DoCoMo FOMA N706i User guide

Easy Search/Contents/Precautions

Before Using the Handset

Voice/Videophone Calls

Phonebook

Sound/Screen/Light Settings

Security Settings

Camera

FOMA® N706i

ISSUE DATE:

NAME:

PHONE NUMBER:

MAIL ADDRESS:

INSTRUCTION MANUAL

‘08.7

i-mode/i-motion/i-Channel

Mail

i-αppli

Osaifu-Keitai/ToruCa

1Seg

Full Browser

Data Display/Edit/Management

Music&Video Channel/

Music Playback

Convenient Functions

Character Entry

Network Services

PC Connection

Overseas Use

Appendix/External Devices/

Troubleshooting

Index/Quick Manual

DOCOMO

W-CDMA and GSM/GPRS Systems

Thank you for purchasing the “FOMA N706i”.
Please read this manual and separate manuals supplied for other optional equipments before
and during use to use the FOMA N706i correctly. If you have further questions regarding
manuals, contact the inquiries number provided on the back of this manual.
The FOMA N706i is your capable partner. Handle the FOMA N706i with care and we hope you
use the FOMA N706i as long as possible.

Before using your FOMA terminal

● The FOMA network operates using radio waves. In a place where the reception is very poor, such as in a

tunnel, in a building and under the ground, or in an out-of-service area, you cannot make a phone call. You
may also have difficulty making a phone call from the upper floors of tall buildings, even if there is no
obvious physical obstruction. And even if the reception is good with 3 antenna bars indicated and you do not
move during the call, you may still find that your call is cut off.

● When you use your FOMA terminal in public places, particularly where it is crowded or quiet, take care not

to disturb the people around you.

● Since the FOMA terminal uses radio waves to communicate, there is always a risk that your call is

wiretapped by the third party.
However, the W-CDMA and GSM/GPRS systems automatically support the tapping prevention for all calls.
Even if a third party succeeds in intercepting your call, only incomprehensible noise will be heard.

● The FOMA terminal communicates via radio waves by converting voices into digital signals. If you move into

an area where the reception is poor, the digital signals may not be accurately decoded and what you hear
may differ slightly from what it actually is.

● The user hereby agrees that the user shall be solely responsible for the result of the use of SSL/TLS.

Neither DOCOMO nor the certifier as listed herein makes any representation or warranty as for security in
the use of SSL/TLS. In the event that the user shall sustain damage or loss due to the use of SSL/TLS,
neither DOCOMO nor the certifier shall be responsible for any damage or loss.
Certifier: VeriSign Japan K.K., Cybertrust Co., Ltd., GlobalSign.K.K, RSA Security Inc. and SECOM Trust
Systems Co., Ltd.

● This FOMA terminal is available in FOMA Plus-Area and FOMA High-speed area.

● The FOMA terminal can be used only via the FOMA network provided by DOCOMO and DOCOMO’s

roaming area.

● It is your responsibility to keep a separate record of all data (such as phonebook, schedule, memo, record

message, voice memo or VP msg.) stored on your FOMA terminal. Under no circumstances shall NTT
DOCOMO be liable for any loss or damage to the data stored on your FOMA terminal, caused by
malfunction, repair, model change, etc.

● It is recommended to back up the important data to the microSD memory card. If you own a PC, you can

also transfer and save the data such as the phonebook, mail or schedule to your PC by using DOCOMO
keitai datalink.

Before using this manual

This FOMA terminal supports Kisekae Tool (P.106). When you change the design of the menu display using
Kisekae Tool, the menu structure may change in accordance with frequency of using functions. Also, you
cannot access some functions entering the menu number assigned to the functions.
In this case, it is not possible to operate it according to this manual, so be sure to switch the functions to the
default menu (P.34) or reset the menu operation log (P.98).

You can download the latest information about this manual from the DOCOMO website.

・“User’s Manual Download”

http://www.nttdocomo.co.jp/english/support/manual/index.html

* The URL and the contents may change without prior notification.

How to Refer to This Manual

In this manual, following methods are available to find the descriptions of functions and
services.

P.426

Index

You can find keywords and functions displayed on the
display of the FOMA terminal.

Easy Search

You can find often-used functions and convenient functions
in simple terms.

Index on the front cover

You can find the table of contents for each chapter by
using the Index on the front cover.

Contents

You can find descriptions using the Table of Contents which is divided by the function.

Main Functions

You can find main functions of the FOMA N706i, such as new functions and convenient
functions.

Menu Function List

You can find menu displayed on the display of the FOMA N706i and default settings.

Quick Manual

You can find brief descriptions of the basic functions. You can also remove the pages to

take along.

Take Quick Manual (For Overseas Use) when using your FOMA terminal abroad.









P. 4





Cover








P. 6






P. 8





P.370






P.440





See the next
page for details.

z In this manual for FOMA N706i, the “FOMA N706i” is described as the “FOMA terminal”.
z This manual describes functions that use the microSD memory card. To use these functions, the

microSD memory card is required. microSD Memory Card →P.267

z It is prohibited to reprint a part or all of the contents of this manual without permission.
z The contents of this manual may change without prior notification.
z The color patterns for the main menu and the screen are described in the default setting for the terminal

of which body color is white.

1

How to Refer to This Manual (continued)

Following example shows how to look up the alarm function using “Index”, “Easy Search” and
“Index on the front cover”.

Index

P.426

You can find keywords and functions displayed on the display of the FOMA terminal.

A

A mode (2in1) . . . . . . . . . . . . . . . . . . .349

AC adapter . . . . . . . . . . . . . . . . . . . . . . .44

Accessories/Options . . . . . . . . . . . . .394

A-Continuous shooting . . . . . . . . . . .134

Add bookmark . . . . . . . . . . . . . . . . . . .152

Adding a new word (Own dictionary)
Additional service (network services)
Address→Mail address
Adjusting the volume

Earpiece volume. . . . . . . . . . . . . . . .65

. . .337

Easy Search

Alarm tone (pre-installed) . . . . . . . . . 88

Alarm tone (stop). . . . . . . . . . . . . . . . 317

Alarm (Timer) . . . . . . . . . . . . . . . . . . . 311

Animation (create). . . . . . . . . . . . . . . 252

Animation (playback) . . . . . . . . . . . . 253

Anniversary (check) . . . . . . . . . . . . . 314

Answer hold. . . . . . . . . . . . . . . . . . . . . . 65

Answer setting. . . . . . . . . . . . . . . . . . . .64

. . .353

Any key answer. . . . . . . . . . . . . . . . . . .64

Area Mail setting . . . . . . . . . . . . . . . . 197

Area Mail (Storage capacity) . . . . . 418

AT Commands . . . . . . . . . . . . . . . . . . 358

P. 4

Auto redial as voice . . . . . . . . . . . . . . 71

Auto reset total cost . . . . . . . . . . . . . 322

Auto save set (Movie) . . . . . . . . . . . 137

Auto save set (Still image) . . . . . . . 133

Auto timer . . . . . . . . . . . . . . . . . . . . . . 138

Auto-display setting . . . . . . . . . . . . . 160

Automatic Manner mode. . . . . . . . . . 92

Automatic replay (i-motion) . . . . . . 165

Automatic sorting settings (Mail) . 189

Auto-start set (i-αppli) . . . . . . . . . . . 217

Auto-start time (i-αppli) . . . . . . . . . . 217

Auto-update (Software Update)

. . . . 410

You can find often-used functions and convenient functions in simple terms.

Use microSD memory card

・

Exchange information with PC or other FOMA terminal

・

Listen to music

・
・
・
・
・
・

P.3 1 1

Use alarm

Use as calculator

Use FOMA terminal overseas

Update for the latest software

Update for the latest security settings

Index on the front cover

P.267

P.291

Music&Video Channel/Music Playback

Alarm

Calculator

P.323

P.408

P.361

Software Update

P.414

Cover

P.2 7 8

P.283

Scanning function

Infrared data exchange/iC communication

TM

communication

OBEX

Refer to “Cover”, “Chapter title page” and “Description pages” sequentially
to find the descriptions of the function you want to set. You can find the
detailed table of contents on the chapter title page.

Convenient Functions

Multi Access.......................................................................................................... 308

Multitask................................................................................................................... 309

Displaying the Data in the Time Series................................................... 310

Changing the Short Cut Key Function of Channel Key.............................. 311

Sorting the Main Menu ........................ ........................................................................... 311

Using the Alarm Function .............................................. ...................................... 311

* The contents above differ from the actual ones in this manual.

2

Life history viewer

Multi access

Multitask

ch-key setting

Alarm

This manual uses illustrations and marks to explain how to operate the function so that you
can use the FOMA terminal correctly.

Describes the
function name.

Sounds the alarm tone continuously for the
specified time.

Auto power ON……Specifies whether the

FOMA terminal is automatically turned on or not
when the time for an alarm is reached.

Set the respective items o (Finish)

4

N

When the FOMA terminal is automatically turned on to
notify you of an alarm, if you set a melody, i-motion or
music downloaded from sites as alarm tone, the
“Clock Alarm Tone” is played.
Before entering an area such as an aircraft or hospital
where there is electronic equipment that uses
extremely precise control systems or very low signal
levels and the use of mobile phones is prohibited, set
the “Auto power ON” setting to “OFF” and then turn
the FOMA terminal off.

Alarm list screen (P.311)/Alarm
detail screen (P.311)

Edit……Edits the alarm.

Display detail*……Displays the alarm contents.

Finish(Set this)……Activates the alarm.

Release this……Disables one alarm.

Release all……Disables all set alarms.

* : Available only with the Alarm list screen.

Continued on next page

Describes the
necessary settings,
notes or useful
information about
the function.

The function menu
title is described
with the icon of the
function menu and
the screen name
on which the
function menu is
displayed.

You can search
the chapters
using the index.

snoitcnuFtneinevnoC

Page number

311

Indicates that the
descriptions go on
to the next page.

Describes the
operation on
each step.

Describes the
screen at the time
of the operation.
Compare it with
the screen when
you operate.

Describes the items
displayed on the
screen (some items
cannot be operated
depending on the
operation).

Describes the
explanation of
each item.

Using the Alarm Function

You can store up to 10 alarms.

i “lifekit” “Alarm”

1

The “Alarm list screen”
appears.

■ To switch ON/OFF with

the last settings

Highlight the setting item
p (ON/OFF)

“ON/OFF” switches each
time you press p.

■ To check the previous

settings

Select the setting item
The “Alarm detail screen”
appears.

Highlight the item to set o (Edit)

2

Select any item:

3

Edit title……

enter up to 6 double-byte or 12 single-byte characters.

Time setting……Enters the time at which the

alarm will sound.

Repeat……Selects the alarm repetitions from

“1 time/Daily ( )/Select day ( )”.

Alarm tone……Selects the alarm tone from

clock alarm tone or folders of melody, i-motion,
music, etc.

Volu me……Sets the alarm tone volume with

c.

Snooze setting……Specifies whether a snooze

(repeating) alarm is set or not.

ON……Enter the number of times for ringing

(01 to 10 times) and the ringing interval (01 to
10 minutes).
The alarm tone (about 1 minute) rings
repeatedly for the set number of times in the
set interval.

OFF……Enter the ringing time (01 to 10

minutes).

<Alarm>

Alarm list

Function menu P.311

Alarm detail

Function menu P.3 1 1

Enters the title of the alarm. You can

* The contents above differ from the actual ones in this manual.

z The screens shown as examples in this manual are displayed when “English” is set for “バイリンガル” (Select

language). Set “English” for “バイリンガル ” (Select language) in advance.→ P. 4 6

z In this manual, “Stand-by display” is set to “OFF”, back color is set to white and font color is set to black in

order to make the screens clear. Also, the parts of the operating instruction screens that need an explanation
are closed up.

z In this manual, descriptions are basically based on the default settings, and screens displayed on the FOMA

terminal may differ from the descriptions in this manual.

z The screens inserted in this manual are only the images, which looks different from the actual screens.
z In this manual, “Osaifu-Keitai i-αppli compatible with IC card function” is described as “Osaifu-Keitai i-αppli”.
z In the operation explanation in this manual, simple key illustrations are used to indicate the operation to press

the key.

3

Easy Search

Easy Search

Find out a function with easy words from the Easy Search index below.

Easy Search/Contents/Precautions

Useful functions for talking

P.4 8

・Do/do not notify your party of your caller ID
・Switch voice/videophone call during call

P.6 5

・Adjust the volume during a call
・Hold the current call

P. 65

Holding

Volume

P. 53

Caller ID Notification

When you cannot answer incoming call

On hold

・Hold the ringing call without answering

P.6 5

・Notify that you cannot answer the call

Public mode (Driving mode) Public mode (Power OFF)

P.6 6 P. 66

Have your party record voice/videophone message

・

P. 68

Record message

Change melody or illumination

Ring volume

P.9 2

P.8 8

P.9 1

P.6 5

Select ring tone

Keypad sound

Manner mode

P.8 2

P.9 9

Ring tone/Image

P. 90

Vibrator

P. 10 0

・Adjust the ring volume
・Set ring tone to specify party
・Change ring tone

Set vibration to notify incoming call or mail

・
・Mute keypad tone
・Set silent mode

Change the display or color of My Signal/incoming call lamp

・

IlluminationMy Signal settings

Change/understand display

P.3 4

P.2 7

Simple Menu

・Mark (icon) on the display
・Switch menu display
・Change standby screen (wallpaper)
・Display calendar on the standby screen

P.1 0 1

・Change font size

Font

4

View display

P.9 5

Display setting

P.9 6

Master mail

P.172

・Send Deco-mail
・Send image or melody
・Sort and save mail automatically

Deco-mail

P.175

Attach file

P.189

Auto-sort

Master camera

Change the size of image to shoot

・

Display the shot

・

Save image on the microSD memory card

・

P.247

My picture

P.132

P.271

Use your phone without worries

Lock the FOMA terminal from remote location when the FOMA terminal is lost

・

Secret mode/Secret data only mode

Prevent others from viewing the phonebook

・

Reject unidentified calls

・

Reject calls from callers who are not stored in phonebook

・

Save data such as phonebook in case of loss of data

・

*1: Omakase Lock is a pay service.
*2: Data Security Service is a pay service you need to apply for. (i-mode subscription is necessary to apply for this service.)

P.124

Call setting w/o ID

P.113

P.125

P.125

Data Security Service

Master 1Seg

Activate 1Seg

・Watch 1Seg

・Record 1Seg

・Book 1Seg programs and recordings

・Change image/sound settings

P.232

P.235

1Seg recording

P.238

Booking program list/Timer recording list

P.236

User settings

P.111

Reject unknown

Omakase Lock

*2

Easy Search/Contents/Precautions

*1

Miscellaneous

Bar code reader

Read QR code or bar code

・

Use microSD memory card

・

Exchange information with PC or other FOMA terminal

・

P.311

P.291

Alarm

P. 32 3

Listen to music

・

Use alarm

・

Use as calculator

・

Use FOMA terminal overseas

・

Update for the latest software

・

Update for the latest security settings

・

For mode information about other operation guides, see “How to Refer to This Manual”. →P. 1
Also, “Quick Manual” instructs you how to operate the functions used often. →P.440

P. 13 9

P.267

Music&Video Channel/Music Playback

Calculator

P.361

Software Update

P.408

P.414

P. 27 8

P.283

Scanning function

Infrared data exchange/iC communication

TM

communication

OBEX

5

Easy Search/Contents/Precautions

Contents

How to Refer to This Manual ..................................................1

Easy Search ...........................................................................4

Contents .................................................................................6

Main Functions of the FOMA N706i........................................8

Mastering the FOMA N706i! .................................................10

Precautions...........................................................................12

Handling with Care ...............................................................18

Intellectual Property Right.....................................................20

Main Components and Optional Equipment .........................22

Before Using the
Handset

P.23

Voice/Videophone
Calls

P.49

Phonebook

P.75

Sound/Screen/Light
Settings

P.87

Security Settings

P.109

Camera

P.127

i-mode/i-motion/
i-Channel

P.145

Mail

P.169

i-αppli

P.205

aNames and functions aHow to view the display/My Signal
aSelecting the menu aBasic operations aFOMA card (UIM) 
aAttaching/removing the battery pack aCharging 
aTurning on the FOMA terminal aInitial setting aSet time 
aCaller ID notification, etc.

aMaking a voice/videophone call 
aSwitching between voice/videophone calls aWORLD CALL 
aHands-free aRedial/Received calls aChaku-moji 
aReceiving a voice/videophone call
aAnswer hold aPublic mode (Driving mode/Power off) 
aRecord message aVideophone settings, etc.

aAdd to phonebook aGroup setting aSearch phonebook 
aEditing/deleting phonebook entries 
aRing tone/Image a Choku-Den 
aData Security Service, etc.

aRing tone aVibrator aManner mode aDisplay setting
aPrivacy angle aBacklight aDisplay design aMenu display set
aMy Signal settings aIllumination aKisekae Tool, etc.

aSecurity code aPIN code aDial lock aOmakase Lock
aSecret mode aSecret folder aOriginal lock aKeypad lock 
aIC card authentication aSide key guard aSelf mode, etc.

aPhoto mode aMovie mode aSettings for shooting 
aBar code reader aText reader, etc.

aWhat is i-mode? aViewing sites 
aHow to view sites and operations aQuick Search
ai-mode password aInternet access aBookmark 
aPhone To/AV Phone To・Mail To・Web To・Media To
aDownloading i-motion aUsing i-Channel, etc.

aWhat is i-mode mail? aComposing/sending i-mode mail
aDeco-mail/Auto Deco-mail aAttaching files 
aReceiving mails aCheck new messages 
aReplying/Forwarding mails aSaving attached files 
aUsing mail boxes aMail Setting aMessage service 
aWhat is Early Warning “Area Mail”? aChat mail aSMS, etc.

aWhat is an i-αppli? aDownloading an i-αppli
aLaunching an i-αppli aPre-installed softwares
ai-αppli standby screen aUpgrading an i-αppli, etc.

aVolume aRing volume 

6

Osaifu-Keitai/
ToruCa

P.221

1Seg

P.229

Full Browser

P.239

Data Display/Edit/
Management

P.245

Music&Video
Channel/Music
Playback

P.291

Convenient
Functions

P.307

Character Entry

P.329

Network Services

P.341

PC Connection

P.355

Overseas Use

P.361

Appendix/External
Devices/
Troubleshooting

P.369

Index/Quick Manual

P.425

aWhat is Osaifu-Keitai? aWhat is iC transfer service?
aUsing Osaifu-Keitai aWhat is ToruCa? 
aAcquiring ToruCa aViewing ToruCa aIC card lock setting, etc.

aWhat is 1Seg? aSetting Channels aWatching 1Seg Programs 
aData Broadcast aRecording 1Seg Programs 
aBooking programs/Timer recordings a1Seg Settings, etc.

aDisplaying website designed for PC
aOperations on the Full Browser screen
aFull Browser settings, etc.

aData box aStill image aMovie/i-motion aPlaying videos 
aChara-den aMelody aMy Signal aKisekae Tool 
amicroSD memory card aMovable contents aUIM operation 
aInfrared data exchange/iC communication aViewing the PDF data
aDisplay documents aDisplay e-books and e-comics, etc.

aWhat is Music&Video Channel? 
aDownloading Chaku-Uta-Full
aUsing playlist aUsing the Music Player, etc.

* “Chaku-Uta-Full” is a registered trademark of Sony Music

Entertainment (Japan) Inc.

aMulti access aMultitask aLife history viewer 
aAlarm aSchedule aTo Do list aAlarm setting aMy profile 
aChecking Call data aCalculator aText memo aDictionary 
aEarphone/microphone with switch aReset settings 
aInitialize, etc.

aCharacter entry a5-touch input aFixed common phrases
aCopying/cutting/pasting text aOwn dictionary
aClear learning record aDownload dictionary a2-touch input
aT9 input, etc.

aVoice Mail service aCall Waiting aCall Forwarding service
aNuisance Call Blocking aCaller ID Request service
aDual Network Service a2in1, etc.

aData communication, etc.

* The details are described in “Manual for PC connection setting”

(PDF format) in the provided CD-ROM.

aWORLD WING aAvailable overseas service
aChecking before using overseas aMaking/Receiving a call abroad
aNW search mode, etc.

aMenu function list aCharacter assignment to dial keys 
aSymbols/pictographs/face marks/fixed common phrases list 
aMulti access/Multitask combination patterns 
aOptions/Accessories aTroubleshooting a
aSoftware Update aSpecifications, etc.

aIndex aQuick Manual
aQuick Manual (For Overseas Use)

®

 aPlaying music 

Error message

Easy Search/Contents/Precautions

7

Main Functions of the FOMA N706i

FOMA is the name of DOCOMO’s service based on the W-CDMA system approved as one of
the global standards for third-generation mobile telecommunication systems (IMT-2000).

Easy Search/Contents/Precautions

i-mode

i-mode is an online service that you can use to send e-mail as well as using the useful information from the i-mode
menu site (program) and i-mode compatible website.

Features of N706i

■

i-mode mail/Deco-mail/Decorate PI

In addition to the message body, you can attach photos
and movies. As the FOMA terminal is compatible with
Deco-mail/Decorate PI, you can change the character
color, size, or background color of the message body or
insert images or moving pictographs.

■ International roaming →P. 36 2

The FOMA terminal, phone number and mail address you
use in Japan are also available overseas (only in GSM/3G
areas). You can use voice call, videophone call, i-mode,
i-mode mail, SMS and network services. The FOMA
terminal comes preinstalled with “日英版しゃべって翻訳
for N”, which translates into English what you said in
Japanese into the phone and vice versa.

■ High-speed communication →P. 35 6

The data is received at the maximum speed of 3.6 Mbps
and sent at the maximum speed of 384 kbps in the FOMA
high speed communication area.
* The maximum speeds are maximum speeds as a

technical standard, and the actual communication
speed will vary depending on network congestion or
communication environment. The speed for receiving
and sending data becomes 384 kbps if data is being
transferred outside the FOMA high speed
communication area or if accessing access points such
as mopera or other non-high speed points.

■ Kisekae Tool →P. 10 6

You can instantly replace your favorite standby screen or
menu screen with them. With N706i, you can replace
menu options depending on the frequency of use, and
also customize menu screens to your preferences.

→PP.170, 172, 171

Wide variety of functions

■ 3 inch Full Wide QVGA LCD

With wide full LCD (240 dots × 427 dots), you can enjoy
1Seg images and images shot using the FOMA terminal’s
camera.

■ Camera →P. 12 7

The CMOS of 200 million effective pixels enables you to
shoot large images of 2M bytes (1,200 dots × 1,600 dots).

■ My Signal →P.2 9

Displays time and informs you if the condition of the
FOMA terminal changes by displaying various animations.

■ Mega i-αppli/Chokkan Game →P. 20 5

i-αppli enables you to enjoy games, or automatically
update information such as stock prices or weather
reports. It also allows you to enjoy Chokkan Games which
sense motion and orientation of the terminal.

■ Chaku-Uta-Full®/Uta-hodai/Music&Video

Channel*/Video clip →PP.296, 291, 164

*: This is a pay service you need to apply for.
You can download full songs (Chaku-Uta-Full
another service (Uta-hodai) download as many songs as
you want for a fixed monthly charge. A Music&Video
Channel is also available for enjoying music programs
automatically downloaded at night after advanced
scheduling. The FOMA terminal also supports i-motion
videos of up to 10M bytes so you can enjoy full length
music videos or music clips.

■ Osaifu-Keitai/ToruCa →PP.215, 221

By downloading an Osaifu-Keitai i-αppli, you can transmit
electric money from the site into the IC card in your FOMA
terminal or check the account balance or transaction
history. The i-αppli of the DOCOMO credit service
“DCMX” is pre-installed in your FOMA terminal. “iC
transfer service” is also suppor ted so that you can easily
move your IC card data to a new terminal when replacing
your FOMA terminal.
ToruCa can be acquired via a reader/writer unit or
websites and easily exchanged via mail or Infrared data
exchange.

■ Music Player → P. 3 0 2

By converting tracks in your music CD to WMA (Windows
Media Audio) data and SD-Audio data in your PC and
save to the microSD memory card, you can play the tracks
with your FOMA terminal.

■ IC Card Authentication →P. 12 1

Instead of entering a security code, putting your FOMA
terminal close to a contactless IC card supporting FeliCa
performs user authentication to release Dial lock or
Keyp ad lock.

®

) or, using

8

■ Original lock/Keypad lock →PP.116, 120

• You can lock the functions which use your personal
information such as phonebook and mails, or restrict
making/receiving calls or sending mails (Original lock).

• You can lock the key operations automatically when the
FOMA terminal is folded or no operation is performed
for a certain period of time (Keypad lock).

■ PDF Viewer/ Document Viewer

• With the PDF viewer, you can easily view useful
information such as a map, catalogue or time table on
your i-mode terminal easily.

• The FOMA terminal has a preinstalled document
viewer that lets you see Microsoft® Word, Microsoft
Excel, and Microsoft® PowerPoint document files.

■ Full Browser → P. 23 9

With Full Browser, you can view websites for PC which
provide you with more information.

→PP.284, 286

®

■ Multi window/One-touch multi window

• You can connect sites up to five by the operation at a
time.

• You can inspect it by switching the connected site page
in the tab.

■ Choku-Den →P. 84

By storing frequently used phonebook to Choku-Den, you
can make a call or send a mail quickly.
You can store up to 5 Choku-Den. When mail addresses
are stored, you can compose i-mode mail or chat mail to
all the members easily.

■ Privacy angle →P. 97

You can set the screen difficult to be seen from an angle.
You can use the FOMA terminal without worrying about
the others.

→PP.150, 154

Security

■ Omakase Lock →P.1 1 1

You can lock the FOMA terminal when you lost it and can
release the lock at your request. Refer to the back of this
manual for the inquiries numbers.
* Omakase Lock is a pay service. If you subscribe to the

service at the same time with the subscription of
suspending the service or while the service is
suspended, no charge applies.

* Omakase Lock is the service to lock the FOMA terminal by

the request from the subscriber. Note that the FOMA
terminal is locked if the subscriber requests to lock the
FOMA terminal even if the subscriber and the user of the
FOMA terminal are different.

Wide variety of network services (→P.341)

• Voice Mail (charged)

• Call Waiting (charged)

• Call Forwarding (free)

*: You need to apply for the service.

*

*

*

• Nuisance Call Blocking (free)

• Caller ID Request (free)

• Dual Network (charged)

■ Auto Deco-mail →P.1 7 3

The FOMA terminal detects the emotion from the mail text
and automatically converts the mail to Deco-mail with
most suitable decorations such as pictographs.

■ Emotion-expressing mail →P.1 7 8

An icon pops up and displays the emotion matching the
contents of the received mail.

■ iC Communication →P.2 8 2

You can exchange data by putting FeliCa marks (e) of
sending and receiving FOMA terminals close to each
other.

■ Infrared data exchange/Infrared remote

control →PP.280, 284

You can exchange data with other FOMA terminals using
infrared communication. You can also use your FOMA
terminal as a remote control.

■ Multi access/Multitask →PP.308, 309

You can use the voice call, packet communication and
SMS at the same time (Multi access). Also, You can run
and use the multiple functions by switching them
(Multitask).

■ Quick Search →P.1 5 1

The FOMA terminal can search information you want to
know while viewing i-mode sites, Mail and schedule, etc
by an easy operation.

■ Comic/book reader →P.2 8 9

You can access e-books and e-comics, so you can simply
read on your FOMA terminal, instead of carrying
numerous books.

■ Data Security Service →P.1 2 5

The Data Security Service enables you to store the
phonebook entries, images or mails on the FOMA
terminal to the Data Security Center and retrieve the data
to the FOMA terminal when you lose the FOMA terminal,
etc. Besides, you can edit or manage the data stored at
the Data Security Center using a PC and save the edited
data on the FOMA terminal.
* For notes on using the “Data Security Service” and

details on how to use the service, refer to “Mobile
Phone User’s Guide [i-mode] FOMA version” and refer
to the back of this manual for the inquiries numbers.

* This is a pay service you need to apply for.

• English Guidance (free)

*

• Multi Number (charged)

• 2in1 (charged)

*

*

Easy Search/Contents/Precautions

9

Mastering the FOMA N706i!

Send and receive real-time movie while talking

Easy Search/Contents/Precautions

Videophone →P. 50

You can talk to the other party while seeing each other's image.
Your FOMA terminal is set to emit other party's voice through the
speaker by default so that you can start talking immediately when
making or answering a call. Furthermore, you can change the call
mode from voice to videophone without having to end the call.

* As FOMA N706i is not equipped with the front camera, during a

videophone call, you can send only the substitute image

(Chara-den) or image from the rear camera to the other party.

Set the screen design all at once

Kisekae Tool/Direct Menu→ P.106

The “Direct menu” feature designed for easy access to frequently used functions/services is
pre-installed on your FOMA terminal. The menu items are categorized in four parts and assigned to
each direction (up/down/left/right). Also, the “LAST10” feature to automatically display the ten menu
items last used is assigned to the center. These five categories linked to Multi-function keys provide
you easy-to-remember and simple menu operation.

: SERVICES (Mail/i-mode/i-αppli/Full Browser/Osaifu-Keitai/1Seg, etc.)

h

: TOOLS (Alarm/Calculator/Text memo/Schedule/Receive Ir data, etc.)

j

: SETTINGS (Settings/Network services/My Profile)

g

: DATABOX (My picture, etc.)

f

d

: LAST10 (displays the ten menu items last used automatically)

* By default, pre-registered functions are assigned to each key.

The ticker appears on the standby screen when the latest information is distributed

i-Channel→P. 16 6

You can receive news or
weather report as graphical
information.
You can also select favorite
channels on the channel list
screen to receive rich, detailed
information which was created
by Flash (more detail→P.150).

* This is a pay ser vice you

need to apply for.

Before subscription

あすの天気：東京  最高

* The screens above are image.
The actual screens will look different.

２８

After subscription

Connect

Image at the other

Image at the other
side

side

Image at your sideImage at your side

Menu screen

“Napster®” compatible

Music Player→ P.302

“Napster®” service provides you of copying songs downloaded from
sites or on music CDs to the microSD memory card using a PC and
play music on the FOMA terminal. Since “Chaku-Uta-Full
supported, you can download the entire track from an online music
distribution site to play it. Other functions include BGM playback,
which allows you to listen to music while you use other functions,
display of album cover images and lyric sheets, and creation of the
playlist on the FOMA terminal.You can also play the i-motion and use
Music&Video Channel that downloads the specified program
automatically during the night.

10

Music

®

” is

CD

microSD

memory card

Music distribution

website

FOMA terminal

Connect the Flat-plug Stereo
Earphone Set (optional).
You can use the FOMA
terminal as a portable
audio player.

