Docomo Lumix P-02D Instruction Manual

Download

ISSUE DATE:

NAME:

PHONE NUMBER:

MAIL ADDRESS:

INSTRUCTION MANUAL

P-02D

Preface

Thank you for selecting the “P-02D”.

For proper use, read this manual before and when you use the P-02D.

Notes on Using this Mobile Phone

󱾀



This mobile phone is compatible with W-CDMA, GSM/GPRS and wireless LAN systems.

󱾀



Because this mobile phone uses radio waves, you cannot use it in places where the radio waves do not reach such as inside tunnels, basements and buildings, where the radio waves are weak even outdoors, or out of FOMA service area. You might not be able to operate this mobile phone even when you are in a place with a fine view such as on upper floors of a high-rise building or apartment. Note that you may experience interruption of calls even when the four-bar antenna mark is displayed indicating a strong radio wave and you are not moving.

󱾀



Since this mobile phone uses radio waves as the medium of telecommunication, calls may be tapped by a third party. However, the W-CDMA and GSM/GPRS systems automatically support tapping prevention, so your conversation will be incomprehensible to the third party, because it is recognized as mere noise.

󱾀



The mobile phones change your voice into digital signals and send them to the other party. In places where the radio waves are weak, the digital signals may not be converted correctly, and in such a case, the voice may sound different from the actual one.

󱾀



This mobile phone supports FOMA Plus-Area and FOMA High-Speed Area.

󱾀



You are advised that you make separate notes of information stored in this mobile phone and keep them in a safe place. Note that we cannot be held responsible for the unlikely event of loss of the stored content due to a malfunction, repair, change of your model, or other mishandling of this mobile phone.

󱾀



You are advised to save your important data on the microSD card.

󱾀



As with PC applications, some applications you have installed in this mobile phone may pose problems: unstable operations of your mobile phone, unauthorized distribution and use of your location and personal information stored in the mobile phone. Therefore, you need to thoroughly check the source and behaviors of intended applications before use.

SIM Unlock

This mobile phone supports SIM unlocking. You can use another operator’s SIM card once you unlock the SIM.

󱾀



Contact a docomo Shop for SIM unlocking.

󱾀



You will be charged a SIM unlocking fee separately.

󱾀



When you use another operator’s SIM card, available services and functions are limited. Note that we provide no warranty of operations with other operator’s SIM cards.

󱾀



For details of SIM unlocking, refer to DOCOMO website.

Basic Package/Samples

P-02D (with warranty and Back Cover P54)

Battery Pack P26

Desktop Holder P48(with warranty)Q

Quick Start Guide (in Japanese)

AC adapter cable P01 (with warranty) <AC adapter> <microUSB cable>

Basic Package

Sample

Q Earphone Plug Adapter (with manual) Q microSD card (2 GB)

(with manual)

*Installed in the mobile

phone at the time of purchase.

• For other optional items, Z P.253

Descriptions of Operating Procedures

The operating procedures of the P-02D are described in the following manuals.

■ “Quick Start Guide” (in Japanese only)

(supplied with this mobile phone)

Describes operating procedures of basic functions.

■ [Instruction Manual] (in Japanese only)

(installed in your mobile phone)

Describes detailed information of functions and operating procedures.

Home screen W

• Before using Instruction Manual for the first time, install the application from Android Market.

W [Instruction Manual]

■ “Instruction Manual” (PDF)

Describes detailed information of functions and operating procedures. Download from DOCOMO website: http://www.nttdocomo.co.jp/support/trouble/manual/ download/index.html

* Note that the URL and published contents may be modified

without notice.

Information

• It is prohibited to copy all or part of this manual without permission.

• The information contained in this manual may be changed without notice.

• Operating procedures when [docomo Palette UI] is set as the home application are explained in this manual. If you change the home application, some operating steps may differ from those described in this manual.

• Screenshots and illustrations shown in this manual are for reference. The actual ones may differ.

• Keys are simplified for explaining operating procedures in this manual.

Handling Precautions for this Mobile Phone

• This mobile phone is not compatible with i-mode site (program) and i-αppli.

•

This mobile phone is designed to perform communication automatically check for the latest software version and maintaining a connection with the server. Communication of a massive amount of data such as application download and video watching will cost expensive packet communication fee, so we strongly recommend subscription to the flat-rate packet service.

• Public mode (drive mode) is not available for this mobile phone.

• Operation sounds such as shutter sound of the camera, etc. are emitted from this mobile phone even in Silent mode in which phone ringtone, touch tones and notification ringtone are muted.

• To confirm your phone number (My Profile), Z

for

some

features such as data synchronization,

P.117

• To confirm the software version of your mobile phone, Z P.162

• New features may be added to this mobile phone and operation method is system (OS) upgrading. For the latest information on additional features and change of operation method, see DOCOMO website.

• OS upgrading may disable applications used in the old OS version or pose unwanted failure.

• For services provided by Google, Inc., read Google Terms of Service. For other web services, read the respective terms of service.

• In the event of loss of your mobile phone, be sure to change passwords for various service accounts from PC in order to prevent others from accessing your accounts for Google services such as Google Talk, Gmail and Android Market, Facebook, Twitter, and/or mixi.

• Providers other than sp-mode, mopera U and business mopera Internet are not supported.

subject to change due to future operating

• Although you can use this mobile phone without installing a microSD card, there are files that can only be stored on microSD card, such as images shot by Camera. Therefore, installing a microSD card is recommended when using this mobile phone.

• sp-mode subscription is required for using tethering.

• When tethering is enabled, sp-mode functions are not available except Internet access and mail service.

• When an external device is connecting to the Internet by tethering, applications (browser, games, etc.) may not work correctly on the device in some situations.

• No security measure such as password setting is applied between a smartphone/tablet and external device in the default setting of tethering. Setting a password is recommended.

• For details including usage fees, visit http://www.nttdocomo.co.jp/english/

Basic Package/Samples. . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Descriptions of Operating Procedures. . . . . . . . . . . . . . . . 2

Handling Precautions for this Mobile Phone. . . . . . . . . . . 3

Precautions (ALWAYS FOLLOW THESE DIRECTIONS). . . . 9

Handling Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Waterproof Performance. . . . . . . . . . . . . . . . . . . . . . . . . 33

Preliminary Check

docomo Palette UI

Initial Setting

Part Names and Functions. . .

docomo mini UIM card. . . . . . . . . . . 45

microSD Card. . . . . . . . . . . . . . . . . 47

Battery Pack. . . . . . . . . . . . . . . . . . 49

Charging. . . . . . . . . . . . . . . . . . . . . 50

Power On/Off. . . . . . . . . . . . . . . . . . 55

Basic Operations (How to Use Touch

Panel). . . . . . . . . . . . . . . . . . . . . . . 57

Screen Display/Icons. . . . . . . . . . . . 60

Character Entry. . . . . . . . . . . . . . . . 64

. . . . . . . . . . . . . . . 78

Home Screen.

Application Screen. . . . . . . . . . . . . . 82

Home Application Settings. . . . . . . . . 90

Initial Setting. . . Changing Screen Display to English

. . . . . . . . . . . . . . . . . . . . . . . . . . . 93

Google Account. . . . . . . . . . . . . . . . 94

Setting Access Point. . . . . . . . . . . . . 95

Email Setting. . . . . . . . . . . . . . . . . . 98

. .

. . . . . . . . . . . . . . . 91

. . . . . . 42

Phone/Network

Services

104

Wi-Fi. . . . . . . . . . . . . . . . . . . . . . . 100

Online Service Accounts. . . . . . . . . 103

Phone. Call Log.

Phonebook. . . . . . . . . . . . . . . . . . . 113

PhoneBookCopy. . . . . . . . . . . . . . . 118

Available Network Services. . . . . . . 120

. . . . . . . . . . . . . . . . . . . . . 104

. . . . . . . . . . . . . . . . . . . . 112

Setting Menu. . .

. . . . . . . . . . . . . . 129

Wireless & Networks. . . . . . . . . . . . 130

Call Settings. . . . . . . . . . . . . . . . . . 134

docomo Service. . . . . . . . . . . . . . . 138

Sound. . . . . . . . . . . . . . . . . . . . . . 139

Display. . . . . . . . . . . . . . . . . . . . . 141

Location & Security. . . . . . . . . . . . . 142

Various Settings

129

Mail/Internet

163

Applications. . . . . . . . . . . . . . . . . . 151

Accounts & Sync. . . . . . . . . . . . . . . 152

Privacy. . . . . . . . . . . . . . . . . . . . . 154

Storage. . . . . . . . . . . . . . . . . . . . . 157

Language & Keyboard. . . . . . . . . . . 158

Voice Input & Output. . . . . . . . . . . 159

Accessibility. . . . . . . . . . . . . . . . . . 160

Date & Time. . . . . . . . . . . . . . . . . 161

About Phone. . . . . . . . . . . . . . . . . 162

. . . . . . . . . . . . . . 163

sp-mode Mail.

. .

Message (SMS). . . . . . . . . . . . . . . 164

Email. . . . . . . . . . . . . . . . . . . . . . 167

Gmail. . . . . . . . . . . . . . . . . . . . . . 170

Early Warning "Area Mail". . . . . . . . 173

Google Talk. . . . . . . . . . . . . . . . . . 175

Web Browser. . . . . . . . . . . . . . . . . 178

. .

Infrared Communication.

. . . . . . 183

File Management

183

Bluetooth Communication. . . . . . . . 186

DIGA/DLNA Device Connection. . . . 190

VPN (Virtual Private Network) Connection

. . . . . . . . . . . . . . . . . . . . . . . . . . 192

External Device Connection. . . . . . . 194

Camera. . . . . . . . . . . . . . . . . . . . . 196

Applications

196

Picture Album. .

. . . . . . . . . . . . . . 205

Media Player. . . . . . . . . . . . . . . . . 209

Android Market. . . . . . . . . . . . . . . . 211

Google Maps. . . . . . . . . . . . . . . . . 213

1Seg. . . . . . . . . . . . . . . . . . . . . . . 215

Osaifu-Keitai. . . . . . . . . . . . . . . . . 225

YouTube. . . . . . . . . . . . . . . . . . . . 229

Clock. . . . . . . . . . . . . . . . . . . . . . . 230

Calendar. . . . . . . . . . . . . . . . . . . . 232

Memo. . . . . . . . . . . . . . . . . . . . . . 235

Calculator. . . . . . . . . . . . . . . . . . . 236

ECONAVI. . . . . . . . . . . . . . . . . . . . 237

Barcode Reader. . . . . . . . . . . . . . . 238

Polaris Office. . . . . . . . . . . . . . . . . 240

iD appli. . . . . . . . . . . . . . . . . . . . . 242

Overview of International Roaming

. . . . . . . . . . . . 243

(WORLD WING).

. .

Overseas Use

243

Available Services. . . . . . . . . . . . . . 244

Confirmation before Use. . . . . . . . . 245

Settings for Overseas Use. . . . . . . . 248

Making/Receiving Calls in the Country You

Stay. . . . . . . . . . . . . . . . . . . . . . . 250

Confirmation after Returning Home

. . . . . . . . . . . . . . . . . . . . . . . . . . 252

Optional Items and Associated Equipment . . .

