shooting screen,
[Submenu]/[Camera settings]/[Face
registration]/[Save new]/register a face

][Camera]/[Pretty arrange cam]

70

1Seg

1Seg is a service provided by TV broadcasters
(broadcast stations), etc. Transmission charges are not
incurred for receiving video, voice and sound. Contact
NHK for details on viewing fees of NHK.

※ Packet transmission charges are incurred when accessing

a site such as a “data broadcasting site”, “i-mode site” or
others.
Also, some sites require information charges to use
(i-mode paid sites).

※ For details on the “1Seg” service, see the website below.

The Association for Promotion of Digital Broadcasting
From a PC http://www.dpa.or.jp/english/
From i-mode http://www.dpa.or.jp/1seg/k/ (in Japanese
only)

※ 1Seg is not available overseas.

About signal

1Seg is one of the broadcasting services, and the receiving
signal (broadcast wave) differs from that of FOMA service.
In the following places, the reception status may be bad.
 Place that is far from the tower which sends the

broadcasting wave

 Mountain areas or behind a building
 A tunnel, basement or a place in the rear of a building

※ Hold the FOMA terminal apart from or close to the body or

move to another place, so that the reception status may
become better.

About battery level

When recording is started with low battery level or battery
level becomes low while recording, the message stating that
recording is impossible appears and then the recording ends.

Screen display for first use of 1Seg

A confirmation screen of disclaimer appears for first use of
1Seg after purchase.

Touch [f] according to the displayed contents. The same

confirmation screen does not appear after that.

Other notes for 1Seg

If you use 1Seg for a long time while charging, the service

life of the battery pack may be shorter than estimated.

DOCOMO shall not be liable for any loss or change of the

saved data due to malfunctions, repairs or other handling
of the FOMA terminal.
When changing the model or asking for repair of your
FOMA terminal, you cannot transfer the stored contents
(video and still pictures taken from 1Seg, TVlink, data in
the broadcasting storage area, etc.) in the terminal.

You cannot use 1Seg overseas since the broadcasting

format and the broadcasting frequency are different (You
can watch 1Seg programs video-recorded on the FOMA
terminal).

Enjoy

71

Setting channels

To watch 1Seg, set the channels first.

Auto channel setting

Select a prefecture/district to use. Broadcast station is
automatically searched and saved into the channel list.
Perform auto channel setting inside the area of a

terrestrial digital TV broadcasting service with the 1Seg
antenna fully pulled out.

][1Seg]/[Channel setting]

1

Point the cursor to the save destination/

2

Enjoy

[Submenu]/[Auto channel set]/[Yes]

Select an area

3

Select a prefecture/district

4

[OK]/[Yes]

5

Preset channel setting

Select a prefecture/district to use and save into the channel
list.

][1Seg]/[Channel setting]

1

Point the cursor to the save destination/

2

[Submenu]/[Preset CH setting]

Select an area

3

Select a prefecture/district

4

[OK]/[Yes]

5

Watching 1Seg

}[Activate 1Seg]

1

Setting timer for starting or recording 1Seg

][1Seg]/[Timer list]/[Submenu]/

1

[New]
[Manual input]/[Reception]/[Recording]

2

Enter/Select an item/[Complete]

3

Playing videos recorded 1Seg

][Data box]/[1Seg]

1

[Video] folder/select a video

2

72

Screen layout and operations

Data
broadcasting

Video

Caption

Icon display
position

Channel
number

Broadcast
station/
Program name

for watching screen

1Seg watching screen layout

Touch panel operations for 1Seg watching
screen

The following operations are available with keys displayed

in video mode.

X

Record 1Seg programs as a still picture

*

Meaning of main icons

Reception status of broadcast waves

bb(Strong b Weak)

Icon indicating the recording status

Operation mode

Dolby Mobile setting

Bluetooth output

Volume

b

V
W
f

[

* If you touch for a while, the recording starts.
The following touch operations are available with keys

displayed in video area.

Adjust volume Quickly slide up/down
Select a station with UP/

DOWN

Select a station with one-touch operation

Turn the volume up

Turn the volume down

Stop recording

Cancel selecting a station by searching a

frequency or with one-touch operation

Quickly slide to the left/right

Enjoy

73

Music

Handling the music data

This manual refers to Chaku-uta full® and WMA (Windows

Media Audio) files played using MUSIC Player as “music
data”.

• “Chaku-uta full” is a registered trademark of the Sony
Music Entertainment (Japan) Inc.

The FOMA terminal can play WMA files or Chaku-uta full

which are protected with copyright protection technology.

When downloading the music data from Internet web

pages, check use conditions (license, prohibited acts, etc.)

Enjoy

carefully before use.

WMA files, which are protected with copyright protection

technology, are played using the information unique to the
FOMA terminal. When the information unique to the
FOMA terminal is changed due to a failure, repair,
upgrade and others, WMA files, which are saved before
change, may not be able to be played.

