Docomo P-02A Instruction Manual

docomo STYLE series

P-02A

INSTRUCTION MANUAL

ISSUE DATE:

‘09.1

NAME:

PHONE NUMBER:

MAIL ADDRESS:

Easy Search/Contents/Precautions

Before Using the Handset

Voice/Videophone Calls/PushTalk

Phonebook

Sound/Screen/Light Settings

Security Settings

Camera

i-mode/i-motion/i-Channel/i-concier

i-αppli/i-Widget

Map/GPS Function

Full Browser/PC Movie

Mail

Osaifu-Keitai/ToruCa

1Seg

Data Management

Music

Convenient Functions

Character Entry

Network Services

PC Connection

Overseas Use

Appendix/Troubleshooting

Index/Quick Manual

DOCOMO W-CDMA・GSM/GPRS System

Thank you for selecting the “docomo STYLE series P-02A”.

Before or during use of the P-02A, make sure that you read this manual and the separate manuals for other optional devices thoroughly so that you can use the P-02A correctly. If you feel any inconvenience in reading the manual, contact the docomo Information Center listed on the back page of this manual. The P-02A is designed to be your close partner. Treat it carefully at all times to ensure long-term performance.

●Because the FOMA terminals use radio waves, they cannot be used in places

where radio waves do not reach, such as inside tunnels, underground, or in buildings; or the outside where radio waves are weak or out of the FOMA service area. They may not be used in the high-rise buildings even when the antennas are unobstructed. You may also experience interruption of calls even when using without moving while the radio waves are strong enough for the three antennas to appear on the display.

●Use the FOMA terminal carefully to avoid disturbing other people when in

public, or in crowded or quiet places.

●Since the FOMA terminals use radio waves as the medium of

telecommunication, calls may be tapped by the third party. However, the W-CDMA・GSM/GPRS system automatically supports tapping prevention, so your conversation will be incomprehensible to the third party, because it is recognized as mere noise.

●The FOMA terminals change your voice into digital signals and send them to

the other party. In places where the radio waves are weak, the digital signals may not be converted correctly, and in such a case, the voice may sound different from the actual original voice.

●

The user hereby agrees that the user shall be solely responsible for the result of the use of SSL. Neither DOCOMO nor the certifiers as listed herein make any representation and warranty as for the security in the use of SSL. In the event that the user shall sustain damage or loss due to the use of SSL, neither DOCOMO nor the certifiers shall be responsible for any such damage or loss. Certifiers: VeriSign Japan K.K., Cybertrust Japan Co., Ltd., GlobalSign K.K.,

RSA Security Japan Ltd., SECOM Trust Systems Co., Ltd., and Comodo CA Ltd.

●This FOMA terminal supports FOMA Plus-Area and FOMA High-Speed Area.

●The FOMA terminal can be used only via the FOMA network provided by

DOCOMO and in DOCOMO’s roaming area.

●It is recommended that you make separate notes of the information (such as

Phonebook entries, schedule events, text memos, record messages, voice memos, movie memos) stored in the FOMA terminal and keep them in a safe place. Note that we cannot be held responsible for the unlikely event of loss of the stored contents due to a malfunction, repair, change of your model, or other mishandling of the FOMA terminal.

●You are advised to save your important data files to the microSD card. If you

have a personal computer, you can transfer and save the information such as Phonebook entries, mail messages, schedule events, and others to the personal computer by using DOCOMO keitai datalink.

Before using your FOMA terminal

For Using This Manual

This FOMA terminal supports Kisekae Tool (page 116). If you use Kisekae Tool to change the design of the Menu display, some menu configurations change according to the usage frequency depending on the type of the menu. Further, some menu numbers that are assigned to the menu items do not apply.

You can download the latest information about this manual from the following DOCOMO website:

・User’s Manual (PDF file) Download

(http://www.nttdocomo.co.jp/english/support/manual/index.html)

※The URL and the content of the website might be modified

without notice.

Easy Search/Contents/Precautions

In this manual, illustrations and symbols are used in the explanations so that you can correctly and easily use the FOMA terminal.

≥The most operating procedures and displays in this manual are described with the

default settings of the “Diamond Black” handset (see page 476). However, the following settings are changed.

・“Display setting” → “Stand-by display”: OFF ・“Display setting” → “Clock” → “Stand-by clock” → “Position”: Pattern 1 ・“Color theme setting”: White ・“Disp. call/receive No.” → “Font color”: Black

≥Displays and illustrations described in this manual are for reference. The actual ones

might differ.

≥In this manual, “Osaifu-Keitai compatible i-αppli which supports the IC card function” is

described as “Osaifu-Keitai compatible i-αppli”.

≥Note that “P-02A” is referred to as “FOMA terminal” in this manual. ≥In the operating procedures of this manual, key operations are described with

simplified key icons.

≥The functions which use a microSD card are described in this manual; however, you

need to obtain a microSD card separately to make these functions available. See page 368 for the microSD card.

Viewing/Searching This Manual

By the following search methods, you can find pages where your desired functions and services are described:

How to Refer to This Manual

Search from the index when you know the names of functions or services.

Search from keywords for the functions you frequently use or the functions that are convenient if you can know any.

Search from the tabs printed on the cover.

See the next page for details.

Search from the contents that categorize functions.

Search from here to use the main functions.

Search from the function list.

Quick Manual gives you a clear, brief description about basic functions. You can take it when you go out. Further, Quick Manual “For Overseas Use” is attached, so refer to it when you use the FOMA terminal overseas.

From the Index

From Easy Search

From the Tabs on the Cover

From the Contents 11P.6

From the Main Functions 11P.8

From the Function List 11P.476

From Quick Manual 11P.550

It is prohibited to copy all or part of this manual without permission. The instructions contained in this manual may be changed without notice.

Easy Search/Contents/Precautions

How to search for “Alarm” is explained here as an example of search method.

Additional guidance . . . . . . . . . .455

Address link function . . . . . . . . . . .203

After-sales services . . . . . . . . . . . . 516

Alarm . . . . . . . . . . . . . . . . . . . . . . . 402

Alarm setting . . . . . . . . . . . . . . . . . 411

Answer setting . . . . . . . . . . . . . . . . . 64

Antenna . . . . . . . . . . . . . . . . . . . . . . 23

From the Index

11P.542

Search for a function or a service name as shown on the right.

Search for the function you frequently use or that is convenient if you know any as shown on the right.

Other things you can do

To reduce the battery consumption .............................. <Power Saver Mode> 113

To scan QR codes or bar codes ...................................... <Bar Code Reader> 243

To listen to music.................................................................. <MUSIC Player> 276

To check your location and area information.................<Map/GPS Function> 324

To use the microSD card ...................................................... <microSD Card> 366

To exchange information using infrared rays.........<Infrared Communication> 380

To use the FOMA terminal as an alarm clock

.....................................<Alarm> 402

To use the FOMA terminal as a calculator ..................................<Calculator> 415

To use the FOMA terminal overseas ........................<International Roaming> 458

To update software programs ........................................... <Software Update> 518

Go to page 404 where “Alarm” is explained.

From Easy Search

11P.4

i-αppli/i-Widget

Map/GPS Function

Osaifu-Keitai/ToruCa

Data Management

Music

Convenient Functions

Character Entry

Network Services

PC Connection

Overseas Use

Appendix/Troubleshooting

Multitask . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <Multitask> 399

Informing You of an Incoming Call/Mail Message by Voice

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <Reading Aloud> 400

Turning Power On/Off Automatically at a Specified Tim e

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <Auto Power ON/OFF> 402

Using Alarm. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <Alarm> 402

Using Calendar to Manage Schedule . . . . . . . . . . .<Schedule> 405

Using ToDo to Manage Schedule . . . . . . . . . . . . . . . . . <ToDo> 409

Setting Operating Conditions of Alarm . . . . . <Alarm Setting>411

From the Tabs on the Cover

11Cover page

Search for the function you want to set in the order of “Cover”

→ “First page of Chapter” → “Description page” as shown

on the right.

Easy Search/Contents/Precautions

402

Convenient Functions

You can set Alarm to alert you at the specified time with an alarm tone, animation and illumination. You can store up to twelve alarms.

mStationeryAlarm

Highlight an alarm and press

l()

Do the following operations.

Press l().

+m-4-4

<Alarm>

Using Alarm

Alarm You can set whether to validate or invalidate the alarm.

ON or OFF

Time Enter the time for sounding the alarm.

pYou cannot set the same time as the time set for the stored

alarm.

