Docomo P-02C Instruction Manual

Download

Page 1

P-02C

INSTRUCTION MANUAL

’10.11

Page 2

DOCOMO W-CDMA System

Thank you for selecting the “docomo STYLE series P-02C”.

Read this manual before use to correctly operate your P-02C.

About manual of P-02C

The operating procedures for the P-02C are also published as in “



onto your FOMA terminal, and “Instruction Manual (Detailed Version)” as a PDF. (In Japanese only)

“Instruction Manual” (this manual)



Description of the displayed content and operating procedures for basic functions

“





Description of the outline and operations of frequently used functions From the P-02C

This function is available in Japanese mode only.

※

“Instruction Manual (Detailed Version)” (PDF)



From a PC, download detailed information about all the functions and the operating procedures. (In Japanese only) http://www.nttdocomo.co.jp/support/trouble/manual/ download/index.html

Note that the URL and published contents may be modiﬁed

※

without notice.

(Guide)” on-screen manual installed



(Guide)” (installed onto your FOMA terminal)

▶

LifeKit

▶



(Guide)



Basic Package

P-02C Handset

⿠

(With Warranty and Back Cover P47)

See page 91 for optional items that support this FOMA

⿠

terminal.

For Using This Manual

Note that “P-02C” is referred to as “FOMA terminal” in this manual.

⿠

Most operating procedures and displays in this manual are shown

⿠

with the default settings of the “BLACK” handset. Further, displays and illustrations shown in this manual are for reference. The actual ones might differ. Most operating procedures and displays in this manual are shown

⿠

when the FOMA terminal is in Normal Style.

Battery Pack P20

⿠

NTTドコモ

Instruction Manual

⿠

(Japanese version)

P-02C CD-ROM

⿠

Desktop Holder P42

⿠

Page 3

FOMA Terminal ····································2 What You can Do with P-02C Part Names and Functions

···················································6

Styles

···············3

·················· 4

Precautions Handling Precautions Waterproof Performance

··········································7

························15

···················18

Introduction

󱽄

P.1



Before Using ····························· 22

Charging, Power ON/OFF, etc.

Screen Explanation ·················· 26

Viewing Display/Icon, etc.

Call Telephone···························45

Making a Call/Videophone Call, Receiving a Call/Videophone Call, Network Services, WORLD WING, etc.

i-mode/Full Browser ·················59

Access Sites, Full Browser, Viewing and Operating Sites, Add Bookmark, Screen Memo, etc.

Camera ······································63

Shoot Still Images/Moving Pictures, etc.

1Seg ···········································66

Watching 1Seg, etc.

Osaifu-Keitai ·····························75

Osaifu-Keitai/ToruCa

i-concier ·····································76

Displaying i-concier, etc.

Support ······································ 84

Troubleshooting, Warranty and After-sales Service, i-mode Fault Diagnosis Site, Updating Software, etc.

It is prohibited to copy all or part of this manual without permission. ※The instructions contained in this manual may be changed without notice.

※

Character Entry·························33

Sound/Screen Setting

Select Ring Tone, Display Setting, etc.

·············· 35

Mail ·············································53

Send i-mode Mail, Deco-mail, Decome-Anime, Receive i-mode Mail, Area Mail, etc.

i-Channel ··································· 62

Music ·········································70

Music&Video Channel, MUSIC Player, etc.

Convenient Tools ······················ 77

Schedule, Alarm, Bar Code Reader

Appendix ··································· 92

Function List, Main Speciﬁcations, SAR, Export Administration Regulations, Intellectual Property Right

Lock/Security ····························41

Various Security Codes, Various Lock Functions, Resetting to Default, etc.

Phonebook ································57

Store Phonebook, Edit Phonebook, Delete Phonebook

i-αppli/i-Widget ·························72

Starting i-αppli, etc.

i-motion/Movie ·························· 74

Play i-motion/Movie, etc.

Data Management ····················· 79

microSD Card, Infrared Communication, iC Communication, PC Connection

Index ········································ 105

Basic Operation

󱽄

P.22



Connect

󱽄

P.45



󱽄

P.59



Enjoy

󱽄

P.63



More Convenient

󱽄

P.75



Others

󱽄

P.84



Page 4

Introduction

FOMA Terminal

⿠Because the FOMA terminal uses radio waves, you cannot use it in places where the radio waves do not reach, where they are weak even outdoors, such as inside tunnels, basements, or buildings, or out-of-service area. You might not be able to operate the FOMA terminal even when you are in a place with a ﬁ ne view such as in a high-rise building or apartment. Note that you may experience interruption of calls even if the three antennas respond to a strong radio wave, and you remain without moving to use the FOMA terminal. ⿠Use the FOMA terminal carefully to avoid disturbing other people when in public, or in crowded or quiet places. ⿠Since the FOMA terminal uses radio waves as the medium of telecommunication, calls may be tapped by a third party. However, the W-CDMA system automatically supports tapping prevention, so your conversation will be incomprehensible to the third party, because it is recognized as mere noise. ⿠The FOMA terminals change your voice into digital signals and send them to the other party. In places where the radio waves are weak, the digital signals may not be converted correctly, and in such a case, the voice may sound different from the actual one. ⿠The user hereby agrees that the user shall be solely responsible for the result of the use of SSL/TLS. Neither DOCOMO nor the certiﬁ ers as listed herein make any representation and warranty as for the security in the use of SSL/TLS. In the event that the user shall sustain damage or loss due to the use of SSL/TLS, neither DOCOMO nor the certiﬁ ers shall be responsible for any such damage or loss. Certiﬁ ers: VeriSign Japan K.K., Cybertrust Japan Co., Ltd., GlobalSign K.K., RSA Security Japan Ltd., SECOM Trust Systems Co., Ltd., Comodo CA Ltd., Entrust, Inc., and Go Daddy, Inc. ⿠This FOMA terminal supports FOMA Plus-Area and FOMA High-Speed Area. ⿠The FOMA terminal can be used only via the FOMA network provided by DOCOMO and in DOCOMO’s roaming area. ⿠You are advised that you make separate notes of information (such as Phonebook entries, schedule events, text memos, record messages, voice memos, movie memos) stored in the FOMA terminal and keep them in a safe place. Note that we cannot be held responsible for the unlikely event of loss of the stored content due to a malfunction, repair, change of your model, or other mishandling of the FOMA terminal. ⿠You are advised to save your important data on the microSD card. If you have a personal computer, you can transfer and save data such as Phonebook entries, mail messages, schedule events, and others on the personal computer by using DOCOMO keitai datalink.

Page 5

What You can Do with P-02C

󱽄



You can check “

(Guide)

使いかたナビ



P.32

(Guide)” on screen for how to operate a function you want. Even when you do not have the printed “Instruction Manual” at hand, you can easily operate your FOMA terminal by referring to it.

This function is available in Japanese mode

※

only.

󱽄

International Roaming

P.52



You can use the FOMA terminal overseas the same way as you use it in Japan, including phone number and mail address. (Supported only in 3G area.)

Waterproof Performance

󱽄

The FOMA terminal is designed to exhibit a waterproof performance equivalent to the IPX5 and IPX7 classes once its connector terminal cover have been closed tightly and the back cover is attached.

ECO NAVI

󱽄

P.40

ECO NAVI is a function that identiﬁ es waste and conserves energy. A notiﬁ cation icon will be displayed when the remaining battery level drops below the set level, or when the FOMA terminal has not been operated for a certain period of time and 1Seg has terminated.

Suzy’s Zoo Contents

You can set popular characters of Suzy’s Zoo in Kisekae Tool or Machi-chara.

P.18

○○鉄道現在、運転見合わせ中です・・・。

「ひつじのしつじくん®」

󱽄

i-concier

P.76

i-concier is a service that enables you to receive useful information from a character (Machi-chara image) on the Stand-by display and download schedule event (i-schedule) ﬁ les for your convenience.

i-concier is available in Japanese

※

only.

Introduction

Page 6

Part Names and Functions

󰿿 󱀀

󱀁

Introduction

󱀂 󱀃

󱀄 󱀅

󱀆

󱀇 󱢳

󱢴 󱢵

󱢶

󱢷 󱢸 󱢹

Light sensor

󰿿

For sensing brightness (Do not cover it with your hands or do not put a sticker on it. Doing so might disable detecting the brightness.)

Earpiece

󱀀

For listening to the other party’s voice

Display

󱀁

Mail key

󱀂+l

For showing the Mail Menu

Clear key/i-Widget key

󱀃+r

Menu key

󱀄+m

For showing the Main Menu

Start key/Hands-free switch key

󱀅+d

Microphone

󱀆

For speaking to the other party

Command navigation key

󱀇+o

For operating functions and menus

i-mode key/i-αppli key

󱢳+i

Camera key/1Seg key

󱢴+c

Power/End key

󱢵+h

For turning on/off the power or ending a call

Numeric keys

󱢶

For entering phone numbers and text

Multi key

󱢷+x

For showing the Task menu

Hook for Horizontal Open Style

󱢸

Connector terminal

󱢹

Integrated terminal for connecting earphone or for charging, etc.

For using earphone

Connect an optional connector-terminalcompatible earphone. When using a connectorterminal-non-compatible earphone, use an optional plug adapter for connection.

Example for connecting the Stereo Earphone Set 01 (option) to external connector terminal

This mobile phone serves as the port where both the AC Adapter (charging) and Stereo Earphone Set 01 (Earphone/microphone terminal) are plugged in.

Stereo Earphone Set 01 AC Adapter

Page 7

󱢺 󱢻

󱢽

󱢾

Call/Charging indicator

󱢺

Lights while you are receiving a call or message, talking, or charging.

⿠The Call/Charging indicator of the

󱢼

󱢿 󱣀

󱣁

󱣂

bottom lights during charging.

Infrared data port

󱢻

For using infrared communication and the infrared remote control

Private window

󱢼

fmark

󱢽

An IC card is installed. Use it for OsaifuKeitai or iC communications.

Back cover

󱢾

Remove this when attaching/removing the battery pack, UIM, and microSD card.

FOMA antenna/ 1Seg antenna

󱢿

The antenna is embedded in the handset. Do not cover the antenna with your hand for better communication/reception.

Camera

󱣀

For shooting portraits and/or landscapes

Speaker

󱣁

Charging terminal

󱣂

󱣆 󱣇

Strap hole

󱣃

󱣃

󱣄 󱣅

Side  key

󱣄.<

For turning up the earpiece volume during a call

Side  key

󱣅.>

For turning down the earpiece volume during a call

One-push open button

󱣆

For opening the FOMA terminal (Be careful not to drop the FOMA terminal by the rebound when opened.)

Horizontal open lever

󱣇

Introduction

Page 8

Styles

The P-02C comes with two styles.

 Normal Style

You can open the FOMA terminal easily by one-push key operation. ( One-push Open)

⿠You can open it also manually without using the button. ⿠You need to close the FOMA terminal manually. If it does not close, open it fully and then close it.

Introduction

 Horizontal Open Style Open the display unit with the horizontal open lever slid into the direction B while you are softly depressing part A. Now you can watch 1Seg broadcast programs or messages in Horizontal Open Style.

⿠When you open the display unit, ensure that the hook is correctly engaged. If the hook is not correctly engaged,

re-open the FOMA terminal after closing it once.

One-push open button

Horizontal open lever

Page 9

Precautions

Don’t

ALWAYS FOLLOW THESE DIRECTIONS

 Before using the FOMA terminal, read these safety precautions carefully so that you can use it correctly. After reading the precautions, keep them in a safe place.  Be sure to observe these safety precautions to prevent you or those around you from inﬂ icting injury and to avoid unnecessary damage to the property.  The symbols below indicate the levels of danger or damage that can be caused if the particular precautions are not observed and equipments are not used properly.

This symbol indicates that incorrect

Danger

Warning

Caution

The following symbols show speciﬁ c directions:

Denotes actions prohibited to do.

Denotes not to disassemble the units.

Do not

disassemble

handling will almost certainly cause death or serious injury.

This symbol indicates that incorrect handling poses a risk of causing death or serious injury.

This symbol indicates that incorrect handling poses a risk of causing a slight injury or damage to the product or property.

Denotes not to touch with wet hands.

Not wet

hands

Denotes not to use where the equipment may get wet, and avoid get it wet.

Avoid Water

Denotes mandatory instructions (matters that must be complied with).

Denotes to pull the power plug out of an outlet.

Pull the

power plug

out

“Precautions” are divided into the following six sections:

General precautions for FOMA terminal, batteries, adapters,

desktop holder, and UIM...................................................................P.8

Precautions for FOMA terminal ........................................................P.9

Precautions for batteries .................................................................P.11

Precautions for adapters and desktop holder .................................P.12

Precautions for UIM ........................................................................P.13

Notes on using near electronic medical equipment ........................P.13

Introduction

Page 10

General precautions for FOMA terminal, batteries, adapters, desktop holder, and UIM

Danger

Do not use, store, or leave the mobile phone or its accessories in places with a high temperature (such as near

Don’t

Introduction

disassemble

ﬁ re, near heating appliances, inside a kotatsu or near other furniture with heating elements, in places exposed to direct sunlight, or in cars heated by the sun).

Fire, burns, or injury may result.

Do not place the FOMA terminal or its accessories inside cooking appliances such as microwave ovens

Don’t

or high-pressure containers.

Fire, burns, injury or electric shock may result.

Do not attempt to disassemble or remodel the FOMA terminal or its accessories.

Do not

Fire, burns, injury or electric shock may result.

Do not allow the FOMA terminal or its accessories to get wet either from water, drinking

Avoid

water or pet urine, etc.

Water

Fire, burns, injury or electric shock may result. See “Waterproof Performance” on page 18 for details on waterproof performance.

With your FOMA terminal, use the batteries and adapters speciﬁ ed by NTT DOCOMO, INC.

Fire, burns, injury or electric shock may result.

Warning

Do not throw the FOMA terminal or accessories, or subject them to severe shocks.

Don’t

Fire, burns, injury or electric shock may result.

Do not allow electrically conductive foreign objects (such as metal pieces or pencil

Don’t

leads) to come into contact with the FOMA terminal’s charging terminal or connector terminal. Do not allow such objects to enter into the FOMA terminal.

Fire, burns, injury or electric shock may result.

Do not cover or wrap the FOMA terminal or its accessories with a cushion, etc. while it is being

Don’t

used or recharged.

Fire or burns may result.

Before entering a gas station or other places where ﬂ ammable gases are generated, be

absolutely sure to turn off the FOMA terminal and stop charging if it is being charged.

Otherwise, the ﬂ ammable gases may ignite. Use the Osaifu-Keitai with the FOMA terminal turned off when you are near a gas station. (When IC Card Lock is set, release the lock, and then turn off the power.)

If odor, overheat, discoloration, or deformation is detected during use, battery charge, or

storage, immediately follow the instructions below:

• Pull the power plug out of the outlet or cigarette lighter socket.

• Turn off the power of the FOMA terminal.

• Remove the battery pack from the FOMA terminal.

Fire, burns, injury or electric shock may result.

Caution

Do not place the FOMA terminal or accessories on unstable locations such as wobbly tables

Don’t

or slanted locations.

They may fall off and cause injury.

Page 11

Do not store in humid or dusty

Don’t

places, or in high temperature environments.

Fire, burns or electric shock may result.

If the FOMA terminal and its accessories are used by a child, a guardian should explain how to operate them correctly. During use, a guardian should also check that they are being used as instructed.

Otherwise, injury may result.

Keep out of the reach of babies and infants.

Accidental swallowing or injury may result.

Take special care when you use the FOMA terminal for a long time with the adapter connected.

If you use the i-αppli programs, talk on the videophone, watch 1Seg programs and so on for a prolonged period of time while charging, the temperature of the FOMA terminal, battery pack or adapter may rise. If you keep direct contact with hightemperature parts, redness, itching, a rash or low-temperature skin burns may result depending on the state of your physical condition or constitution.

Precautions for FOMA terminal

Warning

Do not directly point the infrared data port at someone’s eyes during transmission.

Doing so may harm the person’s eyes.

While using infrared communication, do not point the FOMA terminal’s infrared data port at a home electrical appliance which is equipped with an infrared device.

The infrared device may malfunction, and possibly cause an accident.

Do not allow liquids such as water, or foreign materials such as metal pieces or ﬂammable materials to get into the UIM or microSD card slot of the FOMA terminal.

Fire, burns, injury or electric shock may result.

Turn off the FOMA terminal in places where use is prohibited such as in airplanes and

hospitals.

Otherwise, the electronic devices and electronic medical equipment in those places may be adversely affected. If the Auto Power ON function is set, deactivate the setting, then turn off the power. For use inside medical facilities, make sure that you comply with their regulations. Engaging in any prohibited acts such as using the FOMA terminal in an airplane is punishable by law.

When talking in Hands-free mode or when a ring tone is sounding, be absolutely sure to keep the FOMA terminal away from your ear. Further, when you play games or play back music with the earphone/microphone etc. connected, adjust the sound volume to moderate volume.

The excessive sound volume impairs your hearing. Further, accidents may result due to the hardness of hearing of surrounding sound.

For those with weak heart conditions, the vibrator and ring volume must be adjusted carefully.

Otherwise, the functions may adversely affect your heart.

Introduction

Page 12

Don’t

Introduction

If you are using an electronic medical device or other type of device, check with its manufacturer or vendor as to whether it will be affected by the signals from the FOMA terminal.

The FOMA terminal may adversely affect the device.

Turn off the FOMA terminal when near electronic devices using high-precision control or weak signals.

The FOMA terminal may cause the electronic devices to malfunction and have other adverse effects.

