DoCoMo Foma D902iS User guide

Page 1

Page 2

DoCoMo W-CDMA System

Thank you for selecting the FOMA D902iS. Carefully read this manual, as well as the individual manuals f or other de vices such as the battery pack, before using your FOMA D902iS, and consult the corresponding manuals while using the phone so that y ou are ab le to use it correctly and eff ectively. If you are unclear as to any point indicated in any of these man uals, contact the DoCoMo Information Center that is listed on the back of this manual. Your FOMA D902iS is a valuable asset. Handle it with care and it will be your trusted partner for years to come.

Before using your FOMA terminal

● The FOMA terminal is cordless so you may not be able to use it in certain locations where signals cannot penetrate, such as in tunnels, undergroun d, in so me b uild in gs or o utdoors if the signal is weak or you are outside the service area. You also may not be able t o use your FOMA terminal on the upper floors of some highrise building, even though there is nothing around you that interferes with the signal. Please note that your call may be disconnected even when the signal is strong (when the signal strength indication shows three bars) a nd you are not moving.

● When using the FOMA terminal in public, busy or quiet places, be careful not to disturb others.

● Since the FOMA terminal relies on radio transmission, it is theoretically possible for third

parties to intercept a call; however, because the W-CDMA system automatically employs a secrecy function for all calls, a third party will pick up nothing but signal noise.

● Since the FOMA terminal operates by the wireless transmission of voices converted to digital signals, if you are in a location where the signal is weak, the original voice may not be accurately reproduced from the received digital signal, therefore, the voice you hear may differ from the original sound of the speaker’s voice.

● DoCoMo asks that you keep a separate record (e.g. written copy) of all information you store in your FOMA terminal. DoCoMo accepts no responsibility whatsoever for any loss that occurs should the contents of the FOMA terminal’s memory be lost or altered.

● The user hereby agrees that the user shall be solely responsible for the result of the use of SSL. Neither DoCoMo nor the certifier as listed herein makes any representation and warranty as for the security in the use of SSL. In the event that the user shall sustain damage or loss due to the use of SSL, neither DoCoMo nor the certifier shall be responsible for any such damage or loss. Certifier: VeriSign Japan K.K., Betrusted Japan Co., Ltd., GeoTrust Japan, inc., RSA Security

● The FOMA terminal can be used in the FOMA Plus-Area.

● The FOMA terminal can be used only via the FOMA network provided by DoCoMo.

Japan Ltd., SECOM Trust.net Co.,Ltd.

Using a FOMA terminal for the first time

When you use a FOMA terminal for the first time, read this manual in the following order. You can understand the preparations for using the FOMA terminal and its basic operations.

1. Install the battery pack and charge it. ☛P41, P42

2. Turn the power on, make initial settings, and then confirm your phone number. ☛P45, P48

3. Understand the functions of keys on the terminal. ☛P26

4. Understand the meaning of icons displayed on the screen. ☛P29

5. Understand how to use the menus. ☛P32

6. Understand how to make and receive calls. ☛P50, P62

The latest information about this manual can be downloaded from the DoCoMo website.

● User’s Manual Download

(http://www.nttdocomo.co.jp/english/support/manual/index.html)

Note: The URL and site contents are subject to change without prior notice.

Page 3

How to use and refer to this manual

You can look for functions or operation procedures that yo u want to know using various searching ways.

Contents/Cautions

Quick Search/

How to use and refer to this manual

Search on INDEX

Search for a function name or service name.

P470 P4

Use Quick Search

Search for frequently-used or useful functions using easy-to-understand words.

Use Contents

Refer to the contents classified into chapters on an objective basis.

P6 P8

Use Menu List

Search using the menu of D902iS.

Use Front Cover Indexes

Search by turning over the pages on this manual using the front cover indexes.

Front Cover

▲

For details, see the next page.

Refer to Features

Search for the features or new functions of D902iS.

Use Quick Reference Manual

This manual describes how to operate frequentlyused functions. Use it by separating from this instruction manual.

P476P416

● In the manual for FOMA D902iS, the FOMA D902iS is usually referr ed to as “FOMA terminal”.

● This manual explains functions performed with a miniSD memory card. A miniSD memory card

is required separately. miniSD memory card ☛P331

● In this manual, “Osaifu-Keitai compatible i-

as “Osaifu-Keitai compatible i-

● The screen display designs have been initialized according to the color of FOMA terminal from

the combinations preset in FOMA terminal (Style Theme). ☛P152 In this manual, the procedure is explained mainly in case that Style Theme is set to Platinum.

