Docomo FOMA P901iS, FOMA P701iD User Manual

Download

Manual for

Contents/Precautions

Confirming before Use

Making Calls/

Receiving Calls

’05.5

Making/Receiving

Video-phone Calls

Phonebook

Tone/Display/

Light Setting

Safety Settings

Camera

i-mode

Mail

i-αppli

i-motion

Mobile Wallet

i-mode FeliCa

Data Display/Edit/

Management

Other Useful

Functions

Network Service

Data Transmission

Entering Characters

Appendix

Easy Search/Index/

Quick Manual

DoCoMo W-CDMA system

Thank you for selecting the “FOMA P901iS”.

Before or during use of the FOMA P901iS, make sure that you read this manual and

the separate manuals such as for the battery pack thoroughly so that you can use

the FOMA P901iS correctly. If you feel any inconvenience in reading the manual,

contact the DoCoMo Information Center listed on the back page of this manual.

The FOMA P901iS is designed to be your close partner.

Treat it carefully at all times to ensure long-term performance.

Before using your FOMA Phone

●

Because the FOMA phones use radio waves, they cannot be used in places where radio waves do not reach, such as inside tunnels, underground, or in buildings; or the outside where radio waves are weak or out of the FOMA service area. They may not be used in the high-rise buildings even when the antennas are unobstructed. You may also experience interruption of calls even when using without moving while the radio waves are strong enough for the three antennas to appear on the display.

●

Use the FOMA phone carefully to avoid disturbing other people when in public, or in crowded or quiet places.

●

Since the FOMA phones use radio waves as the medium of telecommunication, calls may be tapped by the third party. However, the W-CDMA system automatically supports tapping prevention, so your conversation will be incomprehensible to the third party.

●

The FOMA phones change your voice into digital signals and send them to the other party. In places where the radio waves are weak, the digital signals may not be converted correctly, and in such a case, the voice heard may sound different from the actual original voice.

●

It is recommended that you make separate notes of the information stored in the FOMA phone and keep such notes in a safe place. DoCoMo cannot be held responsible in any way for the loss of data stored in the phone.

●

The user hereby agrees that the user shall be solely responsible for the result of the use of SSL. Neither DoCoMo nor the certifier as listed herein makes any representation and warranty as for the security in the use of SSL. In the event that the user shall sustain damage or loss due to the use of SSL, neither DoCoMo nor the certifier shall be responsible for any such damage or loss. Certifier: VeriSign Japan K.K. Betrusted Japan Co., Ltd. GeoTrust Japan, inc.

●

This FOMA phone supports FOMA Plus-Area.

●

The FOMA phone can be used only via the FOMA network provided by DoCoMo.

Before using this manual

The following ways are available to search for the functions you want to know:

・Search for from the Contents • • • • •Page 2

You search for the functions from the contents.

・Search for from the Index • • • • • • • •Page 582

You search for the functions from keywords such as the function names or service names.

・Search using the Tab • • • • • • • • • • •Cover page

You search for the functions from the tabs affixed to pages (title for each chapter).

●The detailed contents by functions are described on the first page of each chapter.

・Search for from the features • • • • • •Page 4

You search for the functions from the features of P901iS.

・Search for from the Easy Search • • •Page 580

You search for the functions you want to use.

The Quick Manual is available as handy-to-use quick reference when you go outing.

・Search for from the Quick Manual • •Page 588

Cut the Quick Manual off this volume for using when you go outing.

Note that “FOMA P901iS” is referred to as “FOMA phone” in this manual.

●

The functions which use a miniSD memory card are described in this manual; however, you need to obtain a

●

miniSD memory card separately to make these functions available. See page 395 for the miniSD memory card. It is prohibited to copy all or part of this manual without permission.

●

The instructions contained in this manual may be changed without notice.

●

Select a menu icon or background image to be changed

Select a folder Select an image

Repeat step 2 and set an image for menu icon or background.

●

While selecting a menu icon or background image, press ( ) to confirm the currently set image. While confirming a demo of “Background image”, press ( ) to set a frame color indicating the group. Select a color and press . Press ( ) to switch between 16 Color and 256 Color.

●

You can use “

ｼﾞｬｹｯﾄｺｰﾃﾞｨﾈｰﾀｰ

(Jacket Coordinator)” to batch-download a variety of source data. Refer to “

別冊内蔵ｉアプリガイ

ド

(Pre-installed i-αppli guide)” for details.

●

The image file you can customize is in JPEG format or GIF format of VGA (640 x 480) or less size and of up to 100 Kbytes. However, you cannot set the animation GIF for the background.

●

You cannot set Customize during PIM Lock. Further, the image of Pattern 1 is displayed if PIM Lock is activated while Customize is set.

●

If you delete the image set by Customize, the image of Pattern 1 is displayed.

●

When you set Pattern 2 or Customize, the image for the Main menu does not switch even if you switch “Select language”.

Information

Function menu

Reset

All reset

Operations

Resets the image to the same image of “Pattern1” (setting at purchase).

YES

●

To cancel, select “NO” and press .

Resets all the menu icons and background to the same images of “Pattern1” (setting at purchase).

YES

●

To cancel, select “NO” and press .

Icon/Background Selection display ( ) Do the following operations.

Function Menu of the Icon/Background Selection Display

Tone/Display/Light Setting

Display Menu display set Menu icon

Pattern1·······················Sets to Pattern 1. The setting is completed. Pattern2·······················Sets to Pattern 2. The setting is completed. Customize····················Select an image for each menu icon and for background respectively.

You can change the icons on the Main menu and the background images.

Pattern1 Pattern2

Setting at purchase

Pattern1

Setting Menu Display

How to Read This Manual

Illustrations and symbols are used in the explanations so that you can easily understand how to use the FOMA phone correctly.

●

Operating methods are described in “Scroll Selection” (see page 29).

●

Screen displays and illustrations described in this manual are for reference. The actual ones might differ.

●

In this manual, “Mobile Wallet compatible i-αppli which supports the IC card function” is described as “Mobile Wallet compatible i-αppli”.

Quick Manual (See page 588)

Indicates the menu number. (See page 32)

Shows the operating procedures. (See page 33)

Describes the item names displayed on the screen. (Some items may not be available depending on the operation.)

Describes details, cautions, or references required for using each function.

Contains the explanation and operating method for each item.

Describes the setting at purchase. The “Function List” also lists the settings at purchase. (See page 532)

Describes the option and explanations displayed on the screen.

Shows the display at an important point in the procedure. See this while referring to the display of the FOMA phone you are using. (Values, settings, and entered characters are for reference.)

You can search for chapters from the tabs.

Confirming before Use

Making Calls/Receiving Calls

Making/Receiving

Video-phone Calls

Phonebook

Tone/Display/Light Setting

113

Safety Settings

145

Camera

161

i-mode

193

Mail

237

Phone Parts and Functions, Display, Icon Descriptions, Method for Selecting Menu, Guide, UIM (FOMA Card), Battery, Charging, One-push Open, Power ON/OFF, Select Language, Initial Setting, Set Time, Notify Caller ID, Own Number, etc.

Making a Call, WORLD CALL, Switching to a

Video-phone

Call, Redial, Pause Dial, Hands-free, Receiving a Call, Answer Setting, Open Phone, Fold Setting, Received Calls, Earpiece Volume, Ring Volume, On Hold, Holding, Drive Mode, Record Message, etc.

About Video-phone, Making a Video-phone Call,

Switching to a Voice Call, Receiving a Video-phone Call, Using Chara-den, Useful Functions for Videophone Calls, Moving Image Quality, Camera Image Sending, Select Image, Voice Call Auto Switch, Indicate Video-phone, Remote Observation, Video-phone Display Setting

Phonebook, Add to Phonebook, Add to Phonebook (UIM), Storing Displayed Phone Number/Mail Address in Phonebook Entries, Group Setting, Search Phonebook, Editing Phonebook Entries, Deleting Phonebook Entries, Number of Phonebook Entries, Making Full Use of Phonebooks, Utilities, Two-Touch Dial, Voice Dial

Select Ring Tone, Vibrator, Voice Announce, Manner Mode, Display Setting, Private Window, Dot-area, Display Light, Color Pattern, Menu Display Set, Illumination, Desktop, Font, Main Window Clock, etc.

Passwords, Change Security Code, PIN Setting, Releasing PIN Lock, All Lock, Self Mode, PIM Lock, Keypad Dial Lock, Secret Mode, Mail Security, Restrictions, Call Setting w/o ID, Ringing Time, Reject Unknown, etc.

Before Using Cameras, Still Image Shot, Moving Image Shot, Settings for Shooting Images, Setting Image Size and Image Quality, Bar Code Reader, Text Reader

What is i-mode?, iMenu, Last URL, My Menu, Change i-mode Password, Enter URL, URL History, Display Home, Bookmark, Screen Memo, Download, Operations from Highlighted Information, i-mode Settings, Message R/F, SSL Certificate Operation, User Certificate Operation, etc.

i-mode Mail, Deco Mail, Photo-sending, Kirari Mail, Mail Receive Option, Check New Message, i-motion Mail, Inbox, Outbox, Draft Box, Auto-Sort, Template, Chat Mail, SMS (Short Messages), etc.

How to Read This Manual··················································1

Contents··············································································2

Features of FOMA P901iS··················································4

Making Full Use of FOMA P901iS! ····································6

Safety Precautions ·····························································8

Notes on Handling····························································16

Intellectual Property Rights·············································18

Accessories and Main Options ·······································20

Contents/Precautions

＊

You need to obtain a miniSD memory card separately to use the functions related to the miniSD memory card. (See page 395)

i-αppli

319

i-motion

335

Mobile Wallet

i-mode FeliCa

339

Data Display/Edit/

Management

345

Other Useful Functions

419

Network Service

453

Data Transmission

467

Entering Characters

509

Appendix

531

Easy Search/Index/

Quick Manual

579

What is i-αppli?, i-αppli Download, i-αppli Launch, Starting i-αppli Automatically, i-αppli Stand-by Display, Settings for when Running i-αppli

What is i-motion?, Obtain i-motion, i-motion Auto Play, i-motion Type

What is Mobile Wallet?, Mobile Wallet Compatible i-αppli, IC Card Lock, Face Reader Settings

Data Box, Picture Viewer, Edit Picture, Original Animation, i-motion Player, Edit i-motion, Chara-den, Melody Player, Play Music (SD-Audio), miniSD Memory Card, Infrared Exchange, PDF Viewer, etc.

Multiaccess, Multitask, Alarm, Schedule, ToDo, Private Menu, Own Number, Voice Memo during a Call, Voice Memo during Standby, Call Data, Calculator, Free Memo, UIM Operation, Reset, Initialize, etc.

Check Messages, Voice Mail, Call Waiting, Call Forwarding, Bar Nuisance Call, Caller ID Notification, Caller ID Request, Dual Network, English Guidance, Arrival Call Act, Set Arrival Act, Remote Access, Additional Service, etc.

Preparation Flow for Data Transmission, Installing Transmission Setup Files, FOMA PC Setup Software, Setting Transmission, W-TCP Setup, APN Setting, Dial-up Network, FirstPass PC Software, AT Command, etc.

Character Entry, Common Phrases, Cutting/Copying/Pasting Characters, Kuten Code, Own Dictionary, Clear Learned, Download Dictionary

Function List, Jacket Style and Non-Jacket Style, Options and Related Equipment, Data Link Software, Troubleshooting, Error Messages, Warranty and Maintenance Services, Software Update, Scanning Function, Specifications, etc.

Easy Search, Index, Quick Manual

Contents/Precautions

Features of FOMA P901iS

Contents/Precautions

i-mode Function

◆

Remarkable i-mode!

See page 194

i-mode is an online service that enables you to get useful information from i-mode sites (programs) or web pages supporting i-mode by using the screen of an i-mode phone. This service also enables you to send or receive messages with ease.

●

i-mode is only available on a subscription basis.

◆

i-motion Movie/i-motion Mail

See pages 243 and 336

You can obtain images and music from sites or Internet web pages. You can set the stored i-motion movie as “Chaku-motion” for a ring tone or ring image. Also, you can attach a moving image shot by the builtin cameras or an i-motion movie obtained from sites or Internet web pages to i-mode mail for sending.

◆

Large Capacity i-αppli/i-αppli DX

See page 320

By downloading i-αppli from sites, you can enjoy playing enhanced games or can update the stock price information and weather forecast automatically. In addition, i-αppli DX enables you to enjoy i-αppli variously by linking to the information in the i-mode phone such as the Phonebook entries and mail messages.

FOMA (Freedom Of Mobile multimedia Access) is the name of the DoCoMo service based on the W-CDMA format, authorized as one of the world’s standards for third-generation mobile telecommunication systems (IMT-2000).

◆

i-shot

See page 242

You can take a shot of a still image with a built-in camera and attach it to mail for sending.

Main Features of the P901iS

◆

Video-phone

See page 74

You can have a conversation with the other party seeing the face each other. You can also let the other party’s voice heard from the speaker or the other party see the landscape around you by switching the inside camera to the outside camera. You can easily switch a voice call to video-phone call without disconnecting.

◆

Chara-den

See pages 80 and 381

During video-phone calls, you can display a preinstalled or downloaded graphic character in place of your own image. You can add expressions or movements to the character by key operation.

◆

Mobile Wallet i-mode FeliCa compatible

See page 340

By downloading Mobile Wallet compatible i-αppli

, your mobile phone will be an increasingly handy tool in your life; from a site, you can replenish electronic money into the IC card inside the FOMA phone and check your account for the balance and usage details. In addition, you can use it as a flight ticket or reward card. You can also lock the IC card to prevent it from being used in an illegal way. Also, you can use the functions such as

“Timer lock”

that locks the IC card automatically

after a certain period or

“Face reader”

that scans the

face data for certificates using a built-in camera.

◆

Deco Mail

See page 242

You can change the font color, font size, or background color of mail text or can insert Deco mail pictures or photos taken by the built-in cameras in the text, so that you can compose and send enhanced messages. In addition, as Deco mail supports the template, you can easily create a Deco mail message by using the format of the received Deco mail or Deco mail downloaded from sites.

◆

PDF Viewer

See page 412

You can browse PDF data. You can download useful information such as maps, catalogs, or railroad timetables from sites or Internet web pages and can check them on the i-mode phone easily as if you carried around a printed material.

＊

You need to obtain a miniSD memory card separately to use the functions related to the miniSD memory card. (See page 395)

Contents/Precautions

◆

Safety Settings

See page 145

You can make full use of the safety settings such as Lock/Security to protect your privacy using the Terminal Security Code and password, or to lock the lost FOMA phone from a distant location to prevent unauthorized use.

◆

Network

See page 454

・

Voice Mail Service (Charged)

●

You need to apply for this service.

・

Call Waiting Service (Charged)

●

You need to apply for this service.

・

Call Forwarding Service (Free)

●

You need to apply for this service.

・

Dual Network Service (Charged)

●

You need to apply for this service.

・

SMS (Free)

●

You do not need to apply for this service.

Various Functions

◆

Multiaccess/Multitask

See pages 420 and 423

The FOMA phone comes with the “Multiaccess” function that enables you to simultaneously use the voice phone and i-mode (or data transmission by packet transmission). SMS is available separately from “Multiaccess”. The FOMA phone comes with also the “Multitask” function that enables you to use multiple menu functions simultaneously.

◆

Bar Code Reader/Text Reader

See pages 182 and 187

You can get and use the information of phone numbers or mail addresses, images, or melodies, by scanning bar codes or QR codes. Also you can scan alphanumeric of phone numbers or mail addresses on printed materials.

◆

Batch-Download

See page 330

You can use the pre-installed i-αppli “

ｼﾞｬｹｯﾄｺｰﾃﾞｨﾈｰﾀｰ

(Jacket Coordinator)” to batch-download a variety of source data for the Custom Jacket.

◆

3D x 3D

See pages 116 and 329

Synergy of enhanced 3D graphics and evolved 3D sound enables you to have realistic sensation when you are

playing games such as TRANCE PINBALL SURROUND.

◆

Infrared Exchange/Infrared RemoteController

See pages 330 and 406

You can exchange data with another FOMA phone or a device using infrared rays. You can use the FOMA phone also as a remote-controller for a TV that supports infrared exchange.

◆

One-push open

See page 42

You can open the FOMA phone easily by pressing the button.

◆

Dot-area

See pages 28 and 130

You can change the data to be displayed on the dot-area. You can also use the pre-installed i-

ppli “

ﾄﾞｯﾄｸﾘｴｲﾀｰ

(Dot Creator)” to create the dot-area data. By changing the dot-area data to suit with the Custom Jacket, you can arrange the light and movement suitable for the Custom Jacket.

◆

SD Related/miniSD Reader & Writer

See page 405

You can use the FOMA phone as the miniSD

reader/writer for personal computers.

◆

SD-Audio

See page 390

By using SD-Jukebox contained in the attached CDROM, you can store music files on the miniSD memory card set on a personal computer and play them back on the FOMA phone. In addition, if you connect the Flat-plug Stereo Earphone Set (option) to the FOMA phone, you can listen to music through the Earphone Set.

Contents/Precautions

Making Full Use of FOMA P901iS!

Mail

Video-phone

◆

“Chara-den” that Conveys Your Feelings

See pages 80 and 381

“Chara-den” is the other self that is sent to the other party as a video-phone image in place of your own photo. If you set a Chara-den image as a substitutive image for a video-phone call, you can give it movements or expressions such as “Delighted” or “Angry” by key operation. Also, you can synchronize the mouth of the Chara-den image with your voice.

◆

Chat Mail

See page 304

You can use i-mode mail for exchanging chat mail as if you are communicating with multiple members. One of convenient features is that you can exchange messages on a single screen.

◆

“Photo-sending” that enables you to send still images while you are communicating

See page 261

You can shoot a still image during a voice call and send it to the other party. You can send your friend a shot of beautiful landscape or lovely gesture of pets that you cannot tell in words without disconnecting the call.

Displaying it during a call

Shooting a still image during a call

Sending it

◆

Kirari Mail

See page 266

The Call/Charging indicator lights for incoming mail according to pictographs so that you can get acquainted with the sender’s sentiment. The Call/Charging indicator lights when created mail is previewed or outgoing/incoming mail is displayed as well.

＊

You need to obtain a miniSD memory card separately to use the functions related to the miniSD memory card. (See page 395)

Contents/Precautions

Camera

◆

Inside Camera/Outside Camera

See page 163

The two cameras (inside camera and outside camera) enable you to take shots of still images and moving images. Use the inside camera for taking a shot of your own photo and the outside camera for taking a shot of landscapes.

◆

Making Full Use of Moving Images

See page 375

You can cut a still image out from moving images shot by a camera, edit the voice part (Record Sound) only, or edit the text information displayed during playback (Edit Ticker).

◆

Making Full Use of Still Images

See page 360

You can compound frames or characters with still images you shot. You can use “Funny transform” that edits the person’s expression and “Funny transform Ⅱ” that animates the person’s expression. You can also use “Cushy mark” that identifies the region of the person’s face and pastes the cushy mark to an appropriate region of the face.

Pre-installed i-αppli

◆Gｶﾞｲﾄﾞ番組表ﾘﾓｺﾝ

(G Guide Program List Remote Controller)

See page 330

This is a convenient i-αppli that bundles TV program list and the AV remote-controller function. Anywhere at any time, you can easily access the TV program information about the time zone you want to know. You can check program titles, program contents, start/end time, and G codes

. You can reserve and list programs you want to watch for storing them as schedule events and can make an alarm to notify you of the programs to start. Further, you can search for the program information by keywords such as genres or names of your favorite personalities. You can also remote-control a TV, video recorder, and DVD player. By using infrared rays, you can also make a reservation for recording programs on a DVD/hard disk recorder. (Some models are not supported.)

◆

ﾌｧｲﾅﾙﾌｧﾝﾀｼﾞｰⅡ

(Final Fantasy Ⅱ)

See page 329

This is a completely immigrated version of “

ﾌｧｲﾅﾙﾌｧﾝﾀｼﾞｰⅡ

(

Final Fantasy Ⅱ)” which is

the second edition of the world-popular role playing game, the “Final Fantasy” series.

An epic drama is being played by young people. They are destined to rise against the powerful Paramekian Empire and to face overcoming a burning ambition of the Empire.

※

Images on the display are for reference. They differ from the actual ones. Local programs broadcast by local channels will appear on your display.

miniSD Memory Card

◆

SD-Audio

See page 390

By using SD-Jukebox contained in the attached CD-ROM, you can store music files on the miniSD memory card set on a personal computer, and play them back on the FOMA phone. You can create a playlist to play back your favorite songs successively or play them back at random. When you connect Flat-plug Stereo Earphone Set (option) and close the FOMA phone, you can hear the songs through the Flat-plug Stereo Earphone Set. You can use the switch of Stereo Earphone Set for the operations such as playback and pause.

Contents/Precautions

■

Before using the FOMA phone, read these safety precautions carefully so that you can use it correctly. After reading the precautions, keep them in a safe place for later reference.

■

Be sure to observe these safety precautions because they are designed to protect you or those around you from causing injury and to avoid unnecessary damage to the property.

■

The symbols below indicate the levels of danger or damage that can be caused if the particular precautions are not observed.

This symbol indicates that incorrect handling will almost certainly cause death or serious injury.

This symbol indicates that incorrect handling poses a risk of causing death or serious injury.

This symbol indicates that incorrect handling poses a risk of causing injury or damage to the product or property.

Danger

Warning

Caution

Denotes things not to do. (Prohibition)

Denotes not to disassemble.

Denotes not to use where it could get wet.

Denotes not to touch with wet hands.

■

The following symbols show specific directions:

■

“Safety Precautions” are divided into the following six sections:

General precautions for FOMA phone, batteries, adapters/chargers, and UIM·····································p.9 Precautions for FOMA phone···············································································································p.10 Precautions for batteries ······················································································································p.12 Precautions for adapters/chargers·······································································································p.13 Precautions for UIM ·····························································································································p.14 Notes on using near electronic medical equipment ·············································································p.15

Do not disassemble

Don’t

Avoid water

Denotes mandatory instructions (matters that must be complied with).

Denotes to pull the power plug out of the outlet.

Pull the power plug out

Safety Precautions

Always follow the safety precautions.

Contents/Precautions

General precautions for FOMA phone, batteries,

adapters/chargers, and UIM

Use only the batteries and adapters/chargers approved by DoCoMo for the FOMA phone.

If you use any type of battery, adapter or charger other than the specified one, the FOMA phone or battery may leak, overheat, burst, catch fire, or give damage. Battery Pack P06 FOMA AC Adapter 01 FOMA AC Adapter 01 for both overseas and domestic usage FOMA DC Adapter 01 Desktop Holder P08 In-Car Holder P08

●

For other specified products, contact a DoCoMo counter.

Do not let the FOMA phone, batteries, adapters/chargers, and UIM get wet.

If liquids such as water or pet urine get onto them, overheating, electric shock, fire or malfunction may result.

Pay attention to the place of use and the way of handling. Avoid water

If the FOMA phone emits smoke or

offensive odors, or is damaged, take

the countermeasures as follows:

1. Pull the power plug off the outlet or socket.

2. Shut down the power to the FOMA phone.

Remove the battery pack from the FOMA phone. If you use or charge the FOMA phone with these symptoms not handled, an accident such as catching a fire could result. Contact one of the DoCoMo counters after you have removed the battery pack.

Do not place the batteries, the FOMA phone, or adapters/chargers in microwave ovens or high-pressure containers.

The battery may leak, overheat, burst, or catch fire. The FOMA phone or the adapter/charger may overheat, smoke, or catch fire, or its circuit parts may burst.

Do not throw the FOMA phone or accessories, or subject them to severe shocks.

The battery may leak, overheat, burst, catch fire, or cause damage to the equipment.

When you are in a place such as a gas station where flammable gas is generated, turn off the FOMA phone, or never do charging. Otherwise, catching fire may result.

Ensure that you use Osaifu-Keitai with the FOMA phone turned off when you are in the vicinity of the gas station. (When IC Card Lock is set, turn off the power with the lock released.)

Be careful not to let electroconductive materials (metal pieces, pencil leads etc.) contact with the charging terminal or external connecting terminals. Also, make sure that those are not entered into the inside of the FOMA phone.

Short-circuit could cause catching fire or malfunction of the FOMA phone.

Don’t

Keep out of the reach of babies and infants.

Accidental swallowing or injury may result.

Do not place the FOMA phone or accessories on unstable locations such as wobbly tables or slanted locations.

The FOMA phone or accessories may fall, resulting in injury or malfunction.

Do not store in humid or dusty places, or in high temperature environments.

Malfunction may result.

f children use the FOMA phone or accessories, a guardian should explain the safety precautions and correct operations. The guardian should also make sure that the instructions are followed during use.

Otherwise, injury may result.

Do not use or leave the FOMA phone or accessories in places where it is exposed to direct sunlight, or in extremely high temperatures such as inside a car in the summer heat.

The battery may leak, overheat, burst, or catch fire, resulting in deformation and malfunction. Also, part of the case might be heated, causing bare skin burns.

Don’t

Danger

Warning

Caution

Contents/Precautions

Precautions for FOMA phone

Warning

Turn off the FOMA phone when near high-precision electronic devices or devices using weak electronic signals.

The FOMA phone may possibly cause these devices to malfunction.

※

Electronic devices that may be affected: Hearing aids, implanted cardiac pacemakers, implanted defibrillators, other medical electronic devices, fire alarms, automatic doors and other automatically controlled devices. If you are using an implanted cardiac pacemaker, implanted defibrillator or any other electronic medical device, consult the manufacturer or retailer of the device for advice regarding possible effects from the radio waves.

Turn off the FOMA phone in places where use is prohibited such as in airplanes and hospitals.