Tone Select a type of alarm toneSelect a folder

Select an alarm tone.

Volume Use Bo to adjust the volume.

pIf you set “Step”, the alarm tone is silent for about three

seconds, and then the volume steps up every about three seconds, from Level 1 through Level 6.

Prefer manner

mode

You can set the alarm tone which sounds at the specified time during Manner Mode.

ON or OFF

ON. . . . . Sounds at the same volume as set for “Alarm volume”.

OFF. . . . Sounds at the volume set for this function.

The icon appears on the desktop. “” . . . Displayed when an alarm is set for today (except the setting for past time).

“” . . . Displayed when an alarm is set for tomorrow or onward only.

pIf you set “Alarm” of the stored schedule event/ToDo item to “OFF”, the icons are not

displayed.

Function Menu while Alarm is Displayed

Edit Go to step 1 of “Using Alarm” on page 402.

Detail You can display the stored alarm contents.

Set this You can validate the stored alarm.

YES

pYou can validate also by pressing Oo().

Set all You can validate all the stored alarm.

YES

Delete

Delete this YES

Delete all Enter you Terminal Security CodeYES

Information

pIf the alarm tone sounds during a call, press any key to stop it. Once again press any

key to end the alarm including Snooze. If the other party on the phone hangs up, an alarm including Snooze ends.

pDuring a call, the alarm tone sounds at the level set for “Volume” (earpiece volume). pTurn off the FOMA terminal after setting “Auto power ON” to “OFF” when you are near

electronic devices using high-precision control or weak signals, or where the use is prohibited such as in airplanes and hospitals.

When you set an alarm for “Alarm”, “Schedule”, and “ToDo”

Note: The page above is a sample.

Menu number (See page 34)

Function name You can find this in Index.

Operating procedure (See page 32)

Reference display (Characters and settings are for reference.)

Options and their explanations

Items shown on the display (Some items cannot be executed.)

Operation and supplementary explanation for each item

Operations related to the function and explanations for supplementary operations

Chapter title

You can search by chapter.

Cautions or references for using each function

Lower sub-menu item of the Function menu

Easy Search/Contents/Precautions

To retrieve a desired function with simple words, refer to the following:

Easy Search

To know convenient functions for making calls

To/Not to notify your phone number to the other party

....................................................................................<Caller ID Notification> 46

To switch to a videophone call during a voice call

...........................................................................<Switch to Videophone Call> 51

To change a volume level of the other party’s voice ....................... <Volume> 65

To put a call on hold during a call.................................................... <Holding> 66

To do the following when you cannot answer calls

To put an incoming call on hold before answering......................... <On Hold> 66

To convey the message that you need to refrain from talking on the phone

.....................................................................Using Public Mode (Drive Mode) 67

....................................................................... Using Public Mode (Power Off) 68

To record voice/video messages..........................<Record Message Setting> 69

To change melody or illumination

To adjust the ring volume........................................................<Ring Volume> 66

To change ring tones according to callers......................<Add to Phonebook> 88

To change ring tones........................................................<Select Ring Tone> 104

To know incoming calls by vibrator .................................................<Vibrator> 106

To mute the keypad sound...................................................<Keypad Sound> 107

To activate Manner Mode...................................................... <Manner Mode> 108

To change colors/lighting patterns of Call indicator for incoming calls

.................................................................................................. <Illumination> 117

To change/know display settings

To know the meaning of marks (icons) on the display .....................<Display> 27

To change the Stand-by display (Wallpaper) ...................... <Display Setting> 111

To display a calendar on the Stand-by display..............................<Calendar> 111

To change the menu display .......................................... <Menu Icon Setting> 115

To change the font size ................................................................ <Font Size> 119

To make full use of mail

To send Deco-mail ...................................................................... <Deco-mail> 146

To send images ....................................................................... <Attachments> 153

To sort and save mail automatically ..............................................<Auto-sort> 172

To make full use of camera

To shoot with the photo light......................................................<Photo Light> 239

To change the shooting size...................................................... <Image Size> 240

To save to the microSD card ...........................................................<Store In> 241

To display shot images......................................................... <Picture Viewer> 344

Easy Search/Contents/Precautions

※1 This is a pay service. ※2 This is a pay service which is available on a subscription basis.

To use the FOMA terminal with a sense of security

To lock the FOMA terminal from away when it gets lost

.........................................................................................<Omakase Lock>※1125

To keep Phonebook entries from prying eyes......................... <Secret Mode> 132

To reject calls without a caller ID.............................. <Call Setting without ID> 135

To reject calls from the phone numbers that are not

in the Phonebook ............................................................ <Reject Unknown> 136

To separately store Phonebook and other data

files in preparation for their erasure.................... <Data Security Service>※2136

To make full use of 1Seg

To watch 1Seg programs ...................................................... <Activate 1Seg> 253

To record 1Seg programs.................. <Record Video> <Record Still Images> 260

To set TV Timer/Timer Recording for 1Seg programs

.......................................................................<TV Timer> <Timer Recording> 261

To change settings of video and audio...................................<User Settings> 266

Other things you can do

To reduce the battery consumption .............................. <Power Saver Mode> 113

To scan QR codes or bar codes ...................................... <Bar Code Reader> 244

To listen to music.................................................................. <MUSIC Player> 278

To check your location and area information.................<Map/GPS Function> 326

To use the microSD card ...................................................... <microSD Card> 368

To exchange information using infrared rays.........<Infrared Communication> 382

To use the FOMA terminal as an alarm clock.....................................<Alarm> 404

To use the FOMA terminal as a calculator .................................. <Calculator> 417

To use the FOMA terminal overseas ........................<International Roaming> 460

To update software programs........................................... <Software Update> 523

To update security ......................................................... <Scanning Function> 529

≥The operating procedures for frequently used functions are summarized in Quick

Manual. (See page 550)

Easy Search/Contents/Precautions

Contents

Viewing/Searching This Manual . . . . .1

Easy Search . . . . . . . . . . . . . . . . . . . . . .4

Contents . . . . . . . . . . . . . . . . . . . . . . . . .6

Main Functions of P-02A. . . . . . . . . . . .8

Precautions. . . . . . . . . . . . . . . . . . . . . 10

Handling Precautions . . . . . . . . . . . . 16

Accessories and Main Options . . . . 20

Before Using the

Handset

Part Names and Functions, Display, Desktop Icon, Selecting Menu, Guide, UIM (FOMA Card), Battery, Charging, Power ON/OFF, Select Language, Set Time, World Time Watch, Caller ID Notification, Own Number, etc.

Voice/

Videophone Calls/

PushTalk

Making a Call/Videophone Call, Call Records, Chaku-moji, Receiving a Call/Videophone Call, Volume, Ring Volume, Public Mode, Record Message Setting, Chara-den, Making a PushTalk Call, Receiving a PushTalk Call, PushTalk Phonebook, etc.

Phonebook

Available Phonebooks, Add to Phonebook (FOMA terminal/UIM), Group Setting, Search Phonebook, Edit Phonebook, Delete Data, No. of Phonebook, 2-touch Dial, Voice Dial

Sound/Screen/

Light Settings

103

Select Ring Tone, Vibrator, Manner Mode, Speed Selector Sound, Display Setting, Backlight, Menu Icon Setting, Kisekae Tool, Set to Machi-chara, Illumination, Font, etc.

Security Settings

121

Security Codes, Change Security Code, Releasing PIN Lock, Lock All, Omakase Lock, Self Mode, Personal Data Lock, Keypad Dial Lock, Secret Mode, Call Setting without ID, Reject Unknown, Reset Settings, Initialize, etc.

Mail

141

i-mode Mail, Deco-mail, Decome-Anime, Template, Attachments, Mail Auto-receive, Receive Option, Check New Messages, Message R/F, Early Warning “Area Mail”, Chat Mail, SMS, Web Mail, etc.

i-mode/i-motion/

i-Channel/i-concier

189

i-mode, iMenu, My Menu, Change i-mode Password, Enter URL, Bookmark, Screen Memo, Download, Upload, Certificate, i-motion, i-Channel, i-concier, etc.