● Some screens do not support the bilingual function and items or keys may be displayed in

Japanese. In this manual, these Japanese words are written by both in Japanese and English only for the first time in a chapter or a section.

● Unauthorized copying of a part or all of the contents of this manual is prohibited.

● The contents of this manual are subject to change without prior notice.

ppli”.

ppli supporting the IC card function” is described

Page 4

Contents/Cautions

Quick Search/

How to use and refer to this manual

Shown below is an example when you search for the page where “My Picture” is described.

How to use and refer to this manual

Searching on INDEX

Use INDEX if you have already known a function or service name.

View/Edit Detail Info........344

Image Display ....................309

▲

Image & Effect Setting....... 213

Image (My Picture).............312

i-melody..............................209

iMenu .................................196

Immediate Update.............. 459

Create/delete fol

Deleting.............

Detail Info..........

Display Light.....

Download..........

i- ppli To..........

miniSD Data......

Using Quick Search

You can easily search for frequently-used or useful functions.

Advanced functions for camera

• Change the size of image to shoot.................... 183 Image size

• Change the shutter sound ................................. 183 Shutter sound

• Turn the compact light on when shooting.......... 176 Compact light

• Save data into the miniSD memory card........... 183 Save to

• Display the shot images ....................................312 My Picture

Using Front Cover Indexes

You can find a target page by proceeding from the front cover to the cover of a chapter (the first page of the chapter) and the page where a function is described.

resworB lluF /ataD gniganaM/gnitidE/gniyalpsiD

cisuM gniyalP snoitcnuF tneinevnoC rehtO

secivreS krowteN

noitacinummoC ataD

yrtnE retcarahC

/egnahcre

ataD/xidneppA

tnI

toohselbuorT

gni

▲

Displaying/Editing/Managing Data/Playing Music

▲

Making full use of images

Displaying images ............................................................................... My Picture 312

Editing still images ..................................................................................................314

Setting the operating conditions of images ................... Settings (My Picture) 318

Saving the still image in the Data Center ....................... Data Security Service 319

Making full use of video/i-motion

Playing video/i-motion ............................................................................ i-motion 320

Editing video/i-motion .............................................................................................322

Setting the operating conditions of video/i-motion ........... Settings (i-motion) 326

● The displays or illustrations provided in this manual are for information purposes only and may

be different from the actual products.

● In this manual, the keys are simplified.

Actual key Description in this manual

● In this manual, the operation procedures are described as follows:

Description Meaning

0 z o z Enter the terminal

security code

Press m0 on the standby display and then press o. Continuously, enter the terminal security code and press o.

Page 5

Contents/Cautions

Quick Search/

Making full use of images

▲

Displaying images

You can display images saved in Image (My Picture) in Data Box in FOMA terminal.

u1 z Select a folder

The following images are stored in each folder:

Camera：

Still images shot by Camera or Chara-den and still images captured from video/ i-motion or PDF data

i-mode：

Images downloaded from a site, i-mode Mail

or i- ppli

Deco-Mail picture：

D i ps al y

gni /

E d i

aM/gn gan

n g

D ta

P al iy

n g

uM s i

yM P

tci

u r

▲

Images preinstalled by default for Deco-mail and images downloaded from sites or read by Bar Code Reader

Item：

Frame images preinstalled by default and frame images/stamp images downloaded from sites

Preinstalled：

Images preinstalled by default

Data transfer：

Images read by Bar Code Reader, images moved/copied from miniSD memory cards and images received via data communications

Album：

Images moved from other folders

･Not displayed by default. To create P343 ･You can enter any album name in creating.

･ To switch to the folder list display of the miniSD

memory card: press t z 1 or 2

･ Using the miniSD memory card P338

Highlight an image

Thumbnail display

cdab

Display name and icons of the data at cursor

aOriginated

Note: The miniSD memory card is not included in the bundle and needs to be purchased. P331

312

Image list

：Preinstalled ：i-mode

My Picture

Title display

Menu 51

Sorting data

You can change the order of data of the list screen.

Default Sort criteria: Saved date & time

1 2 3

INFORMATION

● In the video/i-motion list, melody list, Chara-den list or

PDF data list, press m and select Sort.

