DoCoMo p-10A User guide

P-10A

ISSUE DATE:

NAME:

PHONE NUMBER:

MAIL ADDRESS:

INSTRUCTION MANUAL

‘09.5

Easy Search/Contents/Precautions

Before Using the Handset

Voice/Videophone Calls

Phonebook

Sound/Screen/Light Settings

Security Settings

Mail

i-mode/i-motion/i-Channel/i-concier

Full Browser/PC Movie

Camera

1Seg

Music

i-αppli

Osaifu-Keitai/ToruCa

Data Management

Convenient Functions

Character Entry

Network Services

Overseas Use

PC Connection

Appendix/Troubleshooting

Index/Quick Manual

DOCOMO W-CDMA System

Before using your FOMA terminal

Thank you for selecting the “docomo STYLE series P-10A”.

Before or during use of the P-10A, make sure that you read this manual and the
separate manuals for other optional devices thoroughly so that you can use the
P-10A correctly.
If you feel any inconvenience in reading the manual, contact the docomo
Information Center listed on the back page of this manual.
The P-10A is designed to be your close partner. Treat it carefully at all times to
ensure long-term performance.

●Because the FOMA terminals use radio waves, they cannot be used in places

where radio waves do not reach, such as inside tunnels, underground, or in
buildings; or the outside where radio waves are weak or out of the FOMA
service area. They may not be used in the high-rise buildings even when the
antennas are unobstructed. You may also experience interruption of calls
even when using without moving while the radio waves are strong enough for
the three antennas to appear on the display.

●Use the FOMA terminal carefully to avoid disturbing other people when in

public, or in crowded or quiet places.

●Since the FOMA terminals use radio waves as the medium of

telecommunication, calls may be tapped by the third party.
However, the W-CDMA system automatically supports tapping prevention, so
your conversation will be incomprehensible to the third party, because it is
recognized as mere noise.

●The FOMA terminals change your voice into digital signals and send them to

the other party. In places where the radio waves are weak, the digital signals
may not be converted correctly, and in such a case, the voice may sound
different from the actual original voice.
The user hereby agrees that the user shall be solely responsible for the result

●

of the use of SSL. Neither DOCOMO nor the certifiers as listed herein make
any representation and warranty as for the security in the use of SSL. In the
event that the user shall sustain damage or loss due to the use of SSL, neither
DOCOMO nor the certifiers shall be responsible for any such damage or loss.
Certifiers: VeriSign Japan K.K., Cybertrust Japan Co., Ltd., GlobalSign K.K.,

RSA Security Japan Ltd., SECOM Trust Systems Co., Ltd., and

●This FOMA terminal supports FOMA Plus-Area and FOMA High-Speed Area.

●The FOMA terminal can be used only via the FOMA network provided by

Comodo CA Ltd.

DOCOMO and in DOCOMO’s roaming area.

●It is recommended that you make separate notes of the information (such as

Phonebook entries, schedule events, text memos, record messages, voice
memos, movie memos) stored in the FOMA terminal and keep them in a safe
place. Note that we cannot be held responsible for the unlikely event of loss of
the stored contents due to a malfunction, repair, change of your model, or
other mishandling of the FOMA terminal.

●You are advised to save your important data files to the microSD card. If you

have a personal computer, you can transfer and save the information such as
Phonebook entries, mail messages, schedule events, and others to the
personal computer by using DOCOMO keitai datalink.

For Using This Manual

This FOMA terminal supports Kisekae Tool (page 111).
If you use Kisekae Tool to change the design of the Menu display,
some menu configurations change according to the usage
frequency depending on the type of the menu. Further, some menu
numbers that are assigned to the menu items do not apply.

You can download the latest information about this manual
from the following DOCOMO website:

・User’s Manual (PDF file) Download

(http://www.nttdocomo.co.jp/english/support/manual/index.html)

※The URL and the content of the website might be modified

without notice.

Easy Search/Contents/Precautions

Search from the index when you know the names of functions or services.

Search from keywords for the functions you frequently use or the functions that are
convenient if you can know any.

Search from the tabs printed on the cover.

See the next page for details.

Search from the contents that categorize functions.

Search from here to use the main functions.

Search from the function list.

Quick Manual gives you a clear, brief description about basic functions. You can take it
when you go out. Further, Quick Manual “For Overseas Use” is attached, so refer to it
when you use the FOMA terminal overseas.

From the Index

From Easy Search

From the Tabs on the Cover

From the Contents 11P.6

From the Main Functions 11P.8

From the Function List 11P.434

From Quick Manual 11P.510

It is prohibited to copy all or part of this manual without permission.
The instructions contained in this manual may be changed without notice.

Viewing/Searching This Manual

In this manual, illustrations and symbols are used in the explanations so
that you can correctly and easily use the FOMA terminal.

≥The most operating procedures and displays in this manual are described with the

default settings of the “GOLD” handset (see page 434). However, the following settings
are changed.

・“Display setting” → “Stand-by display/Stand-by disp. Wide”: OFF
・“Display setting” → “Clock” → “Stand-by clock/Stand-by clock Wide”

→ “Position”: Pattern 1

≥The most operating procedures and displays in this manual are described in the state

of Normal Style. In Horizontal Open Style, you can operate in the same way as in
Normal Style. See page 29 and page 30 for the operations in Horizontal Open Style.

≥Displays and illustrations described in this manual are for reference. The actual ones

might differ.

≥In this manual, “Osaifu-Keitai compatible i-αppli which supports the IC card function” is

described as “Osaifu-Keitai compatible i- αppli”.

≥Note that “P-10A” is referred to as “FOMA terminal” in this manual.
≥In the operating procedures of this manual, key operations are described with

simplified key icons.

≥The functions which use a microSD card are described in this manual; however, you

need to obtain a microSD card separately to make these functions available. See
page 335 for the microSD card.

How to Refer to This Manual

By the following search methods, you can find pages where your desired
functions and services are described:

Easy Search/Contents/Precautions

1

How to search for “Alarm” is explained here as an example of search method.

Additional guidance. . . . . . . . . . .415

Address link function . . . . . . . . . . .198

After-sales services . . . . . . . . . . . . 479

Alarm . . . . . . . . . . . . . . . . . . . . . . .368

Alarm setting. . . . . . . . . . . . . . . . . . 377

Answer setting . . . . . . . . . . . . . . . . .70

Antenna . . . . . . . . . . . . . . . . . . . . . .27

From the Index

11P.502

Search for a function or a service
name as shown on the right.

Search for the functi on you
frequently use or that is
convenient if you know any as
shown on the right.

Other things you can do

To reduce the battery consumption ..............................<Power Saver Mode> 108

To scan QR codes or bar codes ......................................<Bar Code Reader> 238

To listen to music.................................................................. <MUSIC Player> 270

To use the microSD card...................................................... <microSD Card> 335

To exchange information using infrared rays.........<Infrared Communication> 349

To use the FOMA terminal as an alarm clock.....................................<Alarm> 368

To use the FOMA terminal as a calculator ..................................<Calculator> 382

To use the F

OMA terminal overseas........................ <International Roaming> 418

To update software programs........................................... <Software Update> 481

To update security .........................................................<Scanning Function> 486

Go to page 368
where “Alarm”
is explained.

From Easy Search

11P.4

i-αppli

Osaifu-Keitai/ToruCa

1Seg

Data Management

Music

Convenient Functions

Character Entry

Network Services

PC Connection

Overseas Use

Appendix/Troubleshooting

Multitask . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <Multitask> 365

Informing You of an Incoming Call/Mail Message by Voice

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <Reading Aloud> 366

Turning Power On/Off Automatically at a Specified Time

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <Auto Power ON/OFF> 368

Using Alarm. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <Alarm> 368

Using Calendar to Manage Schedule . . . . . . . . . . .<Schedule> 371

Using ToDo to Manage Schedule . . . . . . . . . . . . . . . . . <ToDo> 375

Setting Operating Conditions of Alarm . . . . . <Alarm Setting> 377

From the Tabs on the
Cover

11Cover page

Search for the function you want
to set in the order of “Cover”

→ “First page of Chapter”
→ “Description page” as shown

on the right.

Easy Search/Contents/Precautions

2

Easy Search/Contents/Precautions

368

Convenient Functions

You can set Alarm to alert you at the specified time with an alarm tone,
animation and illumination. You can store up to 12 alarms.

1

mStationeryAlarmHighlight an
alarm and press l()

Do the following operations.

2

Press l().

+m-4-4

<Alarm>

Using Alarm

Alarm You can set whether to validate or invalidate the alarm.

ON or OFF

Time Enter the time for sounding the alarm.

pYou cannot set the same time as the time set for the stored

alarm.

Tone Select a type of alarm toneSelect a folder

Select an alarm tone.

Volume Use Bo to adjust the volume.

pIf you set “Step”, the alarm tone is silent for about three

seconds, and then the volume steps up every about three
seconds, from Level 1 through Level 6.

Prefer manner

mode

You can set the alarm tone which sounds at the specified time
during Manner Mode.

ON or OFF

ON. . . . . Sounds at the same volume as set for “Alarm volume”.

OFF. . . . Sounds at the volume set for this function.

The icon appears on the Stand-by display.
“” . . . Displayed when an alarm is set for today (except the setting for past time).

“” . . . Displayed when an alarm is set for tomorrow or onward only.
pIf you set “Alarm” of a schedule event/ToDo item to “OFF”, the icon is not displayed.

Function Menu while Alarm is Displayed

Edit Go to step 1 of “Using Alarm” on page368.

Detail You can display the stored alarm contents.

Set this You can validate the stored alarm.

YES

pYou can validate also by pressing Oo().

Set all You can validate all the stored alarm.

YES

Delete

Delete this YES

Delete all Enter you Terminal Security CodeYES

Information

pIf the alarm tone sounds during a call, press any key to stop it. Once again press any

key to end the alarm including Snooze. If the other party on the phone hangs up, an
alarm including Snooze ends.

pDuring a call, the alarm tone sounds at the level set for “Volume” (earpiece volume).
pTurn off the FOMA terminal after setting “Auto power ON” to “OFF” when you are near

electronic devices using high-precision control or weak signals, or where the use is
prohibited such as in airplanes and hospitals.

When you set an alarm for “Alarm”, “Schedule”, and “ToDo”

Note: The page above is a sample.

Menu number
(See page 39)

Function name
You can find this in
Index.

Operating
procedure
(See page 38)

Reference display
(Characters and settings
are for reference.)

Options and their
explanations

Items shown on the
display
(Some items cannot
be executed.)

Operation and
supplementary
explanation for each
item

Operations related to
the function and
explanations for
supplementary
operations

Chapter title

You can
search by
chapter.

Cautions or
references for using
each function

Lower sub-menu item
of the Function menu

3

Easy Search

To retrieve a desired function with simple words, refer to the following:

To know convenient functions for making calls

To/Not to notify your phone number to the other party

....................................................................................<Caller ID Notification> 51

To switch to a videophone call during a voice call

...........................................................................<Switch to Videophone Call> 57

To change a volume level of the other party’s voice....................... <Volume> 71

To put a call on hold during a call.................................................... <Holding> 72

To do the following when you cannot answer calls

To put an incoming call on hold before answering......................... <On Hold> 72

Easy Search/Contents/Precautions

To convey the message that you need to refrain from talking on the phone

.....................................................................Using Public Mode (Drive Mode) 73

....................................................................... Using Public Mode (Power Off) 74

To record voice/video messages..........................<Record Message Setting> 75

To change melody or illumination

To adjust the ring volume........................................................<Ring Volume> 72

To change ring tones according to callers......................<Add to Phonebook> 84

To change ring tones........................................................<Select Ring Tone> 98

To know incoming calls by vibrator .................................................<Vibrator> 100

To mute the keypad sound...................................................<Keypad Sound> 101

To activate Manner Mode...................................................... <Manner Mode> 102

To change colors/lighting patterns of Call indicator for incoming calls

.................................................................................................. <Illumination> 112

To change/know display settings

To know the meaning of marks (icons) on the display .....................<Display> 32

To change the Stand-by display (Wallpaper) ...................... <Display Setting> 105

To display a calendar on the Stand-by display..............................<Calendar> 105

To change the menu display .......................................... <Menu Icon Setting> 110

To change the font size ................................................................<Font Size> 115

To make full use of mail

To send Deco-mail ...................................................................... <Deco-mail> 139

To send images ....................................................................... <Attachments> 146

To sort and save mail automatically ..............................................<Auto-sort> 165

To make full use of camera

To change the shooting size...................................................... <Image Size> 234

To save to the microSD card ...........................................................<Store In> 235

To display shot images......................................................... <Picture Viewer> 312

4

Easy Search/Contents/Precautions

To use the FOMA terminal with a sense of security

To lock the FOMA terminal from away when it gets lost

.........................................................................................<Omakase Lock>※1121

To keep Phonebook entries from prying eyes......................... <Secret Mode> 126

To reject calls without a caller ID.............................. <Call Setting without ID> 128

To reject calls from the phone numbers that are not

in the Phonebook ............................................................<Reject Unknown> 129

To separately store Phonebook and other data

files in preparation for their erasure.................... <Data Security Service>※2130

※1 This is a pay service.
※2 This is a pay service which is available on a subscription basis.

To make full use of 1Seg

To watch 1Seg programs ...................................................... <Activate 1Seg> 245

To record 1Seg programs.................. <Record Video> <Record Still Images> 252

To set TV Timer/Timer Recording for 1Seg programs

.......................................................................<TV Timer> <Timer Recording> 253

To change settings of video and audio...................................<User Settings> 258

Other things you can do

To reduce the battery consumption .............................. <Power Saver Mode> 108

To scan QR codes or bar codes ...................................... <Bar Code Reader> 238

To listen to music.................................................................. <MUSIC Player> 270

To use the microSD card ...................................................... <microSD Card> 335

To exchange information using infrared rays.........<Infrared Communication> 349

To use the FOMA terminal as an alarm clock.....................................<Alarm> 368

To use the FOMA terminal as a calculator ..................................<Calculator> 382

To use the FOMA terminal overseas ........................<International Roaming> 418

To update software programs........................................... <Software Update> 481

To update security ......................................................... <Scanning Function> 486

≥The operating procedures for frequently used functions are summarized in Quick

Manual. (See page 510)

5

Contents

Viewing/Searching This Manual . . . . . 1

Easy Search . . . . . . . . . . . . . . . . . . . . . . 4

Contents . . . . . . . . . . . . . . . . . . . . . . . . . 6

Main Functions of P-10A. . . . . . . . . . . . 8

Precautions. . . . . . . . . . . . . . . . . . . . . . 10

Before Using the

Handset

25

Voice/

Videophone Calls

53

Easy Search/Contents/Precautions

Phonebook

83

Sound/Screen/

Light Settings

97

Part Names and Functions, Styles, Display,
Desktop Icon, Selecting Menu, Guide,
UIM (FOMA Card), Battery, Charging, Power ON/OFF,
Select Language, Set Time, Caller ID Notification,
Own Number, etc.

Making a Call/Videophone Call, Call Records,
Chaku-moji, WORLD CALL, Hands-free,
Receiving a Call/Videophone Call, Volume, Ring Volume,
Public Mode, Record Message Setting, Chara-den, etc.

Available Phonebooks,
Add to Phonebook (FOMA terminal/UIM),
Group Setting, Search Phonebook, Edit Phonebook,
Delete Data, No. of Phonebook, 2-touch Dial,
Voice Dial

Select Ring Tone, Vibrator, Manner Mode,
Display Setting, Backlight, Menu Icon Setting,
Kisekae Tool, Set to Machi-chara,
Horizontal Open Menu, Illumination, Font, etc.

Handling Precautions . . . . . . . . . . . . 16

Waterproof Performance . . . . . . . . . 19

Basic Package and Main Options . . . 23

Mail

135

i-mode/i-motion/

i-Channel/i-concier

183

Full Browser/

PC Movie

209

Camera

225

1Seg

241

i-mode Mail, Deco-mail, Decome-Anime, Template,
Attachments, Mail Auto-receive, Receive Option,
Check New Messages, Message R/F,
Early Warning “Area Mail”, Chat Mail, SMS, Web Mail,
etc.

i-mode, iMenu, My Menu,
Change i-mode Password, Enter URL, Bookmark,
Screen Memo, Download, Upload, Certificate, i-motion,
i-Channel, i-concier, etc.

Full Browser, Full Browser Settings, PC Movie,
Downloading PC Movies, PC Movie Player

Before Using Camera, Still Image Shoot, Movie Shoot,
Settings for Shooting, Setting Image Size/Image Quality,
Bar Code Reader

1Seg, Before Using 1Seg, Channel Setting,
Activate 1Seg, i-αppli Program Guide,
Data Broadcasting, TVlink, Recording 1Seg,
TV Timer/Timer Recording, User Settings

Security Settings

117

6

Security Codes, Change Security Code,
Releasing PIN Lock, Lock All, Omakase Lock,
Self Mode, Personal Data Lock, Keypad Dial Lock,
Secret Mode, Call Setting without ID, Reject Unknown,
Reset Settings, Initialize, etc.

Music

261

Music&Video Channel, Set Program,
Playing/Operating Programs, Playing Music,
Saving Music Files, MUSIC Player, Playlist

i-αppli

281

Osaifu-Keitai/

ToruCa

297

Data Management

309

Convenient

Functions

363

Character Entry

387

Network Services

397

i-αppli, i-αppli Download, i-αppli Run, iαppli Settings,
Starting i-αppli Automatically, i-αppli Stand-by Display,
iαppli Data

Osaifu-Keitai, iC Transfer Service, IC Card Content,
IC Card Lock, Check IC Owner, ToruCa,
Receive ToruCa Files, ToruCa Viewer,
ToruCa File List/Detailed ToruCa File Display,
ToruCa Settings

Picture Viewer, i-motion Player, Video Player,
Chara-den, Machi-chara, Melody Player, Kisekae Tool,
microSD Card, Voice Recorder, PDF Viewer,
Document Viewer, etc.

Multiaccess, Multitask, Reading Aloud,
Auto Power ON/OFF, Alarm, Schedule, ToDo,
Multi Key Long Press Setting, Own Number,
Voice Memo, Movie Memo, Call Data, Calculator,
Text Memo, UIM Operation, etc.

Character Entry, Mode 1 (5-touch), Common Phrases,
Cut/Copy/Paste, Own Dictionary, Learned Words,
Download Dictionary, Mode 2 (2-touch),
Mode 3 (NIKO-touch)

Check New Messages, Voice Mail, Call Waiting,
Call Forwarding, Nuisance Call Blocking,
Caller ID Request, Dual Network, Service Numbers,
Remote Control, Multi Number, 2in1, OFFICEED, etc.

Overseas Use

417

PC Connection

427

Appendix/

Troubleshooting

433

Index/

Quick Manual

501

Outline of International Roaming (WORLD WING),
Available Services, Confirmation for Using,
Making a Call at the Country You Stay,
Receiving a Call, Set Roaming Guidance,
Network Services, etc.

Available Data Communication,
Before Using Data Communication,
Setup Flow for Data Transfer (OBEX™ Communication),
Setup Flow for Data Communication, AT Command,
CD-ROM, DOCOMO Keitai Datalink

Function List, Options and Related Devices,
Troubleshooting, Error Messages, Warranty and
After-sales Services, i-mode Fault Diagnosis Site,
Software Update, Scanning Function, Main Specifications,
SAR, Export Administration Regulations, etc.

Index, Quick Manual,
Quick Manual “For Overseas Use”

Easy Search/Contents/Precautions

7

Main Functions of P-10A

◆i-concier 11P.206

i-concier is a service that enables you to receive useful information from a character
(Machi-chara image) on the Stand-by display and download schedule event
(i-schedule) files for your convenience.
Downloaded i-schedule events or ToruCa files are automatically updated to the latest
information, and the address information of shops/companies, etc. is automatically
added to the Phonebook.

◆

i-mode mail/Deco-mail/Deco-mail pictogram

Besides mail text, you can attach photos or movie files, etc. The FOMA terminal
supports Deco-mail/Deco-mail pictograms, so you can change the font color, font size,
and background color of mail text, and insert images and moving pictograms. Further,
Decome-Anime enables you to compose joyful mail messages with animations, just by
inserting messages into the Decome-Anime template.

 11P.136, P.139, P.310

◆International Roaming 11P.418

Your FOMA terminal, phone number, and mail address are available overseas

Easy Search/Contents/Precautions

(Supported only in 3G area).

◆Happy Illumination 11P.112

■Private Window, Call/Charging Indicator

When you open/close the FOMA terminal, animation appears on the Private window.
You can select a pattern of animation by “Illum. when closed” for when the FOMA
terminal is closed.
With the combination of the Call/Charging indicator and the Private window, you can
enjoy richly expressive illumination.

◆1Seg 11P.242

You can watch 1Seg programs of the terrestrial digital broadcasting for mobile objects.
Use TV Timer/Timer Recording not to miss an opportunity to watch or record
programs.

◆Full Wide QVGA Display

You can display still images or movies in the Full Wide QVGA (240 dots x 427 dots)
display of approx. 3.0 inches and can enjoy watching 1Seg programs on the impressive
display.
Also, the light sensor automatically adjusts the backlight in accordance with the ambient
brightness, and the LCD AI compensates the image quality in accordance with the
brightness.

◆W-Open Style 11P.28

You can watch 1Seg programs and videos on the horizontal full display in Horizontal
Open Style besides on the normal vertical display. Further, you can see the Internet
websites with Full Browser without scrolling sideways.

◆Waterproof Performance 11P.19

IPX5/IPX7 equivalent waterproof performance has been established with the
connector terminal firmly closed and the back cover attached.
You can make/receive calls or send/receive mail messages in the rain, in a bathtub, or
around poolside. If it gets dirty, you can clean it up with tap water.

◆Kisekae Tool 11P.111, P.334

You can set popular characters of NHK educational
programs by Kisekae Tool. Cute characters appear in each
menu.
The characters are also pre-installed in the folders of
Deco-mail pictograms and Deco-mail pictures.

© NHK Enterprises, Inc.

Arranged by PansonWorks

8

◆Abundant Lock Functions

■Customization of Personal Data Lock 11P.123

You can set the performance for during Personal Data Lock, such as about alarm
tones and mail receiving notification, etc.

■Lock OFF At Open 11P.124

When you open the FOMA terminal, the display for releasing a lock appears so that
you can release it easily.

◆Folder Jump Function 11P.35, P.227, P.378

You can check shot images from the Finder display of the camera by pressing a key.
You can check shot images also by pressing and holding x for at least one second
from the Stand-by display, or by selecting a desktop icon.

◆Face Detection 11P.233

You can shoot still images adjusting the camera focus on person’s face automatically.

Easy Search/Contents/Precautions

◆One-push Open 11P.28

■Setting when opened 11P.71

When a call comes in, just press the one-push open button, and you can open the
FOMA terminal to answer the call.

■Recv. Mail/Call at Open 11P.108

When a missed call or new mail message is found, just press the one-push open
button, and you can open the FOMA terminal to display the detailed Missed Call
display or the Inbox list.

◆Random Display 11P.105

On the Stand-by display, you can automatically show the images in a folder.
Enjoy the images which are automatically switched hourly/daily.

◆View Blind 11P.109

You can make the display hard to see from an angle. You can use the FOMA terminal
without concern for others’ eyes.

◆Shikkari Talk 11P.67

You can make the other party’s voice clear according to surrounding noise.

◆Yuttari Talk 11P.67

You can slow down the other party’s speaking speed during a call.

◆Document Viewer 11P.360

On your FOMA terminal, you can display Microsoft Word files, Microsoft Excel files,
and Microsoft PowerPoint files created by personal computers.

◆Voice Recorder 11P.355

You can record your voice as a substitute for taking notes. You can repeatedly
play it back, so it is convenient to record the proceedings at a meeting, etc.

◆Chaku-moji 11P.60

◆Videophone 11P.54

◆i-αppli/Mega i-αppli 11P.282

◆High-Speed Communication Supported 11P.428

◆Chaku-uta Full®/Uta-hodai/Music&Video Channel 

11P.262, P.268, P.270

≥“Chaku-uta Full” is a registered trademark of Sony Music Entertainment Inc.

◆MUSIC Player 11P.270

◆Osaifu-Keitai/ToruCa 11P.298, P.300

◆Respective Network Services 11P.397

◆Security Settings 11P.117

9

Precautions

ALWAYS FOLLOW THESE DIRECTIONS

Don’t

disassemble

Avoid
Water

Do

■Before using the FOMA terminal, read these safety precautions carefully so that

you can use it correctly.
After reading the precautions, keep them in a safe place.

■Be sure to observe these safety precautions because they are designed to

protect you or those around you from causing injury and to avoid unnecessary
damage to the property.

■The symbols below indicate the levels of danger or damage that can be caused

if the particular precautions are not observed.

This symbol indicates that incorrect handling

Danger
Warning

Easy Search/Contents/Precautions

Caution

will almost certainly cause death or serious
injury.

This symbol indicates that incorrect handling
poses a risk of causing death or serious
injury.

This symbol indicates that incorrect handling
poses a risk of causing injury or damage to
the product or property.

■The following symbols show specific directions:

Denotes things not to do. (Prohibition)

Denotes not to disassemble.

Do not

Not wet

hands

Denotes not to touch with wet hands.

Denotes not to use where it could get wet or not to wet it.

Denotes mandatory instructions (matters that must be complied
with).

10

Pull the

power plug

■“Safety Precautions” are divided into the following six sections:

General precautions for FOMA terminal, batteries, adapters, and UIM... P.11

Precautions for FOMA terminal ................................................................. P.12

Precautions for batteries ............................................................................ P.13

Precautions for adapters............................................................................ P.14

Precautions for UIM.................................................................................... P.15

Notes on using near electronic medical equipment .................................. P.15

Denotes to pull the power plug out of the outlet.

out

Don’t

Do not

disassemble

Avoid
Water

Do

Don’t

Do

Don’t

Don’t

Do

Do

General precautions for FOMA
terminal, batteries, adapters, and UIM

Danger

Do not use, store, or leave the mobile
phone or its accessories in places
with a high temperature (such as
near fire, near heating appliances,
inside a kotatsu or near other
furniture with heating elements, in
places exposed to direct sunlight, or
in cars heated by the sun).

The devices could be deformed or
malfunction, or the battery may leak,
overheat, burst, or catch fire, thus resulting
in the deterioration of performance and
shortening of the life of devices.
Also, part of the case could get heated,
causing bare skin burns.

Do not disassemble, modify or solder
the FOMA terminal or accessories.

Accidents such as fire, injury, or electric
shock, or malfunction may result. The battery
may leak, overheat, burst or catch fire.

Do not wet the FOMA terminal or
accessories.

If liquids such as water or pet urine get
onto them, overheating, electric shock,
fire, malfunction, injury or others may
result. Pay attention to the place of use
and the way of handling.

With your FOMA terminal, use the
batteries and adapters specified
by NTT DOCOMO, INC.

If you use any type of battery or adapter
other than the specified one, your FOMA
terminal, battery or other accessories
may leak, overheat, burst, catch fire or
malfunction.

Warning

Do not place the batteries, the
FOMA terminal, adapters, or UIM
in cooking appliances such as

Don’t

Don’t

microwave ovens or
high-pressure containers.

The battery may leak, overheat, burst, or
catch fire. The FOMA terminal or the
adapter may overheat, smoke, or catch
fire, or its circuit parts may become
damaged.

Do not throw the FOMA terminal
or accessories, or subject them
to severe shocks.

The battery may leak, overheat, burst, or
catch fire. Also, malfunction or fire may
result.

Be careful not to let
electroconductive materials
(metal pieces, pencil leads etc.)
contact with the charging
terminal or connector terminal.
Also, make sure that those are
not entered into the inside of the
FOMA terminal.

Short-circuit could cause fire or
malfunction of the FOMA terminal.

When you are in a place such as a
gas station where flammable gas
is generated, turn off the FOMA
terminal, and never do charging.

Do

Otherwise, catching fire may
result.

Ensure that you use Osaifu-Keitai with
the FOMA terminal turned off when you
are in the vicinity of the gas station.
(When IC Card Lock is set, turn off the
power with the lock released.)

