Docomo N-02D Instruction Manual
N-02D
INSTRUCTION MANUAL
’11.11
Thank you for choosing "N-02D".
Before use, be sure to thoroughly read this manual to ensure that you use N-02D correctly.
About manual of N-02D
The operations of N-02D are also described in " 使い か た ガ イ ド " (Guide) (available in this FOMA
terminal) and "Instruction Manual (Detailed version)" (Japanese) (PDF file) other than this manual.
■
"INSTRUCTION MANUAL" (this manual): Provides information about screens and basic operations.
■ "使いかたガイド " (Guide) (available in this FOMA terminal):
outline of freq
On the N-02D standby screen, Iis "便利ツール " (Tool) s " 使いかたガイド" (Guide)
* "
使いかたガイド " (Guide) is not available when "English" is set for "Select language".
■ "Instruction Manual (Detailed version)" (Japanese): Provides detailed information about
all functions and operat
From PC: Download from NTT DOCOMO'S website
http://www.nttdocomo.co.jp/support/trouble/manual/download/index.html
uently-used functions and of operations (in Japanese only).
ions.
Provides information about the
* The URL and content may change without prior notice.
Accessories and major optional extras
■ Basic package
N-02D (including written warranty
and Back Cover N56)
■ Options and accessories compatible with this FOMA terminal →p.89
N-02D INSTRUCTION MANUAL
(Japanese)
Battery Pack N16
Desktop Holder N35
Before using this manual
・ Note that "N-02D" is referred to as "FOMA terminal" in this manual.
・ This manual uses the default settings and screen shots for "WHITE" to describe operations. To
read a screen easily in this manual, "Stand-by display" is set to "OFF", and the font color is black
while the backgr
・ The screens shown as examples in this manual are displayed when "English" is set for "Select
language". Set "English" for "Select language" in advance. (
・
The images or illustration used in this manual are examples. They may differ from the actual displays.
・ Unauthorized copying of all or part of this manual is prohibited.
ound color is whit
e.
→p.24)
Contents
FOMA Terminal ..........................2
What You Can Do with N-02D ...3
Pa
rt Names and Functions .......4
Before Using .............................21
Screen Explanation .
Character Entry .
Call Telephone .........................44
Mail ............................................51
i-mode/Full Browser ...............56
i-Channel ..................................59
Camera ......................................62
1Seg ...........................................65
Music .........................................67
Osaifu-Keitai ............................72
i-concier ....................................7
Support .....................................81
Appendix ..................................90
................25
.......................33
Style ............................................. 6
Precautions (Always follow these directions)
Waterproof/Dustproof Function
Sound/Screen Setting .
Lock/Security ...........................39
Phonebook ...............................55
Map/GPS ...................................60
i-
αppli/i-Widget .......................70
i-motion/Movie........................71
Convenient Tools .....................74
3
Data Management ..................77
Index ...................................... 102
...7
...17
...........35
Introduction
p.1
Basic Operation
p.21
Connect
p.44
Search
p.56
Enjoy
p.62
More Convenient
p.72
Others
p.81
1
FOMA Terminal
Introduction
・
N-02D supports W-CDMA and GSM/GPRS systems.
・
FOMA terminals use wireless communications and cannot be used in tunnels, underground
areas, buildings, and other areas without reception; in outdoor locations with weak reception; or
ou
tside the service area. Reception may also be weak in even some unobstructed upper floors
of
high-rise buildings and apartments.
disconnected even under optimal conditions when reception is strong and all three antenna
icons ar
・
・
・
・
・
・
・
■
This FOMA terminal suppor ts SIM lock removal. Removing the SIM lock allows you to use another
operator's SIM card.
・
SIM lock can be removed at any docomo Shop.
・
An unlocking fee is charged.
・
Certain services and features might be disabled when another operator's SIM card is used. Please be
・
For details of SIM lock removal, refer to NTT DOCOMO website.
e displayed, and when in a stationary position.
A third party may be able to use special equipment to listen in on your calls, as FOMA terminals
use radio waves. However, W-CDMA and GSM/GPRS systems automatically support privacy
pro
tection with a scrambling function for all calls to make conversations incomprehensive to
third par
FOMA terminals convert voice into digital signals for wireless communications, and therefore
Please keep a separate record of the information (Phonebook, Schedule, Memo, Record message
It is recommended that you back up important data to a microSD card. If you own a PC, you can
The user hereby agrees that the user shall be solely responsible for the result of the use of SSL/
This FOMA terminal is available for use in the FOMA Plus-Area and FOMA HIGH-SPEED area.
The explanations in this manual are based on use of the FOMA terminal with a DOCOMO UIM.
ties.
if you are in an area where radio reception is weak, these digital signals may not be properly
rest
ored and this may result in distortion of the actual caller's voice.
or Voice memo) you have registered in your FOMA terminal. Please be aware that DOCOMO
bears no obligation or responsibilit
also transfer and save
keitai datalink.
TLS. Neither DOCOMO nor the certifier as listed herein makes any representation or warranty as
for
security in the use of SSL/TLS. In the event that the user shall sustain damage or loss due to
th
e use of SSL/TLS, neither DOCOMO nor the certifier shall be responsible for any damage or loss.
Cer
tifier: VeriSign Japan K.K., Cybertrust Japan Co., Ltd., GlobalSign K.K., RSA Security Japan Ltd.,
SECOM
Trust Systems Co., Ltd., Comodo CA Ltd., Entrust, Inc. and Go Daddy, Inc.
data, such as Phonebook, Mail or Schedule, to your PC using DOCOMO
SIM Lock Removal
aware that DOCOMO does not under any circumstances guarantee operation.
Please be aware that calls or communications may be
y in the event that data is altered or lost.
2
What You Can Do with N-02D
docomo Palette UI
MyFACE
This function lets you paste MyFACE content for displaying various information on
the right and left of the standby screen. MyFACE information is updated regularly,
ensuring that you always get the latest information. You can download your favorite
MyFACE content easily from sites and add, sort or delete it.
p.29
Introduction
Shortcut
This function allows you to paste shortcuts at the bottom of the standby screen. Pasting
shortcuts to frequently used functions and content enables easier access.
You can also easily create groups and sort your shortcuts.
使いかたガイド (Guide)
"使いかたガイド " (Guide) is useful for checking the operation procedure of the function
you want to use on the FOMA terminal. Wit
find out the operation quickly (in Japanese only).
使いかたガイド " (Guide) is not available when "English" is set for "Select language".
* "
hout Instruction Manual at hand, you can
eco mode
This function allows you to reduce battery consumption by adjusting the brightness of
the display, etc. In addition, eco mode can be automatically enabled according to the
battery level.
Shabette-Kensaku
This function is useful for making an i-mode search by voice. While "Speak keyword
in Japanese" is displayed, you can use i-mode search simply by saying the relevant
keyword (a word that you want to check or a station name, address, etc.) in Japanese.
p.30
p.32
p.38
p.74
3
Part Names and Functions
Introduction
Charge lamp
Multi-function keys
f/g: Up/Down key
・
Move the cursor or contents etc.
upward or downward.