Full Browser/

PC Movie

215

Full Browser, Full Browser Settings, PC Movie, Downloading PC Movies, PC Movie Player

Camera

229

Before Using Camera, Still Image Shoot, Movie Shoot, Settings for Shooting, Setting Image Size/Image Quality, Bar Code Reader

1Seg

249

1Seg, Before Using 1Seg, Channel Setting, Activate 1Seg, i-αppli Program Guide, Data Broadcasting, TVlink, Recording 1Seg, TV Timer/Timer Recording, User Settings

Music

269

Music&Video Channel, Set Program, Playing/Operating Programs, Playing Music, Saving Music Files, MUSIC Player, Playlist

Easy Search/Contents/Precautions

i-αppli/i-Widget

289

i-αppli, i-αppli Download, i-αppli Run, iαppli Settings, Starting i-αppli Automatically, iαppli Call, i-αppli Stand-by Display, iαppli Data, i-Widget, Start Widget αppli

Osaifu-Keitai/

ToruCa

313

Osaifu-Keitai, iC Transfer Service, IC Card Content, IC Card Lock, Check IC Owner, ToruCa, Receive ToruCa Files, ToruCa Viewer, ToruCa File List/Detailed ToruCa File Display, ToruCa Settings

Map/GPS Function

325

Using GPS Function, Position Location, Map/GPS Compatible i-αppli, Provide Location, Notify of Location, Location History, GPS Settings

Data Management

341

Picture Viewer, i-motion Player, Video Player, Chara-den, Machi-chara, Melody Player, Kisekae Tool, microSD Card, Voice Recorder, PDF Viewer, Document Viewer, etc.

Convenient

Functions

399

Multiaccess, Multitask, Reading Aloud, Auto Power ON/OFF, Alarm, Schedule, ToDo, Own Number, Voice Memo, Movie Memo, Call Data, Calculator, Text Memo, UIM Operation, Bluetooth Function, etc.

Character Entry

429

Character Entry, Mode 1 (5-touch), Common Phrases, Cut/Copy/Paste, Own Dictionary, Learned Words, Download Dictionary, Mode 2 (2-touch), Mode 3 (NIKO-touch)

Network Services

439

Check New Messages, Voice Mail, Call Waiting, Call Forwarding, Nuisance Call Blocking, Caller ID Request, Dual Network, Service Numbers, Remote Control, Multi Number, 2in1, OFFICEED, etc.

Overseas Use

459

Outline of International Roaming (WORLD WING), Available Services, Confirmation for Using, Making a Call at the Country You Stay, Receiving a Call, 3G/GSM Setting, Set Roaming Guidance, Network Services, etc.

PC Connection

469

Available Data Communication, Before Using Data Communication, Preparation Flow for Data Transfer (OBEX™ Communication), Preparation Flow for Data Communication, AT Command, CD-ROM, DOCOMO Keitai Datalink

Appendix/

Troubleshooting

475

Function List, Options and Related Devices, Troubleshooting, Error Messages, Warranty and After-sales Services, i-mode Fault Diagnosis Site, Software Update, Scanning Function, Main Specifications, SAR, Export Administration Regulations, etc.

Index/

Quick Manual

541

Index, Quick Manual, Quick Manual “For Overseas Use”

Easy Search/Contents/Precautions

Main Functions of P-02A

◆i-concier 11P.211

i-concier is a service that enables you to receive useful information from a character (Machi-chara image) on the Stand-by display and download schedule event (i-schedule) files for your convenience. Downloaded i-schedule events or ToruCa files are automatically updated to the latest information, and the address information of shops/companies, etc. is automatically added to the Phonebook.

◆i-αppli Call 11P.306

i-αppli call is a useful function for online games that enables your content provider or third party to give notice to your opponent to start the specified corresponding application.

◆

International Roaming

11P.296, P.460

Your FOMA terminal, phone number, and mail address are available overseas (3G/ GSM areas are supported). Further, “日英版／日中版しゃべって翻訳 for P (J-E/J-C Speech Translation for P)”, which translates words into English or Chinese if you talk in Japanese, and into Japanese if in English or Chinese, is pre-installed.

◆i-Widget 11P.309

i-Widget is a useful function that enables you to easily access the tools and commonly-used contents (Widget αppli) such as a calculator, clock, TV program list, and stock prices information. By launching the i-Widget display, you can check your desired latest information at a glance.

◆1Seg 11P.250

You can watch 1Seg programs of the terrestrial digital broadcasting for mobile objects. Also, you can record a still image or video while watching a 1Seg program.

◆Bluetooth Function 11P.421

The wirelessly-connected FOMA terminal and a Bluetooth device enable you to talk or listen to music while you are carrying the FOMA terminal in your bag.

◆Full Wide VGA Display

You can display still images or movies in the Full Wide VGA (480 dots x 854 dots) display of approx. 3.1 inches and can enjoy watching 1Seg programs on the impressive display. Moreover, you can use the side key to shoot still images and movies with horizontal wide display just like using a digital camera. Also, the light sensor automatically adjusts the backlight in accordance with the ambient brightness, and the LCD AI compensates the image quality in accordance with the brightness.

◆Feel＊Mail 11P.177

Animation of 45 characters and illumination reproduce the atmosphere of mail messages. Pleasant animation appears and illumination lights according to the contents of mail message.

◆Recv. Mail/Call at Open 11P.113

When a missed call or new mail message is found, just open the FOMA terminal to display the detailed Missed Call display or the Inbox list.

Easy Search/Contents/Precautions

◆Speed Selector 11P.25

By the rotating operation, you can scroll displays and select items quickly. Further, in various situation, you can comfortably operate functions such as volume adjustment during music playback or during a call, and zoom adjustment for when shooting with the camera.

◆Swing Slide 11P.24

When you slide to open, the display slightly comes up to your side, so it is easy to see and you feel the naturally-angled touch when putting it on your face during a call.

◆View Blind 11P.115

You can make the display hard to see from an angle. You can use the FOMA terminal without concern for others’ eyes.

◆Shikkari Talk 11P.61

You can make the other party’s voice clear according to surrounding noise.

◆Yuttari Talk 11P.61

You can slow down the other party’s speaking speed during a call.

◆Face Detection 11P.239

You can shoot still images adjusting the camera focus on person’s face automatically.

◆Document Viewer 11P.393

On your FOMA terminal, you can display Microsoft Word files, Microsoft Excel files, and Microsoft PowerPoint files created by personal computers.

◆Voice Recorder 11P.388

You can record your voice as a substitute for taking notes. You can repeatedly play it back, so it is convenient to record the proceedings at a meeting, etc.

◆Chaku-moji 11P.54

◆Videophone 11P.48

◆

i-mode mail/Deco-mail/Deco-mail pictogram

11P.142, P.146, P.342

◆i-αppli/Mega i-αppli/Intuitive Games 11P.290

◆High-Speed Communication Supported 11P.470

◆Chaku-uta Full®/Uta-hodai/Music&Video Channel/Video Clips 11P.208, P.270, P.276, P.278

≥“Chaku-uta Full” is a registered trademark of Sony Music Entertainment Inc.

◆MUSIC Player 11P.278

◆GPS 11P.326

◆Osaifu-Keitai/ToruCa 11P.314, P.316

◆Kisekae Tool 11P.116, P.367

◆Respective Network Services 11P.439

◆Security Settings 11P.121

Easy Search/Contents/Precautions

■Before using the FOMA terminal, read these safety precautions carefully so that

you can use it correctly. After reading the precautions, keep them in a safe place.

■Be sure to observe these safety precautions because they are designed to

protect you or those around you from causing injury and to avoid unnecessary damage to the property.

■The symbols below indicate the levels of danger or damage that can be caused

if the particular precautions are not observed.

Precautions

Danger

This symbol indicates that incorrect handling will almost certainly cause death or serious injury.

Warning

This symbol indicates that incorrect handling poses a risk of causing death or serious injury.

Caution

This symbol indicates that incorrect handling poses a risk of causing injury or damage to the product or property.

ALWAYS FOLLOW THESE DIRECTIONS

■The following symbols show specific directions:

■“Safety Precautions” are divided into the following six sections:

General precautions for FOMA terminal, batteries, adapters/chargers, and

UIM ............................................................................................................. P.11

Precautions for FOMA terminal ................................................................. P.12

Precautions for batteries ............................................................................ P.14

Precautions for adapters/chargers............................................................. P.15

Precautions for UIM.................................................................................... P.16

Notes on using near electronic medical equipment .................................. P.16

Denotes things not to do. (Prohibition)

Denotes not to disassemble.

Denotes not to touch with wet hands.

Denotes not to use where it could get wet or not to wet it.

Denotes mandatory instructions (matters that must be complied with).

Denotes to pull the power plug out of the outlet.

Don’t

Do not

disassemble

Not wet

hands

Avoid Water

Pull the

power plug

out

Easy Search/Contents/Precautions

Do not use, store or leave the FOMA terminal and its accessories in places with a high temperature such as near fire or places exposed to direct sunlight, or in cars under the blazing sun.