● If one-byte and two-byte characters are mixed in the

display name, the sorted result may not correspond to Japanese syllabary.

cdba

Order: Descending

Sorting data in Image (My Picture)

Example

u1 z Select a folder m7 Select each item to set z Press p

Sort criteria：Sets the sorting method. Order ：Sets the sorting order of data.

Reading the recording screen

c d

Save to

Indicates the memory to save.

Type

Indicates to record sound.

Indicator <For during standby for recording>

Indicates the usage rate of the storage area in the memory to save.

･The miniSD memory card storage area usage

Indicates the rate of the recorded sound size to the file size set in size restrictions (or the allowable saving size when None is set).

Counter <For during standby for recording>

Indicates the approximate maximum recording time of sounds that can be saved in FOMA terminal or the miniSD memory card in the current

: FOMA terminal : miniSD memory card

rate may not become 0 even when no recorded sounds have been saved.

P185

Index Shortcut operation

☛P34

Sort

Title & Function name: Function names are listed on INDEX.

Functional overview and notes for operation

How to use and refer to this manual

Default setting Operation procedure

INFORMATION: In this manual, information items are categorized as follows:

●：Alternative

operation procedures

●：General notes

●：Detailed

description of the function

Column: Useful information

The page shown here is an example. It may differ from the actual page.

Supplement to the operation

● If there is especially no notice, the operation procedures from the standby display are mentioned.

● The operation procedure is mainly explained in shortcut operations using the normal menu.

When there are two or more possible procedures, the simplest one is mentioned.

● In this manual, to place the cursor at an item with (Speed Selector) is referred to as “highlight”.

In addition, to select an item by placing the cursor with (Speed Selector) and pressing

(Enter key) is referred to as “select”. The step of pressing which is required after entering characters in the entry field is omitted in description.

Page 6

Contents/Cautions

Quick Search/

Quick Search

Use this Quick Search to look for the frequently-used or convenient functions directly.

Quick Search

Useful functions for phone calls

When unable to answer an incoming call

How to change melodies or lighting patterns

• Notify/not notify your phone number....................48 Caller ID Notification

• Talk facing the phone screen..............................81 Speakerphone function

• Adjust the volume of the other party’s voice........ 68 Listen Volume

• Put the current call on hold..................................51 On-hold

• Switch to videophone call during voice call .........53

Switch to videophone

• Record caller’s messages ................................... 75 Answer Machine

• Use Voice Mail Service...................................... 392 Voice Mail

• Put the incoming call on hold............................... 71 Response and Hold

• Mute the sound heard when pressing keypads.....130 Keypad Sound

• Use your favorite ring alerts............................... 128 Sound Setting

• Adjust the volume of ring alerts ...........................68 Call alert volume

• Turn Silent Mode on ..........................................134 Silent Mode

• Use the vibrator for incoming calls .................... 133 Vibrator Setting

•

Customize the incoming lighting colo r and pattern....

• Use a personal ring alert for each caller............ 109

148 Light Alert Setting

Alert by Contact

How to change the screen display

• Customize the standby display (wallpaper).......136

• Show a calendar on the standby display ..........139 Calendar

• Adjust the date and time...................................... 47 Date and Time Setting

• Change the size of characters...........................150 Font Size Setting

• Learn the meaning of icons on the screen ..........29 Reading display

Note: The miniSD memory card is not included in the bundle and needs to be purchased. ☛P331

Standby Display Setting

Page 7

Contents/Cautions

Quick Search/

Advanced functions for mail

Advanced functions for camera

Settings for your phone safety

• Send your original Deco-mail ............................ 230 Deco-mail

• Send images with mail....................................... 234 Attachment

• Sort and save mail automatically....................... 255 Sort Criteria

• Change the size of image to shoot....................183 Image size

• Change the shutter sound .................................183 Shutter sound

• Turn the compact light on when shooting..........176 Compact light

• Save data into the miniSD memory card...........183 Save to

• Display the shot images ....................................312 My Picture

• Keep your phonebook data secret..................... 123 Secret Attribute

• Reject calls without caller ID.............................. 166 Anonymous Caller

• Reject callers not registered in the phonebook... 168

Reject non-Reg. Caller

• Disable the key operation..................................164 Key Lock

• Lock your phone remotely when it is lost etc.....159 Om akase Lock

• Save the phonebook and other data to

prevent data loss...............................................169

*1 This is a pay service and requires a subscription.