DOCOMO shall not be liable for handling of CCCD (Copy

Controlled CD) or even if you cannot save music data as a
WMA file.

You can use music data saved on the FOMA terminal or

the microSD Card for personal use only. Refrain from
infringing upon intellectual property rights of a third party’s
copyrighted material. Do not copy or transfer music data
saved on the FOMA terminal or the microSD Card to PC
or any other medium.

®

74

Music&Video Channel Acquiring/Playing programs

※ The Music&Video Channel service is provided in

Japanese.

Music&Video Channel is a service that set music
programs, etc. are automatically distributed at night.

Music&Video Channel is a paid service that requires a

subscription (i-mode and the flat-rate i-mode packet
transmission service are also required to be subscribed).

A separate fee may be required in addition to

Music&Video Channel service charge.

If you insert the FOMA card to the FOMA terminal, which

does not support Music&Video Channel, after subscribing
Music&Video Channel, you cannot use Music&Video
Channel. However, a service usage fee is incurred unless
you cancel Music&Video Channel subscription.

During international roaming, setting or acquiring

programs is not available, however, packet transmission
charges are incurred for connecting to i-mode if you do so.
When going abroad, deactivate the distribution of
programs in advance.

If you cancel i-mode or Music&Video Channel or delete

My Menu registration, the program data in the Delivery
program folder may be deleted.

Acquiring programs

][MUSIC]/[Music&Video ch]/[Set

1

program]/[Yes]

Follow instructions on screen and set a

2

program

[ ] appears in the stand-by display 12 hours before

the program distribution.
The acquisition of the program is automatically
performed at night. Stock icon displayed differs
depending on whether acquisition is successful/failed
(nP.26). If it failed, acquire the program manually.

Playing programs

][MUSIC]/[Music&Video ch]

1

Select a program

2

Enjoy

75

Downloading music data from
sites

You can save Chaku-uta full® downloading from sites.

You can download up to 5 MB Chaku-uta full

While viewing sites, select Chaku-uta full

1

[Save]/select a save destination

2

Playing music data

][Data box]/[MUSIC]

1

Enjoy

Alternatively, ][MUSIC]/[MUSIC Player] to

play music data.

Creating playlists

Point the cursor to the music data/

1

[Submenu]/[Add to playlist]

®

.

®

[Add one]

2

Save

3

To create a new playlist and save: [New]/enter a

playlist name/[OK]

To add music data: Select a playlist
To overwrite music data: Point the cursor to the

playlist/[Ovrwrite]/[Yes]

Playing a playlist

76

Select music data

2

][Data box]/[MUSIC]/[Playlist]

1

Point the cursor to the playlist/[Play]

2

Screen layout and operations

Title

Artist’s name

Play time/Total time

Jacket image

Icon display
position

for MUSIC Player screen

MUSIC Player screen layout

Meaning of main icons

Playback status

Playback mode setting

Bluetooth output

Dolby Mobile setting

Volume

Touch panel operations for MUSIC Player
screen

The following operations are available with keys

displayed.

Q
N

R
J
K
O
T
U
V
W

* If you touch for a while, fast reverse/forward starts.
The following touch operations are available.

Adjust volume Quickly slide up/down
Mute/Disable Touch the volume icon
Play next song/return to

previous song (Return to
beginning of song)

Display next/previous image/
lyric

Play previous song (Return to beginning of

*

song)
Pause/Play
Play next song
Turn the volume up
Turn the volume down
Stop
Display the folder list screen
Display the list screen of music data for playback
Save an image/lyric
Display next image/lyric

*

Quickly slide to the left/right

Quickly slide to the left/right

Enjoy

77

i-appli/i-Widget

QR code to

connect to

the site

“i-appli” is software for the i-mode compatible mobile
phone. Download various software from i-mode sites for
more convenient use of the FOMA terminal, such as
updating stock prices or weather information
automatically, or enjoying games without connecting to
the network, etc.
i-Widget is a convenient function used to access to
contents (Widget Appli) such as stock prices only with
i-Widget button ([%]). You can add Widget Appli by
downloading it from sites provided by IP (Information
Provider), etc.

Packet transmission charges are incurred when

Enjoy

If the i-Widget screen is displayed, multiple Widget Appli

For use overseas, packet transmission charges differ from

Refer to “Mobile Phone User’s Guide [i-mode] FOMA

To use preset software again after deleting,

78

downloading i-appli and Widget Appli, and connecting to a
site.

may communicate. In such cases, packet transmission
charges are incurred.

those in Japan.

version” for details on i-appli/i-Widget.

you can download it from the iMenu site,
[SH-MODE] (in Japanese only).

[iMenu]/[メニューリスト]/[ケータイ電話
メーカー]/[SH-MODE]

• Packet transmission charges are incurred
when downloading.

