Docomo P-01D Instruction Manual

Download

P-01D

ISSUE DATE:

NAME:

PHONE NUMBER:

MAIL ADDRESS:

INSTRUCTION MANUAL

Preface

Thank you for selecting the “P-01D”.

For proper use, read this manual before and when you use the P-01D.

Notes on Using this Mobile Phone

󱾀



This mobile phone is compatible with W-CDMA, GSM/GPRS and wireless LAN systems.

󱾀



Because this mobile phone uses radio waves, you cannot use it in places where the radio waves do not reach such as inside tunnels, basements and buildings, where the radio waves are weak even outdoors, or out of FOMA service area. You might not be able to operate this mobile phone even when you are in a place with a fine view such as on upper floors of a high-rise building or apartment. Note that you may experience interruption of calls even when the four-bar antenna mark is displayed indicating a strong radio wave and you are not moving.

󱾀



Since this mobile phone uses radio waves as the medium of telecommunication, calls may be tapped by a third party. However, the W-CDMA and GSM/GPRS systems automatically support tapping prevention, so your conversation will be incomprehensible to the third party, because it is recognized as mere noise.

󱾀



The mobile phones change your voice into digital signals and send them to the other party. In places where the radio waves are weak, the digital signals may not be converted correctly, and in such a case, the voice may sound different from the actual one.

󱾀



This mobile phone supports FOMA Plus-Area and FOMA High-Speed Area.

󱾀



You are advised that you make separate notes of information stored in this mobile phone and keep them in a safe place. Note that we cannot be held responsible for the unlikely event of loss of the stored content due to a malfunction, repair, change of your model, or other mishandling of this mobile phone.

󱾀



You are advised to save your important data on the microSD card.

󱾀



As with PC applications, some applications you have installed in this mobile phone may pose problems: unstable operations of your mobile phone, unauthorized distribution and use of your location and personal information stored in the mobile phone. Therefore, you need to thoroughly check the source and behaviors of intended applications before use.

󱾀



This manual assumes use of a DOCOMO UIM.

SIM Unlock

This mobile phone supports SIM unlocking. You can use another operator’s SIM card once you unlock the SIM.

󱾀



Contact a docomo Shop for SIM unlocking.

󱾀



You will be charged a SIM unlocking fee separately.

󱾀



When you use another operator’s SIM card, available services and functions are limited. Note that we provide no warranty of operations with other operator’s SIM cards.

󱾀



For details of SIM unlocking, refer to DOCOMO website.

Basic Package/Samples

P-01D (with warranty and Back Cover P53)

Battery Pack P25

Quick Start Guide (in Japanese)

AC Adapter Cable P01 (with warranty) <AC adapter>

Basic Package

Sample

microSD card (2 GB) (with manual)

*Installed in the mobile phone at the time of purchase.

• For other optional items, Z P.234

Descriptions of Operating Procedures

The operating procedures of the P-01D are described in the following manuals.

■ “Quick Start Guide” (in Japanese only)

(supplied with this mobile phone)

Describes operating procedures of basic functions.

■ [Instruction Manual] (in Japanese only)

(installed in your mobile phone)

Describes detailed information of functions and operating procedures.

Home screen W

• Before using Instruction Manual for the first time, install the application from Android Market.

W [Instruction Manual]

■ “Instruction Manual” (PDF)

Describes detailed information of functions and operating procedures. Download from DOCOMO website: http://www.nttdocomo.co.jp/support/trouble/manual/ download/index.html

* Note that the URL and published contents may be modified

without notice.

Information

• It is prohibited to copy all or part of this manual without permission.

• The information contained in this manual may be changed without notice.

• Operating procedures when [docomo Palette UI] home application are explained in this manual. If you change the home application, some operating steps may differ from those described in this manual.

• Screenshots and illustrations shown in this manual are for reference. The actual ones may differ.

• Keys are simplified for explaining operating procedures in this manual.

set as the

Handling Precautions for this Mobile Phone

• This mobile phone is not compatible with i-mode site (program) and i-αppli.

•

This mobile phone is designed to perform communication automatically check for the latest software version and maintaining a connection with the server. Communication of a massive amount of data such as application download and video watching will cost expensive packet communication fee, so we strongly recommend subscription to the flat-rate packet service.

• Public mode (drive mode) is not available for this mobile phone.

• Operation sounds such as shutter sound of the camera, etc. are emitted from this mobile phone even in Silent mode in which phone ringtone, touch tones and notification ringtone are muted.

• To confirm your phone number (My Details), Z P.104

for

some

features such as data synchronization,

• To confirm the software version of your mobile phone, Z P.143

• New features may be added to this mobile phone and operation system (OS) upgrading. For the latest information on additional features and change of operation method, see DOCOMO website.

• OS upgrading may disable applications used in the old OS version or pose unwanted failure.

• For services provided by Google, Inc., read Google Terms of Service. For other web services, read the respective terms of service.

• In the event of loss of your mobile phone, be sure to change passwords for various service accounts from PC in order to prevent others from accessing your accounts for Google services such as Google Talk, Gmail and Android Market, Facebook, Twitter, and/or mixi.

• Providers other than sp-mode, mopera U and business mopera Internet are not supported.

method is

subject to change due to future operating

• Although you can use this mobile phone without installing a microSD card, there are files that can only be stored on microSD card, such as images shot by Camera. Therefore, installing a microSD card is recommended when using this mobile phone.

• sp-mode subscription is required for using tethering.

• When using tethering, packet communication fee varies depending strongly recommended. If you subscribe to a flat-rate packet service, packet communication fee is charged based on “communications made by connecting to a PC or other external device”. When tethering is enabled, all packet communications are regarded as “communications made by connecting to a PC or other external device”, even when the external devices are not connected. Be sure to disable tethering when communication on the external device is finished.

• When tethering is enabled, sp-mode functions are not available except Internet access and mail service.

• When an external device is connecting to the Internet by tethering, applications (browser, games, etc.) may not work correctly on the device in some situations.

• No security measure such as password setting is applied between a smartphone/tablet and external device in the default setting of tethering. Setting a password is recommended.

• For details including usage fees, visit http://www.nttdocomo.co.jp/english/

on the

price plan. Using a flat-rate packet service is

Basic Package/Samples. . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Descriptions of Operating Procedures. . . . . . . . . . . . . . . . 2

Handling Precautions for this Mobile Phone. . . . . . . . . . . 3

Precautions (ALWAYS FOLLOW THESE DIRECTIONS). . . . 9

Handling Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Preliminary Check

docomo Palette UI

Initial Setting

Part Names and Functions. . .

UIM. . . . . . . . . . . . . . . . . . . . . . . . 35

microSD Card. . . . . . . . . . . . . . . . . 37

Battery Pack. . . . . . . . . . . . . . . . . . 39

Charging. . . . . . . . . . . . . . . . . . . . . 41

Power On/Off. . . . . . . . . . . . . . . . . . 44

Basic Operations (How to Use Touch

Panel). . . . . . . . . . . . . . . . . . . . . . . 46

Screen Display/Icons. . . . . . . . . . . . 49

Character Entry. . . . . . . . . . . . . . . . 53

. . . . . . . . . . . . . . . 67

Home Screen.

Application Screen. . . . . . . . . . . . . . 71

Home Application Settings. . . . . . . . . 79

Initial Setting. . . Changing Screen Display to English

. . . . . . . . . . . . . . . . . . . . . . . . . . . 82

Google Account. . . . . . . . . . . . . . . . 83

Setting Access Point. . . . . . . . . . . . . 84

Email Setting. . . . . . . . . . . . . . . . . . 87

. .

. . . . . . . . . . . . . . . 80

. . . . . . 32

Phone/Network

Services

Wi-Fi. . . . . . . . . . . . . . . . . . . . . . . . 89

Online Service Accounts. . . . . . . . . . 92

Phone. . . . . . . . . . . . . . . . . . . . . . . 93

Call Log. . . . . . . . . . . . . . . . . . . . . . 99

Phonebook. . . . . . . . . . . . . . . . . . . 100

PhoneBookCopy. . . . . . . . . . . . . . . 105

Available Network Services. . . . . . . 107

Setting Menu. . .

. . . . . . . . . . . . . . 115

Wireless & Networks. . . . . . . . . . . . 116

Call Settings. . . . . . . . . . . . . . . . . . 120

Sound. . . . . . . . . . . . . . . . . . . . . . 122

Display. . . . . . . . . . . . . . . . . . . . . 124

Location & Security. . . . . . . . . . . . . 125

Various Settings

115

Mail/Internet

144

Applications. . . . . . . . . . . . . . . . . . 134

Accounts & Sync. . . . . . . . . . . . . . . 135

Privacy. . . . . . . . . . . . . . . . . . . . . 137

Storage. . . . . . . . . . . . . . . . . . . . . 138

Language & Keyboard. . . . . . . . . . . 139

Voice Input & Output. . . . . . . . . . . 140

Accessibility. . . . . . . . . . . . . . . . . . 141

Date & Time. . . . . . . . . . . . . . . . . 142

About Phone. . . . . . . . . . . . . . . . . 143

sp-mode Mail.

. . . . . . . . . . . . . . . . 144

Message (SMS). . . . . . . . . . . . . . . 145

Email. . . . . . . . . . . . . . . . . . . . . . 148

Gmail. . . . . . . . . . . . . . . . . . . . . . 151

Early Warning "Area Mail". . . . . . . . 154

Google Talk. . . . . . . . . . . . . . . . . . 156

Web Browser. . . . . . . . . . . . . . . . . 159

. .

Infrared Communication.

. . . . . . 164

File Management

164

Bluetooth Communication. . . . . . . . 167

VPN (Virtual Private Network) Connection

. . . . . . . . . . . . . . . . . . . . . . . . . . 171

External Device Connection. . . . . . . 173

Camera. . . . . . . . . . . . . . . . . . . . . 175

Applications

175

Gallery. .

. . . . . . . . . . . . . . . . . . . 181

Music Player. . . . . . . . . . . . . . . . . . 183

Android Market. . . . . . . . . . . . . . . . 186

Using docomo market. . . . . . . . . . . 188

Future Plus. . . . . . . . . . . . . . . . . . 189

Google Maps. . . . . . . . . . . . . . . . . 197

1Seg. . . . . . . . . . . . . . . . . . . . . . . 199

ToruCa. . . . . . . . . . . . . . . . . . . . . 207

YouTube. . . . . . . . . . . . . . . . . . . . 208

News & Weather. . . . . . . . . . . . . . 209

Clock. . . . . . . . . . . . . . . . . . . . . . . 211

Calendar. . . . . . . . . . . . . . . . . . . . 213

Calculator. . . . . . . . . . . . . . . . . . . 216

ECONAVI. . . . . . . . . . . . . . . . . . . . 217

Barcode Reader. . . . . . . . . . . . . . . 218

Catalyst Reader. . . . . . . . . . . . . . . 220

SD backup. . . . . . . . . . . . . . . . . . . 222

Overseas Use

224

Overview of International Roaming

. . . . . . . . . . . . 224

(WORLD WING).