If odor, overheat, discoloration,
or deformation is detected during
use, battery charge, or storage,
immediately observe the
following:

1. Pull the power plug out of the
outlet or cigarette lighter socket.

2. Turn off the power to the FOMA
terminal.

3. Remove the battery pack from
the FOMA terminal.

If you use the FOMA terminal and its
accessories as they are, overheat, burst,
or catching fire could result or the
battery could leak.

Caution

Do not place the FOMA terminal
or accessories on unstable
locations such as wobbly tables
or slanted locations.

The FOMA terminal or accessories may
fall, resulting in injury or malfunction.

Do not store in humid or dusty
places, or in high temperature
environments.

Malfunction may result.

If children use the FOMA terminal or
accessories, a guardian should
explain the safety precautions and
correct operations. The guardian
should also make sure that the
instructions are followed during use.

Otherwise, injury may result.

Keep out of the reach of babies
and infants.

Accidental swallowing or injury may
result.

Easy Search/Contents/Precautions

11

Be especially careful when you

Do

Don’t

Don’t

Don’t

Do

Do

Do

Do

use the FOMA terminal for a long
time with the adapter connected.

If you use i-αppli programs, talk on the
videophone, watch 1Seg programs and
so on for a long time during charging,
the temperature of the FOMA terminal,
battery pack, or adapter might rise.
If you directly touch the part of high
temperature continuously, redness,
itching, rash, or low-temperature bare
skin burns may result depending on your
physical conditions or predisposition.

Precautions for FOMA terminal

Warning

Do not directly point the infrared
data port at someone’s eyes
during transmission.

His/her eyes may possibly be affected.
Other infrared devices may operate
erroneously if the infrared data port is
pointed at them during transmission.

Do not put the FOMA terminal in
the place where it could be
affected by an expanded airbag,
e.g., on the dashboard.

If the airbag expands, the FOMA
terminal could hit you and others,
causing accidents such as injury and the
FOMA terminal could malfunction and
become damaged.

Easy Search/Contents/Precautions

12

Don’t

Do

Do

If you have any implanted
electronic medical equipment, do
not place your FOMA terminal in
a chest pocket or inner pocket.

If the FOMA terminal is positioned close
to electronic medical equipment, it may
cause that equipment to malfunction.

Do not allow liquids such as water,
or foreign materials such as metal
pieces or flammable materials to
get into the UIM or microSD card
slot of the FOMA terminal.

Fire, electric shock or malfunction may
result.

Turn off the FOMA terminal in
places where use is prohibited
such as in airplanes and hospitals.

Otherwise, electronic devices and
electronic medical appliances may be
adversely affected. If the Auto Power
ON function is set, deactivate the
setting, then turn the power off.
For use inside medical facilities, make
sure that you comply with their
regulations. You may be punished for
using the FOMA terminal in airplanes,
which is prohibited by law.

When talking with the FOMA
terminal set to Hands-free, be
sure to keep the FOMA terminal
away from your ear.
Further, when you play games or
play back music with the
earphone/microphone
connected, adjust the sound
volume to moderate volume.

The excessive sound volume impairs
your hearing.
Further, accidents may result due to the
hardness of hearing of surrounding
sound.

For those with weak heart
conditions, the vibrator and ring
volume must be adjusted
carefully.

Those functions may cause an effect on
the heart.

If thunder starts to rumble while
you are using the FOMA terminal
outdoors, turn off the power and
move to a safe place.

Otherwise, you could be struck by
lightning or suffer an electric shock.

Turn off the FOMA terminal when
near electronic devices using
high-precision control or weak
signals.

The FOMA terminal may possibly cause
these devices to malfunction.
※Electronic devices that may be

affected: Hearing aids, im planted
cardiac pacemakers, implanted
defibrillators, other medical electronic
devices, fire alarms, automatic doors
and other automatically controlled
devices. If you use an implanted
cardiac pacemaker, implanted
defibrillator or any other electronic
medical device, consult the
manufacturer or retailer of the device
for advice regarding possible effects
from the radio waves.

If the display part or camera lens
is broken, be careful about
broken glasses or the exposed
interior of the FOMA terminal.

Plastic panels are used for the surfaces
of the display part and camera lens so
that glasses do not easily get scattered,
however, pay attention not to
erroneously touch the broken part or
interior. Otherwise, injury may result.

Caution

Don’t

Don’t

Don’t

Don’t

Do

Do

Don’t

Do not swing the FOMA terminal
by its strap.

The FOMA terminal may hit you or
persons around you, and accidents such
as injury or malfunction and damage
may result.

If you erroneously break the
display part and then crystal
liquid gets leaked, never take or
suck the liquid to or into your
mouth, or apply to skin.
If the crystal liquid gets into the
eyes or mouth, immediately rinse
it out with clean water and then
seek medical attention.
When it adheres to your skin or
clothes, immediately wipe it away
with alcohol etc., and then rinse it
out with water and soap.

Otherwise, the loss of eyesight or injury
to your skin may result.

Do not bring your ears close to
the speakers while a ring tone
sounds or a melody is played
back from the FOMA terminal.

Otherwise, your hearing could be
impaired.

Do not open the FOMA terminal
by pressing the one-push open
button near persons around you
or your face.

The FOMA terminal may hit you or
persons around you, causing accidents
and injuries.

Do not use the FOMA terminal
with the hook for Horizontal Open
Style protruded.

Don’t

Otherwise, injury may result.

Electronic devices in some types
of cars can be affected by use of
the FOMA terminal.

For safety’s sake, make sure not to use

Do

the FOMA terminal inside such cars.

Itching, rash or eczema may be
caused depending on your
physical conditions or
predisposition. If an abnormality

Do

occurs, stop using the FOMA
terminal immediately, and then

Metals are used for the following parts:

Charging terminal Copper

Hook for Horizontal
Open Style

Metal part of the
one-push open button
Metal part of upper part
of the private window

Private window PC Hard coating
Battery installation part
inside surface

seek medical attention.

Where it is used Material Finishing

alloy

Stainless
steel

Aluminum Alumite

PC Evaporated

PC+ASA Copper-plated,

Gold-plated finish
with nickel-plated
and
palladium-plated
ground
Chrome-plated
finish with
nickel-plated
ground

treatment

aluminum, hard
coating

Nickel-plated

Be careful not to get your finger
or a strap caught in the parts
when you close or open the
FOMA terminal.

Accidents such as injury or damage may
result.

When you watch a 1Seg program,
watch in a place bright enough
taking a certain distance from the
display.

Otherwise, your visual acuity could be
reduced.

Precautions for batteries

■Check the description on the label of the

battery pack for the type of battery.

Description Type

Li-ion Lithium-ion battery

Danger

Do not let any metal object such
as a wire come in contact the
battery terminals. Also do not
carry or store the battery together
with any metal objects like a
necklace.

The battery may leak, overheat, burst or
catch fire.

Easy Search/Contents/Precautions

13

Don’t

Don’t

Don’t

Do

Don’t

Don’t

Don’t

Don’t

Don’t

Don’t

Easy Search/Contents/Precautions

14

Do not use excessive force to
attach the battery to the FOMA
terminal even when you cannot
attach it successfully. Also,
check that the battery is the right
way round when you attach it.

The battery may leak, overheat, burst or
catch fire.

Do not throw the battery into fire.

The battery may leak, overheat, burst or
catch fire.

Do not pierce it with nails, hit it
with a hammer, or step on it.

The battery may leak, overheat, burst or
catch fire.

If the battery fluid gets into your
eyes, do not rub them. Flush your
eyes with clean water and seek
medical attention immediately.

Otherwise, the loss of eyesight may
result.

Warning

When any abnormality due to
external shock such as the
deformation or scratches by
dropping is found on the battery
pack, immediately stop using it.

The battery may leak, overheat, burst, or
catch fire. Also, malfunction or fire may
result.

If charging is not completed at
the end of the specified charging
time, stop charging.

Otherwise, the battery may leak,

Do

overheat, become damaged or catch fire.

Immediately stop using the FOMA
terminal and keep it away from
fire if the battery leaks or emits
an odor

Do

The leaked battery fluid may ignite,
causing fire or burst.

Be careful that your pets do not
bite into the battery pack.

The battery may leak, overheat, burst, or
catch fire. Also, malfunction or fire may

Do

result.

Caution

An exhausted battery should not
be disposed of with other waste.

The battery may catch fire or damage

Don’t

Don’t

the environment. After insulating the
battery terminals with tape, take the
unneeded battery to a handling counter
such as a docomo Shop or dispose of it
in accordance with local waste disposal
regulations.

Do not charge the wet battery.

The battery pack may overheat, catch
fire, or burst.

If the battery fluid comes in
contact with skin or clothes,
immediately stop using, then
rinse it out thoroughly with clean

Do

water.

Skin injury may result.

Precautions for adapters

Warning

Do not use a damaged adapter
cord or power cord.

Electric shock, overheating or fire may

.

result.

Do not use the AC adapter and
desktop holder in steamy places
such as a bathroom.

Electric shock may occur.

The DC adapter is for use only in
a negative (-) grounded vehicle.
Do not use it in a positive (+)
grounded vehicle.

Fire may result.

If it starts to thunder, do not
touch the FOMA terminal and
adapter.

You might be struck by lighting or suffer
an electric shock.

Never short-circuit the charging
terminal when the adapter is
plugged into the power outlet or
cigarette lighter socket. Also,
never touch the charging terminal
with fingers or other bare skin.

Fire, malfunction, electric shock or injury
may result.

Place the adapter and desktop

Don’t

Don’t

Not wet

hands

Do

Do

Pull the

power plug

out

Pull the

power plug

out

Pull the

power plug

out

Do

Do

holder on a stable location while
charging. Do not cover or wrap
the adapter and desktop holder in
cloth or bedding.

The FOMA terminal may drop off, or the
adapter and desktop holder may
overheat, causing fire or malfunction.

Do not place something heavy on
the adapter cord and power cord.

Electric shock or fire may result.

Do not touch the adapter cord or
power outlet with wet hands.

Electric shock may result.

Use the adapter at the specified V
AC.

If you use it at a wrong voltage, fire or
malfunction may result. When using the
FOMA terminal overseas, use FOMA
AC adapter available overseas.
AC adapter: 100 V AC
DC adapter: 12/24 V DC
[For negative (-) grounded vehicles only]
AC adapter available overseas: 100 V to
240 V AC
[Connect only to household AC outlet]

If a fuse of the DC adapter has
blown, replace it with a specified
fuse.

If you use an unspecified fuse, fire or
malfunction may result. For the specified
fuse, refer to each instruction manual.

Keep the power plugs dust-free.

Otherwise, fire may result.

Do

When pulling the AC adapter into
the power outlet, firmly plug it in,
taking care not to contact with
metal straps or the like.

Do

Otherwise, electric shock, short-circuit or
fire may result.

When removing the adapter out
of the outlet or cigarette lighter
socket, do not forcibly pull the
adapter cord or power cord,

Do

instead take hold of the power
plug and then pull.

If you pull the plug out by the cord, the
cord may be damaged, which could
result in electric shock or fire.

When the adapter is not to be
used for a long period of time,
unplug the power cord from the
outlet.

Otherwise, electric shock, fire, or
malfunction may result.

If liquids such as water get in the
adapter, unplug the power cord
immediately from the outlet or
cigarette lighter socket.

Otherwise, electric shock, smoke or fire
may result.

Before cleaning, pull the power
plug out of the outlet or cigarette
lighter socket.

Otherwise, electric shock may result.

Precautions for UIM

Caution

Be careful not to touch the cut
surface of the UIM (IC portion)
when removing it.

You may hurt your hand or fingers.

Notes on using near electronic
medical equipment

■The description below meets “Guidelines on

the Use of Radio-communication Equipment
such as Cellular Telephones – Safeguards for
Electronic Medical Equipment” by the
Electromagnetic Compatibility Conference
Japan.

Warning

Comply with the following in
hospitals or health care facilities:

≥Do not carry the FOMA terminal into

operating rooms, intensive care units
(ICU) or coronary care units (CCU).

≥Turn off the FOMA terminal in hospital

wards.

≥If there is any electronic medical

equipment near you, turn off the
FOMA terminal even when in a
location such as a lobby.

≥Comply with any regulations of

hospital and health care facilities
instructing you not to use or carry in a
mobile phone.

≥If the Auto Power ON function is set,

deactivate the setting, then turn the
power off.

Easy Search/Contents/Precautions

15

Do

Do

Do

Easy Search/Contents/Precautions

16

Turn off the FOMA terminal in
crowded areas such as inside
trains during rush hour, as
someone with an implanted
cardiac pacemaker or implanted
defibrillator may be near you.

Operation of an implanted cardiac
pacemaker or implanted defibrillator can
be affected by radio waves.

If you use an implanted cardiac
pacemaker or implanted
defibrillator, use the mobile
phone 22 cm or more away from
an implanted cardiac pacemaker
or implanted defibrillator.

Operation of an implanted cardiac
pacemaker or implanted defibrillator can
be affected by radio waves.

Patients using electronic medical
equipment other than implanted
cardiac pacemakers or implanted
defibrillators (outside medical
establishments for treatment at
home, etc.) should check the
influence of radio waves upon the
equipment by consulting its
manufacturer.

Operation of electronic medical
equipment can be affected by radio
waves.

Handling Precautions

General notes

■The P-10A is provided with the waterproof

performance, however, do not have water
entered into the inside of the unit, or do not
spray water over accessories and optional
items.

The FOMA terminal is waterproofed (IPX5 and IPX7
equivalent) with the connector terminal firmly closed
and the back cover attached, however, it is not that the
FOMA terminal is completely waterproofed.
Do not attach/remove the battery pack, nor open/close
the connector terminal cover or back cover while you
are in the rain or with drops of rain remained on your
FOMA terminal. Otherwise the water entered into the
inside of your FOMA terminal might cause corrosion of
internal parts. Note that accessories and optional items
are not provided with waterproof performance.
If the trouble with your FOMA terminal is found to be
resulted from such exposure to water, the guarantee is
not supported. In that case your troubled FOMA
terminal is to be repaired fees charged.

■Use a dry soft cloth such as the one for

cleaning glasses to clean the equipment.

≥The screen of the FOMA terminal sometimes has a

special coating so that they are easier to see. If you
rub it roughly with a dry cloth, it might be scratched.
Take care of the way of handling, and use only a dry,
soft cloth such as the one for cleaning glasses. If the
screen is left with water drop or stain adhered, smear
may be generated or the coating might peel off.

≥Do not use alcohol, thinner, benzene, detergent or

other solvents for cleaning, otherwise the printing
may be removed or discoloration may result.

■Occasionally clean the terminals of the

equipment using a dry cotton swab, etc.

The soiled terminals deteriorate the connection and
might cause power discontinuity or incomplete
charging. Wipe the terminals with a cotton swab, etc.
Take care not to damage the terminals when cleaning
them.

■Do not place the FOMA terminal near an air

conditioner outlets.

Condensation may form due to rapid changes in
temperature, and this may corrode internal parts and
cause malfunction.

■Do not apply excessive force onto the FOMA

terminal and battery pack.

If you put the FOMA terminal in a bag along with many
other articles or sit with the FOMA terminal in a clothes
pocket, the display, internal circuitry and the battery
pack could be damaged or malfunction. Also, if an
external device is left connected to the connector
terminal (earphone/microphone terminal), the
connector could be damaged, or malfunction.

■Carefully read each instruction manual

attached to the FOMA terminal, adapter, or
desktop holder.

■Do not rub or scratch the display part with

metals.

Doing so might cause damage to the part, resulting in
trouble or malfunction.

Notes on handling the FOMA terminal

■

Avoid using in extremely high or low temperatures.

The FOMA terminal should be used within a
temperature range of 5°C to 40°C (however, the use at
36°C or higher should be limited to temporal use in a
bathroom etc.) and a humidity range of 45% to 85%.

■The FOMA terminal, if operated near land-line

phones, television sets, radios or other
devices that are in use, may affect them. You
should operate your FOMA terminal as far
away from such equipment as possible.

■It is recommended that you make separate

notes of the information stored in the FOMA
terminal and keep such notes in a safe place.

We take no responsibility for any loss of the stored data
items.

■Do not drop the FOMA terminal or subject it to

strong impacts.

Malfunction or damage may result.

■Do not insert an external device to the

connector terminal (earphone/microphone
terminal) at a slant when connecting, and do
not pull it out when it is inserted.

Malfunction or damage may result.

■Make sure that nothing, such as a strap, gets

caught between the parts of the FOMA
terminal when you close it.

Otherwise, malfunction or damage may result.

■The FOMA terminal becomes warm during

use or charging but this is not an abnormality.
Use the FOMA terminal as it is.

■Do not leave the camera in places exposed to

direct sunlight.

Pixels may be discolored or burns may result.

■Usually, put the cover of the connector

terminal and microSD card slot to use the
FOMA terminal.

Dust or water might enter into the FOMA terminal,
causing malfunction.

■Do not use the FOMA terminal with the back

cover left removed.

The battery pack might come out, or malfunction or
damage may result.

■Do not apply an excessively thick sticker onto

the surfaces of the display, keys, or buttons.

Malfunction may result.

■While you are using the microSD card, never

take it off or turn off the power to the FOMA
terminal.

Data may be erased or malfunction may result.

■Do not place magnetic cards or similar

objects near the FOMA terminal or between
phone parts.

Magnetic data on cash cards, credit cards, telephone
cards and floppy disks, etc. may be deleted.

■Do not bring magnetic substances close to

your FOMA terminal.

Strong magnetic items might cause in erroneous
operation.

Notes on handling batteries

■Batteries have a limited life.

Though it varies depending on the usage state, you are
advised to replace the battery if its usable time is
extremely short even when you fully charge it. Make
sure that you buy the specified battery.

■

Charge the battery in a place with an
appropriate ambient temperature of 5°C to 35°C.

■Make sure that the battery is charged when

you use the FOMA terminal for the first time
or have not used it for a long period of time.

■

The usable time of the battery differs depending
on the usage environment or its remaining life.

■Depending on how the battery pack is used, it

might swell as its operating life becomes
short, but this is not a problem.

■Note the following points when you store a

battery pack over a long period:

≥Storage in a fully charged state (the state immediately

after charging is completed)
Storage with no battery power left (the state you cannot

≥

turn on the power of the handset due to battery drain)
These may lower the battery pack’s performance and
shorten its operating life.
You are advised to store the battery pack in the state of
two bars of battery icon indication as a guide for when
you store it for a long period.

Notes on handling adapters

■Charge the battery in a place with an

appropriate ambient temperature of 5°C to
35°C.

■Charge the battery where:

≥There is very little humidity, vibration, and dust.
≥There are no land-line phones, television sets or

radios nearby.

■While you are charging, the adapter may

become warm. This is not a malfunction, so
you can keep on using.

■Do not use the DC adapter for charging the

battery when the car engine is not running.

The car battery could go flat.

■When using the power outlet having the

disengaging prevention mechanism, observe
the instructions given in that instruction
manual.

■Do not give a strong shock. Also, do not

deform the charging terminal.

Malfunction may result.

Easy Search/Contents/Precautions

17

Notes on handling the UIM

■Never use more force than necessary when

inserting/removing the UIM.

■The UIM may become warm during use, but

this is not a sign of a malfunction. Continue
using it as it is.

■The warranty does not cover damage caused

by inserting the UIM into some other types of
IC card reader/writer.

■Always keep the IC portion clean.

■Use a dry soft cloth such as the one for

cleaning glasses to clean the equipment.

■It is recommended that you make separate

notes of the information stored on the UIM
and keep such notes in a safe place.

We take no responsibility for any loss of the stored data
items.

■For the environmental protection, bring any

Easy Search/Contents/Precautions

unneeded UIMs to a handling counter such as
a docomo Shop.

■Avoid using in extremely high or low

temperatures.

■Do not damage, carelessly touch, or

short-circuit the IC.

Data might be lost or malfunction may result.

■Do not drop the UIM or subject it to strong

impacts.

Malfunction may result.

■Do not bend the UIM or place something

heavy on it.

Malfunction may result.

■Into the FOMA terminal, do not insert the UIM

with a label or sticker pasted.

Malfunction may result.

Notes on handling the FeliCa reader/
writer

■The FeliCa reader/writer function on the

FOMA terminal uses very weak radio waves
which do not require to be licensed as radio
stations.

■The FeliCa reader/writer is operated on the

13.56 MHz frequencies. When you use
another reader/writer nearby, take enough
distance between your FOMA terminal and
the reader/writer. Further, ensure that there
are no radio stations that use the same
frequencies.

Caution

■Do not use the modified FOMA terminal.

Using a modified FOMA terminal infringes the
Radio Law.

The FOMA terminals are granted technical regulations
conformity certification as the specified radio equipment
under the Radio Law and bear a “technical conformity
mark ” on the nameplate as evidence of conformity.
Unscrewing the FOMA terminal and modifying internal
components void the technical regulations conformity
certification. Do not use the FOMA terminal in this state,
which infringes the Radio Law.

■Be especially careful not to operate the FOMA

terminal while driving.

You will be imposed punishment if you use the mobile
phone in your hand while driving. If you answer a call
out of necessity, tell the caller with Hands-free that you
will call him/her back, park your car to somewhere safe,
and then dial.

■Use the FeliCa reader/writer functions in

Japan only.

The FeliCa reader/writer functions on the FOMA
terminal have been authorized in compliance with the
radio transmission standards in Japan.
You might be imposed punishment if you use them
overseas.

18

Waterproof Performance

Soap/detergent

Sea/pool

Spa/bath salts

Your P-10A comes with the waterproof performance equivalent to IPX5
(former JIS protection standard 5)
standard 7)

closed and no clearance gap and float found in them.

※1IPX5 class equivalent: Denotes that the phone performance is retained even when

※2IPX7 class equivalent: Denotes that no water enters into the inside of the unit and the

(Note) This is not that the waterproof performance is guaranteed in all given conditions of

You can operate the FOMA terminal in the rain, in your kitchen, and also around
poolside.

※2

with the connector terminal cover and back cover firmly

water jet flow is sprayed over the FOMA terminal from all directions on condition that

12. 5 L/minute is sprayed at a distance of about 3 m for at least three minutes using

6.3 mm caliber of a nozzle.

phone performance is retained even when the unit is slowly sunk to 1 m depth of a
tap static water tank, and left as is for about 30 minutes at an ambient temperature.

actual use. Read this manual thoroughly before use to prevent invasion of water
or foreign materials and then to enable you to safely use your FOMA terminal.

In the Rain

≥You can communicate in the rain taking hold of the phone with your wet hand without

umbrella.

※Up to slightly strong rain (to such a degree that there is less than 20 mm/hour of

rainfall, and your feet get wet by drops of rain rebounded off the ground)

※When your hands are wet or water drops remain on the FOMA terminal, do not attach/

remove the back cover, nor open/close the connector terminal cover.

Wash

≥When the FOMA terminal gets dirty, you can slowly swing and

wash it in a bowl filled with fresh water or tap water at an ambient
temperature, or wash it by hand while spraying a slightly-weak
water flow from a faucet.

≥Wash your FOMA terminal with the back cover firmly closed and

while you are pushing the cover of the connector terminal down.

≥Do not use brushes, sponges, soaps, or detergents for washing.

※1

and IPX7 (former JIS protection

On Leisure

≥Do not soak or drop your FOMA terminal into a pool or the sea nor

operate it in water.

≥If you get pool water or seawater over the FOMA terminal, wash it

with tap water at an ambient temperature.

In the Bathroom

≥Do not soak or drop your FOMA terminal into a bathtub, nor use it in

water.

≥Do not soak the FOMA terminal into spa or water containing soap

detergent or bath addictive.

≥Do not directly spray the water flow strong enough to give pain on

your skin.

≥Avoid using the FOMA terminal for a long time in a bathroom.
≥If you take your FOMA terminal from a cold place to a warm

bathroom, condensation might result because of sudden change in ambient
temperature. Warm it up until ambient temperature is restored, and then take it to the
bathroom.

≥When any condensation is found inside the display, leave your FOMA terminal in

ambient temperature until the condensation is removed.

In the Kitchen

≥Do not spray liquids other than fresh water or tap water such as soaps, detergents,

seasonings, or juices, over the FOMA terminal nor soak it in them.

≥Do not spray hot or cold water over the FOMA terminal, nor soak it in them. It is not

designed to be heat-resistant.

≥Do not spray a strong water flow over the FOMA terminal.

Easy Search/Contents/Precautions

19

Important Issues at Start of Using

Hook

②①③

Upper
claw

Rear surface of back cover

Packing

≥Before use, ensure that you firmly close the connector terminal cover and back cover

so that they are completely attached. If any fine dirt (fine fibers, hairs, or sands) is
between the covers and the unit, water could enter into the inside of the unit.

≥Ensure that the connector terminal cover and back cover are completely closed and no

float is found.

■Opening the connector terminal cover

① Hook your finger over the groove and open.

(See page 47)

■Closing the connector terminal cover
① Place the FOMA terminal and the bottom part

of the connector terminal cover in parallel.

② Securely hold the base of the connector

terminal cover.

③ Push the connector terminal cover straight

from the front.

④ Ensure that no float is found with the

Easy Search/Contents/Precautions

connector terminal cover as a whole.

■Attaching the back cover
① Fit the upper claw of the back cover correctly into the FOMA terminal, and then

fit the left, right, and lower part of claws to attach the back cover.

② Push the seven ● marks on the sticker and

ensure that no float is found anywhere on the
back cover.

≥Do not soak the FOMA terminal into liquids other than fresh water or tap water at an

ambient temperature.

≥To enhance the waterproof performance, you need to replace parts without fail once

two years regardless whether any abnormality with the FOMA terminal is found or not.
You are charged for replacement of parts. Take your FOMA terminal to a repair
counter specified by DOCOMO.

Caution

■About FOMA terminal

≥Do not wash the FOMA terminal with a washing machine or ultrasonic cleaner.
≥Never charge the battery when it gets wet.
≥Do not leave the FOMA terminal with drops of water remained on.

・The connector terminal might be short-circuited.
・Water might enter into the inside of the FOMA terminal through the keys or hinges. In

cold districts, drops of water on the FOMA terminal might freeze, resulting in

malfunction.
When the FOMA terminal gets wet, stay the back cover attached and the connector
terminal cover closed, swing it to remove water, and immediately wipe it off with a clean
dry cloth.

≥

Do not drop the FOMA terminal nor give a shock to it.
The deterioration of the waterproof performance might result depending on the damage.

≥Do not soak the FOMA terminal in hot water, use in a sauna, nor expose to hot wind

currents such as those of a dryer.
The FOMA terminal is not designed to be heat-resistant.

≥The FOMA terminal does not float on water.
≥Do not spray a water flow stronger than standard into the FOMA terminal, nor sink it

into water.
The FOMA terminal is not designed to be hydraulic pressure resistant.

≥Do not directly place the FOMA terminal on sandy beaches.

・Sands enter into the holes on the microphone, earpiece, or speakers, and it might

happen that volume is reduced.

・If you operate the FOMA terminal with water drops or sands adhered to, sound might

be deteriorated.

・ Even the slightest sands entered from the connector terminal cover or back cover

could cause water to enter the inside of the FOMA terminal.

■About the connector terminal cover and back cover

≥Do not open or close them with gloves put on hands.

Fine dirt might adhere to the contact surface of the packing.

≥Be careful that no fibers adhere to the packing when you try to wipe off moisture with a

clean dry cloth.

20

≥Do not peal the packing off. Also do not insert something pointed at the head into the

<Draining from earpiece> <Draining from microphone>

<Draining from speakers>

clearance of the connector terminal cover or back cover.
The packing is damaged, resulting in water to enter into the FOMA terminal.

≥If the packing for the connector terminal cover or back cover is damaged or deformed,

replace them at a repair counter specified by DOCOMO.

≥If the back cover is broken, replace it with new one.

Otherwise liquid such as water enters into the inside of the FOMA terminal through
broken portions, and an electric shock or corrosion of the battery pack could result.

≥When the FOMA terminal gets wet with the connector terminal cover or back cover left

open, water enters inside, and an electric shock or malfunction could be caused. Do
not use it as is, but turn off the power, remove the battery pack, and then take it to a
repair counter specified by DOCOMO.

■About microphone, earpiece, and speakers

≥Do not thrust something pointed at the head into the holes on microphone, earpiece, or

speakers.

