DoCoMo p-08A User guide

P-08A

ISSUE DATE:

NAME:

PHONE NUMBER:

MAIL ADDRESS:

INSTRUCTION MANUAL

‘09.6

Easy Search/Contents/Precautions

Before Using the Handset

Voice/Videophone Calls/PushTalk

Phonebook

Sound/Screen/Light Settings

Security Settings

Mail

i-mode/Full Browser

i-motion/Movie/i-Channel/i-concier

Camera

1Seg

Music

i-αppli/i-Widget

Osaifu-Keitai/ToruCa

Map/GPS Function

Data Management

Convenient Functions

Character Entry

Network Services

Overseas Use

PC Connection

Appendix/Troubleshooting

Index/Quick Manual

DOCOMO W-CDMA・GSM/GPRS System

Before using your FOMA terminal

Thank you for selecting the “docomo STYLE series P-08A”.

Before or during use of the P-08A, make sure that you read this manual and the
separate manuals for other optional devices thoroughly so that you can use the
P-08A correctly.
If you feel any inconvenience in reading the manual, contact the docomo
Information Center listed on the back page of this manual.
The P-08A is designed to be your close partner. Treat it carefully at all times to
ensure long-term performance.

●Because the FOMA terminals use radio waves, they cannot be used in places

where radio waves do not reach, such as inside tunnels, underground, or in
buildings; or the outside where radio waves are weak or out of the FOMA
service area. They may not be used in the high-rise buildings even when the
antennas are unobstructed. You may also experience interruption of calls
even when using without moving while the radio waves are strong enough for
the three antennas to appear on the display.

●Use the FOMA terminal carefully to avoid disturbing other people when in

public, or in crowded or quiet places.

●Since the FOMA terminals use radio waves as the medium of

telecommunication, calls may be tapped by the third party.
However, the W-CDMA・GSM/GPRS system automatically supports tapping
prevention, so your conversation will be incomprehensible to the third party,
because it is recognized as mere noise.

●The FOMA terminals change your voice into digital signals and send them to

the other party. In places where the radio waves are weak, the digital signals
may not be converted correctly, and in such a case, the voice may sound
different from the actual original voice.
The user hereby agrees that the user shall be solely responsible for the result of

●

the use of SSL/TLS. Neither DOCOMO nor the certifiers as listed herein make any
representation and warranty as for the security in the use of SSL/TLS. In the event
that the user shall sustain damage or loss due to the use of SSL/TLS, neither
DOCOMO nor the certifiers shall be responsible for any such damage or loss.
Certifiers: VeriSign Japan K.K., Cybertrust Japan Co., Ltd., GlobalSign K.K.,

RSA Security Japan Ltd., SECOM Trust Systems Co., Ltd., and

●This FOMA terminal supports FOMA Plus-Area and FOMA High-Speed Area.

●The FOMA terminal can be used only via the FOMA network provided by

Comodo CA Ltd.

DOCOMO and in DOCOMO’s roaming area.

●It is recommended that you make separate notes of the information (such as

Phonebook entries, schedule events, text memos, record messages, voice
memos, movie memos) stored in the FOMA terminal and keep them in a safe
place. Note that we cannot be held responsible for the unlikely event of loss of
the stored contents due to a malfunction, repair, change of your model, or
other mishandling of the FOMA terminal.

●You are advised to save your important data files to the microSD card. If you

have a personal computer, you can transfer and save the information such as
Phonebook entries, mail messages, schedule events, and others to the
personal computer by using DOCOMO keitai datalink.

For Using This Manual

This FOMA terminal supports Kisekae Tool (page 114).
If you use Kisekae Tool to change the design of the Menu display,
some menu configurations change according to the usage
frequency depending on the type of the menu. Further, some menu
numbers that are assigned to the menu items do not apply.

You can download the latest information about this manual
from the following DOCOMO website:

・User’s Manual (PDF file) Download

(http://www.nttdocomo.co.jp/english/support/manual/index.html)

※The URL and the content of the website might be modified

without notice.

Easy Search/Contents/Precautions

Search from the index when you know the names of functions or services.

Search from keywords for the functions you frequently use or the functions that are
convenient if you can know any.

Search from the tabs printed on the cover.

See the next page for details.

Search from the contents that categorize functions.

Search from here to use the main functions.

Search from the function list.

Quick Manual gives you a clear, brief description about basic functions. You can take it
when you go out. Further, Quick Manual “For Overseas Use” is attached, so refer to it
when you use the FOMA terminal overseas.

From the Index

From Easy Search

From the Tabs on the Cover

From the Contents 11P.6

From the Main Functions 11P.8

From the Function List 11P.466

From Quick Manual 11P.550

It is prohibited to copy all or part of this manual without permission.
The instructions contained in this manual may be changed without notice.

Viewing/Searching This Manual

In this manual, illustrations and symbols are used in the explanations so
that you can correctly and easily use the FOMA terminal.

≥The most operating procedures and displays in this manual are described with the

default settings of the “Mat Black” (see page 466) handset. However, the following
settings are changed.

・“Display setting” → “Stand-by display”: OFF
・“Display setting” → “Clock” → “Stand-by clock” → “Position”: Pattern 1
・“Color theme setting”: White
・“Menu icon setting”: Normal
・“Disp. call/receive No.” → “Font color”: Black

≥Displays and illustrations described in this manual are for reference. The actual ones

might differ.

≥In this manual, “Osaifu-Keitai compatible i-αppli which supports the IC card function” is

described as “Osaifu-Keitai compatible i- αppli”.

≥Note that “P-08A” is referred to as “FOMA terminal” in this manual.
≥In the operating procedures of this manual, key operations are described with

simplified key icons.

≥The functions which use a microSD card are described in this manual; however, you

need to obtain a microSD card separately to make these functions available. See
page 360 for the microSD card.

How to Refer to This Manual

By the following search methods, you can find pages where your desired
functions and services are described:

Easy Search/Contents/Precautions

1

How to search for “Alarm” is explained here as an example of search method.

Additional guidance . . . . . . . . . .448

Address link function . . . . . . . . . . .208

After-sales services . . . . . . . . . . . . 513

Alarm . . . . . . . . . . . . . . . . . . . . . . . 394

Alarm setting . . . . . . . . . . . . . . . . . 403

Answer setting . . . . . . . . . . . . . . . . . 64

Antenna . . . . . . . . . . . . . . . . . . . . . . 23

From the Index

11P.540

Search for a function or a service
name as shown on the right.

Search for the functi on you
frequently use or that is
convenient if you know any as
shown on the right.

Other things you can do

To reduce the battery consumption ..............................<Power Saver Mode> 112

To scan QR codes or bar codes ......................................<Bar Code Reader> 241

To listen to music.................................................................. <MUSIC Player> 274

To check your location and area information.................<Map/GPS Function> 322

To use the microSD card...................................................... <microSD Card> 360

To exchange information using infrared rays.........<Infrared Communication> 374

To use the FOMA terminal as an alarm clock.....................................<Alarm> 394

To use the FOMA termin

al as a calculator ..................................<Calculator> 408

To use the FOMA terminal overseas ........................<International Roaming> 450

To update software programs........................................... <Software Update> 515

Go to page 394
where “Alarm”
is explained.

From Easy Search

11P.4

i-αppli/i-Widget

Map/GPS Function

Osaifu-Keitai/ToruCa

Data Management

Music

Convenient Functions

Character Entry

Network Services

PC Connection

Overseas Use

Appendix/Troubleshooting

Multitask . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <Multitask> 391

Informing You of an Incoming Call/Mail Message by Voice

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <Reading Aloud> 392

Turning Power On/Off Automatically at a Specified Time

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <Auto Power ON/OFF> 394

Using Alarm. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <Alarm> 394

Using Calendar to Manage Schedule . . . . . . . . . . .<Schedule> 397

Using ToDo to Manage Schedule . . . . . . . . . . . . . . . . . <ToDo> 401

Setting Operating Conditions of Alarm . . . . . <Alarm Setting>403

From the Tabs on the
Cover

11Cover page

Search for the function you want
to set in the order of “Cover”

→ “First page of Chapter”
→ “Description page” as shown

on the right.

Easy Search/Contents/Precautions

2

Easy Search/Contents/Precautions

394

Convenient Functions

You can set Alarm to alert you at the specified time with an alarm tone,
animation and illumination. You can store up to 12 alarms.

1

mStationeryAlarmHighlight an
alarm and press l()

Do the following operations.

2

Press l().

+m-4-4

<Alarm>

Using Alarm

Alarm You can set whether to validate or invalidate the alarm.

ON or OFF

Time Enter the time for sounding the alarm.

pYou cannot set the same time as the time set for the stored

alarm.

Tone Select a type of alarm toneSelect a folder

Select an alarm tone.

Volume Use Bo to adjust the volume.

pIf you set “Step”, the alarm tone is silent for about three

seconds, and then the volume steps up every about three
seconds, from Level 1 through Level 6.

Prefer manner

mode

You can set the alarm tone which sounds at the specified time
during Manner Mode.

ON or OFF

ON. . . . . Sounds at the same volume as set for “Alarm volume”.

OFF. . . . Sounds at the volume set for this function.

The icon appears on the Stand-by display.
“” . . . Displayed when an alarm is set for today (except the setting for past time).

“” . . . Displayed when an alarm is set for tomorrow or onward only.
pIf you set “Alarm” of a schedule event/ToDo item to “OFF”, the icon is not displayed.

Function Menu while Alarm is Displayed

Edit Go to step 1 of “Using Alarm” on page394.

Detail You can display the stored alarm contents.

Set this You can validate the stored alarm.

YES

pYou can validate also by pressing Oo().

Set all You can validate all the stored alarm.

YES

Delete

Delete this YES

Delete all Enter you Terminal Security CodeYES

Information

pIf the alarm tone sounds during a call, press any key to stop it. Once again press any

key to end the alarm including Snooze. If the other party on the phone hangs up, an
alarm including Snooze ends.

pDuring a call, the alarm tone sounds at the level set for “Volume” (earpiece volume).
pTurn off the FOMA terminal after setting “Auto power ON” to “OFF” when you are near

electronic devices using high-precision control or weak signals, or where the use is
prohibited such as in airplanes and hospitals.

When you set an alarm for “Alarm”, “Schedule”, and “ToDo”

Note: The page above is a sample.

Menu number
(See page 34)

Function name
You can find this in
Index.

Operating
procedure
(See page 32)

Reference display
(Characters and settings
are for reference.)

Options and their
explanations

Items shown on the
display
(Some items cannot
be executed.)

Operation and
supplementary
explanation for each
item

Operations related to
the function and
explanations for
supplementary
operations

Chapter title

You can
search by
chapter.

Cautions or
references for using
each function

Lower sub-menu item
of the Function menu

3

Easy Search

To retrieve a desired function with simple words, refer to the following:

To know convenient functions for making calls

To/Not to notify your phone number to the other party

.................................................................................... <Caller ID Notification> 46

To switch to a videophone call during a voice call

...........................................................................<Switch to Videophone Call> 51

To change a volume level of the other party’s voice....................... <Volume> 66

To put a call on hold during a call.................................................... <Holding> 67

To do the following when you cannot answer calls

To put an incoming call on hold before answering......................... <On Hold> 67

Easy Search/Contents/Precautions

To convey the message that you need to refrain from talking on the phone

.....................................................................Using Public Mode (Drive Mode) 68

....................................................................... Using Public Mode (Power Off) 68

To record voice/video messages..........................<Record Message Setting> 69

To change melody or illumination

To adjust the ring volume........................................................<Ring Volume> 66

To change ring tones according to callers......................<Add to Phonebook> 88

To change ring tones........................................................<Select Ring Tone> 102

To know incoming calls by vibrator .................................................<Vibrator> 104

To mute the keypad sound...................................................<Keypad Sound> 105

To activate Manner Mode...................................................... <Manner Mode> 106

To change colors/lighting patterns of Call indicator for incoming calls

.................................................................................................. <Illumination> 115

To change/know display settings

To know the meaning of marks (icons) on the display .....................<Display> 27

To change the Stand-by display (Wallpaper) ...................... <Display Setting> 109

To display a calendar on the Stand-by display..............................<Calendar> 109

To change the menu display .......................................... <Menu Icon Setting> 114

To change the font size .................................................... <Font Size Setting> 118

To make full use of mail

To send Deco-mail ...................................................................... <Deco-mail> 145

To send images ....................................................................... <Attachments> 152

To sort and save mail automatically ..............................................<Auto-sort> 171

To make full use of camera

To shoot with the flash/photo light........... <Flash Setting/Photo Light Setting> 236

To change the shooting size...................................................... <Image Size> 237

To save to the microSD card ...........................................................<Store In> 238

To display shot images......................................................... <Picture Viewer> 334

4

Easy Search/Contents/Precautions

To use the FOMA terminal with a sense of security

To lock the FOMA terminal from away when it gets lost

......................................................................................... <Omakase Lock>※1125

To keep Phonebook entries from prying eyes......................... <Secret Mode> 133

To reject calls without a caller ID.............................. <Call Setting without ID> 135

To reject calls from the phone numbers that are not

in the Phonebook ............................................................<Reject Unknown> 136

To separately store Phonebook and other data

files in preparation for their erasure.................... <Data Security Service>※2137

※1 This is a pay service.
※2 This is a pay service which is available on a subscription basis.

To make full use of 1Seg

To watch 1Seg programs ...................................................... <Activate 1Seg> 249

To record 1Seg programs.................. <Record Video> <Record Still Images> 256

To set TV Timer/Timer Recording for 1Seg programs

.......................................................................<TV Timer> <Timer Recording> 257

To change settings of video and audio...................................<User Settings> 262

Other things you can do

To reduce the battery consumption .............................. <Power Saver Mode> 112

To scan QR codes or bar codes ...................................... <Bar Code Reader> 241

To listen to music.................................................................. <MUSIC Player> 274

To check your location and area information.................<Map/GPS Function> 322

To use the microSD card ...................................................... <microSD Card> 360

To exchange information using infrared rays.........<Infrared Communication> 374

To use the FOMA terminal as an alarm clock.....................................<Alarm> 394

To use the FOMA terminal as a calculator ..................................<Calculator> 408

To use the FOMA terminal overseas ........................<International Roaming> 450

To update software programs........................................... <Software Update> 515

To update security ......................................................... <Scanning Function> 520

≥The operating procedures for frequently used functions are summarized in Quick

Manual. (See page 550)

5

Contents

Viewing/Searching This Manual . . . . .1

Easy Search . . . . . . . . . . . . . . . . . . . . . .4

Contents . . . . . . . . . . . . . . . . . . . . . . . . .6

Main Functions of P-08A. . . . . . . . . . . .8

Before Using the

Handset

21

Voice/

Videophone Calls/

PushTalk

47

Easy Search/Contents/Precautions

Phonebook

87

Sound/Screen/

Light Settings

101

Part Names and Functions, Display, Desktop Icon,
Selecting Menu, Guide, UIM (FOMA Card),
Battery Pack, Charging, Power ON/OFF,
Select Language, Set Time, World Time Watch,
Caller ID Notification, Own Number, etc.

Making a Call/Videophone Call, Call Records,
Chaku-moji, Receiving a Call/Videophone Call, Volume,
Ring Volume, Public Mode, Record Message Setting,
Chara-den, Making a PushTalk Call,
Receiving a PushTalk Call, PushTalk Phonebook, etc.

Available Phonebooks,
Add to Phonebook (FOMA terminal/UIM),
Group Setting, Search Phonebook, Edit Phonebook,
Delete Data, No. of Phonebook, 2-touch Dial,
Voice Dial

Select Ring Tone, Vibrator, Speed Selector Sound,
Manner Mode, Display Setting, Backlight,
Menu Icon Setting, Kisekae Tool, Set to Machi-chara,
Illumination, Font, etc.

Precautions. . . . . . . . . . . . . . . . . . . . . . 10

Handling Precautions . . . . . . . . . . . . . 16

Basic Package and Main Options . . . 20

Mail

141

i-mode/

Full Browser

189

i-motion/Movie/

i-Channel/i-concier

217

Camera

225

1Seg

245

i-mode Mail, Deco-mail, Decome-Anime, Template,
Attachments, Mail Auto-receive, Receive Option,
Check New Messages, Message R/F,
Early Warning “Area Mail”, Chat Mail, SMS, etc.

i-mode, iMenu, My Menu, Change i-mode Password,
Full Browser, Last URL, Enter URL, Bookmark,
Screen Memo, Download, Upload, i-mode Settings,
Certificate, etc.

i-motion/Movie, Download i-motion/Movie,
Movie Auto Play Setting, i-Channel, i-concier

Before Using Camera, Still Image Shoot,
Moving Picture Shoot, Settings for Shooting,
Setting Image Size/Image Quality, Bar Code Reader

1Seg, Before Using 1Seg, Channel Setting,
Activate 1Seg, i-αppli Program Guide,
Data Broadcasting, TVlink, Recording 1Seg,
TV Timer/Timer Recording, User Settings

Security Settings

121

6

Security Codes, Change Security Code,
Releasing PIN Lock, Lock All, Omakase Lock,
Self Mode, Personal Data Lock, Keypad Dial Lock,
Secret Mode, Call Setting without ID, Reject Unknown,
Reset Settings, Initialize, etc.

Music

265

Music&Video Channel, Set Program,
Playing/Operating Programs, Playing Music,
Saving Music Files, MUSIC Player, Playlist

i-αppli/i-Widget

285

i-αppli, i-αppli Download, i-αppli Run, iαppli Settings,
Starting i-αppli Automatically, iαppli Call,
i-αppli Stand-by Display, iαppli Data, i-Widget,
Start Widget Appli

Network Services

431

Check New Messages, Voice Mail, Call Waiting,
Call Forwarding, Nuisance Call Blocking,
Caller ID Request, Dual Network, Service Numbers,
Remote Control, Multi Number, 2in1, OFFICEED, etc.

Easy Search/Contents/Precautions

Osaifu-Keitai/

ToruCa

309

Map/GPS Function

321

Data Management

331

Convenient

Functions

389

Character Entry

421

Osaifu-Keitai, iC Transfer Service, IC Card Content,
IC Card Lock, Check IC Owner, ToruCa,
Receive ToruCa Files, ToruCa Viewer,
ToruCa File List/Detailed ToruCa File Display,
ToruCa Settings

Using GPS Function, Position Location,
Map/GPS Compatible i-αppli, Provide Location,
Notify of Location, Location History, GPS Settings

Picture Viewer, i-motion Player, Movie Player,
Video Player, Chara-den, Machi-chara, Melody Player,
Kisekae Tool, microSD Card, Voice Recorder,
PDF Viewer, etc.

Multiaccess, Multitask, Reading Aloud,
Auto Power ON/OFF, Alarm, Schedule, ToDo,
Multi Key Long Press Setting, Own Number, Call Data,
Calculator, Bluetooth Function, Check Settings, etc.

Character Entry, Mode 1 (5-touch), Common Phrases,
Cut/Copy/Paste, Own Dictionary, Learned Words,
Download Dictionary, Mode 2 (2-touch),
Mode 3 (NIKO-touch)

Overseas Use

449

PC Connection

459

Appendix/

Troubleshooting

465

Index/

Quick Manual

539

Outline of International Roaming (WORLD WING),
Available Services, Confirmation for Using,
Making a Call at the Country You Stay,
Receiving a Call, 3G/GSM Setting,
Set Roaming Guidance, Network Services, etc.

Available Data Communication,
Before Using Data Communication,
Setup Flow for Data Transfer (OBEX™ Communication),
Setup Flow for Data Communication, AT Command,
CD-ROM, DOCOMO Keitai Datalink

Function List, Options and Related Devices,
Troubleshooting, Error Messages, Warranty and
After-sales Services, i-mode Fault Diagnosis Site,
Software Update, Scanning Function, Main Specifications,
SAR, Export Administration Regulations, etc.

Index, Quick Manual,
Quick Manual “For Overseas Use”

7

Main Functions of P-08A

◆i-concier 11P.222

i-concier is a service that enables you to receive useful information from a character
(Machi-chara image) on the Stand-by display and download schedule event
(i-schedule) files for your convenience.
Downloaded i-schedule events or ToruCa files are automatically updated to the latest
information, and the address information of shops/companies, etc. is automatically
added to the Phonebook.

◆i-αppli Call 11P.302

i-αppli call is a useful function for online games that enables your content provider or
third party to give notice to your opponent to start the specified corresponding
application.

◆International Roaming 11P.293, P.450

Easy Search/Contents/Precautions

Your FOMA terminal, phone number, and mail address are available overseas (3G/
GSM areas are supported).
Further, “日英版／日中版 しゃべって翻訳 for P (J-E/J-C Speech Translation for
P)”, which translates words into English or Chinese if you talk in Japanese, and into
Japanese if in English or Chinese, is pre-installed.

◆Display Battery 11P.42

You can check detailed battery level by 100 steps.

◆i-Widget 11P.306

i-Widget is a useful function that enables you to easily access the tools and
commonly-used contents (Widget Appli) such as a calculator, clock, TV program list,
and stock prices information.
By launching the i-Widget display, you can check your desired latest information at a
glance.

◆i-mode 11P.190

You are now enabled to check websites more easily for information by enhanced
operational performance, and to enjoy various moving picture contents as Flash
Video and Windows Media® Video are supported.

®

◆1Seg 11P.246

You can watch 1Seg programs of the terrestrial digital broadcasting for mobile
objects. By Mobile W-Speed, the outline of images are automatically corrected so
that you can watch more smooth videos of 1Seg programs. Also, the light sensor
automatically adjusts the backlight in accordance with the ambient brightness, and
the LCD AI compensates the image quality in accordance with the brightness.

◆Bluetooth Function 11P.412

The wirelessly-connected FOMA terminal and a Bluetooth device enable you to talk
or listen to music while you are carrying the FOMA terminal in your bag.

◆Impressive Liquid Crystal Display

You can display still images and moving pictures in the Full Wide VGA (480 dots x
854 dots) display of approx. 3.1 inches and can enjoy watching 1Seg programs on
the impressive display.
Moreover, you can use the side key to shoot still images and moving pictures with
horizontal wide display just like using a digital camera.

◆Feel＊Mail 11P.176

Animation of 45 characters and illumination reproduce the atmosphere of mail
messages. Pleasant animation appears and illumination lights according to the
contents of mail message.

8

◆Speed Selector 11P.25

By the rotating operation, you can scroll displays and select items quickly. Further, in
various situation, you can comfortably operate functions such as volume adjustment
during music playback or during a call, and zoom adjustment for when shooting with
the camera.

◆Swing Slide 11P.24

When you slide to open, the display slightly comes up to your side, so it is easy to see
and you feel the naturally-angled touch when putting it on your face during a call.

◆Recv. Mail/Call at Open 11P.111

When a missed call or new mail message is found, just open the FOMA terminal to
display the detailed Missed Call display or the Inbox list.

◆Chaku-moji 11P.54

◆Videophone 11P.48

◆i-mode mail/Deco-mail/Deco-mail pictogram 11P.142, P.145, P.332

◆i-αppli/Mega i-αppli/Intuitive Games 11P.286

◆High-Speed Communication Supported 11P.460

◆Chaku-uta Full®/Uta-hodai/Music&Video Channel 11P.266, P.272, P.274

≥“Chaku-uta Full” is a registered trademark of Sony Music Entertainment Inc.

◆MUSIC Player 11P.274

◆GPS 11P.322

◆Osaifu-Keitai/ToruCa 11P.310, P.312

◆Kisekae Tool 11P.114, P.359

◆Respective Network Services 11P.431

◆Security Settings 11P.121

◆View Blind 11P.113

You can make the display hard to see from an angle. You can use the FOMA
terminal without concern for others’ eyes.

◆Camera 11P.226

You can use approximate 8,100,000 pixels of high-precision camera to shoot still
images and moving pictures. Further, owing to Intelligent Auto, you can shoot still
images in a mode that is most suitable for your photographing scene, and can detect
the outline of a person’s face to automatically focus on his or her face.
Further, you can use a flare of flash or photo light when you are in a dim place for
shooting.

◆Voice Recorder 11P.380

You can record your voice as a substitute for taking notes. You can repeatedly play it
back, so it is convenient to record the proceedings at a meeting, etc.

Easy Search/Contents/Precautions

9

Precautions

ALWAYS FOLLOW THESE DIRECTIONS

Don’t

disassemble

Avoid
Water

Do

Pull the

power plug

out

■Before using the FOMA terminal, read these safety precautions carefully so that

you can use it correctly.
After reading the precautions, keep them in a safe place.

■Be sure to observe these safety precautions because they are designed to

protect you or those around you from causing injury and to avoid unnecessary
damage to the property.

■The symbols below indicate the levels of danger or damage that can be caused

if the particular precautions are not observed.

This symbol indicates that incorrect handling

Danger
Warning

Easy Search/Contents/Precautions

Caution

will almost certainly cause death or serious
injury.

This symbol indicates that incorrect handling
poses a risk of causing death or serious
injury.

This symbol indicates that incorrect handling
poses a risk of causing injury or damage to
the product or property.

■The following symbols show specific directions:

Denotes things not to do. (Prohibition)

Denotes not to disassemble.

Do not

Not wet

hands

■“Safety Precautions” are divided into the following six sections:

General precautions for FOMA terminal, batteries, adapters, and UIM... P.11

Precautions for FOMA terminal ................................................................. P.12

Precautions for batteries ............................................................................ P.14

Precautions for adapters............................................................................ P.15

Precautions for UIM.................................................................................... P.16

Notes on using near electronic medical equipment .................................. P.16

Denotes not to touch with wet hands.

Denotes not to use where it could get wet or not to wet it.

Denotes mandatory instructions (matters that must be complied
with).

Denotes to pull the power plug out of the outlet.

10

Don’t

Do not

disassemble

Avoid
Water

Do

Do

Don’t

Don’t

Do

Do

General precautions for FOMA
terminal, batteries, adapters, and UIM

Danger

Do not use, store, or leave the mobile
phone or its accessories in places
with a high temperature (such as
near fire, near heating appliances,
inside a kotatsu or near other
furniture with heating elements, in
places exposed to direct sunlight, or
in cars heated by the sun).

The devices could be deformed or
malfunction, or the battery may leak,
overheat, burst, or catch fire, thus resulting
in the deterioration of performance and
shortening of the life of devices.
Also, part of the case could get heated,
causing bare skin burns.

Do not disassemble, modify or solder
the FOMA terminal or accessories.

Accidents such as fire, injury, or electric
shock, or malfunction may result. The battery
may leak, overheat, burst or catch fire.

Do not wet the FOMA terminal or
accessories.

If liquids such as water or pet urine get
onto them, overheating, electric shock,
fire, malfunction, injury or others may
result. Pay attention to the place of use
and the way of handling.

With your FOMA terminal, use the
batteries and adapters specified
by NTT DOCOMO, INC.

If you use any type of battery or adapter
other than the specified one, your FOMA
terminal, battery or other accessories
may leak, overheat, burst, catch fire or
malfunction.

Warning

Do not place the batteries, the
FOMA terminal, adapters, or UIM
in cooking appliances such as

Don’t

Don’t

Don’t

microwave ovens or
high-pressure containers.

The battery may leak, overheat, burst, or
catch fire. The FOMA terminal or the
adapter may overheat, smoke, or catch
fire, or its circuit parts may become
damaged.

Do not throw the FOMA terminal
or accessories, or subject them
to severe shocks.

The battery may leak, overheat, burst, or
catch fire. Also, malfunction or fire may
result.

Be careful not to let
electroconductive materials (metal
pieces, pencil leads etc.) contact
with the charging terminal or
connector terminal. Also, make
sure that those are not entered into
the inside of the FOMA terminal.

Short-circuit could cause fire or
malfunction of the FOMA terminal.

When you are in a place such as a
gas station where flammable gas
is generated, turn off the FOMA
terminal, and never do charging.

Do

Otherwise, catching fire may
result.

Ensure that you use Osaifu-Keitai with
the FOMA terminal turned off when you
are in the vicinity of the gas station.
(When IC Card Lock is set, turn off the
power with the lock released.)

If odor, overheat, discoloration,
or deformation is detected during
use, battery charge, or storage,
immediately observe the
following:

1. Pull the power plug out of the
outlet or cigarette lighter socket.

2. Turn off the power to the FOMA
terminal.

3. Remove the battery pack from
the FOMA terminal.

If you use the FOMA terminal and its
accessories as they are, overheat, burst,
or catching fire could result or the
battery could leak.

Caution

Do not place the FOMA terminal
or accessories on unstable
locations such as wobbly tables
or slanted locations.

The FOMA terminal or accessories may
fall, resulting in injury or malfunction.

Do not store in humid or dusty
places, or in high temperature
environments.

Malfunction may result.

If children use the FOMA terminal or
accessories, a guardian should
explain the safety precautions and
correct operations. The guardian
should also make sure that the
instructions are followed during use.

Otherwise, injury may result.

Keep out of the reach of babies
and infants.

Accidental swallowing or injury may
result.

Easy Search/Contents/Precautions

11

Be especially careful when you

Do

Don’t

Don’t

Don’t

Do

Do

Do

Do

use the FOMA terminal for a long
time with the adapter connected.

If you use i-αppli programs, talk on the
videophone, watch 1Seg programs and
so on for a long time during charging,
the temperature of the FOMA terminal,
battery pack, or adapter might rise.
If you directly touch the part of high
temperature continuously, redness,
itching, rash, or low-temperature bare
skin burns may result depending on your
physical conditions or predisposition.

Precautions for FOMA terminal

Warning

Do not directly point the infrared

Easy Search/Contents/Precautions

data port at someone’s eyes
during transmission.