・
Display the Search phonebook menu screen.
・
Activate shortcut.
h/j : Left/Right key
・
Move the cursor to the left or right.
・ Activate MyFACE.
d : OK key
・ Perform the function
displayed on this key.
i key
Display the main menu.
o key
Display the mail menu.
r Start key
Make calls.
Dial keys
Enter phone numbers or characters.
w
/Public mode (Drive mode) key
Set Public mode (Drive mode).
Q Quick key
Activate a function selected
in "Quick button set".
Earpiece
Hear other party's voice from here.
Illuminance sensor
Detect brightness. Do not
cover with hand or put
sticker on it.
Display (Touchscreen)
u key
Display the still image
shooting screen.
p key
Display the iMenu.
t
Back (Clear)/i-Channel key
・ Return to the previous
step or delete the
entered characters.
・ Display i-Channel.
y Power/End/Hold key
q/Manner key
m Multi key
Display the TASK MENU screen.
Mouthpiece/Microphone
<Using Earphone>
Connect an external-connector-terminal-
compatible earphone (optional). To use
an incompatible earphone, connect an
adapter converter (optional).
4
Stereo Earphone/Microphone 01 for External
connector terminal (optional) connection example
The AC adapter (for charging) and the Stereo Earphone/Microphone 01
(earphone/microphone terminal) use the same slot.
Stereo Earphone/
Microphone 01
AC adapter
Illumination/Charge lamp
Camera
Speaker (monaural)
Light/Recording indicator
Back cover
Charging terminal
Strap hole
External connector terminal
Multi-terminal for charging,
connecting an earphone, etc.
Connect AC Adapter
(optional), DC Adapter
(optional), FOMA USB
Cable with Charge Function
02 (optional) or Stereo
Earphone/Microphone 01
(optional), etc.
GPS antenna
The antenna is built-in. Covering
the antenna part with your hand
may affect the quality.
FOMA antenna
The antenna is built-in. Covering
the antenna part with your hand
may affect the quality.
Bluetooth antenna
The antenna is built-in. Covering
the antenna part with your hand
may affect the quality.
e mark
Read the IC card and make iC
transmissions.
Infrared data port
microSD card slot (inside)
1Seg antenna
Extend until
it stops
When storing the antenna, hold lower part and
push it until it stops.
n Screen lock key
Prevent unintentional operation in Touch style.
a Volume up key
Raise the earpiece volume or set Manner mode.
s Volume down key
Lower the earpiece volume or turn on the Light.
Introduction
5
Style
Introduction
This FOMA terminal has three styles; folded, opened (Communication style),
or folded with the display rot
Folded Touch styleCommunication style
・ In this manual, operations by keys with the FOMA terminal opened (Communication
style) are mainly described. Even if touch operation is available, key operations
description takes priority.
Switching to Touch style
ated outward (Touch style).
Notes on use
6
Open the display Fold the display
• Don't rotate the display forcibly or put excessive force. The FOMA
terminal may be damaged.
• Don't rotate the display left-handed or more than 180 degrees.
• Be careful not to pinch your finger when rotating the display.
Rotate the display 180
degrees right-handed
Precautions (Always follow these directions)
n
To en sure tha t you u se yo ur FO MA termi nal
correctly, read "Precautions" carefully before use.
Keep this manual af
n
The precautions must be observed at all times
since t hey conta in inf orma tion intend ed to
pre
vent the bodily injury or damage to property.
n
The following symbols indicate the different
degrees of injury and damage that may occur if
th
e information provided is not obser ved and
the FOMA t
DANGER
WARNING
CAUTION
n
The fol lowi ng symb ols ind icate spec ific
directions:
Don't
No disassembly
No wet hands
No liquids
ter reading for future reference.
erminal is used incorrectly:
In dicates th at de ath o r seriou s
bodily injury may result directly and
immediat
ely from improper use.
Indicates that death or serious
bod ily injury may result from
improper use
Indicates that slight bodily injury
and/or damage to the property
may r
.
esult from improper use.
Indicates that it is prohibited.
Ind ic ates that it must not be
disassembled.
Indicates that you must not touch
it with wet hands.
Indicates that it must not be used
near water, which means that you
must not let it become wet
.
n
1. Precautions for the FOMA terminal, Battery Pack,
2. Precautions for the FOMA terminal
3. Precautions for the Battery Pack
4.
5. Precautions for the UIM
6.
1. Precautions for the FOMA terminal,
Don't
Don't
No disassembly
No liquids
Indicates that it is an instructionbased compulsory conduct (must
be acted).
Do
Indicates that you must un plug
the power cord from the outlet.
Unplug
Safety precautions are explained in the following categories:
Adapter, Desktop Holder and UIM (Common)
Precautions for the Adapter and Desktop Holder
Precautions for Use Near Electronic Medical Devices
･･････････････････ p.12
Battery Pack, Adapter, Desktop
Holder and UIM (Common)
Do not use, keep or leave the devices in locations
subject to high temperatures, such as near fire,
indirect sunlight or inside a car on a hot day.
Doing so may cause fire, burns, or injury.
Do not put the devices in a microwave
oven or pressurized container.
Doing so may cause fire, burns, injury or electric shock.
Do not disassemble or modify the equipment.
Doing so may cause fire, burns, injury or
electric shock.
Do not allow the devices to become wet with
liquids, such as water, drinking water or pet urine.
Doing so may cause fire, burns, injury or electric shock.
For waterproof function, refer to the following:
→p.17 "Waterproof/Dustproof Function"
･･･
p.7
･････････ p.8
･･････････ p.10
･･･ p.11
･･･ p.12
Introduction
7
Don't
Don't
Do
Do
Introduction
8
Use the battery pack and adapter specified
by NTT DOCOMO for the FOMA terminal.
Failure to observe this precaution may cause
fire, burns, injury or electric shock.
WARNING
Do not apply excessive force to the FOMA
terminal, throw it or expose it to strong shocks.
Doing so may cause fire, burns, injury or
Don't
electric shock.
Do not place electrically conductive objects
(wires, pencil leads, etc.) in contact with the
charging terminals or exte
Don't
terminal. Do not insert those materials
in
side the terminal.
Doing so may cause fire, burns, injury or
electric shock.
Do not cover or wrap the devices with
bedding, etc. while in use or charging.
Doing so may cause fire or burns.
Don't
Make sure to turn off the FOMA terminal
and stop charging before you get close
to the places like a gas station where a
flammable gas is genera
Doing so may cause the gas to ignite.
Turn off the power, when you use Osaifu-
Keitai a
t a gas station (if the IC card lock is set,
turn the po
If something unusual happens, such as
unusual odor, overheating, discoloration
or deformation during use, charge or
Do
stor
・
・ Turn off the power.
・ Remove the battery pack from the
Failure to observe these precautions may
cause fire, burns, injury or electric shock.
wer off after the lock is released).
age, be sure to:
Unplug the power cord from the power
outlet or the cigarette ligh
FOMA terminal.
rnal connector
ted.
ter socket.
CAUTION
Do not leave the devices on a slope or
unstable surface.