涼やかな風鈴の音色が響いています

。

Remind the precious day by Illumination

Birthday/Anniversary Remind →PP.77, 314, 319

The FOMA terminal reminds the birthday of your friends recorded
in Phonebook or the precious anniversary added to Schedule
using Desktop icon. Reminder can be selected from several
options of 1week before, 3days before, 1day before or on the day,
and you do not miss the important event. Moreover, adding your
birthday to My Profile congratulates Happy Birthday with image
and melody.

Use 2 phone numbers and 2 e-mail addresses for your FOMA terminal

2in1→P.349

You can separately use 2 phone numbers and
2 mail addresses on your FOMA terminal as if
you have 2 terminals. You can manage the
data in your FOMA terminal, such as
Phonebook, mail boxes, Dialed calls or
standby screen, separately in “A mode” and “B
mode” , or all together of A/B mode in “Dual
mode” .

* Subscription is required (Charged).

A mode

Phone number : 090-AAAA-AAAA
Mail address : [e-mail]
Phonebook : For A mode

Make a call/send

a mail in A mode

A

mode

B mode

Phone number : 090-BBBB-BBBB
Mail address : [e-mail]
Phonebook : For B mode

Dual

mode

Make a call/send

a mail in B mode

B

mode

Easy Search/Contents/Precautions

Phonebook A
Mail box A
Dialed/received calls A
Voice mail A

・・・・・

Phonebook A/B
Mail box A/B
Dialed/received calls A/B
Voice mail A/B

・・・・・

Digital terrestrial broadcasting service

1Seg→ P.229

Enjoy watching 1Seg on your FOMA terminal.
1Seg is a digital terrestrial broadcasting service for mobile
handsets and provides you with subtitle and data broadcasting as well.
You can also record programs as you watch them, and booking
programs and timer recording are also available.

Notify the arrival of your phone call with an animation before answering

Chaku-moji→P. 58

When calling someone, you can show a message on the screen
of the other party's phone. The other party can see your
business or feeling from the message before answering the call.

Chaku-moji

Phonebook B
Mail box B
Dialed/received calls B
Voice mail B

・・・・・

ドキュメンタリー

１１：００−１１：３０

涼やかな風鈴の音色が響いています

涼やかな風鈴の音色が響いています
。

11

Precautions

(ALWAYS FOLLOW THESE DIRECTIONS)

■ To ensure that you use your FOMA terminal

Easy Search/Contents/Precautions

correctly, read the Precautions carefully
before use. Keep this manual after reading
for future reference.

■ The precautions must be observed at all

times since they contain the information
intended to prevent the bodily injuries or
the damage to the property.

■ The following symbols indicate the

different degrees of injuries and damage
that may occur if the information provided
is not observed and the FOMA terminal is
used incorrectly:

Indicates that the death or
serious bodily injury may result

DANGER

WARNING

CAUTION

■ The following symbols indicate the specific

directions:

Don’t

No disassembly

No wet hands

No liquids

Do

Unplug

directly and immediately from
the improper use.

Indicates that the death or
serious bodily injury may
result from the improper use.

Indicates that the bodily injury and/
or damage to the property may
result from the improper use.

Indicates that it is prohibited.

Indicates that it must not be
disassembled.

Indicates that you must not touch
it with your wet hand.

Indicates that it must not be used
near the water, which means that
you must not wet it.

Indicates that you must do it
following the instructions.

Indicates that you must unplug
the power code from the outlet.

■ Safety Precautions are explained in the

following categories:

1. Handling the FOMA terminal, Battery Pack,
Adapter (including the Charger) and FOMA

card (Common) ........................................... 12

2. Handling the FOMA terminal ..................... 13

3. Handling the Battery Pack ......................... 15

4. Handling the Adapter (including the

Charger)....................................................... 16

5. Handling the FOMA card (UIM) .................. 17

6. Handling Mobile Phones near Electronic

Medical Equipment ..................................... 17

1.

Handling the FOMA terminal, Battery
Pack, Adapter (including the Charger)
and FOMA card (Common)

DANGER

Do not use, keep or leave the devices
in locations subject to high
temperatures, such as near the fire or

Don’t

heater, in direct sunlight or inside a
car on a hot day.

This may cause the battery pack to leak,
overheat, explode or ignite, cause the
devices to malfunction or be deformed, or
suffer performance loss and a reduced
service life. Also, this may cause a part of
the case to become hot and burn you.

Do not disassemble or rebuild. Also,
do not solder the devices.

This may cause fire, injury, electric shock or

No disassembly

malfunction.
This also may cause the battery pack to
leak, overheat, explode or ignite.

Do not wet the devices.

Exposing the FOMA terminal and other
devices to liquids such as water or pet urine

No liquids

may cause overheating, electric shock, fire,
malfunction, injury, etc. Be careful where
and how you use the devices.

Use the battery pack and adapter
(including the charger) specified by
NTT DOCOMO for the FOMA terminal.

Do

Using the devices other than those specified by
NTT DOCOMO may cause the FOMA terminal,
battery pack and other devices to leak, overheat,
explode, ignite or malfunction.

Battery Pack N18
Desktop Holder N18
FOMA AC Adapter 01/02
FOMA DC Adapter 01/02
Data Communications Adapter N01
FOMA AC Adapter 01 for Global use
FOMA Dry Battery Adapter 01

12

FOMA USB Cable with Charge Function 01/02
FOMA Portable Charging Adapter 01

* For the information on other compatible

products, contact the NTT DOCOMO shop
or service counter.

WARNING

Do not place the FOMA terminal,
battery pack, adapters (including the
charger) or FOMA card in cooking

Don’t

appliances such as microwave ovens
or in a pressure cooker.

This may cause the battery pack to leak,
overheat, explode or ignite, cause the FOMA
terminal or adapter (including the charger) to
overheat, smoke or ignite, or damage the IC.

Do not shock or throw the FOMA
terminal.

This may cause the battery pack to leak,

Don’t

overheat, explode or ignite, or cause the
devices to malfunction or ignite.

Keep the conductive foreign materials
(metal, pencil lead, etc.) away from the
charge terminal or external connector.

Don’t

Do not insert those matters inside.

This may result in the short-circuit causing
the FOMA terminal to ignite or malfunction.

Turn off the FOMA terminal, when you
are near the flammable gas such as at
the gas station. Do not also charge. It

Do

may cause to ignite to the gas.

Turn off the FOMA terminal, when you use
Osaifu-keitai at the gas station (if IC card
lock is set, turn the FOMA Terminal off after
lock is released).

If you find extraordinary happenings,
such as an unusual odor, overheating,
discoloration or deformation during the

Do

use, charge or storage, make sure to:

1.

Unplug the power code from the
power outlet or the cigar lighter outlet.

2. Turn off the FOMA terminal.

3. Remove the battery pack from the
FOMA terminal.

Continuing to use or charge the FOMA
terminal may cause it to overheat, explode,
ignite or leak of battery.

CAUTION

Do not leave the FOMA terminal on a
slope or unstable surface.

This may fall the FOMA terminal and cause

Don’t

the injury or malfunction.

Keep the FOMA terminal away from
the humid, dusty or hot places.

This may cause malfunction.

Don’t

If your child uses the FOMA terminal,
instruct him/her how to use it. Make
sure that he/she always uses the

Do

FOMA terminal correctly as you
instruct.

Improper usage could result in the bodily
injury.

Keep the FOMA terminal out of young
children’s reach.

A young child may swallow it or suffer from

Do

the injury.

Pay a special attention when you use
the FOMA terminal connected to the
adapter (including the charger) for a

Do

long duration.

If you use i-αppli or videophone or watch
1Seg programs for a long time while
charging the FOMA terminal, the
temperature of the FOMA terminal, battery
pack or adapter (including charger) may rise.
If you touch the warm part of these devices
for a long period of time, it may cause
redness, itch, skin irritation, or burns
depending on your constitution or physical
condition.

2. Handling the FOMA terminal

WARNING

Do not direct the infrared data port
towards your or another person’s eyes.

This may cause the eye injury. Do not aim or

Don’t

direct the infrared data port towards another
infrared device as this may interfere with the
operation of the device.

Do not put the FOMA terminal on the
dashboard, etc. as a problem may
occur due to air bag inflation.

Don’t

The air bag inflation may cause the FOMA
terminal to hit you or another person, which
may lead to injury, malfunction, breakage, etc.

If you are wearing electronic medical
equipment, do not put the FOMA
terminal in your breast pocket or in

Don’t

the inside pocket.

Using the FOMA terminal in close proximity
to electronic medical equipment may cause
the equipment to malfunction.

Continued on next page

Easy Search/Contents/Precautions

13

Do not put fluids such as water or
objects such as pieces of metal or
flammable materials into the FOMA

Don’t

card inserting slots or microSD
memory card slots inside of the FOMA

Easy Search/Contents/Precautions

terminal.

Such actions could cause fire, electric shock
or malfunction.

Turn off the FOMA terminal in a place
where it is prohibited to use the
mobile phone, such as in an airplane

Do

or in a hospital.

This may affect the electric or medical
equipment. If the FOMA terminal is set with
the Auto power function, make sure to
disable the function before turning off the
FOMA terminal.
Follow the instructions provided by the medical
facility about using the mobile phone.

If you use the phone in an airplane,
which is prohibited, you may be
punished by law.

Make sure to hold the FOMA terminal
off your ear and keep enough distance
from it when you talk in the hands-free

Do

mode. When you also play games or
music with an earphone-microphone
connected to the FOMA terminal,
adjust the volume properly.

If the volume is too high, it may cause an
auditory disturbance.
Also, it may cause an accident if you have
difficulty in hearing the sound of your
surroundings.

If you have a weak heart, take
precautions when setting the Vibrator
or Ring volume.

Do

This may affect your heart.

If you hear thunder while using the
FOMA terminal outdoors, immediately
turn off the FOMA terminal and take

Do

shelter in a safe location.

There is a risk of being struck by the
lightning and suffering an electric shock.

Turn off the FOMA terminal near the
electric equipment using the high­precision control or weak signals.

Do

This may interfere with the operation of
sensitive electronic equipment.

* Take great care on the following electric

devices:

Hearing aids, implantable cardiac
pacemakers, implantable cardioverter-

14

defibrillators, and other electronic medical
equipment, fire alarms, automatic doors and
other equipment controlled by electronic
signals.
If you use an implantable cardiac
pacemaker, implantable cardioverter­defibrillator or other electronic medical
equipment, contact the respective
manufacturer or vendor to check whether the
operation of the equipment is affected by
radio waves.

If the display or camera lens is broken,
be careful of the broken glass and the
inside of exposed FOMA terminal.

Do

The surface of the display or camera lens is
covered by a plastic panel to minimize the
possibility of glass scattering. However,
touching the broken or exposed parts cause
the injury.

CAUTION

Do not swing the FOMA terminal by its
strap or other parts.

The FOMA terminal may strike you or others

Don’t

around you, resulting in body injury,
malfunction or damage to the FOMA
terminal or other property.

When you use the motion tracking, be
sure to confirm surrounding safety,
grasp the FOMA terminal firmly and

Don’t

do not swing the FOMA terminal more
than the necessity.

Motion tracking is a function to operate the
FOMA terminal by inclining and shaking it. It
hits the person and others because of the
shake too much, and there is a possibility of
causing a serious accident and damage.

With metallic straps or other metallic
objects in the FOMA terminal and
applying the motion tracking, be sure

Don’t

to not hit the person or others.

It causes injury, malfunction or breakage.

Do not let the FOMA terminal come
close to or sandwich magnetic cards,
etc. between the FOMA terminal.

Don’t

The magnetic data stored on cash cards,
credit cards, telephone cards, floppy disks,
etc. may be erased.

Do not let the FOMA terminal come
close to magnetism.

If strong magnetism is brought close,

Don’t

operation may fail.

If the display is broken and the liquid
crystal leaks, do not take it in, draw it
in or put it on your skin.

Don’t

If the liquid crystal comes into your
eyes or mouth, immediately rinse your
eyes or mouth with clean water and
see a doctor. If the liquid crystal
adheres to your skin or clothing,
immediately wipe it off with alcohol
and rinse it off with water and soap.

It may cause a loss of eyesight or damage
your skin.

When the FOMA terminal plays the
ring tone or plays a melody, do not
bring the speaker close to your ear.

Don’t

It may cause a hearing defect.

In some types of vehicle, using the
FOMA terminal in the vehicle may
interfere with the operation of the

Do

vehicle’s electronic equipment.

Do not use the FOMA terminal if the terminal
may impair the safe driving.

Using the FOMA terminal may cause
skin irritations such as itch, rashes or
eczema. If this occurs, immediately

Do

stop using the FOMA terminal and see
a doctor.

Metal components are used for the following
parts.

Parts Material Finish

Multi-function
keys

Volume up key ABS resin Chrome plating

Volume down key

Design Plate Nickel Ruthenium

Take care not to pinch your finger or
strap when opening or folding the
FOMA terminal.

Do

It cause injury or breakage.

When you watch the 1Seg programs,
be sure to have some distance from
the screen and use it in a very bright

Do

place.

This may affect his/her eyes and cause
impaired vision.

Polycarbonate Vapor deposited

aluminum,
UV coating

on nickel plating

plating (body:
black), chrome
plating (body:
white, gold),
rhodium plating
(body: pink)

3. Handling the Battery Pack

■ Refer to the information shown on

the battery pack label to check the
type of battery pack you have.

Display Battery type

Li-ion00 Lithium-ion

DANGER

Do not let wire or other metals touch
the terminal. Also, do not carry or
store the battery pack with metallic

Don’t

necklaces, etc.

This may cause the battery pack to leak,
overheat, explode or ignite.

If you have difficulty in attaching the
battery pack to the FOMA terminal, do
not use the excessive pressure to

Don’t

force the battery into place. Check that
the battery pack is facing in the
correct direction before you try to
attach it.

This may cause the battery pack to leak,
overheat, explode or ignite.

Do not throw the battery pack into a
fire.

This may cause the battery pack to leak,

Don’t

overheat, explode or ignite.

Do not puncture the battery pack, hit it
with a hammer or step on it.

This may cause the battery pack to leak,

Don’t

overheat, explode or ignite.

If battery fluid comes into your eyes,
do not rub your eyes but immediately
rinse your eyes with clean water and

Do

see a doctor.

This may result in loss of eyesight.

WARNING

If a malfunction is found due to an
external shock such as deformation or
damage by a fall, immediately stop

Don’t

using the FOMA terminal.

This may cause the battery pack to leak,
overheat, explode or ignite, or cause the
devices to malfunction or ignite.

Continued on next page

Easy Search/Contents/Precautions

15

If the battery pack is not fully charged
after the specified charging time has
elapsed, stop charging.

Do

This may cause the battery pack to leak,

Easy Search/Contents/Precautions

overheat, explode or ignite.

If the battery pack leaks or emits an
unusual odor, stop using it
immediately and move it away from

Do

any flame or fire.

The battery fluid is flammable and could
ignite, causing a fire or explosion.

Be sure that your pet doesn’t bite to
the battery pack.

This may cause the battery pack to leak,

Do

overheat, explode or ignite, or cause the
devices to malfunction or ignite.

CAUTION

Do not dispose of used battery packs
with ordinary garbage.

This causes a fire and constitute an

Don’t

environmental hazard. Apply insulation tape
to the terminal of used battery pack and
return it to the NTT DOCOMO shop or
service counter, or dispose the battery pack
in accordance with your local regulations.

Do not charge the wet battery pack.

This causes the battery pack to overheat,
ignite, or explode.

Don’t

If battery fluid comes into contact with
your skin or clothing, stop using the
FOMA terminal immediately and rinse

Do

it off with clean water.

Battery fluid is harmful to your skin.

4. Handling the Adapter
(including the Charger)

WARNING

Do not use the adapter (including
charger) of which the cord or power
cord is damaged.

Don’t

This may cause electric shock, overheat or fire.

Do not use the AC adapter or desktop
holder in humid locations such as
bathroom.

Don’t

This may cause an electric shock.

The DC adapter must be used only for
vehicles with a negative ground. Do
not use the adapter in positively

Don’t

grounded vehicles.

This may cause a fire.

Do not touch the FOMA terminal,
adapter (including charger) when you
hear a crash of thunder.

Don’t

There is a risk of being struck by the
lightning and suffering an electric shock.

Do not short-circuit the charging
terminal when the adapter or charger
is plugged to the power outlet or the

Don’t

socket in a vehicle. Also, do not let the
charging terminal contact with your
body (hand, finger, etc.).

This may cause fire, malfunction, electric
shock or injury.

Place the charger or desktop holder
on a stable surface during charging.
Also, do not cover or wrap the charger

Don’t

or desktop holder with clothing or
bedding.

This may cause the FOMA terminal to fall
out of the charger or heat to build up,
resulting in a fire or malfunction.

Do not put heavy objects on the power
cord of the adapter (including
charger).

Don’t

This may cause electric shock or fire.

Do not touch the power cords of the
adapter (including charger) or the
power outlet with wet hands.

No wet hands

This may cause an electric shock.

Use the specified power supply and
voltage.

Using the adapters with incorrect voltage

Do

may cause a fire or malfunction. Use the AC
adapter for global use to charge the terminal
overseas.
AC adapter: AC 100V
DC adapter:

DC12V/24V (specific to vehicle with
negative ground)

AC Adapter for global use:

100V to 240V AC (should be plugged to
AC power outlet for home use only)

16

If the fuse in the DC adapter blows,
always replace it with the specified
type of fuse.

Do

Using the unspecified fuse may cause a fire
or malfunction.
Refer to the respective manuals for the
information on the specified fuse.

Wipe off any dust on the plug.

This may cause a fire.

Do

When plugging the AC adapter into a
power outlet, make sure that no
metallic straps or other metallic

Do

objects are caught between the plug
and the socket.

This may result in an electric shock, short­circuit or fire.

Always grasp the plug when
unplugging the adapter or charger
from the power outlet or cigar lighter

Do

socket. Do not pull the cord itself.

Pulling the cord may damage the cord and
cause an electric shock or fire.

Unplug the power code from the
power outlet when it will be left
unused for a long period.

Unplug

This may cause electrical shock, fire or
malfunction.

If any water or other liquid gets into
the adapter or charger, immediately
unplug it from the power outlet or

Unplug

socket.

This may cause an electric shock, smoke
emission or fire.

5. Handling the FOMA card

CAUTION

Be careful about a cut surface when
dismounting the FOMA card (IC part).

This may injure your hands or fingers.

Do

6. Handling Mobile Phones near
Electronic Medical Equipment

■ The following precautions conform

to the guidelines drawn up during
the Electromagnetic Compatibility
Conference Japan, regarding how
to protect electronic medical
equipment from radio waves
emitted by mobile phones.

WARNING

Observe the following in hospitals or
other medical facilities:

a Do not take your FOMA terminal into

Do

Do

Do

Do

operating rooms, ICUs (Intensive Care
Units) or CCUs (Coronary Care Units).

a Turn off your FOMA terminal inside

hospital wards.

a Turn off the FOMA terminal even if you

are in a hospital lobby when electronic
medical equipments are in use nearby.

a If a medical facility gives specific

instructions prohibiting you from
carrying or using mobile phones, follow
those instructions.

a

If the FOMA terminal is set with the Auto power
function, make sure to disable the function
before turning off the FOMA terminal.

Turn off the FOMA terminal in crowded
places such as rush-hour trains in case
somebody nearby is using an
implantable cardiac pacemaker or
implantable cardioverter-defibrillator.

Radio waves may affect the operation of
implantable cardiac pacemakers or
implantable cardioverter-defibrillators.

If you use an implantable cardiac
pacemaker or implantable cardioverter­defibrillator, keep the FOMA terminal at
least 22 cm away from the devices.

Radio waves may affect the operation of
implantable cardiac pacemakers or
implantable cardioverter-defibrillators.

If you use the electronic medical equipment
other than implantable cardiac pacemakers
or implantable cardioverter-defibrillators out
of the medical facility due to the home
treatment, etc,, consult the respective
manufacturers for the information about the
effects of radio waves on the equipment.

Radio waves may affect the operations of
the electronic medical equipment.

17

Easy Search/Contents/Precautions

Handling with Care

General Notes

c Do not water the devices.

Easy Search/Contents/Precautions

The FOMA terminal, battery pack, adapter
(including the charger) and the FOMA card (UIM)
are not water-proof. Do not use them in humid
locations such as bathrooms, and avoid exposing
them to rain. If you carry your FOMA terminal close
to your skin, sweat may cause internal components
to corrode and result in a malfunction. If the
problem is found to be due to moisture, it will not be
covered by the warranty and in some cases may be
irreparable. Even if it can be fixed, you will be
charged since the damage is not covered by the
warranty.

c Wipe with a soft, dry cloth (such as a cloth

for glasses).

aThe surface of the FOMA terminal’s LCD has a

specific coating to improve the visibility of the
color display. Rubbing the LCD of the FOMA
terminal with a dry cloth to clean it may scratch
the LCD surface. Handle the FOMA terminal
carefully and clean it using a soft dry cloth (of a
type used for eyeglasses). The LCD coating may
peel off or stain if moisture or soiling is left on the
surface for a long period.

aNever use chemicals such as alcohol, thinners,

benzene or detergents as these agents may
erase the printing on the FOMA terminal or
cause discoloration.

c Occasionally clean the connection

terminals with a dry cotton bud.

Soiled connection terminals may result in poor
connections and loss of power. Also, as it may
cause insufficient charging, clean the terminal with
a dry cloth or cotton bud when it is dirty.

c Do not place the FOMA terminal near an air

conditioning vent.

Condensation may form due to rapid changes in
temperature, and this may cause internal corrosion
and malfunction.

c Do not apply an excessive pressure or

weight to the FOMA terminal and battery
pack.

Do not put the FOMA terminal in a bag filled with
many objects or in the hip pocket of clothing as you
sit down. This may result in faults or damage to the
LCD, other internal components or battery pack.
When an external device is connected to external
connector (earphone/microphone terminal), it may
cause connecting breakage or malfunction.

c Read the separate manuals supplied with

the FOMA terminal, adapter and charger
carefully.

c Do not scrabble the display with metallic

objects.

This may cause scratch, malfunction or damage.

Handling the FOMA Terminal

c Avoid using the FOMA terminal in extremely

high or low temperatures.

Use the FOMA terminal within a temperature range
between 5°C and 35°C with humidity between 45%
and 85%.

c Using the FOMA terminal close to ordinary

phones, TVs or radios may affect the
operation of such devices. Use the FOMA
terminal away from such devices.

c It is your responsibility to keep a separate

record of all data stored on your FOMA
terminal.

Under no circumstances shall NTT DOCOMO be
liable for any loss or damage to the data stored on
your FOMA terminal.

c When connecting an external device to the

external connector (earphone/microphone
terminal), do not plug inclined in the
connector or pull the code.

This may cause malfunction or damage.

c Do not fold the FOMA terminal with its strap

caught between the folding parts.

This may cause malfunction or damage.

c It is normal for the FOMA terminal to

become warm while being used or charged.
It is not a malfunction and you can keep on
using.

c Do not leave the camera exposed to direct

sunlight.

This may discolor or burn the element.

c Usually fit the external connector cap and

microSD memory card slot cap before use.

Failing to fit these covers may cause the FOMA
terminal to malfunction due to the dust or water
getting in.

c Do not use FOMA terminal when the back

cover is removed.

This may cause of removing the battery pack,
malfunction or damage.

c

Do not put a sticker with an extreme thickness,
etc. on the face of the display or keys.

This may cause malfunction.

c Do not remove the microSD memory card or

turn off the FOMA terminal when using the
microSD memory card.

Otherwise, loss of data or malfunction may result.

Handling the Battery Pack

c The battery pack is consumable.

If the battery pack does not work for enough time
even when it is fully charged, it is time to exchange
it. Exchange it for a specified new battery pack.

c Charge the battery pack within the proper

ambient temperature range (5°C to 35°C).

18

c

Make sure to charge the battery when you use
the FOMA terminal for the first time or if you
have not used it for a long period of time.

c The available operating time of the battery

pack depends on the conditions in which
you use it and the condition of the battery
pack itself.

c When the life of the battery pack is near

end, the battery pack may expand a little
according to the usage condition, but this is
not a malfunction.

c Do not keep or leave the battery pack

empty.

The performance and life of the battery pack may
be deteriorated.

Handling the Adapter (including the
Charger)

c Charge the battery pack within the proper

ambient temperature range (5°C to 35°C).

c

Do not charge the battery pack in the
following places:

aIn a humid, dusty or shaky place
aNear your home phone, TV or radio

c It is normal for the adapter or charger to

become warm while being charged. It is not
a malfunction and you can keep on using.

c Do not use the DC adapter to charge the

battery pack when the car engine is not
running.

This may drain the car battery.

c If you use an electrical outlet with a

disconnection prevention mechanism,
follow the instructions of the user’s manual
of the outlet.

c Do not shock the adapter or charger. Do not

deform the charging terminal.

This may cause malfunction.

Handling the FOMA card

c Do not apply unnecessary force to attach or

remove the FOMA card.

c It is normal for the FOMA card to become

warm while being used. It is not a
malfunction and you can keep on using.

c The warranty does not cover damage

caused by inserting the FOMA card into
some other type of IC Card reader/writer.

c Always keep the IC part clean.
c Wipe with a soft, dry cloth (such as a cloth

for glasses).

c It is the user’s responsibility to keep a

separate record of all data stored on your
FOMA card.

Under no circumstances shall NTT DOCOMO be
liable for any loss or damage to the data stored on
your FOMA terminal.

c To preserve the environment, take

discarded FOMA card to the NTT DOCOMO
shop or service counter.

c Avoid using the FOMA card in extremely

high or low temperatures.

c Do not damage, scratch, touch imprudently,

or short circuit the IC.

Otherwise, loss of data or malfunction may result.

c Be careful not to drop the FOMA card or

apply an impact to it.

This may cause malfunction.

c Do not bend the FOMA card or place a

heavy object on it.

This may cause malfunction.

c Do not attach the FOMA card to the FOMA

terminal with a label or sticker is pasted.

This may cause malfunction.

Handling the FeliCa Reader/Writer

c The FeliCa reader/writer function of the

FOMA terminal uses very weak radio waves
that require no licensing of radio stations.

c The 13.56MHz frequency band is used. If

there is another reader/writer around, keep
enough distance between the FOMA
terminal and that reader/writer. Also, make
sure that there is no radio equipment using
the same frequency band nearby.

Caution

c Do not use the altered FOMA terminal.

Using the altered device is a violation of the
Radio Law.

The FOMA terminal is certified to conform to
technical regulations for specified radio
equipments that are based on the Radio Law, and
“Technical Conformity Mark ” is affixed on the
model name seal as the certification. If you remove
the screw and alter inside of the FOMA terminal,
the technical regulations conformity certification
becomes invalid. Do not use the FOMA terminal
with the certification invalid, as it is a violation of
the Radio Law.

c Be careful when you use the FOMA terminal

while driving a vehicle.

The penalty is imposed on using a mobile phone
while driving. Unwillingly receiving a call, use the
Hands-free to tell the caller that you will call back,
then stop the car in a safe place before using the
phone.

c Use the FeliCa reader/writer function in

Japan.

The FeliCa reader/writer function of the FOMA
terminal complies with radio standard in Japan.
You may be punished if you use it overseas.

c Use the IC card authentication function in

Japan.

Continued on next page

19

Easy Search/Contents/Precautions

The IC card authentication function of the FOMA
terminal complies with radio standard in Japan and
is certified. You may be punished if you use it
overseas.

Intellectual Property Right

Easy Search/Contents/Precautions

Copyright and Portrait Right

It is prohibited to duplicate, modify or publicly transmit
content such as text, images, music or software that was
photographed using the FOMA terminal or downloaded
from Internet website and that is subject to third-party
copyright without the permission of the copyright folder,
except where the duplication or quoting of the content for
personal use is permitted under copyright law.

It may be prohibited to shoot or record the stage
performance, entertainment or exhibition even if it is for
personal use.
Shooting a photo of someone by the FOMA terminal
without his or her permission, or displaying a photo of
someone shot by the FOMA terminal on the website
without his or her permission is a breach of portrait right.

Trademarks

a“FOMA”, “mova”, “i-mode”, “i-αppli”, “i-αppli DX”,

“i-motion”, “Deco-mail”, “Chaku-motion”, “Chara­den”, “ToruCa”, “mopera”, “mopera U”, “WORLD
CALL”, “Dual Network”, “FirstPass”, “visualnet”,
“V-live”, “i-Channel”, “DCMX”, “iD”, “Security Scan”,
“i-shot”, “i-motion mail”, “i-area”, “Short Mail”,
“WORLD WING”, “Public mode”, “DoPa”,
“sigmarion”, “musea”, “IMCS”, “OFFICEED”, “2in1”,
“Chokkan Game”, “FOMA” logo, “i-mode” logo,
“i-αppli” logo, “ToruCa” logo, “DCMX” logo, “iD”
logo, “Choku-Den” logo, “Music&Video Channel”
logo and “HIGH-SPEED” logo are trademarks or
registered trademarks of NTT DOCOMO, Inc.

aFree Dial logo mark is a registered trademark of

NTT Communications Corporation.

a“Catch Phone (Call waiting service)” is a registered

trademark of Nippon Telegraph and Telephone
Corporation.

aNapster is a registered trademark of Napster, LLC.

and/or its affiliates in the US and/or other countries.

®

aMcAfee

aG-GUIDE, G-GUIDE MOBILE and their logos are

aPowered by JBlend

a is a registered trademark of FeliCa Networks,

is registered trademarks or trademarks of
McAfee, Inc. and/or its affiliates in the US and/or
other countries.

registered trademarks in Japan of U.S. Gemstar-TV
Guide International, Inc. and/or its affiliates.

TM

Corporation. All rights reserved.
JBlend and JBlend-related trademarks are
trademarks or registered trademarks of
Aplix Corporation in Japan and other
countries.

Copyright 2002-2008 Aplix

Inc.

aQR code is a registered trademark of Denso Wave

Inc.

aThe microSD logo is a trademark.
a“Multitask”, “Emotion-expressing mail”, “ みんなNらん

ど”, “Privacy angle”, “Life history viewer”, and “Quick
Info” are trademarks or registered trademarks of NEC
Corporation.

aFrancfranc is a registered trademark of BALS

Corporation.

aQuickTime is a registered trademark of Apple Inc., in

the US and other countries.

aMicrosoft

aJava and all Java-related trademarks and logos are

aT9

aPowered By Mascot Capsule

aThe other company names and brand names

®

, Windows®, Windows Media® and

®

Windows Vista
trademarks of Microsoft Corporation in the United
States and/or other countries.

trademarks or registered trademarks of US Sun
Microsystems, Inc. in the United States and other
countries.

®

is a trademark or registered trademark
of Nuance Communications, Inc., and
entities held by Nuance in the United
States and other countries.