Activating i-appli

}[Software list]

1

Select software

2

Activating Widget Appli

Activate Widget Appli. If you paste the Widget Appli on the
i-Widget screen after operations, you can use it quickly next
time.

}[%]

1

i-Widget screen appears.

Select Widget Appli

2

[Back]

3

Widget Appli is pasted on the i-Widget screen.
To end Widget Appli: [Deactivate]/[YES]

i-motion/Movie

i-motion refers to image, voice and music data. You can
download i-motion to the FOMA terminal from i-motion
compatible sites, etc. and play the downloaded i-motion.

Also, you can search for i-motion compatible sites in [メ
ニューリスト] of iMenu.

In addition, you can play movies provided in portal sites,
etc. on Internet with Internet movie player.

Internet movie player supports the playback of Windows

Media Video and Windows Media Audio.

Making a transmission with large-volume data such as

streaming type movie without download limits for Full
Browser will lead to higher packet transmission charges.

Playable i-motion

Standard type
(can be saved

Streaming type
(cannot be saved)

* Some i-motion cannot be saved.

Playable movie

Streaming type Movie is distributed in real time (live

Play during or after downloading data.

*

)

Play during downloading data.

distribution).
Movie prepared on server in advance is

distributed (on-demand distribution).

Playing i-motion/Movie

Playing i-motion downloaded from sites

While viewing sites, select i-motion

1

To save i-motion: While playing/stopping (pausing)

i-motion, [I]/[Save]/select a save destination/

[Fix]

• You can play saved i-motion using the i-motion
player.

Playing movies downloaded from sites

While viewing sites, select a movie/

1

[Yes]/[Agree]

To play movies saved to the Import folder of the

microSD Card: ][LifeKit]/[microSD]/
[Import]/[i-motion/movie]/select a movie/[Agree]

Enjoy

79

Wellness

More Convenient

Press H to switch among stand-by
display, stand-by memo display,
calendar display and wellness
display.
Quickly slide up/down to switch
among steps/distance display, firm
steps/time display and kcal/burn fat
amount display during wellness
display.

Supports your daily walking by using the pedometer. The
number of steps, burned calories, etc. are saved as a
history and you can check them in a graph format.

The measured number of steps may not be correctly

displayed depending on the way of installation, measuring
or walking.

Registering profile

][LifeKit]/[Wellness]/[Register

1

More Convenient

profile]/enter the terminal security
code/[OK]

Enter/Select an item/[Complete]

2

Using pedometer

If you set the pedometer, you can measure the number of
steps everyday and check the number of steps, the distance,
and the burned calories.

][LifeKit]/[Wellness]/[Settings]/

1

[Set pedometer]
[ON]/select the setting

2

; To check the number of steps:

][LifeKit]/[Wellness]/[Check no.

of steps]

Displaying number of steps or burned
calories in stand-by display

][Settings]/[Disp/LED/Power

1

saver]/[Stand-by settings]/[Wellness
display]/[ON]

80

Osaifu-Keitai

b mark

Osaifu-Keitai/ToruCa

Osaifu-Keitai is a function which has built-in IC card and
allows you to pay by simply holding the FOMA terminal
over the scanning device at stores.
Moreover, you can deposit electronic money and check
your balance or usage history using transmission. In
addition, Osaifu-Keitai has enough securities to use.
ToruCa is an electronic card that can be retrieved with
Osaifu-Keitai. You can use ToruCa conveniently as fliers,
restaurant cards, coupons, etc.

FOMA terminal malfunctions may cause data (including

electronic money, points, etc.) saved in the IC card to be
lost or changed (Note that as a rule, you will be asked to
delete data when leaving your FOMA terminal for repairs,
etc.). For the service such as a reissue, restoration,
temporary keeping or transfer of the data except the
transfer by iC transfer service, contact your provider of
Osaifu-Keitai compatible service. Be sure to use a service
including a backup service for important data.

DOCOMO shall not be liable for any loss or change of

data in the IC card or the damage of Osaifu-Keitai service
caused by any reason such as malfunctions and
upgrading.

When the FOMA terminal is stolen or lost, immediately

contact your provider of Osaifu-Keitai compatible service
for handling methods.

Holding b mark over scanning devices

Hold the b mark of the FOMA terminal over the scanning
device to use as electronic money or railway tickets, or
retrieve ToruCa.
Pay attention to the following points when holding the b

mark over the scanning device.
 Avoid contact between the FOMA terminal and the

scanning device

 Hold the b mark parallel over the scanning device
 Hold the b mark over the center of the scanning

device

 If the scanning device does not recognize, hold the b

mark over the scanning device and move the handset
around

 Do not attach a metallic substance on the b mark

side

More Convenient

81

i-concier

“ひつじのしつじくん®”

©NTT DOCOMO

※ The i-concier service is provided in Japanese.

“i-concier” is a service to support your life like butler or
concierge. It can keep your various data and timely
provide information tailored to your living area or current
location, or hobby and interests. i-concier information is
provided by Machi-chara (a character in the stand-by
display) in the stand-by display.

i-concier is a paid service that requires a subscription

(i-mode subscription is required).