. .

Available Services. . . . . . . . . . . . . . 225

Confirmation before Use. . . . . . . . . 226

Settings for Overseas Use. . . . . . . . 229

Making/Receiving Calls in the Country You

Stay. . . . . . . . . . . . . . . . . . . . . . . 231

Confirmation after Returning Home

. . . . . . . . . . . . . . . . . . . . . . . . . . 233

Optional Items and Associated Equipment . . .

. . . . . . . . . . . . . . . . . . . . . . . 234

Troubleshooting (FAQ). . . . . . . . . . 235

Warranty and After-Sales Service. . . 244

Software Update. . . . . . . . . . . . . . 248

Main Specifications. . . . . . . . . . . . . 262

Specific Absorption Rate (SAR) of the

Phone. . . . . . . . . . . . . . . . . . . . . . 266

Appendix

234

European RF Exposure Information

. . . . . . . . . . . . . . . . . . . . . . . . . . 268

Declaration of Conformity. . . . . . . . 269

FCC Notice. . . . . . . . . . . . . . . . . . . 270

FCC RF Exposure Information. . . . . 271

Important Safety Information. . . . . 273

Export Administration Regulations

. . . . . . . . . . . . . . . . . . . . . . . . . . 275

Intellectual Property Right. . . . . . . . 276

Index. . . . . . . . . . . . . . . . . . . . . . 280

Precautions (ALWAYS FOLLOW THESE

Danger

Warning

Caution

Don’t

Do not

disassemble

Not wet

hands

Avoid Water

DIRECTIONS)

■Before using the mobile phone, read these safety

precautions carefully so that you can use it correctly. After reading the precautions, keep them in a safe place.

■Be sure to observe these safety precautions to prevent you

or those around you from inflicting injury and to avoid unnecessary damage to the property.

■The symbols below indicate the levels of danger or damage

that can be caused if the particular precautions are not observed and equipments are not used properly.

This symbol indicates that incorrect handling poses an imminent risk of causing death or serious injury.

This symbol indicates that incorrect handling poses a potential risk of causing death or serious injury.

This symbol indicates that incorrect handling poses a risk of causing an injury or damage to property.

■The following symbols show specific directions:

Denotes actions prohibited to do.

Denotes not to disassemble the units.

Denotes not to touch with wet hands.

Denotes not to use where the equipment may get wet, and avoid get it wet.

Denotes mandatory instructions (matters that must be

Pull the

power plug

out

Danger

Don’t

Do not

disassemble

Avoid Water

complied with).

Denotes to pull the power plug out of an outlet.

■“Precautions” are divided into the following six sections:

General Precautions for this Mobile Phone, Battery Packs, AC Adapter Cable, and UIM. . .

. . . . . . . . . . . . . . . . . . . . . . P.10

Precautions for this Mobile Phone. . . . . . . . . . . . . . . . . . . P.12

Precautions for Battery Packs. . . . . . . . . . . . . . . . . . . . . . P.15

Precautions for AC Adapter Cable. . . . . . . . . . . . . . . . . . . P.17

Precautions for UIM. . . . . . . . . . . . . . . . . . . . . . . . . . . . P.19

Notes on Using near Electronic Medical Equipment. . . . . . . P.19

General Precautions for this Mobile Phone, Battery Packs, AC Adapter Cable, and UIM

Do not use, store, or leave the mobile phone or its accessories

places as near fire, near heating appliances, inside a kotatsu or near other furniture with heating elements, in places exposed to direct sunlight, or in cars heated by the sun).

Fire, burns, or injury may result.

Do not place the mobile phone or its accessories inside cooking appliances such as microwave ovens or high pressure containers.

Fire, burns, injury or electric shock may result.

Do not attempt to disassemble or remodel the mobile phone or its accessories.

Fire, burns, injury or electric shock may result.

with a high temperature (such

Do not allow the mobile phone or its accessories to get wet either from water, drinking water or pet urine, etc.

Fire, burns, injury or electric shock may result.

With your mobile phone, use the battery packs and

Warning

Don’t

Caution

Don’t

AC adapter cables specified by NTT DOCOMO, INC.

Fire, burns, injury or electric shock may result.

Do not throw the mobile phone or accessories, or subject them to severe force or shocks.

Fire, burns, injury or electric shock may result.

Do not allow electrically conductive foreign objects (such as metal pieces or pencil leads) to come into contact with connector terminal or earphone/ microphone terminal. Do not allow such objects to enter into the mobile phone.

Fire, burns, injury or electric shock may result.

Do not cover or wrap the mobile phone or its accessories with a cushion, etc. while it is being used or recharged.

Fire or burns may result.

Before entering a gas station or other places where flammable gases are generated, be absolutely sure to turn off this mobile phone and stop charging if it is being charged.

Otherwise, the flammable gases may ignite.

If odor, overheat, discoloration, or deformation is detected during use, battery charge, or storage, immediately follow the instructions below:

• Pull the power plug out of the outlet.

• Turn off the power of this mobile phone.

• Remove the battery pack from this mobile phone.

Fire, burns, injury or electric shock may result.

Do not place the mobile phone or accessories on unstable locations such as wobbly tables or slanted locations.

They may fall off and cause injury.

Do not store in humid or dusty places, or in high temperature environments.

Fire, burns or electric shock may result.

If the mobile phone and its accessories are used by a

Warning

Don’t

child, a guardian

should explain how to operate them correctly. During use, a guardian should also check that they are being used as instructed.

Otherwise, injury may result.

Keep out of the reach of small children.

Accidental swallowing or injury may result.

Take special care when you use this mobile phone for a long time with the AC adapter cable connected.

If you watch 1Seg programs and so on for a prolonged period of time while charging, the temperature of this mobile phone, battery pack or AC adapter cable may rise. If you keep direct contact with high-temperature parts, redness, itching, a rash or low-temperature skin burns may result depending on the state of your physical condition or constitution.

Precautions for this Mobile Phone

Do not directly point the infrared data port at someone’s eyes during transmission.

Doing so may harm the person’s eyes.

While using infrared communication, do not point the mobile phone’s infrared appliance which is equipped with an infrared device.

The infrared device may malfunction, and possibly cause an accident.

Do not light the light close to eyes. Especially when shooting small children, be sure to stay at least 1 m away from them.

Doing so can damage eyesight. Also, accidents such as injury

might occur

if someone is startled or dazzled by the light.

data port at a home electrical

Do not allow liquids such as water, or foreign materials such as to get into the UIM or microSD card slot of this mobile phone.

Fire, burns, injury or electric shock may result.

metal pieces or flammable materials

Don’t

Do not turn on the light toward car drivers.

It disturbs driving, and accidents may result.

Turn off this mobile phone in places where use is prohibited such as in airplanes and hospitals.

Otherwise, the electronic devices and electronic medical equipment in those places may be adversely affected. If the Auto power ON function is set, deactivate the setting, then turn off the power.

use inside medical facilities, make sure that you comply

For with their regulations. Engaging in any prohibited acts such as using the mobile phone in an airplane is punishable by law. However, if use of the mobile phones in an airplane is permitted provided that radio wave transmission is turned off, you may do so in accordance with instructions of each airline.

When talking in Hands-free mode or when a ring tone is sounding, be absolutely sure to keep this mobile phone away from your ear. Further, when you play games or play back music etc. with the earphone/microphone etc. connected, adjust the sound volume to moderate volume.

The excessive sound volume impairs your hearing. Further, accidents may result due to the hardness of hearing of surrounding sound.

For those with weak heart conditions, the vibrator and ring volume must be adjusted carefully.

Otherwise, the functions may adversely affect your heart.

If you are using an electronic medical device or other type of device,

check with its manufacturer or vendor regarding the influence of radio waves upon the device.

The mobile phone may adversely affect the device.

Turn off this mobile phone when near electronic

Caution

Don’t

devices using high-precision control or weak signals.

The mobile phone may cause the electronic devices to malfunction and have other adverse effects. * Electronic devices that may be affected: Hearing aids, implanted cardiac pacemakers, implanted defibrillators, other electronic medical equipment, fire alarms, automatic doors and other automatically controlled devices. If you use an implanted cardiac pacemaker, implanted defibrillator or any other electronic medical

equipment, consult

the manufacturer or retailer of the device for advice regarding possible effects from the radio waves.

If the display part or camera lens is broken, be careful about broken glasses or the exposed interior of this mobile phone.

A film is coated on the surface of the display area and the plastic panel is used for the surface of the camera lens, making

it hard

for the glass to break into pieces. However, if you touch the damaged or exposed parts by mistake, you may injure yourself.

Do not swing around this mobile phone by its strap, antenna or other parts.

You may hit yourself or others, possibly causing injury or other accidents.

Do not use this mobile phone if it has been damaged.

Fire, burns, injury or electric shock may result.

When using the motion sensor, ensure that you check around you for safety, securely take hold of your mobile phone, and do not swing more than necessitated.

Otherwise, injury or other accidents may result.

Don’t

The surface of the display is coated by a film that

Don’t

prevents the surface

from damage so that your safety is ensured when you accidentally drop or give shock to your mobile phone (for preventing the reinforced glass from scattering). Do not forcibly peel off or give damage to the film.

If the display is damaged while you operate the mobile phone with the film peeled off, you might suffer an injury.

If you accidentally damage the display part and the substance inside

leaks out, keep your face, hands

and skin away from it.

Otherwise, you may impair your eyesight or damage your skin. If this substance should get into your eyes or mouth, immediately rinse them with clean water, and then seek medical attention. If it should adhere to your skin or clothing, immediately wipe it off with alcohol or similar liquid, and then rinse the affected area with soap and water.

Before using the mobile phone inside a car, check with its manufacturer or dealer whether the radio waves will have any adverse effects.

In some vehicle models, the radio waves may adversely affect

the electronic

devices inside the vehicle. Such cases are rare. However, if this happens, stop using the mobile phone immediately.

Itching, rash or eczema may be caused depending on your physical conditions or predisposition. If an abnormality occurs, stop using the mobile phone immediately, and then seek medical attention.

For

material

each part, Z P.20 “List of materials used”

View the display in a sufficiently light place keeping a certain distance from your eyes.

Otherwise, your eyesight may become impaired.

Precautions for Battery Packs

■Check the description on the label of the battery pack for

the type of battery.

Description Type

Li-ion 00 Lithium-ion battery

Danger

Don’t

Do not let any metal object such as a wire come in

Don’t

Warning

Don’t

contact with the battery terminals. Also do not carry or store the battery pack together with any metal objects like a necklace.

Otherwise, the battery pack may ignite, burst or overheat and its electrolyte may leak.

When installing the battery pack in this mobile phone, check that it

is facing the right way, and if the battery pack cannot be installed easily, do not force it into place.

Otherwise, the battery pack may ignite, burst or overheat and its electrolyte may leak.

Do not throw the battery pack into fire.