≥Do not leave water drops adhered to them. It might happen that communications are

disabled.

■Others

≥Accessories and optional items are not waterproofed. When you watch 1Seg programs

with your FOMA terminal inserted into the desktop holder, do not operate it in a
bathroom, shower room, kitchen, or lavatory where water is used, even if you do not
connect to AC adapter.

≥It is not that the waterproof performance is guaranteed in all given conditions of actual

use. If the damage is found to be caused by your mishandling of the FOMA terminal as
a result of our inspection, the guarantee is not supported.

Draining Water

≥If you operate the FOMA terminal with water drops left adhered to, a volume level from

the speakers might be decreased or sound quality vary.

≥It might have happened that moisture has entered inside through the clearance gap of

the keys or hinges.

Follow the procedures described below to wipe moisture off the FOMA terminal:

① Wipe completely moisture off the surface of the FOMA terminal with a clean dry

cloth.

② Securely take hold of the FOMA terminal, and firmly swing each surface at least

20 times until no moisture sprays off.

Easy Search/Contents/Precautions

21

③ Lightly push the FOMA terminal against a clean dry cloth, and wipe moisture

off the clearance gap of the microphone, earpiece, speaker, keys, or hinges.

≥Do not directly wipe moisture out of joint gap using a cotton swab, etc.

④ Fully drain moisture and then operate the FOMA terminal.

≥Even when you follow the procedures for draining water as described above, moisture

might remain inside the FOMA terminal. So, use the FOMA terminal after adequate air
seasoning. Further, take care not to place anything you do not want to get wet close to
the FOMA terminal.

When Charging Battery

Accessories and optional items are not waterproofed. Check the following before and

Easy Search/Contents/Precautions

after charging:
≥Never charge the battery with the FOMA terminal left wet. Malfunction or catching fire

could be caused if an electric shock or short-circuit occurs. If the FOMA terminal gets
wet, drain and wipe off moisture with a clean dry cloth and then charge.

≥When you charge the battery with the connector terminal cover open, firmly close it

after charging. To prevent water from entering inside through the connector terminal,
you are advised to use the desktop holder for charging.

≥Do not touch the AC adapter and desktop holder with your hands wet. An electric

shock could result.

≥Do not use the AC adapter and desktop holder in a bathroom, shower room, kitchen,

and lavatory where water is used. Catching fire or an electric shock could be caused.

22

Basic Package and Main Options

NTTドコモ

<Basic package> <Main Options>

≥P-10A Handset

(With Warranty and Back Cover P38)

≥P-10A CD-ROM

The PDF versions of “Manual for PC Connection”
and “Kuten Code List” are included.

≥FOMA AC Adapter 01/02

(With Warranty and Instruction Manual)

Easy Search/Contents/Precautions

≥Instruction Manual

Quick Manual included (See page 510)

≥Battery Pack P19 ≥Desktop Holder P35

(With Instruction Manual)

Other Options → Page 466

23

24

Before Using the Handset

Part Names and Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Styles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Navigation Displays and Key Operations . . . . . . . . . . . . . . . . . 29

Main Key Operations from the Stand-by Display . . . . . . . . . . . 30

Viewing Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Using Icons on Desktop . . . . . . . . . . . . . . . . . .<Desktop Icon> 34

Displaying Description of Icons . . . . . . . . . . . . . . . . . . <Icons> 36

Private Window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Selecting Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

When You Forget Key Operation . . . . . . . . . . . . . . . . . <Guide> 42

Using UIM (FOMA Card) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Attaching/Removing Battery Pack . . . . . . . . . . . . . . . . . . . . . . . 44

Charging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Checking Battery Level . . . . . . . . . . . . . . . . . . .<Battery Level> 48

Turning Power ON/OFF . . . . . . . . . . . . . . . . . <Power ON/OFF> 48

Switching to English Display . . . . . . . . . . . <Select Language> 49

Configuring Initial Setting . . . . . . . . . . . . . . . . .<Initial Setting> 49

Setting Date and Time . . . . . . . . . . . . . . . . . . . . . . . <Set Time> 50

Displaying World Time . . . . . . . . . . . . . . <World Time Watch> 50

Notifying the Other Party of Your Phone Number

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <Caller ID Notification> 51

Checking Your Own Phone Number . . . . . . . . <Own Number> 51

25

Part Names and Functions

■For using earphone

Connect an optional connector-terminal-compatible earphone.
When using a connector-terminal-non-compatible earphone, use an
optional plug adapter for connection.
≥When inserting or pulling the plug adapter, take hold of the plug for the

handset side and insert or pull it straight. Be careful not to take hold of
the cover of the connector terminal and plug for the handset side
together when you pull it out.

Flat plug of the
Flat-plug Earphone/
Microphone with Switch

Plug for the
handset side

Earphone terminal (Flat-plug)

Example for connecting the Flat-plug
Earphone/Microphone with Switch (option)

2

;
<

>

:

=

6

?

3

8

4

9

A

H

J

F

5

7

D
E

I

M

K

@

G

N

1

L

B

C

Before Using the Handset

26

1Light sensor

・For sensing brightness (See page 108)

≥Do not cover the light sensor with your hands or do

not put a sticker on it. Doing so might disable you to
detect the brightness.

2Earpiece

・For listening to the other party’s voice

3Display

(See page 32)

4l Mail key

5m Menu key

6r Clear key

・For returning to the previous operation
・For clearing entered text or a phone number

7d Start key/Hands-free key

・For making/receiving calls (See page 54 and page 68)
・For talking with Hands-free (See page 67)

8Microphone

・For speaking to the other party

9Connector terminal

・For connecting the AC adapter (option), DC adapter

(option), FOMA USB Cable with Charge Function 01/
02 (option), or Stereo Earphone Set 01 (option), etc.

≥Integrated terminal for connecting earphone or for

charging, etc.

:o Command navigation key

・For operation of function or menu (See page 29)

;i i-mode key/i-αppli key

<c Camera key/1Seg key

=h Power/End key

・For ending calls
・For ending respective functions
・For turning on the power (for at least one second)/

For turning off the power (for at least two seconds)
(See page 48)

>Numeric keys

・For entering phone numbers and text

?x Multi key

@Hook for Horizontal Open Style

AInfrared data port

・Used for infrared communication and the infrared

remote control. (See page 349 and page 353)

BCall/Charging indicator

・Flickers for incoming calls/mail and during a call.

(See page 112)

・Lights in red during charging.
・Lights/Flickers when you shoot with the camera.

CPrivate window

(See page 37)

DCamera

・For shooting portraits and/or landscapes

(See page 226)

・For catching sight of persons and/or landscapes

during a videophone call

Ef mark

・The IC card is mounted.

≥Use the IC card function placing this mark over the

scanning device. You cannot dismount the IC card.
(See page 299)

FFOMA antenna/1Seg antenna

≥The antenna is embedded in the handset. Do not

cover the antenna with your hand for better
communication/receiving.

GSpeaker

・For sounding ring tones
・For listening to the other party’s voice when

Hands-free is activated (See page 67)

HBack cover

・Remove this when attaching/removing the battery

pack, UIM or microSD card. (See page 42, page 44 or
page 336)

ICharging terminal

JStrap hole

K<Side ▲ key

・For scrolling up page by page

L>Side ▼ key

・For scrolling down page by page
・For checking for missed calls and new mail

(See page 114)

<Press and hold for at least one second with the

FOMA terminal closed>

・For activating/deactivating Manner Mode

(See page 102)

MOne-push open button

(See page 28)

NHorizontal open lever

(See page 28)

Before Using the Handset

27

Styles

One-push open button

Horizontal open lever

Information

Information

Information

The P-10A comes with two styles (W-Open style).

■Normal Style
You can open the FOMA terminal easily by one-push key operation.
(One-push Open)

≥You can open it also manually without using the button.
≥You need to close the FOMA terminal manually. If it does not close, open it fully and

then close it.

Before Using the Handset

■Horizontal Open Style
Hold down the part A and open the display part with the horizontal open
lever slid into the direction B. From the horizontal display, you can use
1Seg, Full Browser, and others.

≥If the latch is not in a state of C when you open the display, re-open the FOMA terminal

after closing it once.

≥When you open the FOMA terminal by pressing the one-push open button, it might

not open fully depending on its direction.

≥When you open the FOMA terminal by pressing the one-push open button, be careful

not to drop it by its rebound.

≥When you press the one-push open button in Horizontal Open Style, the FOMA

terminal will open in Normal Style after it is closed.

≥Before switching the styles, be sure to completely close the FOMA terminal. If you

operate the horizontal open lever in Normal Style or with the display part unlatched,
malfunction or damage may result.

≥Some operating procedures and items on the display in Horizontal Open Style differ

from the ones described for Normal Style in this manual.

≥When you switch styles while a confirmation display for selecting “YES/NO” is shown,

the confirmation display may be cleared.

Work with Style

You can set which operation starts for when you switch to Horizontal
Open Style from the Stand-by display.

m1Set./Service1Other settings1Work with style

1

1Select an item.

Horizontal open menu . . .Shows Horizontal Open Menu. (See page 40)

1Seg . . . . . . . . . . . . . . . . . .Activates 1Seg. (See page 245)

Camera . . . . . . . . . . . . . . . .Activates the camera in Photo Mode. (See page 229)

OFF . . . . . . . . . . . . . . . . . . .Shows the Stand-by display (wide). (See page 105)

≥When you switch styles from Main Menu or Horizontal Open Menu, the Stand-by

display appears regardless of the setting of this function.

28

Navigation Displays and Key Operations

Zo

display up. (Press and hold to scroll
continuously.)

Vo

・Moves the cursor to the right.
・Scrolls forward page by page.

(Press and hold to scroll
continuously.)

Oo

・Fixes the oper ation.

Co

and hold to scroll continuously.)

Xo

・Moves the cursor or highlighted

display down. (Press and hold to
scroll continuously.)

・Scrolls the page dow n.

■Operating command navigation key

Key Operations in Normal Style

When you want to execute the operation shown on the display in Normal
Style, press the corresponding key as below.

■Basic display examples and key assignments

Indicates the operation you can perform with

1

the l key.

Indicates the operation you can perform with

2

the m key.

Indicates the operation you can perform with
the Oo key.

3

Indicates the direction in which you can scroll
and select items with the Mo key.

Indicates the operation you can perform with

4

the c key.

Indicates the operation you can perform with

5

the i key.

Before Using the Handset

Key Operations in Horizontal Open Style

While the vertical display is shown, you
can operate in the same way as in
Normal Style.
While the horizontal display is shown,
you can operate in the same way by
pressing the corresponding key as
shown on the right.

≥Even when you have operated on the horizontal

display, the display might switch to the vertical
display depending on the function.

29

Main Key Operations from the Stand-by Display

From the vertical Stand-by display in Normal Style or the horizontal
Stand-by display in Horizontal Open Style, you can execute the following
actions by operating each key:

+Oo

Before Using the Handset

+Zo

+Xo

+Co

+Vo

Key operation

for a short time

for at least one
second

for a short time

for at least one
second

for a short time

for at least one
second

for a short time

for at least one
second

for a short time

for at least one
second

Performance in Normal Style

(on the vertical display)

Shows the display for selecting
an icon, etc. on the Stand-by
display. (See page 36,
page 74, page 105)

Sets/Releases Key Lock. (See page 125)

Shows the Channel list.
(See page 205)

Shows the Search Phonebook
display. (See page 89)

Shows the registration display
for the Phonebook entries.
(See page 84)

Shows the Received Call list.
(See page 59)

Shows the Received Address
list. (See page 164)

Shows the Redial list.
(See page 58)

Shows the Sent Address list.
(See page 164)

Performance in Horizontal Open
Style (on the horizontal display)

Shows the display for selecting
a notification icon.
(See page 36, page 74)

—

—

—

—

—

—

—

—

Key operation

for a short time Shows the Mail menu. (See page 155)

+l

for at least one
second

for a short time Shows the i-mode menu. (See page 184)

+i

for at least one
second

for a short time

+m

for at least one
second

for a short time Activates the camera in Photo Mode. (See page 229)

+c

for at least one
second

for a short time Makes a call. (See page 54) —

-d

for at least one
second

for a short time

-h

for at least two
seconds

for a short time

+r

for at least one
second

Performance in Normal Style

(on the vertical display)

Executes Check New Messages. (See page 150)

Shows the Software list. (See page 283)

Shows Main Menu.
(See page 38)

Sets/Releases IC Card Lock. (See page 300)

Starts 1Seg. (See page 245)

Accesses a voice dial entry.
(See page 95)

Shows/Clears the icons, etc. on the Stand-by display.
(See page 106)

Turns off the power. (See page 49)

Switches between the i-αppli
Stand-by display and normal
i-αppli program.
(See page 295)

Resets Main Menu.
(See page 111)

Performance in Horizontal Open

Style (on the horizontal display)

Shows Horizontal Open Menu.
(See page 40)

—

—

—

30

Key operation

for a short time Enters “0”. —

-0

for at least one
second

for a short time

-1

for at least one
second

for a short time

-2

for at least one
second

for a short time

-3

for at least one
second

for a short time Enters “4”. —

-4

for at least one
second

for a short time Enters “5”. —

-5

for at least one
second

for a short time Enters “6”. —

-6

for at least one
second

for a short time

-7

for at least one
second

for a short time Enters “8”. —

-8

for at least one
second

for a short time

-9

for at least one
second

Performance in Normal Style

(on the vertical display)

Enters “+”. —

Enters “1”.

Enters “2”. —

Enters “3”. —

Sets/Releases Secret Mode. (See page 126)

Switches the backlight on/off. (See page 109)

Sets/Releases Personal Data Lock. (See page 123)

Enters “7”. —

Switches View Blind on/off. (See page 109)

Enters “9”. —

Performance in Horizontal Open
Style (on the horizontal display)

Key operation

for a short time Enters “:”. —

-a

for at least one
second

—

—

for a short time Enters “#”. —

-s

for at least one
second

for a short time Shows the Multitask Menu. (See page 366)

-x

for at least one
second

for a short time —

.<

for at least one
second

for a short time

.>

for at least one
second

Performance in Normal Style

(on the vertical display)

Activates/Deactivates Public mode (Drive mode).
(See page 73)

Activates/Deactivates Manner Mode. (See page 102)

Activates a function set by Multi Key Long Press Setting.
(See page 378)

Switches menu functions. (See page 366)

Activates 2in1. (See page 408) —

Plays back a record message/
voice memo. (See page 76)

Plays back a videophone
record message/movie memo.
(See page 77)

Performance in Horizontal Open
Style (on the horizontal display)

—

—

Before Using the Handset

31

Viewing Display

<Private window>

1235 8 :9<;@

ABC

D

G

H

I

J

KE

F

L

4

2 5

31 : =

M

;

=>

?

C

I

6

7

N

1

2

Before Using the Handset

3

4

(dark blue)

5

(dark blue)

Battery level (estimate) (See page 48)

Radio waves reception level (estimate)

Strong Weak

You are out of the FOMA service area or
radio waves do not reach.

During Self Mode (See pag e 122)

During i-mode (See page 1 84)

During i-mode communication (S ee page 184)

During packet communication (The icon differs
depending on the communication status.)

You get out of the service area while
Network Search Mode is set to “Manual”.
(See page 423)

During SSL communication (See page 185)

Unread i-mode mail or an SMS message

(pink)

exists. (See page 148 and page 180)

The area for i-mode mail and SMS
messages in the FOMA terminal is full.
(See page 148 and page 180)

The area for SMS messages on the UIM
(FOMA card) is full.

Unread mail exists, and the area for SMS

(pink)

messages on the UIM (FOMA card) is full.

Both the FOMA terminal and UIM (FOMA
card) are full.

Area Mail exists. (See page 173)

32

Unread Messages R/F exist.

(yellow)

6

(dark blue)

(dark blue)

7

(yellow)

(dark blue)

8

9

(See page 170)

The area for Messages R/F in the FOMA
terminal is full. (See page 171)

i-mode mail is held at the i-mode Center.

(pink)

(See page 150)

The box for i-mode mail at the i-mode
Center is full. (See page 148)

Messages R/F are held at the i-mode
Center. (See page 171)

The box for Messages R/F at the i-mode
Center is full. (See page 171)

i-mode mail is held at the i-mode Center
while Receive Option Setting is se t to “ON”.
(See page 149)

New i-concier information exists.
(See page 206)

During a voice call

During a videophone call

During 64K data communication

:

A microSD card is inserted. (See page 336)

Data is being read to/written f rom the
microSD card.

A write-protected microSD card is inserted.
(See page 336)

The inserted microSD card cann ot be used.
(See page 336)

A microSD card is inserted, and the FOMA
USB Cable with Charge Function 01/02
(option) is connected in micro SD Mode.
(See page 345)

A microSD card is inserted, and the FOMA
USB Cable with Charge Function 01/02
(option) is connected in MTP Mode.
(See page 345)

During Lock All (See page 120)

Information

During Personal Data Lock (See page 123)

During Keypad Dial Lock (See p age 125)

During Secret Mode or Secret Data Only
(See page 126)

During IC Card Lock (See page 300)

Both Keypad Dial Lock and Personal Data
Lock are set.

Both Keypad Dial Lock and Secret Mode/
Secret Data Only are set.

;

<

=

>

Both IC Card Lock and Lock All are set.

Both IC Card Lock and Personal Data Lock
are set.

Both IC Card Lock and Keypad Dial Lock
are set.

Both IC Card Lock and Secret M ode/Secret
Data Only are set.

IC Card Lock, Keypad Dial Lock, and
Personal Data Lock are simultaneously set.

IC Card Lock, Keypad Dial Lock, and Secret
Mode/Secret Data Only are simultaneously
set.

Type of in-use network (See page 419)

You are in the OFFICEED area.
(See page 414)

Timer Lock ON At Close is set.
(See page 124)

During Key Lock (See page 1 25)

During Multitask (See page 365)

Multiple functions are activated.
(See page 365)

While watching a 1Seg program
(See page 245)

During recording of a 1Seg program
(See page 252)

>

?

@

A

B

C

D

E

F

G

During recording of a 1Seg program by
Timer Recording (See page 256)

During pause of 1Seg program recordin g
(See page 253)

During music playback (See page 271)

During music pause (See page 271)

During infrared communication
(See page 349 and page 353)

The FOMA USB Cable with Charge
Function 01/02 (option) is connected in
Communication Mode.

The FOMA USB Cable with Charge
Function 01/02 (option) is connected in
microSD Mode. (See page 345)

During talk or communication through a
USB Hands-free compatible device
(See page 67)

A USB Hands-free compatible device is
connected. (See page 67)

A USB Hands-free compatible device is
connected in microSD Mode. (S ee page 67)

Vibrator is set to other th an “OFF”.
(See page 100)

Ring Volume is set to “Silent” or
Mail/Msg. Ring Time is set to “OFF”.
(See page 72 and page 101)

During Manner Mode (See page 102)

During Public mode (Drive mode)
(See page 73)

The call cost has exceeded the specified
limit. (See page 382)

An alarm is set.
(See page 256 and page 369)

A Music&Video Channel program is booked.
(See page 262)

Backlight is set to “OFF”. (See page 108)

H

I

J

K

L

M

N

≥For the horizontal display, icons appear at the lower right

of the display.

≥The clock at the upper right of the display (at the lower

right of the horizontal display) does not appear when the
icon ? or @ is displayed.

≥Some characters and symbols on the display and

Private window might be modified or abbreviated.

≥The color liquid crystal display uses high-precision

production technology. The slightest change in the
environment or other factors may result in unlit or
permanently lit pixels, but this is not a manufacturing
defect.

View Blind is set to “ON”. (See p age 109)

Backlight is set to “OFF” and View Blind is
set to “ON”.

Side Keys Guard is set to “ON”.
(See page 125)

USB Mode Setting is set to “micro SD
mode”. (See page 345)

USB Mode Setting is set to “MTP mode”.
(See page 345)

Voice mail messages for Number B are held

〜・

at the Voice Mail Center in Dual Mode of
2in1. (See page 413)

Voice mail messages are held at the Voice

〜・

Mail Center. (See page 398)

The number of record m essages

〜

(See page 75)

The number of videophone record

〜

messages (See page 75)

Before Using the Handset

33

<Desktop Icon>

Status icon

Notification icon
Desktop icon

Using Icons on Desktop

■Operation when a status icon is selected

Shows the display for Vibrator. (See page 100)

Shows the display for Ring Volume. (See page 72)

Shows the display for Manner Mode Set. (See page 104)

Shows the display for releasing Public mode (Drive mode). (See page 73)

Shows the display for Notice Call Cost. (See page 382)

Before Using the Handset

〜・

〜・

■Operation when a notification icon is selected

34

Shows the list of Alarm, Schedul e, ToDo, TV Timer, or Timer Recording.
(See page 253, page 254, page 368, page 372 or page 375)

Shows the Music&Video Channel display. (See page 262)

Shows the display for Backlight. (See page 108)

Shows the display for View Blind. (See page 109)
Shows the display for “Set./Service” → “Display”.

Shows the display for Side Key Guard. (See page 125)

Shows the display for USB Mode Setting. (See page 345)

Shows the display for playing back Voice Mail messages.
(See page 399)

Shows the display for playing back Voice Mail messages.
(See page 399)

Shows the display for Rec. Msg/Voice Memo.

〜

(See page 75, page 76, page 100 and page 380)

Shows the display for Rec. Msg/Voice Memo.

〜

(See page 75, page 76, page 100 and page 380)

Missed call

Shows the Missed Call list. (See page 59)

Missed call to Number B of 2in1

Shows the Missed Call list. (See page 59)

Record message

Shows the Record Message list. (See page 76)

Videophone record message

Shows the Videophone Record Message list. (See page 77)

New i-mode mail or SMS

Shows the Inbox list. (See page 153)

New chat mail

Starts Chat Mail. (See page 177)

New Message R/F

Shows the Message R/F list. (See page 171)

i-αppli did not start automatically

Shows the i-αppli Auto Start Info. (See page 294)

A ToruCa file is received from a scanning device

Shows the ToruCa File list. (See page 304)

A security error occurred on the i-αppli Stand-by display

Shows the Security Error History. (See page 285)

Success in downloading a Music&Video Channel program

Activates Music&Video Channel. (See page 262)

Failure in downloading a Music&Video Channel program

Activates Music&Video Channel. (See page 263)

Missed alarm

Shows the contents of the alarm that could not be notified. (See page 370)

Missed TV timer

Shows the contents of the TV timer that could not be notified.
(See page 257)

Timer recording was completed

Shows the contents and results of the timer recording. (See page 257)

Messages are held at the Voice Mail Center

Shows the display for playing back Voice Mail messages. (See page 399)

The Phonebook could not be updated by Data Security Service

Shows the update display for Data Security Service. (See page 131)

Software Update is needed

Information

Starts Software Update. (See page 483)

Software Update was executed

Shows the Update Completion display or the reason for not completing.
(See page 484)

Software rewriting is possible

Shows the rewriting confirmation display. (See page 482)

Pattern data was updated automatically

Shows the updated result. (See page 487)

The FOMA terminal and a personal computer are connected by the FOMA
USB Cable with Charge Function 01/02 (option)

Shows the display for USB Mode Setting. (See page 345)

■Operation when a desktop icon is selected

Shows the dialing display with the phone number entered. (See page 54)

Shows the site of that URL. (See page 184)

Shows the site of that URL by Full Browser. (See page 210)

Shows the Message Composition display with the mail address entered.
(See page 136)

Shows the SMS Composition display with the mail address entered. (See page 179)

Starts the i-αppli program.※ (See page 283)

Shows it on the Picture viewer.※ (See page 312)

Plays it back by the i-motion player.※ (See page 319)

Plays it back by the Video player.※ (See page 325)

Plays it back by the Chara-den player.※ (See page 329)

Plays it back by the Melody player.※ (See page 332)

Shows it on the PDF viewer.※ (See page 356)

Shows it on the ToruCa viewer.※ (See page 302)

Shows the Bookmark Folder list (i-mode). (See page 191)

Shows the Bookmark Folder list (Full Browser). (See page 191)

Shows the Private menu. (See page 377)

Shows the Still Image list for the storage location folder of the camera.
(See page 312)

Shows the list of Alarm. (See page 368)

Shows the Calendar display. (See page 372)

Shows the ToDo list. (See page 375)

Shows the list of Text Memo. (See page 382)

Shows the calculator. (See page 382)
Shows the display for 使いかたナビ (Guide). (See page 42)

Shows the Bar Code Reader display. (See page 238)

Shows the Ir Data Receiving display. (See page 352 and page 353)

Shows the Camera menu. (See page 229 and page 231)

Starts Voice Recorder. (See page 355)

Shows the i-concier display. (See page 207)

Starts MUSIC Player. (See page 270)

Shows the Music&Video Channel display. (See page 264)

Shows the Viewer display. (See page 245)

Starts i-αppli Program Guide. (See page 250)

※ When the original data is deleted, the desktop icon is disabled.

Paste Icons to Desktop

You can paste up to 15 desktop icons of such as phone numbers, mail
addresses, etc.

Select “Add desktop icon” from the Function menu of

1

the item to be pasted1YES

≥If the addresses of the sender and another recipient of simultaneous mail are

found or the multiple destination addresses are found when you operate from the
Function menu of the detailed mail display, select a mail address or phone
number to be pasted.

≥You may not be able to paste the URL to the desktop depending on the site.
≥When the URL title exceeds 16 full-pitch/32 half-pitch characters, the excess is

deleted. If no title exists, up to 22 half-pitch characters of the URL excluding “http://” or
“https://” is displayed.

≥Some files and data might not be pasted to the desktop.

Before Using the Handset

35

Proceed to Respective Functions from Icons on Desktop

When a record message

icon is selected

Information

Desktop Icon list

Press Oo.

1

≥Desktop icons are not displayed on the horizontal

Stand-by display. Further, you cannot select status
icons by pressing Oo.

Use Mo to highlight an icon, and press Oo().

2

≥Up to five “Desktop icons”

are displayed. If there are
six or more icons, “ ” and
“ ” are displayed.

≥A “Notification icon” is

deleted when each function
is executed. To delete all
“Notification icons”, press

Before Using the Handset

and hold r for at least one second from the display in step 1.

≥When the notification icon of “Messages are held at the Voice Mail Center” ( )

appears while you are overseas, you cannot operate the Voice Mail function from the
notification icon. Follow the steps of “Operate Voice Mail Service at the Country You
Stay” on page 426.

Check Details of Desktop Icon

+m-6-3

m1Set./Service1Display

1

1Desktop icon

The list of desktop icons pasted to the desktop is
displayed.

Select the icon whose details are to be displayed.

2

Function Menu of the Desktop Icon List

≥You can show the Function menu also by pressing i( ), while highlighting an

icon from the Stand-by display.

Add to desktop 1Put a check mark for the function to be added

Edit title 1Enter a title.

Sort 1Select a desktop icon1Use Bo to change the order

long press set. See page 378.

Reset desktop The desktop icons are reset to the default.

Delete this 1YES

Delete all 1YES

<Icons>

1l()

≥You can enter up to 16 full-pitch/32 half-pitch characters.

However, the number of characters for the title displayed when
you highlight the icon is up to 11 full-pitch/ 22 half-pitch
characters from the beginning of the title.

1Oo()

≥To change the order in succession, repeat the above steps.

1l()1YES

1YES

+m-3-6

Displaying Description of Icons

The symbols on the display (such as , , and ) are called icons. You
can check the meanings of them on the display.

m1Set./Service1Display1Icons

1

1Use Mo to highlight an icon.

36

Private Window

Clock Receiving a call

During a voice call

Dialing

Time only Icons and Date/time

Various information is displayed on the Private window like the following
examples:
Information is displayed for about 15 seconds in cases such as when you
press </> with the FOMA terminal closed.

When a missed call is found

When the FOMA terminal is closed, “Missed call” appears.
Press < to display the missed call record. The name is
displayed for the missed call coming from the party stored in the
Phonebook. When there are multiple missed calls, up to three
missed call records are displayed each time you press <.
≥If you have received 30 or more incoming calls after a missed

call, the missed call record disappears.

≥Missed call records might not be displayed while another function is activated.
≥After you display a missed call record, “Missed call” disappears.