Otherwise, electronic devices and electronic medical appliances may be adversely affected. If the Auto Power ON function is set, deactivate the setting, then turn the power off. For use inside medical facilities, make sure that you comply with their regulations. You may be punished for using the FOMA phone in airplanes, which is prohibited by law.

If you have any implanted electronic medical equipment, do not place your FOMA phone in a chest pocket or inner pocket.

If the FOMA phone is positioned close to electronic medical equipment, it may cause that equipment to malfunction.

When talking with the FOMA phone set to Hands-free, be sure to keep the FOMA phone away from your ear.

Otherwise, your hearing could be impaired.

Do not disassemble or modify the FOMA phone.

Accidents such as fire, injury, or electric shock, or malfunction may result.

Do not use or leave the battery near a fire, heater or other source of heat.

The FOMA phone may overheat, burst or catch fire.

Do not operate the FOMA phone while driving a vehicle.

Your safety driving will be interfered and an accident may result. Park the car in a safe place before using the FOMA phone or activate Drive Mode. In accordance with the revision of the Road Traffic Law, you will be penalized for using a mobile phone during drive from November 1, 2004.

For those with weak heart conditions, the vibrator and ring volume must be adjusted carefully.

Those functions may cause an effect on the heart.

Do not directly point the infrared data port at someone’s eyes during transmission.

His/her eyes may possibly be affected. Other infrared devices may operate erroneously if the infrared data port is pointed at them during transmission.

Do not shine the photo light close to eyes.

Doing so can damage eyesight. Also, accidents such as injury might occur if someone is startled or dazzled by the light.

Do not direct the photo light to a car driver, etc.

Drivers may be dazzled by the light and could cause traffic accidents.

Do not put the FOMA phone in the place where it could be affected by an expanded airbag, e.g., on the dashboard.

If the airbag expands, the FOMA phone could hit you and others, causing accidents such as injury and the FOMA phone could become damaged.

Don’t

Do not

disassemble

Don’t

Contents/Precautions

Electronic devices in some types of cars can be affected by use of the FOMA phone.

For safety’s sake, do not use the FOMA phone inside such cars.

If thunder starts to rumble while you are using the FOMA phone outdoors, turn the power off, and move to a safe place.

Otherwise, you could be struck by lightning or suffer an electric shock.

Do not swing the FOMA phone by its strap.

The FOMA phone may hit you or persons around you, and accidents such as injury or malfunction may result.

Do not place magnetic cards or similar objects near the FOMA phone or between phone parts.

Information on magnetic cards such as cash cards, credit cards, telephone cards and floppy disks may be deleted.

Do not expose the cameras to a strong light or sun light for a long period of time.

The camera lens will condense the light and may cause a fire.

Do not allow liquids such as water, or foreign materials such as metal pieces or flammable materials to get into the UIM insertion slit or miniSD memory card slot of the FOMA phone.

Fire, electric shock or malfunction may occur.

Do not open the FOMA phone by pressing the one-push open button near persons around you or your face.

The FOMA phone may hit you or persons around you, causing accidents and injuries.

Don’t

Itching, rash or eczema may be caused depending on your physical conditions or predisposition. If an abnormality occurs, stop using the FOMA phone immediately, and then seek medical attention.

Metals are used for the following parts:

Caution

Where it is used Material Finishing

Command Navigation key ABS Copper-and-nickel plated ground chrome finish Display case Magnesium alloy Baking finish Hinge part Outside camera panel Stainless Nickel plated ground chrome finish Screws for Jacket StyleIron

Iron

Copper-and-nickel plated ground chrome finish

Screws for Non-Jacket Style

An exhausted battery should not be disposed of with other waste.

The battery may catch fire or destroy the environment. After insulating the battery terminals with tape, bring them to a DoCoMo counter or dispose of them in accordance with local waste disposal regulations.

Don’t

Contents/Precautions

If the battery fluid gets into your eyes, do not rub them. Flush your eyes with clean water and get medical attention immediately.

Otherwise, the loss of eyesight may result.

Do not disassemble or modify the battery. Do not solder the terminal of the battery.

The battery may leak, overheat, burst or catch fire.

Do not let any metal such as a wire contact the terminal. Also do not carry or store the battery together with a metal necklace.

The battery may leak, overheat, burst or catch fire.

Do not throw the battery into fire.

The battery may leak, overheat, burst or catch fire.

Do not use excessive force when attaching the battery to the FOMA phone. Also, check that the battery is the right way round when you attach it.

The battery may leak, overheat, burst or catch fire.

Do not pierce it with nails, hit it with a hammer, or step on it.

The battery may leak, overheat, burst or catch fire.

Do not use or leave the battery near a fire, heater or other source of heat.

The battery may leak, overheat, burst or catch fire.

Don’t

Do not

disassemble

Danger

Warning

If the battery begins to emit an odor, overheat, discolor, deform, etc., while being used, charged, or stored, remove the battery from the FOMA phone and do not use it.

If such a battery is used, it may leak, overheat, burst or catch fire.

Don’t

Do not use or leave the battery in places where it is exposed to direct sunlight, or in extremely high temperatures such as inside a car in the summer heat.

The battery may leak or overheat, or its performance and longevity may deteriorate.

If charging is not completed at the end of the specified charging time, stop charging.

Otherwise, the battery may leak, overheat, burst or catch fire.

If the battery fluid comes in contact with skin or clothes, immediately stop using, then wash affected areas thoroughly with clean water.

The battery fluid is harmful to skin.

Immediately stop using the battery if it leaks or emits an odor, and keep it away from fire.

The battery fluid, being flammable, may catch fire and cause an explosion.

Don’t

Caution

Precautions for batteries

■

Check the description on the label of the battery pack for the type of battery.

Description Type

Li-ion Lithium-ion battery

Contents/Precautions

Precautions for adapters/chargers

Use the adapter/charger at the specified VAC.

Otherwise, fire or malfunction may result. When using the FOMA phone overseas, use FOMA AC Adapter 01 for both overseas and domestic usage. AC adapter: 100 VAC FOMA AC Adapter for both overseas and domestic usage: 100 to 240 VAC (Connect only to home AC outlet) DC adapter: 12/24 VDC

[For negative (-) grounded vehicles only]

If liquids such as water get in the charger, unplug the power cord immediately from the outlet or cigarette lighter socket.

Liquid inside the charger may cause electric shock, smoke, or fire.

Keep the power plugs dust-free.

Otherwise, fire may result.

Do not use a damaged adapter/charger cord or power cord.

Electric shock, overheating or fire may result.

Do not use the AC adapter and desktop holder in steamy places such as a bathroom.

Electric shock may occur.

When the adapter/charger is not to be used for a long period of time, unplug the power cord from the outlet.

Otherwise, electric shock, fire, or malfunction may result.

If a fuse of the DC adapter or In-Car adapter has blown, replace it with a specified fuse.

Otherwise, catching fire or malfunction may result. For the specified fuse, see the user’s manual.

The DC adapter is for use only in a negative (-) grounded vehicle. Never use it in a positive (+) grounded vehicle.

Fire may result.

Place the charger and desktop holder on a stable location during charging. Do not cover or wrap the charger and desktop holder in cloth or bedding.

The FOMA phone may become separated from the desktop holder, or overheat, leading to fire or malfunction.

Do not disassemble or modify the adapter/charger.

Electric shock, fire, or malfunction may result.

When plugging the AC adapter into the power outlet, firmly plug it in, taking care not to contact with metal straps or the like.

Otherwise, electric shock, short-circuit or fire may result.

Do not touch the adapter/charger, power cord, or power outlet with wet hands.

Electric shock may result.

Never short-circuit the charging terminals when the adapter is plugged into the power outlet or cigarette lighter socket. Also, never touch the charging terminals with fingers or other bare skin.

Fire, malfunction, electric shock or injury may result.

If it starts to thunder, do not touch the FOMA phone and adapter/ charger.

You might be struck by lighting or suffer an electric shock.

Don’t

Avoid water

Do not

disassemble

Don’t

Pull the

power plug

out

Don’t

Pull the

power plug

out

Warning

Contents/Precautions

Caution

Always hold the plug when pulling the adapter/charger out of the power outlet or cigarette lighter socket.

If you pull the plug out by the cord, the cord may be damaged, which could result in electric shock or fire.

Do not charge the wet battery.

Overheating, fire, or burst may result.

Do not place heavy objects on the adapter/charger cord and power cord.

Electric shock or fire may result.

Before cleaning, pull the plug out of the power outlet or cigarette lighter socket.

Otherwise, electric shock may result.

Pull the

power

plug out

Don’t

Precautions for UIM

Warning

Do not place the UIM in microwave ovens or high-pressure containers.

Melting, overheating, generating smoke, erasure of data, or malfunction may occur.

Don’t

Caution

Use the UIM only with equipment approved by DoCoMo.

If used with a non-approved equipment, erasure of data or malfunction may occur. For information on approved equipment, contact a DoCoMo counter.

Keep the UIM out of the reach of babies and infants.

Accidental swallowing or other injuries may occur.

Do not bend the UIM or place heavy objects on it.

Malfunction may result.

Do not toss the UIM into fire or heat it.

Melting, overheating, smoke generation, erasure of data, or malfunction may occur.

Do not store the UIM in places where it is exposed to direct sunlight, high humidity, or high temperatures.

Malfunction may result.

Be careful when removing the UIM (IC portion).

Your hand or finger may be injured.

Do not touch the IC portion unnecessarily or short it out.

Erasure of data or malfunction may occur.

Do not drop the UIM or subject it to strong impacts.

Malfunction may result.

Do not damage the IC portion.

Malfunction may result.

Don’t

Precautions for adapters/chargers (continued)

Contents/Precautions

Caution

Do not let the UIM get wet.

If liquids such as water or pet urine get onto the UIM, malfunction may occur.

Do not use or leave the UIM near a fire, heater or other source of heat.

Melting, overheating, smoke generation, erasure of data, or malfunction may occur.

Do not store the UIM in dusty places.

Malfunction may result.

Do not disassemble or modify the UIM.

Erasure of data or malfunction may occur.

Do not

disassemble

Don’t

Avoid water

Notes on using near electronic medical equipment

■

The description below meets “Guidelines on the Use of Radio-communication Equipment such as Cellular Telephones – Safeguards for Electronic Medical Equipment” by the Electromagnetic Compatibility Conference Japan.

If you use an implanted cardiac pacemaker or implanted defibrillator, use the mobile phone 22 cm or more away from an implanted cardiac pacemaker or implanted defibrillator.

Operation of an implanted cardiac pacemaker or implanted defibrillator can be affected by radio waves.

Turn off the phone in crowded areas such as inside trains during rush hour, as someone with an implanted cardiac pacemaker or implanted defibrillator may be near you.

Operation of an implanted cardiac pacemaker or implanted defibrillator can be affected by radio waves.

Comply with the following in hospitals or health care facilities:

●

Do not carry the FOMA phone into operating rooms, intensive care units (ICU) or coronary care units (CCU).

●

Turn off the FOMA phone in hospital wards.

●

If there is any electronic medical equipment near you, turn off the FOMA phone even when in a location such as a lobby.

●

Comply with any regulations of hospital and health care facilities instructing you not to use or carry in a mobile phone.

●

If the Auto Power On function is set, deactivate the setting, then turn the power off.

Patients using electronic medical equipment other than implanted cardiac pacemakers or implanted defibrillators (outside medical establishments for treatment at home, etc.) should check the influence of radio waves upon the equipment by consulting its manufacturer.

Operation of electronic medical equipment can be affected by radio waves.

Warning

Contents/Precautions

■

Do not let the equipment get wet.

The FOMA phone, battery and adapter/charger are not waterproofed. Do not use them in environments, which are high in humidity such as in bathrooms, and do not allow them to get wet from rain. Furthermore, if carrying them against your body, the internal parts may become corroded if exposed to body perspiration. If the parts are found to have been damaged due to exposure to the liquids, any repairs will not be covered by warranty, or repairs may not be possible. This may be repaired at a cost if repairs are possible.

■

Do not place the FOMA phone in places where it may be subjected to excessive pressure.

Do not place the FOMA phone in a bag along with many other articles or in a trouser pocket, because this can damage the LCD display and internal circuitry. Malfunctions caused by such damage is not covered by the warranty.

■

Use a dry soft cloth to clean the equipment.

●

The camera lens and screen of the FOMA phone sometimes have a special coating so that they are easier to see. If you rub them roughly with a dry cloth, it might be scratched. Take care of the way of handling, and use only a dry, soft cloth such as used for cleaning glasses. If the lens or screen is left with water drop or stain adhered, smear may be generated.

●

Do not use alcohol, thinner, benzene, detergent or other solvents for cleaning, otherwise the printing may be removed or discoloration may result.

■

Occasionally clean the connecting terminals of the equipment using a dry cotton swab.

If the connector terminal becomes soiled, the connection might deteriorate so that the power goes off or the battery does not charge fully. Wipe the connector terminal with a dry cloth or cotton swab.

■

Do not place the FOMA phone near an air conditioner outlets.

Condensation may form due to rapid changes in temperature, and this may corrode internal parts and cause malfunction.

■

Do carefully read each instruction manual attached to the battery or adapter/charger.

■

Avoid using in extremely high or low temperatures.

The FOMA phone should be used within a temperature range of 5°C to 40°C and a humidity range of 35% to 85%.

■

It is recommended that you make separate notes of the information stored in the FOMA phone and keep such notes in a safe place.

We take no responsibility for any loss of the stored data items.

■

The FOMA phone, if operated near ordinary phones, televisions or radios that are in use, may affect them. You should operate your FOMA phone as far away from such equipment as possible.

■

Do not sit with the FOMA phone in your trousers or skirts pocket. Do not place the FOMA phone under heavy objects in a bag.

Malfunction may result.

■

Make sure that nothing, such as a strap, gets caught between the parts of the FOMA phone when you close it.

Otherwise, malfunction or breakage may result.

■

The FOMA phone may become warm during use or charging but this is not an abnormality. Use the FOMA phone as it is.

■

Do not leave the FOMA phone with a camera pointing direct to the sunlight.

Pixels may be discolored or burns may result.

Notes on handling the FOMA phone

General notes

Notes on Handling

Contents/Precautions

■

Charge the battery in a place with an ambient temperature of 5°C to 35°C.

■

Make sure that the battery is charged when you use the FOMA phone for the first time or have not used it for a long period of time.

■

The usable time of the battery differs depending on the usage environment or its remaining life.

■

Do not store or leave the empty battery pack.

If you do not use the FOMA phone for a long period of time, remove the battery pack from the FOMA phone and then store it in a dry, cool and dim place. Make sure that you charge the battery once a half year.

■

Batteries have a limited life.

If the usable time of your FOMA phone is extremely short even when the battery is fully charged, replace the battery. Make sure that you only buy the specified battery.

■

An exhausted battery should not be disposed of with other waste.

After insulating the battery terminals with tape, bring them to a DoCoMo counter or dispose of them in accordance with local waste disposal regulations.

■

Charge the battery where:

The temperature is between 5°C and 35°C. There is very little humidity, vibration, and dust. There are no ordinary phones, television sets or radios nearby.

■

During charging, the adapter or charger may become warm. This is not an abnormality, so continue charging.

■

Do not use the DC Adapter for charging the battery when the car engine is not running.

The car battery could go flat.

■

When using the power outlet having the disengaging prevention mechanism, observe the instructions given in that instruction manual.

■

Do not give a strong shock. Also, do not deform the charging terminal.

Malfunction may result.

■

Avoid using in extremely high or low temperatures.

■

Always keep the IC portion clean.

■

Do not use unnecessary force when inserting it into the phone.

■

The UIM may become warm during use, but this is not a sign of a malfunction. Continue using it as it is.

■

The warranty does not cover damage caused by inserting the UIM into some other types of IC card reader/writer.

■

For the environmental protection, bring any unneeded UIMs to a DoCoMo counter.

■

It is recommended that you make separate notes of the information stored on the UIM and keep such notes in a safe place.

We take no responsibility for any loss of the stored data items.

■

Use a dry soft cloth to clean the equipment.

Notes on handling the UIM

Notes on handling chargers and adapters

Notes on handling batteries

Please respect the privacy of individuals around you when taking and sending photos using camera-equipped mobile phones.

●

You may be imposed punishment according to the law and rule (such as the nuisance prevention ordinance) if you use the FOMA phone to give a remarkable nuisance and misdeed to the public.

・

“FOMA”, “mova”, “KIRARI MAIL”, “mopera”, “mopera U”, “WORLD CALL”, “FirstPass”, “Security Scan”, “WORLD WING”, “DoPa”,

“sigmarion”, “musea”, and the logos of “FOMA”, “mova”, “i-mode”, “i-motion”, “WORLD CALL” and “FirstPass” are trademarks or

registered trademarks of NTT DoCoMo, Inc.

・

“Multitask” is a trademark of the NEC Corporation.

・

使いかたナビ

is a registered trademark of CANNAC, Inc.

・ν

Maicovicon™ is a trademark for the Image Sensor of Matsushita Electric Co., Ltd.

・

Adobe and Reader are trademarks or registered trademarks of Adobe Systems Incorporated in the United States and other countries.

・

Java and Java related trademarks and logos are trademarks or registered trademarks of Sun Microsystems, Inc. in the United States

and other countries.

・

miniSD™ is a trademark of SD Association.

・

NetFront and are trademarks or registered trademarks of ACCESS Co., Ltd. in Japan and other countries.

・

IrFront is a trademark or registered trademark of ACCESS Co., Ltd. in Japan and other countries.

・

LCフォント

, LC FONT,

エルシーフォント

and LC logo mark are registered trademarks of SHARP Corporation.

・

T9 Text Input®and the T9 logo are registered trademarks of Tegic Communications.

T9 Text Input

is patented (Patent No. 3532780, patent No. 3492981) or pending patent in Japan.

T9 Text Input

is patented or pending patent worldwide.

・

QuickTime is a trademark of Apple Computer, Inc. in the United States and other countries.

・

Microsoft, MS, and Windows are registered trademarks or trademarks of Microsoft Corporation in the United States and other countries.

・

Macromedia, Flash, Flash Lite, Macromedia Flash and Macromedia Flash Lite are trademarks or registered

trademarks of Macromedia, Inc. in the United States and other countries.

・

is a registered trademark of Tao Group Limited.

・

“QR code” is a registered trademark of DENSO WAVE Inc.

・

ＦｅｌｉＣａ

is a registered trademark of Sony Corporation.

・

Gガイドモバイル

, G-GUIDE Mobile, and the G Guide Mobile logo are trademarks of Gemstar-TV Guide International, Inc. of the United

States in Japan, and

Gガイド

, G-GUIDE, the G Guide logo,

Gコード

and G-Code are registered trademarks of Gemstar-TV Guide

International, Inc. of the United States in Japan.

・

McAfee and VirusScan are registered trademarks or trademarks of McAfee, Inc. and/or its affiliates in the US and/or other countries. All

other registered and unregistered trademarks herein are the sole property of their respective owners.

・

“Powered by Mascot Capsule®”, “Micro3D EditionTM”, and “Mascot Capsule®” are trademarks of HI corporation.

・

Other company names and product names described in the text are trademarks or registered trademarks of those companies.

Contents/Precautions

Intellectual Property Rights

You have no right to copy, modify, or distribute the contents such as text, images, music, or software downloaded from web pages on the Internet, or images shot by the cameras of this product without permission from the copyright holder except for when the copy or quote is for personal use that is allowed by the Copyright Law. Note that it may be prohibited to shoot or record live performances or exhibitions even for personal use. Make sure that you refrain from taking portraits of other persons and distributing such portraits over the Internet without consent, as this violates portrait rights.

Copyrights and Rights of Portrait

Trademarks

Contents/Precautions

Others

・

This product is embedded with LC Font technology, which was developed by SHARP Corporation for clearly displaying easy-to-read

characters on an LCD screen. Other fonts are used for displaying some screen pages including, but not limited to Calculator, Calendar,

pictograph symbols, and marks.

・

This product contains the Macromedia®Flash Player technology developed by Macromedia, Inc.

・

This product contains NetFront v3.2 for FOMA Internet browser software of ACCESS Co., Ltd.

NetFront v3.2 is a product of ACCESS Co., Ltd.

1996-2005 ACCESS Co., Ltd.

・

This product contains the IrFront®technology of ACCESS Co., Ltd. as an OBEX protocol.

・

IrFront®is a product of ACCESS Co., Ltd.

1996-2005 ACCESS Co., Ltd.

・

This product contains technology of Reallusion Inc. for the Funny Transform function and Funny Transform

Ⅱ

function.

・

ＦｅｌｉＣａ

is a non-contact IC card technology developed by Sony Corporation.

・

Some part of the software in this product contains modules developed by Independent JPEG Group.

・

This product contains Adobe Reader of Adobe Systems Inc.

Adobe, the Adobe logo and Reader are either registered trademarks or trademarks of Adobe Systems Incorporated.

・

This product is licensed under the MPEG-4 patent portfolio license for the personal and non-commercial use of a consumer to

●

encode video in compliance with the MPEG-4 Visual Standard (“MPEG-4 Video”) and/or

●

decode MPEG-4 Video that was encoded by a consumer engaged in a personal and non-commercial activity and/or was obtained

from a licensed video provider. No license is granted or implied for any other use.

Additional information may be obtained from MPEG LA, LLC.

・

Licensed by QUALCOMM Incorporated under one or more of the following United States Patents and/or their counterparts in other

nations:

4,901,307 5,490,165 5,056,109 5,504,773 5,101,501 5,506,865 5,109,390 5,511,073

5,228,054 5,535,239 5,267,261 5,544,196 5,267,262 5,568,483 5,337,338 5,600,754

5,414,796 5,657,420 5,416,797 5,659,569 5,710,784 5,778,338

・

The FOMA phone comes with the software licensed from GNU General Public License (GPL), GNU Lesser General Public License (LGPL), and others. See “readme.txt” inside the “

GPL・LGPL等について

(about GPL/LGPL and others)” folder on the accessory CD-ROM for details about

that software.

Contents/Precautions

Accessories and Main Options

Other Options →See page 551

●

FOMA P901iS Handset (With Warranty and Rear Cover P05

）

●

Instruction Manual

・

Quick Manual included (See page 588)

●

CD-ROM for FOMA P901iS

●

Battery Pack P06 (With Instruction Manual)

●

FOMA AC Adapter 01 (With Warranty and Instruction Manual)

●

Desktop Holder P08 (With Instruction Manual)

●

別冊内蔵ｉアプリガイド

(Pre-installed i-αppli guide)

●

Screws for Non-Jacket Style (4)/Screw driver for Custom Jacket (See page 550)

Confirming before Use

Phone Parts and Functions ·········································································································· 22 Display ············································································································································ 24 Displaying Description of Icons·································································<Icon Descriptions> 26 Navigation Displays······················································································································· 26 Private Window ······························································································································ 27 About Dot-area ······························································································································· 28 Method for Selecting Menu ··········································································································· 29 Displaying Shortcut Menu············································································································· 33 When You do not Remember Key Operation································································<Guide> 34 Using the UIM (FOMA Card)·········································································································· 36 Attach/Remove Batteries ·············································································································· 39 Charging the FOMA Phone ··········································································································· 40 Opening the FOMA Phone by Using a Button ·············································<One-push Open> 42 Confirming Battery Level ···················································································<Battery Level> 42 Turning Power On/Off ······················································································<Power ON/OFF> 43 Switching to English·····················································································<Select Language> 43 Executing Initial Settings ···················································································<Initial Setting> 44 Setting Date and Time ································································································<Set Time> 45 Notifying the Other Party of Your Phone Number ········································<Notify Caller ID> 45 Confirming Your Own Number···········································································<Own Number> 46

Confirming before Use

Phone Parts and Functions

●

The antenna is inside the FOMA phone.

＊

You need to obtain a miniSD memory card separately to use the functions related to the miniSD memory card. (See page 395)

Size H: Approx. 102 mm (when closed) W: Approx. 49 mm

D: Approx. 26 mm

(In Non-Jacket Style: Approx. 25 mm) Weight Approx. 120 g (with battery attached) (In Non-Jacket Style:Approx. 115 g)

8 9

{

}

0 o



†

■

For inserting the Flat-plug Earphone/Microphone Set with Switch (option)

Infrared data port

Used for infrared exchange and an infrared remotecontroller. (See pages 330 and 406)

Inside camera

For taking photos of yourself. (See page 163) For catching sight of yourself during a video-phone call.

Display (See page 24)

Speaker

Sounds for incoming calls. Also, you hear the other party’s voice through this speaker when Hands-free is on. (See page 59)

Close-up lever

Switches the outside camera to the close-up mode. (See page 176)

One-push open button (See page 42)

Mode/Home key

(

モード／ホーム

)

Press to switch the camera mode while the camera is activated. (See pages 166, 167, and 172) Press from the Stand-by display to bring up the Internet web page set for the home URL. (See page 211) In addition, press to scroll by page while a site is displayed. (See page 201)

Mail key

Press from the Stand-by display to bring up the Mail menu. (See page 245) Press and hold for at least one second to check new messages

(See page 268) Press to operate the function shown at the lower left corner of the display. (See page 26)

Memo/Check key

(

メモ／確認

)

Press to check for missed calls and new mail, and to use Record Message. (See pages 71 and 138) In addition, press to scroll by page while a site is displayed. (See page 201)

Menu key

Press to bring up the Main menu. (See page 29) Press and hold for at least one second to lock the IC card. (See page 342)

Earphone/Microphone terminal

(See pages 22 and 449)

Send/Answer key

Press to make/receive calls. (See pages 48 and 60) When entering text, press to switch between uppercase/lowercase. (See page 521) Press and hold for at least one second to start a new line. (See page 522)

Numeric keys

Press to enter phone numbers and text.