MASCOT CAPSULE® are registered trademarks of

are either registered trademarks or

®

/Micro3D Edition

TM

HI CORPORATION.

described in this manual are trademarks or
registered trademarks of the respective companies.

Others

aThis product is licensed complying with MPEG-4

Visual Patent Portfolio License, and you are
permitted to use personally and for the nonprofit
purpose in the following situations:
aTo record a movie based on the standard of

MPEG-4 Visual (MPEG-4 Video)

aTo play MPEG-4 Video recorded by the consumer

engaged in the nonprofit activities

aTo play MPEG-4 Video provided by the provider

licensed by MPEG-LA
When you use it for other purposes, such as
promotion, in-house information and profit activity,
contact the U.S. corporation MPEG LA, LLC.

aFeliCa is a contactless IC card technology

developed by Sony Corporation. FeliCa is a
registered trademark of Sony Corporation.

aContains Adobe

Reader
Incorporated.
Adobe Flash Lite copyright
Systems Incorporated. All rights reserved.
Adobe Reader LE copyright
Systems Incorporated. All rights reserved.
Adobe, Adobe Reader, Flash and Flash Lite are
either registered trademarks or trademarks of
Adobe Systems Incorporated in the United States
and/or other countries.

®

Flash® LiteTM and Adobe

®

LE technology by Adobe Systems

©

2003-2007 Adobe

©

1993-2007 Adobe

®

20

aLicensed by QUALCOMM Incorporated under one

or more of the following United States Patents and/
or their counterparts in other nations:
4,901,307 5,490,165 5,056,109 5,504,773
5,101,501 5,506,865 5,109,390 5,511,073
5,228,054 5,535,239 5,267,261 5,544,196
5,267,262 5,568,483 5,337,338 5,600,754
5,414,796 5,657,420 5,416,797 5,659,569
5,710,784 5,778,338

aContent owners protect copyrighted intellectual

properties by WMDRM (Windows Media digital
rights management) technology. This product uses
the WMDRM software to access WMDRM­protected contents. If the WMDRM software is
unable to protect contents, the content owners
request Microsoft to disable the WMDRM function
of the software for playing or copying protected
contents. No contents other than protected ones
are affected by disabling the function. Please note
that, if downloading the license to use protected
contents, Microsoft may include the revocation list
in the license. Content owners may request
upgrading of the WMDRM software when you
access the contents. If rejecting the upgrade,
contents requiring the upgrade cannot be
accessed.

aThis product contains ACCESS CO., LTD's

NetFront Browser and NetFront Sync Client.
ACCESS and NetFront are trademarks or
registered trademarks of ACCESS CO., LTD. in
Japan, the United States and other countries.
Copyright© 2008 ACCESS CO., LTD. All rights
reserved.

aThis product contains the module developed by

Independent JPEG Group.

aThis product contains NetFront Document Viewer of

ACCESS CO., LTD. as the document viewer.
ACCESS and NetFront are
trademarks or registered
trademarks of ACCESS CO., LTD.
in Japan and other countries.

aIrSimple

aThis product is equipped with IrFront

aDialog Clarity and WOW technologies are

TM

are trademarks of Infrared Data
Association

by ACCESS CO,. LTD. as the infrared data
exchange function.
Copyright© 1996-2008 ACCESS CO., LTD.

ACCESS and IrFront are trademarks or registered
trademarks of ACCESS CO., LTD. in Japan and/or
other countries.

industrialized based on the license from SRS Labs,
Inc.

Dialog Clarity, SRS, WOW and the symbol
are trademarks of SRS Labs, Inc.

, IrSSTM or IrSimpleShot

®

.

TM

aThis product contains software licensed complying

with GNU General Public License (GPL), GNU
Lesser General Public License (LGPL), etc. For
more details, see “readme.txt” in the “GPL・LGPL
等について” folder on the bundled CD-ROM.
(“readme.txt” is only available in Japanese version.)

aThis product contains NetFront DTV Profile

Wireless Edition of ACCESS CO., LTD. as the data
broadcast BML browser.
This product contains Media: of ACCESS CO., LTD.
as the contents activating function.
Copyright ©1996-2008 ACCESS CO., LTD.
ACCESS, NetFront and Media:/Media colon are
trademarks or registered trademarks of ACCESS
CO., LTD. in Japan and/or other countries.

aThis product equipped with the font “FontAvenue”

product by NEC Corporation.
FontAvenue is a registered trademark of NEC
Corporation.

aThis product is anti bacterial-coated.

Antibacterial part is Phone body (excluding the
display, keys/buttons and terminals)
Inorganic antimicrobial agent, coating,
JP0122112A0003N
The SIAA brand mark is borne on products
evaluated according to ISO 22196 and they are
under quality control and information disclosure by
the guidelines of the Society of Industrial
Technology for Antimicrobial Articles.

a“Francfranc” is either registered trademark or

trademark of BALS Corporation.

aThis product is equipped with GestureTek

technology.
Copyright© 2006-2008, GestureTek, Inc. All Rights
Reserved.

a© 2008 Joho Center Publishing Co.,Ltd.
a© 2008 Evidence Japan Co.,Ltd.
a© Primeworks
a© 2008 ZENRIN DataCom CO., LTD.

© 2008 ZENRIN CO., LTD.

a© mobcast
a© 2008 Google - Map data ©2008 Geocentre

Consulting, NFGIS, ZENRIN, Europa Technologies

a© ATR-Trek Co.,Ltd.
a© yoshiyasu / icca
a© Apt. / NEW WORLD RECORDS Co.,Ltd.

Description of Windows

aIn this manual, each OS (Japanese Edition) is

described as follows:

• Windows Vista stands for Windows Vista
Basic, Home Premium, Business, Enterprise,
Ultimate).

• Windows XP stands for Microsoft
Professional operating system or Microsoft
Windows® XP Home Edition operating system.

• Windows 2000 stands for Microsoft
2000 Professional operating system.

®

(Home

®

Windows® XP

®

®

Windows

®

Easy Search/Contents/Precautions

21

Main Components and Optional Equipment

<Main Components>

Easy Search/Contents/Precautions

FOMA N706i

(Including the warranty and Back
Cover N29)

Manual for FOMA N706i

(This manual)

* The Quick Manual starts on P.440.

<Optional Equipment>

FOMA AC Adapter 01/02

(Including warranty and manual)

Battery Pack N18

CD-ROM for FOMA N706i

* This CD-ROM contains the PDF files of

“Manual for PC connection setting” and
“Kuten Code List”.

Desktop Holder N18

(Including manual)

Other options and accessories→ P. 3 9 4

22

Before Using the Handset

Component Names and Functions ................................................................................. 24

How to View the Display ................................................................................................. 27

How to view My Signal ................................................................................................... 29

Selecting the Menu ......................................................................................................... 30

Changing the Main Menu................................................................................................ 34

The Basic Operations on the Screens ............................................................................ 35

Description of the Operations ......................................................................................... 37

Function Menu ................................................................................................................ 38

Setting the FOMA Card .................................................................................................. 40

Attaching/Removing the Battery Pack ............................................................................ 42

Charging the FOMA Terminal ......................................................................................... 42

Checking the Battery Level ........................................................................... 45

Turning the FOMA Terminal On/Off ......................................................... 46

Switching between Japanese and English.............................................. 46

Setting the Default ........................................................................................ 47

Setting the Clock............................................................................................................. 47

Notifying the Other Party of Your Phone Number............................. 48

Checking Your Own Phone Number ................................................................ 48

Battery level

Power ON/OFF

Select language

Initial setting

Caller ID Notification

My Profile

23

Component Names and Functions

(
)

q

*

1

Before Using the Handset

2

3

y

4

6
8
0

5

7
9

!

u

w

@

#

$

^

* : The Antenna of the FOMA terminal is built-in. To make calls under better condition, do not cover the antenna part

with your hands.

■ Functions

1 Infrared data port→ P. 2 8 0
2 Earpiece
3 Display
4 Illuminance sensor →P.9 7
5 Multi-function keys

f/g

• Moves the cursor or the displayed contents, etc.
up or down (scrolls continuously when the key is
held down)

• f: Displays Choku-Den →P. 8 4

• g: Displays the search phonebook menu
screen

%

&

h/j

• Moves the cursor to the left or right

• Scrolls the display to the previous or next

screens by pages→ P. 3 5

• h: Displays the Received calls record →P. 5 6

• j: Displays the Redial →P. 5 6

d

• Performs the displayed function (“Select” or

“Set”, mainly) →P. 3 3

6 oFunction key 1

• Performs the displayed function→P. 3 3

• Displays the mail menu

• Makes videophone calls →P. 5 0

e
r

t

*

i

o

p

24

7 pFunction key 2

• Performs the displayed function→P. 3 3

• Displays the i-mode menu

• Switches the character type when entering

characters→ P.334

8 iFunction key 3

• Performs the displayed function→P. 3 3

• Displays the main menu/Simple Menu

→PP.30, 34

• Displays the task change screen →P.309

9 uFunction key 4

• Performs the displayed function (function

menus, mainly) →P. 3 3

• Activates the function selected in “ch-key

setting”→P. 3 1 1

*Displays the Channel list of i-Channel at the time

of purchase.

0 r Send key

• Makes voice calls →P. 5 0

• Receives voice/videophone calls →P. 6 2

• Returns to the previous reading when entering
characters using the 5-touch input mode
→P.330

! t Back (Clear) key

• Undoes the last step in the operation→ P. 3 6

• Puts a call on hold →P. 6 5

• Deletes the entered phone number or
characters→ PP.50, 335

@ y Power/End of operation/Hold key

• Turns on the power (1 second or longer)/turns
off the power (2 seconds or longer)→ P. 4 6

• Ends each function→ P. 3 6

• Ends a call →P. 5 1

• Puts an incoming call on hold→ P. 6 5

# 0 to 9 Dial keys

• Enters phone numbers, characters and numbers

$ w/Public mode (Driving mode) key

• Sets Public mode (Driving mode) (1 second or
longer)→P. 6 6

• Switches the entered character into upper or
lower case→ P.334

• Enters “ ＊” or dakuten/handakuten →P.334

% q/Manner key

• Sets Manner mode (1 second or longer)→ P. 9 2

• Enters “ ＃” or “,. ”, etc.→P.381

^ Mouthpiece/Microphone
& Through-hole for strap
* Charging terminal
(

Volume up key/(マナー)

a

• Sets Manner mode (1 second or longer)→ P. 9 2

• Raises the earpiece volume during a call→ P. 6 5

• Scrolls back the display to the previous screens
by pages→ P. 3 5

• Connects to the site set as “Home URL”→ P.160

)

Volume down key/(MUSIC)

s

• Lowers the earpiece volume during a call→ P. 6 5

• Scrolls the display to the next screens by pages

→P. 3 5

• Reads out the current time (Voice clock)

(Japanese mode)→ P. 6 8

• Plays recorded messages →P. 7 0

q microSD memory card slot

• Used to inser t the microSD memory card

→P.267

w External connecter

• Connects an AC adapter (optional), DC adapter
(optional), FOMA USB Cable with Charge
Function 01/02 (optional) or Earphone Plug
Adapter for External connector terminal 01

*

etc.

(optional)

* : Connects the flat-plug stereo earphone set

(optional) or the flat-plug earphone/microphone with
switch (optional), etc.

e Speaker
r Design Plate
t My Signal

• Displays the clock or various information about
the FOMA terminal →P. 2 9

y Charge lamp/Incoming call lamp/Shooting

indicator/Communication indicator

• Lights in red while charging→ P. 4 5

• Flashes in the selected color while receiving a
call or when there is a missed call→P. 6 8

• Flashes in the selected color while receiving a
mail or when there is a new mail→ P. 6 8

• Flashes in red during shooting mode→ P. 1 2 8

• Flashes in blue while the auto timer is activated
→P.128

• Lights/flashes while using a communication
function→P.101

u Lens selector switch

• Switches ● (Standard)/ (Macro) for the
camera→ P. 1 2 8

i Camera

• Shoots still images and movies

• Shoots the movie of scenery during videophone
calls

o FeliCa mark

• Reads the IC card →P.222

• iC communication →P.282

p Back cover

* a ( マナー ) and s (MUSIC) are referred to as side keys in

this manual.

Before Using the Handset

25

Functions that involve holding down keys for 1 second or
longer

The functions available by holding down each key for 1 second or longer in the standby screen are as
follows:

Key Function

Before Using the Handset

h Displays the Received address list. P.192

j Displays the Sent address list. P.192
2 Changes the mode of 2in1. P.349
3 Sets the IC card lock. P.227
5 Turns the display light on/off. P.97
7 Displays the font setting screen P.101
8 Switches Privacy angle. P.97
0 Enters “+”. P.54
q Sets/Releases Manner mode. P.92

Sets/Releases Public mode

w

(Driving mode)

Ref. page

P. 6 6

Key Function

c Adjusts the earpiece volume. P.65

Sets/Releases Manner mode. P.92

a

Uses the IC card authentication.

(

マナー

)

(when Dial lock/Keypad lock is set)

Activates/Quits the music player

s

(During BGM play)

(MUSIC)

o Check new messages P.180

Displays the i-αppli software list

p

screen.

Ref. page

P. 1 2 1

P. 3 0 5

P. 2 0 7

26

How to View the Display

z The symbols (such as , , , etc.) displayed on the screen are referred to as icons.
z A calendar, etc. can be set to the display.→ P. 9 6

The status of the FOMA terminal is indicated with icons in this area→ P. 2 7

Clock display→P.102

Desktop icon display area

・ etc. : Desktop icons providing information→P.102
・ etc. : Pasted desktop icons →P. 1 0 2

Task icon display area

・ etc. : Task icons of the activated functions→P. 3 0 9
・Displays the status of the network being used→ P. 3 6 3

Function /i-Channel ticker display area →PP.33, 166

(Photo mode), (Quick Search) and (1Seg) are the

default settings.

● Icons that indicates the status of the FOMA terminal

Icon Description

5 /

(Red)

Icon Description

1

2

3 / i-mode/i-mode communication in

/ / Packet communication in progress

/ Packet communication in progress

Battery level→ P. 4 5

Signal strength→ P. 4 6

Out of service area/Radio wave
does not reach→ P. 4 6

Self mode→ P. 1 2 5

progress→ P. 1 4 6

(no data exchange/sending/

*

receiving)

(sending/receiving)

*

(Red)

6 /

(Red)

/

(Red)

/ / / Unread message R and F (in red

7 /

(Red)

4 SSL-compatible page displayed

→P. 1 4 8

/

(Red)

Unread mail/Inbox is full→ P. 1 7 8

SMS in the FOMA card (UIM) is full
→P. 2 7 7

Unread mail/SMS in the FOMA
card (UIM) is full→PP.178, 277

Inbox is full/SMS in the FOMA card
(UIM) is full→ PP.178, 277

Unread Area Mail→ P.197

Unread MessageR/Full→P. 1 9 5

Unread MessageF/Full→ P. 1 9 5

when each of them is full)→P. 1 9 5

Mail kept at the i-mode Center/Full
→P. 1 8 0

“Receive option setting” is set to
“ON” and a mail is kept at the
i-mode Center →P. 1 7 9

MessageR kept at the i-mode
Center/Full→ P. 1 9 5

Before Using the Handset

Continued on next page

27

Icon Description

/

7

(Red)

8

Before Using the Handset

/

/

9

MessageF kept at the i-mode
Center/Full→ P. 1 9 5

Dial lock→ P. 1 1 1

Secret mode/Secret data only
mode→ P. 1 1 3

Original lock/Original lock released
temporarily→ PP.116, 117

Secret mode or Secret data only
mode and Original lock is set or
released temporarily
→PP.113, 116, 117

IC card lock→ P. 2 2 7

0 / microSD mode/MTP mode set

→P. 2 7 4

//

//

//

USB cable connected and
Communication mode/microSD
mode/MTP mode set→ P. 2 7 4

Hands-free compatible device
connected and Communication
mode/microSD mode/MTP mode
set→ PP.62, 274

USB cable/Hands-free compatible
device connected and
Communication mode/microSD
mode/MTP mode set→ PP.62, 274

! Infrared data exchange in progress

→P. 2 8 0

Infrared remote control operated
→P. 2 8 4

IC card authentication in progress
→P. 1 2 1

iC communication in progress
(sending/receiving data) →P. 2 8 2

@ microSD memory card inser ted

→P. 2 6 7

microSD memory card (invalid)
inserted →P. 2 6 7

microSD reader/writer operated
→P. 2 7 4

Icon Description

@

#

$

%

^

&

microSD being accessed→ P. 2 7 0

During a voice call→P. 5 0

64K data communication in

*

progress

During a videophone call→ P. 5 0

Switching between voice call and
videophone call→ PP.53, 63

Vibrator→ P. 9 0

Ring volume set to “Silent”→ P. 6 5
Mail/Msg. ring time is set to “OFF”

→P. 9 1

Manner mode→ P. 9 2

Start/cancel Automatic Manner
mode→ P. 9 2

Public mode (Driving mode)→P. 6 6

* Music&Video Channel program

reservation set→ P. 2 9 3

( Alarm notification function

→PP.236, 316

) Timed 1Seg recording in progress

→P. 2 3 6

q

〜 Voice mail message →P. 3 4 2

w

〜 Record message →P. 6 9

e

〜 Record VP message→ P. 6 9

r

t

y

* : For details on the icons, refer to the “Manual for PC

connection setting” (PDF format) in the provided CD­ROM.

Backlight set to “OFF”→ P. 9 7

Privacy angle set to “ON”→ P. 9 7

Privacy angle set to “ON”, backlight
set to “OFF” →P. 9 7

Keypad lock set→P. 1 2 0

Side key guard set to “ON”→P. 1 2 2

N

z The display adopts state-of-the-art technology; some dots (points) may not light up while others may constantly light

up due to its characteristics. Note that this phenomenon is not a failure.

z You can check the name of the displayed icons by selecting “settings”X“Display”X“Icons”.

28

How to View My Signal

When the status of the FOMA terminal changes, My Signal displays various animations to notify you of it.

● Example of the display

Before Using the Handset

folded (Close display)

Missed call New mail New Area Mail New ToruCa

Manner mode set to ON Keypad lock set to ON Alarm notification for Alarm Alarm notification for

While receiving a call While receiving a mail While receiving a messageWhen the FOMA terminal is

Schedule/To Do list/Booking

program/Timer recording

■ Music Player

During pause Volume (Level 10)Tra ck nu mb er

N

z You can download My Signal animation data from “ みんなN らんど ”. →P. 1 4 7

z You can set My Signal animations such as close display, calling display and in-call display in “My Signal settings”.

z By using “Ring tone/Image” setting, you can identify the phone caller or sender of mails with the animation.

→P. 8 2

Displaying the clock to check time

Press a (マナー ) or s (MUSIC) with the FOMA terminal folded to display the clock on My Signal.

z When you press s (MUSIC), the clock is displayed and the current time is read out at the same time (when

there is no missed call, new mail, etc.).→ P. 6 8

Clock display on My Signal

N

z You can set the pattern of the clock display in “My Signal settings”.

z The clock of My Signal cannot be displayed all the time.

29

Selecting the Menu

You can run, set, and check the FOMA terminal’s functions in a variety of ways. There are various
methods of the rest though the method of selecting the function from the main menu is general.

Selecting functions from the main menu

Before Using the Handset

You can select the functions of the FOMA terminal from the main menu displayed by pressing i in the
standby screen. The menus are sorted by function.→ P. 3 7 0

<Example: To set the “Illumination in talk” function>

Press i on the standby screen to display the main menu

1

i

If you do not press any key for 15 seconds while
the main menu is displayed, the main menu is
turned off and returns to the previous screen.

Use b to move the highlight, then press d (Select) to select the displayed

2

menu sequentially

Tip

30

b

c

The highlighted item is
displayed in two lines
and the current setting
is displayed.

d 

d 

c

Holding down c
moves the highlight
in sequence.

d 

Tip

Accessing functions with the short cut keys

On each screen, you can access functions easily by pressing the function keys pre-assigned to the
function.

Press the function key on the standby screen

1

Before Using the Handset

Pressing f
displays the Choku­Den screen.→ P. 8 4

Pressing o
displays the mail
menu.→ P.170

Pressing g displays
the Search phonebook
screen.→ P. 8 0

Pressing p
displays the i-mode
menu. →P. 1 4 6

Pressing h displays
the Received calls
screen.→ P. 5 6

Pressing u displays
the Channel list.→ P.166

Pressing j
displays the Redial
screen.→ P. 5 6

N

z When using the Simple Menu (P.34), pressing o or p on the standby screen displays the Simple Menu.

z You can change the function accessed with u key. →P. 3 1 1

31

Searching menu items to access functions

Even if you do not know the procedure to access the menu, you can still access the desired function by
entering key words to search menu items.

<Example: To access “Select ring tone”>

Before Using the Handset

Press i on the standby screen, then press u (FUNC), and highlight

1

“Search”, then press d (Select)

i

u

d

Enter “ring” and press d (Set), then select the displayed menu

2

d

The search result
is displayed with an
underline.

Selecting functions from the original menu

By storing your frequently used functions (P.99), you can access the menus easily.

Press i on the standby screen to display the main menu, then press p

1

(Original) in sequence

Pressing p switches between the main menu and the original menu.

i

p

If there are two or
more search
results, press p
(Next) to move the
frame.

p

d

32

p

Accessing functions by selecting menu numbers

When the main menu is set to “Standard” (P.34), you can access functions quickly by pressing the keys
pre-assigned to the menu numbers (P.370).

<Example: To access “Select ring tone”>

Press i on the standby screen, then press 13 in sequence

1

Before Using the Handset

i

1

3

How to use the function keys

The operation icons (Function display) corresponding to o, d, p, i, u and the direction icons
corresponding to b are displayed on the screen. Only when the corresponding keys can be used, those
icons are displayed.

■ Performing the functions assigned to the function key

Press the key for 1 to 5, the function is activated.

1 includes (Settings), (Edit), (Finish), (Play), (Send), (New), etc.

The center of 2 includes (Select), (Set), (Play), (Dial) etc.

3 includes (Disp SW), (Ir data), (Chrct) etc.
4 includes (MENU) and (MULTI).
5 includes (ch), (FUNC), (Close) etc.

Press u while (FUNC) is displayed to display the function menu.→ P. 3 8

■ Moving or scrolling the screen

Press b in the direction you want to scroll.

2

1

4

1

4

3

5

2

3

5

[Notation]

■ Description of the function display

In this manual, operations related to the keys for the function display are generally described with the
function display in the parenthesis, such as Dd (Select) and Fu (FUNC).

33

Changing the Main Menu

You can change the design of the main menu (style for background or icon, etc.) as you want.

z When you change the design of the menu display using Kisekae Tool, the menu structure may change in

accordance with frequency of using functions. Also, you cannot access some functions entering the menu
number assigned to the functions. In this case, it is not possible to operate it according to this manual, so be

Before Using the Handset

sure to switch the functions to the default menu or reset the menu operation log (P.98).

Press i on the standby screen, then press o (Change) in sequence

1

Switching pages→ P. 3 5

i

o

ThemeMain Menu

Select an item

2

“Flock” 〜 “Standard”

Switches the display design in each menu. When set to “Standard”, you can
access functions by entering the menu numbers.→ P. 3 3

“Simple Menu”

Simple Menu consists of frequently used menus, and its character size is large and
operation procedure is simple.→ P. 3 8 0
Sets the character size of the screens to “X-large” all at once. →P.101
“Original theme”→P. 9 8

You can change the icons and background image used on the main menu. You can
also set the picture you shot as the background.
“Kisekae Tool”→ P.106
You can change various design of the FOMA terminal such as the main menu all at once with the
Kisekae Tool package. Select “拡大メニュー ”, switch to the menu in the large character size.

■ Changing the Main Menu temporarily

Highlight an item on the theme screen and press o (Change) to change the main menu temporarily.
When the main menu is displayed again, the main menu before it sets is displayed.

Simple Menu

N

z When you set the menu that suppor ts the user customizing, you can sort the menu items by selecting “Manual-sort”

by push ing u (FUNC) in the main menu. →P. 3 1 1

[Notation]

■ Description of the main menu

The description of the main menu is different depending on the main menu design. In this manual,
instructions for main menu operations are described in capital letter in accordarce with the default menu
setting.
mail i-mode i-αppli
settings data box lifekit
service phonebook own data
music 1seg osaifu-keitai

34

The Basic Operations on the Screens

● When items appear in multiple pages

Press v to display other pages

1

To switch the page, press h (or a (マナー )) for the previous page and press j (or s (MUSIC)) for
the next page.

Current page/Total pages

j

h

■ To display other pages using c

Pressing f displays the previous page when the highlight is located at the top of the list, and pressing
g displays the next page when the highlight is located at the bottom of the list.

● Using the dial keys to select items

Press 1 to 90wq corresponding to the menu numbers

1

3

The number corresponding to the dial key

● Selecting “YES/NO” or “ON/OFF”

Before Using the Handset

Press c to move the frame, then press d (Select)

1

35

● To display an image in the picture list

Press b to move the frame, then press d (Disp.)

1

Before Using the Handset

● Entering a security code

Enter the 4 to 8 digit security code, then press d (Set)

1

● Entering numbers

Enter numbers by pressing 0 to 9

1

● To cancel operations, and to return to the standby screen

■ t

Press t to cancel the last operation, such as when you select wrong menu item. Though the previous
screen appears basically, another screen may appear depending on the function.

■ y

Press y to complete operations such as settings and to return to the standby screen. Though the function is
completed and the standby screen appears basically, another screen may appear depending on the current
displayed screen and function. If you press y during setting operation, the setting operation is canceled and
the standby screen reappears.

The numbers of the entered security code is displayed as “_”.
The detail screen of the function is displayed when the security code is
successfully entered.

■ If the entered security code is incorrect

A message notifying that the security code is wrong is displayed. Re-enter the
security code from the beginning.

To enter a 1-digit number or 2-digit number in a 3-digit number entry screen, press
0 twice or once before entering a number.

■ To enter “3”

X003

36

Description of the Operations

X

X

In this manual, instructions for menu operations are briefly described in almost all cases as follows:

The example of description of operations and the actual operations

① ② ③

i

“lifekit”X“Alarm”XHighlight the item to set

④ ⑤

u (FUNC)

1

①: Press i on the standby screen.
②: Press b to move the highlight to the menu in the double quotation mark, then press d (Select).
③: Press b to move the highlight to the item in the double quotation mark, and then press d

(Select).
Or, press 1 to 90wq for the menu number in the double quotation mark.

④: Press b to move the highlight.
⑤: Press the key for the function displayed in parentheses.

[Notation]

■ Omission of Dd in the “Select” and “Set” operations

• When a target function is selected from the main menu or list, such as example ② and ③, Dd (Select) is

omitted.

• In the cases such as “Select an item” or “Enter your security code”, Dd (Select) and Dd (Set) are omitted

in the same way.

• When you are supposed to move to the next step without pressing Dd (Select), “Highlight xxx” is used,

such as example ④.

■ Easy operations are preferred

• Though the operation of the main menu has been described, this manual gives priority to the operations
by short cut keys operations (P.31).

• If you select the menu from the Simple Menu, refer to “Simple Menu function list” (P.380).

■ Omission of the descriptions after completing the operations

• The descriptions for the operations after completing the function are omitted.

• “To cancel operations, and to return to the standby screen”→ P. 3 6

■ Brief description of keys and menus

• In this manual, instructions for key illustrations/menu displays/holding down keys are simply described as
follows:

Key Menu display Holding down keys

Actual display/operation Menu
Description in this manual 1 iMenu q (1 second or longer)

■ Describing multiple menus together

When multiple menus are described together, “・” is used between the items as follows:

<Example: Function menu of the Choku-Den screen>

Release this・Release all……Releases one or all Choku-Den.

Press and hold down q for 1
second or longer

Before Using the Handset

37

Function Menu

“Function Menu” is one of the menus of the FOMA terminal that can be accessed from the function
display. The function menu activates supplementary functions of each screen.
For example, you can use the function menu to delete a mail after reading it, or to select the folder to
save an image you shot with the camera.

Before Using the Handset

● How to use the function menu

There are mainly three ways to use the function menus. Use the appropriate method depending on the
situation.

① Refer to the explanation of the function menu items from the reference page stated with the operation

screen.

② Refer to the explanation of the function menu items from the function menu index.
③ Find the procedure to display the operation screen from the reference page of the function menu.

Operation screen with the reference page for the function menu is illustrated
in a shaded colored frame and differentiated from others.

Function menu

Mail

Address screen (list/detail). . . . . 192

Detail screen . . . . . . . . . . . . . . . . . . 191

Folder list screen . . . . . . . . . . . . . . 188

List screen . . . . . . . . . . . . . . . . . . . . 190

Message screen. . . . . . . . . . . . . . . 172

New mail screen. . . . . . . . . . . . . . . 171

New mail

①

③ ②

New mail screen (P.170)

Send……Sends i-mode mail.

Save→P. 1 7 6

Delete receiver……If there are 2 or more addresses

entered, you can delete the address that is highlighted.

Change rcv. type……Changes the address type with an

address highlighted.

Function menu¨P. 17 1

* “Function menu item” and “Function menu index” in the above illustration are only excerpts.

● Operation target on the list screen

In the function menu on the list screen, either data highlighted in the list or all the data in the list is
targeted by the function. For example, “Edit title” or “Delete this” targets a highlighted title or data, and
“Delete all” targets all the data.
When you select a function menu which targets one data in the list, such as “Edit title” or “Delete this”,
highlight the data, then press u (FUNC).

<Example: To edit the bookmark title on the list screen>

XHighlight the

bookmark

Xu (FUNC)

X“Edit title”

XEdit the title
Xd (Set)

The bookmark title
changes.

38

● About multiple-choice

When you delete unnecessary data, protect important data or move the data you do not want to be
viewed by others to the secret folder, etc., you can select not only one data or all data but also multiple
data. In this case, perform the following operation.

<Example: To delete multiple mail on the received mail list screen>

Before Using the Handset

X“Delete

selected”

XCheck mails to

delete

Xo (Finish) X“YES”

Marking a checkbox

When you use b to move the frame to the item to select and press d (Select), the checkbox changes
from to . This means that the item is selected. Pressing d (Select) switches between and .
In the picture list, appears when the item is selected. Nothing appears when unselected.

d

d

• When “ ” appears on the function display area, pressing u (FUNC) allows you to use “Select all”

or “Release all”.

d

d

● Menus which switch alternately

Depending on the menu, menu items switches alternately as follows:

<Example 1> <Example 2>

In “Standard font” In “Big font”

When the text size in the phonebook list screen
is displayed in “Standard font”, the size is
displayed as “Big font” such as in <Example 1>.
When you choose “Big font” under these
conditions, the text size will change to Big font,
and the next time you open the function menu,
the menu name will be “Standard font”.

[Notation]

■ Description of the menus which switch alternately

Such menus are described as “Big font⇔ Standard font”.