. . . . . . . . . . . . . . . . . . . . . . . 253

Troubleshooting (FAQ). . . . . . . . . . 254

Warranty and After-Sales Service. . . 263

Software Update. . . . . . . . . . . . . . 267

Main Specifications. . . . . . . . . . . . . 281

Specific Absorption Rate (SAR) of the

Phone. . . . . . . . . . . . . . . . . . . . . . 286

Appendix

253

European RF Exposure Information

. . . . . . . . . . . . . . . . . . . . . . . . . . 288

Declaration of Conformity. . . . . . . . 289

FCC Notice. . . . . . . . . . . . . . . . . . . 290

FCC RF Exposure Information. . . . . 291

Important Safety Information. . . . . 293

Export Administration Regulations

. . . . . . . . . . . . . . . . . . . . . . . . . . 295

Intellectual Property Right. . . . . . . . 296

Index. . . . . . . . . . . . . . . . . . . . . . 301

Precautions (ALWAYS FOLLOW THESE

Danger

Warning

Caution

Don’t

Do not

disassemble

Not wet

hands

Avoid Water

DIRECTIONS)

■Before using the mobile phone, read these safety

precautions carefully so that you can use it correctly. After reading the precautions, keep them in a safe place.

■Be sure to observe these safety precautions to prevent you

or those around you from inflicting injury and to avoid unnecessary damage to the property.

■The symbols below indicate the levels of danger or damage

that can be caused if the particular precautions are not observed and equipments are not used properly.

This symbol indicates that incorrect handling poses an imminent risk of causing death or serious injury.

This symbol indicates that incorrect handling poses a potential risk of causing death or serious injury.

This symbol indicates that incorrect handling poses a risk of causing an injury or damage to property.

■The following symbols show specific directions:

Denotes actions prohibited to do.

Denotes not to disassemble the units.

Denotes not to touch with wet hands.

Denotes not to use where the equipment may get wet, and avoid get it wet.

Denotes mandatory instructions (matters that must be

Pull the

power plug

out

Danger

Don’t

Do not

disassemble

complied with).

Denotes to pull the power plug out of an outlet.

■“Precautions” are divided into the following six sections:

General Precautions for this Mobile Phone, Battery Packs, AC Adapter Cable, Desktop

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P.10

Precautions for this Mobile Phone. . . . . . . . . . . . . . . . . . . P.12

Precautions for Battery Packs. . . . . . . . . . . . . . . . . . . . . . P.16

Precautions for AC Adapter Cable and Desktop Holder. . . . P.18

Precautions for docomo mini UIM card. . . . . . . . . . . . . . . P.19

Notes on Using near Electronic Medical Equipment. . . . . . . P.20

Holder, and docomo mini UIM card　　　

General Precautions for this Mobile Phone, Battery Packs, AC Adapter Cable, Desktop Holder, and docomo mini UIM card　　　

Do not use, store, or leave the mobile phone or its accessories in places as near fire, near heating appliances, inside a kotatsu or near other furniture with heating elements, in places exposed to direct sunlight, or in cars heated by the sun).

Fire, burns, or injury may result.

Do not place the mobile phone or its accessories inside cooking appliances such as microwave ovens or high pressure containers.

Fire, burns, injury or electric shock may result.

with a high temperature (such

Do not attempt to disassemble or remodel the mobile phone or its accessories.

Fire, burns, injury or electric shock may result.

Avoid Water

Do not allow the mobile phone or its accessories to

Warning

Don’t

get wet either from water, drinking water or pet urine, etc.

Fire, burns, injury or electric shock may result. For details about waterproof performance, see the following: Z P.33 "Waterproof Performance"

With your mobile phone, use the battery packs and AC adapter cables specified by NTT DOCOMO, INC.

Fire, burns, injury or electric shock may result.

Do not throw the mobile phone or accessories, or subject them to severe force or shocks.

Fire, burns, injury or electric shock may result.

Do not allow electrically conductive foreign objects (such as metal pieces or pencil leads) to come into contact with charging

terminal or connector terminal. Do not allow such objects to enter into the mobile phone.

Fire, burns, injury or electric shock may result.

Do not cover or wrap the mobile phone or its accessories with a cushion, etc. while it is being used or recharged.

Fire or burns may result.

Before entering a gas station or other places where flammable gases are

generated, be absolutely sure to turn off this mobile phone and stop charging if it is being charged.

Otherwise, the flammable gases may ignite. Use the Osaifu-Keitai with the mobile phone turned off when you are near a gas station. (When Osaifu-Keitai lock is set, release the lock, and then turn off the power.)

If odor, overheat, discoloration, or deformation is detected during use, battery charge, or storage, immediately follow the instructions below:

• Pull the power plug out of the outlet.

• Turn off the power of this mobile phone.

• Remove the battery pack from this mobile phone.

Fire, burns, injury or electric shock may result.

Caution

Don’t

Do not place the mobile phone or accessories on

Don’t

Warning

Don’t

unstable locations such as wobbly tables or slanted locations.

They may fall off and cause injury.

Do not store in humid or dusty places, or in high temperature environments.

Fire, burns or electric shock may result.

If the mobile phone and its accessories are used by a child, a guardian correctly. During use, a guardian should also check that they are being used as instructed.

Otherwise, injury may result.

Keep out of the reach of small children.

Accidental swallowing or injury may result.

Take special care when you use this mobile phone for a long time with the AC adapter cable connected.

If you watch 1Seg programs and so on for a prolonged period of time while charging, the temperature of this mobile phone, battery pack or AC adapter cable may rise. If you keep direct contact with high-temperature parts, redness, itching, a rash or low-temperature skin burns may result depending on the state of your physical condition or constitution.

should explain how to operate them

Precautions for this Mobile Phone

Do not directly point the infrared data port at someone’s eyes during transmission.

Doing so may harm the person’s eyes.

While using infrared communication, do not point the mobile phone’s infrared appliance which is equipped with an infrared device.

The infrared device may malfunction, and possibly cause an accident.

data port at a home electrical

Don’t

Do not light the light close to eyes. Especially when

Don’t

shooting small children, be sure to stay at least 1 m away from them.

Doing so can damage eyesight. Also, accidents such as injury

might occur

if someone is startled or dazzled by the

light.

Do not allow liquids such as water, or foreign materials such as

metal pieces or flammable materials to get into the docomo mini UIM card or microSD card slot of this mobile phone.

Fire, burns, injury or electric shock may result.

Do not turn on the light toward car drivers.

It disturbs driving, and accidents may result.

Turn off this mobile phone in places where use is prohibited such as in airplanes and hospitals.

Otherwise, the electronic devices and electronic medical equipment in those places may be adversely affected. If the Auto power ON function is set, deactivate the setting, then turn off the power.

use inside

For

medical facilities, make sure that you comply with their regulations. Engaging in any prohibited acts such as using the mobile phone in an airplane is punishable by law. However, if use of the mobile phones in an airplane is permitted provided that radio wave transmission is turned off, you may do so in accordance with instructions of each airline.

When talking in Hands-free mode or when a ring tone is sounding, be absolutely sure to keep this mobile phone away from your ear. Further, when you play games or play back music etc. with the earphone/microphone etc. connected, adjust the sound volume to moderate volume.

The excessive sound volume impairs your hearing. Further, accidents may result due to the hardness of hearing of surrounding sound.

For those with weak heart conditions, the vibrator and ring volume must be adjusted carefully.

Otherwise, the functions may adversely affect your heart.

If you are using an electronic medical device or other

Caution

Don’t

type of device,

check with its manufacturer or vendor regarding the influence of radio waves upon the device.

The mobile phone may adversely affect the device.

Turn off this mobile phone when near electronic devices using high-precision control or weak signals.

The mobile phone may cause the electronic devices to malfunction and have other adverse effects. * Electronic devices that may be affected: Hearing aids, implanted cardiac pacemakers, implanted defibrillators, other electronic medical equipment, fire alarms, automatic doors and other automatically controlled devices. If you use an implanted cardiac pacemaker, implanted defibrillator or any other electronic medical

equipment,

consult

the manufacturer or retailer of the device for advice regarding possible effects from the radio waves.

If the display part or camera lens is broken, be careful about broken glasses or the exposed interior of this mobile phone.

A film is coated on the surface of the display area and the plastic panel is used for the surface of the camera lens, making

it hard for the glass to break into pieces. However, if you touch the damaged or exposed parts by mistake, you may injure yourself.

Do not swing around this mobile phone by its strap, antenna or other parts.

You may hit yourself or others, possibly causing injury or other accidents.

Do not use this mobile phone if it has been damaged.

Fire, burns, injury or electric shock may result.

When using the motion sensor, ensure that you check around you for safety, securely take hold of your mobile phone, and do not swing more than necessitated.

Otherwise, injury or other accidents may result.

Don’t

The surface of the display is coated by a film that

Don’t

prevents the surface

from damage so that your safety is ensured when you accidentally drop or give shock to your mobile phone (for preventing the reinforced glass from scattering). Do not forcibly peel off or give damage to the film.

If the display is damaged while you operate the mobile phone with the film peeled off, you might suffer an injury.

If you accidentally damage the display part and the substance inside

leaks out, keep your face, hands

and skin away from it.

Otherwise, you may impair your eyesight or damage your skin. If this substance should get into your eyes or mouth, immediately rinse them with clean water, and then seek medical attention. If it should adhere to your skin or clothing, immediately wipe it off with alcohol or similar liquid, and then rinse the affected area with soap and water.

Before using the mobile phone inside a car, check with its manufacturer or dealer whether the radio waves will have any adverse effects.

In some vehicle models, the radio waves may adversely affect

the electronic

devices inside the vehicle. Such cases are rare. However, if this happens, stop using the mobile phone immediately.

Itching, rash or eczema may be caused depending on your physical conditions or predisposition. If an abnormality occurs, stop using the mobile phone immediately, and then seek medical attention.

For

material

each part, Z P.21 “List of materials used”

View the display in a sufficiently light place keeping a certain distance from your eyes.

Otherwise, your eyesight may become impaired.

Precautions for Battery Packs

Danger

Don’t

Warning

Don’t

■Check the description on the label of the battery pack for

the type of battery.

Description Type

Li-ion 00 Lithium-ion battery

Do not let any metal object such as a wire come in contact with the battery terminals. Also do not carry or store the battery pack together with any metal objects like a necklace.

Otherwise, the battery pack may ignite, burst or overheat and its electrolyte may leak.

When installing the battery pack in this mobile phone, check that it pack cannot be installed easily, do not force it into place.

Otherwise, the battery pack may ignite, burst or overheat and its electrolyte may leak.

is facing the right way, and if the battery

Do not throw the battery pack into fire.

Otherwise, the battery pack may ignite, burst or overheat and its electrolyte may leak.

Do not pierce it with nails, hit it with a hammer, or step on it.

Otherwise, the battery pack may ignite, burst or overheat and its electrolyte may leak.

If the battery fluid or other material gets into your eyes, do not rub them. Flush your eyes with clean water and seek medical attention immediately.

Otherwise, the loss of eyesight may result.

Never use the mobile phone if it has damages such as deformities or scratches as a result of dropping it.

Otherwise, the battery pack may ignite, burst or overheat and its electrolyte may leak.

Immediately stop using the mobile phone and keep it

Caution

Don’t

away from fire if the battery pack leaks or emits an odor.

The leaked battery fluid may ignite, causing fire or burst.

Be careful that your pets do not bite into the battery pack.