Electronic devices that may be

※

affected: Hearing aids, implanted cardiac pacemakers, implanted deﬁbrillators, other electronic medical equipment, ﬁre alarms, automatic doors and other automatically controlled devices. If you use an implanted cardiac pacemaker, implanted deﬁbrillator or any other electronic medical equipment, consult the manufacturer or retailer of the device for advice regarding possible effects from the radio waves.

If the display part or camera lens is broken, be careful about broken glasses or the exposed

interior of the FOMA terminal.

Plastic panels are used for the surfaces of the display area and camera lens, making it hard for the glass to break into pieces. However, if you touch the damaged or exposed parts by mistake, you may injure yourself.

Caution

Do not swing around the FOMA terminal by its strap or other parts.

You may hit yourself or others, possibly causing injury or other accidents.

Do not use the FOMA terminal if it has been damaged.

Fire, burns, injury or electric shock may result.

If you accidentally damage the display part and the substance inside leaks out, keep your eyes, face, hands and skin away from it.

Otherwise, you may impair your eyesight or damage your skin. If this substance should get into your eyes or mouth, immediately rinse them with clean water, and then seek medical attention. If it should adhere to your skin or clothing, immediately wipe it off with alcohol or similar liquid, and then rinse the affected area with soap and water.

Do not open the FOMA terminal by pressing the one-push open button near persons around you or your face.

The FOMA terminal may hit you or persons around you, causing accidents and injuries.

Do not use the FOMA terminal with the hook for Horizontal Open Style protruded.

Otherwise, injury may result.

Before using the FOMA terminal inside a car, check with its manufacturer or dealer whether the signals from the FOMA terminal will have any adverse effects.

In some vehicle models, the signals may adversely affect the electronic devices inside the vehicle. Such cases are rare. However, if this happens, stop using the FOMA terminal immediately.

Itching, rash or eczema may be caused depending on your physical conditions or predisposition. If an abnormality occurs, stop using the FOMA terminal immediately, and then seek medical attention.

See “List of materials used” on page 14 for material of each part.

Be careful not to get your ﬁnger or a strap caught in the parts when you close or open the FOMA terminal.

Otherwise, injury or other accidents may result.

Page 13

Don’t

View the display in a sufﬁciently light place keeping a certain distance from your eyes.

Otherwise, your eyesight may become impaired.

Precautions for batteries

Check the description on the label of

■

the battery pack for the type of battery.

Description Type

Li-ion 00 Lithium-ion battery

Danger

Do not let any metal object such as a wire come in contact with the battery terminals. Also do not carry or store the battery together with any metal objects like a necklace.

Otherwise, the battery pack may ignite, burst or overheat and its electrolyte may leak.

When installing the battery in the FOMA terminal, check that it is facing the right way, and if the battery cannot be installed easily, do not force it into place.

Otherwise, the battery pack may ignite, burst or overheat and its electrolyte may leak.

Do not throw the battery into ﬁre.

Otherwise, the battery pack may ignite, burst or overheat and its electrolyte may leak.

Do not pierce it with nails, hit it with a hammer, or step on it.

Otherwise, the battery pack may ignite, burst or overheat and its electrolyte may leak.

If the battery ﬂuid or other material gets into your eyes, do not rub them. Flush your eyes with clean water and seek medical attention immediately.

Otherwise, the loss of eyesight may result.

Warning

Never use the FOMA terminal if it has damages such as deformities or scratches as a result of dropping it.

Otherwise, the battery pack may ignite, burst or overheat and its electrolyte may leak.

Immediately stop using the FOMA terminal and keep it away from ﬁre if the battery leaks or emits an odor.

The leaked battery ﬂuid may ignite, causing ﬁre or burst.

Be careful that your pets do not bite into the battery pack.

Otherwise, the battery pack may ignite, burst or overheat and its electrolyte may

leak.

Caution

Do not dispose of the exhausted battery with other waste.

The battery may catch ﬁre or damage the environment. After insulating the battery terminals with tape, take the unneeded battery to a handling counter such as a docomo Shop or dispose of it in accordance with local waste disposal regulations.

Do not use or attempt to charge a wet battery.

Otherwise, the battery pack may ignite, burst or overheat and its electrolyte may leak.

If the electrolyte ﬂuid material

inside the battery has leaked out, do not allow it to come into contact with the skin on your face, hands or any other part of your body.

Contact may result in loss of sight or skin problems. If you get the ﬂuid or other material in your eyes or mouth, or on skin or clothing, immediately wash the affected areas with clean water. If you get it in your eyes or mouth, immediately seek medical attention after rinsing.

Introduction

or other

Page 14

Precautions for adapters and

Don’t

desktop holder

Warning

Do not use the adapter if its cord has been damaged.

Fire, burns or electric shock may result.

Introduction

Do not use the AC adapter and desktop holder in humid places such as a bathroom.

Fire, burns or electric shock may result.

The DC adapter is for use only in a negative (-) grounded vehicle. Do not use it in a positive (+) grounded vehicle.

Fire, burns or electric shock may result.

If a thunderstorm is nearby, do not touch the adapter.

Otherwise, you may receive an electric shock.

Never short-circuit the charging terminal when the adapter is plugged into the power outlet or cigarette lighter socket. Also, never touch the charging terminal with ﬁngers or other bare skin.

Fire, burns or electric shock may result.

Do not place heavy objects on the adapter cord.

Fire, burns or electric shock may result.

When plugging the AC adapter into the power outlet, or when unplugging it from the outlet, do not allow metal straps or other metal objects to come in contact with it.

Fire, burns or electric shock may result.

Do not touch the adapter cord, desktop holder, or power outlet with wet hands.

Not wet

Fire, burns or electric shock may result.

hands

Use the adapter at the speciﬁed V AC. When charging the FOMA

terminal overseas, use the AC adapter available for use overseas to charge the FOMA terminal.

Supplying the wrong voltage to the AC adapter may result in a ﬁre, burns or electric shocks. AC adapter: 100 V AC DC adapter: 12/24 V DC [For negative (-) grounded vehicles only] AC adapter available for use overseas: 100 V to 240 V AC [Connect only to household AC outlet]

If a fuse of the DC adapter has blown, replace it with a speciﬁed fuse.

Fire, burns or electric shock may result. For the speciﬁed fuse, refer to each instruction manual.

Keep the power plugs dust-free.

Fire, burns or electric shock may result.

When plugging the AC adapter into the power outlet, plug it in securely.

Fire, burns or electric shock may result.

When unplugging the adapter from the power outlet or cigarette lighter socket, do

not yank the adapter cord, but take hold of the power plug to unplug it.

Fire, burns or electric shock may result.

When you do not intend to use the adapter for a long period of time, disconnect the power

Pull the

plug from the power outlet or

power plug

cigarette lighter socket.

out

Fire, burns or electric shock may result.

Page 15

If liquids such as water get in

the adapter, unplug the power cord immediately from the outlet

Pull the

or cigarette lighter socket.

power plug

Fire, burns or electric shock may result.

out

Before cleaning, pull the power plug out of the outlet or cigarette lighter socket.

Pull the

Fire, burns or electric shock may result.

power plug

out

Precautions for UIM

Caution

Be careful not to touch the cut surface of the UIM when removing it.

Otherwise, injury may result.

Notes on using near electronic medical equipment

The description below meets

■

“Guidelines on the Use of Radiocommunication Equipment such as Cellular Telephones – Safeguards for Electronic Medical Equipment” by the Electromagnetic Compatibility Conference Japan.

Warning

Comply with the following in hospitals or health care facilities:

Do not carry the FOMA terminal into

⿠

operating rooms, intensive care units (ICU) or coronary care units (CCU). Turn off the FOMA terminal in hospital

⿠

wards. If there is any electronic medical

⿠

equipment near you, turn off the FOMA terminal even when in a location such as a lobby. Comply with any regulations of hospital

⿠

and health care facilities instructing you not to use or carry in a mobile phone. If the Auto Power ON function is set,

⿠

deactivate the setting, then turn off the power.

Turn off the FOMA terminal in trains during the rush hour or other crowded areas as there

may be someone near you with an implanted cardiac pacemaker or implanted deﬁbrillator.

The FOMA terminal’s signals may adversely affect the operation of implanted cardiac pacemakers and implanted deﬁbrillators.

If you use an implanted cardiac pacemaker or implanted deﬁbrillator, use the FOMA terminal 22 cm or more away from an implanted cardiac pacemaker or implanted deﬁbrillator.

The FOMA terminal’s signals may adversely affect the operation of implanted cardiac pacemakers and implanted deﬁbrillators.

Patients using electronic medical equipment other than implanted cardiac pacemakers or implanted deﬁbrillators (outside medical establishments for treatment at home, etc.) should check the inﬂuence of radio waves upon the equipment by consulting its manufacturer.

The FOMA terminal’s signals may adversely affect the operation of electronic medical equipment.

Introduction

Page 16

List of materials used



Where it is used Material/Finishing

Outer casing Display surface,

Introduction

Connector terminal Stainless steel/nickel plating + tin plating Connector terminal cover

Camera panel PMMA/Hard coating Side ▲ key, Side ▼ key ABS/UV coating Charging terminal Phosphor bronze/

Operation key surface Display panel PMMA/hard coating

Battery compartment surface Battery

terminal

Operation key surface, Battery surface Private window panel, Private window surface, Infrared data port side of private window surface, Back cover, Battery surface (Hinge side) Infrared data port area Battery compartment surface of back cover Battery compartment surface seal of back cover Charging terminal side cap

Cover PC, Elastomer/UV coating Packing Silicon rubber

Key area, Sheet area, Hinge side cap

Resin part Terminal area

PA/UV coating

PC/UV coating

PMMA/UV coating

PC, Silicon rubber

PP synthetic paper

ABS/UV coating

palladium plating + gold plating Acrylic urethane

PC + ASA/copper plating + nickel plating PPS Beryllium copper/nickel plating +

nickel palladium plating + gold plating

Where it is used Material/Finishing

Battery pack Resin area PC

Screw (Battery compartment) Aluminum-killed steel/nickel plating Hinge area Display side PA/UV coating

Hook for Horizontal Open Style Stainless steel/

Roller area for Horizontal Open Style, Upper area of roller for Horizontal Open Style Horizontal open lever POM Label (Battery compartment) Polyester One-push open button PC Metal part of the one-push open button microSD card slot (Battery compartment)

Label PET Terminal area Glass epoxy substrate/

Private window side, FOMA antenna side Cap PET

Resin part LCP Metal part Stainless steel/nickel plating

nickel plating + gold plating

ABS/UV coating

nickel plating + chrome plating PC + ABS/UV coating

Aluminum/alumite treatment

Page 17

Handling Precautions

General notes

The P-02C is provided with the waterproof performance, however, do not have water entered into the inside of the FOMA terminal, or do not spray water over accessories and optional items.

The battery, adapter, and UIM are not waterproofed. Do not use them in environments, which are high in humidity such as in bathrooms, and do not allow them to get wet from rain. Furthermore, if carrying them against your body, they become moist due to perspiration and the internal parts may become corroded, causing malfunction. If the parts are found to have been damaged due to exposure to the liquids, any repairs will not be covered by warranty, or repairs may not be possible. This may be repaired at a cost if repairs are possible.

Use a dry soft cloth such as the one for cleaning glasses to clean the equipment.

⿠The display may be scratched if it is rubbed

hard with a dry cloth.

⿠Stains may result from droplets of water or dirt

if they are left on the display.

⿠Do not use alcohol, thinner, benzene, detergent

or other solvents for cleaning, otherwise the printing may be removed or discoloration may result.

Occasionally clean the terminals of the equipment using a dry cotton swab, etc.

The soiled terminals deteriorate the connection and might cause power discontinuity or incomplete charging. Wipe the terminals with a cotton swab, etc. Take care not to damage the terminals when cleaning them.

Do not place the FOMA terminal near an air conditioner outlets.

Condensation may form due to rapid changes in temperature, and this may corrode internal parts and cause malfunction.

Do not apply excessive force onto the FOMA terminal and battery pack.

If you put the FOMA terminal in a bag along with many other articles or sit with the FOMA terminal in a clothes pocket, the display, internal circuitry and the battery pack could be damaged or malfunction. Also, if an external device is left connected to the connector terminal (earphone/ microphone terminal), the connector could be damaged, or malfunction.

Do not rub or scratch the display part with metals.

Doing so might cause damage to the part, resulting in trouble or malfunction.

Carefully read each instruction manual attached to battery pack or adapter.

Notes on handling the FOMA terminal

Avoid using in extremely high or low temperatures.

The FOMA terminal should be used within a temperature range of 5°C to 40°C (however, the use at 36°C or higher should be limited to temporal use in a bathroom etc.) and a humidity range of 45% to 85%.

If the FOMA terminal is operated near a land-line phone, television set, radio or other devices in use, it may adversely affect the devices. Operate the FOMA terminal as far away from these devices as possible.

It is recommended that you make separate notes of the information stored in the FOMA terminal and keep such notes in a safe place.

We take no responsibility for any loss of the stored data items.

Do not drop the FOMA terminal or subject it to strong impacts.

Malfunction or damage may result.

Do not insert an external device to the connector terminal (earphone/microphone terminal) at a slant when connecting, and do not pull it out when it is inserted.

Malfunction or damage may result.

Make sure that nothing, such as a strap, gets caught between the parts of the FOMA terminal when you close it.

Otherwise, malfunction or damage may result.

The FOMA terminal becomes warm during use or charging but this is not an abnormality. Use the FOMA terminal as it is.

Do not leave the camera in places exposed to direct sunlight.

Pixels may be discolored or burns may result.

When using the FOMA terminal, ensure that you shut the cover for the connector terminal.

Dust or water might enter into the FOMA terminal, causing malfunction.

Do not use the FOMA terminal with the back cover left removed.

The battery pack might come out, or malfunction or damage may result.

Introduction

Page 18

Do not apply an excessively thick sticker



onto the surfaces of the display or keys.

Otherwise, malfunctioning, damage or problems with operation may result.

While you are using the microSD card,



never take it off or turn off the power of the FOMA terminal.

Data may be erased or malfunction may result.

Do not place magnetic cards or similar



objects near the FOMA terminal or between phone parts.

Magnetic data on cash cards, credit cards, telephone cards and ﬂoppy disks, etc. may be

Introduction

deleted.

Do not bring magnetic substances close to



your FOMA terminal.

Problems with operation may result if items with strong magnetic ﬁelds are brought close to the FOMA terminal.

Notes on handling batteries

Batteries have a limited life.



Though it varies depending on the usage state, you are advised to replace the battery if its usable time is extremely short even when you fully charge it. Make sure that you buy the speciﬁed battery.

Charge the battery in a place with an



appropriate ambient temperature of 5°C to 35°C.

The usable time of the battery differs



depending on the usage environment or its remaining life.

Depending on how the battery pack is



used, it might swell as its operating life becomes short, but this is not a problem.

Note the following points when you store a



battery pack:

Storage in a fully charged state (the state

⿠

immediately after charging is completed) Storage with no battery power left (the state you

⿠

cannot turn on the power of the handset due to

battery drain) These may lower the battery pack’s performance and shorten its operating life. Before storing a battery, check its remaining battery level: it is recommendable, as a general rule, for the battery icon to show two bars or for its remaining battery level to be about 40%.

Notes on handling adapters and desktop holder

Charge the battery in a place with an



appropriate ambient temperature of 5°C to 35°C.

Charge the battery where:



There is very little humidity, vibration, and dust.

⿠

There are no land-line phones, television sets or

⿠

radios nearby.

While you are charging, the adapter may



become warm. This is not a malfunction, so you can keep on using.

Do not use the DC adapter for charging the



battery when the car engine is not running.

The car battery could go ﬂat.

When using the power outlet having the



disengaging prevention mechanism, observe the instructions given in that instruction manual.

Do not give a strong shock. Also, do not



deform the charging terminal.

Malfunction may result.

Notes on handling the UIM

Do not apply more force than is necessary



when installing or removing the UIM. The warranty does not cover damage



caused by inserting the UIM into some other types of IC card reader/writer.

Always keep the IC portion clean.



Use a dry soft cloth such as the one for



cleaning glasses to clean the equipment. It is recommended that you make separate



notes of the information stored on the UIM and keep such notes in a safe place.

We take no responsibility for any loss of the stored data items.

For the environmental protection, bring



any unneeded UIMs to a handling counter such as a docomo Shop.

Do not damage, carelessly touch, or short-



circuit the IC.

Data might be lost or malfunction may result.

Do not drop the UIM or subject it to strong



impacts.

Malfunction may result.

Do not bend the UIM or place something



heavy on it.

Malfunction may result.

Into the FOMA terminal, do not insert the



UIM with a label or sticker pasted.

Malfunction may result.

Page 19

Notes on handling the FeliCa reader/writer

The FeliCa reader/writer function on the



FOMA terminal uses very weak radio waves which do not require to be licensed as radio stations.

The FeliCa reader/writer is operated on



the 13.56 MHz frequencies. When you use another reader/writer nearby, take enough distance between your FOMA terminal and the reader/writer. Further, ensure that there are no radio stations that use the same frequencies.

Caution

Do not use the modiﬁed FOMA terminal.



Using a modiﬁed FOMA terminal infringes the Radio Law.

The FOMA terminals are granted technical regulations conformity certiﬁcation as the speciﬁed radio equipment under the Radio Law and bear a “technical conformity mark as evidence of conformity. Unscrewing the FOMA terminal and modifying internal components void the technical regulations conformity certiﬁcation. Do not use the FOMA terminal in this state, which infringes the Radio Law.

Take special care not to operate the FOMA



terminal while driving.

Holding a mobile phone in your hand while driving is subject to a ﬁne or other penalties. However, this does not apply in unavoidable circumstances when, for instance, responding to someone who is sick or injured or when maintaining public order.