The devices may fall and cause injury.
Do not leave the devices in humid, dusty
or hot places.
Doing so may cause fire, burns or electric shock.
If your child uses the FOMA terminal, instruct
him/her on how to use it. Check if he/she always
Do
uses the FOMA terminal correctly as you instruct.
Improper usage could result in bodily injury.
Keep the FOMA terminal out of young
children's reach.
A young child may try to swallow it or suffer injury.
Do
Pay special attention when you use the FOMA
terminal connected to the adapter for a long period.
Do
If you use i-αppli or videophone or watch 1Seg
programs for a long time while charging, the
temper
ature of the FOMA terminal, battery
pack or adapter may r
If you touch the warm part of these devices for a
long period of time, it may cause redness, itch, skin
irr
itation or low temperature burns depending on
your c
onstitution or physical condition.
2.
Precautions for the FOMA terminal
ise.
WARNING
Do not direct the infrared data port
towards your or another person's eyes.
Doing so may cause eye injury.
Don't
Do not direct the infrared data port towards
consumer equipment with infrared devices
during infrared c
Don't
Doing so may cause malfunction of the
infrared devices and result in an accident.
ommunication.
Do
Do
Do
Don't
Don't
Do
Do not turn on the light near a person's eyes.
In particular, make sure you stand at least
1m away when shooting young children.
Don't
The light may affect eyesight. Also, this may
dazzle or surprise him/her and cause injur
Do not put fluids such as water or substances
such as pieces of metal or flammable
materials into the UIM slot or microSD card
slot inside of the FOMA terminal
Doing so may cause fire, burns, injury or electric shock.
Do not turn on the light against the car
drivers, etc.
Doing so may interfere with driving and cause
a traffic accident.
Please turn off your FOMA terminal when
inside an airplane, hospital, or other area
where use is prohibited.
The terminal may adversely affect electronic
or medical equipment. If the Auto power
function
is set, make sure to disable the
function bef
Follo
medical facility for the use of mobile phones
You will be punished if you take activity
pr
ph
phones may be permi
transmissions using radio waves, etc., but
fo
Make sure to hold the FOMA terminal at a safe
distance from your ear when you use the
handsfree mode or the ring tone sounds. Also,
Do
when y
earphone/microphone et
FOMA terminal, adjust the volume properly.
Too large a volume may lead to defective hearing.
Also, hearing difficulties may cause an accident.
If you have a weak heart, take precautions
when setting the Vibrator or Ring volume.
Do
Failure to observe this precaution may affect your heart.
ore turning off the power.
w the instructions provided by the
ohibited by law such as use of mobile
ones in airpl
llow airline instructions for proper use.
anes. However, use of mobile
tted by turning off
ou play games or music, etc. with an
c. connected to the
If you are wearing electronic medical devices,
ask the manufacturer or sales agent whether
the devices can be affected by radio waves
befor
y.
.
.
e using your FOMA terminal.
The terminal may adversely affect electronic
medical devices.
Please turn off the power near electronic
equipment that contains high-precision
mechanisms or handles delicate signals
The terminal may interfere with the operation
of sensitive electronic equipment.
* Electr
onic equipment to watch out for:
Hearing
aids, implanted pacemakers, ICDs and
other elec
tronic medical devices; fire alarms,
automa
tic doors, and other automatically
con
trolled apparatus.
Users of implanted pacemakers, ICDs, and other
electronic medical devices are advised to ask
th
e manufacturer or sales agent whether or not
th
ese devices can be affected by radio waves.
If the display or camera lens is broken, be
careful with the broken glass and any
exposed FOMA terminal parts.
A protective film is used for the display, and a plastic
panel is used for the surface of the camera lens to
prev
ent glass from shattering. However, touching
broken or e
xposed parts may cause injury.
Introduction
.
CAUTION
The display has a protective film on its
surface. It helps you ensure safety
(prevents hardened glass from shattering)
Don't
ev
en when the display gets damaged due
to
a fall or shock.
scratch the protective film.
If you use the FOMA terminal with the protective
film removed, the display may be damaged and
you ma
y get hurt.
Do not swing the FOMA terminal by its
antenna, strap or other parts.
The terminal may strike you or others around
Don't
you, resulting bodily injury.
Do not remove or
9
Don't
Do
Do
Don't
Do
Introduction
10
Do not use the damaged FOMA terminal.
Doing so may cause fire, burns, injury or
electric shock.
Don't
When using motion sensor, make sure you are in
a safe place, hold the FOMA terminal securely,
and do not shake it more than nec
Failure to observe this precaution may cause injury.
If the display is broken and the liquid
crystal leaks, do not allow it to come in
contact with your face, hands, etc.
Don't
Failure to obser ve this precaution may cause loss of
eyesight or damage to your skin. If the liquid crystal
comes
into your eyes or mouth, immediately rinse
with clean wa
If the liquid crystal adheres to your skin or clothing,
immediat
soap and wa
Before using your FOMA terminal in a
vehicle, ask the manufacturer or sales
agent whether the operation of the
Do
vehicle can be aff
In some types of vehicle, using the FOMA
terminal may interfere with the operation of
the v
stop using the FOM
There may be cases where the customer's
physical condition or predisposition
leads to itchiness, rashes, or sores. If this
occurs
FOMA t
Material used in each part→p.13 "Material list"
Take care not to pinch your fingers or the
strap when opening/folding the display
of the FOMA terminal
Such pinching may cause injury.
When viewing the display, keep a proper distance
between your eyes and it in a bright place.
Failure to observe this precaution may impair
Do
your vision.
ter and see a doct
ely wipe it off with alcohol and wash with
ter.
or.
ected by radio waves.
ehicle's electronic equipment. In this case,
, immediately stop using the
erminal and see a doctor.
A terminal immediately.
.
essary.
3. Precautions for the Battery Pack
n
Refer to the information shown on the battery
pack label to check the type of ba
ttery.
Display Battery type
Li-ion00 Lithium-ion
Do not place metal items such as wires in contact with
the charging terminals. Also, do not carry or store the
battery pack with metal items such as necklaces.
Doing so may cause the battery pack to ignite,
explode, overheat or leak.
Check the orientation of the battery pack
before attaching it. If you have difficulty
attaching it to the FOMA terminal, do not
Don't
put e
xcessive pressure on the battery pack.
Failure to observe this precaution may cause the
battery pack to ignite, explode, overheat or leak.
Do not throw the battery pack into fire.
Doing so may cause the battery pack to ignite,
explode, overheat or leak.
Don't
Do not puncture the battery pack, hit it
with a hammer or step on it.
Doing so may cause the battery pack to ignite,
Don't
explode, overheat or leak.
If battery fluid etc. comes into contact with your
eyes, do not rub your eyes but immediately rinse
your eyes with clean water and see a doctor.
Failure to observe this precaution may result in loss of eyesight.
WARNING
Never use the battery pack if it has fallen
to have something abnormal such as
deformation and damage.
Don't
Failure to observe this precaution may cause the
battery pack to ignite, explode, overheat or leak.