・

Press and hold for at least one second to activate Manner Mode. (See page 122)

・

Press and hold for at least one second to activate Drive Mode. (See page 67)

・

Press and hold for at least one second to switch the display light on/off.

(See page 133)

Video-phone/Camera key

Press to make/receive video-phone calls. (See pages 75 and 78) Press and hold for at least one second to activate a camera. (See pages 166, 167, and 172)

Microphone

For speaking to the other party.

Call/Charging indicator

Flickers for incoming calls/mail and during calls. (See pages 135 and 138) Lights (flickers) when you take photos. Lights in red during charging.

Earpiece

For listening to the other party’s voice.

Command Navigation key

For operating functions and menus.

(See page 26)

i-mode key

Press from the Stand-by display to bring up the i-mode menu. (See page 201) Press and hold for at least one second to bring up the i-αppli Software List. (See page 324) Also, press to operate the function shown at the bottom right of the display. (See page 26)

Clear key

Press to return to the previous operation. Also, press to clear entered text or a phone number.

Power/End key

Press and hold for at least one second to turn the power on or two seconds to turn the power off. (See page 43) Press briefly to end calls, put incoming calls on hold (see page 66), and end functions.

Multi key

Press to display the Multitask menu. When multiple functions are running, press and hold for at least one second to switch functions. (See pages 423 and 424)

{

Private window (See page 27)

Photo light

Used for shooting in a dark place. (See page 176)

}

Strap holder

miniSD memory card slot

For inserting the miniSD memory card. (See page 396)



Dot-area (See page 28)

†

Outside camera

For taking photos of persons and/or landscapes. (See page 163) For catching sight of persons and/or landscapes during a video-phone call.

FeliCa mark

The IC card is mounted. Use the IC card function placing this mark over the scanning device (reader/writer). You cannot dismount the IC card. (See page 341)

Rear cover (See page 39)

Connector terminal

For connecting the AC Adapter (option), DC Adapter (option), or FOMA USB Cable (option).

Confirming before Use

■

Meanings of icons

: The battery level (estimate) is displayed. (See page 42)

: Displayed during All Lock. (See page 150)

: Displayed during PIM Lock. (See page 152)

: Displayed during Keypad Dial Lock. (See page 153)

: Displayed during Secret Mode or Secret Only Mode.

(See page 155) : Displayed during IC Card Lock. (See page 342) : Displayed when both Keypad Dial Lock and PIM

Lock are activated. : Displayed when both Keypad Dial Lock and Secret

Mode/Secret Only Mode are activated. : Displayed when both IC Card Lock and All Lock are

activated. : Displayed when both IC Card Lock and PIM Lock

are activated. : Displayed when both IC Card Lock and Keypad Dial

Lock are activated. : Displayed when both IC Card Lock and Secret

Mode/Secret Only Mode are activated. : Displayed when IC Card Lock, Keypad Dial Lock,

and PIM Lock are simultaneously activated. : Displayed when IC Card Lock, Keypad Dial Lock,

and Secret Mode/Secret Only Mode are

simultaneously activated.

(

pink

) :

Unread i-mode mail or an SMS message exists. (See pages 264 and 314)

(

gray

) :

The area for i-mode mail and SMS messages in the FOMA phone is full. (See pages 265 and 314)

The area for SMS messages in the UIM (FOMA card) is full.

Both the FOMA phone and UIM (FOMA card) are full.

An unread mail exists, and the area for SMS messages in the UIM (FOMA card) is full.

(

yellow

) :

An unread Message R (Request) exists. (See page 225)

(

gray

) :

The area for Messages R (Request) in the FOMA phone is full. (See page 226)

(

yellow

) :

An unread Message F (Free) exists. (See page 225)

(

gray

) :

The area for Messages F (Free) in the FOMA phone is full. (See page 226)

(

pink

) :

i-mode mail remains at the i-mode Center. (See page 268)

(

gray

) :

The box for i-mode mail at the i-mode Center is full. (See page 241)

Confirming before Use

Display

1357 9o

246 8 0 p

q 135 7

24 6 8

＊

You need to obtain a miniSD memory card separately to use the functions related to the miniSD memory card. (See page 395)

suwy{

tvxz

}

Confirming before Use

■

About the contents displayed:

●

Some characters and symbols on the display and Private window might be modified or abbreviated.

●

The explanations in this manual are mainly based on the settings at purchase so the display on your FOMA phone may

not match the explanations if you have changed the settings since purchase.

●

The color liquid crystal display uses high-precision production technology. The slightest change in the environment may

result in unlit or permanently lit pixels, but this is not a manufacturing defect.

●

The color display is shown as black and white in this manual, so the actual display looks slightly different.

(

yellow

) :

Messages R (Request) remain at the i-mode Center. (See page 226)

(

gray

) :

The box for Messages R (Request) at the i-mode Center is full. (See page 226)

(

yellow

) :

Messages F (Free) remain at the i-mode Center. (See page 226)

(

gray

) :

The box for Messages F (Free) at the i-mode Center is full. (See page 226)

i-mode mail is held at the i-mode Center while Receive Option Setting is set to “ON”. (See page 268)

: Shows the level of the received radio waves.

(Weak) (Strong) “” is displayed when out of the FOMA phone service area or where radio waves do not reach.

Displayed during Self Mode.

(See page 152)

Blinks while i-mode is activated. “ ” is displayed during data transmission while connecting to i-mode. (See pages 201 and 202)

Displayed during packet transmission. The icon differs depending on the transmission status. (See pages 483 and 498)

: Displayed during SSL transmission. (See page 201)

: Displayed while the FOMA USB Cable (option) is

connected in the Communication Mode. (See page 471)

: Displayed while the FOMA USB Cable (option) is

connected in the miniSD Mode. (See page 405)

: Displayed during infrared exchange. (See page 406)

: Displayed while the infrared remote-controller is

working. (See page 330)

miniSD memory card is inserted. (See page 396)

Inserted miniSD memory card cannot be used. (See page 396)

miniSD memory card is inserted, and the FOMA USB Cable (option) is connected in the miniSD Mode. (See page 405) (Does not appear on the Private window.)

: Displayed during a voice call.

: Displayed during a video-phone call (64K).

: Displayed during a video-phone call (32K).

: Displayed during 64K data transmission.

: Displayed during Multitask.

While multiple functions are active, “ ” is displayed. (See page 423)

Displayed while Vibrator is set to “ON”. (See page 117)

: Displayed while Ring Volume is set to “Silent”. (See page 66)

: Displayed during Manner Mode. (See page 122)

: Displayed while Remote Observation is set to “ON”.

(See page 89)

: Displayed during Drive Mode. (See page 67)

: Displayed when the call charge has exceeded the

specified limit. (See page 445)

: Displayed while an alarm for “Alarm”, “Schedule”, or

“ToDo” is set. If an alarm is set for that day, “ ” is displayed. (See page 427)

〜

: Shows the number of record messages (0-5). (See page 70)

〜

: Shows the number of voice mail messages (1-9) held at the Voice Mail Center. If 10 or more messages are held, “ ” is displayed. (See page 454)

{

Displayed while Display Light is set to “OFF”.

(See page 133)

: Displayed while Side Keys Guard is set to “ON”.

(See page 154)

}

: Displayed during Timer Lock. (See page 342)

Confirming before Use

Display Icons Use to select an icon

The description of the selected icon appears.

The symbols at the top of the display (such as ) are called icons. You can check the meanings of the icons on the display.

Displaying Description of Icons

・

Moves the cursor or highlighted display up. (Press and hold to scroll continuously.)

・

Scrolls while a site or mail text is displayed.

・

Press from the Stand-by display to bring up the display for selecting a Phonebook function (Phonebook menu).

・

Press and hold for at least one second to raise the earpiece volume. (See page 65)

・

Converts entered characters to katakana or kanji. (See page 519)

Right/Redial

・

Moves the cursor to the right.

・

Press from the Stand-by display to bring up

the Redial List. (See page 53)

・

Scrolls forward by page. (Press and hold to

scroll continuously.)

・

Moves to the next page while displaying a site.

Left/Received Call Record

・

Moves the cursor to the left.

・

Press from the Stand-by display to bring up the Received Call Record List. (See page 63)

・

Scrolls back by page. (Press and hold to scroll continuously.)

・

Returns to the previous page while displaying a site.

OK key

・

Fixes the operation.

Down

・

Moves the cursor or highlighted display down.

(Press and hold to scroll continuously.)

・

Scrolls while a site or mail text is displayed.

・

Press from the Stand-by display to bring up

the Phonebook Search display.

(See page 101)

・

Press and hold for at least one second to

lower the earpiece volume. (See page 65)

・

Converts entered characters to kanji or

katakana. (See page 519)

■

Operating Command Navigation key

Navigation Displays

When you want to execute an operation on the display, press the corresponding key as below.

■

Operation display examples and basic key assignments

Indicates the operation you can perform with the

key.

Indicates the operation you can perform with the

key.

Indicates the direction in which you can scroll and

select items.

Indicates the operation you can perform with the

key.

Confirming before Use

■

Missed calls

When the FOMA phone is closed, “Missed call” appears on the Private window. Press to display Missed Call Record. The name is displayed for the missed call coming in from the party stored in the Phonebook. When there are multiple missed calls, up to three missed call records are displayed each time you press .

●

f you have received 30 or more incoming calls after a missed call, the record for the missed call disappears.

●

Missed call records are not displayed while a function for Tool Group (see page 423) is activated.

●

After you display a missed call record, “Missed call” disappears.

■

New mail

When the FOMA phone is closed, “New mail” appears on the Private window. Press to display the received date and time, sender’s address (name), and subject of the received mail. The sender’s name is displayed for the mail coming from the party stored in the Phonebook. When you receive an SMS message, “SMS” is displayed for subject. When you receive multiple mail messages at a time, up to three mail messages are displayed each time you press .

●

For this function, you need to trace “Private window” →“Private window setting” →“Display information”, and set “Mail” to “ON”.

●

The received date and time, sender’s address (name), and subject of the mail in the box or folders with security are not displayed.

●

After you display the received date and time, sender’s address (name), and subject of the received mail, “New mail” disappears.

●

Any information does not appear on the Private window when a mail message arrives during a voice call or video-phone call, or on the display other than the Stand-by display while “Receiving display” is set to “Operation preferred”.

You can display various information such as a clock and icons on the Private window like the following examples:

●

The display for the schedule alarm differs according to the schedule icon you set. (See page 429)

Information

Private Window

Enlarge Clock Display

You can switch the size of the clock by pressing

Confirming before Use

About Dot-area

You can display various information and illustration (dot-area data) depending on the dot-area setting or status of the FOMA phone. The dot-area data appears for about 15 seconds maximum. See page 130 for how to set the dot-area.

・

You can display various dot-area data each time you close the FOMA phone.

・

You can display the dot-area data automatically at the specified time (0 minutes every hour).

・

Press to display various dot-area data.

<Example> When clock is displayed

The time when is pressed is displayed in flow from the right to left.

■

You can do the following by using i-αppli:

・

You can use “

ﾄﾞｯﾄｸﾘｴｲﾀｰ

(Dot Creator)” to create and display your preferred dot-area data.

・

You can display the dot-area data by linking to “

ｲﾝﾌｫｽｸﾘｰﾝ

(Info-screen)”.

●

Refer to “

別冊内蔵ｉアプリガイド

(Pre-installed i-αppli guide)” for detailed operations of

“

ﾄﾞｯﾄｸﾘｴｲﾀｰ

(Dot Creator)” and “

ｲﾝﾌｫｽｸﾘｰﾝ

(Info-screen)”.

●

The dot-area data is not displayed when “Dot-area” is set to “OFF” or during battery charge.

●

When the time passes while it is displayed on the dot-area, the time on the dot-area may lag behind the time on the Private window.

●

The dot-area data that notifies the mail arrival does not appear when a mail message arrives during a voice call or video-phone call , or on the display other than the Stand-by display while “Receiving display” is set to “Operation preferred”.

Information

Confirming before Use

Press to bring up the Main menu so that you can execute, set, or check functions.

■

Scroll Selection The Main menu consists of nine main menu icons indicating respective functions and it is divided into four groups (Mail, i-mode, Setting, and Tool). (See page 423) If you select a main menu icon on the Main menu, the display for selecting a sub-menu item is displayed. If you further select a sub-menu item, the display for selecting a lower sub-menu item is displayed. By repeating selecting, you can set and check the function.

■

Menu Number Selection

You can display some functions by pressing + the menu number.

●

The FOMA phone provides “Multitask”, where you can use a function such as a voice call, which does not belong to any of the groups, and a function from each of the Mail group, the i-mode group, the Setting group and the Tool group (maximum three functions) simultaneously. (See page 423)

Method for Selecting Menu

Scroll selection is explained below using the example of selecting the function “Quality alarm”.

Select a main menu icon from the menu function

Select from the Main menu.

●

The enlarged icon is the main menu icon currently selected.

●

Press to move to the icon below, to move to the icon above, to move to the icon on the left, and to move to the icon on the right.

●

Press and hold to scroll the icons continuously.

●

The guidance for the selected icon is displayed. (You can set not to display this guidance by “Menu display set”.)

●

If you have not touched the key for 15 seconds, the Stand-by display returns.

Scroll Selection

Guidance for the selected icon

Confirming before Use

Select the sub-menu item from the menu function

Select “Talk” from “Settings”.

Select the desired lower sub-menu item (function)

Select “Quality alarm” from “Talk”.

■

To check the settings of the function from the selection display for the lower sub-menu item

If you set “Menu display” of “Menu display set” to “Detail”, you can check the settings and menu number of the function.

Main menu icon

Setting

Menu number

Previous and next lower sub-menu items

Function name

Current page Total pages

●

The highlighted item is the currently selected one.

●

Press to move to the item below, and to move to the item above.

●

Press and hold to scroll the items continuously.

●

When the items are listed over multiple pages, the total number of pages and the current

page number are shown at the upper right of the display.

●

Press or to scroll by page.

●

Press to display the previous lower sub-menu item, and to display the next lower sub-menu item.

●

Press and hold to scroll the items continuously.

Confirming before Use

Set or check the selected function. Some menu items have even more detailed menus. The example below shows how to set “Low tone” for “Quality alarm”.

Set or check the function

■

When the “YES/NO” or “ON/OFF” prompt appears

●

When the “YES/NO” prompt appears

1. Press to select “YES” or “NO”.

2. Press .

●

When the “ON/OFF” prompt appears

1. Press to select “ON” or “OFF”.

2. Press .

For Reset setting

For Keypad sound

■

When the display prompts you to enter your Terminal Security Code

With some items, the prompt for entering your Terminal Security Code appears before the setting display comes up. You need to enter your Terminal Security Code to set or check the function.

●

See page 146 for the Terminal Security Code.

1. Enter your Terminal Security Code and press . When you enter your Terminal Security Code, this is indicated by “_” ; the number you enter is not shown.

For Reset settings

●

The highlighted item is the currently selected one.

●

Press to move to the item below, and to move to the item above.

●

Press and hold to scroll the items continuously.

●

There are several methods of setting functions: Selecting from a list as shown in the example of operations, selecting “YES/NO” or “ON/OFF” and entering a numeric value.

●

The items you cannot select are grayed out.

Information

Confirming before Use

■

Function menu display

●

When “ ” appears at the lower right of the display, press to bring up the Function menu. The contents of the Function menu depend on the display from which you bring up the Function menu. The items you cannot select are grayed out.

●

Selectable items such as “Save”, “Edit” or “Delete” in each operation appear on the display.

●

When the items are listed over multiple pages, the total number of pages and the current page number are shown at the upper right of the display. From the item at the top or bottom of the Function menu, press to go to the previous page or the next page. Press or to scroll by page.

Menu number selection is explained below using the example of selecting the function “Quality alarm”.

From the Stand-by display, press .

Bring up the function using the menu number

●

See “Function List” for details about menu numbers. (See page 532)

Information

Menu Number Selection

■

To select items quickly <Direct selection>

You can select them also by simply pressing the numeric keys corresponding to the item numbers.

Item number

■

To finish or cancel the menu operation

●

To finish the menu operation When you have set each function, the selection display for the lower sub-menu item comes up (or the Stand-by display returns in some cases). When you have finished setting the function, press . This ends the menu operation and the Stand-by display returns (except during Multitask).

●

To cancel the menu operation Press to cancel setting midway. The contents of the settings are abandoned and the Stand-by display or the display prior to starting the setting operation returns. In some cases, a prompt comes up to confirm whether you really want to abandon the settings. You can press to return to the previous operation.

Confirming before Use

Talk Quality alarm

No tone ······Does not sound. High tone····High alarm sounds. Low tone ····Low alarm sounds.

In this manual, the description for the command navigation key operation (selection of top, bottom, left, or right and press of after a function item is selected) is simplified.

Description Example for Operations

Description Example for Operation

Description Example for Function Menu

Main menu icon Sub-menu item Function name of lower sub-menu item

Step No.

Displayed item in the Function menu

Operating procedures after selecting an item in the Function menu

Displayed item

Function menu

Delete all

Operations

Enter the Terminal Security Code YES

●

To cancel, select “NO” and press .

Press three times.

Shortcut menu is displayed.

●

You can display the guidance for the selected icon. (You can set not to display this guidance by “Menu

display set”.)

●

Press twice to display the Private menu.

●

If you have not touched the key for at least 15 seconds, the Stand-by display returns.

Select an icon

Displaying Shortcut Menu

You can start a camera with the settings for the required purposes, and can start the Picture viewer and i-motion Player by easy operations.

Confirming before Use

■

Icons

CAMERA You can start a camera in Photo Mode.

MOVIE You can start a camera in Movie Mode.

BAR CODE READER You can read in JAN codes, QR codes and view the read data.

TEXT READER You can read in alphanumerics and view the read data.

My picture You can view still images shot by a camera or downloaded from sites.

i-motion You can view moving images recorded by a camera or i-motion movies obtained from sites.

GUIDE This is available in Japanese Mode only.

You can check the functions you want to know or operating method you want to use.

SD-Audio You can play the music saved to the miniSD memory card.

SELF MODE You can set Self Mode to block incoming calls while you are recording moving images.

<Guide>

When You do not Remember Key Operation

You can search for the functions you want to know and use, and then confirm the operating methods. You can execute some functions from “

使いかたナビ

(Guide)”. This function is available in Japanese Mode

only.

使いかたナビ

(Guide)

基本の操作

(Basic operations) ····························Displays the basic functions. Skip to step 6.

おすすめ機能

(Recommendable functions)·········Displays the recommendable functions. Skip to step 6.

機能検索

(Function search)·································Searches for and displays functions.

検索履歴

(Search history) ···································Displays up to 30 search histories. Skip to step 6.

●

You can start up “

使いかたナビ

(Guide)” also by selecting from the Shortcut menu and pressing .

●

Select a required item and press ( ); then the detailed operating methods are displayed.

Select a searching method

音声入力キーワード検索

(From your voice)········Vocalize a keyword for search.

文字入力キーワード検索

(From your words) ······Enter a keyword and retrieve. Skip to step 5.

索引検索

(From index) ········································Retrieves functions with Japanese syllabic order. Press or to display

the preceding or following row. Skip to step 6.

機能一覧検索

(From Function List) ·····················Retrieves from the function list. Skip to step 6.

●

Select each item required and press ( ); then the detailed operating methods are displayed. If you select “

音声入力キーワード検索

(From your voice)” and press ( ), select “

音声入力キーワード検索

(From your voice)” or “

音声入力のしかた

(How to input)” and press .

If you select “

文字入力キーワード検索

(From your words)” and press ( ), select “

文字入力キーワード検索

(From your words)” or “

文字入力のしかた

(How to input)” and press .

＊

You need to obtain a miniSD memory card separately to use the functions related to the miniSD memory card. (See page 395)

Confirming before Use

Enter a keyword

Up to 50 search results are displayed.

●

You can enter up to 24 full-pitch or 48 half-pitch characters.

●

See page 510 for how to enter characters.

●

When “Select language” is set to “英語(English)”, you cannot operate this function.

●

The keywords you can input by the voice are limited to the ones that have been pre-installed to the FOMA phone. If the vocalized keyword is not detected easily, vocalize a different word.

●

The voice detecting start tone sounds at Level 2 of the sound volume.

●

The voice detecting start tone does not sound during Manner Mode.

●

When the keyword is not detected, the detection rate may rise by changing “Identify as” (see page 112).

Information

Function menu

1件削除

(Delete this)

全削除

(Delete all)

Operations

YES

●

To cancel, select “NO” and press .

YES

●

To cancel, select “NO” and press .

While the search history is displayed ( ) Do the following operations.

Function Menu while Search History is Displayed

Select a function

この機能を使う

(Operate function) ·····················Executes the function. Operate each function.

操作のしかた

(How to operate)···························Displays the operating method.

機能の説明

(Description)·····································Displays explanations for the function.

Using the UIM (FOMA Card)

The UIM is an IC card that holds your information such as phone numbers. It can hold data such as the Phonebook entries and SMS messages as well. By replacing the UIM, you can operate multiple FOMA phones for multiple purposes. You cannot use the FOMA phone for voice and video-phone calls, i-mode, sending/receiving mail, or packet transmission unless the UIM is inserted. You can set two security codes, PIN1 code and PIN2 code, for the UIM. (See page 146) Refer to the UIM manual for details about how to use it. When inserting or removing the UIM, take care not to accidentally touch or scratch the IC.

Insert/Remove UIM (FOMA Card)

You need to remove the battery before you insert the UIM. (See page 39)

■

Inserting

Pull the claw to pull the tray out.

●

Pull out the tray straight until it clicks.

Push the tray inwards.

●

Push the tray into the bottom until it is fixed.

Follow step 1 of “Inserting” to pull out the tray and remove the UIM

Place the UIM on the tray with its IC-side facing up.

●

Fit the cut corners of the UIM and tray in place.

Claw

Cut corner

IC-side is faced up

■

If the tray is disengaged

Fit and push it straight into the guide rail.

■

Removing

●

Before inserting or removing the UIM, turn off the power and close the FOMA phone.

●

Make sure that the tray for the UIM is not drawn out when attaching the battery. If the tray is drawn out, the battery cannot be attached. Note that if the battery is forcibly attached, the UIM or tray may be damaged.

●

Take care not to force the UIM into place because this can break it.

●

Take care not to lose the UIM once you remove it.

Information

Confirming before Use

Functions Restricted by UIM (FOMA Card)

The UIM has a restriction function to protect your data and files. If you obtain data and files by the method below with the UIM inserted, restrictions are automatically set to them.

・

When downloading images or melodies and so on, from sites or Internet web pages

・

When receiving i-mode mail with file attachments

●

Data and files set with the UIM restrictions can be read, played back, started up, edited, attached to mail, and transferred by the infrared exchange function, only when the UIM that acquired them is inserted.

●

If the UIM used to obtain data and files is not inserted, or if it is replaced with another UIM, the restrictions will protect the data from being read, played back, started up, edited, attached to mail, and transferred by the

infrared exchange function. In the explanation hereafter, the UIM used to obtain data and files is referred to as “your UIM” and other UIMs as “another person’s UIM”.

●

When the UIM is not inserted, or when another person’s UIM is inserted, the following types of data and files are displayed with the restrictions symbol, “ ”:

・

Melodies, images, i-motion movies, i-αppli, Chara-den images, or PDF data downloaded or obtained from sites or Internet web pages

・

Downloaded dictionaries

・

Screen memos containing melodies, images, i-motion movies, Chara-den images or downloaded dictionaries

・

Files (melodies, images, Chara-den pictures, or Chara-den movies) attached or pasted to i-mode mail in the Inbox

・

Files (melodies, images, i-motion movies, Chara-den pictures, or Chara-den movies) attached to i-mode mail in the Outbox, or Draft, except the data edited or taken with the FOMA phone

・

Messages R/F with files (melodies or images) attached or pasted

・

Images inserted into Deco mail text

※

This function applies to the pre-installed i-αppli and Chara-den images if they are reinstalled (upgraded) from a site.

●

The data set with the UIM restrictions appear on the preview display as shown on the right.

If the UIM used for acquiring the data or messages is inserted, you can browse or play back UIMrestricted data.

Unless the UIM used for acquiring the data or messages is inserted, you cannot browse or play back UIM-restricted data.

Your UIM

Another person’s

UIM

Replacing UIMs

About Password of UIM

You can set two passwords, PIN1 and PIN2, for a UIM. (See page 146)

♪

Confirming before Use

■

WORLD WING

WORLD WING is a DoCoMo FOMA international roaming service that enables you to use the mobile phone number you are using in Japan for receiving or making calls overseas by inserting the UIM (green) into the mobile phone for international use (GSM format) supporting this service. WORLD WING is available on a subscription basis. Contact “DoCoMo Information Center” on the back page of the manual for inquiries about subscription.

Differences of UIM (FOMA Card)

●

When the UIM restrictions are set for data and files, you cannot set those data and files for the functions such as “Display setting” and “Select ring tone” when another person’s UIM is inserted instead.

●

If you have set the data and files with the UIM restrictions for the functions such as “Display setting” and “Select ring tone”, these will work with their default settings if you remove your UIM or insert another person’s UIM. If you replace that UIM with your UIM, then your settings will be enabled again. <Example: Setting ring tone for “Melody A” set with UIM restrictions> When you remove your UIM or replace it with another person’s UIM, the setting displayed for “Select ring tone” will be “Melody A”, but the actual ring tone will be the same as the setting at purchase. If you insert your UIM, “Melody A” will be played back for incoming calls again.

●

UIM restrictions are not set for the data acquired using the infrared exchange function or data transmission (OBEX) function or the still images/moving images edited or taken with the FOMA phone.

●

Even when another person’s UIM is inserted, data and files set with the UIM restrictions can be moved or deleted.