His/her eyes may possibly be affected.
Other infrared devices may operate
erroneously if the infrared data port is
pointed at them during transmission.

Do not shine the flash/photo light
close to eyes.

Doing so can damage eyesight. Also,
accidents such as injury might occur if
someone is startled or dazzled by the
light.

Don’t

Don’t

Don’t

Do not put the FOMA terminal in
the place where it could be
affected by an expanded airbag,
e.g., on the dashboard.

If the airbag expands, the FOMA
terminal could hit you and others,
causing accidents such as injury and the
FOMA terminal could malfunction and
become damaged.

If you have any implanted
electronic medical equipment, do
not place your FOMA terminal in
a chest pocket or inner pocket.

If the FOMA terminal is positioned close
to electronic medical equipment, it may
cause that equipment to malfunction.

Do not allow liquids such as
water, or foreign materials such
as metal pieces or flammable
materials to get into the UIM or
microSD card slot of the FOMA
terminal.

Fire, electric shock or malfunction may
result.

Do not turn on the flash/photo
light to drivers of cars, and others.

It disturbs driving, and accidents may
result.

Turn off the FOMA terminal in
places where use is prohibited
such as in airplanes and hospitals.

Otherwise, electronic devices and
electronic medical appliances may be
adversely affected. If the Auto Power
ON function is set, deactivate the
setting, then turn the power off.
For use inside medical facilities, make
sure that you comply with their
regulations. You may be punished for
using the FOMA terminal in airplanes,
which is prohibited by law.

When talking with the FOMA
terminal set to Hands-free, be
sure to keep the FOMA terminal
away from your ear.
Further, when you play games or
play back music with the
earphone/microphone
connected, adjust the sound
volume to moderate volume.

The excessive sound volume impairs
your hearing.
Further, accidents may result due to the
hardness of hearing of surrounding
sound.

For those with weak heart
conditions, the vibrator and ring
volume must be adjusted carefully.

Those functions may cause an effect on
the heart.

If thunder starts to rumble while
you are using the FOMA terminal
outdoors, house the antenna,
turn off the power and move to a
safe place.

Otherwise, you could be struck by
lightning or suffer an electric shock.

12

Turn off the FOMA terminal when

Do

Do

Don’t

Don’t

Don’t

Do

near electronic devices using
high-precision control or weak
signals.

The FOMA terminal may possibly cause
these devices to malfunction.

※

Electronic devices that may be affected:
Hearing aids, implanted cardiac
pacemakers, implanted defibrillators,
other medical electronic devices, fire
alarms, automatic doors and other
automatically controlled devices. If you
use an implanted cardiac pacemaker,
implanted defibrillator or any other
electronic medical device, consult the
manufacturer or retailer of the device for
advice regarding possible effects from
the radio waves.

If the display part or camera lens
is broken, be careful about
broken glasses or the exposed
interior of the FOMA terminal.

Plastic panels are used for the surfaces
of the display part and camera lens so
that glasses do not easily get scattered,
however, pay attention not to
erroneously touch the broken part or
interior. Otherwise, injury may result.

Caution

Do not swing the FOMA terminal
by its antenna or strap.

The FOMA terminal may hit you or

Don’t

Don’t

Don’t

Don’t

persons around you, and accidents such
as injury or malfunction and damage
may result.

Do not use in places crowded
with people.

The antenna may hit against others,
causing an accident such as injury.

Do not use the FOMA terminal
with the damaged antenna.

If the damaged antenna comes in
contact with your skin, an accident such
as a burn or injury could be caused.

When using the motion tracking,
ensure that you check around
you for safety, securely take hold
of your FOMA terminal, and do
not swing to an extent more than
necessitated.

The motion tracking is the function to
incline or swing the FOMA terminal for
operation. If you excessively swing your
FOMA terminal, it might happen that it
hits against persons or objects, resulting
in critical accidents or damage.

When a metallic strap is attached
to your FOMA terminal, be careful
that it does not hit against
persons or objects when using
the motion tracking.

Accidents such as injury or malfunction
and damage may result.

If you erroneously break the
display part and then crystal
liquid gets leaked, never take or
suck the liquid to or into your
mouth, or apply to skin.
If the crystal liquid gets into the
eyes or mouth, immediately rinse
it out with clean water and then
seek medical attention.
When it adheres to your skin or
clothes, immediately wipe it away
with alcohol etc., and then rinse it
out with water and soap.

Otherwise, the loss of eyesight or injury
to your skin may result.

Do not bring your ears close to
the speakers while a ring tone
sounds or a melody is played
back from the FOMA terminal.

Otherwise, your hearing could be
impaired.

Electronic devices in some types
of cars can be affected by use of
the FOMA terminal.

For safety’s sake, make sure not to use
the FOMA terminal inside such cars.

Easy Search/Contents/Precautions

13

Itching, rash or eczema may be

Do

Do

Do

Don’t

Do

Don’t

Do

Do

Do

caused depending on your
physical conditions or
predisposition. If an abnormality
occurs, stop using the FOMA
terminal immediately, and then

Metals are used for the following parts:

Where it is used Material Finishing

Charging terminal Phosphor

Slide rail SUS304 Fluorine coating
Metal
part of
the 1Seg
antenna

Easy Search/Contents/Precautions

Metal part of the
speed selector
Shutter/
PushTalk key

seek medical attention.

Gold-plated finish with

bronze

nickel-plated ground

Top Brass Tin-and-cobalt-plated

Middle SUS304 —
Hinge at
bottom
part
Screw at
bottom
part

finish with
nickel-plated ground

SUS304 Tin-and-cobalt-plated

finish with
nickel-plated ground

Brass Nickel-plated

PC Evaporated aluminum

Be careful not to get your finger
or a strap caught in the parts
when you close or open the
FOMA terminal.

Accidents such as injury or damage may
result.

When you watch a 1Seg program,
watch in a place bright enough
taking a certain distance from the
display.

Otherwise, your visual acuity could be
reduced.

Precautions for batteries

■Check the description on the label of the

battery pack for the type of battery.

Description Type

Li-ion Lithium-ion battery

Danger

Do not let any metal object such
as a wire come in contact the
battery terminals. Also do not

Don’t

Don’t

Don’t

carry or store the battery together
with any metal objects like a
necklace.

The battery may leak, overheat, burst or
catch fire.

Do not use excessive force to
attach the battery to the FOMA
terminal even when you cannot
attach it successfully. Also,
check that the battery is the right
way round when you attach it.

The battery may leak, overheat, burst or
catch fire.

Do not throw the battery into fire.

The battery may leak, overheat, burst or
catch fire.

Do not pierce it with nails, hit it
with a hammer, or step on it.

The battery may leak, overheat, burst or
catch fire.

If the battery fluid gets into your
eyes, do not rub them. Flush your
eyes with clean water and seek
medical attention immediately.

Otherwise, the loss of eyesight may
result.

Warning

When any abnormality due to
external shock such as the
deformation or scratches by
dropping is found on the battery
pack, immediately stop using it.

The battery may leak, overheat, burst, or
catch fire. Also, malfunction or fire may
result.

If charging is not completed at
the end of the specified charging
time, stop charging.

Otherwise, the battery may leak,
overheat, become damaged or catch
fire.

Immediately stop using the FOMA
terminal and keep it away from
fire if the battery leaks or emits
an odor

.

The leaked battery fluid may ignite,
causing fire or burst.

Be careful that your pets do not
bite into the battery pack.

The battery may leak, overheat, burst, or
catch fire. Also, malfunction or fire may
result.

14

Caution

Don’t

Don’t

Do

Don’t

Don’t

Not wet

hands

Do

Do

Do

Do

An exhausted battery should not
be disposed of with other waste.

The battery may catch fire or damage
the environment. After insulating the
battery terminals with tape, take the
unneeded battery to a handling counter
such as a docomo Shop or dispose of it
in accordance with local waste disposal
regulations.

Do not charge the wet battery.

The battery pack may overheat, catch
fire, or burst.

If the battery fluid comes in
contact with skin or clothes,
immediately stop using, then
rinse it out thoroughly with clean
water.

Skin injury may result.

Precautions for adapters

Warning

Do not use a damaged adapter
cord or power cord.

Electric shock, overheating or fire may
result.

Do not use the AC adapter and
desktop holder in steamy places
such as a bathroom.

Electric shock may occur.

Don’t

Don’t

Don’t

Don’t

Don’t

The DC adapter is for use only in
a negative (-) grounded vehicle.
Do not use it in a positive (+)
grounded vehicle.

Fire may result.

If it starts to thunder, do not
touch the FOMA terminal and
adapter.

You might be struck by lighting or suffer
an electric shock.

Never short-circuit the charging
terminal when the adapter is
plugged into the power outlet or
cigarette lighter socket. Also,
never touch the charging terminal
with fingers or other bare skin.

Fire, malfunction, electric shock or injury
may result.

Place the adapter and desktop
holder on a stable location while
charging. Do not cover or wrap
the adapter and desktop holder in
cloth or bedding.

The FOMA terminal may drop off, or the
adapter and desktop holder may
overheat, causing fire or malfunction.

Do not place something heavy on
the adapter cord and power cord.

Electric shock or fire may result.

Do not touch the adapter cord or
power outlet with wet hands.

Electric shock may result.

Use the adapter at the specified V
AC.

If you use it at a wrong voltage, fire or
malfunction may result. When using the
FOMA terminal overseas, use FOMA
AC adapter available overseas.
AC adapter: 100 V AC
DC adapter: 12/24 V DC
[For negative (-) grounded vehicles only]
AC adapter available overseas: 100 V to
240 V AC
[Connect only to household AC outlet]

If a fuse of the DC adapter has
blown, replace it with a specified
fuse.

If you use an unspecified fuse, fire or
malfunction may result. For the specified
fuse, refer to each instruction manual.

Keep the power plugs dust-free.

Otherwise, fire may result.

When pulling the AC adapter into
the power outlet, firmly plug it in,
taking care not to contact with
metal straps or the like.

Otherwise, electric shock, short-circuit or
fire may result.

Easy Search/Contents/Precautions

15

When removing the adapter out

Do

Pull the

power plug

out

Pull the

power plug

out

Pull the

power plug

out

Do

Do

Do

Do

of the outlet or cigarette lighter
socket, do not forcibly pull the
adapter cord or power cord,
instead take hold of the power
plug and then pull.

If you pull the plug out by the cord, the
cord may be damaged, which could
result in electric shock or fire.

When the adapter is not to be
used for a long period of time,
unplug the power cord from the
outlet.

Otherwise, electric shock, fire, or
malfunction may result.

If liquids such as water get in the
adapter, unplug the power cord
immediately from the outlet or

Easy Search/Contents/Precautions

cigarette lighter socket.

Otherwise, electric shock, smoke or fire
may result.

Before cleaning, pull the power
plug out of the outlet or cigarette
lighter socket.

Otherwise, electric shock may result.

Precautions for UIM

Caution

Be careful not to touch the cut
surface of the UIM (IC portion)
when removing it.

You may hurt your hand or fingers.

Notes on using near electronic
medical equipment

■The description below meets “Guidelines on

the Use of Radio-communication Equipment
such as Cellular Telephones – Safeguards for
Electronic Medical Equipment” by the
Electromagnetic Compatibility Conference
Japan.

Warning

Comply with the following in
hospitals or health care facilities:

≥Do not carry the FOMA terminal into

Do

operating rooms, intensive care units
(ICU) or coronary care units (CCU).

≥Turn off the FOMA terminal in hospital

wards.

≥If there is any electronic medical

equipment near you, turn off the
FOMA terminal even when in a
location such as a lobby.

≥Comply with any regulations of

hospital and health care facilities
instructing you not to use or carry in a
mobile phone.

≥If the Auto Power ON function is set,

deactivate the setting, then turn the
power off.

Turn off the FOMA terminal in
crowded areas such as inside
trains during rush hour, as
someone with an implanted
cardiac pacemaker or implanted
defibrillator may be near you.

Operation of an implanted cardiac
pacemaker or implanted defibrillator can
be affected by radio waves.

If you use an implanted cardiac
pacemaker or implanted
defibrillator, use the mobile
phone 22 cm or more away from
an implanted cardiac pacemaker
or implanted defibrillator.

Operation of an implanted cardiac
pacemaker or implanted defibrillator can
be affected by radio waves.

Patients using electronic medical
equipment other than implanted
cardiac pacemakers or implanted
defibrillators (outside medical
establishments for treatment at
home, etc.) should check the
influence of radio waves upon the
equipment by consulting its
manufacturer.

Operation of electronic medical
equipment can be affected by radio
waves.

Handling Precautions

General notes

■Do not wet the equipment.

The FOMA terminal, battery, adapter, and UIM are not
waterproofed. Do not use them in environments, which
are high in humidity such as in bathrooms, and do not
allow them to get wet from rain. Furthermore, if carrying
them against your body, they become moist due to
perspiration and the internal parts may become
corroded, causing malfunction. If the parts are found to
have been damaged due to exposure to the liquids, any
repairs will not be covered by warranty, or repairs may
not be possible. This may be repaired at a cost if
repairs are possible.

16

■Use a dry soft cloth such as the one for

cleaning glasses to clean the equipment.

≥The screen of the FOMA terminal sometimes has a

special coating so that they are easier to see. If you
rub it roughly with a dry cloth, it might be scratched.
Take care of the way of handling, and use only a dry,
soft cloth such as the one for cleaning glasses. If the
screen is left with water drop or stain adhered, smear
may be generated or the coating might peel off.

≥Do not use alcohol, thinner, benzene, detergent or

other solvents for cleaning, otherwise the printing
may be removed or discoloration may result.

■Occasionally clean the terminals of the

equipment using a dry cotton swab, etc.

The soiled terminals deteriorate the connection and
might cause power discontinuity or incomplete
charging. Wipe the terminals with a cotton swab, etc.
Take care not to damage the terminals when cleaning
them.

■Do not place the FOMA terminal near an air

conditioner outlets.

Condensation may form due to rapid changes in
temperature, and this may corrode internal parts and
cause malfunction.

■Do not apply excessive force onto the FOMA

terminal and battery pack.

If you put the FOMA terminal in a bag along with many
other articles or sit with the FOMA terminal in a clothes
pocket, the display, internal circuitry and the battery
pack could be damaged or malfunction. Also, if an
external device is left connected to the connector
terminal (earphone/microphone terminal), the
connector could be damaged, or malfunction.

■Carefully read each instruction manual

attached to the FOMA terminal, adapter, or
desktop holder.

■Do not rub or scratch the display part with

metals.

Doing so might cause damage to the part, resulting in
trouble or malfunction.

Notes on handling the FOMA terminal

■Avoid using in extremely high or low

temperatures.

The FOMA terminal should be used within a temperature
range of 5°C to 35°C and a humidity range of 45% to 85%.

■The FOMA terminal, if operated near land-line

phones, television sets, radios or other
devices that are in use, may affect them. You
should operate your FOMA terminal as far
away from such equipment as possible.

■It is recommended that you make separate

notes of the information stored in the FOMA
terminal and keep such notes in a safe place.

We take no responsibility for any loss of the stored data
items.

■Do not drop the FOMA terminal or subject it to

strong impacts.

Malfunction or damage may result.

■Do not insert an external device to the

connector terminal (earphone/microphone
terminal) at a slant when connecting, and do
not pull it out when it is inserted.

Malfunction or damage may result.

■Make sure that nothing, such as a strap, gets

caught between the parts of the FOMA
terminal when you close it.

Otherwise, malfunction or damage may result.

■The FOMA terminal becomes warm during

use or charging but this is not an abnormality.
Use the FOMA terminal as it is.

■Do not leave the camera in places exposed to

direct sunlight.

Pixels may be discolored or burns may result.

■Usually, put the cover of the connector

terminal and microSD card slot to use the
FOMA terminal.

Dust or water might enter into the FOMA terminal,
causing malfunction.

■Do not use the FOMA terminal with the back

cover left removed.

The battery pack might come out, or malfunction or
damage may result.

■Do not put a label or sticker on the back of the

display part of the FOMA terminal.

They may be caught in when you open/close the FOMA
terminal, and malfunction or damage may result.

■While you are using the microSD card, never

take it off or turn off the power to the FOMA
terminal.

Data may be erased or malfunction may result.

■Do not place magnetic cards or similar

objects near the FOMA terminal or between
phone parts.

Magnetic data on cash cards, credit cards, telephone
cards and floppy disks, etc. may be deleted.

■Do not bring magnetic substances close to

your FOMA terminal.

Strong magnetic items might cause in erroneous
operation.

Notes on handling batteries

■Batteries have a limited life.

Though it varies depending on the usage state, you are
advised to replace the battery if its usable time is
extremely short even when you fully charge it. Make
sure that you buy the specified battery.

■Charge the battery in a place with an

appropriate ambient temperature of 5°C to
35°C.

Easy Search/Contents/Precautions

17

■Make sure that the battery is charged when

you use the FOMA terminal for the first time
or have not used it for a long period of time.

■The usable time of the battery differs

depending on the usage environment or its
remaining life.

■Depending on how the battery pack is used, it

might swell as its operating life becomes
short, but this is not a problem.

■Note the following points when you store a

battery pack over a long period:

≥Storage in a fully charged state (the state immediately

after charging is completed)

≥

Storage with no battery power left (the state you cannot

turn on the power of the handset due to battery drain)
These may lower the battery pack’s performance and
shorten its operating life.
You are advised to store the battery pack in the state of
two or three bars of battery icon indication as a guide
for when you store it for a long period.

Easy Search/Contents/Precautions

Notes on handling adapters

■Charge the battery in a place with an

appropriate ambient temperature of 5°C to
35°C.

■Charge the battery where:

≥There is very little humidity, vibration, and dust.
≥There are no land-line phones, television sets or

radios nearby.

■While you are charging, the adapter may

become warm. This is not a malfunction, so
you can keep on using.

■Do not use the DC adapter for charging the

battery when the car engine is not running.

The car battery could go flat.

■When using the power outlet having the

disengaging prevention mechanism, observe
the instructions given in that instruction
manual.

18

■Do not give a strong shock. Also, do not

deform the charging terminal.

Malfunction may result.

■Be careful not to get your finger or the

adapter cord caught in the parts when you
house the stand of the desktop holder.

Accidents such as injury or damage may result.

Notes on handling the UIM

■Never use more force than necessary when

inserting/removing the UIM.

■The UIM may become warm during use, but

this is not a sign of a malfunction. Continue
using it as it is.

■The warranty does not cover damage caused

by inserting the UIM into some other types of
IC card reader/writer.

■Always keep the IC portion clean.

■Use a dry soft cloth such as the one for

cleaning glasses to clean the equipment.

■It is recommended that you make separate

notes of the information stored on the UIM
and keep such notes in a safe place.

We take no responsibility for any loss of the stored data
items.

■For the environmental protection, bring any

unneeded UIMs to a handling counter such as
a docomo Shop.

■Avoid using in extremely high or low

temperatures.

■Do not damage, carelessly touch, or

short-circuit the IC.

Data might be lost or malfunction may result.

■Do not drop the UIM or subject it to strong

impacts.

Malfunction may result.

■Do not bend the UIM or place something

heavy on it.

Malfunction may result.

■Into the FOMA terminal, do not insert the UIM

with a label or sticker pasted.

Malfunction may result.

Notes on using Bluetooth function

■As the security for communication using the

Bluetooth function, the FOMA terminal
supports the security function that meets the
Bluetooth Specification. However, the
security may not be sufficient depending on
the configuration. Take care of the security
for communication using the Bluetooth
function.

■Note that even if any leak of data or

information occurs while making connection
using the Bluetooth function, we take no
responsibility.

■With the FOMA terminal, you can use the

following: Headset, Hands-Free, Audio,
Dial-up Communication, Object Push, and
Serial Port. With Audio, you might be able to
use Audio Video Remote Control. (Only with
the compatible Bluetooth devices)

■Radio frequencies

2.4 FH 1

2.4 : Indicates radio facilities that use 2400 MHz
frequencies.

FH : Indicates the modulation system is the FH-SS

system.

1 : Indicates that a supposed coverage distance is

10 meters or less.

: Indicates that all radio frequencies 2400 MHz

through 2483.5 MHz are used, and that the
frequencies for mobile object identifiers shall
not be avoided.

The radio frequencies the Bluetooth function
of the FOMA terminal uses are as follows:

■Cautions on Using Bluetooth Devices
Bluetooth operates at radio frequencies assigned to
the in-house radio stations for mobile object
identifiers that have to be licensed and are used in
production lines of a factory, specific unlicensed low
power radio stations, and amateur radio stations
(hereafter, referred to “another radio station”) in
addition to scientific, medical, industrial devices, or
home electric appliances such as microwave ovens.

1. Before using this product, make sure that
“another radio station” is not operating nearby.

2. If radio interference between this product and
“another radio station” occurs, move immediately
to another place or turn off power to avoid
interference.

3. For further details, contact “docomo Information
Center” on the back page of this manual.

Notes on handling the FeliCa reader/
writer

■The FeliCa reader/writer function on the

FOMA terminal uses very weak radio waves
which do not require to be licensed as radio
stations.

■The FeliCa reader/writer is operated on the

13.56 MHz frequencies. When you use
another reader/writer nearby, take enough
distance between your FOMA terminal and
the reader/writer. Further, ensure that there
are no radio stations that use the same
frequencies.

Caution

■Do not use the modified FOMA terminal.

Using a modified FOMA terminal infringes the
Radio Law.

The FOMA terminals are granted technical regulations
conformity certification as the specified radio equipment
under the Radio Law and bear a “technical conformity
mark ” on the nameplate as evidence of conformity.
Unscrewing the FOMA terminal and modifying internal
components void the technical regulations conformity
certification. Do not use the FOMA terminal in this state,
which infringes the Radio Law.

■Be especially careful not to operate the FOMA

terminal while driving.

You will be imposed punishment if you use the mobile
phone in your hand while driving. If you answer a call
out of necessity, tell the caller with Hands-free that you
will call him/her back, park your car to somewhere safe,
and then dial.

■Use the Bluetooth functions in Japan only.

The Bluetooth functions on the FOMA terminal have
been authorized in compliance with the radio
transmission standards in Japan.
You might be imposed punishment if you use them
overseas.

■Use the FeliCa reader/writer functions in

Japan only.

The FeliCa reader/writer functions on the FOMA
terminal have been authorized in compliance with the
radio transmission standards in Japan.
You might be imposed punishment if you use them
overseas.

Easy Search/Contents/Precautions

19

Basic Package and Main Options

NTTドコモ

<Basic package> <Main Options>

≥P-08A Handset

(With Warranty and Back Cover P36)

≥P-08A CD-ROM

The PDF versions of “Manual for PC Connection”
and “Kuten Code List” are included.

≥FOMA AC Adapter 01/02

(With Warranty and Instruction Manual)

Easy Search/Contents/Precautions

20

≥Instruction Manual

Quick Manual included (See page 550)

≥Battery Pack P19 ≥Desktop Holder P33

(With Instruction Manual)

Other Options → Page 500

Before Using the Handset

Part Names and Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Opening/Closing FOMA Terminal . . . . . . . . . . . . . . . . . . . . . . . . 24

Navigation Displays and Key Operations . . . . . . . . . . . . . . . . . 24

Main Key Operations from the Stand-by Display . . . . . . . . . . . 26

Viewing Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Using Icons on Desktop . . . . . . . . . . . . . . . . . .<Desktop Icon> 29

i-Widget Display and Operations . . . . . . . . . . . . . . . . . . . . . . . . 32

Displaying Description of Icons . . . . . . . . . . . . . . . . . . <Icons> 32

Selecting Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

When You Forget Key Operation . . . . . . . . . . . . . . . . . <Guide> 37

Using UIM (FOMA Card) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Attaching/Removing Battery Pack . . . . . . . . . . . . . . . . . . . . . . . 39

Charging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Checking Battery Level . . . . . . . . . . . . . . . . . . .<Battery Level> 42

Turning Power ON/OFF . . . . . . . . . . . . . . . . . <Power ON/OFF> 43

Switching to English Display . . . . . . . . . . . <Select Language> 44

Configuring Initial Setting . . . . . . . . . . . . . . . . .<Initial Setting> 44

Setting Date and Time . . . . . . . . . . . . . . . . . . . . . . . <Set Time> 45

Displaying World Time . . . . . . . . . . . . . . <World Time Watch> 46

Notifying the Other Party of Your Phone Number

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <Caller ID Notification> 46

Checking Your Own Phone Number . . . . . . . . <Own Number> 46

21

Part Names and Functions

■For using earphone

Connect an optional connector-terminal-compatible earphone. When using a
connector-terminal-non-compatible earphone, use an optional plug adapter for connection.
≥When inserting or pulling the plug adapter, take hold of the plug for the handset side and insert or pull

it straight. Be careful not to take hold of the cover of the connector terminal and plug for the handset
side together when you pull it out.

≥The Earphone Plug Adapter for External connector terminal 01 (option) can be connected with a

triple pole mini plug only. For details, refer to the instruction manual for the Earphone Plug Adapter
for External connector terminal 01.

Flat plug of the
Flat-plug Earphone/
Microphone with Switch

Earphone terminal (Flat-plug)

Example for connecting the Flat-plug
Earphone/Microphone with Switch (option)

Plug for the
handset side

2

<
=

?

;

>

6

@

3

8

4

:

B

K

L

5

7

G

H

M

N

E

A

1

J

9

F

I

O

C
D

H

Before Using the Handset

22

1Light sensor

・For sensing brightness (See page 112)

≥Do not cover the light sensor with your hands or do

not put a sticker on it. Doing so might disable you to
detect the brightness.

2Earpiece

・For listening to the other party’s voice

3Display

(See page 27)

4l Mail key
5m Menu key
6d Start key/Hands-free key

・For making/receiving calls (See page 48 and page 62)
・For talking with Hands-free (See page 61)

7r Clear key/i-Widget key

・For returning to the previous operation
・For clearing entered text or a phone number

8Microphone

・For speaking to the other party

9Inside camera

・For shooting photos of yourself (See page 226)
・For displaying your face during a videophone call

:o Speed selector

・For operation of function or menu (See page 25)

;Call/Charging indicator

・Flickers for incoming calls/mail and during a call.

(See page 115)

・Lights in red during charging.
・Lights/Flickers when you shoot with the camera.

≥The flickering pattern and color tone of the illumination

might look different depending on the FOMA terminal
you use.

<i i-mode key/i-αppli key
=c Camera key/1Seg key

>h Power/End key

・For ending calls
・For ending respective functions
・For turning on the power (for at least one second)/

For turning off the power (for at least two seconds)
(See page 43)

?Numeric keys

・For entering phone numbers and text

@Connector terminal

・For connecting the AC adapter (option), DC adapter

(option), FOMA USB Cable with Charge Function 01/
02 (option), or Stereo Earphone Set 01 (option), etc.

≥Integrated terminal for connecting earphone or for

charging, etc.

A1Seg antenna

・For receiving 1Seg broadcasting (See page 247)

BOutside camera

・For shooting portraits and/or landscapes

(See page 226)

・For catching sight of persons and/or landscapes

during a videophone call

CInfrared data port

・Used for infrared communication and the infrared

remote control. (See page 374 and page 378)

Df mark

・The IC card is mounted.

≥Use the IC card function placing this mark over the

scanning device. You cannot dismount the IC card.
(See page 311)

EFOMA antenna

≥The FOMA antenna is embedded in the handset. Do

not cover the antenna with your hand for better
communication.

FSpeaker

・For sounding ring tones
・For listening to the other party’s voice when

Hands-free is activated (See page 61)

GFlash/Photo light

・Lights/Flickers when you shoot with the camera.
・Used for shooting in a dark place. (See page 236)

HmicroSD card slot

・For inserting microSD card (See page 360)

IBack cover

・Remove this when attaching/removing the battery

pack and UIM. (See page 37 and page 39)

≥Do not peel off the sticker on the back of the back

cover. If you peel it off, you might not be able to read
and write the IC card.

JCharging terminal
Kx Multi key
L<Side ▲ key

・For scrolling up page by page

M>Side ▼ key

・For scrolling down page by page

Np Shutter key/PushTalk key

・For making/receiving PushTalk calls

(See page 79 and page 82)

≥You can focus on a subject by pressing half way when

shooting with the camera. (See page 235)

OStrap hole

Before Using the Handset

23

Opening/Closing FOMA Terminal

Information

Hold the FOMA terminal with both hands to slide the display upward/
downward.
Take care not to touch the keys when you open or close the FOMA
terminal. Key operation errors may result.

≥You can answer a call just by opening the FOMA

terminal while it is ringing. Also, you can end or hold a
call by closing the FOMA terminal during a call. (See
page 65)

≥When a missed call or new mail message is found,

you can display the detailed Missed Call display or the
Inbox list just by opening the FOMA terminal. (See
page 111)

Before Using the Handset

Navigation Displays and Key Operations

When you want to execute the operation shown on the vertical display,
press the corresponding key as below.

≥While the horizontal display is shown, you can operate in the same way as on the

vertical display depending on the function.

■Basic display examples and key assignments

≥When you open/close the FOMA terminal while a confirmation display for selecting

“YES/NO” is shown, the confirmation display may be cleared.

24

Indicates the operation you can perform with

1

the l key.

Indicates the operation you can perform with

2

the m key.

Indicates the operation you can perform with
the Oo key.

3

Indicates the direction in which you can scroll
and select items with the Mo key.

Indicates the operation you can perform with

4

the c key.

Indicates the operation you can perform with

5

the i key.