The devices could be deformed or malfunction, or the battery may leak, overheat, burst, or catch fire, thus resulting in the deterioration of performance and shortening of the life of devices. Also, part of the case could get heated, causing bare skin burns.

Do not disassemble, modify or solder the FOMA terminal or accessories.

Accidents such as fire, injury, or electric shock, or malfunction may result. The battery may leak, overheat, burst or catch fire.

Do not wet the FOMA terminal or accessories.

If liquids such as water or pet urine get onto them, overheating, electric shock, fire, malfunction, injury or others may result. Pay attention to the place of use and the way of handling.

General precautions for FOMA terminal, batteries, adapters/ chargers, and UIM

Danger

Don’t

Do not

disassemble

Avoid

Water

With your FOMA terminal, use the batteries and adapters/chargers specified by NTT DOCOMO, INC.

If you use any type of battery, adapter or charger other than the specified one, your FOMA terminal, battery or other accessories may leak, overheat, burst, catch fire or malfunction. Battery Pack P19 FOMA AC Adapter 01/02 FOMA AC Adapter 01 for Global use FOMA DC Adapter 01/02 Desktop Holder P29 FOMA Dry Battery Adapter 01 FOMA Portable Charging Adapter 01 FOMA USB Cable with Charge Function 01/02 ※For other compatible products,

contact a handling counter such as a docomo shop.

Do not place the batteries, the FOMA terminal, adapters/ chargers, or UIM in cooking appliances such as microwave ovens or high-pressure containers.

The battery may leak, overheat, burst, or catch fire. The FOMA terminal or the adapter/charger may overheat, smoke, or catch fire, or its circuit parts may become damaged.

Do not throw the FOMA terminal or accessories, or subject them to severe shocks.

The battery may leak, overheat, burst, or catch fire. Also, malfunction or fire may result.

Warning

Don’t

Be careful not to let electroconductive materials (metal pieces, pencil leads etc.) contact with the charging terminal or connector terminal. Also, make sure that those are not entered into the inside of the FOMA terminal.

Short-circuit could cause fire or malfunction of the FOMA terminal.

When you are in a place such as a gas station where flammable gas is generated, turn off the FOMA terminal, and never do charging. Otherwise, catching fire may result.

Ensure that you use Osaifu-Keitai with the FOMA terminal turned off when you are in the vicinity of the gas station. (When IC Card Lock is set, turn off the power with the lock released.)

If odor, overheat, discoloration, or deformation is detected during use, battery charge, or storage, immediately observe the following:

1. Pull the power plug out of the outlet or cigarette lighter socket.

2. Turn off the power to the FOMA terminal.

3. Remove the battery pack from the FOMA terminal.

If you use the FOMA terminal and its accessories as they are, overheat, burst, or catching fire could result or the battery could leak.

Don’t

Easy Search/Contents/Precautions

Do not place the FOMA terminal or accessories on unstable locations such as wobbly tables or slanted locations.

The FOMA terminal or accessories may fall, resulting in injury or malfunction.

Do not store in humid or dusty places, or in high temperature environments.

Malfunction may result.

If children use the FOMA terminal or accessories, a guardian should explain the safety precautions and correct operations. The guardian should also make sure that the instructions are followed during use.

Otherwise, injury may result.

Keep out of the reach of babies and infants.

Accidental swallowing or injury may result.

Be especially careful when you use the FOMA terminal for a long time with the adapter/charger connected.

If you use i-αppli programs, talk on the videophone, watch 1Seg programs and so on for a long time during charging, the temperature of the FOMA terminal, battery pack, or adapter/charger might rise. If you directly touch the part of high temperature continuously, redness, itching, rash, or low-temperature bare skin burns may result depending on your physical conditions or predisposition.

Caution

Don’t

Do not directly point the infrared data port at someone’s eyes during transmission.

His/her eyes may possibly be affected. Other infrared devices may operate erroneously if the infrared data port is pointed at them during transmission.

Do not shine the photo light close to eyes.

Doing so can damage eyesight. Also, accidents such as injury might occur if someone is startled or dazzled by the light.

Do not put the FOMA terminal in the place where it could be affected by an expanded airbag, e.g., on the dashboard.

If the airbag expands, the FOMA terminal could hit you and others, causing accidents such as injury and the FOMA terminal could malfunction and become damaged.

If you have any implanted electronic medical equipment, do not place your FOMA terminal in a chest pocket or inner pocket.

If the FOMA terminal is positioned close to electronic medical equipment, it may cause that equipment to malfunction.

Precautions for FOMA terminal

Warning

Don’t

Do not allow liquids such as water, or foreign materials such as metal pieces or flammable materials to get into the UIM or microSD card slot of the FOMA terminal.

Fire, electric shock or malfunction may result.

Do not turn on the photo light to drivers of cars, and others.

It disturbs driving, and accidents may result.

Turn off the FOMA terminal in places where use is prohibited such as in airplanes and hospitals.

Otherwise, electronic devices and electronic medical appliances may be adversely affected. If the Auto Power ON function is set, deactivate the setting, then turn the power off. For use inside medical facilities, make sure that you comply with their regulations. You may be punished for using the FOMA terminal in airplanes, which is prohibited by law.

When talking with the FOMA terminal set to Hands-free, be sure to keep the FOMA terminal away from your ear. Further, when you play games or play back music with the earphone/microphone connected, adjust the sound volume to moderate volume.

The excessive sound volume impairs your hearing. Further, accidents may result due to the hardness of hearing of surrounding sound.

Don’t

Easy Search/Contents/Precautions

For those with weak heart conditions, the vibrator and ring volume must be adjusted carefully.

Those functions may cause an effect on the heart.

If thunder starts to rumble while you are using the FOMA terminal outdoors, house the antenna, turn off the power and move to a safe place.

Otherwise, you could be struck by lightning or suffer an electric shock.

Turn off the FOMA terminal when near electronic devices using high-precision control or weak signals.

The FOMA terminal may possibly cause these devices to malfunction.

※

Electronic devices that may be affected: Hearing aids, implanted cardiac pacemakers, implanted defibrillators, other medical electronic devices, fire alarms, automatic doors and other automatically controlled devices. If you use an implanted cardiac pacemaker, implanted defibrillator or any other electronic medical device, consult the manufacturer or retailer of the device for advice regarding possible effects from the radio waves.

If the display part or camera lens is broken, be careful about broken glasses or the exposed interior of the FOMA terminal.

Plastic panels are used for the surfaces of the display part and camera lens so that glasses do not easily get scattered, however, pay attention not to erroneously touch the broken part or interior. Otherwise, injury may result.

Do not swing the FOMA terminal by its antenna or strap.

The FOMA terminal may hit you or persons around you, and accidents such as injury or malfunction and damage may result.

Do not use in places crowded with people.

The antenna may hit against others, causing an accident such as injury.

Do not use the FOMA terminal with the damaged antenna.

If the damaged antenna comes in contact with your skin, an accident such as a burn or injury could be caused.

When using the motion tracking, ensure that you check around you for safety, securely take hold of your FOMA terminal, and do not swing to an extent more than necessitated.

The motion tracking is the function to incline or swing the FOMA terminal for operation. If you excessively swing your FOMA terminal, it might happen that it hits against persons or objects, resulting in critical accidents or damage.

When a metallic strap is attached to your FOMA terminal, be careful that it does not hit against persons or objects when using the motion tracking.

Accidents such as injury or malfunction and damage may result.

Caution

Don’t

Do not place magnetic cards or similar objects near the FOMA terminal.

Magnetic data on cash cards, credit cards, telephone cards and floppy disks, etc. may be deleted.

Do not bring magnetic substances close to your FOMA terminal.

Strong magnetic items might cause in erroneous operation.

If you erroneously break the display part and then crystal liquid gets leaked, never take or suck the liquid to or into your mouth, or apply to skin. If the crystal liquid gets into the eyes or mouth, immediately rinse it out with clean water and then seek medical attention. When it adheres to your skin or clothes, immediately wipe it away with alcohol etc., and then rinse it out with water and soap.

Otherwise, the loss of eyesight or injury to your skin may result.

Do not bring your ears close to the speakers while a ring tone sounds or a melody is played back from the FOMA terminal.

Otherwise, your hearing could be impaired.

Don’t

Easy Search/Contents/Precautions

Electronic devices in some types of cars can be affected by use of the FOMA terminal.