●

You cannot launch the i-αppli set with the UIM restrictions even if you select the highlighted text from the detailed i-mode mail display unless the UIM that was inserted at download is inserted.

Information

If you are using the blue UIM with your FOMA phone, note that some specifications differ from those of the green UIM.

Functions

UIM UIM

Reference

(blue) (green)

Number of digits of the phone number that can be stored

20 max. 26 max. See page 98

in the UIM Phonebook

Operation of user certificate to use FirstPass Cannot be used Can be used See page 232

WORLD WING Cannot be used Can be used

−

Using service dialing of “DoCoMo repair counter” and “General inquiries <DoCoMo Information Center>”.

Cannot be used Can be used See page 463

Confirming before Use

Attach/Remove Batteries

■

Attaching

While pressing the “ ”

part, slide the rear cover

(2 mm or more) to unlock in

the direction of the arrow.

Insert the battery pack in the direction A with the arrow mark facing upwards and push it in the direction B.

●

Securely fit the claws of the battery pack into the grooves of the phone.

Slide the rear cover in the direction of the arrow and attach it in place.

■

Removing

●

Turn the power off before replacing the battery.

●

If you try to force the battery into place, you could damage the charging terminals of the FOMA phone.

●

For details about the battery, see the manual for Battery Pack P06.

Information

Arrow

While pressing the “ ”

part, slide the rear cover

(2 mm or more) to unlock in

the direction of the arrow.

Take hold of the projection of the battery pack to lift it up.

Projection

Confirming before Use

Use the FOMA phone’s dedicated Battery Pack P06 to get the most out of your FOMA phone.

Battery life?

●

Batteries are consumables. The usage time of all chargeable batteries shortens slightly each time they are charged.

●

The battery’s life is considered to be exhausted when the usage time of the battery after charging is about half the time it was at purchase. (The life of the battery is about one year. However, it might be shorter if used very frequently.)

Charging

●

For details, refer to the manuals for the FOMA AC Adapter 01 (option), FOMA AC Adapter 01 for both overseas and domestic usage (option), and FOMA DC Adapter 01 (option).

●

For charging the battery via the AC or DC Adapter, the battery must be attached to the FOMA phone.

●

During charging, you can still answer calls if the FOMA phone is turned on. This will consume the charged amount so that charging will take longer.

●

If you have a long time video-phone call during charging, the temperature inside the FOMA phone may rise and charging may be suspended. In such a case, wait for a while and try charging again.

●

Remove and insert the connector slowly and carefully, without using unnecessary force.

Do not charge for long periods of time (several days) with the FOMA phone switched on.

●

Do not leave the FOMA phone power on for long periods of time while charging. Otherwise, when charging finishes, the FOMA phone will attempt to receive power from the battery so that when you actually use the FOMA phone, you will be able to do so for just a short amount of time before the battery alarm sounds. If this happens, charge the battery correctly. When charging the battery again, first remove the FOMA phone from the AC Adapter (or Desktop Holder) or DC Adapter and then set it again.

For environmental protection, bring the exhausted battery to an NTT DoCoMo,

dealer, or recycle shop.

Li-ion

Charging the FOMA Phone

Continuous standby time Standstill : Approx. 460 hours

In motion : Approx. 350 hours

Continuous talk time Voice call : Approx. 140 minutes

Video-phone call : Approx. 90 minutes

Estimated usage time for battery

(The usage time for the battery varies with the charging time and the remaining life of the battery.)

※

Continuous talk time is the estimated time that the FOMA phone can be used for calls when radio waves can be sent and received normally.

※

Continuous standby time is the estimated time when radio waves can be received normally. The standby time could be about half of this estimate depending on the battery level, function settings, other ambient conditions such as temperature, and the status of radio waves in the area (weak or no radio waves, for instance). When you use i-mode communications, the talk/transmission time and standby time will be shorter. Further, even if you do not make calls or execute i-mode transmission, the talk/transmission time and standby time will be shorter if you compose i-mode mail, start up a downloaded i-αppli or the i-αppli Stand-by display, execute data transmission or Multiaccess, or use SD-Audio.

※

The continuous standby time for standstill is the average number of hours you can use the FOMA phone in standstill status when it is closed and can receive radio waves normally.

※

The continuous standby time for in motion is the average number of hours you can use the FOMA phone in the combined status of “standstill” “moving” and “out of service area” when it is closed, in an area where it can receive radio waves normally.

AC Adapter Approx. 130 minutes DC Adapter Approx. 130 minutes

Estimated time for charging battery

※

The estimated charging time is for when the FOMA phone is off and the battery is being charged from empty. The charging time will be longer if you charge the battery with the power turned on.

●

You may not be able to store still or moving images when the battery is completely flat or when the battery is removed.

Information

Confirming before Use

Charge with AC Adapter and Desktop Holder

Connect the AC Adapter (option) to the Desktop Holder (option).

Insert the AC Adapter’s plug into a power socket.

Set the FOMA phone onto the Desktop Holder.

Push it until it clicks. Check that the Call/Charging indicator lights in red. When the Call/Charging indicator flickers, dismount the AC adapter and battery pack from the FOMA phone and then re-mount them for charging. If the symptom persists, troubles with the AC Adapter, Desktop Holder or battery pack may be involved, so consult one of the DoCoMo shop counters.

●

Attach the battery pack to the FOMA phone beforehand.

●

Be sure to set the FOMA phone firmly onto the Desktop Holder. Also, be careful that the connector cap or a commercial strap is not caught between the FOMA phone and Desktop Holder.

●

Charging can be done even when the FOMA phone is opened.

When charging completes, take the FOMA phone off the Desktop Holder.

●

Unplug the AC Adapter from the power socket when you are not going to use it for a long time.

Desktop Holder P08

FOMA AC Adapter 01

100 VAC

●

You can take calls even during charging when the power is turned on. (Charging will take longer in this case.)

●

If the power is turned on, the “Charge sound” beeps at the volume set for “Phone” of “Ring volume” when charging starts and ends. (See page 120)

●

You cannot display any information on the dot-area while charging except when the dot-area lights at a camera start-up.

●

Make sure that you plug in or out the AC adapter connector horizontally.

●

The FOMA AC Adapter 01 uses 100 VAC only.

●

You cannot charge the battery pack by itself. The battery pack must be attached to the FOMA phone for charging.

●

If the fuse blows off when charging with the DC adapter, be sure to use a 2A fuse. The 2A fuse is consumables, and it is available at auto parts stores in your neighborhood.

Information

Plug horizontally with engraved side facing down

■

DC Adapter (option) With the DC Adapter, you can use a cigarette lighter socket (12 V/24 V) to charge the FOMA phone with the battery pack attached. Read the manual for the FOMA DC Adapter 01 for details.

Call/Charging indicator “ ” display

Charging Lights in red Blinks

Charging completed Off Lights

■

Indicator and display during charging and when charging is

completed

※

When the FOMA phone is turned off, “ ” does not appear. If you start charging with the battery flat, the Call/Charging indicator might not light immediately; however, charging itself has started.

■

Charge with the AC Adapter only

The Call/Charging indicator (lights in red)

Plug horizontally with engraved side facing up

Open the connector cap

①

②

Confirming before Use

Confirming Battery Level

When the FOMA phone is turned on, an estimate of the battery level is indicated by the icon.

・

Almost full ············································· (green)

・

Getting low ············································ (green)

・

Almost empty ········································ (red)

●

Charge the battery when it is almost empty.

Confirm by Display and Tone

You can check an estimate of the battery level by the display and sound.

Other settings Battery level

●

The pictograph disappears in about three seconds.

●

The battery tone does not sound while “Manner mode”, “Super silent”, or “Original” is activated, or “Keypad sound” is set to “OFF”.

Almost full Getting low Almost empty

※

Charge the battery soon.

Three beeps Two beeps One beep

●

When “Open phone” is set to “Answer”, you can start talking just by opening the FOMA phone during ringing.

●

The FOMA phone might not open fully, depending on its direction.

●

When you open the FOMA phone by pressing the button, be careful not to drop it by its rebound.

●

You need to fold the FOMA phone manually. If it does not close, open it fully and then close it.

Information

■

When the battery is running out

The display on the right appears and the empty battery alarm sounds for about 10 seconds. To stop this alarm, press any key other than and . About one minute later, the FOMA phone will be turned off.

●

During a call, a beeping tone also notifies you of the empty battery. About 20 seconds later your call will be cut and then one minute later the FOMA phone will be turned off.

●

The battery tone does not sound while “Manner mode” or “Super silent” is activated, or when “LVA tone” is set to “OFF” in “Original”.

<One-push Open>

Opening the FOMA Phone by Using a Button

You can open the FOMA phone easily by pressing the button. You can open it also manually without using the button.

Press the one-push open button.

The FOMA phone opens up.

Confirming before Use

Press and hold for at least one second.

After the Wake-up display (see page 126) is displayed, the Stand-by display appears.

●

If you have stored many Phonebook entries or mail messages, it may take a while for the display to appear.

●

If the clock is set, the current date and time are shown. When Set Time is set to “Automatic”, the time is automatically compensated.

●

When “ ” is displayed, the FOMA phone is out of the service area or in the place where the radio waves do not reach. Move to a location where “ ” disappears.

●

When “PIN1 code entry set” of “PIN setting” (see page 148) is set to “ON”, enter the four- to eight-digit PIN1 code after you turn on the power. When the correct PIN1 code is entered, the Stand-by display appears. See page 146 for PIN1 code.

●

When “Auto reset setting” of “Notice call cost” is set to “ON”, enter the four- to eight-digit PIN2 code after you turn on the power. When the correct PIN2 code is entered, the Stand-by display appears. If you press or without entering the correct PIN2 code, “Auto reset setting” is set to “OFF” and the Stand-by display appears. See page 146 for PIN2 code.

●

If the UIM is not attached or there is something wrong with it,

a warning message will come up.

<Stand-by display>

When the UIM is

malfunctioning

When the UIM is not

attached or damaged

■

To turn the power off

Press and hold for at least two seconds.

The exit display appears and the power goes off.

●

You cannot turn on the power immediately after turning off the power. Wait a few seconds.

●

If “Starting system Wait a minute” is displayed when you turn on the power, wait for a while and then proceed.

●

The radio waves become unstable when you move around during a call. Because of the nature of the digital technology, your call might be cut off suddenly. Try to keep displayed when using the FOMA phone.

●

The default Stand-by display differs depending on the color of the handset. In this manual, the descriptions for the Stand-by display are given using the “Silver x GEKKA” color handset. See page 125 for the default Stand-by displays of the handsets in other colors.

Information

■

When you have not operated FOMA phone for a certain period

If you have not operated the FOMA phone for a certain period while it has been turned on, the indication on the display and Private

window goes off and the Command Navigation key flickers at about five-second interval when the FOMA phone is opened. The

display comes on again when you perform any operation.

●

You can set the display to remain on, for even when the FOMA phone has not been operated for a certain period, by setting “Power saver mode” of “Display setting” to “OFF”. (See page 128)

Turning Power On/Off

ディスプレイ

(Display)

バイリンガル

(Select language)

Japanese (

日本語

)······Switches to Japanese.

English (

英語

)··············Switches to English.

Setting at purchase

Japanese

Switching to English

Confirming before Use

●

If there is any unset function, the unset function is displayed every time the power is turned on.

●

You cannot set the initial settings during All Lock or Keypad Dial Lock.

●

The display for the initial settings is displayed also after you execute “Initialize”.

●

The completed settings are valid even when total setting is interrupted by an incoming call or canceled by pressing or midway.

●

When the clock is set and the power is automatically turned on by an alarm notification, the display for the initial setting does not appear even if there is any unset function.

Information

Turn the power on YES

●

When “PIN1 code entry set” of “PIN setting” (see page 148) is set to “ON”, enter the four- to eight-digit PIN1 code after you turn on the power. See page 146 for PIN1 code.

●

To cancel, select “NO” and press .

If the date and time, Terminal Security Code, and Keypad Sound are not set, the display for the initial setting appears when the power is turned on. You can set the initial settings also from each menu function separately.

Executing Initial Settings

Set the date and time.

●

-You can select “Automatic” or “Manual” for setting the time. (See page 45)

Set the Terminal Security Code.

●

-You can set the Terminal Security Code required for setting functions.

1. Enter “0000”

2. Enter the new Terminal Security Code (four to eight digits) YES

●

To cancel, select “NO” and press .

●

See page 146 for the Terminal Security Code.

Set the Keypad Sound.

●

-You can perform operations confirming whether keys are pressed securely by the sound.

1. ON or OFF ON ·········Makes the keypad sound. OFF ·······Does not make the keypad sound.

●

See page 120 for Keypad Sound.

●

You cannot switch languages while another function is working.

●

When the UIM is inserted, the “

バイリンガル

(Select language)” setting is stored in the UIM.

Information

●

The following functions are different between Japanese display and English display:

Functions Japanese English

“Display” of

日本語

(Japanese) Not available

Main Window

英語

(English) ON

Clock OFF OFF

Info Notice

電子音

(Electrical tone)

Setting

ボイス

(Voice) Not available

OFF OFF

使いかたナビ

Available Not available

(Guide)

Confirming before Use

Notifying the Other Party of Your Phone Number

You can set the FOMA phone to send your phone number to the called party’s phone when dialing. Your phone number is valuable information, so take utmost care when notifying your phone number. This function works only when the other party’s phone is the digital terminal such as the FOMA phone or mobile phone which has the function to display the caller ID.

●

The three setting methods for Notify Caller ID are available as follows:

Setting method Reference

Setting your Caller ID per call See page 46 Prefixing “186/184” See page 46 Setting on the network beforehand

See page 461

Clock Set time

Automatic·····················

Corrects the date/time automatically. The setting is completed

If the time is not automatically corrected such as when the date/time has not been set and

“”

is displayed, the display for manually correcting the time appears. Follow step 2 to set the date/time. However, the display for manually correcting the time does not appear when you set the date/time by Initial Setting.

Manual ·························Sets the date/time manually.

●

When “Notice call cost” is set to “ON”, the Terminal Security Code Entry display appears. Enter the Terminal Security Code

and press . See page 146 for the Terminal Security Code.

●

You can set the clock also during a call.

●

If you enter a wrong number (such as “13” for the month) and press , the entry is invalid. Enter the correct number.

●

You cannot use the following functions unless the clock is set: Current time display during calls (see pages 48 and 74), Calendar (see page 125), Alarm (see page 425), Schedule (see page 428), ToDo (see page 435), Software update (see page 569), i-αppli auto start (see page 332), the pattern data update of the Scanning function (see page 574), and Auto Reset Setting of Notice Call Cost (see page 444).

●

The FOMA phone has an internal backup battery. The set time is stored in the internal backup battery so is kept even when you change the battery. However, the time could be reset if the battery is detached for two or more weeks. In this case, charge the FOMA phone and then set the clock again. Also, when using the FOMA phone for the first time after purchase, attach the battery to the FOMA phone and then charge it. This charges the internal backup battery as well.

●

This function supports clock settings from 00:00 on January 1, 2005 through 23:59 on December 31, 2037.

Information

Enter year, month, date and time

Use to move the cursor and the numeric keys to enter numbers.

●

Enter the A.D. year.

●

Enter the time in the 24-hour format.

●

To enter one-digit numeral for the date and time, enter two digits beginning with “0” as in “01” to “09”.

●

The set date and time will appear on the Stand-by and other displays.

■

About time correction function

The time displayed on the FOMA phone is corrected when the power is turned on, according to the clock information obtained from the DoCoMo network. When the date/time has not been set, the time is set by receiving the clock information. When the date/time has been set, the time is corrected by setting “Set time” to “Automatic”. Then, the time is corrected at 3 a.m. (during standby). If you want to set the time with a lag, set the time manually. When you re-set to “Automatic”, turn the power off and on and then set to “Automatic”.

●

You cannot correct the time while another function is working, at power on after software update, when the UIM is not inserted, or while an animation or Flash movie set for the Stand-by display is played back. In addition, you might not be able to correct the time depending on the radio wave conditions, the timing the FOMA phone is turned on, or the i-

ppli software set for the i-αppli Stand-by display.

●

If no clock information is obtained by the FOMA phone, the time is not corrected by setting “Set time” to “Automatic” or even when 3 a.m. arrives.

●

Some few second errors might occur.

You can select whether to correct the time automatically or set it manually. To set the date/time manually, set

“Set time”

“Manual”

Setting at purchase

Automatic

Setting Date and Time

Confirming before Use

Confirming Your Own Number

You can display your phone number (own number). The phone number stored in the UIM is displayed as “Own number”.

You can select whether to notify the other party of your phone number also by entering “186 (or :31#)/184 (or #31#)” before the party’s phone number.

■

To notify the Caller ID (Effective when “Activate” of “Caller ID notification” is set to “OFF”)

186 (:31#) + +

■

Not to notify the Caller ID (Effective when “Activate” of “Caller ID notification” is set to “ON”)

184 (#31#)+ +

Destination phone number

●

When you dial out and hear a message requesting your Caller ID, set the FOMA phone to notify your Caller ID and redial.

Information

Own number

If mail address 1 is stored, you can switch displays by pressing .

●

See page 440 for storing/displaying personal data.

●

You can send your own number data by touch-tone signals during a call by pressing ( ) from the display on the right and pressing .

●

“186/184” or “:31#/#31#” is added to the beginning of a redial item/dialed call record and then stored.

Information

Enter a phone number, or bring up the detailed display of a Phonebook entry, redial item, dialed call record, or received call record.

()Notify caller ID

Don’t notify/OFF···········Does not notify your phone number. Notify caller/ON············Notifies your phone number. Cancel prefix················Activates the setting for “Caller ID Notification” on page 461.

Set Caller ID Notification when Making a Call

Each time you dial out, you can set whether to notify your phone number.

Making Calls/Receiving Calls

Making Calls

Making a Call·································································································································· 48 International Calls ·····························································································<WORLD CALL> 50 Making an International Call Easily ···············································<International Dial Setting> 50 Switching from a Voice Call to Video-phone Call ······································································· 53 Redialing Phone Numbers You have Dialed ································································<Redial> 53 Sending Touch-tone Signals Quickly ····································································<Pause Dial> 55 Storing Prefix Numbers ·····················································································<Prefix Setting> 57 Making a Call with Specified Subaddress ·············································<Subaddress Setting> 58 Selecting Alarm for Reconnecting···························································<Reconnect Control> 58 Reducing Surrounding Noise to Make Voice Clear····································<Noise Reduction> 59 Switching to Hands-free·························································································<Hands-free> 59 Using Hands-free Compatible Devices ························································<USB Hands-free> 59

Receiving Calls

Receiving a Call ····························································································································· 60 Setting Response of Key Operation for Answering Incoming Calls ··········<Answer Setting> 61 Setting Response for Opening FOMA Phone during Ringing··························<Open Phone> 62 Setting Response for Closing FOMA Phone during a Call ·······························<Fold Setting> 62 Using Received Call Record············································································<Received Calls> 63 Adjusting Earpiece Volume ·········································································<Earpiece Volume> 65 Adjusting Ring Volume ·······················································································<Ring Volume> 65

When You Cannot or Could not Answer the Call

Putting an Incoming Call on Hold ··············································································<On Hold> 66 Putting a Call on Hold during a Call ···········································································<Holding> 66 Setting Hold Tone ················································································<Call Response Setting> 67 Using Driving Mode································································································<Drive Mode> 67 If You could not Answer an Incoming Call ·················································································· 68 Recording Messages when You cannot Answer the Call ·························<Record Message> 69 Recording Messages when You cannot Answer the Call while Ringing

·············································································································<Quick Record Message> 71

Playing/Erasing Record Messages/Voice Memo··································<Play/Erase Message> 71

Making Calls/Receiving Calls

Enter the other party’s phone number, starting with the area code.

●

Even when you are dialing within the same area, you need to enter the area code before the phone number. <Example> Area code City code Phone number

●

To make calls to mobile phone

Other party’s phone number (11 digits)

●

To make calls to PHS

Other party’s phone number (11 digits)

●

You can make a call also by vocalizing and retrieving a Phonebook entry stored in the Voice Dial List. (See page 111)

●

To store an entered phone number in the Phonebook, press

()

. Go to step 2 on page 99.

070−XXXX−XXXX

090−XXXX−XXXX

080−XXXX−XXXX

XXXXXXXX03

Start talking when the other party answers.

●

The FOMA phone differs from ordinary phones in making a transmission signal before the call signal.

●

“” blinks at the upper right of the display during calling, and lights steadily once you are connected.

●

You can dial out also by entering the phone number and then pressing .

●

You will hear a message to the effect that your call cannot be connected when the destination mobile phone or PHS is not turned on or the radio waves do not reach.

●

If you hear a message requesting your Caller ID (see page 461), follow the procedure for “To notify the Caller ID” (see page 46) to enter “186” or “:31#” and redial the number.

●

When the line is busy, you will hear the busy tone. Press and wait a while before dialing again.

●

You can press the numeric keys to send touch-tone signals during a call.

●

If you close the FOMA phone during a call, the FOMA phone works according to “Fold setting”. (See page 62)

●

If date and time have already been set, the current time is displayed on the “Talking” display.

Press to end the call after talking.

●

You can make voice calls using “Multiaccess” even when using i-mode or exchanging mail.

●

You cannot make voice calls during 64K data transmission or video-phone calls.

●

If you have brought up a display other than the “Talking” display during a call, you can return to the “Talking” display by pressing several times. You can end the call by pressing from the “Talking” display.

●

Internal phones and other phones that do not support the entry of area codes cannot be used for dialing to the FOMA phones.

●

You can dial out also by pressing and then entering the party’s phone number. If you make a mistake when entering the phone number, press and then enter the number again after the wrong number is cleared.

●

You cannot dial out by entering the phone number while “Keypad dial lock”, “Restrict dialing” or “Self mode” is activated.

Information

Making a Call

■

Display during dialing

The other party’s name and icon will be displayed if you have stored the party’s phone number and name in the Phonebook. However, the image will not be displayed, even if you have stored it for that party. The phone number instead of the name will be displayed if the party has been stored in the Phonebook in “Secret mode” or “Secret only mode”, or if PIM Lock is activated. If the same phone number is stored with multiple names in the Phonebook entries, the name that comes first in the search order (see page 104) is displayed.

■

If you make a mistake while entering the phone number

To clear one digit at a time, press briefly.

Each time you press it, the digit on the far right is cleared.

●

Use to move the cursor to the digit you want to clear, and then press to clear it.

To clear all the digits, press and hold for at least one second.

All the digits are cleared and the Stand-by display returns.

●

To clear all the digits on and to the right of the cursor, use to move the cursor and then press and hold for at least one second.

■

Photo-sending during a call

During a voice call, you can send the other party the still images you have taken on the spot or ones you have saved. (See page 261)

Function menu

Notify caller ID

Prefix numbers

International dial

Multi number

Add to phonebook

Compose message

Dialing speed

Select image

Operations

You can set whether to notify caller ID. (See page 46)

You can add a prefix number. (See page 58)

You can make an international call. (See page 52)

See page 464.

You can store the data in the Phonebook. (See page 99)

You can compose a mail message to send to the phone number set as the destination address. Go to step 3 on page 245.

You can set the dialing speed of video-phone calls. (See page 76)

You can select an image for video-phone calls. (See page 87)

For at least

one second

Making Calls/Receiving Calls

●

When the phone number and mail address are stored in the Phonebook together, you can compose a message to send to that mail address. When multiple mail addresses are stored, you can compose a message to send to the first mail address.

Information

While entering a phone number ( ) Do the following operations.

Function Menu while Entering Phone Number

Making Calls/Receiving Calls

●

Contact “DoCoMo Information Center” on the back page of this manual for inquiries about WORLD CALL.

●

When using international carriers other than DoCoMo, please contact them.

●

You can call about 220 countries and regions.

●

The WORLD CALL charges are added to your monthly FOMA bill.

●

Application/monthly fee is free of charge.

●

Changes in procedures for international call “My Line” service is not available for mobile communications, so cannot be used with WORLD CALL. However, in conjunction with the launch of “My Line” service, the dialing procedure for international calls from mobile phones has changed. Note that the old way of dialing (without “010” above) no longer works.

・

If the other party uses a specific 3G mobile phone overseas, you can make an “International Video-phone Call” by dialing out in Video-phone call mode after following the dialing method described above.

●

See the DoCoMo web page for the information about connectable countries and telecommunications carriers.

●

Images sent from the other party may blur on your FOMA phone or you may not be able to connect, depending on the other party’s phone used for the international video-phone.

Making an International Call Easily

■

How to make calls

009130 - 010 - Country code - Area code - Destination phone number

※

You can store the procedures above in the FOMA phone’s Phonebook.

※

When the area code begins with “0”, leave this out when dialing. (However, include “0” for ordinary phones in Italy.)

WORLD CALL is the international call service available from DoCoMo mobile phones.

※

When you have signed up for FOMA service, you have contracted to use “WORLD CALL” (except those who have applied not to use it).

International Calls

You can set whether to automatically replace “+” at the beginning of a phone number, or “+” of “

31#+” or “#31#+” with the international access number set by “IDD Prefix setting”. When you are entering a phone number for dialing or storing it in the Phonebook, press and hold for at least one second to enter “+”.

Auto Assist Setting

Other settings Int’l dial setting Auto assist setting

Auto············Automatically adds the international access number.

When no country code is registered, the confirmation display appears asking whether to register the country code. To register, select “YES”, press , and go to step 2 of “Storing/Editing Country Code” on page 51. To cancel, select “NO” and press .

OFF············Does not automatically add the international access number. The setting is completed.

Select a country name

Setting at purchase

Auto

Making Calls/Receiving Calls

You can change the international access number to be added to the beginning of phone number for making an international call.

IDD Prefix Setting

Other settings Int’l dial setting IDD Prefix setting

()

Enter the name to store

●

You can enter up to 8 full-pitch or 16 half-pitch characters.