If non-subscribers of the Data Security Service newly

More Convenient

subscribe to i-concier, they are supposed to be
subscribers of the Data Security Service.

In addition to monthly usage fees of i-concier, a separate

fee may be incurred depending on contents (information,
i-schedule, etc.).

Packet transmission charges are incurred for receiving

information excluding some cases.

Packet transmission charges are incurred for using

detailed information.

Packet transmission charges are incurred for receiving

information and viewing detailed information during
international roaming. In addition, for use overseas,
packet transmission charges differ from those in Japan.

Packet transmission charges are incurred for

automatically updating i-schedule, ToruCa, or phonebook.

Refer to “Mobile Phone User’s Guide [i-mode] FOMA

version” for details on i-concier.

82

When information is received

Receive information

1

A popup message appears in the

stand-by display.

Select the message

2

Select the information

3

Displaying i-concier screen

}[i-concier]

1

Select the information

2

Select a key to retrieve the detailed

3

information

Convenient Tools

Mainly, the following codes can be
scanned.

JAN code

QR code

Scanned result:
[4942857119022]

Scanned result:
[株式会社NTTドコモ]

Using schedules

][LifeKit]/[Classic schedule]

1

To check a schedule: Select a date/select a

schedule

[Submenu]/[New]

2

Enter/Select an item/[Complete]

3

Using alarm

][LifeKit]/[Alarm]

1

Select a save destination

2

Enter/Select an item/[Complete]

3

Using bar code reader

You can connect to i-mode or Full Browser, compose a
mail, make voice/videophone calls, compose SMS and
run i-appli with scanned text from bar codes (JAN/QR
codes).

][Camera]/[LifeKit]/[Bar code

1

reader]

[Scan]

2

Position the camera 10 cm or more from the bar code.

Use the scanned results

3

More Convenient

83

Other convenient tools

Function name Details Starting method

Column reader You can scan an article in newspaper or magazine

and compose a mail or a text memo.

Card reader You can scan a business card (Japanese/English)

and newly save to the phonebook.

Information reader You can scan information such as store name, phone

PDF Viewer You can display PDF data. ][LifeKit]/[PDF Viewer]/select a file

More Convenient

Document Viewer You can display Microsoft Word, Microsoft Excel, and

Manga&BookReader You can display e-book/e-dictionary/e-comic. ][LifeKit]/[Manga&BookReader]/

Handwriting You can compose a handwritten memo with the

number, etc. from a magazine, etc. and newly save it
to the phonebook.

image files, etc.

touch panel.

][Camera]/[Column reader]

][Camera]/[LifeKit]/[Card reader]

][Camera]/[LifeKit]/[Information reader]

][LifeKit]/[Document Viewer]/select a

file

select data

}[Handwriting]

84

Data Management

Using microSD Card

You can save data, such as the phonebook, mail or
bookmark in the FOMA terminal to microSD Card or
import data in microSD Card to the FOMA terminal.
microSD Card is sold separately.
You can purchase microSD Card and its adapter at home
electronics shops.

SH-03B is compatible with commercially available

microSD Card of up to 2 GB and microSDHC Card of up to
16 GB (as of January 2010). Refer to the following sites (in
Japanese only) for the latest information of the microSD
Card. In addition, for microSD Cards that are not provided
in the sites, some of them may not work.

From i-mode [SH-MODE] (as of January 2010)



[iMenu]

/[メニューリスト]/[ケータイ電話メーカー]/

[SH-MODE]

 From a PC

http://k-tai.sharp.co.jp/support/d/sh-03b/
Note that the provided information is the information
checked for operation. DOCOMO shall not be liable for all
operations.

Do not insert or remove a microSD Card while the FOMA

terminal is on. Data may be damaged and operation may
not work properly.

Do not remove the microSD Card or turn off the FOMA

terminal immediately after inserting the microSD Card to
the FOMA terminal, or while editing data on a microSD
Card. Data may be damaged and operation may not work
properly.

Format unformatted microSD Cards on the FOMA terminal

before use. microSD Cards formatted by PCs or other
devices may not be used properly by the FOMA terminal.

When a microSD Card used with another FOMA terminal

or PC is inserted, it may not be used.

Back up the data saved in a microSD Card and store in

another place. DOCOMO shall not be liable for any loss or
change of the saved data.

There is no guarantee for the save and copy of data since

the microSD Card which is not compatible with copyright
protection functions is unsupported by FOMA terminal.

More Convenient

85

Inserting microSD Card

Insert the microSD Card with the metal

1

terminal side turned down

Gently push the microSD Card in before removing.

More Convenient

Push the microSD Card until it clicks when inserting/

removing it.

Note that excessive force may damage the FOMA

terminal or microSD Card.