Do
If the battery pack leaks or emits an
Don't
Don't
No wet hands
unusual odor, stop using it immediately
and move it away from any flame or fire.
The ba ttery fluid is fl ammab le and coul d
ignite, causing a fire or explosion.
Keep your pets away from the battery
pack as they may accidentally bite it.
Failure to observe this precaution may cause the
Do
battery pack to ignite, explode, overheat or leak.
CAUTION
Do not dispose of used battery packs
with ordinary garbage.
Doing so may cause fire and create an
environmental hazard. Put insulation tape on
the t
erminals of used battery pack and return
it t
o a docomo Shop or Service Counter, or
dispose of
with your local r
Do not use or charge the wet battery pack.
Doing so may cause the battery pack to ignite,
explode, overheat or leak.
Don't
If the battery pack leaks, do not touch
battery fluid etc. with your face, hands, etc.
Failure to observe this precaution may cause
Do
loss of eyesight or damage to your skin. If
the ba
mouth or
immediat
that
mouth, see
the battery pack in accordance
egulations.
ttery fluid etc. comes into your eyes or
it adheres to your skin or clothing,
ely rinse with clean water. In the case
it comes into contact with your eyes or
a doctor immediately after rinsing.
4. Precautions for the Adapter and
Desktop Holder
WARNING
Do not use the adapter if its power cord
is damaged.
Don't
Doing so may cause fire, burns or electric shock.
Do not use the AC adapter or desktop holder
in humid locations such as a bathroom.
Don't
Doing so may cause fire, burns or electric shock.
The DC adapter must be used only in vehicles
with a negative ground. Do not use the
adapter in vehicles with a positive ground.
Don't
Doing so may cause fire, burns or electric shock.
Do not touch the adapter when you see
lightning or hear thunder.
Doing so may cause electric shock.
Don't
Do not short-circuit the charging terminals
when the adapter is plugged into the
power outlet or cigarette lighter socket.
Don't
Al
so, do not let the charging terminals
co
ntact with your body (hand, finger, etc.).
Doing so may cause fire, burns or electric shock.
Do not put heavy objects on the power
cord of the adapter.
Doing so may cause fire, burns or electric shock.
Don't
When plugging/unplugging the AC adapter
into/from the power outlet, make sure that
no metallic straps or other metallic objects
are
caught between the plug and the socket.
Metallic objects may cause fire, burns or
electric shock.
Do not touch the power cord of the adapter,
Desktop Holder or the power outlet with wet hands.
Doing so may cause fire, burns or electric shock.
Use the specified voltage and current. Use
the AC Adapter for Global use to charge
the battery overseas.
Do
Using the adapters with incorrect voltage may
cause fire, burns or electric shock.
AC A
dapter : AC 100V
DC Adapt
er : DC 12V/24V
(specific to v
AC A
AC 100V t
ehicle with negative ground)
dapter for Global Use :
o 240V (household AC outlet only)
Introduction
11
Do
If the fuse in the DC adapter blows, always
Do
Do
replace it with the specified type of fuse.
Failure to observe this precaution may cause fire,
Introduction
burns or electric shock. Refer to the respective
manuals f
Wipe off any dust on the plug.
Failure to observe this precaution may cause
Do
fire, burns or electric shock.
When plugging the AC adapter into the
power outlet, make sure to insert it firmly.
Failure to observe this precaution may cause
fire, burns or electric shock.
Always grasp the adapter when unplugging
the plug from the power outlet or cigarette
lighter socket. Do not pull the cord itself.
Do
Failure to observe this precaution may cause
fire, burns or electric shock.
Unplug the adapter from the power outlet
or cigarette lighter socket when the adapter
will be left unused for a long period.
Unplug
Failure to observe this precaution may cause
fire, burns or electric shock.
If water or other liquid gets into the adapter, immediately
unplug it from the power outlet or cigarette lighter socket.
Failure to observe this precaution may cause
Unplug
fire, burns or electric shock.
Unplug the adapter from the power outlet
or cigarette lighter socket before cleaning it.
Failure to observe this precaution may cause
Unplug
fire, burns or electric shock.
5. Precautions for the UIM
Be ca refu l wi th sha rp edge s when
removing the UIM.
12
Sharp edges may cause injury.
or the information on the specified fuse.
CAUTION
6. Precautions for Use Near
Electronic Medical Devices
n
Ac cor din g to th e Gui deline s on the Use o f Radi o
communication Equipment such as Cellular Telephones -
feguards for Electronic Medical Equipment established
Sa
tromagnetic Compatibility Conference Japan.
by the Elec
WARNING
Take care of the following inside hospitals.
Do not take your FOMA terminal into an
operating room, intensive care unit (ICU),
Do
or coronary care unit (CCU).
Turn off the power inside hospital wards.
Turn off the power even in hospital lobbies,
waiting rooms, and corridors if electronic
medical devices may be in use near y
For use inside medical institutions, please follow
the instructions given at individual locations.
I f the Auto power function is set, make
su re to disa ble t he fun cti on before
turning off the po
Turn off the power in crowded places such
as peak-hour trains if implanted pacemakers
and ICDs may be in use near you
Do
Radio waves emitted by the FOMA terminal
may adversely affect implanted pacemakers
and ICDs when used in close pro
Anyone with an electronic medical device,
such as an implanted pacemaker or ICD
should use or carry the FOMA terminal at
Do
least 22 cm from the site of implan
Radio waves from the FOMA terminal can
adversely affect electronic medical devices.
Electronic medical devices other than
implanted pacemakers and ICDs may also
be used outside hospitals. Users of
Do
electr
onic medical devices are advised to
ask the
instruments
Radio waves from the FOMA terminal can
adversely affect electronic medical devices.
wer.
.
ximity
tation.
manufacturer whether these
can be affected by radio waves.
ou.
.