■Operating speed selector

Zo

display up. (Press and hold to scroll
continuously.)

Vo

・Moves the cursor to the right.
・Scrolls forward page by page.

(Press and hold to scroll
continuously.)

Oo

・Fixes the operation.

Co

and hold to scroll continuously.)

Xo

・Moves the cursor or highlighted

display down. (Press and hold to
scroll continuously.)

・Scrolls the page down.

Scrolling pages

Selecting items Selecting pictograms, etc.

Moving a cursor

Rotating direction

Operation example

Information

Information

Operating by Rotating Speed Selector

Depending on the display being shown, you can select items and move
the cursor by rotating the speed selector in the same way as you press

Mo.

≥The following operations are also available:

・Adjusting earpiece volume, ring volume, etc. (see page 66)

・Adjusting zoom magnification when shooting with the camera (see page 234)
・Adjusting volume during music playback, etc. (see page 277)
・Switching the displayed still images (see page 335)
・Adjusting volume during playback of i-motion files, during playback of movie files, etc.

(see page 342)

≥The rotating operation is not valid in Power Saver Mode.
≥The rotating operation may not be valid depending on the function.

Speed Selector Setting

You can set whether to validate the rotating operation of the speed
selector.

m1Set./Service1Other settings

1

1Speed selector setting1ON or OFF

≥Depending on the i-αppli program, the speed selector might not be operable even

when “ON” is set.

Key Guidance

You can set whether to show the operation for such as pressing Zo, Xo,

Co, and Vo, when you rotate the speed selector from the Stand-by

display.

m1Set./Service1Display1Key guidance

1

1ON or OFF

When “ON” is set

When you rotate the speed selector from the Stand-by display,
the operation for such as pressing Zo, Xo, Co, and Vo are
shown. (See page 26)
≥The key guidance is shown regardless of “Speed selector

setting”.

25

Before Using the Handset

Main Key Operations from the Stand-by Display

From the Stand-by display, you can execute the following actions by
operating each key:

Before Using the Handset

Key

operation

*Oo

*Zo

*Xo

*Co

*Vo

+l

+i

+m

+c

-d

-h

+r

-0

Press the key for a short time

Shows the display for selecting an
icon, etc. on the Stand-by display.
(See page 31, page 69, page 109)

Shows the Channel list.
(See page 221)

Shows the Search Phonebook
display. (See page 93)

Shows the Received Call list.
(See page 53)

Shows the Redial list. (See page 52)

Shows the Mail menu.
(See page 160)

Shows the iMenu. (See page 190)

Shows the i-mode menu.
(See page 190)

Shows Main Menu. (See page 32)

Activates the camera in Photo Mode.
(See page 230)

Makes a call. (See page 48)

Shows/Clears the icons, etc. on the
Stand-by display. (See page 110)

Executes i-Widget. (See page 306) Resets Main Menu. (See page 115)

Enters “0”. Enters “+”.

Press and hold the key for at least

Switches Key Lock on/off.
(See page 132)

Shows the registration display for the
Phonebook entries. (See page 88)

Shows the Received Address list.
(See page 170)

Shows the Sent Address list.
(See page 169)

Executes Check New Messages.
(See page 155)

Shows the Software list.
(See page 287)

Sets/Releases IC Card Lock.
(See page 312)

Starts 1Seg. (See page 249)

Accesses a voice dial entry.
(See page 99)

Turns off the power. (Press and hold
the key for at least two seconds)
(See page 44)

one second

—

Key

operation

-1

-2

-3

-4

-5

-6

-7

-8

-9

-a

-s

.x

.<

.>

.p

Press the key for a short time

Enters “1”.

Enters “2”.

Enters “3”.

Enters “4”.

Enters “5”.

Enters “6”.

Enters “7”.

Enters “8”.

Enters “9”.

Enters “:”.

Enters “#”.

Shows the Multitask Menu.
(See page 392)

Switches between the i-αppli
Stand-by display and normal i-αppli
program. (See page 304)

Plays back a record message/voice
memo. (See page 71)

Shows the PushTalk Phonebook list.
(See page 83)

Press and hold the key for at least

Measures your current location and
executes the GPS function.
(See page 322)

Sets/Releases Secret Mode.
(See page 133)

Switches the backlight on/off.
(See page 112)

Sets/Releases Personal Data Lock.
(See page 127)

Switches View Blind on/off.
(See page 113)

Activates/Deactivates Public mode
(Drive mode). (See page 68)

Activates/Deactivates Manner Mode.
(See page 106)

Activates a function set by Multi Key
Long Press Setting. (See page 404)

Switches menu functions.
(See page 392)

Activates/Deactivates Manner Mode
with the FOMA terminal closed.
(See page 106)

Activates 2in1 with the FOMA
terminal opened. (See page 442)

Plays back a videophone record
message/movie memo.
(See page 71)

Activates MUSIC Player.
(See page 275)

one second

26

Viewing Display

1235 8 ;:=>?<C

D

E

H

I

J

K

F

G

4

@A

9B6

7

P

O

N

M

L

Before Using the Handset

1

2

3

4

(dark blue)

5

(dark blue)

Battery level (estimate) (See page 42)

Radio waves reception level (est imate)

Strong Weak

You are out of the FOMA service area or
radio waves do not reach.

During Self Mode (See pag e 126)

During i-mode (See page 190 )

During i-mode communication (S ee page 190)

During packet communication (The icon differs
depending on the communication status.)

During PushTalk communication (See page 79)

You get out of the service area while
Network Search Mode is set to “Manual”.
(See page 455)

During SSL/TLS communication (See page 190)

Unread i-mode mail or an SMS message

(pink)

exists. (See page 154 and page 186)

The area for i-mode mail and SMS
messages in the FOMA terminal is full.
(See page 154 and page 186)

The area for SMS messages on the UIM
(FOMA card) is full.

Unread mail exists, and the area for SMS

(pink)

messages on the UIM (FOMA card) is full.

Both the FOMA terminal and UIM (FOMA
card) are full.

Area Mail exists. (See page 179)

Unread Messages R/F exist.

(yellow)

6

(dark blue)

(dark blue)

7

(yellow)

(dark blue)

8

9

:

(See page 176)

The area for Messages R/F in the FOMA
terminal is full. (See page 177)

i-mode mail is held at the i-mode Center.

(pink)

(See page 155)

The box for i-mode mail at the i-mode
Center is full. (See page 154)

Messages R/F are held at the i-mode
Center. (See page 177)

The box for Messages R/F at the i-mode
Center is full. (See page 177)

i-mode mail is held at the i-mode Center
while Receive Option Setting is se t to “ON”.
(See page 155)

New i-concier information exists.
(See page 223)

An i-αppli call you did not reply to exists.
(See page 303)

During a voice call

During a videophone call

During 64K data communication

;

<

=

During measuring the current lo cation
(See page 322)

Location Request Set. is set to “ON” or
“Reject numbers unset”, and it is within the
validity period. (See page 328 )

Location Request Set. is set to “ON” or
“Reject numbers unset”, and it is out of the
validity period. (See page 328 )

A microSD card is inserted. (See page 361)

Data is being read to/written f rom the
microSD card.

A write-protected microSD card is inserted.
(See page 361)

The inserted microSD card cannot be used.
(See page 361)

A microSD card is inserted, and the FOMA
USB Cable with Charge Function 01/ 02
(option) is connected in micro SD Mode.
(See page 369)

A microSD card is inserted, and the FOMA
USB Cable with Charge Function 01/ 02
(option) is connected in MTP M ode.
(See page 369)

A Bluetooth device is connected.

(blue)

(See page 415 and page 417)

A Bluetooth device is connected and power

(black)

consumption is low. (See page 41 5)

27

Before Using the Handset

Information

During Lock All (See page 124)

During Personal Data Lock (See page 127)

During Keypad Dial Lock (See p age 131)

During Secret Mode or Secret Data Only
(See page 133)

During IC Card Lock (See page 312)

Both Keypad Dial Lock and Personal Data
Lock are set.

Both Keypad Dial Lock and Secret Mode/
Secret Data Only are set.

>

Both IC Card Lock and Lock All are set.

Both IC Card Lock and Personal Data Lock
are set.

Both IC Card Lock and Keypad Dial Lock
are set.

Both IC Card Lock and Secret M ode/Secret
Data Only are set.

IC Card Lock, Keypad Dial Lock, and
Personal Data Lock are simultaneously set.

IC Card Lock, Keypad Dial Lock, and Secret
Mode/Secret Data Only are simultaneously
set.

Type of in-use network (See page 451)

A

B

C

?

You are in the OFFICEED area.
(See page 447)

Timer Lock ON At Close is set.
(See page 128)

@

During Key Lock (See page 1 32)

While Key Lock is temporarily released
(See page 132)

D

E

F

G

During Multitask (See page 391)

Multiple functions are activated.
(See page 391)

While watching a 1Seg pro gram
(See page 249)

During recording of a 1Seg program
(See page 256)

During recording of a 1Seg program by
Timer Recording (See page 260)

During pause of 1Seg program recording
(See page 256)

During music playback (See page 275)

During music pause (See page 275)

During infrared communication
(See page 374 and page 378)

The FOMA USB Cable with Charge
Function 01/02 (option) is connected in
Communication Mode.

The FOMA USB Cable with Charge
Function 01/02 (option) is connected in
microSD Mode. (See page 369)

During talk or communication through a
USB Hands-free compatible device
(See page 61)

A USB Hands-free compatible device is
connected. (See page 61)

A USB Hands-free compatible device is
connected in microSD Mode. (See page 61)

Vibrator is set to other th an “OFF”.
(See page 104)

Ring Volume is set to “Silent” or
Mail/Msg. Ring Time is set to “OFF”.
(See page 66 and page 106)

During Manner Mode (See page 106)

Remote Monitoring is set to “ON”.
(See page 77)

During Public mode (Drive mode)
(See page 68)

H

I

J

K

L

M

N

O

P

≥For the horizontal display, icons appear at the lower right

of the display.

≥The clock at the upper right of the display (at the lower

right of the horizontal display) does not appear when the
icon B or C is displayed.

≥Some characters and symbols on the display might be

modified or abbreviated.

≥The color liquid crystal display uses high-precision

production technology. The slightest change in the
environment or other factors may result in unlit or
permanently lit pixels, but this is not a manufacturing
defect.

The call cost has exceeded the specified
limit. (See page 408)

An alarm is set.
(See page 260 and page 395)

A Music&Video Channel program is booked.
(See page 266)

Backlight is set to “OFF”. (See page 112)

View Blind is set to “ON”. (See p age 113)

Backlight is set to “OFF” and View Blind is
set to “ON”.

USB Mode Setting is set to “microSD
mode”. (See page 369)

USB Mode Setting is set to “MTP m ode”.
(See page 369)

Voice mail messages for Number B are held

〜・

at the Voice Mail Center in Dual Mod e of
2in1. (See page 446)

Voice mail messages are held at the Voice

〜・

Mail Center. (See page 432)

The number of record m essages

〜

(See page 69)

The number of videophone record

〜

messages (See page 69)

28

<Desktop Icon>

Status icon

Notification icon
Desktop icon

Using Icons on Desktop

■Operation when a status icon is selected

Shows the display for Vibrator. (See page 104)

Shows the display for Ring Volume. (See page 66)

Shows the display for Manner Mode Set. (See page 108)

Shows the display for Remote Monitoring. (See

Shows the display for releasing Public mode (Drive mode).
(See page 68)

Shows the display for Notice Call Cost. (See page 408)

Shows the list of Alarm, Schedule, ToDo, TV Timer, or Timer Recording.
(See page 257, page 258, page 394, page 398 or page 401)

Shows the Music&Video Channel display. (See page 266)

Shows the display for Backlight. (See page 112)

Shows the display for View Blind. (See page 113)
Shows the display for “Set./Service” → “Display”.

Shows the display for USB Mode Setting. (See page 369)

〜・

〜・

Shows the display for playing back Voice Mail messages.
(See page 433)

Shows the display for playing back Voice Mail messages.
(See page 433)

Shows the display for Rec. Msg/Voice Memo.

〜

(See page 69, page 71, page 104 and page 406)

Shows the display for Rec. Msg/Voice Memo.

〜

(See page 69, page 71, page 104 and page 406)

page 77

■Operation when a notification icon is selected

Missed call

Shows the Missed Call list. (See page 53)

Missed call to Number B of 2in1

Shows the Missed Call list. (See page 53)

Record message

Shows the Record Message list. (See page 71)

Videophone record message

Shows the Videophone Record Message list. (See page 71)

New i-mode mail or SMS

Shows the Inbox list. (See page 159)

New chat mail

)

Starts Chat Mail. (See page 183)

New Message R/F

Shows the Message R/F list. (See page 177)

i-αppli did not start automatically

Shows the i-αppli Auto Start Info. (See page 302)

i-αppli call you did not reply to

Shows the i-αppli call logs. (See page 303)

A ToruCa file is received from a scanning device

Shows the ToruCa File list. (See page 316)

A security error occurred on the i-αppli Stand-by display

Shows the Security Error History. (See page 289)

Success in downloading a Music&Video Channel program

Activates Music&Video Channel. (See page 266)

Failure in downloading a Music&Video Channel program

Activates Music&Video Channel. (See page 267)

Missed alarm

Shows the contents of the alarm that could not be notified. (See page 396)

Missed TV timer

Shows the contents of the TV timer that could not be notified.
(See page 261)

Before Using the Handset

29

Timer recording was completed

Shows the contents and results of the timer recording. (See page 261)

Messages are held at the Voice Mail Center

Shows the display for playing back Voice Mail messages. (See page 433)

The Phonebook could not be updated by Data Secu rity Service

Shows the update display for Data Security Service. (See page 137)

Provide Location was executed automatically

Shows Location History. (See page 326)

Provide Location could not be executed automatically

Shows Location History. (See page 326)

You did not respond to a location provision request

Shows Location History. (See page 326)

Software Update is needed

Starts Software Update. (See page 517)

Software Update was executed

Shows the Update Completion display or the reason for not completing.

Before Using the Handset

(See page 518)

Software rewriting is possible

Shows the rewriting confirmation display. (See page 516)

Pattern data was updated automatically

Shows the updated result. (See page 521)

The FOMA terminal and a personal computer are connected by the FOMA
USB Cable with Charge Function 01/02 (option)

Shows the display for USB Mode Setting. (See page 369)

Charging stopped midway

Shows the message to the effect that charging stopped automatically.
(See page 42)

■Operation when a desktop icon is selected

Shows the dialing display with the phone number entered.
(See page 48 and page 79)

Shows the site of that URL. (See page 190)

Shows the site of that URL by Full Browser. (See page 192)

Shows the Message Composition display with the mail address entered.
(See page 142)

Shows the SMS Composition display with the mail address entered.
(See page 185)

30

Starts the i-αppli program.

Shows it on the Picture viewer.

Plays it back by the i-motion player.※ (See page 342)

Plays it back by the Video player.※ (See page 350)

Plays it back by the Chara-den player.※ (See page 353)

Plays it back by the Melody player.※ (See page 356)

Shows it on the PDF viewer.※ (See page 381)

Shows it on the ToruCa viewer.※ (See page 314)

Shows the Bookmark Folder list. (See page 200)

Shows the Private menu. (See page 403)

Shows the Still Image list for the storage location folder of the camera.
(See page 334)

Shows the list of Alarm. (See page 394)

Shows the Calendar display. (See page 398)

Shows the ToDo list. (See page 401)

Shows the list of Text Memo. (See page 408)

Shows the calculator. (See page 408)
Shows the display for 使いかたナビ (Guide). (See page 37)

Shows the Bar Code Reader display. (See page 241)

Shows the Ir Data Receiving display. (See page 377 and page 378)

Shows the Camera menu. (See page 230 and page 233)

Shows the Bluetooth Function Selection display.
(See page 415, page 417, and page 419)

Starts Voice Recorder. (See page 380)

Shows the i-concier display. (See page 223)

Shows the Music&Video Channel display. (See page 268)

Starts MUSIC Player. (See page 274)

Shows the Viewer display. (See page 249)

Starts i-αppli Program Guide. (See page 254)

※ When the original data is deleted, the desktop icon is disabled.

※

(See page 287)

※

(See page 334)

Paste Icons to Desktop

Information

When a record message

icon is selected

Information

Desktop Icon list

You can paste up to 15 desktop icons of such as phone numbers, mail
addresses, etc.

Select “Add desktop icon” from the Function menu of

1

the item to be pasted 1YES

≥If the addresses of the sender and another recipient of simultaneous mail are

found or the multiple destination addresses are found when you operate from the
Function menu of the detailed mail display, select a mail address or phone
number to be pasted.

≥You may not be able to paste the URL to the desktop depending on the site.
≥When the URL title exceeds 16 full-pitch/32 half-pitch characters, the excess is

deleted. If no title exists, up to 22 half-pitch characters of the URL excluding “http://” or
“https://” is displayed.

≥Some files and data might not be pasted to the desktop.

Proceed to Respective Functions from Icons on Desktop

Press Oo.

1

Use Mo to highlight an icon, and press Oo().

2

≥Up to five “Desktop icons”

are displayed. If there are
six or more icons, “ ” and
“ ” are displayed.

≥A “Notification icon” is

deleted when each function
is executed. To delete all
“Notification icons”, press
and hold r for at least one second from the display in step 1.

≥When the notification icon of “Messages are held at the Voice Mail Center” ( )

appears while you are overseas, you cannot operate the Voice Mail function from the
notification icon. Follow the steps of “Operate Voice Mail Service at the Country You
Stay” on page 458.

Check Details of Desktop Icon

+m-6-3

m1Set./Service1Display

1

1Desktop icon

The list of desktop icons pasted to the desktop is
displayed.

Select the icon whose details are to be displayed.

2

Function Menu of the Desktop Icon List

≥You can show the Function menu also by pressing i( ), while highlighting an

icon from the Stand-by display.

Add to desktop 1Put a check mark for the function to be added

Edit title 1Enter a title.

Sort 1Select a desktop icon1Use Bo to change the order

long press set. See page 404.

1l()

≥You can enter up to 16 full-pitch/32 half-pitch characters.

However, the number of characters for the title displayed when
you highlight the icon is up to 11 full-pitch/ 22 half-pitch
characters from the beginning of the title.

1Oo()

≥To change the order in succession, repeat the above steps.

1l()1YES

Before Using the Handset

31

Reset desktop The desktop icons are reset to the default.

i-Widget display

1

2

Delete this 1YES

Delete all 1YES

1YES

i-Widget Display and Operations

From the i-Widget display, you can simultaneously start multiple Widget
Appli programs and show them on a list.

1Widget Appli
You can show a Widget Appli program.
You can show the Widget Appli operation display by
selecting it.
2Navigation displays
Navigations corresponding to the key operations are
indicated.
≥You can randomly change the display order of Widget

Before Using the Handset

Appli programs by pressing i[シャッフル (Shuffle)]
from the i-Widget display.

≥See page 306 for detailed operations of i-Widget.

Selecting Menu

Press m of the FOMA terminal to show Main Menu and then execute,
set, or check respective functions. In this manual, the way to call up
functions from Main Menu is described as a standard method.
Menus are classified by functions. (See page 466)

≥Some functions can be selected also by the operation other than pressing m. In this

case, the operation by the easier way is described.

≥This FOMA terminal supports Kisekae Tool (see page 114). If you use Kisekae Tool to

change the design of the Menu display, some menu configurations change according
to the usage frequency depending on the type of the menu.
Further, some menu numbers that are assigned to the menu items do not apply.

■Scroll Selection

Main Menu is composed of 12 main menu icons indicating each function.
≥If you select a main menu icon, the Sub-menu Item Selection display appears. If you

further select a sub-menu item, the Lower Sub-menu Item Selection display appears.

≥By repeating selecting, you can set and check the function.

■Menu Number Selection

You can display some functions by pressing m + menu number (see page 466).

■Multitask is Supported

≥You can simultaneously use some functions in Main Menu. (See page 391)

<Icons>

Displaying Description of Icons

The symbols on the display (such as , , and ) are called icons. You
can check the meanings of them on the display.

m1Set./Service1Display1Icons

1

1Use Mo to highlight an icon.

32

+m-3-6

Scroll Selection

1

Main menu icon

Sub-menu item

Function name of lower sub-menu item

Items which appear on the display

No tone. . . . . . . . . Does not sound.

High tone. . . . . . . . High alarm sounds.

Low tone

. . . . . . . . Low alarm sounds.

m

Set./ServiceTalkQuality alarmSelect an alarm.

1

≥Press *Mo to highlight the icon. Press and hold *Mo to scroll

the icons continuously.

≥If you have not touched any key for 15 seconds, the

Stand-by display returns.

+m

*Mo

*Oo

Main Menu

In this manual, the description of the speed selector operation (selection
of top/bottom/left/right, and press of Oo after selecting/entering a
function item) is omitted. Scroll selection is explained below using the
example of selecting the function “Quality alarm”:

Description Example of Steps

Select a main menu icon from the menu function

Select “Set./Service” from Main Menu. Main Menu at purchase differs depending on the
body color. (See page 471)

Before Using the Handset

33

Select a sub-menu item from the menu function

2

*Oo

≥The highlighted item is the currently

selected one.

≥Press *Xo to highlight the item

below, and *Zo to highlight the item
above.

≥Press and hold *Bo to scroll the

items continuously.

≥Press *No to scroll page by page.

3

*Oo

≥

Press

*Xo

to highlight the item below,

and

*Zo

to highlight the item above.

≥

Press and hold

*Bo

to scroll the items

continuously.

≥

When the items are listed over
multiple pages, the total number of
pages and the current page number
are shown at the upper right of the
display.

*Oo

≥The highlighted item is the currently

selected one.

≥Press *Xo to highlight the item

below, and *Zo to highlight the item
above.

≥Press and hold *Bo to scroll the

items continuously.

Menu number

<Quality Alarm>

Sounding Alarm when a Line is Nearly Disconnecting



+m-7-5

Select “Talk” from “Set./Service”.

Before Using the Handset

Set or check the function

4

Some menu items have even more detailed menus.
The example below shows how to set “Low tone” for “Quality alarm”.

Select a desired lower sub-menu item (function)

Select “Quality alarm” from “Talk”.

34

Menu Number Selection

Menu Number Selection is explained below using the following example:

Description Example of Menu Number

Call up the function using the menu number

1

+m

-7-5

+i

Delete all You can delete all files.



Enter your Terminal Security CodeYES

Item displayed in the Function menu

Operating procedures after selecting
an item in the Function menu

From the Stand-by display, press m75.

Function Menu

If you press i when “ ” is shown at the lower right of the display,
the Function menu including selectable items such as “Save”, “Edit”,
and “Delete” appears in each operation. The contents of the Function
menu depend on the display from which you show the Function menu.

≥When the items are listed

over multiple pages, the total
number of pages and the
current page number are
shown at the upper right of
the Function Menu display.

Before Using the Handset

Simple Menu

Simple Menu is a menu focusing on only basic functions for easy
operation. By setting “Menu icon setting” to “Simple menu”, you can
show the Simple Menu by pressing m from the Stand-by display.

≥Some operating procedures or items which appear on the display in Simple Menu differ

from the ones described in this manual.

≥See “Simple Menu Function List” on page 486 for the contents of Simple Menu.

Description Example for Function Menu

In this manual, the operation of the Function menu is described as
follows:

35

An actual operation is done as follows:

Press +i().

Use *Mo to highlight
“Delete all” and press

*Oo().

Enter your Terminal
Security Code and press

*Oo().

Use *Bo to highlight
“YES” and press

*Oo().

Item number

For Reset Settings

Before Using the Handset

To select an item quickly <Direct selection>

Press the numeric key corresponding to the
displayed item number.

Item scroll

When menu items are listed over multiple pages, you can show the previous/next page
by pressing Bo with the uppermost/lowermost item highlighted. You can press No to
scroll through page by page. When / is displayed on the display, you can
scroll through page by page also by pressing m()/c().
≥Depending on the display being shown, such as lower sub-menu items, you might be

able to scroll through page by page also by pressing </> instead of No.

Check box

With the functions you can select multiple items, put a check
mark for check boxes to select them.
Each time you press
“”.
With some functions, you can put or clea r check marks at a time by pressing
and selecting “Select all/Release all”or by pressing
≥ “ ” is placed to the selected item depending on the function.

Oo

( ), you can switch “ ” and

m(/)

i()

.

After finishing the operation

The Lower Sub-menu Item Selection display is shown. When you press h, the
Stand-by display returns (except during Multitask). The Stand-by display or the former
display automatically returns depending on the function.

To cancel the operation midway

Press h. The contents of the setting are abandoned and the Stand-by display or the
former display returns. The confirmation display appears asking whether to abandon the
setting contents depending on the function. You can press r to return to the previous
operation.

When the “YES/NO” selection display appears

Press Bo to highlight “YES” or “NO”, then press Oo().

36

<Guide>

Cut

When You Forget Key Operation

You can search for the functions you want to know and use, and then
check the operating methods. You can execute some functions from
“

使いかたナビ

1

2
3

(Guide)”. This function is available in Japanese Mode only.

m1ステーショナリー

1

使いかたナビ

おすすめ機能 (Recommendable functions)

. . . Displays the recommendable functions. Go to step 3.

キーワード検索 (From keywords)

. . . Enter keywords and retrieve. Go to step 2

機能一覧検索 (From Function list)

. . . Retrieves from the function list. Go to step 3.

検索履歴 (Search history)

. . . Displays up to 30 search histories. Go to step 3.
≥Highlight each item and press l( ); then the

detailed operating methods are displayed.

≥The 使いかたナビ(Guide) display appears also by selecting the 使いかたナビ

(Guide) icon “ ” pasted on the desktop at purchase.

≥You can store “使いかたナビ (Guide)” for Multi Key Long Press Setting. (See

page 404)

(Guide)1Select an item.

(Stationery)

Enter a keyword.

Up to 50 search results are displayed.
≥You can enter up to 24 full-pitch/48 half-pitch characters.

Select a function1Select an item.

機能の説明 (Description) . . . . . . . . Displays explanations for the function.

操作のしかた (How to operate) . . . Displays the operating method.
この機能を使う (Operate function)

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Executes the function. Operate each function.

≥For some functions, press Oo( ) several times for selection.
≥You can display explanations about the function also by pressing l()

while highlighting the function.

≥To delete search history, press i( ) and select “1件削除 (Delete this)” or

“全削除 (Delete all)”, then select “YES”.

Using UIM (FOMA Card)

The UIM is an IC card that holds your information such as phone
numbers. It can hold data such as Phonebook entries and SMS
messages as well. By sharing a UIM, you can operate multiple FOMA
terminals for multiple purposes.
You cannot use the FOMA terminal for communication such as voice and
videophone calls, i-mode, sending/receiving mail, or packet
communication unless the UIM is inserted.
For details on how to use the UIM, refer to the UIM instruction manual.
When inserting or removing the UIM, take care not to accidentally touch
or scratch the IC.

Insert/Remove

You need to turn off the power and then remove the battery before you
insert the UIM. (See page 39)

■Inserting

With the golden IC surface

1

downward, push the UIM slowly
to the end while pressing the
surface of it.

■Removing

While sliding the UIM, pull it out

1

slowly.

Before Using the Handset

37

Information

≥Make sure that you insert/remove the UIM with the FOMA terminal closed and held in

♪

♪

♪

♪

♪

If the UIM used for
obtaining data files
or mail messages is
inserted, you can
browse/play back the
data files with the UIM
security.

♪

♪

♪

♪

♪

Unless the UIM used
for obtaining data files
or mail messages is
inserted, you cannot
browse/play back the
data files with the UIM
security.

Your UIM

Another

person’s UIM

Replacing UIMs

your hand.

≥Take care not to force the UIM into place because this can break it.
≥Take care not to lose the UIM once you remove it.
≥When you replace your UIM (except during Omakase Lock), you need to enter the

four- to eight-digit Terminal Security Code after turning on the power. When you enter
the correct Terminal Security Code, the Stand-by display appears. If you enter the
incorrect Terminal Security Code five times in succession, the power turns off.
(However, you can turn on the power again.)

Security Code

You can set two security codes, PIN1 and PIN2, for a UIM. (See page 122)

Security Function of UIM

Before Using the Handset

The FOMA terminal has the UIM security function (UIM restriction
function) as a security function to protect your data files.
If you obtain data files by the method below with the UIM inserted, UIM
security function is automatically set to them.

・When downloading images or melodies and so on, from sites or

Internet websites

・When receiving i-mode mail with file attachments

The data files with the UIM security can be browsed, played back, started,
edited, attached to mail, or transferred via infrared rays only when the
UIM used for obtaining is inserted. When the UIM used for obtaining the
data or files is not inserted, or when another UIM is inserted, these
functions are not operable.

≥In the explanation hereafter, the UIM used to obtain data and files is referred to

as “your UIM” and other UIMs as “another person’s UIM”.

38

≥When the UIM is not inserted or when another person’s UIM is inserted, the following

types of data and files are displayed with the restrictions symbol, “ ”:

・Videophone record messages ・Movie memos ・Screen memos
・Templates ・i-αppli programs ・Images
・i-motion files ・Chara-den images ・Melodies
・Machi-chara images ・Kisekae Tool files ・PDF files
・Chaku-uta®/Chaku-uta Full® music files ・Downloaded dictionaries
・Files attached or pasted to i-mode mail in the Inbox
・Files attached to i-mode mail in the Outbox/Draft (except the data shot or edited

with the FOMA terminal)

・Messages R/F with files (melodies or images) attached or pasted
・Images inserted into Deco-mail text

※This function applies to the pre-installed i-αppli programs, Chara-den images,

Deco-mail pictograms, etc. if they are reinstalled (upgraded) from a site.