When a new mail message or Message R/F is received

When the FOMA terminal is closed, a Feel＊Mail image is played
back, and then “New mail” appears.
When you press <, the latest Feel＊Mail image is played back.
(For Messages R/F, the Feel＊Mail image is not played back.)
When “Mail” on page 108 is set to “ON”, the received date/time,
sender’s address (name), and subject of the mail or the received
date/time and subject of the Message R/F are displayed. The
sender’s name is displayed for the mail coming from the party
stored in the Phonebook. When multiple mail messages or
Messages R/F are received, up to three mail messages or
Messages R/F appear each time you press < with “New mail”
displayed.
≥Press < to end the playback of the Feel＊Mail image or to clear the received date/

time, and others.

≥For the mail messages and Messages R/F sorted to the box or folder with security set,

the Feel＊Mail images, received date/time, and others are not played back/displayed.

≥When a mail message or Message R/F comes in while “Receiving display” is set to

“Operation preferred” and a display other than the Stand-by display is shown, “New
mail” appears without showing any information.

≥Depending on the setting of “Auto-display”, “New mail” appears without showing any

information when a Message R/F comes in.

≥After you display the received date/time and others of the received mail or Message

R/F, “New mail” disappears.

≥When a mail message or Message R/F comes in during a voice call or a videophone

call, information is not displ ayed even when “Receiving display” is set to “Alarm
preferred”.

≥When you set “Secret mail display” to “OFF” and you receive a secret mail message in

Normal Mode, a Feel＊Mail image is not played back.

When i-Channel is received

When “i-Channel ticker” on page 108 is set to “ON” and the
FOMA terminal is closed, tickers flow on the Private window.
≥Press </> to end the tickers’ flow.

Change Clock Display

You can change displayed contents by pressing < while clock is shown.

Before Using the Handset

37

Selecting Menu

1

Main menu icon

Sub-menu item

Function name of lower sub-menu item

Items which appear on the display

No tone. . . . . . . . . Does not sound.

High tone. . . . . . . . High alarm sounds.

Low tone

. . . . . . . . Low alarm sounds.

m

Set./ServiceTalkQuality alarmSelect an alarm.

1

≥Press +Mo to highlight the icon. Press and hold +Mo to scroll

the icons continuously.

≥If you have not touched any key for 15 seconds, the

Stand-by display returns.

+m

+Mo

+Oo

Main Menu

Press m of the FOMA terminal to show Main Menu and then execute,
set, or check respective functions. In this manual, the way to call up
functions from Main Menu is described as a standard method.
Menu are classified by functions. (See page 434)

≥Some functions can be selected also by the operation other than pressing m. In this

case, the operation by the easier way is described.

≥This FOMA terminal supports Kisekae Tool (see page 111). If you use Kisekae Tool to

change the design of the Menu display, some menu configurations change according
to the usage frequency depending on the type of the menu.
Further, some menu numbers that are assigned to the menu items do not apply.

■Scroll Selection

Main Menu is composed of 12 main menu icons indicating each function.
≥If you select a main menu icon, the Sub-menu Item Selection display appears. If you

further select a sub-menu item, the Lower Sub-menu Item Selection display appears.

≥By repeating selecting, you can set and check the function.

Before Using the Handset

■Menu Number Selection

You can display some functions by pressing m + menu number (see page 434).

■Multitask is Supported

≥You can simultaneously use some functions in Main Menu. (See page 365)

Scroll Selection

In this manual, the description of the command navigation key operation
(selection of top/bottom/left/right, and press of Oo after selecting/
entering a function item) is omitted. Scroll selection is explained below
using the example of selecting the function “Quality alarm”:

Description Example of Steps

38

Select a main menu icon from the menu function

Select “Set./Service” from Main Menu. Main Menu at purchase differs depending on the
body color. (See page 438)

Select a sub-menu item from the menu function

2

+Oo

≥The highlighted item is the currently

selected one.

≥Press +Xo to highlight the item

below, and +Zo to highlight the item
above.

≥Press and hold +Bo to scroll the

items continuously.

≥Press +No to scroll page by page.

3

+Oo

≥

Press

+Xo

to highlight the item below,

and

+Zo

to highlight the item above.

≥

Press and hold

+Bo

to scroll the items

continuously.

≥

When the items are listed over
multiple pages, the total number of
pages and the current page number
are shown at the upper right of the
display.

+Oo

≥The highlighted item is the currently

selected one.

≥Press +Xo to highlight the item

below, and +Zo to highlight the item
above.

≥Press and hold +Bo to scroll the

items continuously.

Menu number

<Quality Alarm>

Sounding Alarm when a Line is Nearly Disconnecting



+m-7-5

Select “Talk” from “Set./Service”.

Set or check the function

4

Some menu items have even more detailed menus.
The example below shows how to set “Low tone” for “Quality alarm”.

Before Using the Handset

Select a desired lower sub-menu item (function)

Select “Quality alarm” from “Talk”.

Menu Number Selection

Menu Number Selection is explained below using the following example:

Description Example of Menu Number

39

Call up the function using the menu number

1

+m

-7-5

+m

+i

Delete all You can delete all files.



Enter your Terminal Security CodeYES

Item displayed in the Function menu

Operating procedures after selecting
an item in the Function menu

From the Stand-by display, press m75.

Before Using the Handset

Horizontal Open Menu

Horizontal Open Menu enables you to quickly access the functions that
are available for the horizontal display. To show Horizontal Open Menu,
press m from the horizontal Stand-by display.

≥Horizontal Open Menu at purchase differs

depending on the body color.
(See page 439)

≥When “Work with style” is set to “Horizontal

open menu”, Horizontal Open Menu
automatically appears just by switching to
Horizontal Open Style.

≥If you have not touched any key for 15

seconds, the Stand-by display returns.

≥Some operating procedures and items on

the display of Horizontal Open Menu differ
from the ones described for Normal Style in
this manual.

Simple Menu

Simple Menu is a menu focusing on only basic functions for easy
operation. By setting “Menu icon setting” to “Simple menu”, you can
show the Simple Menu by pressing m from the vertical Stand-by
display.

≥Some operating procedures or items which appear on the display in Simple Menu differ

from the ones described in this manual.

≥See “Simple Menu Function List” on page 452 for the contents of Simple Menu.

Function Menu

If you press i when “ ” is shown at the lower right of the display,
the Function menu including selectable items such as “Save”, “Edit”,
and “Delete” appears in each operation. The contents of the Function
menu depend on the display from which you show the Function menu.

≥When the items are listed

over multiple pages, the total
number of pages and the
current page number are
shown at the upper right of
the Function Menu display.

Description Example for Function Menu

In this manual, the operation of the Function menu is described as
follows:

40

An actual operation is done as follows:

Press +i().

Use +Mo to highlight
“Delete all” and press

+Oo().

Enter your Terminal
Security Code and
press +Oo().

Use +Bo to highlight
“YES” and press

+Oo().

Item number

For Reset Settings

To select an item quickly <Direct selection>

Press the numeric key corresponding to the
displayed item number.

Item scroll

When menu items are listed over multiple pages, you can show the previous/next page
by pressing Bo with the uppermost/lowermost item highlighted. You can press No to
scroll through page by page. When / is displayed on the display, you can
scroll through page by page also by pressing m()/c().
≥Depending on the display being shown, such as lower sub-menu items, you might be

able to scroll through page by page also by pressing </> instead of No.

Check box

With the functions you can select multiple items, put a check
mark for check boxes to select them.
Each time you press
“”.
With some functions, you can put or clea r check marks at a time by pressing
and selecting “Select all/Release all”or by pressing
≥ “ ” is placed to the selected item depending on the function.

Oo

( ), you can switch “ ” and

m(/)

i()

.

After finishing the operation

The Lower Sub-menu Item Selection display is shown. When you press h, the
Stand-by display returns (except during Multitask). The Stand-by display or the former
display automatically returns depending on the function.

To cancel the operation midway

Press h. The contents of the setting are abandoned and the Stand-by display or the
former display returns. The confirmation display appears asking whether to abandon the
setting contents depending on the function. You can press r to return to the previous
operation.

When the “YES/NO” selection display appears

Press Bo to highlight “YES” or “NO”, then press Oo().

Before Using the Handset

41

<Guide>

Cut

When You Forget Key Operation

You can search for the functions you want to know and use, and then
check the operating methods. You can execute some functions from
“

使いかたナビ

m1ステーショナリー

1

1

おすすめ機能 (Recommendable functions)

. . . .Displays the recommendable functions. Go to step 3.

キーワード検索 (From keywords)

. . . .Enter keywords and retrieve. Go to step 2

機能一覧検索 (From Function list)

. . . .Retrieves from the function list. Go to step 3.

検索履歴 (Search history)

Before Using the Handset

. . . .Displays up to 30 search histories. Go to step 3.

≥Highlight each item and press l( ); then the

≥The 使いかたナビ(Guide) display appears also by selecting the 使いかたナビ

≥You can store “使いかたナビ (Guide)” for Multi Key Long Press Setting. (See

Enter a keyword.

2

Up to 50 search results are displayed.
≥You can enter up to 24 full-pitch/48 half-pitch characters.

Select a function1Select an item.

3

機能の説明 (Description) . . . . . . . . Displays explanations for the function.

操作のしかた (How to operate) . . . Displays the operating method.
この機能を使う (Operate function)

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Executes the function. Operate each function.

≥For some functions, press Oo( ) several times for selection.
≥You can display explanations about the function also by pressing l()

≥To delete search history, press i( ) and select “1件削除 (Delete this)” or

(Guide)”. This function is available in Japanese Mode only.

(Stationery)

使いかたナビ

detailed operating methods are displayed.

(Guide) icon “ ” pasted on the desktop at purchase.

page 378)

while highlighting the function.

“全削除 (Delete all)”, then select “YES”.

(Guide)1Select an item.

Using UIM (FOMA Card)

The UIM is an IC card that holds your information such as phone
numbers. It can hold data such as Phonebook entries and SMS
messages as well. By sharing a UIM, you can operate multiple FOMA
terminals for multiple purposes.
You cannot use the FOMA terminal for communication such as voice and
videophone calls, i-mode, sending/receiving mail, or packet
communication unless the UIM is inserted.
For details on how to use the UIM, refer to the UIM instruction manual.
When inserting or removing the UIM, take care not to accidentally touch
or scratch the IC.

Insert/Remove

You need to turn off the power and then remove the battery before you
insert the UIM. (See page 44)

■Inserting

With the golden IC surface

1

downward, push the UIM slowly to
the end while pressing the surface
of it.

■Removing

While sliding the UIM, pull it out

1

slowly.

42

Information

≥Make sure that you insert/remove the UIM with the FOMA terminal closed and held in

your hand.

≥Take care not to force the UIM into place because this can break it.
≥Take care not to lose the UIM once you remove it.
≥When you replace your UIM (except during Omakase Lock), you need to enter the

four- to eight-digit Terminal Security Code after turning on the power. When you enter
the correct Terminal Security Code, the Stand-by display appears. If you enter the
incorrect Terminal Security Code five times in succession, the power turns off.
(However, you can turn on the power again.)

Security Code

You can set two security codes, PIN1 and PIN2, for a UIM. (See page 118)

Security Function of UIM

The FOMA terminal has the UIM security function (UIM restriction
function) as a security function to protect your data files.
If you obtain data files by the method below with the UIM inserted, UIM
security function is automatically set to them.

・When downloading images or melodies and so on, from sites or

Internet websites

・When receiving i-mode mail with file attachments

The data files with the UIM security can be browsed, played back, started,
edited, attached to mail, or transferred via infrared rays only when the
UIM used for obtaining is inserted. When the UIM used for obtaining the
data or files is not inserted, or when another UIM is inserted, these
functions are not operable.

≥In the explanation hereafter, the UIM used to obtain data and files is referred to

as “your UIM” and other UIMs as “another person’s UIM”.

♪

♪

♪

♪

♪

If the UIM used for
obtaining data files
or mail messages is
inserted, you can
browse/play back the
data files with the UIM
security.

≥When the UIM is not inserted or when another person’s UIM is inserted, the following

types of data and files are displayed with the restrictions symbol, “ ”:

・Videophone record messages ・Movie memos ・Screen memos
・Templates ・i-αppli programs ・Images
・i-motion movies ・Chara-den images ・Melodies
・Machi-chara images ・Kisekae Tool files ・PDF files
・Chaku-uta®/Chaku-uta Full® music files ・Downloaded dictionaries
・Files attached or pasted to i-mode mail in the Inbox
・Files attached to i-mode mail in the Outbox/Draft (except the data shot or edited

with the FOMA terminal)

・Messages R/F with files (melodies or images) attached or pasted
・Images inserted into Deco-mail text

※This function applies to the pre-installed i-αppli programs, Chara-den images,

Deco-mail pictograms, etc. if they are reinstalled (upgraded) from a site.

※“Chaku-uta” is a registered trademark of Sony Music Entertainment Inc.

≥The preview image for the data file with the UIM security appears as

shown on the right.

Replacing UIMs

Your UIM

Another

person’s UIM

♪

♪

♪

♪

Unless the UIM used
for obtaining data files
or mail messages is
inserted, you cannot
browse/play back the
data files with the UIM
security.

♪

Before Using the Handset

43

Information

≥When the UIM security is set for data files, you cannot set them for the functions such

as “Display setting” and “Select ring tone” when another person’s UIM is inserted.

≥When the data files with the UIM security is set for “Display setting” or “Select ring

tone”, the FOMA terminal works with their default settings if you remove your UIM or
replace it with another person’s UIM. Also, a Machi-chara image is cleared. If you
insert your UIM again, your settings are enabled again.

≥The UIM security function is not set for the data files received using the infrared

communication function or data transmission (OBEX™ communication) function and
the still images/movies shot or edited with the FOMA terminal.

≥Even when another person’s UIM is inserted, you can move/delete data files with the

UIM security.

≥The settings of the following functions are stored on the UIM:

・SMS validity period ・SMS center selection ・Select language
・PLMN setting ・PIN1 code, PIN2 code ・PIN1 code entry set
・Validating/Invalidating DOCOMO Certificate 1 and user certificate

Before Using the Handset

Types of UIM (FOMA Card)

If you use the blue UIM with your FOMA terminal, note that following
specifications differ from those of the green/white UIM:

Functions

Number of digits of the phone number
that can be stored in the UIM Phonebook

Operation of user certificate to use
FirstPass

Use of WORLD WING Not available Available 418

Use of Service Numbers for “DOCOMO
repair counter” and “General inquiries
<docomo Information Center>”

UIM

(blue)

20 max. 26 max. 85

Not available Available 200

Not available Available 405

(green/white)

Reference

■WORLD WING

WORLD WING is the DOCOMO FOMA international roaming service that enables
you to use the current phone number overseas for making and receiving calls using
the UIM (green/white) and service compatible mobile phone.
You can use P-10A only in the DOCOMO 3G roaming service area. For the use in a
GSM service area, insert the UIM into a GSM service compatible mobile phone.
≥You do not need to subscribe to WORLD WING if you have subscribed to the FOMA

service after September 1, 2005. If you offered that you did not need WORLD WING
at the time you signed up for the FOMA service, or when you have midway canceled
WORLD WING, you are required to take the procedures to newly subscribe to
WORLD WING.

≥If you have signed up for the FOMA service before August 31, 2005, and have not

yet subscribed to WORLD WING, you are required to subscribe to it.

≥This service is not available with some billing pl ans.
≥If you lose your UIM (green/white) or have it stolen overseas, immediately contact

DOCOMO to take the steps necessary for suspending the use of the UIM. For
inquiries, see “docomo Information Center” on the back page of this manual. Note
that you are still charged the call and communication fees incurred after you lose it or
have it stolen.

Attaching/Removing Battery Pack

Use the FOMA terminal’s dedicated Battery Pack P19.

■Attaching

From the “ ” part on

1

the FOMA terminal, lift
the back cover up in the
direction of the arrow
mark, and remove.

≥Sound might be emitted when

you remove the back cover.

44

With the arrow mark facing up, fit

Arrow mark

Upper
claw

Packing

Rear surface of back cover

Projection

Information

2

the tab side of the battery pack to
the FOMA terminal securely, and
then push the battery pack into
the direction B while pressing it
against the direction A.

Correctly fit the claw at the upper part of the back cover

3

into the FOMA terminal, and fit the claws at the left, right,
and bottom into the notches for attaching.

Push the seven ● marks printed

4

on the sticker, and ensure that no
float is found anywhere on the
cover.

Waterproof Performance

≥When you remove the back cover, ensure that you wipe well moisture off the FOMA

terminal.

≥Do not peal off or give damage to the packing at the rear of the back cover. The

waterproof performance might be deteriorated.

≥When you attach the back cover, ensure that no dirt or stain adheres to around the

back cover (especially to the packing).

≥Water might enter inside unless you attach the back cover securely.

■Removing

Remove the back cover following

1

the step 1 of “■Attaching”, and
take hold of the projection of the
battery pack to lift it up.

≥Make sure that you turn off the power, hold the closed FOMA terminal in your hand,

and then attach/remove the battery pack. Also, take care not to press the one-push
open button when you attach/remove the battery pack.

≥If you try to force the battery pack into place, you could damage the UIM or the

terminal part of the FOMA terminal.

Before Using the Handset

45

Charging

Li-ion 00

Use the FOMA terminal’s dedicated Battery Pack P19.
Life of battery pack

≥Battery packs are consumables. The usable time shortens slightly each time they are

charged.

≥When the usable time of the battery pack becomes half the time it was purchased,

replacing is recommended because the battery pack is nearing the end of its life.
Depending on the use conditions, the battery pack may swell as it nears the end of its
life, but this is not a problem.

≥The life of the battery pack may shorten if you use i-αppli programs, talk on the

videophone, watch 1Seg programs and so on for a long time during charging.

To prevent damage to the environment, bring used battery
packs to a docomo service counter, a docomo agent or a
recycle center.

Charging

≥For details, refer to the instruction manuals for the FOMA AC Adapter 01/02 (option),

Before Using the Handset

FOMA AC Adapter 01 for Global use (option), and FOMA DC Adapter 01/02 (option).

≥The FOMA AC Adapter 01 supports 100 V AC only. The FOMA AC Adapter 02 and

FOMA AC Adapter 01 for Global use support from 100 V AC through 240 V AC.

≥The shape of the plug for the AC adapter is for 100 V AC (for domestic use). To use the

AC adapter that supports from 100 V AC through 240 V AC overseas, you need to
have a conversion plug adapter that is compatible with the voltage of the country you
stay. Do not use a transformer for overseas travel to charge the battery pack.

≥Even during charging, you can still answer calls if the FOMA terminal is turned on. This

will consume the charged amount so that charging will take longer. Also, the standby
time or talk time might be shorter if you charge the battery pack with your FOMA
terminal open.

≥If you have a long time videophone call during charging, the temperature in the FOMA

terminal may rise and charging may be suspended. In such a case, wait for a while and
try charging again.

≥Remove and insert the connector slowly and carefully, without using unnecessary

force.

≥Do not remove the battery pack during charging.

46

Do not charge for long periods of time (several days) with the FOMA
terminal turned on.

≥If you leave the FOMA terminal powered on for long periods of time during charging,

you may not be able to use the FOMA terminal for long duration as expected and the
low battery alarm may sound soon, because the FOMA terminal receives the power
from the battery pack after charging is completed. If this happens, charge the battery
pack correctly. When charging the battery pack again, first remove the FOMA terminal
from the AC adapter (or desktop holder) or DC adapter and then set it again.

Estimated usable time for battery pack (The usable time for the battery pack

varies with the charging time and the remaining life of the battery pack.)

Continuous standby time
(

FOMA/3G)
Continuous talk time
(

FOMA/3G

)

1Seg watching time

※The continuous talk time is the estimated time that the FOMA terminal can be used for

calls when radio waves can be sent and received normally.

※The 1Seg watching time is the estimated time for when radio waves can be received

normally with the Stereo Earphone Set 01 (option) connected.

※The continuous standby time is the estimated time for when radio waves can be

received normally. The talk/communication time and standby time could be about half
of the estimate and 1Seg watching time could be shorter depending on the charge
level of the battery pack, function settings, other ambient conditions such as
temperature, and the status of radio waves in the area (weak or no radio waves, for
instance). When you use i-mode communication, the talk/communication time and
standby time will be shorter. Further, even if you do not make calls or not execute
i-mode communication, the talk/communication time and standby time will be shorter if
you watch 1Seg programs, compose i-mode mail, start up a downloaded i-αppli
program or the i-αppli Stand-by display, execute data communication or Multiaccess,
use the camera, or play back movie, i-motion movie or music.

※The continuous talk time and the continuous standby time may be shortened

depending on the network environment in the country you stay.

※

The continuous standby time for standstill is the average number of hours you can use the
FOMA terminal in standstill status when it is closed and can receive radio waves normally.

※The continuous standby time for in motion is the average number of hours you can

use the FOMA terminal in the combined status of “standstill” “moving” and “out of the
service area” when it is closed, in an area where it can receive radio waves normally.

Estimated time for charging battery pack

AC adapter Approx. 120 minutes DC adapter Approx. 120 minutes

※The charging time is an estimate of time for when empty battery pack is charged with

the FOMA terminal turned off. The charging time will be longer if you charge the
battery pack with the power of the FOMA terminal turned on.

Standstill: Approx. 640 hours
In motion: Approx. 400 hours
Voice call: Approx. 200 minutes
Videophone call: Approx. 140 minutes
Approx. 350 minutes
(when Mobile W-Speed is OFF: Approx. 390 minutes)
(in ECO Mode: Approx. 500 minutes)

Charge with AC Adapter and Desktop Holder

1

Plug the connector of AC
Adapter (option) horizontally
with its engraved side facing
down into the connector
terminal of the Desktop Holder
(option).

2

Pull out the AC Adapter's plug,
and plug it into a household
power socket of 100 V AC.

Call/Charging
indicator

Desktop Holder

Engraved surface
(down side)

AC Adapter

Stopper

Power
socket

Lock claw

AC Adapter’s
plug

Connector

Release
buttons

Engraved
surface

Put the bottom of the FOMA terminal into the stopper of

3

the desktop holder (A) to fit the head to the lock claw,
and then depress the FOMA terminal until it clicks (B).

Check that the Call/Charging indicator lights in red.
When the Call/Charging indicator flickers, dismount the AC adapter and battery
pack from the FOMA terminal and then re-mount them for charging.
If the symptom persists, troubles with the AC adapter, desktop holder or battery
pack may be involved, so consult a handling counter such as a docomo Shop.

≥Be sure to charge the FOMA terminal with the FOMA terminal closed.
≥The charging confirmation tone (see page 101) sounds when charging starts and

ends. However, it does not sound when the power is off or during Manner Mode
or Public mode (Drive mode).

≥Be sure to set the FOMA terminal firmly onto the desktop holder. Also, be careful

that the connector cover or a commercial strap is not caught between the FOMA
terminal and desktop holder.

When charging is completed, hold the desktop holder

4

with fingers and lift up the head of FOMA terminal to
remove.

≥Unplug the AC adapter from the power socket when you are not going to use it for

a long time.

■Indicator and display during charging and when charging is completed

Call/Charging indicator “ ” display

Charging Lights in red Blinks

Charging completed Off Lights

≥When the FOMA terminal is turned off, “ ” does not appear.

If you start charging with the battery flat, the Call/Charging indicator might not light
immediately; however, charging itself has started.

When charging only with the AC adapter

Insert the connector with the engraved surface
facing up until it clicks. Pull straight the connector
out while pressing the release buttons.

≥

To charge the battery, place the cover of the
connector terminal as illustrated.
Hook your finger over the groove (see page 20), pull
out the cover to direction A, and turn it as direction B.

※Check the facing direction (front or rear) of the

AC adapter plug and then insert or pull it
horizontally into or out of the FOMA terminal.
Malfunction could result if you try to pull it
forcibly.

■DC adapter (option)
With the DC adapter, you can use a cigarette lighter socket (12 V/24 V) of cars to
charge the FOMA terminal with the battery pack attached.
For details, refer to the instruction manual for the FOMA DC Adapter 01/02.

Waterproof Performance

≥To prevent water from entering inside through the connector terminal, you are advised

to use the desktop holder for charging.

≥Do not peal off or give damage to the packing at the rear of the back cover. The

waterproof performance might be deteriorated.

≥Securely close the connector terminal cover after charging is completed. Otherwise

water might enter inside.

47

Before Using the Handset

Information

≥If the fuse blows off when charging with the DC adapter, be sure to use a 2A fuse. The

Almost full Getting low Almost empty

※

Almost empty.
Charge the battery pack.

Three beeps Two beeps One beep

Recharge Battery

display

Stand-by display

2A fuse is consumables, so purchase at auto parts stores in your neighborhood.

<Battery Level>

Checking Battery Level

When the FOMA terminal is turned on, an estimate of the battery level is
indicated by the icon.

・Almost full . . . . . . . . . . . . . . . . . . .

・Getting low . . . . . . . . . . . . . . . . . .

・Almost empty . . . . . . . . . . . . . . . .

≥Charge the battery pack when it is almost empty.

Check Estimate of Battery Level by Display and Tone

Before Using the Handset

You can check an estimate of the battery level by the display and sound.

m1Set./Service1Other settings1Battery

1

1Battery level

≥The pictogram disappears in about three seconds.
≥The battery level tone does not sound during Manner Mode or when you set

“Keypad sound” to “OFF”.

48

When the battery is running out

When the battery runs out, the display on the right appears and
the low battery alarm sounds for about 10 seconds. To stop
this alarm, press any key other than < and >. About one
minute later, the FOMA terminal will be turned off.
≥During a call, a beeping tone from the earpiece notifies you of

the low battery. About 20 seconds later your call will be cut
and then one minute later the FOMA terminal will be turned
off.

<Power ON/OFF>

Turning Power ON/OFF

Turn Power On

Press and hold h for at least one

1

second.

After the Wake-up display (see page 106) and notes of
waterproof are displayed, the Stand-by display appears.

≥It may take a while for the Wake-up display to appear.
≥If Set Time is set, the current date and time are shown.
≥When “ ” is displayed, the FOMA terminal is out of

the service area or in the place where the radio waves
do not reach. Move to a location where “ ”
disappears.

When your UIM is replaced (except during Omakase Lock)

Enter the four- to eight-digit Terminal Security Code after turning on the power. When
you enter the correct Terminal Security Code, the Stand-by display appears. If you enter
the incorrect Terminal Security Code five times in succession, the power turns off.
(However, you can turn on the power again.)

When “PIN1 code entry set” of “UIM setting” is set to “ON”

Enter the four- to eight-digit PIN1 code after you turn on the power. When you enter the
correct PIN1 code, the Stand-by display appears. See page 118 for PIN1 code.

When “Auto reset setting” of “Notice call cost” is set to “ON”

Information

Information

(except during Omakase Lock)

Enter the four- to eight-digit PIN2 code after you turn on the power. When you enter the
correct PIN2 code, the Stand-by display appears. If you press r or h without
entering the correct PIN2 code, “Auto reset setting” is set to “OFF” and the Stand-by
display appears. See page 118 for PIN2 code.

Check Welcome Mail

The mail messages “Welcome ドコモ動画 (Welcome DOCOMO
Movie )” and “緊急速報「エリアメール」のご案内 (Introduction of Early Warning
“Area Mail”)” have been saved by default. Press +Oo twice or perform step 1 on
page 153 to show the Inbox list.

≥Each entry display appears in the order of “PIN1 code” → “Terminal Security Code”

→ “PIN2 code”.

Turn Power Off

Press and hold h for at least two seconds.

1

The exit display appears and the power turns off.
≥You cannot turn on the power immediately after turning off the power. Wait a few

seconds.

<Select Language>

+m-1-5

Switching to English Display

m1

1

設定／サービス

1

ディスプレイ

1

Japanese (

≥

The following functions are different between Japanese display and English display:

→ “Stand-by clock/Stand-by clock Wide”

日本語

Functions Japanese English

Info Notice Setting 電子音 (Electrical tone)

“Clock” of Display Setting

→“Day of week”

(Set./Service)

(Display)1バイリンガル

) or English (英語)

ボイス (Voice)

OFF

Available Not available

(Select language)

ON

Not available

OFF

Functions Japanese English

使いかたナビ (Guide) Available Not available

Voice Guidance Available Not available

≥When you insert the UIM, the “バイリンガル (Select language)” setting is stored on

the UIM.