Keep your face away from microSD Card when inserting

or removing card. When taking your fingers off abruptly,
card may pop out.

Formatting

][LifeKit]/[microSD]/[Format]

1

Enter the terminal security code/[OK]/

2

[Yes]

Note that all the data on the microSD Card is deleted

when formatted.

Displaying data

][LifeKit]/[microSD]/[View

1

microSD data]

Select data

2

Copying data to microSD Card

Example: i-motion

][Data box]/[i-motion/Movie]

1

Point the cursor to i-motion/

2

[Submenu]/[Move/Copy]/[Copy to
microSD]

[Copy one]/point the cursor to the copy

3

destination folder/[Fix]

Backing up data to microSD Card

You can collectively backup phonebook, mail, schedule,
bookmark, text memo, settings and information of the FOMA
terminal to microSD Card.

][LifeKit]/[microSD]/[Backup/

1

recovery all]/[Backup to microSD]
Enter the terminal security code/[OK]/

2

[Yes]

86

Bluetooth function

You can connect the FOMA terminal to Bluetooth devices
wirelessly.

Wireless communications with all the Bluetooth devices

are not completely guaranteed.
Electromagnetic signals from the Bluetooth device may
affect the operation of electronic medical equipment. As
some cases may result in accident, turn off the FOMA
terminal and other Bluetooth devices in the following place.

 On trains  On airplanes  In hospitals
 Nearby automatic doors or fire alarms
 In places such as gas stations where flammable gas is

generated

Registering Bluetooth devices

Switch the other party’s Bluetooth device to the

registration stand-by status in advance.

][LifeKit]/[Bluetooth]/[List/cnnct/

1

discnnct]/[Yes]

Point the cursor to the Bluetooth device to

2

register/[Submenu]/[Register Devices]
Enter the Bluetooth passkey/[OK]

3

Enter the same user-specified 4- to 16-digit number

on the FOMA terminal and the other party’s Bluetooth
device.

Entering the Bluetooth passkey may not be required

depending on the other party’s Bluetooth device.

Connecting to registered Bluetooth devices

][LifeKit]/[Bluetooth]/[List/cnnct/

1

discnnct]

Select a Bluetooth device to connect to

2

Setting registration stand-by/connection
stand-by

Set to receive a registration request/connection request from
other Bluetooth devices in the stand-by display.

][LifeKit]/[Bluetooth]/[Accept

1

Registered]

To select a service to set to connection stand-by:

Point the cursor to [Accept Registered]/[Type]/
select a service/[Confirm]

Turn off the Bluetooth power to disable the stand-by

status.

Turning on/off Bluetooth power on the
FOMA terminal

If the Bluetooth power is turned off, all services being

connected or in connection stand-by stop. If the Bluetooth
power is turned on, services previously connected or in
connection stand-by, or some services which have been
connected are set to connection stand-by.

{[Bluetooth]/[Yes]

1

More Convenient

87

Sending and receiving data via

Infrared port

Approx. 20 cm

or less

b mark

Ir communication

15°

15°

More Convenient

Face the infrared ports of the receiver’s and sender’s

FOMA terminal each other and set the distance between
them to approximately 20 cm or less.

Sending data

Point the cursor to data/[Submenu]/

1

[Send data]/[Send Ir data]/[Send]/
[Yes]

Receiving data

][LifeKit]/[Receive Ir data]/

1

[Receive]/[Yes]/[Yes]

88

Sending and receiving data via
iC communication

Use while placing the b mark of receiver’s FOMA

terminal on that of sender’s FOMA terminal.

Sending data

Point the cursor to data/[Submenu]/

1

[Send data]/[iC transmission]/[Send]/
[Yes]/place the b marks together

Receiving data

^place the b marks together

1

[Yes]

2

Support

Others

Troubleshooting

First, check whether the software update is required. If it is required,

update the software (nP.92).
If there is no improvement in problems even after checking the
following items, feel free to contact the number listed in “Repairs” (in
Japanese only) on the back of this manual, or a repair center that
DOCOMO specifies.

Power

The FOMA terminal is not turned on

Is the battery pack attached properly? P.21
Make sure the battery has not run out. –

Charging

Cannot charge the battery (Charging LED does not illuminate, or
it flashes)

Is the battery pack attached properly? P.21
Is the adapter power plug inserted into the outlet or

cigarette lighter socket properly?

Are the adapter and the FOMA terminal set properly? P.22
When using the AC adapter (sold separately), is the

connector of the AC adapter properly connected to the
FOMA terminal or the desktop holder (sold separately)?

When using the desktop holder, make sure the charger

terminal of the FOMA terminal is not dirty. If the terminal
becomes dirty, clean it with a dry cloth or cotton swab.

P.22

P.22

–

If calling, transmitting, or another function is performed

for a long time with charging, the FOMA terminal may
become warm and charging LED may flash. Charge
again after the terminal temperature lowers.

