Watch Television via Your D903iTV

Here is a set of major instructions for you to watch television via your D903iTV. For more information, see “Manual for FOMA D903iTV”.

1 Before Watching TV

When you view 1Seg TV, attach the supplied 1Seg antenna. The following two types of 1Seg antenna are supplied:

● 1Seg Antenna with Strap for storage D01

Use this antenna to listen 1Seg sound via the speaker. You can carry the antenna in the strap case.

As shown below, you should use the antenna after connecting it to your FOMA terminal.

● Earphone Plug Adapter with Built-in 1Seg

Antenna D01

The D01 is an earphone plug adapter with a built-in 1Seg antenna. You can use it when you want to listen 1Seg sound via a commercially available stereo earphone set.

• No earphone is supplied.

• You can enjoy listening to 1Seg sound without

using an earphone.

Earphone Plug Adapter with Built-in 1Seg Antenna D01

Commercially available stereo earphone set

• While you are not viewing 1Seg, disconnect the 1Seg antenna from the FOMA terminal.

• Keep the 1Seg Antenna with Strap for storage D01 in the supplied strap case. Take care not to bend the

antenna. For example, do not put the antenna, when in its strap case, into a pocket of your pants.

• If you view the 1Seg TV after connecting the Earphone Plug Adapter with Built-in 1Seg Antenna D01, sound is

produced through an earphone set.

・To hear sound from the speaker on the FOMA terminal, press m982 on the 1Seg viewing screen

(vertical screen).

・Sound quality may differ depending on the earphone set. Some earphone sets may produce a lower level sound.

• Note that you cannot view the 1Seg TV if no UIM (FOMA card) is inserted, if the subscription contract with

DoCoMo is already terminated, or if using the FOMA service is being halted.

• Even if a UIM being currently contracted with DoCoMo is inserted, you may fail to activate the 1Seg

function if you repeatedly attempt to view the 1Seg TV while communication is unavailable (for example, when you are outside the FOMA service area). If this occurs, activate the 1Seg function again after establishing a communication state; for example, by entering a FOMA service area.

• When you view the 1Seg TV for the first time, you need to activate the 1Seg function while you are in a

FOMA service area.

1 2

Page 3

2 Watching TV

Connect the 1Seg antenna while the standby display is being displayed

• By default, the 1Seg service is activated automatically if you connect the furnished 1Seg antenna while

the standby display is being displayed. You can modify this in the Activate 1Seg setting ( 2 on the standby display).

• Activating the 1Seg function with key operation: C (for over a second) on the standby display

Insert the earphone’s mini-plug (3.5mm in diameter)

Either of them

A confirmation screen appears to prompt you to confirm the usage conditions.

• Except for the first time, no confirmation screen appears and you receive the

channel you were viewing previously. Go to step 6.

Confirm the usage conditions and press o

Confirm the displayed message and press o

Select Select area z Select an area in Large area z Select an area in Area detail

A confirmation screen appears to encourage you to confirm the broadcast storage area.

A screen appears to prompt you to select a method of creating a channel list.

• Channel setting based on area selection may prevent you from assigning

proper settings depending on the region. In this case, you should use automatic channel setting.

• You can create channel lists for individual areas and switch them for use.

Pay attention to the direction of the 1Seg antenna when connecting it. Inserting the antenna in the opposite direction would lead to a broken or faulty terminal.

Press p

The channel list is registered. 1Seg reception starts and the 1Seg viewing screen appears.

View 1Seg TV

To end viewing, press fz Select Yes

Page 4

3 1Seg Viewing Screen

When you activate 1Seg with your FOMA terminal open, it is displayed on the vertical screen. With your FOMA terminal closed, 1Seg is displayed on the horizontal screen. While viewing the 1Seg TV, you can press a to switch between the screens.

• You can also switch between the screens by opening or closing your FOMA terminal while viewing the 1Seg TV.

• Note that the screens will not be switched while a submenu is being displayed or the data broadcast operation

mode is being set.

Operation mode (only the vertical screen)

: TV operation mode : Data broadcast operation mode : Data broadcast operation mode

Image area

Data broadcast area (only the vertical screen)

Level of broadcast signal reception

: High - : Low : Outside the

broadcasting service area

・

Channel (Remote control number)

・・

・

Sound volume

・

(when data is enlarged)

To switch between the TV operation mode and

the data broadcast operation mode:

To enlarge or reduce the data broadcast area

in the data broadcast operation mode:

To move to the previous or next channel: You can also change channels if you highlight a

channel by rotating the Speed Selector and press

You can also change channels if you press the

key corresponding to a remote control number. The remote control numbers 1 to 9 to the keys numbers 10, 11, and 12 correspond to the keys

To change the sound volume:

(

1 to

; the remote control

, and #, respectively.

correspond

Sound volume

Channel (Remote control number)

Level of broadcast signal reception

The operation procedure is the same as that for the vertical screen, although you can select

・

no submenus.

The operation of % and & switches according to the orientation of the screen.

・

Other Convenient Operations

■Hiding images (Sound mode): n (for over a second)

•

To show the images you have hidden: Press any key other than the k key or open FOMA terminal

■Muting sound (Mute):

•

To unmute the muted sound:

or %

■Confirming the program name, etc.: o

■Using the program guide i-

αppli: p z Follow the instructions on the screen

• When Privacy Mode is on (with Authorized access set for Schedule), you cannot make view

reservations from the TV program guide ican be executed.

αppli. Likewise, no already registered view reservations

Page 5

4 Recording TV

You can use the FOMA terminal’s built-in memory for only 1Seg video recording.

• Even if you make or receive a voice call during video recording, the process will continue, although it interrupts

the 1Seg image and sound.

• Video recording is terminated if you make or receive a videophone call. The same also occurs if a PushTalk call

is made or received.

Starting video recording

C (for over a second) on the 1Seg viewing screen

• ( for the horizontal screen) appears, when video recording is started.

Terminating video recording

C on the 1Seg viewing screen z Select Yes

Replaying the video

u92 on the standby display z Select the video

• To pause/resume: o

• To fast-forward/rewind:

・Pressing r in the fast-forward mode results in fast-forward at ultra speed.

Similarly, pressing l in the rewind mode results in rewind at ultra speed.

・Pressing o returns you to the normal playback mode.

•

To specify the point to start playback (Skip replay): & (for over a second) z & or rotate the Speed Selector to select the point to start playback z

• To terminate playback: p or c on the TV operation mode z Select Yes

r/l

5 Making Convenient Use of the 1Seg Function

Convenient functions and settings available on the 1Seg viewing screen

This assumes that you have changed from the horizontal screen to the vertical screen.

■Displaying subtitles: m911

The vertical screen shows an area for subtitles below its image area. The horizontal screen shows a

•

translucent area for subtitles within its image area. For non-subtitled programs, the translucent area may disappear automatically.

■Turning off the icons and time on the horizontal screen: m922

If you select OFF, the horizontal screen may display nothing (black screen) for a certain period of time when

•

the broadcast signal reception level is low.

■Using the 1Seg OFF timer: m05 z 2 to 5

One of the following appears: , , , (but , , , for the horizontal screen). If the

•

specified time passes, the 1Seg function is terminated. If video recording is in progress, it is also terminated.

■Displaying the Help: m07

The Help shows the explanation of key operations not usually displayed on the guide row.

•

Combined Use of Activate 1Seg Setting and Key Lock

If you set Unlock key lock as Unlock in the Activate 1Seg Setting (m962 on the standby display), the key lock is canceled automatically when the 1Seg function is activated. If you set Key lock timer as ON in the Key Lock Timer setting (m83152 on the standby display), the key lock is turned on automatically if the specified time passes on the standby display after the 1Seg function is terminated.

Made from 100% recycled

paper.

07.2 (1st edition) 860D242A

Page 6

DoCoMo W-CDMA System

Thank you for selecting the FOMA D903iTV. Carefully read this manual and other manuals delive red with device s such as the battery pack, before using your FOMA D903iTV, and consult th e corresponding manuals while using the phone so that y ou are ab le to use it correctly and eff ectively. If you are unclear as to any point indicated in any of these man uals, contact the DoCoMo Information Center that is listed on the back of this manual. Your FOMA D903iTV is a valuable asset. Handle it with care and it will be your trusted partner for years to come.

Before using your FOMA terminal

● The FOMA terminal is cordless so you may not be able to use it in certain lo ca tions whe re signals cannot penetrate, such as in tunnels, undergroun d, in so me b uild in gs or o utdoors if the signal is weak or you are outside the service area. You also may not be able t o use your FOMA terminal on the upper floors of some highrise building, even though there is nothing around you that interferes with the signal. Please note that your call may be disconnected even when the signal is strong (when the signal strength indication shows three bars) a nd you are not moving.

● When using the FOMA terminal in public, busy or quiet places, be careful not to disturb others.

● Since the FOMA terminal relies on radio transmission, it is theoretically possible for third

parties to intercept a call; however, because the W-CDMA system automatically employs a secrecy function for all calls, a third party will pick up nothing but signal noise.

● Since the FOMA terminal operates by the wireless transmission of voices converted to digital signals, if you are in a location where the signal is weak, the original voice may not be accurately reproduced from the received digital signal, therefore, the voice you hear may differ from the original sound of the speaker’s voice.

● DoCoMo asks that you keep a separate record (e.g. written copy) of all information you store in your FOMA terminal. DoCoMo accepts no responsibility whatsoever for any loss that occurs should the contents of the FOMA terminal’s memory be lost or altered.

● The user hereby agrees that the user shall be solely responsible for the result of the use of SSL. Neither DoCoMo nor the certifier as listed herein makes any representation and warranty as for the security in the use of SSL. In the event that the user shall sustain damage or loss due to the use of SSL, neither DoCoMo nor the certifier shall be responsible for any such damage or loss. Certifier: VeriSign Japan K.K., Cybertrust Japan Co., Ltd., GeoTrust Japan, inc., RSA

● The FOMA terminal can be used in the FOMA Plus-Area.

● The FOMA terminal can be used only via the FOMA network provided by DoCoMo.

Security Japan Ltd., Secom Trust Systems Co.,Ltd.

For first time user of the FOMA terminal

If this is your first FOMA terminal, read this manual in the following order . Y ou can understand the preparations for using the FOMA terminal and its basic operations.

1. Install the battery pack and charge it. ☛P38, P39

2. Turn the power on, make initial settings, and then confirm your phone number. ☛P43, P46

3. Understand the functions of keys on the terminal. ☛P24

4. Understand the meaning of icons displayed on the screen. ☛ P27

5. Understand how to use the menus. ☛P30

6. Understand how to make and receive calls. ☛ P49, P64

The latest information about this manual can be downloaded from the DoCoMo website.

● User’s Manual Download

(http://www.nttdocomo.co.jp/english/support/manual/index.html)

Note: The URL and site contents are subject to change without prior notice.

Page 7

How to use and refer to this manual

You can look for functions or operation procedures that yo u want to know using various searching ways.

Search on INDEX P470

Search for a function name or service name.

Use Quick Search P4

Search for frequently-used or useful functions using easy-to-understand words. 

Use Front Cover Indexes Front Cover

Search by turning over the pages on this manual using the front cover indexes.

▲

See the next page for details.

Use Contents P6

Refer to the contents classified into chapters on an objective basis.

Refer to Features and Functions P8

▲

See the next page for details.

▲

See the next page for details.

Search for the features or new functions of D903iTV.

Use Menu List P422

Search using the menu of D903iTV.

Use Quick Reference Manual P476

Quick Reference Manual describes how to operate frequently-used functions. Use it by separating from this instruction manual.

● In the manual for FOMA D903iTV, the FOMA D903iTV is usually referred to as “FOMA terminal”.

● This manual explains functions performed with a microSD memory card. A microSD memory

card is required separately. For microSD memory card ☛P331

● In this manual, “Osaifu-Keitai compatible i-

as “Osaifu-Keitai compatible i-

● The design of screen displays has been initialized according to the color of FOMA terminal from

the combinations preset in FOMA terminal (Style Theme). ☛P141 In this manual, the procedure is explained mainly in case that Style Theme is set to White.

● Unauthorized copying of a part or all of the contents of this manual is prohibited.

● The contents of this manual are subject to change without prior notice.

ppli”.

ppli supporting the IC card function” is described

Quick Search/Contents/Cautions

Page 8

How to use and refer to this manual

. .

Shown below is an example when you search for the page where “My Picture” is described.

Searching on INDEX

Use INDEX if you have already known a function or service name.

Using Quick Search

You can easily search for frequently-used or useful functions.

Advanced functions for camera

• Change the size of image to shoot....................176 Image size

• Save data into the microSD memory card......... 176 Save to

• Display the shot images .................................... 312 My Pict ure

Using Front Cover Indexes

You can find a target page by proceeding from the front cover to the cover of a chapter (the first page of the chapter) and the page where a function is described.

▲

My Menu................................ 191

My Picture.............................. 312

Deleting.............................. 347

Sort.................................... 347

Use albums.........................344

View/Edit Detail In

PDF Viewer Personalized silent

Ph Book No. Search Phone

............

Settings..............

Call Option

Make calls ..........

.........

resworB lluF

idE/gniyalpsiD

taD

ataD gniganaM/gnit

gniyalP cisuM

snoitcnuF tneinevnoC rehtO

secivreS krowteN

noitacinummoC a

▲

Displaying/Editing/ Managing Data

▲

Making full use of images

Displaying images ............................................................................... My Picture 312

Editing still images ..................................................................................................314

Setting the operating conditions of images ......................................... Settings 317

Saving still images in the Data Center ........................... Data Security Service 318

Making full use of video/i-motion

Playing video/i-motion ............................................................................ i-motion 318

Editing video/i-motion .............................................................................................321

Setting the operating conditions of video/i-motion ............................. Settings 323

Moving video/i-motion to the microSD memory card ......... Movable Contents 324

● The displays or illustrations provided in this manual are for information purposes only and may

be different from the actual products.

● In this manual, the keys are simplified.

Actual key Description in this manual

• The typestyle of key characters is different depending on the color of the terminal. (Example: , )

● In this manual, the operation procedures are described as follows:

Description Meaning

0 z o z Enter the

terminal security code

Quick Search/Contents/Cautions

Press m0 on the standby display and then press o. Continuously, enter the terminal security code and press o.

Page 9

Making full use of images

▲

Displaying images

You can display images saved in My Picture in Data Box in FOMA terminal.

u1 z Select a folder

Camera：

Still images shot by the camera or still images captured from video/i-motion or PDF data

i-mode：

Images acquired with i-mode, Full Browser, i-mode Mail and i- ppli

Deco-mail picture：

Preinstalled images for Deco-mail and images downloaded from sites, received via i-mode mails, etc.

Deco-mail pict：

Preinstalled pictograms for Deco-mail and Deco-mail pictograms downloaded from sites, received via i-mode mails, etc.

Item：

Frame images preinstalled by default and frame images/stamp images downloaded from sites

Preinstalled：

Images preinstalled by default

Data transfer：

Images read by Bar Code Reader, images moved/copied from microSD memory cards and images received via data communications

Album：

Images moved from other folders

･Not displayed by default. To create an

P344

Album folder

･ To switch to the folder list display of the

microSD memory card: t on the folder list z 1 to 3

･ For details about the microSD memory card

P338

Highlight an image

Thumbnail display

cdab

Image list

：Camera ：i-mode

▲

312

aOriginated

Displaying/Editing/Managing Data

Menu 51

My Picture

Title display

Sorting data

You can change the order of data of the list screen.

･To sort music data in Music P368

Default By: Saved date & time

Order: Descending

Sorting data in My Picture

Example

u1 z Select a folder

Select each item to set z Press p

By ：Sets the sorting method. Order

：Sets the sorting order of data.

INFORMATION

● In the video/i-motion list, melody list, PDF data list,

document list of Other, Chara-den list, Machi-chara list, 1Seg image list or video list, press m and select Sort.

● If one-byte and two-byte characters are mixed in the

display name, the sorted result may not correspond to Japanese syllabary.

The recording screen

■ Upper screen

■ Lower screen

d e

Setting guide

Use & to change settings for recording.

Save to

: FOMA terminal

cdba

: microSD memory card

Type

Indicates to record sound.

Indicator

Indicates the usage rate of the storage area in the memory to save.

･The microSD memory card storage area usage

rate may not become 0 even when no recorded sounds have been saved.

P177

P357

Shortcut operation ☛P31

Sort

Title & function name: Function names are listed on INDEX.

Functional overview and notes for operation

Default setting Operation procedure

INFORMATION: In this manual, information items are categorized as follows:

●：Alternative

operation procedures

●：General notes

●：Detailed

description of the function

Column: Useful information

The page shown here is an example. It may differ from the actual page.

Supplement to the operation

Chapter title

● If there is especially no notice, the operation procedures from the standby display are mentioned.

● The operation procedure is mainly explained in shortcut operations using the normal menu (except

the simple menu). When there are two or more possible procedures, the simplest one is mentioned.

● In this manual, to place the cursor at an item with (Speed Selector) is referred to as “highlight”.

In addition, to select an item by placing the cursor with (Speed Selector) and pressing

(Enter key) is referred to as “select”. The step of pressing which is required after entering characters in the entry field is omitted in description.

● In this manual, the words and phrases displayed on the screen are written in italic characters.

● Some screens do not support the bilingual function and items or keys may be displayed in

Japanese. In this manual, these Japanese words are written by both in Japanese and English only for the first time in a chapter or a section.

Quick Search/Contents/Cautions

Page 10

Quick Search

Use this Quick Search to search for a function using easy-to-understand words.

Useful functions for phone calls

• Notify/not notify your phone number....................45 Caller ID Notification

• Put the current call on hold..................................51 On-hold

• Switch to videophone call during voice call.........53

Switch to videophone

• Adjust the volume of the other party’s voice........68 Listen Volume

When unable to answer an incoming call

How to change melodies or lighting patterns

How to change the screen displays

• Put the incoming call on hold...............................70 Response and Hold

• Inform the caller that you should not use the phone

.............................................................................72

.............................................................................74

Public mode (Driving mode) Public mode (power off)

• Record caller’s messages ................................... 75 Answer Machine

• Adjust the volume of ring alerts...........................68 Adjust Volume

• Use a personal ring alert for each caller............103 Alert by Contact

• Use your favorite ring alerts...............................120 Sound Setting

• Mute the sound heard when pressing keypad.......123 Keypad Sound

• Use the vibrator for incoming calls ....................126 Vibrator Setting

• Turn Silent Mode on..........................................127 Silent Mode

•

Customize the incoming lighting colo r and pattern....

144 Light Alert Setting

• Learn the meaning of icons on the screen .......... 27 Reading display

• Change the menu display format.........................30 Selecting menu

• Customize the standby display (wallpaper)....... 129

Standby Display Setting

• Show a calendar on the standby display .......... 132 Calendar

• Change the size of characters........................... 146 Font Size Setting

Quick Search/Contents/Cautions

Page 11

Advanced functions for mail

Advanced functions for camera

• Send your original Deco-mail ............................ 218 Deco-mail

• Send images with mail.......................................222 Attachment

• Sort and save mail automatically.......................244 Sort Criteria

• Change the size of image to shoot.................... 176 Image size

• Save data into the microSD memory card.........176 Save to

• Display the shot images .................................... 312 My Picture

Settings for your phone safety

Advanced functions for TV

Other useful functions

• Keep your phonebook data secret.....................115 Secret Attribute

• Lock your phone remotely when it is lost, etc....155 Omakase Lock

• Reject calls without caller ID..............................163 Anonymous Caller

• Reject callers not registered in the phonebook... 165

Reject Unregistered Caller

• Save the phonebook and other data to

prevent data loss...............................................165

*1 This is a pay service and requires a subscription.

Data Security Service

• Watch TV...........................................................293 Activate 1Seg

• Schedule TV programs viewing.........................296 Booking Program List

• Record TV programs.........................................300 1Seg Recording

• Change the settings of image and soud............ 301 1Seg Setting

• Increase the life of the battery........................... 137 Display Light Setting

• Read a QR code or barcode ............................. 184 Bar Code Reader

• Use the microSD memory card......................... 331 microSD memory card

• Send/receive data via infrared communication....348

Infrared communication

• Listen to music .................................................. 364 Playing music

• Use your phone as an alarm clock.................... 376 Alarm Clock

• Use your phone as a calculator......................... 392 Calculator

• Update software................................................ 460 Software Update

• Update the security ........................................... 464 Virus Scan Function

● The operation procedures of frequently-used functions are described in Quick Manual. ☛P476

Quick Search/Contents/Cautions

Page 12

Before using your FOMA terminal............. Inside front cover

For first time user of the FOMA terminal... Inside front cover

How to use and refer to this manual ...................................1

Quick Search.......................................................................4

Features and functions of FOMA D903iTV .........................8

Making full use of D903iTV ............................................... 10

SAFETY PRECAUTIONS (Always follow these directions)..... 12

Handling instructions.........................................................18

About intellectual property rights.......................................20

Basic package and optional accessories ..........................22

Before Using D903iTV 23

Names and functions of parts Reading the display Selecting the menu Using the UIM (FOMA card) Attaching/removing the battery pack Charging Battery Level Power ON/OFF Select Language Date and Time Setting Caller ID Notification Own Number

Calls/Videophone Calls 47

Making calls Redial/Received Calls Chaku-moji 186/184 Call WORLD CALL Receiving calls Any Key Answer Open Answer Close Setting Listen Volume Adjust Volume Response and Hold Public mode (Driving mode/power off) Answer Machine Using Chara-den Videophone Settings etc.

PushTalk 87

PushTalk Making PushTalk calls Receiving PushTalk calls PushTalk Phonebook etc.

Phonebook 99

Phonebook New Entry Group Setting Phonebook Search Edit Phonebook Delete Phonebook Secret Attribute Quick Dial etc.

Sounds/Displays/Lights Settings 119

Sound Setting Vibrator Setting Silent Mode Standby Display Setting Call Image Mail Image Display Light Setting Menu Setting Style Theme Kisekae tool Machi-chara Setting Light Alert Setting Indicator Light Clock Display Format etc.

Safety Settings 149

Security code Change Security Code PIN code All Lock Omakase Lock Self Mode PIM Lock Keypad Dial Lock Privacy Mode Setting Key Lock Secret Mode Data Security Service etc.

Camera 167

Still Camera Movie Camera Settings during shooting Bar Code Reader etc.

i-mode/i-motion/i-channel 187

What’s i-mode? Displaying sites Change i-mode Password Internet Connection Bookmark Screen Memo Downloading images and melodies i-mode Setting Message R/F Certificate i-motion Downloading i-motion i-motion Setting i-channel Channel List i-Channel Ticker etc.

Mail 213

Composing and sending i-mode Mail Deco-mail Attachment Save Mail Receiving i-mode Mail Check i-mode Message Display/Play/Save Attachment Using mail box Received Msg. Log/Sent Msg. Log Mail Setting Composing and sending chat mail Composing and sending SMS etc.

Quick Search/Contents/Cautions

Page 13

Contents

i-αppli 259

i-αppli Downloading Starting i-αppli i-αppli To i-αppli Standby Display etc.

Osaifu-Keitai/ToruCa 277

Osaifu-Keitai iC transfer service Starting Osaifu-Keitai compatible i-αppli ToruCa Obtaining ToruCa Displaying ToruCa Setting ToruCa IC Card Lock

Watching TV 289

TV Channel Setting Activate 1Seg Program Guide Booking Program List 1Seg Recording etc.

Full Browser 303

Full Browser Browser Setting

Displaying/Editing/Managing Data 311

Displaying/editing images Playing/editing video/i-motion Chara-den Machi-chara Playing melodies Viewing 1Seg image/playing video microSD memory card Managing data Infrared communication iC Communication Sound Recorder PDF Viewer Document Viewer etc.

Music Playing 363

Downloading Transferring from PC Music Player etc.