<Initial Setting>

Configuring Initial Setting

If the date and time, Terminal Security Code, Keypad Sound, or Font Size
is not set, the Initial Setting display appears when you turn on the power.
You can set the initial settings also from each menu function separately.

Turn on the power1YES

1

≥When the display for entering your Terminal Security

Code, PIN1 code, or PIN2 code appears, follow the
operation on page 48.

Set the date and time.

2

You can select “Auto time adjust ON” or “Auto time adjust OFF” for setting the time.
(See page 50)

Set your Terminal Security Code.

3

You can set your Terminal Security Code required for setting functions.
(See page 118)

1. Enter “0000”1Enter your new Terminal Security Code (four to eight digits)

1YES

Set Keypad Sound.

4

You can set whether to make a keypad sound. (See page 101)

Set the size of characters.

5

You can set the size of characters on the display at a time. (See page 115)

Before Using the Handset

49

Information

≥When an unset function is found, the Initial Setting display for the unset function

Information

appears each time you turn on the power.

≥The completed settings are valid even when total setting is interrupted by an incoming

call or canceled by pressing -h or -r midway.

≥When the power is automatically turned on by alarm notification, the Initial Setting

display does not appear even if there is any unset function.

≥When you finish the initial settings, the confirmation display appears telling that

updating software is executed automatically. This display appears only at the first
time, and after that, does not appear until you execute Reset Settings or Initialize.

<Set Time>

+m-3-1

Setting Date and Time

You can select whether to correct the time automatically or set it
manually. The time is set/displayed on the 24-hour basis.

Before Using the Handset

m1Set./Service1Clock1Set time

1

1Auto time adjust ON or Auto time adjust OFF

Auto time adjust ON

. . . . Corrects the date/time automatically. The setting is completed.

When the time cannot be corrected automatically such as when “ ” is
displayed and the date/time has not been set, the Manual Time Setting
display appears. Follow step 2 to set the date/time.

Auto time adjust OFF

. . . . Sets the date/time manually.

≥When “Notice call cost” is set to “ON”, you need to enter your Terminal Security

Code.

Enter year, month, date and time.

2

Use Mo to move the cursor and enter numbers by the
numeric keys.
≥To enter one-digit numeral for the date and time, enter

two digits beginning with “0” as in “01” through “09”.

≥Highlight “Time zone” and press l( ) to set the

time zone. Use Mo to select a region and press Oo().

About date/time correction function

This function corrects the time of the FOMA terminal according to the clock information
obtained from the network when you turn on the power.
The time is corrected when you show the Stand-by display with “Auto time adjust ON”
set.
If the time is not corrected for a while after you turn on the power, turn it off and then on
again.

≥

Some few second errors might occur. You might not be able to correct the time depending
on the radio wave conditions, or the i-αppli program set for the i-αppli Stand-by display.

≥When you receive the clock information overseas and the time difference correction

information differs from the previously received one, “Time is adjusted” is displayed and
the time difference is corrected automatically. Press “OK” to update the time and show
Redial, Dialed Calls, Received Calls, sent/received mail messages and others in local
time.

≥Depending on the overseas carrier, the time difference might not be correctly adjusted.

In such a case, set a time zone manually.

≥Unless Set Time is set, the functions which use the clock such as Schedule do not

work correctly. Further, the date/time for redial items and received call records are not
stored.

≥The set time is retained even when the battery pack is replaced, however, it might be

reset if the battery pack is left removed for a long time. In that case, charge the FOMA
terminal and then perform the clock setting.

≥When “Time zone” is set to other than “GMT +9” or the time difference is corrected

overseas, the sub clock (Japanese date/time, etc.) is displayed on the Stand-by
display.

≥This function supports clock settings from 00:00 on January 1, 2009 through 23:59 on

December 31, 2037.

<World Time Watch>

Displaying World Time

You can display the time of the specified area on the Stand-by display.

m1Set./Service1Clock1World time watch

1

1ON or OFF
1Use Mo to select an area and press Oo().

50

Information

≥World Time Watch does not appear when “Display setting” → “Clock” → “Stand-by

Own Number display

Phone number tab

List tab

Information

clock/Stand-by clock Wide” → “Position” is set to “OFF”, or when you use the FOMA
terminal overseas.

Summer Time

You can advance the time displayed for the overseas country you stay
and for a region of World Time Watch by one hour.

m1Set./Service1Clock1Summer time1ON or OFF

1

<Own Number>

Checking Your Own Phone Number

≥Your phone number (own number) is stored on the UIM.

m1Phonebook1Own number

1

You can press No to switch the tabs.
≥See page 379 fo r storing/displaying personal data.

+m-0

Before Using the Handset

<Caller ID Notification>

Notifying the Other Party of Your Phone Number

You can set the FOMA terminal to send your phone number to the called
party’s phone when dialing. Your phone number is important
information, so take utmost care when notifying your phone number.
This function is available only when the other party’s phone supports
Caller ID.

Set Caller ID Notification to Network

You can set whether to notify your caller ID on the network.

m1Set./Service1NW services1Caller ID notification

1

1Do the following operations.

Activate 1ON or OFF

Check setting You can check the setting contents of “Activate”.

+m-1-7

≥In Dual Mode of 2in1, you can switch between Number A and Number B by pressing

+Oo( ) from the Own Number display. “ ” appears for Number A, and “ ”

appears for Number B.

≥When you replace a UIM with another one while using 2in1, 2in1 Setting is

deactivated. For using 2in1, activate 2in1 Setting.

51

52

Voice/Videophone Calls

Making Calls/Videophone Calls

Videophone Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Making a Call/Videophone Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Switching a Voice/Videophone Call . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Using Call Records. . . . .<Redial> <Dialed Calls> <Received Calls> 58

Using Chaku-moji . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <Chaku-moji> 60

Setting Caller ID to Send/Not to Send for Each Call . . . . .<186/184> 62

Sending Touch-tone Signals . . . . . . . . . . . . . . . . . . . . . <Pause Dial> 63

Making International Calls . . . . . . . . . . . . . . . . . . . . <WORLD CALL> 64

Setting for International Calls . . . . . . . . .<International Dial Assist> 65

Storing Numbers to be Added to the Beginning of a Phone Number

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .<Prefix Setting> 66

Making a Call Specifying a Sub-address . . . <Sub-address Setting> 66

Setting Alarm for Reconnecting . . . . . . . . . . . . <Reconnect Signal> 66

Making Voice Clear According to Surrounding Noise

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <Shikkari Talk> 67

Reducing Surrounding Noise to Make Voice Clear

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <Noise Reduction> 67

Slowing Down the Other Party’s Speaking Speed

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <Yuttari Talk> 67

Switching to Hands-free. . . . . . . . . . . . . . . . . . . . . . . . .<Hands-free> 67

Using Hands-free Compatible Devices. . . . . . . <In-Car Hands-free> 67

Receiving Calls/Videophone Calls

Receiving a Call/Videophone Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

Switched between a Call and a Videophone Call by the Other Party

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

Setting Response of Key Operation for Answering Incoming Calls

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <Answer Setting> 70

Setting Response for when Opening FOMA Terminal while Ringing

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <Setting when Opened> 71

Setting Response for when Closing FOMA Terminal during a Call

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <Setting when Closed> 71

Adjusting Earpiece Volume . . . . . . . . . . . . . . . . . . . . . . . . .<Volume> 71

Adjusting Ring Volume . . . . . . . . . . . . . . . . . . . . . . . <Ring Volume> 72

When You cannot/could not Answer a Voice/
Videophone Call

Putting a Call on Hold when You cannot Answer Immediately

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <On Hold> 72

Putting a Call on Hold during a Call . . . . . . . . . . . . . . . . . <Holding> 72

Setting Hold Tone . . . . . . . . . . . . . . . . . . . . . . . . . . . <Set Hold Tone> 73

Using Public Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

When You could not Answer an Incoming Call . . . . <Missed Calls> 74

Recording Voice/Video Messages when You cannot Answer a Call

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <Record Message Setting> 75

Recording a Message when You cannot Answer an Incoming Call

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <Quick Record Message> 76

Playing/Erasing Record Messages/a Voice Memo/Videophone Record
Messages/Movie Memos

. . . . . . . <Play/Erase Messages> <Play/Erase Videophone Messages> 76

Making Full Use of Videophone Calls

Using Chara-den . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77

Useful Functions for Videophone Calls . . . . . . . . . . . . . . . . . . . . . . . 78

Setting Hands-free Videophone. . . . <Hands-free with Videophone> 80

Setting Image Quality for Videophone Calls

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <Visual Preference> 80

Changing Image Displays for Videophone Calls . . . <Select Image> 80
Redialing as a Voice Call when a Videophone Call cannot be

Connected . . . . . . . . . . . . . . . . . . . . . . . <Voice Call Auto Redial> 81

Setting for Switching a Voice/Videophone Call during a Call

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <Notify Switchable Mode> 81

Selecting Response to Incoming Videophone Calls during i-mode

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <Videophone while Packet> 82

Using Videophone Calls by Interfacing to External Devices . . . . . . 82

53

Videophone Calls

1

3

4

2

4…Status

: Voice sending/receiving
(gray): Voice sending/

receiving failed

※1

: Image sending/receiving
(gray): Image sending/

receiving failed

※2

: Camera image sending
: Still image sending
: Chara-den talking

: Hands-free activated
: Close-up
: Landscape
: Night Mode

: Chara-den Whole

Action Mode

: Chara-den Parts Action

Mode

: DTMF Transmission

Mode

Between the DOCOMO phones which support videophone calls, you can
talk while viewing sent/received images. By default, the substitute image
is displayed at the position of the sent image.

This FOMA terminal has no inward-facing camera. Therefore, the image sent to
the other party is a Chara-den image, still image, or image being shot by the
outward-facing camera.

DOCOMO videophones conform to 3G-324M, standardized by the international
standard 3GPP. You cannot connect to the videophone that uses a different format.

≥3GPP (3rd Generation Partnership Project):

This is the regional standards organization for developing common technical
specifications for third-generation mobile telecommunication systems (IMT-2000).

≥3G-324M:

This is the international standard for the third generation of mobile videophones.

≥P-10A supports only 64 kbps communication speed of the videophone.

You cannot talk on the videophone at 32 kbps communication speed.

Voice/Videophone Calls

■Display during videophone calls

1…Received image (The other party’s image through the

camera or substitute image)

2…Sent image (Substitute image or Image through your

camera)

3…Call duration

※1 When voice sending fails, the other party cannot hear your voice.

When voice receiving fails, you cannot hear the other party’s voice.

※2 When image sending fails, the sent image is not displayed at the other end.

When image receiving fails, the received image is not displayed.
When voice or image sending/receiving fails, it does not recover automatically. You need
to make a videophone call again.

54

Making a Call/Videophone Call

Enter the other party’s phone number,

1

starting with the city code.

≥When 27 or more digits are entered, the lower 26 digits

only are displayed.

≥To store an entered phone number in the Phonebook,

press m( ). Go to step 2 on page 88.

≥Even when you are dialing within the same area, you

need to enter the city code before the phone number.

When Making a Voice Call

2

Press d or Oo().

≥“ ” blinks during dialing, and lights during a call.

When Making a Videophone Call

The digital communication
charging starts from this
display.

Information

Information

Press l().

≥“ ” blinks during dialing and lights during the call.
≥Press m during a videophone call to switch between

the substitute image and image through your camera
for sending to the other party.

Press h to end the call after talking.

3

≥If you hear the guidance requesting your caller ID (see page 404), follow the steps of

“To notify your caller ID” on page 62 to enter “186” and redial.

≥When an earphone/microphone (option) is connected, you can hear the other party’s

voice from the earphone. (See page 384)

≥If you close the FOMA terminal during a call, the FOMA terminal works in accordance

with the setting of “Setting when closed”. (See page 71)

≥If you switch to Horizontal Open Style during a call, the FOMA terminal is set to “No

tone” (see page 71). For a videophone call, the still image set for “Holding” of “Select
image” is sent to the other party.

≥You can press numeric keys to send touch-tone signals during a call. During a

Chara-den call, you need to switch to DTMF Transmission Mode. (See page 79)

≥You cannot make a call in Horizontal Open Style. However, when an earphone/

microphone (option) is connected, you can make a voice call in Horizontal Open
Style.

≥In Dual Mode of 2in1, you can make a call after selecting Number A or Number B.

(See page 410)

<For Voice Calls>

≥You can make a voice call also by pressing -d and then entering the party’s phone

number. If you enter a wrong number, press -h to clear the display and then redial.

<For Videophone Calls>

≥Just after purchase, Hands-free is automatically activated by “Hands-free

w/ V. phone” (see page 80). However, Hands-free is deactivated during Manner Mode
regardless of “Hands-free w/ V. phone”.

≥When you make a videophone call with substitute image, note that you will still be

charged for the digital communication, not the voice calls.

≥If you make a videophone call at 110/119/118 from the FOMA terminal, it is

automatically dialed out as a voice call.

≥The international videophone call is available using the DOCOMO international call

service “WORLD CALL”. (See page 64)

Display when dialing

The other party’s name and icon are displayed if the party’s phone number and name
are stored in the Phonebook. However, the image is not displayed even if it is stored in
the Phonebook.
≥If the same phone number is stored with multiple names in the Phonebook, the name

that comes first in the search order (see page 90) is displayed.

≥The phone number instead of the name is displayed when you make a call during

Personal Data Lock or to the party stored as secret data in the Phonebook.

If you entered a wrong phone number

Each time you press r, the digit on the far right is cleared. If you press and hold r
for at least one second, all the digits are cleared and the Stand-by display returns.
≥Press No to move the cursor to the digit you want to clear, and then press r to clear

it. To clear all the digits on and to the right of the cursor, press and hold r for at least
one second.

Voice/Videophone Calls

55

If a videophone call could not be connected

The reason why it could not be connected is displayed. (The displayed reason might not
be the same as the actual reason depending on the type of the other party’s phone and
contract for network services.)

Messages Reasons

Check number, then
redial
Busy The other party is busy. (Depending on the receiver’s

Busy with packet
transmission
Out of service area/power
off
Set caller ID to ON Your caller ID is not notified. (when dialing “visualnet”, etc.)
Your call is being
forwarded

Voice/Videophone Calls

Redial using voice call The other party activates Call Forwarding Service but the

Upper limit has been
exceeded
Connection failed
Please make your call
from the i-mode web page

Connection failed Redial after setting “Activate” of “Caller ID notification” to

You have dialed a non-existent phone number.

phone, this message might be displayed during packet
communication as well.)
The packet communication is progress at the other end.

The other party’s phone is out of the service area or turned
off.

During forwarding

forwarding destination phone does not support videophone
calls.
The upper limit for the plan with the limit function (Type
Limit, Family Wide Limit) is exceeded.

You did not make a videophone call from the IP (Information
Provider) site among i-mode official sites (at dialing to
V-live).

“ON”.
≥This may appear in the case other than above.

Auto-redialing

If “Voice call auto redial” is set to “ON”, and a videophone call is not connected, a voice
call is automatically made.
≥Videophone calls cannot be connected to the phones that do not support the

videophone function, or to the phones that are out of the service area or turned off even
if they are videophones. If you have set “Voice call auto redial” to “ON” and attempt to
dial a phone that does not have the videophone function, the number will be redialed
as a voice call. However, this operation might not work if you call the phone connected
with ISDN-synchronous 64K or the ISDN videophone that does not support 3G-324M
(as of April 2009), or if you dial the wrong number. Note that you could be charged for
the communication.

Function Menu while Entering Phone Number

Notify caller ID See page 62.

Prefix numbers See page 66.

Int’l dial assist See page 65.

Select image See page 81.

Multi number You can select a phone number to be notified to the other party.

Add to phonebook See page 88.

Compose message You can compose a mail message to send to the phone number

Chaku-moji See page 61.

(See page 407)

set as the destination address.
Go to step 3 on page 136.

56

Switching a Voice/Videophone Call

Information

You (caller) can switch between a voice call and a videophone call. This

function is available for the mobile phones that can switch between a

voice call and a videophone call.

Switch from a Voice Call to a Videophone Call

When the other party’s phone has a function to switch between the calls,

“ ” is displayed on your phone and you can switch from the voice

call to videophone call.

During a voice call1c()1Change

1

≥When you select an image

to be sent to the other
party, select “Select
image”. Go to step 2 of “Set
by Call” on page 81.

≥When “Cancel” is selected,

the FOMA terminal cancels
switching and returns to the
voice call.

≥While switching, the voice

guidance is played back.

Switch from a Videophone Call to a Voice Call

When the other party’s phone has a function to switch between calls, you
can switch from a videophone call to a voice call by selecting “CHG to
voice call” from the Function menu.

During a videophone call1i()

1

1CHG to voice call1YES

≥Select “NO” on the

confirmation display to stop
switching and to resume
the videophone call.

≥While switching, the voice

guidance is played back.

≥You can switch between a voice call and a videophone call repeatedly.
≥When i-mode or packet communication is in progress, the communication is

disconnected and then the voice call is switched to the videophone call.

≥When packet communication is in progress at the other end, the message to the

effect that the communication cannot be switched is displayed and the voice call
continues without switching to the videophone call.

≥You cannot switch from a voice call to a videophone call while “Multi calling” is

displayed during a call if you have signed up for Call Waiting Service.

≥It takes about five seconds to switch. Switching may take a longer time depending on

the radio wave conditions.

≥

Depending on how the caller’s phone is working or on the radio wave conditions, switching
between a voice call and a videophone call may fail and the connection may be cut off.

≥If you switch between a voice call and a videophone call during a call, the call duration

and call cost are counted respectively for each call. You are not charged while
“Changing” is displayed.

≥You cannot switch between a videophone call and a voice call unless “Notify

switchable mode” on page 81 is set to “Indication ON” at the other end.

≥When you switch from a videophone call to a voice call, Hands-free is deactivated.

57

Voice/Videophone Calls

<Redial> <Dialed Calls> <Received Calls>

For Redial

For Redial

Using Call Records

The FOMA terminal can store the other party’s phone number and date/
time you have dialed or received. You can call back to the other party.

■Redial

Up to 30 records of dialed voice calls and videophone calls are stored in total, and the
older record of dialing to the same phone number is deleted.

■Dialed Calls

Up to 30 records of dialed voice calls and videophone calls are stored in total, and up to
30 records of 64K data and pa cket communications are stored in total as well. The older
records of dialing to the same phone number are also retained.

■Received Calls

Up to 30 records of incoming voice calls and videophone calls are stored in total, and up
to 30 records of 64K data and packet communications are stored in total as well. The
older records coming from the same phone number are also retained.
≥When a call is switched between a voice call and a videophone call, the call of the type

Voice/Videophone Calls

that is dialed/received first is stored.

≥When more than 30 calls are dialed, the older records are automatically deleted. Even

if you turn off the FOMA terminal, call records are not deleted.

≥When you use 2in1, up to 30 records for Number A and up to 30 records for Number B

are stored respectively regardless of the mode.

■Icons for Redial, Dialed Calls, and Received Calls

58

※

/

/

/

/

/

/

Dialed and received calls/missed calls of voice call

※

Dialed and received calls/missed calls of videophone call

Voice/Video messages are recorded on Record Message

※

Dialed and received calls/missed calls of international call

Dialed and received calls/missed calls of international videophone

※

call

Dialed calls of 64K data communication

※

Received calls/missed calls of 64K data communication

Dialed calls of packet communication

※

Received calls/missed calls of packet communication

Received calls of 64K data communication and packet
communication when no external device is connected

Received Chaku-moji message

Records with time difference corrected

Records for Number B (only in Dual Mode of 2in1)

※ The unchecked missed call icons are highlighted.

Use Redial/Dialed Calls

When Using Redial

1

Press Vo.

When Using Dialed Calls

m1Phonebook1Dialed/recv. calls

1Dialed calls

The list for call records is displayed.

≥Press m( ) to display the Sent Address list.
≥You cannot show the Redial list by pressing Vo from the horizontal Stand-by

display.

Select a call record.

2

The detailed display for the call record is displayed.
≥When the other party is stored in the Phonebook, the

phone number, name, and icon are displayed. If the
same phone number is stored with multiple names in
the Phonebook, the name and icon that come first in the
search order (see page 90) are displayed.

Use Received Calls

Received Call list

Detailed Received

Call display

Information

Information

Press Co.

1

≥You can display the Received Call list also by

m1Phonebook1Dialed/recv. calls1Received calls

1All calls or Missed calls.

All calls . . . . . . All the records including missed calls

Missed calls. . . The records of missed calls only
In Dual Mode of 2in1, the number of missed calls for
Number A and Number B is displayed respectively.
(If unchecked missed calls are found, the number of them is displayed.)

≥Press m( ) to display the Received Address list.
≥You cannot show the Received Call list by pressing Co from the horizontal

Stand-by display.

Select a received call record.

2

≥The other party’s phone number is displayed if it is

provided.
If this caller is stored in the Phonebook, the phone
number, name, and icon are displayed. If the same
phone number is stored with multiple names in the
Phonebook, the name and icon that come first in search
order (see page 90) are displayed.
If there is a call for packet communication, the sender’s
access point name (APN) is displayed.
When the other party’s phone number is not notified, the reason for no caller ID is
displayed.

≥For missed calls, the ring time is displayed on the right of the received date/time.
≥When a Chaku-moji message is received, it is displayed.

To make a call to a displayed redial item, dialed call record, or
received call record

Press d to make a voice call. You can make a voice call also by pressing

Oo( ) from the detailed display. Press l( ) to make a videophone call.

≥You can make a voice call to the most recently dialed or received number by pressing

-d from the Stand-by display and then +No.

≥When you make/receive a call with an additional number of Multi Number, the stored

name for the additional number is displayed below the phone number on the detailed
display. If you store a phone number for “Number setting” of “Multi number”, the
phone number is displayed as well.

≥Even if you make a voice call (or videophone call) to the phone number in a received

call record with a Chaku-moji message displayed, the received message is not sent.

≥When a call comes in from a party who uses a dial-in phone number, a different

phone number might be displayed.

Function Menu while Redial/Dialed Calls/Received Calls is Displayed

Notify caller ID See page 62.

Prefix numbers See page 66.

Int’l dial assist See page 65.

Select image See page 81.

2in1 dial You can select a phone number to be notified to the other

Multi number You can select a phone number to notify the other party. (See

Chaku-moji See page 61.
Search location You can access the site of “イマドコかんたんサーチ

Add to phonebook See page 88.

Mail

Compose message You can compose a mail message to send to the phone

Compose SMS You can compose an SMS message to send to the phone

party in Dual Mode of 2in1. (See page 410)

page 407)

(imadoco kantan search)”.

1YES

≥You can store the phone number in the Phonebook also by

pressing m( ) from the detailed display. Go to
step 2 on page 88.

number set as the destination address.
Go to step 3 on page 136.

number set as the destination address.
Go to step 3 on page 179.

Voice/Videophone Calls

59

Ring time

Information

[Received Call list only]

Font size You can switch font sizes for Redial, Dialed Calls, Received

Set desktop/ key

Add desktop icon See page 35.

long press set. See page 378.

Sent address

[Redial/Dialed Calls only]

Received address

[Received Calls only]

Delete

Voice/Videophone Calls

Delete this 1YES

Delete selected 1Put a check mark for redial items, dialed call records, or

Delete all 1Enter your Terminal Security Code1YES

<Delete>

≥If you execute “Delete all” from the Function menu of Redial/Dialed Calls, all records

in both Redial and Dialed Calls are deleted. Even if you execute “Delete this” or
“Delete selected” of Redial, the records are not deleted from Dialed Calls and they are
retained. To delete the dialed call records, delete them from the Function menu while
“Dialed calls” is displayed.

You can display the ring time for missed calls. Even if you
have set “Missed calls display” of “Ring time” to “Not display”,
the missed calls which stopped ringing within the ring start
time and their ring times are displayed.

Calls, Sent Address, and Received Address. (See “Dialed/
recv. calls” on page 115)

See page 164.

See page 164.

received call records to be deleted1l()1YES

<Chaku-moji>

Using Chaku-moji

When making a voice call or videophone call, you can send your text
message to tell the subject during calling.

≥For details on Chaku-moji or compatible models, refer to DOCOMO website or “Mobile

Phone User’s Guide [Network Services]”.

≥The sending end is charged, but the receiving end is not charged.

When a message is received

A Chaku-moji message is displayed below a caller. The
Chaku-moji message is stored in Received Calls as well.
≥The Chaku-moji message is displayed only during ringing. It

is not displayed during a call.

≥Even when a Chaku-moji message comes in within the ring

start time set by “Ring time”, it is received and recorded in
Received Calls.

≥The Chaku-moji message is displayed on the Private window when “Chaku-moji” of

“Called” on page 108 is set to “ON”.

≥The Chaku-moji message is not displayed during Lock All, Omakase Lock, or Personal

Data Lock. However, you can check the Chaku-moji message from Received Calls
after the lock is released.

Store Messages

You can store up to 10 Chaku-moji messages in the Message list.

m1Set./Service1NW services1Chaku-moji

1

1Create message
1Highlight <Not stored> and press l()
1Enter a message.

≥To edit a stored message, highlight it and press l().
≥You can enter up to 10 characters regardless of whether they are pictograms,

symbols, or full-pitch/half-pitch characters.

60

Make a Call with a Message

Information

Information

Enter a phone number

1

or

call up the detailed display of a Phonebook entry, redial
item, dialed call record, or received call record.

i

()

1

Chaku-moji1Do the following operations.

2

Create message You can create a Chaku-moji message just before dialing.

Select message From the Message list, you can select a stored message.

Sent messages From the Sent Message list, you can select a Chaku-moji

Press d or Oo().

3

≥Press l( ) to make a videophone call.
≥The Chaku-moji message being sent is displayed while you are dialing.

≥When a Chaku-moji message has arrived at the other party’s phone, “Transmission

completed” is displayed, and you are charged a transmission fee.

≥When a Chaku-moji message does not arrive at the other party’s phone such as when

the other party’s phone is not a Chaku-moji compatible mobile phone or the call is not
allowed by “Message disp. settings” at the receiving end, “Transmission failed” is
displayed. In this case, you are not charged a transmission fee.

≥Depending on the radio wave conditions, the transmission result may not be

displayed at the sending end even if a Chaku-moji message has arrived at the other
party’s phone. In this case, you are charged a transmission fee.

1Enter a message.

≥You can enter up to 10 characters regardless of whether they

are pictograms, symbols, or full-pitch/half-pitch characters.

≥The Chaku-moji message created using this function is not

stored in the Message list.

1Select a message.

message to be sent. Up to 10 sent Chaku-moji messages only
are stored in the Sent Message list. If you send the same
Chaku-moji message, the older one also remains. When the
number of sent Chaku-moji messages exceeds 10, the
messages are deleted from the oldest one.

1Select a sent message.

≥Even if you make a call sending a Chaku-moji message, the Chaku-moji message is

not displayed and you are not charged a transmission fee (the call is not recorded in
Received Calls at the receiving end) when the other party’s phone is out of the service
area, turned off, during Public mode (Drive mode), or the ring time for Record
Message Setting is set to 0 seconds. Also, the transmission result is not displayed at
the sending end.

≥When a videophone call is not connected and automatically dialed as a voice call, the

Chaku-moji message is resent as well.

≥You cannot send/receive Chaku-moji messages overseas.

Sent Messages

Up to 10 sent Chaku-moji messages are stored in Sent Messages, and
you can check for the other party’s phone number and the date/time the
Chaku-moji messages were sent. Older messages sent to the same
phone number are also retained.

≥In Dual Mode of 2in1, up to 10 latest records for Number A and Number B can be

displayed in total.

m1Set./Service1NW services

1

1Chaku-moji1Sent messages

. . . . Chaku-moji message successfully sent

. . . . Chaku-moji message unsuccessfully sent

. . . . . . . Chaku-moji message for Number B (only in Dual Mode of 2in1)

≥When the transmission result is not displayed, “ ” or “ ” is not

displayed.

≥Depending on the radio wave conditions, the transmission result might not be

displayed correctly.

Select a sent message.