” on the nameplate

Use the FeliCa reader/writer functions in



Japan only.

The FeliCa reader/writer functions on the FOMA terminal have been authorized in compliance with the radio transmission standards in Japan. You might be imposed punishment if you use them overseas.

Introduction

Page 20

Waterproof Performance

Your P-02C comes with the waterproof performance equivalent to IPX5 (former JIS protection standard 5)1 and IPX7 (former JIS protection standard 7)2 with the connector terminal cover and back cover ﬁ rmly closed and no clearance gap and ﬂ oat found in them.

IPX5 means that the P-02C maintains its performance as a phone even

※

after a water jet ﬂ ow has been sprayed over the FOMA terminal from all directions under conditions where water in a volume of 12.5 liters/minute is sprayed from a distance of about 3 meters for at least 3 minutes using a water-pouring nozzle with an inside diameter of 6.3 mm.

Introduction

2 IPX7 means that the P-02C maintains its performance as a phone

※

even after the phone has been gently submerged in a container of still city water to a depth of 1 meter at room temperature, and left in place for about 30 minutes, and then removed from the water.

(Note) This does not mean that the waterproof performance is

guaranteed in all given conditions of actual use. Read this manual thoroughly before use to prevent invasion of water or foreign materials and then to enable you to safely use your FOMA terminal.

You can operate the FOMA terminal in the rain, in your kitchen, in the bathroom, and also around poolside.

In the Rain

⿠You can talk on the phone by holding the phone in the rain with your wet hand without umbrella. (Less than 20 mm/hour of rainfall, and your feet get wet by drops of rain rebounded off the ground) When your hands are wet or water drops remain on the FOMA

※

terminal, do not attach/remove the back cover, nor open/close the connector terminal cover.

Wash

⿠When the FOMA terminal gets dirty, you can slowly swing and wash it in a bowl ﬁ lled with fresh water or tap water at an ambient temperature, or wash it by hand while running a slightly-weak water ﬂ ow from a faucet. ⿠Wash your FOMA terminal with the back cover ﬁ rmly attached and while you are pushing the cover of the connector terminal down.

Soap/detergent

⿠Do not use brushes, sponges, soaps, or detergents for washing. ⿠After rinsing off the FOMA terminal in water, wipe its surfaces thoroughly using a dry cloth, drain off the water (see page 21), and allow the FOMA terminal to dry out naturally.

On Leisure

⿠Do not soak or drop your FOMA terminal into a pool or the sea nor operate it in water. ⿠If pool water or seawater splash the FOMA terminal, wash the terminal by following the prescribed method (see page 18).

Sea/pool

In the Bathroom

⿠Do not soak or drop your FOMA terminal into a bathtub, nor use it in water. ⿠Do not soak the FOMA terminal into spa or water containing soap detergent or bath additive. ⿠Do not directly expose to the strong water ﬂ ows (such as water jets from a faucet or shower head strong enough to feel pain on the skin) that exceed the standard (see page 18). ⿠Avoid using the FOMA terminal for a long time in the bathroom. ⿠If you take your FOMA terminal from a cold place to a warm bathroom, condensation might result because of sudden change in ambient temperature. Warm it up until ambient temperature is restored, and then take it to the bathroom.

Spa/bath salts

In the Kitchen

⿠Do not spray liquids other than fresh water or tap water at room temperature onto the FOMA terminal or soak the terminal in them. ⿠Do not spray hot water or cold water onto the FOMA terminal or soak it in them.

Page 21

⿠

Important Information before Use

Before using the FOMA terminal, make sure that you attach

⿠

the back cover ﬁrmly after tightly closing the connector terminal cover. If there is any small particles (ﬁne ﬁbers, hair or grains of sand) between the covers and the phone, water could ﬁnd its way inside the phone. When attaching the back cover after closing the connector terminal cover, ensure that there is no particles or dirt on or around these parts (especially the packing). ⿠Ensure that the connector terminal cover and back cover are closed tightly and that none of these covers are askew. If the covers are not closed tightly, water could ﬁnd its way inside the FOMA terminal. To keep the waterproof performance, you need to replace parts

⿠

without fail once two years regardless whether any abnormality with the FOMA terminal is found or not. You are charged for replacement of parts. Take your FOMA terminal to a repair counter speciﬁed by DOCOMO.

Opening/Closing the Connector Terminal Cover

■

Opening the connector terminal cover



Hook your ﬁnger over the groove, pull

①

out the cover to direction A, and turn it as direction B.

Closing the connector terminal cover



Align the connector terminal cover in

①

parallel with the FOMA terminal, and while holding its base ﬁrmly, push it into place.

Ensure that no ﬂoat is found with the

②

connector terminal cover as a whole.

Base

Hook

Removing/Attaching the Back Cover

■

Removing the back cover



From the “ ” part on the

①

FOMA terminal, lift the back cover up in the direction of the arrow mark, and remove.

The back cover should be

⿠

ﬁrmly closed for maintaining waterproofness. Opening the cover forcibly may injure your nails or ﬁngers.

Attaching the back cover



Correctly ﬁt the claw at the upper part of the back cover into

①

the FOMA terminal, and ﬁt the claws at the left, right, and bottom into the notches for attaching.

Upper claw

Packing

Rear surface of back cover

Push the seven

②

on the sticker, and ensure that no ﬂoat is found anywhere on the cover.

marks printed

󰿥

Introduction

Page 22

Caution

About FOMA terminal



Do not wash the FOMA terminal with a washing machine or

⿠

ultrasonic cleaner. Never charge the battery when it gets wet.

⿠

Do not leave the FOMA terminal with drops of water remained on.

⿠

· The connector terminal might be short-circuited.

· Water might enter into the inside of the FOMA terminal through the keys or hinges. In cold districts, drops of water on the FOMA

Introduction

terminal might freeze, resulting in malfunction.

If the FOMA terminal gets wet, keep the back cover attached and the connector terminal cover closed, drain off the water (see page

21), and immediately wipe off the moisture remaining on the FOMA

terminal with a clean dry cloth. Do not drop the FOMA terminal nor give a shock to it.

⿠

The deterioration of the waterproof performance might result depending on the damage. Do not soak the FOMA terminal in hot water, use in a sauna, nor

⿠

expose to hot wind currents such as those of a dryer. The FOMA terminal does not ﬂoat on water.

⿠

Do not directly expose to the strong water ﬂows that exceed the

⿠

standard (see page 18) or submerge the mobile phone in water. Do not directly place the FOMA terminal on sandy beaches.

⿠

· Sands enter into the holes on the microphone, earpiece, or speakers may reduce the volume.

· If you operate the FOMA terminal with water drops or sands adhered to, sound might be deteriorated.

· Even the slightest sands entered from the connector terminal cover or back cover could cause water to enter the inside of the FOMA terminal.

About the connector terminal cover and back cover



Do not open or close them with gloves put on hands.

⿠

Fine dirt might adhere to the contact surface of the packing. Be careful that no ﬁbers adhere to the packing when you try to wipe

⿠

off moisture with a clean dry cloth. Do not peal the packing off. Also do not insert something pointed at

⿠

the head into the clearance of the connector terminal cover. The packing is damaged, resulting in water to enter into the FOMA terminal. If the packing for the connector terminal cover is damaged or

⿠

deformed, replace them at a repair counter speciﬁed by DOCOMO. If the back cover is broken, replace it with new one.

⿠

Otherwise liquid such as water enters into the inside of the FOMA terminal through broken portions, and an electric shock or corrosion of the battery pack could result. When the FOMA terminal gets wet with the connector terminal

⿠

cover or back cover left open, water enters inside, and an electric shock or malfunction could be caused. Do not use it as is, but turn off the power, remove the batter y pack, and then take it to a repair counter speciﬁed by DOCOMO.

About microphone, earpiece, and speakers



Do not thrust something pointed at the head into the holes on

⿠

microphone, earpiece, or speakers. Do not leave water drops adhered to them. It might happen that

⿠

communications are disabled.

Others



Accessories and optional items are not waterproofed. When you

⿠

watch 1Seg programs with your FOMA terminal attached to the desktop holder provided, do not operate it in a bathroom, shower room, kitchen, or lavatory where water is used, even if you do not connect to AC adapter. It is not that the waterproof performance is guaranteed in all given

⿠

conditions of actual use. If the damage is found to be caused by your mishandling of the FOMA terminal as a result of our inspection, the guarantee is not supported.

Page 23

Draining Water

If you operate the FOMA terminal with water drops left adhered to,

⿠

the volume level from the speakers might be decreased or sound quality vary. Moisture may have entered inside through the clearance gap of the

⿠

keys or hinges. Follow the procedures described below to wipe moisture off the FOMA terminal:

Wipe completely moisture off the surface of the FOMA

①

terminal with a clean dry cloth.

Securely take hold of the FOMA terminal, and ﬁrmly swing

②

each surface at least 20 times until no moisture sprays off.

Lightly push the FOMA terminal against a clean dry cloth,

③

and wipe moisture off the clearance gap of the microphone, earpiece, speaker, keys, or hinges.

Do not directly wipe moisture out of joint gap using a cotton

⿠

swab, etc.

Fully drain moisture and then operate the FOMA terminal.

④

Even when you follow the procedures for draining water as

⿠

described above, moisture might remain in the FOMA terminal. Therefore, use the FOMA terminal after allowing it to dry out naturally. Also, take care to keep any objects you do not want to get wet away from the FOMA terminal since water may leak out from the FOMA terminal.

When Charging Battery

Accessories and optional items are not waterproofed. Check the following before and after charging:

Never charge the battery with the FOMA terminal left wet. If the

⿠

FOMA terminal gets wet, drain and wipe off moisture with a clean dry cloth and then charge. When you charge the battery with the connector terminal cover

⿠

open, ﬁrmly close it after charging. To prevent water from entering inside through the connector terminal, you are advised to use the desktop holder provided for charging. Do not touch the AC adapter and desktop holder with your hands

⿠

wet. Do not use the AC adapter and desktop holder in a bathroom,

⿠

shower room, kitchen, and lavatory where water is used.

Introduction

Page 24

Before Using

Attaching UIM (FOMA Card)/ Battery Pack

To insert the UIM/battery pack, remove the back cover, and insert. (See page 19)

Insert the UIM.

With the golden IC surface downward, push the UIM slowly to the end while pressing surface.

⿠Take care not to damage the IC portion.

Basic Operation

When you remove the UIM

⿠Pull it out slowly while sliding.

Cut

Attach the battery

Projection

pack.

With the arrow mark facing up, ﬁ t the tab side of the battery pack to the FOMA terminal securely, and then push the battery pack in direction B while pressing it against direction A.

When you remove the battery pack

Lift the battery up using the projection of it.

⿠Ensure that you turn off, close, and take hold of the FOMA terminal when you install or remove the UIM or battery pack. ⿠You cannot use the UIM (blue) on your FOMA terminal. If you have that blue one, have it replaced at a docomo Shop.

Arrow mark

The UIM is an IC card that holds your

About UIM

information such as phone numbers. You cannot use the FOMA terminal for communications such as voice/videophone calls, i-mode, or sending/ receiving mail, unless the UIM is inserted.

Page 25

Charging

Charging Using Desktop Holder

■

Call/Charging indicator

Lock claw

AC Adapter

Connector

Engraved surface (down side)

With the engraved surface of the

connector of the AC Adapter (option) face down, plug the connector straight into the connector terminal of the desktop holder.

Pull out the AC Adapter’s plug, and

plug it into a household power socket of 100 V AC.

Put the bottom of the FOMA terminal

into the stopper of the desktop holder (A) to ﬁ t the head to the lock claw, and then depress the FOMA terminal until it clicks (B).

⿠Be careful that a commercial strap is not caught between the FOMA terminal and desktop holder.

Desktop

Holder

Stopper

Power socket

AC Adapter’s plug

When charging is completed, hold the

desktop holder with ﬁ ngers and lift up the head of FOMA terminal to remove.

Charging Using AC Adapter

■

Power socket

AC Adapter

Open the cover of the connector terminal.

AC Adapter’s plug

Connector

Engraved surface

Call/Charging indicator

Cover

Connector terminal

Release buttons

(See page 19)

⿠To charge the battery, place the cover of the connector terminal as illustrated.

Insert the connector with the engraved

surface facing up until it clicks.

⿠For detaching, pull out the connector horizontally while pressing the release buttons. Malfunction could result if you try to pull it forcibly. ⿠When charging starts, the Call/Charging indicator lights in red. When charging is completed, it turns off.

Basic Operation

Page 26

Turning Power ON

Basic Operation

The Initial Setting display appears when any of Initial Setting items have not been set. In that case, follow on-screen instructions.

Press and hold -h for at least one second.

After the Wake-up display and notes of waterproof are displayed, the Stand-by display appears.

To turn off the power

Press and hold -h for at least two seconds.

Conﬁ guring Initial Setting

The Initial Setting display appears when you turn on the power for the ﬁ rst time.

Set your Terminal Security Code.

You can set your Terminal Security Code required for setting functions.

⿠“0000” is set at purchase.

Set Keypad Sound.

You can select whether to play a keypad sound.

Set the size of fonts.

You can set the size of fonts on the display at a time.

Page 27

Checking Your Own Phone Number

Switching to English Display

from the Stand-by

▶

display

▶

Own number

You can press tabs.

⿠From the display on the right, press +l( name, mail address, etc. ⿠Refer to “Mobile Phone User’s Guide [i-mode] FOMA version” for how to check or change your mail address.

Phonebook

to switch the

+No

) to store your

You can check your own phone number also by pressing from the Stand-by display.

+m-0

Own number

from the Stand-by display

▶



󱽄



󱽄



Select “English (

⿠The “

バイリンガル

on the UIM.

(Set./Service) (Display) ( Select language)

)”.



(Select language)” setting is saved

Basic Operation

Page 28

Screen Explanation

Viewing Display/Icon

Battery level (estimate)

Full Low

⿠When is shown, charge the battery. ⿠Depending on the usage state, the battery level indication might signiﬁ cantly vary.

Radio waves reception level (estimate)

Basic Operation

Strong Weak

··········· You are out of the FOMA service area or radio waves do not reach.

(black) ···eco Mode is set.

(gray) ····Auto eco Mode is set.

··············Unread i-mode mail or SMS messages exist.

············New i-concier information exists.

·············

A microSD card is inserted.

Status icon

········Vibrator is set.

········Ring Volume is set to “Silent”.

········In Manner Mode

····An alarm is set.

········· View Blind is set.

········The number of record messages

·········The number of videophone record messages

Here are given descriptions of the main icons. For descriptions of other icons appearing on the display, you can get them following the procedures as shown below:

from the Stand-by display

󱽄

Display󱽄Icons

󱽄

Set./Service

Page 29

Notiﬁ cation icon

···

New i-mode mail or SMS

···Missed call

····· Record message

····· Videophone record message

···

The mode has automatically changed to eco Mode (ECO NAVI)

··· 1Seg has automatically terminated (ECO NAVI)

Desktop icon

·····i-concier

·····



····Battery/eco mode set.

···Picture album

·····

P-SQUARE (Maker site)

⿠“P-SQUARE” is available in Japanese only.

Proceed to respective functions from icons

You can proceed to respective functions from “Status icon”, “Notiﬁ cation icon”, and “Desktop icon”.

from the Stand-by display

+Oo

▶

Use

to highlight an icon

+Mo

(Guide)

▶

(

+Oo

)

Private Window

Various information is displayed on the Private window like the following examples: Information is displayed for about 15 seconds in cases such as when you press .</.> with the FOMA terminal closed.

Clock Receiving a call

When a missed call, new mail or message exists

Status Display Press

Missed calls Missed call Display the missed

New mail messages/New Messages R/F

For Messages R/F, the FeelMail image is not played

※

back.

Changing Clock Display

■

You can change displayed contents by pressing .< while clock is shown.

Icons and Time

Dialing

call record.

New mail FeelMail image

is played back.

Date and Day of week

Time only

※

Basic Operation

Page 30

Navigation Displays and Key Operations

Key Operations in Normal Style

■

Key operations you can perform while you are operating a function are shown at the bottom of the display. (Navigation displays)

Key assignments and basic navigation displays



Basic Operation

Operations you can perform with the +l

󰿿

key.

Operations you can perform with the +m

󱀀

key.

Operations you can perform with the key.

󱀁

Directions in which you can scroll and select items with the

Operations you can perform with the +c

󱀂

key.

Operations you can perform with the +i

󱀃

key.

+Mo

key.

+Oo

Navigation Displays while Dialing

Enter numeric strings on the Stand-by display. Then key operations of the several available function appear on the display according to the number of digits. You can now get the target function with a single key press. You can start up the functions like Calculator, Schedule, Alarm etc. <Example> Enter “0218” to display Schedule of

February 18th.

1. Press-

2. Press

0-2-1-8

+Zo

from the Stand-by display.

+Zo

Navigation displays

Page 31

Command navigation key



+Zo

Moves the cursor or

⿠

highlighted display up. (Hold down to scroll continuously.) Scrolls the page up.

⿠

+Vo

Moves the cursor to the

⿠

right. Scrolls forward page by

⿠

page. (Hold down to scroll continuously.)

+Oo

Fixes the operation.

⿠

+Co

Moves the cursor to the left.

⿠

Scrolls back page by page. (Hold

⿠

down to scroll continuously.)

Key Operations in Horizontal Open Style

■

+Xo

Moves the cursor or

⿠

highlighted display down. (Hold down to scroll continuously.) Scrolls the page down.

⿠

Key operations you can do are shown the same way as in Normal Style at the bottom of the display.

While the vertical display is shown,

⿠

you can operate the same way as in Normal Style even in Horizontal Open Style. Even when you have operated on

⿠

the horizontal display, the display might switch to the vertical display depending on the function.