N

z When the displayed menu contains sub menus, “ ” appears on the right.
z The displayed contents of the function menu may vary or you may not be able to select the item of function menu

depending on the operating function and settings. The function menu items you cannot select are displayed in gray.

39

Setting the FOMA Card

The FOMA card is an IC card that contains private
information such as your phone number.
Before inserting or removing the FOMA card, first turn
the power off and remove the battery pack. →P. 4 2
Note also that when you try to insert or remove the

Before Using the Handset

FOMA card, keep the FOMA terminal folded and held
in your hand.

● Attaching/Removing the FOMA card

The illustration shows how to attach the FOMA card.

Put the FOMA card into the card

1

inserting slot with the IC side
downward as shown in the illustration

Cut corner

IC

FOMA card
(UIM)

FOMA card
inserting slot

Gold colored IC
side down

Insert the FOMA card until it is fixed

2

To remove the FOMA card, carefully pull it out
straight from the following status.

When properly inserted

Security codes for the FOMA card

You can set two security codes of PIN1 code and
PIN2 code for the FOMA card (UIM). →P. 1 1 0

FOMA card security function

The FOMA terminal incorporates the FOMA card
security function (FOMA card operational restriction
function) to protect your data and files.
z When you download data or files from sites or

receive data attached to mails, the FOMA card
security function is automatically set to these data
and files.

z Data and files with this function set are accessible

only when the same FOMA card (UIM) used when
downloading these data or files is used.

z Target data and files for the FOMA card security

function are as follows:

• File attached to i-mode mail (except for ToruCa)

• Screen memo

• Image inser ted into Deco-mail or signature

•i-αppli (including i-αppli standby screen)

• Image (including the animation and Flash movie)

• Melody

• Word/Excel/PowerPoint data

• Image of ToruCa (detail)

• Image downloaded from the Data Security
Center

• Program of the Music&Video Channel

• Movable contents data

• i-motion

• Chara-den

• Chaku-Uta

• PDF data

• My Signal animation data

• Kisekae Tool

• Record Videophone message

• Mail template including data with operational
restrictions

• DL dictionary

• MessageR/F with attached file (melody/image)

• e-books/e-comics

* : “Chaku-Uta” is a registered trademark of Sony Music

z The FOMA card (UIM) that was inserted when you

downloaded or received data or files is referred to
as “your FOMA card (UIM)” and other FOMA cards
as “other FOMA card (UIM)” hereinafter.

®*

/Chaku-Uta-Full

Entertainment (Japan) Inc.

®

40

• Cookie settings for Full Browser
(Cookie information is kept)

z Functions of which current settings of the FOMA

card (UIM) become invalid

• Program setting of the Music&Video Channel
(Set the program again)

When the inserted FOMA
card (UIM) was used to
download data or receive
mails, you can view or play
the data which has had the
FOMA card security function
applied to it.

Changing the FOMA card

When the inserted FOMA
card (UIM) was not used to
download data or receive
mails, you cannot view or
play the data which has had
the FOMA card security
function applied to it.

Your FOMA card

Other

FOMA card

N

z If the FOMA card (UIM) is not attached or you replace

the FOMA card (UIM) with another one, “ ” is
attached to data and files with this function set and
you cannot set these data to “Display setting” or
“Select ring tone”.

z Data and files with this function can be moved and

deleted with other FOMA cards (UIM).

z If you remove the FOMA card (UIM) or change to

other FOMA card (UIM) when data or a file with this
function set is set to “Display setting” or “Select ring
tone”, these settings are reset to the default settings.
When your FOMA card (UIM) is inserted again, the
settings return to your settings.

Settings for replacing the FOMA card

When you replace the FOMA card (UIM) inserted to
the FOMA terminal with other FOMA card (UIM), the
following settings are changed:

z Functions of which settings are changed to settings

stored on the newly inserted FOMA card (UIM)

• Select language • SMS center selection

• SMS validity period • PIN setting

• Host selection of Connection setting

z Functions that are reverted to the default setting

• i-Channel setting

• Access setting for Full Browser

z Functions that are set to “Invalid”

FOMA card types

The FOMA card (UIM) (blue) has the following
functional differences from the FOMA card (green/
white).

Function Blue Green/White

Max number of
digits for phone
number to be
stored in the UIM
phonebook

User certificate
operation to use
FirstPass

WORLD WING Not available Available

Service Numbers Not available Available

20 digits 26 digits

Not available Available

WORLD WING

WORLD WING is the FOMA international roaming
service that enables you to make and receive calls
in overseas with the same mobile phone number
you use in Japan with the FOMA card (green/
white) and the mobile phone which is compatible
with the service.
z For the customers who have subscribed to the

FOMA service on September 1, 2005 or after, a
separate subscription is not necessary.
However, customers who declared that they did
not require this service at the FOMA service
subscription or who unsubscribe from this
service need a separate subscription.

z For the customers who have subscribed to the

FOMA service on August 31, 2005 or before
without subscribing to “WORLD WING”, a
separate subscription is necessary.

z This service is not available in some payment

plans.

z In case the FOMA card (UIM) (green/white) is

lost or stolen in overseas, contact to DOCOMO
as soon as possible and take the course of
service interruption. Refer to the back of this
manual for the inquiries numbers. Note that you
are charged for the call and communication even
after the FOMA card (UIM) (green/white) is lost
or stolen.

Before Using the Handset

41

Attaching/Removing the Battery Pack

z Make sure to turn the FOMA terminal off before

removing the battery pack. Note also to keep the
FOMA terminal folded and held in your hand.

Before Using the Handset

● Attaching

Remove the back cover

1

Pressing the back cover in direction ①, slide it in
direction ② to remove the back cover.

Attach the battery pack

2

With the “ ” side of the battery pack facing up,

B

attach the battery pack in direction ③ making
sure that the “▲” mark of the battery pack fits
the “▲ ” mark of the FOMA terminal (Phone),
then press the battery pack down in direction ④.

Attach the back cover

3

With the back cover about 3 mm away from the
FOMA terminal, align the catches on its
underside with the grooves in the FOMA
terminal (Phone). Pressing the back cover in
direction ⑤, slide it in direction ⑥ and press the
back cover until it clicks shut.

Fit the “▲” mark

Underside catches

● Removing

Remove the back cover

1

Remove the battery pack

2

Press the tab on the side of the battery pack in
direction ①, then lift upwards in direction ② to

remove the battery pack.

Finger tab

N

z Do not use excessive force when the tip of the back

cover is inserted into the FOMA terminal. The catches
of the back cover may break.

Charging the FOMA Terminal

Use the specified Battery Pack N18 for the FOMA
terminal.

■ Battery pack life

• The battery pack is consumable. The amount of
usable time decreases every time the battery pack
is recharged.

• When a fully charged battery pack only lasts half as
long as it did at the time of purchase, the battery
pack life is almost over, so it is recommended to
replace it with a new one. When the life of the
battery pack is near end, the battery pack may
expand a little according to the usage condition, but
this is not a malfunction.

• The battery pack life may be shortened if i-αppli,
videophone or 1Seg is used for a long time while
charging.

Make sure that there is no space between the
Back cover and the FOMA terminal (Phone).

42

To protect the environment,
take used battery packs to
NTT DOCOMO, the agency,
the recycle shop, etc.

■ Battery pack charging

• For details, refer to the manuals for the FOMA AC
Adapter 01/02 (optional), FOMA AC Adapter for
Global use 01 (optional) and FOMA DC Adapter
01/02 (optional).

• FOMA AC Adapter 01 supports voltage of 100V AC
only.

• FOMA AC Adapter 02 and FOMA AC Adapter 01
for Global use supports voltage from 100V AC to
240V AC, but the plug shape of the AC adapter is
for 100V AC (domestic). To use AC adapters from
100V AC to 240V AC while overseas, the
compatible conversion plug adapter is required. Do
not charge the battery using the transformer for
travel. For overseas use, the compatible conversion
plug adapter is required. Do not charge the battery
using the transformer for travel.

• When charging the battery pack, the battery pack
must be attached to the FOMA terminal.

• You can receive calls during charging if the FOMA
terminal is turned on. However, the battery level will
fall during the call and the time required for
charging will increase. Charging time also
increases when “Charging” of “Backlight” setting is
set to “All time ON”.

• When plugging in or out the connector, do it slowly
and securely not to apply an excessive force.

• When you make a call or perform packet
communication during charging in a high­temperature environment, the FOMA terminal’s
temperature may rise and the charging may be
stopped. If this occurs, stop a running function and
wait for the temperature or the FOMA terminal to
fall before you retry charging.

■ Do not charge the battery pack for a long

period of time (several days) with the
FOMA terminal turned on

• If you charge the battery pack for a long period of
time with the FOMA terminal turned on, power to
the FOMA terminal will be supplied from the battery
pack once charging ends. As a result, you will only
be able to use the FOMA terminal for a short time
and the low-voltage alarm may sound immediately.
In this case, recharge the battery pack correctly.
Disconnect the FOMA terminal from the AC
adapter (or desktop holder) or DC adapter, then set
it again for recharging.

■ Battery usage time (The duration varies

depending on the charging time and the
deterioration of the battery pack.)

Continuous standby time

[FOMA/3G] Stationary (when set to “AUTO”*):

[GSM] Stationary (when set to “AUTO”*):

[FOMA/3G] Voice call: Approx. 220 min.

[GSM] Voice call: Approx. 190 min.

Watching: Approx. 280 min.
ECO mode: Approx. 350 min.

* : To switch the network connection, select “3G/GSM

• The continuous standby time in stationary is the

• The continuous standby time in moving is the

• Note that the actual continuous talk/standby time/

• Depending on the network condition of the country, talk

• If “3G/GSM setting” (P.366) is set to “3G”, the talk

Approx. 580 hours
Moving (when set to “3G”*):
Approx. 430 hours
Moving (when set to “AUTO”*):
Approx. 360 hours

Approx. 290 hours

Continuous talk time

Videophone call: Approx. 100 min.

1Seg viewing time

setting” (P.366).

average usage time when the FOMA terminal is
folded and standing still while radio waves can be
normally received.

average usage time when the FOMA terminal is
folded under condition of “stationary”, “moving”,
and “out of service area” within the area where
radio waves can be normally received.

1Seg viewing time may decrease by as much as half
depending on the following conditions: the battery
pack charging level, the function settings, ambient
environment such as temperature, the status of radio
waves (out of service area or weak radio waves).
Using i-mode, composing i-mode mail, using data

α

communication or multi access, activating i-

α

ppli standby screen, using camera, playing movie/

i-

ppli or

i-motion or music, 1Seg audition also decreases the
talk (communication) and standby times.

(communications) and standby times may decrease.

(communication) and standby time will increase
when using it domestically.

Before Using the Handset

43

Charging the battery pack with the AC/
DC adapter

■AC adapter (optional)

Before Using the Handset

100V AC power outlet

Connector cap

Plug

3

FOMA AC Adapter 01/02

■DC adapter (optional)

Cigarette lighter socket

3

Plug

Connector

Plug the connector with arrows
side facing upward

Release
button

12

When charging is completed, remove

4

the AC adapter/DC adapter connector
horizontally from the FOMA terminal
while pressing the release button

Do not pull the connector with excessive force
because this may cause a malfunction.

Unplug the AC adapter from the outlet

5

Unplug the DC adapter from the
cigarette lighter socket in your car

Close the external connector cap of

6

the FOMA terminal

Charging the battery pack with the
desktop holder

Plug the connector
with arrows side
facing upward

100V AC
power outlet

1

Connector

2

Plug

2

Charge lamp

3

FOMA DC Adapter 01/02

Open the external connector cap of the

1

FOMA terminal

Plug the AC/DC adapter connector

2

horizontally into the FOMA terminal’s
external connector

Plug the AC adapter into the outlet

3

Plug the DC adapter into the cigarette
lighter socket in your car

Charging starts.

Standard charging time

Approx. 120 min.

44

Desktop Holder N18

FOMA AC Adapter 01/02

Plug the connector of the AC adapter

1

(optional) horizontally to the terminal on
the back of the desktop holder (optional)

Plug the AC adapter into the outlet

2

Holding down the desktop holder,

X

X

3

insert the FOMA terminal in direction
① and push it in direction ② until it is

secure

The charge lamp lights up in red during
charging. The charge lamp turns off when
charging ends (Full charge). If the FOMA
terminal is turned on, “ ” flashes during
charging and “ ” lights when charging ends.

Standard charging time

Approx. 120 min.

After charging is completed, hold

4

down the desktop holder, tilt the FOMA
terminal toward you and lift it in the
direction of the arrow

N

z The battery pack cannot be charged separately.

Always charge the battery pack while it is attached to
the FOMA terminal.

z If the battery runs out, the charging lamp may not

lights up right away, but the charging itself has started.

<AC adapter/DC adapter>

z When the charge lamp of the FOMA terminal (Phone)

and “ ” on the display disappears, and the message
“Charge unusual Stop charge” is displayed,
disconnect the FOMA terminal from the AC adapter or
DC adapter and remove the battery pack. Then set
them again for recharging. If the same error occurs
again, there may be a problem or fault on the AC
adapter or DC adapter. Contact the NTT DOCOMO
shop or service counter.

z

The DC Adapter uses a 2A fuse. If the fuse (2A) blows,
always use a fuse with the same specifications. Fuses
(2A) are consumable items. Purchase a replacement
fuse at your local car accessory shop, etc.

<Desktop holder>

z Attach the FOMA terminal to the desktop holder

securely. Also, take care not to pinch the strap.

Checking the Battery Level

<Battery level>

The indicated battery level is only a reference.

Checking the battery level with icon

When the FOMA terminal is turned on, the icon
indicating the remaining battery level is displayed.

: Full charge.

: Partial charge.

: The battery is almost

running out. Recharge the
battery.

Checking the battery level with sound
and animation

The current battery level is indicated by sound and
animation.

i

“settings”X“Other settings”

1

“Battery level”

The check screen is displayed, and beeps sound
in accordance with the level. The battery level
animation disappears in about 3 seconds.
“3 short beeps” : Full charge.
“2 short beeps” : Partial charge.
“1 short beep” : The battery is almost running

out. Recharge the battery.

When the battery runs out

The screen as shown on the left
appears and the low-voltage
alarm sounds. The alarm sounds
for about 10 seconds and the
power is turned off in about 1
minute. To stop this alarm, press
any key (except for side keys).

N

z The recharge battery screen and 3 short beeps sound

during a voice call and the recharge battery screen
(“Camera Off” message to the other party) appears
during a videophone call to notify. Note that the call
will be disconnected in about 20 seconds and the
power turns off in about one minute.

Before Using the Handset

45

Turning the FOMA Terminal

X

On/Off

Turning the FOMA terminal on

z Before turning the FOMA terminal on, make sure

Before Using the Handset

that the FOMA card is inserted correctly.

1

N

z Wake-up tone rings when the wake-up display of

z When you change the FOMA card (UIM), you have to

z A screen is displayed to inform you if the terminal was

<Power ON/OFF>

y (1 second or longer)

After Wake-up screen is displayed at the same
time the Wake-up tone rings, and the standby
screen or initial settings screen appears. If you
have just attached the battery pack or you
turned the FOMA terminal back on immediately
after turning it off, the “WAIT A MINUTE”
message may appear for a short time.

■ When “ ” appears

You are outside the FOMA
service area or in a place
where radio waves do not
reach. Move to a place where
the radio reception level icon
such as “ ” appears. The
reception level is displayed
as follows:

Good Poor

■ If the Initial setting screen appears→P. 4 7

■ If the PIN1 code/PIN2 code entry screen
appears→ P.110

■ When checking “N706i Happy

News” mail

“N706i Happy News” mail is saved in
your terminal at the time of purchase. Refer to
“Viewing a new mail” →P.178

“Display setting” is set besides “OFF”.

enter the 4 to 8 digit security code after turning on the
FOMA terminal. The standby screen appears when
the security code is successfully entered. When you
enter wrong security code for 5 times, the FOMA
terminal turns off (however, you can turn on the FOMA
terminal again).

shut down automaticaly or due to lack of power.

Standby

Turning the FOMA terminal off

y (2 seconds or longer)

1

The shutdown screen “SEE YOU” appears and
the power is turned off.

Turning the FOMA terminal on/off
automatically

Set the Auto power function, the power supply
automatically on or off at the specified time.
z The FOMA terminal does not turn off during using

another function, even if the Auto power OFF set
time is reached. In addition, the FOMA terminal
does not turn off when the alarm notification time or
the i-αppli Auto-start time is the same as the Auto
power OFF set time. The FOMA terminal turns off
after finish the function.

z If the FOMA terminal turns off, the Music&Video

Channel program is not downloaded and reserved
update of the software or timer recording are not
available. Note above when setting Auto power
OFF.

<Example: Turning the FOMA terminal on
automatically>

i

“settings”X“Clock”X“Auto power

1

ON”

■ Turning the FOMA terminal off

automatically

X“Auto power OFF”

“ON”XEnter the timeXSelect whether

2

to repeat or not

■ To cancel the Auto power ON/OFF

X“OFF”

N

z Before entering an area such as an aircraft or hospital

where there is electronic equipment that uses
extremely precise control systems or very low signal
levels and the use of mobile phones is prohibited, set
the “Auto power ON” setting to “OFF” and then turn
the FOMA terminal off.

<Auto power ON/OFF>

Switching between Japanese and English

You can switch the languages between Japanese and
English to display function names and messages on
the display.

<Select language>

46

i

X

X

X

“settings”X“ディスプレイ”X“バ

1

イリンガル”

■ To change from English to Japanese

X“日本語”

“English”

N

z When the FOMA card (UIM) is inserted, Select

language setting is stored on the FOMA card (UIM).

You can switch announcement language between
Japanese and English for outgoing and incoming
calls in some announcements.→ P.346

Setting the Default

After turning the FOMA terminal on, you can set “Set
main time”, “Change security code”, “Character size”
and “Keypad sound” as initial settings.

Initial setting screenX“YES”

1

Set the main time→ P. 4 7

2

Change the security

3

code→P. 1 1 1

The default setting is “0000” (4
zeros).

Set the character size → P. 1 01

4

Set the keypad sound→ P. 9 1

5

Check the contents about Software

6

Update, then select “OK”

<Initial setting>

Initial setting

N

z When you set all functions, the initial setting screen no

longer appears when you turn on the FOMA terminal.

Setting the Clock

You can set the FOMA terminal to correct the date
and time by the function of Set main time. In the
function of the sub clock, you can specify the display
mode view/close of the sub clock.

z The FOMA terminal can automatically correct the

clock based on the time information (Greenwich
Mean Time GMT) and the time zone (the local
time).

z The time difference to Greenwich Mean Time is set

as for the time zone every hour. When another city
or area is registered by the same time difference,
“ ” is displayed in the function display, and it
can switch the city or the area with o.

Set the main clock

i

“settings”X“Clock”X“Set main

1

time”X“Auto time adjust”

■ To set the summer time

X“Summer time”

When set to “ON”, time is displayed with 1 hour
added.

Select any item:

2

Auto……The date and time of the main clock are set

automatically.

Auto……The time information and the time

zone information are retrieved and the date
and time are set automatically. The local time is
displayed during international roaming.

Manual (Time zone set) ……Selects the time

zone, and the local time is displayed.

Manual (Date time set) ……Enters the date and

time in the main clock manually. Select the time
zone, then enter the date and time.

■To enter the date and time

Using b to move the highlight, then use the dial
keys to enter the numbers.

<Set main time>

N

z After you set the date and time, you can use functions

such as “Alarm” or “Schedule” which manages the
date and time.

z The adjustable range of the date and time is between

00:00 on January 1, 2004 and 23:59 on December 31,

2037.

<Auto time adjust>

z The FOMA terminal's clock is automatically corrected

when the FOMA card is inserted into the terminal and
the terminal is turned on.

z There may occur a time lag for a few seconds. The

time lag may not be corrected depending on the
condition of the wave or the i-αppli set for the i-αppli
standby screen.

z Automatic correction may not be performed,

depending on the network of the carrier being used
while overseas.

Before Using the Handset

47

Setting the sub clock

X

X

X

i

“settings”X“Clock”X“Set sub

1

clock”X“display method”

■ To set the summer time

X“Summer time”

When set to “ON”, time is displayed with 1 hour

Before Using the Handset

added.

Select any item:

2

Auto……The sub clock is automatically displayed

during international roaming. For example, the main
clock is automatically switched to the local time
when Auto time difference is set to “Auto”, but the
sub clock displays the Japan standard time.

Always……Selects the Time zone and sets the sub

clock to display the local time at all times.

OFF……Sub clock is not displayed.

<Set sub clock>

N

z The sub clock is displayed only when “Size” of “Clock

display” is set to “Small”.

z When you set “Auto” in this function, the sub clock

displays the Japan time except when the time zone of
“Set main time” is “GMT+09” (the sub clock is not
displayed for “GMT+09” in Japan).

Notifying the Other Party of Your Phone Number

<Caller ID Notification>

The FOMA terminal can send your phone number
(caller ID) to the other party’s phone (Display) when
you make a call.

z Since the phone number is important information,

please take care when you send your caller ID.

z You cannot perform the setting when “ ” is

displayed.

z You can notify/withdraw your caller ID for individual

calls.→ P. 5 9

i

“service”X“Caller ID

1

Notification”

Activate/Deactivate……Sets whether to send your

caller ID or not.

Check setting……Checks the current Caller ID

Notification settings.

Select any item:

N

z This function is only available when the recipient's

phone allows the display of caller ID.

z When you hear the guidance instructions to display

your caller ID, notify your caller ID to call again.

Checking Your Own Phone Number

You can display and check your phone number (own
number) stored in your FOMA card (UIM).

iX0

1

N

z You can easily quote the information stored in “My

Profile” when entering the owner information (such as
name or mail address) on websites, etc. →P. 3 3 6

z You can check your i-mode address by selecting

pX“iMenu”X“English”X“Options” X“Mail Settings”

X“Confirm Settings”.

z When 2in1 is in Dual mode, press c to switch the My

Profile display.

z Reset My Profile in B mode when you exchange the

FOMA card (UIM) while using 2in1. →P. 3 1 8

<My Profile>

48

Voice/Videophone Calls

■Making a Voice/Videophone Call

Making a Voice/Videophone Call .................................................................................... 50

Switching a Voice/Videophone Call during a Call (Caller) .............................................. 53

Making International Calls ........................................................................ 54

Using Hands-free Call during a Call .............................................................. 55

Using the Redial/Dialed Calls/Received Calls Record..... 56

Using Chaku-moji .......................................................................................... 58

Notifying/Withholding Your Caller ID for Individual Calls................................................. 59

Sending Push Signals..................................................................................... 60

Using the Prefix Function................................................................................................ 61

Setting Sub-addresses When Making Calls ...................................... 61

Setting the Alarm Used for Reconnection.............................................. 62

Blocking Out Ambient Noise .................................................................... 62

Making Hands-free Calls in the Car...................................................... 62

Redial/Dialed calls/Received calls

■Receiving a Voice/Videophone Call

Receiving a Voice/Videophone Call................................................................................ 62

When the Other Party Switches a Voice/Videophone Call (Caller)................................. 63

Using the Dial Keys to Answer a Call........................................................ 64

Ending/Holding Calls with the FOMA Terminal Folded...................... 64

Adjusting the Earpiece Volume ........................................................................... 65

Adjusting the Ring Volume........................................................................... 65

■Settings for when you cannot take calls

Holding the Ringing/Current Call ...................................................... 65

Using the Public Mode (Driving Mode) ................................... 66

Using the Public Mode (Power OFF) ......................................... 66

When You Cannot Answer a Received Call................................................... 67

Having the Caller Leave a Message ....................................................... 68

Having Callers Leave a Message during an Incoming Call ..................... 69

Playing/Erasing Recorded Messages and Voice Memos ............................................... 70

Public mode (Driving mode)

Public mode (Power OFF)

■Setting the Videophone

Using Chara-den............................................................................................................. 71

Setting Functions for the Videophone............................................................................. 71

Using the Videophone Connecting to External Devices ................................................. 73

WORLD CALL

Hands-free

Chaku-moji

Pause dial

Sub-address setting

Reconnect signal

Noise reduction

In-car Hands-free

Answer setting

Setting when folded

Vol ume

Ring volume

Answer hold/Holding

Missed call

Record message

Quick message

49

Making a Voice/Videophone Call

* As FOMA N706i is not equipped with the front

camera, during a videophone call, you can send
only the substitute image (Chara-den) or image
from the rear camera to the other party.
You can change the substitute image (Chara-

Voice/Videophone Calls

den) to other data such as an image of My picture
in “Select image”.→P. 7 1

Enter the phone number of the other

1

party

The “Enter phone number
screen” appears.
Always start by entering the
area code, even for calls
within the same area.
You can enter up to 80 digits
for the phone number.
However, only the last 26
digits are displayed.

<When you enter a wrong number>

■ To insert a number

Press v to move the cursor to the number to
the left of the position where you want to insert
the number, then enter the number.

■ To delete a number

Press v to move the cursor to the number you
want to delete, then press t.
Hold down t for 1 second or longer to delete
all the numbers to the left of the cursor and the
number in the cursor position.

■ To re-enter the number

Move the cursor to the beginning or end of the
number and hold down t for 1 second or
longer to return to the standby screen.

<Videophone>

■ To change the substitute image (Chara-

den)

XFu (FUNC)X“Select image”X“Chara-den”
XSelect Chara-den

Enter phone number

Function menu¨P. 52

r (voice call) /o (V. phone)

2

<Voice call>

The “In-call screen”
appears.
“ ” flashes while dialing
and lights up during the
call.

■ If you hear the busy

tone

The line is busy. Call again
after a while.

■ If you hear a message saying that the

other party cannot be reached

The other party’s mobile phone is not turned
on or is out of signal range. Call again after a
while.

■ If you hear a message requesting your

caller ID

Call again with caller ID notification enabled.
→PP.48, 59

<Videophone>

The “Videophone in-call
screen” appears.
“ ” flashes while dialing
a videophone call and
lights up during the call.

■ If a videophone call is
not connected→ P. 5 2

■ To switch between
substitute image and
camera image

XFDd (Change)

Each time you press FDd (Change), the
substitute image and camera image switches.

■ To switch the main screen

XDd (1 second or longer)

“Change main disp.” →P. 5 2

■ To enlarge the camera image to be sent

XAdjust the zoom using Fv

Zoom→ P.138

■ To mute the voice to send

XSa (マナー ) (1 second or longer)

The “ ” icon is displayed.
To cancel muting, press Sa (マナー ) for 1

second or longer again.

Videophone in-call

Function menu¨P. 52

In-call

50

■ To switch a voice/videophone call during a
call→ P. 5 3

■ To put the current voice/videophone call
on hold→ P. 6 5

■ When the 2in1 is in Dual mode

The Outgoing number selection screen appears.
Select a phone number.

To end the call, press y

3

N

<Videophone call>

z If you make a videophone call to an emergency

number (110, 119 or 118) from the FOMA terminal,
the call is automatically changed to a voice call.

z You cannot receive i-mode mail or a MessageR/F

during a videophone call (you can receive SMS).
Received mail is kept at the i-mode Center and can be
retrieved using “Check new messages” after the
videophone call.

z When you are using the videophone at the same time

as 1Seg recording with the camera during charging,
on rare occasions the “Camera Off” message may
appear and the camera may turn off depending on the
temperature of the FOMA terminal.

z Digital communication charges are still applied to the

caller when the substitute image is displayed during a
videophone call.

You can use the videophone call function

What is the Videophone

between the terminals that support the DOCOMO
videophone system.

z DOCOMO videophone conforms to “the 3G-

*2

standard set down in the international

324M

*1

standards”. Your FOMA terminal

3GPP
cannot connect to a videophone terminal that
uses a different system from DOCOMO
videophones.

*1: 3GPP (3rd Generation Partnership Project)

A regional standardization body established to
develop commonly applied technical specifications
for 3rd-generation mobile communications
systems (IMT-2000).

*2: 3G-324M

An international standard for 3rd-generation
mobile videophones.

■How to view the videophone screen

11

33

44

①Main screen (Camera image of the other party

is displayed at the time of purchase)

②Sub-screen (Your own substitute image is

displayed at the time of purchase)

③Call duration
④Settings

: Sending or receiving voice/

Transmission error

: Sending or receiving video/

Transmission error

: Sending camera image/Sending

substitute image/Sending Chara­den

: Hands-free ON/OFF

: Muting

: Photo mode (Portrait/Scenery/

Close-up)

: Key operation mode (DTMF

*1

/Whole action mode*2/

mode
Parts action mode

*1: “Send DTMF tone/DTMF tone OFF”→P. 5 2
*2: “Using Chara-den”→ P. 7 1

22

*2

)

Voice/Videophone Calls

51

Enter phone number screen
(P.50)

Notify Caller ID→ P. 5 9

Prefix numbers→ P. 6 1

Chaku-moji→ P. 5 8

Int’l call→ P. 5 5

Multi Number→ P. 3 4 8

Voice/Videophone Calls

Add to phonebook→ P. 7 6

Compose message*→P. 1 7 0

Select image……Selects the substitute image used

during a videophone call from Chara-den.
Select “Release settings” to cancel the setting.

* : Not available when 2in1 is in B mode.

Videophone in-call screen
(P.50)

Substitute image ⇔camera image……Switches

between the camera image and the substitute image.

Change main disp.……Changes the main display.

The screen changes in the order of “Displaying the image
from the other party’s camera on your main screen.”→

“Displaying the image from your own camera on your
main screen.” →“Displaying only the image from the other
party’s camera.” →“Displaying only the image from your

own camera.”

V.phone settings……Sets the screen for videophone

call.

Visual prefer.……Sets the image sent to and

received from the other party from “Normal/Prefer
img qual/Prefer motion spd”.
This setting is only retained during the call.

Brightness……Five brightness levels (-2 to 0 to +2)

are available.

White balance……Sets image color tones. →P. 1 3 2

This setting is also applied to the equivalent camera
functions.

Color mode set……Selects the image effect from

“Normal/Sepia/Monochrome”.
This setting is only retained during the call.

Photo mode……Sets modes suited to the scene

being shot. →P. 1 3 2

Chara-den set.……You can set the followings when

Chara-den is used. This setting cannot be set for the
camera images.

Switch Chara-den……Selects the character to be

displayed.

52

Action List……Checks the available actions and

the corresponding keys. You can also view the action
list by pressing w.

Change Action……Changes the Action mode.

Switch image……Displays the still image selected

in “Substitute image” (P.71) on the other party’s
display.

Display light……Sets lighting of backlight.

All time ON (default)……Turns the backlight on all

the time.

15 seconds ON……Turns the backlight on for 15

seconds only.

Own number……Displays your phone number during a

videophone call.

Send DTMF tone⇔ DTMF tone OFF……Sets/cancels

push signal transmission mode during Chara-den.
Except for Chara-den, videophone calls are always in
push signal transmission mode.