※“Chaku-uta” is a registered trademark of Sony Music Entertainment Inc.

≥The preview image for the data file with the UIM security appears as

shown on the right.

Information

≥When the UIM security is set for data files, you cannot set them for the functions such

Arrow mark

as “Display setting” and “Select ring tone” when another person’s UIM is inserted.

≥When the data files with the UIM security is set for “Display setting” or “Select ring

tone”, the FOMA terminal works with their default settings if you remove your UIM or
replace it with another person’s UIM. Also, a Machi-chara image is cleared. If you
insert your UIM again, your settings are enabled again.

≥The UIM security function is not set for the data files received using the infrared

communication function or data transmission (OBEX™ communication) function and
the still images/moving pictures shot or edited with the FOMA terminal.

≥Even when another person’s UIM is inserted, you can move/delete data files with the

UIM security.

≥The settings of the following functions are stored on the UIM:

・SMS validity period ・SMS center setting ・Select language
・PLMN setting ・PIN1 code, PIN2 code ・PIN1 code entry set
・Validating/Invalidating DOCOMO Certificate 1 and user certificate

Types of UIM (FOMA Card)

If you use the blue UIM with your FOMA terminal, note that following
specifications differ from those of the green/white UIM:

Functions

Number of digits of the phone number
that can be stored in the UIM Phonebook

Operation of user certificate to use
FirstPass

Use of WORLD WING Not available Available 450

Use of Service Numbers for “DOCOMO
repair counter” and “General inquiries
<docomo Information Center>”

Not available Available 213

Not available Available 439

UIM

(blue)

20 max. 26 max. 89

(green/white)

Reference

■WORLD WING

WORLD WING is the DOCOMO FOMA international roaming service that enables
you to use the current phone number overseas for making and receiving calls using
the UIM (green/white) and service compatible mobile phone.
≥You do not need to subscribe to WORLD WING if you have subscribed to the FOMA

service after September 1, 2005. If you offered that you did not need WORLD WING
at the time you signed up for the FOMA service, or when you have midway canceled
WORLD WING, you are required to take the procedures to newly subscribe to
WORLD WING.

≥If you have signed up for the FOMA service before August 31, 2005, and have not

yet subscribed to WORLD WING, you are required to subscribe to it.

≥This service is not available with some billing pl ans.
≥If you lose your UIM (green/white) or have it stolen overseas, immediately contact

DOCOMO to take the steps necessary for suspending the use of the UIM. For
inquiries, see “docomo Information Center” on the back page of this manual. Note
that you are still charged the call and communication fees incurred after you lose it or
have it stolen.

Attaching/Removing Battery Pack

Use the FOMA terminal’s dedicated Battery Pack P19.

■Attaching

While pressing the “ ” part of

1

the back cover in the direction A,
slide the back cover (2 mm or
more) in the direction B to
unlock and remove it.

≥Securely hold the FOMA terminal not to let it

open and then remove the back cover.

With the arrow mark facing up, fit

2

the tab side of the battery pack to
the FOMA terminal securely, and
then push the battery pack into
the direction B while pressing it
against the direction A.

Before Using the Handset

39

Put the back cover to the FOMA

Projection

Information

Li-ion 00

3

terminal as illustrated, and while
pressing the whole part of back
cover downward, slide it in the
direction of the arrow to attach it.

≥Confirm there is no gap between the back

cover and the FOMA terminal.

■Removing

Remove the back cover

1

following the step 1 of
“■Attaching”, and take hold of
the projection of the battery pack
to lift it up.

Before Using the Handset

≥Make sure that you turn off the power, hold the closed FOMA terminal in your hand,

and then attach/remove the battery pack.

≥If you try to force the battery pack into place, you could damage the UIM or the

terminal part of the FOMA terminal.

Charging

Use the FOMA terminal’s dedicated Battery Pack P19.
Life of battery pack

≥Battery packs are consumables. The usable time shortens slightly each time they are

charged.

≥When the usable time of the battery pack becomes half the time it was purchased,

replacing is recommended because the battery pack is nearing the end of its life.
Depending on the use conditions, the battery pack may swell as it nears the end of its
life, but this is not a problem.

≥The life of the battery pack may shorten if you use i-αppli programs, talk on the

videophone, watch 1Seg programs and so on for a long time during charging.

To prevent damage to the environment, bring used battery
packs to a docomo service counter, a docomo agent or a
recycle center.

Charging

≥For details, refer to the instruction manuals for the FOMA AC Adapter 01/02 (option),

FOMA AC Adapter 01 for Global use (option), and FOMA DC Adapter 01/02 (option).

≥The FOMA AC Adapter 01 supports 100 V AC only. The FOMA AC Adapter 02 and

FOMA AC Adapter 01 for Global use support from 100 V AC through 240 V AC.

≥The shape of the plug for the AC adapter is for 100 V AC (for domestic use). To use the

AC adapter that supports from 100 V AC through 240 V AC overseas, you need to
have a conversion plug adapter that is compatible with the voltage of the country you
stay. Do not use a transformer for overseas travel to charge the battery pack.

≥Even during charging, you can still answer calls if the FOMA terminal is turned on. This

will consume the charged amount so that charging will take longer. Also, the standby
time or talk time might be shorter if you charge the battery pack with your FOMA
terminal open.

≥If you have a long time videophone call during charging, the temperature in the FOMA

terminal may rise and charging may be suspended. In such a case, wait for a while and
try charging again.

≥Remove and insert the connector slowly and carefully, without using unnecessary

force.

≥Do not remove the battery pack during charging.

40

Do not charge for long periods of time (several days) with the FOMA

1

Plug the connector of AC
Adapter (option) horizontally
with its engraved side facing
down into the connector
terminal of the Desktop Holder
(option).

2

Pull out the AC Adapter's plug,
and plug it into a household
power socket of 100 V AC.

Call/Charging
indicator

Desktop Holder

Engraved surface
(down side)

AC Adapter

Stopper

Power
socket

Lock claw

AC
Adapter’s
plug

Connector

terminal turned on.

≥If you leave the FOMA terminal powered on for long periods of time during charging,

you may not be able to use the FOMA terminal for long duration as expected and the
low battery alarm may sound soon, because the FOMA terminal receives the power
from the battery pack after charging is completed. If this happens, charge the battery
pack correctly. When charging the battery pack again, first remove the FOMA terminal
from the AC adapter (or desktop holder) or DC adapter and then set it again.

Estimated usable time for battery pack (The usable time for the battery pack

varies with the charging time and the remaining life of the battery pack.)

Continuous
standby time

Continuous
talk time

1Seg watching time Approx. 220 minutes

※The continuous talk time is the estimated time that the FOMA terminal can be used for

calls when radio waves can be sent and received normally.

※The 1Seg watching time is the estimated time for when radio waves can be received

normally with the Stereo Earphone Set 01 (option) connected.

※The continuous standby time is the estimated time for when radio waves can be

received normally. The talk/communication time and standby time could be about half
of the estimate and 1Seg watching time could be shorter depending on the charge
level of the battery pack, function settings, other ambient conditions such as
temperature, and the status of radio waves in the area (weak or no radio waves, for
instance). When you use i-mode communication, the talk/communication time and
standby time will be shorter. Further, even if you do not make calls or not execute
i-mode communication, the talk/communication time and standby time will be shorter if
you watch 1Seg programs, compose i-mode mail, start up a downloaded i-αppli
program or the i-αppli Stand-by display, execute data communication or Multiaccess,
use the camera, play back i-motion files, movie files or music, or use Bluetooth
connections.

※The continuous talk time and the continuous standby time may be shortened

depending on the network environment in the country you stay.

FOMA/3G

GSM

FOMA/3G Voice call: Approx. 200 minutes

GSM Voice call: Approx. 260 minutes

3G/GSM setting
[3G]
3G/GSM setting
[Auto]
3G/GSM setting
[Auto]

In motion: Approx. 390 hours

Standstill: Approx. 620 hours
In motion: Approx. 370 hours
Standstill: Approx. 270 hours

Videophone call: Approx. 110 minutes

(when Mobile W-Speed is OFF:
Approx. 270 minutes)
(in ECO Mode: Approx. 380 minutes)

※

The continuous standby time for standstill is the average number of hours you can use the
FOMA terminal in standstill status when it is closed and can receive radio waves normally.

※The continuous standby time for in motion is the average number of hours you can

use the FOMA terminal in the combined status of “standstill” “moving” and “out of the
service area” when it is closed, in an area where it can receive radio waves normally.

Estimated time for charging battery pack

AC adapter Approx. 120 minutes DC adapter Approx. 120 minutes

※The charging time is an estimate of time for when empty battery pack is charged with

the FOMA terminal turned off. The charging time will be longer if you charge the
battery pack with the power of the FOMA terminal turned on.

Charge with AC Adapter and Desktop Holder

41

Before Using the Handset

Put the bottom of the FOMA terminal into the stopper of

Engraved
surface

Release
buttons

Cover

Information

3

the desktop holder (A) to fit the head to the lock claw,
and then depress the FOMA terminal until it clicks (B).

Check that the Call/Charging indicator lights in red.
When the Call/Charging indicator flickers, dismount the AC adapter and battery
pack from the FOMA terminal and then re-mount them for charging.
If the symptom persists, troubles with the AC adapter, desktop holder or battery
pack may be involved, so consult a handling counter such as a docomo Shop.
≥The charging confirmation tone (see page 105) sounds when charging starts and

ends. However, it does not sound when the power is off or during Manner Mode
or Public mode (Drive mode).

≥Be sure to set the FOMA terminal firmly onto the desktop holder. Also, be careful

that the connector cover or a commercial strap is not caught between the FOMA
terminal and desktop holder.

When charging is completed, hold the desktop holder

4

with fingers and lift up the head of FOMA terminal to

Before Using the Handset

remove.

≥Unplug the AC adapter from the power socket when you are not going to use it for

a long time.

■Indicator and display during charging and when charging is completed

Call/Charging indicator Battery icon

Charging Lights in red Blinks

Charging completed Off Lights

≥When the FOMA terminal is turned off, the battery icon does not appear.

If you start charging with the battery flat, the Call/Charging indicator might not light
immediately; however, charging itself has started.

≥When charging automatically stops for safety, “ ” might be displayed on the

desktop.

■Stand

≥Standing up the desktop holder to put the FOMA terminal with a slope makes easier to

watch 1Seg programs, etc. For details, refer to the instruction manual for the desktop
holder.

When charging only with the AC adapter

Insert the connector with the engraved surface
facing up until it clicks. Pull straight the connector
out while pressing the release buttons.
≥To charge the battery, place the cover of the

connector terminal as illustrated. Pull out the
cover of the connector terminal to direction A,
and turn it as direction B.

※

Check the facing direction (front or rear) of the
AC adapter plug and then insert or pull it
horizontally into or out of the FOMA terminal.
Malfunction could result if you try to pull it
forcibly.

■DC adapter (option)
With the DC adapter, you can use a cigarette lighter socket (12 V/24 V) of cars to
charge the FOMA terminal with the battery pack attached.
For details, refer to the instruction manual for the FOMA DC Adapter 01/02.

≥If the fuse blows off when charging with the DC adapter, be sure to use a 2A fuse. The

2A fuse is consumables, so purchase at auto parts stores in your neighborhood.

<Battery Level>

Checking Battery Level

When you turn on the FOMA terminal, an estimate of the battery level is
indicated. It is indicated by icons when you set “Battery” of “Display
setting” to “Icon”, and it is indicated in percent figures when you set it to
“Numerals”.

Battery level Icon display Numerals display

Almost full

Slightly low

Getting low

Fairly low

Almost empty

≥Charge the battery pack when it is almost empty.

〜
〜
〜
〜
〜

42

Information

≥Depending on the usage state, the battery level indication might significantly vary.

Almost full

Five beeps

Slightly low
Four beeps

Getting low

Three beeps

Fairly low

Two beeps

Almost empty

One beep

※Almost empty.

Charge the battery pack.

Recharge Battery

display

Stand-by display

Check Estimate of Battery Level by Display and Tone

You can check an estimate of the battery level by the display and sound.

m1Set./Service1Other settings1Battery

1

1Battery level

≥The estimate of the battery level is indicated in percent figures below the

pictograms.

≥The pictogram disappears in about three seconds.
≥The battery level tone does not sound during Manner Mode or when you set

“Keypad sound” to “OFF”.

When the battery is running out

When the battery runs out, the display on the right ap pears and
the low battery alarm sounds for about 10 seconds. To stop
this alarm, press any key other than < and >. About one
minute later, the FOMA terminal will be turned off.
≥During a call, a beeping tone from the earpiece notifies you of

the low battery. About 20 seconds later your call will be cut
and then one minute later the FOMA terminal will be turned
off.

≥The low battery alarm may sound when the battery level becomes about 10 percent or

less.

<Power ON/OFF>

Turning Power ON/OFF

Turn Power On

Press and hold h for at least one

1

second.

After the Wake-up display (see page 110) is displayed,
the Stand-by display appears.

≥It may take a while for the Wake-up display to appear.
≥If Set Time is set, the current date and time are shown.
≥When “ ” is displayed, the FOMA terminal is out of

the service area or in the place where the radio waves
do not reach. Move to a location where “ ”
disappears.

When your UIM is replaced (except during Omakase Lock)

Enter the four- to eight-digit Terminal Security Code after turning on the power. When
you enter the correct Terminal Security Code, the Stand-by display appears. If you enter
the incorrect Terminal Security Code five times in succession, the power turns off.
(However, you can turn on the power again.)

When “PIN1 code entry set” of “UIM setting” is set to “ON”

Enter the four- to eight-digit PIN1 code after you turn on the power. When you enter the
correct PIN1 code, the Stand-by display appears. See page 122 for PIN1 code.

When “Auto reset setting” of “Notice call cost” is set to “ON”
(except during Omakase Lock)

Enter the four- to eight-digit PIN2 code after you turn on the power. When you enter the
correct PIN2 code, the Stand-by display appears. If you press r or h without
entering the correct PIN2 code, “Auto reset setting” is set to “OFF” and the Stand-by
display appears. See page 122 for PIN2 code.

43

Before Using the Handset

Check Welcome Mail

Information

Information

The mail messages “Welcome ドコモ動画 (Welcome DOCOMO moving
picture )” and “緊急速報「エリアメール」のご案内 (Introduction of Early Warning
“Area Mail”)” have been saved by default. Press Oo twice or perform step 1 of “Display
Mail from Inbox” on page 158 to show the Inbox list.

≥Each entry display appears in the order of “PIN1 code” → “Terminal Security Code”

→ “PIN2 code”.

Turn Power Off

Press and hold h for at least two seconds.

1

The exit display appears and the power turns off.
≥You cannot turn on the power immediately after turning off the power. Wait a few

seconds.

Before Using the Handset

<Select Language>

+m-1-5

Switching to English Display

m1

1

≥When you insert the UIM, the “バイリンガル (Select language)” setting is stored on

設定／サービス

1

ディスプレイ

1

Japanese (

≥

The following functions are different between Japanese display and English display:

→ “Stand-by clock” →“Day of week”

the UIM.

Functions Japanese English

“Clock” of Display Setting

使いかたナビ (Guide) Available Not available

Voice Guidance Available Not available

(Set./Service)

(Display)1バイリンガル

日本語

) or English (英語)

(Select language)

Available Not available

<Initial Setting>

Configuring Initial Setting

If the date and time, Terminal Security Code, Keypad Sound, Speed
Selector Sound, Location Request Set., or Font Size Setting is not set, the
Initial Setting display appears when you turn on the power. You can set
the initial settings also from each menu function separately.

Turn on the power1YES

1

≥When the display for entering your Terminal Security

Code, PIN1 code, or PIN2 code appears, follow the
operation on page 43.

Set the date and time.

2

You can select “Auto time adjust ON” or “Auto time adjust OFF” for setting the time.
(See page 45)

Set your Terminal Security Code.

3

You can set your Terminal Security Code required for setting functions.
(See page 122)

1. Enter “0000”1Enter your new Terminal Security Code (four to eight digits)

1YES

Set Keypad Sound.

4

You can set whether to make a keypad sound. (See page 105)

Set Speed Selector Sound.

5

You can set the sound for when you rotate the speed selector. (See page 105)

Set Location Request Set..

6

You can set whether to notify your current location for when a GPS location
provision request arrives. (See page 328)

44

Set the size of characters.

Information

Information

7

You can set the size of characters on the display at a time. (See page 118)

≥When an unset function is found, the Initial Setting display for the unset function

appears each time you turn on the power.

≥The completed settings are valid even when total setting is interrupted by an incoming

call or canceled by pressing -h or -r midway.

≥When the power is automatically turned on by alarm notification, the Initial Setting

display does not appear even if there is any unset function.

≥When you finish the initial settings, the confirmation display appears telling that

updating software is executed automatically. This display appears only at the first
time, and after that, does not appear until you execute Reset Settings or Initialize.

<Set Time>

+m-3-1

Setting Date and Time

You can select whether to correct the time automatically or set it
manually. The time is set/displayed on the 24-hour basis.

m1Set./Service1Clock1Set time

1

1Auto time adjust ON or Auto time adjust OFF

Auto time adjust ON

. . . .Corrects the date/time automatically. The setting is completed.

When the time cannot be corrected automatically such as when “ ” is
displayed and the date/time has not been set, the Manual Time Setting
display appears. Follow step 2 to set the date/time.

Auto time adjust OFF

. . . .Sets the date/time manually.

≥When “Notice call cost” is set to “ON”, you need to enter your Terminal Security

Code.

Enter year, month, date and time.

2

Use Mo to move the cursor and enter numbers by the
numeric keys.
≥To enter one-digit numeral for the date and time, enter

two digits beginning with “0” as in “01” through “09”.

≥Highlight “Time zone” and press l( ) to set the

time zone. Use Mo to select a region and press Oo().

About date/time correction function

This function corrects the time of the FOMA terminal according to the clock information
obtained from the network when you turn on the power.
The time is corrected when you show the Stand-by display with “Auto time adjust ON”
set.
If the time is not corrected for a while after you turn on the power, turn it off and then on
again.

≥

Some few second errors might occur. You might not be able to correct the time depending
on the radio wave conditions, or the i-αppli program set for the i-αppli Stand-by display.

≥When you receive the clock information overseas and the time difference correction

information differs from the previously received one, “Time is adjusted” is displayed and
the time difference is corrected automatically. Press “OK” to update the time and show
Redial, Dialed Calls, Received Calls, sent/received mail messages and others in local
time.

≥Depending on the overseas carrier, the time difference might not be correctly adjusted.

In such a case, set a time zone manually.

≥Unless Set Time is set, the functions which use the clock such as Schedule do not

work correctly. Further, the date/time for redial items and received call records are not
stored.

≥The set time is retained even when the battery pack is replaced, however, it might be

reset if the battery pack is left removed for a long time. In that case, charge the FOMA
terminal and then perform the clock setting.

≥When “Time zone” is set to other than “GMT +9” or the time difference is corrected

overseas, the sub clock (Japanese date/time, etc.) is displayed on the Stand-by
display.

≥This function supports clock settings from 00:00 on January 1, 2009 through 23:59 on

December 31, 2037.

Before Using the Handset

45

<World Time Watch>

Information

Information

Own Number display

Phone number tab

List tab

Information

Displaying World Time

You can display the time of the specified area on the Stand-by display.

m1Set./Service1Clock1World time watch

1

1ON or OFF
1Use Mo to select an area and press Oo().

Set Caller ID Notification to Network

You can set whether to notify your caller ID on the network.

m1Set./Service1NW services1Caller ID notification

1

1Do the following operations.

Activate/Deactivate 1Activate or Deactivate

Check setting You can check the setting contents of “Activate/Deactivate”.

+m-1-7

≥World Time Watch does not appear when “Display setting” → “Clock” → “Stand-by

clock” → “Position” is set to “OFF”, or when you use the FOMA terminal overseas.

Summer Time

You can advance the time displayed for the overseas country you stay
and for a region of World Time Watch by one hour.

Before Using the Handset

m1Set./Service1Clock1Summer time1ON or OFF

1

<Caller ID Notification>

Notifying the Other Party of Your Phone Number

You can set the FOMA terminal to send your phone number to the called
party’s phone when dialing. Your phone number is important
information, so take utmost care when notifying your phone number.
This function is available only when the other party’s phone supports
Caller ID.

46

≥“Activate/Deactivate” of “Caller ID notification” is also valid for making a PushTalk call.

<Own Number>

+m-0

Checking Your Own Phone Number

≥Your phone number (own number) is stored on the UIM.

m1Phonebook1Own number

1

You can press No to switch the tabs.

≥See page 405 for storing/displaying personal data.

≥In Dual Mode of 2in1, you can switch between Number A and Number B by pressing

*Oo( ) from the Own Number display. “ ” appears for Number A, and “ ”

appears for Number B.

≥When you replace a UIM with another one while using 2in1, 2in1 Setting is

deactivated. For using 2in1, activate 2in1 Setting.

Voice/Videophone Calls/PushTalk

Making Calls/Videophone Calls

Videophone Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Making a Call/Videophone Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Switching a Voice/Videophone Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

Using Call Records. . . . . . . . . <Redial> <Dialed Calls> <Received Calls> 52

Using Chaku-moji . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <Chaku-moji> 54

Setting Caller ID to Send/Not to Send for Each Call . . . . . . . . . <186/184> 56

Sending Touch-tone Signals . . . . . . . . . . . . . . . . . . . . . . . . . .<Pause Dial> 57

Making International Calls . . . . . . . . . . . . . . . . . . . . . . . . . <WORLD CALL> 58

Setting for International Calls . . . . . . . . . . . . . <International Dial Assist> 59

Storing Numbers to be Added to the Beginning of a Phone Number

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <Prefix Setting> 60

Making a Call Specifying a Sub-address . . . . . . . <Sub-address Setting> 60

Setting Alarm for Reconnecting . . . . . . . . . . . . . . . . . <Reconnect Signal> 60

Making Voice Clear According to Surrounding Noise . . . <Shikkari Talk> 61
Reducing Surrounding Noise to Make Voice Clear . . .<Noise Reduction> 61

Slowing Down the Other Party’s Speaking Speed . . . . . . . <Yuttari Talk> 61

Switching to Hands-free. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .<Hands-free> 61

Using Hands-free Compatible Devices. . . . . . . . . . . . <In-Car Hands-free> 61

Receiving Calls/Videophone Calls

Receiving a Call/Videophone Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

Switched between a Call and a Videophone Call by the Other Party. . . 64
Setting Response of Key Operation for Answering Incoming Calls

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <Answer Setting> 64

Setting Response for when Opening FOMA Terminal while Ringing

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .<Setting when Opened> 65

Setting Response for when Closing FOMA Terminal during a Call

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <Setting when Closed> 65

Adjusting Earpiece Volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <Volume> 66

Adjusting Ring Volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . <Ring Volume> 66

When You cannot/could not Answer a Voice/Videophone Call

Putting a Call on Hold when You cannot Answer Immediately

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <On Hold> 67

Putting a Call on Hold during a Call . . . . . . . . . . . . . . . . . . . . . . <Holding> 67

Setting Hold Tone . . . . . . . . . . . . . . . . . . . . . . . . . . . . .<Hold Tone Setting> 67

Using Public Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

When You could not Answer an Incoming Call . . . . . . . . <Missed Calls> 69

Recording Voice/Video Messages when You cannot Answer a Call

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <Record Message Setting> 69

Recording a Message when You cannot Answer an Incoming Call

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .<Quick Record Message> 70

Playing/Erasing Record Messages/a Voice Memo/Videophone Record
Messages/Movie Memos

. . . . . . . . . .<Play/Erase Messages> <Play/Erase Videophone Messages> 71

Making Full Use of Videophone Calls

Using Chara-den . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

Useful Functions for Videophone Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

Setting Hands-free Videophone . . . . . . . . <Hands-free with Videophone> 75

Setting Image Quality for Videophone Calls . . . . . . . <Visual Preference> 75

Changing Image Displays for Videophone Calls . . . . . . . <Select Image> 75

Redialing as a Voice Call when a Videophone Call cannot be Connected

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <Voice Call Auto Redial> 76

Setting for Switching a Voice/Videophone Call during a Call

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <Notify Switchable Mode> 76

Selecting Response to Incoming Videophone Calls during i-mode

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .<Videophone while Packet> 76

Using Videophone Calls by Interfacing to External Devices . . . . . . . . . . . 77

Checking inside of a Room when You are Out . . . . <Remote Monitoring> 77

PushTalk

PushTalk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

Making a PushTalk Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

Adding a Member during a PushTalk Call . . . . . . . . . . . . . . . . . . . . . . . . . . 81

Receiving a PushTalk Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82

Adding Entries to PushTalk Phonebook

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <Store in PushTalk Phonebook> 83

Making a Call from PushTalk Phonebook . . . . . . . . . . . . . . . . . . . . . . . . . . 84

Deleting PushTalk Phonebook Entries

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .<Delete from PushTalk Phonebook> 85

Setting for Making/Receiving a PushTalk Call . . . . . . . . . . . . . . . . . . . . . . 85

47

Videophone Calls

1

3

4

2

4…Status

: Voice sending/receiving
(gray): Voice sending/

receiving failed

※1

: Image sending/receiving
(gray): Image sending/

receiving failed

※2

: Camera image sending
: Still image sending
: Chara-den talking

: Hands-free activated
: AV output
: Bluetooth

communicating

: Portrait
: Close-up
: Landscape
: Night Mode

: Chara-den Whole

Action Mode

: Chara-den Parts Action

Mode

: DTMF Transmission

Mode

You and the other party can talk viewing each other’s images.

DOCOMO videophones conform to 3G-324M, standardized by the international
standard 3GPP. You cannot connect to the videophone that uses a different format.

≥3GPP (3rd Generation Partnership Project):

This is the regional standards organization for developing common technical
specifications for third-generation mobile telecommunication systems (IMT-2000).

≥3G-324M:

This is the international standard for the third generation of mobile videophones.

≥P-08A supports only 64 kbps communication speed of the videophone.

You cannot talk on the videophone at 32 kbps communication speed.

■Display during videophone calls

1…Received image (The other party’s image through the

camera or substitute image)

2…Sent image (Image through your camera or substitute

image)

3…Call duration

Voice/Videophone Calls/PushTalk

※1 When voice sending fails, the other party cannot hear your voice.

When voice receiving fails, you cannot hear the other party’s voice.

※2 When image sending fails, the sent image is not displayed at the other end.

When image receiving fails, the received image is not displayed.
When voice or image sending/receiving fails, it does not recover automatically. You need
to make a videophone call again.

48

Making a Call/Videophone Call

Enter the other party’s phone number,

1

starting with the city code.

≥When 27 or more digits are entered, the lower 26 digits

only are displayed.

≥To store an entered phone number in the Phonebook,

press m( ). Go to step 2 on page 92.

≥Even when you are dialing within the same area, you

need to enter the city code before the phone number.

When Making a Voice Call

2

Press d or Oo().

≥“ ” blinks during dialing, and lights during a call.

When Making a Videophone Call

The digital communication
charging starts from this
display.

Information

Information

Press l().

≥“ ” blinks during dialing and lights during the call.
≥Press m during a videophone call to switch between

the image through your camera and substitute image
for sending to the other party.

Press h to end the call after talking.

3

≥If you hear the guidance requesting your caller ID (see page 438), follow the steps of

“To notify your caller ID” on page 57 to enter “186” and redial.

≥When an earphone/microphone (option) is connected, you can hear the other party’s

voice from the earphone. (See page 410)

≥If you close the FOMA terminal during a call, the FOMA terminal works in accordance

with the setting of “Setting when closed”. (See page 65)

≥You can press numeric keys to send touch-tone signals during a call. During a

Chara-den call, you need to switch to DTMF Transmission Mode. (See page 74)

≥In Dual Mode of 2in1, you can make a call after selecting Number A or Number B.

(See page 444)

<For Voice Calls>

≥You can make a voice call also by pressing -d and then entering the party’s phone

number. If you enter a wrong number, press -h to clear the display and then redial.

<For Videophone Calls>

≥Just after purchase, Hands-free is automatically activated by “Hands-free

w/ V. phone” (see page 75). However, Hands-free is deactivated during Manner Mode
regardless of “Hands-free w/ V. phone”.

≥When you make a videophone call with substitute image, note that you will still be

charged for the digital communication, not the voice calls.

≥If you make a videophone call at 110/119/118 from the FOMA terminal, it is

automatically dialed out as a voice call.

≥During a videophone call, you can send a Chara-den image to the other party instead

of the image through your camera. (See page 72)

≥The international videophone call is available using the DOCOMO international call

service “WORLD CALL”. (See page 58)

Display when dialing

The other party’s name and icon are displayed if the party’s phone number and name
are stored in the Phonebook. However, the image is not displayed even if it is stored in
the Phonebook.
≥If the same phone number is stored with multiple names in the Phonebook, the name

that comes first in the search order (see page 94) is displayed.

≥The phone number instead of the name is displayed when you make a call during

Personal Data Lock or to the party stored as secret data in the Phonebook.

If you entered a wrong phone number

Each time you press r, the digit on the far right is cleared. If you press and hold r
for at least one second, all the digits are cleared and the Stand-by display returns.
≥Press No to move the cursor to the digit you want to clear, and then press r to clear

it. To clear all the digits on and to the right of the cursor, press and hold r for at least
one second.