Data Security Service

Quick Search

Other useful functions

• Call up function menus quickly............................34 Shortcut operations

• Use your phone as a calculator.........................383 Calculator

• Read a QR code or barcode.............................. 192 Bar Code Reader

• Send/receive data via infrared communication... 347

Infrared communication

• Use your phone as an alarm clock ....................368 Alarm Clock

• Use the miniSD memory card............................ 331 miniSD memory card

• Update software ................................................ 457 Software Update

• Update the security............................................ 461 Virus Scan Func t i on

Page 8

Contents/Cautions

Quick Search/

Before using your FOMA terminal............. Inside front cover

Using a FOM A t e r m i n a l f o r t h e first time..... Inside front cover

How to use and refer to this manual ...................................1

Contents

Quick Search.......................................................................4

Features of FOMA D902iS..................................................8

Making full use of D902iS ................................................. 10

SAFETY PRECAUTIONS (Always follow these directions)..... 12

Handling instructions.........................................................19

About intellectual property rights.......................................21

Basic package and optional accessories ..........................24

Before Using D902iS 25

Names and functions of parts Reading the display Selecting the menu Using the UIM (FOMA card) Attaching/removing the battery pack Charging Battery Level Power ON/OFF Select Language Date and Time Setting Caller ID Notification Own Number etc.

Making/Receiving Calls 49

Making calls Chaku-moji Redial 186/184 Call WORLD CALL Receiving calls Any Key Answer Open Answer Close Setting Received Calls Listen Volume Adjust Volume Response and Hold Public mode (Driving mode/power off) Answer Machine etc.

Making/Receiving Videophone Calls 79

Making videophone calls Receiving videophone calls Using Chara-den Setting images to send Customizing display during videophone call Videophone Settings etc.

PushTalk 95

PushTalk Making PushTalk calls Receiving PushTalk calls PushTalk Phonebook etc.

Phonebook 105

Phonebook New Entry Group Setting Phonebook Search Edit Phonebook Delete Phonebook Secret Attribute Quick Dial etc.

Sounds/Displays/Lights Settings 127

Sound Setting Vibrator Setting Silent Mode Standby Display Setting Mail/Call Image Menu Setting Light Alert Setting Indicator Light Clock Display Format Style Theme etc.

Safety Settings 153

Security code Change Security Code PIN code All Lock Omakase Lock Self Mode PIM Lock Keypad Dial Lock Privacy Mode Setting Key Lock Secret Mode Data Security Service etc.

Camera 171

Still Camera Movie Camera Setting for shooting Bar Code Reader etc.

i-mode/i-motion 195

What’s i-mode? Site display Change i-mode Password Internet Connection Bookmark Screen Memo Save Image i-melody Downloading PDF data i-mode Setting Message R/F Certificate i-motion Downloading i-motion i-motion Setting etc.

Page 9

Contents

Mail 223

Composing and sending i-mode Mail Deco-mail Attachment Save Mail Receiving i-mode Mail Check i-mode Message Display/Save Image i-motion Mail Play/Save Melody Displaying and saving ToruCa Mail Setting Composing and sending Chat Mail Composing and sending SMS etc.

i-αppli 269

i-αppli Downloading Starting i-αppli i-αppli To i-αppli Standby Display etc.

i-channel 289

i-channel Channel List Ticker Setting

Osaifu-Keitai/ToruCa 293

Osaifu-Keitai Starting Osaifu-Keitai compatible i-αppli ToruCa Obtaining ToruCa Displaying ToruCa ToruCa Setting IC Card Lock

Full Browser 303

Full Browser Browser Setting

Displaying/Editing/Managing Data/Playing Music 311

Displaying/editing images Playing/editing video/i-motion Chara-den Playing melodies miniSD memory card Managing data Infrared communication Sound Recorder Displaying the PDF data Playing music etc.

Other Convenient Functions 363

Multiaccess Multitask Edit by Slide Auto Power ON/OFF Timer Alarm Clock Scheduler Custom Menu Own Number Voice Memo/Movie Memo Call Duration/Call Cost Reset Call Cost Call Cost Limit Calculator Notepad Electronic dictionaries Earphone/Microphone Set with Switch Quick Start-up Reset Delete All Data etc.