Otherwise, the battery pack may ignite, burst or overheat and its electrolyte may leak.

Do not dispose of the battery pack with other waste.

The battery pack may catch fire or damage the environment. After insulating the battery terminals with tape, take the unneeded battery pack to a handling counter such as a docomo Shop or dispose of it in accordance with local waste disposal regulations.

Do not use or attempt to charge a wet battery pack.

Otherwise, the battery pack may ignite, burst or overheat and its electrolyte may leak.

If the electrolyte fluid or other material inside the battery pack has leaked out, do not allow it to come into contact with the skin on your face, hands or any other part of your body.

Contact may result in loss of sight or skin problems.

you get

the fluid or other material in your eyes or mouth, or on skin or clothing, immediately wash the affected areas with clean water. If you get it in your eyes or mouth, immediately seek medical attention after rinsing.

Precautions for AC Adapter Cable and

Danger

Don’t

Warning

Don’t

Not wet

hands

Desktop Holder

Do not connect microUSB cables other than the supplied one.

Fire, burns or electric shock may result.

Do not use the microUSB cable if it has been damaged.

Fire, burns or electric shock may result.

Do not use the AC adapter cable and desktop holder in humid places such as a bathroom.

Fire, burns or electric shock may result.

If a thunderstorm is nearby, do not touch the AC adapter cable.

Otherwise, you may receive an electric shock.

Never short-circuit the charging terminal when the adapter is plugged touch the charging terminal with fingers or other bare skin.

Fire, burns or electric shock may result.

Do not place heavy objects on the microUSB cable.

Fire, burns or electric shock may result.

When plugging the AC adapter into the power outlet, or when unplugging it from the outlet, do not allow metal straps or other metal objects to come in contact with it.

Fire, burns or electric shock may result.

Do not touch the AC adapter cable, desktop holder, or power outlet with wet hands.

Fire, burns or electric shock may result.

into the power outlet. Also, never

Use the adapter at the specified V AC.

Pull the

power plug

out

Pull the

power plug

out

Pull the

power plug

out

Caution

Supplying the wrong

voltage to the AC adapter may result in a fire, burns or electric shocks. 100 V - 240 V AC (Connect only to household AC outlet.)

Keep the power plugs dust-free.

Fire, burns or electric shock may result.

When plugging the AC adapter into the power outlet, plug it in securely.

Fire, burns or electric shock may result.

When unplugging the power plug from the power outlet, take hold of the AC adapter to unplug it.

Fire, burns or electric shock may result.

When you do not intend to use the adapter for a long period of time, disconnect the power plug from the power outlet.

Fire, burns or electric shock may result.

If liquids such as water get in the adapter, unplug the power plug immediately from the outlet.

Fire, burns or electric shock may result.

Before cleaning, pull the power plug out of the outlet.

Fire, burns or electric shock may result.

Precautions for docomo mini UIM card

Be careful not to touch the cut surface of the docomo mini UIM card when removing it.

Otherwise, injury may result.

Notes on Using near Electronic Medical

Warning

Equipment

■The description below meets “Guidelines on the Use of

Radio-communication Equipment such as Cellular Telephones – Safeguards for Electronic Medical Equipment” by the Electromagnetic Compatibility Conference Japan.

Comply with the following in hospitals or health care facilities:

• Do not carry this mobile phone into operating rooms, intensive care units

• Turn off this mobile phone in hospital wards.

• If there is any electronic medical equipment near you,

off this

turn as a lobby.

• Comply with any regulations of hospital and health care facilities instructing you not to use or carry in a mobile phone.

• If the Auto power ON function is set, deactivate the setting, then turn off the power.

mobile phone even when in a location such

(ICU) or coronary care units (CCU).

Turn off this mobile phone in trains during the rush hour or other crowded areas as there may be someone near you with an implanted cardiac pacemaker or implanted defibrillator.

The mobile phone’s radio waves may adversely affect the operation defibrillators.

If you use electronic medical equipment such as implanted cardiac pacemaker or implanted defibrillator, carry and more away from the implanted cardiac pacemaker or implanted defibrillator.

The mobile phone’s radio waves may adversely affect the operation of electronic medical equipment.

of implanted

cardiac pacemakers and implanted

use this mobile phone 22 cm or

Patients using electronic medical equipment other than implanted cardiac pacemakers or implanted defibrillators (outside medical establishments for treatment at home, etc.) should check the influence of radio waves upon the equipment by consulting its manufacturer.

The mobile phone’s radio waves may adversely affect the operation of electronic medical equipment.

■ List of materials used

Where it is used Material/Finishing

Outer casing Around the key

of side surface Display surface PA/UV coating Around the key

of display surface, Battery surface, Side surfaces of the back cover side

Back cover PC/aluminum foil, UV coating

Connector terminal Stainless steel/nickel plating,

Connector terminal cover Elastomer, Silicon rubber,

Camera ring area (Inside) Aluminum/alumite treatment Camera ring area (Outside) ABS/UV coating

ABS/UV coating

PC/UV coating

tin plating

PC/UV coating

Camera lens area, Infrared data port area

Charging terminal Brass/nickel plating, palladium

Display panel Glass, Battery compartment Glass epoxy substrate Battery compartment surface Aluminum Battery

terminal

Resin part PA Terminal area Titanium copper/nickel plating,

PMMA/hard coating, AR coating,

plating, gold plating

gold plating

water-repellent coating

PET/surface hard coating

Where it is used Material/Finishing

Battery pack Resin part PC

Terminal area Glass epoxy substrate/nickel

plating, gold plating

Label PET

docomo mini UIM card tray

Packing (Rear surface of back

Metal area Stainless steel Resin area LCP

Silicon rubber

cover) Flash area PMMA Keys Menu key,

PC/UV coating Home key, Back key, Power key, Volume keys

Shutter key PC/aluminum vapor deposition,

UV coating

Label (Battery compartment

Polyester

surface) Label (Battery surface) PC Label (Inside of the back cover) PET 1Seg antenna Tip resin part ABS/UV coating

Metal part

Stainless steel (Pipe area)

Metal part

Nickel-titanium alloy (Wire area)

Metal part

Brass/tin-cobalt plating (Wire connection area)

Metal part

Stainless steel/nickel plating (Hinge area)

microSD card slot

Resin part LCP Metal part Phosphor bronze/nickel plating

Handling Precautions

General Notes

■The P-02D is provided with the waterproof performance,

however, do not have water entered into the inside of this mobile phone, or do not spray water over accessories and optional items.

The battery pack, AC adapter cable, desktop holder, and docomo mini UIM card are not waterproofed. Do not use them in environments, which are high in humidity such as in bathrooms, and do not allow them to get wet from rain. Furthermore, if carrying them against your body, they become moist due to perspiration and the internal parts may become corroded, causing malfunction. If the parts are found to have been damaged due to exposure to the liquids, any repairs will not be covered by warranty, or repairs may not be possible. This may be repaired at a cost if repairs are possible.

■Use a dry soft cloth such as the one for cleaning glasses to

clean the equipment.

• The display may be scratched if it is rubbed hard with a dry cloth.

• Stains may result from droplets of water or dirt if they are left on the display.

• Do not use alcohol, thinner, benzene, detergent or other solvents for cleaning, otherwise the printing may be removed or discoloration may result.

■Occasionally clean the terminals of the equipment using a

dry cotton swab, etc.

The soiled terminals deteriorate the connection and might cause power discontinuity or incomplete charging. Wipe the terminals with a cotton swab, etc. Take care not to damage the terminals when cleaning them.

■Do not place the mobile phone near an air conditioner

outlets.

Condensation may form due to rapid changes in temperature, and this may corrode internal parts and cause malfunction.

■Do not apply excessive force onto this mobile phone and

battery pack.

If you put the mobile phone in a bag along with many other articles or sit with the mobile phone in a clothes pocket, the display, internal circuitry and the battery pack could be damaged or malfunction. Also, if an external device is left connected to the connector terminal, the connector could be damaged, or malfunction.

■Do not rub or scratch the display part with metals.

Doing so might cause damage to the part, resulting in failure or malfunction.

■Carefully read each instruction manual attached to battery

pack or AC adapter cable.

Notes on Handling this Mobile Phone

■Never forcibly press the surface of the touch panel, or

operate it with something having a sharp point like a claw, ballpoint pen, or pin.

Damage to the touch panel might result.

■Avoid using in extremely high or low temperatures.　

The mobile phone should be used within a temperature range of 5°C to 35°C and a humidity range of 45 % to 85 %.

■If the mobile phone is operated near a land-line phone,

television set, radio or other devices in use, it may adversely affect the devices. Operate the mobile phone as far away from these devices as possible.

■It is recommended that you make separate notes of the

information stored in this mobile phone and keep such notes in a safe place.

We take no responsibility for any loss of the stored data items.

■Do not drop this mobile phone or subject it to strong

impacts.

Malfunction or damage may result.

■Do not insert an external device to the connector

terminal at a slant when connecting, and do not pull it out when it is inserted.

Malfunction or damage may result.

■This mobile phone becomes warm during use or charging

but this is not an abnormality. Use the mobile phone as it is.

■Do not leave the camera in places exposed to direct

sunlight.

Pixels may be discolored or burns may result.

■When using the mobile phone, ensure that you close the

cover for the connector terminal.

Dust or water might enter into the mobile phone, causing malfunction.

■Do not use the mobile phone with the back cover left

removed.

The battery pack might come out, or malfunction or damage may result.

■While you are using the microSD card, never take it off or

turn off the power of this mobile phone.

Data may be erased or malfunction may result.

■Do not place magnetic cards or similar objects near this

mobile phone.

Magnetic floppy disks, etc. may be deleted.

data on cash cards, credit cards, telephone cards and

■Do not bring magnetic substances close to your mobile

phone.

Problems with operation may result if items with strong magnetic fields are brought close to the mobile phone.

Notes on Handling Battery Packs

■Battery pack is a consumable item.

Though it depends on the usage state, you are advised to replace the battery pack if its usable time is extremely short even when you fully charge it. Make sure that you buy a specified battery pack.

■Charge

temperature of 5°C to 35°C.

the

battery

in a place with an appropriate ambient

■The usable time of the battery pack differs depending on

the usage environment and its remaining life.

■Depending on how the battery pack is used, it might swell

as its remaining life becomes short, but this is not a problem.

■Note the following points when you store a battery pack:

• Storage in a fully charged state (the state immediately after charging is completed)

• Storage with no battery power left (the state you cannot turn on the power of the main unit due to battery drain)

These may lower the battery pack’s performance and shorten its operating life. Before it is recommendable, as a general rule, for its remaining battery level to be about 40 %.

storing a battery pack, check its remaining battery level:

Notes on Handling AC Adapter Cable

■Charge the battery in a place with an appropriate ambient

temperature of 5°C to 35°C.

■Charge the battery where:

• There is very little humidity, vibration, and dust.

• There are no land-line phones, television sets or radios nearby.

■While

warm. This is not a malfunction, so you can keep on using.

you are

■When using the power outlet having the disengaging

prevention mechanism, observe the instructions given in that instruction manual.

■Do not give a strong shock. Also, do not deform the

charging terminal.

Malfunction may result.

charging, the AC adapter cable may become

Notes on Handling the docomo mini UIM card

■Do

not

apply

or removing the docomo mini UIM card.

more force than is necessary when installing

■The warranty does not cover damage caused by inserting

the docomo mini UIM card into some other types of IC card reader/writer.