For safety’s sake, make sure not to use the FOMA terminal inside such cars.

Itching, rash or eczema may be caused depending on your physical conditions or predisposition. If an abnormality occurs, stop using the FOMA terminal immediately, and then seek medical attention.

Metals are used for the following parts:

Be careful not to get your finger or a strap caught in the parts when you close or open the FOMA terminal.

Accidents such as injury or damage may result.

Where it is used Material Finishing

Charging terminal Phosphor

bronze

Gold-plated finish with

nickel-plated ground Slide rail SUS304 Fluorine coating Metal part of the 1Seg antenna

Top Brass Tin-and-cobalt-plated

finish with

nickel-plated ground

Middle SUS304 — Hinge at bottom part

SUS304 Tin-and-cobalt-plated

finish with

nickel-plated ground

Screw at bottom part

Brass Nickel-plated

Recording/ PushTalk key

ABS Chrome-plated finish

with copper-and-

nickel-plated ground

When you watch a 1Seg program, watch in a place bright enough taking a certain distance from the display.

Otherwise, your visual acuity could be reduced.

■Check the description on the label of the

battery pack for the type of battery.

Do not let any metal object such as a wire come in contact the battery terminals. Also do not carry or store the battery together with any metal objects like a necklace.

The battery may leak, overheat, burst or catch fire.

Do not use excessive force to attach the battery to the FOMA terminal even when you cannot attach it successfully. Also, check that the battery is the right way round when you attach it.

The battery may leak, overheat, burst or catch fire.

Do not throw the battery into fire.

The battery may leak, overheat, burst or catch fire.

Precautions for batteries

Description Type

Li-ion Lithium-ion battery

Danger

Don’t

Do not pierce it with nails, hit it with a hammer, or step on it.

The battery may leak, overheat, burst or catch fire.

If the battery fluid gets into your eyes, do not rub them. Flush your eyes with clean water and seek medical attention immediately.

Otherwise, the loss of eyesight may result.

When any abnormality due to external shock such as the deformation or scratches by dropping is found on the battery pack, immediately stop using it.

The battery may leak, overheat, burst, or catch fire. Also, malfunction or fire may result.

If charging is not completed at the end of the specified charging time, stop charging.

Otherwise, the battery may leak, overheat, become damaged or catch fire.

Immediately stop using the FOMA terminal and keep it away from fire if the battery leaks or emits an odor

The leaked battery fluid may ignite, causing fire or burst.

Be careful that your pets do not bite into the battery pack.

The battery may leak, overheat, burst, or catch fire. Also, malfunction or fire may result.

Warning

Don’t

Easy Search/Contents/Precautions

An exhausted battery should not be disposed of with other waste.

The battery may catch fire or damage the environment. After insulating the battery terminals with tape, take the unneeded battery to a handling counter such as a docomo shop or dispose of it in accordance with local waste disposal regulations.

Do not charge the wet battery.

The battery pack may overheat, catch fire, or burst.

If the battery fluid comes in contact with skin or clothes, immediately stop using, then rinse it out thoroughly with clean water.

Skin injury may result.

Do not use a damaged adapter/ charger cord or power cord.

Electric shock, overheating or fire may result.

Do not use the AC adapter and desktop holder in steamy places such as a bathroom.

Electric shock may occur.

Caution

Precautions for adapters/chargers

Warning

Don’t

The DC adapter is for use only in a negative (-) grounded vehicle. Do not use it in a positive (+) grounded vehicle.

Fire may result.

If it starts to thunder, do not touch the FOMA terminal and adapter/charger.

You might be struck by lighting or suffer an electric shock.

Never short-circuit the charging terminal when the adapter is plugged into the power outlet or cigarette lighter socket. Also, never touch the charging terminal with fingers or other bare skin.

Fire, malfunction, electric shock or injury may result.

Place the charger and desktop holder on a stable location during charging. Do not cover or wrap the charger and desktop holder in cloth or bedding.

The FOMA terminal may drop off, or the charger and desktop holder may overheat, causing fire or malfunction.

Do not place something heavy on the adapter/charger cord and power cord.

Electric shock or fire may result.

Do not touch the power cord of the adapter/charger, or power outlet with wet hands.

Electric shock may result.

Don’t

Not wet

hands

Use the adapter/charger at the specified V AC.

If you use it at a wrong voltage, fire or malfunction may result. When using the FOMA terminal overseas, use FOMA AC adapter available overseas. AC adapter: 100 V AC DC adapter: 12/24 V DC [For negative (-) grounded vehicles only] AC adapter available overseas: 100 V to 240 V AC [Connect only to household AC outlet]

If a fuse of the DC adapter has blown, replace it with a specified fuse.

If you use an unspecified fuse, fire or malfunction may result. For the specified fuse, refer to each instruction manual.

Keep the power plugs dust-free.

Otherwise, fire may result.

When pulling the AC adapter into the power outlet, firmly plug it in, taking care not to contact with metal straps or the like.

Otherwise, electric shock, short-circuit or fire may result.

Easy Search/Contents/Precautions

When removing the adapter/ charger out of the outlet or cigarette lighter socket, do not forcibly pull the adapter/charger cord or power cord, instead take hold of the power plug and then pull.

If you pull the plug out by the cord, the cord may be damaged, which could result in electric shock or fire.

When the adapter/charger is not to be used for a long period of time, unplug the power cord from the outlet.

Otherwise, electric shock, fire, or malfunction may result.

If liquids such as water get in the charger, unplug the power cord immediately from the outlet or cigarette lighter socket.

Otherwise, electric shock, smoke or fire may result.

Before cleaning, pull the power plug out of the outlet or cigarette lighter socket.

Otherwise, electric shock may result.

Be careful not to touch the cut surface of the UIM (IC portion) when removing it.

You may hurt your hand or fingers.

Precautions for UIM

Caution

Pull the

power plug

out

Pull the

power plug

out

Pull the

power plug

out

■The description below meets “Guidelines on

the Use of Radio-communication Equipment such as Cellular Telephones – Safeguards for Electronic Medical Equipment” by the Electromagnetic Compatibility Conference Japan.

Comply with the following in hospitals or health care facilities:

≥Do not carry the FOMA terminal into

operating rooms, intensive care units (ICU) or coronary care units (CCU).

≥Turn off the FOMA terminal in hospital

wards.

≥If there is any electronic medical

equipment near you, turn off the FOMA terminal even when in a location such as a lobby.

≥Comply with any regulations of

hospital and health care facilities instructing you not to use or carry in a mobile phone.

≥If the Auto Power ON function is set,

deactivate the setting, then turn the power off.

Turn off the FOMA terminal in crowded areas such as inside trains during rush hour, as someone with an implanted cardiac pacemaker or implanted defibrillator may be near you.

Operation of an implanted cardiac pacemaker or implanted defibrillator can be affected by radio waves.

Notes on using near electronic medical equipment

Warning

If you use an implanted cardiac pacemaker or implanted defibrillator, use the mobile phone 22 cm or more away from an implanted cardiac pacemaker or implanted defibrillator.

Operation of an implanted cardiac pacemaker or implanted defibrillator can be affected by radio waves.

Patients using electronic medical equipment other than implanted cardiac pacemakers or implanted defibrillators (outside medical establishments for treatment at home, etc.) should check the influence of radio waves upon the equipment by consulting its manufacturer.

Operation of electronic medical equipment can be affected by radio waves.

■Do not wet the equipment.

The FOMA terminal, battery, adapter/charger, and UIM are not waterproofed. Do not use them in environments, which are high in humidity such as in bathrooms, and do not allow them to get wet from rain. Furthermore, if carrying them against your body, they become moist due to perspiration and the internal parts may become corroded, causing malfunction. If the parts are found to have been damaged due to exposure to the liquids, any repairs will not be covered by warranty, or repairs may not be possible. This may be repaired at a cost if repairs are possible.

Handling Precautions

General notes

Easy Search/Contents/Precautions

■Use a dry soft cloth such as the one for

cleaning glasses to clean the equipment.

≥The screen of the FOMA terminal sometimes has a

special coating so that they are easier to see. If you rub it roughly with a dry cloth, it might be scratched. Take care of the way of handling, and use only a dry, soft cloth such as the one for cleaning glasses. If the screen is left with water drop or stain adhered, smear may be generated or the coating might peel off.

≥Do not use alcohol, thinner, benzene, detergent or

other solvents for cleaning, otherwise the printing may be removed or discoloration may result.

■Occasionally clean the terminals of the

equipment using a dry cotton swab.