Terminal operation

Becomes hot while operating/charging

Temperature of the FOMA terminal, battery pack, or adapter
may rise while operating or charging, or when performing
i-

a

ppli, making a videophone call, or watching 1Seg for a

long time with charging. There is no safety hazard.

Battery usage time is short

Make sure the battery pack is not left for a long time

outside the service area.
Outside the service area, since electric waves are
searched to make transmission available, more electric
power than usual is used.

The usage time for the battery pack depends on the

usage environment and deterioration level.

Battery pack is a consumable product. Service time per

charge is gradually reduced every time the battery is
charged.
Purchase a specified new battery pack if the usage time
becomes extremely shorter than when the battery was
purchased even after fully charged.

Power turns off/The FOMA terminal restarts

Unclean terminals for the battery pack may result in poor

connections and loss of power. Wipe with a dry cloth or a
cotton swab.

Make sure the IC portion of the FOMA card is not dirty. –

–

–

–

–

–

–

Others

89

Not activated by touching or pressing keys

Make sure All lock is not set. P.48
Make sure Touch panel/Key lock is not set. P.48
Make sure the FOMA terminal is not turned off. P.23

FOMA card does not recognize

Is a FOMA card inserted facing right direction? P.21
Make sure the FOMA card (blue) is not inserted. P.21

Calling

Calls cannot be made with the dial

Make sure All lock is not set. P.48
Make sure Touch panel/Key lock is not set. P.48
Make sure Keypad dial lock is not set. P.48
Make sure self mode is not set. P.48

Connection cannot be made ([ ] does not disappear even after
moving to another place, or calls cannot be made/received even
though signal status is not bad)

Turn the power on again, or attach the battery pack or

FOMA card again.

Depending on the signal type, even though status is

“inside the service area” or “[ ] (indicating signal
status) appears”, making/receiving a call may not be
available. Move to another place and call again.

Make sure Accept calls/Reject calls is not set. –

Others

In crowded place, heavy telephone/mail traffic may be

caused and make it difficult to get a connection. In such
case, [Please wait] appears and a busy signal is played.
Move to another place or call again later.

P.21
P.23

–

–

Osaifu-Keitai

Cannot use Osaifu-Keitai

If the battery pack is removed or Omakase Lock is

activated, IC card functions are not available regardless
of the IC card lock setting.

Make sure IC card lock is not set. P.48
Is the b mark of the FOMA terminal held over the

scanning device?

P.48

P.81

Warranty and After-Sales Service

Warranty

Make sure that the warranty card is included with your FOMA

terminal at the time of purchase. Check that the name of the
retailer, the date of purchase, and the necessary details have been
filled in on the warranty card. Be sure to keep it in a safe place.
Contact the retailer if any necessary details on the warranty card
are not completed.
The warranty period without charge is 1 year from the date of
purchase.

For the purpose of improvement, the specifications for this product

and its accessories are subject to complete or partial change
without prior notice.

After-Sales Services

If you have problems with your FOMA terminal

Refer to “Troubleshooting” in this manual or “Support Book” (in
Japanese only) contained in the FOMA terminal before requesting
repairs.
Contact the number listed in Repairs (in Japanese only) on the back of
this manual if problems persist.

90

If your FOMA terminal needs repairs after

技術基準適合認証品

contacting DOCOMO

Bring your FOMA terminal to a repair counter that DOCOMO specifies.
However, the repair shop is only open during business hours. Note that
it may take several days to repair depending on the damaged condition.

During the warranty period

The FOMA terminal will be repaired without charge in accordance

with the terms of the warranty.

When bringing the FOMA terminal in for repairs, be sure to bring the

warranty card. Even during the warranty period, a fee will be
charged for repairs of malfunctions or damage caused by your
improper handling (damage of LCD and connector), or when no
warranty certificate is presented.

Repairs for damages caused by the use of devices and accessories

other than those specified by DOCOMO will also incur a fee, even
during the warranty period.

Repairs may not be possible in the following circumstances.

When a repair counter considered water exposure (Example: When

the moisture detection seal has reacted)

As a result of inspection, when damage from water exposure,

condensation, sweat, or other liquids are found, or when the internal
circuit board is damaged or deformed (Repairs may not be possible
when external connector terminal (earphone/microphone terminal),
LCD, etc. is damaged, or when a housing is cracked)

※ Even when repairs are possible, repair charges will be incurred

because the warranty does not cover such damage.

After the warranty period has expired

Charged repairs will be carried out upon request.

Replacement parts

Replacement parts (required to maintain the functionality of the FOMA
terminal) will be kept in stock basically for 6 years following production.
However, note that there may be a case when repair is not possible for
the shortage of replacement parts depending on the faulty part.

IMPORTANT!

Never attempt to modify the FOMA terminal or its accessories.



Repairs may be refused depending on the extent of the modification.
The following cases may be considered as a modification.