Difference in key operations

Key assignments differ between Normal Style and Horizontal Open Style. Follow and operate respective Navigation displays. <Example: Displaying the Function Menu on the Inbox

Folder list>

In Normal Style



Press +i.

In Horizontal Open Style



Press +c.

Basic Operation

Page 32

Menu Operation

Main Menu

■

Press +m from the Stand-by display to show Main Menu.

Menu icons

Menu icon name

In this manual, the item names shown here are described in operating

Basic Operation

Stand-by display Main Menu

Use Functions categorized by the menu items are displayed. Repeat selecting items to call up the target function.

⿠

to highlight a menu icon and press

+Mo

You can press -r to return to the previous display.

When you press -h from any display, the Stand-by

display returns.

You can display some functions by pressing +m + menu number from the Stand-by display. See “Function List” for the menu items and menu numbers of each function. (See page 92) In this manual, the descriptions of operating procedures are given mainly starting with the Stand-by display.

procedures, etc.

( ).

+Oo

Horizontal Open Menu

■

Press +m from the horizontal Stand-by display to open Horizontal Open Menu that enables you to quickly access the functions that are available to the horizontal display.

Some operating

⿠

procedures and menus shown on the Horizontal Open Menu differ from those on the display in Normal Style as described

Simple Menu

■

Simple Menu is a menu focusing on only basic functions for easy operation. By setting “Menu icon setting” to “Simple menu”, you can show the Simple Menu by pressing +m from the Stand-by display.

Some operating procedures or items

⿠

which appear on the display in Simple Menu differ from the ones described in this manual.

in this manual.

Page 33

Function menu

When “

” is displayed at the lower right of the display, you can use functions such as Store, Edit, and Delete by pressing +i.

<Example> Display the Function menu of a Phonebook

entry

When a function can be operated also by a key, the

⿠

numeric key number or other marks may appear on the right of the function name.

Functions Starting with Simple Operation

Depending on the function, you can start it either by selecting a menu item or by key operation from the Stand-by display. The following are the functions you can start by pressing keys for at least one second.

Key Performance

+Oo

Switches Key Lock on/off.

+Xo

Shows the Registration display for Phonebook entries.

Executes Check New Messages.

Shows the Software list.

-m

Sets/Releases IC Card Lock.

Starts 1Seg.

-5

Sets/Releases eco Mode.

-6

Sets/Releases Personal Data Lock.

-8

Switches View Blind on/off.

-a

Activates/Deactivates Public mode (Drive mode).

-s

Activates/Deactivates Manner Mode.

Operations while the FOMA terminal is closed



Key Performance

Activates/Deactivates Manner Mode.

Basic Operation

Page 34

Using Guide

You can search and check the operating methods of the functions you want to know and use. You can execute some functions from “ This function is available in Japanese mode only.

from the Stand-by

▶

display

󱽄



Enter a keyword or select

Basic Operation

a way of searching.

Highlight each item and press +l ( ). The detailed operating methods are displayed.

LifeKit



(Guide)

(Guide)”.

Page 35

Character Entry

You can enter characters on the Registration display for Phonebook entries or the Composition display for mail messages, etc.

Switch between input modes.

Each time you press +l( ), input modes are switched.

abc: Alphabet input mode

123: Numeral input mode

: Kanji/Hiragana input mode



: Katakana input mode



Enter characters.

By repeatedly pressing a numeric key, you can enter other characters assigned to the key.

<Example> When you press

Kanji/Hiragana input mode

「か→き→く→け→こ」

Katakana input mode

「ｶ→ｷ→ｸ→ｹ→ｺ→2」

Alphabet input mode

「a→b→c→A→B→C→2」

Numeral input mode

「2」

-2

Other key operations

(

+m +c

-s

-a

-d

-r

): Enter pictograms.

(

): Enter smileys.

(for at least one second): Enter symbols.

: Enter a line feed.

(You can switch between uppercase and lowercase or enter “゛” and “゜” by pressing this key after you enter a character.)

(for at least one second): Undo the ﬁ xed/erased

: Clear text.

Convert/ﬁ x characters.

1. Press to be converted.

2. Press

onto the candidate list.

3. Press

conversion candidate.

4. Press

to specify the area

+No

to move the cursor

+Bo

to select a

+Mo

to ﬁ x the character.

+Oo

characters.

Basic Operation

Page 36

<Example> Entering “



” in a text memo.

from the Stand-by

display

▶

Text memo

▶

Select <Not recorded>.

Enter hiragana characters

Basic Operation

in Kanji/Hiragana input mode.

Press -4 once and

た→

once.

Press -4 once and -a

だ→

once.

Press -5 ﬁ ve times.

の→

Press -2 once.

か→

Press -3 twice.

し→

⿠When a character on the same key comes after a character such as “あ” and “い”, press the cursor, and enter the next character.

▶

Stationery

+Vo

Use

to move the

+Co

cursor onto “”.

Use

to move the

+Bo

cursor onto the candidate

▶

Use

list

to move

+Vo

“



(

Use

+Bo

candidate list “

” and press Oo(



to highlight

+Mo

” and press

to move the cursor onto the

▶

Use

to highlight

+Mo

Page 37

Sound/Screen Setting

Changing Ring Tone

<Example> Changing the ring tone for incoming voice

calls

from the Stand-by display

▶

Set./Service▶Sound

▶

Select ring tone

Select “Phone”.

⿠Press +l( ) to check the content actually played back or displayed. ⿠To set a ring tone for mail messages, videophone calls, and so on, select the corresponding item.

Select “Select ring tone”.

Select a type of ring tone.

Select a folder▶Select a ring tone.

Adjusting Ring Volume

<Example> Adjusting the ring volume for incoming

voice calls

from the Stand-by display

▶

Set./Service▶Sound▶Ring volume

Select “Phone”.

⿠To adjust ring volume for mail messages, videophone calls, and so on, select the corresponding item.

Use

to adjust the volume.

+Bo

Setting Vibrator

You can set the vibrator to notify you of incoming calls. <Example> Setting the vibrator for incoming voice calls

from the Stand-by display

▶

Set./Service▶Incoming call

▶

Vibrator

Select “Phone”.

⿠To set a vibrator for mail messages, videophone calls, and so on, select the corresponding item.

Select a pattern.

Basic Operation

Page 38

Using Manner Mode

With a single key press, you can set a tone from the FOMA terminal such as a ring tone, keypad sound, and alarm sound silent. When you start Manner Mode, not a sound but the vibration notiﬁ es you of incoming calls or messages.

Basic Operation

Using Original

You can use “Original” to tailor your FOMA terminal to how it works while Manner Mode is ON.

1. +m from the Stand-by display

▶

Incoming call▶Manner mode set▶Original

2. Set each item.

3. Press +l(

⿠Even in Manner Mode, the shutter tone and focus lock tone of the camera, and the start/end tones of

the voice recorder sound.

Press and hold -s for at least one second from the Stand-by display.

“ ” appears on the Stand-by display.

To release

Perform the same operation.

▶

Set./Service

Setting Keypad Sound OFF

You can silence a Keypad sound for when you press a key.

from the Stand-by display

▶

Set./Service▶Sound▶Keypad sound

Select “OFF”.

Changing Display Settings

Changing Stand-by display

■

from the Stand-by display

▶

Set./Service▶Display

▶

Display setting

Select “Stand-by display”.

⿠To set a display for making/receiving calls, or to change a battery icon, select the menu that corresponds to that item.

Select a type of image.

Select a folder▶Select an image.

Page 39

Changing Display Brightness

■

You can set Backlight to OFF. Then the display dims, and the key light turns off. You can also set the time that elapses before Power Saver Mode activates.

from the Stand-by display

▶

Set./Service▶Display▶Backlight

Select “Lighting”▶Select “OFF”.

⿠When “OFF” is set, “ ” appears.

Enter a time [time to saver (in

seconds)].

Making Display Hard to See from

■

People Around

You can set “View blind” to make it harder for the people around you to see the display from oblique angles.

Press and hold -8 for at least one second from the Stand-by display.

“ ” appears on the Stand-by display.

To release

Perform the same operation.

Basic Operation

Power Saver Mode

Power Saver Mode activates when the time set for “time to saver” has elapsed without any operations on the FOMA terminal. The display turns off to reduce battery consumption.

Changing Main Menu Display

■

from the Stand-by display

▶

(

Select a pattern.

)

Page 40

Changing Font Size

■

You can change font sizes at a time.

from the Stand-by display

▶

Set./Service▶Display

▶

Font size setting

Select “Set at one time”.

⿠You can also specify a font size for each function such as “Mail” or “Phonebook”.

Select a font size.

Basic Operation

Changing Machi-chara Setting

■

You can change the Machi-chara image which appears to inform you of missed calls, new mail messages, new i-concier information and others.

from the Stand-by display

▶

Set./Service▶Display▶Machi-chara

▶

Set to Machi-chara

Highlight a Machi-chara image and

press +l(

Using Kisekae Tool

You can set the ring tone, Stand-by display, menu icons and others at a time.

from the Stand-by display

▶

Set./Service▶Kisekae

Highlight a Kisekae Tool ﬁ le and

press +l(

Select “YES”.

⿠Some menu conﬁ gurations change according to the usage frequency depending on the type of the menu.

Reset Menu Icons to Default

1. +m from the Stand-by display

▶

Reset

2. Enter your Terminal Security Code

▶

Select “Reset menu screen”▶Select “YES”.

▶

(

)

Page 41

Changing Illumination

You can set the pattern of the illuminations such as for incoming calls and talking at a time.

from the Stand-by display

▶

Set./Service▶Illumination

Select “All illum. setting”.

⿠To set each illumination separately, select a type of illumination.

Select a pattern.

Play back an Animation on the Private Window

When you set “Illum. when opened”, “Illum. when closed” and “Hourly illumination” to other than “OFF”, the FOMA terminal will display an animation respectively when the phone is opened, closed, and on the hour.

1. +m from the Stand-by display

▶

Illumination

2. Select a type of illumination

▶

Set./Service

▶

Select an item.

Checking Missed Calls and New Mail by Tone and Call/Charging Indicator

With the FOMA terminal closed, you can check for missed calls, new mail and others.

Checking Missed Calls and New Mail

■

by Voice

A voice message announces that you have a missed call or new mail.

⿠This function is available in Japanese mode only.

Press .> while the FOMA terminal is closed.

You are notiﬁ ed by the electronic sound and lighting of the Call/Charging indicator. Double-beep tone: You have a missed call or new mail. Triple-beep tone: You have no missed calls or new mail.

from the Stand-by display

▶



▶ ▶

Select “

(Incoming call)

 



(Set./Service)

(Info notice setting)

(Voice)”.

Basic Operation

Page 42

Switching to the eco Mode

With a single key press, you can set the eco Mode that reduces battery consumption. Changing to eco Mode affects items speciﬁ ed in “eco mode setting”, e.g. dimming the display.

Basic Operation

eco Mode Setting

■

You can set the items for reducing battery consumption for when the eco Mode activates.

from the Stand-by display

▶

Set./Service▶Other settings

▶

Battery/eco mode set.

▶

eco mode setting

Put a check mark for items to be set.

Press and hold -5 for at least one second from the Stand-by display.

“ (black)” appears on the Stand-by display.

To release

Perform the same operation.

Auto eco Mode Setting

■

This setting ensures that the mode will be automatically set to the eco Mode when the remaining battery level has dropped below the set level. “Auto eco mode setting” is set to “ON” in default.

from the Stand-by display

▶

Set./Service▶Other settings

▶

Battery/eco mode set.

▶

Auto eco mode setting

Select “ON”.

Select a battery level.

Select “Notiﬁ cation icon ON”.

When the “Auto eco mode setting” is set to “ON”, “

(gray)” will be displayed. When the mobile phone automatically switches to eco Mode, “ “

(black)” will be displayed and

” will be displayed on the desktop.

Press +l( ).

Page 43

Lock/Security

Various Security Codes

■Caution on security codes ⿠You should avoid using the numbers for security codes such as denoting your birth date, part of your phone number, local address number, room number, “1111” or “1234” that is easily decoded by a third party. Also make sure that you take a note of the security codes you have selected just in case you forget them. ⿠Take care not to let others know your security codes. Even if your security codes are known and used by a third party, we at DOCOMO take no responsibility in any event for the resultant loss. ⿠If you do not remember your respective security codes, you need to bring an identiﬁ cation card such as your driver’s license, the FOMA terminal and UIM to the handling counter of a docomo Shop. For details, contact “docomo Information Center” on the back page of this manual. ⿠The PIN unblocking key (PUK) is described on the application form (your copy) that is handed over to you at a docomo Shop at the time of contract. If your contract has been made at a shop other than a docomo Shop, you need to bring an identiﬁ cation card such as your driver’s license, and the UIM to the handling counter of a docomo Shop, or consult “docomo Information Center” on the back page of this manual.

Terminal Security Code

■

“0000” at purchase

This is a four-to-eight digit number for deleting all ﬁ les or changing settings. When the display for entering the Terminal Security Code appears, enter your four-to-eight digit code and press

+Oo

(

To change

1. +m from the Stand-by display

▶

Lock/Security▶Change security code

Network Security Code

■

▶

Set./Service

Determining at the time of contract

This is a four-digit number required for your identiﬁ cation when you place an order at a docomo Shop, docomo Information Center, or “



(User support)”

site, or when you use respective network services.

⿠“

お客様サポート

(User support)” is available in Japanese only.

To change

From i-mode, you can change your Network Security Code by selecting “iMenu” → “ support)” → “

各種設定（確認・変更・利用）

お客様サポート

settings (Conﬁ rmation/Change/Use)]” → “

証番号変更

i-mode Password

■

(Change Network Security Code)”.

“0000” at the time of your contract

(User

[Respective

ネットワーク暗

This is a four-digit number required for registering/ deleting My Menu, applying for/canceling Message Services or i-mode pay services, etc.

To change

From i-mode, you can change your i-mode password by selecting “iMenu” → “English” → “Options”

“Change i-mode Password”.

→

Basic Operation

Page 44

PIN1 Code/ PIN2 Code

■

For the UIM, you can set two security codes, namely the PIN1 code and PIN2 code. The PIN1 code is a four-to-eight digit number for checking the user each time the UIM is inserted into the FOMA terminal or each time the FOMA terminal is turned on, to prevent the unauthorized use by a third party. The PIN2 code is a four-to-eight digit number for executing Reset Total Cost, using the user certiﬁ cate or applying for the issue of it. When the PIN1 Code/PIN2 Code entry display appears, enter your four-to-eight digit PIN1 code/PIN2 code and press

Basic Operation

⿠If you enter a wrong PIN1 code/PIN2 code three times in succession, the FOMA terminal locks and cannot be used.

To change

1. +m from the Stand-by display

▶

2. Enter your Terminal Security Code

▶

⿠You need to have set “PIN1 code entry set” to “ON” to change the PIN1 code in advance.

(

+Oo

Lock/Security▶UIM setting

Select “Change PIN1 code” or “Change PIN2 code”.

“0000” at the time of your contract

▶

Set./Service

PIN Unblocking Key (PUK)

■

The PIN unblocking key (PUK) is the eight-digit number for releasing the blocked PIN1 code and PIN2 code. You cannot change this code by yourself.

⿠If you enter a wrong PIN unblocking key (PUK) 10 times in succession, the UIM is locked. In that case contact one of docomo Shops.

PIN1 Code Entry Set

■

You can set the FOMA terminal not to work unless you enter your PIN1 code when turning on the power.

from the Stand-by display

▶

Set./Service▶Lock/Security

▶

UIM setting

Enter your Terminal Security Code

▶

Select “PIN1 code entry set”.

Select “ON”▶Enter the PIN1 code.

To release

Select “OFF”.

Page 45

Various Lock Functions

A variety of lock functions is installed on your FOMA terminal such as preventing illegal use of a third party, or protecting your private information.

Lock All You can set your FOMA terminal not

to be used by a third party. You can do no operations other than answering calls and turning on/off the power.

from the Stand-by display

▶

Set./Service▶Lock/Security

▶

Lock all

▶

Enter your Terminal Security Code.

To cancel, enter your Terminal

⿠

Security Code from the Stand-by display.

IC Card Lock You can lock the IC card function.

You cannot use the Osaifu-Keitai, ToruCa download, iC Communication, etc.

1. Press and hold -m for at least one second from the Stand-by display.

To cancel, perform the same

⿠

operation and enter your Terminal Security Code.

Omakase Lock

Personal Data Lock

Key Lock

When you have lost your FOMA terminal or in other cases, you can lock your personal data (such as Phonebook entries) and the IC card function of Osaifu-Keitai by contacting DOCOMO.

For details on Omakase Lock, refer to

⿠

“User’s Guide [Basic Usage]”.

Setting/Releasing Omakase Lock



0120-524-360 (In Japanese only)

Business hours: 24 hours (open all year round)

Unavailable from some IP phones.

※

You can set/release also from the My docomo

⿠

site via your personal computer or other devices. (In Japanese only)

You can lock functions which utilize personal information such as Phonebook entries or schedule events.

1. Press and hold -6 for at least one second from the Stand-by display.

⿠To cancel, perform the same operation and enter your Terminal Security Code.

The keys except -h are disabled.

1. Press and hold

for at least one

+Oo

second from the Stand-by display.

⿠To release, perform the same operation. Even during Key Lock, you can answer

⿠

incoming calls by pressing -d.

Basic Operation

Page 46

Setting Incoming Call Restriction

Rejecting Calls without Caller ID

■

You can set whether to receive (accept) or not to receive (reject) a voice call and videophone call according to the reason for no caller ID. There are three reasons; “Unavailable”, “PublicPhone”, and “User unset”.

from the Stand-by display

▶

Set./Service▶Lock/Security

▶

Call setting w/o ID

Enter your Terminal Security Code

▶

Select a reason for no caller ID.