If the terminals become soiled, the connection might deteriorate so that the power turns off or the battery does not charge fully. Wipe the terminals with a dry cloth or cotton swab.

■Do not place the FOMA terminal near an air

conditioner outlets.

Condensation may form due to rapid changes in temperature, and this may corrode internal parts and cause malfunction.

■Do not apply excessive force onto the FOMA

terminal and battery pack.

If you put the FOMA terminal in a bag along with many other articles or sit with the FOMA terminal in a clothes pocket, the display, internal circuitry and the battery pack could be damaged or malfunction. Also, if an external device is left connected to the connector terminal, the connector could be damaged, or malfunction.

■Carefully read each instruction manual

attached to the FOMA terminal, adapter/ charger, or desktop holder.

■Do not rub or scratch the display part with

metals.

Doing so might cause damage to the part, resulting in trouble or malfunction.

■Avoid using in extremely high or low

temperatures.

The FOMA terminal should be used within a temperature range of 5°C to 35°C and a humidity range of 45% to 85%.

■The FOMA terminal, if operated near land-line

phones, television sets, radios or other devices that are in use, may affect them. You should operate your FOMA terminal as far away from such equipment as possible.

■It is recommended that you make separate

notes of the information stored in the FOMA terminal and keep such notes in a safe place.

We take no responsibility for any loss of the stored data items.

■Do not drop the FOMA terminal or subject it to

strong impacts.

Malfunction or damage may result.

■Do not insert an external device to the

connector terminal (earphone/microphone terminal) at a slant when connecting, and do not pull it out when it is inserted.

Malfunction or damage may result.

■Make sure that nothing, such as a strap, gets

caught between the parts of the FOMA terminal when you close it.

Otherwise, malfunction or damage may result.

■The FOMA terminal becomes warm during

use or charging but this is not an abnormality. Use the FOMA terminal as it is.

■Do not leave the camera in places exposed to

direct sunlight.

Pixels may be discolored or burns may result.

■Usually, put the cover of the connector

terminal and microSD card slot to use the FOMA terminal.

Dust or water might enter into the FOMA terminal, causing malfunction.

Notes on handling the FOMA terminal

■Do not use the FOMA terminal with the back

cover left removed.

The battery pack might come out, or malfunction or damage may result.

■Do not put a label or sticker on the back of the

display part of the FOMA terminal.

They may be caught in when you open/close the FOMA terminal, and malfunction or damage may result.

■While you are using the microSD card, never

take it off or turn off the power to the FOMA terminal.

Data may be erased or malfunction may result.

■Batteries have a limited life.

Though it varies depending on the usage state, you are advised to replace the battery if its usable time is extremely short even when you fully charge it. Make sure that you buy the specified battery.

■Charge the battery in a place with an

appropriate ambient temperature of 5°C to 35°C.

■Make sure that the battery is charged when

you use the FOMA terminal for the first time or have not used it for a long period of time.

■The usable time of the battery differs

depending on the usage environment or its remaining life.

■Depending on how the battery pack is used, it

might swell as its operating life becomes short, but this is not a problem.

Notes on handling batteries

Easy Search/Contents/Precautions

■Note the following points when you store a

battery pack over a long period:

≥Storage in a fully charged state (the state immediately

after charging is completed)

≥

Storage with no battery power left (the state you cannot

turn on the power of the handset due to battery drain) These may lower the battery pack’s performance and shorten its operating life. You are advised to store the battery pack in the state of two bars of battery icon indication as a guide when you store it for a long period.

■Charge the battery in a place with an

appropriate ambient temperature of 5°C to 35°C.

■Charge the battery where:

≥There is very little humidity, vibration, and dust. ≥There are no land-line phones, television sets or

radios nearby.

■During charging, the adapter/charger may

become warm. This is not an abnormality, so continue charging.

■Do not use the DC adapter for charging the

battery when the car engine is not running.

The car battery could go flat.

■When using the power outlet having the

disengaging prevention mechanism, observe the instructions given in that instruction manual.

■Do not give a strong shock. Also, do not

deform the charging terminal.

Malfunction may result.

■Be careful not to get your finger or the

adapter/charger cord caught in the parts when you house the stand of the desktop holder.

Accidents such as injury or damage may result.

Notes on handling chargers/adapters

■Never use more force than necessary when

inserting/removing the UIM.

■The UIM may become warm during use, but

this is not a sign of a malfunction. Continue using it as it is.

■The warranty does not cover damage caused

by inserting the UIM into some other types of IC card reader/writer.

■Always keep the IC portion clean.

■Use a dry soft cloth such as the one for

cleaning glasses to clean the equipment.

■It is recommended that you make separate

notes of the information stored on the UIM and keep such notes in a safe place.

We take no responsibility for any loss of the stored data items.

■For the environmental protection, bring any

unneeded UIMs to a handling counter such as a docomo shop.

■Avoid using in extremely high or low

temperatures.

■Do not damage, carelessly touch, or

short-circuit the IC.

Data might be lost or malfunction may result.

■Do not drop the UIM or subject it to strong

impacts.

Malfunction may result.

■Do not bend the UIM or place something

heavy on it.

Malfunction may result.

Notes on handling the UIM

■Into the FOMA terminal, do not insert the UIM

with a label or sticker pasted.

Malfunction may result.

■As the security for communication using the

Bluetooth function, the FOMA terminal supports the security function that meets the Bluetooth Specification. However, the security may not be sufficient depending on the configuration. Take care of the security for communication using the Bluetooth function.

■Note that even if any leak of data or

information occurs while making connection using the Bluetooth function, we take no responsibility.

■With the FOMA terminal, you can use the

following: Headset, Hands-Free, Audio, Dial-up Communication, Object Push, and Serial Port. With Audio, you might be able to use Audio Video Remote Control. (Only with the compatible Bluetooth devices)

Notes on using Bluetooth function

Easy Search/Contents/Precautions

■Radio frequencies

The radio frequencies the Bluetooth function of the FOMA terminal uses are as follows:

■Cautions on Using Bluetooth Devices Bluetooth operates at radio frequencies assigned to the in-house radio stations for mobile object identifiers that have to be licensed and are used in production lines of a factory, specific unlicensed low power radio stations, and amateur radio stations (hereafter, referred to “another radio station”) in addition to scientific, medical, industrial devices, or home electric appliances such as microwave ovens.

1. Before using this product, make sure that “another radio station” is not operating nearby.

2. If radio interference between this product and “another radio station” occurs, move immediately to another place or turn off power to avoid interference.

3. For further details, contact “docomo Information Center” on the back page of this manual.

2.4 FH 1

2.4 : Indicates radio facilities that use 2400 MHz frequencies.

FH : Indicates the modulation system is the FH-SS

system.

1 : Indicates that a supposed coverage distance is

10 meters or less.

: Indicates that all radio frequencies 2400 MHz

through 2483.5 MHz are used, and that the frequencies for mobile object identifiers shall not be avoided.

■The FeliCa reader/writer function on the

FOMA terminal uses very weak radio waves which do not require to be licensed as radio stations.

■The FeliCa reader/writer is operated on the

13.56 MHz frequencies. When you use another reader/writer nearby, take enough distance between your FOMA terminal and the reader/writer. Further, ensure that there are no radio stations that use the same frequencies.

■Do not use the modified FOMA terminal.

Using a modified FOMA terminal infringes the Radio Law.

The FOMA terminals are granted technical regulations conformity certification as the specified radio equipment under the Radio Law and bear a “technical conformity mark ” on the nameplate as evidence of conformity. Unscrewing the FOMA terminal and modifying internal components void the technical regulations conformity certification. Do not use the FOMA terminal in this state, which infringes the Radio Law.

■Be especially careful not to operate the FOMA

terminal while driving.

You will be imposed punishment if you use the mobile phone in your hand while driving. If you answer a call out of necessity, tell the caller with Hands-free that you will call him/her back, park your car to somewhere safe, and then dial.

■Use the Bluetooth functions in Japan only.

The Bluetooth functions on the FOMA terminal have been authorized in compliance with the radio transmission standards in Japan. You might be imposed punishment if you use them overseas.

Notes on handling the FeliCa reader/ writer

Caution

■Use the FeliCa reader/writer functions in

Japan only.

The FeliCa reader/writer functions on the FOMA terminal have been authorized in compliance with the radio transmission standards in Japan. You might be imposed punishment if you use them overseas.

Easy Search/Contents/Precautions

Other Options → See page 507

Accessories and Main Options

≥P-02A Handset

(With Warranty and Back Cover P30)

≥P-02A CD-ROM

The PDF versions of “Manual for PC Connection” and “Kuten Code List” are included.