■Always keep the IC portion clean.

■Use a dry soft cloth such as the one for cleaning glasses to

clean the docomo mini UIM card.

■It is recommended that you make separate notes of the

information stored on the docomo mini UIM card and keep such notes in a safe place. 　

We take no responsibility for any loss of the stored data items.

■For the environmental protection, bring unneeded docomo

mini UIM cards to a handling counter such as a docomo Shop.

■Do not damage, carelessly touch, or shortcircuit the IC.

Data might be lost or malfunction may result.

■Do not drop the docomo mini UIM card or subject it to

strong impacts.

Malfunction may result.

■Do not bend the docomo mini UIM card or place something

heavy on it.

Malfunction may result.

■Into this mobile phone, do not insert the docomo mini UIM

card with a label or sticker pasted.

Malfunction may result.

Notes on Using Bluetooth Function

2.4FH1

■This mobile phone supports the security function that

meets the Bluetooth Specification, to secure Bluetooth communication. However, the security may not be sufficient depending on the settings. Take care of the security for communication when using the Bluetooth function.

■Note that even if any leak of data or information occurs

while take no responsibility.

making

■With this mobile phone, you can use the following:

Headset, Hands-Free, Audio, and Object Push. With Audio, you might be able to use Audio Video Remote Control. (Only with the compatible Bluetooth devices)

■Radio frequencies

The radio frequencies for the Bluetooth function of this mobile phone are as follows:

connection

using the Bluetooth function, we

2.4 : Indicates radio facilities that use 2400 MHz frequencies.

FH : Indicates modulation is the FH-SS system. 1 : Indicates that an estimated interference distance is

10 meters or less.

: Indicates that all radio frequencies 2400 MHz

through 2483.5 MHz are used, and that the frequencies for mobile object identifiers shall not be avoided.

To use on airplane, confirm with airline company in advance. Use of Bluetooth may be prohibited in some countries. Please confirm laws and regulations applicable in the country/region before use.

■Cautions on Using Bluetooth Devices

Bluetooth operates at house radio stations for mobile object identifiers that have to be licensed and are used in production lines of a factory, specific unlicensed low power radio stations, and amateur radio stations (hereafter, referred to “another radio station”) in addition to scientific, medical, industrial devices, or home electric appliances such as microwave ovens.

1. Before using this mobile phone, make sure that “another radio station” is not operating nearby.

2. If radio wave interference between this mobile phone and “another radio station” occurs, move immediately to another place or turn off power to avoid interference.

3. For further details, contact “General Inquiries” on the back page of this manual.

radio frequencies assigned to the in-

Notes on Handling Wireless LAN (WLAN)

■Wireless LAN (WLAN) has an advantage of any-place LAN

connectivity within the radio wave range as it establishes communication via radio wave. At the same time, however, you have a risk that malicious third party may break without security measures. It is recommended to take security measures at your discretion and responsibility.

into the

network and steal communication contents

■Wireless LAN

Do not use Wireless LAN in a place where magnetized by electric product, AV, OA equipment, etc. or where electromagnetic wave is generated.

• If magnetism or electrostatic noise affects your mobile phone, noise may be increased or communication may not be

available (especially

affect your mobile phone).

• Using near TV or radio may cause poor reception or TV screen may be disturbed.

• When multiple wireless LAN access points exist near your mobile phone and they use the same channel, search may not be performed correctly.

when using microwave oven, it may

■Radio frequencies

2.4DS/OF4

The radio frequencies for WLAN devices are written on battery compartment of your mobile phone. Label description are as follows:

2.4 : Indicates radio facilities that use 2400 MHz frequencies.

DS/OF : Indicates modulation is the DS-SS/OFDM system. 4 : Indicates that an estimated interference distance

is 40 meters or less.

: Indicates that all radio frequencies 2400 MHz

through 2483.5 MHz are used, and that the frequencies for mobile object identifiers shall be avoided.

Available channels vary depending on countries. To use on airplane, confirm with airline company in advance.

of wireless

Use confirm laws and regulations applicable in the country/region before use.

LAN may be prohibited in some countries. Please

■Cautions on Using 2.4 GHz Devices

The bandwidth of the WLAN devices is assigned to the inplant radio stations in production lines of a factory (a license is required), specified low power radio stations (a license is not required), or amateur radio stations (a license is required), in addition to home electric appliances such as a microwave oven, industrial/scientific/medical devices.

1. Before using this device, confirm that in-plant radio stations power radio stations or amateur radio stations are not in operation in your neighborhood.

2. If this device generates harmful radio wave interference against in-plant radio stations for identification of mobile or stop using wireless LAN function, and contact “General Inquiries” on the back page of this manual, then consult about treatment for prevention of the interference (for example, installation of partitions etc.).

3. If this device generates harmful radio wave interference against in-plant radio stations for identification of mobile objects or amateur radio stations, or if any trouble occurs, contact “General Inquiries” on the back page of this manual.

for identification

objects, immediately

for identification of mobile objects used

of mobile objects, specified low

change the radio frequency

Notes on Handling the FeliCa Reader/Writer

■The FeliCa reader/writer function on this mobile phone

uses very weak radio waves which do not require to be licensed as radio stations.

■The FeliCa reader/writer is operated on the 13.56 MHz

frequencies. take enough distance between your mobile phone and the reader/writer. Further, ensure that there are no radio stations that use the same frequencies.

When you

use another reader/writer nearby,

Caution

■Do not use the modified mobile phone. Using a modified

mobile phone infringes the Radio Law.

The

mobile

certification as the specified radio equipment under the Radio Law and bear a “technical conformity mark

nameplate as evidence of conformity. Unscrewing the mobile phone and modifying internal components void the technical regulations conformity certification. Do not use the mobile phone in this state, which infringes the Radio Law.

phones

are granted technical regulations conformity

” on the

■Take special care not to operate the mobile phone while

driving.

Holding a mobile a fine or other penalties. However, this does not apply in unavoidable circumstances when, for instance, rescuing someone who is sick or injured or when maintaining public order.

phone in your hand while driving is subject to

■Use the FeliCa reader/writer functions in Japan only.

The FeliCa reader/writer functions on this mobile phone have been authorized in compliance with the radio transmission standards in Japan. You might be imposed punishment if you use them overseas.

■Do not make any unauthorized or unsanctioned changes

to the basic software.

Such changes will be construed as remodeling and, as a result, requests to repair faults may be denied.

Waterproof Performance

Your P-02D comes with the waterproof performance equivalent to IPX5*1 and IPX7*2 with the connector terminal

cover and back cover firmly closed and no clearance gap and float found in them.

*1 IPX5 means that the P-02D maintains its performance as a

phone even after mobile phone from all directions under conditions where water in a volume of 12.5 liters/minute is sprayed from a distance of about 3 meters for at least 3 minutes using a water-pouring nozzle with an inside diameter of 6.3 mm.

*2 IPX7 means that the P-02D maintains its performance as a

phone even after the phone has been gently submerged in

container of

a temperature, and left in place for about 30 minutes, and then removed from the water.

a water jet flow has been sprayed over the

still city water to a depth of 1 meter at room

(Note) This does not mean that the waterproof performance is

guaranteed in all given conditions of actual use. Read this manual thoroughly before use to prevent invasion of water or foreign materials and then to enable you to safely use your mobile phone.

You can operate the mobile phone in the rain, in your kitchen, in the bathroom, and also around poolside.

■In the Rain

• You can talk on the mobile phone by holding the mobile phone the rain

in mm/hour of rainfall, and your feet get wet by drops of rain rebounded off the ground)

* When your hands are wet or water drops remain on the mobile

phone, do not attach/remove the back cover, nor open/close the connector terminal cover.

with your wet hand without umbrella. (Less than 20

■Wash

Soap/detergent

Sea/pool

Spa/bath salts

• When the mobile phone gets dirty, you can

slowly swing and wash it in a bowl filled with fresh water temperature, or wash it by hand while running a slightly-weak water flow from a faucet.

• Wash your mobile phone with the back

cover firmly attached and while you are pushing down.

• Do not use brushes, sponges, soaps, or detergents for

washing.

• After rinsing off the mobile phone in water, wipe its surfaces

thoroughly allow the mobile phone to dry out naturally.

the cover

using a

or tap water at an ambient

of the connector terminal

dry cloth, drain off the water (Z P.40), and

■On Leisure

• Do not soak or drop your mobile phone into

a pool or the sea nor operate it in water.

• If pool water or seawater splash the mobile

phone, wash the the prescribed method (Z P.34).

mobile phone by following

■In the Bathroom

• Do not soak or drop your mobile phone into

a bathtub, nor use it in water.

• Do not soak the mobile phone into spa or

water containing soap detergent or bath additive.

• Do not directly expose to the strong water

flows (such as water jets from a faucet or shower the skin) that exceed the standard.

• Avoid using the mobile phone for a long time in the bathroom.

• If you take your mobile phone from a cold place to a warm

bathroom, condensation might result because of sudden change in ambient temperature. Warm it up until ambient temperature is restored, and then take it to the bathroom.

head strong

enough to feel pain on

■In the Kitchen

Hook

• Do not spray liquids other than fresh water or tap water at

room temperature onto the mobile phone or soak it in them.

• Do not spray hot water or cold water onto the mobile phone or

soak it in them.

Important Information before Use

• Before using the mobile phone, make sure that you attach the

back cover firmly after tightly closing the connector terminal cover. of sand) between the covers and the mobile phone, water could find its way inside the mobile phone. When attaching the back cover after closing the connector terminal cover, ensure that there is no particles or dirt on or around these parts (especially the packing).

• Ensure that the connector terminal cover and back cover are

closed tightly and that none of these covers are askew. If the covers are not closed tightly, water could find its way inside the mobile phone.

• To keep the waterproof performance, you need to replace

parts without fail once two years regardless whether any abnormality with the mobile phone is found or not. You are charged for replacement of parts. Take your mobile phone to a repair counter specified by DOCOMO.

If there

is any small particles (fine fibers, hair or grains

Opening the Connector Terminal Cover

Hook your fingertip over the groove, pull out the cover to direction of the arrow

Closing the Connector Terminal Cover

Base

Align the connector terminal cover in parallel with the mobile phone, and while holding its base part firmly, push it into place

Ensure that no float is found with the connector terminal cover as a whole

Removing the Back Cover

From the " " part on the mobile phone, lift the back cover up in the direction of the arrow mark, and remove

• The back cover should be firmly closed for

maintaining waterproofness. Opening the cover forcibly may injure your nails or fingers.

Attaching the Back Cover

Claws

Rear surface of back cover

Packing

Align the claws of the back cover with the mobile phone securely, insert in direction 1 and press

down in direction 2

Firmly push the seven ○ marks on the back cover, and ensure that no float is found anywhere on the cover

Caution

■About mobile phone

• Do not wash the mobile phone with a washing machine or

ultrasonic cleaner.

• Never charge the battery when it gets wet.

• Do not leave the mobile phone with drops of water remained

on.

• The connector terminal might be short-circuited.

• Water might enter into the inside of the mobile phone through mobile phone might freeze, resulting in malfunction.

If the mobile phone gets wet, keep the back cover attached and

the connector terminal cover closed, drain off the water (Z P.40), and immediately wipe off the moisture remaining on the mobile phone with a clean dry cloth.