Voice/Videophone Calls/PushTalk

49

If a videophone call could not be connected

The reason why it could not be connected is displayed. (The displayed reason might not
be the same as the actual reason depending on the type of the other party’s phone and
contract for network services.)

Messages Reasons

Check number, then
redial
Busy The other party is busy. (Depending on the receiver’s

Busy with packet
transmission
Out of service area/power
off
Set caller ID to ON Your caller ID is not notified. (when dialing “visualnet”, etc.)
Your call is being
forwarded
Redial using voice call The other party activates Call Forwarding Service but the

Upper limit has been
exceeded

Voice/Videophone Calls/PushTalk

Connection failed
Please make your call
from the i-mode web page

Connection failed Redial after setting “Activate/Deactivate” of “Caller ID

You have dialed a non-existent phone number.

phone, this message might be displayed during packet
communication as well.)
The packet communication is progress at the other end.

The other party’s phone is out of the service area or turned
off.

During forwarding

forwarding destination phone does not support videophone
calls.
The upper limit for the plan with the limit function (Type
Limit, Family Wide Limit) is exceeded.

You did not make a videophone call from the IP (Information
Provider) site among i-mode official sites (at dialing to
V-live).

notification” to “Activate”.
≥This may appear in the case other than above.

Auto-redialing

If “Voice call auto redial” is set to “ON”, and a videophone call is not connected, a voice
call is automatically made.
≥Videophone calls cannot be connected to the phones that do not support the

videophone function, or to the phones that are out of the service area or turned off even
if they are videophones. If you have set “Voice call auto redial” to “ON” and attempt to
dial a phone that does not have the videophone function, the number will be redialed
as a voice call. However, this operation might not work if you call the phone connected
with ISDN-synchronous 64K or the ISDN videophone that does not support 3G-324M
(as of April 2009), or if you dial the wrong number. Note that you could be charged for
the communication.

Function Menu while Entering Phone Number

Notify caller ID See page 56.

Prefix numbers See page 60.

Int’l dial assist See page 59.

Select image See page 76.

Multi number You can select a phone number to be notified to the other party.

Add to phonebook See page 92.

Compose message You can compose a mail message to send to the phone number

Chaku-moji See page 55.

(See page 441)

set as the destination address.
Go to step 3 on page 142.

50

Switching a Voice/Videophone Call

Information

You (caller) can switch between a voice call and a videophone call. This

function is available for the mobile phones that can switch between a

voice call and a videophone call.

Switch from a Voice Call to a Videophone Call

When the other party’s phone has a function to switch between the calls,

“ ” is displayed on your phone and you can switch from the voice

call to videophone call.

During a voice call1c()1Change

1

≥When you select an image

to be sent to the other
party, select “Select
image”. Go to step 2 on
page 76.

≥When “Cancel” is selected,

the FOMA terminal cancels
switching and returns to the
voice call.

≥While switching, the voice

guidance is played back.

Switch from a Videophone Call to a Voice Call

When the other party’s phone has a function to switch between calls, you
can switch from a videophone call to a voice call by selecting “CHG to
voice call” from the Function menu.

During a videophone call1i()

1

1CHG to voice call1YES

≥Select “NO” on the

confirmation display to stop
switching and to resume
the videophone call.

≥While switching, the voice

guidance is played back.

≥You can switch between a voice call and a videophone call repeatedly.
≥When i-mode or packet communication is in progress, the communication is

disconnected and then the voice call is switched to the videophone call.

≥When packet communication is in progress at the other end, the message to the

effect that the communication cannot be switched is displayed and the voice call
continues without switching to the videophone call.

≥You cannot switch from a voice call to a videophone call while “Multi calling” is

displayed during a call if you have signed up for Call Waiting Service.

≥It takes about five seconds to switch. Switching may take a longer time depending on

the radio wave conditions.

≥

Depending on how the caller’s phone is working or on the radio wave conditions, switching
between a voice call and a videophone call may fail and the connection may be cut off.

≥If you switch between a voice call and a videophone call during a call, the call duration

and call cost are counted respectively for each call. You are not charged while
“Changing” is displayed.

≥You cannot switch between a videophone call and a voice call unless “Notify

switchable mode” on page 76 is set to “Indication ON” at the other end.

≥When you switch from a videophone call to a voice call, Hands-free is deactivated.

51

Voice/Videophone Calls/PushTalk

<Redial> <Dialed Calls> <Received Calls>

For Redial

For Redial

Using Call Records

The FOMA terminal can store the other party’s phone number and date/
time you have dialed or received. You can call back to the other party.

■Redial

Up to 30 records of dialed voice calls, videophone calls and PushTalk calls are stored in
total, and the older record of dialing to the same phone number is deleted. However, the
dialing by PushTalk is retained in Redial separately from that of the voice call or
videophone call even if you dial to the same phone number.

■Dialed Calls

Up to 30 records of dialed voice calls, videophone calls and PushTalk calls are stored in
total, and up to 30 records of 64K data and packet communications are stored in total as
well. The older records of dialing to the same phone number are also retained.

■Received Calls

Up to 30 records of incoming voice calls, videophone calls and PushTalk calls are stored
in total, and up to 30 records of 64K data and packet communications are stored in total
as well. The older records coming from the same phone number are also retained.
≥When a call is switched between a voice call and a videophone call, the call of the type

that is dialed/received first is stored.

≥When more than 30 calls are dialed, the older records are automatically deleted. Even

if you turn off the FOMA terminal, call records are not deleted.

Voice/Videophone Calls/PushTalk

≥When you use 2in1, up to 30 records for Number A and up to 30 records for Number B

are stored respectively regardless of the mode.

■Icons for Redial, Dialed Calls, and Received Calls

※

/

/

/

/

/

/

/

Dialed and received calls/missed calls of voice call

※

Dialed and received calls/missed calls of videophone call

※

Dialed and received calls/missed calls of PushTalk

※

Dialed and received group calls/missed group calls of PushTalk

Dialed and received calls/missed calls of PushTalk via server’s

※

Phonebook

Voice/Video messages are recorded on Record Message

Incoming calls of Remote Monitoring

※

Dialed and received calls/missed calls of international call

Dialed and received calls/missed calls of international videophone

※

call

Dialed calls of 64K data communication

※

/

/

※ The unchecked missed call icons are highlighted.

Received calls/missed calls of 64K data communication

Dialed calls of packet communication

※

Received calls/missed calls of packet communication

Received calls of 64K data communication and packet
communication when no external device is connected

Received Chaku-moji message

Records with time difference corrected

Records for Number B (only in Dual Mode of 2in1)

Use Redial/Dialed Calls

When Using Redial

1

Press Vo.

When Using Dialed Calls

m1Phonebook1Dialed/recv. calls

1Dialed calls

The list for call records is displayed.
≥For redial items of PushTalk, press Oo() to

show the Redial list of the group. Highlight a party and press p to make a
PushTalk call. If you do not highlight any party and press p, you can make a
group call.

≥Press m( ) to display the Sent Address list.

Select a call record.

2

The detailed display for the call record is displayed.
≥When the other party is stored in the Phonebook, the

phone number, name, and icon are displayed. If the
same phone number is stored with multiple names in
the Phonebook, the name and icon that come first in the
search order (see page 94) are displayed.

52

Use Received Calls

Received Call list

Detailed Received

Call display

Information

Press Co.

1

≥You can display the Received Call list also by

m1Phonebook1Dialed/recv. calls1Received calls

1All calls or Missed calls.

All calls . . . . . . All the records including missed calls

Missed calls. . . The records of missed calls only
In Dual Mode of 2in1, the number of missed calls for
Number A and Number B is displayed respectively.
(If unchecked missed calls are found, the number of them is displayed.)

≥For received call records of PushTalk, press Oo( ) to show the Received

Call list of the group with “★” mark added to the caller. Highlight a party and
press p to make a PushTalk call. If you do not highlight any party and press p,
you can make a group call.

≥Press m( ) to display the Received Address list.

Select a received call record.

2

≥The other party’s phone number is displayed if it is

provided. If that phone number is not stored in the
Phonebook but recorded as a voice call in Redial,
“Callback” is displayed.
If this caller is stored in the Phonebook, the phone
number, name, and icon are displayed.
If the same phone number is stored with multiple names
in the Phonebook, the name and icon that come first in
search order (see page 94) are displayed.
If there is a call for packet communication, the sender’s access point name (APN)
is displayed.
When the other party’s phone number is not notified, the reason for no caller ID is
displayed.

≥For missed calls, the ring time is displayed on the right of the received date/time.
≥When a Chaku-moji message is received, it is displayed.

To make a call to a displayed redial item, dialed call record, or
received call record

Press d to make a voice call. You can make a voice call also by pressing

Oo( ) from the detailed display. Press l( ) to make a videophone call

and press p to make a PushTalk call.

≥You can make a voice call to the most recently dialed or received number by pressing

-d from the Stand-by display and then *No.

≥“Callback” is not displayed for incoming videophone calls and PushTalk calls.
≥When you make/receive a call with an additional number of Multi Number, the stored

name for the additional number is displayed below the phone number on the detailed
display. If you store a phone number for “Number setting” of “Multi number”, the
phone number is displayed as well.

≥Dialed call records of 64K data communication are not stored when you use a

Bluetooth device.

≥Even if you make a voice call (or videophone call) to the phone number in a received

call record with a Chaku-moji message displayed, the received message is not sent.

≥When a call comes in from a party who uses a dial-in phone number, a different

phone number might be displayed.

Function Menu while Redial/Dialed Calls/Received Calls is Displayed

Notify caller ID See page 56.

Prefix numbers See page 60.

Int’l dial assist See page 59.

Select image See page 76.

2in1 dial You can select a phone number to be notified to the other

Multi number You can select a phone number to notify the other party. (See

Chaku-moji See page 55.
Search location You can access the site of “イマドコかんたんサーチ

Add to phonebook See page 92.

Add to PushTalk

party in Dual Mode of 2in1. (See page 444)

page 441)

(imadoco kantan search)”.

1YES

≥You can store the phone number in the Phonebook also by

pressing m( ) from the detailed display. Go to
step 2 on page 92.

Voice/Videophone Calls/PushTalk

53

Store in P-Talk PB 1YES

Information

Store P-Talk group 1Select a group.

Mail

Compose message You can compose a mail message to send to the phone

Compose SMS You can compose an SMS message to send to the phone

Ring time

[Received Call list only]

Change font size You can switch font sizes for Redial, Dialed Calls, Received

Voice/Videophone Calls/PushTalk

Set desktop/ key

Add desktop icon See page 31.

long press set. See page 404.

Sent address

[Redial/Dialed Calls only]

Received address

[Received Calls only]

Delete

Delete this 1YES

≥When members who are not stored in the PushTalk

Phonebook are found, the confirmation display appears
asking whether to store them.

1Enter a group name.

≥You can enter up to 16 full-pitch/32 half-pitch characters.

number set as the destination address.
Go to step 3 on page 142.

number set as the destination address.
Go to step 3 on page 185.

You can display the ring time for missed calls. Even if you
have set “Missed calls display” of “Ring time” to “Not display”,
the missed calls which stopped ringing within the ring start
time and their ring times are displayed.

Calls, Sent Address, and Received Address. (See “Dialed/
recv. calls” on page 118)

See page 169.

See page 169.

Delete selected 1Put a check mark for redial items, dialed call records, or

Delete all 1Enter your Terminal Security Code1YES

<Store in P-Talk PB>

≥You cannot store from the call record for the party who is not stored in the Phonebook.

<Store P-Talk group>
≥You cannot store in a PushTalk group unless all the members are stored in the FOMA

terminal’s Phonebook.

<Delete>
≥If you execute “Delete all” from the Function menu of Redial/Dialed Calls, all records

in both Redial and Dialed Calls are deleted. Even if you execute “Delete this” or
“Delete selected” of Redial, the records are not deleted from Dialed Calls and they are
retained. To delete the dialed call records, delete them from the Function menu while
“Dialed calls” is displayed.

received call records to be deleted1l()1YES

<Chaku-moji>

Using Chaku-moji

When making a voice call or videophone call, you can send your text
message to tell the subject during calling.

≥For details on Chaku-moji or compatible models, refer to DOCOMO website or “Mobile

Phone User’s Guide [Network Services]”.

≥The sending end is charged, but the receiving end is not charged.

When a message is received

A Chaku-moji message is displayed below a caller. The
Chaku-moji message is stored in Received Calls as well.
≥The Chaku-moji message is displayed only during ringing. It

is not displayed during a call.

≥Even when a Chaku-moji message comes in within the ring

start time set by “Ring time”, it is received and recorded in
Received Calls.

≥The Chaku-moji message is not displayed during Lock All, Omakase Lock, or Personal

Data Lock. However, you can check the Chaku-moji message from Received Calls
after the lock is released.

54

Store Messages

Information

You can store up to 10 Chaku-moji messages in the Message list.

m1Set./Service1NW services1Chaku-moji

1

1Create message
1Highlight <Not stored> and press l()
1Enter a message.

≥To edit a stored message, highlight it and press l().
≥You can enter up to 10 characters regardless of whether they are pictograms,

symbols, or full-pitch/half-pitch characters.

Make a Call with a Message

Enter a phone number

1

or

call up the detailed display of a Phonebook entry, redial
item, dialed call record, or received call record.

i

()

1

Chaku-moji1Do the following operations.

2

Create message You can create a Chaku-moji message just before dialing.

Select message From the Message list, you can select a stored message.

Sent messages From the Sent Message list, you can select a Chaku-moji

Press d or Oo().

3

≥Press l( ) to make a videophone call.
≥The Chaku-moji message being sent is displayed while you are dialing.

1Enter a message.

≥You can enter up to 10 characters regardless of whether they

are pictograms, symbols, or full-pitch/half-pitch characters.

≥The Chaku-moji message created using this function is not

stored in the Message list.

1Select a message.

message to be sent. Up to 10 sent Chaku-moji messages only
are stored in the Sent Message list. If you send the same
Chaku-moji message, the older one also remains. When the
number of sent Chaku-moji messages exceeds 10, the
messages are deleted from the oldest one.

1Select a sent message.

≥When a Chaku-moji message has arrived at the other party’s phone, “Transmission

completed” is displayed, and you are charged a transmission fee.

≥When a Chaku-moji message does not arrive at the other party’s phone such as when

the other party’s phone is not a Chaku-moji compatible mobile phone or the call is not
allowed by “Message disp. settings” at the receiving end, “Transmission failed” is
displayed. In this case, you are not charged a transmission fee.

≥Depending on the radio wave conditions, the transmission result may not be

displayed at the sending end even if a Chaku-moji message has arrived at the other
party’s phone. In this case, you are charged a transmission fee.

≥Even if you make a call sending a Chaku-moji message, the Chaku-moji message is

not displayed and you are not charged a transmission fee (the call is not recorded in
Received Calls at the receiving end) when the other party’s phone is out of the service
area, turned off, during Public mode (Drive mode), or the ring time for Record
Message Setting is set to 0 seconds. Also, the transmission result is not displayed at
the sending end.

≥When a videophone call is not connected and automatically dialed as a voice call, the

Chaku-moji message is resent as well.

≥Chaku-moji does not support PushTalk.
≥You cannot send/receive Chaku-moji messages overseas.

Sent Messages

Up to 10 sent Chaku-moji messages are stored in Sent Messages, and
you can check for the other party’s phone number and the date/time the
Chaku-moji messages were sent. Older messages sent to the same
phone number are also retained.

≥In Dual Mode of 2in1, up to 10 latest records for Number A and Number B can be

displayed in total.

m1Set./Service1NW services

1

1Chaku-moji1Sent messages

. . . . Chaku-moji message successfully sent

. . . . Chaku-moji message unsuccessfully sent

. . . . . . . Chaku-moji message for Number B (only in Dual Mode of 2in1)

≥When the transmission result is not displayed, “ ” or “ ” is not

displayed.

≥Depending on the radio wave conditions, the transmission result might not be

displayed correctly.

55

Voice/Videophone Calls/PushTalk

Select a sent message.

Information

2

≥When the other party’s phone number is stored in the

Phonebook, the phone number, name, and icon are
displayed.

Function Menu while “Sent Messages” is Displayed

Store You can store a sent Chaku-moji message in the Message list.

Delete this 1YES

Delete all 1Enter your Terminal Security Code1YES

Message Display Settings

You can set how incoming Chaku-moji messages are displayed.

m1Set./Service1NW services1Chaku-moji

1

1Message disp. settings1Select an item.

Voice/Videophone Calls/PushTalk

Display all messages . . . . Displays Chaku-moji messages from all callers.

Numbers stored in PB . . .Displays Chaku-moji messages only from the callers

Calls with callerID. . . . . . .Displays Chaku-moji messages only from the caller

Hide all messages. . . . . . .Does not display Chaku-moji messages.

≥When you set to “Numbers stored in PB”, you cannot receive Chaku-moji messages

from the callers stored in the Phonebook B in A Mode of 2in1 (and vice versa).

1<Not stored>

≥You can store also by pressing l().

stored in the Phonebook.

notifying his/her phone number.

Prefer Chaku-moji

You can set how your FOMA terminal works for incoming Chaku-moji
messages for when “Setting when opened” is set to “Answer”.

m1Set./Service1NW services1Chaku-moji

1

1Prefer Chaku-moji1ON or OFF

ON . . . . Does not answer by opening the FOMA terminal during ringing, so you

can check a Chaku-moji message.

OFF . . . Answers by opening the FOMA terminal while it is ringing.

<186/184>

Setting Caller ID to Send/Not to Send for Each Call

Set Caller ID Notification when Making a Call

Each time you dial out, you can set whether to notify your caller ID.

Enter a phone number

1

or

call up the detailed display of a Phonebook entry, redial
item, dialed call record, or received call record.

i()1Notify caller ID

2

1Don’t notify or Notify caller

≥To release “Notify caller ID”, select “Cancel prefix”. Whether to notify or not

follows the setting for “Activate/Deactivate” of “Caller ID notification”.

Set “Notify/Not Notify” by Entering “186/184”

You can select whether to notify the other party of your phone number
also by entering “186”/“184” before the other party’s phone number.

56

To notify your caller ID

Information

Information

186→Destination phone number1d or Oo()

1

≥Press l( ) to make a videophone call.

Not to notify your caller ID

184→Destination phone number1d or Oo()

1

≥Press l( ) to make a videophone call.

≥When you make a call and hear the guidance requesting your caller ID (see

page 438), follow the steps of “To notify your caller ID” to enter “186” and redial.

≥When you make a PushTalk call, “Notify caller ID” is valid, but “notify/not notify” by

adding “186”/ “184” is invalid.

≥You cannot set “Caller ID notification” while “ ” is displayed.

<Pause Dial>

+m-8-4

Sending Touch-tone Signals

You can send touch-tone signals from your FOMA terminal to use

services such as reserving tickets, checking bank balance, etc.

Store Pause Dial

You need to store a number string to be sent as a touch-tone signal in the

Pause Dial list. If you have inserted a pause (p), you can send a number

string breaking at the point where the pause is inserted.

m1Set./Service1

1

1l

()

≥When a number string is already stored, it is displayed.
≥To delete a stored pause dial, press i( ) and select “Delete”, then select

“YES”.

Other settings1Pause dial

Enter a number string.

2

≥Enter the pause (p) by pressing and holding a for at least one second.
≥You can use only 0 through 9, s, a to enter a number string and the

pause (p).

≥You can enter up to 128 digits.
≥You cannot enter a pause (p) at the beginning and end of a number string, or

enter it consecutively.

Send Pause Dial

m1Set./Service1

1

1Oo

()

1d

or Oo()

A voice call is made. Once the line is connected, a number string stored in Pause
Dial is displayed up to the first pause (p).
≥When the other party’s phone number is stored in the Phonebook, you can

retrieve it selecting from the Search Phonebook display by pressing Bo.

≥You can search for the phone number also from Received Calls by pressing Co

or from Redial by pressing Vo.

Check that the line is connected1d or Oo()

2

A number string up to the first pause (p) is sent, and a number string up to the next
pause (p) is displayed.
A number string up to the pause (p) is sent each time you press d or

Oo().

When you have finished sending the last number, the “Talking” display appears.
≥To send multiple pieces of a number string at a time, press and hold Vo for at

least one second, and select “Send at one time”.

≥During a call, you can send a number string also by displaying the Function menu of

the Pause Dial display.

≥Some devices on the receiving end cannot receive signals.
≥You cannot send a number string with pauses during a videophone call.

Other settings1Pause dial

1

Enter a phone number

Voice/Videophone Calls/PushTalk

57

<WORLD CALL>

Making International Calls

WORLD CALL is the international call service available from DOCOMO
mobile phones.
When you have signed up for FOMA service, you have contracted to use
“WORLD CALL” (except those who have applied not to use it).

≥You can make calls to about 240 countries and regions.
≥The WORLD CALL charges are added to your monthly bill for FOMA service.
≥The application/monthly fee is free of charge.
≥The service is not available with some billing plans.
≥Contact “docomo Information Center” on the back page of this manual for inquiries

about WORLD CALL.

≥When using international carriers other than DOCOMO, contact them.
≥The caller ID might not be notified, or might not be displayed correctly depending on

the carrier. In this case, you cannot make a call by using Received Calls.

About international videophone calls

You can make international videophone calls to users of the specified 3G mobile phone
carriers overseas and FOMA users. Press l( ) instead of d or Oo()
in the steps of “Enter a Phone Number to Make an International Call”. (See page 58)
≥For the information about connectable countries and telecommunications carriers, refer

Voice/Videophone Calls/PushTalk

to “Mobile Phone User’s Guide [International Services]” or the DOCOMO International
Services website.

≥Images sent from the other party may blur on your FOMA terminal or you may not be

able to connect, depending on the other party’s phone used for the international
videophone call.

Use “+” to Make an International Call

When you enter a phone number for dialing or storing it in the
Phonebook, press and hold 0 for at least one second to enter “+”. You
can use “+” to make international calls without entering an international
call access code.

≥If you set “Auto assist setting” of “Int’l dial assist” to “ON”, an international call access

code of “IDD prefix setting” is automatically entered.

0(for at least one second)

1

1Enter numbers in order of country/area code

→area code (city code)→destination phone number

1d or Oo()1Dial

≥

When the area code (city code) begins with “0”, enter it except for the “0”. However,
include “0” when making a call to some countries or regions such as Italy.

≥Press l( ) to make an international videophone call.
≥When you select “Dial with orig. No.”, an international call is dialed to the phone

number you entered in the FOMA terminal.

Enter a Phone Number to Make an International Call

Enter numbers in order of 010→country/area code

1

→area code (city code)→destination phone number

1d or Oo()

≥You can make an international call also by entering 009130→010

→country/area code→area code (city code)→destination phone number.

≥

When the area code (city code) begins with “0”, enter it except for the “0”. However,
include “0” when making a call to some countries or regions such as Italy.

≥Press l( ) to make an international videophone call.

58

International Dial Assist

You can make a call adding a country/area code or international call

access code to a phone number. (Except for some countries and regions,

if the phone number starts with “0”, the “0” at the beginning is

automatically deleted.)

Enter a phone number

1

or

call up the detailed display of a Phonebook entry, redial
item, dialed call record, or received call record.

i()1Int’l dial assist

2

1Select a country/area name
1Select a name of International call access code
1d or Oo()

≥Press l( ) to make an international videophone call.
≥When the beginning of the phone number is “+”, the display for selecting a

country/area name is not displayed.

≥When “Japan” is selected as a country/area name, the display for selecting a

name of International call access code is not displayed.

<International Dial Assist>

Setting for International Calls

Auto Assist Setting

You can set whether to replace “+” at the beginning of a phone number

with an international call access code for when you make an international

call from Japan.

m1Set./Service1Network setting1Int’l dial assist

1

1Auto assist setting1ON or OFF
1Select a country/area name
1Select a name of International call access code.

≥When no country/area code or international call access code is stored, the

confirmation display appears asking whether to store it. Select “YES” and go to
step 2 of “Country/Area Code” on page 59 for a country/area code, and go to
step 2 of “IDD Prefix Setting” on page 59 for an international call access code.

Country/Area Code

You can store up to 27 country/area codes to be added for making
international calls from overseas.

m1Set./Service1Network setting1Int’l dial assist

1

1Country/Area Code
1Highlight <Not recorded> and press l().

≥If you select a stored country/area name, you can check the stored contents.

Enter a country/area name 1Enter a country/area code.

2

≥You can enter a country/area name of up to 8 full-pitch/16 half-pitch characters.
≥You can enter a country/area code of up to 5 digits. But you cannot use #, :, and

+.

IDD Prefix Setting

You can store up to three international call access codes to be added to
the beginning of a phone number for making an international call.

m1Set./Service1Network setting1Int’l dial assist

1

1IDD prefix setting
1Highlight <Not recorded> and press l().

≥If you select the stored item, you can check the stored contents.

Enter a name1Enter an international call access code.

2

≥You can enter a name of up to 8 full-pitch/16 half-pitch characters.
≥You can enter an international call access code of up to 16 digits.

Function Menu while Country/Area Code /IDD Prefix
Setting is Displayed

Edit Go to step 2 of “Country/Area Code” on page 59 for Country/Area

Delete this 1YES

Code, and go to step 2 of “IDD Prefix Setting” on page 59 for IDD
Prefix Setting.
≥You can edit the item also by pressing l().

59

Voice/Videophone Calls/PushTalk

Delete all 1Enter your Terminal Security Code1YES

Information

Information

<Delete this> <Delete all>

≥You cannot delete the country/area code or international call access code set by

“Auto assist setting”.

<Prefix Setting>

Storing Numbers to be Added to the Beginning of a Phone Number

You can store prefix numbers such as international call access codes or
“186”/“184” and add them to the phone number for dialing. You can store
up to seven prefix numbers.

m1Set./Service1Network setting1Prefix setting

1

1Highlight <Not recorded> and press l().

≥If you select a stored prefix, you can check the stored contents.
≥To delete a stored prefix, press i( ) and select “Delete this” or “Delete

all” then select “YES”. If you select “Delete all”, you need to enter your Terminal
Security Code.

Enter a name1Enter a prefix number.

Voice/Videophone Calls/PushTalk

2

≥You can enter a name of up to 8 full-pitch/16 half-pitch characters.
≥You can enter a prefix number of up to 16 digits. The keys for entry are limited to

0 through 9, s and a.

Prefix Numbers

You can add a prefix number to the beginning of phone number when
you make a call.

Enter a phone number

1

or

call up the detailed display of a Phonebook entry, redial
item, dialed call record, or received call record.

i()1Prefix numbers1Select a name

2

1d or Oo()

≥Press l( ) to make a videophone call and press p to make a PushTalk

call.

≥For making a PushTalk call, adding a prefix number such as “186” or “184” to the

beginning of the phone number is disabled.

<Sub-address Setting>

Making a Call Specifying a Sub-address

You can set whether to regard the numbers after “:” of a phone number
as a sub-address to access the specified phones or data terminals.

≥The sub-address is a number assigned to identify each ISDN terminal connected to an

ISDN line. It is also used for selecting contents on “V-live”.

m1Set./Service1Other settings

1

1Sub-address setting1ON or OFF

≥Even if you set “Sub-address setting” to “ON”, “:” at the top of phone numbers and

“:” immediately after the prefix number or “186”/“184” are not regarded as
sub-address mark-off symbols.

<Reconnect Signal>

+m-7-7

Setting Alarm for Reconnecting

You can set an alarm that sounds until a voice call, videophone call, or
PushTalk communication is reconnected after disconnected owing to
bad radio wave conditions.

m1Set./Service1Talk1Reconnect signal

1

1Select an alarm.

60

Information

≥

Information

Information

The reconnectable time differs depending on the usage status and radio wave conditions.
An estimate is about 10 seconds and the call charge is applied also for that duration.

≥While you are disconnected, no sound is transmitted to the other party.

<Shikkari Talk>

Making Voice Clear According to Surrounding Noise

The volume of the other party’s voice is turned up according to the

surrounding noise during a call. This setting is effective only when the

other party’s voice is output from the earpiece.

m1Set./Service1Talk1Shikkari Talk1ON or OFF

1

<Noise Reduction>

Reducing Surrounding Noise to Make Voice Clear

The noise sent to the other party is reduced according to the surrounding

noise during a call.

m1Set./Service1Talk1Noise reduction1ON or OFF

1

<Yuttari Talk>

Slowing Down the Other Party’s Speaking Speed

During a voice call1m()

1

While Yuttari Talk is activated, “Yuttari Talk ” is displayed.

≥Press m( ) again to return to the normal speed.

≥Yuttari Talk is effective only during a current voice call. The speaking speed returns to

normal one when you end the call, switch calling parties during Multi calling, or switch
from the voice call to a videophone call.

+m-7-6

<Hands-free>

Switching to Hands-free

When you switch to Hands-free, sound such as the other party’s voice is
audible over the speaker.

During a call, dialing, or connecting1d

1

When Hands-free is activated, “ ” is displayed.

≥Press d again to deactivate Hands-free.
≥The sound volume during a Hands-free call follows the setting specified by

“Volume” (earpiece volume).

≥You can switch to Hands-free even during Manner Mode. Also, you will still hear

voice through the speaker even when you activate Manner Mode during a
Hands-free call.

≥While an earphone/microphone (option) is connected, you cannot hear voice through

the speaker even if you switch to Hands-free.

≥Keep the FOMA terminal well away from your ear during a Hands-free call. Otherwise

you could affect or damage your hearing.

≥Talk into the FOMA terminal within a distance of about 50 cm.