●

See page 510 for how to enter characters.

Enter the international access number

●

You can enter up to 10 digits.

■

When adding international access number automatically

The confirmation display appears asking whether to make an international call. Select how to dial and press . Dial·····························Dials out with adding the international access number. Dial with orig. No.·······Dials out without adding the international access number. Cancel························Does not dial.

●

International access number is not added if you enter 81 (Country code of Japan) after emergency call 110/119/118 or “+”.

Information

Setting at purchase

WORLD CALL (009130010)

You can store up to three country codes.

Storing/Editing Country Code

Other settings Int’l dial setting Country Code setting

Select <Not recorded> ( )

●

To edit, select the stored country name.

Enter a country name

●

You can enter up to 8 full-pitch or 16 half-pitch characters.

●

See page 510 for how to enter characters.

Enter a country code

●

You can enter up to 5 digits. But you cannot use #, :, and +.

Setting at purchase

アメリカ

(U.S.A.), +1

Confirming Country Code

Other settings Int’l dial setting Country Code setting

Select a country name

Making Calls/Receiving Calls

●

You cannot delete the country code set by “Auto assist setting”.

Information

Function menu

Edit

Delete this

Delete all

Operations

Go to step 2 of “Storing/Editing Country Code” on page 51.

YES

●

To cancel, select “NO” and press .

Enter the Terminal Security Code YES

●

To cancel, select “NO” and press .

●

See page 146 for the Terminal Security Code.

●

When the phone number has “0” at the beginning, “0” is replaced by the international access number and the country code.

Information

You can make a call by replacing “+” at the beginning of a phone number or “+” of “

31#+” or “#31#+” with the international access number. When you are entering a phone number for dialing or storing it in the Phonebook, press and hold for at least one second to enter “+”.

International Dial

Enter a phone number, or bring up a Phonebook entry, redial item, dialed call record, or received call record.

()International dial

Press ( ) or to make an international call (video-phone call).

■

When the beginning of the phone number is other than “+”, “:31#+”, or “#31#+”

The display for selecting a country name appears in step 2. If you select a country name, the international access number and the country code are added.

While Country Code Setting is displayed ( )

Do the following operations.

Function Menu while Country Code Setting is Displayed

Making Calls/Receiving Calls

The FOMA phone can store the other party’s phone number, date and time you have dialed in “Redial” and “Dialed calls”. In “Redial”, a total of 30 dialed phone numbers of voice phone calls and video-phone calls can be stored. If you dial the same phone number twice, the older one is deleted. In “Dialed calls”, a total of 30 dialed phone numbers of voice phone calls and video-phone calls, and 30 pieces of 64K data transmission and packet transmission are stored. The same phone number you dialed before is also retained in “Dialed calls”. See page 64 about icons for the Redial/Dialed Call Record.

●

To store the dialed date and time in the FOMA phone, set the date and time by “Set time” in advance.

●

When more than 30 calls are received, the older records are automatically deleted.

Redialing Phone Numbers You have Dialed

Stand-by display

●

Redial cannot be displayed during a video-phone call.

●

The latest data is displayed on the top.

●

Press ( ) to make a call (video-phone call) at the selected phone number.

●

Press

()

to display the Sent Address List.

Use Redial

●

When i-mode or packet transmission is in progress, the transmission is disconnected and the voice call is switched to the video-phone call. With packet transmission, a confirmation display appears asking whether to disconnect the transmission. Select “YES” and press to disconnect it and to switch to the video-phone call. To cancel, select “NO” and press .

●

When packet transmission is in progress at the other end, the message to the effect that the transmission cannot be switched is displayed and the voice call continues without switching to the video-phone call.

●

You cannot switch from the voice call to the video-phone call while “Multi calling” is displayed if you have signed up for Call Waiting Service.

●

It takes about five seconds to switch. Switching may take a longer time depending on the radio wave conditions.

●

Depending on how the caller

’s

phone is working or on the radio wave conditions, switching from a voice call to video-phone call may fail and

the connection may be cut off.

●

If you switch between the voice call and video-phone call during a call, the call duration and call charge are counted respectively for the calls. You are not charged while “Changing” is displayed.

●

You cannot switch between the video-phone call and voice call unless “Indicate V-phone” is set to “Activate” at the other end. See page 88 for “Indicate V-phone”.

●

Hands-free is not released even if you switch from the voice call to video-phone call during Hands-free. You cannot set Hands-free ON/OFF while the display for “Changing” is displayed.

●

An alarm for “Quality alarm” and “Reconnect control” does not sound during switching.

●

See page 78 for switching from a video-phone call to voice call.

Information

During a voice call

（）

Charge ·························Switches from a voice call to video-phone call. Cancel··························Cancels switching and returns to the voice call. Select image ················Selects the image to be sent to the other party. Go to step 2 on page 87.

●

While switching, the “Changing” display appears and the voice guidance to that effect is played back.

You (caller) can switch from a voice call to a video-phone call during a call. When the other party’s phone has a function to switch between the calls, “ ” is displayed on your phone and you can switch from the voice call to video-phone call. (901iS series only supported, as of May 2005)

Switching from a Voice Call to Video-phone Call

Making Calls/Receiving Calls

●

The dialed call records of 64K data transmission are stored only when the FOMA USB Cable (option) is connected.

●

During “PIM lock”, only the phone number is displayed even when the name and icon for the other party are stored in the Phonebook. The name and icon stored in the Phonebook are displayed after “PIM lock” is released.

●

If you activate “PIM lock”, “Keypad dial lock”, or “Restrict dialing”, the dialed call records up to that point are all deleted. All records after “PIM lock”, “Keypad dial lock”, or “Restrict dialing” is activated are retained.

Information

Function menu

Notify caller ID

Prefix numbers

International dial

Multi number

Operations

You can set whether to notify caller ID. (See page 46)

You can add a prefix number. (See page 58)

You can make an international call. (See page 52)

See page 464.

While Redial/Dialed Call Record is displayed ( )

Do the following operations.

Function Menu while Redial/Dialed Call Record is Displayed

Dialed calls

●

The latest data is displayed on the top.

●

Press ( ) to dial (video-phone call) the phone number you have selected.

●

Press

()

to display the Sent Address List.

●

You can make a voice call (or video-phone call) to the most recently dialed number by pressing ( ) and then from the Stand-by display.

●

If you activate “PIM lock”, “Keypad dial lock”, or “Restrict dialing”, the redialed records up to that point are all deleted. All records after “PIM lock”, “Keypad dial lock”, or “Restrict dialing” is activated are retained.

Information

Select a redial item

●

When the other party is stored in the Phonebook, the phone number, name, and icon are displayed.

●

Press ( ) or to make a call (video-phone call) at the displayed phone number.

●

To add the record to the Phonebook, press ( ). Go to step 2 on page 99.

Use Dialed Call Record

Select a dialed call record

●

When the other party is stored in the Phonebook, the phone number, name, and icon are displayed.

●

Press ( ) or to make a call (video-phone call) at the displayed phone number.

●

To add the record to the Phonebook, press ( ). Go to step 2 on page 99.

Making Calls/Receiving Calls

Pause Dial is useful when you send messages to pagers※, reserve tickets, or check your bank balance by the phone. If you enter a pause (p) into the dial data, you can send it out with breaks.

You can store only one pause dial.

Store Pause Dial

Other settings Pause dial ( )

●

When the dial data is already stored, it is displayed.

Setting at purchase

Not stored

Sending Touch-tone Signals Quickly

●

When the phone number and mail address are stored in a Phonebook entry together, you can compose a mail message to send to that mail address. When multiple mail addresses are stored, you can compose a message to send to the first mail address.

●

If you execute “Delete all”, all records in both Redial and Dialed Call Record are deleted. Note that even if you execute “Delete this” or “Delete selected” of Redial, those are not deleted from Dialed Call Record and the records are retained. To delete the dialed call records, delete them from the Function menu while “Dialed calls” is displayed.

●

Even if you turn off the power, redial items and dialed call records are not deleted.

Information

Function menu

Add to phonebook

Add desktop icon

Compose message

Compose SMS

Sent address

Delete this

Delete selected

Delete all

Dialing speed

Select image

Operations

You can store the data in the Phonebook. (See page 99)

You can paste the phone number to the desktop. (See page 139)

You can compose a mail message to send to the phone number set as the destination address. Go to step 3 on page 245.

You can compose an SMS message to send to the phone number set as the destination address. Go to step 3 of “Composing SMS (Short Messages) to Send” on page 312.

You can display the Sent Address List. (See page 292)

YES

●

To cancel, select “NO” and press .

Put check marks for the redial items or dialed call records to be deleted ( ) YES

●

“” and “ ” switch each time you press . You can check or uncheck all items by pressing

() and selecting “Select all/Release all”.

●

To cancel, select “NO” and press .

Enter the Terminal Security Code YES

●

To cancel, select “NO” and press .

●

See page 146 for the Terminal Security Code.

You can set the dialing speed of video-phone calls. (See page 76)

You can select an image for video-phone calls. (See page 87)

※

The name of the DoCoMo pager has been changed to QuickCast since January 2001.

Making Calls/Receiving Calls

■

To send dial data all at once

1. From the display in step 3, press and hold for at least one second.

2. Select “Send at one time” and press .

●

Select “Send pause dial” and press ; then the dial data up to the next pause (p) will be sent.

■

To enter “p” in ordinary phone number entry

You can send the dial data also by entering the phone number in the usual way, and pressing and holding for at least one second to enter the pause (p). You can enter up to 80 digits including the phone number.

1. From the Stand-by display, enter the destination phone number and then the pause (p).

2. Press to dial the number.

3. When the line is connected, press and hold for at least one second, select “Send pause dial” from the menu, and press ; the dial data up to the next pause (p) will be sent.

For at least one second

For at least

one second

Enter the dial data

●

Enter the pause (p) by pressing and holding for at least one second.

●

You can use only through , , to enter the dial data and the pause (p).

●

You can enter up to 128 digits.

●

You cannot enter a pause (p) at the beginning of dial data, or enter it consecutively.

Send Pause Dial

Enter a phone number or

A voice call is made. Once the line is connected, the dial data stored in Pause Dial is displayed up to the first pause (p).

●

When the other party’s phone number is stored in the Phonebook, press to bring up the Phonebook Search display, select the phone number, and dial from there.

●

You can search for the phone number also from Received Call Record by pressing or from Redial by pressing .

●

See page 101 for how to search the Phonebook.

Other settings Pause dial

Check that the line is connected or

The dial data up to the first pause (p) is sent, and the dial data up to the next pause (p) is displayed. Dial data up to the pause (p) is sent each time you press or . When you have finished sending the last number, the “Talking” display comes up.

Making Calls/Receiving Calls

You can store prefix numbers such as international access numbers or “186/184” and add them to the beginning of the phone number for dialing. You can store up to seven prefix numbers.

Other settings Prefix setting Select <Not recorded>

()

●

To edit a stored prefix, select it.

Enter a name

●

You can enter up to 8 full-pitch or 16 half-pitch characters.

●

See page 510 for how to enter characters.

Enter a prefix number

●

You can enter up to 10 digits.

●

The keys for entry are limited to through , and .

Store/Edit Prefix

●

During a call, you can send dial data also by displaying the Function menu of the Pause Dial display.

●

Some devices on the receiving end cannot receive signals.

●

You cannot send pause dial data with a video-phone call.

Information

Function menu

Edit

Send pause dial

Delete

Operations

Go to step 2 of “Store Pause Dial” on page 56.

Go to step 2 of “Send Pause Dial” on page 56.

YES

●

To cancel, select “NO” and press .

Pause Dial display ( ) Do the following operations.

Function Menu of the Pause Dial Display

Setting at purchase

WORLD CALL (009130010)

Storing Prefix Numbers

Other settings Prefix setting Select a prefix

Check Prefix

While “Prefix setting” is displayed ( ) Do the following operations.

Function Menu while Prefix Setting is Displayed

Function menu

Edit

Delete this

Operations

Go to step 2 of “Store/Edit Prefix” on this page.

YES

●

To cancel, select “NO” and press .

Making Calls/Receiving Calls

You can select an alarm that sounds until you are reconnected after disconnected owing to bad radio wave conditions.

Talk Reconnect control

No tone ························Does not sound. High tone ·····················High alarm sounds. Low tone ······················Low alarm sounds.

●

The call fee is charged for the time until you are reconnected (up to about 10 seconds).

●

The reconnectable time differs depending on the usage status and radio wave conditions. An estimate is about 10 seconds.

●

While you are disconnected, no sound is transmitted to the other party.

●

An alarm for “Reconnect control” does not sound during switching between a voice call and video-phone call.

Information

Setting at purchase

No tone

Selecting Alarm for Reconnecting

The subaddress is the number required for receiving services such as Subaddress Notification Service of ISDN. If you set “Sub-address” to “ON”, “

” included in the phone number is regarded as a separator and subsequent numbers are identified as a subaddress so that you can call a specific phone or connect to a data terminal. You can use this function for selecting contents from “M-stage V

LIVE

”.

Other settings Sub-address

ON··············Regards “:” and onward as a subaddress. OFF············Does not regard “

” and onward as a subaddress.

●

Even if you set “Sub-address” to “ON”, “

” at the top of phone numbers and “:” immediately after the prefix number or

“186 (or

31#)”/“184 (or #31#)” are not regarded as subaddress mark-off symbols.

Information

Setting at purchase

Making a Call with Specified Subaddress

You can add a prefix number to the top of phone number when you make a call.

Prefix Numbers

Enter a phone number, or bring up the detailed display of a Phonebook entry, redial item, dialed call record, or received call record.

()Prefix numbers

When a phone

number is entered

Select a prefix item

You can make a voice call (or video-phone call) by pressing ( ) or .

Function menu

Delete all

Operations

Enter the Terminal Security Code YES

●

To cancel, select “NO” and press .

●

See page 146 for the Terminal Security Code.

Making Calls/Receiving Calls

<Hands-free>

Switching to Hands-free

Using Hands-free Compatible Devices

During a call

When Hands-free is activated, “ ” is displayed.

●

Press again to switch Hands-free off.

●

You can switch to Hands-free even during Manner Mode.

Manner Mode is reactivated when you switch Hands-free off or end the call. Also, you will still hear sound through the speaker when you activate Manner Mode during a Hands-free call.

When you switch to Hands-free during a call, sound such as the other party’s voice, which is normally heard through the earpiece, will be audible over the speaker.

●

Keep the FOMA phone well away from your ear when Hands-free is on. Otherwise you could affect or damage your hearing.

●

When noise of your surroundings or of the receiving end is loud, you might hardly hear the other party’s voice. Set Hands-free to OFF and then talk.

●

Talk into the FOMA phone within a distance of about 50 cm.

Information

During a

video-phone call

During a voice call

●

Noise Reduction is always effective during a video-phone call.

Information

You can suppress surrounding noise to make your voice and the other party’s voice from the earpiece clear.

Talk Noise reduction

ON··············Validates Noise Reduction. OFF············Invalidates Noise Reduction.

Setting at purchase

Reducing Surrounding Noise to Make Voice Clear

Using a FOMA USB Cable (option), you can connect the FOMA phone with a Hands-free compatible device (commercial item) such as a car navigation system, and can make or receive voice calls or video-phone calls from that device. Refer to the respective instruction manuals for how to operate Hands-free compatible devices.

※

This function is optional and is coming to be available when Hands-free devices are released. As of May 2005, Hands-free devices have not appeared in the market.

●

Screen display or a ring tone for incoming calls is in accordance with the settings of the FOMA phone.

●

When the ring tone is set to sound from a Hands-free compatible device, the ring tone sounds from that device even when Manner Mode is activated or “Ring volume” of the FOMA phone is set to “Silent”.

●

The receiving operation in Drive Mode works in accordance with the “Drive mode” setting.

●

The receiving operation while Record Message is activated works in accordance with the “Record message” setting.

●

If you make a video-phone call from a Hands-free device using the Phonebook, a dialing speed is set in accordance with that device. The dialing speed is 64K when it is not set.

●

When the ring tone is set to sound from the FOMA phone, the FOMA phone works in accordance with “Fold setting” if it is closed during a call. When the ring tone is set to sound from a Hands-free device, communicating conditions do not vary even if you close the FOMA phone, regardless of “Fold setting”.

Information

Making Calls/Receiving Calls

Press or to take the call.

●

You can set “Illumination in talk” so that the Call/Charging indicator flickers during a call.

●

When “Answer setting” is set to “Any key answer”, the call is placed on hold if you take the call by pressing with the FOMA phone closed. If you have set “Fold setting” to “No tone” or “End the call”, the other party hears nothing, and if you have set “Fold setting” to “Tone on”, the call hold tone is played back. You can start talking by opening the FOMA phone. “Holding” appears on the Private window.

●

If you close the FOMA phone during a call, the FOMA phone works in accordance with “Fold setting”. (See page 62)

■

One-push answer

When a voice call comes in with the FOMA phone closed, you can answer the call just by pressing the one-push open button and opening the FOMA phone.

●

You need to set “Phone” of “Open phone” to “Answer” in advance. (See page 62)

●

You can answer the call also by opening the FOMA phone manually without using the one-push open button.

■

Any Key Answer

Voice calls can be taken by pressing any key of through , , , , (top, bottom, left, or right of the Command Navigation key), and in addition to or .

●

When “Answer setting” is set to “Quick silent”, you can stop only the ring tone by pressing a certain key.

Press to end the call after talking.

When you receive a call, the ring tone sounds and the Call/Charging indicator and Command Navigation key flicker.

●

You can use “Illumination” to set an illumination pattern for the Call/Charging indicator.

●

To vibrate the phone for incoming calls, set “Phone” of “Vibrator” to other than “OFF”.

●

While “Manner mode” or “Super silent” is set, the ring tone does not sound. (See pages 122 and 123)

●

While receiving a call, information is displayed on the Private window and the dot-area data for the incoming call is displayed.

●

“” is displayed at the upper right of the phone number for incoming international calls.

Receiving a Call

●

During ringing, you can activate Manner Mode by pressing or ; “Record message” will be activated so that the caller’s message can be recorded. You can still take the call during recording by pressing or . (The message until you press or will be recorded. Also, Manner Mode will remain activated after the call ends.)

●

You might hear beeps (ring tone in call) during a call. If you have signed up for any of Voice Mail Service, Call Waiting Service, or Call Forwarding Service and set “Arrival call act” to “Answer”, the beeps (ring tone in call) will sound for another incoming call, enabling you to do the following operations: Voice Mail Service ·····················Transfer the call to the Voice Mail Service Center. (See page 456) Call Waiting Service ··················Put your current call on hold and take the incoming call. (See page 457) Call Forwarding Service ············Transfer the call to the registered forwarding destination. (See page 459)

●

During Drive Mode, the ring tone does not sound and the Call/Charging indicator does not flicker for incoming calls. Incoming calls are recorded as missed calls in Received Call Record.

●

You cannot receive calls from the phone numbers set for “Call rejection” in “Restrictions”. Also, you cannot receive calls from the phone numbers except those set for “Call acceptation”.

●

By setting “Ring start time” of “Ringing time”, you can specify the time until ringing starts for when a call comes in from the phone number not stored in the Phonebook.

●

You can set “Reject unknown” not to accept calls from the phone numbers not stored in the Phonebook.

Information

Making Calls/Receiving Calls

■

Display for incoming calls

When the Caller ID is provided

If the caller’s name, phone number, and image are stored in the Phonebook, the name, phone number, and icon (or image) are displayed. For a forwarded call, the phone number or name of the caller and the forwarder is displayed. (The forwarder’s phone number might not be displayed in the case of some forwarders.) The phone number but not the name will be displayed if the party has been stored in the Phonebook in “Secret mode” or “Secret only mode”, or if PIM Lock is activated. If the same phone number is stored with multiple names in the Phonebook, the name that comes first in the search order (see page 104) is displayed.

When the Caller ID is not provided

The reason for No Caller ID is displayed. (See page 158)

Caller

Forwarder

Function menu

Call rejection

Call forwarding

Voice mail

Operations

You can hang up the phone without answering the call.

●

You cannot reject calls if you have set “Phone” of “Open phone” to “Answer” and the call is received with the FOMA phone closed.

You can forward the call to the forwarding destination. (See page 459)

You can connect to the Voice Mail Service Center. (See page 456)

You can set the FOMA phone to receive calls by pressing a key other than and (Any key answer) or to stop the ring tone by pressing a key other than and (Quick silent).

Incoming call Answer setting

Any key answer ···········Press any of to , , , , , or to answer the voice phone call. Quick silent ··················When a voice phone call or video-phone call comes in, press any of the to , , ,

, , and keys to stop the ring tone or vibrator. If you set “Open phone” to “Keep ringing”, you can stop them by opening the FOMA phone. Even if you stop the ring tone to sound or vibrator to work, the other party hears a ringing tone. Press or (including for video-phone call) to answer the call after stopping the ring tone or vibrator.

OFF······························You can answer the call only when you press or (including for video-phone call).

Setting at purchase

Any key answer

Setting Response of Key Operation for Answering Incoming Calls

While a voice phone call is ringing ( ) Do the following operations.

Function Menu while Voice Phone Call Rings

When you have set “Indicate V-Phone” to “ON”, the caller (the other party) can switch from a voice call to video-phone call.

Switched from a Voice Call to Video-phone Call by the Other Party

During a voice call The other party switches to a video-phone call.

YES············Sends the image through your camera to the caller. NO··············Sends a pre-installed substitutive image to the caller.

●

While switching, the message to that effect is displayed and the voice guidance is played back.

●

You (receiving end) cannot switch the call to video-phone call.

When the caller’s phone

number is notified

When the call is

forwarded from

Making Calls/Receiving Calls

Setting at purchase

Keep ringing

Setting Response for Opening FOMA Phone during Ringing

Incoming call Open phone

Phone ··························Sets Open Phone for incoming voice calls. Video-phone ················Sets Open Phone for incoming video-phone calls.

Keep ringing or Answer

Keep ringing·················Does not start talking even if the FOMA phone is opened. Answer·························Starts talking when the FOMA phone is opened. For video-phone calls, the still image set for

“Substitutive image” of “Select image” is sent to the other party.

●

If you have set “Open phone” to “Answer”, you can start talking also by pressing the one-push open button and opening the FOMA phone. (See page 42)

●

If a call comes in with “Answer” set and the FOMA phone closed, On Hold (see page 66), Call Rejection (see pages 61 and 79), Voice Mail Service (see page 456) and Call Forwarding Service (see page 459) during ringing are not available.

●

Even if you have set “Open phone” to “Answer”, “Keep ringing” works for the incoming call within the specified “Ring start time” of “Ringing time”. “Keep ringing” works also for the incoming call during a call if you have signed up for Call Waiting Service

Information

●

If a video-phone call comes in, “Any key answer” is disabled.

●

While “Manner mode” is activated, “Any key answer” works even if “Quick silent” has been set.

●

Even when “Any key answer” or “Quick silent” has been set, the display light switches ON/OFF if you press and hold for at least one second; “Any key answer” or “Quick silent” does not work.

●

When “Side keys guard” is set to “OFF”, “Any key answer” or “Quick silent” does not work by pressing with the FOMA phone closed.

●

While the Flat-plug Earphone/Microphone Set with Switch (option) is connected, you can press the switch to receive calls, regardless of “Answer setting”. For video-phone calls, the substitutive image is sent to the other party.

●

If you have set “Open phone” to “Answer”, you can answer calls by opening the FOMA phone regardless of “Answer setting”.

Information

Incoming call Fold setting

No tone ························The voice is muted (silenced). The hold tone is not played back. The setting is completed. Tone on························The other party hears the hold tone set for “Holding tone” of “Call response setting” while the FOMA

phone is closed.

End the call ··················

The call is finished. This is the same operation as pressing during a call. The setting is completed.

Speaker ON or Speaker OFF

Speaker ON ·················The hold tone is played from the speaker. Speaker OFF ···············The hold tone is not played from the speaker.

Setting at purchase

End the call

Setting Response for Closing FOMA Phone during a Call

Making Calls/Receiving Calls

The FOMA phone can store the caller’s phone numbers and the date and time you received calls in “Received calls”. A total of 30 phone numbers of voice phone calls and video-phone calls, and a total of 30 pieces of 64K data transmission and packet transmission are stored respectively.

●

To store the dialed date and time in the FOMA phone, set the date and time by “Set time” in advance.

●

When more than 30 calls are received, the older records are automatically deleted.

Received calls

All calls·························Displays all the data including missed calls. Missed calls ·················Displays the data of only the missed calls.

●

If unknown missed calls are found, the number of the unconfirmed calls is displayed.

●

You can bring up the display on the right also by pressing from the Stand-by display.

●

The latest data is displayed on the top.

●

Press ( ) to dial (video-phone call) the phone number you have selected.

●

Press ( ) to display the Received Address List.

Using Received Call Record

When “All calls” is selected

●

If you have set “Missed calls display” of “Ringing time” to “Not display”, missed calls within “Ring start time” are not displayed in Received Call Record.

●

While “PIM lock” is activated, only the phone number is displayed even if the name and icon are stored in the Phonebook. Further, when “Restrict dialing” is activated, only the phone number is displayed, even when the name and icon are stored in the Phonebook, unless the Phonebook entry has been specified in “Restrict dialing”. After releasing “PIM lock” and “Restrict dialing”, the name and icon stored in the Phonebook are displayed.

●

You can make a voice call (or video-phone call) to the most recent phone number in Received Call Record by pressing () and then from the Stand-by display.

●

You can neither save phone numbers of 64K data transmission and packet transmission from Received Call Record to the Phonebook, nor compose new mail messages or SMS messages for them.