2

≥When the other party’s phone number is stored in the

Phonebook, the phone number, name, and icon are
displayed.

61

Voice/Videophone Calls

Function Menu while “Sent Messages” is Displayed

Information

Store You can store a sent Chaku-moji message in the Message list.

Delete this 1YES

Delete all 1Enter your Terminal Security Code1YES

Message Display Settings

You can set how incoming Chaku-moji messages are displayed.

m1Set./Service1NW services1Chaku-moji

1

1Message disp. settings1Select an item.

Display all messages . . . . Displays Chaku-moji messages from all callers.

Numbers stored in PB . . .Displays Chaku-moji messages only from the callers

Voice/Videophone Calls

Calls with callerID. . . . . . .Displays Chaku-moji messages only from the caller

Hide all messages. . . . . . .Does not display Chaku-moji messages.

≥When you set to “Numbers stored in PB”, you cannot receive Chaku-moji messages

from the callers stored in the Phonebook B in A Mode of 2in1 (and vice versa).

Prefer Chaku-moji

You can set how your FOMA terminal works for incoming Chaku-moji
messages for when “Setting when opened” is set to “Answer”.

m1Set./Service1NW services1Chaku-moji

1

1Prefer Chaku-moji1ON or OFF

ON . . . . Does not answer by opening the FOMA terminal during ringing, so you

OFF . . . Answers by opening the FOMA terminal while it is ringing.

1<Not stored>

≥You can store also by pressing l().

stored in the Phonebook.

notifying his/her phone number.

can check a Chaku-moji message.

<186/184>

Setting Caller ID to Send/Not to Send for Each Call

Set Caller ID Notification when Making a Call

Each time you dial out, you can set whether to notify your caller ID.

Enter a phone number

1

or

call up the detailed display of a Phonebook entry, redial
item, dialed call record, or received call record.

i()1Notify caller ID

2

1Don’t notify or Notify caller

≥To release “Notify caller ID”, select “Cancel prefix”. Whether to notify or not

follows the setting for “Activate” of “Caller ID notification”.

Set “Notify/Not Notify” by Entering “186/184”

You can select whether to notify the other party of your phone number
also by entering “186”/“184” before the other party’s phone number.

To notify your caller ID

186→Destination phone number1d or Oo()

1

≥Press l( ) to make a videophone call.

Not to notify your caller ID

184→Destination phone number1d or Oo()

1

≥Press l( ) to make a videophone call.

62

Information

≥When you make a call and hear the guidance requesting your caller ID (see

Information

page 404), follow the steps of “To notify your caller ID” to enter “186” and redial.

≥You cannot set “Caller ID notification” while “ ” is displayed.

<Pause Dial>

+m-8-4

Sending Touch-tone Signals

You can send touch-tone signals from your FOMA terminal to use

services such as reserving tickets, checking bank balance, etc.

Store Pause Dial

You need to store a number string to be sent as a touch-tone signal in the

Pause Dial list. If you have inserted a pause (p), you can send a number

string breaking at the point where the pause is inserted.

m1Set./Service1

1

1l

()

≥When a number string is already stored, it is displayed.
≥To delete a stored pause dial, press i( ) and select “Delete”, then select

“YES”.

Enter a number string.

2

≥Enter the pause (p) by pressing and holding a for at least one second.
≥You can use only 0 through 9, s, a to enter a number string and the

pause (p).

≥You can enter up to 128 digits.
≥You cannot enter a pause (p) at the beginning and end of a number string, or

enter it consecutively.

Other settings1Pause dial

Send Pause Dial

m1Set./Service1

1

1Oo

()1Enter a phone number

1d

or Oo()

A voice call is made. Once the line is connected, a number string stored in Pause
Dial is displayed up to the first pause (p).
≥When the other party’s phone number is stored in the Phonebook, you can

retrieve it selecting from the Search Phonebook display by pressing Bo.

≥You can search for the phone number also from Received Calls by pressing Co

or from Redial by pressing Vo.

Other settings1Pause dial

Check that the line is connected1d or Oo()

2

A number string up to the first pause (p) is sent, and a number string up to the next
pause (p) is displayed.
A number string up to the pause (p) is sent each time you press d or

Oo().

When you have finished sending the last number, the “Talking” display appears.
≥To send multiple pieces of a number string at a time, press and hold Vo for at

least one second, and select “Send at one time”.

≥During a call, you can send a number string also by displaying the Function menu of

the Pause Dial display.

≥Some devices on the receiving end cannot receive signals.
≥You cannot send a number string with pauses during a videophone call.

Voice/Videophone Calls

63

<WORLD CALL>

Making International Calls

WORLD CALL is the international call service available from DOCOMO
mobile phones.
When you have signed up for FOMA service, you have contracted to use
“WORLD CALL” (except those who have applied not to use it).

≥You can make calls to about 240 countries and regions.
≥The WORLD CALL charges are added to your monthly bill for FOMA service.
≥The application/monthly fee is free of charge.
≥The service is not available with some billing plans.
≥Contact “docomo Information Center” on the back page of this manual for inquiries

about WORLD CALL.

≥When using international carriers other than DOCOMO, contact them.
≥The caller ID might not be notified, or might not be displayed correctly depending on

the carrier. In this case, you cannot make a call by using Received Calls.

About international videophone calls

Voice/Videophone Calls

You can make international videophone calls to users of the specified 3G mobile phone
carriers overseas and FOMA users. Press l( ) instead of d or Oo()
in the steps of “Enter a Phone Number to Make an International Call”. (See page 64)
≥For the information about connectable countries and telecommunica tions carriers, refer

to “Mobile Phone User’s Guide [International Services]” or the DOCOMO International
Services website.

≥Images sent from the other party may blur on your FOMA terminal or you may not be

able to connect, depending on the other party’s phone used for the international
videophone call.

Use “+” to Make an International Call

When you enter a phone number for dialing or storing it in the
Phonebook, press and hold 0 for at least one second to enter “+”. You
can use “+” to make international calls without entering an international
call access code.

≥If you set “Auto assist setting” of “Int’l dial assist” to “ON”, an international call access

code of “IDD prefix setting” is automatically entered.

0(for at least one second)

1

1Enter numbers in order of country/area code

→area code (city code)→destination phone number

1d or Oo()1Dial

≥

When the area code (city code) begins with “0”, enter it except for the “0”. However,
include “0” when making a call to some countries or regions such as Italy.

≥Press l( ) to make an international videophone call.
≥When you select “Dial with orig. No.”, an international call is dialed to the phone

number you entered in the FOMA terminal.

Enter a Phone Number to Make an International Call

Enter numbers in order of 010→country/area code

1

→area code (city code)→destination phone number

1d or Oo()

≥You can make an international call also by entering 009130→010

→country/area code→area code (city code)→destination phone number.

≥

When the area code (city code) begins with “0”, enter it except for the “0”. However,
include “0” when making a call to some countries or regions such as Italy.

≥Press l( ) to make an international videophone call.

64

International Dial Assist

You can make a call adding a country/area code or international call

access code to a phone number. (Except for some countries and regions,

if the phone number starts with “0”, the “0” at the beginning is

automatically deleted.)

Enter a phone number

1

or

call up the detailed display of a Phonebook entry, redial
item, dialed call record, or received call record.

i()1Int’l dial assist

2

1Select a country/area name1Select a name
1d or Oo()

≥Press l( ) to make an international videophone call.
≥When the beginning of the phone number is “+”, the display for selecting a

country/area name is not displayed.

≥When “Japan” is selected as a country/area name, the display for selecting a

name is not displayed.

<International Dial Assist>

Setting for International Calls

Auto Assist Setting

You can set whether to replace “+” at the beginning of a phone number

with an international call access code for when you make an international

call from Japan.

m1Set./Service1Network setting1Int’l dial assist

1

1Auto assist setting1ON or OFF
1Select a country/area name1Select a name.

≥When no country/area code or international call access code is stored, the

confirmation display appears asking whether to store it. Select “YES” and go to
step 2 of “Country/Area Code” on page 65 for a country/area code, and go to
step 2 of “IDD Prefix Setting” on page 65 for an international call access code.

Country/Area Code

You can store up to 27 country/area codes to be added for making
international calls from overseas.

m1Set./Service1Network setting1Int’l dial assist

1

1Country/Area Code
1Highlight <Not recorded> and press l().

≥If you select a stored country/area name, you can check the stored contents.

Enter a country/area name 1Enter a country/area code.

2

≥You can enter a country/area name of up to 8 full-pitch/16 half-pitch characters.
≥You can enter a country/area code of up to 5 digits. But you cannot use #, :, and

+.

IDD Prefix Setting

You can store up to three international call access codes to be added to
the beginning of a phone number for making an international call.

m1Set./Service1Network setting1Int’l dial assist

1

1IDD prefix setting
1Highlight <Not recorded> and press l().

≥If you select the stored item, you can check the stored contents.

Enter a name1Enter an international call access code.

2

≥You can enter a name of up to 8 full-pitch/16 half-pitch characters.
≥You can enter an international call access code of up to 16 digits.

Function Menu while Country/Area Code /IDD Prefix
Setting is Displayed

Edit Go to step 2 of “Country/Area Code” on page 65 for Country/Area

Delete this 1YES

Code, and go to step 2 of “IDD Prefix Setting” on page 65 for IDD
Prefix Setting.
≥You can edit the item also by pressing l().

Voice/Videophone Calls

65

Delete all 1Enter your Terminal Security Code1YES

Information

Information

Information

<Delete this> <Delete all>

≥You cannot delete the country/area code or international call access code set by

“Auto assist setting”.

<Prefix Setting>

Storing Numbers to be Added to the Beginning of a Phone Number

You can store prefix numbers such as international call access codes or
“186”/“184” and add them to the phone number for dialing. You can store
up to seven prefix numbers.

m1Set./Service1Network setting1Prefix setting

1

1Highlight <Not recorded> and press l().

Voice/Videophone Calls

≥If you select a stored prefix, you can check the stored contents.
≥To delete a stored prefix, press i( ) and select “Delete this” or “Delete

all” then select “YES”. If you select “Delete all”, you need to enter your Terminal
Security Code.

Enter a name1Enter a prefix number.

2

≥You can enter a name of up to 8 full-pitch/16 half-pitch characters.
≥You can enter a prefix number of up to 16 digits. The keys for entry are limited to

0 through 9, s and a.

Prefix Numbers

You can add a prefix number to the beginning of phone number when
you make a call.

Enter a phone number

1

or

call up the detailed display of a Phonebook entry, redial
item, dialed call record, or received call record.

i()1Prefix numbers1Select a name

2

1d or Oo()

≥Press l( ) to make a videophone call.

<Sub-address Setting>

Making a Call Specifying a Sub-address

You can set whether to regard the numbers after “:” of a phone number
as a sub-address to access the specified phones or data terminals.

≥The sub-address is a number assigned to identify each ISDN terminal connected to an

ISDN line. It is also used for selecting contents on “V-live”.

m1Set./Service1Other settings

1

1Sub-address setting1ON or OFF

≥Even if you set “Sub-address setting” to “ON”, “:” at the top of phone numbers and

“:” immediately after the prefix number or “186”/“184” are not regarded as
sub-address mark-off symbols.

<Reconnect Signal>

+m-7-7

Setting Alarm for Reconnecting

You can set an alarm that sounds until a voice call or videophone call is
reconnected after disconnected owing to bad radio wave conditions.

m1Set./Service1Talk1Reconnect signal

1

1Select an alarm.

≥

The reconnectable time differs d epending on the usage status and radio wave conditions.
An estimate is about 10 seconds and the call charge is applied also for that duration.

≥While you are disconnected, no sound is transmitted to the other party.

66

<Shikkari Talk>

Information

Information

Information

Making Voice Clear According to Surrounding Noise

The volume of the other party’s voice is turned up according to the

surrounding noise during a call. This setting is effective only when the

other party’s voice is output from the earpiece.

m1Set./Service1Talk1Shikkari Talk1ON or OFF

1

<Noise Reduction>

Reducing Surrounding Noise to Make Voice Clear

The noise sent to the other party is reduced according to the surrounding

noise during a call.

m1Set./Service1Talk1Noise reduction1ON or OFF

+m-7-6

1

<Yuttari Talk>

Slowing Down the Other Party’s Speaking Speed

During a voice call1m()

1

While Yuttari Talk is activated, “Yuttari Talk ” is displayed.

≥Press m( ) again to return to the normal speed.

≥Yuttari Talk is effective only during a current voice call. The speaking speed returns to

normal one when you end the call, switch calling parties during Multi calling, or switch
from the voice call to a videophone call.

<Hands-free>

Switching to Hands-free

When you switch to Hands-free, sound such as the other party’s voice is
audible over the speaker.

During a call, dialing, or connecting1d

1

When Hands-free is activated, “ ” is displayed.

≥Press d again to deactivate Hands-free.
≥The sound volume during a Hands-free call follows the setting specified by

“Volume” (earpiece volume).

≥You can switch to Hands-free even during Manner Mode. Also, you will still hear

voice through the speaker even when you activate Manner Mode during a
Hands-free call.

≥While an earphone/microphone (option) is connected, you cannot hear voice through

the speaker even if you switch to Hands-free.

≥Keep the FOMA terminal well away from your ear during a Hands-free call. Otherwise

you could affect or damage your hearing.

≥Talk into the FOMA terminal within a distance of about 50 cm.

<In-Car Hands-free>

Using Hands-free Compatible Devices

You can make or receive voice calls from a Hands-free compatible device
such as In-Car Hands-Free Kit 01 (option) or a car navigation system by
connecting with your FOMA terminal.

≥Connect using a cable (USB connection):

To use/charge via the In-Car Hands-Free Kit 01 (option), you need to have the FOMA
In-Car Hands-Free Cable 01 (option).

※For how to operate Hands-free compatible devices, refer to the respective instruction

manuals.

≥To connect using a cable (USB connection), set “USB mode setting” to

“Communication mode”.

Voice/Videophone Calls

67

≥“ ” appears while you are talking or communicating using a USB Hands-free

Information

Chaku-moji message

(See page 60)

Information

compatible device.

≥“ ” might appear while the FOMA terminal is connected to a USB Hands-free

compatible device, and “ ” while “USB mode setting” is set to “microSD mode”,
depending on the Hands-free device connected.

≥The display or ring tone for incoming calls follows the settings of the FOMA terminal.
≥When the sound is set to output from a Hands-free compatible device, the ring tone

sounds from that device even when Manner Mode is activated or “Ring volume” of the
FOMA terminal is set to “Silent”.

≥The receiving operation in Public mode (Drive mode) follows the setting of “Public

(Drive) mode”.

≥The receiving operation while Record Message is activated follows the setting of

“Record message setting”.

≥When the sound is set to output from the FOMA terminal, the operation for when the

FOMA terminal is closed during a call follows the setting of “Setting when closed”.
When the sound is set to output from a Hands-free device, the communication state

Voice/Videophone Calls

does not change regardless of “Setting when closed” even if you close the FOMA
terminal.

Receiving a Call/Videophone Call

When you receive a call, the ring tone

1

sounds and the Call/Charging indicator
flickers.

≥To vibrate the FOMA terminal for incoming calls, set

“Phone” or “Videophone” of “Vibrator” to other than
“OFF”.

≥While the phone is ringing for a videophone call,

“Incoming V.phone” is displayed. However, while
ringing for a voice call, this kind of indication is not
displayed.

≥“ ” is displayed at the upper left of the phone

number for incoming international calls.

For Answering a Voice Call

2

Press d or Oo( ) to answer
the call.

For Answering a Videophone Call

Press d

or Oo()

to answer

the videophone call.

The substitute image is sent to the other party.
≥Press m during a videophone call to switch between

the substitute image and image through your camera
for sending to the other party.

Press h to end the call after talking.

3

≥If you close the FOMA terminal during a call, the FOMA terminal works in accordance

with the setting of “Setting when closed”. (See page 71)

68

≥You might hear beeps (in-call ring tone) during a call.

Information

If you have signed up for any of Voice Mail Service, Call Waiting Service, or Call
Forwarding Service and set “Arrival call act” to “Answer”, the beeps (in-call ring tone)
will sound for another incoming call, enabling you to do the following operations:
Voice Mail Service

. . . . Transfer the call to the Voice Mail Service Center. (See page 400)

Call Waiting Service

. . . . Put your current call on hold and answer the incoming call. (See page 400)

Call Forwarding Service

. . . . Transfer the call to the registered forwarding destination. (See page 403)

≥You can set “Reject unknown” not to accept calls from the phone numbers that are not

stored in the Phonebook.

≥You cannot answer calls in Horizontal Open Style. However, when an earphone/

microphone (option) is connected, you can answer calls in Horizontal Open Style.

<For Voice Calls>

≥When “Answer setting” is set to “Any key answer”, the call is put on hold if you answer

the call by pressing .< with the FOMA terminal closed. When “Setting when closed” is
set to “No tone” or “End the call”, the other party hears nothing, and when it is set to
“Hold”, the call hold tone is played back. You can start talking by opening the FOMA
terminal.

<For Videophone Calls>

≥Just after purchase, Hands-free is automatically activated during a videophone call as

“Hands-free w/ V. phone” has been set to “ON” (see page 80). However, Hands-free
is deactivated during Manner Mode regardless of “Hands-free w/ V. phone”.

≥Even if Call Forwarding Service is set to “Activate”, the call is not forwarded unless the

forwarding destination is a phone compatible with the videophone conforming to
3G-324M (see page 54). Check the phone you are forwarding the call to and then
activate the service. The videophone caller does not hear the guidance to the effect
that the call is forwarded. (The message to the effect that the call is to be forwarded
appears, depending on the receiver’s FOMA terminal.)

≥If a videophone call comes in from the phone number to be rejected by Nuisance Call

Blocking Service, the video guidance for Call Rejection is played back and the call is
disconnected.

Display for incoming calls

When a caller’s phone number is provided

If the caller’s name, phone number, and image are stored in the Phonebook, the name,
phone number, and icon (or image) are displayed.
≥If the same phone number is stored with multiple names in the Phonebook, the name

that comes first in the search order (see page 90) is displayed.

≥The phone number but not the name is displayed during Personal Data Lock.

However, when “Phonebook available” is set to “Accept” for “Customize” of Personal
Data Lock, the name is displayed even during Personal Data Lock.

≥For a forwarded call, the forwarder’s phone number is displayed below the caller. (It

might not be displayed in the case of some forwarders.)

≥When you receive a call to an additional number of Multi Number, the stored name for

the additional number is displayed below the caller. (With a forwarded call, you can
press c( ) to switch to display of the forwarder.)

When a caller’s phone number is not provided

The reason for no caller ID is displayed. (See page 128)

Function Menu while a Call is Ringing

Call rejection You can disconnect the call without answering.

Call forwarding See page 403.

Voice mail See page 400.

Switched between a Call and a Videophone Call by the Other Party

When you have set “Notify switchable mode” to “Indication ON”, a caller
(the other party) can switch between a voice call and a videophone call.
When the caller (the other party) switches between a voice call and a
videophone call, the message telling that the call is being switched is
displayed, the voice guidance is played back, and then the call is
switched.

≥You (receiving end) cannot switch between a voice call and a videophone call.

Voice/Videophone Calls

69

<Answer Setting>

Information

+m-5-8

Setting Response of Key Operation for Answering Incoming Calls

You can set to start talking (Any key answer) or to stop the ring tone
(Quick silent) by pressing a key besides d, Oo for when a call comes
in.

m1Set./Service1Incoming call1Answer setting

1

1Select a key operation.

Any key answer

You can start talking by pressing any key shown below:

d, Oo, 0 through 9, a, s, r, m, c※3, No,

※1※2

Voice call

≥When receiving a videophone call, you can start talking by pressing d or Oo.

Voice/Videophone Calls

Quick silent

The following are the keys you can press to stop the ring tone, vibrator or voice
guidance:
When “Setting when opened” is set to “Keep ringing”, you can stop the ring tone,
vibrator or voice guidance also by opening the FOMA terminal in Normal Style.
Even if you stop it, the other party still hears a ringback tone.

Voice call

Videophone call

※1※2

≥After you stop the ring tone, vibrator or voice guidance, you can start talking by

pressing d or Oo.

<

※1※2

0 through 9, a, s, r, m, c※3, No, <

OFF

You can start talking by pressing a key shown below:

Voice call

Videophone call

※1 You can activate Any Key Answer or Quick Silent also by pressing l when

record messages have been recorded to the maximum.

※2 During Key Lock, you can activate Any Key Answer and Quick Silent by

pressing and holding < for at least one second.

※3 While “ ” is displayed, you cannot activate Any Key Answer or Quick

Silent by pressing c.

≥While an earphone/microphone (option) is connected, you can press the switch to

start talking, regardless of “Answer setting”. (See page 385)

d, Oo

70

<Setting when Opened>

Information

Information

Information

Setting Response for when Opening FOMA Terminal while Ringing

m1Set./Service1Incoming call

1

1Setting when opened1Select an incoming type
1Keep ringing or Answer

Keep ringing. . . You can keep the incoming call ringing.

Answer . . . . . . . You can answer the incoming call. For videophone calls, the still

≥You cannot answer calls by opening the FOMA terminal in Horizontal Open Style

even when “Answer” is set.

<Setting when Closed>

image set for “Substitute image” of “Select image” is sent to the
other party.

+m-1-8

Setting Response for when Closing FOMA Terminal during a Call

m1Set./Service1Talk1Setting when closed

1

1Select an item.

No tone . . . . . . . The voice is muted. The hold tone does not sound. The setting is

Hold . . . . . . . . . .The other party hears the hold tone set for “Holding tone” of “Set

End the call. . . . The call is finished. This is the same operation as pressing h

Speaker ON or Speaker OFF

2

Speaker ON . . . . The hold tone sounds from the speaker.

Speaker OFF . . . The hold tone does not sound from the speaker.

completed.

hold tone”. For videophone calls, the still image set for “Holding”
of “Select image” is displayed.

during a call. The setting is completed.

≥This function is disabled when an earphone/microphone (option) is connected. The

communication state does not change even if you close the FOMA terminal.
However, if you close the FOMA terminal during a videophone call with “No tone” set,
the substitute image is sent to the other party.

≥If you close the FOMA terminal during a videophone call with “No tone” set, the

substitute image is sent to the other party. When “Hold” is set, the still image set for
“Holding” of “Select image” is sent.

≥If you set to “No tone” or “Hold”, “Holding” is displayed on the Private window when

the FOMA terminal is closed.

≥Even when “End the call” has been set, the call does not end if you close your FOMA

terminal from Horizontal Open Style. “No tone” works for a voice call/videophone call.

<Volume>

Adjusting Earpiece Volume

m1Set./Service1Talk1Volume

1

1Use Bo or </> to adjust the earpiece volume.

Adjust the earpiece volume to Level 1 (minimum) through Level 6 (maximum).
≥You can adjust the volume by pressing Zo or </> during a voice call and

calling, Bo or </> during a videophone call, and by pressing and holding Zo
(for at least one second) while you are entering a phone number. Press Bo or
</> within two seconds to adjust it.

≥The earpiece volume adjusted during a call is retained even after the call ends.
≥When you adjust the earpiece volume, the sound volume during a Hands-free call is

also adjusted.

Voice/Videophone Calls

71

<Ring Volume>

Information

Adjusting Ring Volume

You can adjust the ring volume for incoming calls and mail.

m1Set./Service1Sound1Ring volume

1

1Select an incoming type
1Use Bo to adjust the volume.

≥The following icons are displayed on the Stand-by display while “Ring volume” is

set to “Silent”:

: Set for “Phone” or “Videophone”.

: Set for “Mail”, “Chat mail”, “MessageR”, “MessageF”, or “i-concier”.

: Set for “Phone” or “Videophone”, and for “Mail”, “Chat mail”, “MessageR”,

“MessageF”, or “i-concier”.

≥If you have set “Step”, the ring tone is silent for about three seconds, and then the

volume steps up every three seconds, from Level 1 through Level 6.

Voice/Videophone Calls

≥While the phone is ringing for a voice call or videophone call, you can adjust the

ring volume by pressing Bo. However, you cannot adjust the ring volume in the
following cases:

・When “Ring volume” is set to “Step”
・When “Answer setting” is set to “Quick silent” and you stop the ring tone or

voice guidance

・During Manner Mode
・When a call is cut off within the ring start time specified by “Ring time”

+m-5-0

<On Hold>

Putting a Call on Hold when You cannot Answer Immediately

During ringing1h

1

The FOMA terminal makes three rapid beeps for confirmation and the call is put on
answer-hold (On Hold).
≥The confirmation tone does not sound during Manner Mode or when “Ring

volume” is “Silent”.

≥The other party hears the hold tone set for “On hold tone” of “Set hold tone”. For

videophone calls, the still image set for “On hold” of “Select image” is displayed.

Press d or Oo( ) to release hold and answer

2

the call.

≥If “Answer setting” is set to “Any key answer”, you can release hold of voice calls

by pressing any key of 0 through 9, a, s, r, m, c, Mo, <, >,
l, or i.

≥If a videophone call is on hold, the substitute image is sent to the other party

when you press d or Oo( ) to release hold.

≥The caller is charged for the call even during answer-hold (On Hold).
≥If you press -h during answer-hold (On Hold), the call will be disconnected.

<Holding>

Putting a Call on Hold during a Call

During a call1Oo ()

1

≥The other party hears the hold tone set for “Holding tone” of “Set hold tone”. For

videophone calls, the still image set for “Holding” of “Select image” is displayed.

≥You can put the call on hold by closing the FOMA terminal during the call if you

have set “Setting when closed” to “Hold”.

72

Press d or Oo( ) to release hold and answer

Information

Information

2

the call.

≥When you have put a voice call on hold, you can release the hold also by

pressing r.

≥If a videophone call is on hold, the substitute image is sent to the other party

when you press d or Oo( ) to release hold.

≥If you have set “Setting when closed” to “Hold” and put a call on hold by closing

the FOMA terminal, you can answer the call by opening the FOMA terminal or by
connecting an earphone/microphone (option).
If you connect an earphone/microphone to answer a videophone call, the
substitute image is sent to the other party.

≥The caller is charged for the call even while the call is on hold.
≥If a new call comes in while the current call is put on hold, the hold (Holding) is

released.

<Set Hold Tone>

Setting Hold Tone

You can set the guidance the other party hears while a call is put on hold.

m1Set./Service1Talk1Set hold tone

1

1On hold tone or Holding tone1Select a hold tone.

Tone 1/2 . . .The caller hears the pre-installed guidance in Japanese.
RHAPSODY ON A THEME OF

. . . . . . . . . . .The caller hears the melody. You can set this for “Holding tone” only.

Voice announce

. . . . . . . . . . .The caller hears the sound recorded by “Voice announce”. If it has

≥Press l( ) to play back a hold tone. Press r to end the demo

not been recorded, this is not displayed.

playback.

Using Public Mode

Using Public Mode (Drive Mode)

Public mode is an auto-answer service that puts importance on manners
in public spaces. Once you activate Public mode, the guidance is played
back telling that you cannot answer the call as you are currently driving
or in a place where you should refrain from speaking on the phone (a
train, bus, movie theater, etc.). Then the call is disconnected.

≥Voice Mail Service※1, Call Forwarding Service※1, and Caller ID Display Request

Service※2 work taking priority over Public mode.
※1If a ring time is set to other than 0 seconds for incoming calls, the service works

after the Public mode guidance.

※2When the other party notifies you of the phone number, Public mode works.

≥Public mode does not work to the calls from the party set to be rejected by Nuisance

Call Blocking Service.

Press and hold a for at least one second.

1

Public mode is activated and “ ” is displayed.
When a call comes in, the guidance “The person you are calling is currently driving
or in an area where cell phone should not be used. Please try again later.” is played
back for incoming calls.
≥To deactivate Public mode, perform the same operation. Then, Public mode is

deactivated and “ ” disappears.

≥You can activate/deactivate Public mode only from the Stand-by display. You can

activate/deactivate Public mode even when “ ” is displayed.

≥You can make calls as usual even during Public mode.
≥If you make an emergency call at 110/119/118, Public mode is released.
≥When Public mode and Manner Mode are activated simultaneously, Public mode has

priority.