<In-Car Hands-free>

Using Hands-free Compatible Devices

You can make or receive voice calls from a Hands-free compatible device
such as In-Car Hands-Free Kit 01 (option) or a car navigation system by
connecting with your FOMA terminal.
You can connect your FOMA terminal to a Hands-free compatible device
using two ways of connections as follows:

≥Connect using a cable (USB connection):

To use/charge via the In-Car Hands-Free Kit 01 (option), you need to have the FOMA
In-Car Hands-Free Cable 01 (option).

≥Connect using Bluetooth (wireless):

To connect to a Bluetooth communication compatible Hands-free device, you need to
register and connect it to the FOMA terminal.

※For how to operate Hands-free compatible devices, refer to the respective instruction

manuals.

61

Voice/Videophone Calls/PushTalk

Information

≥To connect using a cable (USB connection), set “USB mode setting” to

Chaku-moji message

(See page 54)

Information

“Communication mode”.

≥“ ” appears while you are talking or communicating using a USB Hands-free

compatible device.

≥“ ” might appear while the FOMA terminal is connected to a USB Hands-free

compatible device, and “ ” while “USB mode setting” is set to “microSD mode”,
depending on the Hands-free device connected.

≥The display or ring tone for incoming calls follows the settings of the FOMA terminal.
≥When the sound is set to output from a Hands-free compatible device, the ring tone

sounds from that device even when Manner Mode is activated or “Ring volume” of the
FOMA terminal is set to “Silent”.

≥The receiving operation in Public mode (Drive mode) follows the setting of “Public

(Drive) mode”.

≥The receiving operation while Record Message is activated follows the setting of

“Record message setting”.

≥When the sound is set to output from the FOMA terminal, the operation for when the

FOMA terminal is closed during a call follows the setting of “Setting when closed”.
When the sound is set to output from a Hands-free device, the communication state
does not change regardless of “Setting when closed” even if you close the FOMA
terminal.

Voice/Videophone Calls/PushTalk

Receiving a Call/Videophone Call

When you receive a call, the ring tone

1

sounds and the Call/Charging indicator
flickers.

≥To vibrate the FOMA terminal for incoming calls, set

“Phone” or “Videophone” of “Vibrator” to other than
“OFF”.

≥While the phone is ringing for a videophone call,

“Incoming V.phone” is displayed. However, while
ringing for a voice call, this kind of indication is not
displayed.

≥“ ” is displayed at the upper left of the phone

number for incoming international calls.

For Answering a Voice Call

2

Press d or Oo( ) to answer
the call.

For Answering a Videophone Call

Press d or Oo( ) to answer
the videophone call.

The image through your camera is sent to the other party.
When you press m( ) to answer the videophone
call, the substitute image is sent to the other party.
(Substitute image answering)
≥Press m during a videophone call to switch between

the image through your camera and substitute image
for sending to the other party.

Press h to end the call after talking.

3

≥If you close the FOMA terminal during a call, the FOMA terminal works in accordance

with the setting of “Setting when closed”. (See page 65)

62

≥You might hear beeps (in-call ring tone) during a call.

Information

If you have signed up for any of Voice Mail Service, Call Waiting Service, or Call
Forwarding Service and set “Arrival call act” to “Answer”, the beeps (in-call ring tone)
will sound for another incoming call, enabling you to do the following operations:
Voice Mail Service

. . . . Transfer the call to the Voice Mail Service Center. (See page 434)

Call Waiting Service

. . . . Put your current call on hold and answer the incoming call. (See page 434)

Call Forwarding Service

. . . . Transfer the call to the registered forwarding destination. (See page 437)

≥You can set “Reject unknown” not to accept calls from the phone numbers that are not

stored in the Phonebook.

<For Videophone Calls>

≥Just after purchase, Hands-free is automatically activated during a videophone call as

“Hands-free w/ V. phone” has been set to “ON” (see page 75). However, Hands-free
is deactivated during Manner Mode regardless of “Hands-free w/ V. phone”.

≥Even if Call Forwarding Service is set to “Activate”, the call is not forwarded unless the

forwarding destination is a phone compatible with the videophone conforming to
3G-324M (see page 48). Check the phone you are forwarding the call to and then
activate the service. The videophone caller does not hear the guidance to the effect
that the call is forwarded. (The message to the effect that the call is to be forwarded
appears, depending on the receiver’s FOMA terminal.)

≥If a videophone call comes in from the phone number to be rejected by Nuisance Call

Blocking Service, the video guidance for Call Rejection is played back and the call is
disconnected.

≥You can send a Chara-den image to the other party instead of the image through your

camera. (See page 72)

Display for incoming calls

When a caller’s phone number is provided

The phone number is displayed. If that phone number is not stored in the Phonebook but
recorded in Redial, “Callback” is displayed.
If the caller’s name, phone number, and image are stored in the Phonebook, the name,
phone number, and icon (or image) are displayed.

≥“Callback” is not displayed for incoming videophone calls and PushTalk calls.
≥If the same phone number is stored with multiple names in the Phonebook, the name

that comes first in the search order (see page 94) is displayed.

≥The phone number but not the name is displayed during Personal Data Lock.

However, when “Phonebook available” is set to “Accept” for “Customize” of Personal
Data Lock, the name is displayed even during Personal Data Lock.

≥For a forwarded call, the forwarder’s phone number is displayed below the caller. (It

might not be displayed in the case of some forwarders.)

≥When you receive a call to an additional number of Multi Number, the stored name for

the additional number is displayed below the caller. (With a forwarded call, you can
press c( ) to switch to display of the forwarder.)

When a caller’s phone number is not provided

The reason for no caller ID is displayed. (See page 135)

Function Menu while a Call is Ringing

Call rejection You can disconnect the call without answering.

Call forwarding See page 437.

Voice mail See page 434.

Voice/Videophone Calls/PushTalk

63

Switched between a Call and a Videophone Call by the Other Party

When you have set “Notify switchable mode” to “Indication ON”, a caller
(the other party) can switch between a voice call and a videophone call.

≥You (receiving end) cannot switch between a voice call and a videophone call.

Switched from a Voice Call to Videophone Call by the
Other Party

The display for switching to a

1

videophone call appears during a voice
call.

YES . . . Sends the image through your camera to the

caller.

NO . . . . Sends a pre-installed substitute image to the

caller.

≥While switching, the message to that effect is displayed

and the voice guidance is played back.

Switched from a Videophone Call to Voice Call by the

Voice/Videophone Calls/PushTalk

Other Party

When the caller (the other party) switches a videophone call to a voice
call, the message telling that the call is being switched appears, the voice
guidance is played back, and then the call is switched to a voice call.

<Answer Setting>

+m-5-8

Setting Response of Key Operation for Answering Incoming Calls

You can set to start talking (Any key answer) or to stop the ring tone
(Quick silent) by pressing a key besides d, Oo, m (for videophone
call), or p (for PushTalk call) for when a call or PushTalk call comes in.

m1Set./Service1Incoming call1Answer setting

1

1Select a key operation.

Any key answer

You can start talking by pressing any key shown below:

※1※2

Voice call

PushTalk call

≥When receiving a videophone call, you can start talking by pressing d, Oo or

m.

Quick silent

The following are the keys you can press to stop the ring tone, vibrator or voice
guidance:
When “Setting when opened” is set to “Keep ringing”, you can stop the ring tone,
vibrator or voice guidance also by opening the FOMA terminal. Even if you stop it,
the other party still hears a ringback tone.

※1※2

Voice call

Videophone call

PushTalk call

≥After you stop the ring tone, vibrator or voice guidance, you can start talking by

pressing d, Oo, m (for videophone calls), or p (for PushTalk calls).

d, Oo, 0 through 9, a, s, r, m, c※3,

No, <

d, Oo, p, 0 through 9, a, r, l, c, Bo,
<

0 through 9, a, s, r, m, c※3, No, <

※1※2

0 through 9, a, s, r, c※3, No, <
0 through 9, a, r, l, c, Bo, <

64

OFF

Information

Information

You can start talking by pressing a key shown below:

Voice call
Videophone call d, Oo, m

PushTalk call

※1 You can activate Any Key Answer or Quick Silent also by pressing l when

record messages have been recorded to the maximum.

※2 During Key Lock, you can activate Any Key Answer and Quick Silent by

pressing and holding < for at least one second.

※3 While “ ” is displayed, you cannot activate Any Key Answer or Quick

Silent by pressing c.

≥While an earphone/microphone (option) is connected, you can press the switch to

start talking, regardless of “Answer setting”. (See page 411)

<Setting when Opened>

d, Oo

d, Oo, p

Setting Response for when Opening FOMA Terminal while Ringing

m1Set./Service1Incoming call

1

1Setting when opened1Select an incoming type
1Keep ringing or Answer

Keep ringing. . . You can keep the incoming call ringing.

Answer . . . . . . . You can answer the incoming call. For videophone calls, the still

image set for “Substitute image” of “Select image” is sent to the
other party.

<Setting when Closed>

+m-1-8

Setting Response for when Closing FOMA Terminal during a Call

Set Response for when Closing FOMA Terminal during a
Voice Call/Videophone Call

m1Set./Service1Talk1Setting when closed

1

1Phone/Videophone1Select an item.

Continue . . . . . .The call is continued. The setting is completed.

Hold . . . . . . . . . .The other party hears the hold tone set for “Holding tone” of “Hold

End the call. . . . The call is finished. This is the same operation as pressing h

Speaker ON or Speaker OFF

2

Speaker ON. . . . . The hold tone sounds from the speaker.

Speaker OFF. . . . The hold tone does not sound from the speaker.

Set Response for when Closing FOMA Terminal during
PushTalk

m1Set./Service1Talk1Setting when closed

1

1PushTalk1Speaker call or End the call

≥This function is disabled when an earphone/microphone (option) is connected. The

communication state does not change even if you close the FOMA terminal.

tone setting”. For videophone calls, the still image set for
“Holding” of “Select image” is displayed.

during a call. The setting is completed.

Voice/Videophone Calls/PushTalk

65

<Volume>

Information

Adjusting Earpiece Volume

m1Set./Service1Talk1Volume

1

1Use Bo or </> to adjust the earpiece volume.

Adjust the earpiece volume to Level 1 (minimum) through Level 6 (maximum).
≥You can adjust the volume by pressing Zo or </> during a voice call and

calling, Bo or </> during a videophone call and PushTalk call, and by
pressing and holding Zo (for at least one second) while you are entering a
phone number. Press Bo or </> within two seconds to adjust it.

≥The earpiece volume adjusted during a call is retained even after the call ends.
≥When you adjust the earpiece volume, the sound volume during a Hands-free call or

speaker call for PushTalk is also adjusted.

Voice/Videophone Calls/PushTalk

<Ring Volume>

Adjusting Ring Volume

You can adjust the ring volume for incoming calls and mail.

m1Set./Service1Sound1Ring volume

1

1Select an incoming type
1Use Bo to adjust the volume.

≥The following icons are displayed on the Stand-by display while “Ring volume” is

set to “Silent”:

: Set for “Phone”, “PushTalk”, or “Videophone”.

: Set for “Mail”, “Chat mail”, “MessageR”, “MessageF”, or “i-concier”.

: Set for “Phone”, “PushTalk”, or “Videophone”, and for “Mail”, “Chat mail”,

“MessageR”, “MessageF”, or “i-concier”.

≥If you have set “Step”, the ring tone is silent for about three seconds, and then the

volume steps up every three seconds, from Level 1 through Level 6.

≥While the phone is ringing for a voice call or videophone call, you can adjust the

ring volume by pressing Bo. However, you cannot adjust the ring volume in the
following cases:

・When “Ring volume” is set to “Step”
・When “Answer setting” is set to “Quick silent” and you stop the ring tone or

voice guidance

・During Manner Mode
・When a call is cut off within the ring start time specified by “Ring time”

+m-5-0

66

<On Hold>

Information

Information

Putting a Call on Hold when You cannot Answer Immediately

During ringing1h

1

The FOMA terminal makes three rapid beeps for confirmation and the call is put on
answer-hold (On Hold).
≥The confirmation tone does not sound during Manner Mode or when “Ring

volume” is “Silent”.

≥The other party hears the hold tone set for “On hold tone” of “Hold tone setting”.

For videophone calls, the still image set for “On hold” of “Select image” is
displayed.

Press d or Oo( ) to release hold and answer

2

the call.

≥If “Answer setting” is set to “Any key answer”, you can release hold of voice calls

by pressing any key of 0 through 9, a, s, r, m, c, Mo, <, >,
l, or i.

≥If a videophone call is on hold, the image through your camera is sent to the other

party when you press d or Oo( ) to release hold. If you press
m( ) to release hold, the substitute image is sent.

≥The caller is charged for the call even during answer-hold (On Hold).
≥If you press -h during answer-hold (On Hold), the call will be disconnected.

<Holding>

Putting a Call on Hold during a Call

During a call1Oo ()

1

≥The other party hears the hold tone set for “Holding tone” of “Hold tone setting”.

For videophone calls, the still image set for “Holding” of “Select image” is
displayed.

≥You can put the call on hold by closing the FOMA terminal during the call if you

have set “Setting when closed” to “Hold”.

Press d or Oo( ) to release hold and answer

2

the call.

≥When you have put a voice call on hold, you can release the hold also by

pressing r.

≥If a videophone call is on hold, the image through your camera is sent to the other

party when you press d or Oo( ) to release hold. If you press
m( ) to release hold, the substitute image is sent.

≥You can release hold also by opening the FOMA terminal.

≥The caller is charged for the call even while the call is on hold.
≥If a new call comes in while the current call is put on hold, the hold (Holding) is

released.

<Hold Tone Setting>

Setting Hold Tone

You can set the guidance the other party hears while a call is put on hold.

m1Set./Service1Talk1Hold tone setting

1

1On hold tone or Holding tone1Select a hold tone.

Tone 1/2 . . The caller hears the pre-installed guidance in Japanese.
RHAPSODY ON A THEME OF

. . . . . . . . . . The caller hears the melody. You can set this for “Holding tone” only.

Voice announce

. . . . . . . . . . The caller hears the sound recorded by “Voice announce”. If it has

≥Press l( ) to play back a hold tone. Press r to end the demo

not been recorded, this is not displayed.

playback.

Voice/Videophone Calls/PushTalk

67

Using Public Mode

Information

Using Public Mode (Drive Mode)

Public mode is an auto-answer service that puts importance on manners
in public spaces. Once you activate Public mode, the guidance is played
back telling that you cannot answer the call as you are currently driving
or in a place where you should refrain from speaking on the phone (a
train, bus, movie theater, etc.). Then the call is disconnected.

≥Voice Mail Service※1, Call Forwarding Service※1, and Caller ID Display Request

Service※2 work taking priority over Public mode.
※1 If a ring time is set to other than 0 seconds for incoming calls, the service works

after the Public mode guidance.

※2 When the other party notifies you of the phone number, Public mode works.

≥Public mode does not work to the calls from the party set to be rejected by Nuisance

Call Blocking Service.

Press and hold a for at least one second.

1

Public mode is activated and “ ” is displayed.
When a call comes in, the guidance “The person you are calling is currently driving
or in an area where cell phone should n ot be used. Please try again later.” is played
back for incoming calls.
≥To deactivate Public mode, perform the same operation. Then, Public mode is

Voice/Videophone Calls/PushTalk

deactivated and “ ” disappears.

≥You can activate/deactivate Public mode only from the Stand-by display. You can

activate/deactivate Public mode even when “ ” is displayed.

≥You can make calls as usual even during Public mode.
≥If you make an emergency call at 110/119/118, Public mode is released.
≥When Public mode and Manner Mode are activated simultaneously, Public mode has

priority.

≥If a “User unset” call comes in while “Caller ID request” is set to “Activate”, the Caller

ID Request guidance is played back. (The Public mode guidance is not played back.)

≥You cannot use this function during data communication.

When Public mode (Drive mode) is activated

・Even when a call comes in, the ring tone does not sound. The “Missed call” icon

appears on the display and the call is stored in “Received calls”. The guidance is
played back to the caller to the effect that you are currently driving or in an area where
mobile phones should not be used. Then the call is disconnected. When a PushTalk
call comes in, no answer is made and the message “Connection failed” appears on the
caller’s display. For the talk among three or more members, the message to the effect
that you are driving is conveyed to them.
However, when the power is off or “ ” is displayed, the caller hears the
out-of-service area guidance instead of the Public mode guidance.

・The ring tone does not sound and the Call/Charging indicator does not flicker even

when mail or a message comes in. In addition, the set vibrator does not work.

・The ring tone for 64K data communication, alarm tone, charging confirmation tone, the

ring tone for i-αppli call and effect tone at the start of i-Widget do not sound, and a
melody while an i-αppli program is running is not played back.

・The tickers of i-Channel are not displayed.
・See page 68 for how Public mode (Drive mode) and each network service work for

incoming calls when they are simultaneously activated.

Using Public Mode (Power Off)

Public mode (Power off) is an auto-answer service that puts importance
on manners in public spaces. Once you activate Public mode (Power off),
the guidance is played back telling that you cannot answer the call as
you are currently in a place where the power should be turned off
(hospital, airplane, around priority seat in a train, etc.). Then the call is
disconnected.

Enter “:25251”1d

1

Public mode (Power off) is set. (Nothing is changed on the Stand-by display.)
After setting Public mode (Power off) and turning off the power, the guidance “The
person you are calling is currently in an area where use is prohibited. Please try
again later.” is played back for incoming calls.

≥To release Public mode (Power off), dial “:25250”.
≥To check the setting for Public mode (Power off), dial “:25259”.

68

When Public mode (Power off) is activated

Notification icon

The setting stays activated until you dial “:25250” to deactivate Public mode (Power

off). You cannot deactivate the setting just by turning on the power.

The guidance is played back to the caller telling that you are currently in a place where

you should turn off the power. Then the call is disconnected. When a PushTalk call

comes in, no answer is made and the message “Connection failed” appears on the

caller’s display. For the talk among three or more members, the message to the effect

that you do not participate is conveyed to them.

The Public mode (Power off) guidance is played back even when you are out of the

service area or out of reach of radio waves.

・See page 68 for how Public mode (Power off) and each network service work for

incoming calls when they are simultaneously activated.

<Missed Calls>

When You could not Answer an Incoming Call

When you could not answer calls (Missed calls), the “Notification icon”

appears on the Stand-by display. You can check Received Calls by

selecting the icon.

Oo1Oo()

1

≥Press h or r to return

to the former display.

≥When multiple icons are

found, use Mo to highlight
an icon and press

Oo().

<Record Message Setting>

+m-5-5

Recording Voice/Video Messages when You cannot Answer a Call

By activating Record Message, you can play back an answer message to
incoming calls and record callers’ voice/video messages when you
cannot answer them even if you have not signed up for Voice Mail
Service.
You can record up to five messages for voice calls and up to two
messages for videophone calls. Each message can be recorded for up to
20 seconds.

Activate Record Message

m1LifeKit1Rec. msg/voice memo

1

1Record message setting1ON or OFF
1Select an answer message.

≥Press l( ) to play back the answer message. Press r to end the

demo playback.

≥When “Japanese 1”, “Japanese 2”, or “English” is set, a beep sounds after

playing back the answer message to the other party. If “Voice announce” is set,
the beep does not sound.

Enter a ring time (seconds).

2

≥Enter from “000” through “120” in three digits.
≥You cannot set the same ring time for Remote Monitoring, Auto Answer Setting

and Record Message Setting. Set a different time for each.

≥While Record Message is activated, “ ”〜“ ” (the number of recorded

messages for voice calls) and “ ”〜“ ” (the number of recorded messages
for videophone calls) are displayed.

Voice/Videophone Calls/PushTalk

69

Incoming calls when Record Message Setting is set to “ON”

Incoming Call Playing back the

answer message

Recording a voice/

video message

The ring time

elapses

Displaying an icon on the

desktop (See page 29)

Information

Information

For videophone calls, the still image set for “Preparing” of
“Select image” is displayed on the other party’s display while
playing back the answer message, and the still image set for
“Record message” of “Select image” is displayed while
recording.
≥To answer a call while the answer message is being played

back or a voice/video message is being recorded, press
d or Oo().
For videophone calls, press d or Oo( ) to send

Voice/Videophone Calls/PushTalk

the image through your camera, or press m( ) to
send a substitute image.
You can answer a call also by pressing the switch on an
earphone/microphone (option). For videophone calls, the image through your camera
is sent to the other party.

≥Record Message does not work when “ ” is displayed.
≥When Public mode (Drive mode) and Record Message are simultaneously activated,

the former has priority and the latter does not work.

≥The priority order of answer messages is as follows: “Setting for Phonebook entry” →

“Group setting” → “Record message setting”.

≥If “Voice announce” selected as an answer message is deleted, the answer message

will be set to “Japanese 1”.

≥When Voice Mail Service or Call Forwarding Service is set at the same time as

Record Message, the priority depends on the ring time set for Voice Mail Service or
Call Forwarding Service. To give Record Message priority, set the ring time for
Record Message Setting shorter than that for Voice Mail Service or Call Forwarding
Service. Even when you do this, Voice Mail Service or Call Forwarding Service works
when record messages have been recorded to the maximum.

≥You cannot receive a call from a third party while a voice/video message is being

recorded. The third party will hear the busy tone.

<Quick Record Message>

Recording a Message when You cannot Answer an Incoming Call

Even if a call comes in while Record Message is not activated, you can
record the caller’s voice/video message just for that incoming call.

During ringing1l() or >

1

The caller will hear the answer message and then can leave you a voice/video
message.

≥During Key Lock, press and hold > for at least one second.
≥Record Message does not work when five messages for voice calls and two

messages for videophone calls have already been recorded. Also if you press >
while a PushTalk call is arriving, Record Message does not work and Manner
Mode is set.

70

<Play/Erase Messages>

Record Message list

Videophone Record

Message list

<Play/Erase Videophone Messages>

+m-5-5

Playing/Erasing Record Messages/a Voice Memo/Videophone Record Messages/ Movie Memos

Play Back/Erase Record Messages/a Voice Memo

m1LifeKit1Rec. msg/voice memo

1

1Play/Erase msg.
1Select a record message or voice

memo.

A beep sounds and playback starts.

≥On the Record Message list, recorded items are indicated by “★”.
≥It is played back at the volume set for “Volume” (earpiece volume).
≥When playback ends, a double-beep sounds and the message “Playing” is

cleared from the display.

≥The date and time the message/memo was recorded are displayed during

playback.

≥When a caller’s phone number is provided, it is displayed during playback of the

record message. If the caller is stored in the Phonebook, his/her name is also
displayed.
However, the name is not displayed and the phone number only is displayed in
the following cases:

・When you play back a record message from the caller stored as secret data in

Normal Mode

・When you play back a record message for Number A in B Mode (or vice versa)

while using 2in1

≥If the caller’s phone number is displayed during playback of a record message,

you can make a voice call to that phone number by pressing d. Press
l( ) to make a videophone call and press p to make a PushTalk call.

To play back using .>

From the Stand-by display, press > to play back the latest record message. When

record messages are not recorded, a voice memo is played back.

To skip to next message

Each time you press > during playback, messages are played back in the following
order: the next new record message → the oldest record message → a voice memo.

To cancel playback midway

Press Oo() or r.

Play Back/Erase Videophone Record Messages/Movie Memos

m1LifeKit1Rec. msg/voice memo

1

1Play/Erase VP msg.
1Select a videophone record message

or movie memo.

≥On the Videophone Record Message list, recorded

items are indicated by “★”.

≥It is played back at the same volume of the playback

sound of i-motion files.

≥The date and time the message/memo was recorded are displayed during

playback.

To play back using .>

From the Stand-by display, press and hold > for at least one second to play back the
latest videophone record message. When videophone record messages are not
recorded, the latest movie memo is played back.

To cancel playback midway

Press Oo() or r.

Function Menu of the Record Message List/Videophone
Record Message List

Play You can play back the message.

Erase this 1YES

≥You can erase the message/memo also by pressing

i( ) during playback.

Voice/Videophone Calls/PushTalk

71

Erase rec. msg. You can erase all record messages from the Record Message

Information

At videophone

start-up

Whole Action

Mode

Erase movie memo

[Videophone Record
Message list only]

Erase all You can erase all record messages and a voice memo from the

list, and can erase all videophone record messages from the
Videophone Record Message list.

1YES

You can erase all movie memos.

1YES

Record Message list, and can erase all videophone record
messages and movie memos from the Videophone Record
Message list.

1YES

Using Chara-den

You can set up for sending a Chara-den image to the other party.

≥See page 353 for Chara-den images.

Set by Call

You can set a Chara-den image to be sent to the other party for making a
videophone call.

Voice/Videophone Calls/PushTalk

Chara-den display/Chara-den list1l()

1

Enter the destination phone number and press l( ) to make a
videophone call.
≥When the other party’s phone number is stored in the Phonebook, you can

retrieve it selecting from the Search Phonebook display by pressing Bo.

≥You can search for the phone number also from Received Calls by pressing Co

or from Redial by pressing Vo.

≥The priority order of substitute images to be sent to the other party is as follows:

“Setting by call” → “Setting for Phonebook entry” →“Group setting” → “Select image”.

Substitute Image

You can set a Chara-den image for “Substitute image” of “Select image”.

Chara-den display/Chara-den list/Chara-den Recording

1

display1i()1Substitute image

≥From the Chara-den list, you can set it also by pressing m().

Chara-den Setup

You can perform settings for a Chara-den call. These settings are
effective only for during a videophone call.

During a Chara-den call1i()

1

1Chara-den setup1Do the following operations.

Switch Chara-den 1Select a Chara-den image.

Action list You can display the list for actions that you can operate.

Change action You can switch the action mode between Whole Action Mode

SW substitute img. You can switch a substitute image to be sent to the other party to

SW orig. subst. img. You can switch a substitute image to be sent to the other party to

≥If you switch Chara-den images, the action mode switches to

Whole Action Mode.

≥Highlight an action and press Oo( ) to execute the

action. Press l( ) to check the details of the action.

≥You can display the Action list also by pressing a.

( ) and Parts Action Mode ( ).
≥You can switch modes also by pressing l.

the still image set for “Pre-installed” of “Select image”.

the still image set for “Original” of “Select image”.

72

Useful Functions for Videophone Calls

Information

+c

c

+cc

Switching Cameras

At videophone start-up Inside camera

You can switch images to be sent to the other party from through the

inside camera to through the outside camera.

During a videophone call1l()

1

≥Press l( ) again to switch to the image through the inside camera.
≥The setting here is effective only for the current videophone call.

Send Substitute Images

You can switch images to be sent to the other party from the image

through your camera to the still image or Chara-den image set as the

substitute image.

See page 353 for Chara-den.

During a videophone call1m()

1

The substitute image is sent to the other party.
“ ” is displayed while the still substitute image is being sent, and “ ” is
displayed if you have set a Chara-den image as a substitute image (during a
Chara-den call).
≥Press m( ) again to switch from the substitute image to the image

through your camera.

≥The priority order of substitute images to be sent to the other party is as follows:

“Setting by call” → “Setting for Phonebook entry” → “Group setting” → “Select image”.
Note that “Setting for Phonebook entry” and “Group setting” are disabled when a
videophone call comes in without notifying the caller ID.

≥Even when you make a videophone call sending a substitute image, you are charged

for the digital communication.

Switch Image Display Positions

You can switch the display locations of the received image and the sent
image.

During a videophone call, press c().

1

≥Each time you press

c( ), the displays
switch.

Voice/Videophone Calls/PushTalk

73

Zoom

At videophone

start-up

OFF

At videophone

start-up

0

At videophone

start-up

Automatic

At videophone

start-up

Normal

At videophone

start-up

OFF

At videophone

start-up

Landscape

At videophone start-up WIDE

You can adjust the magnification for the camera image to be sent to the
other party. During a videophone call, the maximum magnification is about

1.9 times for the inside camera and about 6.9 times for the outside camera.

During a videophone call

1

1Use No to adjust the magnification.

≥The former zoom setting returns when the videophone call ends.

Function Menu during Videophone Call

CHG to voice call See page 51.

Photo light You can turn on the photo light while sending the images

through the outside camera.

1ON or OFF

White balance You can adjust the colors of the camera image to be sent to

Color mode set You can switch the color tone of the camera image to be sent

Night mode You can lengthen the camera’s exposure time to make the

the other party, to make the colors look more natural.

1Select an item.

Fine weather. . . . . . For talking outdoors in fine weather

Cloudy weather . . . For talking in cloudy weather or in the

Automatic. . . . . . . . For adjusting white balance

Light bulb . . . . . . . . For talking under incandescent light

to the other party.

1Select a color tone.

camera image to be sent clear in a dark place.

1ON or OFF

shade

automatically

Talk on BT/Phone You can set whether to communicate through the FOMA

Send DTMF tone/

Voice/Videophone Calls/PushTalk

DTMF tone OFF

V.phone settings

Visual preference See page 75.

Brightness You can adjust the brightness of the camera image to be sent

74

terminal or a Bluetooth device. (See page 417)

During a Chara-den call, you can switch to the DTMF
Transmission Mode that enables you to enter the data from
the numeric keys and to send DTMF (touch-tone signals). You
can operate it only during a Chara-den call.
≥“Send DTMF tone” is displayed when the mode is not DTMF

Transmission Mode and “DTMF tone OFF” is displayed in
DTMF Transmission Mode.

≥In DTMF Transmission Mode, you cannot operate the action

of Chara-den images.

≥The DTMF tone may not be received depending on the

device of a receiving end.

to other party to -3 (dark) through +3 (bright).

1Select a brightness level.

Focus You can set the focus for the outside camera during a

Chara-den setup See page 72.