Other Convenient Functions 373

Multiaccess Multitask Edit by Slide Auto Power ON/OFF Timer Alarm Clock Scheduler Custom Menu Speed Menu Own Number Voice Memo/Video Memo Call Duration/Call Cost Reset Call Cost Call Cost Limit Calculator Notepad Electronic dictionaries Earphone/Microphone with Switch Quick Start-up Reset Delete All Data etc.

Network Services 399

Voice Mail Call Waiting Call Forwarding Nuisance Call Blocking Caller ID Request Dual Network English Guidance Service Dialing Number Remote Control Multi Number etc.

Data Communication 407

Data communication Flow of setup AT command etc.

Character Entry 411

Entering characters 5-touch Input Method Save Phrase Copy Character KUTEN Code Input Save Word Downloaded Dictionary Slot Input Method Input Method Setting

Appendix/Data Interchange/Troubleshooting 421

Menu list Data set by default List of character assignments Options and related devices Troubleshooting Error Message Warranty and After-Sales Service Software Update Virus Scan Function Main specification etc.

INDEX/Quick Reference Manual 469

INDEX Quick Reference Manual

Quick Search/Contents/Cautions

Page 14

Features and functions of FOMA D903iTV

FOMA is the name of a set of services provided by DoCoMo based on W-CDMA, which is recognized as one of the systems compliant to the global standard for third generation mobile communications (IMT-2000).

It’s amazing because

it’s i-mode!

i-mode is an online service used with i-mode terminals. This service supports connection to i-mode sites (programs) or i-mode compatible websites that provide a variety of useful information and allows you to exchange i-mode Mail.

i-mode Mail/Deco-mail pictogram ☛P217

In addition to the message text, data of up to 2 Mbytes or up to 10 files (JPEG, ToruCa, PDF data , etc.) can be attached to a mail. ☛P222 Deco-mail/Deco-mail pictograms allow you to change the character color, size or background color of the message. You can enjoy composing and sending expressive mails. ☛P218

Chaku-Uta Full

You can download an entire full-length song of your choice. Downloaded song can be set as the ring alert. ☛P370

☛P364

･“Chaku-Uta Full” is a registered trademark of

Sony Music Entertainment (Japan ) Inc.

Safety settings

Omakase Lock ☛P155

You can lock your FOMA terminal in case it is lo st and also cancel the lock, by informing DoCoMo. For contact information, refer to the back of this manual.

･Note that FOMA terminal is locked when a

request is made by the subscriber even if the subscriber is not the user of FOMA terminal.

Mega i-αppli/i-αppli DX ☛P260

Downloading i-αppli from sites allows you to enjoy various games and automatically update stock prices and weather information on your phone. High-capacity mega i-αppli is supported, which allows you to enjoy high-definition 3D games and full-length RPG games. i-αppli DX provides better uses in conjunction with i-mode terminal information such as the phonebook and mail.

Data Security Service

Allows you to back up the phonebo ok data, still images and mails stored in FOMA terminal to the Data Center. When your FOMA terminal is lost, etc., you can restore the backup data to the new FOMA terminal. In addition, you can edit and manage the backup data in the Data Cent er from your PC, and save the edited data to your FOMA terminal. ☛P165 For important notes on using Data Security Service and detail information about how to use the service, see “Mobile Phone User’s Guide [i-mode]”. For contact information, refer to the back of this manual.

･ This is a pay service and requires a subscription.

Wide array of network services

･Voice Mail Service (charged) ･Call Forwarding Service (free of charg e) ･

SMS (Short Message) (free of charge)

Quick Search/Contents/Cautions

☛P400

☛P254

☛P402

･ Call Waiting Service (charged) ･ Dual Network Service (charged)

*1 A separate subscription is required.

☛P401

☛P403

Page 15

Useful functions

High-definition large display

The large TFT LCD of about 2.8 inches (240 x 400 dots) is provided for the display. It clearly displays fine images and characters on the large screen.

Speed Selector

In addition to up, down, left and right operations, rotating operation is now possible. This allows you to scroll the screen and select it ems quickly. ☛P26 The Enter key in the center of the Speed Selector lights up in various patterns when there is an incoming call, the Speed Selector is rotated, etc. ☛P144

Built-in camera ☛P168

FOMA terminal contains an out-camera and incamera. You can take images while viewing the large display. In addition to a maximum 10x zoom, various modes are available for shooting including close-up, framed shooting and continuous shooting. Out-camera: Effective pi xels: Approx. 1.3M (Max

record pixels: Approx. 1.2M)

In-camera : Effective pixel s: Approx. 0.1M (Max

record pixels: Approx. 0.1M)

Usable mail functions

･You can block other people from peeping your

mail messages by a simple key operation (Only View). ☛P248

･The characters can be converted efficiently with

ATOK and APOT (AI presumption conversion) provided.

Machi-chara ☛P143

A character, moving around the screen, can be displayed on the standby display, etc. You can download Machi-chara from compatible sites. ☛P199

Infrared communication/iC communication

･ You can exchange data between two FOMA

terminals using infrared or iC communication. ☛P348, P353

･ In addition, you can operate devices that support

TV infrared remote control from FOMA terminal. ☛P352

Document Viewer ☛P361

Word, Excel and PowerPoint files can be viewed on FOMA terminal. You can zoom in and out on the viewer easily using the Speed Selector.

Support for microSD memory card

･ A microSD memory card enables you to back up

data in your FOMA terminal such as images, melodies, phonebook data and mails. ☛P331

･ By connecting your FOMA terminal to a PC with

the FOMA USB Cable (optional), the microSD memory card in FOMA terminal can be used as an external memory of the PC. ☛P342

Speed Menu ☛ P387

Use your voice to quickly start 1Seg, Still Camera, Music Player and Full Browser.

Full Browser ☛P304

Allows you to view websites for PC on FOMA terminal. Horizontal display is available on the Full Browser screen.

Kisekae tool ☛P142

You can set the ring alert, standby display, menu icon, etc. collectively according to a theme. Kisekae tool of your favorite character can be downloaded from sites. ☛P199

Quick Search/Contents/Cautions

Page 16

Making full use of D903iTV

A variety of functions of D903iTV visual communications are explained here.

Videophone

Using the videophone, talk with a party in the distance while looking at the other’s face. I nstead of your image, you can also send to the other party a surrounding scenery image through the out-camera or a character image using Chara-den.

Your terminal Other party’s terminal Other party’s terminal Other party’s terminal

Talk while seeing each other. ☛P49, P64 Image of your

surroundings is displayed. ☛P82

PushTalk

You can talk with multiple person s (up to 5 persons including yourself) by easy operations. Press the PushTalk button (g) for over a second to activate PushTalk Phonebook and press g after selecting a party. ☛P88

Osaifu-Keitai/ToruCa

･ Downloading the Osaifu-Keitai compatible i-

charge electronic money from sites to the IC card of your FOMA terminal or check the balance and us age history. The preinstalled i-αppli that is compatible with the DoCoMo’s credit service “DCMX” makes your Osaifu-Keitai more convenient in dai ly life . In ad di tio n, the iC transfer service that allows you to easily move the IC card data between FOMA terminals is suppor ted. This is useful when replacing a model, etc. ☛P278

･ You can use ToruCa by obtaining it through the reader/writer, from sites

or from QR codes. ToruCa is an electronic card that is available through Osaifu-Keitai, which can be used as a flyer, restaurant card , coupon, etc. ToruCa can also be exchanged using mail, infrared communication, iC communication or the microSD memory card. ☛P280

ppli enables you to

Character is displayed. ☛P78

Quick Search/Contents/Cautions

Page 17

i-channel

Music Pl

You can receive a variety of information on a regular basis without additional operations. In addition, press the i-channel compatible key (c) to display the channel list so that you can get more richly detailed information. ☛P210

Not subscribed After subscription

Connect

Chaku-moji

When you make a call, you can set a message (Chaku-moji) to be displayed on the other party’s incoming screen. The other par ty can see the message (Chaku-moji) and know in ad vance what the matter is and how you are feeling. ☛P57

Other party’s terminal

Chaku-moji

You can watch 1Seg (terrestrial digital TV broadcasting service for mobile terminals) on the large display. The screen is swit ched between horizontal and verti cal display each time you open and close FOMA terminal. You can record TV programs or save as still image. In addition, you can schedule TV programs for viewing and use data broadcast. ☛P290

Playing music

FOMA terminal supports Chaku-Uta Full® that allows you to download an entire full-length song, and the import from CDs. Also supported is Windows Media Audio (WMA) to allow you to utilize various music-distribution sites. Downloaded music can be played on Music Player.

ayer

Horizontal screen Vertical screen

Quick Search/Contents/Cautions

Page 18

SAFETY PRECAUTIONS (Always follow these directions)

● Read the following SAFETY PRECAUTIONS to ensure that the phone is used correctly. Also, store this manual in a convenient location for future reference.

● It is essential that these precautions be observed to prevent injury to the user and third parties as well as damage to property.

● The following symbols are used to indicate the degree of danger o r damage that may result from failing to follow the specified precautions.

● The following symbols are used to

highlight instructions that are very important and that must be strictly followed.

This indicates the action is prohibited.

This indicates disassembly is prohibited.

This indicates that handling with wet hands is prohibited.

DANGER

Indicates an imminently hazardous situation, which, if not avoided, will result in death or serious injury.

WARNING

Indicates a potentially hazardous situation, which, if not avoided, could result in death or serious injury.

CAUTION

Indicates a potentially hazardous situation, which, if not avoided, may result in injury or property damage.

This indicates the part must not be exposed to water.

This indicates the action must be performed in accordance with the directions.

This indicates you must remove the plug from the power outlet.

● SAFETY PRECAUTIONS is separated into six categories.

Handling the FOMA terminal, battery pack, adapter (and charger) and the UIM (general

information)...............................................P13

Handling the FOMA terminal.....................P14

Handling the battery pack.........................P15

Handling optional devices (AC adapter/DC

adapter/Desktop Holder/In-Car Holder).... P16

Handling the UIM (FOMA card).................P17

Handling the FOMA terminal in the vicinity

of medical devices.....................................P17

Quick Search/Contents/Cautions

Page 19

Handling the FOMA terminal, battery pa ck, adapter (and charger) and the UIM (general information)

DANGER

Use only DoCoMo-certified battery packs and adapters (and chargers) with the FOMA terminal.

Use of non-specified items could cause the FOMA terminal, battery pack or other devices to leak, overheat, rupture, catch fire or malfunction.

Battery Pack D09 Desktop Holder D12 FOMA AC Adapter 01 FOMA DC Adapter 01 FOMA Dry Battery Adapter 01 FOMA USB Cable with Charge Function 01 FOMA AC Adapter 01 for Global use

･For additional items related to the

compatible products, contact the nearest DoCoMo Shop.

WARNING

Be sure to turn off the FOMA terminal before entering a place such as a gas station that is subject to flammable gases. Do not charge in such a place. Charging could cause fire.

When using Osaifu-Keitai inside a gas station, make sure to turn off the FOMA terminal in advance. (If IC Card Lock is set, cancel the lock and then turn the power off.)

Do not place the battery pack, FOMA terminal, adapter (and charger) or UIM in the microwave oven, high-pressure cooker or other cooking appliances.

Doing so could cause the battery pack to leak, overheat, rupture or ignite, and could damage the circuitry of the FOMA terminal and adapter (and charger), causing overheat, smoke or fire.

Do not attempt to disassemble or remodel. In addition, do not attempt to solder.

Attempting to do so will lead to an accident, such as a fire, injury, or electrical shock and damage the equipment. Doing so may also cause the battery pack to leak, overheat, rupture, or ignite.

Do not use or leave in a place near fire or heaters. Also avoid a high-temperature place exposed to direct sunlight or a car under the scorching sun.

Otherwise, the equipment will get deformed or troubled. The battery pack may leak, overheat, rupture or ignite, and a reduction in performance and life may result. Sometimes, the casing will partly get heated, resulting in an extremely high temperature to get you burnt.

Do not expose to water.

The equipment may overheat, cause electric shock, fire, damage or injury if exposed to water, pet urine or other liquids. Do not use the equipment in locations where it could get wet.

Do not expose to strong shocks by dropping or throwing.

Doing so could cause the battery pack to leak, overheat, rupture or ignite, and damage the equipment, resulting in fire.

Do not let the recharging terminal and external device terminal touch any conductive material, such as a piece of metal or lead. Also do not put any conductive material into the recharging terminal and external device terminal.

The battery can short-circuit, causing fire and damage.

If there is anything wrong (such as strange odor, heat generation, color change, deformation, or the like) during use, battery charge or storage, you should take the following steps immediately.

1. Remove the power plug from the wall outlet or cigarette lighter socket.

2. Turn off the FOMA terminal.

3. Remove the battery pack from the FOMA terminal.

Continuing to use the equipment without taking these steps will cause it to overheat, rupture, or ignite or cause the battery pack to leak.

Quick Search/Contents/Cautions

▲

Page 20

CAUTION

When a child uses the FOMA terminal, first be sure an experienced adult teaches proper usage methods and techniques. Observe the child to determine that they are using the FOMA terminal correctly.

Failure to do so could result in injury.

Do not place on an unstable or tilted surface.

Doing so could cause the equipment to slide off, possibly causing personal injury or damaging the equipment.

Keep out of the reach of small children.

The components can be accidentally swallowed, resulting in injury.

Do not store in locations subject to high temperature, humidity or excessive dust.

Doing so could damage the equipment.

The temperature of the FOMA terminal, battery pack or adapter (and charger) may become high when charging the battery, recording/playing a video, or using videophone, 1Seg, i-mode

ppli repeatedly or for a

or ilong period of time.

If you touch the part with a high temperature directly for a long period of time, redness, itchiness, rash, etc. may arise in your skin depending on your constitution or condition. Be especially careful when you use the FOMA terminal connected to an adapte r (and charger) continuously for a prolonged period.

Handling the FOMA terminal

WARNING

Turn off the FOMA terminal inside an aircraft, hospital or other location where use of mobile phones is prohibited.

The FOMA terminal may interfere with the correct functioning of electronic equipment. If the automatic power on function is used, cancel the setting and turn the power off. Observe any regulations posted in medical facilities. If you have done prohibition acts such as using the FOMA terminal inside an aircraft, you may be punished as stipulated by law.

Quick Search/Contents/Cautions

Turn off the FOMA terminal in the vicinity of electronic equipment that relies on highprecision control or faint signals.

The FOMA terminal may interfere with the correct functioning of such electronic equipment.

･Examples: hearing aids, implanted

cardiac pacemakers, implanted defibrillators, other medical devices, fire alarms, automatic doors and other automatically controlled equipment. Users of such medical equipments should check with the electronic equipment or device manufacturer with respect to the effect of electromagnetic interference.

Do not place the FOMA terminal in a breast or inner pocket if you are carrying or using electronic medical equipment.

The FOMA terminal could cause any medical equipment in its vicinity to malfunction.

People with weak hearts should take care with respect to the setting of the incoming vibrator and ring volume.

The FOMA terminal may affect hearts.

Do not use the FOMA terminal while driving.

From November 1, 2004, using mobile phones while driving is set as the object of penal regulations. Even if you use the handsfree device, park the car in a safe place before using the phone. Use Public mode or Voice Mail Service while driving.

Do not aim the infrared port at eyes and attempt to transmit.

Eyes could be affected. Aiming at other infrared devices and transmitting could cause other devices to malfunction.

When you talk under handsfree settings (with the speakerphone function), be sure to keep a distance between the FOMA terminal and your ear.

Failure to do so could cause the hearing loss.

Do not place the FOMA terminal in an area over an air bag or in an air bag deployment area such as on a dashboard in a vehicle.

If the air bag inflates, the FOMA terminal may hit you and injury and damage to itself could result.

Page 21

If you hear thunder while using the FOMA terminal outdoors, immediately turn the power off and move to a safe location.

Use of the phone in such a situation could expose you to lightning strikes or electric shock.

Use the FeliCa reader/writer function in Japan.

The FeliCa reader/writer function of the FOMA terminal is certified to be compliant with the Japanese radio communication standard. If you use this function overseas, you may be punished.

CAUTION

Do not swing the FOMA terminal around by the strap.

Doing so could cause injury to yourself or a third party or damage the phone.

Rarely, some FOMA terminal users may develop itching, skin irritation or eczema. If such a condition occurs, stop using the FOMA terminal immediately and seek medical attention.

Metal is used in the following components:

Part Material Surface treatment

Speed Selector Aluminum Aluminum stain

Do not allow water or other liquids, pieces of metal or other foreign material to enter into the UIM slot and microSD memory card slot of the FOMA terminal.

Doing so could cause fire, electric shock, or damage to the phone.

Use in certain makes of cars may affect onboard electronic equipment.

Continued use under such conditions could cause unsafe driving. Do not use the FOMA terminal in such a case.

Do not bring magnetic cards near the FOMA terminal.

Magnetic data stored on bank cards, credit cards, telephone cards, and floppy disks may be corrupted or lost.

Do not get your fingers or palm caught between the display and keypad parts when closing the FOMA terminal.

Doing so could cause injury.

When you watch 1Seg, watch in a bright place keeping an appropriate distance from the display.

Failure to do so could damage your eyesight.

Handling the battery pack

■ Check the battery type indicated on the battery pack label.

Indication Battery type

Li-ion Lithium ion battery

DANGER

If electrolyte from the battery pack gets in your eyes, do not rub; instead, rinse immediately wi th copious amounts of clean water and seek medical attentio n.

Doing so could cause the loss of vision.

Do not throw the battery pack into a fire.

Doing so could cause the battery pack to leak, overheat, rupture or catch fire.

Do not attach metallic materials such as wire to the port. Do not carry or store the battery pack together with a necklace or other metallic items.

Doing so could cause the battery pack to leak, overheat, rupture or catch fire.

Do not pierce the battery pack with nails, hammer on it or step on it.

Doing so could cause the battery pack to leak, overheat, rupture or catch fire.

When you attach the battery pack to the FOMA terminal, never attempt to forcefully insert, because it should slide in easily and fit correctly. Check the direction of the battery pack and try again.

Doing so could cause the battery pack to leak, overheat, rupture or catch fire.

Quick Search/Contents/Cautions

▲

Page 22

WARNING

Should any electrolyte from the battery pack come into contact with your skin or clothing, immediately stop using the battery and rinse with clean water.

Failure to do so could ca use ski n injur ies.

Stop charging if it is not possible to fully charge the battery pack within the specified time.

Failure to do so could cause the battery pack to leak, overheat, rupture or catch fire.

If the battery pack leaks or emits strange odors, immediately stop using it, and always keep away from sources of fire.

Failure to do so could cause the battery liquid to catch fire, and the battery pack itself to rupture.

CAUTION

Do not dispose of the battery pack with other regular household waste.

Failure to properly dispose of the battery pack in an environmentally sensitive manner could cause the battery pack to catch fire and damage the environment. Use adhesive tape to cover the terminal of battery pack when it is no longer used and bring it to a DoCoMo Shop after the insulation. Alternatively, you can also dispose of the battery pack in accordance with local regulations.

Handling optional devices (AC adapter/DC adapter/Desktop Holder/In-Car Holder)

WARNING

Use care not to short circuit the recharging terminal when the adapter (and charger) is connected to a wall outlet or cigarette lighter socket. Do not touch the recharging terminal with your hands or fingers, or some other part of the body.

Doing so could cause fire, equipment failure, electric shock or other injury.

Do not touch the adapter (and charger) cord or wall outlet with wet hands.

Doing so could cause electric shock.

Do not use th

e AC adapter and Desktop Holder in bathrooms or other potentially high humidity locations.

Doing so could cause electric shock.

When the adapter (and charger) is not to be used for a prolonged period, disconnect the power plug from the wall outlet.

Failure to do so could result in electric shock, fire, or equipment failure.

Never use the adapter (and charger) when it has a damaged power cord.

Failure to do so could result in electric shock, overheat or fire.

If the adapter (and charger) or holder is exposed to water or other liquid, immediately disconnect the power plug from the wall outlet or cigarette lighter socket.

Failure to do so could result in electric shock, smoke or fire.

When connected to a wall outlet, make sure that the AC adapter does not come into contact with metallic straps or other metal objects and the plug is properly seated.

Failure to do so could result in electric shock, short circuit, or fire.

Use the designated power source and correct voltage.

Use of incorrect voltage could cause fire or equipment failure. When using the FOMA terminal overseas, use the FOMA

AC adapter: 100 V AC FOMA AC adapter for Global use: 100 V to 240 V AC (Always connect to the outlet for internal household use.) DC adapter: 12 V DC, 24 V DC (specific for negative ground

AC Adapter 01 for Global use.

vehicle)

Use only the specified fuse for the DC adapter.

Use of the incorrect fuse could cause fire or equipment failure. Check the instruction manual for details of the correct fuse to use.

The DC adapter is for use with negative ground cars. Do not use it with positive ground cars.

Doing so could result in fire.

Quick Search/Contents/Cautions

Page 23

Be sure the power plug is free of dust.

Failure to do so could cause the equipment to catch fire.

During charging, place the adapter (and charger) and Desktop Holder in a stable location. Do not cover or wrap the adapter (and charger) and Desktop Holder with a cloth or blanket, etc.

Using the equipment under such conditions could cause the FOMA terminal to be detached from the holder, or cause a heat buildup that leads to fire or equipment failure.

Do not touch the FOMA terminal and the adapter (and charger) when hearing thunder.

Contact with the FOMA terminal and adapter could cause you lightning strikes or electric shock.

CAUTION

Disconnect the power plug from the wall outlet or cigarette lighter socket befo r e b e g i n n i n g a n y maintenance.

Failure to do so could cause electric shock.

Disconnect the adapter (and charger) from the wall outlet or cigarette lighter socket by pulling the adapter, not the adapter (and charger) cord or the power cord.

Pulling the cord could damage the cord, resulting in electric shock or fire.

Do not place heavy objects on the adapter (and charger) cord or power cord.

Doing so could cause electric shock or fire.

Handling the UIM (FOMA card)

CAUTION

Take care when removing the UIM (the IC).

Failure to do so could cause injury to hand and fingers.

Handling the FOMA terminal in the vicinity of medical devices

The information given below conforms to the guidelines set forth by the Electromagnetic Compatibility Conference regarding the protection of electronic medical equipment from radio waves emitted by mobile phone units.

WARNING

Turn off the FOMA terminal on packed trains or in crowded places as someone with an implanted cardiac pacemaker or implanted defibrillator may be nearby.

The electromagnetic waves emitted by your phone could affect the function of an implanted cardiac pacemaker or implanted defibrillator.

When inside a medical institution, always remember the following guidelines:

Never take the FOMA terminal inside

･

an operating room, intensive care unit (ICU) or coronary care unit (CCU).

･Always turn off the FOMA terminal in

hospital wards.

･Even in the lobby and other areas,

always turn off the FOMA terminal when electronic medical equipment is nearby.

･Follow the directives of the medical

institution. There may be specific regulations as to items that are prohibited or use of which is restricted.

･If you are using the automatic power

on function, cancel the setting and turn off the power.

If you have an implanted cardiac pacemaker or implanted defibrillator, keep your FOMA terminal at least 22 cm away from it.

The electromagnetic waves emitted by your phone could affect the function of an implanted cardiac pacemaker or implanted defibrillator.

If you are using electronic medical equipment other than implanted cardiac pacemakers or implanted defibrillators at your home or outside the confines of a medical institution, be sure to check with the manufacturer about possible adverse effects caused by electromagnetic interference.

The electromagnetic waves emitted by your phone could affect the function of electronic medical equipment.

Quick Search/Contents/Cautions

Page 24

Handling instructions

General

● Do not get the components wet. The FOMA terminal, battery pack, adapter (and charger) and UIM are not waterproof. Avoid usin g the components in a bathroom or other high humidity areas or locations exposed to rain. If you carry the components, sweat could cause internal corrosion that leads to equipment fail ur e. As a result of investigation, if component failure is found to be water-related, repair is not covered by the warranty and may not be able to be performe d. In such a case, should it be found to be possible to repair the unit, you will be billed for all repairs.