• Stickers are applied to the LCD or keys

•

Decorations are made to the FOMA terminal with adhesive agent

• Exterior parts are replaced with those which are not standard
DOCOMO product

 Repairs for any malfunction or damage caused by such

modifications will incur fees, even during the warranty period.

Do not peel off the model nameplate attached to the FOMA terminal.



If the nameplate seal does not function as a certification, repairs may
be refused because conformity to the standards cannot be determined.

Information stored in your FOMA terminal, such as the settings of

various functions and the total call duration, may be cleared or reset
if your FOMA terminal is damaged, repaired, or mishandled.



If this occurs, please re-enter the information or re-specify the settings.

The following sections of the FOMA terminal contain parts that

generate magnetic waves. Keep ATM cards and other objects likely
to be affected by magnetic waves away from the FOMA terminal.
Cards may become unusable.
 Sections: speaker, mouthpiece
If the FOMA terminal gets wet or becomes moist, immediately turn off
the power and remove the battery pack. Then, visit a repair counter.
The FOMA terminal may not be repaired depending on its condition.

Others

91

Others

QR code to

connect to

the site

92

i-mode fault diagnosis site

※ The i-mode fault diagnosis site is only available in Japanese.

You can check whether the FOMA terminal can normally send and
receive mails, download images or melodies or perform other
operations. When a malfunction is found after checking, contact
the number listed in “Repairs” (in Japanese only) on the back of
this manual.

Accessing the “i-mode fault diagnosis site”

i-mode site: [iMenu]/[お知らせ]/[サービス・機能]/
[ｉモード]/[ｉモード故障診断]
Packet transmission charges are not incurred for the

i-mode fault diagnosis.

• Access from abroad is charged.

Updating software

You can update software if the FOMA terminal software
need to be updated using packet transmission.

※ Packet transmission charges are not incurred.

Check the DOCOMO website or “お客様サポート” (user
support) (in Japanese only) on iMenu for updates. When

updating, select “Auto-update”, “Now update” or
“Reserve”.

You can update software even if the FOMA terminal

contains phonebook, camera image, downloaded data,
etc. However, DOCOMO cannot protect some data that
could be lost due to malfunction, damage, water exposure
and so on. It is recommended that important data be
backed up before updating. Note that some data, such as
downloaded data, cannot be backed up.

Using software update

Do not remove the battery pack while the software is

updating. Failure to update software may occur.

Recharge battery before updating software.
Updating (downloading and rewriting) software may take

time.

Making/Receiving calls, transmission functions and other

functions cannot be used while software is being updated
(Receiving voice calls is possible during download).

It is recommended to update software at a location with a

strong signal (three bars for the antenna icon) and you are
not moving. If signal status becomes weak or download is
interrupted when downloading software, update software
again in a location with good signal conditions.

When updating software, the information unique to the

FOMA terminal (model, serial number, etc.) is
automatically sent to the server (DOCOMO software
update server). Sent information is only used for software
update.

If software update fails, [Rewrite failed] appears and all

operations are not available. In this case, bring the FOMA
terminal to a repair center that DOCOMO specifies.

Updating software is not available overseas.

Starting software update from stock icon

When the software is automatically downloaded, the stock
icon appears in the stand-by display (nP.26).

^select the stock icon [6] (Update

1

required)

[OK]

2

To set the day of week and time: [Change]
To rewrite immediately: [Now rewrite]

Starting software update from menu screen

][Settings]/[General settings]/

1

[Software update]
Enter the terminal security code/[OK]/

2

[Set auto-update]

Select the update method

3

Checking harmful data

Delete or stop activating any data or applications that
could cause operational malfunctions. These types of
data include data or programs that are downloaded to the
FOMA terminal.

The scan function helps to protect the handset from

damage caused by data such as data received from web
pages or mails. If the pattern definition corresponding to a
particular harmful file is not downloaded or saved, the
scan function will not be able to protect the FOMA
terminal.

Pattern definitions vary depending on the phone model.

Therefore, DOCOMO may discontinue offering pattern
definitions for a particular model 3 years after the release
date.

Updating pattern definitions

First, update pattern definitions to bring them up-to-date.

][Settings]/[General settings]/

1

[Scanning function]/[Update]/[Yes]/
[Yes]

[OK] when updating is completed

2

Others

93

Displaying scanned results

Displaying detected errors

If you select [Detail] in the warning screen, error names appear. When no error name exists for the

contents of the pattern data, [Detail] does not appear.

Up to five error names appear. [Etc] appears below the fifth error name when six or more are detected. If

same error is detected more than once, it is only listed once.

Displaying scanned results

Level 0 Level 1 Level 2 Level 3 Level 4

[Agree]: To display/
activate/call

Others

94

[Yes]: To cancel
[No]: To display/
activate/call

[Agree]: To end [Yes]: To the delete

confirmation screen
[No]: To end without
deleting

[Agree]: To delete the
data

Introduction of options and
related devices

Combine the FOMA terminal with various optional
accessories (sold separately) for expanded personal and
business use.
Some products may not be available in certain areas.
Contact a docomo Shop or retailer for details.
Refer to the user’s guide of each product for more
details.