Backlight You can select whether to light the display constantly or light

LCD AI See page 113.

Own number You can display your phone number.

Key guide You can display the guide of key operation during a

videophone call.

1Close-up or Landscape

≥The focus for the inside camera is fixed to “Portrait” (suitable

mode to shoot portraits), so you cannot change the setting.

for about 15 seconds after an operation.

1Constant light or 15 seconds light

videophone call.

<Hands-free with Videophone>

Information

Information

Setting Hands-free Videophone

You can set whether to switch to Hands-free automatically for when a

videophone call starts.

m1Set./Service1Videophone

1

1Hands-free w/ V. phone1ON or OFF

≥See page 61 for the operation while Hands-free is activated and how to switch to

Hands-free.

<Visual Preference>

Setting Image Quality for Videophone Calls

You can set the quality of the received image on the display.

m1Set./Service1Videophone1Visual preference

1

1Select an image quality.

≥“Prefer motion spd” is effective when there is motion in an image. When there is

little motion, the quality becomes better if you set to “Prefer img qual”.

≥If you operate from the Function menu during a videophone call, the setting is

effective only for the current videophone call.

≥If the radio wave conditions weaken during a videophone call, the image may appear

like a mosaic.

<Select Image>

Changing Image Displays for Videophone Calls

You can set an image to be sent to the other party.

m1Set./Service1Videophone1Select image

1

1Select an item.

On hold . . . . . Sets an image for during answer-hold (On hold).

Holding . . . . . Sets an image for while a call is on hold (Holding).

Substitute image

. . . . . . . . . . . .Sets a substitute image (still image or Chara-den) for when the

Record message

. . . . . . . . . . . .Sets an image while recording a record message.

Preparing . . .Sets an image for while playing back an answer message.
Movie memo

. . . . . . . . . . . .Sets an image for while recording a movie memo.

Select an image.

2

Pre-installed . . . For sending a pre-installed still image to the other party.

Original . . . . . . . For sending an appropriate message with a still image stored

Chara-den . . . . . For sending a Chara-den image selected by “Substitute image”

≥Press l( ) to play back a demo to check the still image or Chara-den

image.

≥To change the setting of “Original” or “Chara-den”, press i( ), select

“Change setting”, then select a still image or Chara-den image. If you have
selected “Original”, select a still image after selecting a folder.

≥Even if you delete the still image selected from “Original”, that still image is displayed

to the other party. To change, set by “Change setting” or “Set display”.

camera is off.

using “Set display”.

from the Function menu while a Chara-den image is displayed.
(See page 72)
(Displayed only when “Substitute image” has been selected in
step 1.)

Voice/Videophone Calls/PushTalk

75

Set by Call

Information

You can set an image to be sent to the other party for making a
videophone call.

Enter a phone number

1

or

call up the detailed display of a Phonebook entry, redial
item, dialed call record, or received call record.

i()1Select image1My side or Chara-den

2

≥The setting is completed when you select “My side”.
≥To cancel the setting by call, select “Release”. The setting is completed.

Select a Chara-den image.

3

<Voice Call Auto Redial>

Redialing as a Voice Call when a Videophone Call cannot be Connected

Voice/Videophone Calls/PushTalk

If a videophone call cannot be connected, it will be automatically redialed
as a voice call.

m1Set./Service1Videophone1Voice call auto redial

1

1ON or OFF

≥The charges for calls once switched to voice calls are billed at the rates for the voice

calls.

≥Voice Call Auto Redial does not work when a videophone call cannot be connected

such as when the line is busy or the other party’s phone is in Public mode (Drive
mode). However, Voice Call Auto Redial works when you make a videophone call to a
phone that does not support the videophone function.

<Notify Switchable Mode>

Setting for Switching a Voice/Videophone Call during a Call

You can let the other party know that your FOMA terminal can switch
between a voice call and a videophone call.
This function is set to “Indication ON” at the time of contract. When
“Notify switchable mode” is set to “Indication ON”, the caller can switch
between the videophone call and voice call.

≥You cannot operate “Notify switchable mode” when you are out of the service area or

radio waves do not reach, or during a call.

m1Set./Service1Videophone

1

1Notify switchable mode1Do the following operations.

Indication ON 1YES1OK

Indication OFF 1YES1OK

Check indication You can check the setting of the function.

<Videophone while Packet>

1OK

Selecting Response to Incoming Videophone Calls during i-mode

m1Set./Service1Incoming call

1

1V.phone while packet1Select an item.

V.phone priority

. . . Shows the Videophone Call Receiving display. When you answer the

videophone call, packet communication is disconnected.

Packet downld priority

. . . Rejects the videophone call and continues the communication.

V.phone answerphone

. . . Connects the incoming videophone call to the Voice Mail Service Center.

Call forwarding

. . . Forwards the incoming videophone call to the forwarding destination.

76

Information

≥If you have not signed up for Voice Mail Service or Call Forwarding Service, “Packet

Information

Other ID list

downld priority” works even if you set to “V.phone answerphone” or “Call forwarding”.

Using Videophone Calls by Interfacing to External Devices

You can operate your FOMA terminal from an external device such as

your personal computer for making or receiving videophone calls by

connecting them using the FOMA USB Cable with Charge Function 01/02

(option).

To use this function, you need to install a videophone application

program on a dedicated external device or personal computer, and

further, you need to prepare equipment (commercial item) such as an

earphone/microphone or USB compatible web camera.

≥For operating environments for a videophone application program and how to set or

operate it, refer to the instruction manual or other literature for an external device.

≥You can use “ドコモテレビ電話ソフト (DOCOMO Videophone Software)” as the

application program that supports this function.
You can download “ドコモテレビ電話ソフト (DOCOMO Videophone Software)”
from the DOCOMO website.

≥You cannot make a videophone call from the external device during a voice call.
≥When you have signed up for Call Waiting Service, an incoming videophone call from

an external device during a voice call is recorded as a missed call in Received Calls.
The same applies for an incoming voice call, videophone call, and 64K data
communication during a videophone call from an external device.

<Remote Monitoring>

Checking inside of a Room when You are Out

You can use the inside camera of the FOMA terminal as a monitoring
camera to observe the remote location from a phone that has the
videophone function based on 3G-324M. While “Remote monitoring” is
set to “ON”, the FOMA terminal automatically starts Remote Monitoring
when it receives a videophone call from a phone number stored as
“Other ID” of “Remote monitoring”.

m1Set./Service1Videophone1Remote monitoring

1

1Enter your Terminal Security Code.

≥To release Remote Monitoring, select “Set”, then select “OFF”.

Other ID1<Not recorded>

2

1Enter a phone number.

≥To change, select the stored phone number.
≥You can enter up to five phone numbers of up to 26

digits by using numerals, #, :, and +.

≥To return to the setting display for Remote Monitoring, press r from the Other

ID list after storing phone number.

Ring time1Enter a ring time (seconds).

3

≥You can enter the time from “003” through “120” in three digits until Remote

Monitoring starts after receiving a videophone call.

≥You cannot set the same ring time for Remote Monitoring, Auto Answer Setting

and Record Message Setting. Set a different time for each.

Set1ON

4

≥When receiving videophone calls from the phone numbers stored as “Other ID”,

the FOMA terminal automatically answers to start Remote Monitoring after the
ring time elapses.

≥“ ” is displayed while this function is set to “ON”.
≥You cannot set to “ON” in Manner Mode.

Voice/Videophone Calls/PushTalk

77

Function Menu of the Other ID List

Information

Information

Look-up address You can call up a phone number in the Phonebook, Dialed Calls,

Delete this 1YES

Delete all 1YES

<Delete this> <Delete all>

≥

If you delete all phone numbers stored as “Other ID”, “Remote monitoring” is set to “OFF”.

or Received Calls to enter it.

1Select an item.

Phonebook

. . .Call up a Phonebook entry and select a phone number.

Dialed calls

. . .Highlight a phone number and press Oo().

Received calls

. . .Highlight a phone number and press Oo().

Perform Remote Monitoring

Make a videophone call from a stored phone number.

After the ring time set for “Remote monitoring” elapses, Remote Monitoring

1

automatically starts.

Voice/Videophone Calls/PushTalk

≥The image through the receiving end’s camera appears and the sound comes

out of the speaker.

≥You cannot set Voice-only Remote Monitoring.
≥Make a videophone call notifying your caller ID. If the caller ID is not notified,

Remote Monitoring will not start and the call will be handled as an ordinary
incoming videophone call.

Remote Monitoring ends when the calling end or

2

receiving end presses

For answering a videophone call without starting Remote
Monitoring at the receiving end

Press d or Oo( ) before the FOMA terminal answers a videophone call
automatically. If you press m( ), the videophone call starts sending the
substitute image to the other party.

≥When a remote monitoring call comes in, “Setting when opened” is disabled.
≥If you press h when a remote monitoring call comes in, the call will be cut and

Remote Monitoring will not start.

78

h.

≥When your FOMA terminal is used for the receiving end, an image through the caller’s

camera appears, and sound comes out. (You cannot switch to a substitute image.)

≥Remote Monitoring does not start during Manner Mode and Public mode (Drive

mode). However, it starts even during Lock All.

≥When Remote Monitoring is set to “ON” and a videophone call comes in from the

phone number set as “Other ID”, Remote Monitoring starts after the set ring time,
even when “Ring time”, “Auto answer setting”, or “Record message setting” is set and
regardless of their ring times.

≥When Remote Monitoring is not performed, it is recorded in Received Calls as a

missed videophone call.

≥If an earphone/microphone (option) is connected when a remote monitoring call

comes in, the ring tone sounds from both the earphone and the speaker, even when
“Headset usage setting” is set to “Headset only”.

≥The ring tone for Remote Monitoring sounds. (You cannot change the ring tone for

Remote Monitoring.)
The ring tone sounds at the volume set for “Videophone” of “Ring volume”, but at
“Level 2” if you have set “Step”, “Level 1” or below. The color is “Gradation”, and its
lighting pattern is “Standard”, regardless of the Incoming Illumination setting.

≥You cannot put incoming remote monitoring calls on answer-hold (On Hold).
≥If you set both Call Forwarding Service and Remote Monitoring, and give priority to

Remote Monitoring, set its ring time shorter than that for Call Forwarding Service.

≥

To use Call Forwarding Service for Remote Monitoring, store the phone number of
dialing side as “Other ID” and set a 3G-324M videophone as the forwarding destination.

≥You may be imposed punishment according to the law and rule (such as the

nuisance prevention ordinance) if you use the FOMA terminal to give a
remarkable nuisance and misdeed to the public.

Please be considerate of the privacy of individuals around you
when shooting and sending photos using camera-equipped
mobile phones.

PushTalk

Information

This service provides you a pleasurable group calls among multiple

parties (two to five persons including yourself). The participants can

speak by turns by pressing the PushTalk key.

※You are charged a PushTalk communication fee each time you press the PushTalk

key (speak).

≥For details on PushTalk or compatible models, refer to DOCOMO website or “Mobile

Phone User’s Guide [Network Services]”.

■PushTalkPlus

This service enables you to have a PushTalk call with up to 20 persons including you.

You can use the shared Phonebook on the network, and can check the members for

their status, thus PushTalk becomes more useful.

※You need to subscribe separately.

≥For details such as how to operate, refer to the booklet which is supplied at

subscription.

※

Making a PushTalk Call

Enter the other party’s phone number

1

1p

When you are dialing, a confirmation tone for starting a
PushTalk call sounds for a few seconds, and then the
same ringback tone as the voice (videophone) call
sounds.
≥You can make a group call to multiple persons using

the PushTalk Phonebook. (See page 83 and page 84)

When the other party answers, talk

2

while pressing p.

When the other party answers, a confirmation tone for
starting communication sounds.
≥“ ” blinks during dialing and lights during

communication.

≥When you get the talker’s right, the talker’s right

obtained tone sounds. The other party hears your voice
only while you are pressing p and having the talker’s
right. When you release p, the talker’s right is
released, and a confirmation tone sounds.

≥You cannot get the talker’s right and an error tone

sounds even if you press p when another member has
it.

≥Press l( ) or press i( ) and select “Add member” to add a

member. Go to step 1 on page 81.

Press h to end the communication after talking.

3

A tone to notify the disconnection of communication sounds at the other end.
≥When a call you made is a group call, the PushTalk communication itself

continues even if you press h, and “Disconnected” appears on each member’s
display and a confirmation tone sounds. However, when all the members cannot
communicate due to “Disconnected”, “No PT Func”, etc., the PushTalk
communication itself ends.

≥The talker is charged a communication fee from when he/she presses .p and the

talker’s right obtained tone sounds.

≥You cannot make emergency calls at 110/119/118 from PushTalk.
≥The duration you can talk per talker’s right is limited. The talker’s right release notice

tone sounds before the limited time arrives, and the talker’s right is released. In
addition, the PushTalk communication itself ends when no one gets the talker’s right
in a certain period of time.

≥Just after purchase, Hands-free is automatically activated by “Hands-free w/

PushTalk” (see page 86). However, Hands-free is deactivated during Manner Mode
regardless of “Hands-free w/ PushTalk”.

≥The FOMA terminal works according to “Setting when closed” if you close it during

communication. You can set also by pressing +i( ) and selecting “Set. when
closed”. (See page 65)

Voice/Videophone Calls/PushTalk

79

≥Whether to notify others of your phone number when you make PushTalk calls follows

Information

1

2

3

During group

communication

the setting for “Activate/Deactivate” of “Caller ID notification” (see page 46). However,
when you set “Notify caller ID” from the Function menu for dialing, or when “Notify”/
“Not notify” is displayed in the detailed Redial/Dialed Call/Received Call display, each
of those settings will work.

≥When you make a PushTalk call with your phone number notified, your phone

number as well as all members’ phone numbers are notified to all members including
added members. When you make a PushTalk call without notifying your phone
number, “User unset” appears in the caller’s and member’s fields on the displays of all
the members including added members. Your phone number is very important
information, so take the utmost care to notify others of it.

≥If you make a PushTalk call during i-mode communication, the i-mode communication

is disconnected.

≥You cannot use PushTalk by Number B of 2in1.

Making/Receiving a PushTalk group call

You can use the PushTalk Phonebook or Redial/Dialed Calls/Received Calls to
communicate with multiple members.
While making or receiving a PushTalk group call, the group name and the members in
the group are displayed. Press No to confirm other members. When a call is received
with the other party’s phone number not provided, “User unset” is displayed.

Voice/Videophone Calls/PushTalk

Re-participating or participating midway in PushTalk
communication

Use Redial/Dialed Calls/Received Calls to make a PushTalk call while the PushTalk
communication continues among other members.
≥If the PushTalk communication has already been finished, your call is dialed as a new

PushTalk call.

■Display while dialing/communicating

1The phone number of the member who has the talker’s

right is displayed, and the state of the talker’s right is
displayed in color of the round icon at the upper left.
When the name of that member, phone number, and
image are stored in the Phonebook, his/her name and
image are displayed. However, when you cannot receive
a member’s information correctly, “?” is displayed.

Color of the

round icon at the

upper left

Blue Calling

Green You can get the talker’s right.

Blinking in green You have the talker’s right.

Blinking in yellow Another member has the talker’s right.

Blinking in green

and red

The talker’s right will be released automatically in a few seconds
because it has long been retained. (A release notice tone
sounds.)

State of the talker’s rights

80

2The corresponding state※ of each member is shown.

Information

Display Corresponding state of members

Calling Calling to the member

Connected Has participated in the PushTalk call.

No PT Func The destination phone does not support PushTalk.

Not avail. The destination phone is out of the service area or turned off.

Busy A voice call, videophone call, or PushTalk communication is in

ID Request You made a call without notifying of your caller ID to the member

Driving The member has activated Public mode (Drive mode).

PublicMode The member has activated Public mode (Power off), and is out of

Disconnected You have dialed a non-existent number.

※

The corresponding states other than “Calling” and “Connected” are displayed only
for the PushTalk communication among three or more members.

3The number of times you have got the talker’s right is the total of the number of “ ”

and the number shown in “ ”. When 999 times are exceeded, the counting is
reset to 0.

progress at the member.

i-mode communication is in progress at the member who has
given priority to i-mode by “i-mode arrival act”.

who has activated “Caller ID request”.

the service area or the power is turned off.

The state is other than above: the member does not answer, has
ended the PushTalk call, or does not use a DOCOMO mobile
phone.

Adding a Member during a PushTalk Call

You can make a PushTalk call to another member during PushTalk
communication and add that member to the communication.
You can add a person to the members by accessing the PushTalk
Phonebook, Phonebook, or Dialed Calls/Received Calls, or by directly
entering a phone number.
You can add up to five members (including yourself), and can repeat
adding up to that number.

≥Members can be added from the calling end only.
≥You can add even the members who use the PushTalk compatible models which do

not have this function.

≥If you have already made a call to four members, you cannot add a new member

though you can call up a member who has exited the call again.

≥The added members are not stored in Redial/Dialed Calls.

During PushTalk communication1l()

1

1Do the following operations.

View PushTalk PB You can call up a PushTalk Phonebook entry to make a PushTalk

View phonebook You can call up a Phonebook entry to make a PushTalk call.

Direct input You can enter a phone number to make a PushTalk call.

View call records You can call up Dialed Calls/Received Calls to make a PushTalk

≥The caller cannot add members if he/she uses a PushTalk compatible model which

does not have this function.

call. (See page 84)
Instead of pressingp, press l( ) to call.
≥Press c to switch between the PushTalk Phonebook list and

PushTalk Group list.

1Call up a Phonebook entry1Highlight a phone number

and press l().

1Enter a phone number1l()

call.

1Dialed calls or Received calls1Select a record
1Select a phone number1l()

Voice/Videophone Calls/PushTalk

81

≥For a member who uses a PushTalk compatible model which does not have this

Information

Information

function, the members added during PushTalk communication are not shown and a
confirmation tone does not sound.

Receiving a PushTalk Call

When a PushTalk call comes in,

1

“PushTalk call” is displayed, the ring
tone sounds, and the Call/Charging
indicator flickers.

≥“PushTalk group call” is displayed for an incoming

group call.

≥To reject a call, press i( ) during ringing and

select “Call rejection”. You can reject the call also by
pressing h.

Press p to answer a PushTalk call

2

1Talk while pressing p.

≥You can answer also by pressing d or Oo()

Voice/Videophone Calls/PushTalk

instead of p.

≥When you get talker’s right, the talker’s right obtained

tone is played back. The other party hears your voice
only while you are pressing p and having the talker’s
right. When you release p, the talker’s right is released
and a confirmation tone sounds.

≥You cannot get the talker’s right and an error tone

sounds, even if you press p when another member
has it.

≥“Setting when opened” and “Record message setting”

become invalid.

Press h to end the communication after talking.

3

A tone for confirming the end of communication sounds at the other end.
≥When a call you received is a group call, the PushTalk communication itself

continues even if you press h, and “Disconnected” appears on each member’s
display and a confirmation tone sounds. However, when all the members cannot
communicate due to “Disconnected”, “No PT Func”, etc., the PushTalk
communication itself ends.

≥The talker is charged a communication fee from when he/she presses .p and the

talker’s right obtained tone sounds.

≥The duration you can talk per talker’s right is limited. The talker’s right release notice

tone sounds before the limited time arrives, and the talker’s right is released. In
addition, the PushTalk communication itself ends when no one gets the talker’s right
in a certain period of time.

≥Just after purchase, Hands-free is automatically activated by “Hands-free w/

PushTalk” (see page 86). However, Hands-free is deactivated during Manner Mode
regardless of “Hands-free w/ PushTalk”.

≥The FOMA terminal works according to “Setting when closed” if you close it during

communication. You can set also by pressing +i( ) and selecting “Set. when
closed”. (See page 65)

≥You cannot use “On hold” or “Holding” for PushTalk.
≥When you received a PushTalk call from the phone number you set for “Call rejection”

or “Reject unknown”, “Disconnected” is replied. When you have activated “Caller ID
request”, “ID Request” is replied.

≥A PushTalk call that comes in during a voice call, a PushTalk call that comes in during

Public mode (Drive mode), and a voice call (when “PushTalk arrival act” is set to other
than “Answer”), a videophone call, data communication, or a PushTalk call that
comes in during PushTalk communication are recorded as missed calls in Received
Calls.

≥A PushTalk call that comes in during a videophone call or during data communication

does not work and is not recorded in Received Calls.

≥After you finish PushTalk communication or when you cannot answer to a PushTalk

call, you can use a received call record to make a PushTalk call and to re-participate
or participate midway in the communication so long as the PushTalk communication
continues among other members. If the PushTalk communication among other
members has already been finished, your call is dialed as a new PushTalk call.

≥When a caller adds members during PushTalk communication, the added members

are not stored in Received Calls.

82

≥See page 86 for how to respond to the PushTalk call during i-mode communication.

Information

PushTalk

Phonebook list

Information

PushTalk Group list

Group Member list Group Member

Selection display

≥When a PushTalk call comes in during Lock All or Omakase Lock, “ ” appears

after the lock is released.

<Store in PushTalk Phonebook>

Adding Entries to PushTalk Phonebook

From the items stored in a FOMA terminal’s Phonebook entry, you need

to store a name (reading) and a phone number in the PushTalk

Phonebook. You can store up to 1,000 entries in the PushTalk

Phonebook.

p1m()

1

1Do the following operations.

≥You can store also by selecting <New>.
≥If you store multiple phone numbers from a Phonebook

entry, the phone number previously stored in the
PushTalk Phonebook is overwritten.

View phonebook You can access an entry already stored in the FOMA terminal’s

Direct input You can store the entry in the PushTalk Phonebook after storing it

View call records You can access a dialed call record or received call record to

Phonebook and store it in the PushTalk Phonebook.

1Call up a Phonebook entry1Select a phone number1YES

in the FOMA terminal’s Phonebook.

1Phone1Select a storing method.

New . . . Go to step 2 on page 88.
Add . . . Go to step 3 on page 92.

≥When multiple phone numbers are stored in a Phonebook

entry, press l( ) and select the phone number you
want to store in the PushTalk Phonebook. The “★” mark is
added to the phone number that has already been stored in the
PushTalk Phonebook.

store it in the PushTalk Phonebook. You cannot store in the
PushTalk Phonebook from the dialed/received call record of the
party who is not stored in the FOMA terminal’s Phonebook.

1Dialed calls or Received calls1Select a record
1Select a phone number1YES

≥In the PushTalk Phonebook, you cannot store the Phonebook entries set to B by

Phonebook 2in1 Setting.

Store in Group

You can store PushTalk Phonebook entries in groups. You can store up
to 19 members per group and create up to 10 groups.

PushTalk Phonebook list

1

1c()

≥Press c( ) to show the PushTalk Phonebook

list.

Select a group1m()

2

1Put a check mark for members to be stored
1l()

≥You can store also by

selecting “<Edit group
members>” from the Group
Member list.

Function Menu of the Group Member Selection Display

Members to store You can display only members applied with a check mark.

Search 1Select a search method.

≥Press Oo( ) to store the members to the group.

Reading? . . See page 93.

Group? . . . . See page 93.

1Select a member.

You can display the Group Member Selection display with the
searched members selected.

Voice/Videophone Calls/PushTalk

83

Making a Call from PushTalk Phonebook

PushTalk

Phonebook list

Information

PushTalk Group list

Group Member list

Information

You can make a group call to up to four members using the PushTalk
Phonebook or PushTalk group.

PushTalk Phonebook list

1

1Put a check mark for members you

want to make a call to

1p or l()

≥Press c( ) to show the PushTalk Group list.
≥When you do not check any members, the call is made

to the highlighted member.

≥When all the members cannot communicate due to “Disconnected”, “No PT Func”,

etc., the PushTalk communication ends.

Make a Call from PushTalk Group

PushTalk Group list1Select a group.

1

≥Select a group and press p or l() to make a

call to all the members in the group.

Voice/Videophone Calls/PushTalk

≥Press c( ) to show the PushTalk Phonebook

list.

Put a check mark for members you

2

want to make a call to

1p or l()

≥When you do not check any members, the call is made

to the highlighted member.

≥When five or more members are stored in a group, you cannot make a call to all the

members by selecting the group.

Function Menu of the PushTalk Phonebook List/PushTalk
Group List/Group Member List

Members to call When the PushTalk Phonebook list or Group Member list is

Search PushTalk
PB

[Phonebook list only]

Store in P-Talk PB

[Phonebook list only]

DEL from P-Talk PB

[Phonebook list only]

Edit group members

[Group list/Member
list]

Edit group name

[Group list only]

DEL from PT group

[Group list only]

displayed, you can display the checked members only.

≥Press p or Oo( ) to make a PushTalk call.
≥Press i( ) to select “Notify caller ID” and then you can

select whether to notify your phone number. When “Cancel
prefix” is selected, the FOMA terminal works according to the
setting by “Caller ID notification”.

1Select a search method.

Reading? . . . See page 93.

Group? . . . . . See page 93.

1Select a member.

You can display the PushTalk Phonebook list with the searched
members selected.

See page 83.

See page 85.

You can edit the members in the group.
Go to step 2 on page 83.

1Enter a group name.

≥You can enter up to 16 full-pitch/32 half-pitch characters.

See page 85.

84

DEL group

Information

members

[Member list only]

Sound setting See page 86.

Vibration setting See page 86.

Auto answer set. See page 85.

Ring time setting See page 85.

Hands-Free See page 86.

Set. when closed See page 65.

i-mode arrival act See page 86.

P-Talk arrival act See page 86.

Network connection You can connect to the network to use PushTalkPlus. This is

<Delete from PushTalk Phonebook>

See page 85.

available only when you have singed up for PushTalkPlus.
(See page 79)

Deleting PushTalk Phonebook Entries

PushTalk Phonebook list1i()

1

1DEL from P-Talk PB1Do the following operations.

Delete this 1Select a deleting method.

DEL from P-Talk PB

. . . Deletes an entry in the PushTalk Phonebook only. Does not

delete the entry in the FOMA terminal’s Phonebook.

DEL from all PBs

. . . Deletes an entry in both the PushTalk Phonebook and

FOMA terminal’s Phonebook.

1YES

Delete all 1Enter your Terminal Security Code1YES

≥The FOMA terminal’s Phonebook entries are not deleted.

Delete from PushTalk Group

PushTalk Group list1i()1DEL from PT group

1

1YES

Delete Group Members

Group Member list1i()1DEL group members

1

1Do the following operations.

Delete this 1YES

Delete all 1Enter your Terminal Security Code1YES

≥Even when you delete PushTalk groups or group members, the PushTalk Phonebook

entries and FOMA terminal’s Phonebook entries are not deleted.

Setting for Making/Receiving a PushTalk Call

m1Set./Service1PushTalk

1

1Do the following operations.

Auto answer setting

Ring time setting 1Enter a ring time (seconds).

1Select an item.

ON . . . . . Automatically answers immediately after receiving

regardless of “Ring time setting”.

OFF . . . . Does not answer automatically.

≥Enter two digits from “01” through “60”.
≥“Disconnected” is displayed at the other end after the ring time

has elapsed.

Voice/Videophone Calls/PushTalk

85

Hands-free w/

Information

Information

PushTalk

PushTalk arrival act 1Select an item.

Sound setting You can set a pattern for the confirmation tones which sound

Vibration setting You can set whether to be notified by vibration for when you try to

Voice/Videophone Calls/PushTalk

<Auto answer setting>

≥When you set to “ON”, calls are automatically answered even when the FOMA

terminal is closed regardless of “Setting when closed”.

≥When you set to “ON”, calls are automatically answered after switching to Hands-free

regardless of “Hands-free w/ PushTalk”. However, the FOMA terminal works following
the setting of “Hands-free w/ PushTalk” if you open the FOMA terminal after you
answer a call with the FOMA terminal closed.

≥When you set to “ON”, the ring tone, vibrator, Call/Charging indicator, and backlight

do not work. Calls are not automatically answered during Manner Mode.

<PushTalk arrival act>

≥If you press -h for an incoming voice call while “Answer” is set, the Call Receiving

display appears after you finish the PushTalk communication, and then you can
answer the voice call. To continue the PushTalk communication, press +i()
and select “Call rejection”, “Call forwarding”, or “Voice mail”.

You can set whether to hear the other party’s voice from the
speaker or from the earpiece for when PushTalk communication
starts.

1ON or OFF

≥See page 61 for how the FOMA terminal works while

Hands-free is activated and how to switch to Hands-free during
communication.

Voice mail . . . . . . . Connects an incoming voice call to the

Call forwarding . . . Forwards an incoming voice call to the

Call rejection . . . . . Rejects an incoming voice call and does not

Answer. . . . . . . . . . Shows the Voice Call Receiving display.

during PushTalk communication.

1Select a pattern.

get the talker’s right or when a member’s state changes to
“Connected”.

1ON or OFF

Voice Mail Service Center.

forwarding destination.

answer.

<Sound setting>

≥In the “Simple” mode, some confirmation tones (talking right obtained tone, etc.)

during PushTalk communication become silent.

i-mode Arrival Act

You can set whether to show the PushTalk Call Receiving display for
when a PushTalk call comes in during i-mode communication.

m1

1

i-mode1i-mode settings1Common settings

1

i-mode arrival act1Select an item.

PushTalk preferred . . . . Ends i-mode communication and brings up the PushTalk

i-mode preferred . . . . . .Rejects receiving a PushTalk call and continues i-mode

Call Receiving display.

communication. The call is not recorded in Received
Calls.