≥If a “User unset” call comes in while “Caller ID request” is set to “Activate”, the Caller

ID Request guidance is played back. (The Public mode guidance is not played back.)

≥You cannot use this function during data communication.

Voice/Videophone Calls

73

When Public mode (Drive mode) is activated

Notification icon

・Even when a call comes in, the ring tone does not sound. The “Missed call” icon

appears on the display and the call is stored in “Received calls”. The guidance is
played back to the caller to the effect that you are currently driving or in an area where
mobile phones should not be used. Then the call is disconnected.
However, when the power is off or “ ” is displayed, the caller hears the
out-of-service area guidance instead of the Public mode guidance.

・The ring tone does not sound and the Call/Charging indicator does not flicker even

when mail or a message comes in. In addition, the set vibrator does not work.

・The ring tone for 64K data communication, alarm tone, charging confirmation tone, and

a melody while an i-αppli program is running is not played back.

・The tickers of i-Channel are not displayed.
・See page 73 for how Public mode (Drive mode) and each network service work for

incoming calls when they are simultaneously activated.

Using Public Mode (Power Off)

Public mode (Power off) is an auto-answer service that puts importance

Voice/Videophone Calls

on manners in public spaces. Once you activate Public mode (Power off),
the guidance is played back telling that you cannot answer the call as
you are currently in a place where the power should be turned off
(hospital, airplane, around priority seat in a train, etc.). Then the call is
disconnected.

Enter “:25251”1d

1

Public mode (Power off) is set. (Nothing is changed on the Stand-by display.)
After setting Public mode (Power off) and turning off the power, the guidance “The
person you are calling is currently in an area where use is prohibited. Please try
again later.” is played back for incoming calls.

≥To release Public mode (Power off), dial “:25250”.
≥To check the setting for Public mode (Power off), dial “:25259”.

When Public mode (Power off) is activated

The setting stays activated until you dial “:25250” to deactivate Public mode (Power
off). You cannot deactivate the setting just by turning on the power.
The guidance is played back to the caller telling that you are currently in a place where
you should turn off the power. Then the call is disconnected.
The Public mode (Power off) guidance is played back even when you are out of the
service area or out of reach of radio waves.

・See page 73 for how Public mode (Power off) and each network service work for

incoming calls when they are simultaneously activated.

<Missed Calls>

When You could not Answer an Incoming Call

When you could not answer calls (Missed calls), the “Notification icon”
appears on the Stand-by display. You can check Received Calls by
selecting the icon.

Oo1Oo()

1

≥Press h or r to return

to the former display.

≥When multiple icons are

found, use Mo to highlight
an icon and press

Oo().

≥See page 37 for when the FOMA terminal is closed.

74

<Record Message Setting>

Incoming Call Playing back the

answer message

Recording a voice/

video message

The ring time

elapses

Displaying an icon on the

desktop (See page 34)

Information

+m-5-5

Recording Voice/Video Messages when You cannot Answer a Call

By activating Record Message, you can play back an answer message to

incoming calls and record callers’ voice/video messages when you

cannot answer them even if you have not signed up for Voice Mail

Service.

You can record up to five messages for voice calls and up to two

messages for videophone calls. Each message can be recorded for up to

20 seconds.

Activate Record Message

m1LifeKit1Rec. msg/voice memo

1

1Record message setting1ON or OFF
1Select an answer message.

≥Press l( ) to play back the answer message. Press r to end the

demo playback.

≥When “Japanese 1”, “Japanese 2”, or “English” is set, a beep sounds after

playing back the answer message to the other party. If “Voice announce” is set,
the beep does not sound.

Enter a ring time (seconds).

2

≥Enter from “000” through “120” in three digits.
≥You cannot set the same ring time for Auto Answer Setting and Record Message

Setting. Set a different time for each.

≥While Record Message is activated, “ ”〜“ ” (the number of recorded

messages for voice calls) and “ ”〜“ ” (the number of recorded messages
for videophone calls) are displayed.

Incoming calls when Record Message Setting is set to “ON”

For videophone calls, the still image set for “Preparing” of
“Select image” is displayed on the other party’s display while
playing back the answer message, and the still image set for
“Record message” of “Select image” is displayed while
recording.
≥To answer a call while the answer message is being played

back or a voice/video message is being recorded, press
d or Oo().
For videophone calls, press d or Oo( ) to send
the substitute image.
You can answer a call also by pressing the switch on an
earphone/microphone (option). For videophone calls, the
substitute image is sent to the other party.

≥Record Message does not work when “ ” is displayed.
≥When Public mode (Drive mode) and Record Message are simultaneously activated,

the former has priority and the latter does not work.

≥The priority order of answer messages is as follows: “Setting for Phonebook entry” →

“Group setting” → “Record message setting”.

≥If “Voice announce” selected as an answer message is deleted, the answer message

will be set to “Japanese 1”.

Voice/Videophone Calls

75

≥When Voice Mail Service or Call Forwarding Service is set at the same time as

Information

Record Message list

Record Message, the priority depends on the ring time set for Voice Mail Service or
Call Forwarding Service. To give Record Message priority, set the ring time for
Record Message Setting shorter than that for Voice Mail Service or Call Forwarding
Service. Even when you do this, Voice Mail Service or Call Forwarding Service works
when record messages have been recorded to the maximum.

≥You cannot receive a call from a third party while a voice/video message is being

recorded. The third party will hear the busy tone.

<Quick Record Message>

Recording a Message when You cannot Answer an Incoming Call

Even if a call comes in while Record Message is not activated, you can
record the caller’s voice/video message just for that incoming call.

During ringing1l() or >

Voice/Videophone Calls

1

The caller will hear the answer message and then can leave you a voice/video
message.

≥During Key Lock, press and hold > for at least one second.
≥Record Message does not work when five messages for voice calls and two

messages for videophone calls have already been recorded.

≥When “Side keys guard” is set to “ON”, Record Message does not work even if

you press > with the FOMA terminal closed.

<Play/Erase Messages>
<Play/Erase Videophone Messages>

+m-5-5

Playing/Erasing Record Messages/a Voice Memo/Videophone Record Messages/ Movie Memos

Play Back/Erase Record Messages/a Voice Memo

m1LifeKit1Rec. msg/voice memo

1

1Play/Erase msg.
1Select a record message or voice

memo.

A beep sounds and playback starts.

≥On the Record Message list, recorded items are indicated by “★”.
≥It is played back at the volume set for “Volume” (earpiece volume).
≥When playback ends, a double-beep sounds and the message “Playing” is

cleared from the display.

≥The date and time the message/memo was recorded are displayed during

playback.

≥When a caller’s phone number is provided, it is displayed during playback of the

record message. If the caller is stored in the Phonebook, his/her name is also
displayed.
However, the name is not displayed and the phone number only is displayed in
the following cases:

・When you play back a record message from the caller stored as secret data in

Normal Mode

・When you play back a record message for Number A in B Mode (or vice versa)

while using 2in1

≥If the caller’s phone number is displayed during playback of a record message,

you can make a voice call to that phone number by pressing d. Press
l( ) to make a videophone call.

To play back using .>

From the vertical Stand-by display, press > to play back the latest record message.
When record messages are not recorded, a voice memo is played back.

76

To skip to next message

Videophone Record

Message list

Information

Each time you press > during playback, messages are played back in the following

order: the next new record message → the oldest record message → a voice memo.

To cancel playback midway

Press Oo() or r.

Play Back/Erase Videophone Record Messages/Movie Memos

m1LifeKit1Rec. msg/voice memo

1

1Play/Erase VP msg.
1Select a videophone record message

or movie memo.

≥On the Videophone Record Message list, recorded

items are indicated by “★”.

≥It is played back at the same volume of the playback

sound of i-motion movies.

≥The date and time the message/memo was recorded are displayed during

playback.

To play back using .>

From the vertical Stand-by display, press and hold > for at least one second to play

back the latest videophone record message. When videophone record messages are

not recorded, the latest movie memo is played back.

To cancel playback midway

Press Oo() or r.

Function Menu of the Record Message List/Videophone
Record Message List

Play You can play back the message.

Erase this 1YES

≥You can erase the message/memo also by pressing

i( ) during playback.

Erase rec. msg. You can erase all record messages from the Record Message

Erase movie memo

[Videophone Record
Message list only]

Erase all You can erase all record messages and a voice memo from the

list, and can erase all videophone record messages from the
Videophone Record Message list.

1YES

You can erase all movie memos.

1YES

Record Message list, and can erase all videophone record
messages and movie memos from the Videophone Record
Message list.

1YES

Using Chara-den

You can set up for sending a Chara-den image to the other party.

≥See page 328 for Chara-den images.

Set by Call

You can set a Chara-den image to be sent to the other party for making a
videophone call.

Chara-den display/Chara-den list1l()

1

Enter the destination phone number and press l( ) to make a
videophone call.
≥When the other party’s phone number is stored in the Phonebook, you can

retrieve it selecting from the Search Phonebook display by pressing Bo.

≥You can search for the phone number also from Received Calls by pressing Co

or from Redial by pressing Vo.

≥The priority order of substitute images to be sent to the other party is as follows:

“Setting by call” → “Setting for Phonebook entry” →“Group setting” → “Select image”.

Voice/Videophone Calls

77

Substitute Image

At videophone

start-up

Whole Action

Mode

Information

You can set a Chara-den image for “Substitute image” of “Select image”.

Chara-den display/Chara-den list/Chara-den Recording

1

display1i()1Substitute image

≥From the Chara-den list, you can set it also by pressing m().

Chara-den Setup

You can perform settings for a Chara-den call. These settings are
effective only for during a videophone call.

During a Chara-den call1i()

1

1Chara-den setup1Do the following operations.

Switch Chara-den 1Select a Chara-den image.

Voice/Videophone Calls

Action list You can display the list for actions that you can operate.

Change action You can switch the action mode between Whole Action Mode

≥If you switch Chara-den images, the action mode switches to

Whole Action Mode.

≥Highlight an action and press Oo( ) to execute the

action. Press l( ) to check the details of the action.

≥You can display the Action list also by pressing a.

( ) and Parts Action Mode ( ).
≥You can switch modes also by pressing l.

Useful Functions for Videophone Calls

Switch Images to be Sent

You can switch images to be sent to the other party from the substitute
image to the image through your camera.
See page 328 for Chara-den.

During a videophone call1m()

1

The image through your camera is sent to the other party.
“ ” is displayed while the image through your camera is being sent.
≥Press m( ) again to switch from the image through your camera to the

substitute image.

≥The priority order of substitute images to be sent to the other party is as follows:

“Setting by call” → “Setting for Phonebook entry” → “Group setting” → “Select image”.
Note that “Setting for Phonebook entry” and “Group setting” are disabled when a
videophone call comes in without notifying the caller ID.

≥Even when you make a videophone call sending a substitute image, you are charged

for the digital communication.

SW substitute img. You can switch a substitute image to be sent to the other party to

SW org. subst. img. You can switch a substitute image to be sent to the other party to

78

the still image set for “Pre-installed” of “Select image”.

the still image set for “Original” of “Select image”.

Switch Image Display Positions

+c

c

+cc

At videophone

start-up

0

At videophone

start-up

Automatic

You can switch the display locations of the received image and the sent

image.

During a videophone call, press c().

1

≥Each time you press

c( ), the displays
switch.

Zoom

At videophone start-up WIDE

You can adjust the magnification for the camera image to be sent to the
other party. During a videophone call, the maximum magnification is about

4.3 times for the camera.

During a videophone call1Use No to adjust the magnification.

1

≥The former zoom setting returns when the videophone call ends.

Function Menu during Videophone Call

CHG to voice call See page 57.

Send DTMF tone/
DTMF tone OFF

V.phone settings

Visual preference See page 80.

Brightness You can adjust the brightness of the camera image to be sent

During a Chara-den call, you can switch to the DTMF
Transmission Mode that enables you to enter the data from
the numeric keys and to send DTMF (touch-tone signals). You
can operate it only during a Chara-den call.
≥“Send DTMF tone” is displayed when the mode is not DTMF

Transmission Mode and “DTMF tone OFF” is displayed in
DTMF Transmission Mode.

≥In DTMF Transmission Mode, you cannot operate the action

of Chara-den images.

≥The DTMF tone may not be received depending on the

device of a receiving end.

to other party to -3 (dark) through +3 (bright).

1Select a brightness level.

Voice/Videophone Calls

White balance You can adjust the colors of the camera image to be sent to

the other party, to make the colors look more natural.

1Select an item.

Fine weather
Cloudy weather

. . . . . . . . . . . . . . . For talking in cloudy weather or in the shade

Automatic
Light bulb

. . . . For talking outdoors in fine weather

. . . . . . For adjusting white balance automatically

. . . . . . For talking under incandescent light

79

Color mode set You can switch the color tone of the camera image to be sent

At videophone

start-up
Normal

At videophone

start-up

OFF

At videophone

start-up

Landscape

Information

Night mode You can lengthen the camera’s exposure time to make the

Focus You can set the focus for during a videophone call.

to the other party.

1Select a color tone.

camera image to be sent clear in a dark place.

1ON or OFF

1Close-up or Landscape

<Visual Preference>

Setting Image Quality for Videophone Calls

You can set the quality of the received image on the display.

m1Set./Service1Videophone1Visual preference

1

1Select an image quality.

≥“Prefer motion spd” is effective when there is motion in an image. When there is

little motion, the quality becomes better if you set to “Prefer img qual”.

≥If you operate from the Function menu during a videophone call, the setting is

effective only for the current videophone call.

Chara-den setup See page 78.

Backlight You can select whether to light the display constantly or light

Voice/Videophone Calls

LCD AI See page 109.

Own number You can display your phone number.

Key guide You can display the guide of key operation during a

<Hands-free with Videophone>

for about 15 seconds after an operation.

1Constant light or 15 seconds light

videophone call.

Setting Hands-free Videophone

You can set whether to switch to Hands-free automatically for when a
videophone call starts.

m1Set./Service1Videophone

1

1Hands-free w/ V. phone1ON or OFF

≥See page 67 for the operation while Hands-free is activated and how to switch to

Hands-free.

80

≥If the radio wave conditions weaken during a videophone call, the image may appear

like a mosaic.

<Select Image>

Changing Image Displays for Videophone Calls

You can set an image to be sent to the other party.

m1Set./Service1Videophone1Select image

1

1Select an item.

On hold. . . . . Sets an image for during answer-hold (On hold).

Holding . . . . . Sets an image for while a call is on hold (Holding).

Substitute image

. . . . . . . . . . . . Sets a substitute image (still image or Chara-den) for when the

Record message

. . . . . . . . . . . . Sets an image while recording a record message.

Preparing . . . Sets an image for while playing back an answer message.
Movie memo

. . . . . . . . . . . . Sets an image for while recording a movie memo.

camera is off.

Select an image.

Information

Information

2

Pre-installed . . . For sending a pre-installed still image to the other party.

Original . . . . . . . For sending an appropriate message with a still image stored

Chara-den. . . . . For sending a Chara-den image selected by “Substitute image”

≥Press l( ) to play back a demo to check the still image or Chara-den

image.

≥To change the setting of “Original” or “Chara-den”, press i( ), select

“Change setting”, then select a still image or Chara-den image. If you have
selected “Original”, select a still image after selecting a folder.
However, you cannot select a still image larger than Stand-by (240 x 428).

≥Even if you delete the still image selected from “Original”, that still image is displayed

to the other party. To change, set by “Change setting” or “Set display”.

using “Set display”.

from the Function menu while a Chara-den image is displayed.
(See page 78)
(Displayed only when “Substitute image” has been selected in
step 1.)

Set by Call

You can set an image to be sent to the other party for making a

videophone call.

Enter a phone number

1

or

call up the detailed display of a Phonebook entry, redial
item, dialed call record, or received call record.

i()1Select image1Chara-den

2

≥To cancel the setting by call, select “Release”. The setting is completed.

Select a Chara-den image.

3

<Voice Call Auto Redial>

Redialing as a Voice Call when a Videophone Call cannot be Connected

If a videophone call cannot be connected, it will be automatically redialed
as a voice call.

m1Set./Service1Videophone1Voice call auto redial

1

1ON or OFF

≥The charges for calls once switched to voice calls are billed at the rates for the voice

calls.

≥Voice Call Auto Redial does not work when a videophone call cannot be connected

such as when the line is busy or the other party’s phone is in Public mode (Drive
mode). However, Voice Call Auto Redial works when you make a videophone call to a
phone that does not support the videophone function.

<Notify Switchable Mode>

Setting for Switching a Voice/Videophone Call during a Call

You can let the other party know that your FOMA terminal can switch
between a voice call and a videophone call.
This function is set to “Indication ON” at the time of contract. When
“Notify switchable mode” is set to “Indication ON”, the caller can switch
between the videophone call and voice call.

≥You cannot operate “Notify switchable mode” when you are out of the service area or

radio waves do not reach, or during a call.

m1Set./Service1Videophone

1

1Notify switchable mode1Do the following operations.

Indication ON 1YES1OK

Indication OFF 1YES1OK

Check indication You can check the setting of the function.

1OK

Voice/Videophone Calls

81

<Videophone while Packet>

Information

Information

Selecting Response to Incoming Videophone Calls during i-mode

m1Set./Service1Incoming call

1

1V.phone while packet1Select an item.

V.phone priority

. . . .Shows the Videophone Call Receiving display. When you answer the

videophone call, packet communication is disconnected.

Packet downld priority

. . . .Rejects the videophone call and continues the communication.

V.phone answerphone

. . . .Connects the incoming videophone call to the Voice Mail Service Center.

Call forwarding

. . . .Forwards the incoming videophone call to the forwarding destination.

Voice/Videophone Calls

≥If you have not signed up for Voice Mail Service or Call Forwarding Service, “Packet

downld priority” works even if you set to “V.phone answerphone” or “Call forwarding”.

Using Videophone Calls by Interfacing to External Devices

You can operate your FOMA terminal from an external device such as
your personal computer for making or receiving videophone calls by
connecting them using the FOMA USB Cable with Charge Function 01/02
(option).
To use this function, you need to install a videophone application
program on a dedicated external device or personal computer, and
further, you need to prepare equipment (commercial item) such as an
earphone/microphone or USB compatible web camera.

≥For operating environments for a videophone application program and how to set or

operate it, refer to the instruction manual or other literature for an external device.

≥You can use “ドコモテレビ電話ソフト (DOCOMO Videophone Software)” as the

application program that supports this function.
You can download “ドコモテレビ電話ソフト (DOCOMO Videophone Software)”
from the DOCOMO website.

≥You cannot make a videophone call from the external device during a voice call.
≥When you have signed up for Call Waiting Service, an incoming videophone call from

an external device during a voice call is recorded as a missed call in Received Calls.
The same applies for an incoming voice call, videophone call, and 64K data
communication during a videophone call from an external device.

82

Phonebook

Phonebooks Available for FOMA Terminal . . . . . . . . . . . . . . . . . 84

Storing Phonebook Entries . . . . . . . . . . . .<Add to Phonebook> 84

Storing Displayed Phone Number/Mail Address in Phonebook

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88

Setting Groups . . . . . . . . . . . . . . . . . . . . . . . . . .<Group Setting> 89

Making a Call from Phonebooks . . . . . . . <Search Phonebook> 89

Editing Phonebook Entries . . . . . . . . . . . . . . <Edit Phonebook> 93

Deleting Phonebook Entries . . . . . . . . . . . . . . . . .<Delete Data> 94

Checking Phonebook Storage Status . . . . <No. of Phonebook> 94

Making a Call with a Few Keys Operation . . . . . <2-touch Dial> 94

Accessing Phonebook Entries by Voice . . . . . . . . <Voice Dial> 95

83

Phonebooks Available for FOMA Terminal

For the FOMA

terminal

For the UIM

You can use two types of Phonebooks, namely the Phonebook in the
FOMA terminal itself, and the Phonebook on the UIM.

Number of entries 1,000 entries 50 entries

Name (Reading)
Group 19 groups 10 groups
Phone number 4 phone numbers 1 phone number
Phone number icon
Mail address 3 mail addresses 1 mail address
Mail address icon

Phonebook

Address

Basic item

Birthday
Memo
Image 100 images —
Memory No. From 000 to 999 —
Ring tone
Vibrator
Illumination
Chara-den 100 Chara-den

Mail ring tone

Setting item

Contents of Phonebook

Mail vibrator
Mail illumination
Answer message
Restrict dialing
Call rejection
Call acceptance
Call forwarding

Restrictions

Voice mail
Secret code
Storage in Secret Mode or
Secret Data Only

FOMA terminal UIM

○○

○

○
○
○
○

○
○
○
○

images

○
○
○
○

○

○
○

—

—
—
—
—

—

—

—

—

Name
Ring tone
Vibrator
Illumination
Chara-den
Mail ring tone
Mail vibrator

Contents of Group

Mail illumination
Answer message

○: Can be stored. —: Cannot be stored.
≥You can set your UIM into another FOMA terminal and use the UIM Phonebook

entries.

FOMA terminal UIM

○○

○

—

<Add to Phonebook>

Storing Phonebook Entries

You can store Phonebook entries in the FOMA terminal (Phone) or on the
UIM.

Xo(for at least one second)1Phone or UIM

1

The Edit Name display appears. Go to step 2 and enter a name.
≥You cannot show the registration display for the Phonebook entries even by

pressing and holding Xo for at least one second from the horizontal Stand-by
display.

Do the following

2

operations.

≥You can press No to switch

between the “Basic item” tab and
“Settings” tab for the FOMA
terminal’s Phonebook.

84

Name You can enter the name of the person or company in kanji,

Reading You can enter the reading in half-pitch katakana, alphabetic

Group In the FOMA terminal, 19 groups are available. On the UIM, 10

hiragana, katakana, alphabetic characters, or numerals.

1Enter a name.

≥For the FOMA terminal, you can enter up to 16 full-pitch/32

half-pitch characters. You ca n enter pictograms and symbols as
well.

≥For the UIM, you can enter up to 10 full-pitch characters/21

half-pitch alphanumeric characters. (Half-pitch katakana
characters cannot be entered.) When the entry contains both
full-pitch and half-pitch characters, you can store up to 10
characters from the beginning regardless of full-pitch or
half-pitch characters.

characters, or numerals.

1Edit a reading.

≥For the FOMA terminal, you can enter up to 32 half-pitch

characters. You can enter half-pitch symbols as well.

≥For the UIM, you can enter up to 12 full-pitch characters/25

half-pitch alphanumeric characters. (Half-pitch katakana
characters cannot be entered.) When the entry contains both
full-pitch and half-pitch characters, you can store up to 12
characters from the beginning regardless of full-pitch or
half-pitch characters.

≥If the displayed reading is acceptable, you do not need to edit it.

However, depending on the characters entered for names or
entering method, they are not reflected in the reading.

≥

If you enter “ゎ (reduced size)” or “ヮ(reduced size)” for a name,
“ワ (half-pitch, regular size)” (for the FOMA terminal) and “ワ
(regular size)” (for the UIM) are displayed in the reading field.

groups are available.

1Select a group.

≥When the storage is completed with no group selected, the

Phonebook entry is stored in “No setting”.

Phone number You can store up to four phone numbers per Phonebook entry in

the FOMA terminal. You can set an icon for each phone number
to categorize mobile phone numbers, office phone numbers, and
so on.
You can store only one phone number per Phonebook entry on
the UIM.

1Enter a phone number.

≥Enter from the city code for the phone numbers.
≥You can enter up to 26 digits. However, you can enter up to 20

digits for blue UIMs.

≥Press and hold a for at least one second to insert a pause (p)

into the phone number you store. However, you cannot insert
the pause (p) to the beginning of phone number or insert it
consecutively. The pause (p) inserted to the end of phone
number is not stored.

≥If you insert “:” in the middle of a phone number, you cannot

make a call. However, the phone number is recorded in Redial
or Dialed Calls.

≥You can store the phone number which includes “#” such as

that for information service as well.

1Select an icon.

≥If you have stored a phone number in the FOMA terminal,

another “ <Phone number>” will appear in the
Add-to-Phonebook display. To store another phone number,
select “ <Phone number>”.

Phonebook

85

Mail address You can store up to three mail addresses per Phonebook entry in

Phonebook

Address 1Enter a ZIP code1Enter a postal address.

Birthday 1Enter a birthday.

Memo 1Enter a memo.

the FOMA terminal. You can set an icon for each mail address to
categorize mobile phone addresses, home addresses, and so on.
You can store only one mail address per Phonebook entry on the
UIM.

1Enter a mail address.

≥The mail address can consist of up to 50 half-pitch alphabets,

numerals or symbol characters.

≥When the mail address is “phone [e-mail]”,

store the phone number only.

≥For the FOMA terminal, you can set a secret code as well. (See

page 93)

1Select an icon.

≥If you have stored a mail address in the FOMA terminal, another

“ <Mail address>” will appear in the Add-to-Phonebook
display. To store another mail address, select “ <Mail
address>”.

≥You can enter up to 7 digits for the zip code.
≥You can enter up to 50 full-pitch/100 half-pitch characters for the

postal address. Further, you can enter pictograms as well.

≥You cannot enter “〒” or “-” (hyphen) in the zip code.

≥You can enter the birthday from January 1, 1800 through

December 31, 2099.

≥You can check the birthday from Schedule. (See page 372)

≥You can enter up to 100 full-pitch/200 half-pitch characters.

Further, you can enter pictograms as well.

Image The stored still image is displayed when you call up the

Memory No. 1Enter a memory number.

Ring tone You can set a ring tone for when a voice call or videophone call

Vibrator You can set a vibration pattern for when a voice call or

Phonebook entry.

1Select an item.

Select image . . . You can store a still image in Data Box.
Shoot image . . . You can store the shot still image.

≥To release the stored still image, select “Release image”.
≥The size of a still image you can store is Stand-by (240 x 428) or

smaller and up to 300 Kbytes in JPEG format or GIF format.

≥If you store a still image larger than 72 x 54 dots, it is displayed

shrunk on the detailed Phonebook display.

≥If you store a still image larger than 240 x 180 dots, it is

displayed shrunk on the Call Receiving display.

≥When “Disp. PH-book image” is set to “ON”, the stored still

image is displayed for an incoming call. However, when another
image is stored for “Picture”, that image is preferentially
displayed for the incoming call.

≥Enter a three-digit number of “000” through “999”.
≥The lowest empty memory number “010” through “999” is

entered in advance.
If “010” through “999” are all occupied, the lowest empty
memory number from “000” through “009” is entered.

comes in from the person stored in the Phonebook.

1Select ring tone

Go to step 2 on page 98.
≥To release the stored ring tone, select “Release ring tone”.

videophone call comes in from the person stored in the
Phonebook.

1Select vibrator1Select a vibration pattern.

≥To release the stored vibrator, select “Release vibrator”.

Perform step 2 through step 3 on page 229.

86

Illumination You can set an illumination pattern for when a voice call or

Picture You can set an image to be displayed for when a call comes in

Chara-den The stored Chara-den image is displayed as a substitute image

Mail ring tone You can set a ring tone for when a mail message comes in from

Mail vibrator You can set a vibration pattern for when a mail message comes

Mail illumination You can set an illumination pattern for when a mail message

videophone call comes in from the person stored in the
Phonebook.

1Select illumination1Select an item.

≥To release the stored illumination, select “Release illumination”.

from the person stored in the Phonebook.

1Select picture1Select a type of image1Select a folder
1Select an image.

≥To release the stored image, select “Release picture”.

for videophone calls with the person stored in the Phonebook.

1Select Chara-den1Select a Chara-den image.

≥To release the stored Chara-den image, select “Release

Chara-den”.

the person stored in the Phonebook.

1Select ring tone

Go to step 2 on page 98.
≥To release the stored mail ring tone, select “Release ring tone”.

in from the person stored in the Phonebook.

1Select vibrator1Select a vibration pattern.

≥To release the stored mail vibrator, select “Release vibrator”.

comes in from the person stored in the Phonebook.

1Select illumination1Select an item.

≥To release the stored mail illumination, select “Release

illumination”.

Answer

message

You can set an answer message for Record Message by
Phonebook entry.

1Select answer message1Select an answer message.

≥To release the stored answer message, select “Release answer

message”.

Press l().

3

≥If you have not entered any name, “ ” is not displayed and you cannot

store the entry.