●

If you activate “PIM lock” or “Keypad dial lock”, the received call records up to that point are all deleted. All records after “PIM lock” or “Keypad dial lock” is activated are retained.

●

When a call comes in from a party who uses a dial-in phone number, a different phone number might be displayed.

Information

Select a received call record

●

The Caller ID is displayed if it was provided; and if this caller has been stored in the Phonebook, the

phone number, name, and icon are displayed. If there was an incoming packet transmission, the sender’s access point name (APN) is displayed. When the other party’s phone number is not notified, the reason for no Caller ID is displayed.

●

For missed calls, the ringing time is displayed on the right of the received date and time.

●

Press ( ) or to dial (video-phone call) the phone number you have displayed.

●

To add the record to the Phonebook, press ( ).

Go to step 2 on page 99.

●

This function is disabled when the Flat-plug Earphone/Microphone Set with Switch (option) is connected. The line is not disconnected even if you close the FOMA phone during a voice call. If you close the FOMA phone during a video-phone call, the substitutive image is sent to the other party with the line connected.

●

If you close the FOMA phone during a video-phone call with “No tone” activated, a substitutive image is sent to the other party. When “Tone on” is set, the still image selected by “Holding” of “Select image” is sent.

●

Even if you have selected “End the call” and close the FOMA phone, the functions of i-mode group and Tool group in working Multitask do not end.

●

If you have selected “End the call” and close the FOMA phone to end a call during i-mode, the display in i-mode prior to the call returns.

●

Even if you have selected “Tone on”, “No tone” works when you close the FOMA phone while “Multi calling” is displayed during a call if you have signed up for Call Waiting Service.

Information

Indicates that you have received (or made) a voice call.

Indicates that you have received (or made) a video-phone call.

Indicates that you have received (or made) an international call.

Indicates that you have received (or made) an international video-phone call.

※

Indicates that you have missed a voice call.

※

Indicates that you have missed a video-phone call.

※

Indicates that you have missed an international call.

※

Indicates that you have missed an international video-phone call.

Indicates that you have received a remotely monitored call. When there has been a missed remotely monitored call, “ ” appears.

Indicates that you have a message recorded in “Record message”.

Indicates that you have made a call for 64K data transmission.

Indicates that you have received a call for 64K data transmission.

Indicates that you have made a call for packet transmission.

Indicates that you have received a call for packet transmission.

※

Indicates that you have missed a call for 64K data transmission.

※

Indicates that you have missed a call for packet transmission.

Indicates that you have received a call for 64K data transmission or packet transmission when a 64K or packet transmission compliant external device such as a personal computer is not connected.

Making Calls/Receiving Calls

■

Icons for Redial, Dialed Call Record, and Received Call Record

Function menu

Notify caller ID

Prefix numbers

International dial

Multi number

Ringing time

Add to phonebook

Add desktop icon

Compose message

Compose SMS

Operations

You can set whether to notify caller ID. (See page 46)

You can add a prefix number. (See page 58)

You can make an international call. (See page 52)

See page 464.

You can display the ringing time for missed calls. Even if you have set “Missed calls display” of “Ringing time” to “Not display”, you can check the missed calls which stopped ringing within the specified ring start time and their ringing times.

●

You cannot operate from the Function menu of the detailed Received Calls display or Missed Call Record.

●

From the display on the right, press to bring up the detailed Received Calls display.

You can store the data in the Phonebook. (See page 99)

You can paste the phone number to the desktop. (See page 139)

You can compose a mail message to send to the phone number set as the destination address. Go to step 3 on page 245.

●

You can compose an SMS message to send to the phone number set as the destination address. Go to step 3 of “Composing SMS (Short Messages) to Send” on page 312.

While Received Call Record is displayed ( )

Do the following operations.

Function Menu while Received Call Record is Displayed

※

Displayed in light purple for unchecked missed calls.

Operations

You can display the Received Address List. (See page 294)

YES

●

To cancel, select “NO” and press .

Put check marks for the received call records to be deleted ( ) YES

●

“” and “ ” switch each time you press . You can check all items or uncheck all items by pressing ( ) and selecting “Select all/Release all”.

●

To cancel, select “NO” and press .

Enter the Terminal Security Code YES

●

To cancel, select “NO” and press .

●

See page 146 for the Terminal Security Code.

You can set the dialing speed of video-phone calls. (See page 76)

You can select an image for video-phone calls. (See page 87)

Making Calls/Receiving Calls

Stand-by display (for at least one second)

●

You cannot adjust the volume during ringing. Adjust it during a call or standby.

●

During a voice call, you can press and hold for at least one second or press briefly to bring up

the Volume Adjustment display. During a video-phone call, you can press or briefly to bring up the Volume Adjustment display.

Setting at purchase

Level 4

Adjusting Earpiece Volume

Volume Adjustment display

Use to adjust the earpiece volume.

Adjust the earpiece volume to Level 1 (minimum) through 6 (maximum). To raise the volume, press or ; to lower it, press or .

●

Within two seconds after you bring up the Volume Adjustment display, press or to adjust the volume.

●

Even if you turn off the FOMA phone, received call records are not deleted.

Information

Function menu

Received address

Delete this

Delete selected

Delete all

Dialing speed

Select image

You can adjust the ring volume for incoming calls and mail.

Incoming call Ring volume

Phone ··························For adjusting the ring volume for incoming voice calls. Video-phone ················For adjusting the ring volume for incoming video-phone calls. Mail ······························For adjusting the ring volume for incoming i-mode mail and SMS messages. Chat mail······················For adjusting the ring volume for incoming chat mail. MessageR····················For adjusting the ring volume for incoming Messages R (Request). MessageF ····················For adjusting the ring volume for incoming Messages F (Free).

Setting at purchase

Level 4

Adjusting Ring Volume

●

The earpiece volume adjusted during a call is retained even after the call ends.

Information

Making Calls/Receiving Calls

Use to adjust the volume

Step ·····························The ring tone is silent for about three seconds, and then the volume steps up

every three seconds, from Level 1 through Level 6.

Levels 1 to 6 ················Level 1 is the weakest volume and Level 6 the loudest. Silent····························The ring tone does not sound.

●

Following icons are displayed while the ring volume is set to “Silent”:

: The ring volume for voice calls or video-phone calls is “Silent”. : The ring volume for mail, chat mail or Messages R/F is “Silent”. : The ring volume for voice calls, video-phone calls, mail, chat mail, and Messages R/F is “Silent”.

●

You cannot adjust the ring volume during ringing.

●

Even if the ring volume for mail, chat mail, or Messages (R/F) is set to any other than “Silent”, “ ” is displayed and the ring tone does not sound while “Mail/Msg. ring time” (see page 121) is set to “OFF”.

Information

During ringing

The FOMA phone makes three rapid beeps for confirmation and the incoming call is put on hold.

●

The confirmation tone does not sound when “Phone” of “Ring volume” is “Silent” or while Manner Mode is activated.

●

The other party hears the hold tone set for “On hold tone” of “Call response setting”. For video-phone calls, the still image selected in “On hold” of “Select image” is displayed.

Press to release hold and answer the call.

●

If a voice call is on hold, you can also press to release hold. If “Answer setting” is set to “Any key answer”, you can release hold by pressing any key of through , ,

, , , , , or .

●

If a video-phone is on hold, the image through your camera is sent to the other party by pressing to release hold. If you press or to release hold, the substitutive image is sent.

Putting an Incoming Call on Hold

●

The caller is charged for the call even during answer-hold.

●

If you press during answer-hold, the call will be disconnected.

●

If the caller on hold hangs up, the call will be disconnected.

●

If you have set “Open phone” to “Answer”, you cannot put an incoming call on hold while the FOMA phone is closed.

Information

Press or to release hold and answer the call.

●

If a video-phone is on hold, the image through your camera is sent to the other party by pressing to release hold. If you press or to release hold, the substitutive image is sent.

●

If you have set “Fold setting” to “Tone on” and put the call on hold by closing the FOMA phone, open the FOMA phone or connect the Flat-plug Earphone/Microphone Set with Switch (option) to take the call. If you connect the Flat-plug Earphone/Microphone Set with Switch to take the video-phone call, the substitutive image is sent to the other party.

During a call

●

The other party hears the hold tone set for “Holding tone” of “Call response setting”. For video-phone calls, the still image set for “Holding” of “Select image” is displayed.

●

You can put the call on hold by closing the FOMA phone during the call if you have set “Fold setting” to “Tone on”.

Putting a Call on Hold during a Call

Making Calls/Receiving Calls

●

The caller is charged for the call even while the call is on hold.

●

If the other party on hold hangs up, the call will be disconnected.

●

If a new call comes in while the current call is put on hold, the hold is released.

●

“Fold setting” is set to “End the call” at purchase. Therefore, you can end calls by closing the FOMA phone.

●

If “Illumination in talk” is not set to “OFF”, the illumination flickers even during call-hold or No Tone mode.

●

If the Flat-plug Earphone/Microphone Set with Switch (option) is connected, hold (during a voice call) is released when you close the FOMA phone.

Information

Setting Hold Tone

Setting at purchase On hold tone ···············Tone 1 Holding tone················JESU JOY OF MEN’S DESIRING

You can set the guidance the other party hears during on hold.

Talk Call response setting On hold tone/Holding tone

Tone 1 ···········································The caller hears the guidance “I cannot answer the call. Hold the line, or redial after a while”

in Japanese. You can set Tone 1 for “On hold tone” only.

Tone 2 ···········································The caller hears the guidance “I cannot answer the call. Redial after a while” in Japanese.

You can set Tone 2 for “On hold tone” only. JESU JOY OF MEN’S ···················The melody is played back. You can set the melody for “Holding tone” only. Voice announce 1··························The caller hears the voice recorded by “Voice announce”. If it has not been recorded, “Voice

announce 1” is not displayed. Voice announce 2··························The caller hears the voice recorded by “Voice announce”. If it has not been recorded, “Voice

announce 2” is not displayed.

●

Press ( ) to hear the guidance or melody from the beginning while setting a hold tone. Press to end the demonstration playback.

●

Whole part of long titles may not be displayed due to restriction of the display size.

Information

Stand-by display (for at least one second)

Drive Mode is activated and “ ” is displayed.

●

To deactivate Drive Mode, perform the same operation.

Drive Mode (the guidance function during driving) is an automatic answering service for safety driving. During Drive Mode, callers hear the guidance that you cannot answer the call due to driving, and the call is disconnected.

Setting at purchase

Released

Using Driving Mode

●

If you dial emergency call phone numbers “110”, “119”, “118” during Drive Mode, Drive Mode is released.

●

Note that “Record message” is disabled even when it is set to “ON” because the Drive Mode message has priority.

●

You can activate/deactivate Drive Mode only from the Stand-by display. You can activate/deactivate Drive Mode even when “ ” is displayed.

●

You can make calls as usual even during Drive Mode.

●

When Drive Mode and Manner Mode are activated simultaneously, Drive Mode has priority.

●

If a “User unset” voice call comes in while “Caller ID request” is set to “Activate”, Drive Mode is deactivated and the caller hears the Caller ID Request guidance.

Information

Making Calls/Receiving Calls

■

During Drive Mode

・

Even when a call comes in, the ring tone does not sound. The “Missed call” icon appears on the display and the call is stored in “Received calls”. The caller hears the guidance to the effect that you cannot answer the call due to driving, and the call is disconnected. However, when the power is off or “ ” is displayed, the caller hears the out-of-service-area message instead.

・

The ring tone does not sound and the Call/Charging indicator does not flicker even when mail or a message comes in. In addition, the activated vibrator does not work.

・

The ring tone for 64K data transmission, alarm tone, and charging confirmation tone do not sound, and a melody while i-

ppli is

running is not played back.

●

When “Voice Mail Service” is activated during Drive Mode

The FOMA phone does not ring for incoming calls, but calls are connected to the Voice Mail Service Center. The “Missed call” icon appears on the display and the call is stored in “Received calls”. The caller hears the guidance to the effect that the call is connected to the Voice Mail Service Center due to driving, and then the call is connected to the Center automatically. However, if the ringing time for “Voice Mail Service” is set to 0 seconds, the power is off, or the FOMA phone is out of the service area, the caller does not hear the Drive Mode guidance and Voice Mail Service works. Note that in this case the call is not indicated by the “Missed call” icon and not kept in “Received calls”.

●

When “Call Forwarding Service” is activated during Drive Mode

The call is forwarded to the specified forwarding phone number without connecting to your FOMA phone. The “Missed call” icon appears on the display and the call is stored in “Received Calls”. The caller hears the guidance to the effect that the call is forwarded due to driving, and then the call is forwarded automatically. However, if the ringing time for “Call Forwarding Service” is set to 0 seconds, the power is off, or the FOMA phone is out of the service area, the caller does not hear the Drive Mode guidance and Call Forwarding Service works. Note that in this case the call is not indicated by “Missed call” icon and not kept in “Received Calls”.

■

Relationship between incoming calls during Drive Mode and respective services

Stand-by display

The explanation of the icon appears.

●

Press or to return to the former display.

When you have not been able to answer calls (Missed calls) or you have new mail, or when a message for record message or Voice Mail Service is recorded, the “Notification icon” appears on the Stand-by display. You can skip to that function by selecting the icon. See page 141 for details about each icon.

If You could not Answer an Incoming Call

Responses to Incoming Video-phone Calls

Disconnects the call without connecting to Voice Mail Service.

Forwards the call to the forwarding destination.

Disconnects the call from the phone number registered to be rejected, without connecting to your FOMA phone.

Disconnects the call without the caller ID, without connecting to your FOMA phone.

Responses to Incoming Voice Calls

Plays back the Drive Mode guidance, and then takes the caller’s message.

Plays back the Drive Mode guidance, and then forwards the call.

Plays back the Call Rejection guidance for the call from the number registered to be rejected.

Plays back the Caller ID Request guidance for the call without the Caller ID. Plays back the Drive Mode guidance and disconnects the call if the Caller ID is provided.

Service

Voice Mail Service

Call Forwarding Service

Nuisance Call Blocking Service

Caller ID Display Request Service

Notification icon

Making Calls/Receiving Calls

Press

●

When multiple icons are found, use to select the icon and press .

●

You cannot make calls in the step for displaying the confirmation display from a “Notification icon”. Similarly, if you have set “Operation preferred” for “Alarm setting”, the alarm does not work in this step. Press or to return to the Stand-by display and then perform the operation.

●

Even when the “New mail” icon is not displayed, the i-mode Center may hold new mail that has not been received by the FOMA phone. Also, even when the “Voice mail” icon is not displayed, the Voice Mail Center may hold a message.

●

A “Notification icon” is deleted when each function is executed. Press and hold for at least one second to delete all the “Notification icons”.

●

“Missed call” icon is not displayed if a missed call stops ringing within the specified ring start time and “Missed calls display” of

“Ringing time” is set to “Not display”.

Information

Enter the ringing time (seconds).

●

Enter from “000” to “120” in three digits.

●

Not to change the ringing time, just press without entering a time.

●

You cannot set the same ringing (response) time for Remote Observation, Automatic Answer and Record Message.

Set a different time for each.

Recording Messages when You cannot Answer the Call

When Record Message is activated, you can play an answer message and can record a caller’s message even if you have not signed up for Voice Mail Service. You can record a total of five messages of voice calls and video-phone calls. Each message can be recorded for up to 20 seconds.

Record message

ON··············Activates Record Message. OFF············Deactivates Record Message. The setting is

completed.

●

Record Message does not work when five record messages have already been recorded. Delete unnecessary messages.

Select an answer message

Japanese 1 ··················

The caller hears a message “I cannot take your call now. Please leave your name and message after the beep in 20 seconds. Even for a video-phone call, you can leave a voice message only.” in Japanese.

Japanese 2 ··················The caller hears a more familiar message “I cannot take your call now. Please leave your message after

the beep. Even for a video-phone call, you can leave a voice message only. Sorry.”

in Japanese.

English ·························

The caller hears an English message “I can’t take your call now. Please leave the message. When you call by video phone, you can leave a voice message.”.

Voice announce 1 ········The caller hears the message and sound recorded by “Voice announce”. If it has not been recorded,

“

Voice announce 1”is not displayed.

Voice announce 2 ········The caller hears the message and sound recorded by “Voice announce

”

. If it has not been recorded,

“

Voice announce 2”is not displayed.

●

Press ( ) to play back the answer message. You can stop it by pressing .

Activate Record Message

Setting at purchase Record message·········OFF Answer message ········Japanese 1

(when “Record message” is set to “ON”)

Ringing time················8 seconds

(when “Record message” is set to “ON”)

■

When the FOMA phone is closed

The information is displayed on the Private window. Press to display Missed Call Record. (See page 27)

Making Calls/Receiving Calls

■

Icons while Record Message is activated

〜

: Indicates the number of recorded messages.

■

Incoming calls when Record Message is set to “ON”

After the ringing time elapses, the caller hears the answer message. For a video-phone call, the still image set for “Preparing” of “Select image” is displayed on the other party’s display. Then recording starts. For a video-phone call, the still image set for “Record message” of “Select image” is displayed on the other party’s display. When recording ends, the “Missed call” icon and “Record message” icon appear on the desktop. Select the “Recorded message” icon and press ; then the display for “Play/Erase msg.” appears.

■

To answer a call while the answer message is played back or a message is recorded.

Press or . For video-phone calls, press to send the image through your camera, and or to send the substitutive image.

You can set an answer message for each phone number stored in the FOMA phone’s Phonebook.

Set Answer Message by Phone Number

Detailed Phonebook display ( ) Utilities Answer message

Follow step 2 of “Activate Record Message” on page 69. “Answer message” is indicated by “

★

”.

●

See page 101 for how to search the Phonebook.

●

To release the answer message for the phone number, perform the same operation.

●

Record Message does not work when “ ” is displayed.

●

When Drive Mode and Record Message are simultaneously activated, the former has priority and the latter does not work.

●

The priority order for answer message is; “Setting by phone number” →“Setting by group” →“Setting by Record Message”.

●

If “Voice announce 1” or “Voice announce 2” selected as an answer message is deleted, the answer message will be set to “Japanese 1”.

●

When Voice Mail Service or Call Forwarding Service is set at the same time as Record Message, the priority depends on the ringing time set for Voice Mail Service or Call Forwarding Service. To give Record Message priority, set its ringing time shorter than that for Voice Mail Service or Call Forwarding Service. Even when you do this, Voice Mail Service or Call Forwarding Service will work if there are already five record messages.

●

When the time set for “Ring start time” of “Ringing time” is longer than the ringing time for Record Message, the Record Message function starts without ringing. To have the ringing action before Record Message starts, set the longer time for Record Message than “Ring start time”.

●

If there are already five record messages, subsequent callers cannot leave messages and will not hear the answer message. Delete the recorded messages so that new messages can be left. (See page 71)

●

You cannot receive a call from a third party while a record message is being recorded. The third party will hear the busy tone.

●

You can record messages during Manner Mode even when Record Message is not set to “ON”. To do so, set Manner Mode to “Original”, and “Record message” to “ON” there.

Information

■

Important

■

The saved contents may be lost owing to a malfunction, repair, or other mishandling of the FOMA phone. We at DoCoMo cannot take any responsibility for the loss of data, so you are advised to take a note of data stored in the FOMA phone and store them separately.

Making Calls/Receiving Calls

●

You cannot set this function for Phonebook entries stored in “Secret mode”, “Secret only mode”, and in the UIM.

●

Note that the setting for “Answer message” of “Utilities” is valid only when the Caller ID is provided. It is advisable to activate “Caller

ID request” in advance.

●

Note that this function is released when you change the set phone number.

●

To change the set answer message, release the current setting and proceed.

●

Use “Utilities” to check which phone number in the Phonebook entry is set, or to release the setting.

Information

You can set an answer message for each group stored in the FOMA phone’s Phonebook. If you have set the answer message by phone number, that setting has priority.

Set Answer Message by Group

Group setting Select a group ( ) Utilities

Answer message

Follow step 2 of “Activate Record Message” on page 69. “Answer message” is indicated by “

★

”.

●

To release the answer message for the group, perform the same operation.

●

You cannot set an answer message for “Group 00” and groups stored in the UIM.

●

Note that the setting for “Answer message” of “Utilities” is valid only when the Caller ID is provided. It is advisable to activate “Caller

ID request” in advance.

●

To change the set answer message, release the current setting and proceed.

●

If you store the same phone number in multiple groups, the answer message set for the group of the phone number which is

accessed initially in the column-search order has priority.

●

You can set this function for either the group in which secret and ordinary Phonebook entries are stored together or the group in

which only secret entries are stored; however this function is disabled if you receive a call from the secret entry.

●

Use “Utilities” to check which group is set, or to release the setting.

Information

Playing/Erasing Record Messages/Voice Memo

Recording Messages when You cannot Answer the Call while Ringing

Play/Erase msg.

●

Recorded items are indicated by “ ” (for voice calls) or “ ” (for video-phone calls). If a voice memo is recorded, “★” is attached.

During ringing or

Manner Mode is also activated. The caller will hear the answer message and then can leave you a record message.

●

Record Message does not work when five record messages have already been recorded.

●

When “Side keys guard” is set to “ON”, you cannot activate Record Message by pressing with the FOMA phone closed.

You can activate Record Message for incoming calls even when it is not activated.

Making Calls/Receiving Calls

Select a record message or voice memo

A beep sounds and playback starts.

●

When playback ends, a double-beep sounds and the message “Playing” is cleared from the display.

●

When the Caller ID is provided, the caller’s phone number, date and time of the call, and Record Message No. are displayed during playback. If the caller is stored in the Phonebook, his/her name is also displayed.

※

The date and time of recording are displayed only when “Set time” is set.

●

If the caller’s phone number appears on the display while playing back a record message, you can make a voice call (video-phone call) to that phone number by pressing

()

●

While “Received calls” of “Record display set” is set to “OFF”, you cannot play back record messages.

●

Record messages and a voice memo cannot be erased during a call.

Information

■

To use for playback

From the Stand-by display, press to play back the most recent message.

■

To skip to next message

Each time you press during playback, messages are played back in the following order; the next new message

→…

→

the oldest record message →a voice memo.

■

To cancel playback midway

Press , or .

Play/Erase msg. ( ) Do the following operations.

Function Menu of Playing/Erasing Record Message

Operations

You can play back a message.

YES

●

To cancel, select “NO” and press .

●

You can erase a message also by pressing ( ) during playback.

You can erase all record messages.

YES

●

To cancel, select “NO” and press .

You can erase all record messages and a voice memo.

YES

●

To cancel, select “NO” and press .

Function menu

Play

Delete this

Delete rec. msg.

Delete all

Making/Receiving Video-phone Calls

About Video-phone························································································································ 74 Making a Video-phone Call ··········································································································· 75 Switching from a Video-phone Call to Voice Call ······································································· 78 Receiving a Video-phone Call······································································································· 78 Using Chara-den ···························································································································· 80 Useful Functions for Video-phone Calls······················································································ 82 Setting Image Quality for Video-phone Calls·····································<Moving Image Quality> 85 Turning Camera On/Off Automatically when Making a Video-phone Call

·············································································································<Camera Image Sending> 85 Changing Image Displays for Video-phone Calls·············································<Select Image> 86 Redialing as a Voice Call when a Video-phone Call cannot be Connected

··············································································································<Voice Call Auto Switch> 87 Setting for Switching between a Voice Call and a Video-phone Call

···················································································································

<Indicate Video-phone> 88 Checking Home from Where You are ···················································<Remote Observation> 88 Setting Display for Video-phone Calls····································<Video-phone Display Setting> 91

Making/Receiving Video-phone Calls

When both you and the other party use DoCoMo video-phones, you can talk seeing each other.

●

You can use the video-phone function between the phones supporting the DoCoMo video-phones.

DoCoMo video-phones conform to 3G-324M, which is the international standard for 3GPP. You cannot connect to the video-phone that uses a different format.

●

3GPP (Third Generation Partnership Project):

This is the regional standards organization for developing common technical specifications for third-generation mobile telecommunication systems (IMT-2000).

●

3G-324M:

This is the international standard for the third generation of mobile video-phones.

Dialing speed of video-phone calls 64K: Transmits at 64 kbps of dialing speed. 32K: Transmits at 32 kbps of dialing speed.

●

Depending on the video-phone setting, you can communicate only by voice sending the image set for “Substitutive image”. (See page 82) Note that you will still be charged for the digital transmission, not the voice calls.

●

You cannot make a video-phone call during a voice call or while exchanging data using packet transmission.

Information

About Video-phone

Image + Sound

■

Display during video-phone calls

①

····Image through other party’s camera②······Image through your camera③······Call duration

④

····Present time

⑤

······Status

: 64K transmitting : Hands-free ON

: 32K transmitting : Night Mode

: Voice sending/receiving : Chara-den Whole Action mode

(gray): Voice sending/receiving failed

※

: Chara-den Parts Action mode

: Image sending/receiving : Send DTMF Mode

(gray): Image sending/receiving failed

※

: Photo image sending

: Substitutive image sending

: Chara-den talking

※

1 When voice sending fails, the other party cannot hear your voice.

When voice receiving fails, you cannot hear the other party’s voice.

※

2 When image sending fails, the other party cannot view the image through your camera.

When image receiving fails, you cannot view the image through the other party’s camera.

When voice or image sending/receiving fails, it does not recover automatically. You need to make the video-phone call again.

①

②

③ ⑤

④

Making/Receiving Video-phone Calls

Start talking when the other party answers.

●

“” or “ ” will blink at the upper right of the display during videophone dialing and light steadily during the call.

●

You can switch to Hands-free during a call by pressing . (See page 59)

●

You can press numeric keys to send touch-tone signals during a call. However, switch to the DTMF transmission mode for a Chara-den call. (See page 85)

●

If you close the FOMA phone during a call, the FOMA phone works in accordance with the setting of “Fold setting”. (See page 62)

●

When the Flat-plug Earphone/Microphone Set with Switch (option) is connected, you can hear the other party’s voice from the earphone. (See page 449)

●

During a video-phone call, you can press to send the substitutive image to the other party. To resume sending the image through your camera, press again.