• Do not drop the mobile phone nor give a shock to it. The deterioration of the waterproof performance might result depending on the damage.

• Do not soak the mobile phone in hot water, use in a sauna, nor expose to hot wind currents such as those of a dryer.

• This mobile phone does not float on water.

• Do not directly expose to the strong water flows that exceed the standard or submerge the mobile phone in water.

• Do not directly place the mobile phone on sandy beaches.

• Sands enter into the holes on the microphone, earpiece, or speakers may reduce the volume.

• If you operate the mobile phone with water drops or sands adhered to, sound might be deteriorated.

• Even the slightest sands entered from the connector terminal inside of the mobile phone.

the keys etc. In cold districts, drops of water on the

cover or back cover could cause water to enter the

■About the connector terminal cover and back

cover

• Do not open or close them with gloves put on hands. Fine dirt might adhere to the contact surface of the packing.

• Be careful that no fibers adhere to the packing when you try to wipe off moisture with a clean dry cloth.

• Do not peal the packing off. Also do not insert something pointed at the head into the clearance of the connector terminal cover. The packing is damaged, resulting in water to enter into the mobile phone.

• If the packing for the connector terminal cover is damaged or deformed, replace them at a repair counter specified by DOCOMO.

• If the back cover is broken, replace it with new one. Otherwise liquid through broken portions, and an electric shock or corrosion of the battery pack could result.

• When the mobile phone gets wet with the connector terminal cover or back cover left open, water enters inside, and an electric is, but turn off the power, remove the battery pack, and then take it to a repair counter specified by DOCOMO.

such as

shock or

water enters into the inside of the mobile phone

malfunction could be caused. Do not use it as

■About microphone, earpiece, and speakers

• Do not thrust something pointed at the head into the holes on microphone, earpiece, or speakers.

• Do not leave water drops adhered to them. It might happen that communications are disabled.

■Others

• Accessories and optional items are not waterproofed. When

watch 1Seg

you the desktop holder provided, do not operate it in a bathroom, shower room, kitchen, or lavatory where water is used, even if you do not connect to AC adapter cable.

• It is not that the waterproof performance is guaranteed in all given conditions of actual use. If the damage is found to be caused our inspection, the guarantee is not supported.

by your

programs with your mobile phone attached to

mishandling of the mobile phone as a result of

Draining Water

• If you operate the mobile phone with water drops left adhered to,

the volume

sound quality vary.

• Moisture may have entered inside through the clearance gap of the keys etc.

Follow the procedures described below to wipe moisture off the mobile phone:

Wipe completely moisture off the surface of the mobile phone with a clean dry cloth

level from the speakers might be decreased or

Securely take hold of the mobile phone, and firmly swing each

surface at least 20 times until

no moisture sprays off

Lightly push the mobile phone against a clean dry cloth, and wipe moisture off the clearance gap of the microphone, earpiece, speaker, or keys etc.

• Do not directly wipe moisture out of joint gap using a cotton swab, etc.

Fully drain moisture and then operate the mobile phone

• Even when you follow the procedures for draining water as described

above, moisture might remain in the mobile phone. Therefore, use the mobile phone after allowing it to dry out naturally. Also, take care to keep any objects you do not want to get wet away from the mobile phone since water may leak out from the mobile phone.

When Charging Battery

Accessories and optional items are not waterproofed. Check the following before and after charging:

• Never charge the battery with the mobile phone left wet. If the mobile phone gets wet, drain and wipe off moisture with a clean dry cloth and then charge.

• When you charge the battery with the connector terminal cover open, firmly close it after charging. To prevent water from entering inside through the connector terminal, you are advised to use the desktop holder provided for charging.

• Do not touch the AC adapter cable and desktop holder with your hands wet.

• Do not use the AC adapter cable and desktop holder in a bathroom, used.

shower room,

kitchen, and lavatory where water is

Preliminary Check

6 7

9 0

(

)

Part Names and Functions

Name Description

1 Charging terminal - 2 Strap hole - 3 Earpiece You can hear voice of the other party

from this part.

4 Light sensor Detects ambient brightness to

automatically adjust the screen brightness. In order for the sensor to detect the brightness, do not cover it with your hand or attach a seal on it.

Proximity sensor A sensor that prevents false operation of

the touch panel during call. Protective seat or seal attached on the proximity sensor may cause malfunction of the sensor.

5 Display (Touch

panel)

Slide your finger to scroll the screen, or tap an item to select it (Z P.57).

6 Microphone Send your voice from this part. Serves as

a microphone when recording sound.

7 A Menu key Display the option menu available in the

current screen.

8 Call/Charging

indicator

Flashes when the mobile phone receives a call or sp-mode mail message. Lights during charging.

9 C Back key Return to the previous screen. 0 B Home key Return to the home screen (Z P.

78). Press and hold this key to display recently-used applications.

! 1Seg antenna

Extend this antenna when you watch 1Seg (Z P.216).

" H Power key Press and hold this key for at least two

seconds to turn

the power on (Z P.55).

To press and hold this key for at least one second when the power is on, set/cancel the Silent mode or Airplane mode, or turn the power off. Set/cancel the Sleep mode (Z P.55).

Name Description

# E / F Volume keys Adjust the volume of the other party’s

voice or sound from the speaker (Z P.111, P.140).

$ L Shutter key Activate the camera (Z % Connector

terminal

Connect the included microUSB cable for charging, or the included Earphone Plug

P.197).

Adapter (sample).

& Kmark An IC card is installed. By holding this

mark up to a reader, you can use the Osaifu-Keitai functionality. You can also send and receive data via iC communication if you download an application

that

supports

it. Note that the

IC card cannot be removed.

' Flash Lights at the time of shooting with the

camera.

( Back cover Do not peel off the sticker on the rear

surface of the back cover. If you peel it off, IC card

may not be written and read.

) FOMA antenna The antenna is embedded in the main

unit. Do not cover this part with your hand, as it may impair antenna quality.

- Wi-Fi/

Bluetooth/GPS antenna

The antenna is embedded in the main unit. Do not cover this part with your hand, as it may impair antenna quality.

a Speaker From this part, you can hear

ringtones, music and the other party’s voice during hands-free call.

b Camera Shoot still images and videos (Z P.196). c Infrared data port Used for infrared communication (Z

P.183

docomo mini UIM card

Tab

The docomo mini UIM card is an IC card that holds your information such as phone number. Unless the docomo mini UIM card is installed, you cannot use the mobile phone’s communication features such as call, messaging and data communication.

• Only the docomo mini UIM card is usable with this mobile phone. If you have a DOCOMO UIM or UIM, bring it to a docomo Shop to replace.

• For details about the docomo mini UIM card, refer to the Instruction Manual of the docomo mini UIM card.

Installation/Removal of docomo mini UIM card

• Installation/removal of the docomo mini UIM card should be performed removed (Z P.49).

with the

mobile phone turned off, the battery pack

• Be careful not to touch or damage the IC part when handling the docomo mini UIM card. Attempts to install/remove the docomo mini UIM card forcibly may damage the docomo mini UIM card.

Installing docomo mini UIM card

Pulling the tab, slowly pull the tray out until it stops

• The tray cannot be removed, so be sure not to pull the tray You may damage the tray or the tab if you do so.

beyond the position at which it stops.

Insert the docomo mini UIM card into the tray

Corner cut

with the gold IC part facing down

• Insert the docomo mini UIM card so that the cut is in the corner of the tray on the right.

Push the docomo mini UIM card all the way in

• Push the tray inward firmly until it is in place.

Removing docomo mini UIM card

Following the step 1 in P.45 "Installing docomo mini UIM card", pull out the tray and then remove the docomo mini UIM card

• After pulling out the tray until about half of the docomo mini UIM card is visible, pull out the docomo mini UIM card by sliding it out.

About Security Codes for docomo mini UIM card

Two security codes are provided for the docomo mini UIM card: PIN1 code and PIN2 code (Z P.145).

microSD Card

• This mobile phone supports microSD cards of up to 2 Gbytes and microSDHC cards For the latest information on supported microSD cards including manufacturers and storage capacities, refer to the following website. For microSD cards not listed on the website, please consult the manufacturer of the microSD card in question. http://panasonic.jp/mobile/ (in Japanese only) Note that since the information in the website has been obtained by checking of some operations, not all operations are guaranteed.

Installation/Removal of microSD Card

• Installation/removal of a microSD card should be performed with the mobile phone turned off, and the battery pack removed (Z P.49).

of up to 32 Gbytes (as of October 2011).

Installing microSD Card

Insert the microSD card into the microSD card slot with the metal terminal facing down in the direction indicated in the illustration until it locks

• Securely insert the card until it clicks.

Removing microSD Card

• Note that the microSD card may pop out when you remove it from the mobile phone.

Lightly press in the microSD card

The microSD card comes out a bit.

Pull out the microSD card straight

Battery Pack

Arrow marks

Projection

Installation/Removal of Battery Pack

• Installation/removal of the battery pack should be performed with the mobile phone turned off, and the back cover removed (Z P.36).

Installing Battery Pack

With the arrow marks facing up, fit the battery pack to the tab side of the mobile phone securely, and then push the battery pack in direction 2

while pressing it against direction 1

Removing Battery Pack

Lift the battery pack in the direction of the arrow using its projection

Charging

■ Precautions for charging

• The included AC adapter plug shape is designed for 100V AC (domestic specification). To charge the battery abroad, a corresponding plug adapter transformer for overseas trip.

• If you charge the mobile phone while using it, it may take more time to fully charge the battery or charging may not be completed. Continuous use of functions consuming large current, such as data communication and call, may decrease battery level even during charging, leading to battery drain.

• If you start charging when the battery is empty, the mobile phone this case, start charging with the mobile phone off and turn it on after a while.

• When the temperature failure icon appears in the status bar, functions shown in the notification panel are disabled.

• When the charge failure icon appears in the status bar, open the notification panel and take appropriate actions.

• If you leave the mobile phone being charged for long time, the mobile phone consumes power from the battery pack after completion of charging, so the usable time may be shortened and alert of empty battery may be displayed soon. In such a case, start charging the battery again in correct manners. For recharging, disconnect the AC adapter cable (or included desktop holder) from the mobile phone and then connect it again.

may not

start up promptly after power-on operation. In

is required. Do not use an adapter

■ Battery pack operating life

• Battery pack is a consumable item. Usable time per charge gradually decreases with repeated charging.

• When its usable time per charge is decreased to about a half

that from

of end of life. So you are recommended to replace with new one soon. Depending on how the battery pack is used, it might swell as its remaining life becomes short, but this is not a problem.

the time of purchase, the battery pack is near the

• Continuous 1Seg watching while charging may shorten the

To prevent damage to the environment, bring used battery packs to a docomo service counter, a docomo agent or a recycle center.

AC adapter

Power plug

USB plug

microUSB plug

microUSB cable

Desktop holder

Call/Charging indicator

Lock claw

battery pack operating life.

Charging by Using Desktop Holder

Insert the provided microUSB plug of microUSB cable horizontally into the terminal of the

desktop holder with USB mark ( ) facing up

Insert the USB plug of microUSB cable horizontally into the USB connector of AC adapter with USB mark faced with you

Unfold the power plug of AC adapter, and plug it into a household outlet of 100 V AC

Put the mobile phone into the desktop holder 1, and then,

lining up the mobile phone with the

lock claws, depress the mobile phone inwards until it clicks 2

• Check the orientation of the mobile phone, and ensure that it is inserted firmly into the desktop holder. Also, be

careful that a commercial strap is not caught between the mobile phone and desktop holder.