Basic Operation

Select “Accept” or “Reject”.

⿠If you select “Accept”, you can set a ring tone for incoming calls without caller IDs.

Rejecting Calls from Numbers not

■

Stored in Phonebook

from the Stand-by display

▶

Set./Service▶Lock/Security

▶

Reject unknown

Enter your Terminal Security Code

▶

Select “Accept” or “Reject”.

Resetting to Default

Resetting the Function Settings to Default

■

You can reset the items on “Function List”, which are indicated by

⿠The items indicated by which do not return to their default settings or state.

from the Stand-by display

▶

Set./Service▶Other settings

▶

Reset settings

Enter your Terminal Security Code

▶

Select “YES”.

Deleting Stored Data at Once

■

You can delete all the stored ﬁ les together and each function setting will return to the default.

from the Stand-by display

▶

Set./Service▶Other settings

▶

Initialize

Enter your Terminal Security Code

▶

Select “YES”.

. (See page 92)

might include the functions

Page 47

Call Telephone

Making a Call/Videophone Call

Making a Call by Entering the Phone

■

Number

From the Stand-by display, enter a

phone number starting with a city code. Press -d to make a call.

⿠To make a videophone call, press +c( ) instead of d.

Press -h to end the call.

Making a Call from Phonebook

■

<Example> Search a Phonebook entry by the name

stored in Phonebook

Press

Select “Name?”.

Enter the reading of the name from the ﬁ rst character. From the second search, the search-method-selection display does not appear. To show it again, press

⿠You can use another search method such as “Phone number?”, and “Mail address?”.

from the Stand-by display.

+Xo

-r

Connect

⿠This FOMA terminal has no inward-facing camera. Therefore, the image sent to the other party is a Chara-den image, still image, or image being shot by the outward-facing camera.

You can put a call on hold by pressing a call. You can release held call by

pressing

+Oo

(

) during

(

Enter a part of the name

⿠If you enter nothing and press display all Phonebook entries.

Select a Phonebook entry.

When an entry contains multiple phone numbers, press

Press -d to make a call.

to select a desired phone number.

+Mo

⿠To make a videophone call, press +l( ) instead of d.

▶

+Bo

; then you can

+Bo

Page 48

■

Connect

Making a Call with Redial/Received Calls

Press

calls) from the Stand-by display.

Select a call record.

Press -d to make a call.

⿠To make a videophone call, press +l( ) instead of d.

(Redial) or

+Vo

(Received

+Co

Notifying Your Caller ID on the Other Party’s Phone

from the Stand-by display

▶

Set./Service▶NW services

▶

Caller ID notiﬁ cation

Select “Activate/Deactivate”.

Select “Activate”.

⿠If you hear the guidance requesting your caller ID, either set the Caller ID notiﬁ cation or add “186” ﬁ rst and then try calling again.

Making an International Call

■

You can use WORLD CALL to make an international call from Japan.

⿠Contact “docomo Information Center” on the back page of this manual for inquiries about WORLD CALL. ⿠When using international carriers other than DOCOMO, contact them.

(for at least one second) from the

-0

󱽄

Stand-by display

Enter numbers in order of country/area codearea code (city code)destination phone number.

⿠When the area code (city code) begins with “0”, enter the area code without “0”. However, include “0” when making a call to some countries or regions such as Italy.

Press -d.

⿠Press +c( ) to make a videophone call.

Select “Dial”.

⿠DOCOMO videophones conform to “3G-324M standardized by the international standard 3GPP”. You cannot connect to the videophone using a different format.

Page 49

Receiving a Call/Videophone Call

A call comes in.

The ring tone sounds and the Call/Charging indicator lights.

Press -d to answer the call.

When a videophone call comes in

You can receive the videophone call the same way as with a voice call. The substitute image is sent to the other party.

Press -h to end the call.

Adjusting Earpiece Volume

Press .< or .> during a call.

Press .</.> to adjust the earpiece

volume.

When You cannot Answer a Call

Activate Record Message

■

By activating Record Message, you can record a caller’s voice/video message when you cannot answer the call.

⿠When a call comes in, an answer message is played back after the ring time elapses. Then, the caller’s voice is recorded with audio or video.

▶

from the Stand-by display

▶

Rec.msg/voice memo

▶

Record message setting

Select “ON”.

Select an answer message

▶

Enter a ring time (seconds).

When a voice or video message is recorded as Record Message, the notiﬁ cation icon like “ appears in the Stand-by display. Select “ either the voice or video message.

” or “ ” icon to play

” or “ ”

LifeKit

Connect

Page 50

Using Public Mode (Drive Mode)

■

Once you activate Public mode (Drive mode), the guidance is played back telling that you cannot answer the call as you are currently driving or in a place where you should refrain from speaking on the phone. Then the call is disconnected.

Press and hold -a for at least one second, from the Stand-by display.

“ ” appears on the Stand-by display.

Connect

To deactivate

Perform the same operation.

When a call comes in during Public mode (Drive mode), the ring tone does not sound and the record is stored in “Received calls”. The alarm does not sound even when the

speciﬁ ed alarm time comes.

Using Public Mode (Power Off)

■

Once you activate Public mode (Power off), the guidance is played back when receiving a call while the power is off, telling that you cannot answer the call as you are currently in a place where the power should be turned off (hospital, airplane, around priority seat in a train, etc.). Then the call is disconnected.

Enter

a-2-5-2-5-1

from the

Stand-by display.

Press -d.

To deactivate

1. Enter

2. Press -d.

-a-2-5-2-5-0

display.

from the Stand-by

Page 51

Using Various Network Services

Network services available

■

The following are the DOCOMO network services available for the FOMA terminal.

The network services are not available when you are out of the service area or out of reach of radio waves.

⿠

For details, refer to “Mobile Phone User’s Guide [Network Services]”.

⿠

For subscriptions and inquiries, contact “docomo Information Center” on the back page of this manual.

⿠

Service Voice Mail Service Required Charged Call Waiting Service Required Charged Call Forwarding Service Required Free Nuisance Call Blocking Service Caller ID Notiﬁcation Service Caller ID Display Request Service Dual Network Service Required Charged

“OFFICEED” is a pay service that is available on a subscription basis.

⿠

For details, refer to the DOCOMO corporate service website (in Japanese only). http://www.docomo.biz/html/service/ofﬁceed/ “Deactivate” does not mean that the contract for Voice Mail Service, Call Forwarding Service or other services is

⿠

canceled. When new network services are provided by DOCOMO, you can add them as menus.

⿠

The outlines of the each network service in this manual are described along with the menus of the FOMA

⿠

terminal.

Application Monthly fee

Not required Not required Not required

Free Free Free

Service English Guidance Multi Number Required Charged 2in1 Required Charged Public mode (Drive mode) Public mode (Power off) OFFICEED Required Charged Melody Call Required Charged

Application Monthly fee Not required

Not required Not required

Free

Free Free

Connect

Page 52

Using Voice Mail Service

■

from the Stand-by display

▶

Set./Service▶NW services

▶

Voice mail

Using Call Waiting Service

■

from the Stand-by display

▶

Set./Service▶NW services

▶

Call waiting

Connect

To activate the service

1. Select “Activate” ⿠You can also specify a ring time.

To play back the message

1. Select “Play messages”

or “Play (videophone)”

2. Operate following the voice guidance. ⿠The display for selecting “Play (voice call)” or “Play (videophone)” does not appear when only either type of message is recorded.

▶

Select “YES”.

▶

Select “Play (voice call)”

Select “YES”.

To activate the service

1. Select “Activate”

Answer an Incoming Call during a Call

Press -d. Each time you press -d, you can switch the parties you can talk with.

Using Call Forwarding Service

■

from the Stand-by display

▶

Set./Service▶NW services

▶

Call forwarding

To activate the service

1. Select “Activate”

▶

Select “YES”. ⿠You can set the phone number of forwarding destination or ring time as well.

▶

Select “YES”.

▶

Select “Activate”

Page 53

Emergency Call

Emergency Calls Phone number

Calls to police 110 Calls to ﬁre station and ambulance 119 Calls for accidents at sea 118

This FOMA terminal supports “Emergency Location Report”. When you make an emergency call such as at

⿠

110/119/118, information about the place where you are dialing from (location information) is automatically notiﬁed to emergency-response agencies such as police stations. It might happen that your correct location is not detected by emergency-response agencies depending on the location you dial from or radio wave conditions. When you do not notify your phone number such as by adding “184” by every call, your location information and phone number are not notiﬁed. However, when an emergency-response agency has judged that the location information and phone number should be detected because of emergency priority such as for protection of human life, it might get location information and phone number regardless of your setting. Areas and timing “Emergency Location Report” introduced vary depending on the preparation of respective emergency-response agencies. When you make a call at 110/119/118 from the FOMA terminal, tell an operator that you are calling from a mobile

⿠

phone and let them know your phone number, and then clearly tell where you are currently around, so that police/ ﬁre station can make a conﬁrmation call to your mobile phone. In addition, stay at the current location while talking preventing the call from being disconnected. Do not turn off the power immediately, and make sure to place your phone standby for at least 10 minutes after the call. You might not be connected to regional police/ﬁre station depending on the area where you are calling from.

⿠

When using the videophone function of the FOMA terminal to place an emergency call to 110, 119 or 118, the call

⿠

will automatically be made as a voice call.

Connect

Page 54

Using Overseas

International Roaming (WORLD WING) is a service that allows you to use the FOMA terminal with the phone number and mail address you use in Japan, in a service area of the overseas carrier partnered with DOCOMO. It enables you to continue using the voice call, SMS and i-mode mail settings without having to make any changes.

Concerning the areas where the service is supported:

⿠

This FOMA terminal is available within the service area of 3G network, and in the countries/regions supporting 3G 850MHz. Check the areas where you can use the service. Refer to the following before you use this FOMA

⿠

terminal overseas:

Connect

・ “海外ご利用ガイド

in “My documents” in Data Box

“Mobile Phone User’s Guide [International Services]”

・

DOCOMO International Services website

・

“海外ご利用ガイド

in Japanese only.

For the country/area codes, international call access

⿠

codes, and international preﬁx numbers for the universal number, refer to “Mobile Phone User’s Guide [International Services]” or the DOCOMO International Services website. A fee charged for overseas use (call fee, packet

⿠

communication fee) differs from that of in Japan.

(Overseas use guide)” pre-installed

(Overseas use guide)” is available

Available Service Overseas

■

Communication Service 3G

※

Voice call Videophone call

※

SMS

※

i-mode i-mode mail i-Channel i-concier i-Widget Packet communication by connecting with a personal

computer

: Available

○

1 When using 2in1, you cannot make calls using your B number.

※

When using Multi number, you cannot make calls using an additional number.

2 If the destination is a FOMA terminal, enter the other party’s

※

phone number as you do in Japan.

3 You need to establish i-mode International Settings.

※

4 You need to establish i-Channel International Settings. You are

※

charged a packet communication fee for automatically updating the basic channel information as well (which, in Japan, is included in the i-Channel fee).

5 You need to establish i-concier International Settings. You are

※

charged a packet communication fee for each information you receive.

6 You need to establish i-Widget roaming settings. When you

※

show an i-Widget display, multiple Widget Appli programs might start communication. In that case, you are charged a packet communication fee for each communication.

Some services are not available depending on the overseas carrier

⿠

or network. For connectable countries, regions, and overseas carriers, refer to “Mobile Phone User’s Guide [International Services]” or the DOCOMO International Services website.

※

※3※

※

○ ○ ○ ○ ○

○ ○ ○

○

Page 55

Making a Call to Outside the Country

■

You Stay in

(for at least one second) from the

-0

▶

Stand-by display

Enter numbers in order of country/area code→area code (city code)→destination phone number.

⿠Enter “81” as a country/area code when you make an international call to Japan. ⿠When the area code (city code) begins with “0”, enter the area code without “0”. However, include “0” when making a call to some countries or regions such as Italy.

Press -d to make a call.

⿠Press +c( ) to make a videophone call.

Making a Call in Country You Stay

■

From the Stand-by display enter a

phone number.

Press -d to make a call.

⿠Press +c( ) to make a videophone call.

Making a Call to WORLD WING User

■

Overseas

When you make a call to a person who is also internationally roaming, make the call the same way as to make international calls to Japan even if he/she is in the country you stay at.

Mail

Sending i-mode Mail

Once you subscribe to i-mode, you can exchange e-mail messages over the Internet. You can attach less than 2 Mbytes of up to 10 ﬁ les (photos, moving pictures, etc.) with body text added. For details on i-mode mail, refer to “Mobile Phone User’s Guide [i-mode] FOMA version”.

from the Stand-by display

▶

(

Enter each item.

Press +l( ).

Select “OK”.

)

Enter a destination (mail address). Enter a subject. Select a ﬁ le such as an image.

Enter text. Operate Auto Deco-mail.

Connect

Page 56

Sending Deco-mail

You can change the color or size of characters or background color, or insert images or Deco-mail pictograms.

from the Stand-by display

▶

Enter an address and subject.

Select the text ﬁ eld

Connect

▶ ▶ ▶

decorations from the palette

▶

(

⿠You can also select “Template” to create Deco-mail.

(

-i

Decorate mail Select one of

▶

(

+Oo

)

Enter text

)

Palette

Sending Decome-Anime

You can create impressive messages by inserting text or images into a Flash ﬁ le.

from the Stand-by display

▶

Create new Decome-Anime

Enter an address and subject.

Select the text ﬁ eld

▶

Select “Phone”

▶

Highlight a DecomeAnime template and press +l(

Edit characters and images

▶

(

)

Press +l( ).

Select “OK”.

Press +l( ).

Select “OK”.

Page 57

Displaying Received i-mode Mail

▶

from the Stand-by display

Select a folder.

Select an i-mode mail message.

When you receive an i-mode mail message,

” appears on the Stand-by display.

“

Inbox

Replying to i-mode Mail

■

Press +l( ) while an i-mode mail

is displayed.

Enter each item.

Press +l( ).

Select “OK”.

Checking New i-mode Mail

■

You can check the i-mode Center for a new mail message or Message R/F.

Press and hold +l for at least one second from the Stand-by display.

When you receive an i-mode mail message or Message R/F, the following display appears.

Number of messages Select an item to show the display for selecting a message.

Connect

Page 58

Sorting i-mode Mail

■

You can use “Auto-sort” to sort received/sent i-mode mail messages into a folder such as “Business” or “Friend” which has been created in advance. <Example> Sorting mail messages, which come from

the address stored in the Phonebook, into a folder

Highlight a folder from Inbox Folder list

and press +i(

▶

Auto-sort

Select “Address sort”.

)▶Sort

Connect

Select “Look-up address”

▶

Select “Phonebook”.

Look up for Phonebook entries and

select a target i-mode mail address.

Early Warning “ Area Mail”

Receiving Area Mail

■

You can receive information such as about earthquake alerts that are issued from the Japan Meteorological Agency as an Area Mail message. When an Area Mail message arrives, “ the buzzer for Area Mail sounds. The received content of some messages is automatically displayed. To erase the displayed content, press

⿠You can receive Area Mail messages even when you are not contracted to use i-mode.

Setting Area Mail

■

from the Stand-by display

▶

Area Mail settings

Select an item to be set

▶

Set each setting.

⿠You can also check “Check ring tone” for how your FOMA terminal works when you receive an Area Mail message.

+Oo

” lights and

Page 59

Using SMS

You can send text messages to the mobile phone number at the other party.

Sending SMS

■

from the Stand-by display

▶

Compose SMS

Enter each item.

Enter a phone number. Enter text.

Press +l( ).

Select “OK”.

Displaying Received SMS Message

■

▶

from the Stand-by display

Select a folder.

Inbox

Phonebook

Storing Phonebook Entries

Storing New Phone Numbers/Mail

■

Addresses, etc.

You can store Phonebook entries in the FOMA terminal (Phone) or on the UIM.

Press and hold

second from the Stand-by display.

Select “Phone”.

The display for entering a name appears. Enter a name and proceed.

When storing entries onto the UIM Phonebook

Select “UIM”.

Enter each item.

Enter a name. Enter a reading.

Enter a phone number.

Enter a mail address.

for at least one

+Xo

Connect

Select an SMS message.

Press +l( ).

Page 60

Storing Phonebook Entries from

■

Redial/Received Call

Press

calls) from the Stand-by display.

Highlight a call record and press

(

▶

Select “Add to phonebook”.

Select “Phone”▶Select “New”.

(Redial) or

+Vo

)

(Received

+Co

Editing Phonebook Entries

from the Stand-by display

+Xo

󱽄

Search and select a Phonebook entry.

(

󱽄

Select an item to be edited

󱽄

Edit the contents.

Press +l( ).

Select “YES”.

)

Connect

Enter each item.

Press +l( ).

Deleting Phonebook Entries

from the Stand-by display

+Xo

󱽄

Search and select a Phonebook entry.

(

Select “This phonebook”.

Select “YES”.

)󱽄Select “Delete data”.

Page 61

i-mode/Full Browser

Displaying i-mode Sites

i-mode is a service that enables you, by using the display of the FOMA terminal supporting i-mode (i-mode phone), to use online services such as site access, Internet access, and i-mode mail.

⿠i-mode is a pay service that is available on a subscription basis. ⿠For details on i-mode, refer to “Mobile Phone User’s Guide [i-mode] FOMA version”. ⿠You can display SSL/TLS terminal.

SSL/TLS are the safer data communication systems

※

using authentication/encryption technology to protect your privacy.

Press +i from the

Stand-by display.

You can access the iMenu. Repeat selecting items (links) to display the desired site.

⿠While you are online, “

Menu is available in English.