≥FOMA AC Adapter 01/02

(With Warranty and Instruction Manual)

≥Instruction Manual

Quick Manual included (See page 550)

≥Battery Pack P19 ≥Desktop Holder P29

(With Instruction Manual)

NTTドコモ

Before Using the Handset

Part Names and Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Opening/Closing FOMA Terminal . . . . . . . . . . . . . . . . . . . . . . . . 24

Navigation Displays and Key Operations . . . . . . . . . . . . . . . . . 24

Main Key Operations from the Stand-by Display . . . . . . . . . . . 26

Viewing Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Using Icons on Desktop . . . . . . . . . . . . . . . . . .<Desktop Icon> 29

i-Widget Display and Operations . . . . . . . . . . . . . . . . . . . . . . . . 32

Displaying Description of Icons . . . . . . . . . . . . . . . . . . <Icons> 32

Selecting Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

When You Forget Key Operation . . . . . . . . . . . . . . . . . <Guide> 36

Using UIM (FOMA Card) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Attaching/Removing Battery Pack . . . . . . . . . . . . . . . . . . . . . . . 39

Charging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Checking Battery Level . . . . . . . . . . . . . . . . . . .<Battery Level> 42

Turning Power ON/OFF . . . . . . . . . . . . . . . . . <Power ON/OFF> 43

Switching to English Display . . . . . . . . . . .<Select Language> 43

Configuring Initial Setting . . . . . . . . . . . . . . . . .<Initial Setting> 44

Setting Date and Time . . . . . . . . . . . . . . . . . . . . . . . <Set Time> 44

Displaying World Time . . . . . . . . . . . . . . <World Time Watch> 45

Notifying the Other Party of Your Phone Number

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <Caller ID Notification> 46

Checking Your Own Phone Number . . . . . . . . <Own Number> 46

Before Using the Handset

Part Names and Functions

;

B C

■For using earphone

Connect an optional connector-terminal-compatible earphone. When using a connector-terminal-non-compatible earphone, use an optional plug adapter for connection. ≥When inserting or pulling the plug adapter, take hold of the plug for the handset side and insert or

pull it straight. Be careful not to take hold of the cover of the connector terminal and plug for the handset side together when you pull it out.

≥The Earphone Plug Adapter for External connector terminal 01 (option) can be connected with a

triple pole mini plug only. For details, refer to the instruction manual for the Earphone Plug Adapter for External connector terminal 01.

Flat plug of the Flat-plug Earphone/ Microphone with Switch

Earphone terminal (Flat-plug)

Example for connecting the Flat-plug Earphone/Microphone with Switch (option)

Plug for the handset side

Before Using the Handset

1Light sensor

・For sensing brightness (See page 114)

≥Do not cover the light sensor with your hands or do

not put a sticker on it. Doing so might disable you to detect the brightness.

2Earpiece

・For listening to the other party’s voice

3Display

(See page 27)

4l Mail key

5m Menu key

6d Start key/Hands-free key

・For making/receiving calls (See page 48 and page 62) ・For talking with Hands-free (See page 61)

7r Clear key/i-Widget key

・For returning to the previous operation ・For clearing entered text or a phone number

8Microphone

・For speaking to the other party

9Inside camera

・For shooting photos of yourself (See page 230) ・For displaying your face during a videophone call

:o Speed selector

;Call/Charging indicator

・Flickers for incoming calls/mail and during a call.

(See page 117)

・Lights in red during charging.

≥The flickering pattern and color tone of the illumination

might look different depending on the type of the FOMA terminal you use.

<i i-mode key/i-αppli key

=c Camera key/1Seg key

>h Power/End key

・For ending calls ・For ending respective functions ・For turning on the power (for at least one second)/

For turning off the power (for at least two seconds) (See page 43)

?Numeric keys

・For entering phone numbers and text

@Connector terminal

・For connecting the AC adapter (option), DC adapter

(option), FOMA USB Cable with Charge Function 01/ 02 (option), or Stereo Earphone Set 01 (option), etc.

≥Integrated terminal for connecting earphone or for

charging, etc.

A1Seg antenna

・For receiving 1Seg broadcasting (See page 251)

BOutside camera

・For shooting portraits and/or landscapes

(See page 230)

・For catching sight of persons and/or landscapes

during a videophone call

CPhoto light

・Lights/Flickers when you shoot with the camera. ・Used for shooting in a dark place. (See page 239)

Df mark

・The IC card is mounted.

≥Use the IC card function placing this mark over the

scanning device. You cannot dismount the IC card. (See page 315)

EFOMA antenna

≥The FOMA antenna is embedded in the handset. Do

not cover the antenna with your hand for better communication.

FSpeaker

・For sounding ring tones ・For listening to the other party’s voice when

Hands-free is activated (See page 61)

GInfrared data port

・Used for infrared communication and the infrared

remote control. (See page 382 and page 386)

HmicroSD card slot

・For inserting microSD card (See page 368)

IBack cover

・Remove this when attaching/removing the battery

pack and UIM. (See page 37 and page 39)

≥Do not peel off the sticker on the back of the back

cover. If you peel it off, you might not be able to read and write the IC card.

JCharging terminal

Kx Multi key

L<Side ▲ key

・For scrolling up page by page

M>Side ▼ key

・For scrolling down page by page

Np Recording key/PushTalk key

・For making/receiving PushTalk calls

(See page 78 and page 81)

OStrap hole

Before Using the Handset

Hold the FOMA terminal with both hands to slide the display upward/ downward. Take care not to touch the keys when you open or close the FOMA terminal. Key operation errors may result.

≥When a call comes in, you can answer it just by

opening the FOMA terminal. (See page 65)

≥When a missed call or new mail message is found,

you can display the detailed Missed Call display or the Inbox list just by opening the FOMA terminal. (See page 113)

Opening/Closing FOMA Terminal

Information

≥You can use the horizontal display for Full Browser, PC Movie player, Camera, 1Seg,

Music&Video Channel, i-αppli, i-motion player, and Video player. You cannot use it for other functions.

≥When you open/close the FOMA terminal while a confirmation display for selecting

“YES/NO” is shown, the confirmation display may be cleared.

When you want to execute the operation shown on the vertical display, press the corresponding key as below.

≥While the horizontal display is shown, you can operate in the same way as on the

vertical display depending on the function.

■Basic display examples and key assignments

Navigation Displays and Key Operations

Indicates the operation you can perform with the l key.

Indicates the operation you can perform with the m key.

Indicates the operation you can perform with the Oo key.

Indicates the direction in which you can scroll and select items with the Mo key.

Indicates the operation you can perform with the c key.

Indicates the operation you can perform with the i key.

Before Using the Handset

■Operating speed selector

Depending on the display being shown, you can select items and move the cursor by rotating the speed selector in the same way as you press

Mo.

≥The following operations are also available:

・Adjusting earpiece volume, ring volume, etc. (See page 65, page 66)

Operating by Rotating Speed Selector

display up. (Press and hold to scroll continuously.)

・Moves the cursor to the right. ・Scrolls forward page by page.

(Press and hold to scroll continuously.)

・Fixes the operation.

and hold to scroll continuously.)

・Moves the cursor or highlighted

display down. (Press and hold to scroll continuously.)

・Scrolls the page down.

Scrolling pages

Selecting items Selecting pictograms, etc.

Moving a cursor

Rotating direction

Operation example

・Adjusting zoom magnification when shooting with the camera (See page 238) ・Adjusting volume during music playback, etc. (See page 281) ・Switching the displayed still images (See page 345) ・Adjusting volume during playback of movies, i-motion movies, etc. (See page 352)

You can set whether to validate the rotating operation of the speed selector.

m1Set./Service1Other settings

1Speed selector setting1ON or OFF

You can set whether to show the operation for such as pressing Zo, Xo,

Co, and Vo, when you rotate the speed selector from the Stand-by

display.

m1Set./Service1Display1Key guidance

1ON or OFF

When you rotate the speed selector from the Stand-by display, the operation for such as pressing Zo, Xo, Co, and Vo are shown. (See page 26) ≥The key guidance is shown regardless of “Speed selector

setting”.

Information

≥The rotating operation is not valid in Power Saver Mode. ≥The rotating operation may not be valid depending on the function.

Speed Selector Setting

Information

≥Depending on the i-αppli program, the speed selector might not be operable even

when “ON” is set.