● Clean the components with a soft dry cloth (such as a lens cloth).

• The FOMA terminal display may have a special

coating on it so that the color LCD provides a clear view. Rubbing the display strongly with a dry cloth for cleaning could damage the display. Handle with care and clean the display with a soft dry cloth (such as a lens cloth). Also note that leaving the display with dirt or moisture attached could cause spots or remove the coating on it.

• Using alcohol, thinner, benzene or detergents

could cause the printed text to fade or disappear, or the equipment to become discolored.

● Occasionally clean the terminals with a dry cotton swab. Dirty terminals could cause intermittent contact that could interrupt the flow of power to the unit. Such a situation also causes insufficient charging. Use a dry cloth or cotton swab to clean the terminals.

● Do not place the components near an air conditioner vent. Sudden changes in temperature could cause condensation, leading to corrosion inside the components and equipment failure.

● Do not place the FOMA terminal in locations where it could be exposed to excessive pressure. Do not place it in a bag together with many other things or in your pocket when you sit down as this could exert pressure on the LCD or damage the internal boards, resulting in equipment failure. Damage arising from such causes is not covered by the warranty.

● Carefully read the instruction manuals supplied with the battery pack and adapter (and charger) before use.

FOMA terminal

● Avoid extremely high or low temperatures. Use in an environment with a temperature of 5 to 35 °C and relative humidity of 45 to 85 %.

● If the FOMA terminal is used near a radio, television or general subscriber phone, it could affect such equipment. Use the phone as far away from such equipment as possible.

● With regard to data stored in the FOMA terminal, keep it separately in a memo, etc. so as not to permanently lose important data. NTT DoCoMo cannot be held responsible in any way for the loss of stored data.

● Do not put the FOMA terminal in your back pocket and sit on it. Avoid putting the phone in the bottom of a bag, etc. where it is subject to excessive pressure. Damage may result.

● Do not close the FOMA terminal with the strap held inside. Malfunction or damage may result.

● It is normal for the FOMA terminal to become warm during using or recharging. You can continue to use it while warm.

● Do not aim the camera directly at the sun and leave it. Elements may be discolored or baked.

Battery pack

● The battery pack will gradually wear out. Battery life also depends on how you use the battery pack; it is time to replace it when the usage time is very short even though you fully charge it. The specified battery pack can be purchased separately.

● Recharge the battery pack in locations where the ambient temperature is between 5 °C and 35 °C.

● When using for the first time or after a long period of non-use, be sure to fully charge the battery pack before use.

● The time of use provided by the battery pack depends on the ambient conditions and the condition of the battery pack itself.

● Depending on usage, the battery pack may swell as it nears the end of its life, but this will not cause a problem.

● Do not expose to the direct sunlight and high temperature. Please keep your battery in an airy and cool place. When you do not use your phone for a long period of time, remove the battery pack from the FOMA terminal with the battery used up, put into the packing plastic bag or other container, and keep it.

Quick Search/Contents/Cautions

Page 25

Adapter (and charger)

● Recharge the battery pack in a loca tion wh ere the ambient temperature is between 5 °C and 35 °C.

● Do not recharge in the following locations:

• Locations that are subject to high humidity, dust

or excessive vibration

• Near general subscriber phones, TVs or radios

● It is normal for the adapter (and charger) to become warm during recharging. You can continue charging with a warm adapter.

● When the battery pack is recharged using the DC adapter, always keep the car engine running. Failure to do so could cause the car battery t o run down more quickly than normal.

● When an outlet with falling prevention mechanism is used, check the instruction manual for the outlet before use.

● Do not expose to the strong shock and deform the recharging terminal. Giving the strong shock on an adapter can cause damage.

UIM (FOMA card)

● Do not use excessive force to remove the UIM.

● Do not place an excessive load on the UIM when

inserting it into the terminal.

● The UIM becomes warm during use. This is normal and not a cause for concern.

● Note that any card failures resulting from inserting the UIM in an IC card reader/writer not designated by NTT DoCoMo are the responsibility of the customer.

● Make sure that the ICs are kept clean.

● Clean the UIM with a soft dry cloth (such as a

lens cloth).

● It is recommended that users maintain data stored on the UIM in some other form. If the data should be erased, NTT DoCoMo assumes no responsibility for the loss of any data.

● The UIMs that are no longer used should be returned to a DoCoMo Shop for environmental protection.

● Avoid extremely high or low temperature.

● Take care not to damage, touch, or short-circuit

the ICs to prevent them from losing their data or from malfunctioning.

● Take care not to drop the UIM or give shock to the UIM to prevent it from malfunctioning.

● Do not bend the UIM and place heavy stuff on it to avoid a failure.

Camera

If you should use the FOMA terminal to make a public nuisance, you might be punished under the laws and bylaws such as Japan’s nuisance prevention ordinance.

Please be considerate of the privacy of individuals around you when taking and sending images using camera-equipped mobile phones.

FeliCa reader/writer

● The FeliCa reader/writer function of the FOMA terminal uses faint radio waves that do not require a radio station license.

● The FeliCa reader/writer operates at a frequency of 13.56 MHz. If you use any other reader/writer in the vicinity, keep a distance from it. Also , make sure that there is no other wireless station that uses the same frequency band.

Quick Search/Contents/Cautions

Page 26

About intellectual property rights

Copyrights and portrait rights

Except in cases where reproduction and quoting for private use is sanctioned under copyright laws, the reproduction, alteration and public transmission of such content as text, images, music or software for which another party owns the copyrights, whether accomplished by using this product to photograph or record that content or by downloading it from Internet websites, is prohibited without the permission of the owner. Taking photographs or recordings of such events as performances and exhibitions may be prohibited even for purposes of private use. In addition, if you use this product to take another person’s photograph without their permission, or display such a photograph without their permission on an Internet website and make that content public to an indeterminate number of people, you may be in violation of portrait rights.

Trademarks

Company names and trade names used in this manual are the trademarks or registered trademarks of their respective companies.

･ FOMA, mova, i-motion, i-mode, i-

i-shot, DoPa, mopera, mopera U, WORLD CALL, WORLD WING, Short Mail, Chaku-motion, Decomail, V-live, i-area, Chara- den , iNetwork, ToruCa, DCMX, visualnet, i-Channel, PushTalk, PushTalkPlus, iD, FirstPass, sigmarion, Security Scan, musea, Public mode, My DoCoMo, IMCS, OFFICEED, the FOMA logo, the i-mode logo,

ppli logo, the DCMX logo, and the iD logo are

the itrademarks or registered trademarks of NTT DoCoMo, Inc.

･ “Catch Phone (Call waiting service)” is a registered

trademark of Nippon Telegraph and Telephone Corporation.

･ Free Dial logo mark is a trademark of NTT

Communications Corporation.

･ McAfee

is registered trademarks or trademarks of McAfee, Inc. and/or its affiliates in the US and/or other countries.

･ G-GUIDE, G-GUIDE MOBILE and

their logos are registered trademarks in Japan of U.S. Gemstar-TV Guide International, Inc. and/or its affiliates.

ppli, i-motion mail,

ppli DX, Dual

･ is a registered trademark of FeliCa Networks,

Inc.

･QR code is a registered trademark of Denso Wave

Inc.

･The microSD logo is a trademark. ･“Multitask” is a registered trademark of NEC

Corporation.

･QuickTime is a registered trademark of Apple

Computer, Inc. in the US and other coun tries.

･Microsoft

, Windows®, Windows Media® and

PowerPoint Corporation in the United States and/ or oth er countries.

are registered trademarks of Microsoft

･Java and all Java-related trademarks are trademarks

or registered trademarks of Sun Microsystems, Inc. in the United States and other countries.

･“ATOK” and “APOT” (Advanced Prediction

Optimization Technology) are registered trademarks of Justsystem Corporation.

･“Privacy Mode” is a registered trademark of

FUJITSU Limited.

･“Napster” is a trademark of Napster, LLC that may

be registered in the US and/or other countries.

･TOEIC is a registered trademark of Educational

Testing Service(ETS).

･In addition to the above, company names and trade

names used in this manual are the trademarks or registered trademarks of their respec tive compani es.

Other rights and responsibilities

This product contains Flash® LiteTM of Adobe

･

Systems Incorporated. Adobe, Flash and Flash Lite are trademarks or registered trademarks of Adobe Systems Incorporated in the US and other countries. Copyright© 1995 - 2007 Adobe Systems Incorporated. All rights reserved.

･This product contains Adobe Reader of Player

technology of Adobe Systems Inc. Copyright© 2007 Adobe Systems Incorporated. All rights reserved. Patents pending. Adobe, the Adobe logo and Reader are either registered trademarks or trademarks of Adobe Systems Incorporated. Adobe and Adobe Reader are trademarks or registered trademarks of Adobe Systems Incorporated in the US and other countries.

Quick Search/Contents/Cautions

Page 27

･ This product contains NetFront of ACCESS CO.,

LTD to provide Internet function. This product contains NetFront DTV Profile Wireless Edition of ACCESS CO., LTD as a BML browser for data broadcast. This product contains Media: of A CCESS CO., LTD to provide function to quickly start data broadcast. Copyright© 1996-2007 ACCESS CO., LTD. ACCESS, NetFront and Media: are trademarks or registered trademarks of ACCESS CO., LTD. in Japan and other countries.

･ This product contains a module developed by the

Independent JPEG Group.

･ Powered by JBlend

･ＦｅｌｉＣａ is a contactless IC card technology

developed by Sony Corporation. ＦｅｌｉＣａ is a registered trademark of Sony

Corporation.

･ This product is licensed based on MPEG-4 Visual/

AVC Patent Portfolio License. The use of MPEG-4 Video Codec function is allowed for personal and nonprofit use only in the following cases:

･ Recording videos that conform to MPEG-4 Visual/

AVC Standard

･ Playing videos that conform to MPEG-4 Visual/

AVC Standard recorded personally by consumers not engaged in profit activities

･ Playing MPEG-4 Videos obtained from the

provider licensed from MPEG LA

For further utilizing such as promoti on, in-ho use use or profit-making business, please contact MPEG LA, LLC in the US.

･ Licensed by QUALCOMM Incorpo rated under

one or more of the following United States Patents and/or their counterparts in other nations;

4,901,307 5,504,773 5,109,390 5,535,239 5,267,262 5,600,754 5,416,797 5,490,165 5,101,501 5,511,073 5,267,261 5,568,483 5,414,796 5,659,569 5,056,109 5,506,865 5,228,054 5,544,196 5,337,338 5,657,420 5,710,784 5,778,338

･ Powered By Mascot Capsule

Mascot Capsule® is a registered trademark of HI CORPORATION.

/Micro3D Edition

･

This product includes software licensed from Symbian Software Ltd. ‘Symbian’, ‘Symbian OS’ and other associated Symbian marks are all trademarks of Symbian Software Ltd. ©1998-2007 Symbian Software Ltd. All rights reserved.

･Microsoft

Excel and Microsoft® Word are product names of Microsoft Corporation in the United States. In this manual, they are referred to as Exce l and Word.

･Word, Excel and PowerPoint file

display technologies are powered by Picsel Technologies Ltd. Picsel, Picsel File Viewer and the Picsel cube logo are trademarks or registered trademarks of Picsel Technologies Ltd.

･“Meikyo Mobile Japanese Dictionary”, “G-Mobile

English-Japanese Dictionary” and “G-Mobile Japanese-English Dictionary” are copyrighted works of TAISHUKAN Publishing Co., Ltd.

･In this manual, each OS (Japanese version) is

written for short as follows:

･ Windows XP is the abbreviation for Microsoft

･ Windows 2000 is the abbreviation for Microsoft

Windows Microsoft system.

Windows

XP Professional operating system or

Windows® XP Home Edition operating

2000 Professional operating system.

･ It may describe like Windows XP and 2000 in

parallel.

･Content owners use Windows Media digital rights

management technology (WMDRM) to protect their intellectual property, including copyrights. This device uses WMDRM software to access WMDRMprotected content. If the WMDRM software fails to protect the content, content owners may ask Microsoft to revoke the software’s ability to use WMDRM to play or copy protected content. Revocation does not affect unprotected content. When you download licenses for protected content, you agree that Microsoft may include a revocation list with the licenses. Content owners may require you to upgrade WMDRM to access their content. If you decline an upgrade, you will not be able to access content that requires the upgrade. This product is protected by certain intellectual property rights of Microsoft. Use or distribution of such technology outside of this produ ct is prohibited without a license from Microsoft.

Quick Search/Contents/Cautions

Page 28

Basic package and optional accessories

Basic package

FOMA D903iTV (including the written warranty and the Back Cover D16)

Watch Television via Your D903iTV (attached)

Watch Tel evision via Your D903iTV

Optional accessories

Instruction manual (this book)

Manual

Quick Reference Manual ☛P476

1Seg Antenna with Strap for storage D01 (including the instruction manual)

CD-ROM for FOMA D903iTV

The PDF version of “Manual for Data Communication” and “Kuten Code List” is contained.

Earphone Plug Adapter with Built-in 1Seg Antenna D01 (including the instruction manual)

FOMA AC Adapter 01 (including the written warranty and the instruction manual)

･ Other optional acces sories ☛P446

Quick Search/Contents/Cautions

Desktop Holder D12 (including the instruction manual)

Battery Pack D09 (including the instruction manual)

Page 29

Before Using D903iTV

Names and functions of parts .........................................................................24

Reading the display .................................................... ..................... .................27

Selecting the menu ...........................................................................................30

Using the UIM (FOMA card) .............................................................................35

Attaching/removing the battery pack .............................................................38

Charging the battery of FOMA terminal ..........................................................39

Checking the remaining battery level .................................... Battery Level 42

Turning the power on/off ..................................................... Po w e r ON/ O FF 43

Switching to English display ............................................ Select Language 43

Setting the date and time ......................................... Date and Time Setting 44

Notifying your phone number to the other party ..... Caller ID Notification 45

Checking your own phone number ........................................ Own Number 46

Page 30

Names and functions of parts

st v w

i j

c d e f

a Earpiece

The other party’s voice comes out of here.

b Display ☛P27 c mMenu/Upper left soft/Silent Mode key

Use this key to display menus, perform the operation shown in the upper left part of the guide row, etc. Hold down for over a second to set/ cancel Silent Mode.

d tSpeed Menu/Start videophone/Scroll/

Lower left soft key

Use this key to display Speed Menu, make/answer videophone calls, scroll mail or site display by a page, switch between upper/lower cases when entering characters, perform the operation shown in the lower left part of the guide row, etc.

Start voice call/Speakerphone/Character key

Use this key to make/answer voice calls, turn on/ off the speakerphone function, mute the sound while viewing 1Seg or playing 1Seg videos, switch input modes when entering characters, etc. Hold down for over a second to switch to the sound mode while viewing 1Seg programs or playing 1Seg videos.

f c i-channel/Clear key

Use this key to display the channel list, start ion the i-

ppli standby display, delete characters, return to the previous screen, etc. Hold down for over a second to set/cancel Self Mode.

g Dial keys

0 to 9

Used to enter phone numbers and text and to select menu items.

( /Public mode (Driving mode) key

Use this key to enter “ ”, etc. Hold down for over a second to set/cancel Public mode (Driving mode).

Before Using D903iTV

l m n

t E

A B

Size (mm)

: 110 (H) x 48 (W) x 19.8 (D)

(when closed)

Weight (g)

: Approx. 118 (with battery pack)

##/Silent Mode/Line-feed key

Use this key to enter “＃”, start a new line when entering characters, etc. Hold down for over a second to set/cancel Silent Mode.

h Microphone

Picks up your voice.

i Infrared data port ☛P348

Exchange data via infrared communication.

j In-camera ☛P82, P168

Used to shoot yourself and send your image during a videophone call.

Speed Selector

･You can rotate the Speed Selector to operate it.

☛P26

oEnter key

Use this key to perform the selected operation, activate Focus Mode, etc. Hold down for over a second to start i-

uData Box/↑ key

Use this key to display the Data Box menu, move the cursor upward, adjust volume, etc. Hold down for over a second to activate Still Camera.

ppli

di-mode/i-

Use this key to display the i-mode menu, move the cursor downward, adjust volume, etc. Hold down for over a second to display the i-

lReceived Calls/←(previous) key

Use this key to display the received call history, switch between pages, move the cursor leftward, etc. Hold down for over a second to set/cancel Privacy Mode.

rRedial/→(next) key

Use this key to display the redial data, switch between pages, move the cursor rightward,

ppli/↓key

ppli folder list.

ppli set for One-key Shortcut.

Page 31

etc. Hold down for over a second to set/ cancel IC Card Lock.

l pPhonebook/Schedule/Upper right soft key

Use this key to display the phonebook, perform the operation shown in the upper right part of the guide row, etc. Hold down for over a second to display schedules.

Mail/Scroll/Lower right soft key

Use this key to display the Mail menu, scroll mail or site display by a page, perform the operation shown in the lower right part of the guid e row, etc. Hold down for over a second to pe rform Check i-mode Message.

n fPower/End key

Use this key to end calls or functions in operation, place incoming calls on hold, cancel Secret Mode, switch displaying/not displaying the custom standby display, etc. Hold down for over 2 seconds to turn the power on/off.

o External connection terminals ☛P40, P343

Used to connect various optional accessories.

p FeliCa mark

The mark means that a piece of IC card is mounted. Use IC card functions by placing the FeliCa mark over the reader/writer. Also, perform iC communication between 2 terminals by holding the FeliCa mark over each other. The IC card cannot be detached.

q Macro mode switch ☛P179

Switches between the standard mode and the macro mode while shooting with the out-camera.

r FOMA antenna (built-in)

The antenna is embedded.

s Back cover t microSD memory card slot ☛P335 u Camera indicator

Lights or flashes when shooting with t he camera.

v Out-camera ☛P82, P168

Used to shoot people or landscape and send these images during a videophone call.

w Strap opening x Speaker

Ring alert, 1Seg sound and other sounds including the other party’s voice when using the speakerphone function come out of here.

y 1Seg antenna/Earphone/microphone jack

Used to connect the supplied 1Seg antenna or the Flat-plug Earphone/Microphone with Switch (optional).

･Connecting the 1Seg antenna ☛P291

z k Keylock switch ☛P160

Hold down this key for over a second to set/ cancel Key Lock.

A bTASK key

Use this key during Multiaccess or Multitask.

B CTV/Answer Machine/Shutter key

Use this key to display the Answer Machine/Voice Memo menu, release the shutter of the camera, stop ring alert/alarm, etc. Hold down for over a second to start Quick Record Message, activate 1Seg viewing, switch between normal display and anti-peeping display (Only View) of the mail view screen.

C One-push open button

Use this button to open FOMA terminal.

D gPushTalk button ☛P89

Use this button to display the PushTalk phonebook, make/answer PushTalk calls and speak during PushTalk.

E Charging terminals

Used when charging FOMA terminal in the Desktop Holder (optional).

･ For the keys explained in g, the typestyle of

characters is different depending on the color of the terminal. (Example: , )

･ o explained in k lights or flashes when a call or

mail is received, FOMA terminal is opened/closed, the Speed Selector is rotated, etc. The lighting pattern and color can be set (☛P144). Also, it flashes when there is new information (☛P146), and lights in red during charging.

Connecting the Earphone/Microphone with Switch

･ You can plug in the Flat-plug Earphone/Microphone

with Switch (optional) and use it. Using the Earp hone Plug Adapter P001 (optional) allows you to use an existing earphone/microphone.

Opening/closing FOMA terminal

To open FOMA terminal, press the one-push open button. To close it, slide the front face (with the display) downward.

One-push open button

Open

･Operations such as ac cessing the screen to

reply to mail or to edit schedules or notes are made easily by opening FOMA terminal. ☛P375

･FOMA terminal allows you to make calls without

opening it. You can also answer an incoming call by opening FOMA terminal and end or put on hold the call by closing it. ☛P67

･Please note that if you open the terminal by

force without pressing the one-push open button or open and close it violently, it will cause the damage of the terminal.

Before Using D903iTV

Page 32

Using the Speed Selector

You can rotate the Speed Selector as well as press o and O to operate it. The operation performed by rotating the Speed Selector varies by the screen.

Operating on the standby display

Display the menu, phonebook or schedule screen, or switch images on the standby display by rotating the Speed Selector. ☛P131

Operating on a screen other than the standby display

Depending on the screen, the same operation as pre ssing % or & is available. Rotating the Speed Select or moves the highlighted item or scrolls t he screen accor ding to how much th e Speed Select or is ro tated. Th is allows you to operate quickly. As the rotating direction, Clockwise or Anticlockwise can be set in Speed Selector Setting.

Direction setting Moving / scrolling operation

List screen List screen View screen Character entry

Clockwise

Anticlockwise

Highlights an item

･While receiving or talking on a voice/videophone/PushTalk call, rotating the Seed Selector adjusts the ring

volume or the earpiece volume. Also, you can adjust the playback volume by rotatin g the Speed Se lector on the player screen of Music Player.

･You can zoom in and out by rotating the Speed Selector on the shooting screen of camera. ･While watching 1Seg, rotating the Speed Selector and pressing o switches channels. ･You can zoom in and out the display by rotating the Speed Selector on PDF Viewer or Document Viewer. ･In entry fields for date/time and number, rotating the Speed Select or increases and decreases values.

However, this operation is unavailable in some entry fields.

･While reversing/rotating a still image, rotating the Speed Selector rotates the image.

Highlights a pictogram

Scrolls Moves the cursor

screen

INFORMATION

● In the following cases, no operation is performed by rotating the Speed Selector but pressing % or & is enabled:

･Displaying sites by shortcuts on the dial input screen ･ Using Calculator ･Moving the cursor, frame (for changing size or clipping) or stamp while editing still image ･The display is off ･ Playing 1Seg videos (except when skipping)

Setting the Speed Selector Speed Selector Setting

Set the rotating operation of the Speed Selector.

Default Speed selector: ON Direction: Clockwise Use at stand-by disp: Menu

m867

Select each item to set

Speed selector：Set whether to enable the rotating operation of the Speed Selector.

Before Using D903iTV

Page 33

Direction： S et the rotating direction of the Speed Selector. Select Clockwise or Anticlockwise. Use at stand-by disp：

Select the function to be executed when the Speed Selector is rotated on the standby display.

･When Menu is set, the menu appears. ･When Phonebook is set, the phonebook list appears. ･When Scheduler is set, the calendar screen of Scheduler appears.

Press p

･When Change image is set to Speed selector in Random Display Image, if you set Use at stand-by disp to

other than OFF, a confirmation screen appears asking whether to enable this sett ing. When you select Yes, Random Display Image is canceled and the default standby display appears.

INFORMATION

● Even if Speed selector is set to OFF, some i-

selector is set to ON and Speed selector in Settings (for i-

by rotating the Speed Selector.