Otherwise, the battery pack may ignite, burst or overheat and its electrolyte may leak.

Do not pierce it with nails, hit it with a hammer, or step on it.

Otherwise, the battery pack may ignite, burst or overheat and its electrolyte may leak.

If the battery fluid or other material gets into your eyes, do not rub them. Flush your eyes with clean water and seek medical attention immediately.

Otherwise, the loss of eyesight may result.

Never use the mobile phone if it has damages such as deformities or scratches as a result of dropping it.

Otherwise, the battery pack may ignite, burst or overheat and its electrolyte may leak.

Immediately stop using the mobile phone and keep it away from fire if the battery pack leaks or emits an odor.

The leaked battery fluid may ignite, causing fire or burst.

Be careful that your pets do not bite into the battery pack.

Otherwise, the battery pack may ignite, burst or overheat and its electrolyte may leak.

Caution

Don’t

Do not dispose of the battery pack with other waste.

Don’t

Danger

Don’t

Warning

Don’t

The battery pack may catch fire or damage the environment. After insulating the battery terminals with tape, take the unneeded battery pack to a handling counter such as a docomo Shop or dispose of it in accordance with local waste disposal regulations.

Do not use or attempt to charge a wet battery pack.

Otherwise, the battery pack may ignite, burst or overheat and its electrolyte may leak.

If the electrolyte fluid or other material inside the battery pack has leaked out, do not allow it to come into contact with the skin on your face, hands or any other part of your body.

Contact may result in loss of sight or skin problems.

you get

If or on skin or clothing, immediately wash the affected areas with clean water. If you get it in your eyes or mouth, immediately seek medical attention after rinsing.

the fluid or other material in your eyes or mouth,

Precautions for AC Adapter Cable

Do not connect microUSB cables other than the supplied one.

Fire, burns or electric shock may result.

Do not use the microUSB cable if it has been damaged.

Fire, burns or electric shock may result.

Do not use the AC adapter cable in humid places such as a bathroom.

Fire, burns or electric shock may result.

Don’t

If a thunderstorm is nearby, do not touch the AC

Don’t

Not wet

hands

Pull the

power plug

out

adapter cable.

Otherwise, you may receive an electric shock.

Never short-circuit the AC adapter cable plug or terminal when the AC adapter is plugged into the power outlet. Also, never touch the plug or terminal with fingers or other bare skin.

Fire, burns or electric shock may result.

Do not place heavy objects on the microUSB cable.

Fire, burns or electric shock may result.

When plugging the AC adapter into the power outlet, or when unplugging it from the outlet, do not allow metal straps or other metal objects to come in contact with it.

Fire, burns or electric shock may result.

Do not touch the AC adapter cable or power outlet with wet hands.

Fire, burns or electric shock may result.

Use the adapter at the specified V AC.

Supplying the wrong

voltage to the AC adapter may result in a fire, burns or electric shocks. 100 V - 240 V AC (Connect only to household AC outlet.)

Keep the power plugs dust-free.

Fire, burns or electric shock may result.

When plugging the AC adapter into the power outlet, plug it in securely.

Fire, burns or electric shock may result.

When unplugging the power plug from the power outlet, take hold of the AC adapter to unplug it.

Fire, burns or electric shock may result.

When you do not intend to use the adapter for a long period of time, disconnect the power plug from the power outlet.

Fire, burns or electric shock may result.

Pull the

power plug

out

If liquids such as water get in the adapter, unplug the

Pull the

power plug

out

Caution

Warning

power plug immediately from the outlet.

Fire, burns or electric shock may result.

Before cleaning, pull the power plug out of the outlet.

Fire, burns or electric shock may result.

Precautions for UIM

Be careful not to touch the cut surface of the UIM when removing it.

Otherwise, injury may result.

Notes on Using near Electronic Medical Equipment

■The description below meets “Guidelines on the Use of

Radio-communication Equipment such as Cellular Telephones – Safeguards for Electronic Medical Equipment” by the Electromagnetic Compatibility Conference Japan.

Comply with the following in hospitals or health care facilities:

• Do not carry this mobile phone into operating rooms, intensive

• Turn off this mobile phone in hospital wards.

• If there is any electronic medical equipment near you, turn as a lobby.

• Comply with any regulations of hospital and health care facilities instructing you not to use or carry in a mobile phone.

• If the Auto power ON function is set, deactivate the setting, then turn off the power.

care units

off this

mobile phone even when in a location such

(ICU) or coronary care units (CCU).

Turn off this mobile phone in trains during the rush

hour or other crowded areas as there may be someone near you with an implanted cardiac pacemaker or implanted defibrillator.

The mobile phone’s radio waves may adversely affect the operation

of implanted

cardiac pacemakers and implanted

defibrillators.

If you use electronic medical equipment such as implanted cardiac pacemaker or implanted defibrillator, carry and use this mobile phone 22 cm or more away from the implanted cardiac pacemaker or implanted defibrillator.

The mobile phone’s radio waves may adversely affect the operation of electronic medical equipment.

Patients using electronic medical equipment other than implanted cardiac pacemakers or implanted defibrillators (outside medical establishments for treatment at home, etc.) should check the influence of radio waves upon the equipment by consulting its manufacturer.

The mobile phone’s radio waves may adversely affect the operation of electronic medical equipment.

■ List of materials used

Where it is used Material/Finishing

Earphone/microphone terminal (resin part)

Outer casing Display surface,

Battery surface Stopper (Battery

surface) Back cover PC+ABS/UV coating

Connector terminal Stainless steel/nickel

Connector terminal cover

Surface PC+ABS/UV coating

Connector area PU Camera lens area PMMA Speaker area Polyester Display panel Glass, PET/surface hard

PC/UV coating

POM

plating

coating

Where it is used Material/Finishing

Battery compartment surface Glass epoxy substrate Battery

terminal

Battery pack Resin part PC+ABS

UIM/microSD card slot

Screws (inside of the back cover) Carbon steel/nickel

Keys PC/UV coating Label Battery surface PP Label (Battery compartment surface) PET

Resin part LCP

Terminal area Beryllium copper/nickel

plating, gold plating

Label PET

Terminal area Copper/nickel plating,

gold plating Resin part LCP Terminal area Beryllium copper/nickel

plating, gold plating Top end area Stainless steel

plating

Label (Battery surface)

1Seg antenna Tip resin part ABS/UV coating

Speaker side PC Camera side Stainless steel

Metal part (Sleeve area/Pipe area/Wire area), Hinge part at bottom part (Wire connection area/Pin/ Lift up area)

Holder area Zinc alloy/nickel plating

Stainless steel

Handling Precautions

General Notes

■Do not wet the equipment.

This mobile phone, battery pack, AC adapter cable, and UIM are not waterproofed. Do not use them in environments, which are high in humidity such as in bathrooms, and do not allow them to get wet from rain. Furthermore, if carrying them against your body, they become moist due to perspiration and the internal parts may become corroded, causing malfunction. If the parts are found to have been damaged due to exposure to the liquids, any repairs will not be covered by warranty, or repairs may not be possible. This may be repaired at a cost if repairs are possible.

■Use a dry soft cloth such as the one for cleaning glasses to

clean the equipment.

• The display may be scratched if it is rubbed hard with a dry cloth.

• Stains may result from droplets of water or dirt if they are left on the display.

• Do not use alcohol, thinner, benzene, detergent or other solvents for cleaning, otherwise the printing may be removed or discoloration may result.

■Occasionally clean the terminals of the equipment using a

dry cotton swab, etc.

soiled terminals

The power discontinuity or incomplete charging. Wipe the terminals with a cotton swab, etc. Take care not to damage the terminals when cleaning them.

deteriorate the connection and might cause

■Do not place the mobile phone near an air conditioner

outlets.

Condensation may form due to rapid changes in temperature, and this may corrode internal parts and cause malfunction.

■Do not apply excessive force onto this mobile phone and

battery pack.

If you put the mobile phone in a bag along with many other articles or sit with the mobile phone in a clothes pocket, the display, internal circuitry and the battery pack could be damaged or malfunction. Also, if an external device is left connected to the connector terminal or the earphone/microphone terminal, the connector could be damaged, or malfunction.

■Do not rub or scratch the display part with metals.

Doing so might cause damage to the part, resulting in failure or malfunction.

■Carefully read each instruction manual attached to battery

pack or AC adapter cable.

Notes on Handling this Mobile Phone

■Never forcibly press the surface of the touch panel, or

operate it with something having a sharp point like a claw, ballpoint pen, or pin.

Damage to the touch panel might result.

■Avoid using in extremely high or low temperatures.　

The mobile phone should be used within a temperature range of 5°C to 35°C and a humidity range of 45 % to 85 %.

■If the mobile phone is operated near a land-line phone,

television set, radio or other devices in use, it may adversely affect the devices. Operate the mobile phone as far away from these devices as possible.

■It is recommended that you make separate notes of the

information stored in this mobile phone and keep such notes in a safe place.

We take no responsibility for any loss of the stored data items.

■Do not drop this mobile phone or subject it to strong

impacts.

Malfunction or damage may result.

■Do not insert an external device to the connector terminal

or the earphone/microphone terminal at a slant when connecting, and do not pull it out when it is inserted.

Malfunction or damage may result.

■This mobile phone becomes warm during use or charging

but this is not an abnormality. Use the mobile phone as it is.

■Do not leave the camera in places exposed to direct

sunlight.

Pixels may be discolored or burns may result.

■When using the mobile phone, ensure that you close the

cover for the connector terminal.

Dust or water might enter into the mobile phone, causing malfunction.

■Do not use the mobile phone with the back cover left

removed.

The battery pack might come out, or malfunction or damage may result.

■While you are using the microSD card, never take it off or

turn off the power of this mobile phone.

Data may be erased or malfunction may result.

■Do not place magnetic cards or similar objects near this

mobile phone.

Magnetic floppy disks, etc. may be deleted.

data on cash cards, credit cards, telephone cards and

■Do not bring magnetic substances close to your mobile

phone.

Problems with operation may result if items with strong magnetic fields are brought close to the mobile phone.

Notes on Handling Battery Packs

■Battery pack is a consumable item.

Though it depends on the usage state, you are advised to replace the battery pack if its usable time is extremely short even when you fully charge it. Make sure that you buy a specified battery pack.

■Charge

temperature of 5°C to 35°C.

the

battery

in a place with an appropriate ambient

■The usable time of the battery pack differs depending on

the usage environment and its remaining life.

■Depending on how the battery pack is used, it might swell

as its remaining life becomes short, but this is not a problem.

■Note the following points when you store a battery pack:

• Storage in a fully charged state (the state immediately after charging is completed)

• Storage with no battery power left (the state you cannot turn on the power of the main unit due to battery drain)

These may lower the battery pack’s performance and shorten its operating life. Before it is recommendable, as a general rule, for its remaining battery level to be about 40 %.

storing a battery pack, check its remaining battery level:

Notes on Handling AC Adapter Cable

■Charge the battery in a place with an appropriate ambient

temperature of 5°C to 35°C.