Key Guidance

When “ON” is set

Before Using the Handset

From the Stand-by display, you can execute the following actions by operating each key:

Main Key Operations from the Stand-by Display

Key

operation

Press the key for a short time

Press and hold the key for at least

one second

*Oo

Shows the display for selecting an icon, etc. on the Stand-by display. (See page 31, page 68, page 111)

Switches Key Lock on/off. (See page 131)

*Zo

Shows the Channel list. (See page 210)

—

*Xo

Shows the Search Phonebook display. (See page 94)

Shows the registration display for the Phonebook entries. (See page 88)

*Co

Shows the Received Call list. (See page 53)

Shows the Received Address list. (See page 171)

*Vo Shows the Redial list. (See page 52)

Shows the Sent Address list. (See page 171)

Shows the Mail menu. (See page 162)

Executes Check New Messages. (See page 157)

Shows the i-mode menu. (See page 190)

Shows the Software list. (See page 291)

+m Shows Main Menu. (See page 32)

Sets/Releases IC Card Lock. (See page 316)

Activates the camera in Photo Mode. (See page 233)

Starts 1Seg. (See page 253)

-d Makes a call. (See page 48)

Accesses a voice dial entry. (See page 100)

-h

Shows/Clears the icons, etc. on the Stand-by display. (See page 112)

Turns off the power. (Press and hold the key for at least two seconds) (See page 43)

+r Executes i-Widget. (See page 310) Resets Main Menu. (See page 116)

-0 Enters “0”. Enters “+”.

-1 Enters “1”.

Measures your current location and executes the GPS function. (See page 326)

-2 Enters “2”.

-3 Enters “3”.

-4 Enters “4”.

-5 Enters “5”.

Switches the backlight on/off. (See page 114)

-6 Enters “6”.

-7 Enters “7”.

-8 Enters “8”.

Switches View Blind on/off. (See page 115)

-9 Enters “9”.

-a Enters “:”.

Activates/Deactivates Public Mode (Drive Mode). (See page 67)

-s Enters “#”.

Activates/Deactivates Manner Mode. (See page 108)

Shows the Multitask Menu. (See page 402)

Shows the display for setting 3G/ GSM Setting. (See page 465)

Switches menu functions. (See page 402)

Switches between the i-αppli Stand-by display and normal i-αppli program. (See page 308)

Activates/Deactivates Manner Mode with the FOMA terminal closed. (See page 108)

Activates 2in1 with the FOMA terminal opened. (See page 450)

Plays back a record message/voice memo. (See page 70)

Plays back a videophone record message/movie memo. (See page 71)

Shows the PushTalk Phonebook list. (See page 82)

Activates MUSIC Player. (See page 279)

Key

operation

Press the key for a short time

Press and hold the key for at least

one second

Before Using the Handset

Viewing Display

1235 8 ;:=>?<C

9B6

Battery level (estimate) (See page 42)

Radio waves reception level (estimate)

Strong Weak

You are out of the FOMA service area or radio waves do not reach.

During Self Mode (See page 126)

During i-mode (See page 190)

During i-mode communication (See page 190)

During packet communication (The icon differs depending on the communication status.)

During PushTalk communication (See page 78)

You get out of the service area while Network Search Mode is set to “Manual”. (See page 465)

During SSL communication (See page 191)

(pink)

Unread i-mode mail or an SMS message exists. (See page 155 and page 187)

(dark blue)

The area for i-mode mail and SMS messages in the FOMA terminal is full. (See page 155 and page 187)

The area for SMS messages on the UIM (FOMA card) is full.

(pink)

Unread mail exists, and the area for SMS messages on the UIM (FOMA card) is full.

(dark blue)

Both the FOMA terminal and UIM (FOMA card) are full.

Area Mail exists. (See page 180)

(yellow)

Unread Messages R/F exist. (See page 177)

(dark blue)

The area for Messages R/F in the FOMA terminal is full. (See page 178)

(pink)

i-mode mail is held at the i-mode Center. (See page 157)

(dark blue)

The box for i-mode mail at the i-mode Center is full. (See page 155)

(yellow)

Messages R/F are held at the i-mode Center. (See page 178)

(dark blue)

The box for Messages R/F at the i-mode Center is full. (See page 178)

i-mode mail is held at the i-mode Center while Receive Option Setting is set to “ON”. (See page 156)

New i-concier information exists. (See page 212)

An i-αppli call you did not reply to exists. (See page 306)

During a voice call

During a videophone call

During 64K data communication

;

During measuring the current location (See page 326)

Location Request Set. is set to “ON” or “Reject numbers unset”, and it is within the validity period. (See page 338)

Location Request Set. is set to “ON” or “Reject numbers unset”, and it is out of the validity period. (See page 338)

A microSD card is inserted.(See page 369)

Data is being read to/written from the microSD card.

A write-protected microSD card is inserted. (See page 369)

The inserted microSD card cannot be used. (See page 369)

A microSD card is inserted, and the FOMA USB Cable with Charge Function 01/02 (option) is connected in microSD Mode. (See page 377)

A microSD card is inserted, and the FOMA USB Cable with Charge Function 01/02 (option) is connected in MTP Mode. (See page 377)

(blue)

A Bluetooth device is connected. (See page 424 and page 426)

(black)

A Bluetooth device is connected and power consumption is low. (See page 424)

Before Using the Handset

≥For the horizontal display, icons appear at the lower right

of the display.

≥The clock at the upper right of the display (at the lower

right of the horizontal display) does not appear when the icon B or C is displayed.

During Lock All (See page 124)

During Personal Data Lock (See page 127)

During Keypad Dial Lock (See page 131)

During Secret Mode or Secret Data Only (See page 132)

During IC Card Lock (See page 316)

Both Keypad Dial Lock and Personal Data Lock are set.

Both Keypad Dial Lock and Secret Mode/ Secret Data Only are set.

Both IC Card Lock and Lock All are set.

Both IC Card Lock and Personal Data Lock are set.

Both IC Card Lock and Keypad Dial Lock are set.

Both IC Card Lock and Secret Mode/Secret Data Only are set.

IC Card Lock, Keypad Dial Lock, and Personal Data Lock are simultaneously set.

IC Card Lock, Keypad Dial Lock, and Secret Mode/Secret Data Only are simultaneously set.

Type of in-use network (See page 461)

You are in the OFFICEED area. (See page 456)

Timer Lock ON At Close is set. (See page 127)

During Key Lock (See page 131)

While Key Lock is temporarily released (See page 132)

During Multitask (See page 401)

Multiple functions are activated. (See page 401)

While watching a 1Seg program (See page 253)

During recording of a 1Seg program (See page 260)

During recording of a 1Seg program by Timer Recording (See page 264)

During pause of 1Seg program recording (See page 261)

During music playback (See page 279)

During music pause (See page 279)

During infrared communication (See page 382 and page 386)

The FOMA USB Cable with Charge Function 01/02 (option) is connected in Communication Mode.

The FOMA USB Cable with Charge Function 01/02 (option) is connected in microSD Mode. (See page 377)

During talk or communication through a USB Hands-free compatible device (See page 61)

A USB Hands-free compatible device is connected. (See page 61)

A USB Hands-free compatible device is connected in microSD Mode. (See page 61)

Vibrator is set to other than “OFF”. (See page 106)

Ring Volume is set to “Silent” or Mail/Msg. Ring Time is set to “OFF”. (See page 66 and page 108)

During Manner Mode (See page 108)

Remote Monitoring is set to “ON”. (See page 77)

During Public Mode (Drive Mode) (See page 67)

The call cost has exceeded the specified limit. (See page 417)

An alarm is set. (See page 264 and page 405)

A Music&Video Channel program is booked. (See page 270)

Backlight is set to “OFF”. (See page 114)

View Blind is set to “ON”. (See page 115)

Backlight is set to “OFF” and View Blind is set to “ON”.

USB Mode Setting is set to “microSD mode”. (See page 377)

USB Mode Setting is set to “MTP mode”. (See page 377)

〜・

Voice mail messages for Number B are held at the Voice Mail Center in Dual Mode of 2in1. (See page 455)

〜・

Voice mail messages are held at the Voice Mail Center. (See page 440)

〜

The number of record messages (See page 69)

〜

The number of videophone record messages (See page 69)

Information

≥Some characters and symbols on the display might be

modified or abbreviated.

≥The color liquid crystal display uses high-precision

production technology. The slightest change in the environment or other factors may result in unlit or permanently lit pixels, but this is not a manufacturing defect.

+ 182 hidden pages

Docomo P-02A Instruction Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