⿠

Select “English” from the display on the right.

※

-compatible pages via FOMA

” blinks.

Before using i-mode

⿠Content of sites or websites is in general protected by copyrights law. You can use data such as text and images for your entertainment, which you download to your i-mode phone, but you cannot use them, part or whole of it as is, or modify them for the purpose of sale or redistribution, without approval from copyright holders. ⿠If you replace the UIM with another one or turn on the power without UIM, depending on the FOMA terminal, you cannot display/play back ﬁ les, such as still images/moving pictures/melodies you download from sites, attached ﬁ les (still images/moving pictures/ melodies and other ﬁ les) sent/received by mail, screen memos, and Messages R/F depending on the model. ⿠When the ﬁ le has been set for the Stand-by display or for speciﬁ ed ring tone, of which display or playback is restricted by the UIM, the settings return to default if you replace it with new one or turn on the power without UIM.

Search

Page 62

Displaying Websites Designed for PC

You can browse Internet websites designed for PCs using the Full Browser function.

⿠Note that you are charged a high communication fee for the massive data communication such as browsing Internet websites having many images or downloading data. For details on the packet communication fee, refer to “Mobile Phone User’s Guide [i-mode] FOMA version”. ⿠You can browse Internet websites composed of frames. You can select a frame to display it as well.

from the Stand-by display

▶

i-mode▶Full Browser Home

⿠By default, a conﬁ rmation display appears asking whether you want to use Full Browser.

⿠You might not correctly display some Internet websites.

Switching Browsers

You can switch to Full Browser to show the Internet websites incorrectly displayed by i-mode.

⿠The billing system differs between i-mode and Full Browser. With the latter, as packet communications fee will be a large sum, you are advised to use i-mode packet ﬂ at-rate service.

(

displayed by i-mode

▶

Switch to FB

Select “YES”.

To switch from Full Browser to i-mode

1. +i(

Full Browser

▶

i-modeBRWSR Switch

) while the website is

▶

Full Browser

) while the website is displayed by

▶

i-mode Browser

Page 63

Viewing and Operating Sites

Operations on site viewing display

Scroll display/Move highlighted/

Move the pointer

Select an item (link):

Return to previous page: +m(

Forward to next page:

Mute/Release mute:

(for at least one second)

-r

:+Mo

(

+Oo

+c

“ ” appears while accessing by Full Browser.

)

(

)

Pointer

Storing Frequently Accessed Sites

Bookmark websites or i-mode sites you frequently visit to get easy access to them.

(

▶

Bookmark▶Add bookmark

Select “YES”▶Select a destination folder.

To access a site stored in Bookmark

1. +m

2. Select a folder▶Select a bookmark.

) while the site is displayed

from the Stand-by display▶i-mode▶Bookmark

Saving Site Contents

If you save the page once you visited as a screen memo, you can easily refer to it without connecting to i-mode.

(

▶

Screen memo▶Save screen memo

Select “Phone”▶Select “YES”

▶

Select a destination folder.

To display a saved screen memo

1. +m from the Stand-by display

▶

Screen memo

2. Select “i-mode Browser” or “Full Browser”.

3. Select a folder

⿠Depending on the site, for instance, when saving of screen memos is disabled at the site, you may not be able to save screen memos properly.

) while the site is displayed

▶

i-mode

▶

Select a screen memo.

Page 64

i-Channel

This service distributes information such as news and weather forecast to i-Channel mobile phones. The automatically received latest information ﬂ ows on the Stand-by display by tickers. You can read it on the i-Channel list by pressing the i-Channel key. Further, two types of channels, “Basic channel” provided by DOCOMO and “Okonomi (Optional) channel” provided by IPs (Information Providers) are available. You are not charged a packet communication fee for auto-updates of “Basic channel” information. You are charged a packet communication fee for autoupdates of “Okonomi (Optional) channel” information that will be available by registering your favorite channels. Note that you are charged separately a packet communication fee for browsing detailed information for both “Basic channel” and “Okonomi (Optional) channel”.

When you use the international roaming service, you are charged a packet communication fee for both auto-update and browsing detailed information.

⿠i-Channel is a pay service which is available on a subscription basis (You need to subscribe to i-mode to apply for i-Channel). ⿠For details on i-Channel, refer to “Mobile Phone User’s Guide [i-mode] FOMA version”. ⿠The i-Channel service is provided in Japanese only.

Displaying i-Channel

■

Press

The display is for reference. The actual one may differ.

※

You can change font size for ticker by following the steps described below;

1. +m from the Stand-by display

▶

2. Select “Ticker font size set.”.

3. Select an item.

from the Stand-by display.

+Zo

Ticker

i-mode▶i-Channel

Select each channel to browse its detailed information.

Page 65

Camera

Viewing and Operating Finder Display

You can check the settings.

Select photo mode

: intelligent Auto

Image size setting

Stand-by (480×854)

Image quality setting

: Super Fine

Store in

: Phone (Camera)

Key guidance

The key operation guide is displayed.

Operations for shooting

Shutter/Save:

Zoom:

Focus function:

Change camera-mode:

+Vo

*Oo

(TELE)/

+Xo

+Co

(WIDE)

For Digicam mode

⿠Do not leave the FOMA terminal with the lens pointing to direct sunlight. Pixels may be discolored or burns may result. ⿠When the battery level is low, you may not be able to save still images/moving pictures you shoot.

Image stabilizer

: Auto

Continuous setting

: 1 image

Number of recordable image

Shows the number of remaining recordable still images.

Top icon

Shows the vertical direction for shooting.

Focus frame

When a subject is focused on, the frame becomes green.

Zoom bar

The zooming status is displayed.

Enjoy

Page 66

Shooting Still Images/Moving Pictures

Shooting Still Images ( Digicam Mode)

■

You can shoot still images within the sizes from WQVGA (240 x 428) to 5M (1944 x 2592).

Press +c from the Stand-by display.

Press

Shooting Still Images ( Photo Mode)

You can shoot still images within the sizes from SubQCIF (96 x 128) to Stand-by (480 x 854).

1. +c from the Stand-by display

▶

Camera-mode▶Photo mode

▶

+Oo

Shooting Moving Pictures

■

You can shoot moving pictures within the sizes from Sub-QCIF (128 x 96) to VGA (640 x 480).

Enjoy

from the Stand-by display

Start recording by pressing

▶

End the recording by pressing

Press

(

+Oo +Oo

+Oo

( ).

)

( ).

▶

+Oo

▶

(

+Oo

Viewing Still Images/ Moving Pictures after Shooting

The still image you shot is saved to “My picture” in Data Box. The shot moving picture is saved to “imotion/Movie” in Data Box. The still image/moving picture can be set for the Stand-by display or other displays.

from the Stand-by display

▶

Data box

▶

My picture or imotion/Movie

Select the “Camera”

)

(

)

(

▶

Select a still image or moving picture.

Picture Album

You can detect a person’s face on the still image you have shot and expand it, or add corrective effects to the detected face. You can also play expressive slide shows with the effect function.

)

1. +m from the Stand-by display

▶

My picture▶Picture album

2. Select the “Camera”

⿠You can display the still images in Picture Album also by pressing +m( display in the Digicam Mode or Photo Mode.

▶

Data box

Select a still image.

) from the Finder

Page 67

Shooting in Various

Continuous Shooting Still Images

■

You can continuously shoot still images within the sizes from WQVGA (240 x 428) to VGA (480 x 640).

(

Digicam Mode

▶

Continuous

Press

Highlight a still image to be saved and

press

⿠You can save all the shot images by pressing

(

) from the Finder display for

▶

( ).

+Oo

( )

+Oo

Ways

Cont. set.

Shooting Still Images Using Auto

■

Shutter

The camera automatically shoots identifying the number of faces and the distance between faces by face recognition. <Example> Using “Group shutter” to shoot a group of

three persons

(

Digicam Mode

Select “Group shutter”.

Select “Three”.

When the faces of three persons are recognized, the self timer works, and about three seconds later an image of the group is shot.

Press

When you select “Love shutter”, the camera automatically shoots identifying the distance between two faces.

) from the Finder display for

▶

Auto shutter

( ).

+Oo

Enjoy

Page 68

1Seg

Using 1Seg

■Using 1Seg 1Seg is a service provided by television entrepreneurs (broadcasting stations). You are not charged a communication fee for receiving video and audio. For about fee charged by NHK, contact NHK.

You are charged a packet communication fee for browsing “Data broadcasting site” and “i-mode site”. You might be



charged an information fee for using some sites (i-mode pay sites). For details on the 1Seg service, browse the following websites:



The Association for Promotion of Digital Broadcasting From personal computer: http://www.dpa.or.jp/english/ From i-mode: http://www.dpa.or.jp/1seg/k/ (In Japanese only)

■Broadcasting waves 1Seg is one of the broadcasting services receiving radio waves (broadcasting waves) different from that used for the FOMA services. Reception condition might be deteriorated or you might not be able to receive 1Seg broadcast in places as follows:

⿠Places far away from radio towers that transmit broadcasting waves

⿠In tunnels, underground, or recesses of buildings The reception conditions might be improved by moving your FOMA terminal away from or close to you, or by moving yourself to another place.

■Battery level If you try to start 1Seg when the battery is low, the battery alert tone sounds, and a conﬁ rmation display appears asking whether to start it. In addition, when the battery level becomes low while you are watching or recording a 1Seg program, the battery alert tone sounds.

Enjoy

⿠When you do nothing on the conﬁ rmation display for about one minute, 1Seg automatically terminates.

■Messages on the display when you use 1Seg for the ﬁ rst time When you use 1Seg for the ﬁ rst time after purchase, the Exemption Clause Conﬁ rmation display appears. If you select “NO” on a conﬁ rmation display which appears after pressing display does not appear afterward.

Mountain-ringed regions or behind buildings

⿠

(

+Oo

), the same conﬁ rmation

Page 69

Setting Channels

When you activate 1Seg for the ﬁ rst time or change the area you are in, you need to operate “Channel setting”. Select “Auto channel setting” to enable you to search automatically for broadcast stations you can watch.

⿠You need to set this function when you are in the terrestrial digital TV broadcasting service area.

▶

from the Stand-by display

▶

Channel setting

▶

Auto channel setting

Select “YES”.

Select “YES”▶Enter a title.

To execute Channel Setting by selecting an area

1. +m from the Stand-by display

▶

Channel setting▶Select area

2. Select an area

3. Select “YES”.

▶

Select a prefecture.

▶

1Seg

Watching 1Seg

When you switch to Horizontal Open Style, you can watch a 1Seg program on the horizontal display.

Press and hold +c for at least one second from the Stand-by display.

1Seg starts and the viewer display appears.

Enjoy

Page 70

Viewing and Operating Viewer Display

Video

Caption

Data Broadcasting

Operation Mode

: Video Mode

: Data Broadcasting Mode

Enjoy

The operation on the viewer display

Channel switch:

Sound volume adjustment: Video recording:

⿠The recorded video is saved on the microSD card.

Displayed while setting 1Seg op-free auto off

+No

+Oo

(for at least one second) Switch TV/data BC:

.<.>

+Bo

(

)(for at least one second)

Switch display directions/Switch to full display:

.<.>

Displayed while you are watching a 1Seg program

Video being recorded Program Information (outline)

Switch Visual Image/Caption

Airwave Reception Level (estimate)

Strong Weak “

” appears out of the broadcasting area.

Sound Volume

Displayed while receiving caption information

Channel (Remote-control number)

When a broadcasting station is broadcasting multiple services (programs), “Viewing service number/Number of all services” is also displayed.

Page 71

Setting Timer Watching or Recording 1Seg

Set the date and time, a channel, and program name, and enter them to the TV Timer List or Timer Recording List. When the set time arrives, watching or recording starts.

▶

from the Stand-by display

Select “TV timer list” or “Timer

recording list”.

1Seg

Playing Recorded Video

from the Stand-by display

▶

Data box▶1Seg

Select “Video”▶Select a ﬁ le.

Press +l( ).

Enter each item.

Press +l( ).

While playing the video, press +c to switch to horizontal display to make images appear enlarged.

Enjoy

Page 72

Music

Music&Video Channel

Setting Programs

from the Stand-by display

▶

Music&Video Channel▶Set program

▶

MUSIC

Music&Video Channel is a service which automatically delivers up to about one-hour programs at night just by selecting your favorite music programs etc. in advance. Further, you can enjoy high-quality video program of up to about 30 minutes. Programs are updated periodically and you can enjoy the delivered programs at any time such as on commuting.

■Before using Music&Video Channel

⿠Music&Video Channel is a pay service that is available on a subscription basis. (To apply for Music&Video Channel, you need to subscribe to i-mode and i-mode packet ﬂ at-rate service.) ⿠In addition to the service fee for using Music&Video Channel, you might be charged separately an information fee depending on the program. If you insert the UIM to the Music&Video Channel

⿠

incompatible FOMA terminal after you subscribe to Music&Video Channel, you cannot use Music&Video Channel Service. Note that the service fee applies unless you cancel the Music&Video Channel subscription.

⿠You cannot set or download programs during international roaming

Enjoy

distribution of programs before going abroad. Then, after homecoming, resume the reception of distribution.

When you try to set or download programs during



international roaming, note that you are charged a packet

communication fee for i-mode communication. ⿠For details on Music&Video Channel, refer to “Mobile Phone User’s Guide [i-mode] FOMA version”. ⿠The Music&Video Channel service is provided in Japanese only.



. Take procedures to halt the

Follow the instructions on the display

to set a program.

The program automatically downloads at night.

Playing Programs

from the Stand-by display

▶

Music&Video Channel

Select a program.

Operation while playing back a Music&Video Channel program

Halt:

Pause:

Sound volume adjustment:

+Bo

Search (fast forward):

Press and hold

Search (fast rewind): Press and hold

+l

(

+Oo

.<.>

)

(

)

+Vo

▶

+Co

MUSIC

Page 73

Downloading Chaku-uta Full® Music Files

You can download Chaku-uta Full® music ﬁ les from sites.

Select a Chaku-uta Full® music ﬁ le

from a downloadable site.

Select “Save”▶Select “YES”.

Select a destination folder.

⿠“Chaku-uta Full” is a registered trademark of Sony Music Entertainment Inc.

Handling music ﬁ les

You can use music ﬁ les saved on the microSD card for personal use only. Before using, give enough consideration not to infringe on the third party’s intellectual property rights or other rights such as copyright.

Playing Music Files

MUSIC Player enables you to play Chaku-uta Full® music ﬁ les you have downloaded from sites, or to play Windows Media the microSD card using your personal computer.

from the Stand-by display

▶

MUSIC Player

Select “All tracks”▶Select a music ﬁ le.

Jacket image

Title

Artist name

Playback time/ Total playback time

Operations of MUSIC Player display

Halt: +l( Search (fast forward): Press and hold

Search (fast rewind): Press and hold

Sound volume adjustment: Replay next ﬁ le: Replay previous ﬁ le: (When playback time is over three seconds, you go back

to the beginning of the ﬁ le.)

Audio (WMA) ﬁ les you saved on

) Pause:

+Bo

or .>(for at least one second)

+Vo

or .<(for at least one second)

+Co

+Oo

+Vo

+Co

.<.>

▶

MUSIC

Sound volume

( )

Enjoy

Page 74

i-αppli/ i-Widget

“i-αppli” is a software program for i-mode mobile phones. By downloading various software programs from the i-mode site, you can use your FOMA terminal more conveniently. You can automatically update the stock price information or weather information, and enjoy games without accessing network. i-Widget is a useful function for gaining easy access to frequently used contents and tools (Widget Appli programs) such as the calculator, clock, memo pad and stock market information. Widget Appli programs can be added by downloading them from the web site.

⿠The packet communication fee for overseas use differs from the one for domestic use. ⿠A multiple number of Widget Appli programs may start communicating when you open the i-Widget display. If you browse detailed information, you are charged separately a packet communication fee. ⿠For details on i-αppli/i-Widget, refer to “Mobile Phone User’s Guide [i-mode] FOMA version”.

Enjoy

Starting i-αppli

Press and hold +i for at least one

second from the Stand-by display.

Select a software

program.

Starting Widget Appli

Press -r from the Stand-by display.

The i-Widget display that can simultaneously start multiple Widget Appli programs appears.

Select a Widget Appli

program.

You can operate Widget Appli program separately.

Widget Appli

Page 75

Downloading i-αppli from Sites

Select a software program from a

downloadable site.

Select “OK” when downloading ends.

Select “YES”.

⿠You can delete the pre-installed i-αppli programs except for the “ TOOL Dictionary)”. You can re-download deleted programs from the “P-SQUARE” site.

You can download not only i-αppli programs but also the pre-installed Chara-den images, Machi-chara images, Kisekae Tool ﬁ les, templates, dictionaries, and Deco-mail pictograms from the “P-SQUARE” site (in Japanese only).

話メーカー

⿠Deadlines for re-download services

・“モバイルGoogleマップ

the end of November, 2013

・“リバーシ・“ハイパー四川省

September, 2014 ⿠The services such as re-downloading might be halted or closed without notice even in the service period.

ケータイTOOL＜辞書＞

→メニューリスト

(Mobile Phone Maker)→P-SQUARE

(REVERSI)”: the end of September, 2014

(Hyper Sichuan)”: the end of

(Menu List)

(Google Map for Mobile)”:

(KEITAI

QR code for

accessing the site

→ケータイ電

Enjoy

Page 76

i-motion/ Movie

i-motion is a ﬁ le consisting from video, audio, and music which you can download to your FOMA terminal from i-motion sites that support i-motion. You can also set it for a ring tone. Also, by using high speed communication, you can play back smooth and high-quality movie ﬁ les provided by portal sites, movie specialty sites and other sites on the Internet.