■Charge the battery where:

• There is very little humidity, vibration, and dust.

• There are no land-line phones, television sets or radios nearby.

■While

warm. This is not a malfunction, so you can keep on using.

you are

■When using the power outlet having the disengaging

prevention mechanism, observe the instructions given in that instruction manual.

■Do not give a strong shock. Also, do not deform the

charging terminal.

Malfunction may result.

charging, the AC adapter cable may become

Notes on Handling the UIM

■Do

or removing the UIM.

not

apply

more force than is necessary when installing

■The warranty does not cover damage caused by inserting

the UIM into some other types of IC card reader/writer.

■Always keep the IC portion clean.

■Use a dry soft cloth such as the one for cleaning glasses to

clean the UIM.

■It is recommended that you make separate notes of the

information stored on the UIM and keep such notes in a safe place. 　

We take no responsibility for any loss of the stored data items.

■For the environmental protection, bring any unneeded

UIMs to a handling counter such as a docomo Shop.

■Do not damage, carelessly touch, or shortcircuit the IC.

Data might be lost or malfunction may result.

■Do not drop the UIM or subject it to strong impacts.

Malfunction may result.

■Do not bend the UIM or place something heavy on it.

Malfunction may result.

■Into this mobile phone, do not insert the UIM with a label

or sticker pasted.

Malfunction may result.

Notes on Using Bluetooth Function

2.4FH1

■This mobile phone supports the security function that

meets the Bluetooth Specification, to secure Bluetooth communication. However, the security may not be sufficient depending on the settings. Take care of the security for communication when using the Bluetooth function.

■Note that even if any leak of data or information occurs

while take no responsibility.

making

■With this mobile phone, you can use the following:

Headset, Hands-Free, Audio, and Object Push. With Audio, you might be able to use Audio Video Remote Control. (Only with the compatible Bluetooth devices)

■Radio frequencies

The radio frequencies for the Bluetooth function of this mobile phone are as follows:

connection

using the Bluetooth function, we

2.4 : Indicates radio facilities that use 2400 MHz frequencies.

FH : Indicates modulation is the FH-SS system. 1 : Indicates that an estimated interference distance is

10 meters or less.

: Indicates that all radio frequencies 2400 MHz

through 2483.5 MHz are used, and that the frequencies for mobile object identifiers shall not be avoided.

To use on airplane, confirm with airline company in advance. Use of Bluetooth may be prohibited in some countries. Please confirm laws and regulations applicable in the country/region before use.

■Cautions on Using Bluetooth Devices

Bluetooth operates at house radio stations for mobile object identifiers that have to be licensed and are used in production lines of a factory, specific unlicensed low power radio stations, and amateur radio stations (hereafter, referred to “another radio station”) in addition to scientific, medical, industrial devices, or home electric appliances such as microwave ovens.

1. Before using this mobile phone, make sure that “another radio station” is not operating nearby.

2. If radio wave interference between this mobile phone and “another radio station” occurs, move immediately to another place or turn off power to avoid interference.

3. For further details, contact “General Inquiries” on the back page of this manual.

radio frequencies assigned to the in-

Notes on Handling Wireless LAN (WLAN)

■Wireless LAN (WLAN) has an advantage of any-place LAN

connectivity within the radio wave range as it establishes communication via radio wave. At the same time, however, you have a risk that malicious third party may break without security measures. It is recommended to take security measures at your discretion and responsibility.

into the

network and steal communication contents

■Wireless LAN

Do not use Wireless LAN in a place where magnetized by electric product, AV, OA equipment, etc. or where electromagnetic wave is generated.

• If magnetism or electrostatic noise affects your mobile phone, noise may be increased or communication may not be

available (especially

affect your mobile phone).

• Using near TV or radio may cause poor reception or TV screen may be disturbed.

• When multiple wireless LAN access points exist near your mobile phone and they use the same channel, search may not be performed correctly.

when using microwave oven, it may

■Radio frequencies

2.4DS/OF4

The radio frequencies for WLAN devices are written on battery compartment of your mobile phone. Label description are as follows:

2.4 : Indicates radio facilities that use 2400 MHz frequencies.

DS/OF : Indicates modulation is the DS-SS/OFDM system. 4 : Indicates that an estimated interference distance

is 40 meters or less.

: Indicates that all radio frequencies 2400 MHz

through 2483.5 MHz are used, and that the frequencies for mobile object identifiers shall be avoided.

Available channels vary depending on countries. To use on airplane, confirm with airline company in advance.

of wireless

Use confirm laws and regulations applicable in the country/region before use.

LAN may be prohibited in some countries. Please

■Cautions on Using 2.4 GHz Devices

The bandwidth of the WLAN devices is assigned to the inplant radio stations in production lines of a factory (a license is required), specified low power radio stations (a license is not required), or amateur radio stations (a license is required), in addition to home electric appliances such as a microwave oven, industrial/scientific/medical devices.

1. Before using this device, confirm that in-plant radio stations power radio stations or amateur radio stations are not in operation in your neighborhood.

2. If this device generates harmful radio wave interference against in-plant radio stations for identification of mobile or stop using wireless LAN function, and contact “General Inquiries” on the back page of this manual, then consult about treatment for prevention of the interference (for example, installation of partitions etc.).

3. If this device generates harmful radio wave interference against in-plant radio stations for identification of mobile objects or amateur radio stations, or if any trouble occurs, contact “General Inquiries” on the back page of this manual.

for identification

objects, immediately change the radio frequency

for identification of mobile objects used

of mobile objects, specified low

Caution

■Do not use the modified mobile phone. Using a modified

mobile phone infringes the Radio Law.

mobile phones

The certification as the specified radio equipment under the Radio

Law and bear a “technical conformity mark nameplate as evidence of conformity. Unscrewing the mobile phone and modifying internal components void the technical regulations conformity certification. Do not use the mobile phone in this state, which infringes the Radio Law.

are granted technical regulations conformity

” on the

■Take special care not to operate the mobile phone while

driving.

Holding a fine or other penalties. However, this does not apply in unavoidable circumstances when, for instance, rescuing someone who is sick or injured or when maintaining public order.

a mobile phone in your hand while driving is subject to

■Do not make any unauthorized or unsanctioned changes

to the basic software.

Such changes will be construed as remodeling and, as a result, requests to repair faults may be denied.

Preliminary Check

0 !

(

)

Part Names and Functions

Name Description

1 H Power key Press and hold this key for at least two

seconds to turn

the power on (Z P.44).

To press and hold this key for at least one second when the power is on, set/cancel the Silent mode or Flight mode, or turn the power off. Set/cancel the Sleep mode (Z P.44).

2 Earphone/

microphone terminal

3 Light sensor Detects ambient brightness to

automatically adjust the screen brightness. In order for the sensor to detect the brightness, do not cover it with your hand or attach a seal on it.

Proximity sensor A sensor that prevents false operation of

the touch panel during call. Protective seat or seal attached on the proximity sensor may cause malfunction of the sensor.

4 Earpiece You can hear voice of the other party

from this part.

5 Display (Touch

panel)

Slide your finger to scroll the screen, or tap an item to select it (Z P.46).

6 A Menu key Display the option menu available in the

current screen.

7 Call/Charging

indicator

Flashes when the mobile phone receives a call or message. Lights during charging.

8 Connector

terminal

9 Wi-Fi/Bluetooth

antenna

Connect the included microUSB cable for charging or a PC connection.

The antenna is embedded in the main unit. Do not cover this part with your hand, as it may impair antenna quality.

0 C Back key Return to the previous screen. ! B Home key Return to the home screen (Z P.

67). Press and hold this key to display recently-used applications.

Name Description

" Microphone Send your voice from this part. Serves as

a microphone when recording sound.

# 1Seg antenna Extend this antenna when you watch

1Seg (Z P.200).

$ Strap hole -

/ F

% E

& Camera Shoot still images and videos (Z P.175). ' Back cover - ( Speaker From this part, you can hear

) Photo light Lights at the time of shooting with the

Volume keys Adjust the volume of the other party’s

voice or sound from the speaker (Z P.98, P.122).

ringtones, music and the other party’s voice during hands-free call.

camera.

- Infrared data port Used for infrared communication (Z

P.164).

a GPS antenna

b FOMA antenna The antenna is embedded in the main

The antenna is embedded in the main unit. Do not cover this part with your hand, as it may impair antenna quality.

unit. Do not cover this part with your hand, as it may impair antenna quality.

UIM

Corner cut

The UIM is an IC card that holds your information such as phone number. Unless the UIM is installed, you cannot use the mobile phone’s communication features such as call, messaging and data communication.

• The UIM (blue) is not usable with this mobile phone. If you have a UIM (blue), bring it to a docomo Shop to replace.

• For details about the UIM, refer to the Instruction Manual of the UIM.

Installation/Removal of UIM

• Installation/removal of the UIM should be performed with the mobile phone turned off, the battery pack removed, and microSD card installed (Z P.37, P.40).

• Be careful not to touch or damage the IC part when handling the UIM. Attempts to install/remove the UIM forcibly may damage the UIM.

Installing UIM

With the UIM's golden IC surface downward, push the UIM straight to the slot at the upper row to the end

• Insert the UIM with the corner cut ahead.

Removing UIM

While pushing the UIM with the tip of your finger, slide it slowly toward you, and remove it

About Security Codes for UIM

Two security codes code (Z P.128).

are provided for the UIM: PIN1 code and PIN2

microSD Card

• This mobile phone supports microSD cards of up to 2 Gbytes and microSDHC cards For the latest information on supported microSD cards including manufacturers and storage capacities, refer to the following website. For microSD cards not listed on the website, please consult the manufacturer of the microSD card in question. http://panasonic.jp/mobile/ (in Japanese only) Note that since the information in the website has been obtained by checking of some operations, not all operations are guaranteed.

Installation/Removal of microSD Card

• Installation/removal of a microSD card should be performed

the mobile

with UIM removed (Z P.36, P.40).

phone turned off, and the battery pack and the

of up to 32 Gbytes (as of October 2011).

Installing microSD Card

Hold the microSD card in such a way that its metal terminal surface is face down, and insert the card straight into the bottom microSD card slot in the direction shown in the illustration

• Insert the microSD card about halfway, and

press down gently on area 1 so that the card is made

insert the edge of the card (area 2) straight into the slot as far as it will go.

level. With the card still pushed halfway in,

Removing microSD Card

Hook the tip of your finger into the groove of the microSD card, and pull the card straight out of the slot

Battery Pack

Speaker

Arrow marks

Installation/Removal of Battery Pack

• Installation/removal of the battery pack should be performed with the mobile phone turned off.

Installing Battery Pack

To remove the back cover, press on the area of the cover around the speaker with both hands, and slide in

the direction indicated by the arrow

until the lock is released as per the illustration

With the arrow marks facing up, fit the battery pack to the tab side of the mobile phone securely, and then push the battery pack in direction 2

while pressing

it against direction 1

To attach the back cover, align the cover with

Projection

the mobile phone and slide it in the direction of the arrow

• Confirm there is no gap between the back cover and the mobile phone.