When charging is completed, hold the desktop holder with fingers and tilt the mobile phone forward to remove

Information

• You cannot charge the battery by using a microUSB cable to connect the desktop holder to a computer.

■ Charging and charging completed indications

● When the mobile phone is turned on

Call/Charging indicator Battery icon

Charging Lights as follows

according to the battery level. 89% or less: Red 90% or more: Green

Charging completed

Lights in green

Indications are switched from the current battery level up to level 6.

Level 4 Level 3 Level 2 Level 1

Level 6 Level 5

● When the mobile phone is turned off

Call/Charging indicator

Charging Lights in red Charging completed Turns off

• The battery icon is not displayed when the mobile phone is turned off. The call/charging indicator may not light promptly when you start charging with the battery in empty state. However, charging has been started. If the call/charging indicator from the mobile phone and then reinstall it before charging again. If the symptom recurs, the AC adapter, desktop holder and battery pack may be failed. Contact a handling counter such as a docomo Shop.

does not

light after a while, remove the battery pack

■ When the battery has almost run out

When the battery starts running out, a message that prompts you to charge appears. When the battery level decreases further, the call/charging indicator flashes slowly in red. When the battery becomes empty, a message that the power is turned off shortly appears and then it is turned off.

Charging by Using AC Adapter Cable

AC adapter

Power plug

USB plug

microUSB plug

microUSB cable

Connector terminal cover

Insert the provided microUSB plug of microUSB cable horizontally into the connector terminal

with USB mark ( ) facing up

• To open the connector terminal cover, Z P.35

Insert the USB plug of microUSB cable horizontally into the USB connector of AC adapter with USB mark faced with you

Unfold the power plug of AC adapter, and plug it into a household outlet of 100 V AC

When charging is completed, pull out the power plug of AC adapter from the outlet

Remove the microUSB cable from the AC adapter and the mobile phone

Charging by Using a PC

This mobile phone can be charged from a PC when you connect the mobile phone and a PC using the included microUSB cable.

• For how to connect the mobile phone to a PC, Z P.194

Power On/Off

Turning Power On

Press and hold H for at least two seconds

The lock screen appears after a while.

Turning Power Off

Press and hold H until Phone options menu appears

• Holding H for 10 seconds or more forcibly turns

off the power.

[Power off] W [OK]

• Wait for a while, as it may take some time before the power is turned off.

When Display Goes Off

If this mobile phone is not operated for a certain period of time, the display automatically goes off and the mobile phone enters the Sleep mode.

H / B

The Sleep mode is canceled and the lock screen appears.

• To enter the Sleep mode manually, press H when the display is on.

Unlocking Lock Screen

Lock screen

Tap

Basic Operations (How to Use Touch Panel)

Touch Panel Operations

The display of this mobile phone is a touch panel, which is operated by direct touch with fingers.

• Before use, peel off the protective sheet which is stuck on the touch panel at the time of purchase.

• The touch panel is designed to be touched lightly with a finger. Do not press it strongly with a finger or pointed objects such as fingernails, ballpoint pens, and pins.

• In the following cases, the touch panel may not work even if you touch it. Also, following operations may cause a malfunction.

• Operation wearing gloves

• Touching with a fingernail

• Operation with foreign objects placed on the operation surface

• Operation on the touch panel on which a protective sheet or a sticker is put

• Operation when the touch panel is wet

• Operation when your fingers are wet, such as from sweat or water

■ Tap

Tap an item or icon on the screen to select it.

■ Double-tap

the screen

Tap again to zoom out.

twice quickly to zoom in the web page. Double-tap

■ Touch and hold

Keep an item or icon on the screen touched with your finger for a while. Do this to display a pop-up menu, etc.

■ Flick

When there are multiple pages or more contents your finger right or left across the surface of the screen to show the previous/next screen.

outside the

screen, quickly move

■ Drag

Move an item or icon on the screen while holding it with your finger.

■ Scroll

Slide your finger up/down or right/left on the screen to show the hidden part.

■ Pinch (spread apart/pinch together)

Placing two fingers on the screen, spread them apart to zoom in, or pinch them together to zoom out, when a web page or still image is displayed.

Switching Vertical/Horizontal Display Modes

The motion sensor, the mobile phone, allows you to switch display modes by holding the mobile phone in vertical or horizontal orientation.

which detects orientation and motion of

Information

• Operate the mobile phone in nearly upright state. If the mobile phone lies flat, the sensor cannot detect a change in orientation and motion properly, and the display modes may not be switched.

• Changing the mobile phone’s orientation may not switch display modes depending on the screen displayed.

Screen Display/Icons

Status bar

Icon Definitions

Icons that indicate the mobile phone status are displayed in the status bar. Notification icons are displayed on the left part while status icons are displayed on the right part of the status bar.

■ Main notification icons

Icon Description Refer to

New Gmail P.171

New Email P.168

New sp-mode mail P.163

New message (SMS) P.165

Failure to send message (SMS) P.164

Voice Mail message P.121

New instant message P.175

Calendar event P.233

Music playing P.209

Wi-Fi open network available P.100

Incoming file via Bluetooth communication P.189

VPN connected/disconnected P.192

USB connected P.194

USB tethering in use P.131

Wi-Fi tethering in use P.132

Both USB tethering and Wi-Fi tethering in use P.131

P.132

Error message -

During call P.104

Missed call P.112

Icon Description Refer to

Call on hold P.111

P.124

Data upload -

Data download -

Application installed from Android Market P.211

Update of Android Market application available P.211

Hidden notification P.63

microSD card unmounted P.157

1Seg notification P.217

Connecting to data broadcast security page P.217

eco mode P.237

Temperature failure P.50

Charge failure P.50

■ Main status icons

Icon Description Refer to

Radio wave strength -

Roaming P.243

Out of service area -

Connecting to GPRS P.246

GPRS in use P.246

Connecting to EDGE P.246

EDGE in use P.246

Connecting to 3G (packet) P.246

3G (packet) in use P.246

Airplane mode P.130

Connecting to Wi-Fi P.100

Bluetooth ON P.187

Bluetooth device connected P.187

Icon Description Refer to

Data sync P.152

Osaifu-Keitai lock set P.227

docomo mini UIM card not installed P.45

Alarm set P.230

Speakerphone ON P.111

Microphone mute P.111

Silent mode (vibration ON) P.139

Silent mode (vibration OFF) P.108

Charge required P.50

Low battery P.50

Sufficient battery P.50

Charging P.50

GPS positioning P.143

*1 Network icons appear in white when Google account is not

set or [Background data] in Accounts & sync settings is unmarked.

Notification Panel

ひつじのしつじくん

©NTTDOCOMO

When notification icons are displayed, you can open the notification panel to check notifications of messages, Calendar events, and so on.

Opening Notification Panel

Drag the status bar downward

• Tap a notification to check details or configure necessary settings.

• Tap [Clear] to clear all items in the notification panel. However, some items may not be cleared.

Closing Notification Panel

Drag the bar at the bottom of the notification panel upward, or press C

Character Entry

With this mobile phone, you can enter characters by tapping the text entry field and using the keypad displayed. You can also enter characters with handwriting.

Switching Input Method

Any of three input methods can be used to enter characters with this mobile phone.

Touch and hold the text entry field

[Input Method] W [Android keyboard]/[Fit Key]/[Quick Handwriting]

Entering with Fit Key

You can select from the two keypad types below:

■ Ten-key keypad

Used for Japanese Kana input.

■ QWERTY keypad

Used for Japanese Romaji input.

Entering Characters with Ten-key Keypad

Tap the text entry field W Touch and hold in the keypad

[10-key ⇔ QWERTY]

8 9

2 3

4 5

• To close the keypad, press C.

1 Indicates the currently used input mode.

: Hiragana-Kanji : Full-width Katakana : Half-width Katakana : Full-width Alphabet : Half-width Alphabet : Full-width Numeric : Half-width Numeric : Pictogram/Symbol

2 Display characters in reverse order.

Tapping the key right after confirming entered characters returns the characters to unconfirmed state.

3 Move the cursor right/left. 4 Switch to Pictogram/Symbol input modes. 5 Alphabet/Numeric/Kana input modes are switched each time

the key is tapped. Touch and hold the key W [10-key ⇔ QWERTY] between ten-key

keypad and QWERTY keypad for each input

to switch

mode. Touch and hold the key W [Input Mode] to switch Full-width/ Half-width.

6 The character assigned to the key concerned is input.

Tap a key repeatedly until desired character is displayed, or touch and hold a key and flick to desired character.

7 Delete a character at the left of the cursor. 8 Insert a space.

When

this key

is tapped with characters entered, conversion

candidates are displayed.

9 Confirm entered characters or feed a new line.

2 3

6 7

The function now

activated is executed using the characters

which have been input.

Entering Characters with QWERTY Keypad

Tap the text entry field W Touch and hold in the keypad

[10-key ⇔ QWERTY]

• To close the keypad, press C.

1 Enter characters indicated on the keys. 2 Switch between uppercase and lowercase characters. 3 Alphabet/Numeric/Romaji input modes are switched each

time the key is tapped. Touch and hold the key W [10-key ⇔ QWERTY] between ten-key

keypad and QWERTY keypad for each input

to switch

mode. Touch and hold the key W [Input Mode] to switch Full-width/ Half-width.

4 Switch to Pictogram/Symbol input modes. 5 Insert a space. 6 Delete a character at the left of the cursor. 7 Confirm entered characters or feed a new line. 8 Move the cursor right/left.

Entering Pictograms/Symbols

3 4

In the Pictogram/Symbol input mode, you can enter Dpictograms, pictograms, symbols or emoticons. You might not the text entry field.

1 Switch D-pictogram/pictogram/symbol/emoticon entering. 2 Scroll the screen up/down and tap a desired D-pictogram/

able

to enter D-pictograms/pictograms depending on

Tap to switch to Pictogram/Symbol input mode

pictogram/symbol/emoticon.

• The pictogram or symbol last used is displayed at the top of the list of D-pictgrams/pictograms/symbols.

3 End Pictogram/Symbol input mode. 4 Scroll the screen up/down.

• On the list of D-pictogram/pictogram, you can scroll the screen up/down on a category by category basis.

5 Delete a D-pictogram/pictogram/symbol/emoticon at the

left of the cursor.

Entering Characters with Handwriting

6 7

Touch and hold the text entry field

[Input Method] W [Quick Handwriting]

Tap the text entry field

1 The types of characters which can be entered are displayed

here.

: Kanji/Hiragana/Katakana/Alphabet/Numeric/Symbol : Hiragana/Katakana/Alphabet/Numeric : Alphabet/Numeric/Symbol : Numeric/Symbol

• The types of characters are switched automatically depending on the application used.

2 Enter characters in input frames with handwriting.

• When a character input frame is pinched out/in, it can be switched to 1 frame, 2 frames or 6 frames.

3 Delete a character at the left of the cursor. 4 Insert a space.

When

this key

is tapped with characters entered, conversion

candidates are displayed.