■ Material list
Parts Material Coating
Display Nylon resin UV coating
External chassis
Display panel Hardened glass Shatter-proof film, Hard coating
Earpiece panel Acrylic Hard coating
Display hinge Nylon resin UV coating
Rear panel hinge Nylon resin UV coating
Hinge cover Polycarbonate resin UV coating
Side key cover Polycarbonate resin UV coating
Hinge cap Polycarbonate resin UV coating
Rotor strike pad Polyester thermoplastic elastomer
Strike pad Silicon rubber −
Key
Key enclosing sheet PET resin Hard coating
Camera panel
Camera ring inner side Polycarbonate resin Tin deposition, UV coating
Camera ring outer side Polycarbonate resin UV coating
Light and Infrared data port panel Acrylic resin UV coating
Back cover
External connector
terminal cap
Charging terminal Brass Gold plating
1Seg antenna
Battery pack storage
Battery terminal
Battery pack
Rear side
Key and battery pack storage
Multi-function keys
Other keys Polycarbonate resin UV coating
Outer side Polycarbonate resin UV coating
Inner side Polycarbonate resin
Inner side water stop Silicon rubber −
Outer side Polycarbonate resin UV coating
Inner side
Water stop Silicon rubber −
Top Stainless alloy UV coating
Middle Stainless alloy
Bottom Nickel-titanium alloy −
Base Stainless alloy Trivalent chrome plating
Base hinge Stainless alloy Nickel plating
Tip cap Cadmium-free brass Trivalent chrome plating
1Seg antenna mounting part
Screw Stainless alloy Nickel plating
Storage
Inner frame Polycarbonate resin −
microSD card holder Stainless alloy −
Battery terminal connector
Terminal Phosphor bronze Gold plating
Battery pack
Terminal Glass epoxy resin Gold plating
Polycarbonate resin UV coating
Aluminum
Nylon resin UV coating
Aluminum alloy Alumite coating
Acrylic, Polycarbonate composite resin
Polycarbonate resin, Polyester thermoplastic elastomer
Low-alloy steel Nickel plating
Metal parts: Stainless alloy
Resin: Nylon resin
LCP resin −
Resin: Polycarbonate resin
Label: PET resin
Alumite coating/Aluminum foundation
Hard coating
Metal parts: Nickel plating
Resin:
−
−
−
−
−
−
Introduction
13
Handling precautions
General Notes
Introduction
N-02D is waterproof/dustproof, however, do
not allow water to seep in or dust to get in the
FOMA
terminal. Also, do not allow accessories
and options to get wet or be e
The battery pack, a dapter, desktop holder and
the UIM are not waterp roof/d ustproof. Do not
us
e them in humid locations such as bathroo
and avoid exp osing th em to rain . I f you carr y
th
e FOM A ter mina l clo se to you r s kin , s weat
ma
y cause internal components to corrode and
re
sult in malfunction. The FOMA terminal cannot
be
repaired in the following c ases : t he wate r
exposur
e detection sticker shows water exposure;
te
sts determine that corrosion has occurred due
to
water exposure, condensation, or perspirat
These cases are not covered by the warranty, and
an
y repairs that may be possible will be carried out
at the subscr
Wipe with a soft, dry cloth (such as an eyeglass
cleaning cloth).
Occasionally clean the connection terminals
with a dry cotton swab, etc.
Soiled connectors may result in poor connections,
loss of power, or incomplete charging. Wipe with
dry cloth or c
Wh
Do not place the FOMA terminal near an air
conditioning vent.
Condensation may form due to rapid changes in
temperature, and this may cause internal corrosion
and malfunction.
14
iber's expense.
Rubbing the display of the FOMA terminal with
a dry cloth may scratch the display surface.
The display surface may be stained if moisture
or dirt is left on it for a long period.
Never use chemicals such as alcohol, thinners,
benz ene or deterge nts as these agent s may
er
ase th e pr inting on the FOMA terminal or
cause discolor
en cleaning, take care not to damage connectors.
ation.
otton swab.
xposed to dust.
ms,
ion.
Do not put excessive pressure on the FOMA
terminal or battery pack.
Do not put the FOMA terminal in a bag filled with many
objects or sit down with it in a hip pocket. Excessive
pre
ssure may result in malfunction or damage to the
display
, internal circuit or the battery pack, etc.
Al so, if a n ex ter nal de vic e is c onnect ed to
th e exter nal conn ect or termi nal ( earpho ne/
microphone terminal) , ex cessive press ure may
result in malfunc
Do not scratch the display with metallic objects.
Doing so may cause scratches, malfunction or damage.
Read the separate manuals supplied with the
battery pack and adapter carefully.
tion or damage to the connector.
Handling the FOMA Terminal
Do not press the surface of the touchscreen firmly
or operate the touchscreen with sharp edge objects,
such as fingernails, ballpoint pens
Doing so may cause touchscreen breakage.
Avoid using the FOMA terminal in extremely
high or low temperatures.
The ambient temperature of the room should be 5℃ to
40
℃ (limited to the temporary use in a bathroom etc. when
temperature is above 36
Reception may be affected if you use your FOMA
terminal near a land-line phone, television, or radio in
use. U
se the FOMA terminal away from such devices.
Please keep a separate record of the information
you have registered in your FOMA terminal.
Please be aware that DOCOMO bears no obligation or
responsibility in the event that data is altered or lost.
Do not drop the FOMA terminal or expose it to strong shocks.
Doing so may cause malfunction or damage.
When connecting an external device to the external
co nn ecto r te rmin al ( ea rpho ne/m icro phon e
terminal), do not inser
Doing so may cause malfunction or damage.
Do not fold the FOMA terminal with the strap
pinched between the folding par
Doing so may cause malfunction or damage.
It is normal for the FOMA terminal to become warm while
being used or charged.
℃ ) with humidity of 45% to 85%.
t at an angle or pull the cord.
This is not a malfunction. Keep using it.
, and pins.
ts.
Do not leave the camera exposed to direct sunlight.
Doing so may discolor or burn the components of
the camera.
Keep the external connector terminal (earphone/
microphone terminal) cap closed when not in use.
Failure to observe th is precaution m ay cause
malfunction due to dust or water getting in.
Do not use FOMA terminal with the back cover removed.
Doing so may cause the battery pack to fall out, or
cause malfunction or damage.
Do not put an extremely-thick sticker, etc. on
the display or keypads.
Doing so may cause malfunction or damage.
Do not remove the microSD card or turn off
the power while in use.
Doing so may cause data loss or malfunction.
Do not let magnetic cards, etc. come close to or
be sandwiched between FOMA t
The m agnetic data in cash cards, credit card s,
telephone cards, floppy disks, etc. may be erased.
Do not let stron g magnetic objec ts come
close to the FOMA terminal parts.
Strong magnetic objects may cause misoperation.
erminal parts.
Handling the Battery Pack
The battery pack is consumable.
Battery life varies depending on usage conditions,
etc., but it is time to change battery packs when
th
e usage time has become extremely short even
though the
In this case
The ambient temperature of the room should be 5℃ to 35℃ .
The availabl e operating time of the battery pack
depends on the conditions of usage and battery pack.
Depending on the usage condition, the battery
pack may inflate slightly when the battery life
is almost ov
Do not store the battery pack in the following cases:
The performance and life of the battery pack may deteriorate.
It is recommended that you store the battery pack with
two battery marks displayed or around 40% battery level.
battery pack has been fully recharged.
, please purchase a new battery pack.
er.
This is not a malfunction.
The battery is fully charged (immediately after
the charging is complete)
The battery has run out (the phone cannot power on)
Handling the Adapter
The ambient temperature of the room should
be 5
℃ to 35℃ .
Do not charge the battery pack:
In a humid, dusty or unstable place
Near a land-line phone, TV or radio
It is normal that the adapter become warm
while charging. K
Do not use the DC adapter to charge the battery
when the car engine is not running.
Doing so may drain the car battery.
If you use an electrical outlet with an unplugging-
protection mechanism, follow the instructions of
the manual for the outlet.
Do not expose the adapter to strong shocks.
Do not deform the charg
Doing so may cause malfunction.
eep using it.
ing terminal.
Handling the UIM
Do not apply excessive force to the UIM when
attaching/removing it.
Note that the warranty does not cover damage
caused by inserting the UIM into another type
of IC card r
Always keep the IC part clean.
Wipe with a soft, dry cloth (such as an eyeglass
cleaning cloth).