Removing Battery Pack

Remove the back cover (Z step 1 in P.39 “Installing Battery Pack”)

Lift the battery pack in the direction of the arrow using its projection

• If you remove the battery pack when there is no UIM

inserted, be

careful not to touch the terminal

in the UIM slot.

Charging

To prevent damage to the environment, bring used battery packs to a docomo service counter, a docomo agent or a recycle center.

■ Precautions for charging

• The included AC adapter plug shape is designed for 100V AC (domestic specification). To charge the battery abroad, a corresponding plug adapter transformer for overseas trip.

• If you charge the mobile phone while using it, it may take more time to fully charge the battery or charging may not be completed. Continuous use of functions consuming large current, such as data communication and call, may decrease battery level even during charging, leading to battery drain.

• If you start charging when the battery is empty, the mobile phone this case, start charging with the mobile phone off and turn it on after a while.

• If you leave the mobile phone being charged for long time, the mobile phone consumes power from the battery pack after completion of charging, so the usable time may be shortened and alert of empty battery may be displayed soon. In such a case, start charging the battery again in correct manners. For recharging, disconnect the AC adapter cable from the mobile phone and then connect it again.

may not

start up promptly after power-on operation. In

is required. Do not use an adapter

■ Battery pack operating life

• Battery pack is a consumable item. Usable time per charge gradually decreases with repeated charging.

• When its usable time per charge is decreased to about a half

that from

of end of life. So you are recommended to replace with new one soon. Depending on how the battery pack is used, it might swell as its remaining life becomes short, but this is not a problem.

• Continuous 1Seg watching while charging may shorten the battery pack operating life.

the time of purchase, the battery pack is near the

Charging by Using AC Adapter Cable

AC adapter

Power plug

USB plug

microUSB plug

microUSB cable

Connector terminal cover

Call/Charging indicator

Hook

Insert the provided microUSB plug of microUSB cable horizontally into the connector terminal

with USB mark ( ) facing up

• Hook

the tip of your finger into the groove of the

external connector terminal cover, pull the cover out in direction 1

direction 2

and then lift the cover in

Insert the USB plug of microUSB cable horizontally into the USB connector of AC adapter with USB mark faced with you

Unfold the power plug of AC adapter, and plug it into a household outlet of 100 V AC

When charging is completed, pull out the power plug of AC adapter from the outlet

Remove the microUSB cable from the AC adapter and the mobile phone

■ Charging and charging completed indications

● When the mobile phone is turned on

Call/Charging indicator Battery icon

Charging Lights as follows

according to the battery level. 89% or less: Red 90% or more: Green

Charging completed

● When the mobile phone is turned off

Charging Lights in red Charging completed Turns off

• The battery icon is not displayed when the mobile phone is turned off. The call/charging indicator may not light promptly when you start charging with the battery in empty state. However, charging has been started. If the call/charging indicator from the mobile phone and then reinstall it before charging again. If the symptom recurs, the AC adapter and battery pack may be failed. Contact a handling counter such as a docomo Shop.

Lights in green

Call/Charging indicator

does

light after a while, remove the battery pack

not

Indications are switched from the current battery level up to level 6.

Level 6 Level 5

Level 4 Level 3

Level 2 Level 1

■ When the battery has almost run out

When the battery starts running out, a message that prompts you to charge appears. When the battery becomes empty, a message that the power is turned off shortly appears and then it is turned off.

Charging by Using a PC

This mobile phone can be charged from a PC when you connect the mobile phone and a PC using the included microUSB cable.

• For how to connect the mobile phone to a PC, Z P.173

Power On/Off

Turning Power On

Press and hold H for at least two seconds

The lock screen appears after a while.

Turning Power Off

Press and hold H until Phone options menu appears

[Power off] W [OK]

• Wait for a while, as it may take some time before the power is turned off.

When Display Goes Off

If this mobile phone is not operated for a certain period of time, the display automatically goes off and the mobile phone enters the Sleep mode.

H / B

The Sleep mode is canceled and the lock screen appears.

• To enter the Sleep mode manually, press H when the display is on.

Unlocking Lock Screen

Lock screen

Drag to the right

• Drag / to left to set/cancel Silent mode.

Basic Operations (How to Use Touch Panel)

Touch Panel Operations

The display of this mobile phone is a touch panel, which is operated by direct touch with fingers.

• Before use, peel off the protective sheet which is stuck on the touch panel at the time of purchase.

• The touch panel is designed to be touched lightly with a finger. Do not press it strongly with a finger or pointed objects such as fingernails, ballpoint pens, and pins.

• In the following cases, the touch panel may not work even if you touch it. Also, following operations may cause a malfunction.

• Operation wearing gloves

• Touching with a fingernail

• Operation with foreign objects placed on the operation surface

• Operation on the touch panel on which a protective sheet or a sticker is put

■ Tap

Tap an item or icon on the screen to select it.

■ Double-tap

the screen

Tap again to zoom out.

twice quickly to zoom in the web page. Double-tap

■ Touch and hold

Keep an item or icon on the screen touched with your finger for a while. Do this to display a pop-up menu, etc.

■ Flick

When there are multiple pages or more contents your finger right or left across the surface of the screen to show the previous/next screen.

outside the

screen, quickly move

■ Drag

Move an item or icon on the screen while holding it with your finger.

■ Scroll

Slide your finger up/down or right/left on the screen to show the hidden part.

■ Pinch (spread apart/pinch together)

Placing two fingers on the screen, spread them apart to zoom in, or pinch them together to zoom out, when a web page or still image is displayed.

Information

• Some multi-touch operations such as operation with three or more touch points are not possible.

Switching Vertical/Horizontal Display Modes

The

motion the mobile phone, allows you to switch display modes by holding the mobile phone in vertical or horizontal orientation.

sensor,

which detects orientation and motion of

Information

• Operate the mobile phone in nearly upright state. If the mobile phone lies flat, the sensor cannot detect a change in orientation and motion properly, and the display modes may not be switched.

• Changing the mobile phone’s orientation may not switch display modes depending on the screen displayed.

Screen Display/Icons

Status bar

Icon Definitions

Icons that indicate the mobile phone status are displayed in the status bar. Notification icons are displayed on the left part while status icons are displayed on the right part of the status bar.

■ Main notification icons

Icon Description Refer to

New Gmail P.152

New Email P.149

New sp-mode mail P.144

New message (SMS) P.146

Failure to send message (SMS) P.145

Voice Mail message P.108

New instant message P.156

Calendar event P.214

Music playing P.183

Wi-Fi open network available P.89

Incoming file via Bluetooth communication P.170

VPN connected/disconnected P.171

USB connected P.173

USB tethering in use P.117

Wi-Fi tethering in use P.118

Both USB tethering and Wi-Fi tethering in use P.117

118

Error message -

During call P.93

Missed call P.99

Icon Description Refer to

Call on hold P.98

P.111

Data upload -

Data download -

Application installed from Android Market P.186

Update of Android Market application available P.186

Hidden notification P.52

microSD card unmounted P.138

Watching a 1Seg program P.200

Connecting to data broadcast security page P.201

eco mode P.217

Positioning error (failure to get desired

P.192

information) Communication disabled (failure to get desired

P.192

information) Communication error (failure to get desired

P.192

information) Last train alarm set P.192

■ Main status icons

Icon Description Refer to

Radio wave strength -

Roaming P.224

Out of service area -

Connecting to GPRS P.227

GPRS in use P.227

Connecting to EDGE P.227

EDGE in use P.227

Connecting to 3G (packet) P.227

3G (packet) in use P.227

Flight mode P.116

Icon Description Refer to

Connecting to Wi-Fi P.89

Bluetooth ON P.168

Bluetooth device connected P.168

Data sync P.135

UIM not installed P.35

Alarm set P.211

Speakerphone ON P.98

Microphone mute P.98

Silent mode (vibration ON) P.122

Silent mode (vibration OFF) P.97

Charge required P.41

Low battery P.41

Sufficient battery P.41

Charging P.41

GPS positioning P.126

*1 Network icons appear in white when Google account is not

set or [Background data] in Accounts & sync settings is unmarked.

Notification Panel

When notification icons are displayed, you can open the notification panel to check notifications of messages, Calendar events, and so on.

Opening Notification Panel

Drag the status bar downward

• Tap a notification to check details or configure necessary settings.

• Tap [Clear] to clear all items in the notification panel. However, some

items may not be cleared.

Closing Notification Panel

Drag the bar at the bottom of the notification panel upward, or press C

Character Entry

With this mobile phone, you can enter characters by tapping the text entry field and using the keypad displayed. You can also enter characters with handwriting.

Switching Input Method

Any of three input methods can be used to enter characters with this mobile phone.

Touch and hold the text entry field

[Input Method] W [Android keyboard]/[Fit Key]/[Quick Handwriting]

Entering with Fit Key

You can select from the two keypad types below:

■ Ten-key keypad

Used for Japanese Kana input.

■ QWERTY keypad

Used for Japanese Romaji input.

Entering Characters with Ten-key Keypad

Tap the text entry field W Touch and hold in the keypad

[10-key ⇔ QWERTY]

5 6

• To close the keypad, press C.

1 Indicates the currently used input mode.

: Hiragana-Kanji : Full-width Katakana : Half-width Katakana : Full-width Alphabet : Half-width Alphabet : Full-width Numeric : Half-width Numeric : Pictogram/Symbol

2 The character assigned to the key concerned is input.

Tap a key repeatedly until desired character is displayed, or touch and hold a key and flick to desired character.

3 Alphabet/Numeric/Pictogram or symbol/Kana input modes

are switched each time the key is tapped. Touch and hold the key W [10-key ⇔ QWERTY] to switch between ten-key

keypad and QWERTY keypad for each input

mode. Touch and hold the key W [Input Mode] to switch Full-width/ Half-width. When you have entered characters, tap to switch the characters between uppercase and lowercase characters, or enter "゛" and "゜".

4 Delete a character at the left of the cursor. 5 Flick to desired direction and move the cursor in four

directions.

6 Insert a space.

3 4

When this key

is tapped with characters entered, conversion candidates are displayed. Flick left to display characters in reverse order. Flicking to left the key right after confirming entered characters returns the characters to unconfirmed state.

7 Confirm entered characters or feed a new line.

function now activated is executed using the characters

The which have been input.

Entering Characters with QWERTY Keypad

Tap the text entry field W Touch and hold in the keypad

[10-key ⇔ QWERTY]

• To close the keypad, press C.

1 Enter characters indicated on the keys. 2 Switch between uppercase and lowercase characters. 3 Alphabet/Numeric/Romaji input modes are switched each

time the key is tapped. Touch and hold the key W [10-key ⇔ QWERTY] between ten-key keypad and QWERTY keypad for each input mode. Touch and hold the key W [Input Mode] to switch Full-width/ Half-width.