86

Phonebook

Phonebooks Available for FOMA Terminal . . . . . . . . . . . . . . . . . 88

Storing Phonebook Entries . . . . . . . . . . . .<Add to Phonebook> 88

Storing Displayed Phone Number/Mail Address in Phonebook

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92

Setting Groups . . . . . . . . . . . . . . . . . . . . . . . . . .<Group Setting> 92

Making a Call from Phonebooks . . . . . . . <Search Phonebook> 93

Editing Phonebook Entries . . . . . . . . . . . . . . <Edit Phonebook> 97

Deleting Phonebook Entries . . . . . . . . . . . . . . . . .<Delete Data> 98

Checking Phonebook Storage Status . . . . <No. of Phonebook> 98

Making a Call with a Few Keys Operation . . . . . <2-touch Dial> 98

Accessing Phonebook Entries by Voice . . . . . . . . <Voice Dial> 99

87

Phonebooks Available for FOMA Terminal

For the FOMA

terminal

For the UIM

You can use two types of Phonebooks, namely the Phonebook in the
FOMA terminal itself, and the Phonebook on the UIM.

Number of entries 1,000 entries 50 entries

Name (Reading)
Group 19 groups 10 groups
Phone number 4 phone numbers 1 phone number
Phone number icon
Mail address 3 mail addresses 1 mail address

Phonebook

Mail address icon
Address

Basic item

Location information
Birthday
Memo
Image 100 images —
Memory No. From 000 to 999 —
Ring tone
Vibrator
Illumination
Chara-den 100 Chara-den

Mail ring tone

Contents of Phonebook

Setting item

Mail vibrator
Mail illumination
Answer message
Restrict dialing
Call rejection
Call acceptance
Call forwarding

Restrictions

Voice mail
Secret code
Storage in Secret Mode or
Secret Data Only

FOMA terminal UIM

○○

○

○
○
○
○
○

○
○
○
○

images

○
○
○
○

○

○
○

—

—
—
—
—
—

—

—

—

—

Name
Ring tone
Vibrator
Illumination
Chara-den
Mail ring tone
Mail vibrator

Contents of Group

Mail illumination
Answer message

○: Can be stored. —: Cannot be stored.
≥You can set your UIM into another FOMA terminal and use the UIM Phonebook

entries.

FOMA terminal UIM

○○

○

—

<Add to Phonebook>

Storing Phonebook Entries

You can store Phonebook entries in the FOMA terminal (Phone) or on the
UIM.

Xo(for at least one second)1Phone or UIM

1

The Edit Name display appears. Go to step 2 and enter a name.

Do the following

2

operations.

≥You can press No to switch

between the “Basic item” tab and
“Settings” tab for the FOMA
terminal’s Phonebook.

88

Name You can enter the name of the person or company in kanji,

Reading You can enter the reading in half-pitch katakana, alphabetic

Group In the FOMA terminal, 19 groups are available. On the UIM, 10

hiragana, katakana, alphabetic characters, or numerals.

1Enter a name.

≥For the FOMA terminal, you can enter up to 16 full-pitch/32

half-pitch characters. You ca n enter pictograms and symbols as
well.

≥For the UIM, you can enter up to 10 full-pitch characters/21

half-pitch alphanumeric characters. (Half-pitch katakana
characters cannot be entered.) When the entry contains both
full-pitch and half-pitch characters, you can store up to 10
characters from the beginning regardless of full-pitch or
half-pitch characters.

characters, or numerals.

1Edit a reading.

≥For the FOMA terminal, you can enter up to 32 half-pitch

characters. You can enter half-pitch symbols as well.

≥For the UIM, you can enter up to 12 full-pitch characters/25

half-pitch alphanumeric characters. (Half-pitch katakana
characters cannot be entered.) When the entry contains both
full-pitch and half-pitch characters, you can store up to 12
characters from the beginning regardless of full-pitch or
half-pitch characters.

≥If the displayed reading is acceptable, you do not need to edit it.

However, depending on the characters entered for names or
entering method, they are not reflected in the reading.

≥

If you enter “ゎ (reduced size)” or “ヮ(reduced size)” for a name,
“ワ (half-pitch, regular size)” (for the FOMA terminal) and “ワ
(regular size)” (for the UIM) are displayed in the reading field.

groups are available.

1Select a group.

≥When the storage is completed with no group selected, the

Phonebook entry is stored in “No setting”.

Phone number

Mail address You can store up to three mail addresses per Phonebook entry in

You can store up to four phone numbers per Phonebook entry in the
FOMA terminal. You can set an icon for each phone number to
categorize mobile phone numbers, office phone numbers, and so on.
You can store only one phone number per Phonebook entry on the
UIM.

1Enter a phone number.

≥Enter from the city code for the phone numbers.
≥You can enter up to 26 digits. However, you can enter up to 20

digits for blue UIMs.

≥Press and hold a for at least one second to insert a pause (p)

into the phone number you store. However, you cannot insert
the pause (p) to the beginning of phone number or insert it
consecutively. The pause (p) inserted to the end of phone
number is not stored.

≥If you insert “:” in the middle of a phone number, you cannot

make a call. However, the phone number is recorded in Redial
or Dialed Calls.

≥You can store the phone number which includes “#” such as

that for information service as well.

1Select an icon.

≥If you have stored a phone number in the FOMA terminal,

another “ <Phone number>” will appear in the
Add-to-Phonebook display. To store another phone number,
select “ <Phone number>”.

the FOMA terminal. You can set an icon for each mail address to
categorize mobile phone addresses, home addresses, and so on.
You can store only one mail address per Phonebook entry on the
UIM.

1Enter a mail address.

≥The mail address can consist of up to 50 half-pitch alphabets,

numerals or symbol characters.

≥When the mail address is “phone [e-mail]”,

store the phone number only.

≥For the FOMA terminal, you can set a secret code as well. (See

page 97)

1Select an icon.

≥

If you have stored a mail address in the FOMA terminal, another
“ <Mail address>” will appear in the Add-to-Phonebook display.
To store another mail address, select “ <Mail address>”.

89

Phonebook

Address 1Enter a ZIP code1Enter a postal address.

Location

information

Phonebook

Birthday 1Enter a birthday.

Memo 1Enter a memo.

≥You can enter up to 7 digits for the zip code.
≥You can enter up to 50 full-pitch/100 half-pitch characters for the

postal address. Further, you can enter pictograms as well.

≥You cannot enter “〒” or “-” (hyphen) in the zip code.

1Select an item.

By position loc.

. . .Measures the current location (see page 322) and store the

location information. After checking the location information,
press Oo().

From loc. history

. . .Select a piece of location information from Location History

(see page 326) and store it.

Attach from image

. . .Stores the location information from an image. Select a

folder, then the image.

From own number

. . .Stores the location information from “Own number”. Enter

your Terminal Security Code and press Oo().

≥To delete the stored location information, select “Delete location

info”.

≥You can enter the birthday from January 1, 1800 through

December 31, 2099.

≥You can check the birthday from Schedule. (See page 398)

≥You can enter up to 100 full-pitch/200 half-pitch characters.

Further, you can enter pictograms as well.

Image The stored still image is displayed when you call up the

Memory No. 1Enter a memory number.

Ring tone You can set a ring tone for when a voice call or videophone call

Vibrator You can set a vibration pattern for when a voice call or

Phonebook entry.

1Select an item.

Select image . . . You can store a still image in Data Box.
Shoot image . . . You can store the shot still image.

≥To release the stored still image, select “Release image”.
≥The size of a still image you can store is Stand-by (480 x 854) or

smaller and up to 300 Kbytes in JPEG format or GIF format.

≥If you store a still image larger than 72 x 54 dots, it is displayed

shrunk on the detailed Phonebook display.

≥If you store a still image larger than 240 x 180 dots, it is

displayed shrunk on the Call Receiving display.

≥When “Disp. PH-book image” is set to “ON”, the stored still

image is displayed for an incoming call. However, when another
image is stored for “Picture”, that image is preferentially
displayed for the incoming call.

≥Enter a three-digit number of “000” through “999”.
≥The lowest empty memory number “010” through “999” is

entered in advance.
If “010” through “999” are all occupied, the lowest empty
memory number from “000” through “009” is entered.

comes in from the person stored in the Phonebook.

1Select ring tone

Go to step 2 on page 102.
≥To release the stored ring tone, select “Release ring tone”.

videophone call comes in from the person stored in the
Phonebook.

1Select vibrator1Select a vibration pattern.

≥To release the stored vibrator, select “Release vibrator”.

Perform step 2 through step 3 on page 230.

90

Illumination You can set an illumination pattern for when a voice call or

Picture You can set an image to be displayed for when a call comes in

Chara-den The stored Chara-den image is displayed as a substitute image

Mail ring tone You can set a ring tone for when a mail message comes in from

Mail vibrator You can set a vibration pattern for when a mail message comes

Mail illumination You can set an illumination pattern for when a mail message

videophone call comes in from the person stored in the
Phonebook.

1Select illumination1Select an item.

≥To release the stored illumination, select “Release illumination”.

from the person stored in the Phonebook.

1Select picture1Select a type of image1Select a folder
1Select an image.

≥To release the stored image, select “Release picture”.

for videophone calls with the person stored in the Phonebook.

1Select Chara-den1Select a Chara-den image.

≥To release the stored Chara-den image, select “Release

Chara-den”.

the person stored in the Phonebook.

1Select ring tone

Go to step 2 on page 102.
≥To release the stored mail ring tone, select “Release ring tone”.

in from the person stored in the Phonebook.

1Select vibrator1Select a vibration pattern.

≥To release the stored mail vibrator, select “Release vibrator”.

comes in from the person stored in the Phonebook.

1Select illumination1Select an item.

≥To release the stored mail illumination, select “Release

illumination”.

Answer

message

You can set an answer message for Record Message by
Phonebook entry.

1Select answer message1Select an answer message.

≥To release the stored answer message, select “Release answer

message”.

Press l().

3

≥If you have not entered any name, “ ” is not displayed and you cannot

store the entry.

Phonebook entries while editing

When the low battery alarm sounds

The Phonebook entry you are editing is saved automatically. The confirmation display
appears asking whether to resume editing when you continue editing after charging the
battery or when you operate step 1 on page 88 and select the storage location for the
interrupted Phonebook entry after changing to a charged battery.

Recall. . . . You can resume editing the Phonebook entry.

New . . . . . You can edit a new Phonebook entry. In this case, the interrupted data is

retained. If you execute “Add to phonebook” after storing the new Phonebook
entry, the confirmation display appears again.

≥Only the most recently interrupted entry is retained.
≥If you resume editing the data but then cancel editing without storing it, that data will be

abandoned. Once you recall the data, be sure to store it.

If you receive a call or mail

You can respond it leaving the edited data as it is, thanks to the Multitask function.
To return to the Phonebook Edit display, press and hold x for at least one second to
switch the menu. You can return to the Phonebook Edit display also by ending the call or
mail function.

Phonebook

91

Storing Displayed Phone Number/Mail

Information

Address in Phonebook

You can store the displayed or selected phone number, mail address,
and still image in the FOMA terminal’s or UIM’s Phonebook.

While a phone number is entered Phone number
While a redial item, dialed call record, or received call
record is displayed
While Sent Address or Received Address is displayed Phone number/Mail address
While a site or screen memo is displayed Phone number/Mail address
While the text of Message R/F or mail is displayed Phone number/Mail address

Phonebook

While the data scanned by Bar Code Reader is displayed Phone number/Mail address
While a ToruCa file is displayed Phone number/Mail address
While your current location is displayed Location information
While the location history is displayed Location information/

While a registered LCS client is displayed Name/Phone number
While the Still Image list or a still image is displayed Still image

Call up/Select an item to be stored1i()

1

1Add to phonebook

≥When you operate from the detailed mail display, select “Store” from the Function

menu and then select “Add to phonebook”.

≥To store the address of the sender (or of another recipient of simultaneous mail)

of the received mail or the destination address of the sent mail into the
Phonebook, select “Store” from the Function menu and then select “Store
address”. If the addresses of the sender and another recipient of simultaneous
mail are found or the multiple destination addresses are found, select a mail
address or phone number to be stored.

≥To store a still image in the Phonebook, select “Set display” from the Function

menu and then select “Phonebook”.

≥When “Add to phonebook” is displayed on the Scanned Code Result display for

Bar Code Reader, select “Add to phonebook”; then other information in the
scanned code besides the phone number or mail address is entered into each
field.

Operation Storable items

Phone number

Phone number/Mail address

Phone or UIM1Select a storing method.

2

New . . . Go to step 2 on page 88.
Add . . . Adds data to the existing Phonebook entry. When storing data on the

UIM, “Overwrite” is displayed.

Select a search method1Search the Phonebook

3

1Select a Phonebook entry to be stored1Oo()

The phone number or mail address is entered automatically.

≥See step 2 on page 88 to edit other items in the Phonebook entry.
≥When you store into the FOMA terminal’s Phonebook, you can remain the

original entry and store a new entry into a different location by changing the
memory number.

l()1YES

4

≥If you store the entry in the UIM Phonebook, select “Overwrite” to overwrite the

original entry, or select “Add” to store it as a new entry.

≥The Phonebook entry does not store the information of “Notify caller ID” included in

Redial/Dialed Calls. To set Caller ID Notification, add “186”/“184” to the phone
number and store it.

≥Characters that cannot be stored may be replaced by spaces or deleted, and then

stored.

≥You may not be able to store the information from some sites into the Phonebook.

<Group Setting>

Setting Groups

You can utilize the Phonebook by sorting the entries by group such as
“Company” or “Friend”, or by your interest such as “Baseball” or
“Ceramic art”. You can set a ring tone, vibration pattern, or illumination
by group.

m1Phonebook1Group setting

1

≥The groups on the UIM are indicated by “ ”.
≥To reset the group names and respective settings by group, which have already

been stored, press i( ), select “Reset group”, and then select “YES”.

92

Highlight a group and press l()

Search Phonebook

display

2

1Select an item to be set1Set the contents.

≥When you select “ Group name”, enter a group name. You can store up to 10

full-pitch/21 half-pitch characters. However, you can store only up to 10
characters (regardless of full-pitch or half-pitch characters) when you enter both
full-pitch and half-pitch characters for a UIM group name.

≥See step 2 on page 88 for the operations of the other items. However, you cannot

set for groups on the UIM.

≥Select a stored group, or press i( ) and select “Check setting” to check

its settings. However, you cannot check the settings of the groups on the UIM.

Press l().

3

<Search Phonebook>

Making a Call from Phonebooks

You can retrieve stored Phonebook entries by eight search methods.

Xo1Do the following operations.

1

≥The display for the same search method as the

previous one appears once you have carried out a
search. Press r to show the Search Phonebook
display.

≥You can show the Search Phonebook display also by

m1Phonebook1Search phonebook.

All? You can show all Phonebook entries.

Reading? You can enter the reading of the other party’s name from the first

≥The tabs appear on the top of the Phonebook list. (See

page 94)

character and search. You do not need to enter the full reading.

1Enter a part of the reading1Bo

≥

The tabs appear on the top of the Phonebook list. (See page 94)

Group? You can show Phonebook entries stored in a specified group.

Memory No.?

[FOMA terminal only]

Name? You can enter the other party’s name from the first character and

Phone number? You can enter a part of the other party’s phone number and

Mail address?

2-touch dial?

[FOMA terminal only]

1Select a group.

The tabs appear on the top of the Phonebook list. (See page 94)

≥
≥If you press i( ) on the Group list, the Function menu

for “Group setting” is displayed.

You can search for the entry by the memory number assigned
when it was stored in the Phonebook.

1Enter the memory number.

≥Enter from “000” through “999” in three digits.
≥

The tabs appear on the top of the Phonebook list. (See page 94)

≥From the Stand-by display, you can press d and then press

Bo to display the Memory No. Dial display. From there you can

make a voice call by entering the memory number of the phone
number.

search. You do not need to enter the full name.

1Enter a part of the name1Bo

search. You can search for the entry even from the middle of
phone number.

1Enter a part of the phone number1Bo

≥You can display the Phonebook list also by entering a part of

the phone number from the Stand-by display or the “Talking”
display, and pressing Bo.

You can enter a part of the other party’s mail address and search.
You can search for the entry even from the middle of mail address.

1Enter a part of the mail address1Bo

You can show the list of Phonebook entries in memory number
000 through 009.
≥Phonebook entries not yet stored or being set with secret are

displayed as ＜−−−＞.

Select an entry1d or Oo()

2

≥When the entry contains multiple phone numbers, or when you searched by “Mail

address?”, press Mo from the detailed display to select a phone number.

≥You can make a videophone call by pressing l( ) or PushTalk call by

pressing p.

Phonebook

93

Information

≥In a search method other than “Group?” and “2-touch dial?”, enter nothing and press

Phonebook list

Detailed Phonebook

display (Item list)

Group
Reading

Name

Memory No.

Still image

Notify caller ID

*Bo; then you can search all through the Phonebook.

≥

When no Phonebook entry is found that matches the condition you entered by
“Reading?” or “Memory No.?”, the entry that is the closest to the condition is displayed.

Search order

The Phonebook entries are searched in the order of readings you entered for storing, as
follows:
“Space at the beginning of the reading” → “Japanese syllabary (

→

“Alphabet (A, a, B, b, ...Z, z)” → “Numerals (0 through 9)” → “Symbols” → “No reading”.
For “All?” and “Reading?”, searching is done in the following order:
“Japanese syllabary (

Phonebook

at the beginning of the reading” → “Numerals (0 through 9)” → “Symbols” → “No reading”.

※The Memory No. Search searches in the order of the memory numbers.

ア、イ、ウ、エ、オ、...ン

)” → “Alphabet (A, a, B, b, ...Z, z)” → “Space

ア、イ、ウ、エ、オ、...ン

About Phonebook List

When you search from “All?”, “Reading?”, “Group?”, or
“Memory No.?”, the tabs appear on the top of the Phonebook
list. With “All?” and “Reading?”, the entries are sorted by every
column of reading, with “Memory No.?” by every 100 of the
memory number, and with “Group?” by every group.
Press No to display the Phonebook entries in the tab at left or
right. However, when there are 12 or more Phonebook entries
in a tab, pressing m(), c(), or </> brings up the previous or next
page.
≥After you search by “Reading?”, you can move the cursor to the “ア” through “ワ”, “英”,

and “他” tab by pressing each numeric key from the list. When you successively press
the same numeric key, you can move the cursor within the same column.
<Example>Press 5 to display the “ナ” tab. Each time you press 5, the cursor

≥After you search by “Group?”, you can move the cursor to the top of each column in the

94

moves to the top of “ニ” “ヌ” and so on.

tab by pressing each numeric key from the list. When you successively press the same
numeric key, you can move the cursor within the same column.
<Example>Press 5 to move the cursor to the top of the “ナ” column. Each time you

press 5, the cursor moves to the top of “ニ” “ヌ” and so on.

≥After you search by “Memory No.?”, you can move the cursor to the “000~” to “900~”

tab by pressing each numeric key from the list.
<Example>Press 5 to move the cursor to the “500~” tab.

≥You can make a voice call to the phone number stored for the name highlighted on the

Phonebook list, by pressing d. Also, press l( ) to make a videophone call
and press p to make a PushTalk call. When multiple phone numbers are stored for
the name, the one stored first will be dialed.

≥For the Phonebook entry stored on the UIM, “ ” is displayed.
≥For the Phonebook entry stored with i-concier information, “ ” is displayed.
≥“ ” appears for the Phonebook entries set to A by Phonebook 2in1 Setting, “ ”

appears for the Phonebook entries set to B, and “ ” appears for the Phonebook

)”

entries set to common data. (Only in Dual Mode)

≥When you refer to the Phonebook from a GPS compatible i-αppli program, “ ”

appears for the Phonebook entries which contain the location information.

About the detailed display

Use No to highlight a tab, then the detailed contents are displayed.
≥For the Phonebook entry stored

on the UIM, “ ” is displayed on
the memory number field.

≥When Notify Caller ID is set to

“Notify caller”, “ ” appears,
and when set to “Don’t notify”,
“ ” appears.

≥

Under the still image, “ ”
appears for the Phonebook entries
set to A by Phonebook 2in1
Setting, “ ” appears for the
Phonebook entries set to B, and
“ ” appears for the Phonebook
entries set to common data. (Only
in Dual Mode)

≥When a Phonebook entry contains the setting for Multi Number or Chaku-moji, the set

contents are displayed in the Item list/Phone Number display.

Item list

The first stored phone number, mail address, postal address, birthday, and memo are
displayed. When i-concier information is stored, a postal address, URL, and memo
obtained from i-concier are displayed instead of a postal address, birthday, and memo.

Phone number

≥When you select the item, you can make a call. (See step 2 of “Making a Call from

Phonebooks” on page 93)

Mail address

≥When you select the item, you can compose an i-mode mail message with that mail

address entered into the address field.

Personal information

≥When you select a postal address, the GPS compatible i-αppli program set by “Select

map” of “GPS settings” starts to show the map. When you highlight a postal address
and press l( ), the full display appears.

≥When you select the location information, the Function menu of the location information

appears. (See page 323)

≥When you select a memo or still image, the full display appears.

i-concier information

≥When you select a postal address, the GPS compatible i-αppli program set by “Select

map” of “GPS settings” starts to show the map. When you highlight a postal address
and press l( ), the full display appears.

≥You can display a site or Internet website when you select a URL, select “i-mode

Browser” or “Full Browser”, and then select “YES”. When you highlight a URL and
press l( ), the full display appears.

≥When you select a memo, the full display appears.
≥If you have not subscribed to i-concier, the i-concier information tab does not appear.

Settings

≥When you select each item, a demo is played back.

Press Oo() or r to end the demo.

Function Menu of the Phonebook List

New You can store a new Phonebook entry.

Attach to mail You can send an i-mode mail message with the

Search location You can access the site of “イマドコかんたんサーチ

Move/copy

Copy to microSD See page 362.

Connect to Center See page 137.

Go to step 1 on page 88.

Phonebook entry attached.
Go to step 2 on page 142.

(imadoco kantan search)”.

1YES

Sort You can change the display order.

Change font size You can switch font sizes for the Phonebook and on the

Send Ir/ trans/BT

Send Ir data

Send phonebook See page 377.

Send all phonebook See page 378.

transmission

Send phonebook See page 379.

Send all phonebook See page 379.

Send to Bluetooth

Send phonebook You can send the Phonebook entry using Bluetooth

Send all phonebook You can send all Phonebook entries using Bluetooth

1Select a type of order.

≥You can sort Phonebook entries in reverse order by

selecting “Ascending” or “Descending”.

≥You cannot sort on the Phonebook list with tabs

displayed.

displays within “Phonebook settings”, etc.
(See “Phonebook” on page 118)

communication.

1Select a Bluetooth device to be sent1YES

≥When no Bluetooth devices are registered, the

confirmation display appears asking whether to search.

≥See page 415 for registering and connecting Bluetooth

devices.

communication.

1Select a Bluetooth device to be sent
1Enter your Terminal Security Code1YES

≥When “Session number setting” of “Bluetooth settings” is

set to “ON”, enter your Terminal Security Code and then
a session number.

≥When no Bluetooth devices are registered, the

confirmation display appears asking whether to search.

≥See page 415 for registering and connecting Bluetooth

devices.

Phonebook

95

Delete data See page 98.

Information

Set secret/Release secret You can activate/deactivate Secret for the Phonebook

<Send to Bluetooth>

≥You cannot send Phonebook entries from the UIM.
≥See page 412 for the Bluetooth function.

Function Menu of the Detailed Phonebook Display

Phonebook

Notify caller ID See page 56.

Prefix numbers See page 60.

Int’l dial assist See page 59.

Select image See page 76.

2in1 dial You can select a phone number to notify the other party in

Multi number You can select a phone number to be notified to the other

Chaku-moji See page 55.

Search location See page 95.

Edit data

Edit phonebook Go to step 1 on page 97.

Sort phone number/
Sort mail address

entry.
≥If you select “Set secret” in ordinary mode (not in “Secret

mode” or “Secret data only”), enter your Terminal
Security Code.

Dual Mode of 2in1. (See page 444)

party. (See page 441)

1Select a phone number or mail address
1Use Bo to change the order1Oo()

≥ From the detailed display, press No to highlight an

item to be sorted. The items you can select from the
Function menu differ depending on the highlighted
item.

≥To change the order in succession, repeat the above

steps.

1l()

Store in P-Talk PB You can store the phone number in the PushTalk

Move/copy

Copy to UIM See page 410.

Copy to microSD See page 362.

Copy to phone See page 410.

Connect to Center See pa ge 137.

Copy item

Copy name You can copy the name of Phonebook entry.

Copy phone number/
Copy mail add./
Copy address/
Copy location info/
Copy birthday/
Copy memo/Copy URL

Mail

Compose message You can compose an i-mode mail message to send to the

Attach to mail You can send an i-mode mail message with the

Compose SMS You can compose an SMS message to send to the phone

Change font size You can switch the font size for the Phonebook and on the

Restrictions See page 134.

Phonebook.

You can copy each item of Phonebook entry.
≥From the detailed display, press Mo to highlight an item

to be copied. The items can be selected in the Function
menu differ depending on the highlighted item.

mail address.
Go to step 3 on page 142.

Phonebook entry attached.
Go to step 2 on page 142.

number set as the destination address.
Go to step 3 on page 185.

displays within “Phonebook settings”, etc.
(See “Phonebook” on page 118)

96

Secret code You need to add the recipient’s secret code when sending

Information

Set desktop/ key

Add desktop icon See page 31.

long press set. See page 404.

Send Ir/ trans/BT

Send Ir data

Send phonebook See page 377.

Send all phonebook See page 378.

transmission

Send phonebook See page 379.

Send all phonebook See page 379.

Send to Bluetooth

Send phonebook See page 95.

Send all phonebook See page 95.

i-mode mail to anyone who has registered a secret code.
Once you set the secret code for the mail address in the
Phonebook entry, it will be added automatically whenever
you send mail to that address.

1Enter your Terminal Security Code1Set code

≥From the detailed display, press Mo to highlight a phone

number or mail address to be set with a secret code.

≥To check the secret code, select “Check code”.
≥To release the secret code, select “Release code”.

1Enter a four-digit secret code1YES

≥In the Function menu, “Secret code” is indicated by “★”,

after it is set.

≥Enter a four-digit number for secret code. You cannot set

“0000”.

Delete data See page 98.

Set secret/Release secret See page 96.

<Secret code>

≥You cannot set secret codes for UIM Phonebook entries.
≥The secret code can be added only when the recipient’s mail address is in the form of

“phone number” or “phone [e-mail]”. It cannot be added to any other
form of mail address.

≥If you have stored the mail address as “phone number＋secret [e-mail]”,

you cannot reply to mail messages from the party of that mail address. After changing
the mail address to “phone [e-mail]”, set the secret code.

<Edit Phonebook>

Editing Phonebook Entries

Detailed Phonebook display1m()

1

1Select an item to be edited1Edit the contents.

≥See step 2 on page 88 for how to edit the Phonebook entry.
≥Even if you edit the Phonebook entry in the FOMA terminal (Phone), you can

remain the original contents in the original location and store the edited contents
in the different location by changing the memory number.

l()1YES

2

≥If you edited the UIM Phonebook entry, select “Overwrite” to overwrite the original

contents, or “Add” to save the contents as a new entry.

Phonebook

97

<Delete Data>

Information

Information

Deleting Phonebook Entries

Delete from the Detailed Phonebook Display

Detailed Phonebook display1i()1Delete data

1

1Do the following operations.

Phone number/
This item

Phonebook

This phonebook 1YES

Delete from the Phonebook List

Phonebook list1i()1Delete data

1

1Do the following operations.

Delete this 1YES

Delete selected 1Put a check mark for Phonebook entries to be deleted

Delete all in tab You can delete all the Phonebook entries for the displayed tab.

Delete all You can delete all Phonebook entries including secret entries.

≥When you delete a Phonebook entry that is stored in the PushTalk Phonebook, the

PushTalk Phonebook entry is also deleted.

1YES

≥Highlight an item to be deleted by pressing Mo from the

detailed display.

≥You cannot delete information obtained by i-concier.

1l()1YES

≥You can check or uncheck entries all at once by pressing

i( ) and selecting “Select all in tab/Select all/Release
all in tab/Release all”.

≥Perform the same operation as that of “Delete all” when you

have selected all Phonebook entries including secret ones.

1YES

1Enter your Terminal Security Code1YES1YES

<No. of Phonebook>

Checking Phonebook Storage Status

m1Phonebook1No. of phonebook

1

Phone
Phonebook . . .The number of Phonebook entries stored in the FOMA terminal

Secret . . . . . . .The number of Phonebook entries stored as secret data

Image. . . . . . . .The number of Phonebook entries in which still images are stored

Chara-den . . . .The number of Phonebook entries in which Chara-den images are

PushTalk . . . . .The number of Phonebook entries stored in the PushTalk

Voice dial. . . . .The number of Phonebook entries set as voice dial entries

Rest . . . . . . . . . : The number of phone numbers that can still be stored

UIM
Phonebook . . .The number of Phonebook entries stored on the UIM

≥When you use 2in1, the number of Phonebook entries for the mode in use is

displayed. (See page 445)

<2-touch Dial>

(Phone)

(Displayed in Secret Mode or Secret Data Only)

stored

Phonebook

: The number of mail addresses that can still be stored

Making a Call with a Few Keys Operation

When the entry is stored in memory number “000” through “009” in the
FOMA terminal’s Phonebook, you can dial the phone number just by
pressing the lowest one digit of memory number and d.

Numeric key (0 to 9)1d or Oo()

1

≥You can make a videophone call by pressing l( ) or a PushTalk call by

pressing p.

98