● When adjusting the volume, zooming in and out on the shooting screen, PDF Viewer or Document Viewer, or increasing

and decreasing values, the setting for Direction is disabled. In this case, rotating the Speed Selector to the right increases the volume/display magnification/value and rotating to the left decreases it. In addition, the setting for Direction is disabled for some i-

ppli.

ppli may be operated by rotating the Speed Selector. And even when Speed

ppli) is set to other than OFF, some i-αppli cannot be operated

Reading the display

The description of icons displayed at the top or the bottom of the display is shown below:

a - l

Date, day of the week and time

m n - y

Received i-channel information ☛P212

a : Battery level icon ☛P42 b : Signal level icon ☛P43

: Out of service area ☛P43 : Self Mode is set ☛P156 : During data transfer ☛P332, P348

DoCoMo keitai datalink in progress ☛P410

c : In i-mode communication (during

i-mode connection) ☛P188

: In i-mode communication (during

packet communication) ☛P203, P228

d : During infrared communication ☛P348

Infrared remote control function in operation ☛P352

: Key Lock is set (in gray when Key Lock

is temporarily released) ☛P160

：Total call cost exceeds the maximum

limit ☛P391

e : Speakerphone function in operatio n

☛P51

: Connecting to handsfree compatible

device ☛P63

f ：Accessing the phonebook on the

network (PushTalkPlus) ☛P88

：During PushTalk calls ☛

: i-mode Mail and Message R/F storage

P88

space is full in the Center*2 ☛P229, P203

: i-mode Mail or Message R/F storage

space is full in the Center

: Both i-mode Mail and Message R/F exist

unreceived in the Center

: i-mode Mail or Message R/F exists

unreceived in the Center

g : Unread i-mode Mail and/or SMS fills

storage space and also SMS storage space is full on UIM ☛P256

Before Using D903iTV

▲

Page 34

: Unread i-mode Mail and/or SMS fills

storage space ☛P229, P256

: SMS full on UIM ☛P256 : Unread i-mode Mail and SMS exist

☛P228,

: Unread i-mode Mail exists ☛P228 : Unread SMS exists ☛P255

P255

(blue)/ (red)

: Unread Message R exists/fills storage

space*3 ☛P203

(green)/ (red)

: Unread Message F exists/fills storage

space*3 ☛P203

h : i-αppli running ☛P263

: i-

ppli standby display on ☛P132

: Starting i-

ppli from the i-αppli standby

display ☛P272

: i-

ppli DX running ☛P263

: i-

ppli DX standby display on ☛P132

: Starting i-

ppli from the i-αppli DX

standby display ☛P272

i : Displaying SSL page, using i-αppli

downloaded from SSL pages and in SSL communication with i-αppli ☛P189 Displaying SSL/TLS page ☛P304

: Auto-send failure mail exists ☛P227 : Auto-send mail exists ☛P227

j : Secret Mode is set ☛P161 k : i-αppli Auto Start failed ☛P271 l : In OFFICEED service area ☛P406

m : Focus Mode icon ☛P34 n : General silent mode is set ☛P127

: Personalized silent mode is set ☛P128

o : Call alert volume is set to silent ☛P68

: Vibrat or for incoming voice call is set

: Call alert volume is set to silent and

vibrator for incoming voice call is set

p : Public mode (Driving mode) is set

☛P72

q : Answer Machine is set ☛P75

: Recorded messages full ☛P75

r : PIM Lock is set ☛P156 s : Connecting to external device via the

FOMA USB Cable (optional) ☛P86, ☛P343

: Effective Speed Selector keys in Focus

Mode ☛P34

u : The communication mode is set

(microSD memory card inserted) ☛P343

/ (blue/gray)

: The microSD mode is set (microSD

memory card inserted/not inserted) ☛P343

/ (blue/gray)

: The MTP mode is set (microSD

memory card inserted/not inserted) ☛P343

v : Reading the UIM ☛P43

: IC Card Lock is set ☛P286

w : Keypad Dial Lock is set ☛P157 x : Alarm Clock is set ☛P376

: Schedule alarm is set ☛P297, P380 : Alarm Clock and schedule alarm are

set simultaneously

y : Software Update reserved ☛P462

/ (succeeded/failed)

: Result of auto-update of the latest

pattern definition ☛P465

☛P126

*1 The current highest priority item is displayed. These icons are listed in the order of priority from the top. *2 Displayed also when the storage space for either i-mode Mail or Message R/F is full and also unreceived mails/

messages exist.

*3 Displayed overlapped on the icon indicating presence of unread i-mode Mail/SMS

Reading the guide row

Operations that can be executed by pressing m, t, o, p and a are displayed in the guide row.

Example

Guide row for the mail message entry screen

The display positions and the keys correspond as shown in the figure. In

Guide

this manual, the operations displayed in the guide row are explained using

row

the corresponding keys (mtopa). The operations displayed in the guide row differ depending on the screen.

･ on the guide row corresponds to O of the Speed Selector (it may be

different depending on the function, i-mode site or website in use).

Before Using D903iTV

Page 35

Reading the task bar

The icon indicating the function (task) in progress appears on the task bar (up to 9 icons). You can confirm functions being used and run. In addition, when receiving mails/messages, the reception result scrolls.

･While entering characters, the input mode appears on the task bar. ☛P412

Task bar (when Scheduler is displayed du ring a voice call)

: Voice call / : Videophone (64K/32K) : Switching voice/videophone

call : Ending call : Videophone call through

external device : Adjusting volume using

Multitask : PushTalk : Phonebook : Received Calls : Redial : Answer Machine/Voice Memo : Own Number : Mail : Receiving i-mode Mail/

Message R/F : Receiving SMS : Chat Mail : Message R/F : Sent Msg. Log : Received Msg. Log : Check i-mode Message/SMS : i-mode/i-channel

Reading the list screen

Example

The setting screen for Color Scheme

: i-mode Bookmark/Internet

Connection/Screen Memo/

i-mode Shortcut : i-αppli : ToruCa

: Full Browser

: My Picture : i-motion : Melody

: PDF Viewer : Document Viewer

: Chara-den

: Machi-chara : Kisekae tool

: Still Camera : Movie Camera

: Sound Recorder

: Bar Code Reader

: Music Player : Viewing 1Seg : Recording 1Seg : 1Seg Image/Video

: Timer : Setting Alarm Clock/alarm

clock sounding

: Scheduler/Booking Program

List : Schedule alarm sounding : Notepad : Calculator

: Dictionaries : Data exchanging through

external device

/ (dark blue /g ra y) : Accessing/waiting for access

to the microSD memory card

: 64K data communication / : Originating/communicating/

sending/receiving packet vi a

USB

/ (dark blue/gray) : Setting/holding each function : Software Update activated : Software Update notified : Update Definition activated/

version display

: Setting each network service : Accessing Data Center : Displaying communication

log with Data Center

The number of the currently displayed page and the total number of pages (when a list extends over multiple pages)

indicates that other selectable items exist above and below the highlighted item.

･ Press % to move the cursor. ･ If you press d on the last item of the page, the next page appears, and if you press

on the first item of the page, the previous page appears.

indicates that selectable items exist over multiple pages.

･ Press & to switch between pages.

･ You cannot switch between pages on the icon selection screen, etc.

Before Using D903iTV

▲

Page 36

INFORMATION

● Note that the following cases may occur due to the characteristics of liquid crystal display (LCD) and they are not

defects in FOMA terminal.

･FOMA terminal display is manufactured by taking advantage of highly advanced technology but some dots may be

always or never lit.

･When the battery pack is removed from FOMA terminal with the power turned on, residual images may remain for

some time. Remove the battery pack with the power turned off.

･When a screen has been displayed for a certain time, if you change it to another screen by performing some

operations, residual images of the previous screen may remain.

Selecting the menu

There are 2 types of the menu: normal menu and custom menu. When you press m, either the normal or custom menu appears according to the setting of Default MENU in Menu Setting.

･For normal menu, the simple menu which offers popular features can be set (Menu Setting ☛P139). ･With custom menu, you can create your original menu. ☛P385 ･You can call up some functions quickly using Speed Menu. ☛P387

Menu display format

The menu display format can be selected from the following types. By default, Animation of the normal menu is set.

Animation*

List view*

*1 The screen is an example of the normal menu displayed when Style Theme is set to White. *2 Can also be set for the custom menu (Menu Setting ☛P139). *3 Can only be set in the Japanese display. Switch to the Japanese display before setting the simple menu.

Before Using D903iTV

Select List view

z p

Select Tile display

z p

Tile display*

Select

Select 3D display

z p

3D display*

Simple menu*

menu)

シンプル

z p

(Simple

Page 37

Selecting functions from the menu

Select menu items by the dial keys (Shortcut operations). Also, use the Speed Selector to select menu items.

･In this manual, the operation procedure is explained mainly in shortcut operations using the normal menu

(except the simple menu).

･When any lock function is set or the UIM is not inserted, some functions are disabled. The disabled

functions are indicated by or dimmed. However, if the menu display format is set to Animation, a message appears when menu items for the disable functions are selected.

Selecting menu items with the dial keys (Shortcut operations)

Each menu item has a number (item number) and can be select ed by pressing t he correspondi ng key. In the 3D display menu, use the same item numbers as the tile display, list view or animation menu.

Example

Executing Phonebook new entry from the normal menu (except the simple menu)

Press m42

The phonebook registration screen appears.

When several shortcuts are available

When there are multiple shortcut operations available with the normal menu (except the simple menu), the shortcut operations other than described in the operat ing procedu re are shown at th e far right of the titl e in the body text.

Example

the PushTalk phonebook

shTalk. You can register them in different groups.

tered (or fewer depending on the type of data registered). egistered in the FOMA terminal phonebook in advance to be registered in the

Performing PushTalk Phonebook New Entry

PushTalk Phonebook New Entry

Menu 44

Press m to show the menu, then press 44 to show the PushTalk phonebook. ･! means pressing a, and ? means pressing d.

Before Using D903iTV

▲

Page 38

Selecting menu items with the Speed Selector

Example

■ Selecting menu items (List view)

■ Selecting menu items (Tile display)

Press O to highlight a menu item and press o.

･To return to the previous menu: c

■ Selecting menu items (3D display)

Press & to bring the desired item to the front of the icon ring and press o.

･Press % to move the the icon at the rear to the front.

Executing Phonebook new entry from the normal menu (Type2 of animation menu)

m z O to highlight Phonebook & Logs z o

･ To return to the previous screen: c ･ To return to the standby display: f ･ Highlighting the desired menu item in other than the animation menu shows

the description of the item’s function.

･ In case of the animation menu, in the guide row does not appear. ･ In case of the animation menu, the operations of O differ depending on the

animation design.

Phonebook & Logs is highlighted

O to highlight Phonebook new entry z Press o

The phonebook registration screen appears.

Menu item that has been highlighted

Menu item that cannot be selected (dimmed)

Lower-level menu exists.

Press % to highlight a menu item and press o or r.

･ To return to the menu of previous level: l or c

Selecting functions from the submenu

When MENU is displayed at the upper left of the guide row, you can use the submenu to perform various operations.

Example

Displaying the Redial submenu

m in the redial list z % to highlight a submenu item z Press o or r

･Selecting menus in the submenu is the same as in

the list view menu.

･To close the submenu: m

Shows that a submenu exists.

Before Using D903iTV

Page 39

Setting each item on the screen

Selecting Yes or No on the confirmation screen

% to highlight Yes or No z Press o

Selecting an item from the pulldown menu

% to highlight an item z o to display the pulldown menu z % to highlight an item

z Press o

Selecting an item from the check box

% to highlight a check box z Press o

･For some functions, items other than Yes or No may appear.

･ You can select an item by the dial key for the item number.

Pulldown menu

The check box changes from to , and is selected.

･Select the selected item to cancel the selection. The check box changes from

to .

･Depending on the function, you can select/cancel all items by pressing m. ･You can select an item by the dial key for the item number.

Before Using D903iTV

Page 40

Displaying information quickly Focus Mode

When the icons such as or are displayed on the standby display, you can quickly display the information.

o z & to highlight an icon such as or z Press o

The screen corresponding to the selected icon appears.

Missed call exists: The received call list appears, letting you check the date and time, the caller information, etc.

Unplayed recorded message exists: The recorded message list appears, letting you pla y the re co rded me ssage s.

Voice mail message exists: The confirmation screen for playing voice mail messages appears, letting you play the messages.

Unread received mail exists: The received mail folder list appears, letting you check unread mail.

Unread ToruCa exists:

The number of stored items is indicated at the right of each icon.

In Focus Mode, the color of the highlighted icon changes.

INFORMATION

● When you highlight an icon and hold down c for over a second, the icon temporarily disappears from the screen. It

reappears when new information is stored or the number of stored items changes by viewing information, etc. For the icon indicating voice mail messages, however, a confirmation screen appears asking whether to clear the icon. Select Yes to clear it temporarily.

The ToruCa list appears, letting you check unread ToruCa.

/ (succeeded/failed) Auto-update result of the latest pattern definition exists:

The result can be checked. ☛P465 Being connected to external device via the FOMA USB Cable (optional): The setting for USB Mode Setting can be changed. ☛P342

･ When , or is displayed: o z O to highlight the icon z o ･ To cancel Focus Mode: c or f

Before Using D903iTV

Page 41

Using the UIM (FOMA card)

The UIM (FOMA card) is a card in which you r phone number and other information are recorded. Insert the UIM into FOMA terminal to use it.

･For details on handling the UIM, refer to the UIM manual.

Inserting/removing the UIM

Use your FOMA terminal with the UIM inserted. If the UIM is not inserted in your FOMA terminal, first insert it.

･Turn the power off before inserting or removing the UIM. ･Insert or remove the UIM with FOMA terminal closed using both hands.

Inserting the card

Tray is pulled out until it stops.

Tray

Cut corner

UIM

Removing the card

aPull out the tray.

･ The operations are the same as a to b in

“Inserting the card”.

bRemove the UIM by sliding it out.

Cut corner

aRemove the back cover and then

the battery pack. ☛P38

bPull out the tray.

Place your finger on the tray and slide it out until the tray stops.

cWith the IC side of the card

facing down, slide the UIM on the tray to match the cut corner of the UIM to the cut corner of the tray.

dPush the tray in until it stops. eReattach the battery pack and

then the back cover. ☛P38

When the UIM tray is removed

Insert and push the tray straight in.

● Remove the UIM before replacing the tray.

INFORMATION

● Insert or remove the UIM carefully as forcing it may damage the card.

● Carefully handle the removed UIM so that it does not become lost.

● When attaching the battery pack, make sure that the UIM tray is in place. If not, you cannot attach the battery pack.

Forcibly attaching the battery pack may damage the UIM or the tray.

● When pushing the UIM tray in, make sure that the UIM is properly placed in the tray. Forcibly pushing the tray into

FOMA terminal may cause an operation error.

Before Using D903iTV

Page 42

UIM security codes

The PIN1 and PIN2 codes are used for the UIM. Both codes are set to “0000” at the time of subscription to the FOMA service. You can change this to any code (4 to 8 digits). ☛P152

UIM operation restriction function

FOMA terminal is provided with the UIM operation restriction function for protecting your data and files.

･When the data or files downloaded from sites or the data attached to mail are saved in FOMA terminal with

the UIM inserted, the UIM operation restriction is automatically set to these data or files.

･If the UIM is replaced by another UIM or is removed from FOMA terminal, the data or files with the UIM

operation restriction set cannot be displayed or played, copied/moved to the microSD memory card or exchanged by infrared/iC communication. However, i-motion compatible with Movable Contents can be moved to the microSD memory card.

･The data which is subject to the restriction is as follows:

・File attached to i-mode Mail (excluding ToruCa) ・Screen memo ・Message R/F ・Image inserted in Deco-mail or signature ・Data compatible with Movable Contents ・i- ・i-motion ・Image (including animation and Flash movie) ・Chara-den ・Machi-chara ・Chaku-Uta Full

・PDF data ・Word/Excel/PowerPoint data ・Kisekae tool ・Recorded message of videophone call ・Video memo ・Image of ToruCa (details) ・Mail template containing data which is subject to the operation restriction

･For i-

ppli with the UIM operation restriction set, if the UIM is replaced by another UIM or is removed from

FOMA terminal, only deleting and protecting the i-

ppli (including the i-αppli standby display)

・Melody

ppli are possible.

INFORMATION

● When the data with the UIM operation restriction enabled is set for the standby display, call image or ring alert, if the

UIM is replaced by another UIM or is removed from FOMA terminal, the image and sound settings return to the default. In this case, the image and sound that are actually displayed/generated may differ from the settings. Inserting the UIM that was used when the data was downloaded cancels the operation restriction and restores the original settings. (Note that the setting of Random Display Image may be canceled if the data was used for it.)

● The UIM operation restriction is not set to the data obtained via infrared/iC communication, the microSD memory card or

DoCoMo keitai datalink, or to the still images or videos taken with the built-in camera.

● When the UIM is inserted in other i-channel compatible terminals, the i-channel information is not displayed as ticker on

the standby display. After that, if the information is updated automatically or if you press c on the standby display to display the channel list, the latest information is received and then displayed as ticker on the standby display.

● When the UIM is not inserted, the i-channel information is not displayed as ticker on the standby display.

Before Using D903iTV

Page 43

Settings saved into the UIM

The following settings are saved into the UIM. If the UIM is replaced, the settings of the new UIM become effective.

･My phone number ･DoCoMo certificate and user certificate set in Manage Certificate ･SMS Setting (except SMS report request) ･Select Language ･The PIN1/PIN2 code of the UIM and PIN1 Code ON/OFF

Functional differences between the UIM types

There are the following functional differences between the UIM (blue) and the UIM (green/while) when used in FOMA terminal:

Item UIM (blue) UIM (green/white) Page

Number of digits of a phone number that can be registered in the UIM phonebook

Certificate Download for using FirstPass Unavailable Available P207 WORLD WING service Unavailable Available P37 Service Dialing Number Unavailable Available P404

WORLD WING

WORLD WING is the DoCoMo international roaming service for FOMA that allows you to make and receive calls with the same mobile phone number overseas by inserting the UIM (green/white) in a FOMA terminal compatible with WORLD WING or in a W-CDMA or GSM mobile phone for overseas use.

● If you subscribed to the FOMA service on and after September 1, 2005, no subscription is required to use WORLD WING. However, if you requested not to subscribe to it at the time of subscription to the FOMA service or have canceled the subscription, a subscription is required.

● If you subscribed to the FOMA service on and before Au gust 31, 2 005 but have not sub scribed to WORL D WING, a subscription is required.

● This service cannot be used with some billing plans.

● If you lose the UIM (green/white) or have it stolen overseas, contact DoCoMo immediately to ha ve the card

suspended. For contact information, refer to “General Inquiries” on the back of this manual. Note that any call or communication charges incurred after the UIM is stolen will be borne by the customer.

Up to 20 digits Up to 26 digits P103

Before Using D903iTV

Page 44

Attaching/removing the battery pack

･Turn the power off before attaching or removing the battery pack. Also, attach or remove it with FOMA

terminal closed using both hands.

･Be careful not to touch the camera lens. ･Use the specified Battery Pack D09.

Attaching the battery pack

Press here.

aRemove the back cover.

While pressing the top of the back cover with your thumb, slide it in the direction of the arrow until it is removed.

bWith the surface with the DoCoMo logo and

the recycle mark facing up, insert the battery pack into FOMA terminal at the angle as shown in the figure.

Do not force the battery pack into FOMA terminal. Doing so could damage t he body connector or battery pack terminals.

cPush the battery pack in. dPlace the back cover plate so that it can slide

about 1 mm on FOMA terminal.

eSlide the back cover in the direction of the

arrow pushing its center with your thumb so that FOMA terminal and the back cover do not gap.

Failure to follow the correct procedure could damage the back cover.

Removing the battery pack

Projection

aRemove the back cover. bLift the projection of the battery pack using

your finger and remove it.

INFORMATION

● The FOMA terminal display uses an active LCD. Due to the characteristics of active LCD, residual images or crossbar

may remain for a while when the battery pack is attached or removed. This is not a fault of FOMA terminal.

Before Using D903iTV

Page 45

Charging the battery of FOMA terminal

When the battery level is low, charge the battery.

･The battery level icon shows how much charge remains in the battery. ☛P42

Charging time and operation time on full charge (estimates)

Charging time Continuous call time Continuous standby time 1Seg viewing time

Approx.

140 minutes

During a voice call: Approx. 170 minutes During a videophone call: Approx. 100 minutes

･ Continuous call tim e is an estimate of call time for FOMA term inal when it can send and receive

signals normally.

･ Continuous standby time is an estimate of operation time of FOMA terminal when it is closed and able

to receive signals normally. Th e call time and standby time may be reduced to about half, depending on the amount of charge in the battery, the function settings, the ambient temperature and signal conditions (radio waves do not or hardly reach). Using i-mode communication reduces the call (communication) time and standby time. Even if you do not make a call or use i-mode, the call (communication) time and standby t ime will be reduced by composing i-mode Mail, or starting the i-αppli software downloaded from sites or on the i-αppli standby display.

･ Continuous standby time (while standing still) is t he average operation time of FOMA terminal when it

is standing still, closed and able to receive signals normally.

･ Continuous standby time (while moving) is the average operation time of FOMA terminal that is standing

still, moving and outside the service area when it is closed and able to receive signals normally.

･ Alternatively, if you perform data communication or Multiaccess, use the camera, play vide o/i-motion

or music, or watch 1Seg, the call (communication) time and standby time will be reduced.

Starting/ending charging and other items to note

The battery pack can be charged regardless of whether FOMA terminal is turned on or off. However, charging takes longer with the power turned on.

･ When charging starts, the Enter key lights in red.

When FOMA terminal is turned on, the charge alert sounds and the battery level icon blinks.

Status Icon ( ) Enter key lighting Meaning

Charging Blinks Lights in red Charging normally. Charged Lights Goes off Charging completed normally.

・The default battery level icon differs depending on the color of FOMA terminal. Even if you change the

battery level icon in Kisekae tool, always appears during charging.

・If the Enter key does not light in red at the start of chargi ng o r it blinks in re d, chargi ng i s unsucce ssful . The

battery may not be charged when the temperature of FOMA terminal is high. Stop any function in progress and confirm that the temperature is low before char ging again. If t he battery pack still can not be charged even after charging again, contact “Repairs” on the back of this man ual.

･ When charging is completed with FOMA terminal turned on, the charge alert sounds and the battery

level icon lights.

･ Do not charge the battery for an extended period (longer than a full day) with FOMA terminal turned

on. FOMA terminal uses power after charging is completed until FOMA term inal is unp lugged from the adapter. In such a case, the AC or DC adapter charges again but when FOMA terminal is removed in the middle of charging, the following could occur:

・Low battery level ・Message appears indicating that the battery runs down. ・FOMA terminal is operational for a short time.

While standing still: Approx. 540 hours While moving: Approx. 380 hours

Economy mode: Approx. 240 minutes Normal mode: Approx. 220 minutes

Before Using D903iTV

▲

Page 46

･ If the battery is fully charged, connecting FOMA terminal to the AC or DC adapter may not start

charging.

･ If you use FOMA terminal for an extended period while charging the battery with the AC or DC adapter

connected, the battery may not be charged temporarily by temperature rise.

･ Insert or remove the co nnector to/from FOMA terminal slowly and firmly without forcing it. When

removing it, be sure to press the release buttons on both sides of the connector and pull it out. Forcibly pulling the connector could cause equipment failure.

･ Insert or remove the connector straight to/from FOMA terminal. ･ Do not view 1Seg for a long time while charging the battery. This may shorten the battery pack life.

Battery pack life

･The battery pack is a consumable part and will gradually wear out. Each time it is charged, it will accept

slightly less charge than the previous time.

･When the battery charge lasts only half as long as when it was new, replace it with a new one immediately,

as the end of battery pack life is approaching. Depending on usage, the battery pack may swell as it nears the end of its life, but this will not cause a problem. The battery pack life is about 1 year. However, if you repeat charging/discharging for a shor t t ime, char ge in high temperature environments or keep charging f or a long period of time, t he batt ery p ack life may be come shorter.

･FOMA terminal uses a lithium ion battery containing valuable materials that should be recycled. To protect

the environment, return used batteries to an NTT DoCoMo service counter, NTT DoCoMo agent or recycling center.

･Please take the following precautions when recycling batteries:

・Attach a piece of adhesive tape on the terminals of used battery packs. ・Do not disassemble or modify battery packs.

Li-ion

Charging from a wall outlet

Use the FOMA AC Adapter 01 (optional) t o charg e the b atter y. Also it can be use d with t he Desktop Holder D12 (optional).

･The battery pack can only be charged when it is attached to FOMA terminal. ･For details, refer to the manuals for the AC adapter and the Desktop Holder.