Please keep a separate record of the information
you have registered in your UIM.
Please be aware that DOCOMO bears no obligation or
responsibility in the event that data is altered or lost.
To preserve the environment, bring discarded
UIM to a docomo Shop or Service Counter.
Do not damage, scratch, unnecessarily touch,
or short-circuit the IC.
Doing so may cause data loss or malfunction.
Do not drop the UIM or expose it to strong shocks.
Doing so may cause malfunction.
Do not bend the UIM or place a heavy object on it.
Doing so may cause malfunction.
Do not put a label or sticker on the UIM when
attaching it to the FOMA terminal.
Doing so may cause malfunction.
eader or writer.
Introduction
15
Using the Bluetooth® Function
To sec ur e th e Bl ueto oth co mm unic atio n
se cur ity, t he FOMA ter min al su pport s the
Introduction
se
cur ity function compliant with B luetooth
st
andards, but the security may not be sufficient
de
pending on the setting. Concern about the
communica
Ple as e be awa re th at DO COMO is no t
responsible for data leak when making data
communica
You can use a headset, handsfree, audio, dial-
up communications, object push and serial
port
re
(O
Frequency band
The following are frequency bands that the FOMA
terminal's Bluetooth function uses:
2.4 ：
FH ：
1 ：
n
Bluetooth cautions
The operating frequency band of this equipment is
used by industrial,
equipment inclu ding micro wave ovens, pre mises
radio
ma
nufacturing lines of plants (radio stations requiring
a
license), specified low power radio stations (radio
st
ati ons requi ring no license ) and amateur radio
stations (her
1.
2.
3.
16
tion using the Bluetooth function.
tions using Bluetooth.
on the FOMA terminal. The audio/video
mote control may be available for audio.
nly on compatible Bluetooth devices)
The radio equipment uses the 2400MHz band.
Modulation scheme is the FH-SS system.
The estimated interference distance is 10 m or less.
：
The full band between 2400 MHz and 2483.5
MHz is used and the band of the mobile
identifica
tion device cannot be avoided.
scientific, consumer and medical
stations for identifying mobile units used in the
einafter referred to as "another station").
Be for e using th is te rmi nal, confir m tha t
"another station" is not being oper
In the event of this term inal causi ng harmf ul
radio wave interference with "another stations",
promptly
change the operating frequency or stop
radio w
ave emission by turning off the power, etc.
If y ou have f urth er ques tion s, please contac t
"General Inquiries" on the last page of this manual.
ated nearby.
Handling the FeliCa Reader/Writer
The FeliCa rea der/wr iter fun ction of t he
FOMA terminal handles delicate signals that
requir
e no radio station license.
The 13. 56 MHz fre quency ban d is u sed.
If t here i s a nother rea der/writer around,
ke
ep enough distance between the FOMA
te
rminal and the reader/writer. Also, make
su
re that there is no radio station using the
same frequenc
y band nearby.
Cautions
Do not use the altered FOMA terminal. Using an
altered device is a violation of the Radio Law.
A " Technical Conformity Mark " affixed on the
manufacturer's specification sticker certifies that
e FOMA terminal meets technical regulations
th
for
specified radio equipment based on the Radio
Law
. If you remove the screws and alter the inside
of
the F OMA terminal, the technical regulations
co
nformity certification becomes invalid. Do not
us
e the F OMA ter minal with th e c erti fica tion
inv
alid, as it is a violation of the Radio Law.
Be careful when using the FOMA terminal while driving.
A penalty may be imposed for holding a mobile
pho ne whil e drivi ng. However, exception s are
ma
de in case of emergency, such as to safeguard
injured persons or t
Use the Bluetooth function only in Japan.
The Blueto oth f unctio n of the F OMA t ermina l
complies wi th radi o standa rds of Jap an and i s
ce
rtified. You may be punished if you use it overseas.
Use the FeliCa reader/writer function only in Japan.
The FeliCa reader/writer func tion of the FOMA
terminal complies with radio standards of Japan.
You ma
y be punished if you use it overseas.
Use the IC card authentication function only in Japan.
The IC card authent icati on func tion of the FOMA
terminal complies with radio standards of Japan and is
cer
tified. You may be punished if you use it overseas.
Do not modify the system software improperly.
This may be regarded as "remodelling" and
requests for repair of the term inal may be
rejec
ted.
o maintain public safety.
Waterproof/Dustproof Function
N-02D is waterproof to IPX5*1 and IPX7*2 standards, and dustproof to IP5X*3 standard if the
external connector terminal cap is closed as well as the back cover is securely attached.
*1 :
IPX5 means that the N-02D continues to function as a phone after being sprayed from all directions with 12.5 liters
of water per minute from a 6.3 mm diameter nozzle for at least 3 minutes, from a distance of approx. 3 meters.
*2 :
IPX7 means that the N-02D retains phone functionality after slowly immersing in still, room-temperature
tap water to a depth of 1 meter and leaving it there for 30 minutes before bringing it out of the water.
*3 :
IP5X means the level of protection. IP5X means that N-02D continues to function as a phone and to maintain
security after being left in a device containing dust (diameter: 75
・
You can talk or watch 1Seg without an umbrella in the rain (approx. 20 mm of rain in an hour).
・
Do not attach/remove the back cover or do not open/close the external connector
terminal cap when your hands are wet or when your FOMA terminal has water drops on it.
・
You can rinse the FOMA terminal by immersing and slowly moving in tap water of room
temperature filled in a bowl, or rinse it with hands under light running water from the faucet.
* Rinse the FOMA terminal with the back cover securely attached while covering the
external connector terminal cap to prevent it from opening.
o not use a brush, sponge, soap, or detergent for washing.
* D
Do not apply running water directly to the mouthpiece/microphone, earpiece or speaker.
*
・ Do not immerse or drop the FOMA terminal in a swimming pool or in the sea.
・
If the FOMA terminal comes in contact with any mud or soil, rinse it immediately. If these
dry up and set, the dirt would be harder to remove, and it may cause scratches and failures.
・
You can use the FOMA terminal in the bathroom. However, do not immerse it in the bathtub.
*
Never immerse the FOMA terminal in hot spring water or water containing soap, detergent or bath powder.
*
Avoid using the FOMA terminal for a long time in the bathroom.
Things to keep in mind
・
Before use, ensure that you securely close the external connector terminal cap and back cover so
that they are completely attached. If any fine dirt (fine fibers, hairs, or sands) is between the cap/
cover and the FOMA terminal, water or dust could enter the inside of the FOMA terminal.
・
Do not spray or immerse the FOMA terminal in liquids other than water of room temperature as illustrated below.
<Example>
μ
m or smaller) for 8 hours, agitated and removed.
Introduction
Soap/Detergent/Bath powder
Sea water
Swimming pool Hot spring
17
Opening/closing the external connector terminal cap
■ Opening
Introduction
Hook your finger on the slot and open the
cap in the direction of ar
row.