Contents/Cautions

Quick Search/

Contents

Network Services 391

Voice Mail Call Waiting Call Forwarding Nuisance Call Blocking Caller ID Request Dual Network English Guidance Service Dialing Number Arrival call act Remote Control Multi Number etc.

Data Communication 399

Data communication Flow of setup AT command

Character Entry 403

Entering characters 5-touch Input Method Save Phrase Copy Character KUTEN Code Input Save Word Download Dictionary Slot Input Method Input Method Setting

Appendix/Data Interchange/Troubleshooting 415

Menu list Data set by default List of dial keys and character assignments Troubleshooting Error Message Warranty and After-Sales Service Software Update Virus Scan Function Main specification etc.

INDEX/Quick Reference Manual 469

INDEX Quick Reference Manual

Page 10

Contents/Cautions

Quick Search/

Features of FOMA D902iS

FOMA is the name of a set of services provided by DoCoMo based on W-CDMA, which is recognized as one of the systems compliant to the global standard for third generation mobile communications (IMT-2000).

It’s amazing because

Features of FOMA D902iS

it’s i-mode!

i-mode is an online service used with i-mode terminals. This service supports connection to i-mode Sites (Programs) or i-mode compatible Internet websites that provide a variety of useful information and allows you to exchange i-mode Mail.

Main functions of FOMA D902iS

PushTalk ☛P96

You can talk with multiple persons (up to 5 persons including yourself) by easy operation of selecting a party from the PushTalk phonebook and pressing the PushTalk button (g).

i-channel ☛P290

Allows you to receive graphical information about news and weather conditions. You can get information on a regular basis and the latest information is run on the standby display as tickers. Also, the information can be displayed in the channel list by pressing the i-channel compatible key (c). Furthermore, you can get rich, detailed information by selecting your desired channel in the channel list.

･

i-channel is a pay service and requires a

Chaku-moji ☛P54

When you call someone, you can have a message be displayed on the incoming screen of his/her terminal. The called party can see your message and know in advance what the matter is and how you are feeling.

Videophone ☛P80

Allows you to see and talk with the par ty in the d istance and show the surrounding scenery to t he other pa rty by switching to the out-camera. This function also supports Chara-den which displays a ch aracter in stead of your self image.

Osaifu-Keitai i-mode FeliCa ☛P294

Downloading the Osaifu-Keitai compatible i-αppli enables you to charge electronic money from sites to the IC card of your FOMA terminal or check the balance and usage history. Also you can use it as an airplane ticket or a reward point card. The Osaifu-Keitai makes your phone more convenient in daily life.

ToruCa ☛P295

ToruCa is an electronic card obtained by Osaifu-Keitai , and you can use conveniently as a flier, a restaurant card, a coupon, etc. ToruCa can be obtained from the reader/writer or sites and can be easily exchanged using mail, infrared rays or the miniSD memory card.

Deco-mail ☛P230

Allows you to compose and send your original messages. Enjoy expressive decorated mail by changing the character color and size or background color, and by pasting images such as Deco-mail pictures or still images shot with the built-in camera in the text.

subscription

PDF compatible viewer ☛P209, P354

Allows you to view PDF. You can check easily useful information such as maps, catalogs and schedules on your i-mode terminal. You don’t need to bring books.

High-capacity i-αppli/i-αppli DX ☛P270

Downloading i-αppli from sites allows you to enjoy various games and automatically review stock prices and weather information on your pho ne. In addition, the 3D graphics and 3D sou nds all ow you t o enjoy realistic ithe contents compatible to 3D x 3D. ibetter uses in conjunction with i-mo de ter min al information such as the phonebook and mail.

ppli games such as car race games in

ppli DX provides

Safety settings

● Key Lock ☛P164

● Secret Mode ☛P165

● Privacy Mode ☛P162

● Voiceprint authentication: You can deactivate IC

Card Lock with your own voice and your terminal security code. ☛P300

Other safety settings ☛P153

Omakase Lock ☛P159

You can lock your FOMA terminal in case it is lost or stolen, and cancel the lock by informing DoCoMo. For contact information, refer to the back of this manual.

Data Security Service

This allows you to back up the phonebook data, still images and mail messages stored in FOMA terminal to the Data Center. When your FOMA terminal is lost, etc., you can restore the backup data to the new FOMA te rminal. In addition, you can edit and manage the backup data in the Data Center from your PC, and save the edited data to your FOMA terminal. For important notes on using Data Security Service and detail information about how to use the service, see “i-mode User’s Manual”. For contact information, refer to the back of this manual.