Change to voice→ P. 5 3

● If a videophone call is not connected

When a videophone call is not connected, the cause
of the failure appears.
z The cause may not appear depending on the

situation.

z Depending on the type of other party’s phone or the

possible lack of a network service subscription, the
reason may not accurately reflect the other party’s
actual status.

Display Cause

Check number then
redial

Busy The line is busy

Busy with packet
transmission

Out of service area/
power off

Your call is being
forwarded

Redial using voice
call

Please activate
caller ID before
dialing again

The called phone number is not
used

• This message may also
appear during packet
communication.

The other party is using packet
communication

The other party is out of service
area or the phone is turned off

The call is being forwarded (A
Videophone call is made when
the forwarding number is for a
3G-324M-compatible
videophone)

The phone for the forwarding
number is not compatible with
videophone calls

The other party sets the Caller
ID request service

X

X

Display Cause

This number is not
available

Upper limit has been
exceeded
Connection failed

Connection failed Set the caller ID notification to

Please make your
call from the i-mode
web page

The other party sets the
Nuisance call blocking service

The upper limit set for a Limit
billing plan (Type Limit and
Family Wide limit) is exceeded

“ON” and retry
You connected without notifying
your caller ID (when dialing into
visualnet, etc.)

• This message may also
appear in other situations

You attempted to make a
videophone call to watch V-live
without browsing the i-mode
official site

z If the videophone call is not connected, your call is

automatically switched to a voice call when you set
“Auto redial as voice” to “ON”. However, the call
may not be handled in this way if you call an ISDN
synchronous 64K or an ISDN videophone which
does not support the 3G-324M standard (as of
May, 2008) or if you dial a wrong number. Note that
call charge may be applied in some cases.

Switching a Voice/ Videophone Call during a Call (Caller)

z You can use this function with the terminals

compatible with voice call/videophone call switch.

z You can switch the voice call only when you are the

caller.

z To switch the call, the receiver needs to set “Ntfy

switch-mode” to notify the switch beforehand.
→P. 7 2

<Example: To switch a voice call to a videophone
call>

In-call screen (P.50)

1

“YES”

While switching, the screen which indicates that
the calls are being switched appears and the
voice guidance is played.

d (V. phone)

The digital
communication fee
is charged after the
appearance of this
screen.

■ To switch a videophone call to a voice call

XVideophone in-call screen (P.50)Xu (FUNC)
X“Change to voice”

N

z It takes about 5 seconds to switch the calls. Note that

the signal quality may affect how long it takes.

z You cannot switch the calls during calling in the

following cases:

• When the other party is holding the call

• When the other party activates Record message

z The displayed call duration is reset to 0 second each

time the calls are switched. However, the total time for
voice and videophone call is displayed after ending a
call.

z Depending on the other party’s communication

conditions or the signal quality, you may not be able to
switch the calls and the call may be canceled.

z When the call is switched, the first dialed or received

call is registered to the Redial/Dialed calls records or
Received calls records.

<When switching from voice call to videophone call>

z If the caller is using i-mode, the i-mode

communication is canceled to switch to videophone.

z If the other party is using packet communication

(including i-mode), you receive the message “No
Switch” meaning you cannot switch the calls.

z You cannot switch the calls when “Call Waiting” is

activated.

Voice/Videophone Calls

53

Making International Calls

<WORLD CALL>

WORLD CALL is an international dialing service that
can be used from DOCOMO mobile phones.
FOMA service subscribers are also subscribed to
“WORLD CALL” when they subscribe to the FOMA
service. (This excludes subscribers who declared that
they did not require the service.)

Voice/Videophone Calls

z WORLD CALL can be used to call around 240

countries and regions worldwide.

z The “WORLD CALL” is charged with your monthly

call charges.

z In addition to dialing a phone number, you can

make an international call by adding “+” or
selecting “Int’l call” or “Prefix numbers” from the
function menu in the enter phone number screen,
Redial/Dialed calls screen, Received calls screen
or Phonebook detail screen.

z This service is not available in some payment

plans.

For additional information regarding WORLD
CALL, refer to the contact information provided on
the back of the manual.

“International videophone calls” can be made to
users of some specific overseas 3G mobile
terminals by pressing o (V. phone) to make the
call after using the dialing procedure below.

z See the DOCOMO website for information on

accessible countries and operators.

z Depending on the other party’s terminal, the image

of the other party displayed on your FOMA terminal
may be distorted or the connection may fail when
making a international videophone.

Using dial keys to make international
calls

Dial the number in the following order:

1

010→Country code→ Area code (Long
distance code) →The other party’s
phone number

You can also dial the number in this order:
009130→010 →Country code→ Area code
(Long distance code)→The other party’s phone

number.
If the area code (long distance code) begins with
“0”, omit the first “0”. However, to call to ordinary
phones in Italy, “0” is required.

r

2

The international call is made.

Quick and simple procedures for
making an international call

z You can store the country codes and IDD prefix

codes in “Int’l dial assistance”.

● Using “+” to make an international call

By using the “+” that is automatically replaced with
the “IDD Prefix Code” set in “Auto int’l call set.”, you
can make international calls without dialing the IDD
prefix code.
z As “Auto int’l call set.” in “Int’l dial assistance” is set

to “ON” (automatically added) at the time of
purchase, the FOMA terminal automatically dials
the IDD prefix code.

On the standby screen, dial the

1

following; + (0 (1 second or longer))
→Country code→Area code (Long

distance code) →The other party’s
phone number

If the area code (long distance code) begins with
“0”, omit the first “0”. However, to call to ordinary
phones in Italy, “0” is required.

rX“Dial”

2

The international call is made.

■ To make a call without converting “+” into

the IDD prefix code

X“Original phone No.”

■ To cancel the call

X“Cancel”

54

● Making an international call from the

X

X

X

function menu

You can make an international call by adding a
country code and IDD prefix code from the function
menu.

z You can use the international dial function from the

“Enter phone number screen” and the detail
screens of “Phonebook/Received calls/Dialed calls/
Redial” screens.

<Example: To use the international dial function from
the enter phone number screen>

Enter the phone number of the other

1

party

u (FUNC)

2

country codeXSelect the IDD prefix

“Int’l call”XSelect the

code

The selected country code and IDD prefix code
are added. If the area code (long distance code)
begins with “0”, the first “0” is automatically
deleted (except when “Italy” is selected for the
country code).

r

3

The international call is made.

Making the setting for the
international call

You can set the automatic conversion of “+”, and also
edit and store the country codes and IDD prefix code
for international calls.

i

“settings”X“Dialing”X“Int’l dial

1

assistance”XSelect any item:

Auto int’l call set.……You can set the automatic

conversion of “+” when you make an international
call.

X“ON”XSelect a country codeXSelect an IDD

prefix code

■When you do not convert automatically

X“OFF”

Country Code setting……

Stores up to 22 country names
and country codes used when
you make an international call.
See the DOCOMO website for
information on country codes.

XHighlight an itemXo

(Edit)XEnter the country
nameXEnter the country
code

<Int’l dial assistance>

Country Code setting

Function menu¨P. 55

IDD Prefix setting……Stores

the IDD prefix name and IDD
prefix code used when you
make an international call. Up
to 3 entries can be stored.

XHighlight an item to be

stored or changedXo
(Edit)XEnter the IDD prefix
nameXEnter the IDD prefix
code

IDD Prefix setting

Function menu¨P. 61

Country Code setting screen
(P.55)

Edit……Edits the country code.

Delete……Selects the deleting method from “Delete this/

Delete selected/Delete all”.

Using Hands-free Call during a Call

You can hear the other party’s voice from the speaker
while talking.

In-call screen (P.50)

1

“ ” appears and you can hear other party’s
voice through a speaker during a hands-free
call.

While your terminal is ringing, you can switch to
hands-free operation by pressing o (/

).

Ex. Voice call

■ To cancel the hands-free operation

XPress o ( ) during a hands-free call

“ ” disappears when you make a voice call.
“ ” is changed to “ ” in case of videophone.

<Hands-free>

o ()

Ex. Videophone call

Voice/Videophone Calls

55

● Notes on using the hands-free operation

X

It is recommended to keep a distance of about 30 cm
from the FOMA terminal during a hands-free call. If
the distance is longer or shorter than 30 cm, the other
party may find it difficult to hear you or your voice may
sound differently.

N

z Move to an area where your call will not disturb other

people before switching to a hands-free call.

Voice/Videophone Calls

z When a call is finished, the hands-free setting is

canceled.

Using the Redial/Dialed Calls/ Received Calls Record

<Redial/Dialed calls/Received calls>

Information on dialed or received calls, including the
caller’s phone number and the date and time are
stored in the Redial/Dialed calls/Received calls
record. You can make a call to the other party easily
by using these records.

z When you make calls to the same phone number

repeatedly, the latest entry is stored as the Redial
record and separate entries are stored for the
Dialed calls record.

z The Redial record can hold up to 30 phone

numbers for voice/videophone calls.

z The Dialed calls/Received calls record stores up to

30 voice/videophone call entries and 30 packet
communication or 64K data communication entries.

z If the maximum number of logs is exceeded, logs

are overwritten starting with the oldest one.

<Example: To make a call from the Redial/Received
calls list screen>

On the standby screen

1

(Received calls)

The “Redial screen (list)”/
“Received calls screen (list)”
appears.

■ To check the Dialed

calls

XiX“own data”X “Dialed

calls”
The “Dialed calls screen
(list)” appears.

j (Redial)/h

Ex. Redial (list)

Function menu¨P. 57

Highlight the Redial/Received calls

2

record entry

■ To make a call after

checking the details of
the Redial/Received
calls record

XSelect the Redial/

Received calls record entry
The “Redial screen (detail)”
or “Received calls screen
(detail)” appears.

r (voice call)/o (V. phone)

3

Ex. Redial (detail)

Function menu¨P. 57

● Checking the number of missed calls

■ To confirm only the missed calls from the

Received calls record

XiX“own data”X“Received calls”

Total number of received calls, the number of missed
calls and the number of unconfirmed missed calls
appear.
When you select “Missed calls”, only the missed calls
appears.

■Redial/Dialed calls/Received calls record icons

*1

Icon

//

//

//

//

*2

/

//
/

//

Description

Incoming and outgoing/missed/
unconfirmed missed voice calls

Incoming and outgoing/missed/
unconfirmed missed international
voice calls

Incoming and outgoing/missed/
unconfirmed missed videophone
calls

Incoming and outgoing/missed/
unconfirmed missed international
videophone calls

Incoming and outgoing calls to B
mode for 2in1 setting

Recorded voice record message/
videophone message

Received calls with Chaku-moji

Incoming and outgoing/missed/
unconfirmed missed packet
communication

Incoming and outgoing/missed/
unconfirmed missed 64K data
communication

56

*1

Icon

*1: Some icons look different between the detail screen and

the list screen.

*2: Displayed only when the 2in1 is in Dual mode.

Description

Incoming packet communication or
64K data communication that is
received without external device
connected

Incoming and outgoing calls when
the Time zone is other than
“GMT+09” regardless of the “Auto
time adjust” setting (the summer
time is displayed when you set the
summer time)

N

z If you use 2in1, up to 30 records are stored for each

phone number. Also, when set to Dual mode, up to 30
Redial/Dialed calls/Received calls records for both
phone numbers and total of the 60 records are
displayed.

<Redial/Dialed calls>

z Setting “Restrict dialing” deletes all the Redial/Dialed

calls records.

z If you make a call by selecting Multi Number from the

function menu, the registered name and number of the
additional number are displayed under the phone
number in the Redial screen (detail)/Dialed calls
record screen (detail). If you make a call without using
the function menu, nothing is displayed even when
“Set Multi Number” is set to additional number.

<Received calls>

z When “Missed calls display” in the “Ring time (sec.)” is

set to “Not display” and you receive a call of which ring
tone sounded for shorter time than the time set in the
“Set mute seconds”, the call is not displayed on the
Received calls record.

z If the caller is using “Dial-in”, a number different from

the “Dial-in” number may be displayed.

z When you have subscribed to Multi Number and make

a call from the Received calls record screen, the
phone call is made from the number which received
the call regardless of the “Set Multi Number” setting.

z When you receive a call for additional number of Multi

Number, the registered name of the additional number
are displayed under the phone number in the
Received calls record screen (detail).

z If the same phone number is registered in multiple

phonebooks under different names, names of
phonebooks are displayed in the Received calls
record in the order of reading.

Redial/Dialed calls/Received
calls screen (P.56)

Notify Caller ID*1→P. 5 9

Prefix numbers*1→P. 6 1

Chaku-moji*1→P. 5 8

Int’l call*1→P. 5 5

2in1/Multi Num.*1→When 2in1 is set to ON and Dual

mode, selects from “Number A/Number B/Cancel
number” (P.352) (not available when A mode or B mode is
set).
Selects from “Basic number/Additional number 1/
Additional number 2/Cancel number” (P.349) at the Multi
Number when 2in1 set to OFF.

*2*3

Ring time

with the ringing times.

Add to phonebook→ P. 7 8

Look-up phonebook……“Accessing the phonebook

from the Redial or Dialed Calls record” →P. 8 0

Add desktop icon→ P. 1 0 2

Compose message*4→P. 1 7 0

Compose SMS*4→P. 2 0 2

Sent address

Received address*2……Displays the received address

list.

Select image……Selects the substitute image used

during a videophone call from Chara-den.
Select “Release settings” to cancel the setting.

Big font⇔ Standard font*3……Switches the character

size of the displayed name. →P. 1 0 1

Delete……Selects the deleting method from “Delete this/

Delete selected/Delete all”.

*1: Available only for the detail screen.
*2: Available only for the Received calls screen.
*3: Available only for the list screen.
*4: Available only when 2in1 is in A mode or Dual mode, and

*5: Available only for the Redial/Dialed calls screen.
*6: Not available when 2in1 is in B mode.

……Displays the missed call record entries

*5*6

……Displays the sent address list.

selecting the record screen for the A mode.

N

z Selecting “Compose message” enables you to

compose a mail with a mail address specified as the
address only when the mail address is stored in the
phonebook together with the phone number.

Voice/Videophone Calls

Continued on next page

57

X

X

N

z Selecting “Delete all” from the Redial/Dialed calls

record deletes all the Redial and Dialed calls records.
Note that selecting “Delete this” or “Delete selected”
for the Redial record does not delete the entries of
Dialed calls record, and selecting “Delete this” or
“Delete selected” for the Dialed calls record does not
delete the entries of the Redial record.

Hide all messages……Hides all Chaku-moji

messages.

3D message display……Sets whether to display

Chaku-moji in 3D animation.

Create message list screen
(P.58)

Voice/Videophone Calls

Using Chaku-moji

When making a voice call or videophone call, you can
send a message (Chaku-moji) to the other party to
show the summary of the call, etc. beforehand.

z 5 Chaku-moji messages are stored at the time of

purchase. You can change the pre-installed Chaku­moji messages.

z You can include pictographs or face marks in

Chaku-moji, and you can send a message of up to
10 characters including pictograph/symbol/double­byte character/single-byte character.

z For details on Chaku-moji and the compatible

models, refer to the DOCOMO website or “Mobile
Phone User’s Guide [Network Services]”.

<Chaku-moji>

Editing and setting message

i

“service”X“Chaku-moji”X Select

1

any item:

Create message……Stores

or edits frequently used
Chaku-moji. You can store up
to 30 Chaku-moji (including 5
pre-installed).

XHighlight an item to be

stored or editedXo (Edit)

XEnter the Chaku-moji

Create message list

Function menu¨P. 58

MSG display settings……Sets the Chaku-moji

display setting when you receive a call with Chaku­moji.

Display all messages……Displays all Chaku-

moji messages.

Only number in PH-book……Displays only

the Chaku-moji messages from senders stored
in the phonebook.

Calls with Caller ID……Displays only the

Chaku-moji messages from senders providing
the caller ID.

Edit……Edits Chaku-moji.

Delete……Selects the deleting method from “Delete this/

Delete selected/Delete all”.

N

z You cannot delete the pre-installed Chaku-moji. Even

when you change a pre-installed Chaku-moji and
delete the Chaku-moji, it is restored to the default.

Making a call with a message

You can add Chaku-moji when making a voice or
videophone call from the “Enter phone number
screen” and the detail screen of the “Phonebook” or
“Redial/Dialed calls/Received calls”.

<Example: To make a call with Chaku-moji from the
enter phone number screen>

Enter phone number screen (P.50)

1

(FUNC)X“Chaku-moji”XSelect any
item:

Create message……Enters Chaku-moji. You can

enter up to 10 characters.

Select message……Selects from the stored Chaku-

moji.
You can edit Chaku-moji by pressing o (Edit) on
the message selection screen.

Sent messages……Selects from the previously

sent Chaku-moji. You can edit Chaku-moji by
pressing o (Edit) on the sent message screen.

■ To delete the entered Chaku-moji (to make

a call without Chaku-moji)

Xu (FUNC)X“Chaku-moji”X“Create message”
XClear all the entered Chaku-moji

u

58

r (voice call) /o (V. phone)

2

z The received

Chaku-moji is
displayed in 3D
animation.

Chaku-moji

When the other party’s terminal receives Chaku­moji, the result “Transmission completed” appears.

N

z Sending Chaku-moji is charged. Receiving Chaku-

moji is not charged.

z You can store up to 30 Chaku-moji in the sent

messages record (if you use 2in1, up to 30 sent
messages records when set to each mode, and up to
30 sent messages records for each and total of the 60
records are stored when set to Dual mode). When you
send same Chaku-moji repeatedly, only the latest one
is recorded. When the entries exceed the maximum
number, entries are overwritten from the oldest entry.

z If the receiver’s terminal is under conditions such as

followings, Chaku-moji cannot be sent. In this case, no
sending charges apply.

• The terminal is not compatible with Chaku-moji
(“Transmission failed” appears)

• Chaku-moji does not appear on the screen of the
receiver terminal because of the “MSG display
settings” on the receiver terminal (“Transmission
failed” appears)

• When Public mode (Driving mode) is set

• The ringing time for recording message is set to 0
second.

“”

or the FOMA terminal is turned off.

•

z Depending on the signal status, sending result does

not appear on the sender terminal even when the
receiver terminal receives Chaku-moji. In this case,
sending charges apply.

z You cannot send or receive Chaku-moji when using

the FOMA terminal overseas.

● When you receive a voice or

videophone call with a message

The Chaku-moji appears on the ringing screen. The
Chaku-moji disappears when you answer the call.

Ex. Voice call

N

z Even when you receive a call whose ring tone

sounded for shorter time than the time set in the “Set
mute seconds” of “Ring time (sec.)”, Chaku-moji is
displayed and recorded in the Received calls record.

z Some pictographs are not displayed in 3D animation.
z Depending on the status of the sender or receiver,

Chaku-moji may not be displayed even if you receive a
call with Chaku-moji.

z When the Original lock is set to “Chaku-moji”, Chaku-

moji is not displayed even if you receive a call with
Chaku-moji. In this case, Chaku-moji is stored to the
Received calls record after releasing the lock.

● Displaying messages from the Received

calls record

When you receive Chaku-moji, the “ ” icon
appears on the Received calls record, and you can
check the Chaku-moji message on the “Received
calls screen (detail)”.

N

z Even when you make a call using the Received calls

record, the Chaku-moji in the record is not sent.

Notifying/Withholding Your Caller ID for Individual Calls

Sets whether to display or withhold your phone
number (caller ID) on the other party’s phone
(display) for each call you make.

z Your phone number is very important personal

information, so take adequate care when notifying
the other party.

z The “Notify Caller ID” setting can be set all at once.

→P. 4 8

Adding the “186”/“184” prefix to the
other party’s phone number

To provide your caller ID, add the “186” prefix when
you dial the phone number. To withhold your caller ID,
use the “184” prefix.

Voice/Videophone Calls

Continued on next page

59

■To provide your phone number

X

X

X

X

186− (The other party’s phone number)Xr (voice
call)/o (V. phone)

■To withhold your phone number

184− (The other party’s phone number)Xr (voice
call)/o (V. phone)

Selecting to Notify/Withhold your
caller ID from the function menu

Voice/Videophone Calls

Select Notify/Withhold your caller ID from the function
menu of the detail screen such as “Enter phone
number screen” and “Phonebook/Received calls/
Dialed calls/Redial”.

<Example: To make a voice call from the Enter phone
number screen>

Enter the phone number of the other

1

party

u (FUNC)

2

or “ON”

■ To cancel “Notify Caller ID”

X“Cancel prefix”

When “Cancel prefix” is selected, the “Caller ID
Notification” setting is applied.

r (voice call) /o (V. phone)

3

N

z This function is available only when the other party’s

phone is capable of displaying the caller ID.

z If you hear a message requesting your caller ID, make

a call again after setting your caller ID activated.

z Even if you add “186”/“184” when making an

international call, the setting may be disabled. Select
“Notify Caller ID” from the function menu.

z If you make a call with the “186”/“184” prefix, the

phone number including this prefix is recorded in the
Redial/Dialed calls.

“Notify Caller ID”X“OFF”

Sending Push Signals

<Pause dial>

By sending push signals from the FOMA terminal,
you can use services such as ticket ordering and
bank balance requests.

Storing dialing data as pause dial
record entries

You can store the dialing data used as push signals to
Pause dial beforehand. Inserting p (pause) into the
dialing data allows you to send data with a separation
where a pause lies.
z You can store 1 dialing data, consisting of up to 128

characters.

z You can enter numbers from 0 to 9, the # and *

symbols, and p (pause) for dialing data.

z You cannot enter p (pause) in succession or at the

beginning of the dialing data.

i

“settings”X“Dialing”X“Pause

1

dial”

The “Pause dial screen”
appears.

■ If there is dialing data

already stored

The stored dialing data
appears.

o (Edit)XEnter the dialing data

2

Press 0 to 9, q and w to enter the
dialing data.

■ To enter p (pause)

Xw (1 second or longer)

Pause dial screen (P.60)

Edit……Edits the dialing data.

Send pause dial……Enters the phone number of the

other party and sends the dialing data.
Each time you press r, the dialing data up to p (pause)
is transmitted.

Delete……Deletes the stored dialing data.

Pause dial

Function menu¨P. 60

60

Transmitting the dialing data as a
pause dial

i

“settings”X“Dialing”X“Pause

1

dial”

d (Send)

Dial the phone number of the

X

X

2

destinationXr

The FOMA terminal calls the entered phone
number and displays the dialing data up to the
first p (pause) while the dialed phone is ringing.
p (pause) is not displayed.

r

3

Each time you press r, the dialing data up to
p (pause) is transmitted. Once the FOMA
terminal has finished sending the last number,
the in-call screen reappears.

■ To transmit all the dialing data at once

Xj (1 second or longer)X“Send at one time”

It may not be possible to send all the data at
once to some recipients.

N

z Some phones may be unable to receive push signals.

Using the Prefix Function

You can store the prefix numbers such as IDD prefix
code (WORLD CALL) and 186/184 for notifying/
withholding your caller ID beforehand and add these
prefix numbers when you make calls.

Prefix setting screen (P.61)/IDD
Prefix setting screen (P.55)

Edit……Edits the prefix number or IDD prefix code.

Delete this*1……Deletes one prefix number.

Delete*2……Deletes one IDD prefix code.

Delete all……Deletes all prefix numbers or IDD prefix

code.

*1: Available only with the Prefix setting screen.
*2: Available only with the IDD prefix setting screen.

Making a call with the Prefix numbers

z You can add the prefix numbers from the “Enter

phone number screen” and the detail screens of
“Phonebook/Received calls/Dialed calls/Redial”
screens.

<Example: To make a voice call by adding prefix
numbers from the enter phone number screen>

Enter the phone number of the other

1

party

u (FUNC)

2

the stored name

“Prefix numbers”XSelect

<Prefix numbers>

r

Voice/Videophone Calls

Storing the prefix numbers

z You can store up to 7 prefix numbers.
z You can enter numbers from 0 to 9 and the #, *

and + symbols.

iX“settings”X“Dialing”X“Prefix

1

setting”

The “Prefix setting screen”
appears.

Highlight the item to

2

store or changeXo

(Edit)

Enter the name to be

3

stored

You can enter up to 8 double-byte or 16 single­byte characters.

Enter the numbers (prefix)

4

You can enter up to 10 digits.

<Prefix setting>

Prefix setting

Function menu¨P. 6 1

Setting Sub-addresses When Making Calls

You can set whether to specify “*” in the phone
number as a separator so that the numbers following
“*” are recognized as a sub-address (ON/OFF).

z Sub-addresses are used in ISDN to identify calls

made from specific communications devices and to
select content in “V-live”.

iX“settings”X“Dialing”X“Sub-

1

address setting”X“ON” or “OFF”

N

z In the following cases, “*” does not function as a sub-

address separator. The entered number including “*”
is recognized as an ordinary phone number:

• When the “*” is entered at the beginning of a

phone number

• When “*” immediately follows “186”/“184” at the

beginning of a phone number

• When “*” immediately follows a number entered

using “Prefix numbers”

• When the phone number contains “*590#/*591#/
*592#”

<Sub-address setting>

61

Setting the Alarm Used for

X

Reconnection

When the signal quality deteriorates during a voice/
videophone call and the call drops out, the FOMA
terminal will automatically reconnect the call if the
signal quality quickly improves. Set the type of alarm
when a call is reconnected for this function.

z The interval for reconnection varies depending on

Voice/Videophone Calls

communication conditions or the signal quality. It
takes about 10 seconds.

i

“settings”X“Talk”X“Reconnect

1

signal”XSelect an alarm tone

Select from “No tone/High tone/Low tone”.

N

z Call charges apply in the interval (up to about 10

seconds) for reconnection.

<Reconnect signal>

N

z When the hands-free device is set to emit the sound

from the hands-free device, the ring tone still sound
through the hands-free device even when the FOMA
terminal is set to Manner mode or the ring volume is
set to “Silent”.

z When the Public mode (Driving mode) is set,

operation for incoming calls and messages is as
specified in the “Public mode (Driving mode)” settings.

z When the Record message is set, operation for

incoming calls is as specified in the “Record message”
settings.

z When the hands-free device is set to emit the sound

from the FOMA terminal, operation when the FOMA
terminal is folded during a call is as specified in
“Setting when folded”. When the hands-free device is
set to emit sound from the hands-free device, folding
the FOMA terminal does not affect the call status
regardless of the “Setting when folded” setting.

Blocking Out Ambient Noise

<Noise reduction>

This function suppresses ambient noise and makes it
easier for the other party in a voice or videophone call
to hear you.

iX“settings”X“Talk”X“Noise

1

reduction”X“ON” or “OFF”

Making Hands-free Calls in the Car

You can make or receive voice calls with hands-free
compatible devices by connecting the FOMA terminal
to hands-free compatible devices such as the In-Car
Hands-Free Kit 01 (optional) or a car navigation
system.
For information on how to use the hands-free device,
refer to the manual provided with the device. The
FOMA In-Car Hands-Free Cable 01 (optional) is
required to use the In-Car Hands-Free Kit 01
(optional).

N

z To operate from the hands-free device, set the USB

mode to “Communication mode”.

z The display and ring tones used for incoming calls and

mail are as specified in the FOMA terminal settings.

<In-car Hands-free>

Receiving a Voice/ Videophone Call

* As FOMA N706i is not equipped with the front

camera, during a videophone call, you can send
only the substitute image (Chara-den) or image
from the rear camera to the other party.
You can change the substitute image (Chara­den) to other data such as an image of My picture
in “Select image”.→P. 7 1

Voice/Videophone call is received

1

The ring tone sounds and the incoming call
animation is displayed in “My Signal”. The
“Ringing screen”/“Videophone ringing screen”
appears.

■ When you receive a call with Chaku-moji

The Chaku-moji appears on the ringing screen/
videophone ringing screen. → P. 5 9

Ringing

Function menu¨P.63 Function menu¨P. 63

Videophone ringing

62

■ To put a voice/videophone call on hold
while the FOMA terminal is ringing →P. 6 5

r

2

The “In-call screen”/“Videophone in-call screen”
appears.

■ Operations during a videophone call

You can perform various operations during a
videophone call such as switching between the
substitute image and the camera image and
muting the sound. →P. 5 0

■ When the other party switches a voice/
videophone call during a call →P. 6 3

■ To put the current voice/videophone call
on hold→ P. 6 5

To end the call, press y

3

Display while receiving a call

■When the other par ty’s phone number is

notified

The other party’s phone number appears on the
screen. When the caller is stored in the
phonebook, the name stored in the phonebook
appears (only the name is displayed while
Keypad lock is set).→P.76

z If the same phone number is registered in the

multiple phonebook entries with different
names, the first name retrieved by the
phonebook search in the order of reading
appears.→ P. 7 9

z If the caller is stored as secret data, the name

or other information does not appear and only
the phone number appears.

z When you receive a call for additional number

of Multi Number, the registered name of the
additional number is displayed on the ringing
screen.

■When the other par ty’s phone number is

not notified

The reason of not notifying appears.

Ringing screen/Videophone
ringing screen (P.62)

Call Rejection……Terminates the receiving call without

answering.

Call Forwarding……Forwards the call.

The call is forwarded regardless of the “Call Forwarding”
setting “Activate/Deactivate”.

Voice Mail……Connects the call to the voice mail service

center.
The call is connected to the voice mail service center
regardless of the “Voice Mail” setting “Activate/
Deactivate”.

Change Display……Switches the display from additional

number 1 or 2 to the number from which the call is
forwarded. This can be selected when receiving multi
number call (for additional number 1 or 2) and the call is
forwarded at the same time.

N

z You can receive a call using a flat-plug earphone/

microphone with switch (optional).→P. 3 2 5

z If you have subscribed to the Call waiting, Voice mail

or Call forwarding service, activate “Set in-call arrival”
and set “Incoming Call Mng” to “Answer”, you will hear
a short double-beep (“bibip”) when you receive a call
when you are already on a call.

• If you subscribe to the Voice mail or Call forwarding
service, you can answer the call by ending the
current call.

• If you subscribe to the Call waiting service, you can
answer the voice call by putting the current call on
hold and you can answer the videophone call by
ending the current call.

z You can set the incoming call management from the

caller who is not stored in the phonebook.
→P. 1 2 4

z You can set the incoming call restriction for each

phone number stored in the phonebook.→P. 1 2 2

<Videophone>

z It may take a few seconds to switch from a camera

image to a substitute image (Chara-den) depending
on the Chara-den.

When the Other Party Switches a Voice/Videophone Call (Caller)

When you receive a voice/videophone call, the other
party can switch the call between voice call and
videophone call.

z The receiver cannot switch a voice call to a

videophone call.

z To switch the call, the receiver needs to set “Ntfy

switch-mode” to notify the switch beforehand.
→P. 7 2

z You can use this function with the terminals

compatible with voice call/videophone call switch.