Slot
Attaching/removing the back cover
■ Removing
Hold the FOMA terminal and hook your finger on
the slot to remove the back cover in the direction
ow without applying excessive force on it.
of arr
Slot
・
When removing the back cover, make sure that you drain water (p.20) and wipe moisture off the FOMA terminal.
・
When attaching the back cover, make sure that no dust or dirt adheres to the back cover (especially to the rubber packing).
・
Water or dust might enter the inside of the FOMA terminal unless you attach the back cover securely.
・
When attaching the back cover, make sure that the UIM, the microSD card and the battery pack are attached
securely. If the UIM or microSD card is not securely inserted, the battery pack sits on the UIM or microSD card which
causes a gap between the FOMA terminal and the back cover when attaching the back cover. The waterproof/
dustproof function might deteriorate because of the gap.
18
■ Closing
Align the tab on the back of the cap with
the concave of the FOMA terminal, then
os e th e cap by pr es sing securely in
cl
tion of arrow.
direc
■ Attaching
Insert the tab on top of the back cover into
the FOMA terminal slot, slide it in direction
and push it down securely in direction
Slot
Tab
Securely push the areas illustrated by and
make sure that there is no space between the
back cover and the FOMA terminal.
①
②.
To maintain waterproof/dustproof function, replacement of parts is required once every 2 years
regardless of whether the FOMA terminal appears normal or abnormal. DOCOMO replaces the parts
as a chargeable service. Bring the FOMA terminal to a repair counter specified by DOCOMO.
Important notices
・
If the FOMA terminal gets wet with water or other liquids with the external connector terminal cap or the back
cover open, the liquid may get inside the FOMA terminal causing electric shock or malfunction. Stop using the
erminal, turn off the power, remove the battery pack and contact a repair counter specified by DOCOMO.
FOMA t
・
The external connector terminal cap and the rubber packing of the back cover play an important role
in maintaining waterproof/dustproof function. Do not remove or scratch them. Also, prevent dust from
hering to them. If the external connector terminal cap and the rubber packing of the back cover is
ad
damaged or deformed
・
Do not insert sharp objects through the gap of the external connector terminal cap or back cover. Doing
so may damage the rubber packing and allow water to seep or dust to get in.
・
If the back cover is damaged, replace it. Water may seep into the inside of the FOMA terminal through a
damaged section causing electr
・
Do not leave the FOMA terminal with water drops. In cold places, water may freeze and cause malfunction.
・
To prevent condensation, do not bring the FOMA terminal from a cold place to a bathroom, etc. without
letting the FOMA ter
・
Do not apply water flow stronger than allowed ( →p.17) (e.g., such water flow that gives you pain when
applied to your skin directly from a faucet or shower head). Doing so may cause malfunction though
N-02D is wa
・
Do not wash the FOMA terminal in a washing machine etc.
・
Accessories and options are not waterproof/dustproof. When watching 1Seg etc. with the FOMA
terpr
terminal attached to the provided desktop holder, do not use it in a bathroom, shower room, kitchen or
washroom even if it is not connected to the AC adapter.
・
Do not put the FOMA terminal in hot water, use it in a sauna or apply hot air flow (from a hair dryer etc.) to it.
・
Do not poke the mouthpiece/microphone, earpiece or speaker with cotton swabs or sharp objects. The
waterproof/dustproof function may deteriorate.
・
Do not leave the FOMA terminal wet. Doing so may cause short-circuit of the supply terminal.
・
The FOMA terminal does not float on water.
・
Do not drop the FOMA terminal. Scratches caused by dropping may result in deterioration of waterproof/
dustproof function.
・
Do not leave water on the mouthpiece/microphone, earpiece or speaker. If water adheres to the FOMA
terminal, the volume of the other party's voice or melody may be decreased, sound quality may deteriorate, or
sound when the camera is functioning ma
・
DOCOMO does not guarantee all operations under actual use conditions. Malfunctions deemed to be
caused by inappropriate operation by the customer are not covered by the warranty.
, replace it at a repair counter specified by DOCOMO.
ic shock, corrosion of the battery pack, or other malfunctions.
minal get back to room temperature.
oof to IPX5 standard.
y be audible. In such a case, drain the water to recover the function.
Introduction
19
Draining water when the FOMA terminal gets wet
When the FOMA terminal gets wet, drain the water following the steps below.
Introduction
・
If water adheres to the mouthpiece/microphone, earpiece or speaker, the volume of the other
party's voice or melody may be decreased or sound quality may deteriorate. In such a case, drain
the water following the steps below and dry the FOMA terminal in open air to recover the function.
❶
Wipe the surface of the
FOMA terminal with a
clean dry cloth, et
❷
Securely hold the FOMA
terminal and shake it
c.
x. 20 times until there
appro
no more water splattering
is
❸ Softly press a clean dry cloth
etc., on the FOMA terminal to
wipe off wa
the mouthpiec
earpiece, speaker, keys or
ter remaining in
e/microphone
hinges
Do not wipe off water
*
remaining in gaps directly
with a cott
on swab etc.
,
<Draining from mouthpiece/
microphone or earpiece>
❹
Thoroughly wipe off water drained from the FOMA
<Draining
from speaker>
terminal with a clean dry cloth, etc.
* Water, if any, remaining in the FOMA terminal
may leak out after wiping off.
When charging the battery
Accessories and options are not waterproof/dustproof. Check the following before and after charging.
・ Make sure that the FOMA ter mi na l is not wet. If the FOMA ter minal is wet ,
thoroughly drain the water and wipe off with a clean dry cloth, etc. before placing it
on a provided desktop holder or opening the external connector terminal cap.
・
When the external connector terminal cap is opened for charging, close the cap securely
after charging. It is recommended that the desktop holder be used for charging to prevent
ter from seeping inside and dust from getting in through the external connector terminal.
wa
* Never try to charge the battery pack when the FOMA terminal is wet.
Do not touch the AC adapter or desktop holder with wet hands. Doing so may cause electric shock.
*
* Use the AC adapter or desktop holder in a place free from water splashes. Do
not use them in a bathroom, sho
20
subject to water. Otherwise, it may cause fire or electric shock.
wer room, kitchen, washroom and other places
Cut corner
Before Using
Attaching UIM/battery pack
Make sure to turn the power off before attaching/removing the UIM or the
battery pack. Also, keep the FOMA terminal folded and held in your hand.
・ The UIM is an IC card that contains private information such as your phone number.
・ This FOMA terminal does not operate with a UIM (Blue) in it. If your UIM is blue,
check with a docomo Shop Service Counter for replacement.
❶ Remove the back cover ( →p.18)
❷ Insert the UIM
Insert the card into the slot until it locks in place
in direc
down.
❸ Attach the battery pack
① with the gold colored IC side
tion
With the side having its product name facing
attach the battery pack in direction
up,
making sure that its metal terminal fits into the
FOMA t
erminal's metal terminal, then press the
batt
ery pack down in direction
❹ Attach the back cover (→p.18)
②
③.
Insertion slot
Gold colored
IC side down
IC
UIM
Basic Operation
21
Charging
FOMA AC Adapter 01/02
For the charging time and continuous talk time, refer to "Main specifications"
・ The battery pack, AC adapter and provided desktop holder are not waterproof/
dustproof. Never charge the battery with the FOMA terminal left wet.