･ This is a pay service and requires a subscription.

☛

P169

Wide array of network services

● Voice Mail Service (charged)*1 ☛P392

● Call Forward ing Serv ice (free of charge)

SMS (Short Message) (free of charge)

●

● Call Waiting Service (charged)

● Dual Network Service (charged)

*1 Separate application is required.

☛P264

☛P393

☛P395

☛P394

Note: The miniSD memory card is not included in the bundle and needs to be purchased. ☛P331

Page 11

Useful functions

Speed Selector ☛P28

In addition to up, down, left and right operations, rotating operation is now possible. This allows you to scroll the screen and select items quickly. Also, you can display the menu, the phonebook, etc. by rotating the Speed Selector on the standby display.

Illumination ☛P148

The Enter key in the center of the Speed Selector lights up in various patterns when there is an incoming call, the Speed Selector is rotated, etc.

One-push open

You can quickly slide and open your FOMA terminal with one hand at the touch of the one-push open button on the side of the terminal.

Functions working with slide operation

● To receive an incoming call, open FOMA terminal by slide operation. ☛P65 To put the call on hold or end the conversation, close it. ☛P65

● The reply screen or the edit screen can be displayed by only opening FOMA terminal while a received mail or schedule is displayed. ☛P366

High-definition large display

The 2.8-inch large TFT LCD (240 x 400 dots) is provided for the display. It clearly displays fine images and characters on the large screen.

High-quality melody playback

FOMA terminal also supports ring alerts such as PCM generated 64-note harmonic, voice and sound effects (ADPCM sounds), etc.

Automatic time correction ☛P47

The time in FOMA terminal is automatically corrected by the information from DoCoMo network. Also you can set the time on your phone ahead or back, if you want.

Built-in camera

● FOMA terminal contains an out-camera and incamera, which allow you to take images while viewing the large display. You can shoot a still image of up to 4M pixels using auto focus. In addition to a maximum 28x zoom, various modes are available for shooting including close-up, framed shooting and continuous shooting. ☛P172 Out-camera: Effective pixels: 2M (Max record pixels:

In-camera : Effective pixels: 0.1M (Max record

● Allows you to record or play video with smooth motion and high quality. ☛P181, P320

Bar Code Reader ☛P192

JAN codes or QR codes can be scanned with the built-in camera. Using scan results, you can perform a variety of operations such as registering phonebook entries, connecting to sites and sending mail.

4M) pixels: 0.1M)

Infrared communication/infrared remote control

Exchange data between two FOMA terminals using infrared communication. Also, you can operate devices that sup port TV infrared remote control from your FOMA terminal.

☛

P347, P351

More usable mail functions

● You can block other people from peeping your mail messages by a simple key operation (Only View). ☛P259

● When you move from outside the service area to inside the service area, unsent mail set to autosend is sent automatically. ☛P238

● If the text of reply mail is registered beforehand, you can reply mail easily (Quick Reply). ☛P258

● You can search mail from the phon ebook or the calendar easily. ☛P113, P375

● The character s can be convert ed ef ficien tly with ATOK+APOT (AI presumption conv ersio n) pro vided .

Multiaccess/Multitask ☛P364, P365

Multiaccess which can use voice call and packet communication simultaneously is supported. In addition, Multitask which can execute several functions at the same time and perform operations by switching the screen is supported.

Simple menu ☛P32

n addition to the normal menu, you can use another menu to display frequently-used functions such as でんわ (phone), メール(mail), カメラ(camera) and ｉモード (i-mode) in large size of characters.

Animation menu ☛P32

The menu that uses animation by Flash movie (Flash® menu) is provided.

Electronic dictionaries ☛P385

Handy Japanese, English-Japanese, and Japanese- English dictionaries are preloaded on FOMA terminal.

Full Browser ☛P304

Allows you to view web sites for PC on FOMA terminal.