●

You can use “Camera image sending” to select whether to send the image through your camera to the other party.

Enter the other party’s phone number.

●

If you press or to dial, the voice phone call is made even when an image to send to the

other party is selected by “Select image” or even when “Dialing speed” is set to “64K” or “32K”.

●

You can make a video-phone call also by vocalizing and retrieving a Phonebook entry stored in the Voice Dial List. (See page 111)

●

Press

()

to store the entered phone number in the Phonebook. Go to step 2 on page 99.

The digital communication charges start from this display.

Press to end the call after talking.

Making a Video-phone Call

■

When a video-phone call cannot be connected

When a video-phone call cannot be connected, the reason is displayed. (The displayed reason might not be the same as the actual reason depending on the other party’s phone and contract for network services.)

Messages Reasons

Check the number and retry You have dialed a wrong phone number. Busy The line is busy or during packet transmission. Out of service area or power off The other party’s phone is out of the service area or turned off.

Select on for Call ID Notification

The Caller ID is not notified. (when dialing “V-live” or “Visualnet”)

Your call is being forwarded When forwarding.

Please redial phone call

Either the other party activates Voice Mail Service or forwarding destination phone does not support the video-phone call.

Failed to connect

Redial after setting “Activate” of “Caller ID notification” to “ON”.

・

This may appear in the case other than above.

Making/Receiving Video-phone Calls

●

Note that when you make a video-phone call sending a substitutive image, you will be charged for the digital transmission.

●

You can make video-phone calls to any DoCoMo video-phone, no matter the type.

●

If you dial 110, 119 or 118 using the video-phone function, the number will be automatically dialed out as a voice call.

●

You cannot receive mail and Messages R/F during video-phone calls. Incoming mail and Messages R/F will be held at the i-mode Center. You can retrieve them using “Check new message”, when you end the video-phone call. However, you can receive SMS messages during a video-phone call.

●

During Hands-free use, be sure to keep the FOMA phone away from your ears. Otherwise, you could affect or damage your hearing.

●

If the battery runs low during a video-phone call, the message “Recharge battery” appears and the substitutive image is sent to the other party. However, if you set “Chara-den” as a substitutive image, the “Pre-installed” substitutive image is displayed. If you charge the battery during a video-phone call, the image set for “Substitutive image” of “Select image” is displayed.

●

You cannot make video-phone calls by entering the phone number when “Keypad dial lock”, “Restrict dialing” or “Self mode” is activated.

●

The International video-phone call is available using the DoCoMo International Call Service “WORLD CALL”. (See page 50)

Information

■

Auto-redialing

If the video-phone call is not connected, dialing at 32K or the voice call is automatically made.

●

The video-phone call by 32K speed is provided to connect with PHSs and similar devices that cannot be connected at 64K depending on the network conditions. When you dial a 64K video-phone call to the phone that can be connected only at 32K, the dialing speed will be switched automatically to 32K.

※

The same digital transmission charge applies to the 32K video-phone connection and 64K digital connection.

●

Video-phone calls cannot be connected to phones if they do not support the video-phone function, are out of the service area, or are switched off. If you have set “Voice call auto switch” to “ON” and attempt to dial a phone that does not have the video-phone function, the video-phone call will be cut off and the number will be redialed as a voice call. Note that this setting might not work if you call an ISDN synchronous 64K or PIAFS access point or an ISDN video-phone that does not support 3G-324M (as of May

2005), or if you dial the wrong number. Nevertheless, you could be charged for the call.

●

Once the video-phone call has started communications, redialing as the voice call will not be made.

Voice call auto switch “ON” Voice call auto switch “OFF”

Could not connect by dialing at 64K. Dials again at 32K. Dials again at 32K. Could not connect by dialing at 32K. Dials again by the voice call. Does not dial again.

While entering a phone number ( ) Do the following operations.

Function Menu while entering Phone Number

Function menu

Notify caller ID

Prefix numbers

International dial

Multi number

Add to phonebook

Compose message

Dialing speed

Select image

Operations

You can select whether to notify caller ID. (See page 46)

You can add a prefix number. (See page 58)

You can make an international call. (See page 52)

See page 464.

You can store the data in the Phonebook. (See page 99)

You can compose a mail message to send to the phone number set as the destination address. Go to step 3 on page 245.

You can set the dialing speed per video-phone call.

64K··················For dialing video-phone calls at 64K. 32K··················For dialing video-phone calls at 32K.

You can select an image for video-phone calls. (See page 87)

Making/Receiving Video-phone Calls

●

●

The priority order for Dialing Speed is; “Setting by call” →“Setting by phone number” →“Setting by group”.

●

The dialing speed is set for just the one call (dial-out). Redial and Dialled Call Record do not store the dialing speed.

●

This setting will be canceled if you make a voice call after setting the dialing speed.

Information

Set Dialing Speed by Phone Number

You can set dialing speed for each phone number stored in the FOMA phone’s Phonebook.

Detailed Phonebook display ( ) Utilities Dialing speed

64K·············For dialing video-phone calls at 64K. 32K·············For dialing video-phone calls at 32K. “Dialing speed” is indicated by “

★

”.

●

See page 101 for how to search the Phonebook.

●

To release the dialing speed for the phone number, perform the same operation.

●

You cannot set the dialing speed for the Phonebook entries stored in “Secret mode” “Secret only mode”, and in the UIM.

●

Note that this setting will be released if you change the phone number in the Phonebook entry.

●

To change the set dialing speed, release the current setting and then proceed.

●

Use “Utilities” to check which phone number in the Phonebook entry is set, or to release the setting.

Information

●

You cannot set the dialing speed for “Group 00” and the groups in the UIM.

●

To change the set dialing speed, release the current setting and then proceed.

●

If the same phone number is stored in multiple groups, the dialing speed set for the group of the phone number which is accessed initially in the column-search order has priority.

●

You can set this function for either the group in which secret and ordinary Phonebook entries are stored together or the group in which only secret entries are stored.

●

Use “Utilities” to check which group is set, or to release the setting.

Information

You can set dialing speed for each group stored in the FOMA phone’s Phonebook. If you set the dialing speed by phone number, that setting has priority.

Group setting Select a group ( ) Utilities Dialing speed

64K·············For dialing video-phone calls at 64K. 32K·············For dialing video-phone calls at 32K. “Dialing speed” is indicated by “

★

”.

●

To release the dialing speed for the group, perform the same operation.

Set Dialing Speed by Group

Making/Receiving Video-phone Calls

When you answer a video-phone call, your image and the caller’s image are displayed. You can answer video-phone calls without sending the image through your camera to the caller’s display (substitutive image answering).

When you receive a video-phone call, “Incoming V.phone” is displayed, the ring tone sounds and the Call/Charging indicator and Command Navigation key flicker.

●

You can use “Illumination” to set an illumination pattern for the Call/Charging indicator.

●

To vibrate the phone for incoming calls, set “Video-phone” of “Vibrator” to other than “OFF”.

●

While “Manner mode” or “Super silent” is set, the ring tone does not sound. (See pages 122 and 123)

●

While receiving a call, information is displayed on the Private window and the dot-area data for the incoming call is displayed.

●

“”

is displayed at the upper right of the phone number for an incoming international video-phone call.

Receiving a Video-phone Call

●

It takes about five seconds to switch. Switching may take a longer time depending on the radio wave conditions.

●

Depending on how the other party

’s

phone is working or on the radio wave conditions,

switching from a video-phone call to voice call may

fail and the connection may be cut off.

●

You cannot switch between the video-phone call and voice call unless “Indicate V-phone” is set to “Activate” at the other end. See page 88 for “Indicate V-phone”.

●

Hands-free is not released even if you switch from the video-phone call to voice call during Hands-free. You cannot set Hands-free ON/OFF while the display for “Changing” is displayed.

●

An alarm for “Quality alarm” and “Reconnect control” does not sound during switching.

●

See page 53 for switching from a voice call to video-phone call.

Information

During a video-phone call ( ) CHG to phone call YES

●

To cancel, select “NO” and press . The video-phone call returns.

●

While switching, the “Changing” display appears and the voice guidance to that effect is played back.

You (caller) can switch from a video-phone call to a voice call during a call. When the other party’s phone has a function to switch between the calls, you can switch from the videophone call to voice call by selecting “CHG to phone call” from the Function menu. (901iS series only supported, as of May 2005)

Switching from a Video-phone Call to Voice Call

Making/Receiving Video-phone Calls

Press to answer the video-phone call.

You can send the image through your camera to the other party. Press or to take a video-phone call, and the substitutive image is sent to the other party.

●

When “Answer setting” is set to “Quick silent”, you can stop only the ring

tone by pressing a certain key.

●

“Any key answer” is disabled.

●

If you take the video-phone call by pressing the switch of Flat-plug

Earphone/Microphone Set with Switch (option) or by using Automatic answer, the substitutive image is sent to the other party. (See pages 450 and 451)

●

You can switch to Hands-free during a call by pressing . (See page 59)

●

Press during a call, and then you can switch between your photo image and substitutive image for sending to the other party.

●

If you close the FOMA phone during a call, the FOMA phone works in accordance with the setting of “Fold setting”. (See page 62)

■

One-push answer

When a video-phone call comes in with the FOMA phone closed, you can answer the video-phone call just by pressing the one-push open button and opening the FOMA phone.

●

The still image set for “Substitutive image” of “Select image” is sent to the other party.

●

You need to set “Video-phone” of “Open phone” to “Answer” in advance.

●

You can answer the call also by opening the FOMA phone manually without using the one-push open button.

Press to end the call after talking.

●

The substitutive image is displayed if the caller’s image is not received during the call because of the caller’s settings.

●

When a video-phone call comes in while Voice Mail Service is set to “Activate”, the call is disconnected after the ringing time specified for the service has elapsed.

●

Even if Call Forwarding Service is set to “Activate”, the call is not forwarded unless the forwarding destination is a phone compatible with the video-phone conforming to 3G-324M (see page 74). Confirm the phone you are forwarding the call to and then activate the service. The video-phone caller does not hear the guidance to the effect that the call is forwarded. (The message to the effect that the call is to be forwarded appears, depending on the destination FOMA phone.)

●

If a video-phone call comes in from the phone number to be rejected by “Nuisance Call Blocking Service”, the call is not connected and then disconnected.

●

During Hands-free use, be sure to keep the FOMA phone away from your ears. Otherwise, you could affect or damage your hearing.

●

If the battery runs low during a video-phone call and the message “Recharge battery” appears, the substitutive image is sent to the other party. However, if you set Chara-den as a substitutive image, the “Pre-installed” substitutive image is displayed. If you charge the battery during a video-phone call, the image set for “Substitutive image” of “Select image” is displayed.

●

During Drive Mode, the ring tone does not sound and the Call/Charging indicator does not flicker for incoming video-phone calls. Incoming calls are recorded as missed calls in the Received Call Record.

●

Note that when you make a video-phone call sending a substitutive image, you are charged for the digital transmission.

Information

Function menu

Call rejection

Call forwarding

Operations

You can hang up the phone without answering the call.

●

You cannot reject calls if you have set “Video-phone” of “Open phone” to “Answer” and the call is received with the FOMA phone closed.

You can forward the call to the forwarding destination. (See page 459)

While a video-phone call is ringing ( ) Do the following operations.

Function Menu while Video-phone Call Rings

Making/Receiving Video-phone Calls

Set by Phone Number

You can set a Chara-den image for each phone number stored in the FOMA phone’s Phonebook as a substitutive image for a video-phone call.

Detailed Phonebook display ( ) Utilities Chara-den setting

Select a Chara-den image

“Chara-den setting” is indicated by “★”.

●

See page 101 for how to search the Phonebook.

●

To release the Chara-den setting for the phone number, perform the same operation.

●

You cannot set this function for Phonebook entries stored as “Secret mode”, “Secret only mode”, and in the UIM.

●

Note that this function is released when you change the set phone number.

●

To change the set Chara-den image, release the current setting and proceed.

●

Use “Utilities” to check which phone number in the Phonebook entry is set, or to release the setting.

Information

You can set a Chara-den image for each group

stored in the FOMA phone’s Phonebook

as a substitutive

image for a video-phone call. If you have set a Chara-den image by phone number, that setting has priority.

Set by Group

Group setting Select a group ( ) Utilities

Chara-den setting Select a Chara-den image

“Chara-den setting” is indicated by “★”.

●

To release the Chara-den setting for the group, perform the same operation.

Using Chara-den

●

The priority order for substitutive images to be sent to the other party is; “Setting by call” →“Setting by phone number”

→

“Setting by group” →“Chara-den image stored in Phonebook” →“Select image”.

●

The setting applies just for the one call (dial-out). The settings for “Camera image sending” and “Select image” do not change. Further, the setting is not stored in Redial/Dialled Call Record.

●

The setting will be canceled if you make a voice call after operating for “Chara-den call”.

Information

Set by Call

Chara-den display/Chara-den List ( ) Chara-den call

Enter the destination phone number and press to make a video-phone call.

●

See page 382 for the key assignment for operating Chara-den.

You can send a Chara-den image instead of the image through your camera. See page 381 for Chara-den.

You can select a Chara-den image to set for making a video-phone call.

When you have set “Indicate V-phone” to “ON”, the caller (the other party) can switch from a videophone call to voice call.

Switched from a Video-phone Call to Voice Call by the Other Party

During a video-phone call The other party switches to a voice call.

●

While switching, the message to that effect is displayed and the voice guidance is played back.

●

You (receiving end) cannot switch the call to voice call.

Making/Receiving Video-phone Calls

●

You cannot set for “Group 00” and groups in the UIM.

●

To change the set Chara-den image, release the current setting and proceed.

●

If you store the same phone number in multiple groups, the Chara-den image set for the group of the phone number which is accessed initially in the column-search order has priority.

●

You can set this function for either the group in which secret and ordinary Phonebook entries are stored together or the group in which only secret entries are stored.

●

Use “Utilities” to check which group is set, or to release the setting.

Information

●

While PIM Lock is activated, a “Pre-installed” substitutive image is sent.

●

If you have deleted a Chara-den image set as a substitutive image, a “Pre-installed” substitutive image is sent.

Information

Substitutive Image

You can set a Chara-den image for “Substitutive image” of “Select image”.

Chara-den display/Chara-den List/Chara-den Recording display ( )

Substitute image

You can switch Chara-den images during a Chara-den call.

During a Chara-den call ( ) Chara-den setup Switch chara-den

Select the Chara-den image to be displayed

Setting at purchase

ブンブン

(Dimo)

Switch Chara-den

Action List

You can display the list for actions that you can operate.

During a Chara-den call ( ) Chara-den setup Action list

●

You can display Action List also by pressing .

●

Select an action and press to execute the action.

●

You can check the details of action by pressing ( ).

Change Action

Setting at purchase

Whole Action Mode

You can switch the action between the Whole Action mode and the Parts Action mode. The Whole Action mode makes an animation character “delighted” or “angry” expressing his or her sentiment by whole aspect. The Parts Action mode makes the animation character “raise right hand” or do other actions expressing his or her sentiment by part aspect.

During a Chara-den call ( ) Chara-den setup Change action

●

The Parts Action mode is switched to the Whole Action mode, and the Whole Action mode is switched to the Parts Action mode.

●

You can switch modes also by pressing .

Switch Substitutive Image

You can switch a substitutive image to send to the other party to the still image set for “Original” of “Select image”.

During a Chara-den call ( ) Chara-den setup SW subst’ve image

●

While PIM Lock is activated, a “Pre-installed” substitutive image is sent.

Information

Making/Receiving Video-phone Calls

■

About substitutive image to be sent

You can set the substitutive image by following the four functions described below:

・

A Chara-den image set by “Utilities” (set by phone number)

・

A Chara-den image set by “Utilities” (set by group)

・

A Chara-den image stored in the Phonebook

・

A still image or Chara-den image set for “Substitutive image” of “Select image” In addition, you can set a Chara-den image by call. (See page 80) The priority order of the substitutive image to be sent to the other party is; “Setting by call” →“Setting by phone number”

→

“Setting by group” →“Chara-den image stored in Phonebook” →“Select image”.

■

To answer a video-phone call sending a substitutive image

Press or to answer a video-phone call during ringing. The substitutive image is sent to the other party.

●

To switch the substitutive image to the image through your camera, press .

●

Note that “Setting by phone number”, “Setting by group”, and “Chara-den image stored in Phonebook” are disabled when a video-phone call comes in without notifying the Caller ID.

●

While PIM Lock is activated, a “Pre-installed” substitutive image is sent.

●

If you have deleted a Chara-den image set as a substitutive image, a “Pre-installed” substitutive image is sent.

Information

During a video-phone call

The camera switches off and the substitutive image is sent to the other party. “” is displayed while the still substitutive image is being sent. However, “” appears if you have set a Chara-den image as a substitutive image (in Chara-den call).

●

Press again to switch from the substitutive image to the image

through your camera.

●

If you have set “Chara-den” as the substitutive image, the Chara-den image will be sent to the other party.

During a Chara-den call, you can operate the keys to add action to the Chara-den image. Some Chara-den images automatically lip-synch to your voice. (See page 382)

You can switch the image to be sent to the other party, from the image through your camera to the still image or Chara-den image set as the substitutive image.

Send Substitutive Images

Useful Functions for Video-phone Calls

●

When switching the cameras, a still image appears but it is not sent to the other party.

Information

You can switch the photo image to be sent to the other party from through the inside camera to through the outside camera.

Switch Cameras

At video-phone start-up

Inside camera

During a video-phone call ( )

●

Press ( ) again to return to the previous camera.

●

You can switch the cameras also by pressing ( ), selecting “Outside camera” or “Inside camera” from the Function menu, and pressing .

●

The setting here is effective only for the current video-phone call.

You can take a close-up shot during a video-phone call. (See page 176)

Close-up

Making/Receiving Video-phone Calls

●

Note that when you make a video-phone call sending a substitutive image, you are charged for the digital transmission.

Information

Switch Image Display Positions

You can adjust zoom magnification for the photo image to be sent to the other party. During a video-phone call, the maximum magnification is 2.0 times for the inside camera and 2.7 times for the outside camera.

During a video-phone call

Use to adjust the zoom magnification

The zoom magnification changes each time you press (telescopic image) or

(wide-angle image). To change the magnification continuously, press and hold (telescopic image) or (wide-angle image).

For wide-angle image

(Wide)

For telescopic image

(Tele)

Zoom

●

The original zoom setting returns when the video-phone call ends.

●

Even if you switch the cameras during a video-phone call (see page 82), the magnification for the inside camera and outside camera is retained.

●

Even if you switch the image being sent to the other party to a substitutive image, and then switch back to the image through your camera, the zoom magnification is retained.

Information

You can switch the display locations of your image and the other party’s image.

During a video-phone call

●

Press to switch displays as follows:

The image through your

camera only appears.

The image through your

camera appears on the main

display.

The image through the other

party’s camera appears on

the main display.

The image through the other

party’s camera only appears.

At video-phone start-up

Wide

Making/Receiving Video-phone Calls

Function menu

V-phone settings (Visual preference)

V-phone settings (Brightness)

V-phone settings (White balance)

V-phone settings (Color mode set)

V-phone settings (Night mode)

Chara-den setup

Display light

Photo light

Call time disp.

Operations

You can set the quality of the other

party’s

image on the display and of your image to be sent.

Visual preference

Normal·····················

Displays/Sends images in standard quality and motion speed. (At video-phone start-up)

Prefer img qual

········

Displays/Sends images laying stress on image quality

Prefer motion spd

····

Displays/Sends images laying stress on motion speed

You can adjust the brightness of the photo image to be sent to the other party.

Brightness +2 ····················Appreciably brighter. +1 ····················Somewhat brighter. 0 ······················Normal. (Setting at purchase)

-1 ·····················Somewhat darker.

-2 ·····················Appreciably darker.

You can adjust the colors of the photo image to be sent to the other party, to make the colors look more natural.

White balance Fine weather ···········For outdoors in fine weather. Cloudy weather ······For outdoors in overcast conditions or in the shade. Automatic················Adjusts the white balance automatically. (Setting at purchase) Light bulb················For artificial lighting.

You can switch the color tone of the photo image to be sent to the other party.

Color mode set Normal·····················Sets a normal tone. (At video-phone start-up) Reverse ···················Switches to a negative tone. Sepia························Switches to a sepia tone. Monochrome···········Switches to a black-and-white tone.

You can lengthen the camera’s exposure time to make the photo image to be sent clear in a dark place.

Night mode ON ···················Sets Night Mode. OFF ·················Releases Night Mode. (At video-phone start-up)

You can select the setting for Chara-den calls. You can set this function only during a Chara-den call.

Switch chara-den ············Switches the Chara-den images. (See page 81) Action list·························Displays the action list for the Chara-den image. (See page 81) Change action ·················Switches the action modes. (See page 81) SW subst’ ve image ········Switches a substitutive image to send to the other party to the still

image set for “Original” of “Select image”. (See page 81)

●

The setting here is effective only for the current video-phone call.

You can set the lighting duration of the display.

Constant light

···········

For keeping the display lit. (Setting at purchase)

15 seconds light

·······

For turning the light off when no operation has been done for about 15 seconds.

You can set Photo Light to light for when sending the image through the outside camera to the other party.

ON ···················Lights the Photo Light. OFF ·················Does not light the Photo Light. (At video-phone start-up)

You can select whether to display the call duration during a video-phone call. (See page 443)

During a video-phone call ( ) Do the following operations.

Function Menu while on Video-phone Call

Making/Receiving Video-phone Calls

<V-phone settings (Visual preference)>

●

“Prefer motion spd” is effective for moving images. When there is little motion, the quality becomes better if you set to “Prefer img qual”.

●

If the radio wave conditions weaken during a video-phone call, the image may appear like a mosaic.

●

Photo Light does not light when you are sending the image through the inside camera or substitutive image.

●

Even in the DTMF transmission mode, you can switch to Manner Mode by pressing and holding for at least one second.

●

In the DTMF transmission mode, you cannot operate a Chara-den image in the Whole Action and Parts Action mode.

●

The DTMF tone may not be received depending on the device of a receiving end.

Information

Video-phone Moving image quality

Normal ·························Displays/Sends images in standard quality and motion speed. (At video-phone start-up) Prefer img qual ············Displays/Sends images laying stress on image quality. Prefer motion spd ········Displays/Sends images laying stress on motion speed.

●

You can set the image quality also from the Function menu by pressing ( ) during a video-phone call. (See page 84) In that case, the setting will be effective only during that video-phone call.

●

“Prefer motion spd” is effective for moving images. When there is little motion, the quality becomes better if you set to “Prefer img qual”.

●

If the radio wave condition weakens during a video-phone call, the image may appear like a mosaic.

Information

Setting at purchase

Normal

Setting Image Quality for Video-phone Calls

You can set the quality of the other party’s image on the display and of your image to be sent.

Video-phone Camera image sending

ON··············Sends the image through your camera to the other party. OFF············Sends the substitutive image automatically to the other party, instead of sending the image through your camera.

Setting at purchase

Turning Camera On/Off Automatically when Making a Video-phone Call

Function menu

Screen size

Outside camera/ Inside camera

CHG to phone call

Send DTMF tone/ DTMF tone OFF

Own number

Operations

You can select how to display the image on the main display. (See page 91)

You can switch the cameras. (See page 82)

You can switch the current video-phone call to the voice call. (See page 78)

During a Chara-den call, you can switch to the DTMF transmission mode that enables you to enter the data from the numeric keys and to send DTMF (touch-tone signals). You can set it only during a Chara-den call.

●

“Send DTMF tone” is displayed when the mode is not the DTMF transmission mode and “DTMF tone OFF” is displayed in the DTMF transmission mode.

●

You can operate this only during a Chara-den call.

You can display your phone number (own number).

●

During PIM Lock, you cannot operate.

BVIG

Making/Receiving Video-phone Calls

●

The stored still image is not deleted even when you switch the image from “Original” to “Pre-installed” or “Chara-den”.

●

The still images set for “Substitutive image”, “Holding”, “On hold”, “Record message” and “Voice memo” are displayed both on your FOMA phone and the other party’s handset. However, a hold tone for “On hold”, and the answer message for Record Message are only sent to the other party’s handset.

●

You cannot delete the “Original” still image. To change the “Original” image, use “Set as display” to overwrite it. Even if you delete the pasted still image, it is displayed on (sent to) the destination phone.

●

While PIM Lock is activated, a “Pre-installed” substitutive image is sent.

●

If you have deleted a Chara-den image set as a substitutive image, a “Pre-installed” substitutive image is sent.

Information

Image Selection display ( ) Do the following operation.

Function Menu of the Image Selection Display

Function menu

Change setting

Operation

You can change the still image set for “Original” or Chara-den image.

If you have selected “Original”

Select a folder Select a still image

●

See pages 346 and 347 for still image folders and lists.

●

Press ( ) to play back the demonstration and check the still image.

If you have selected “Chara-den”

Select a Chara-den image

●

You can play back a Chara-den image for confirmation by pressing ( ).

You can set the image to be sent to the other party instead of the image through your camera.

Video-phone Select image

On hold ························

Sets the still image to send when you put the other party on hold during ringing of a video-phone call. Holding·························Sets the still image to send when you put the other party on hold during a video-phone call. Substitutive image ·······Sets the substitutive image (still image or Chara-den image) to send when the camera is off during a

video-phone call. Record message··········Sets the still image to send while recording a video-phone record message from callers. Preparing ·····················Sets the still image to send while playing back an answer message for a video-phone record message. Voice memo·················Sets the still image to send while recording a video-phone voice memo.