5 Switch to Pictogram/Symbol input modes.

When this key

is tapped with characters entered, switch Fullwidth/Half-width. To change Quick Handwriting settings, touch and hold the key W [Change Settings].

6 Move the cursor right/left.

• When the cursor is moved during character input, a list of recognition candidates for the handwritten character input is displayed.

7 Confirm entered characters or feed a new line.

The function now which have been input.

activated is executed using the characters

Character Entry Menu

Copy/Cut/Paste

Enter characters W Touch and hold the text entry field

[Select word]/[Select all]

Drag the slider in four directions to select characters W Touch and

hold the text entry field

[Cut]/[Copy]

• When pasting a copied character, move the cursor to the

position where the character is to be

pasted, touch and hold the text entry field W Tap [Paste].

Character Entry Settings

You can configure various settings regarding character entry.

Fit Key Settings

Home screen W A W [Settings] W [Language & keyboard] W [Fit Key]

Perform operations listed below:

Sound on Key Press

Vibrate on Key Press

Key Preview Display key preview. Auto

Capitalization Keyboard

Type Voice Input Set whether or not to use voice input. Flick Input Enable flick input. Flick

Sensitivity Toggle Input Enable toggle input when flick input is enabled. Auto Cursor

Movement

Enable key-tapping sound.

Enable key-tapping vibration.

Automatically capitalize the first character of a sentence in alphabet input mode.

Set keyboard type for each screen orientation and input mode.

Specify flick sensitivity.

Set the speed at which the cursor is to move automatically during character entry.

Input Word Learning

Word Prediction

Typing Error Correction

Wildcard Prediction

Lines of Candidate Area

Mushroom Use mushroom applications. Japanese

User Dictionary

English User Dictionary

Learn converted words.

Display conversion candidates as you enter characters.

Display correction candidates for typing errors.

Predict conversion candidates from specified reading string length.

Set the number of lines to be displayed in the candidate area.

Z P.72

Edit words in English User Dictionary.

Clear Learning Dictionary

Z P.73

Download Dictionary

iWnn IME Version of iWnn IME etc. are displayed.

Set whether to enable dictionaries which were downloaded from websites.

Quick Handwriting Settings

Home screen W A W [Settings] W [Language & keyboard] W [Quick Handwriting]

Perform operations listed below:

Input Input

Method Context

Correction

Automatic Fixation

Inputbox position

Japanese Address Input

Set input frames number.

Set whether to use the context correction function during character recognition.

Set the speed at which the input characters are confirmed.

• This can be set only when 1 frame input has been selected as the input method.

Set input frames position.

• This can be set only when 1 frame input has been selected as the input method.

Enable Japanese on URL/Email address.

Full-width Space

Input

Set whether to input spaces as full-width spaces during character entry.

Conversion Word

Prediction

Display conversion candidates as you enter characters.

Input Word Learning

Recognition Error Correction

User Dictionary

Clear Learning Dictionary

Sound on Operation

Vibration Vibrate on

Sound on Key Press

Writing

Vibrate on Key Press

Learn converted words.

Display the conversion candidates including the recognition error correction candidates.

Z P.72

Z P.73

Enable key-tapping sound.

Set whether or not to vibrate when characters are entered in input frames.

Set whether or not to vibrate when a key is tapped.

Design Background

Color Key

Preview

Initialization Restore the default Quick Handwriting

Quick Handwriting Version of Quick Handwriting etc. are

Set input frames background color.

Enlarge tapped keys during character entry.

settings.

• Not clear learning dictionary and user dictionary.

displayed.

Adding Words to User Dictionary

You can add frequently-used words in Kana input mode to Japanese User Dictionary so that the added words are preferentially shown as conversion candidates when you enter the reading.

Home screen W A W [Settings] W [Language & keyboard]

For Fit Key

[Fit Key] W

[Japanese User Dictionary]

• To add English words used in half-width alphabet input mode, tap [English User Dictionary].

For Quick Handwriting

[Quick Handwriting] W

[Conversion] W [User

Dictionary]

A W [Add]

Tap the text entry field of [Reading] W Enter reading

Tap the text entry field of [Word] W

Enter word

[Save]

Clearing Learning Dictionary

Words and phrases you entered are automatically learned and displayed as conversion candidates by predictive conversion feature. When you clear the learning dictionary, learned is reset to the default status.

words

Home screen W A W [Settings] W [Language & keyboard]

For Fit Key

[Fit Key] W [Clear Learning Dictionary]

For Quick Handwriting

[Quick Handwriting] W [Conversion] Learning Dictionary]

phrases are all cleared and the dictionary

and

[Clear

[OK]

Customizing Fit Key

2 3

6 7 8 9

You can adjust the size and position of the keypad to fit on your hand. In addition, you can decorate the keypad with stamps and change the color, background and key shape.

Tap the text entry field W Touch and hold in the keypad W [Customize]

1 Pallet

Flick right or left to select.

2 Save the edited data. 3 Switch to the stamp setting screen. 4 Switch to the color setting screen. 5 Keypad preview 6 Undo one operation on the keypad. 7 Switch to the package setting screen. 8 Switch to the key shape setting screen. 9 Switch to the background setting screen.

Drag inward/outward the guide icons at four corners of the

keypad preview to define the size

W Drag the keypad preview to define the

position

• When the text entry field is hidden by the keypad or candidate display, you can display the text entry field by reducing the size of the keypad.

To attach stamps

[デコ

(Deco)] W Select a pallet W Tap a stamp to attach W Tap preferred location in the keypad preview to attach the stamp W Perform stamp operations as necessary (Z P.76)

To change color

[カラー (Color)] W Select a pallet

• Drag the slider to adjust color transparency.

• Tap [グラデーション (Gradation) ON/OFF] to switch gradation/solid color.

To change background

[ピクチャ (Picture)] W Select a pallet

• You can select from still images you recently saved in microSD card. To select from other still images, tap [すべて見る (View all)].

•

Tap [背景写真をアクティブ (Activate background photo)]

to adjust position of the still image.

• To shoot a still image for background, tap [カメラ起動(Activate camera)] W

Display the object in

the keypad preview W

To change key shape

[キーパッド (Keypad)] W Select a pallet

To select from packages

[パッケージ (Package)] W Select a pallet

• Tapping [初期状態に戻す (Initialize)]

[Yes] will

reset the keypad to the default state.

• You can receive/send the package via infrared communication by tapping [赤外線受信 (Receive via IrDA)]/[赤外線送信 (Send via IrDA)]

• You can load and select a package from microSD card

by tapping

[SDから読み込み (Load from SD)].

• When you tap [SDに保存 (Save in SD)], the package is saved in Packages folder of KeyboardCustomize folder in microSD card, and given a file name of the saved date and time (e.g., if a package is saved at 10:00:05 a.m. February 16, 2012, the file name of the saved package is “2012-02-16_10_00_05.pkg”).

• You can delete package files saved in microSD card

by connecting this mobile phone to a PC (Z

P.194).

When you finish editing, [保存 (Save)] W [Yes]

Edited data is saved in this mobile phone and reflected in the keypad.

• Five packages can be saved in this mobile phone.

■ Stamp operations in keypad preview

When a stamp stamp.

Operation Procedure

Move Display the stamp guide W Drag the center

Zoom in/out at the same magnification

Increase/ decrease height/ width

is tapped, the stamp guide is displayed around the

of the stamp guide Display the stamp guide W Put your fingers

around the stamp guide to pinch out/in

Display the stamp guide W Drag the stamp guide corner to increase/decrease height/ width

Operation Procedure

Rotate Display the stamp guide W Trace the outer

side of the stamp guide corner in direction you want to rotate

Copy & paste Display the stamp guide W Touch and

hold the center location you want to attach the stamp

• The stamps are attached each time you tap. Tap [コピー (Copy)] to end.

Delete Display the stamp guide W

• You can also delete a stamp by tapping [削除 (Delete)]

Delete all [スタンプ全消し (Erase all stamps)] W [Yes] Paste

consecutively

Tap [連続貼り付け (Paste consecutively)] to select

W Tap a stamp to attach W Trace the keypad

preview

(line)/ (curve) W Select a pallet

of the stamp guide W Tap the

[削除 (Delete)]

W Tap a stamp to delete.

docomo Palette UI

4 5

ひつじのしつじくん

©NTTDOCOMO

Home Screen

Home screen is the start screen from which you can start using applications. Press B to display the home screen. You can choose from the following four home applications: docomo Palette UI, “Fit Home”, Selector” and Launcher. This section describes how to operate docomo Palette UI.

“Touch Speed

1 Indicators

Current location (sheet) within the home screen is indicated. You can use up to 12 sheets and switch the screens (sheets) by flicking the screen right and left. From

[Personal area], you can check information such as your contract details.

2 Quick search box (Z 3 Shortcuts, widgets,

P.81)

folders and groups can be freely placed in

home screens.

4 This part is displayed on all sheets other than [Personal

area]

, and displays the application list screen.

5 Dock

This part is displayed on all sheets other than [Personal area], and shortcuts, folders and groups can be placed.

Information

•

If you change to a different home application, items on the screen such as widgets might not be displayed correctly depending on the home screen layout etc.

■New! icon

New! icon is a mark that notifies of any newly-purchased (downloaded) application. appears above each new application in the

cleared once the application is activated.

home screens and application list screen.

Adding Shortcuts etc. to Home Screen

Home screen W

Touch

• Applications or groups can also be added by touching and holding the target application or group on the application list screen, and then by tapping [Add]

[Shortcut]/[Widget]/[Folder]/[Group]

Select a shortcut etc. to add

Touch and hold a shortcut etc. added to the home screen, and drag it to preferred location

and

hold the background

Changing Folder Name

Tap a folder W Touch and hold the title bar

• You can also change folder name by touching and holding a folder,

Enter folder name W [OK]

and then by tapping [Edit name].

Deleting Shortcuts

Home screen W Touch and hold a shortcut etc. to delete, and drag it into

• When the shortcut is dragged into , the color of the shortcut icon changes to red.

• You can also delete shortcuts by touching and holding shortcuts etc., and then by tapping [Delete].

Changing Shortcuts etc. in a Dock

Home screen W Touch and hold a shortcut etc. and drag it in the dock

• To delete a shortcut in the dock etc. touch and hold the shortcut, and drag it into .

Uninstalling Applications or Widgets

Home screen W Touch and hold an application or a widget to uninstall W [Uninstall] W [OK]

• Applications can also be uninstalled by touching and holding the target application on the application list screen, and then by tapping

[Uninstall]

[OK].

Changing Kisekae of Home Screen

Home screen W Touch and hold

W [Kisekae]

Select a Kisekae W [Set]

the background

Changing Wallpaper of Home Screen

Home screen W

W [Wallpaper]

Touch

and

hold the background

Tap a wallpaper type W Select an image

• If you select an image from ["Picture Album"], select a display method to complete the setting.

• If an image has been selected using [Gallery], decide on the trimming position, and then tap [Save]

[Set wallpaper]

to complete the setting.

Adding Home Screens

Home screen W A W [Home screens] W

• [+] is displayed if the home screen is less than 11 sheets.

Touch and hold the home screen, and drag it to preferred location

• To delete a home screen, touch and hold the home screen, and drag it into .

Searching for Mobile Phone Applications and Web Page Information

Home screen W Tap the entry field within the quick search box

• You can also search by displaying the application list screen W A W [Search].