⿠When downloading or streaming an i-motion/movie ﬁ le, you might receive a bulky ﬁ le. When data size required for sending or receiving is bulky, packet communications fees will be a large sum. You are advised to use i-mode packet ﬂ at-rate service. ⿠Two types of i-motion/movie ﬁ les, streaming type and normal/download type are available.

Categories Description

Streaming type (cannot be saved) Normal/Download

Enjoy

type (can be saved)

Plays data while receiving.

When download is completed, the Download Completion display appears. You can then play or save data.

Downloading i-motion/Movie

Select an i-motion/movie ﬁ le from a

downloadable site.

⿠For a movie ﬁ le, select “YES”.

Select “Save”▶Select “YES”.

⿠For an i-motion ﬁ le, select a destination folder.

Playing i-motion/ Movie

from the Stand-by display

▶

Data box

Select a folder

▶

Select an i-motion ﬁ le or a movie ﬁ le.

▶

motion/Movie

Page 77

Osaifu-Keitai

Osaifu-Keitai/ ToruCa

Osaifu-Keitai is equipped with the IC card which enables you to make payments, use coupons, enjoy stamp rallies and so on by placing the FOMA terminal over the scanning device in the stores or other locations. Furthermore, by placing the FOMA terminal over a scanning device, you can access sites and web pages, obtain the latest coupons by communication, and check the deposits of electronic money and the status of its use. Security of the card is well established so that you can use it carefree. ToruCa is an electronic card that you can receive with Osaifu-Keitai for use as ﬂ iers, restaurant cards, and coupon tickets. You can download ToruCa ﬁ les from scanning devices, sites, or data broadcasting, and can easily exchange them using mail, infrared communication, iC communication, or a microSD card. The downloaded ToruCa ﬁ les are saved to “ToruCa” on “Osaifu-Keitai”. For details on Osaifu-Keitai and ToruCa, refer to “Mobile Phone User’s Guide [i-mode] FOMA version”.

⿠Data on the IC card (including electronic money, reward points, etc.) might be lost or deformed owing to the malfunction of the FOMA terminal. (You cannot deposit your FOMA terminal at our hand for repair, remaining data ﬁ les on it. You are asked, as a rule, to delete them by yourself.) As to the support such as reissue, restoration, temporal storage, and transfer of data, consult the provider of your Osaifu-Keitai compatible service, except for the transfer by the iC transfer service. For your important data, be sure to use the service with backup support. ⿠In any case including malfunction or model change, we cannot be held responsible for the loss or deformation of data on the IC card or other losses caused regarding Osaifu-Keitai compatible services. ⿠When your FOMA terminal is stolen or lost, immediately inquire of the provider of your Osaifu-Keitai compatible service about the countermeasures. ⿠Even when the power is turned off or the battery runs out, the “Osaifu-Keitai” function is available by holding the

mark over the scanning device. The function may not be available, however, if you do not use the battery pack

for a long time or leave the battery uncharged after the battery alert activates.

Place the f mark over a scanning

device.

The Call/Charging indicator lights when you bring your FOMA terminal close to the scanning device and communication becomes ready.

Place the f mark over a scanning device.

More Convenient

Page 78

i-concier

“i-concier” works to serve you with a pleasant life just like a clerk or concierge does. The service holds your data (area information about your neighborhood, Schedule, ToruCa, Phonebook, etc.) and sends you information, with good timing, about a variety of things according to your living area, your current location, or your preference or taste. This service automatically updates schedule events or ToruCa ﬁ les to the latest ones, and automatically adds useful information such as about the opening period of various shops to your Phonebook. It also allows you to share the schedules or images held by the DOCOMO’s Data Storage Center with friends, family members or other groups. It also enables you to easily print out the images held. i-concier information is notiﬁ ed by a Machichara image (cartoon character that appears on the Stand-by display).

⿠For details on i-concier, refer to “Mobile Phone User’s Guide [i-mode] FOMA version”. ⿠i-concier is a pay service which is available on a subscription basis (You need to subscribe to i-mode to apply for i-concier). ⿠If you have not subscribed to Data Security Service but will newly subscribe to i-concier, you are to subscribe

More Convenient

to Data Security Service as well as i-concier. ⿠Depending on the content (information, i-schedule, and others), you might be charged separately an information fee other than the i-concier monthly fee. ⿠You are charged a packet communication fee separately for receiving information except some. ⿠You are charged separately a packet communication fee for using detailed information. ⿠You are charged separately a packet communication fee for auto-updates of i-schedule, ToruCa, and Phonebook.

⿠i-concier is available in Japanese only.

Receiving Information

When information arrives,

blinks and the content is displayed on the Standby display.

Select a message.

Displaying i-concier

from the Stand-by display

▶

i-concier

Select a piece of information.

Page 79

Convenient Tools

Using Schedule

from the Stand-by

▶

display

▶

Schedule

Select a date to show a schedule event of the selected date. Select the schedule event to conﬁ rm its details.

Stationery

Using Alarm

from the Stand-by display

▶

Stationery▶Alarm

Highlight an alarm and press

(

Enter each item.

More Convenient

(

You can store a new schedule event.

Enter each item.

Press +l( ).

)▶Select “New”.

Press +l( ).

⿠The alarm does not sound in Public mode (Drive mode), Lock All, Personal Data Lock, or Omakase Lock.

Page 80

Using Bar Code Reader

You can use the camera to scan QR codes and others, and store them as ﬁ les. From the scanned data, you can make calls, compose i-mode mail messages, access Internet websites, and so on.

When scanning with Bar Code Reader

⿠Scan the code as large as possible within the guide frame. ⿠Autofocus works when you scan the code about 10 cm or more away from it. When you scan the code in the outof-focus state, the recognition rate lowers. ⿠Hold the camera in parallel with the code when you scan.

More Convenient

 QR code

QR code is one of the 2-dimensional codes that denotes data in the vertical and horizontal directions.

⿠“

株式会社

INC.)” is displayed when you scan the QR code with the FOMA terminal.

NTT

(NTT DOCOMO,

ドコモ

Guide frame

Scan a Code

■

<Example> Access P-SQUARE by using

QR code on the right

from the Stand-by display

▶

Bar code reader

Select “Scan code”.

Fit a code to the guide frame and

press

The subject is focused on by autofocus function.

Press

A URL is displayed as a scanned result.

Select the URL

▶

Select “i-mode Browser”

▶

Select “YES”.

+Xo

( ) to scan the code.

+Oo

QR code for

accessing the site

▶

LifeKit

Page 81

Data Management

Using microSD Card

If you do not have a microSD card, you need to purchase it.

⿠P-02C supports a commercial microSD card of up to 2 Gbytes and microSDHC card of up to 16 Gbytes (As of September 2010). For the latest operation check information such as the memory capacity and manufacturers of microSD cards, access the following sites (in Japanese only). Note that the microSD cards other than published in the sites might not correctly work.

From i-mode to P-SQUARE (As of September 2010)

・

→ケータイ電話メーカー →

From personal computers

・

http://panasonic.jp/mobile/ Note that the published information is the result obtained from the operation check, which does not necessarily guarantee all performances of those microSD cards.

⿠Make sure that you turn off the power, and then insert/remove the microSD card.

→メニューリスト

P-SQUARE

(Menu List)

(Mobile Phone Maker)

Inserting/Removing microSD Card

■

With the metal

terminal surface facing downward, make sure that the cut edge is positioned at right and then insert.

⿠Push it until it clicks.

When you remove the microSD card

Push the microSD card until it stops and remove it.

⿠Note that the microSD card may pop out when you insert or remove it.

The inserting slot of the microSD card is in the inside of the back cover. To inser t, ﬁ rst remove the back cover

and battery pack.

More Convenient

Page 82

Icons on the Display

: A microSD card is inserted. : Data is being read/written.

(Do not remove the microSD card nor turn off the FOMA terminal.)

: The microSD card is write-protected.

: The microSD card cannot be used.

(Insert the microSD card again. If “ displayed, execute “Check microSD” or “microSD format”.)

More Convenient

” is still

Formatting microSD Card

■

When you use the microSD card for the ﬁ rst time, you need to format (initialize) it.

⿠Be sure to use P-02C for formatting. The microSD card formatted using other devices such as personal computers may not work properly. ⿠Note that formatting deletes all content on the microSD card.

▶

from the Stand-by display

▶

microSD▶Refer microSD data

▶

(

Enter your Terminal Security Code

Select “YES”.

)▶microSD format

LifeKit

Page 83

Copying Data to microSD Card

■

<Example> Copying a still image

from the Stand-by display

▶

Data box▶My picture

▶

Select a folder.

Displaying Data Stored on microSD

■

Card

<Example> Displaying a still image

from the Stand-by display

▶

Data box▶My picture

▶

(

)

Highlight a still image to be copied and

press +i(

▶

Select “Copy to microSD”

▶

Select “Copy this”.

Copying Data to FOMA Terminal

■

<Example> Copying a still image

from the Stand-by display

▶

Data box▶My picture

▶

Select a folder.

Highlight a still image to be copied and

press +i(

▶

Select “Copy to phone”

▶

Select “Copy this”.

)

▶

(

)

Select a folder▶Select an image.

Check Capacity of microSD Card

You can check the used and unused memory space (estimate) on the microSD card.

1. +m from the Stand-by display

▶

Refer microSD data

2. +i(

)▶Select “microSD info”.

▶

)

More Convenient

LifeKit▶microSD

Page 84

Backing up Data to microSD Card

■

You can back up Phonebook entries, schedule events, ToDo items, messages, text memos, bookmarks, and the settings on and information about your FOMA terminal collectively onto the microSD card. When restoring the backup data onto your FOMA terminal, they are collectively restored.

⿠Backing up data from the FOMA terminal onto the microSD card is collectively applied to all data, so emptied ﬁ les in the FOMA terminal are also backed up on the microSD card. When you restore such data onto your FOMA terminal, emptied ﬁ les on the microSD card overwrite the data in the FOMA terminal created later.

from the Stand-by display

▶

microSD▶Backup/Restore

▶

Backup to microSD

More Convenient

Enter your Terminal Security Code

▶

Select “YES”.

To restore backup data to FOMA terminal

▶

LifeKit▶microSD

▶

1. +m from the Stand-by display

▶

Backup/Restore▶Restore to phone

2. Enter your Terminal Security Code

▶

LifeKit

Select “YES”.

Sending/Receiving Data by Infrared Communication/ iC Communication

You can send or receive data such as Phonebook entries to or from a device supporting infrared communication function or iC communication function.

⿠You cannot exchange data depending on the other party’s device or FOMA terminal.

Within about 20 cm

Infrared data port

Within ±15° from the center

Face one another’s marks f.

Page 85

Sending Data

■

⿠For infrared communications, set the receiving end terminal ﬁ rst, and then start sending data within 30 seconds.

Function menu of the data to be sent

▶

Select “Send Ir data” or “iC

transmission”.

⿠Procedure for sending data might differ depending on the data.

Select “YES”.

Receiving Data by Infrared Communication

■

▶

from the Stand-by display

▶

Receive Ir data▶Receive

Select “YES”.

Receiving Data by iC Communication

■

Face the f mark of the receiving end

LifeKit

terminal which shows the Stand-by

display, to the f mark of the sending

end terminal.

Select “YES”.

Connecting to a PC

You can connect the FOMA terminal to a personal computer to exchange WMA ﬁ les, images or other ﬁ les stored on microSD card. You can also access the Internet to perform data communication.

⿠You need the FOMA USB Cable with Charge Function 02 (option) or FOMA USB Cable (option). ⿠To perform data communication, you need to install the “FOMA communication conﬁ guration ﬁ le” (driver) on the CD-ROM provided. For details, refer to the “Manual for PC Connection” on the CD-ROM provided.

More Convenient

Page 86

Support

Troubleshooting

⿠First of all, check to see if you need to update the software program and then update it if necessary. See page 88 for how to update software programs. ⿠When symptom persists even after you check the countermeasures for the problem you suffer, contact the “Repairs” counter listed on the back page of this manual or a repair counter speciﬁ ed by DOCOMO. The “Repairs” counter is available in Japanese only.

Power source

The FOMA terminal does not turn on.

…Make sure the battery pack is attached to the FOMA terminal correctly. (See page 22) …Make sure the battery is fully charged. (See page 23)

Others

Charging

Cannot charge. (The Call/Charging indicator does not light, or it ﬂ ickers.)

…Make sure the battery pack is attached to the FOMA terminal

correctly. (See page 22)

…Make sure the power plug of the adapter is securely inserted into

the outlet or cigarette lighter socket.

…Make sure the adapter and the FOMA terminal are connected

correctly. (See page 23)

…When you use an AC adapter (option), make sure its connector

is ﬁ rmly connected to the FOMA terminal or the provided desktop holder. (See page 23)

…When you use the desktop holder, make sure the connector

terminal of the FOMA terminal is not stained. If it is stained, wipe the terminal part with a dry cotton swab, etc.

…If you talk on the phone, have communications, or operate other

functions for a long time during battery charge, the temperature of the FOMA terminal may rise to ﬂ icker the Call/Charging indicator. In that case, charge the battery after the FOMA terminal cools down. (See page 23)

Operation of terminal

While you operate the FOMA terminal or charge the battery, they get hot.

…While operating or charging, or when you operate i-αppli

programs, talk on the videophone, or watch 1Seg programs for a long time during battery charge, the FOMA terminal, battery pack, or adapter may become warm, but this is not a safety hazard, so you can continue to use them.

Page 87

The usable time of the battery is short.

…Make sure not to leave the FOMA terminal out-of-service-area for a long time. If your FOMA terminal is left out-of-service area, it searches for radio waves to establish communications, consuming more power. …The usable time of the battery pack varies depending on the usage environment or its remaining life. …Battery packs are consumables. The usable time slightly shortens each time you charge the battery. If the usable time becomes extremely short as compared with the default state even if fully charged, purchase the speciﬁ ed battery pack.

The power of the FOMA terminal shuts down and restarts.

…If the terminal of the battery pack is stained, the connection might deteriorate to shut down the power. Wipe the battery terminal with a dry cotton swab, etc.

Pressing keys is disabled.

…Make sure Lock All is deactivated. (See page 43) …Make sure Key Lock is deactivated. (See page 43) …Make sure Side Keys Guard is set to “OFF”.

The UIM is not recognized.

…Make sure you insert the UIM in the correct direction. (See page 22)

The clock does not show the correct time.

…The clock may not show the correct time when the power has been kept on for a prolonged period of time. Check whether “Auto time adjust ON” has been selected as the clock setting and then, move to a location with good signal reception, turn off the power of FOMA terminal and then back on.

Call

Cannot make a call by pressing numeric keys.

…Make sure Keypad Dial Lock is deactivated. …Make sure Restrict Dialing is deactivated. …Make sure Lock All is deactivated. (See page 43) …Make sure Self Mode is deactivated.

Cannot talk. (“

” does not disappear even if you move to another place. You cannot make or receive a call, though the radio wave conditions are not bad.)

…Turn off and on the FOMA terminal, or remove and attach/insert

the battery pack or UIM. (See page 22, page 24)

…Depending on the characteristics of the radio waves, you may not

be able to make or receive a call even if the FOMA terminal is “within service area” or “ condition. Move to another place and redial.

…Make sure the call restrictions such as Call Rejection, Call

Acceptance, etc. are deactivated.

…Depending on the radio wave congestion state, calls and mail

messages may be congested and hard to be connected in crowded places. In that case, the message “Please wait” or “Please wait for a while” is displayed and a busy tone sounds. Move to another place or wait for a while, and then redial.

Osaifu-Keitai

Cannot use Osaifu-Keitai function.

…If you remove the battery pack or activate Omakase Lock, the IC

card function becomes unavailable regardless of the setting of IC

Card Lock. (See page 22, page 43) …Make sure IC Card Lock is deactivated. (See page 43) …Make sure you place the f mark on the FOMA terminal over

the scanning device. (See page 75)

” is displayed for a radio wave

Others

Page 88

Warranty and After-sales Service

Warranty

■

Make sure that you have received a warranty card provided at

⿠

purchase. After checking the contents of the warranty card as well as “Shop name and date of purchase”, keep the warranty card in a safe place. If you notice that necessary items of the warranty card are not ﬁlled in, immediately contact the shop where you purchased the FOMA terminal from. The term of the warranty is one year from the date of purchase. All or part of this product including the accessories may be modiﬁed

⿠

for improvement without notice.

After-sales Services

■

When there is a problem with the FOMA terminal



Before asking repairs, check “Troubleshooting” in this manual or in “

使いかたナビ

たナビ

remains unsolved, contact the “Repairs” counter listed on the back page of this manual for malfunction and consult them. The “Repairs” counter is available in Japanese only.

When repairs are necessitated as a result of consultation



Bring your FOMA terminal to a repair counter speciﬁed by DOCOMO. Note that your FOMA terminal is accepted for repair during the repair counter’s business hours. Further, note that you may need to wait for ﬁxing depending on the malfunction state.

Others

(Guide)” mounted on the FOMA terminal. (“

(Guide)” is available in Japanese mode only.) If the problem

使いか

In warranty period



Your FOMA terminal is repaired charge free in accordance with

・

the terms of warranty.

Make sure that you bring the warranty card to the counter for

・

repair. If you do not show the warranty card, or when troubles or malfunctions are regarded to be caused by your mishandling (the damages of display, connector, etc.), the repair cost is charged even within the warranty period.

The cost for troubles caused by the use of devices and

・

consumables other than those speciﬁed by DOCOMO is charged even within the warranty period.