4 Switch to Pictogram/Symbol input modes.

to switch

5 Insert a space. 6 Delete a character at the left of the cursor. 7 Confirm entered characters or feed a new line. 8 Move the cursor right/left.

Entering Pictograms/Symbols

3 4

In the Pictogram/Symbol input mode, you can enter pictograms,

symbols

enter pictograms depending on the text entry field.

Tap several times to switch to Pictogram/ Symbol input mode

1 Switch pictogram/symbol/emoticon entering. 2 Scroll the screen up/down and tap a desired pictogram/

symbol/emoticon.

• The pictogram or symbol last used is displayed at the top of the list of pictograms or symbols.

emoticons. You might not be able to

3 End Pictogram/Symbol input mode. 4 Scroll the screen up/down.

• On the pictogram list, you can scroll the screen up/down on a category by category basis.

5 Delete a pictogram/symbol/emoticon at the left of the

cursor.

Entering Characters with Handwriting

5 6

Touch and hold the text entry field

[Input Method] W [Quick Handwriting]

Tap the text entry field

1 The types of characters which can be entered are displayed

here.

: Kanji/Hiragana/Katakana/Alphabet/Numeric/Symbol : Hiragana/Katakana/Alphabet/Numeric : Alphabet/Numeric/Symbol : Numeric/Symbol

• The types of characters are switched automatically depending on the application used.

2 Enter characters in input frames with handwriting.

• When a character input frame is pinched out/in, it can be switched to 1 frame, 2 frames or 6 frames.

3 Delete a character at the left of the cursor. 4 Insert a space.

When

this key

is tapped with characters entered, conversion

candidates are displayed.

5 Switch to Pictogram/Symbol input modes.

When this key

is tapped with characters entered, switch Fullwidth/Half-width. To change Quick Handwriting settings, touch and hold the key W [Change Settings].

6 Move the cursor right/left.

• When the cursor is moved during character input, a list of recognition candidates for the handwritten character input is displayed.

7 Confirm entered characters or feed a new line.

The function now which have been input.

activated is executed using the characters

Character Entry Menu

Copy/Cut/Paste

Enter characters W Touch and hold the text entry field

[Select word]/[Select all]

Drag the slider in four directions to select characters W Touch and

hold the text entry field

[Cut]/[Copy]

• When pasting a copied character, move the cursor to the

position where the character is to be

pasted, touch and hold the text entry field W Tap [Paste].

Character Entry Settings

You can configure various settings regarding character entry.

Fit Key Settings

Home screen W A W [Setting] W [Language & keyboard] W

[Fit Key]

Perform operations listed below:

Sound on Key Press

Vibrate on Key Press

Key Preview Display key preview. Auto

Capitalization Keyboard

Type Voice Input Set whether or not to use voice input. Flick Input Enable flick input. Flick

Sensitivity Toggle Input Enable toggle input when flick input is enabled. Auto Cursor

Movement

Enable key-tapping sound.

Enable key-tapping vibration.

Automatically capitalize the first character of a sentence in alphabet input mode.

Set keyboard type for each screen orientation and input mode.

Specify flick sensitivity.

Set the speed at which the cursor is to move automatically during character entry.

Input Word Learning

Word Prediction

Typing Error Correction

Wildcard Prediction

Lines of Candidate Area

Mushroom Use mushroom applications. Japanese

User Dictionary

English User Dictionary

Learn converted words.

Display conversion candidates as you enter characters.

Display correction candidates for typing errors.

Predict conversion candidates from specified reading string length.

Set the number of lines to be displayed in the candidate area.

Z P.61

Edit words in English User Dictionary.

Clear Learning Dictionary

Z P.62

Download Dictionary

iWnn IME Version of iWnn IME etc. are displayed.

Set whether to enable dictionaries which were downloaded from websites.

Quick Handwriting Settings

Home screen W A W [Setting] W [Language & keyboard] W

[Quick Handwriting]

Perform operations listed below:

Input Input

Method Context

Correction

Automatic Fixation

Inputbox position

Set input frames number.

Set whether to use the context correction function during character recognition.

Set the speed at which the input characters are confirmed.

• This can be set only when 1 frame input has been selected as the input method.

Set input frames position.

• This can be set only when 1 frame input has been selected as the input method.

Japanese Address Input

Full-width Space

Input

Enable Japanese on URL/Email address.

Set whether to input spaces as full-width spaces during character entry.

Conversion Word

Prediction

Display conversion candidates as you enter characters.

Input Word Learning

Recognition Error Correction

User Dictionary

Clear Learning Dictionary

Sound on Operation

Vibration Vibrate on

Sound on Key Press

Writing

Vibrate on Key Press

Learn converted words.

Display the conversion candidates including the recognition error correction candidates.

Z P.61

Z P.62

Enable key-tapping sound.

Set whether or not to vibrate when characters are entered in input frames.

Set whether or not to vibrate when a key is tapped.

Design Background

Color Key

Preview

Initialization Restore the default Quick Handwriting

Quick Handwriting Version of Quick Handwriting etc. are

Set input frames background color.

Enlarge tapped keys during character entry.

settings.

• Not clear learning dictionary and user dictionary.

displayed.

Adding Words to User Dictionary

You can add frequently-used words in Kana input mode to Japanese User Dictionary so that the added words are preferentially shown as conversion candidates when you enter the reading.

Home screen W A W [Setting] W [Language & keyboard]

For Fit Key

[Fit Key] W

[Japanese User Dictionary]

• To add English words used in half-width alphabet input mode, tap [English User Dictionary].

For Quick Handwriting

[Quick Handwriting] W

[Conversion] W [User

Dictionary]

A W [Add]

Tap the text entry field of [Reading] W Enter reading

Tap the text entry field of [Word] W

Enter word

[Save]

Clearing Learning Dictionary

Words and phrases you entered are automatically learned and displayed as conversion candidates by predictive conversion feature. When you clear the learning dictionary, learned is reset to the default status.

words

Home screen W A W [Setting] W [Language & keyboard]

For Fit Key

[Fit Key] W [Clear Learning Dictionary]

For Quick Handwriting

[Quick Handwriting] W [Conversion] Learning Dictionary]

phrases are all cleared and the dictionary

and

[Clear

[OK]

Customizing Fit Key

2 3

6 7 8

You can adjust the size and position of the keypad to fit on your hand. In addition, you can decorate the keypad with stamps and change the color, background and key shape.

Home screen W W [Fit Key]

1 Pallet

Flick right or left to select.

2 Save the edited data. 3 Switch to the stamp setting screen. 4 Switch to the color setting screen. 5 Keypad preview 6 Undo one operation on the keypad. 7 Switch to the package setting screen. 8 Switch to the key shape setting screen. 9 Switch to the background setting screen.

Drag inward/outward the guide icons at four corners of the

keypad preview to define the size

W Drag the keypad preview to define the

position

• When the text entry field is hidden by the keypad or candidate display, you can display the text entry field by reducing the size of the keypad.

To attach stamps

[デコ

(Deco)] W Select a pallet W Tap a stamp to attach W Tap preferred location in the keypad preview to attach the stamp W Perform stamp operations as necessary (Z P.65)

To change color

[カラー (Color)] W Select a pallet

• Drag the slider to adjust color transparency.

• Tap [グラデーション (Gradation) ON/OFF] to switch gradation/solid color.

To change background

[ピクチャ (Picture)] W Select a pallet

• You can select from still images you recently saved in microSD card. To select from other still images, tap [すべて見る (View all)].

•

Tap [背景写真をアクティブ (Activate background photo)]

to adjust position of the still image.

• To shoot a still image for background, tap [カメラ起動(Activate camera)] W

Display the object in

the keypad preview W

To change key shape

[キーパッド (Keypad)] W

Select a pallet

To select from packages

[パッケージ (Package)] W Select a pallet

• Tapping [初期状態に戻す (Initialize)]

[Yes] will

reset the keypad to the default state.

• You can receive/send the package via infrared communication by tapping [赤外線受信 (Receive via IrDA)]/[赤外線送信 (Send via IrDA)]

• You can load and select a package from microSD card

by tapping

[SDから読み込み (Load from SD)].

• When you tap [SDに保存 (Save in SD)], the package is saved in Packages folder of KeyboardCustomize folder in microSD card, and given a file name of the saved date and time (e.g., if a package is saved at 10:00:05 a.m. February 16, 2012, the file name of the saved package is “2012-02-16_10_00_05.pkg”).

• You can delete package files saved in microSD card

by connecting this mobile phone to a PC (Z

P.173).

When you finish editing, [保存 (Save)] W [Yes]

Edited data is saved in this mobile phone and reflected in the keypad.

• Up to five packages can be saved in this mobile phone.

■ Stamp operations in keypad preview

When a stamp stamp.

Operation Procedure

Move Display the stamp guide W Drag the center

Zoom in/out at the same magnification

Increase/ decrease height/ width

is tapped, the stamp guide is displayed around the

of the stamp guide Display the stamp guide W Put your fingers

around the stamp guide to pinch out/in

Display the stamp guide W Drag the stamp guide corner to increase/decrease height/ width

Operation Procedure

Rotate Display the stamp guide W Trace the outer

side of the stamp guide corner in direction you want to rotate

Copy & paste Display the stamp guide W Touch and

hold the center location you want to attach the stamp

Delete Display the stamp guide W [削除 (Delete)]

• You can also delete a stamp by tapping [

除 (Delete)] W

Delete all [スタンプ全消し (Erase all stamps)] W Paste

consecutively

Tap [連続貼り付け (Paste consecutively)] select

W Tap a stamp to attach W Trace the keypad

preview

(line)/ (curve) W Select a

of the stamp guide W Tap the

Tap a stamp to delete.

[Yes]

pallet

削

docomo Palette UI

4 5

Home Screen

Home screen is the start screen from which you can start using applications. Press B to display the home screen. You can choose from the following three home applications: docomo Palette UI, “Fit Home” and Launcher. This section describes how to operate docomo Palette UI.

1 Indicators

Current location (sheet) within the home screen is indicated. You can use up to 12 sheets and switch the screens (sheets) by flicking the screen right and left.

2 Quick search box (Z 3 Shortcuts, widgets, folders, groups and web pages can be

freely placed in home screens.

4 This

screen.

5 Dook

This part is displayed on all sheets to place shortcuts, folders and groups.

Information

• If you change to a different home application, items on the screen such as widgets might not be displayed correctly depending on the home screen layout etc.

is displayed on all sheets to show the application list

part

P.70)

Adding Shortcuts etc. to Home Screen

Home screen W Touch and

• Applications or groups can also be added by touching and holding the target application or group on the application list screen, and then by tapping [Add to home].

[Shortcut]/[Widget]/[Folder]/[Group]/[Web page]

Select a shortcut etc. to add

• Set the updating interval if [Web page] has been selected.