・
It is recommended that the desktop holder be used for charging to prevent water
from seeping inside and dust from getting in through the external connector terminal.
Basic Operation
・
The charge lamp lights up when charging starts. The charge lamp turns off when
charging ends (fully charged).
Charging using desktop holder
❶
Plug the connector of the AC adapter (optional) horizontally
to the terminal on the back of the provided desktop holder
❷ Plug the AC adapter into the outlet
❸
Holding down the desktop holder, insert the FOMA
terminal in direction
・
Take care not to pinch the strap, etc. when attaching it.
❹ When charging is complete, hold down the
①
and securely attach it
des ktop ho lde r, the n remo ve the FOM A
ter
minal in reverse procedure of attaching
Charging using AC adapter
❶ Open the external connector terminal cap of
the FOMA terminal (
adapter connector horizonta
terminal's external connector terminal
❷ Plug the AC adapter into the outlet
❸ When charging is complete, remove the AC
adapter connector horizontally from the FOMA
te
rminal while pressing the release buttons,
then unplug the AC adapter fr
22
→ p.18), then plug the AC
lly into the FOMA
om the outlet
With the arrow
side facing up
❶
100V AC
power outlet
❷
100V AC
power outlet
❷
Plug
FOMA
AC Adapter
01/02
Connector
Plug
Terminal
cap
Release
buttons
Desktop Holder N35
Charge lamp
With the arrow
side facing up
(→
❸
Charge
lamp
❶
Connector
p.94).
Turning power ON
❶
y (1 second or longer)
■ If Initial setting screen appears
When you turn the power on for the first time after purchase, Initial setting screen appears.
■ To turn the power off
Press y for 2 seconds or longer.
d
Standby screen
Configuring default setting
After turning the power on for the first time after purchase,
screens for initial settings such as "Auto time", "Change
security code" and "Keypad sound" appear.
・
For the initial settings, you can also set the time difference adjustment, character
size and location notification.
・
After you set all functions, Initial setting screen will no longer appear at power on.
Basic Operation
23
Notifying your caller ID on the other party's phone
Set whether to show your phone number (caller ID) on the other party's
phone (display) when making a call.
❶
is "TEL function" s "Dial/Receive setting" s "Caller ID
Basic Operation
notification"
・
If you hear a message requesting your caller ID, make a call again with Caller ID
notification enabled or with 186 prefix.
s "Activate/Deactivate" s "ON" or "OFF"
Checking your own phone number
On Profile screen, check your phone number (own number) stored in your
UIM and model name.
❶
is "Profile"
You can also check your phone number by pressing is0.
・ Only phone number is stored by default in Profile screen.
To save mail address, enter directly or obtain from i-mode automatically as follows.
On Profile screen,
s "Acquire Automatically" sConnect to i-mode to enter your mail address
to <Mail address> field automatically
・ To change your mail address, refer to "Mobile Phone User's Guide [i-mode] FOMA
version".
Uu (Edit)sEnter your security codes <Mail address>
sUu (Finish).
Switching between Japanese and English
24
❶
is
"本体設定 "s"文字表示 / 入力 "s"Select language"s"English"
Screen Explanation
Viewing display/icon
Symbols ( , , , etc.) displayed on the screen are referred to as icons.
Icons indicate the status of such as the FOMA terminal and signal reception.
■ Icons indicating the status of the FOMA terminal
At the top of the screen, icons indicate the status of the FOMA terminal.
Battery level (use this icon as a guide)
：Fully charged.
：Recharge the battery.
Signal strength
Good
：Out of the FOMA service
Poor
area
：During i-mode
：Unread mail
：During a voice call
：Dial lock is set
：New i-concier information
：Multitask activating
：Bluetooth ON (Lights up)
：microSD card inserted
• Only major icons are covered here. To check the
names of the icons,
Display"
s "Icons".
：Vibrator set
：
Ring volume set to "Silent"
：Manner mode ON
：
Public mode (Drive mode) ON
：
Alarm notification function ON
：
The number of Voice Mail messages
for voice/videophone calls
：
The number of record VP messages
：eco mode set
：Auto-key lock set
：USB cable connected and
Communication mode on
Iis "Setting" s "Screen/
Basic Operation
25
■ Desktop icons and shortcut icons
In the middle of the screen, desktop icons indicate the status of new arrivals. You can
paste shortcut icons, with which you can launch functions.
Desktop icons (examples)
：Missed call
：Record message
Basic Operation
：Record VP message
：Voice Mail
：New mail
Shortcut icons (examples)
： i-concier
： 使いかたガイド
(Guide) (Japanese)
： Voice quick start
： Medias viewer
・
To selec t a desktop icon or shortcut icon to launch a function, on the standby
screen
s
Xd
.
Function display area
→p.28
26
Viewing main menu
You can select various functions of the FOMA terminal from the main menu.
・ The main menu here is in "Standard".
Mail ： Display the mail functions.
i-mode/web
i-αppli ： Display the i-αppli menu.
CAMERA/TV/MUSIC
Data box
Tool
TEL function
Setting ：
Map/Overseas
i-concier ： Display the i-concier screen.
Profile
Osaifu-Keitai
p (Original) : Display the original menu.
■ Changing the design of the main menu
You can change the design of the main menu (background, icon, etc.). Choose from
"Standard", "Simple", "Original theme" and "Kisekae Tool".
❶
is u (Kisekae) s Select a design
：
Display the menus of i-mode and Full Browser.
： Display the menus of Camera, MUSIC
Player, Music&Video Channel and 1Seg.
： Display folders in Data box.
： Display useful functions.
：
Di spl ay ph one f unc tions su ch as the
phonebook, dialed/received calls, etc.
Display the setting menu of the FOMA terminal.
：
Display the setting menus of GPS and Overseas use.
： Display the UIM own number, etc.
： Display the setting menus of IC card, ToruCa, etc.
Basic Operation
27
Key operation
The soft keys (Function display) corresponding to i, d, u, o, p, and the direction icons
corresponding to
b
are displayed on the screen. These icons appear only when the corresponding keys can be used.
Performing the functions assigned to the function key
Basic Operation
❷❹❶ ❺ ❸
❻
■ Display examples and assigned functions
❶ shows (Submenu), (Exit), (MENU), etc.
❷ shows (Select), (Set), (Play), (Send), etc.
❸ shows (Set), (Edit), (Finish), (Play), (Send), (New), etc.
❹ shows (Back), (microSD), (←Set.), etc.
❺ shows (Change), (Delete), (Set. →), etc.
❻ shows an icon ( ) to indicate direction available for
moving or scrolling vertically and horizontally. Press
move or scroll the direction.
Menu operation
You can select various functions of the FOMA terminal from the main menu,
which appears when you press i on the standby screen.
❶
isb
to move the highlight, then d (Select)sSelect the displayed menu sequentially
b
to
i
s
・
If no key is pressed for 15 seconds or longer while the main menu is displayed, the main menu ends and the previous screen reappears.
28
b
s
d
s
Loading...