■ Charging the battery with the AC adapter alone

You can charge the battery with FOMA terminal either closed or open.

aUnfold the power plug from the AC

adapter and plug it into a 100 V AC outlet.

bOpen the external connection terminal

Power plug

100 V AC outlet

cap of FOMA terminal.

cInsert the AC adapter connector in

firmly until it clicks.

dCheck that charging starts.

Check that the Enter key lights in red. When charging is completed, remove the AC adapter connector from FOMA terminal

Enter key

Release button

Connector ( up)

AC adapter

while pressing the release buttons on both sides of the connector, and unplug the AC adapter from the outlet. The n, close the terminal cap.

Before Using D903iTV

Page 47

■ Charging the battery in the Desktop Holder

aUnfold the power plug from the AC

adapter and plug it into a 100 V AC outlet.

bInsert the AC adapter connector in the

Power plug

100 V AC outlet

Desktop Holder until it clicks.

Enter key

cAlong with the Desktop Holder, insert

FOMA terminal at the angle as shown in the figure in the direction of the arrow c.

Connector ( up)

Desktop Holder

AC adapter

dCheck that charging starts.

Check that the Enter key lights in red. When charging is completed, remove FOMA terminal from the Desktop Holder by tilting it to the front while holding the Desktop Holder by hand.

･ When inserting FOMA terminal into the Desktop Holder, be careful not to put a strap in the holder. ･ When FOMA terminal is not inserted firmly or it leans, the battery is not charged normally. Insert

FOMA terminal until it clicks.

･ Insert FOMA terminal into the Desktop Holder in the direction as shown in the above figure. If you

insert in a wrong direction, it cannot be charged.

･ When you push the projection of the Desktop Holder, the charging terminals protrude. Do not push the

projection unless you charge FOMA terminal. Do not touch the charging terminals with your hands or fingers, or some other part of the body when the Desktop Holder is connected to a wall outlet.

Charging in a car

Use the FOMA DC Adapter 01 (optional) to charge the battery in a car. It can be used in negative ground cars (both 12 V and 24 V).

･For details, refer to the DC adapter manual.

aInsert the cigarette lighter plug of the DC adapter into the cigarette lighter socket of the car. bTurn off the power of FOMA termin al and open the external connection terminal cap. cInsert the DC adapter connector firmly until it clicks. dCheck that charging starts.

Check that the Enter key lights in red. When charging is completed, remo ve the DC adapter connector from FOMA terminal while pressing th e re le as e bu tto ns on both sides of the connector, and re mo ve the cigarette lighter plug from the cigarette lighter socket. Then, close the terminal cap.

Cigarette lighter plug

Enter key

Connector ( up)

Release button

Cigarette lighter socket

DC adapter

INFORMATION

● If you charge FOMA terminal with the car engine off, the car battery may be discharged. Charge the battery when the

car engine is running.

● When not charging, remove the DC adapter from the cigarette lighter socket.

● The DC adapter fuses (2A) are consumable items. New fuses are available at automotive supply stores.

Before Using D903iTV

Page 48

Checking the remaining battery level Battery Level

The display indicates an estim ate of the remaining battery level in 3 levels.

(Level 3): Amply charged (Level 2): Charging decreased

Battery level icon

Checking the remaining battery level by sound and display

Press m8685

(Level 3)

(Level 1): Almost empty. Charge the battery.

･The default battery level icon differs depending on the color of FOMA

terminal.

(Level 2)

(Level 1)

The remaining battery level is displayed. The confirmation sound rings by the sound set in Keypad Sound.

Sounds 3 times.

Sounds twice.

Sounds once.

When the battery almost runs down

A message appears or an alert tone sounds to indicate that the battery level is low. Charging the battery stops the low battery alert. To stop it immediately, press f.

･In standby, a message indicating low battery appears. The message disappears by pressing o, c or

f, but afte r a perio d o f t i m e , it reappe ars and th e low batter y al ert sounds. At thi s time, all the icons on the

top of the screen blink and after about 1 minute, the power turns off automatically.

･During a call, the low battery alert sounds from the earpiece and a message indicating low battery appears.

The message disappears by pressing o, c or f. When about 20 seconds elapse after the low battery alert is heard from the earpiece, the call is cut off and the standby display reappears. Then, after about 1 minute, the power turns off automatically.

Setting the low battery alert not to sound Low Battery Alert

Default ON

m81165

Press 2

･ To set the alert: 1

INFORMATION

● When the battery almost runs down during a call, even if OFF is set, the low battery alert sounds from the earpiece.

Before Using D903iTV

Page 49

Turning the power on/off Power ON/OFF

･When FOMA terminal is turned on for the first time, a confirmation screen appears asking whether to

perform Software Update. ☛P460

Turning the power on

Hold down f for over 2 seconds

The wake-up screen appears and then the standby display. The wake-up screen may take some time to appear.

Received signal level (Signal level icon)

The standby image is displayed.

is indicated while reading the UIM and

disappears when reading is completed.

Turning the power off

Hold down f for over 2 seconds

INFORMATION

● When you turn on the power of FOMA terminal after replacing the UIM (except when Omakase Lock (Remote Lock) is set),

entry of the 4 to 8-digit terminal security code is required. After entering the correct terminal security code, the standby display appears. If a wrong terminal security code is entered 5 times consecutively, the power is turned off ( but c an be turned on again).

● When you turn on FOMA terminal, the PIN1/PIN2 code entry screen appears depending on the setting (☛P152, P391).

Enter the PIN1 code or PIN2 code.

● When Normal use of Display light time in Display Light Setting is set to other than Always, if you do not press any keys for

about 90 seconds, the screen display disappears. ☛P137

Icon Received

signal level

･ The default signal level icon differs depending on the color of

FOMA terminal.

･ If the date and time have not been set, a message appears

indicating that. When FOMA terminal receives the time information and the time is automatically corrected, the message disappears. Press o to set the date and time manually.

･ If no UIM is inserted, a message appears indicating that

insertion of the UIM is required. Turn the power off, insert the UIM and then turn the power back on.

Strong Weak Outsid e the serv ice a rea

or where radio waves are hard to reach

Switching to English display Select Language

Default Japanese

m8272

Press 2

･To switch to Japanese display: 1

INFORMATION

● This setting is saved in the UIM.

Before Using D903iTV

Page 50

Setting the date and time Date and Time Setting

The time setting can be performed in 2 ways: obtaining the time information from the DoCoMo network to automatically adjust the time setting of FOMA terminal, or manually entering the current time to the terminal.

Default Auto time adjust: ON Offset: +,00h00m

m8611

Select each item to set z Press p

Auto time adjust ：Set whether to automatically correct the time. Offset ：Specify the amount of time advance (+) or delay (-) so that your terminal's clock

Date, Time ：Enter the date and time.

･ The entered number can also be increased or decreased with %. You can also reenter the number af ter

highlighting it with &.

When the automatic time correction is set

The automatic time correction takes place when the UIM is inserted and you turn the power on in a location where radio waves reach.

･The automatic time correction sometimes causes a time error of several seconds. In addition, it may fail to

correct the time depending on the radio wave condition.

･If the time information is received while i- ･Even if Auto time adjust is set to ON, the time may not be corrected for a while. To ena ble the au tomatic time

correction, turn the power off and then on.

･When no UIM is inserted or FOMA terminal is out of the service area, the automatic time correction is not

performed even if you turn the power off and then on.

･ When you set Auto time adjust to ON, Offset can be set.

To enter the date and time manually, set Auto time adjust to OFF.

advances from or delays to the time obtained for a given length of time.

･The date can be set from January 1, 2000 to December 31, 2050.

ppli is running, the time may not be corrected depending on the i-αppli.

INFORMATION

● You cannot use the following functions when the date and time are not set:

･Auto Power ON/OFF ･ Alarm Clock ･Certificate Download ･i-

ppli Auto Start ･i-αppli DX ･ Flash movie which uses the date and time setting

･Software Update ･Update Definition ･SSL communication (authentication) ･Scheduler (including data transfer and display of schedule data) ･ Machi-chara ･Activate 1Seg ･TV link ･1Seg Video ･Downloading and playing i-motion with replay restrictions set ･ Booking Program List ･Random Display Image (when Change image is set to other than Open slide or Speed selector) ･Downloading Chaku-Uta Full

Before Using D903iTV

and playing WMA files for which replay restrictions are set for copyright protection

Page 51

● If the date and time are not set, the date and time are not recorded for the following functions and “----/--/--” or

“----------------” is displayed. A number to segmentalize (segmental number) may be appended.

･ Redial/Received Calls ･ Answer Machine/Voice Memo ･ Date and time of still image/video shot with the camera ･ Notepad ･ Date and time of sent mail/unsent mail ･ Sent Msg. Log ･ Date and time of sound recorded with Sound Recorder ･ Date and time of the last reset of call duration/call cost ･ Date and time in the file name of data scanned by Bar Code Reader ･ Date and time of downloaded i-

ppli (detail information) ･Date and time of received ToruCa

･ Saved date and time of downloaded data and file ･ Saved date and time of created mail template

● The set time is retained even if the battery pack is replaced, but may be reset if the battery pack is removed for an

extended period. In that case, set the date and time again.

Notifying your phone number to the other party Caller ID Notification

Set FOMA terminal to send your phone number (caller ID) to be displayed on the other party’s phone every time you make a call.

･The caller ID is your important information. Carefully consider whether to send your caller ID. ･The caller ID is displayed only when the other party’s phone can display the caller ID. ･For details, see “Mobile Phone User’s Guide [Network Services]”.

m87411

･To check the current setting: m87412 z Select Yes

Enter the network security code z Press 1

･To hide the caller ID: 2

INFORMATION

● You can use several methods to set the caller ID notification. When setting/operating multiple caller ID notification

methods at the same time, the caller ID is notified in the following priority. However, the caller ID notification setting shown on the display may differ from the actual setting.

1. Caller ID notification set in Call Option when making a call ☛P59

2. Setting by adding “186”/“184” before the other party’s phone number ☛P59

3. Caller ID Setting of the phonebook ☛P114

4. Caller ID Notification setting

● If you hear a guidance requesting your caller ID when you make a call, call back after setting to send caller ID.

● You need to make the setting separately for PushTalk caller ID notification. ☛P95

Before Using D903iTV

Page 52

Menu 49

Checking your own phone number Own Number

Check your phone number (My phone number), name, mail address, etc.

Default My phone number: subscribed phone number Other than that: not recorded

Press m0

･ Setting and checking your i-mode Mail address ☛P214

■ Checking your phone number during a call: b0

Before Using D903iTV

Page 53

Calls/Videophone Calls

Making calls/videophone calls

Videophone ....................................................................................................... 48

Making calls/videophone calls ........................................................................49

Transmitting tone signals (DTMF) ............................................. Send DTMF 52

Switching between a voice call and videophone call ....................................53

Using Redial/Received Calls ..................................... Redial/Received Calls 54

Setting Chaku-moji ..................................................................... Chaku-moji 57

Showing/hiding your caller ID for each call ............................ 186/184 Call 59

Making calls by setting the conditions .......................................Call Option 59

Using international calls ........................................................ WORLD CALL 60

Setting prefix numbers added to phone number .................. Prefix Dialing 62

Making a call by specifying a sub-address ............................ Sub Address 62

Setting the alarm indicating reconnection of interrupted call

............................................................................................. Reconnect Alarm 63

Suppressing ambient noises to improve the call quality

.............................................................................................. Noise Reduction 63

Talking without using hands in a car ............................... In-car Handsfree 63

Receiving calls/videophone calls

Receiving calls/videophone calls ....................................................................64

Switching a received call between a voice call and videophone call ..........66

Enabling use of dial keys to answer a call ...................... Any Key Answer 67

Setting to start talking by opening FOMA terminal .............. Open Answer 67

Setting to disconnect/continue/hold a call by closing FOMA terminal

.................................................................................................... Close Setting 67

Adjusting the volume of the other party’s voice during a call

.................................................................................................. Listen Volume 68

Adjusting the volume of ring alerts and other sounds emitted from FOMA

terminal ................................................................................... Adjust Volume 68

Setting for incoming voice/videophone/PushTalk calls

.................................................. Call Alert/Videophone Alert/PushTalk Alert 69

Setting the priority screen for incoming calls during a call or packet

communication ............................................................ Priority Comm Mode 70

When you can or could not answer a call/videophone call

Putting incoming calls on hold when you cannot answer right away

......................................................................................... Response and Hold 70

Setting the response hold guidance .................................. Status Message 71

Setting the on-hold tone ........................................................ On-hold Tone 72

Using Public mode (Driving mode) ............... Public mode (Driving mode) 72

Using Public mode (power off) ............................. Public mode (power off) 74

Allowing the caller to leave message when you cannot answer the call

.............................................................................................. Answer Machine 75

Using Chara-den ...............................................................................................78

Setting images being sent to the other party .................................................79

Customizing the screen settings during a videophone call .........................82

Changing the videophone settings ........................... Videophone Settings 83

Setting of switching between a voice call and videophone call

.................................................................................. Notify Switchable Mode 85

Setting how incoming videophone calls are handled during i-mode

................................................................................. Data Session Arrival Act 85

Using the videophone by connecting to an external device

................................................................................................ External Device 86

Page 54

Videophone

The videophone function is available between terminals that support DoCoMo’s videophone. By using the videophone, you can talk on the phone while looking ea ch other imag es. It is also possible to display a still image, substitute image, Chara-den, etc. instead of your self image.

･Chara-den ☛P324

DoCoMo videophone specifications are compliant with “3G-324M* standard 3GPP*

”. Note that the connection with videophones of different specifications cannot be established. *1 3G-324M…An international standard for the 3rd generation mobile videophone. *2 3GPP (3rd Generation Partnership Project)…Area standardization organization established to develop the

standard technology specification for the 3rd generation mobile communications systems (IMT-2000).

･ The following 2 commu nication speeds are provided fo r the videophone:

・64K: Connects at communication speed of 64 kbps. ・32K: Connects at communication speed of 32 kbps.

Screen display during a videophone call

Main screen The other party’s image is displayed by default.

Communication

speed Speakerphone

function Sub screen Your image is displayed by default.

Zoom to : Normal to 2x (in-camera)

Status : Sending your self image

Action mode : Action : Action of parts Scene mode/

effect Quality of

outgoing image Sending and

receiving status of sound/image

Speakerphone/ earpiece volume

j Videophone and

voice call switching

k Call duration Displayed in the HH:MM:SS format

The icons for other modes/effects ☛P80 No icon: Normal : Prefer motion speed

No icon: Switching is not available. : Switching is available.*

*1 Displayed only on the caller’s terminal.

that has been standardized by the international

: 64K : 32K

: On No icon: Off

to : Normal to 4x (out-camera)

: Sending the camera-off image : Sending Chara-den : Sending a frame : Sending a still image : On-hold : On Response and Hold : Recording a message : Recording a video memo

: Full auto, etc.

: Prefer image quality : Sending and receiving sound

: Sending and receiving image : Sending and receiving sound/image

to : Adjusting speakerphone/earpiece volume

Calls/Videophone Calls

Page 55

Making calls/videophone cal ls

Making calls/videophone calls

Enter the phone number

n (voice call) or t (videophone call)

You will hear a dial tone. You can start talking when the call is answered.

Voice call Videophone call

Talking screen Talking screenConnecting screen

･If the other party is busy, you will hear a busy signal. For a videophone call, the message Busy. or

Connection failed. appears on the screen. Press f to end t he call an d call agai n later . You can call back

quickly using Redial.

･If the other party’s mobile phone or PHS is turned off or is in an area where radio waves are hard to

reach, a guidance informs that the connection is unavailable.

･While a videophone call is being connected, your image is displayed on the screen. ･Charging begins when Connected to videophone. appears. ･The other party’s voice comes out of the speaker during a videophone call (Speakerphone function). ･For a videophone call, the substitute image may be displayed depending on the other party’s settings. ･The following operations are available during a voice call:

・To display received calls: l ・To display redials: r ・To start the phonebook: p

･When calling general subscriber phones, always include the area code, even

from the same city.

･Up to 80 digits can be entered. However, only 24 digits are displayed. ･To correct the phone number: c ･To return to the standby display: c (for over a second)

Press f when you finish the call

Calls/Videophone Calls

▲

Page 56

INFORMATION

[Common]

● If you hear a guidance requesting your caller ID when making a call, call again after setting FOMA terminal to send

caller ID. ☛P45

● When you have subscribed to the Multi Number service, you can call after selecting a registered multi-number. ☛P405

[Voice call]

● You can also make a voice call in order of Step 2, Step 1. A voice call will be made automatically about 5 seconds after

you have pressed n and entered the phone number.

[Videophone call]

● If a videophone call is not connected, one of the following messages appears on the screen and then the standby

display returns. Note that the displayed message may not reflect the status of the other party’s terminal correctly, depending on the type of the terminal or the network service used by the other party.

Busy. The other party is busy.*

Message Description

Redial using voice call. This message appears when the other party has activated Call Forwarding Service

with the forwarding destination set to a terminal incompatible with videophone.

Upper limit exceeded. Connection failed.

This message appears when the upper limit of a billing plan with a charge limit (such as Type limit and Family Wide limit) is exceeded.

Connection failed. Set Caller ID Notification to Notify and dial again.

･The message may appear in cases other than the above.

Out of service area/power off. The other party is outside the service area or the other party’s terminal is turned off. Busy with packet transmission. The other party is in packet communication. Set Caller ID to ON. This message appears in case of connecting without notifying the caller ID (when

accessing to V-live or visualnet).

Check number, then redial. You dialed the phone number not used. Make call from i-mode web page. This message appears when using V-live. Access to the IP site via i-mode then

make a videophone call on the site screen.

*1 The message may also appear when the other party is in packet communication, depending on his/her terminal.

● If a videophone call is not connected, redialing is automatically performed as described below:

Call type

Auto redial as

voice call

Redialing operation

If redialing as voice call occurs, voice call charges ap ply.

64K ON 64K → 32K → Voice call

OFF 64K → 32K → Disconnection

32K ON 32K → Voice call

OFF 32K → Disconnection

● When there is an incoming call while dialing a videophone call or redialing, the dialing may be interrupted and the ring

alert may sound.

● Even if sending/receiving the voice or image is aborted and (voice only) or (image only) appears during

a videophone call, the call may be continued.

● Please note that digital communication charges apply for videophone calls instead of voice call charges even if the

substitute image or Chara-den is used.

● Videophone at 32K is intended for connection with devices such as PHS with which videophone calls at 64K may not be

available depending on the network condition. When a videophone call is made at 64K, the call type is automatically switched to 32K when redialing if the communication environment of the other party is found to be the 32K area. When ON is set for Auto redial as voice in Videophone Settings, redialing at 32K is also given priority. ☛P83

･Even if a call is made at 32K, the 64K digital communication charges will apply.

Calls/Videophone Calls

Page 57

Putting calls on hold while talking On-hold

Putting the call on hold while talking allows you to talk without the other party hearing your voice. Callers are charged for the time spent on hold.

Press o during a call

Flashes

The call is put on hold and a guidance (on-hold tone) is played. For videophone calls, the onhold image appears on the other party’s terminal.

On-hold image

Voice call on hold

Videophone call

on hold

･Press o or n while a voice call is on hold to cancel the hold. ･Press o while a videophone call is on hold to cancel the hold and send the image that has been sent

before the hold. Press t or n to cancel the hold and send your image to the other party and press a to cancel the hold and send a substitute image.

Using the speakerphone function

You can make a call allowing the other party’s voice to be heard through the speaker.

Example

Making a voice call

Enter the phone number z Hold down n for over a second

･ appears at the top of the display while the speakerphone function is on. ･The same operation is possible from the phonebook list, redial list, received call list, recorded message

list and voice memo list.

■ Making a videophone call: Enter the phone number z t

･ If Speakerphone is set to OFF in Videophone Settings or Silent Mode is acti ve, hold down t for over a

second.

■ Making a PushTalk call: Enter the phone number z g

･ If P-Talk Speakerphone is set to OFF or Silent Mode is active, hold down g for over a second.

■ Turning on/off the speakerphone during a call/PushTalk: a or n

･ While dialing or calling, press n to turn on/off the speakerphone.

■ Adjusting the speakerphone volume: % during a call z O to adjust the volume

･ The setting is retained even after the call is ended, and is also reflected to the volume of playback

sound for recorded videophone call messages.

INFORMATION

● When the speakerphone function is turned on, the volume may suddenly increase and damage your ears. Use it with

FOMA terminal away from your ears.

● If a call is hard to hear with a large amount of noise around you or the other party, turn off the speakerphone function.

● Talk to FOMA terminal within about 30 cm.

● The speakerphone function can be used even when Silent Mode is on.

Calls/Videophone Calls

Page 58

Transmitting tone signals (DTMF) Send DTMF

･You can input tone signals (DTMF) during a videophone call while sending your self image ( ), the

camera-off image ( ) or Chara-den ( ).

Example

During a videophone call

m7 during a videophone call z Enter with dial keys

The entered number appears on the screen and the tone signals (DTMF) are transmitted.

･ To cancel transmitting tone signals (DTMF): c ･ The tone signals (DTMF) are transmitted by pressing dial keys without pressing m7 while your self

image or the camera-off image is being sent.

･ When the tone signals (DTMF) are transmitted, the set frame and still image are canceled. ･ Because tone signals (DTMF) are transmitted using dial keys, you cannot use dial keys to make actions

while sending Chara-den.

■ Transmitting tone signals (DTMF) during a voice call: Enter with dial keys during a voice call

Entering pauses or timed pauses

Pauses and timed pauses are available only for voice calls.

Example

Calling to “03XXXXXXXXP12345” (P=Entered pause)

When you press o after the call is connected, the numbers after the pause are sent.

Entering a pause “P”

A pause (P) is used for sending messages to beepers, operating the answering system at home, reserving tickets, etc. At the point the pause (P) is entered, the dial digits are separat ed and tone signals (DTMF) are se nt.

Hold down ( for over a second

･ You cannot make a call if a pause is entered at the beginning of the phone number.

Entering a timed pause “T”

A timed pause (T) is used to dial outside line numbers with extensions. Enter a timed pause (T) between the outside line and extension numbers to dial the extension number after a set number of seconds following the outside line number.

Hold down # for over a second

･ Timed pauses can be entered in succession. ･ Each timed pause is followed by a second interval. ･ You cannot make a call if a timed pause is entered at the beginning of the phone number.

Calls/Videophone Calls

Page 59

INFORMATION

● Tone signals (DTMF) may not be received depending on the receiving device.

● You cannot make a call to another party by putting the current call on hold and entering a pause (P) or timed pause (T).

Switching between a voice call and videophone call

You can switch between a voice call and a videophone call by operating from the submenu during a call when the other party’s terminal can sw itch calls . Swit chin g can b e perf or med onl y from th e termin al tha t made the call.

･This operation is available between the terminals that support switching between a voice call and

videophone call.

･To switch calls, the other party needs to set Indication ON of Notify Switch able Mode in advance. ☛P85

Example

Switching a voice call to a videophone call

m1 during a voice call z Select Yes

･A guidance informing that the call is being switched is played during switching. ･Select No to return to the voice call talking screen. ･If Speakerphone is set to ON in Videophone Settings, the speakerphone is turned on when the call is

switched to a videophone call.

■ Switching a videophone call to a voice call: m1 during a videophone call z Select Yes

INFORMATION

● When you are in packet communication, disconnect the packet communication and switch to a videophone call.

● When the other party is in packet communication, the call cannot be switched to a videophone call.

● During a voice call using Call Waiting Service, you cannot switch the call to a videophone call.

● It takes about 5 seconds to switch. However, it may take longer depending on radio wave conditions.

● Depending on radio wave conditions, a voice call and videophone call may not be switched and the call may be disconnected.

● The speakerphone function is turned off when a videophone call is switched to a voice call.