Voice/Videophone Calls

Continued on next page

63

<Example: When the other party switched a voice call

X

X

X

X

to a videophone call>

In-call screen (P.50)XThe other party

1

switches to a videophone call

While switching, the screen which indicates that
the calls are being switched appears and the
voice guidance is played.
When the voice call is switched to the
videophone call, the substitute image is sent to

Voice/Videophone Calls

the other party.

■ When the other party switched a

videophone call to a voice call

XVideophone in-call screen (P.50)XThe other

party switches to a voice call
The videophone call is switched to the voice call.

Using the Dial Keys to Answer a Call

You can use this setting to turn off the ring tone or
answer the phone quickly when you receive a call.

i

“settings”X“Incoming call”

1

“Answer setting”XSelect any item:

Any key answer……Valid for voice calls. You can

answer the call by pressing any of the following keys.

r, d (Answer) , 0 to 9, w, t, o, p,
a (マナー ), b

* For videophone calls, you can answer the call only by

ordinary key operations (r, d (Subst.)).

<Answer setting>

Quick silent ……Pressing any of the following keys

or opening the FOMA terminal stops the ring tone
while the caller continues to hear the ring tone.
0 to 9, w, t, b, p, a (マナー ) or o
(for voice calls only)
To answer the call, press

OFF……You can answer the call only with r, d

(Answer/Subst.).

r, d (Answer/Subst.).

N

z Even when “Quick silent” is set, the “Any key answer”

function is used in Manner mode.

z When “Any key answer” is set and you press a (マ

ナー) during the FOMA terminal folded, a voice call is

put on hold. In this time, the other party hears the hold
tone when “Setting when folded” set to “Tone on”, but
the other party does not hear the hold tone when “No
tone” or “End the call” is set.

Ending/Holding Calls with the FOMA Terminal Folded

<Setting when folded>

You can set how your FOMA terminal operates when
it is folded during a voice or videophone call.

i

“settings”X“Talk”X“Setting when

1

folded”

No tone……Mutes the sound. The other party does

not hear the hold tone.

Tone on……Puts a call on hold (holding). When the

FOMA terminal is folded, the other party hears the
hold tone set in “Set hold tone”. For videophone
calls, the image for holding is sent to the other party.

End the call……Ends the call. It is the same

operation as pressing y .

N

z When Manner mode is set, no sound is played

through the speaker even if “Speaker ON” is set.
When a flat-plug earphone/microphone with switch

z

(optional) is connected, this function is disabled.

z Even if the “Tone on” setting is selected, folding the

FOMA terminal activates the “No tone” setting if “Call
Waiting” is switched on.

Select any item:

Speaker ON……The hold tone is sent to the

other party and also plays through the speaker.

Speaker OFF……Only the other party hears

the hold tone.

64

Adjusting the Earpiece

X

X

X

X

X

Volum e

On the standby screen

1

or longer)

■ To adjust the earpiece volume during a

call

During a voice call: c (1 second or longer)
During a videophone call: c

• You can also adjust with a ( マナー )/s

(MUSIC).

N

z If you adjust the volume during a call, the adjusted

setting is retained after you end the call.

Adjust the volume with c

Pressing c (1 second or
longer) displays the
earpiece volume screen. If
no operation is conducted
for 2 seconds or longer
when the earpiece volume
screen is displayed, the
earpiece volume screen is
expired.
You can adjust the volume in
6 steps from “Level 1”
(quietest) to “Level 6”
(loudest).

<Volume>

c (1 second

Adjusting the Ring Volume

<Ring volume>

You can adjust the volume of the ring tone for a
incoming call, mail, chat mail or MessageR/F in 6
steps for each type of call. You can also set to silent
or to gradually get louder.

i

“settings”X“Incoming call”

1

“Ring volume”XSelect an item to
adjust its volume

Select “Phone” to adjust the ring tone volume for
voice calls and 64K data communication.
Select “Mail” to adjust the ring tone volume for
i-mode mail, Area Mail, SMS or packet
communication.

Use c to adjust the ring volumeXd

2

(Set)

■ To raise the volume gradually

XPress f in “Level 6”

When set to “Step”, the ring volume becomes
louder and louder in every 3 seconds.

■ To set to silent

XPress g in “Level 1”

An icon appears in the standby screen to
confirm that a “Silent” ring tone is set.

: “Phone” or “Videophone” is set to “Silent”
: “Silent” is set for “Mail”, “Chat mail”,

“MessageR” and/or “MessageF”.

: Both “ ” and “ ” are set.

N

z The ring volume setting specified for “Phone” in this

function is also applied to the “Select ring tone” setting
for a voice call, the alarm tones for “Schedule” and “To
Do list”.

Holding the Ringing/Current Call

<Example: To put the ringing call on hold>

While ringing

1

■ To put the current call on hold

XDuring a callXt

■ To end the call during answer hold/

holding

Xy

Press r to resume the call

2

You can also use t to cancel holding when
you put the current call on hold.

N

z Call charges apply while putting the ringing call or

current call on hold.

Setting the hold tone

You can set the guidance messages to the other
party during the answer hold.

z You cannot change the hold tone that is played

during a call.

<Answer hold/Holding>

y

The FOMA terminal makes
three rapid beeps and puts
the call on hold.
The caller hears a message
saying that you cannot
answer at the moment and
the call is held without
hanging up.

<Set hold tone>

Continued on next page

Voice/Videophone Calls

65

iX“settings”X“Talk”X“Set hold

X

1

tone”X“On hold tone” XSelect the
hold tone

Select from “Tone 1/Tone 2/Voice announce 1*/
Voice announce 2

* : Not available when no Voice announce is recorded.

*

”.

Using the Public Mode

Voice/Videophone Calls

(Driving Mode)

The Public mode is an automatic answering service
provided to keep manner in public circumstances.
During Public mode, a caller hears a message that
you cannot answer the call because you are driving or
you are in the place you have to refrain from calling
(on the train or bus, in the theater, etc.), then the call
ends.

z Public mode can only be set/released from the

standby screen. (It can also be set/released when
the “ ” icon is displayed.)

z You can still make calls when the FOMA terminal is

in Public mode.

z This function is not available during data

communication.

z When you receive a call of “User unset” while

Caller ID Request is set to “Activate”, caller ID
request message is announced. (The Public mode
message is not announced.)

On the standby screen

1

or longer)

■ To release the Public mode (Driving mode)

XOn the standby screenXw (1 second or

longer)
Public mode is canceled and “ ” disappears.

N

z The Public mode setting takes priority when “Record

message” is “ON”.

z The Public mode setting takes priority when Manner

mode is set at the same time.

z If you make a voice call to an emergency number

(110, 119 or 118) while Public mode is set, Public
mode is released.

66

<Public mode (Driving mode)>

w (1 second

Public mode is set and “ ”
appears.
When you receive a call, the
caller hears the message “I
can’t answer the call
because I am driving or I
have to refrain from calling
now. Please call back later.”

N

z The following tones do not sound in Public mode:

• Ring tone for voice/videophone call

• Ring tone for mail or message

• Alarm tone

• Wake-up tone

• Charge sound

• Software tone for i-αppli

• Ring tone for packet communication/64k data
communication

● When Public mode (Driving mode) is set

The FOMA terminal does not ring when you receive a
voice or videophone call. Calls are logged in the
“Received calls” record as “Missed calls” record, and
the “Missed call” desktop icon appears on the
standby screen.
z A caller making a voice call hears a message that

you cannot answer the call because you are driving
or you are in the place you have to refrain from
using mobile phones, then the call ends.

z A caller making a videophone call sees the Public

mode video message on his or her display, then the
call ends.

z If the FOMA terminal is set to Public mode (Driving

mode) while network services are activated, voice
calls and videophone calls are handled as shown in
the Tab le 1 (P.67).

z When you receive a mail, the ring tone does not

sound and the “New mail” desktop icon appears on
the standby screen.

N

z If the power is off or “ ” is displayed, the message

for “ ” is announced instead of the Public mode
message even when Public mode is set.

Using the Public Mode (Power OFF)

The Public mode (Power OFF) is an automatic
answering service provided to keep manner in public
circumstances. During Public mode (Power OFF), a
caller who made a call while the FOMA terminal is
turned off hears a message that you cannot answer
the call because you are in the place you have to turn
off the mobile phone (in the hospital, on the airplane,
around the priority seat on the train, etc.), then the
call ends.

<Public mode (Power OFF)>

On the standby screen

X

XdX

1

251Xr

Public mode (Power OFF) is set. (Nothing
changes on the standby screen.)
When you receive a call after setting Public
mode (Power OFF) and turning off the FOMA
terminal, the caller hears the message “The
person you are calling is in an area where cell
phone should not be used. Please call back
later.”

■ To cancel the Public mode (Power OFF)

XOn the standby screenXw252

50Xr

■ To check Public mode (Power OFF) setting

XOn the standby screenXw252

59Xr

w25

● When Public mode (Power OFF) is set

The setting is valid until “*25250” is dialed to release
the Public mode (Power OFF). The setting is not
canceled only by turning on the FOMA terminal.
The Public mode (Power OFF) message is
announced even when you are in an out-of-service
area or where the reception is very poor.

z A caller making a voice call hears a message that

you cannot answer the call because you are in the
place you have to turn off the mobile phone, then
the call ends.

z A caller making a videophone call sees the Public

mode (Power OFF) video message on his or her
display, then the call ends.

z If the FOMA terminal is set to Public mode (Power

OFF) while network services are activated, voice
calls and videophone calls are handled as shown in
the Ta bl e1 (P.67).

When You Cannot Answer a Received Call

When you cannot answer a received call, the
appears on the standby screen. When you select ,
you can check the date, time and the caller ID about
the call.

z “Icons providing information”→ P.102

On the standby screen

1

“”

The Missed calls list screen appears.

<Missed call>

Select

[Table 1] Handling of received calls when network services and Public mode (Driving mode/
Power OFF) are set

Service When a voice call is received When a videophone call is received

Voice Mail
Service

Call
Forwarding
Service

Nuisance
Call Blocking

Caller ID
Request

* : If the ring time is set to 0 second, the Public mode message is not announced and the “Voice Mail Service” or “Call

Forwarding Service” is applied. In addition, they are not recorded in the “Received calls” record and “Missed call”
desktop icon does not appear.

• Connects to the Voice mail service center after
announcing the Public mode message.

• Transfers the call to the forwarding number
after announcing the Public mode message.

• The Public mode message is announced or
not depending on the setting of the call
forwarding service.

• Ends the call after showing the message that
the connection could not be established for the
barred callers.

• Ends the call after announcing the Public
mode message for other callers.

• Ends the call after announcing the caller ID
request message for the callers who do not
provide the caller ID.

• Ends the call after announcing the Public
mode message for the callers who provide the
caller ID.

*

• Connects to the Voice mail service center
without showing the Public mode video
message.

• Transfers the videophone call to the forwarding

*

number without showing the Public mode video
message.

• The connection is not established when the
videophone for the forwarding number is not
compatible with 3G-324M.

• Ends the call after showing the video message
that the connection could not be established for
the barred callers.

• Ends the call after showing the Public mode
video message for other callers.

• Ends the call after showing the caller ID request
video message for the callers who do not
provide the caller ID.

• Ends the call after showing the Public mode
video message for the callers who provide the
caller ID.

Voice/Videophone Calls

67

To check the information with the

X

X

FOMA terminal folded

When there is a missed call, new mail (i-mode mail,
Area Mail and SMS)or new chat mail, the incoming
call lamp keeps on flashing. When you press s
(MUSIC), you can confirm the caller or sender in the
voice.

Press s (MUSIC) with the FOMA

1

Voice/Videophone Calls

terminal folded

Notify it with a voice according to the setting of
“Info notice setting”.

● Flashing of the Incoming call lamp

When there is a missed call, new mail or new chat
mail, the incoming call lamp keeps on flashing in its
set color.

• Phone/Videophone: Color set for “Phone”

• New mail/Area Mail: Color set for “Mail”

• New chat mail: Color set for “Chat mail”

* When there is new mail and new chat mail, the lamp

lights up in the each color set.

■Flashing color and conditions

• The lamp does not flash when the Missed info of
“Illumination” is set to “OFF”.

• The lamp does not flash when the Missed info of
“My Signal settings” is set to “ON”.

• The lamp flashes in the default color when
Gradation is set in “Illumination”.

• You can set the specified color for the caller/sender
in the phonebook.→ P. 8 3

• The lamp does not flash in Public mode (Driving
mode).

■To turn off the lamp

• Selects the icon for “Missed call”, “New mail” or
“Chat mail” in the display or push t (1 second or
longer) to check the description.

Setting the Notification Method for
Missed Calls

You can set the notification method when s (MUSIC)
is pressed.

z The notification method for details on each setting

item is as follows:

When there is a missed

Item

call, new mail, etc.

ON “Bibip, bibip” tone. “Bibip” tone.

OFF The Confirmation Tone does not sound.

<Info notice setting>

When there is no missed

call, new mail, etc.

i

“settings”X“Incoming call”

1

“Info notice setting”X“ON” or “OFF”

■ When ボイス(Voice) is selected

If you set “日本語 ” (Japanese) in the setting of
“Select language”, you can select “電子音 ”
(electronic sound), “ボイス ” (voice) and “OFF”.
You can set the voice to read out (ON) the name
or not (OFF) when the caller is stored in the
phonebook or when the recording of the
message.

N

z This function aler ts you using a “YES” indication when

the “Missed call”, “New mail”, “Chat mail”, etc. desktop
icon is displayed on the standby screen. →P. 1 0 2

z You cannot use s (MUSIC) to check for missed calls

or new mail in the following cases:

• When Side key guard is set to “ON”

• When playing music with the Music player/
Music&Video Channel

z The volume set in the “Phone” in the “Ring volume”

setting is used (if “Phone” is set to “Silent” or “Step”,
the volume is set to “Level 2”).

z Opening the FOMA terminal during the notification

stops the notification.

z Choose between ON/OFF when the language setting

is set to English.

z If the reading of caller’s name is not stored in the

phonebook or the name stored in the phonebook is
not displayed, the caller’s name is not read out even
when “名前通知 ” (name notification) of “ボイス ”
(voice) is set to “ON” in Japanese language mode.

Having the Caller Leave a Message

When you cannot answer a voice or videophone call,
this function allows you to record a message from the
caller on your FOMA terminal.
z The voice call can record 5 messages up to 20

seconds, and the videophone call can record 2
messages up to 20 seconds for each 1 case.

Setting Record message

iX“settings”X“Incoming call”X

1

“Record message”XSelect any item:

ON……Select the desired type of answer message

from “Japanese 1/Japanese 2/English/Voice
announce 1*/Voice announce 2*”, then set the record
message.

OFF……Cancels the Record message setting.

<Record message>

68

* : Not available when no Voice announce is recorded.

X

Enter the ringing time (000 to 120

2

seconds in 3 digits)

The record message is set and “ ” and “ ”
appear on the standby screen.

N

z To give priority to “Record message” function when

“Voice Mail”, “Call Forwarding” and “Record message”
are set at the same time, set the ringing time of
Record message shorter than that of Voice mail and
Call forwarding.

z If the mute time set in “Ring time (sec.)” is longer than

the ringing time set for the Record message function,
the FOMA terminal switches directly to Record
message without ringing first. To have the FOMA
terminal ring before it records a message, make sure
that the ringing time for Record message is longer
than the mute time.

z You can use “Ring tone/Image” (for each phonebook

entry) to set an answer message for each phone
number and “Ring tone/Image” (for the phonebook
group) to set an answer message for each group.

■When message recording ends

to : Recorded voice messages (1 to 5)

/ : Recorded videophone messages (1 or 2)

zThe original screen

reappears and the “Missed
call” desktop icon and
“Record message” desktop
icon appear on the standby
screen. You can check the
contents by selecting the one
of the desktop icons.→P. 7 0

zNumber of recordings are

displayed with icons on the
icon display area at the top of
the screen.

N

z When Manner mode is set, you cannot hear the

caller’s voice during a message recording.

z You cannot answer another call while recording a

message.

Voice/Videophone Calls

When you receive a call with “Record
message” set to “ON”

The record message activates when the set time is
elapsed.

z To the caller of a voice call, the answer message is

played and the recording starts.

z To the caller of a videophone call, the “Preparing”

image is sent and the answer message is played,
then the “Recording” image is sent and the
recording starts.

■When message recording starts

z The recording screen appears. The caller’s voice

can be heard through the FOMA terminal earpiece
during message recording.

■To answer the voice call/

videophone call while
recording

Xr

Ex. Voice call

Having Callers Leave a Message during an Incoming Call

Even when the “Record message” function is not set
to “ON”, you can record messages while receiving a
call by pressing a key.

While ringing

1

The recording of the message starts.

■ To set the FOMA terminal to Manner mode

at the same time recording is started

XWhile ringingXq

N

z You cannot set “Record message” to “ON” with this

operation.

z When you receive a voice or videophone call when the

messages are full, the record message is not
activated and the FOMA terminal keeps on ringing
(when q is pressed, the ringing continues at the
setting of “Manner mode set”).

<Quick message>

s (MUSIC)

69

Playing/Erasing Recorded

XdX

Messages and Voice Memos

z When there is a recorded message which has not

been played, “ ” (for a recorded message) or
“ ” (for a recorded video message) appears on
the standby screen.

<Example: To check the recorded message which

Voice/Videophone Calls

has not been played>

On the standby screen

1

“ ” (for a recorded message) or “ ”
(for a recorded video message)

The “Play/Erase msg.
screen” or “Play/Erase VP
msg. screen” appears.
“★ ” appears for the
recorded item.

■ To play the recorded

message with the menu
operation

XiX“lifekit”X“Play/Erase. msg.” (voice) or

“Play/Erase. VP msg.”

Select the item to play

2

<Record message/Voice memo>

The FOMA terminal beeps and playback
begins. When the playback ends, the FOMA
terminal gives 2 short beeps and the “Play/
Erase msg. screen” reappears.
You can also play the messages by pressing Ss
(MUSIC) on the standby screen.

■ To play the next message while playing

a message

XSs (MUSIC)

Each time you press Ss (MUSIC), the recorded
messages are played from the newest one.
Voice memos are played last.

■ To stop the playback

XDd (Stop) or Rt

The “Play/Erase msg. screen” reappears.

Select

Play/Erase msg.

Function menu¨P. 70

<Record Videophone message>

The playback starts. When the playback ends,
the “Play/Erase VP msg. screen” reappears.

■ To play another message while playing a

message

XFv

■ To adjust volume while playing a

message

XFc

■ To switch ON/OFF of the speaker while

playing a message

XFu (FUNC)X“Speaker ON” or “Speaker

OFF”

■ To pause the playback

XDd (Stop)

To resume playback, press Dd (Play).

■ To stop the playback

XRt

The “Play/Erase VP msg. screen” reappears.

■ To make a voice/videophone call to the

phone number displayed while playing a
message

Xr (voice call) /o (V. phone)

■ To erase the playing message

Xu (FUNC)X“Erase”X“YES”

N

z When 2in1 is in A mode or B mode, “★” does not

appear for the recorded message recorded in the
unused phone number. When set to “Dual mode”, “★”

appears for the recorded message recorded in the
both phone numbers.

Play/Erase msg. screen (voice/
video) (P.70)

Play……Plays the message.

Delete this……Erases one recorded message or voice

memo.

Delete rec. msg.*……Erases all the recorded messages.

Voice memos are not erased.

Delete all……Erases all the recorded messages and

voice memos.

* : Available only with the Play/Erase msg. screen.

70

Using Chara-den

X

X

This function sends a cartoon character instead of
your own image when you make a videophone call.
“What is Chara-den?”→P.260

z You can display your favorite Chara-den if you set

“Substitute image” of “Select image” to “Chara-den”
beforehand.
You can also use Chara-den by setting Chara-den
in the phonebook or Ring tone/Image function.

While sending a substitute image

1

(Chara-den) during a videophone call

Control your Chara-den by pressing

the dial keys

Chara-den

Pressing a dial key makes the character perform
the action assigned to that key.
“Using Chara-den characters”→ P.260

Setting Functions for the Videophone

iX“settings”X“Videophone”

1

The “Videophone settings
screen” appears.

Select any item:

2

Visual preference……Selects the image quality of

videophone calls from “Normal/Prefer img qual/
Prefer motion spd”.

Select image→ P. 7 1

Auto redial as voice……Sets whether to switch to a

voice call when a videophone call cannot be made
(ON/OFF).

Display setting

Videophone settings

Main display……Selects the image displayed

on the main display from “Other side/My side”.

Ntfy switch-mode→P. 7 2

Hands-free switch……Sets whether to switch to

Hands-free automatically when starting a
videophone call (ON/OFF).

V-phone while packet →P. 7 2

Setting the image sent during
videophone calls

z You can set a JPEG image whose file size is 100K

bytes or less and not larger than 854 dots wide ×
854 dots high, or a GIF image whose file size is
100K bytes or less and not larger than 854 dots
wide × 480 dots high or 480 dots wide × 854 dots
high (except for the files with restrictions).

Videophone settings screen (P.71)

1

“Select image”XSelect any item:

On hold……Sets the image sent for a call on

answer hold.

Holding……Sets the image sent while holding a

call.

Substitute image……Sets the image sent as a

substitute image.

Record message……You can set the image sent

while recording videophone messages.

Preparing……You can set the image sent while

preparing for recording videophone messages.

Voice memo……Sets the image sent while

recording the voice memo.

Select the image to be sent:

2

Pre-installed……Sends only a message.

Original……Sends an image and a message.

To change the image, select an image from My
picture from “Change setting” of the function menu.

Chara-den*……Sends the image selected in

“Substitute image”.
Function menu of Chara-den list screen →P.261
Priority order for Chara-den setting→ P. 7 8

To change the Chara-den, select a Chara-den from
Chara-den list from “Change setting” of the function
menu.

* : Available only when “Substitute image” is selected.

<Select image>

Voice/Videophone Calls

71

Setting for Switching between Voice

X

Call and Videophone Call

You can set whether to notify the other party that your
FOMA terminal supports the switch between a voice
call and a videophone call.

z The other party cannot switch the call when set to

“Indication OFF”.

z You cannot set this function during a call or while

Voice/Videophone Calls

“ ” appears.

Videophone settings screen (P.71) X

1

“Ntfy switch-mode”XSelect any item:

Indication ON・Indication OFF……Activates or

deactivates the Ntfy switch-mode.

Check Indication……Displays the “Ntfy switch-

mode” setting.

<Ntfy switch-mode>

Setting the answer mode when you
receive a videophone call during
i-mode

z As the multi access function cannot be used for

videophone, incoming videophone calls during
i-mode communication or while sending or
receiving mails are handled according to this
setting.→P.391

Videophone settings screen (P.71)

1

“V-phone while packet”XSelect any
item:

V-phone priority……Switches to the videophone

ringing screen. When you answer the incoming
videophone, i-mode communication is disconnected.

Packet downld priority……Rejects the incoming

videophone call.

V-phone answerphone……If you have subscribed

to the “Voice Mail Service”, the videophone call is
connected to the Voice Mail service center
regardless of “Activate/Deactivate” setting of Voice
Mail. When you have not subscribed to this service,
“Packet downld priority” is activated.

Call forwarding……If you have subscribed to the

Call Forwarding Service, the videophone call is
forwarded regardless of “Activate/Deactivate” setting
of “Call Forwarding”. When you have not subscribed
to this service, “Packet downld priority” is activated.

<V-phone while packet>

N

<Visual preference>

z If the signal quality deteriorates during a videophone

call, the image may become grainy or patchy
regardless of the settings in “Visual preference”.

<Select image>

z If you delete the original still image, the “pre-installed”

image is displayed (sent).

z When the Chara-den character set as the substitute

image is deleted and the “Chara-den” substitute
image cannot be displayed, the pre-installed “ビーン

ズ (Beans)” is sent. If you delete the pre-installed “
ビーンズ (Beans)”, the “Pre-installed” substitute still

image is sent.

<Auto redial as voice>

z When a videophone call is switched and redialed as a

voice call, the call is charged as a voice call and digital
communication charges are not applied.

z When a call is redialed, only the voice call records are

logged in the “Redial/Dialed calls” record.

z Even if “Auto redial as voice” is set to “ON”, it may not

be possible to redial due to the conditions of the
network or the other party, such as busy.

<Hands-free switch>

z The FOMA terminal does not switch to hands-free

mode automatically in the following cases even when
“Hands-free switch” is set to “ON”:

• While Manner mode is set

• When a flat-plug earphone/microphone with switch
(optional) is connected (however, the microphone
operation follows the “Select microphone” setting)

• When holding a call or Record message is activated
for the incoming call

<V-phone while packet>

z Even when set to “V-phone priority”, you cannot

answer the videophone call if you are using multi
access such as using the i-mode communication
during a voice call.

z When set to “Packet downld priority”, “V-phone

answerphone” or “Call forwarding”, the received
videophone calls are recorded as “Missed calls” in the
“Received calls”.

z Even when set to “V-phone priority” or “Packet downld

priority”, “Voice Mail” or “Call Forwarding” service is
activated if the ring time for the “Voice Mail” or “Call
Forwarding” service is set to 0 second.

72

Using the Videophone Connecting to External Devices

You can make or receive videophone calls from
external devices such as the PC by connecting them
to the FOMA terminal with the FOMA USB Cable with
Charge Function 01/02 (optional).
To use this function, you have to install a videophone
application on the dedicated external device or PC
and prepare commercially available devices such as
an earphone/microphone and USB compatible Web
camera.

z Set the USB mode setting to “Communication

mode”. There is no specific settings for connecting
external devices.

z For details on the operational environment,

settings, operations of the videophone application,
refer to the manuals supplied with the external
terminals.

z “ドコモテレビ電話ソフト (DOCOMO Videophone

Software)” (only in Japanese) is available as the
application which is compatible with this function.
You can download the Software from the website of
DOCOMO Videophone Software (only in
Japanese).
(For details of the PC operating environment, etc.,
refer to the support website.)

[http://videophonesoft.nttdocomo.co.jp/] (Only in
Japanese)

N

z You cannot make a videophone call from the external

device during a voice call.

z When you have subscribed to either of the Call

Waiting service, Voice Mail Service or Call Forwarding
and you receive a videophone call from an external
device during a voice call, you can answer the call
after ending the current call. When you receive a voice
call, videophone call or 64K data communication
during a videophone call from the external device, you
can answer these calls in the same way.

Voice/Videophone Calls

Base station

FOMA videophone
Connection speed: 64K

FOMA

network

73

Phonebook

Phonebooks Available with the FOMA Terminal ............................................................. 76

Adding Information to the Phonebook .................................................. 76

Adding Phonebook Entries from the Redial, Dialed Calls and Other Records ............... 78

Renaming Groups....................................................................................... 78

Making a Call from the Phonebook..................................................... 79

Editing the Phonebook............................................................................. 82

Deleting a Phonebook Entry.......................................................................... 82

Checking the Phonebook Storage Status............................................. 82

Setting Different FOMA Terminal Actions for Each Phone Number and Mail Address

........................................................................................................................ 82

Using Choku-Den .......................................................................................... 84

Using Dialing Shortcuts ........................................................................ 85

Storing the Phonebook at the Data Security Center............................ 85

Add to phonebook

Group setting

Search phonebook

Edit phonebook

Delete data

No. of phonebook

Ring tone/Image

Choku-Den

Two-touch dialing

Data security serv.

75

Phonebooks Available with the FOMA Terminal

Your FOMA terminal contains two phonebooks. One
is the phonebook in the FOMA terminal (Phone) itself,
for which you can set a range of functions, and the
other is the UIM phonebook, which can also be used
in other FOMA terminals. Each phonebook can be
used differently depending on the purpose.

Differences between the FOMA

Phonebook

terminal (Phone) phonebook and UIM
phonebook

■Data stored

Data

stored

Number
of entries

Group No Group, Group 01 to 19No Group,

Phone
number
storage

E-mail
address
storage

storage

Other
data
storage

■Features of the FOMA terminal (Phone)

phonebook

The following utility functions can be used with entries
stored in the FOMA terminal (Phone) phonebook:

• “Choku-Den” →P. 8 4

• “Two-touch dialing”→ P. 8 5

• “Ring tone/Image” →P. 8 2

• “Restrictions”→ P.122

• Storing as secret data→ P.113

• Secret code setting→ P. 8 1

FOMA terminal

(Phone) phonebook

Up to 1,000 entries Up to 50 entries

4 numbers per entry
(4,000 numbers in total
in the phonebook)

You can select from 23
icons

3 addresses per entry
(3,000 addresses in
total in the phonebook)

You can select from 5
icons

1 sill image and 1
Chara-den per entry
(respectively 100 in total
in the phonebook)

Name, Reading, ZIP
code, Address, Birthday
(up to 100 Reminder
entries), Memo

UIM

phonebook

Group 01 to 10

1 number per
entry

“” only

1 address per
entry

“” only

−

Name, Reading

■Features of the UIM phonebook

As phonebook entries are stored on the FOMA card
(UIM), you can transfer your phonebook entries to
another FOMA terminal simply by switching the
FOMA card (UIM). This makes the UIM phonebook
very useful when you use multiple FOMA terminals.

Displaying names

■Voice and videophone calls

When receiving a call with
caller ID notified from
someone who is stored in the
phonebook, the phone
number and caller’s name is
displayed.

When a still image is stored in
the phonebook, the image is
displayed. However,
depending on the size and
amount of data of the stored
image, it may take time to
display the image.
The caller’s name is also

calls”, “Dialed calls” and “Redial” records.

■Displaying names for i-mode mail and SMS

When you send/receive i-mode mail or SMS to/from
someone who is stored in the phonebook, his/her
name is displayed in the sent/received mail list/detail
screen or address list.

displayed in the “Received

Adding Information to the Phonebook

z The entry cannot be stored unless the “Name” field

is filled.

iX“phonebook”Xu (FUNC)X “Add

1

to phonebook”XSelect a phonebook

XEnter a name

You can enter kanji characters, hiragana,
katakana, alphabets, numbers, symbols and
pictographs (Phone only).
You can store up to 16 double-byte or 32 single­byte characters for “Phone” and 10 double-byte
or 21 single-byte alphanumeric characters only
(including some single-byte symbols) for “UIM”.

<Add to phonebook>

76

Check the readingXd (Set)

2

■ When the reading is incorrect

Correct the reading using katakana (single-byte
for “Phone” and double-byte for “UIM”), single­byte alphabet, numbers and symbols.
You can store up to 32 single-byte characters for
“Phone” and 12 double-byte or 25 single-byte
alphanumeric characters only (including some
single-byte symbols) for “UIM”.

Select any item:

3

Select group……Selects a group number

among “Group 01-19” for “Phone” or among “Group
01-10” for “UIM”. If no group is selected, the entry is
automatically assigned to “No Group”.

Enter phone number……Enters the phone

number.