FOMA AC Adapter 01
Battery Pack SH21
Back Cover SH36
Desktop Holder SH30
Earphone Terminal P001
Flat-plug Stereo Earphone Set P01
Flat-plug Earphone/Microphone with Switch P01*3/P02
Stereo Earphone Set P001
Earphone/Microphone with Switch P001*2/P002
Earphone/Microphone 01
Stereo Earphone/Microphone 01
Earphone Plug Adapter P001
Earphone Plug Adapter for External connector terminal 01
Earphone Plug Adapter 01
FOMA USB Cable
Wireless Earphone Set 02
FOMA AC Adapter 01 for Global use 01
FOMA DC Adapter 01/02
FOMA Indoor Booster Antenna
In-Car Hands-Free Kit 01

*1

*1

/02

*2

*3

*2

*3

*4

*1

*5

*6

*3

*2

FOMA In-Car Hands-Free Cable 01
In-Car Holder 01

*7

FOMA Dry Battery Adapter 01
Carry Case L 01
Bone conduction microphone/receiver 01
FOMA USB Cable with Charge Function 02
FOMA Portable Charging Adapter 01
FOMA Indoor Booster Antenna (Stand Type)

*3

/02

*4

*5

*1 Refer to P.22 for details on charging with an AC adapter.
*2 Connect Earphone Plug Adapter for External connector

terminal 01 and Earphone Plug Adapter to use these
options and related devices.

*3 Connect Earphone Plug Adapter for External connector

terminal 01 to use these options and related devices.
*4 The use of USB HUB may prevent working correctly.
*5 For use only in Japan.
*6 FOMA In-Car Hands-Free Cable 01 is required to charge

SH-03B.
*7 Activate Touch panel/Key lock to use the In-Car Holder

01.

Others

95

Appendix

Menu list

When settings are reset (nP.49), functions return to default

settings (marked with ).

• Some items may include functions which do not return to default
settings.

Custom menu/Basic menu/Horizontal menu
list

Depending on the Kisekae tool set in the custom menu, the function

names may differ from those described.

i-mode menu

i-mode

iMenu/Search
Bookmark
Screen Memo
Last URL
Enter URL Enter URL

Others

i-Channel Run i-Channel list

i-mode setting i-mode Browser Set.

96

URL enter history

i-Channel ticker
Reset i-Channel

Full Browser Set.
Common Settings
Check i-mode setting
Reset i-mode setting

i-mode

RSS reader
Full Browser Home

i-appli menu

i-appli

Software list
i-appli call logs
i-appli setting i-appli volume

Software info
Auto start
Power saver set
i-appli call DL
i-Widget roaming
i-Widget sound fx
AUTO-GPS pref

Used by i-appli
Info Auto start error

Force quit history
Security error
Trace info

Camera menu

Camera

Shoot still pic
Shoot movie
Pretty arrange cam
Column reader
Bar code reader
Card reader
Information reader
Motiondeco
Shotdeco
Cameraloupe

Mail menu

Mail

Inbox
Outbox
Unsent messages
Compose message
Compose Decome-Anime
Compose SMS
Template Decome-Template

Decome-Anime Template
Check new messages
Check new SMS
Receive option Receive option

Receive opt. set

Mail

Mail setting Quick reply mail

Rcv attached file
Melody Auto replay
Font size setting
Rcv/Auto send disp
Check new message
Direct detail disp
Auto message display
Receive opt. set
Blog/SNS settings
Mail member
Save signature
Mail ticker set
SMS setting
Area Mail setting
Auto save at edit
Mark read after pv
Check mail set
Reset mail settings
Secret mail settings
Address/Spam Mail Settings

Others

97

Settings menu

Snd/Vibrator/Manner Select volume

Disp/LED/Power saver Stand-by settings

General settings Check status

Others

Settings

Select sound

Vibrator

Manner mode

Quick silent

Headset setting

Ring time setting

Set mute ring time

Hold/On hold tone

Sound playback

Font style

Color/Graphic set

LED settings

Display img quality

Light/Power saver

VeilView

Menu priority

Text input setting

Auto power ON/OFF

Date settings

Select language

Panel unlock set

USB mode setting

Scanning function

Software update

Reset settings

Settings

NW Services Voice Mail

Call waiting
Call Forwarding
Nuis. call blocking
Notify caller ID
Caller ID request
Talk time/cost
2in1 setting
In-call arrival act

Other NW Services Remote access

Dual network
English guidance
Contact DOCOMO
Additional service
Multi number
Chaku-moji
Roaming guidance

Phone settings In-call settings

Headset sw to call
Incoming settings
Videophone set
Record message
Setting when slid
Self mode
Femtocell setting
Other settings

98