● The settings (such as switching the cameras or selecting the frame) made during a videophone call are canceled when

a videophone call is switched to a voice call.

● According to the call duration of a voice call and videophone call, the call charges are added up, respectively.

● The call is not charged while Switching... is displayed.

Calls/Videophone Calls

Page 60

Menu 46 / Menu 45

Using Redial/Received Calls Redial/Received Calls

FOMA terminal records voice calls, videophone calls and PushTalk calls that you made in Redial and those you received in Received Calls . With Re c eiv ed Calls, you can check unanswered calls (mis sed calls) and recorded messages.

･Up to 30 calls are recorded in each log, respectively. When the number exceeds 30, calls are deleted

staring with the oldest one.

Example

Making a call using Redial

r z Highlight a party in the redial list

･ To make a call using Received Calls: l z Highlight a party in the received

call list

･ To display the details screen: Select a call

Press n (voice call) or t (videophone call)

･ To make a PushTalk call: g ･ To make a call with the same call type as the highlighted call: o on the details screen

･ A videophone call is dialed according to the setting of Connection Speed in the phonebook. ･ If you use a received call with Chaku-moji to make a call, the Chaku-moji is not attached when dialing.

■ Making a call using PushTalk call log: Select a PushTalk call z p z Select a member z

t or g

Operating on the redial/received call list

You can perform the following operations such as phonebook registration also from t he details screen.

■ Registering an entry in the phonebook:

a Highlight a call z m41

･ To add to an existing phonebook entry: m42 ･ For a PushTalk call (with multiple parties), select the party.

b 1 or 2 z Register the name or mail address ☛P101, P103

･ To add to an existing phonebook entry: 1 or 2 z Select the party z Edit the data ☛P111

■ Registering an entry in the PushTalk phonebook: Highlight a call z m43 z Select Yes

･The party can be registered only if registered in the FOMA terminal phonebook. ･When a PushTalk call (with multiple parties) is highlighted, press m43, select the party, press p

and then select Yes.

■ Registering a group in the PushTalk phonebook:

The parties of a PushTalk call (with multiple parties) can be registered as a group if registered in the PushTalk phonebook.

a Highlight a redial z m44 b Enter a group name z p

Calls/Videophone Calls

Page 61

■ Deleting redials/received calls:

･You cannot delete multiple calls at once on the details screen.

a Highlight a call z m51

･ To delete multiple calls: m52 z Select calls z p ･ To delete all: m53

b Select Yes

■ Composing SMS: Highlight a call z a (for ove r a second)

The SMS composition screen appears with the phone number of the highlighted call specified as the address.

･If the phone number is saved in the phonebook together with mail addresses, pressing a displays the

i-mode Mail composition screen with the first mail address specified as the address. If not, the SMS composition screen appears with the phone number specified as the address.

･For a PushTalk call, the above applies when there is only one party.

■ Setting whether to display the image on the details screen: m8 on the details screen z

1 to 3

･For details ☛P110

■ Other operations available on the list screen

･To switch between the redial list and received call list: m6 ･To switch to the sent message log: p in the redial list ･To switch to the received message log: p in the received call list ･To display the details screen for PushTalk call: Select a PushTalk call z o z Select a member

INFORMATION

● If you switch between a voice call and videophone call during a call, the call type (voice/videophone call) that was

specified when you dialed/received is recorded in the call log.

● When multiple voice/videophone calls are made to the same number, only the most recent call is recorded as a redial

for each caller ID preference: show, hide or no setting. When a PushTalk call is made to the same number, the call is recorded as a separate record.

● Calls received from callers using dial-in services in such as office may display different numbers from the caller’s dial-in

number.

● Selecting a multi-number registered for Multi Number ☛P405

Unanswered voice/videophone/PushTalk calls (Missed calls)

(with the number of missed calls) is indicated and the call is recorded as a received call. ☛P34

･When there is a missed call from an unknown phone number, the ringing ti me enables you to ch eck whether

the call is a malicious call (One-Ring Call, etc.) made for the sole purpose of leaving a received call record.

INFORMATION

● Press m81 in the received call list to display all the calls including the missed calls of which ringing times are

shorter than the delay time set in Mute Ring Time Setting. To hide such short ringing calls, press m82.

● If only missed calls of which ringing times are shorter than the delay time set in Mute Ring Time Setting are recorded as

received calls, pressing l on the standby display shows a confirmation screen asking whether to display missed calls.

Calls/Videophone Calls

Page 62

Reading the redial/received call list screen

Example

a f

c g

For Redial

Date and time Calling/receiving date and time

Icon Icon registered in the phonebook*

c d e f

Ringing time

Call type / (domestic/overseas): Voice call

･ appears when a PushTalk call was made to a

group.

*2 Displayed for missed call only

/ (domestic/overseas): Videophone call / (domestic/overseas): 64K da ta

List screen

communication (for received cal l only )

/ (one party/multiple parties): PushTalk / (one party/multiple parties): PushTalk using

PushTalkPlus ☛P88

Details screen

d e

Caller ID

notification* Call status (with

Chaku-moji/ without Chakumoji)

i j

Other party

information

: Notify/Show caller ID : Not notify/Hide caller ID /No icon: Answered / : Missed call (checked) / : Missed call (unchecked) / : Recorded message

/ : Recorded message (deleted) Phone number (list screen only), name* the following:

･ PushTalk group name*

for redial (list screen

only)

･ Reason for no caller ID for received call

Chaku-moji Displayed for a received call with Chaku-moji

Other party information Image Image registered in the phonebook*

Name of multi-

number

Phone number Not displayed for a call without the caller ID

*1 Displayed when registered in the phonebook (not displayed during PIM Lock or while not in Secret Mod e

for a phonebook entry with Secret Attribute). *2 99+ appears on the list screen if the ring time is 100 or more seconds. *3 Displayed when caller ID notification is set in Call Option, Caller ID Setting of the phonebook, or PT

Caller ID Notification. *4 Displayed when registered in the phonebook (while not in Secret Mode, the phone number is displayed

for a phonebook entry with Secret Attribute). *5 The first member’s name is displayed when you made a PushTalk call to multiple parties not by using

group calling. *6 Displayed according to the setting of View Preference, when registered in the phonebook. *7 For redial, displayed for a call made using Call Option.

attached PushTalk group name (details screen only)

Displayed when you have subscribed to the Multi Number service

(the name of the basic number or additional number used by the call made/ received)

or one of

Calls/Videophone Calls

Page 63

Setting Chaku-moji Chaku-moji

When you make a voice/videophone ca ll, you can set a message (Chaku-moj i) to be displayed on the incoming screen of the other party’s terminal. This allows the other party to know what the matter is in advance.

･ Supporting models:902iS series, SH902iSL, N902iX HIGH-SPEED, N902iL, 903i

･ Senders are charged, but receivers are not charged. ･ Received Chaku-moji is recorded in the received call history.

Chaku-moji appears on the incoming screen of the other party’s terminal. When the call is answered, the Chaku-moji is cleared.

Editing and setting for Chaku-moji

Creating a Chaku-moji message

･Up to 10 messages can be registered.

m8731

Select <New message>

■ Using the history of sent messages: m1 z Select a Chaku-moji

message z Go to Step 4

■ Deleting:

a Highlight a Chaku-moji message z m2

･ To delete all: m3

b Select Yes

series, 702iS series (except N702iS, M702iS and M70 2iG), 70 3i series, 601i series (except L601i) and D800iDS

Enter a message (up to 10 one-byte or two-byte characters)

･Kanji, hiragana, katakana, alphabetic and numeric characters, symbols, and pictograms (except Deco-

mail pictograms) can be entered.

Press p

･When you have edited a registered Chaku-moji message, a confirmation screen appears asking whether

to register it. Select Yes to overwrite.

Calls/Videophone Calls

▲

Page 64

Making the Chaku-moji reception setting Message Display Setting

Default Only with Caller ID

m8732

Press any of 1 to 4

Display all ：Displays all Chaku-moji. Hide all ：Hides Chaku-moji. Only from stored No.：Displays Chaku-moji only from a party registered in the phonebook. Only with Caller ID ：Displays Chaku-moji only from a party with the caller ID.

Making a call by attaching Chaku-moji

･Up to 10 messages can be recorded in the history of sent messages. When the number of recorded

messages exceeds 10, they are deleted, oldest first.

Enter the phone number z m3

Select a Chaku-moji message

■ Creating a message: 1 z Create a Chaku-moji message

･ Follow the procedure from Step 3 in “Creating a Chaku-moji message”. ☛P57

■ Selecting a registered message: 2 z Select a Chaku-moji message

■ Selecting from the history of sent messages: 3 z Select a Chaku-moji message

Press m

･ When the Chaku-moji is received by the other party’s terminal, Transmission completed appears and

transmission fee is charged.

･ When the Chaku-moji is sent to an incompatible terminal or is not received due to Message Display

Setting of the other party’s terminal, Transmission failed appears and transmission fee is not charged.

INFORMATION

● PushTalk does not support Chaku-moji.

● If the receiver’s terminal is in one of the following cases, Chaku-moji is not received and not recorded in the received call

history. In addition, the transmission result does not appear on the sender’s screen. In this case, transmission fee is not charged.

･Outside the service area or turned off ･ In Public mode (Driving mode) ･When the response time of Answer Machine is set to 0 second, etc.

● Even when Chaku-moji is received, the transmission result may not appear on the sender’s screen depending on radio

wave conditions. In this case, the sender is charged for the transmission.

● When a call with Chaku-moji is received within the delay time set in Mute Ring Time Setting, the Chaku -moji is displayed

and is recorded in the received call history. In this case, the sender is charged for the transmission.

● You cannot send Chaku-moji to a party overseas.

Calls/Videophone Calls

Page 65

Showing/hiding your caller ID for each call 186/184 Call

Prefix a specific number to the beginning of the phone number when you make a call.

･The caller ID is your important information. Carefully consider whether to send your caller ID. ･The caller ID is displayed only when the other party’s phone can display caller ID.

Showing your caller ID

186 z Enter the phone number z Press n (voice call) or t (videophone

call)

Hiding your caller ID

184 z Enter the phone number z Press n (voice call) or t (videophone

call)

INFORMATION

● For an international call, the caller ID may not be notified depending on the phone company that handles a call even if

“186” is added.

● When you make a call by adding “186”/“184” to the other party’s phone number, the phone number with “186”/“184”

added is recorded in the redial data.

● Caller ID notification priority ☛P45

Making calls by setting the conditions Call Option

You can set the dialing conditions each time yo u mak e a vo i ce /v id eophone call.

･When calling to a PushTalk group, you can set only the call type and whether to show/hide your caller ID.

Enter the phone number z m2

■ Making an international call: Enter the country code z area code (city code) z phone number

z m2

･ For an international call, dial without “0” when the area code begins with “0” (when calling to a general

subscriber phone and other phones in Italy, you need to dial “0”).

Select each item to set

Chaku-moji ：Create or select the Chaku-moji message to be sent to the other party. ☛P58 Multi-No ：Select the number to be notified to the other party from the basic number or additional

Call type ：Select from Voice call, 64K V.phone, 32K V.phone or PushTalk. Caller ID ：Set whether to show/hide caller ID.

Prefix ：Select the number (Prefix ☛P62) to be appended before the phone number. Intn’l prefix ：Select the international access code set in Int’l Call Assist.

numbers. ☛P405

･ Caller ID notification priority ☛P45; Caller ID notification priority for PushTalk ☛P95

Calls/Videophone Calls

▲

Page 66

Press m

A call is made by the settings.

･ When you select 64K V.phone or 32K V.phone in Call type, press t to select Chara-den to be displayed

during a videophone call.

･ When you have set Prefix or Intn’l prefix to other than Unspecified, press m and select Yes. Press m

and select No, use original to cancel other settings than the setting of Chaku-moji and call type and make a call.

INFORMATION

● In the redial list, received call list, recorded message list, voice memo list, details screen of Own Number, member list/

group list of the PushTalk phonebook, or member list for schedule, press m and select Call option.

● In the FOMA terminal phonebook list/details screen or the UIM phonebook list/details screen, highlight a phone number,

press m and select Mail/Call option → Call option.

● For an international call, the caller ID may not be notified depending on the phone company that handles a call even

when Notify is selected for Caller ID.

Using international calls WORLD CALL

DoCoMo international call service “WORLD CALL”

･The international call service “WORLD CALL” is available for DoCoMo mobile phones. ･How to call

009130 z 010 z Enter the country code z area code (city code) z phone number z n

･ The above phone number can be registered in the FOMA terminal phonebook. ･ When the area code begins with “0”, dial without “0” (when calling to a general subscriber phone and

other phones in Italy, you need to dial “0”).

･You can call to about 240 countries and regions around the world. ･WORLD CALL charges are added to the FOMA service charges every month. ･No subscription charges or monthly fee is required.

・You were subscribed to “WORLD CALL” as one of standard services at the time of subscription to the

FOMA service (unless you request not to subscribe to it).

･Changes in international call dialing procedure

MY LINE service is not applicable to mobile phone communications, including WORLD CALL service. However, along with the introduction of MY LINE service, th e dialing p rocedure f or intern ational calls using a mobile phone was changed. Consequently, the previous dialing procedure (without prefix “010”) no longer be used.

･Contact “General Inquiries” on the back of this manual for details.

・To use international call services other than the DoCoMo service, contact each carrier for details.

･This service cannot be used with some billing plans.

“International videophone” calls to parties using specific overseas 3G mobile phone terminals can be made by dialing as described above and placing a call in the videophone mode.

･For the countries and overseas carriers you can connect to, visit the DoCoMo website for international services. ･The image of the other party displayed on FOMA terminal may be distorted or connection may not be established

depending on the terminal at the other end of the international videophone line.

Calls/Videophone Calls

Page 67

Setting for international calls Int’l Call Assist

You can set whether to make an international call by replacing “+” which was entered at the beginning of a phone number with the international access code set in this setting.

Default Intn’l prefix: ON (Name: World Call, Intn’l prefix No.: 009130010)

Setting the auto-switch function

m881

Set each item z Press p

Intn’l prefix ：Set whether to automatically replace “+” with the international access code.

Registering the international access code (International prefix)

･Up to 3 international access codes can be registered.

m882

Select <Not recorded>

■ Setting the international access code which is to replace “+”: Highlight an item z p

■ Deleting: Highlight an item z m3 z Select Yes

Select Name field z Enter a name (up to 16 one-byte or 8 two-byte characters)

Select Intn’l prefix No. field z Enter a code (up to 10 digits) z Press p

･ When ON is selected, select an international access code.

is displayed indicating the set code.

Using “+” to make an international call

When you enter “+” at the beginning of a phone number for dialing, a confirmation screen appears asking whether to replace “+” with the international access code according to Int’l Call Assist.

･If you make a call by entering “+” before the country code of Japan “ 81”, the in ter nationa l access co de does

replace it.

･This operation is valid when Intn’l prefix of Int’l Call Assist is set to ON.

0 (for over a second) z Enter the country code z area code (city code) z phone

number z n

･Hold down 0 for over a second to enter “+”. ･When the area code begins with “0”, dial without “0” (when calling to a general subscriber phone and

other phones in Italy, you need to dial “0”).

Select Yes

･Select No, use original to dial the phone number without replacing “+”.

Calls/Videophone Calls

Page 68

Setting prefix numbers added to phone number Prefix Dialing

By registering the number (prefix) such as an international access code, “186” or “184” to add to the beginning of the phone number in advance, you can add a prefix after entering the phone number to make a call easily. ☛P59

Default 009130010

m8462

Select Prefix1 to 3 field z Enter a number z Press p

･ Up to 3 numbers in total and up to 10 digits for each number can be entered. ･ Do not include a pause or timed pause in the number (prefix). If you set a prefix containing a pause or

timed pause, you cannot add the prefix when making a call.

Making a call by specifying a sub-address Sub Address

Specify a sub-address to call a specific phone or communication device.

･This setting is also used to select the contents in a video delivery service, “V-live”.

Enabling use of a sub-address

Default ON

m8463

Press 1

･ To cancel the setting: 2

Making a call by specifying a sub-address

Enter the phone number z ( z Enter the sub-address

･ You can also make a call by entering “” at the beginning of the phone number.

Press n (voice call) or t (videophone call)

･ The sub-address needs to be set on the other party’s phone or communication device.

INFORMATION

● Even when Sub Address is set to ON, if “ ” is entered after entering a pause, timed pause or “#”, it is not recognized

as a sub-address delimiter and sent as tone signals (DTMF) containing “ ”.

Calls/Videophone Calls

Page 69

Setting the alarm indicating reconnection of interrupted call

Set an alarm that is heard at the time of reconnecting a voice call, videophone call or PushTalk call interrupted due to poor signal conditions in a tunnel or behind a building, etc. when signal conditions improve.

･The other party hears no sound while signals are disrupted. ･The time until the call is reconnected depends on line use or signal conditions. The approximate time is a

maximum of 10 seconds.

･Note that the call is charged for the time until the call is reconnected (up to 10 seconds). ･The call may be cut off before the alarm sounds depending on line use or signal conditions.

Default High alarm

m81164 z Press any of 1 to 3

Reconnect Alarm

Suppressing ambient noises to improve the call quality Noise Reduction

By suppressing ambient noises during a call, the other party can hear your voice clearly and you can also hear the other party’s vo ice clearly.

･It is recommended that this function usually be set to ON.

Default ON

m8471

Press 1

･To cancel the setting: 2

Talking without using hands in a car In-car Handsfree

You can make and receive voice calls from a handsfree compatible device by connecting FOMA terminal via USB to such device as the In-Car Hands-Free Kit 01 (optional) or car navigation system.

･For operations of handsfree devices, refer to the instruction ma nual for each handsfree d evice. Note tha t the

FOMA In-Car Hands-Free Cable 01 (optional) is required to use the In-Car Hands-Free Kit 01 (optional).

INFORMATION

● If the setting is made to play sounds from a handsfree device, the ring alert sounds from a handsfree device regardless

of the Silent Mode setting or the ring alert settings on FOMA terminal.

● If a videophone call is made with a handsfree device using the phonebook or redial data, the communication speed

setting of the handsfree device is used. If it is not set, the videophone call is made at fixed 64K.

● When a videophone call is made or received with a handsfree device, a substitute image is sent to the other party.

● The operation during incoming calls when Answer Machine is set follows the Answer Machine settings.

● If the setting is made to play sounds from a handsfree device, the call continues even if FOMA terminal is closed,

regardless of Close Setting.

Calls/Videophone Calls

Page 70

Receiving calls/videophone calls

A call arrives

The ring alert sounds, the display light turns on and the Enter key lights/flashes.

The call duration is displayed.

Voice call Videophone call

Talking screen Talking screenConnecting screen

･ You can also answer a voice call by pressing 0 to 9, (, or # other than n (Any Key

Answer). ☛P67

･ While a videophone call is being connected, your image is displayed on the screen. ･ You can also answer a videophone call by pressing t. ･ The other party’s voice comes out of the speaker during a videophone call (Speakerphone function). ･ For a videophone call, the substitute image may be displayed depending on the other party’s settings.

■ Receiving a videophone call with the substitute image: a

The substitute image is sent to the other party when the videophone call is connected.

･ Even when Chara-den is set as the substitute image, Chara-den may not be displayed. If this happens,

the default image for the substitute image setting is sent to the other party.

Press f when you finish the call

Display information

The caller’s phone number, name, image and/or video/i-motion will be displayed on the screen according to the dialing condition of the caller and your FOMA terminal settings. You can set FOMA terminal not to display the name or phone number. ☛P137

■ When the caller has notified caller ID

If the caller’s phone number is not registered in your phonebook, the phone number is displayed. Also, the image set in Call Alert, Videophone Alert or other settings is displayed.

･ Priority of incoming images ☛P135

Calls/Videophone Calls

Page 71

If the caller’s phone number is already registered in your phonebook, the name and phone number are displayed. When Contact Image is set to ON, the image or video/i-motion set in the phonebook is also displayed. ☛P136

･Received Chaku-moji is recorded in the received call history.

Chaku-moji ☛P57

■ When the caller has not notified caller ID

The reason why no caller ID is sent is displayed.

Reason for no

caller ID

Anonymous The caller selected not to send the caller ID. Payphone The call was made from a payphone, etc. Unavailable The call was made from a party who cannot send caller ID, such

as a call from overseas or from a general subscriber phone via forwarding service (however, caller ID may be displayed depending on the phone company that handles a call).

Description

Operations available from the submenu while receiving a call

If you set Arrival call act to Answer, the same operations are available from the submenu when there is another incoming voice call during a call.

Submenu item Description

aCall Rejection bVoice Mail (V-phone answerphone) cCall Forwarding

* 1Valid when you have subscribed to Voice Mail Service. * 2Valid when you have subscribed to Call Forwarding Service and have set the forwarding phone number.

Disconnects the call (the caller does not pay for the call).

Connects the incoming call to the Voice Mail Service Center. Forwards the incoming call to the forwarding phone number.

When you hear beeps (call waiting ring tone) during a voice call

If Voice Mail Service, Call Waiting Service or Call Forwarding Service is subscribed, you will hear beeps (call waiting ring tone) when you receive another incoming voice call duri ng a voice cal l and the following oper ati ons can be performed:

Service Operation

Voice Mail Service Call Waiting Service Puts the current call on hold and answers the second call. Call Forwarding Service

*1 Available from the submenu when Arrival call act is set to Answer and Set arrival act is active.

Connects the second call to the Voice Mail Service Center.

Forwards the second call to the forwarding phone number.

･If Call Waiting Service is not subscribed, you cannot answer the call even if you hear the call waiting ring

tone.

Calls/Videophone Calls

▲

Page 72

INFORMATION

● When a call forwarded from a FOMA terminal arrives, the phone number from which it was forwarded is displayed if it is

not registered in the phonebook. If it is registered, the name is displayed. However, the phone number or name may not be displayed depending on the forwarding source.

● Even if video/i-motion is set as the incoming image in the phonebook or in Call Alert, it is not played and the first frame

of the video/i-motion is displayed when there is an incoming voice call during a voice call.

● When you receive an international call, a plus sign (+) appears at the beginning of the caller ID.

● For calls received from callers not registered in the phonebook, you can reject calls or set the ring alert and vibrator

ringer action not to start immediately. ☛P165, P164

● Call rejection can be set for some parties registered in the phonebook. ☛P162

● When a videophone call arrives, it is not connected if the forwarding destination is not set to a videophone terminal

compliant with the 3G-324M even if Call Forwarding Service is activated. Check the specifications of the forwarding destination when setting it.

Switching a received call between a voice call and videophone call

･The switching operation can be performed only from the terminal that made a call. It cannot be performed

from the terminal that received the call.

･To receive the request of switching calls, set Indication ON of Notify Switchable Mode in advance. ☛P85

Example

Switching a received voice call to a videophone call

Receive the request of switching to a videophone call during a voice call

･ A guidance informing that the call is being switched

is played during switching.

Select Yes

The call is switched to a videophone call and your self image is sent to the other party.

･ To send the substitute image (camera-off image): Select No ･ When you select Yes, your self image is sent for the first time.

■ Switching a received videophone call to a voice call: Receive the request of switching to a voice call

during a videophone call

The videophone call is switched to a voice call automatically.

･A guidance informing that the call is being switched is played during switching.

Calls/Videophone Calls

Page 73

Enabling use of dial keys to answer a call Any Key Answer

Allows you to answer a call by pressing 0 to 9, (, or # other than n.

･This function is available for voice calls and PushTalk calls. However, it is unavailable when receiving a call

while talking.

Default ON

m843

Press 1

･To cancel the setting: 2

Setting to start talking by opening FOMA terminal Open Answer

･This function is available for voice calls (available even while Key Lock is on).

Default OFF

m8464

Press 1

･To cancel the setting: 2

Setting to disconnect/continue/hold a call by closing FOMA terminal Close Setting

･This function does not operate during 64K data communication or packet communication. ･You can end a PushTalk call by closing FOMA terminal. Use PushTalk Close Setting to set it.