• Also select an icon for “Phone”. You can enter up
to 26 digits for the phone number. Once you have
stored the first phone number, the “ <Not
stored>” option appears on the Phonebook edit
screen. Select this option to store an additional
phone number.

• You can enter 20 digits for a blue FOMA card
(UIM), and 26 digits for a green/white FOMA card
(UIM).

Enter mail address……Enters the e-mail

address. You can enter up to 50 single-byte
alphabets, numbers and symbols.
Also select an icon for “Phone”. Once you have
stored the first e-mail address, the “ <Not
stored>” option appears on the Phonebook edit
screen. Select this option to store an additional
e-mail address.

Enter ZIP code・Enter address……Enters the

ZIP code and street address. Enter the 7 single-byte
numbers for ZIP codes. You can enter up to 50
double-byte or 100 single-byte kanji characters,
hiragana, katakana, alphabets, numbers and
pictographs.

Enter birthday……Store birthdays and

reminder for birthdays, and press t.

Enter birthday……Enters the contact’s

birthday (year, month and day). Any year from
1800 to 2099 can be set.

Reminder……Selects checkbox for the day by

which to notify a bir thday (1 week before, 3
days before, the day before, the day of). When
it turns 0:00 on the date registered here, a
desktop icon appears on the display. → P. 1 0 3

Enter memorandums……Enters a memo

(short note). You can enter up to 100 double-byte or
200 single-byte characters which include kanji
characters, hiragana, katakana, alphabets, numbers
and pictographs.

Set image……Shoots or selects the image

displayed when you receive a call from the contact.

Select Chara-den……Selects the “Chara-den”

character displayed as the substitute image for
videophone calls.

Enter memory No.……Memory numbers are

automatically* assigned when an entry is stored in
the phonebook, but can be changed to any number
between 000 and 999.

* : Assigned to the available number between 010 to

999 from the smallest number. If no number is
available from 010 to 999, it is assigned to the
available number between 000 to 009.

o (Finish)

4

N

z Phonebook entries stored using symbols or

pictographs may not be displayed correctly when data
are transferred by the infrared communication, etc.

z Enter the correct domain when storing e-mail

addresses. The domain is the part of the address that
follows the “@” symbol.
However, if the contact’s e-mail address is in the
“[phone number]@docomo.ne.jp” format, store just the
phone number as the e-mail address.

z Phonebook 2in1 setting is set in “2in1 setting”. The

setting of “Phonebook 2in1 setting” ( / / ) is
displayed on the Phonebook list screen or Phonebook
detail screen when 2in1 mode is in Dual mode.
However, when attaching the phonebook to a mail or
copying it to the UIM phonebook, Phonebook 2in1
setting is not to be sent.

Mode Phonebook 2in1 setting

Dual mode A
A mode A
B mode B
OFF A

You can change the Phonebook 2in1 setting in “2in1
setting”. →P. 3 5 1

<Enter birthday (Reminder)>

z Reminder is not given for phonebooks stored as

secret data and phonebooks other than those with
Restrict dialing set.

Phonebook

Continued on next page

77

N

<Chara-den settings priority sequence>

z The priority order for Chara-den settings is as follows:

① Chara-den setting of Ring tone/Image (for

individual)

② Chara-den setting of Ring tone/Image (for group)
③ Chara-den stored in the phonebook entry
④ Substitute image in Select image

When phonebook editing is
interrupted

Phonebook

You can resume editing the phonebook entry which is
stopped being edited because of the battery dying or
activation of a task of Tool groups using Multitask,
etc.

iX“phonebook”Xu (FUNC)X “Add

1

to phonebook”XSelect the
destinationX“Recall”

When you are re-editing the
entry, if you cancel editing
without storing the changes,
the data being edited is erased.

■ To add a new phonebook

entry

X“New”

Adding Phonebook Entries from the Redial, Dialed Calls and Other Records

You can add information to the phonebook from the
“Received calls”, “Dialed calls”, “Redial”, “Received
address”, “Sent address”, “Text reader”, Site screen
or enter phone number screen, etc.

<Example: Adding information from the “Received
calls” record to the FOMA terminal (Phone)
phonebook>

Received calls screen (P.56)Xu

1

(FUNC)X“Add to phonebook”X
“Phone”

■ To add to the FOMA card (UIM)

X“UIM”

“Add”XSearch for the phonebook

2

entry to add the information

Searching the phonebook→P. 7 9

■ To add a new phonebook entry

X“New”

■ To add information to the UIM

X“New” or “Overwrite”

Display the phonebook detail screenX

3

d (Select)

Phone number is automatically entered and the
phonebook editing screen appears.
Editing the phonebook→P. 8 2

After completing the changes, press

4

o (Finish)

■ If a message appears asking whether to

overwrite existing data

X“YES”

N

z The “Notify Caller ID” setting (“Notify” or “Not notify”)

displayed in the “Dialed calls” and “Redial” records is
not stored in the phonebook.

Renaming Groups

You can assign your stored phonebook entries to
groups according to the contact role (“Work”,
“Friends”, etc.) or by hobby (“Baseball”, “Football”,
etc.). This allows you to use the phonebook as if it
were divided into different volumes according to
purpose.
z “No Group” cannot be renamed.

Phonebook list screen (P.79)Xu

1

(FUNC)X“Group setting”

The “Group setting screen”
appears.

Select a groupXEnter

2

the new group name

The “ ” icon appears next
to UIM groups.
You can enter up to 10
double-byte or 21 single­byte characters.
If the same name is used for
groups on the FOMA
terminal (Phone) and UIM, they are displayed as
separate groups.

<Group setting>

Group setting

Function menu¨P. 78

Group setting screen (P.78)

Edit group name……Edits the group name.

Ring tone/Image→ P. 8 2

Reset group name……The changed group name is reset

to the default name assigned at the time of purchase.

78

X

X

N

T

z Resetting the group name does not clear the “Ring

tone/Image” setting.

■ To switch the tab display

Xu (FUNC)X“Change Display”XSelect the tab

from “Alphabet/Memory No./Group”

Making a Call from the Phonebook

You can make a call by searching for the phonebook
entry from the FOMA terminal (Phone) phonebook or
the UIM phonebook.

z When tabs appear on the phonebook list screen,

you can switch the display as follows:
<Example: To switch tabs from “他 (Others)” to “Ta-

column” in the Alphabet display>

ab

List of “他 (Others)”

N

z You can use v to switch pages within the same tab.
z You cannot switch the tab with o ( ) when you

store to the Choku-Den or compose a message with
using the Look-up phonebook.

Searching for the phonebook entry of
the person you want to make a call

i

“phonebook”

1

The “Phonebook list screen”
appears.

■ To make a voice call

from the list screen

XHighlight the phonebook

entry you want to callXr
(voice call)
If the phonebook entry
contains multiple phone
numbers, the call is made to
the first phone number
stored for that entry.

<Search phonebook>

p ()
Four times

o ()
Four times

List of “Ta-column”

Phonebook list

Function menu¨P. 8 0

Alphabet Memory No.

Group

Select the phonebook entry you want

2

The “Phonebook detail
screen” appears.

Use v to display the

3

phone number you
want

r (voice call)

or o (V. phone)

■ To send a mail

XUse v to display the e-

mail address you wantXd
(MAIL)
“Composing and Sending i-mode Mail”→P.170

Phonebook detail

Function menu¨P. 81

N

z Pressing f during a call displays the group search

screen and pressing g displays the column search
screen.

Searching for the phonebook entry by
specifying the search method

You can search for a phonebook entry using any of 8
search criteria; reading, name, phone number, e-mail
address, memory number, group or “column” in
Japanese phonetics (a, ka, sa, ta, na, etc.) or all.

z Search results are displayed in the sequence

shown below based on the reading entered when
the entry was stored (except for memory number
search).
katakana → alphabets → numbers → 
symbols → the reading of caller’s name is not
stored

* If a space is placed at the beginning, it is searched first.

Phonebook

Continued on next page

79

On the standby screen Xg

1

■ To display your

preferred search
method first

XHighlight the search

method that you want to
display firstXo (Prefer)X
“OK”
“★ ” appears next to the
preferred search method.
Pressing g on the standby

Phonebook

screen displays the
phonebook search screen
with your preferred method.

■ To cancel your preferred search method

setting

XOn the standby screenXgXtXHighlight

the search method with the star “★”Xo
(Reset)

Select the search method:

2

Search reading……XEnter the readingXc

Enter the reading from the beginning. You do not
need to enter the entire name.

Search name……XEnter the nameXc

Enter the name from the beginning. You do not need
to enter the entire name.

Search phone No.……XEnter the phone

numberXc

Enter some digits numbers of the phone number.
You can also search the phone number by entering a
part of the phone number and press c on the
“Enter phone number screen” (P.50).

Search e-mail……XEnter the e-mail addressXc

You do not need to enter the entire address.

Search memory No.……XEnter the 3 digits

memory number.

You cannot search the UIM phonebook by memory
number.

Search group……XSelect the group you want

Note that the UIM phonebook uses different groups
from the FOMA terminal (Phone) phonebook.

Search column……XPress the key for the

“column” (tab) you want to search

1: “a” column 2: “ka” column 
3: “sa” column 4: “ta” column 
5: “na” column 6: “ha” column 
7: “ma” column 8: “ya” column 
9: “ra” column 0: “wa” column 
w: Others (alphabet or number, etc.)

Search all……All the stored phonebook entries are

displayed in the “Alphabet” tab.

80

When the search ends, the
“Phonebook list screen” that
meets the searching conditions
appears. “ ” is displayed for
the UIM phonebook.

Phonebook list

Function menu¨P. 80

● Accessing the phonebook from the

Redial or Dialed Calls record

You can access the stored phonebook detail screen
from the function menu of “Received calls”, “Dialed
calls”, “Redial”, “Received address” or “Sent address”
screen by selecting “Look-up phonebook”.

Phonebook list screen (P.80)

z The available functions vary depending on the

searching method and display method.

Add to phonebook→ P. 7 6

Connect to Center……Stores the phonebook data at the

DOCOMO Data Security Center. →P. 8 5

Sort*1……Sorts the phonebook list by selected criteria.

Change Display……Select from “Alphabet/Memory No./

Group”.

Ring tone/Image→ P. 8 4

Restrictions→ P. 1 2 2

Group setting→ P. 7 8

Copy to microSD*2→P. 2 7 1

• When “Copy all” is selected, you can select whether to
copy the My Profile data in addition to the phonebook
data.

iC transmission*2→P.282

iC trans. all*2→P.283

Send Ir data*2→P. 2 8 0

Send all Ir data*2→P. 2 8 1

No. of phonebook→ P. 8 2

Attach to mail

the phonebook data attached.

Big font⇔ Standard font……Switches the displayed font

size between “Big font/Standard font”. →P. 1 0 1

microSD phonebook⇔ Original phonebook……Refers

to the phonebook in the microSD memory card or the
FOMA terminal (Phone).

*2*3

……Displays a new mail screen with

Birthday reminder……Displays the phonebook lists that

have “Reminder” for birthdays set.

Delete data……Selects the deleting method from “Delete

this/Delete selected/Delete all”.

• “Delete all” deletes the phonebook on the FOMA card
(UIM).

*1: You can use this in the results screen displayed when

entering criteria such as Search reading and performing

Search phonebook.
*2: Does not function for the UIM phonebook.
*3: Not available when 2in1 is in B mode.

Phonebook detail screen (P.79)

Edit phonebook→ P. 8 2

Notify Caller ID→ P. 5 9

Chaku-moji→ P. 5 8

Dial setting

Prefix numbers →P. 6 1

Int’l call→ P. 5 5

2in1/Multi Num.……When 2in1 is set to ON and

Dual mode, selects from “Number A/Number B/
Cancel number” (P.352) (not available when A mode
or B mode is set).
Selects from “Basic number/Additional number 1/
Additional number 2/Cancel number” (P.349) at the
Multi Number when 2in1 set to OFF.

Select image……Selects the substitute image used

during a videophone call from “Chara-den”.
Select “Release settings” to cancel the setting.

Ring tone/Image*1→P. 8 2

Restrictions*1→P.122

Move to top*1……Moves the displayed phone number/

mail address to the top when multiple phone numbers/
mail addresses are stored in one phonebook entry.

Add to Choku-Den*1→P. 8 4

Add desktop icon→ P. 1 0 2

Compose message*2→P. 1 7 0

Attach to mail

the phonebook data attached.

Compose SMS*2→P. 2 0 2

iC transmission*1→P. 2 8 2

iC trans. all*1→P. 2 8 3

Send Ir data*1→P. 2 8 0

Send all Ir data*1→P. 2 8 1

Copy to microSD*1→P. 2 7 1

*1*2

……Displays a new mail screen with

Copy

Name……Copies the name. The copied name can

be pasted into input and other screens. →P. 3 3 7

Phone number*3……Copies the phone number.

The copied phone number can be pasted into input
and other screens. →P. 3 3 7

Secret code*1→P. 8 1

Set code……Sets the secret code (4 digits).

Check code……Confirms the set secret code.

Release settings……Cancels the set secret code.

*1*4

Set secret

Copy to UIM*5→P.277

Big font⇔ Standard font……Switches the displayed font

size between “Big font/Standard font”. →P. 1 0 1

Delete data→ P. 8 2

*1: Does not function for the UIM phonebook.
*2: Not available when 2in1 is in B mode.
*3: Depending on the selected item, one of “Mail address/

Address/Birthday/Memorandums” appears.

*4: “Release secret” when referring to the phonebook of the

secret data.

*5: “Copy from UIM” when referring to the UIM phonebook.

→P. 1 1 3

N

<Add to Choku-Den>

z When stored to Choku-Den, “★ ” appears on the

function menu.

● Secret code

When the mail address of the other party is “[phone
number]@docomo.ne.jp” and he/she sets a secret
code, you have to specify “[phone number + secret
code]@docomo.ne.jp” as the e-mail address.
There are 2 ways to send an e-mail to such a
destination.

z Set a secret code for the phonebook entry from the

phonebook detail screen function menu (when
referring to the mail address, the secret code is
automatically added to the mail address in the
phonebook).

z Store the mail address with a secret code in the

phonebook.

N

z Secret code settings are valid only to mail addresses

in “[phone number]@docomo.ne.jp” or “phone
number” format.

z You cannot set secret codes for the UIM phonebook.

Phonebook

81

Editing the Phonebook

<Edit phonebook>

Checking the Phonebook Storage Status

<No. of phonebook>

Phonebook detail screen (P.79)Xu

1

(FUNC)X“Edit phonebook”XEdit the
respective items

Edit the required items using the procedure used
in “Add to phonebook”.
Adding information to the phonebook→P. 7 6

■ To store in a new memory number

Phonebook

XSelect “ ”XEnter a memory number (000 to

999) that has not already been stored.
The original phonebook entry is left in its pre­edited state and the edited entry is stored as a
new phonebook entry with a different memory
number.

After editing, press o (Finish)X“YES”

2

■ To add information to the UIM

Xo (Finish)X“Overwrite” or “Add”

Selecting “Overwrite” stores the edited
information.
Selecting “Add” leaves the original phonebook
entry unchanged and stores the edited entry as
a new phonebook entry.

N

z When the edited entry is stored to the Choku-Den, the

Choku-Den is also changed.

Deleting a Phonebook Entry

<Delete data>

Phonebook detail screen (P.79)Xu

1

(FUNC)X“Delete data”XSelect any
item:

Delete phone No.*……Deletes the selected phone

number (e-mail address, address, bir thday,
memorandums, image or “Chara-den” character).

Delete this……Deletes the phonebook entry.

* : Depending on the selected item, one of “Delete mail

add./Delete address/Delete birthday/Delete
memorandums/Delete image/Delete Chara-den”
appears.

N

z If you delete a phone number or mail address in the

phonebook entry in which multiple phone numbers or
mail addresses are stored, the order of the
subsequent phone numbers or mail addresses moves
up.

Phonebook list screen (P.79)Xu

1

(FUNC)X“No. of phonebook”

■ Phone (the phonebook stored on the

FOMA terminal)

Phonebook : Displays the number of entries

Secret : Displays the number of entries

Image : Displays the number of images

Chara-den : Displays the number of “Chara-

Birthday remind

■ UIM (the phonebook stored on the FOMA

card (UIM))

Phonebook : Displays the number of entries

stored in the phonebook.
Number of stored data/1,000
(storage limit)

stored as secret data. (This can
only be displayed in “Secret mode”
or “Secret data only mode”.)

stored in the phonebook.
Number of stored data/100
(storage limit)

den” characters stored in the
phonebook.
Number of stored data/100
(storage limit)

: Displays the number of

“Reminder” entries for birthdays
set.
Number of stored data/100
(storage limit)

stored in the phonebook.
Number of stored data/50 (storage
limit)

Setting Different FOMA Terminal Actions for Each Phone Number and Mail Address

You can set different ring tones or answer messages
for the Record message depending on groups, phone
numbers or e-mail address in the phonebook. This
function is useful when you want to distinguish the
caller only by the ring tone.
z You cannot set this setting for “No Group” on the

FOMA terminal (Phone) or the phonebook or
groups on the FOMA card (UIM).

<Ring tone/Image>

82

z You cannot set “Illumination” and “My Signal

X

settings” at the same time.

z The Ring tone/Image functions are disabled when

the caller does not notify the caller ID. It is
recommended to set the “Caller ID Request”
service.

Phonebook detail screen (P.79)

1

(FUNC)X“Ring tone/Image”

u

The “Ring tone/Image
screen” appears.
“★ ” appears next to the
selected function.
The available functions vary

Ring tone/Image

depending on the item
selected in the phonebook detail screen.

■ To set this function for each group

XGroup setting screen (P.78)Xu

(FUNC)X“Ring tone/Image”

Select the item to distinguish

2

Select the item from “Voice call (recv.)/V.phone
(dial/recv.)/Mail (recv.)”.

• When “Mail (recv.)” is selected, this function is
applied not only i-mode mail but SMS.

Select any item:

3

“★ ” appears next to the selected function.

■ To release a selected function

XHighlight the function with “★”Xo (Reset)

The function is released and the “★” disappears.

Ring tone*1……Sets ring tones to distinguish the

caller of the phone or sender of mail.
“Changing the Ring Tone”→ P. 8 8

*1*2


……Sets images to distinguish the caller

of the phone. “Changing the Display”→ P. 9 5

Chara-den setup

displayed as the substitute image for videophone
calls.

Illumination*1……Sets the incoming call lamp

colors to distinguish the caller of the phone or
sender of mail.
“Setting the Flashing Mode of the Incoming Call
Lamp for Incoming Calls”→ P.100

Vibrator*1……Sets vibration patterns to distinguish

the caller of the phone or sender of mail.
“Setting the Vibration to Notify You of Incoming
Calls”→P. 9 0

Answer message*2……Changes the answer

message used when record message*5 or quick
message starts up depending on the caller.
“Having the Caller Leave a Message”→P. 6 8

*3*4

……Selects Chara-den to be

My Signal*6……Sorts calls/e-mail according to

sender using My Signal animation.

* If you highlight an item in the list while choosing an

animation, that animation is displayed in My Signal.

*1: You can also distinguish the incoming 64K data

communication.

*2: Available only when “Voice call (recv.)” or “V.phone

(dial/recv.)” is selected.

*3: Available only when “V.phone (dial/recv.)” is

selected.

*4: You need to set “My Signal settings” indicating the

incoming/outgoing of “Phone”, “Videophone”, “Mail/
Chat mail” (P.99) to “OFF”.

*5: You need to set “Record message” to “ON”

beforehand.

*6: You need to set “My Signal settings” indicating the

incoming/outgoing of “Phone”, “Videophone”, “Mail/
Chat mail” (P.99) to be displayed.

■When you set Ring tone/Image

An icon appears in the phonebook detail screen
indicating that each item is set.

: Ring tone (voice/

videophone call)
: Ring tone (mail)
: Illumination (voice/

videophone call)
: Illumination (mail)
: Vibration (voice/

videophone call)
: Vibration (mail)
: Image (voice/videophone call)
: Answer message (voice/videophone call)
: My Signal (voice/videophone call)
: My Signal (mail)
: Chara-den (videophone call)

N

z You cannot set this setting for the phonebook stored

as the secret data. Even if the setting is made for the
group, it is disabled for the phonebook entry stored as
the secret data.

z The “Mail (recv.)” setting set for a phone number is

activated when you receive an SMS or the sender’s e­mail address is “[phone-number]@ docomo.ne.jp”.

z Refer to the following pages for the priority when the

Ring tone/Image settings and other settings for
incoming calls, etc. are duplicated.

• Ring tone priority→ P. 8 9

• Vibrator priority→ P. 9 0

• Image priority →P. 8 9

• Chara-den priority→P. 7 8

• Incoming call lamp priority→ P. 1 0 1

• My Signal priority→P. 1 0 0

Phonebook

83

Checking the Ring tone/Image

X

X

X

X

X

X

settings

You can check the phonebook entries or groups set in
“Ring tone/Image” by function or item.

Phonebook list screen (P.79)

1

(FUNC)

The “Ring tone/Image screen” appears.
“★ ” appears next to the items to which this

function is set.

Select the function or item with “ ★ ”

Phonebook

2

“★ ”

Check settings……Checks the setting status.
XHighlight the function or item with “ ★”

Check the phonebook or group which is set

Release settings……Releases all the settings of

the functions marked with “★”.

* : The number of the selected items (the number of

“Ring tone/Image”

Highlight the function or item with

u (FUNC)

times d is pressed) varies depending on the
function or setting specified.

Select any item:

Using Choku-Den

By storing frequently used phonebook to Choku-Den,
you can make a call or send a mail quickly.

z You can store up to 5 Choku-Den by quoting the

stored data (such as phone number) from the
FOMA terminal (Phone) phonebook.

z When mail addresses are stored to Choku-Den,

you can compose i-mode mail or chat mail to all the
members easily.

z You cannot use this function in Secret data only

mode.

z You can use this function in Secret mode, but you

cannot add the phonebook stored as secret data to
Choku-Den, or store data in Choku-Den after
storing it in the phonebook.

u

<Choku-Den>

Adding to Choku-Den

On the standby screen

1

The “Choku-Den screen”
appears.
When there is a stored data,
the Choku-Den screen of
the first tab with the stored
data appears.

■ To change the location

to add

XUse v to move the tab

You can also use 1 to
5 to move to the tab of

*

X

the respective number.

o (Store)

2

■ To change the added contents

o (Edit)

X

“View phonebook” XSearch the

3

phonebook

Searching the phonebook→P. 7 9

■ To add to Choku-den after adding the data

to the phonebook

X“Direct input”

Add data to the phonebook (P.76), and go to
step 4.

d (Select)

4

The “View phonebook
screen” appears.

Use c to select a checkbox (□ )

5

Select only one phone number and mail address
to add respectively.
When a checkbox (□ ) is selected, other phone
numbers or mail addresses are displayed in gray
and the checkbox cannot be selected. To select
another checkbox, release the selected
checkbox first.

o (Finish)

6

f

Choku-Den

Function menu¨P. 85

View phonebook

84

X

X

N

z The setting of “Phonebook 2in1 setting” is displayed

on the Choku-Den screen when 2in1 mode is in Dual
mode.

z When an image is stored in the phonebook, the image

in the phonebook is added to Choku-Den.

Making a call/composing a mail from
Choku-Den

<Example: To make a call>

Choku-Den screen (P.84)

1

display Choku-Den screen to make a

Use v to

call

You can also use 1 to
5 to move to the tab of the

respective number.

Use c to select

2

“CALL”

■ To compose a mail

XUse c to select “MAIL”

→P.170

■ To make a videophone call

XUse c to select “VIDEO PHONE”

Choku-Den screen (P.84)

Store/Edit……Adds a phonebook to Choku-Den which is

not stored or edits the stored Choku-Den.→P. 8 4

Image……Changes the image displayed in Choku-Den

by selecting an image from “My picture”.

Broadcast mail……Displays the new mail screen with all

mail addresses stored to Choku-Den are entered to the
address. →P. 1 7 0

Broadcast chat……Displays the chat screen with all mail

addresses stored to Choku-Den are entered to the chat
members. →P. 1 9 8

Release this・Release all……Releases one or all

Choku-Den.

N

<Image>

z You can add an image whose file size is 100K bytes or

smaller and whose width or height is 854 dots or
smaller. However, you cannot add images other than
JPEG or GIF.

Using Dialing Shortcuts

<Two-touch dialing>

By assigning memory numbers “000” to “009” to
phone numbers in the phonebook, you can call those
phone numbers only by pressing one of 0 to 9
(last digit of the memory number) and r.

0 to 9Xr (voice call)/o (V.

1

phone)

N

z If the phonebook entry contains multiple phone

numbers, the call is made to the first phone number
stored for that entry.

Storing the Phonebook at the Data Security Center

<Data security serv.>

You can store the FOMA terminal (Phone) phonebook
at the DOCOMO Data Security Center. The stored
phonebook can be restored to the FOMA terminal or
updated by connecting to the Data Security Center.

z Data Security Service is a pay service you need to

apply for. If you have not subscribed to the service
and try to connect to the Data Security Center, the
notification screen appears.

z You cannot use the Data Security Service when

outside the i-mode service area or when the power
is OFF.

z To perform operations such as restoring or setting

automatic update of the phonebook, follow the
procedure below.

pX“iMenu”X“English”X“My Menu”X“電話帳お預
かり”

z For details on how to use the Data Security

Service, refer to “Mobile Phone User’s Guide
[i-mode] FOMA version”.

i

“lifekit”X“Data security serv.”

1

X “Connect to Center”

■ To set about sending images in the

phonebook

X“Sndg img in Phonebook”X“ON” (default:

“OFF”)
The images stored in the phonebook are also
stored at the Data Security Center.

Enter your security codeX“YES”

2

The FOMA terminal connects to the Data
Security Center to start saving the phonebook.

o (Finish)

3

Continued on next page

85

Phonebook

X

X

N

z You cannot store the phonebook stored in the FOMA

card (UIM) at the Data Security Center.

z Note that a phonebook entry with a image which

exceeds 100K bytes cannot be stored or updated.

● Restoring/updating the phonebook

The phonebook data stored at the Data Security
Center can be stored on the FOMA terminal from the
site of the Data Security Center.
You can also edit the phonebook data stored at the
Data Security Center from a PC, etc.

Phonebook

For details on how to use, refer to “Mobile Phone
User’s Guide [i-mode] FOMA version”.

N

z Automatic update is not performed when another

function is activated while updating the phonebook.

z When the phonebook is not updated, it is notified with

“ ” desktop icon.

z When you restore the phonebook data stored at the

Data Security Center to the FOMA terminal, icons
stored with phone number or mail address may be
replaced with “ ” or “ ”.

z Please note that if the phonebook data in the FOMA

terminal is deleted, the phonebook stored in the Data
Security Center will also be deleted when the
phonebook is updated. Follow the steps below to
download the phonebook from the Data Security
Center to your FOMA terminal.

X“iMenu”X“English”X“My Menu”X“ 電話帳お預か

p

り”

X“①お預かりセンター ”XEnter i-mode

X“決定 ”X“ ケータイへダウンロード”

password

X“OK”

The download starts in approximately 15 seconds, so
return the screen to the standby screen.

● Checking the communication log with

the Data Security Center

z You can check up to 30 communication logs. If the

maximum number of logs is exceeded, logs are
overwritten starting with the oldest one.

z On the communication log detail screen, the

transmission results, dates, transmission details,
data sizes, sending results to the Data Security
Center, reception results of the mobile phone and
number of data files left in the Data Security Center
appear.

i

“lifekit”X“Data security serv.”

1

“Exchanging history”

The “Exchanging history
screen” appears.

Exchanging history

Function menu¨P. 86

Select the communication log item

2

Exchanging history screen
(P.86)

Delete this・Delete selected・Delete all……Select the

deleting method.

86

Sound/Screen/Light

Settings

■Sound Settings

Changing the Ring Tone .......................................................................... 88

Setting Sound Effect for Ring Tones and Melodies....................................... 90

Setting the Vibration to Notify You of Incoming Calls......................................... 90

Changing the Ringback Tone.............................................................. 91

Setting the Keypad Tone........................................................................... 91

Setting the Confirmation Tone for Charging............................................... 91

Setting the Clock Alarm Tone .......................................................... 91

Setting the FOMA Terminal to Warn You before a Call Drops Out ............. 91

Setting the Ring Time for Incoming Mail ............................................. 91

Enabling the Tone to Ring through the Earphones and Speaker.... 92

Switching Off the FOMA Terminal’s Tone .................................................. 92

Modifying Manner Mode ....................................................................... 94

Select ring tone

Sound effect

Vibrator

Melody Call setting

Keypad sound

Charge sound

Clock Alarm Tone set

Quality alarm

Mail/Msg. ring time

Headset usage setting

Manner mode

Manner mode set

■Screen/Light Settings

Changing the Display................................................................................ 95

Displaying Phonebook Images When You Receive Calls ............. 96

Setting the Color for Incoming Call Display ...................................... 97

Preventing Others from Peeping the Screen ............................................. 97

Setting the Display and Keypad Lighting .......................................................... 97

Changing the Display Design..................................................................... 98

Changing the Menu Display............................................................................................ 98

Setting the Display Mode of My Signal.................................................. 99

Setting the Flashing Mode of the Incoming Call Lamp for Incoming Calls..... 100

Setting the Flashing Mode of the Incoming Call Lamp during Calls ..... 101

Changing the Font .................................................................................................. 101

Setting the Clock Display ............................................................................ 102

Using Desktop Icons ................................................................................... 102

Displaying Desktop Icon Messages for New Mail in 3D Animation....... 104

Selecting the Icons to Display on the Standby Screen ................................ 105

Setting the Kisekae Tool .................................................................... 106

Display setting

Disp. phonebook image

Disp. call/receive No.

Privacy angle

Backlight

Display design

My Signal setting

Illumination

Illumination in talk

Font

Clock display

Desktop icon

3D display setting

Icons setting

Kisekae Tool setting

87

Changing the Ring Tone

X

X

<Select ring tone>

You can set the ring tone and receiving screen in
each voice call, videophone call or i-mode mail. You
can also set the ring tone for specified phone number,
mail address or group of phonebook respectively.
→P. 8 2

z Guide to the melody list→ P. 2 6 3
z Setting the sending screen→ P. 9 5

i

“settings”X“Incoming call”

1

“Select ring tone”XSelect an item to
set a ring tone:

Sound/Screen/Light Settings

Select the item from “Phone/Videophone/Mail/
Chat mail/MessageR/MessageF”.

• When “Phone” is selected, the ring tone for
voice calls and 64K data communication is set.

• When “Mail” is selected, the ring tone for
i-mode mails, SMS and packet communication
is set.

“Select ring tone”XSelect any item:

2

Melody……Select the ring tone or melody.

i-motion……Select the i-motion/Chaku-Uta

downloaded to the FOMA terminal or a movie
(i-motion) shot using the camera.
When you receive a call, the video or sound for the
selected i-motion is played (Chaku-motion).