Changing Image Displays for Video-phone Calls

Setting at purchase On hold ·······················Pre-installed Holding························Pre-installed Substitutive image·······Chara-den [

ブンブン

(Dimo)] Record message·········Pre-installed Preparing ····················Pre-installed Voice memo················Pre-installed

Select an image

Pre-installed ·············For sending a pre-installed still image to the other party. Original·····················For sending an appropriate message with a still image stored using

“Set (as) display”.

Chara-den ················For sending the Chara-den image selected by “Substitute image”. (See page 81)

(Displayed only when “Substitutive image” has been selected in step 1.)

●

You can play back the still image or Chara-den image for confirmation by pressing ( ).

Making/Receiving Video-phone Calls

If a video-phone call cannot be connected, it will be automatically redialed as a voice call.

Video-phone Voice call auto switch

ON··············Switches automatically to a voice call when a video-phone call is not connected. OFF············Displays the message that you have failed to connect the video-phone call, and returns to the Stand-by display.

Setting at purchase

OFF

Redialing as a Voice Call when a Video-phone Call cannot be Connected

Select a Chara-den image

●

The charges for calls once switched to voice calls are billed at the rates for the voice calls, not the digital transmission.

●

Once the dialed video-phone is connected, the dialing operation for a voice call cannot be done.

●

“Voice call auto switch” cannot be done when the dialed video-phone is a non-existent number, busy, out of the service area, off, set to be rejected because of no ID, or in Drive Mode.

●

When “Voice call auto switch” has been operated, only the last call is stored in the Dialled Call Record.

Information

Set by Call

You can set the image to be sent to the other party for making a video-phone call.

()Select image

Me································Sends the image through your camera to the other party. The setting is completed. Chara-den····················Sends a Chara-den image to the other party. Terminate (Release) ····Cancels the setting by every call. The setting is completed.

●

During PIM Lock, you cannot select “Chara-den”.

Enter a phone number, or bring up the detailed display of a Phonebook entry, redial item, dialed call record, or received call record.

●

The priority order for images to be sent to the other party is; “Setting by call” →“Camera image sending”.

●

You cannot select “Chara-den” while you are receiving i-mode mail attached with the JPEG image in excess of 10,000 bytes.

●

The setting will be canceled if you make a voice call after setting “Select image”.

Information

●

You cannot operate while selecting “Pre-installed”.

●

See page 355 for settable still images.

Information

Making/Receiving Video-phone Calls

Checking Home from Where You are

Store/Change Other ID

You need to previously store the phone numbers from which the installed FOMA phone takes calls. You can store up to five phone numbers. You cannot set “Remote observation” to “ON” when no “Other ID” is stored.

Video-phone Remote observation

Enter the Terminal Security Code Other ID

●

See page 146 for the Terminal Security Code.

You can observe the remote location by calling the FOMA phone from a phone that has the video-phone function based on 3G-324M. While “Remote observation” is set to “ON”, the FOMA phone automatically starts remote observation when receiving a video-phone call from a phone number stored as “Other ID” of “Remote observation”. (The FOMA phone needs to be opened.)

Setting at purchase

Not recorded

Setting for switching between a Voice Call and a Video-phone Call

You can let the other party know that your FOMA phone can switch between the voice call and videophone call. This function is set to “Activate” at the time of contract. When “Indicate V-phone” is set to “Activate”, the caller can switch between the video-phone call and voice phone call. You cannot operate “Indicate V-phone” when you are out of the service area or radio waves do not reach.

Activate

You can activate the function.

Video-phone Indicate V-phone Activate YES OK

●

To cancel, select “NO” and press .

●

You cannot operate these functions during a voice call or video-phone call.

Information

Deactivate

You can deactivate the function.

Video-phone Indicate V-phone Deactivate YES OK

●

To cancel, select “NO” and press .

Check Indication

You can check the setting of the function.

Video-phone Indicate V-phone Check indication

●

After checking, press .

Ringing Time

Making/Receiving Video-phone Calls

●

If you delete all Other IDs, “Remote observation” is set to “OFF”.

Information

Function menu

Look-up address

Delete this

Delete all

Operations

You can look up a phone number in the Phonebook, Dialed Call Record, or Received Call Record. (See page 246)

YES

●

To cancel, select “NO” and press .

YES

●

To cancel, select “NO” and press .

Other ID List ( ) Do the following operations.

Function Menu of the Other ID List

Video-phone Remote observation Enter the Terminal Security Code

Ringing time

●

See page 146 for the Terminal Security Code.

Enter a ringing time (seconds).

●

Enter from “003” to “120” in three digits.

●

Not to change a ringing time, just press without entering a time.

●

You cannot set the same ringing (response) time for Remote Observation, Automatic Answer and Record Message. Set

different time for each.

You can set the time until remote observation starts after receiving a video-phone call.

Setting at purchase

5 seconds (When set to “ON”)

Video-phone Remote observation Enter the Terminal Security Code

Set

ON··············

Automatically answers video-phone calls from phone numbers stored as “Other ID” to start remote observation after the set ringing time. (You cannot select “ON” when “Other ID” is not stored.)

OFF············Performs usual answering operation even if video-phone calls come in from phone numbers stored as “Other ID”.

●

“” is displayed while this function is set to “ON”.

●

You cannot set “ON” in Manner Mode. The message telling that the remote observation in Manner Mode is disabled appears.

●

See page 146 for the Terminal Security Code.

Set Remote Observation

You can set whether to activate remote observation for when receiving video-phone calls from phone numbers stored as “Other ID”.

Setting at purchase

OFF

<Not recorded> Enter the phone number

●

To change, select the stored phone number.

●

You can enter up to 26 digits by using numeric, #, :, or +. If the entered phone number does not match the incoming Caller ID, remote observation will not be activated.

Making/Receiving Video-phone Calls

A video-phone call comes in from a stored phone number.

●

The ring tone for remote observation sounds. (You cannot change the ring tone for remote observation.) The ring tone sounds at the volume set for “Video-phone” of “Ring volume”, but at “Level 2” if you have set “Step”, “Level 1” or below.

●

The illumination color for incoming remote observation calls is “Gradation”, and its illumination pattern is “Standard”, regardless of the Illumination setting.

●

When a remote observation call comes in, “Open phone” is disabled.

●

Even when remote observation is set, you can press to take the video-phone call before automatic answering and send the image through your camera to the other phone. Also, if you press or , the video-phone call will start by sending the substitutive image to the other party.

●

If you press when a remote observation call comes in, the call will be cut and remote observation will not be done.

●

To make a remote observation call, the caller needs to notify the Caller ID and make a video-phone call.

●

If the caller does not notify the Caller ID, remote observation will not be done and the call will be treated as an ordinary incoming video-phone call.

Observation by Video-phone

The call is taken automatically after the ringing time set for “Remote observation”, and remote observation begins.

The camera setting switches to “ON” regardless of the setting for “Camera image sending”, and the image through the camera and sound will be sent. (You cannot switch to a substitutive image.)

●

The image through the caller’s camera appears on the display and the sound is played back from the speaker.

●

You cannot set voice-only remote observation.

●

During remote observation, the receiving end cannot operate anything other than pressing to end remote observation.

End remote observation.

Remote observation ends when either the dialing side or receiving side presses .

●

Remote observation can be done using video-phones in conformity to 3G-324M.

●

You cannot be remote-observed during Manner Mode and Drive Mode. However, you can be remote-observed during All Lock.

●

When Remote Observation is “ON” and a video-phone call comes in from “Other ID”, remote observation starts after the set ringing time, even when “Ringing time”, “Automatic answer”, or “Record message” is set and regardless of their ringing times.

●

When Remote Observation is “ON” and a video-phone call comes in from “Other ID”, the call will be registered as remote observation in Received Call Record. If remote observation is not done, the call will be registered as a missed video-phone call in Received Call Record.

●

If the Flat-plug Earphone/Microphone Set with Switch (option) is connected when a remote observation call comes in, the ring tone will sound from both the earphone and the speaker, even when “Earphone” is set to “Earphone”. Also, if you press the switch before answering automatically, the video-phone starts and the substitutive image is sent to the other party.

●

Open the FOMA phone for receiving remote observation. If the FOMA phone is closed when a remote observation call comes in, the call is rejected and remote observation does not start.

●

Closing the FOMA phone during remote observation activates the operation set for “Fold setting”. However, “Fold setting” is disabled when the Flat-plug Earphone/Microphone Set with Switch (option) is connected, so the substitutive image is sent to the other party when the FOMA phone is closed.

●

You cannot switch the cameras during remote observation.

●

When “Call acceptation” has been set for other phone numbers, and not for the phone number stored as “Other ID” of “Remote observation”, calls from that phone number will be rejected and remote observation will not start.

●

When “Call rejection” has been set for the phone number stored as “Other ID” of “Remote observation”, calls from that phone number will be rejected and remote observation will not start.

●

When “Reject unknown” is set to “Reject”, and the phone number stored as “Other ID” of “Remote observation” is not stored in the Phonebook, the calls from that phone number will be rejected, and remote observation will not start.

●

You cannot put incoming remote observation calls on hold.

●

During remote observation, the message “REMOTE MONITORING” is displayed on the Private window.

●

If you set both Call Forwarding Service and remote observation, and give priority to remote observation, set its ringing time shorter than that for Call Forwarding Service.

●

To use Call Forwarding Service for remote observation, store the phone number of dialing side as “Other ID” and set a 3G-324M video-phone as the forwarding destination.

Information

Making/Receiving Video-phone Calls

<Video-phone Display Setting>

Setting Display for Video-phone Calls

Please respect the privacy of individuals around you when taking and sending photos using camera-equipped mobile phones.

●

You may be imposed punishment according to the law and rule (such as the nuisance prevention ordinance) if you use the FOMA phone to give a remarkable nuisance and misdeed to the public.

Main Display

You can set the main display for video-phone calls.

Setting at purchase

Other image

Video-phone Disp. setting V-phone Main display

Other image ·················Displays the other party’s image on the main display and your own image on the sub display. Camera image ·············Displays your own image on the main display and the the other party’s image on the sub display. Only other image ·········Displays the other party’s image only. Only camera image······Displays your own image only.

Display Screen Size

You can set the image size on the main display for video-phone calls.

Setting at purchase

Fit in display

Video-phone Disp. setting V-phone Display screen size

Fit in display·················Displays the image in size fit to the screen size (232 x 192 dots). Normal ·························Displays the image in original size (equivalent).

●

Press ( ) to select “Screen size” during a video-phone call.

Only other imageCamera imageOther image Only camera image

Phonebook

Phonebooks Available for FOMA Phone ····················································································· 94 Storing Phonebook Entries in FOMA Phone···········································<Add to Phonebook> 95 Storing Phonebook Entries in UIM·················································<Add to Phonebook (UIM)> 98 Storing Displayed Phone Number/Mail Address in Phonebook Entries ·································· 99 Changing Group Names····················································································<Group Setting> 100 Dialing from Phonebooks·········································································<Search Phonebook> 101 Editing Phonebook Entries ···········································································<Edit Phonebook> 104 Deleting Phonebook Entries ·················································································<Delete Data> 105 Checking Number of Phonebook Entries ·················································<No. of Phonebook> 106 Making Full Use of Phonebooks··································································································· 106 Checking/Releasing Phonebook Utility Functions····················································<Utilities> 108 Making a Call with a Few Touches ································································<Two-Touch Dial> 109 Accessing Phonebook Entries by Voice································································<Voice Dial> 110

Phonebook

Phonebooks Available for FOMA Phone

You can use two types of Phonebook, namely the Phonebook in the FOMA phone itself, and the Phonebook in the UIM. If you categorize the use of these Phonebooks, you will be able to manage your data efficiently.

●

You can set your UIM into another FOMA phone and use the UIM Phonebook entries.

※

The number of entries you can store in the Phonebook may decrease depending on the stored contents.

Phonebook of UIM

50 entries max. in the Phonebook

Only one name per Phonebook entry

One phone number per Phonebook entry (up to 50 phone numbers in the whole Phonebook)

One

address per Phonebook entry (up to 50 addresses in the whole Phonebook)

Cannot be set

Cannot be stored

11 groups from 00 to 10

None

Six ways: By reading, name, phone number, address (mail), group, and column

Not available

Cannot be set

Cannot be stored

Phonebook of FOMA phone

700 entries max.※in the Phonebook

Only one name per Phonebook entry

Up to 4 phone numbers per Phonebook entry (up to 700 phone numbers in the whole Phonebook)

Up to 3 addresses per Phonebook entry (up to 700 addresses in the whole Phonebook)

Only one icon can be set for each phone number and each mail address

Only one address per Phonebook entry

Only one birthday per Phonebook entry

Only one memo per Phonebook entry

Up to 100 images. Only one per Phonebook entry

Up to 100 Chara-den images. Only one per Phonebook entry

20 groups from 00 to 19

From 000 to 699

Seven ways: By reading, name, phone number, address (mail), memory No., group, and column

Available (when stored in memory No. 000 to 009)

Can be set per stored phone number or

group

Can be set per stored phone number, mail

address, or group

Can be set per stored phone number or group

Can be set per stored phone number

Can be set per stored phone number or mail address

Can be stored

Item

Number that can be stored

Name (Reading)

Phone number

Mail address

Icon setting

Postal address (zip code)

Birthday

Memorandums

Still image

Chara-den

Group No.

Memory No.

Search phonebook

Two-touch dial

Ring tone

Vibrator

Illumination


Answer message

Mail ring tone

Mail vibrator

Mail illumination

Dialing speed

Chara-den setting

Restrict dialing

Call rejection

Call acceptation

Call forwarding

Voice mail

Secret code setting

Storage in Secret Mode or Secret Only Mode

Restrictions

Utilities

Contents

You can store Phonebook entries in the FOMA phone.

Add to phonebook Phone

The display for entering the name appears. Go to step 2 and enter the name.

●

You can bring up the display for selecting a storage location also by pressing ( ) from the Phonebook List.

Storing Phonebook Entries in FOMA Phone

Phonebook

Do the following operations.

Item

(Name)

(Reading)

(Group)

(Phone number)

Operations

You can enter the name of the person or company in kanji, hiragana, katakana, letters of the alphabet, or numerals. When you finish entering the name, enter the reading in succession.

Enter a name

●

You can enter up to 16 full-pitch characters. You can enter pictographs as well.

●

See page 510 for how to enter characters.

You can enter the reading in half-pitch katakana, letters of the alphabet, or numerals.

Enter a reading

●

You can enter up to 32 half-pitch characters.

●

See page 510 for how to enter characters.

●

If the displayed reading is acceptable, you do not need to edit it. However, depending on the characters entered for names or entering method, you need to enter/edit the reading.

20 groups from “Group 00” through “Group 19” are available. It is handy if you store the group names in advance. (See page 100)

Select a group

●

When the storage is completed with no group selected, the Phonebook entry is automatically stored in “Group 00”.

You can store up to 4 phone numbers per Phonebook entry. However, up to 700 phone numbers can be stored in the whole Phonebook. You can set an icon for each phone number to categorize mobile phone numbers, office phone numbers, and so on.

Enter a phone number

●

Enter from the area codes for phone numbers.

●

You can enter up to 26 digits.

●

Press and hold for at least one second to insert a pause (p) into the phone number you store. However, you cannot insert the pause (p) to the beginning of phone number or insert it consecutively. The pause (p) inserted to the end of phone number is not stored.

●

If you insert “:” in the middle of a phone number, you cannot make a call. However, the phone number is retained in Redial or Dialed Call Record.

●

You can store the phone number which includes “#” such as that for information service as well.

Select an icon

●

Another “ <Not stored>” will appear in the Add-to-Phonebook display. To store another phone number, select “ <Not stored>”.

Item

(Mail address)

(Postal address)

(Birthday)

(Memorandums)

(Image)

(Chara-den)

(Memory No.)

Operations

You can store up to 3 mail addresses per Phonebook entry. However, up to 700 mail addresses can be stored in the whole Phonebook. You can set an icon for each mail address to categorize mobile phone addresses, home addresses, and so on.

Enter a mail address

●

The mail address can consist of up to 50 half-pitch alphabets, numerals or symbol characters.

●

See page 510 for how to enter characters.

●

Store the mail address correctly including the domain (part after @). When the mail address is “phone number@docomo.ne.jp”, store the phone number only.

●

You can set the Secret Code as well. (See page 108)

Select an icon

●

Another “ <Not stored>” will appear in the Add-to-Phonebook display. To store another mail address, select “ <Not stored>”.

Enter a ZIP code Enter a postal address

●

You can enter up to 7 digits for the zip code and up to 50 full-pitch or 100 half-pitch characters for the postal address.

●

See page 510 for how to enter characters.

●

You cannot enter “〒” or “-” (hyphen) in the zip code.

●

In the postal address, you can enter pictographs as well.

Enter a birthday

●

You can enter the birthday from January 1, 1800 through December 31, 2099.

Enter memorandums

●

You can enter up to 100 full-pitch or 200 half-pitch characters for the memo.

●

See page 510 for how to enter characters.

●

You can enter pictographs as well.

The stored still image is displayed when a call comes in from the other party whose phone number is stored in the Phonebook. You can store up to 100 images out of 700 Phonebook entries.

Select image ···········Stores a still image. Release this ············Releases the stored still image. The setting for the still image is completed.

Select a folder Select a still image

●

See pages 346 and 347 for still image folders and lists.

The stored Chara-den image is displayed as a substitutive image for video-phone calls with the other party stored in the Phonebook. You can store up to 100 Chara-den images out of 700 Phonebook entries.

Select Chara-den····Stores a Chara-den image. Cancel Chara-den···Releases the stored Chara-den image. The setting for Chara-den image is

completed.

Select a Chara-den image

Enter a memory number

●

Enter a three-digit number of 000 through 699.

●

The lowest empty memory number 010 through 699 is entered as a memory number. If 010 through 699 are occupied, the lowest empty memory number from 000 through 009 is entered.

Phonebook

Press ( ).

●

If you have not entered any name, “ ” is not displayed and you cannot store the entry.

＊

You need to obtain a miniSD memory card separately to use the functions related to the miniSD memory card. (See page 395)

Phonebook

■

When you cannot add Phonebook entry

●

If the location (Memory No.) you have selected already contains an entry, the confirmation display appears asking whether to overwrite it. Select “YES” and press to replace the existing entry with the new one. Select “NO” and press to keep the original entry in that location (Memory No.) and return to the Add/Edit display. Enter another memory number.

●

In ordinary mode other than “Secret mode” or “Secret only mode”, you cannot overwrite the entry stored in “Secret mode” or “Secret only mode”. Enter another memory number.

●

You cannot store Phonebook entries while “Keypad dial lock”, “Restrict dialing” or “PIM lock” is set.

■

When Phonebook editing is interrupted

When the battery goes flat

When the battery alarm sounds while you are editing a Phonebook entry, the message “Recharge battery” (see page 42) appears. The data you are editing will be saved automatically, so you can charge the battery and continue editing, or you can change to a charged battery and then resume editing as follows:

1. Add to phonebook Phone/UIM

●

If you select the storage location for the interrupted Phonebook entry, the confirmation display appears asking whether to resume editing.

2. Re-edit.

●

To add a new Phonebook entry, select “New” and press . In the case, the data you are editing is retained. If you try to store the interrupted entry after you finish storing a new one, the confirmation display appears again.

3. Resume editing the interrupted entry.

●

Only the most recently interrupted entry is retained.

●

If you resume editing the data but then cancel editing without storing it, that data will be abandoned. Once you recall the data, be sure to store it.

If you receive a call or mail

If you receive a call or mail while editing a Phonebook entry, you can respond it leaving the edited data as it is, thanks to the Multitask function. To return to the Phonebook Edit display, press and hold for at least one second to switch the menu. You can return to the Phonebook Edit display also by ending the call or mail function.

■

Important

■

●

The stored contents may be lost due to a malfunction, repair, or other mishandling of the FOMA phone. You are well advised to take notes of the contents stored in the FOMA phone, or save them to the miniSD memory card (see page 395). If you have a personal computer, you can save them also to the personal computer by using the FOMA USB Cable (option) and the Data Link Software (see page 551).

●

Note that we at DoCoMo shop counters might not be able to copy data from your existing FOMA phone to the new one, depending on the specifications.

Be advised that we cannot be held responsible for the loss of data stored in your FOMA phone.

●

If you enter Russian or Greek letters, certain symbols, pictographs, or full-pitch characters that are not in the Kuten Code List, for a name, you cannot display them in the Reading Edit display.

●

If you enter “ゎ(reduced size)” or “ヮ(reduced size)” for a name, “ワ(half-pitch, regular size)” is displayed in the reading field.

●

The file size of a still image that you can store is VGA (640 x 480) or less and an image of up to 100 Kbytes in JPEG format or GIF format.

●

If you store a still image larger than 128 x 96 dots, it is displayed shrunk on the detailed Phonebook display.

●

If you store a still image larger than 176 x 144 dots, it is displayed shrunk on the Call Receiving display.

●

If you store a Chara-den image larger than 128 x 96 dots, it is displayed shrunk on the detailed Phonebook display.

●

If 700 phone numbers are already stored, “ <Not stored>” is not displayed.

●

If 700 mail addresses are already stored, “ <Not stored>” is not displayed.

Information

Phonebook

You can store Phonebook entries in the UIM.

Add to phonebook UIM

The display for entering the name appears. Go to step 2 and enter the name.

●

You can bring up the display for selecting a storage location also by pressing ( ) from the Phonebook List.

●

See page 36 for the UIM.

Storing Phonebook Entries in UIM

Do the following operations.

Item

(Name)

(Reading)

(Group)

(Phone number)

(Mail address)

Operations

You can enter the name of the person or company in kanji, hiragana, katakana, letters of the alphabet, or numerals. When you are finished entering the name, enter reading in succession.

Enter a name

●

You can enter up to 10 full-pitch characters or 21 half-pitch alphanumeric characters. (Half-pitch katakana characters cannot be entered.)

●

See page 510 for how to enter characters.

You can enter the reading in full-pitch katakana, half-pitch alphanumeric characters.

Enter a reading

●

You can enter up to 12 full-pitch characters or 25 half-pitch alphanumeric characters. (Half-pitch katakana characters cannot be entered.)

●

See page 510 for how to enter characters.

●

If the displayed reading is acceptable, you do not need to edit it. However, depending on the characters entered for names or entering method, you need to enter/edit the reading.

11 groups from “Group 00” through “Group 10” are available. It is handy if you store the group names in advance. (See page 100)

Select a group

●

When the storage is completed with no group selected, the Phonebook entry is automatically stored in “Group 00”.

You can store one phone number per Phonebook entry.

Enter a phone number

●

Enter from the area codes for phone numbers.

●

You can enter up to 20 digits for blue UIMs and up to 26 digits for green UIMs.

●

If you insert “:” in the middle of a phone number, you cannot make a call. However, the phone number is retained in Redial or Dialled Call Record.

●

You can store the phone number which includes “#” such as that for information service as well.

You can store one mail address per Phonebook entry.

Enter a mail address

●

The mail address can consist of up to 50 half-pitch alphabets, numerals or symbol characters.

●

See page 510 for how to enter characters.

●

Store the mail address correctly including the domain (part after @). When the mail address is “phone number@docomo.ne.jp”, store the phone number only.

Docomo FOMA P901iS, FOMA P701iD User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Before using your FOMA Phone

How to Read This Manual

Contents

Contents/Precautions

Features of FOMA P901iS

Making Full Use of FOMA P901iS!

Safety Precautions

Notes on Handling

Intellectual Property Rights

Accessories and Main Options

Confirming before Use

Phone Parts and Functions

Display

Displaying Description of Icons

Navigation Displays

Private Window

About Dot-area

Method for Selecting Menu

Displaying Shortcut Menu

When You do not Remember Key Operation

Using the UIM (FOMA Card)

Attach/Remove Batteries

Charging the FOMA Phone

Confirming Battery Level

Opening the FOMA Phone by Using a Button

Turning Power On/Off

Switching to English

Executing Initial Settings

Notifying the Other Party of Your Phone Number

Setting Date and Time

Confirming Your Own Number

Making Calls/Receiving Calls

Making a Call

Making an International Call Easily

International Calls

Redialing Phone Numbers You have Dialed

Switching from a Voice Call to Video-phone Call

Sending Touch-tone Signals Quickly

Storing Prefix Numbers

Selecting Alarm for Reconnecting

Making a Call with Specified Subaddress

Switching to Hands-free

Using Hands-free Compatible Devices

Reducing Surrounding Noise to Make Voice Clear

Receiving a Call

Setting Response of Key Operation for Answering Incoming Calls

Setting Response for Opening FOMA Phone during Ringing

Setting Response for Closing FOMA Phone during a Call

Using Received Call Record

Adjusting Earpiece Volume

Adjusting Ring Volume

Putting an Incoming Call on Hold

Putting a Call on Hold during a Call

Setting Hold Tone

Using Driving Mode

If You could not Answer an Incoming Call

Recording Messages when You cannot Answer the Call

Playing/Erasing Record Messages/Voice Memo

Recording Messages when You cannot Answer the Call while Ringing

Making/Receiving Video-phone Calls

About Video-phone

Making a Video-phone Call

Receiving a Video-phone Call

Switching from a Video-phone Call to Voice Call

Using Chara-den

Useful Functions for Video-phone Calls

Setting Image Quality for Video-phone Calls

Turning Camera On/Off Automatically when Making a Video-phone Call

Changing Image Displays for Video-phone Calls

Redialing as a Voice Call when a Video-phone Call cannot be Connected

Checking Home from Where You are

Setting for switching between a Voice Call and a Video-phone Call

Setting Display for Video-phone Calls

Phonebook

Phonebooks Available for FOMA Phone

Storing Phonebook Entries in FOMA Phone