Default Continue

m8472

Press any of 1 to 3

End the call：Ends the call. Continue ：Continues the call. On hold ：Puts the call on hold. The other party hears a guidance (on-hold tone).

INFORMATION

● When you close FOMA terminal during a call using the Flat-plug Earphone/Microphone with Switch (optional) or a

handsfree device (available in market), the call continues regardless of this setting if the settings is made to play sounds from the connected device. Even if you remove the Flat-plug Earphone/Microphone with Switch (optional) or handsfree device in this state, the call will continue.

● When you close FOMA terminal while recording a message, the recording continues regardless of this setting.

● This setting applies when you close FOMA terminal while recording a talking voice memo/video memo. When On hold is

set, the contents recorded just before putting a call on hold are saved.

Calls/Videophone Calls

Page 74

Adjusting the volume of the other party’s voice during a call Listen Volume

The volume of the other party’s voice can be adjusted from level 1 (lowest volume) to level 6 (highest volume).

･The volume changed while talking is retained even after the call is ended. ･The set volume is retained even if the power is turned off.

Default Level 4

% during a call z O to adjust the volume

The volume is set automatically by pressing o or waiting for a while after you stop key operations.

･ To turn up the volume: u or r ･ To turn down the volume: d or l

Adjusting the volume of ring alerts and other sounds emitted from FOMA terminal

Adjust the volume of call, PushTalk, mail and Message R/F ring alerts, alarm clock, schedule alarm, i-αppli sounds, and the sound that plays when obtaining ToruCa.

･The volume can be adjusted in 7 levels, from silent to level 1 to level 6 (the volume of Movie ringtone can

also be adjusted in 7 levels). You can also set STEPTONE (the volume changes into silent → level 1→ level 6 about every 3 seconds) in standby.

Adjust Volume

Adjusting the volume of ring alerts while receiving

･The ring volume changed while receiving a call is reset to the original volume when a call or PushTalk is

ended.

% while receiving a call z O to adjust the volume

The volume is set automatically by pressing o or waiting for a while after you stop key operations.

･ To turn up the volume: u or r ･ To turn down the volume: d or l

INFORMATION

● To stop the ring alert and vibrator: C while receiving a call

● While receiving a call, the ring volume cannot be set to STEPTONE.

Adjusting the volume of ring alerts and other sounds in standby

･Listen volume cannot be set to silent. ･Listen volume, i- ･The ring volume changed while in standby is retained even if the power is turned off.

Default Level 4 (all)

ppli effect sound and ToruCa receive alert cannot be set to STEPTONE.

...

→

m812

1 to 3, 5 or 6

■ Adjusting the volume of alarm clock: 41

■ Adjusting the volume of schedule alarm: 42

Calls/Videophone Calls

Page 75

Call alert volume ：Adjusts the ring volume for voice calls, videophone calls and PushTalk calls.

The set volume also applies to the following sounds:

･ Timer alarm ･ Alarm for Call Cost Limit ･ Sound indicating the battery level ･Playback sound of melodies attached to mail

Mail/Msg alert vol.：Adjusts the ring volume for mails, chat mails and Message R/Fs. Listen volume ：Adjusts the earpiece volume during a voice call, videophone call and PushTalk call.

The set volume also applies to the following sounds:

･ Keypad sound ･ Sound of rotating the Speed Selector ･ Playback sound of voice call messages ･ Playback sound of voice memos

Alarm volume (Alarm clock sound/Schedule reminder):

Adjusts the volume of alarm clock that will be used when the volume is set to Terminal setting on the Set sound screen of Alarm Clock. Also adjusts the volume of schedule alarm.

ppli effect sound ：Adjusts the volume of effect sound for i-αppli.

iToruCa receive alert：Adjusts the volume of sound that plays when obtaining ToruCa. This setting is

O to adjust the volume z Press o

･To set to STEPTONE: ･To set to silent:

reflected to the setting of ToruCa Alert. ☛P284

or r when the volume is level 6

or l when the volume is level 1

INFORMATION

● is indicated on the standby display when Call alert volume is set to silent. If the vibrator for incoming voice calls is set

at the same time, is indicated.

Setting for incoming voice/videophone/PushTalk calls

Call Alert/Videophone Alert/PushTalk Alert

･For PushTalk Alert, Show image cannot be set.

Default Ring alert: Melody/Vivaldism (Call Alert), Melody/電話・メロディ A(Phone, melody A) (Videophone Alert),

Melody/電話・メロディ B(Phone, melody B) (PushTalk Alert) Show image: Standard image Vibrate alert: OFF Light alert: Flash/Blue (Call Alert/Videophone Alert), Flash/Red (PushTalk Alert)

Example

Setting operations when receiving a voice call

m8412

■ Setting operations when receiving a videophone call: m8512

■ Setting operations when receiving a PushTalk call: m8531

Select each item to set z Press p

Ring alert ：Sets the ring alert for incoming calls.

･When any of Melody, Movie ringtone or Music is selected, select a ring alert tone.

Show image：Sets the image displayed for incoming calls.

Setting music data ☛P121

･When Select image or i-motion is selected, set an image.

Vibrate alert：Sets the vibration for incoming calls. Light alert ：Sets the lighting pattern and color of the Enter key for incoming calls.

･When Kisekae tool is set ☛P143 ･Playing and checking a melody or video/i-motion file when selecting ☛P120

Calls/Videophone Calls

▲

Page 76

INFORMATION

● Setting Created animation for the incoming image displays the first frame.

● When the video/i-motion with sound only (i-motion without image such as singer’s vocals) or music data is set for Ring

alert, if Show image is reset to the video/i-motion with image only or Flash movie, the ring alert is reset to the default setting. The melody can be changed afterward.

● Some video/i-motion may not be set for the incoming image. Also, the video/i-motion with sound cannot be set.

● When setting video/i-motion for PushTalk Alert, only the video/i-motion with sound only can be set for the ring alert.

● The settings of this function are reflected to the settings of Sound Setting (☛P120), Vibrator Setting (☛P126) and Light

Alert Setting (☛P144). The setting of Show image is reflected to the settings of Incoming Call or Videophone Receiving of Call Image. ☛P134

Setting the priority screen for incoming calls during a call or packet communication

Set the priority of the screen to be displayed when you receive a packet communication through a connected PC during a voice call or you receive a voice call during i-mode.

Priority Comm Mode

･When there is incoming i-mode packet communication during a voice call, the voice call talking screen

appears by priority regardless of this setting.

･The screen change caused by this function does not interrupt the call or packet communication.

Default No Set Up

m8461

Press any of 1 to 3

No Set Up：Displays the screen for the latest incoming call/communication without setting the priority. Voice call：Displays the voice call talking screen by priority. Packet ：Displays the packet communication screen during a voice call, and the i-mode communication

screen during i-mode.

･Press b to display the Switch Task menu then answer an incoming call.

When you can or could no t answer a call/videoph one call

Putting incoming calls on hold when you cannot answer right away

Response and Hold

･Callers are charged for the time spent on hold.

f while receiving a call

The incoming call is put on hold (Response and Hold). The other party hears the response hold guidance. For videophone calls, the response hold image appears on your and the other party’s terminals.

･ If f is pressed or the other party hangs up

during Response and Hold, the call is disconnected.

Incoming voice

call on hold

Calls/Videophone Calls

Incoming videophone

call on hold

Page 77

Press n when you are ready to answer the call

ill

･Press t or n for a videophone call. Press a to send the substitute image ( ☛P84) to th e other party.

INFORMATION

● When you have subscribed to Voice Mail Service or Call Forwarding Service, you can use the service by pressing m

and selecting Voice Mail (V-phone answerphone) or Call Forwarding while receiving a call.

Setting the response hold guidance Status Message

You can record your own voice as response hold guidance.

･One guidance of up to about 10 seconds long can be recorded. ･While a voice call or videophone call is during Response and Hold, the guidance set by this function is

played.

Default Standard

Example

1 2

INFORMATION

● If you delete the recorded guidance, the default guidance (Standard) is restored.

● If Standard is set, the guidance “I cannot answer the phone right now. Please wait or call back later (in Japanese)” is

played for the other party during Response and Hold.

Setting a recorded guidance

m81161 z Select On-hold tone field

･To reset to the default guidance: 1 z Go to Step 4

Select Record in Edit message field z Speak a response hold guidance after a tone (beep)

Indication of the allowable recording time

Press p

ecording w

･An end tone (beep) sounds in about 10 seconds

from the start of recording.

･To stop the recording: o ･To check the recorded guidance: Select Play ･To record again, select Delete, select Yes and record

after deleting the recorded guidance.

start after a message appears.

Calls/Videophone Calls

Page 78

Setting the on-hold tone On-hold Tone

･While a voice call or videophone call is during On-hold, the melody set by this function is played.

Default 保留音・ボイス(On-hold tone, voice)

m81162

Press any of 1 to 3

･ To play a melody: Highlight a melody z p

Using Public mode (Driving mode) Public mode (Driving mode)

Public mode is an automatic answering service considering etiquette in highly public places. When Public mode is activated and a call is received, a guidance is played and informs the caller that the called party is driving or in an area (train, bus, movie theater, etc.) where use of the phone sh ou ld be refrained and cannot answer the call. Then the call is disconnected.

･Public mode can be activated/canceled only in standby (including when

displayed on the screen).

･Even in Public mode you can make calls as normal. ･This function is not available during data communication.

Activating Public mode (Driving mode)

Hold down ( for over a second

Public mode is activated and appears on the standby di splay. When a call is received, a guidance is played saying “ The person you a re calling is curren tly driving or in an area where cellphone should not be used. Please try again later”.

･ When Silent Mode is activated at the same time, Public mode takes precedence.

■ Canceling: ( (for over a second)

■ When Public mode (Driving mode ) is activated

No ring alert plays when your FOMA terminal receives a call. (with the number of missed calls) appears on the standby display and the call is recorded in the received call history. The caller hears a guidance informing that you are driving or in an area where use of the mobile phone should be refrained and the call is then ended.

･When there is an incoming PushTalk call, neither the ring alert nor the incoming indication works.

(with the number of missed calls) appears on the standby display and the call cannot be answered. Connection failed. appears on the caller’s screen. In case of the PushTalk call with 3 or more parties, the connected members are notified that you are driving.

圏外

(outside service area) is

Calls/Videophone Calls

Page 79

■ Operation when receiving calls in Public mode (Driving mode) with network service activated

Service Receiving voice calls Receiving videophone calls

Voice Mail Service

Call Forwarding Service

Call Waiting Service

Nuisance Call Blocking Service

Caller ID Request Service

The caller hears the Public mode guida nce and the call is then connected to the Voice Mail Service Center.*

The caller hears the Public mode guida nce and the call is then forwarded to the specified destination.* Whether the caller hears the guidance or not depends on the setting for Call Forwarding Service. When the guidance is on, the Public mode guidance is played. When the guidance is off, no guidance is played.

The caller hears the Public mode guida nce and the call is then disconnected.

If registered as nuisance call er, the caller hears a guidance indicating that the call cannot be connected and the call is then disconnected.

･The caller who has not notified the caller ID

hears a guidance requesting caller ID and the call is then disconnected.

･The caller who has notified the caller ID

hears the Public mode guidance and the call is then disconnected.

*1 If the ringing time is set to 0 second, the Public mode guidance is not played.

The call is connected to the Voice Mail Service Center without the Public mode video guidance.

The call is forwarded to the specified destination without the Public mode video guidance. If the destination party uses the phone not compatible with videophone, the call is disconnected.

The caller sees the Public mode video guidance and the call is then disconnected.

If registered as nuisance caller, the caller sees a video guidance indicating that the call cannot be connected and the call is then disconnected.

･ The caller who has not notified the caller ID

sees a video guidance requesting caller ID and the call is then disconnected.

･ The caller who has notified the caller ID sees

the Public mode video guidance and the call is then disconnected.

INFORMATION

● In Public mode, the following sounds are disabled. In addition, the vibrator does not operate or the Enter key does not

light/flash for incoming calls/mails, etc.

･ Ring alert ･Alarm clock ･ Schedule alarm ･ Timer alarm ･ i-

ppli sound ･Charge alert ･ Low battery alert

･ Alarm for Call Cost Limit (Even if Alert for Call Cost Limit is set to ON and an alarm is set, a message is not displayed.)

● Even in Public mode, the following sounds are played:

･ Keypad sound ･ Speed Selector sound ･ Shutter sound ･Slide sound ･ 1Seg sound ･ 1Seg sound effects

● In Public mode, neither the i-channel ticker nor Chaku-moji appears on the standby display.

● Even if a mail or Message R/F is received, the receiving screen and reception result screen do not appear. But, when

Check i-mode Message is performed, these screens appear.

● Making emergency calls (110, 119 or 118) in Public mode cancels Public mode. However, it is not canceled when

emergency calls are made using videophone.

Calls/Videophone Calls

Page 80

Using Public mode (power off) Public mode (power off)

Public mode (power off) is an automatic answering service considering etiquettes in highly public places. When Public mode (power off) is set and then a call is received with FOMA terminal switched off, a guidance is played and informs the caller that the called party is in an area (hospital, airplane, priority seat area on a train, etc) where the phone should be turned off and cannot answer the call. Then the call is disconnected.

Activating Public mode (power off)

(25251 z Press n

Public mode (power off) is set. There will be no change on the standby display. When you subsequently turn the power off, Public mode (power off) is activated. In Public mode (power off) if a call is received with FOMA terminal off, a guidance is played saying “The person you are calling is currently in an area where use is prohibited. Please try again later”.

■ Canceling: (25250 z n

■ Checking the setting: (25259 z n

■ When Public mode (power off) is ac tivated

The setting is retained until Public mode (power off) is canceled by dialing “ 25250”. The setting is not canceled by turning the power on. The Public mode (power off) guidance is played even in locations outside the service area or where radio waves are hard to reach. The caller hears a guidance informing that you are in an area where the phone should be turned off and the call is then ended.

･An incoming PushTalk call is not answered, and Connection failed. appears on the caller’s screen. In case

of the PushTalk call with 3 or more parties, the connected members are notified that you are not connected.

■ Operation when receiving calls in Public mode (power off) with network service activated

Service Receiving voice calls Receiving videophone calls

Voice Mail Service

Call Forwarding Service

Nuisance Call Blocking Service

Caller ID Request Service

*1 If the ringing time is set to 0 second, the Public mode (power off) guidance is not played.

The caller hears the Public mode (power off) guidance and the call is then connected to the Voice Mail Service Center.*

The caller hears the Public mode (power off) guidance and the call is then forwarded to the specified destination.* Whether the caller hears the guidance or not depends on the setting for Call Forwarding Service. When the guidance is on, the Public mode guidance is played. When the guidance is off, no guidance is played.

If registered as nuisance caller, the caller hears a guidance indicating that the call cannot be connected and the call is then disconnected.

･

The caller who has not notified the caller ID hears a guidance requesting caller ID and the call is then disconnected.

･

The caller who has notified the cal ler ID he ars the Public mode (power off) guidance and the call is then disconnected.

The call is connected to the Voice Mail Service Center without the Public mode (power off) video guidance.

The call is forwarded to the specified d estination without the Public mode (power off) video guidance. If the destination party uses the phone not compatible with videophone, the call is disconnected.

If registered as nuisance caller, the caller sees a video guidance indicating that the call cannot be connected and the call is then disconnected.

･

The caller who has not notified the caller ID sees a video guidance requesting caller ID and the call is then disconnected.

･

The caller who has notified the caller ID sees the Public mode (power off) video guidance and the call is then disconnected.

Calls/Videophone Calls

Page 81

Allowing the caller to leave message when you cannot answer the c all

By setting Answer Machine, you can play the greeting message and record the caller’s message when you cannot answer the call.

Answer Machine

･Up to 4 messages can be recorded for voice/videophone calls in total, a maximum of about 30 seconds for

each.

･For voice calls, the caller’s voice is recorded. For videophone calls, the caller’s voice and image are

recorded.

･You can set the time interval between the reception of the call and the start of the greeting. ･The greeting in your own voice can be recorded. ･Incoming PushTalk calls cannot be answered by Answer Machine. ･It is advisable that the contents of recorded messages be separately written down in a notebook, etc.

Recorded data may be lost due to failure, repair, change of model or other handlings of FOMA terminal. If the data should be erased, DoCoMo assumes no responsibility for the loss of any data.

Menu 4711

Setting Answer Machine

Default Deactivate

Press C11

appears on the standby display.

■ Canceling: C12

Replying with Quick Record Message

When Answer Machine has not been set to start, you can activate this functi on only on ce by holding down C for over a second while receiving a call. This operation does not set Answer Machine to start.

INFORMATION

● When the number of recorded messages reaches 4, is indicated on the standby display. The icon does not

disappear even if Answer Machine is canceled.

● If there are already 4 recorded messages, Answer Machine cannot be set. If you attempt to activate Quick Record

Message while receiving a call, the warning tone (rapid beeps) sounds and the ring alert keeps sounding. Delete unnecessary recorded messages and set again.

Calls/Videophone Calls

Page 82

Receiving a call while Answer Machine is set

A call arrives

After the ring alert sounds according to Greeting Response Time, the greeting message screen appears.

･ When the greeting message is set to Preinstalled, the caller hears the guidance “I cannot answer the

phone right now, please leave your name and message after the beep (in Japa nese)”. Set Personalized to play a recorded guidance.

Recording the caller’s message starts

Indication of the allowable recording time

Recording a voice call

message

When the recording is completed, the call is disconnected

INFORMATION

● When FOMA terminal is turned off or outside the service area, Answer Machine does not operate. Use Voice Mail

Service (pay service).

● Answer Machine does not operate and the ring alert keeps sounding when 4 messages have already been recorded.

If Voice Mail Service or Call Forwarding Service is activated, each service starts its operation.

● Public mode (Driving mode) takes precedence over Answer Machine. In Public mode (Driving mode), Answer Machine

does not operate.

● The recording may be disrupted or the image may be distorted if the signal conditions are poor.

● Another call received while playing the greeting or recording a message is rejected and playing or recording continues.

If Voice Mail Service, Call Forwarding Service or Call Waiting Service is subscribed, the rejected incoming call is recorded in the received call history.

● You can answer a call even while playing the greeting or recording a message. Press n to answer a voice call. To

answer a videophone call and send your image, press n or t. To send the substitute image, press a. If you answer the call, the content recorded up to that point is not saved.

(with the number of recorded messages) appears on the standby display.

Recording a videophone

call message

･A beep announces the caller the

start and end of the recording. And when about 25 seconds have elapsed since the start of recording, rapid beeps sound to indicate that the end of recording is approaching.

Menu 4713

Setting the response time until the greeting starts Greeting Response Time

Default 013 Sec.

C13

Enter the response time (0 to 120 seconds)

･ To increase or decrease the entered values: %

Calls/Videophone Calls

Page 83

INFORMATION

● When Auto Answer, Voice Mail Service or Call Forwarding Service and this function are set simultaneously, the priority

depends on the ringing time set for each service and function. To give priority to Answer Machine, the response time for this function should be set shorter than the ringing times set for Auto Answer, Voice Mail Service and Call Forwarding Service. Note that Answer Machine may not be given priority depending on the signal conditions. In this case, answer a call with Quick Record Message.

● The delayed time of Auto Answer and the response time of Answer Machine cannot be set to the same time period.

Menu 4714

Setting the greeting message Greeting Message Setting

You can record your own voice as greeting message.

･One greeting of up to about 10 seconds long can be recorded.

Default Preinstalled

Example

1 2

INFORMATION

● If you delete the recorded greeting, the default greeting is restored.

Setting a recorded greeting

C14 z Select Greeting message field

･To reset to the default greeting: 1 z Go to Step 4

Select Record in Edit message field z Speak a greeting message after a tone (beep)

･The operation procedure is the same as when recording the response hold guidance. ☛P71

Press p

Playing recorded messages

You can play or delete recorded messages from the list.

･Unplayed recorded messages, if any, can be played quickly from the standby display. ☛P34

On the recorded message list screen, the recording date and time and the caller’s phone number appear.

: Voice call message (unplayed) : Videophone call message (unplayed) : Voice call message (played) : Videophone call message (played)

･If the caller’s phone number is notified, it is displayed. If not, the reason for no

caller ID is displayed. If the notified caller’s phone number is registered in the phonebook, the name is displayed.

･When you have subscribed to the Multi Number service, the name of basic

number or additional number used by a received call is also displayed.

Menu 472

Calls/Videophone Calls

▲

Page 84

Select a recorded message to play

Indication of the playing time

Playing a voice call

message

Select Yes or No

･ To delete the recorded message: Select Yes

･ During playback, the following operations are available:

：Adjust volume

% n：Speakerphone on/off (for voice call messages only)

■ Deleting:

a Highlight a recorded message z m21

･ To delete all: m22

b Select Yes

■ Registering an entry in the phonebook:

a Highlight a recorded message z m4

･ To add to an existing phonebook entry: m5

b 1 or 2 z Register the name or address ☛P101, P103

･ To add to an existing phonebook entry: 1 or 2 z Select the party

z Edit the data ☛P111

■ Making a call: Highlight a recorded message z n (voice call) or t

(videophone call)

：Stop

Using Chara-den

A character can be sent instea d of your image when making a videophone call.

m321 during a call

Select a folder z Select a Chara-den image

Chara-den

Action list scrolls.

INFORMATION

● Some Chara-den has either one of full actions or parts actions or has no actions at all.

Calls/Videophone Calls

･ If you press dial keys while sending Chara-den as the substitute image, the

character performs the action correspondin g to the key pressed. The following operations can also be performed:

0：Cancel action (：Display the action list

･Selecting an action moves the character.

( (for over a second):

Switch action modes (Action/Action of parts)

Page 85

Setting images being sent to the other party

You can change the image being sent to the other party or apply special effects to it during a videophone call. Also, you can switch between t he in-camera and the out-camera.

Switching the outgoing image between your self image and the substitute image

Press t during a call

The substitute image

Setting the quality of outgoing and incoming images

･Setting Prefer motion spd makes motions smoother in a little lower-definit ion image. ･Setting Prefer img qual makes motions a little slower in a higher-definition image.

Default Normal

･Each press switches the image between your self image ( ) and the

substitute image ( or ). ☛P84

･Even when Chara-den is set as the substitute image, Chara-den may not be

displayed. If this happens, the default image for the substitute image setting is sent to the other party. ☛P84

Example

Setting the quality of outgoing image

m51 during a call

■ Setting the quality of incoming image: m52 during a call

Press any of 1 to 3

Calls/Videophone Calls

Page 86

Setting a frame on the outgoing images Frame

The frame can be set while sending your self image.

･Only the frame with the display size of 176 x 144 or smaller can be selected. As for downloaded frames,

only the frame with the display size of 176 x 144 can be selected.

m31 during a call

Select a frame

･ While the in-camera is used, the mirror image (left-right reversed image) is

displayed on the screen, but the normal image (right directed image) is sent to the other party. While the out-camera is used, the same image as disp layed on the screen is sent to the other party.

･ To cancel sending the frame: o while sending a frame ･ Frames set by default ☛P431

Applying special effects to outgoing images Scene Mode/Effect

You can apply the following effects to outgoing images. This setting is available only while sending your self image.

Item Icon Item Icon Item Icon Item Icon

Full auto Twilight Letter Mono tone (green) Adjust backlight Surf&Snow Whiten Mono tone (blue) Spot photometry Sport Suntan Monochrome Scenery Pet Soft touch Sepia Night Gourmet Mono tone (red)

･For details ☛P179

Default Full auto

m21 during a call

Press any of 1 to 9, 0, ( or #

Current effect applied

Calls/Videophone Calls

Page 87

Adjusting the brightness/color density/flicker of outgoing images Camera Setting

You can adjust the brightness and color density in 5 levels. Also, you may be able to control the flicker of images, if it occurs, by making settings according to the power supply frequency in your area.