Music……Sets the Chaku-Uta-Full®. Set any item

from the following when the Chaku-Uta-Full
contains the portion where the ring tone is specified
by the provider:

Fullsong ring tone……Sets the whole song

as the ring tone.

Point ring tone……Sets a part of the song as

the ring tone.

XUse v to specify the portion (displayed

in orange) to set as the ring toneXd (Set)

When you select “Movable contents” folder,
select “YES” and select the destination folder.

Voice announce……Sets the message recorded

using “Voice announce”.

Random melody……Selects a folder containing

stored melodies. When you receive a call or
message, one of the melodies stored in the folder
played at random.

OFF……The FOMA terminal plays no ring tone.

■ To set the calling/receiving display

X“Select calling disp.” or “Select receiving disp.”

In “Ringing screen”, select an image from the My
picture or i-motion.
In “Select receiving disp.”, select an image from
the My picture.

Select the ring tone

3

When you select a melody, the FOMA terminal
plays the melody.
Press r, q, o, p or u to stop the
melody playback.

®

®

■Pre-installed ring tones, melodies and alarms

Display Track title Composer

Pattern 1 to 4

Calling 1 to 2

Classical
Telephone

Tr ip Tr ip

Sunshine Place Sunshine Place

Gymnopedies Gymnopedies SATIE ERIK

Jupiter “The Planets”

You’ve got mail 1

You’ve got mail 2

Good Morning 1

Time of Schedule

Baby Birds

Signal

Calmness

Relief

Simple Bell

Sonic

Phonon

■Pre-installed Chaku-Uta-Full

Display Track title Composer

If.... If.... DAISHI DANCE

Recording patent No. : T-0840119

−−

−−

−−

−

−

®

GUSTAV

THEODORE

HOLST

Jupiter

−−

−−

−−

−−

−−

−−

−−

−−

−−

−−

−−

88

N

z Some i-motion (i-motion with video only) and Chaku-

®

Uta-Full

z An i-motion with sound only (an i-motion with no video,

z Flash movies can be set in the Select calling disp. /

z Even if the movie/i-motion can be set as Chaku-

z When you select the i-motion in the Movable contents

z When you select the Chaku-Uta-Full® in the Movable

z When you set Chaku-Uta-Full® stored on the FOMA

z The ring tone is played at the volume set in “Ring

z If you set an i-motion that includes both video and

z If you set something other than an i-motion that

z When the i-motion is set to the ring tone for mail, the

z When you set Chaku-Uta-Full

cannot be specified to the ring tone.

such as a singer’s voice) cannot be specified as the
receiving display.

Select receiving disp., but the ring tone used is the
tone set in “Select ring tone”.

motion or image displayed for incoming calls, you
cannot set these movie/i-motion in the following
cases:

• When the movie/i-motion is transferred to a PC or
other FOMA terminal through infrared data
exchange function, IC communication function or
DOCOMO keitai datalink (P.359), then returned to
the FOMA terminal

• When the movie/i-motion is copied from a microSD
memory card to the FOMA terminal (including the
case that the movie/i-motion is copied from the
FOMA terminal to a microSD memory card, then
copied to the FOMA terminal)

folder, the selected i-motion is moved to the Inbox
folder of “i-motion”.

contents folder and “Fullsong ring tone” is set, the
selected Chaku-Uta-Full® is moved to the Inbox folder
of “Music”. When “Point ring tone” is set, the selected
portion is clipped as an i-motion and stored in the
folder of “i-motion”.

terminal as a ring tone with “Point ring tone”, it is not
clipped as an i-motion and the selected portion is set
to the ring tone.

volume” while selecting the ring tone.

sound as the ring tone and receiving display, the
FOMA terminal plays the i-motion set as the ring tone.

includes both video and sound as the ring tone and
then set an i-motion that includes both video and
sound as the receiving display, the FOMA terminal
plays the i-motion set as the receiving display.

default ring tone of “Mail” is used for the ring tone of
packet communication. The special screen appears
when packet communication is received regardless of
the incoming screen settings.

jacket image as the ring tone, the jacket image is not
displayed when you receive a call.

®

which contains the

N

z When multiple mails or MessageR/F are received at

the same time, the operation of the ring tone becomes
as follows:

Received contents Operation of the ring tone

Multiple mails are
received

Mail and MessageR/
F are received at the
same time

MessageR/F are
received at the same
time

<Ring tone priority for incoming calls>

z When the ring tone settings for incoming calls are

duplicated, the priority is assigned as follows:

①Ring tone for Multi Number (additional number 1, 2)
②Ring tone for Ring tone/Image (for individual)
③Ring tone for Ring tone/Image (for group)
④Ring tone for B mode of 2in1
⑤Ring tone for Select ring tone/Kisekae Tool setting

* The priority is assigned as follows in the Ring tone/

Image (② above) and the Ring tone/Image (③
above).

①i-motion for Ring tone
②i-motion for Calling display
③i-motion for Ring tone (i-motion with no video,

such as a singer’s voice), melody or Chaku-Uta-

®

Full

<Ring tone priority for mails (including SMS)>

z When the ring tone settings for mails are duplicated,

the priority is assigned as follows:

①Ring tone for Ring tone/Image (for individual)
②Ring tone for Ring tone/Image (for group)
③Ring tone for B mode of 2in1
④Mail ring tone for Select ring tone/Kisekae Tool

setting

<Image priority>

z When the image settings for incoming calls are

duplicated, the priority is assigned as follows:

①Image setting for Ring tone/Image (for individual)
②Image setting for “Ring tone/Image (for group)”
③Still image stored in the phonebook
④Image setting for B mode of 2in1
⑤i-motion for Select ring tone
⑥Display setting/Kisekae Tool setting

* The priority is assigned as follows in the “Ring tone/

Image (for individual)” (① above) and the “Ring
tone/Image (for group)” ( ② above):

①i-motion for Ring tone
②i-motion or still image/image for Select calling

disp.

The ring tone set for the last
received mail is used. If a
chat mail is contained, the
ring tone set for the chat
mail is used.

The ring tone set for
MessageR is used.

Sound/Screen/Light Settings

89

Setting Sound Effect for Ring

X

X

X

X

X

Tones and Melodies

<Sound effect>

Setting the Vibration to Notify You of Incoming Calls

<Vibrator>

Use this function to get richer fuller sound when the
FOMA terminal with a Stereo Earphone Set (optional)
plays melodies, ring tones for voice/videophone call
or mail, sound effects and i-motion sound.

i

“settings”X“Incoming call”

1

“Sound effect”X“Stereo&3D sound”
“ON” or “OFF”

● What is Sound effect

Sound/Screen/Light Settings

It is the function uses a Stereo Earphone Set to
produce 3-dimensional and resonating sound. This
function allows you to enjoy i-αppli games and
melody playback with richer and more realistic sound.
When you play an i-motion with sound effects, the
effects simultaneously enhance the sound played
through the speaker and earphones. Sound is
enhanced by effects that provide a natural-sounding
3D sound field and rich low tones as well as clearly
defined voice and music audio.

z i-motion with sound effects can be identified by the

icon shown on the movie list screen.→ P.248

N

z The 3D effect differs depending on the individual. If

the 3D sound bothers you, set this function to “OFF”.

z The sound with the built-in speaker cannot be

changed by sound effect even when this function set
to “ON”.

z When “Headset usage setting” is set to

“Headset+speaker”, this function is deactivated. When
set to “Headset only”, the function is activated.

You can set different vibration patterns to notify you
when you receive a voice call, videophone call or
mail.

i

“settings”X“Incoming call”

1

“Vibrator”XSelect an item to set the
vibration:

Select “Phone” to set the vibration for voice calls
and 64K data communication.
Select “Mail” to set the vibration for i-mode mail,
Area Mail (ring tone), SMS and packet
communication.

Select the vibration pattern:

2

Pattern 1- Pattern 3……Vibrates in each pattern.

When you switch the highlighted item while selecting
an item, the FOMA terminal vibrates in the
highlighted pattern.

Melody linkage……The FOMA terminal vibrates in

a pattern matched to the melody set as the ring tone.

OFF……The FOMA terminal does not vibrate.

■Icons on the standby display while setting the

vibration pattern

: The vibration star ts when receiving either voice

or videophone calls.

: The vibration star ts when receiving either mail/

chat mail/MessageR/F.

: Both “ ” and “ ” are set.

N

z When the vibration is set, take care that the vibration

does not move the FOMA terminal towards fire (e.g.
on a space heater) or cause it to fall off a table, etc.

z Even when “Melody linkage” is selected, the FOMA

terminal not always vibrates to the melody. When no
vibration pattern is set for the melody or when an
i-motion or Chaku-Uta-Full
FOMA terminal vibrates in Pattern 2.

z For Area Mail’s beep, the FOMA terminal will vibrate

regardless of this function’s setting.

<Vibrator priority>

z When the vibrator settings are duplicated, the priority

is assigned as follows:

①Vibrator for “Ring tone/Image (for individual)”
②Vibrator for “Ring tone/Image (for group)”
③Vibrator setting

®

is set as the ring tone, the

90

Changing the Ringback Tone

X

X

X

X

X

X

<Melody Call setting>

Setting the Clock Alarm Tone

<Clock Alarm Tone set>

You can set whether to change the tone heard by the
other party or not (YES/NO) when you receive a voice
call.

i

“settings”X“Incoming call”

1

“Melody Call setting”X“YES” or “NO”

By selecting “YES”, you can access the Melody
Call i-mode site. While accessing the setting
sites does not generate a packet communication
charge, a packet communication charge is
applied when you connect to the IP site, i-mode
menu site and the free music corner.
Follow the instructions on the screen to set.

N

z Melody Call is not activated when the other party dial

up from a videophone call.

Setting the Keypad Tone

<Keypad sound>

z Setting this function to “OFF” also disables the

battery level tone and the warning tone.

z The keypad sound is played at the level set in

“Volume” during a call, and fixed at the same level
while not talking on the phone.

i

“settings”X“Other settings”

1

“Keypad sound”X“ON” or “OFF”

Setting the Confirmation Tone for Charging

This function sets to emit a short double-beep
(“bibip”) when charging starts and ends.

z When the screen other than Standby screen is

displayed or when Manner mode or Public mode
(Driving mode) is set, the charge sound does not
ring.

iX“settings”X“Other settings”X

1

“Charge sound”X“ON” or “OFF”

<Charge sound>

You can change the clock alarm tone for the alarm,
schedule, To Do list and 1Seg booking program.

iX“settings”X“Clock”X“Clock

1

Alarm Tone set”XSelect any item:

Select the alarm tone from “Melody/i-motion/
Music/Voice announce/OFF”.

Setting the FOMA Terminal to Warn You before a Call Drops Out

The FOMA terminal emits an alarm tone to warn you
that the signal quality is deteriorating and the call is
likely to drop out.

z The call may drop out without a warning tone if the

signal quality worsens very quickly.

iX“settings”X“Talk”X“Quality

1

alarm”XSelect an alarm tone

Select the alarm tone from “No tone/High tone/
Low tone”.

<Quality alarm>

Setting the Ring Time for Incoming Mail

You can set a ring time when you receive mail, chat
mail or a MessageR/F.

i

“settings”X“Incoming call”

1

“Mail/Msg. ring time”XSelect an item
to set the ring time:

Select “Mail” to set the ring time for i-mode mail,
Area Mail and SMS.

“ON”XEnter the ring time (01 to 30

2

seconds in 2 digits)

■ To turn off the ring tone

X“OFF”

When “Vibrator” is activated, the vibration stops.

<Mail/Msg. ring time>

Sound/Screen/Light Settings

91

Enabling the Tone to Ring

X

X

X

through the Earphone and
Speaker

You can set the FOMA terminal to play the ring tone
or alarm notification through the earphones and
speaker when a flat-plug earphone/microphone with
switch (optional) is connected.

i

“settings”X“External

1

connection”X“Headset usage setting”

“Headset+speaker” or “Headset

only”

Sound/Screen/Light Settings

N

z If “Ring volume” is set to “Silent”, there is no sound

from the earphone or speaker.

z When “Phone vol.” and “Mail vol.” in the Manner mode

(Original) is set to other than “Silent”, the ring tone still
sound. However, Manner mode (Manner mode and
Super silent) is set, the ring tone sounds only from the
earphones.

<Headset usage setting>

Switching Off the FOMA Terminal’s Tone

You can set the FOMA terminal not to play the ring
tones or keypad tones through the speaker with a
single key operation.

z Refer to the Table 1 (P.93) and Tabl e 2 (P.93) for

details of Manner mode setting.

z In “Manner mode set”, you can select “Manner

mode/Super silent/Original” as the FOMA terminal
operation mode when Manner mode is set.

On the standby screen

1

or longer) or a ( マナー ) (1 second or

longer)

: The FOMA terminal notifies

you using “Vibrator”

: “Ring volume” is set to “Silent”

<Manner mode>

q (1 second

You can set the Manner
mode by pressing q (for 1
second or longer) during a
call.
The FOMA terminal is set to
Manner mode, “ ”
appears, and the information
specified in “Manner mode
set” is displayed.

〜

: “Record message” and

〜

During a call, the FOMA terminal emits a short
double-beep (“bibip”) and a message appears
notifying you that Manner mode is set.

■ To cancel Manner mode

XOn the standby screenXq (1 second or

longer) or a (マナー ) (1 second or longer)
You can cancel the Manner mode by pressing
q (for 1 second or longer) during a call.
Manner mode is canceled and “ ” disappears.
During a call, the FOMA terminal emits a short
double-beep (“bibip”) and a message appears
notifying you that Manner mode is canceled.

“Record VP message” is set to
record messages (The
number indicates the number
of recorded messages)

N

z Even when set to Manner mode, the FOMA terminal

still plays the shutter sound of the camera.

z When the vibration is set, take care that the vibration

does not move the FOMA terminal towards fire (e.g.
on a space heater) or cause it to fall off a table, etc.

92

[Table 1] When you set Manner mode

Item

Record msg. activation Record msg.

Vibrator ON “Vibrator” setting

Ring volume for voice/videophone call and
64K data communication

Ring volume for mail, chat mail, Area Mail,
packet communication and MessageR/F

Alarm volume (including snooze function) Silent “Alarm vol.” setting

Wake-up tone Silent “Phone vol.” setting

i-αppli volume Silent “i-αppli vol.” setting

Schedule/To Do List/1Seg booking
program & timer recording/Cost limit alarm
volume

Activation and completion tones for
recorded messages, voice memos, etc.

Keypad sound OFF “Keypad sound” setting

Microphone sensitivity during calls Up “Mic sensitiv.” setting

Holding tone Silent “Phone vol.” setting

On hold tone Silent “Phone vol.” setting

Low-voltage alarm OFF “LVA tone” setting

Reading out received mails “Phone” setting of “Ring volume”

Missed call/new mail confirmation tones
when the FOMA terminal is folded

ToruCa acquisition tone Silent “Phone vol.” setting

Manner

Played at “Level 2” when set to “Silent” or “Step”
Valid only when “Read out message” in the function menu of the
received mail detail screen is selected

Super

Mode

silent

(displays the Original manner mode settings)

(P.68) setting

Silent “Phone vol.” setting

Silent “Mail vol.” setting

Silent “Phone vol.” setting

ON OFF “VM tone” setting

Silent “Phone vol.” setting

“Record msg.” setting

The beep for Area Mail is always set at “Level 6”,
except when it is “Silent”

Played at “Level 2” when set to “Step”

Played at “Level 1” when set to other than “Silent”

Played at “Level 2” when set to “Step”

Even when “Phone vol.” is set to “Silent”, the low­voltage alarm sounds at “Level 1” when “LVA
tone” is set to “ON”.

Played at “Level 2” when set to “Step”

Played at “Level 4” when set to “Step”

[Table 2] When earphones are connected

Item

Reading out received mails “Phone” setting of “Ring volume”

Voice clock (during standby or snooze)
and missed call/new mail confirmation
tones when the FOMA terminal is folded

Music player volume Volume setting of the music player (P.303)

Ring Volume of watching 1Seg/playing
back 1Seg

Manner

Played at “Level 2” when set to “Silent” or “Step”

“Phone” setting of
“Ring volume”
Played at “Level 2”
when set to
“Silent” or “Step”

Volume setting of the 1Seg watching/during recording playback (P.233)

Mode

Super
silent

(displays the Original manner mode settings)

“Phone vol.” setting
Played at “Level 2” when set to “Step”

Original

Sound/Screen/Light Settings

Original

93

Automatically starting/canceling

X

X

X

X

X

X

Manner mode

You can start or cancel Manner mode at a pre-set
time.

z You can set up to two different start/cancel times.

<Making Manner Mode activate automatically>

i

“settings”X“Incoming call”

1

“Manner mode setting”X“Manner start
time”

The “Manner start time list screen” appears.

■ To cancel Manner mode

Sound/Screen/Light Settings

automatically

X“Manner release time”

“Manner release time list
screen” is displayed.

■ To keep the previous

setting but switch
between ON/OFF

XHighlight the settingXp

[ON/OFF]
“ON/OFF” changes each
time you press p.

■ To check the previous

setting

XSelect the setting

The “Start time set detail
screen” appears.

Highlight the setting

2

o (Edit)

Select any item

3

Edit start time……Sets the time at which

Manner mode will start/cancel.

Repeat……Selects the Automatic Manner

mode repetitions from “1 time/Daily ( )/Select day
()”.

Set the respective items

4

N

z Manner mode will not start or cancel at the set time if

the FOMA terminal is switched off.

z If another function is being used when the set start or

cancel time arrives, Manner mode will not start or
cancel. Manner mode will start or cancel after finishing
with the other function.

<Automatic Manner mode>

Manner start (release) time list

Function menu¨P. 94

Start (release) time set detail

Function menu¨P. 94

o (Finish)

● After you have set Automatic Manner

mode

An icon will be displayed on the standby screen.

: Automatic Manner mode

will be automatically
started.

: Automatic Manner mode

will be automatically

canceled.
You can check the start time or cancel time for
Automatic Manner mode by highlighting the icon.

Manner start (release) time list
screen (P.94) /Start (release)
time set detail screen (P.94)

Edit……Edits the Automatic Manner mode settings.

Display detail*……Displays Automatic Manner mode

details.

Finish (Set this)……Activates Automatic Manner mode.

Release this……Deactivates Automatic Manner mode for

1 set time.

Release all……Deactivates Automatic Manner mode for

all set times.

* : Only available in Manner st art (release) time list screen.

Modifying Manner Mode

<Manner mode set>

You can select the FOMA terminal operations used in
Manner mode.

i

“settings”X“Incoming call”

1

“Manner mode setting”X“Manner
mode set screen”

The “Manner mode set
screen” appears.

Select any item:

2

Manner mode……Mutes all tones played through

the speaker and uses vibration to notify you of
incoming calls, etc. However, confirmation tones
played through earpiece (when a voice memo or
memo is played) are not muted.

Super silent……Mutes all tones played through the

speaker and confirmation tones played through the
earpiece and uses vibration to notify you of incoming
calls, etc.

Original→ P. 9 5

Manner mode set

94

Setting the Original manner

X

You can set your preferred Manner mode setting.

z The following are the default settings of the

“Original” manner mode:

• Record msg.: OFF

• Vibrator: ON

• Phone vol.: Silent

• Mail vol.: Silent

• Alarm vol.: Silent

•i-αppli vol.: Silent

• VM tone: ON

• Keypad sound: OFF

• Mic sensitiv.: Up

• LVA tone: OFF

Manner mode set screen (P.94)X

1

“Original”XSelect any item:

Record msg.……Sets the Record message. →P. 6 8

Vibrator……Sets the vibrator. →P. 9 0

Phone vol.……Sets the ring tone volume for voice/

videophone calls and 64K data communication.
→P. 6 5

Mail vol.……Sets the ring tone volume for mail, chat

mail, packet communication and MessageR/F.
→P. 6 5

Alarm vol.……Sets the volume of the alarm.

→P. 3 1 1

i-αppli vol.……Sets the volume of the i-αppli.

→P. 2 0 9
However, “Step” cannot be set.

VM tone……Sets confirmation tones for “Record

msg.”, “Voice memo”, etc.

Keypad sound……Sets the keypad sound. →P. 9 1

Mic sensitiv.……Selects from “Normal/Up” for the

microphone sensitivity during calls.

LVA tone……Sets the low-voltage alarm.

“When the battery runs out”→ P. 4 5

Set the respective items

2

N

z The record message function set in “Original” starts

up after the ringing time set in “Record message”
(P.68) (when set to “OFF”, the recording starts after 13
seconds).

z If the microphone sensitivity during calls is set to “Up”,

the volume of the voice heard by the other party raises
even if you speak quietly. The microphone sensitivity
is set to “Normal” when shooting movies in “Camera”
mode.

o (Finish)

Changing the Display

<Display setting>

You can also set the still images you shot or
downloaded images as the standby screen, dialing/
calling screen, etc.

iX“settings”X“Display”X“Display

1

setting”

The “Display setting screen”
appears.

Display setting

Select any item:

2

Stand-by display……Changes the standby screen

image. →P. 9 6

Wake-up display……Specifies a message or image

displayed when the FOMA terminal is turned on.

OFF……Wake-up tone does not ring with no

image.

Message……Enters a message. You can enter

up to 50 double-byte or 100 single-byte
characters.

My picture……Selects an image to be

displayed from My picture.

Dialing/Calling/V.phone Dialing/V.phone Calling/
Mail sending/Mail receiving……Sets the image

displayed when making/receiving voice/videophone
calls or sending/receiving mails (i-mode mails and
SMS).

■Dialing/V.phone Dialing/Mail sending setting

Select from My picture.

■Calling/V.phone Calling/Mail receiving setting

“Changing the Ring Tone (Step 2)”→ P. 8 8

Check new messages・Mail rec’d result……

Selects the image displayed for “Check new
messages” (i-mode mails and messages), “Check
new SMS” or mail received result screen from My
picture.

N

z Some i-motion cannot be specified.
z You can not change the melody of Wake-up tone. The

volume is set to the same volume set at “Phone” of
“Ring volume” (Played at “Level 2” when set to “Step”).
Press any key to stop the melody.

Sound/Screen/Light Settings

Continued on next page

95

N

<Priority sequence for standby screen>

z Priority is assigned as follows when standby screen

settings are duplicated:

①Standby screen (i-αppli)
②Display setting/Kisekae Tool setting

Changing the standby screen image

z Some screens change its image depending on the

displayed timing.

z This function sets the standby screen when 2in1 is

in A mode or “2in1 setting” is set to OFF. The
settings are not applied when set to “B mode” or
“Dual mode”. Set “Standby display” of “2in1

Sound/Screen/Light Settings

setting”.

Display setting screen (P.95) X

1

“Stand-by display”XSelect any item:

OFF……No image is displayed.

Calendar……Sets a calendar.

Background……For the background image for

the calendar, selects one from My picture.

No background……Displays the calendar

only.

My picture……Selects the standby screen image.

i-motion*……Selects the i-motion to be displayed

on the standby screen.

i-αppli display……Sets the i-αppli standby screen.

→P.219
When the i-αppli standby screen is set, “★” is
displayed.

Random display……Displays an image in the

specified folder at random each time you open the
FOMA terminal or display the standby screen.

* : When you select the i-motion in the Movable

contents folder, the content is moved to the Inbox
folder of the FOMA terminal, then set.

■ When the screen for setting the display

style is displayed

XSelect the display styleXCheck the imageX

d (Set)
Following display styles are available:

• Centering disp. (centering an image on the
screen)

• Fit in disp. (enlarging/reducing an image size
until its height or width fits to the screen)

• Arrange disp. (displaying images from upper
left side in order)

• Full-screen disp. (enlarging or clipping an
image to fit it into the screen size)

N

z You may not select how to display depends on images

you select.

z If a movie or i-motion is set in the standby screen, it is

played when you open the FOMA terminal.

z When a flash movie or an animation GIF image is set

as the standby screen, the movie or animation is
played when the following operations are performed
(no sound):

• FOMA terminal is opened

• t is pressed on the standby screen

• Retur n to the standby screen from another screen
Some Flash movies function as a clock. If the clock
stops, perform the procedure above to resume the
clock.
However, as Flash movies are not played when the
Keypad lock, etc. is set, release the lock beforehand.

z When “Bigger” is set to “Clock display” and Calendar

is also set, “Big” is applied.

● When you set the calendar for the

standby screen

The calendar appears on the standby screen. You
can quickly and easily refer to previous or next
calendar dates or activate the schedule.

■To check the adjacent months on the calendar

Press d on the standby screen to select the
desktop icons or calendar. After using c to highlight
the calendar, press d (Select). The desktop icons
disappear and you can check the calendar of
previous or next month with c.

■To activate the schedule function

When the calendar of the previous or the next month
can be displayed with f or g, press d (Select) to
launch the schedule function and store a scheduled
event for the displayed month.

Displaying Phonebook Images When You Receive Calls

You can set whether to display a still image when
receiving a voice/videophone call from a phone
number of which still image is stored in the
phonebook (ON/OFF).

iX“settings”X“Incoming call”X

1

“Disp. phonebook image”X“ON” or
“OFF”

<Disp. phonebook image>

96

Setting the Color for

X

X

X

Incoming Call Display

<Disp. call/receive No.>

You can display names, phone numbers or mail
address on the Redial/Received calls screen or sent/
received address list screen with their font color
changed.

i

“settings”X“Incoming call”X

1

“Disp. call/receive No.”XSelect a color

N

z Press o (Change) to switch the number of colors to

be selected from 16 to 256. The pallet of 16 colors and
256 colors switches each time you press o
(Change).

z The color set in this function may be changed

depending on the “Color pattern” setting. After
changing the setting in this function, press p (Reset)
to reset the color corresponding to the “Color pattern”
setting.

z When you use 2in1, information of Number A/Address

A are displayed in the color set in this function. To
display the information of Number B/Address B in
different colors, set “Disp. call/receive No.” from “Set
call/receive No.” of “2in1setting”.

Preventing Others from Peeping the Screen

You can make it difficult for others to see the contents
on the display.

8 (1 second or longer)

1

The privacy angle is set and “ ” appears.

■ To release the setting

X8 (for 1 second or longer)

N

z You cannot set or release Privacy angle during editing

the text or i-αppli is activated.

<Privacy angle>

Setting the Display and Keypad Lighting

i

“settings”X“Display”

1

“Backlight”XSelect any item:

Lighting……Selects the normal backlight operation

and Power saver mode from “ON/OFF”.
Enter the waiting time for the Power saver mode (01
to 20 minutes in 2 digits) when you set the Power
saver mode to “ON”.

• You can also change the backlight operation (ON/

OFF) with 5 (1 second or longer).

• Setting the normal lighting settings for the
backlight to “OFF” displays the “ ” icon on the
standby screen.

• If you set the Power saver mode to “ON”, the
standby screen turns off when the specified
waiting time has elapsed. If any key is pressed
during the Power saver mode, the Power saver
mode is canceled.

Charging……Selects the backlight operation during

charging from “Standard/All time ON”.

• When set to “Standard”, the backlight lights up
with the setting of Lighting ON (not enter Power
saver mode).

• When set to “All time ON”, the backlight on the
screen remains on (the backlight changes to
“Dark” if no operation occurs for 15 seconds).

Area……Selects the lighting area of the backlight

form “LCD+Keys/LCD”.

Brightness……Specifies whether automatically to

adjust the backlight from “ON/OFF”, and selects
brightness from “Bright/Middle/Dark”.

• When set to “ON”, the Illuminance sensor detects
the brightness of surroundings and the brightness
of the backlight of the screen is automatically
adjusted. Turns the keypad light ON/OFF
automatically.

N

z When “Lighting” is set to “ON”, the backlight turns on

when a call is received and lights for about 15 seconds
when you turn the FOMA terminal on, press one of the
keys, or unfold the FOMA terminal. The backlight also
stays on while using the camera or playing a movie/
i-motion. If you select “OFF”, the backlight does not
turn on. However, the backlight turns on during movie
shooting or when viewing an e-book/e-comic,
regardless of the “Lighting” setting.

z The keypad backlight flashes when set to Power saver

mode with the FOMA terminal opened.

z If you cover the illuminance censor with your fingers,

the brightness may be not detected correctly.

<Backlight>

Sound/Screen/Light Settings

97

Changing the Display Design

X

<Display design>

You can change the text, background and the
background pattern for the function keys.

i

“settings”X“Display”X“Display

1

design”XSelect any item:

Color pattern……Selects the color pattern from

“Black/White/Golden Yellow/Pink/Blue”.

Icon pattern……Selects the design for the Battery

icon or Antenna icon from “Basic/Flock/Nyancos/
Francfranc”.

Sound/Screen/Light Settings

Soft key……Selects the background pattern for the

function keys from “Gray/Matte Black/Purple”.

N

z There are some screens or functions that are not

affected by the changes made to the settings of this
function, such as i-mode sites.

Changing the Menu Display

Memory focus……Sets whether to highlight the last

selected function when the Main Menu or Simple
Menu is redisplayed (Last one function).

Reset menu op. log*……Resets the menu

operation log, such as for the automatic sort of menu
items (P.34).

* : Only available on the menu display that supports this

function.

N

z Last one function memorize the main menu icon when

a branch menu is displayed. The icon is not
memorized when the operation is interrupted while
sub item is selected.

Changing the main menu screen

You can change the icons and background image
used on the main setting selection screen (main
menu).

Menu display set screen (P.98) X

1

“Theme”X“Original theme”

The “Original theme screen”
appears.

Setting the menu display mode

You can change the display of the branch settings
(functions) of “settings” and the main menu design.
You can also set the last one function of the Main
Menu and Simple Menu.

iX“settings”X“Display”X“Menu

1

display set”

The “Menu display set
screen” appears.

Select any item:

2

Menu display……Selects the display mode for the

branch settings from “List/Detail”.

Theme……Selects the background or icon for the

main menu from “Flock/Popets/Nyancos/Francfranc/
Standard/Simple Menu/Original theme/Kisekae
Tool”. For some types of menu, the background on
the main menu is changed depending on the
displayed timing.

• When Original theme is selected →P. 9 8

• When Kisekae Tool is selected→P.106

<Menu display set>

Menu display set

98

Original theme

Select any item:

2

Mail・i-mode・i-αppli・Settings・Data box・
LifeKit・Network service・Phonebook・Own
data・MUSIC・1Seg・Osaifu-Keitai……Selects

the icon images for the main menu from My picture.

Background image……Selects the background

image for the main menu from My picture.

Function menu¨P. 99

N

z The following images cannot be set.

• The image larger than 854 dots (wide or high)

• The image larger than 100KB

z If the image is larger than the display area, the size is

reduced without changing the aspect ratio, and
displayed in the middle if the image is smaller than the
display area.