[＋]

• Press A search target types and settings.

W Tap a search target W Enter keyword

Search candidates that contain characters you just entered appear.

W [Search settings] to change

Application Screen

ひつじのしつじくん

©NTTDOCOMO

Displaying Application List Screen

On the application list screen, the installed applications are displayed on a group by group basis.

Home screen W

1 The group names and number of applications are displayed.

Tap a group to switch between displaying and hiding the application icons.

2 Show the application list for each group.

List of Applications

The following is the list of applications that are preinstalled in the mobile phone at the time of purchase.

• To use some applications may require the separate subscription (charged).

• Before using some applications for the first time, it may be necessary to install them from Android Market.

• Some applications do not work without microSD card. Install a microSD card when using applications.

Icon Application Description Refer to

Book Store MyShelf

DLNA Use Wi-Fi communication to

dmarket This application starts dmarket,

dmenu This application is a shortcut to

Use this application to read electronic books purchased from the dmarket Book Store.

exchange data between DLNA compatible devices.

from which you can purchase music, videos, books, content. Android Market applications are also featured.

dmenu, from which you can easily search for anything from familiar i-mode content to entertaining and convenient content available only for smartphones.

and other

P.190

Facebook Sign in to Facebook for news

feed check, posting, message exchange and photo sharing.

Gmail Exchange mails of Google

account.

P.170

Icon Application Description Refer to

Gガイド番組表 (G-Guide EPG)

View electronic program guide of terrestrial and

BS broadcasts. You can search programs by keyword or category, set timer for watching/recording 1Seg broadcasts, and record remotely when you are out.

iD設定アプリ (iD appli)

This application performs settings for use with iD electronic money services.

ｉチャネル (ichannel)

An application, which allows you to use i-channel.

Latitude Share location information with

friends on a map.

Polaris Office View Office documents and PDF

files.

SD-Video Play back 1Seg recording data

or videos recorded with a Bluray Disc recorder.

P.242

P.214

P.240

－

spモードメール (sp-mode mail)

Exchange mails using docomo mail address (@docomo.ne.jp). You can use Pictograms and Deco-mail, and automatic reception is also supported.

Twitter A Twitter official client

application. Post short messages on the website and communicate with people.

YouTube You can play videos from and

post files to YouTube.

Anshin Scan An application protects your

mobile phone from damage of virus. Search virus hidden in installed applications or in a microSD card, etc.

ECONAVI By adjusting various settings

such as display brightness, an application sets "eco mode" to reduce battery consumption.

P.163

P.229

P.237

Icon Application Description Refer to

Area Mail An application, which allows you

P.173 to receive Early Warning "Area Mail", or check received Area Mail messages.

AUTO-GPS Use this application to access

－ services that support AUTOGPS, giving you information about the surrounding area, such

as the weather and nearby shops, sightseeing, and other information based on your location.

Osaifu-Keitai You can use Osaifu-Keitai. P.225

Camera Shoot still images and videos. P.196

Calendar Manage schedule. P.232

Gallery View still images and videos. -

Schedule Create/manage a schedule. -

Downloads Files downloaded from websites

are listed.

Talk You can chat with people using

Google Talk.

docomo backup Back up and restore the

phonebook data etc.

docomo location information

This application provides location information, including imadoco search, imadoco kantan search, Keitai-Osagashi Service, and Emergency Location Report. You can change the various settings

and access

sites related

to settings and services.

ToruCa Inport/view/find/update etc.

ToruCa data.

P.180

P.175

－

P.228

Navigation Direction to the destination is

provided.

P.214

Icon Application Description Refer to

バーコードリーダー (Barcode

Read barcodes and QR codes with the camera.

Reader) Picture Album Perform such operations as

displaying still images

and video separated into categories by person or year and month, or using Picture jump to upload files.

PicMate Upload still images and video to

PicMate, the photo-sharing site by Panasonic. You can create an album from the files you upload, and share the album.

Browser You can browse web pages as

you do with a PC.

P.238

P.205

－

P.178

Places Search for stores and facilities

P.213

near your location by category.

Home Switcher An application, which allows you

to switch home applications.

Market Use Android Market. P.211

Machi-chara This application displays a

－ character on the screen of the mobile phone. This character moves around on the widgets and

gives

information, such

you as notifications of receiving a mail or incoming call etc.

Maps You can locate your current

P.213 position, and search for places and routes to destinations.

Email Exchange Emails with PCs, etc. P.167

Messaging Exchange messages (SMS). P.164

Media Player Play music and video. P.209

Memo Create/manage notes. P.235

Icon Application Description Refer to

Mobage An application, which allows you

to enjoy content provided by Mobage.

1Seg You can watch 1Seg. P.215

Voice Search Search for web page

information by voice input.

Google Search Search for mobile phone

P.81 applications and web page information.

声の宅配便 (Koeno-Takuhaibin)

This applications allows the simple and convenient use of

P.127

"Koe-no-Takuhaibin" by smartphone. You can record and play voice messages using simple commands.

災害用キット (Disaster kit)

Store or check messages etc. on Disaster Message Board.

Infrared An application, which allows you

P.183 to exchange data such as Phonebook etc. via infrared communication.

Settings Configure various settings of

P.129 this mobile phone.

地図アプリ (Map appli)

This application provides maps, a search function for stores and

facilities, navigation, public transportation timetables, a record of places visited, and other functions to support you when you go out.

Calculator You can perform calculations

P.236 such as addition, subtraction, multiplication and division.

Phone Make phone calls. P.104

Phonebook Add and manage contacts in the

phonebook.

P.113

Icon Application Description Refer to

PhoneBookCopy Using an external recording

medium such as a microSD card, you can move or copy your phonebook.

Clock On the clock screen, different

types of information and shortcuts are shown along with the time. You can also set alarms.

Instruction Manual

Name card creator

Instruction manual for this mobile phone. You can activate required functions directly from relevant descriptions.

Use this application to create an original name card, which is displayed in the My profile section of the "Phonebook" application.

P.118

P.230

P.2

－

Reservation and recording

Reserve times to watch or record 1Seg broadcasts. You can also play back recording data.

P.224

Moving an Application

Application list screen W Touch and hold the application, and drag it to preferred location

Adding Groups

Application list screen W A W [Add group]

Enter a group name W [OK]

Touch and hold the group, and drag it to preferred location

• To change the name or color of a group, touch and hold the group, and then tap [Edit name]/ [Edit label]

• To delete a group, touch and hold the group, and

[Delete].

tap

Changing the Layout of the Application List Screen

Application list screen W A W [List format]/ [Tile format]

Home Application Settings

Home screen W A W [More] W Perform operations listed below:

Home settings Set Sync function etc. Help Display help information about home

application.

Application info Display the version of home application etc.

Initial Setting

When time after purchase, configure settings for Google account and GPS positioning by following the on-screen instructions.

you

turn

on the power of this mobile phone for the first

[言語変更] W [English (United States)]

• During initial setup, when the [機能バージョンアップ (Update features)]

guide screen appears, tap [OK] to configure docomo service settings. After doing so, the display will return to the previous screen, and you can continue with operation.

Tap the Android logo W [Create]

• If you already have a Google account, tap [Sign in].

• If you do not set a Google account, tap [Skip].

Enter your first name, last name, and desired username (part before @gmail.com) for the Google account W [Next]

Enter a password W Enter the password again for confirmation W [Next]

Select a security question W Enter answer

in the

answer field W Enter a mail address you already have in the secondary Email field

• In case you forget your password, you can make it sent to your secondary mail address by matching

the security

question and answer in the

Google website.

[Create]

Read Google Terms of Service W [I agree, Next]

Enter characters indicated in the picture

W [Next]

Read the note about Google location service

W [Next]

• To make your data backed up in the Google server with your Google account, mark the checkbox.

[Next] W [Finish setup]

Changing Screen Display to English

If you have not changed the display language to English in the initial setting, you can do it by following the steps below.

Home screen W A W [本体設定] W [言語とキーボード] W States)]

[言語を選択] W [English (United

Google Account

Once Google account is set, you can download applications from Android Market. If you already have your own Google account, you can use the existing account with this mobile phone.

Home screen W A W [Settings] W [Accounts & sync] W [Add account]

[Google] W [Next] W [Create]

• If you already have your own Google account, tap [Sign in].

Take step 3 to 8 in P.91 "Initial Setting"

Mark data items to be synced W [Finish] W [Finish setup]

Setting Access Point

Access points for Internet connection (sp-mode and mopera U) are added by default. You can add and modify access points as necessary.

• By default, sp-mode is selected as default access point. However, the settings may differ depending on the terms set forth in your contract.

Checking Access Point in Use

Home screen W A W [Settings] W [Wireless & networks] W

[Mobile networks] W [Access

Point Names]

Setting Additional Access Point

• Do not change MCC to other than 440, or MNC other than 10. If you change MCC/MNC, the access point will no longer be displayed on the screen.

Home screen W A W [Settings] W [Wireless & networks] W Point Names]

A W [New APN]

[Name] W Enter the name of network profile to create W [OK]

[Mobile networks] W [Access

[APN] W Enter an access point W [OK]

Enter other items required by the network operator W A W [Save]

• If MCC or MNC has been changed and the access point is not

displayed on the screen, reset access point settings to the default status, or manually configure the access point.

Resetting Access Point

Resetting the access point restores the default status.

Home screen W A W [Settings] W [Wireless & networks] W

[Mobile networks] W [Access

Point Names]

A W [Reset to default]

sp-mode

sp-mode is an ISP for NTT DOCOMO smartphones. In addition to the Internet connection, you can use mail service with the same mail address (@docomo.ne.jp) as that of the i-mode. sp-mode is a pay service requiring subscription. For details of sp-mode, refer to DOCOMO website.

mopera U

mopera U is NTT DOCOMO’s ISP. Subscribers for mopera U can use the Internet with simple settings. mopera U is a pay service requiring subscription.

Setting mopera U

Home screen W A W [Settings] W [Wireless & networks] W [Mobile networks] W [Access Point Names]

Mark [mopera U (スマートフォン定額) (flat-rate for smartphone)]/ setting)] checkbox

[mopera U設定 (mopera U

Information

• [mopera U設定 (mopera U setting)] is an access point for mopera U setting. Connection via the access point for mopera U setting costs no packet communication fee. Note that you cannot access the screens other than those for initial settings and changing settings. For details of mopera U setting, refer to mopera U website.

• To use [mopera U (スマートフォン定額) (flat-rate for smartphone)] required. For details of mopera U (スマートフォン定額) (flatrate for smartphone), refer to DOCOMO website.

, subscription to flat-rate packet service is

Email Setting

You can configure mail account provided by mopera U or general providers to use mail function.

• Configure access point setting in advance (Z P.95).

Setting mopera U Mail Account

Subscribers for mopera U can use mopera U mail.

■ To use POP server

Home screen W W [Email]

Enter mopera U mail address and mopera U password W [Next] W [POP3]

Enter mopera U user name and password W Enter [mail.mopera.net] for POP3 server

Select [None] or security type in the security type field W Confirm your entry W [Next]

Enter [mail.mopera.net] for SMTP server W Confirm mopera U

user name and password you

entered W [Next]

Option setting screen W Set frequency of automatic mail check etc. W [Next]

Mail account register screen W Enter the name displayed for the sent message W [Done]