Phonebook entries while editing

When the low battery alarm sounds

The Phonebook entry you are editing is saved automatically. The confirmation display
appears asking whether to resume editing when you continue editing after charging the
battery or when you operate step 1 on page 84 and select the storage location for the
interrupted Phonebook entry after changing to a charged battery.

Recall. . . . You can resume editing the Phonebook entry.

New . . . . . You can edit a new Phonebook entry. In this case, the interrupted data is

retained. If you execute “Add to phonebook” after storing the new Phonebook
entry, the confirmation display appears again.

≥Only the most recently interrupted entry is retained.
≥If you resume editing the data but then cancel editing without storing it, that data will be

abandoned. Once you recall the data, be sure to store it.

If you receive a call or mail

You can respond it leaving the edited data as it is, thanks to the Multitask function.
To return to the Phonebook Edit display, press and hold x for at least one second to
switch the menu. You can return to the Phonebook Edit display also by ending the call or
mail function.

Phonebook

87

Storing Displayed Phone Number/Mail

Information

Address in Phonebook

You can store the displayed or selected phone number, mail address,
and still image in the FOMA terminal’s or UIM’s Phonebook.

While a phone number is entered Phone number
While a redial item, dialed call record, or received call
record is displayed
While Sent Address or Received Address is displayed Phone number/Mail address
While a site or screen memo is displayed Phone number/Mail address
While the text of Message R/F or mail is displayed Phone number/Mail address

Phonebook

While the data scanned by Bar Code Reader is displayed Phone number/Mail address
While a ToruCa file is displayed Phone number/Mail address
While the Still Image list or a still image is displayed Still image

Call up/Select an item to be stored1i()

1

1Add to phonebook

≥To store the address of the sender (or of another recipient of simultaneous mail)

of the received mail or the destination address of the sent mail into the
Phonebook, select “Store address”.
When the addresses of the sender and anothe r recipient of simultaneous mail are
found or the multiple destination addresses are found, the display for selecting an
address appears. Use Bo to select the mail address or phone number you want
to store.

≥To store a still image in the Phonebook, select “Phonebook” from “Set display”.
≥When “Add to phonebook” is displayed on the Scanned Code Result display for

Bar Code Reader, select “Add to phonebook”; then other information in the
scanned code besides the phone number or mail address is entered into each
field.

Operation Storable items

Phone number

Phone or UIM1Select a storing method.

2

New . . . Go to step 2 on page 84.
Add . . . Adds data to the existing Phonebook entry. When storing data on the

UIM, “Overwrite” is displayed.

Select a search method1Search the Phonebook

3

1Select a Phonebook entry to be stored1Oo()

The phone number or mail address is entered automatically.

≥See step 2 on page 84 to edit other items in the Phonebook entry.
≥When you store into the FOMA terminal’s Phonebook, you can remain the

original entry and store a new entry into a different location by changing the
memory number.

l()1YES

4

≥If you store the entry in the UIM Phonebook, select “Overwrite” to overwrite the

original entry, or select “Add” to store it as a new entry.

≥The Phonebook entry does not store the information of “Notify caller ID” included in

Redial/Dialed Calls. To set Caller ID Notification, add “186”/“184” to the phone
number and store it.

≥Characters that cannot be stored may be replaced by spaces or deleted, and then

stored.

≥You may not be able to store the information from some sites into the Phonebook.

88

<Group Setting>

Search Phonebook

display

Setting Groups

You can utilize the Phonebook by sorting the entries by group such as
“Company” or “Friend”, or by your interest such as “Baseball” or
“Ceramic art”. You can set a ring tone, vibration pattern, or illumination
by group.

m1Phonebook1Group setting

1

≥The groups on the UIM are indicated by “ ”.

≥To reset the group names and respective settings by group, which have already

been stored, press i( ), select “Reset group”, and then select “YES”.

Highlight a group and press l()

2

1Select an item to be set1Set the contents.

≥When you select “ Group name”, enter a group name. You can store up to 10

full-pitch/21 half-pitch characters. However, you can store only up to 10
characters (regardless of full-pitch or half-pitch characters) when you enter both
full-pitch and half-pitch characters for a UIM group name.

≥See step 2 on page 84 for the operations of the other items. However, you cannot

set for groups on the UIM.

≥Select a stored group, or press i( ) and select “Check setting” to check

its settings. However, you cannot check the settings of the groups on the UIM.

Press l().

3

<Search Phonebook>

Making a Call from Phonebooks

You can retrieve stored Phonebook entries by eight search methods.

Xo1Do the following operations.

1

≥The display for the same search method as the

previous one appears once you have carried out a
search. Press r to show the Search Phonebook
display.

≥You can show the Search Phonebook display also by

m1Phonebook1Search phonebook.

≥You cannot show the Search Phonebook display even

by pressing Xo from the horizontal Stand-by display.

All? You can show all Phonebook entries.

Reading? You can enter the reading of the other party’s name from the first

Group? You can show Phonebook entries stored in a specified group.

Memory No.?

[FOMA terminal only]

≥

The tabs appear on the top of the Phonebook list. (See page 90)

character and search. You do not need to enter the full reading.

1Enter a part of the reading1Bo

≥

The tabs appear on the top of the Phonebook list. (See page 90)

1Select a group.

≥

The tabs appear on the top of the Phonebook list. (See page 90)

≥If you press i( ) on the Group list, the Function menu

for “Group setting” is displayed.

You can search for the entry by the memory number assigned
when it was stored in the Phonebook.

1Enter the memory number.

≥Enter from “000” through “999” in three digits.
≥

The tabs appear on the top of the Phonebook list. (See page 90)

≥From the Stand-by display, you can press d and then press

Bo to display the Memory No. Dial display. From there you can

make a voice call by entering the memory number of the phone
number.

Phonebook

89

Name? You can enter the other party’s name from the first character and

Information

Phonebook list

Phone number? You can enter a part of the other party’s phone number and

Mail address?

Phonebook

2-touch dial?

[FOMA terminal only]

search. You do not need to enter the full name.

1Enter a part of the name1Bo

search. You can search for the entry even from the middle of
phone number.

1Enter a part of the phone number1Bo

≥You can display the Phonebook list also by entering a part of

the phone number from the Stand-by display or the “Talking”
display, and pressing Bo.

You can enter a part of the other party’s mail address and search.
You can search for the entry even from the middle of mail address.

1Enter a part of the mail address1Bo

You can show the list of Phonebook entries in memory number
000 through 009.
≥Phonebook entries not yet stored or being set with secret are

displayed as ＜−−−＞.

Select an entry1d or Oo()

2

≥When the entry contains multiple phone numbers, or when you searched by “Mail

address?”, press Mo from the detailed display to select a phone number.

≥You can make a videophone call by pressing l().

≥In a search method other than “Group?” and “2-touch dial?”, enter nothing and press

+Bo; then you can search all through the Phonebook.

≥

When no Phonebook entry is found that matches the condition you entered by
“Reading?” or “Memory No.?”, the entry that is the closest to the condition is displayed.

Search order

The Phonebook entries are searched in the order of readings you entered for storing, as
follows:
“Space at the beginning of the reading” → “Japanese syllabary (

→

“Alphabet (A, a, B, b, ...Z, z)” → “Numerals (0 through 9)” → “Symbols” → “No reading”.
For “All?” and “Reading?”, searching is done in the following order:
“Japanese syllabary (
at the beginning of the reading” → “Numerals (0 through 9)” → “Symbols” → “No reading”.

※The Memory No. Search searches in the order of the memory numbers.

ア、イ、ウ、エ、オ、...ン

)” → “Alphabet (A, a, B, b, ...Z, z)” → “Space

ア、イ、ウ、エ、オ、...ン

About Phonebook List

When you search from “All?”, “Reading?”, “Group?”, or
“Memory No.?”, the tabs appear on the top of the Phonebook
list. With “All?” and “Reading?”, the entries are sorted by every
column of reading, with “Memory No.?” by every 100 of the
memory number, and with “Group?” by every group.
Press No to display the Phonebook entries in the tab at left or
right. However, when there are 12 or more Phonebook entries
in a tab, pressing m(), c(), or </> brings up the previous or next
page.
≥After you search by “Reading?”, you can move the cursor to the “ア” through “ワ”, “英”,

and “他” tab by pressing each numeric key from the list. When you successively press
the same numeric key, you can move the cursor within the same column.
<Example>Press 5 to display the “ナ” tab. Each time you press 5, the cursor

≥After you search by “Group?”, you can move the cursor to the top of each column in the

tab by pressing each numeric key from the list. When you successively press the same
numeric key, you can move the cursor within the same column.
<Example>Press 5 to move the cursor to the top of the “ナ” column. Each time you

≥After you search by “Memory No.?”, you can move the cursor to the “000~” to “900~”

tab by pressing each numeric key from the list.
<Example>Press 5 to move the cursor to the “500~” tab.

moves to the top of “ニ” “ヌ” and so on.

press 5, the cursor moves to the top of “ニ” “ヌ” and so on.

)”

90

Detailed Phonebook

display (Item list)

Group
Reading

Name

Memory No.

Still image

Notify caller ID

≥

You can make a voice call to the phone number stored for the name highlighted on the
Phonebook list, by pressing d. Also, press l( ) to make a videophone call.
When multiple phone numbers are stored for the name, the one stored first will be dialed.

≥For the Phonebook entry stored on the UIM, “ ” is displayed.
≥For the Phonebook entry stored with i-concier information, “ ” is displayed.
≥“ ” appears for the Phonebook entries set to A by Phonebook 2in1 Setting, “ ”

appears for the Phonebook entries set to B, and “ ” appears for the Phonebook
entries set to common data. (Only in Dual Mode)

About the detailed display

Use No to highlight a tab, then the detailed contents are displayed.
≥For the Phonebook entry stored

on the UIM, “ ” is displayed on
the memory number field.

≥When Notify Caller ID is set to

“Notify caller”, “ ” appears,
and when set to “Don’t notify”,
“ ” appears.

≥

Under the still image, “ ”
appears for the Phonebook
entries set to A by Phonebook
2in1 Setting, “ ” appears for
the Phonebook entries set to B,
and “ ” appears for the
Phonebook entries set to common
data. (Only in Dual Mode)

≥When a Phonebook entry contains the setting for Multi Number or Chaku-moji, the set

contents are displayed in the Item list/Phone Number display.

Item list

The first stored phone number, mail address, postal address, birthday, and memo are
displayed. When i-concier information is stored, a postal address, URL, and memo
obtained from i-concier are displayed instead of a postal address, birthday, and memo.

Phone number

≥When you select the item, you can make a call. (See step 2 on page 90)

Mail address

≥When you select the item, you can compose an i-mode mail message with that mail

address entered into the address field.

Personal information

≥When you select a postal address, memo or still image, the full display appears.

i-concier information

≥You can display a site or Internet website when you select a URL, select “i-mode” or

“Full Browser”, and then select “YES”. When you highlight a URL and press
l( ), the full display appears.

≥When you select a postal address or memo, the full display appears.
≥If you have not subscribed to i-concier, the i-concier information tab does not appear.

Settings

≥When you select each item, a demo is played back.

Press Oo() or r to end the demo.

Function Menu of the Phonebook List

New You can store a new Phonebook entry.

Attach to mail You can send an i-mode mail message with the

Search location You can access the site of “イマドコかんたんサーチ

Move/copy

Copy to microSD See page 338.

Connect to Center See pa ge 130.

Sort You can change the display order.

Font size You can switch font sizes for the Phonebook and on the

Send Ir/ trans

Send Ir data

Send phonebook See page 352.

Go to step 1 on page 84.

Phonebook entry attached.
Go to step 2 on page 136.

(imadoco kantan search)”.

1YES

1Select a type of order.

≥You can sort Phonebook entries in reverse order by

selecting “Ascending” or “Descending”.

≥You cannot sort on the Phonebook list with tabs

displayed.

displays within “Phonebook settings”, etc.
(See “Phonebook” on page 115)

Phonebook

91

Send all phonebook See page 353.

transmission

Send phonebook See page 354.

Send all phonebook See page 355.

Delete data See page 94.

Set secret/Release secret You can activate/deactivate Secret for the Phonebook

Function Menu of the Detailed Phonebook Display

Phonebook

Notify caller ID See page 62.

Prefix numbers See page 66.

Int’l dial assist See page 65.

Select image See page 81.

2in1 dial You can select a phone number to notify the other party in

Multi number You can select a phone number to be notified to the other

Chaku-moji See page 61.

Search location See page 91.

Edit data

Edit phonebook Go to step 1 on page 93.

entry.
≥If you select “Set secret” in ordinary mode (not in “Secret

mode” or “Secret data only”), enter your Terminal
Security Code.

Dual Mode of 2in1. (See page 410)

party. (See page 407)

Sort phone number/
Sort mail address

Move/copy

Copy to UIM See page 384.

Copy to microSD See page 338.

Copy to phone See page 384.

Connect to Center See pa ge 130.

Copy item

Copy name You can copy the name of Phonebook entry.

Copy phone number/
Copy mail add./
Copy address/
Copy birthday/
Copy memo/Copy URL

Mail

Compose message You can compose an i-mode mail message to send to the

Attach to mail You can send an i-mode mail message with the

Compose SMS You can compose an SMS message to send to the phone

1Select a phone number or mail address
1Use Bo to change the order1Oo()

≥ From the detailed display, press No to highlight an

item to be sorted. The items you can select from the
Function menu differ depending on the highlighted
item.

≥To change the order in succession, repeat the above

steps.

1l()

You can copy each item of Phonebook entry.
≥From the detailed display, press Mo to highlight an item

to be copied. The items can be selected in the Function
menu differ depending on the highlighted item.

mail address.
Go to step 3 on page 136.

Phonebook entry attached.
Go to step 2 on page 136.

number set as the destination address.
Go to step 3 on page 179.

92

Font size You can switch the font size for the Phonebook and on the

Information

Restrictions See page 127.

Secret code You need to add the recipient’s secret code when sending

Set desktop/ key

Add desktop icon See page 35.

long press set. See page 378.

Send Ir/ trans

Send Ir data

Send phonebook See page 352.

Send all phonebook See page 353.

transmission

Send phonebook See page 354.

Send all phonebook See page 355.

displays within “Phonebook settings”, etc.
(See “Phonebook” on page 115)

i-mode mail to anyone who has registered a secret code.
Once you set the secret code for the mail address in the
Phonebook entry, it will be added automatically whenever
you send mail to that address.

1Enter your Terminal Security Code1Set code

≥From the detailed display, press Mo to highlight a phone

number or mail address to be set with a secret code.

≥To check the secret code, select “Check code”.
≥To release the secret code, select “Release code”.

1Enter a four-digit secret code1YES

≥In the Function menu, “Secret code” is indicated by “★”,

after it is set.

≥Enter a four-digit number for secret code. You cannot set

“0000”.

Delete data See page 94.

Set secret/Release secret See page 92.

<Secret code>

≥You cannot set secret codes for UIM Phonebook entries.
≥The secret code can be added only when the recipient’s mail address is in the form of

“phone number” or “phone [e-mail]”. It cannot be added to any other
form of mail address.

≥If you have stored the mail address as “phone number＋secret [e-mail]”,

you cannot reply to mail messages from the party of that mail address. After changing
the mail address to “phone [e-mail]”, set the secret code.

<Edit Phonebook>

Editing Phonebook Entries

Detailed Phonebook display1m()

1

1Select an item to be edited1Edit the contents.

≥See step 2 on page 84 for how to edit the Phonebook entry.
≥Even if you edit the Phonebook entry in the FOMA terminal (Phone), you can

remain the original contents in the original location and store the edited contents
in the different location by changing the memory number.

l()1YES

2

≥If you edited the UIM Phonebook entry, select “Overwrite” to overwrite the original

contents, or “Add” to save the contents as a new entry.

Phonebook

93

<Delete Data>

Information

Information

Deleting Phonebook Entries

Delete from the Detailed Phonebook Display

Detailed Phonebook display1i()1Delete data

1

1Do the following operations.

Phone number/
This item

Phonebook

This phonebook 1YES

Delete from the Phonebook List

Phonebook list1i()1Delete data

1

1Do the following operations.

Delete this 1YES

Delete selected 1Put a check mark for Phonebook entries to be deleted

Delete all in tab You can delete all the Phonebook entries for the displayed tab.

Delete all You can delete all Phonebook entries including secret entries.

1YES

≥Highlight an item to be deleted by pressing Mo from the

detailed display.

≥You cannot delete information obtained by i-concier.

1l()1YES

≥You can check or uncheck entries all at once by pressing

i( ) and selecting “Select all in tab/Select all/Release
all in tab/Release all”.

≥Perform the same operation as that of “Delete all” when you

have selected all Phonebook entries including secret ones.

1YES

1Enter your Terminal Security Code1YES1YES

<No. of Phonebook>

Checking Phonebook Storage Status

m1Phonebook1No. of phonebook

1

Phone
Phonebook . . .The number of Phonebook entries stored in the FOMA terminal

Secret . . . . . . .The number of Phonebook entries stored as secret data

Image. . . . . . . .The number of Phonebook entries in which still images are stored

Chara-den . . . .The number of Phonebook entries in which Chara-den images are

Voice dial. . . . .The number of Phonebook entries set as voice dial entries

Rest . . . . . . . . . : The number of phone numbers that can still be stored

UIM
Phonebook . . .The number of Phonebook entries stored on the UIM

≥When you use 2in1, the number of Phonebook entries for the mode in use is

displayed. (See page 411)

<2-touch Dial>

(Phone)

(Displayed in Secret Mode or Secret Data Only)

stored

: The number of mail addresses that can still be stored

Making a Call with a Few Keys Operation

When the entry is stored in memory number “000” through “009” in the
FOMA terminal’s Phonebook, you can dial the phone number just by
pressing the lowest one digit of memory number and d.

Numeric key (0 to 9)1d or Oo()

1

≥You can make a videophone call by pressing l().

≥When the Phonebook entry contains multiple phone numbers, the first phone number

will be dialed.

≥When you set “Restrict dialing” to a Phonebook entry of memory number 000 through

009, set it to the first phone number in the Phonebook entry.

94

≥When you store a Phonebook entry of memory number from 000 through 009 as

Information

Information

Information

Information

secret data, make a call to that entry in Secret Mode or Secret Data Only.

<Voice Dial>

Accessing Phonebook Entries by Voice

Just vocalize the other party’s voice dial name and then the Phonebook
entry is accessed for making a call.

Voice Dial Setting

You can store up to 100 voice dial entries selecting from among the
Phonebook entries stored in the FOMA terminal (Phone).

m1Phonebook1Phonebook settings

1

1Voice dial setting1<New>

≥You can edit the stored voice dial name by pressing l( ). Go to step 3.
≥To delete the stored voice dial entry, press i( ) and select “Delete” or

“Delete all” and then select “YES”.

Search the Phonebook1Select a Phonebook entry.

2

The display for search method you used last time appears.
≥The “★” mark is added to the Phonebook entry stored in the Voice Dial list.

Enter a voice dial name.

3

≥You can enter up to 22 half-pitch katakana characters.
≥The reading (katakana only) of the Phonebook entry is displayed as the voice dial

name. Correct the name to the easy-to-identify words.

≥The voice dial name set by this function is effective only for calling up a voice dial

entry. For the voice guidance function, the reading (name) stored in the Phonebook is
read aloud.

+m-2-6

≥When multiple similar voice dial names are stored or when the voice dial name is

short, the recognition rate lowers and a wrong voice dial entry (Phonebook entry)
might be accessed. In this case, rename the existing voice dial name and store it.

≥You cannot store “ボイスセッテイ (Boisusettei)” as a voice dial name.

Dial from Phonebook by Voice

By your voice, you can access the Phonebook entry you set in the Voice
Dial list. When “Read aloud settings” is set to “ON” and “Voice dial” is
checked, the operation is guided by the voice guidance.

d(for at least one second)

1

1As soon as the voice recognition start tone sounds,

vocalize the voice dial name.

Start vocalizing within four seconds after the voice recognition start tone sounds.
Once the voice is recognized as a voice dial entry, the detected result is displayed.
≥You cannot change the volume of the voice recognition start tone. The voice

recognition start tone does not sound during Manner Mode.

≥If you say the word “ボイス設定 (Boisusettei)”, the display of “Voice settings”

appears. (See page 96)

≥When “Auto voice dial” is set to “ON”, the display for Auto Voice Dial appears

after the voice is recognized as a voice dial entry. Then about two seconds later,
the FOMA terminal automatically dials out.

≥You cannot access a voice dial entry even by pressing and holding d for at

least one second from the horizontal Stand-by display.

Highlight a detected result and press d or Oo().

2

The first phone number in the selected Phonebook entry is dialed.
≥You can show the detailed Phonebook display by pressing l().

Highlight a phone number and press d or Oo( ) to make a voice call.
Also, you can make a videophone call by pressing l().

≥When you vocalize, keep your mouth away from the microphone about 10 cm. If your

voice is too distant, it may be difficult to recognize your voice.

≥Pronounce the voice dial name as clearly as possible.
≥Before and after voice production, avoid making the sounds unrelated to the voice dial

name such as clearing your throat, clicking your tongue, noisy breathing or other
noise.

95

Phonebook

≥Vocalize in quiet, noise-free locations.

Information

≥While vocalizing, do not put your fingers over the microphone, or press or brush the

keys.

To access a voice dial entry using an earphone/microphone

You need to set “Voice headset dial” to “ON” and open the FOMA
terminal in advance.

Press and hold the switch of the earphone/microphone

1

(option) for at least one second.

Perform the operations of “Dial from Phonebook by

Phonebook

2

Voice” on page 95.

≥You can make a call also by pressing the switch of the earphone/microphone

instead of pressing d or Oo.

Voice Settings

m1Set./Service1Other settings1Voice settings

1

1Do the following operations.

Auto voice dial You can automatically make a call to the phone number

Voice headset dial You can access the voice dial entries by using an earphone/

Read aloud settings See page 366.

Read aloud volume See page 367.

Read aloud speed See page 367.

Read aloud output See page 367.

accessed by voice.

1ON or OFF

microphone (option).

1ON or OFF

Read aloud valid
set.

See page 367.

96

Sound/Screen/Light Settings

Sound Settings

Changing Ring Tone . . . . . . . . . . . . . . . . . . . <Select Ring Tone> 98

Setting Sound Effects of Ring Tone or Melody

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <Melody Effect> 99

Informing You of an Incoming Call by Vibration. . . . . <Vibrator> 100

Using Recorded Sound as Ring Tone . . . . . .<Voice Announce> 100

Changing Ringback Tone . . . . . . . . . . . . . <Melody Call Setting> 100

Setting Keypad Sound. . . . . . . . . . . . . . . . . . . . <Keypad Sound> 101

Setting Charging-start/end Tones . . . . . . . . . . <Charge Sound> 101

Sounding Alarm when a Line is Nearly Disconnecting

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <Quality Alarm> 101

Setting Ring Time for Mail and Messages R/F

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <Mail/Message Ring Time> 101

Sounding Ring Tone from Earphone Only

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <Headset Usage Setting> 102

Muting Tones from FOMA Terminal . . . . . . . . . . <Manner Mode> 102

Selecting Manner Mode Type . . . . . . . . . . . . <Manner Mode Set> 103

Screen/Light Settings

Changing Displays . . . . . . . . . . . . . . . . . . . . . . <Display Setting> 105

Displaying an Image Stored in Phonebook while Ringing

. . . . . . . . . . . . . . . . . . . . . . . . . . . . .<Display Phonebook Image> 107

Setting Displays for Private Window . . . . . . . . <Private Window> 107

Displaying Arrival Information by Opening FOMA Terminal

. . . . . . . . . . . . . . . . . . . . . . . . . . . . <Received Mail/Call at Open> 108

Setting Lights for Display and Keypad . . . . . . . . . . . <Backlight> 108

Adjusting Quality of Display Automatically . . . . . . . . . <LCD AI> 109

Making Display Hard to See from People Around

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <View Blind> 109

Setting Quality of Display. . . . . . . . . . . . . . . . . . <Image Quality> 110

Setting Color Combination for Display

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <Color Theme Setting> 110

Setting Displays for Main Menu . . . . . . . . . .<Menu Icon Setting> 110

Using Kisekae Tool . . . . . . . . . . . . . . . . . . . . . . . . <Kisekae Tool> 111

Setting Machi-chara Image. . . . . . . . . . . . . <Set to Machi-chara> 112

Setting Display of Horizontal Open Menu

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <Horizontal Open Menu> 112

Setting Color and Others of Call/Charging Indicator

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <Illumination> 112

Checking Missed Calls and New Mail by Tone and Call/Charging

Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . <Info Notice Setting> 114

Changing Character Font . . . . . . . . . . . . . . . . . . . . . . . . . . <Font> 114

Changing Font Size. . . . . . . . . . . . . . . . . . . . . . . . . . . <Font Size> 115

Setting Clock Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116

97

<Select Ring Tone>

Information

Changing Ring Tone

You can set a ring tone for each incoming type.
If you select an i-motion movie, the i-motion movie is played back with
sound for incoming calls/messages. (Chaku-motion)

≥The ring tone is the PCM sound source, chord of 128 tones, and ADPCM compliant.
≥See “Add to Phonebook” on page 84 for setting a ring tone by Phonebook entry, and

see “Group Setting” on page 89 for setting it by group.

■Ring Tone List (pre-installed)

Display Title Name of Lyricist/Composer
Pattern 1
Pattern 2
Pattern 3
Pattern 4
Pattern 5

※1

Animals
Seaside Resort Seaside Resort

HEIGH HO // SNOW

※1

WHI

※1

SONATINE

Sound/Screen/Light Settings

PARADE OF THE

※1

WOODEN

SUMMERTIME SUMMERTIME

SOMEDAY MY PRINCE WISOMEDAY MY PRINCE

PEER GYNT SUITE NR
1

Sound effect1
Sound effect2
Old Type Phone
Steelpan

※1

Minimal
Magical Stick
Ukulele

98

※1

ーー
ーー
ーー
ーー
ーー

Animals

HEIGH HO // SNOW
WHITE AND THE
SEVEN DWARFS /INST

SONATINE

PARADE OF THE
WOODEN SOLDIERS

WILL COME
PEER GYNT SUITE NR
1 OP 46/
MORGENSTEMNING

ーー
ーー
ーー
ーー
ーー
ーー
ーー

Composer:
CHURCHILL FRANK E

Composer:
WOLFGANG AMADEUS
MOZART
Composer:
JESSEL LEON
Composer:
GERSHWIN GEORGE
Composer:
CHURCHILL FRANK E

Composer:
GRIEG EDVARD HAGERUP

ー
ー

+m-1-3

Display Title Name of Lyricist/Composer

Waterdrop

タイムスリップTV

※1 3D sound is supported. See page 99 for 3D sound.
※2 i-motion movie
※3 © NHK Enterprises, Inc. © Kappa-za © Mitsuru Kaneko

© The Kawamoto productions Ltd. © Studio japipo
© Puppet theater La CLARTE Arranged by PansonWorks

(Note) The names of lyricists and composers are described conforming to the JASRAC

website.
Whole part of long titles may not be displayed due to restriction of the display
size.

※2※3

ーー

タイムスリップTV (Time

Slip TV)

ー

m1Set./Service1Sound1Select ring tone

1

1Select an incoming type.

≥Select an item and press l( ) to check the contents actually played

back or displayed.

Select ring tone1Select a type of ring tone.

2

Melody . . . . . . . . . . . Sets a melody as a ring tone.

MUSIC. . . . . . . . . . . . Sets a Chaku-uta Full® music file as a ring tone.

imotion . . . . . . . . . Sets an i-motion movie as a ring tone. (Chaku-motion/

Voice announce . . . Sets the sound recorded by “Voice announce” as a ring

OFF . . . . . . . . . . . . . . Sets a ring tone off. The setting is completed.

Chaku-uta®)

tone. The setting is completed.

Select a folder1Select a ring tone.

3

≥If you select “MUSIC” in step 2, select “Fullsong ring tone” or “Point ring tone”.

(See page 276)

≥See page 196 when you select “Search by i-mode”.

≥You can set the Call Receiving display by selecting “Phone” or “Videophone”, and

then by selecting “Select calling disp.”. Go to step 2 on page 106.