･This setting is available only while your self image is being sent. ･The brightness and color density may not be changed depending on the settings of Screen Mode/Eff ect. ･This setting is retained even after the call is finished.

Default Brightness: level 3 Density: level 3 Flicker adjustment: Auto

m2 during a call z Select an item

■ Adjusting brightness and color density:

a 2 z Highlight Brightness slider z b d to highlight Density slider z & z p

･ Your self image is displayed on the main screen while adjusting. ･ If you do nothing on the terminal for some time after changing the

slider’s position, the settings are not changed and the talking screen reappears.

■ Adjusting flicker: 3 z 1 to 3

INFORMATION

● The flicker adjustment settings for the camera and Bar Code Reader will reflect changes in this setting. ☛P183, P184

Sending the still image/camera-off image

Select a still image or the image displayed as Camera off (camera-off image).

･This setting is not available while a frame is being sent. ☛P80 ･Only the still image that is 176 x 144 or smaller and is permitted to output from FOMA terminal can be set.

m3 during a call z Select an item

■ Sending the camera-off image: 3

･ When the camera-off image is set, the substitute image set in Videophone Image Setting is sent.

However, if Chara-den is set as the substitute image, the default image (camera-off image) is sent.

■ Sending a still image:

a 4 z Select a folder b Select a still image

･ To view a still image: Highlight a still image z p ･ To send the previous image: o while sending a still image

Calls/Videophone Calls

Page 88

Switching display magnifications Zoom

･This setting is available only while your self image is being sent.

Default normal ( )

Press & during a call

･ Each press of r switches the magnification of image as follows. Press l to switch in the reverse

order. In-camera : normal ( ) → 2x ( ) Out-camera: normal ( ) → 2x ( ) → 4x ( )

INFORMATION

● Zooming will be canceled if you switch between the in-camera and out-camera.

Switching to the out-camera

･This setting is available only while your self image is being sent.

Default in-camera

Press m4 during a call

The image through the out-camera is sent.

･ Each press switches between the in-camera and

out-camera.

･ Even if you switch the cameras, the frame and the

brightness/color density/flicker settings of outgoing image are kept.

In-camera selected Out-camera selected

INFORMATION

● To shoot an object from a very short distance using the out-camera, switch to the macro mode. ☛P179

Customizing the screen settings during a videophone call

･The settings are retained even after the call is finished.

Switching between the main screen and sub screen

Default Main screen image: other party’s image Sub screen image: your self image

Press p during a call

･ Each press switches the images on the main screen and sub screen by turns.

Main screen: other party’s image Main screen: your self image Sub screen: your self image Sub screen: other party’s image

Calls/Videophone Calls

Page 89

Changing the main screen size

Default large

Hold down p for over a second during a call

･Each press switches the screen size in the following order: large → standard → small → large → .

Setting the screen displayed during a call Videophone Settings during a call

Default Display setting: Both sides Sub screen: My side Screen size: Large Display light: Always on(normal)

m6 during a call

Select each item to set z Press p

･For setting each item (Display setting, Sub screen, Screen size and Display light), follow Step 2 in “Changing

the videophone settings”.

…

Changing the videophone settings Videophone Settings

Set the operation to be performed when a videophone call is not connected, the screen displayed during a videophone call, etc.

･The setting of Auto redial as voice is provided to ensure access to the other party. By setting this function to

ON, a dialed videophone call will be automa tically redialed as voice call if the other party’s t erminal does n ot

support the videophone function or cannot r eceive the videophone call whi le using the mova service through Dual Network Service. Redialing does not occur, however, if you call an ISDN-sync 64 kbps or PIAFS access point, or an ISDN videophone incompatible with 3G-324M (as of January 2007), or if you dial the wrong number. Note that some calls may require the call charge.

Default

Auto redial as voice: OFF Display setting: Both sides Sub screen: My side Screen size : Large Visual preference: Normal Display light: Always on(normal) Speakerphone: ON

m8513

Select each item to set z Press p

Auto redial as voice：Sets whether to redial as voice call automat ically when a videophone call is not connected. Display setting ：Specifies whether to display either your self image or the other party’s image or both

Sub screen ：Specifies whether to display your self image or the other party’s image on the sub

Screen size ：Sets the main screen view size. Visual preference ：Sets the quality of image sent from the other party. Display light ：Sets the display light during a videophone call.

Speakerphone ：Specifies whether to turn on the speakerphone function automatically once a videophone

images during a videophone call.

screen during a videophone call.

･When Terminal settings is set, the setting of Display light time (Normal use) in Display

Light Setting (☛P137) applies.

call is connected.

Calls/Videophone Calls

▲

Page 90

INFORMATION

● Even when Auto redial as voice is set to ON, redialing may not be performed depending on the situation of the other party

or the network.

● When Auto redial as voice is set to ON, if you make a videophone call during a packet communication with a PC

connected, the call is redialed as voice call without connecting to a videophone call. During a voice call or 64K data communication, the call is not connected to a videophone call and redialing is not performed, either.

● If redialing as voice call occurs with Auto redial as voice set to ON, voice call charges apply instead of digital

communication charges.

● When you talk on a videophone call while the Flat-plug Earphone/Microphone with Switch (optional) is connected, the

voice sounds from the connected earphone/microphone regardless of the setting of Speakerphone.

● If a videophone call is made to emergency calls (110, 119 or 118) from FOMA terminal while Auto redial as voice is set to

ON, the call automatically switches to a voice call.

Menu 8235

Setting the substitute and on-hold images to be displayed during a videophone call

Change the images to be sent to the other party durin g a video phon e ca ll such as the substi tut e ima ge, answer machine image, response hold image, on-hold image and video memo image.

Videophone Image Setting

･You cannot set the following images:

・Still image with a size larger than 176 x 144 ・Still image in the format other than JPEG and GIF ・Animation and Created animation ・Image not permitted to output from FOMA terminal

Setting the substitute image

Default Default Chara-den

m8515

1 z Select Image field z Press p

■ Setting the default Chara-den: 1

Default Chara-den (Dimo) is set.

■ Setting the default still image: 2

Default image (camera-off image) is set.

Chara-den

■ Setting other Chara-den:

a 3 z Select Select image z Select a folder b Select a Chara-den image

･ To display Chara-den: Highlight a Chara-den image z

■ Setting other still images:

a 4 z Select Select image z Select a fo lde r b Select a still imag e

･To display a still image: Highlight a still image z p ･The selected image with the text message on it appears on the other party’s terminal.

INFORMATION

● If the Chara-den set as the substitute image is deleted, the substitute image is reset to Default Chara-den. If the still

image or the default Chara-den is deleted, the substitute image is reset to Default image.

Calls/Videophone Calls

Page 91

Changing the answer machine/response hold/on-hold/video memo images

Default Answer machine im age, Response hold image, On-hold imag e, Movie memo image: Default

m8515

2 to 5 z Select Image field z Press p

■ Setting the default still image: 1

The default image is set.

■ Setting other still images:

a 2 z Select Select image z Select a folder b Select a still image

･ To display a still image: Highlight a still image z p

In case of the answer

machine image

･ The selected image with the text message on it appears on the other

party’s terminal.

Setting of switching between a voice call and videophone call

Set whether to notify the other party’s terminal that your terminal can switch between a voice call and a videophone call.

･You cannot change the setting during a voice call or videophone call. ･This setting cannot be made outside the service area. Operate the terminal in locations with good radio

wave condition.

Time of subscription Indication ON

m85171

■ Deactivating: m85172

■ Checking the current setting: m85173

Select Yes

Setting how incoming videophone calls are handled during i-mode

Videophone calls can be receiv ed during i-mode packet communication.

Default V.phone priority

m8514

Press any of 1 to 4

V.phone priority ：Receives a videophone call. When the call is answered, the current packet

Packet DL priority ：Rejects an incoming videophone call and continues the packet communication. V.phone answerphone：Connects an incoming videophone call to the Voice Mail Service Center. Call forwarding ：Forwards an incoming videophone call to the forwarding phone number.

communication is disconnected.

Notify Switchable Mod e

Data Session Arrival Act

Calls/Videophone Calls

▲

Page 92

INFORMATION

● Without subscription to Voice Mail Service or Call Forwarding Service, even if you set V.phone answerphone or Call

forwarding, the action of Packet DL priority takes place.

● If Voice Mail Service or Call Forwarding Service is activated and the ringing time for each service is set to 0 second,

either service starts its operation, regardless of this setting. Incoming calls are not recorded in the received call history.

Using the videophone by connecting to an external device External Device

By connecting FOMA terminal to an external device such as PC by the FOMA USB Cable (optional), you can make and receive videophone calls from the external device. To use this function, install a videophone application in a dedicated external device or a PC, and prepare devices such as an earphone/microp hone or USB-compatible Web camera (available in market).

･This function is not available when FOMA terminal is not connected to an external device. ･Refer to the instruction manual of external devices for hardware requirements or setting/operating

instructions of videophone applications.

･The application called “ドコモテレビ電話ソフト 2005 (DoCoMo videophone software 2005)” that is

compatible with this function is available on the DoCoMo videophone software website. Visit the site below and download it (visit the support website for details of the environment for usage on PC):

http://videophonesoft.nttdocomo.co.jp/ (in Japanese only)

Default Terminal

Base station

FOMA videophone communication speed: 64K or 32K

FOMA

network

m8516

Press 1 or 2

INFORMATION

● A videophone call cannot be made from an external device during a voice call.

● When Call Waiting Service is subscribed, if a videophone call is received through an external device during a voice call,

it is recorded as a missed call in the received call history. The same applies when a voice call, videophone call or 64K data communication is received during a videophone call using an external device.

Calls/Videophone Calls

Page 93

PushTalk

What’s PushTalk? .............................................................................................88

Making PushTalk calls .....................................................................................88

Receiving PushTalk calls .................................................................................91

Registering entries into the PushTalk phonebook

.................................................................... PushTalk Phonebook New Entry 92

Making a PushTalk call by using the PushTalk phonebook .........................93

Deleting members from the PushTalk phonebook

.......................................................................... Delete PushTalk Phonebook 94

Setting for incoming/outgoing PushTalk calls ..............................................95

Page 94

音の設定

What’s PushTalk?

The PushTalk button (g) allows you to communicate with multiple peo ple (up to 5 including yourself) by si mple operation. Press the PushTalk button for over a second to make access to the PushTalk phonebook, select the parties to talk to and press g. PushTalk communication fee is c harged every time y ou press g (speak). Hold down g while you are speaking and the other parties only listen to you. On the screen, you can see who is speaking and the states of the other memb ers. This function is very useful when communicating within a group or delivering a brief message to multiple persons.

･Supporting models: 902i series, 902iS series, SO902iWP+, SH902iSL, N902iX HIGH-SPEED, N90 2iL, 903 i

series, 702i series (except SH702iD, N7 02iD, F702iD, D 702i, SA702i an d SO702i), 70 2iS series (except N702iS, D702iF, M702iS and M702 iG), 703i serie s (except N703i D, F703i,

D703i, P703iμ and N703iμ) Also, for the following models* during PushTalk again. * 1 903i series, 703i series (except N703iD, F703i, D703i, P703iμ and N703iμ)

Talk between two persons

, you can add a new member or call the party who has not been connected

Talk among multiple persons

Hello.

Receiver

Callout

ReceiverCaller

Speak while holding down g.

Receiver Receiver

I’ll arrive soon.

ReceiverCaller

Speak while holding down g.

PushTalkPlus

PushTalkPlus is a service in which you can communicate with up to 20 persons including you by using a phonebook on the network registered in advance. This service also provides some useful functions such as allowing you to check the member’s state. Note that the optional subscription is needed if you use PushTalkPlus.

● For details about how to operate PushTalkPlus, see the separately-provided booklet.

Making PushTalk calls

PushTalk communication screen

Member that is speaking now

Name*1, phone number, Anonymous*2, Myself, a blank*3, or *4 is displayed.

Group name (indicated only on the screen of the party who started group calling) The other party’s status

Member

Name*1, phone number, or Anonymous*2 is displayed.

*1 Displayed when the phone number is registered in the FOMA terminal phonebook (Name displays ☛P100).

: Calling the other party : Participating in PushTalk

: No response, PushTalk ended, or the other party’s terminal is outside service area

or turned off

: Public mode (Driving mode) set on the other party’s terminal

PushTalk

Page 95

*2 When a caller makes a PushTalk call not notifying the caller ID, the members are indicated as Anonymous on

receiver’s screen.

*3 Displayed when no party is speaking. *4 Displayed when the speaking party cannot be identified. *5 Displayed when 3 or more parties are communicating.

Communicating on PushTalk

Enter the phone number z g

When the other party answers, the answering tone sounds and PushTalk starts.

Communicate on PushTalk

･When a member answers while 3 or more parties are communicating, the connection tone sounds. ･When a member exits from PushTalk while 3 or more parties are communicating, the tone sounds to

indicate the disconnection of a member.

■ Turning on/off the speakerphone function: a or n

■ Speaking:

a Hold down g while speaking

･ When you press g, you hear the floor acquisition sound. ･ While another party is speaking, pressing g makes the floor acquisition failure sound and you

cannot speak.

b Release g when you finish speaking

･ When you release g, a tone sounds to indicate the end of floor acquisition. ･ When the limit of time for the floor acquisition approaches, a tone sounds to indicate the floor

acquisition is ending.

･When FOMA terminal is closed or P-Talk Speakerphone is set to ON, the

speakerphone function is turned on. If P-Talk Speakerphone is set to OFF or Silent Mode is active, hold down g for over a second to make a call usi ng the speakerphone.

Press f when you end PushTalk

INFORMATION

● You can make a PushTalk call from the FOMA terminal phonebook, UIM phonebook, redial data, received call history,

sent message log, received message log, icall from mail, sites, or Phone To (AV Phone To) in ToruCa.

● You cannot make a PushTalk call during a voice call, videophone call or data communication. During PushTalk, you

cannot make a voice call or videophone call to a different party.

● When you make a PushTalk call during i-mode, i-mode is disconnected.

● When you make a PushTalk call when i-

● Speaking time with a single floor acquisition is limited. When the time limit arrives, the floor acquisition is canceled.

● If no party acquires the floor for a certain period of time, PushTalk ends.

● You cannot call an emergency number (110, 119, or 118) during PushTalk.

ppli, or scan result of Bar Code Reader. You can also make a PushTalk

ppli is running, i-αppli is suspended.

PushTalk

Page 96

Adding a member during PushTalk

The caller can add another member during a PushTalk call until the maximum number of particip ants (5 persons including yourself) is reached.

･A member who is already connected or is being called cannot be added again. ･Even while adding a member, the PushTalk operation such as talking is possible. ･A member can be added repeatedly until the maximum number of participants is reached. ･You can add a member who uses a model that is not compatible with PushTalk member addition. The

added member will be notified to the connected members by display. However, a connected member using a model not compatible with PushTalk member addition will neither receive such notification nor hear the connection tone or the tone ind icating th e disconnec tion. Th e caller using an incomp atible mod el cannot ad d a member.

･The added member is recorded in neither the redial data nor the received call history.

p during a PushTalk call

Select the adding method and make a call

■ Selecting from the PushTalk phonebook: Select View PT ph.book z Select a member z t

･ Do the same as you select members from the PushTalk phonebook. ☛P93 ･ To add from a PushTalk group: p in the PushTalk phonebook list z Select a group z Select a member z

■ Selecting from the phonebook: Select View phonebook z Select a member

■ Selecting from the redial data or received call history:

a Select View call records

･To switch between the redial list and received call list: p ･Only the calls with the caller ID are displayed in the received call list. ･The calls using PushTalkPlus (☛P88) are not displayed.

b Highlight a member

･To select from a PushTalk call log: Select a PushTalk call log z o z Select a member z t

Select a member in the PushTalk call log and press m to check the detail information. Press o to make a call.

･Select a member from the log of voice/videophone call: High light a log of voice /videophone ca ll z t

Select a voice/videophone call to check the detai l info rma ti on. Pr ess o to make a call.

■ Entering the phone number: Select Direct input z Enter the phone number (up to 26 digits) z t

PushTalk

Page 97

Receiving PushTalk calls

An incoming PushTalk call arrives

The PushTalk ring alert sounds, the display light turns on, and the Enter key lights or flashes.

Blinking

Phone number, name (when the phone number is registered in the FOMA terminal phonebook), or Anonymous*1 is displayed.

*1 When a caller makes a PushTalk call not notifying the caller ID, the members are indicated as Anonymous on

receiver’s screen.

g or n

You can answer the PushTalk call and Connected is notified to the other party.

･When FOMA terminal is closed, the speakerphone function is turned on. When FOMA terminal is open, the

setting of P-Talk Speakerphone applies (in Silent Mode, however, the speakerphone function is not turned on).

･You can also answer a PushTalk call by pressing 0 to 9, (, or # (Any Key Answer ☛P67). ･Pressing f disconnects the call without answering it (Response and Hold is not available). For a group

call, Disconnected is notified to the connected members.

Communicate on PushTalk

･For details, follow Step 2 of “Communicating on PushTalk”. ☛P89

Press f when you end PushTalk

INFORMATION

● You cannot answer incoming PushTalk calls during a voice call. They are recorded in the received call history.

● PushTalk calls cannot be received during a videophone call, videophone call through an external device, data

communication, software update, or pattern definition update. The missed calls are not recorded in the received call history.

● If you receive a PushTalk call during i-mode, the action will be subject to the setting of i-mode Arrival Act: PT.

● i-mode cannot be used during PushTalk.

● Even if there is an incoming videophone call, PushTalk call or data communication du ring PushTalk, you cannot answer.

They are recorded in the received call history.

● When no answer is received within the duration (in seconds) set in PushTalk Ring Time, the incoming PushTalk call is

terminated. In case of the PushTalk call with 3 or more parties, Disconnected is notified to the connected members.

● In Public mode (Driving mode), neither the ring alert sounds nor the incoming screen appears for an incoming PushTalk

call. (with the number of calls) appears on the screen and the call cannot be answered. In case of the PushTalk call with 3 or more parties, Driving is notified to the connected members.

● Even if you do not answer an incoming PushTalk call or you exit from the PushTalk communication, you can rejoin the

communication from the received call history while the caller is communicating on PushTalk.

● When PushTalk Arrival Act is set to Answer and an incoming voice call arrives during PushTalk, the operation is the

same as during a voice call. ☛P65

indicates the caller.

PushTalk

Page 98

Menu 44

Registering entries into the PushTalk phonebook PushTalk Phonebook New Entry

･Up to 700 entries can be registered (or fewer depending on the type of data registered). ･The phone numbers must be registered in the FOMA terminal phonebook in advance to be registered in the

PushTalk phonebook.

･If you delete or change a phone number in the FOMA terminal phonebook, the same phone number in the

PushTalk phonebook is changed in the same way. The setting for Secret Attribute will also be reflected.

Example

2 3

INFORMATION

● To register a member from the FOMA terminal phonebook to the PushTalk phonebook, highlight a party from the

phonebook list, press m33, and select Yes. When multiple phone numbers are registered, only one of them can be registered. Select the desired phone number and select Yes. You can also make the same registration by highlighting a phone number on the phonebook details screen, pressing m43, and selecting Yes.

Registering by searching the FOMA terminal phonebook

g (for over a second)

Select View phonebook

･ When registering a phone number that is not registered in the FOMA terminal phonebook, select Direct

input. The FOMA terminal phonebook registration screen appears (☛P101). Set the required ite ms and

save them. The phone number will be reg istered i n both th e PushTalk ph oneboo k and the FOMA termina l phonebook. If you register multiple phone numbers, select the number you want to register in the PushTalk phonebook. Then registration to the PushTalk phonebook is completed.

Search the phonebook z Select the party z Select Yes

･ To register additional members: Repeat Step 2 to 4

Registering members into groups

You can register members registered in the PushTalk phonebook into different groups.

･Up to 30 groups can be registered. ･Up to 19 members can be registered in one group. However, a Push Talk communication can include up to 5

members. When you make a PushTalk call, select up to 4 members other than yourself.

･The same member can be registered in different groups.

g (for over a second) z p

PushTalk

･ To register members in a registered group, go to Step 3.

■ Changing the group name: Highlight a group z m3 z Enter th e

group name z p

･ Changing the group name will not automatically change the name in the

redial data.

Page 99

a z Enter the group name (up to 20 one-byte or 10 two-byte characters) z p

Select the group z a z Select the member z Press p

Making a PushTalk call by using the PushTalk phonebook

･To make a PushTalk call to multiple parties, their phone numbers must be registered in the PushTalk phonebook.

g (for over a second)

Highlighted member’s phone number Name registered in the FOMA terminal phonebook

Select members

Members are displayed in the following order of readings:

1. Japanese syllabary order 2. Alphabetical order 3. Numbers

4. Entries starting with a blank 5. Symbols 6. No reading

･Pressing 1 to 9 or 0 highlights the first member of the column

corresponding to the Japanese character (あ(a) to ら(ra) and わ(wa)) assigned to each dial key. Pressing ( or # highlights a member whose name (reading) starts with other than Japanese kana character.

･When you press m6 on the member list, you will connect to the network

and can use PushTalkPlus. ☛ P88

･Up to 4 members can be selected for making a call. ･To check the selected members: m1

Selected members

g or t

When the first member answers, the answering tone sounds and PushTalk starts.

･If you do not select any member, a call is made to the highlighted member. ･If P-Talk Speakerphone is set to OFF or Silent Mode is active, hold down g or t for over a second to

make a call using the speakerphone.

Communicate on PushTalk

･For details, follow Step 2 of “Communicating on PushTalk”. ☛P89

Press f when you end PushTalk

･When the caller presses f, PushTalk communication of all present members comes to an end. If the

caller is still calling a member, a confirmation screen app ears asking wheth er to end Pu shTalk. Select Yes to end.

INFORMATION

● You can make a PushTalk call to multiple parties from the redial data or received call history.

● The phonebook data to which Secret Attribute is set is not displayed unless Secret Mode is on.

● If you add “184” or “186” to a member’s phone number, it is ignored.

● When you make a PushTalk call to multiple members and if the phone number is registered more than once with

different names, the first name in the Japanese syllabary appears on the PushTalk communication screen.

Highlighted member

PushTalk

Page 100

Making a PushTalk call from the PushTalk group

g (for over a second) z p z Select the group

･ To make a PushTalk call to all the members of the group: g (for over a second) z p z Highlight a

group z Go to Step 3

Select the member to make a PushTalk call

Press g or t

･ If you make a call from the group list, the call is made to all the members of the highlighted group. When

5 or more members are registered, a message appears warning that the number of allowable parities is exceeded. Select up to 4 members and make a PushTalk call.

･ For the subsequent steps, follow the procedure from Step 4 in “Making a PushTalk call by using the

PushTalk phonebook”. ☛P93

INFORMATION

● When Secret Mode is not set, the call is only made to members whose Secret Attribute is not set.

･ All the members of the group are selected. ･ Up to 4 members can be selected for making a call. ･ To check the selected members: m1

Deleting members from the PushTalk phonebook Delete PushTalk Phonebook

g (for over a second) z Highlight the member z m3

Selected member Highlighted member

･ Not the member you selected but the highlighted member is deleted.

Select Yes z Select No

･ To also delete from the FOMA terminal phonebook: Select Yes z Select Yes ･ If you delete a member registered in a group, the member is also deleted from the group.

Deleting a group

g (for over a second) z p z Highlight the group z m2 z Select Yes

･ Deleting a group does not delete its members from the PushTalk phonebook or the FOMA terminal phonebook.

Deleting a member registered in the group

g (for over a second) z p z Select the group z Highlight a member z m3

z Select Yes

･ Deleting a group member does not delete the member from the PushTalk phonebook or the FOMA

terminal phonebook.

PushTalk