Touch and hold a shortcut etc. added to the home screen, and drag it to preferred location

hold the background

Changing Folder Name

Tap a folder W Touch and hold the title bar

Enter folder name W [OK]

Deleting Shortcuts

Home screen W Touch and hold a shortcut etc. to delete, and drag it into

• When the shortcut is dragged into , the color of the shortcut icon changes to red.

Changing Shortcuts etc. in a Dock

Home screen W Touch and hold a shortcut etc. and drag it in the dock

• To delete a shortcut in the dock etc. touch and hold the shortcut, and drag it into .

Uninstalling Applications or Widgets

Home screen W Touch and hold an application or a widget to uninstall W [Uninstall] W [OK]

• Applications can also be uninstalled by touching and holding the target application on the application list screen, and then by tapping

[Uninstall]

[OK].

Changing Wallpaper of Home Screen

Home screen W Touch and hold the background

W [Wallpaper]

Tap a wallpaper type W Select an image

• If an image has been selected using [Gallery], decide on the trimming position, and then tap [Save] to complete the setting.

[Set wallpaper]

Adding Home Screens

Home screen W A W [Home screen list] W [＋]

•

[+] is displayed if the home screen is less than 11

sheets.

Touch and hold the home screen, and drag it to preferred location

• To delete a home screen, touch and hold the home screen, and drag it into .

Searching for Mobile Phone Applications and Web Page Information

Home screen W Tap the entry field within the quick search box

• You can also search by displaying the application list screen W A W [Search].

• Press A search target types and settings.

W Tap a search target W Enter keyword

Search candidates that contain characters you just entered appear.

W [Search settings] to change

Application Screen

1 2

Displaying Application List Screen

On the application list screen, the installed applications are displayed on a group by group basis.

Home screen W

1 The group names and number of applications are displayed.

Tap a group to switch between displaying and hiding the application icons.

2 Show the application list for each group.

List of Applications

The following is the list of applications that are preinstalled in the mobile phone at the time of purchase.

• To use some applications may require the separate subscription (charged).

• Before using some applications for the first time, it may be necessary to install them from Android Market.

• Some applications do not work without microSD card. Install a microSD card when using applications.

Icon Application Description Refer to

BeeTV BeeTV is a broadcast station

dedicated for mobile phones. You can view original drama, music, and variety programs.

BOOKストア 2Dfacto (Book Store 2Dfacto)

Catalyst Reader View Office documents and PDF

docomo災害用伝言板 (docomo Disaster Message Board Service)

Evernote Save various information

Electric book store in which you can buy and view various electric books including serious literary works, popular comics, and hot business books.

files. This is a disaster message board

application. It allows your personal safety to be registered and checked at times when a disaster has occurred.

(website contents, photos, idea memos, etc.) to a server, and search and view it whenever you need. You can save and view information devices, as well as from this mobile phone.

from a

PC and other

P.220

Facebook Sign in to Facebook for news

feed check, posting, message exchange and photo sharing.

Icon Application Description Refer to

Future Plus Check desired information,

Twitter updates, new

messages (SMS), sp-mode mails, etc. on the same screen.

Gmail Exchange mails of Google

account.

GREE for P This allows you to conduct

simple searches for games of "GREE", which has more than

million users, and provides a

26 wide range of applications in addition to its SNS function.

Gガイド番組表 (G-Guide EPG)

View electronic program guide of terrestrial and BS digital broadcasts. You can search programs by keyword and by category.

P.189

P.151

ｉチャネル (ichannel)

An application, which allows you to use i-channel.

Latitude Share location information with

friends on a map.

mixi An official application of "mixi"

that allows you

to share photos, chat and communicate with friends in other ways with more fun and style.

Mobage An application, which allows you

to enjoy content provided by Mobage.

My docomo アプリ (My docomo appli)

An application, which allows you to easily view information such as your usage fees and your docomo points.

NAVITIME You can use transit guide, train

service information and map search features.

P.198

Psmart Access the manufacturer’s

website to get contents and information.

Icon Application Description Refer to

SD backup Back up and restore

phonebook, messages (SMS) and bookmarks to/from microSD card.

spモードメール (sp-mode mail)

Exchange mails using docomo mail address (@docomo.ne.jp). You can use Pictograms and Deco-mail, and automatic reception is also supported.

Twitter A Twitter official client

application. Post short messages on the website and communicate with people.

VirusScan (docomo security scan)

An application protects your mobile phone from damage of virus. Search virus hidden in installed applications or in a microSD card, etc.

P.222

P.144

YouTube You can play videos from and

post files to YouTube.

あんしんモードアプリ (Security mode appli)

This application allows you to limit installation and running of applications, making and receiving calls, and access to the internet via Wi-Fi, so that even children can use this device securely.

ウェザーニュースタッチ (Weather news touch)

View weather forecasts throughout Japan and live shows.

ECONAVI By adjusting various settings

such as display brightness, an application sets "eco mode" to reduce battery consumption.

Area Mail An application, which allows you

to receive Early Warning "Area Mail", or check received Area Mail messages.

P.208

P.217

P.154

Camera Shoot still images and videos. P.175

Icon Application Description Refer to

Calendar Manage schedule. P.213

Gallery View still images and videos. P.181

ぐるなび (Gurunavi)

Search for restaurants by area, cuisine and budget, etc.

Downloads Files downloaded from websites

are listed.

Task Viewer You can check and terminate

running applications.

Talk You can chat with people using

Google Talk.

docomo market Access docomo market to

search for applications and videos.

ドコモ海外利用 (docomo Overseas Use)

This application supports packet communication while overseas. When using data roaming settings, or Global Pake-hodai, you can easily set compatible operators.

P.161

P.156

P.188

ToruCa Inport/view/find/update etc.

ToruCa data.

Navigation Direction to the destination is

provided.

News & Weather

バーコードリーダー (Barcode

View weather forecast and news.

Read barcodes and QR codes with the camera.

Reader) Fit Key Adjust size and position of the

keypad to fit on your hand. In addition, you can decorate the keypad.

Browser You can browse web pages as

you do with a PC.

Places Search for stores and facilities

near your location by category.

P.207

P.198

P.209

P.218

P.63

P.159

P.197

Icon Application Description Refer to

Voice Dialer Just say the name of the other

P.104 party to call up the contact and make a call.

Home Switcher An application, which allows you

to switch home applications.

Market Use Android Market. P.186

マクドナルド Launcher

You can use coupons for McDonald’s and store locator.

(McDonald’s Launcher)

Maps You can locate your current

P.197 position, and search for places and routes to destinations.

Email Exchange Emails with PCs, etc. P.148

Messaging Exchange messages (SMS). P.145

melodycall An application, which allows you

to use melodycall.

1Seg You can watch 1Seg. P.199

Music Play music. P.183

Voice Search Search for web page

information by voice input.

Google Search Search for mobile phone

P.70 applications and web page information.

Koe no Takuhaibin

This applications allows the simple and convenient use of

"Koe no Takuhaibin" by smartphone. You can record and play voice messages using simple commands.

書籍・コミック E ★エブリスタ (Books & Comics E★eburista)

You can read hot electric books and comics etc. from original works of professional writers

celebrities

and

popular works

posted by general users.

Icon Application Description Refer to

Infrared An application, which allows you

P.164 to exchange data such as Phonebook etc. via infrared communication.

Settings Configure various settings of

P.115 this mobile phone.

地図アプリ (Map appli)

This application provides maps, a search function for stores and

facilities, navigation, public transportation timetables, a record of places visited, and other functions to support you when you go out.

Calculator You can perform calculations

P.216 such as addition, subtraction, multiplication and division.

Phone Make phone calls. P.93

Phonebook Add and manage contacts in the

phonebook.

PhoneBookCopy Using an external recording

medium such as a microSD card, you can move or copy your phonebook.

Phonebook backup

You can automatically back up contacts to the Phonebook backup center on a regular basis. Recover the data in case your

mobile phone

is lost or the phonebook data is accidentally deleted.

Clock On the clock screen, different

types of information and shortcuts are shown along with the time. You can also set alarms.

P.100

P.105

P.211

Instruction Manual

Instruction manual for this mobile phone. You can activate required functions directly from relevant descriptions.

P.2

Icon Application Description Refer to

毎日新聞 (The Mainichi Daily News)

楽天 gateway (Rakuten gateway)

楽天オークション (Rakuten auction)

View latest news stories provided by THE MAINICHI NEWSPAPERS.

Allow easy access to all kinds of Rakuten services via launcher.

This application lets you list items or place bids on Rakuten auction.

the service

Moving an Application

Application list screen W Touch and hold the application, and drag it to preferred location

Adding Groups

Application list screen W A W [Add group]

Enter a group name W [OK]

Touch and hold the group, and drag it to preferred location

• To change the name or color of a group, touch and hold the group, and then tap [Edit name]/ [Change color]

• To delete a group, touch and hold the group, and

[Delete].

tap

Changing the Layout of the Application List Screen

Application list screen W A W [List view]／ [Tile view]

Home Application Settings

Home screen W A W [More] W Perform operations listed below:

Home Settings Set Version check etc. Application info Display the version of home application etc.

Initial Setting

When time after purchase, configure settings for Google account and GPS positioning by following the on-screen instructions.

you

turn

on the power of this mobile phone for the first

[言語変更] W [English (United States)]

• If [機能バージョンアップ (Update features)]

screen is displayed during initial setting, tap [OK] to return to the previous screen and continue operation.

Tap the Android logo W [Create]

• If you already have a Google account, tap [Sign in].

• If you do not set a Google account, tap [Skip].

Enter your first name, last name, and desired username (part before @gmail.com) for the Google account W [Next]

Enter a password W Enter the password again for confirmation W [Next]

Select a security question W Enter answer

in the

answer field W Enter a mail address you already have in the secondary Email field

• In case you forget your password, you can make it sent to your secondary mail address by matching

the security

question and answer in the

Google website.

[Create]

Read Google Terms of Service W [I agree, Next]

Enter characters indicated in the picture

W [Next]

Read the note about Google location service

W [Next]

• To make your data backed up in the Google server with your Google account, mark the checkbox.

[Next] W [Finish setup]

Changing Screen Display to English

If you have not changed the display language to English in the initial setting, you can do it by following the steps below.

Home screen W A W [本体設定] W [言語とキーボード] W States)]

[言語を選択] W [English (United

Google Account

Once Google account is set, you can download applications from Android Market. If you already have your own Google account, you can use the existing account with this mobile phone.

Home screen W A W [Setting] W

[Accounts

& sync] W [Add account]

[Google] W [Next] W [Create]

• If you already have your own Google account, tap [Sign in].

Take step 3 to 8 in P.80 "Initial Setting"

Mark data items to be synced W [Finish] W [Finish setup]

Setting Access Point

Access points for Internet connection (sp-mode and mopera U) are added by default. You can add and modify access points as necessary.

• By default, sp-mode is selected as default access point. However, the settings may differ depending on the terms set forth in your contract.