Repairs may not be carried out in the following cases:



When exposure to water is found at our repair counter (Example:

・

When the moisture detection sticker has reacted) When, as a result of inspection at our repair center, corrosion is

・

found due to exposure to water, dew condensation, or sweat, or when damage or deformation is found in the circuit board [Repairs might not be carried out when damage to the connector terminal (earphone/ microphone terminal) or display, or cracks in the body are found.]

Even if repair is feasible, the repair cost is charged when the

※

trouble you suffer matches one of the symptoms listed above, which is not supported by the warranty.

After the warranty period



We will repair your FOMA terminal on request (charges will apply).

Spare parts availability period



The minimum storage period of the performance spare parts (parts required for maintaining performance) for the FOMA terminal is basically six years after the closure of its production. Note, however, that your FOMA terminal might not be repaired depending on the troubled portions because of the shortage of spare parts.

Page 89

Other points to note



Make sure not to modify the FOMA terminal or its accessories.

⿠

We might reject to repair depending on the degrees of your

・

modiﬁcation. The following might be regarded as modiﬁcations:

To put stickers, etc. onto the display or keys

・

To decorate the FOMA terminal using adhesives

・

To replace the coverings etc. with those of other than

・

DOCOMO genuine products

Repairs of troubles or malfunctions resulting from the

・

modiﬁcations are charged even within the warranty period. ⿠Do not peel the nameplate off the FOMA terminal. Note that when we cannot ensure the contents described on the nameplate and therefore cannot verify the product conformity to the technical standard, it might happen that we at DOCOMO reject to repair the malfunction. The information such as about function settings and Total

⿠

Calls Duration, etc. might be reset depending on the troubles or repairs, or the way you handle the FOMA terminal. Set the settings again. The parts generating magnetism are used in the following

⿠

portions of the FOMA terminal. Note that if you place a magnetism-sensitive object such as a cash card near the FOMA terminal, the card might become unusable. Portions: speaker, earpiece The P-02C comes with the waterproof performance, however,

⿠

if the inside of the FOMA terminal gets wet or becomes moist, immediately turn off the power and remove the battery pack; then visit a repair counter. The FOMA terminal may not be repaired depending on the condition.

i-mode Fault Diagnosis Site

You can check on your FOMA terminal whether sending/receiving mail messages, downloading images/melodies, and others are normally working. When you think your FOMA terminal is in trouble as a result of your check, contact the “Repairs” counter listed on the back page of this manual. The “Repairs” counter is available in Japanese only.

To connect to “

⿠

ｉモード故障診断サイト

Diagnosis Site)” [in Japanese only] i-mode site: iMenu

→お知らせ →サポート情報 →お問い合わせ

(Support information) (Inquiries)

→故障・電波状況お問い合わせ先

& Radio wave condition)

→ｉモード故障診断

Diagnosis)

When you access from overseas, you are charged a

⿠

fee.

(i-mode Fault

(News)

(Failures

(i-mode Fault

QR code for

accessing the site

Others

Page 90

Updating Software

This function is to check whether you need to update software programs in the FOMA terminal by connecting to the network, and if necessary, you can download some parts of software programs using packet communication, and can update the software programs. If you need to update the software programs, the DOCOMO website and “

Menu lets you know information about updating software programs. There are three kinds for updating software

programs; “Auto-update”, “Update Now” and “Reserve Update”.

You can update software programs, with data retained, such as Phonebook entries, images shot by the camera, or

⿠

downloaded data in the FOMA terminal; however note that data may not be protected depending on the conditions (such as malfunction, damage, or drench) your FOMA terminal is placed in. You are advised to back up important data. Note that data such as downloaded ones might not be backed up. Before using Software Update

■

Do not remove the battery pack while updating software programs. You may fail to update.

⿠

Fully charge the battery before updating software programs.

⿠

It may take time to update (download or rewrite) software programs.

⿠

You cannot make/receive calls, use communication functions, and other functions while updating software programs.

⿠

(You can receive voice calls, forward calls or operate Record Message during download.) You are advised to update software programs when radio wave is strong enough with the three antennas displayed and

⿠

while you are not moving. If radio wave conditions get worse while downloading software programs, or download is suspended, move to a place with better radio wave conditions and try again to update software programs. When updating software programs, the proprietary information about your FOMA terminal (model name or serial number,

⿠

etc.) is automatically sent to the server (DOCOMO-managed server for Software Update). We at DOCOMO never use the sent information for purposes other than to update software programs. If you fail to update software programs, “Rewrite failed” is displayed and you cannot do all operations. In that

⿠

Others

case, you are kindly requested to come to a repair counter speciﬁed by DOCOMO.



(User support)” in Japanese

Page 91

Start Software Update from Icon

When update is necessary, “Update

■

Select “Update notiﬁ cation icon” on the

Stand-by display.

Update notiﬁ cation icon

Check whether you need to update software programs.

When update is necessary, “Update

is needed” is displayed. And you can select either “Now update” or “Reserve”.

⿠When you select “Now update”, update immediately starts. ⿠When rewriting is completed, your FOMA terminal automatically restarts and the Update Completion Conﬁ rmation display appears. ⿠When you select “Reserve”, you can select the date and time you want.

Start Software Update from Menu

■

from the Stand-by display

▶

Set./Service▶Other settings

▶

Software update

Enter your Terminal

Security Code

▶

Select “Update”.

Go to step 2 of “Start Software Update

from Icon” on page 89.

Others

Page 92

Check Harmful Data

You can detect data or application programs, which might cause troubles, from among those downloaded to your FOMA terminal, and then can delete the data or stop starting the application programs.

This scan function provides a certain protective measure to ﬁlter out data that might cause troubles with your FOMA terminal at the time

⿠

when you browse websites or receive messages. Note that when the virus pattern data supporting respective troubles is not yet downloaded to your FOMA terminal, or when no virus pattern data supporting them is found, this function does not prevent troubles from occurring. The virus pattern data installed on the FOMA terminal differs in content by every model. Note that we at DOCOMO might stop distributing the

⿠

virus pattern data for models on market for last three years since their release.

Update pattern data

First of all, update the pattern data to obtain the latest.

▶

from the Stand-by display

About displays for scanning results

About the display for scanned problem elements



The displays for scanning result



Alert level 0 Alert level 1 Alert level 2 Alert level 3 Alert level 4

OK .....Continues the

Others

operation.

A warning display appears when problematic data is found. Select “Detail” from the warning display to show the name of the problem element.

⿠ ⿠

Set./Service▶Lock/Security▶Scanning function▶Update▶YES▶YES▶OK

When six or more problem elements are found, the sixth and later problem element names are omitted. “Detail” might not appear depending on the detected problem element.

⿠

YES ...Stops and ends

the operation.

..... Continues the

operation.

.....Stops and ends

the operation.

YES ...Deletes the data

and ends the operation.

..... Stops and ends

the operation.

.....Deletes the data

and ends the operation.

The alert displays for displaying i-mode mail mess

ages or SMS messages may differ from those at left.

Page 93

Introduction of Options and Related Devices

Combining various options with the FOMA terminal, you can realize more versatile use from personal purpose to business purposes. Some products may not be dealt in depending on the area. For details, consult a handling counter such as a docomo Shop. For details on options, refer to the user’s manuals of respective options and related devices.

Battery Pack P20

・

Back Cover P47

・

Desktop Holder P42

・

FOMA AC Adapter 01/02

・

FOMA AC Adapter 01 for Global use

・

FOMA DC Adapter 01/02

・

FOMA Portable Charging Adapter 01/02

・

FOMA Dry Battery Adapter 01

・

FOMA USB Cable with Charge Function 02

・

FOMA USB Cable

・

FOMA Indoor Booster Antenna

・

FOMA Indoor Booster Antenna (Stand Type)

・

Carry Case S 01

・

Carry Case 02

・

1 See page 23 for charging batteries using AC adapter.

※

2 If you use a USB hub, outer devices may not work correctly.

※

3 Use it in Japan only.

※

4 Earphone Plug Adapter P001 and Earphone Plug Adapter for External connector terminal 01 are required.

※

5 Earphone Plug Adapter for External connector terminal 01 is required.

※

6 To use/charge the P-02C, FOMA In-Car Hands-Free Cable 01 is required.

※

In-Car Holder 01

・

Earphone/Microphone 01

・

Stereo Earphone Set 01

・

Earphone/Microphone with Switch P001/P002

・

Flat-plug Earphone/Microphone with Switch P01/P02

・

Flat-plug Stereo Earphone Set P01

・

Earphone Plug Adapter P001

・

Earphone Plug Adapter for External connector terminal 01

・

Earphone Plug Adapter 01

・

Flat-plug Connector/Stereo Mini-jack Conversion Adapter P01

・

Bone conduction microphone/receiver 01

・

In-Car Hands-Free Kit 01

・

FOMA In-Car Hands-Free Cable 01

・

※

Others

Page 94

Appendix

Function List

Execute “Resetting the Function Settings to Default” on page 44 for the items indicated by the respective defaults.

Inbox

Mail

Outbox Draft Compose message Create new Decome-Anime

Template

Check new messages Compose SMS Check new SMS Receive option

Mail settings

Others

Deco-mail Decome-Anime

Scroll Font size setting Mail list display Message display Mail security Secret mail display Auto color label Pred. conv. at reply Header/signature Set check new messages Auto-display Receiving display

to return to

Mail

Mail settings

SMS settings

Area Mail settings

Bookmark

i-mode

Screen memo

Last URL Enter URL

i-Channel

Receive option setting Attachment preference Auto-start attachment Address/Spam Mail set. Feel＊Mail Auto save setting Text predict Auto Deco-mail setting Check settings SMS report request SMS validity period SMS input character SMS center setting Receive setting Beep time Manner/Public mode set Check ring tone Other menu

i-mode Browser Full Browser

Channel list Ticker ON/OFF Ticker font size set. Ticker color set. Ticker scroll speed Reset i-Channel

Page 95

Post blog

i-mode

i-mode settings

Full Browser Home

Software list (phone)

ppli

ppli (microSD)

ppli call logs

ppli info

ppli settings

About

ppli

i-mode Browser set. Full Browser set. Common settings Check settings Reset i-mode setting

Software list

ppli data

End stand-by info End Widget appli inf Security error history Auto start info Trace info Auto start setting Disp. software info i-Widget roaming set. i-Widget sound effect

ppli call settings

ppli volume

Preferred tone

Backlight

Power saver

Vibrator

Check settings

Sound

Set./Service

Display

Illumination

Select ring tone ( Ring volume ( Keypad sound ( Melody effect (

13)

50)

30)

64) Headset usage setting ( Mail/Msg. ring time (

Charge sound Display setting ( Backlight (

70)

56)

View blind Color theme setting ( Machi-chara Menu icon setting (

Horizontal open menu Private menu setting (

66)

63)

93)

Desktop icon ( Private window (

Font ( Font size setting Select language (

15) Recv. mail/call at open Image quality LCD AI

Icons (

36) All illum. setting Incoming illumination ( Illumination in talk Missed/unread illum. Music&Video Ch illum. Illum. when opened Illum. when closed

57)

68)

86)

51)

52)

Others

89)

Page 96

90)

75)

58)

76)

77)

65)

18)

17)

Hourly illumination

Illumination

Set./Service

Kisekae i-concier Information disp. set.

MUSIC illumination IC card illumination Check settings

Set./Service

Incoming call

Self mode Lock all Personal data lock IC card lock

40)

41)

Talk

Lock/Security

Secret mode ( Secret data only ( Secret recv. call Keypad dial lock Reject unknown Call setting w/o ID ( Change security code (

10)

29) UIM setting Scanning function

Call time/cost

Lock setting Call data (

61) Reset total cost&dura. ( Notice call cost CLR max cost icon Set time (

31)

60)

Videophone

Network setting

World time watch

Others

Clock

Incoming call

Summer time Auto power ON/OFF Alarm setting

Vibrator (

54)

Manner mode set (

NW services

20)

Answer setting ( Setting when opened Record display set Disp. PH-book image Set call/receive No. Ring time ( Info notice setting ( V.phone while packet Auto call/answer set. Melody Call setting Volume Setting when closed ( Hold tone setting Shikkari Talk Noise reduction ( Quality alarm ( Reconnect signal ( Visual preference Select image Hands-free w/ V.phone Voice call auto redial Notify switchable mode Reject videophone Preﬁx setting Femtocell setting Caller ID notiﬁcation ( Voice mail Call waiting Call forwarding Nuis. call blocking Caller ID request

Page 97

Set./Service

NW services

Other settings

2in1 setting Multi number Arrival call act Set in-call arrival act Remote access Dual network English guidance Overseas NW search Overseas setting Overseas service Additional service Contact DOCOMO OFFICEED Chaku-moji Work with style Side keys guard

long press set. Character input method ( Battery/eco mode set. Pause dial (

84) Sub-address setting Headset mic. setting Voice settings USB mode setting Check settings Reset settings (

23) Initialize Software update

35)

My picture (+m46) MUSIC Music&Video Channel

Data box

motion/Movie

Melody (

16) My documents Kisekae Tool Machi-chara Chara-den

1Seg

Document viewer Font SD other ﬁ les

Image Video Position memory

Others

Page 98

Others

Bar code reader

LifeKit

Receive Ir data

(

79)

microSD

Camera

Rec. msg/voice memo (

Voice recorder

Data Security Service

Guide

i-concier

55)

Scan code Saved data Receive Receive all Refer microSD data Backup/Restore Digicam mode Photo mode Movie mode View photos View movies Play/Erase msg. Play/Erase VP msg. Record message setting Voice memo Voice announce

Check/How to update Exchanging history PB image sending Backup PB etc./update Backup set./update Backup images

Add to phonebook

Phonebook

Search phonebook

UIM operation

Dialed/recv. calls

(

24) Own number ( Group setting

Restrictions

Phonebook settings

(

26)

No. of phonebook

Phone UIM Reading? Group? Memory No.? Name? Phone number? Mail address? 2-touch dial? Copy Delete Dialed calls Received calls

Restrict dialing Call rejection Call acceptance Call forwarding Voice mail Font size setting Voice dial setting Mail group Forwarding image

Page 99

Alarm (+m44)

95)

45)

42)

85)

Schedule ( ToDo ( Text memo (

Stationery

Calculator ( Dictionary

Phrase/own dict.

(

38)

MUSIC Player

MUSIC

Music&Video Channel

Activate 1Seg Program guide

1Seg

TV timer list Timer recording list Recording result TVlink Channel list

Channel setting

User settings

Common phrases Own dictionary Download dictionary Create learned wd list

Select area Auto channel setting Display/operation Video Display light Sound effect Recording Data broadcasting Energy saving setting

Reset channel setting

1Seg

User settings

Reset storage area Reset TV settings Check TV settings

IC card content DCMX ToruCa

IC card lock set.

Osaifu-Keitai

IC card lock IC lock (power-off) ToruCa from IC card Auto reading ToruCa

Settings

Recv. ToruCa display ToruCa from 1Seg

Check same ToruCa Check IC owner Change IC owner Search by i-mode

Clock display of Private window Redial

Others

Public mode (Drive mode) Manner mode eco mode Videophone Character input

Others

Page 100

Main Speciﬁcations

Handset



Model P-02C Dimensions (when closed) Height: Approx. 109 mm

Weight (with the battery pack attached)

Continuous standby time (FOMA/3G)

Continuous talk time (FOMA/3G)

1Seg watching time Approx. 220 minutes

Charging time AC adapter: Approx. 120 minutes

Display Type Display: TFT 262,144 colors

Size Display: Approx. 3.0 inches

Number of pixels Display: 409,920 pixels

Others

Image pickup device

Type CMOS Size 1/4.0 inches

Width: Approx. 50 mm Depth: Approx. 17.8 mm

(at thickest point: Approx. 17.9 mm)

Approx. 128 g

Standstill: Approx. 570 hours In motion: Approx. 370 hours

Voice call : Approx. 190 minutes Videophone call : Approx. 130 minutes

(when Mobile W-Speed is OFF: Approx. 280 minutes) (in 1Seg eco Mode: Approx. 300 minutes)

DC adapter: Approx. 120 minutes

Private window: Organic EL 1 color

Private window: Approx. 0.4 inches

(480 dots x 854 dots) Private window: 672 pixels (56 dots x 12 dots)

Camera Number of

Approx. 5,100,000 pixels

effective pixels Number of recording

Approx. 5,000,000 pixels

pixels (maximum)

Recording

Number of recordable still



images Number of

still images for continuous shooting

Approx. 2,400 max. (default)

For Digicam Mode in Continuous setting VGA: 8 Square (small): 8 WQVGA: 8 For Continuous Mode VGA: 4 QVGA: 5 to 10 QCIF: 5 to 20 Sub-QCIF: 5 to 20

Music playback

Continuous playback time

SD-Audio ﬁle (supports Play Background):



Approx. 6,500 minutes

※

Chaku-uta Full® music file (supports Play Background): Approx. 6,000 minutes i-motion ﬁle (including Chaku-uta® music ﬁle): Approx. 1,260 minutes WMA ﬁle (supports Play Background): Approx. 4,600 minutes Music&Video Channel program (supports Play Background) Sound : Approx. 6,000 minutes Moving picture : Approx. 270 minutes

Memory capacity

“Chaku-uta” is a registered trademark of Sony Music Entertainment Inc.

※ ※

Chaku-uta Chaku-uta Full

1: Image size: QVGA (320 x 240), Image quality: Nor mal, File size: 25 Kbytes 2: The continuous playback time is the estimated duration that you can play back

using the Stereo Earphone Set 01 (option) with the FOMA terminal closed. 3: File format: AAC 4: Shares with still images, i-motion ﬁles, melodies, PDF ﬁles, Music&Video Channel

programs, Kisekae Tool ﬁles, Machi-chara images, font ﬁles, ToruCa ﬁles, and

i-αppli programs.

Approx. 211 Mbytes (default)

※