Checking Access Point in Use

Home screen W A W [Setting] W [Wireless & networks] W [Mobile networks] W

[Access

Point Names]

Setting Additional Access Point

• Do not change MCC to other than 440, or MNC other than 10. If you change MCC/MNC, the access point will no longer be displayed on the screen.

Home screen W A W [Setting] W [Wireless & networks] W [Mobile networks] W Point Names]

A W [New APN]

[Name] W Enter the name of network profile to create W [OK]

[Access

[APN] W Enter an access point W [OK]

Enter other items required by the network operator W A W [Save]

• If MCC or MNC has been changed and the access point is not

displayed on the screen, reset access point settings to the default status, or manually configure the access point.

Resetting Access Point

Resetting the access point restores the default status.

Home screen W A W [Setting] W [Wireless & networks] W [Mobile networks] W

[Access

Point Names]

A W [Reset to default]

sp-mode

sp-mode is an ISP for NTT DOCOMO smartphones. In addition to the Internet connection, you can use mail service with the same mail address (@docomo.ne.jp) as that of the i-mode. sp-mode is a pay service requiring subscription. For details of sp-mode, refer to DOCOMO website.

mopera U

mopera U is NTT DOCOMO’s ISP. Subscribers for mopera U can use the Internet with simple settings. mopera U is a pay service requiring subscription.

Setting mopera U

Home screen W A W [Setting] W [Wireless & networks] W [Mobile networks] W [Access Point Names]

Mark [mopera U (Smartphone Fixed Rate)]/ [mopera U Settings] checkbox

Information

• [mopera U Settings] is an access point for mopera U setting. Connection via the access point for mopera U setting costs no packet communication fee. Note that you cannot access the screens other than those for initial settings and changing settings. For details of mopera U setting, refer to mopera U website.

• To use [mopera U (Smartphone Fixed Rate)], subscription to flat-rate packet service is required. For details of mopera U (スマートフォン定額) (flat-rate for smartphone), refer to DOCOMO website.

Email Setting

You can configure mail account provided by mopera U or general providers to use mail function.

• Configure access point setting in advance (Z P.84).

Setting mopera U Mail Account

Subscribers for mopera U can use mopera U mail.

■ To use POP server

Home screen W W [Email]

Enter mopera U mail address and mopera U password W [Next] W [POP3]

Enter mopera U user name and password W Enter [mail.mopera.net] for POP3 server

Select [None] or security type in the security type field W Confirm your entry W [Next]

Enter [mail.mopera.net] for SMTP server W Confirm mopera U

user name and password you

entered W [Next]

Option setting screen W Set frequency of automatic mail check etc. W [Next]

Mail account register screen W Enter the name displayed for the sent message W [Done]

Setting General Provider’s Mail Account

• Obtain information required for settings from your service provider in advance.

Home screen W W [Email]

Enter mail address and password W [Next]

Follow on-screen instructions

Information

• If automatic settings of mail account does not complete, tap [Manual setup] information manually.

• To add another mail account, display the mail list screen W

in step 2 to enter the account setting

[Accounts]

W A W [Add account].

Wi-Fi

You can use mail and the Internet by connecting to your home or corporate network or a public wireless LAN access point using the Wi-Fi function of this mobile phone.

Home screen W A W [Setting] W [Wireless & networks] W Mark [Wi-Fi] checkbox

Wi-Fi is turned on and available Wi-Fi networks are detected.

[Wi-Fi settings]

Network name and security settings (open network or security protected) of each detected Wi-Fi network are displayed in the Wi-Fi network list.

• To manually add a Wi-Fi network, [Add Wi-Fi network]

W Enter required information W

Tap

[Save]. Select security setting from [Open]/[WEP]/ [WPA/WPA2 PSK].

Select Wi-Fi network W [Connect]

• If you select a security-protected Wi-Fi network, enter the password (security key) and tap [Connect].

• To disconnect from the Wi-Fi network which is now connected, select the Wi-Fi network, and then tap [Forget]

Information

• You can also use packet communication when the Wi-Fi function is enabled. However, Wi-Fi is given priority when the mobile phone connects to Wi-Fi network. If the mobile phone is disconnected from the Wi-Fi network, 3G/GPRS network connection will automatically take over. Note that packet communication fee will be charged if you continue using the network connection.

■ Available channels

The Wi-Fi function of this mobile phone can use the frequency bands of channels 1 to 11.

■ Radio wave interference with Bluetooth devices

Wireless LAN (IEEE802.11b/g/n) and Bluetooth devices use the same frequency band phone near a Bluetooth device, radio wave interference may occur, causing a drop in the communication speed and/or resulting in noise or a connection failure. In cases like this, take the following action.

• Place the Bluetooth device at least 10 meters away from the mobile phone.

• If you must use the mobile phone within 10 meters of the Bluetooth device, turn off the power of the Bluetooth device.

Scanning Wi-Fi Networks

(2.4 GHz). As such, when using the mobile

Turn on Wi-Fi in advance.

Home screen W A W [Setting] W

[Wireless

& networks] W [Wi-Fi settings]

A W [Scan]

Wi-Fi network scanning

starts, and the detected Wi-

Fi networks are displayed on the Wi-Fi network list.

Setting Behavior in Sleep Mode

You can set how the Wi-Fi function is to operate when Sleep mode is set or during charging.

Home screen W A W [Setting] W [Wireless & networks] W [Wi-Fi settings]

A W [Advanced] W [Wi-Fi sleep policy] W Select behavior to set

Checking MAC Address or IP Address

Home screen W A W [Setting] W [Wireless & networks] W [Wi-Fi settings]

A W [Advanced]

"MAC address" and "IP address" are displayed.

Using Static IP Address

You can also connect to a Wi-Fi network by inputting its static IP address.

Home screen W A W [Setting] W [Wireless & networks] W [Wi-Fi settings]

A W [Advanced] W Mark [Use static IP] checkbox

Select [IP address] and other input items W Enter required information W [OK]

• To enable a static IP address, you must select settings for [IP address], [Gateway], [Netmask] and [DNS 1]

Online Service Accounts

You can set accounts of online services such as mixi and Twitter, and synchronize and exchange data between this mobile phone and each service server.

• To set Exchange account, check with your network administrator about setting information.

Home screen W A W [Setting] W

[Accounts

& sync] W [Add account]

Select a type of account to add W Follow onscreen instructions

• Added account is displayed in the “Manage accounts” list. Tap an account to configure settings of each account.

Phone/Network Services

Phone

Making a Call

Home screen W W [Phone] W Enter the other party’s phone number

If you enter a wrong number, tap

• the entered number.

To end the call, [End]

Emergency Call

to clear

Emergency call Phone number

Call to police 110 Call to fire station and ambulance 119 Call for accidents at sea 118

• If UIM is not installed, it is not possible to make an emergency call at 110/119/118 in Japan.

• This mobile phone supports “Emergency Location Report”. When you make an emergency call such as at 110/119/118, information about the place where you are dialing from (location information) is automatically notified to emergencyresponse agencies such as police stations. It might happen that your correct location is not detected by emergencyresponse agencies depending on the location you dial from or radio wave conditions. When

you

not notify your phone number such as by adding

do “184” for each call, your location information and phone number are not notified. However, when an emergencyresponse agency has judged that the location information and phone number should be detected because of emergency priority such as for protection of human life, it might get location information and phone number regardless of your setting. Areas and timing to introduce “Emergency Location Report” vary depending on the preparation of respective emergencyresponse agencies.

• When you make a call at 110/119/118 from this mobile phone, tell an operator that you are calling from a mobile phone, as well

as your

phone number and exact location, so that police/ fire station can make a confirmation call to you. In addition, stay at the current location while talking preventing the call from being disconnected. Do not turn off the power immediately, and make sure to place your phone standby for at least ten minutes after the call.

• You might not be connected to regional police/fire station depending on the area where you are calling from.

• When [Emergency call] is displayed on the screen, you can make an emergency call by tapping

[Emergency call]. Note, however, that you cannot make an emergency call in Japan from the PIN code entry screen or PIN unblocking key (PUK) entry screen, or when the UIM is completely locked.

Selecting Whether to Notify or Withhold Caller ID for Each Call

• Caller ID is your important information. Be careful about notifying it.

Home screen W W [Phone] W Enter the other party’s phone number

A W [Set Notify caller ID active] (186 added)/[Set Notify caller ID inactive]

(184

added) W

Entering Push Signals

Push signals are used for operating home answer phone or for using services such as ticket reservation and bank balance check.

Home screen W W [Phone] W number

A W [Add pause]

“,” is entered.

Enter push signals to transmit W

Enter phone

Push signals are automatically transmitted about two seconds after connection is made.

• If you select [Add wait] in step 2, “;” is added and you can transmit push signals manually. Transmit each signal after step 3.

Using International Call

• For overseas use, Z P.224

• If you have any question about WORLD CALL, contact “General Inquiries” on the back page of this manual.

Home screen W W [Phone]

Enter + (touch and hold [0]) W Country code W Area code W

Phone number

• If the area code starts with “0”, omit “0”. However,

“0”

necessary for some countries and

regions such as Italy.

Receiving a Call

A call comes in W Drag to the right

• To decline the call, drag to the left.

To end the call, [End]

Information

• Answer holding feature is not available with this mobile phone.

Muting Phone Ringtone Temporarily

Incoming call W E/F

Silent Mode

When you set video and alarm is muted.

the Silent mode, any sound other than music,

Press and hold H for at least one second W [Silent mode]

Either or appears in the status bar depending on the vibration setting (Z P.122).

• Setting the ringer volume to 0 by pressing F also

sets the Silent mode.

■ To cancel Silent mode

In Silent mode W Press and hold H for at least one second W [Silent mode]

Information

• Shutter sound and recording start/end sounds of Camera are not muted in Silent mode.

Operations during Call

6 7

: Hold the call. : Unhold the call. : Switch parties.

*1*2

2 End the call. 3 Make a call to another party. 4 Switch to hands-free call using a Bluetooth headset. 5 Display the dialpad to transmit push signals.

6 Mute the microphone so that your voice is not heard by the

other party.

7 Turn the speakerphone on for hands-free call in which you hear

the other party’s voice from the speaker.

*1 Subscription to Call Waiting Service (Z P.111) is required. *2 Tap again to restore the previous state.

Information

• Voice input during call may generate noise or not be recognized properly.

Adjusting Volume of Other Party’s Voice

During call W E (increase)/F (decrease)

Docomo P-01D Instruction Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Notes on Using this Mobile Phone

Basic Package/Samples

Descriptions of Operating Procedures

Handling Precautions for this Mobile Phone

Contents

Handling Precautions

Preliminary Check

Part Names and Functions

microSD Card

Battery Pack

Charging

Power On/Off

Basic Operations (How to Use Touch Panel)

Screen Display/Icons

Character Entry

docomo Palette UI

Home Screen

Application Screen

Home Application Settings

Initial Setting

Initial Setting

Changing Screen Display to English

Google Account

Setting Access Point

Email Setting

Wi-Fi

Online Service Accounts

Phone/Network Services

Phone