Support for miniSD memory card

● A miniSD memory card enables you to back up

data stored in your FOMA terminal such as images, melodies, phonebook entries and mail messages. ☛P331

● By connecting your FOMA terminal to a PC with

the FOMA USB cable (optional), the miniSD memory card in FOMA terminal can be used as an external memory of a PC. ☛P342

Playing music ☛P359

Music Player allows you to play the music files (i-motion without image) in the miniSD memory card more easily. The functions such as shuffle play and intro play are provided. In addition, you can import music files to the miniSD memory card with ease using the supplied software, BeatJam 2006 for D902iS.

Easy import of video files ☛P445

Video files on a PC can be easily converted to a format playable on FOMA terminal, using the supplied software, Motion Smoothy 2.

Contents/Cautions

Quick Search/

Features of FOMA D902iS

Page 12

Contents/Cautions

Quick Search/

Making full use of D902iS

A variety of functions of D902iS visual communications are explained here.

Videophone

You can see and talk with a party in the distance. You can also show to the other party a surrounding scenery image through the out-camera or a character using Chara-den instead of your image.

Your screen The other party’s screen The other party’s screen The other party’s screen

Talk while seeing each other. ☛P80, P83 Image of your

surroundings is displayed. ☛P89

Character is displayed. ☛P85

PushTalk

You can talk with multiple person s (up to 5 persons including yourself) by easy operations of only pressing the PushTalk button (g) for over a second to activate PushTalk Phonebook and pressing g after selecting a party. ☛P96

ToruCa

ToruCa can be obtained from the reader/writer or sites and can be easily exchanged using mail, infrared rays or the miniSD memory card. The obtained ToruCa is saved in ToruCa in the LifeKit menu. ☛P295

Obtain ToruCa by holding up Osaifu-Keitai to the reader/writer.

Note: The miniSD memory card is not included in the bundle and needs to be purchased. ☛P331

Select obtained ToruCa from the ToruCa list. Press the 詳細 (Details) button to view more detailed information.

Page 13

Chaku-moji

When you make a call, you can set a message to be displayed on the other party’s incoming screen. The other party can see the message and know in advance what the matter is and how you are feeling. ☛P54

The other party’s screen

Message

i-channel

You can receive a variety of information on a regular basis without additional operations. In addition, press the i-channel compatible key (c) to display the channel list so that you can get more richly detailed information. ☛P290

Not subscribed After subscription

Connect

Contents/Cautions

Quick Search/

Making full use of D902iS

G-GUIDE TV Remote Controller

The FOMA terminal is equipped with an i-αppli “G-GUIDE TV Remote Controller” for operating the TV, video deck and DVD player remotely while viewing the TV program information. You can search for TV programs using keywords such as the program category or your favorite entertainer. In addition, it allows you to reserve recording a program in the DVD rec or de r via the Inte rn et. ☛P279

TV/Video deck/ DVD player

Program*

Keyword Search

Program information

ppli server

*1 The screen shown here

is for information purpose only and may differ from the actual screen. The actual screen displays the program in your area.

Page 14

Contents/Cautions

Quick Search/

SAFETY PRECAUTIONS (Always follow these directions)

● Read the following SAFETY PRECAUTIONS to ensure that the phone is used correctly. Also, store this manual in a convenient location for future reference.

● It is essential that these precautions be observed to prevent injury to the user and third parties

SAFETY PRECAUTIONS

as well as damage to property.

● The following symbols are used to indicate the degree of danger or damage that may result from failing to follow the specified precautions.

● The following symbols are used to highlight instructions that are very important and that must be strictly followed.

Indicates an imminently hazardous situation, which, if

DANGER WARNING CAUTION

This indicates the action is prohibited.

not avoided, will result in death or serious injury.

Indicates a potentially hazardous situation, which, if not avoided, could result in death or serious injury.

Indicates a potentially hazardous situation, which, if not avoided, may result in injury or property damage.

This indicates disassembly is prohibited.

This indicates that handling with wet hands is prohibited.

This indicates an action that must be performed in accordance with the directions.

This indicates you must remove the plug from the power outlet.

● SAFETY PRECAUTIONS is separated into six categories.

Handling the FOMA terminal, ba ttery pack, adapter (and charger) and the UIM (general information

Handling the FOMA terminal......................................................................................................... P14

Handling the battery pack............................................................................................................. P15

Handling optional devices (AC adapter/DC adapter/desktop holder/in-car holder) ...................... P17

Handling the UIM (FOMA card)....................................................................................................P18

Handling the FOMA terminal in the vicinity of medical devices .................................................... P18

This indicates the part must not be exposed to water.

)......... P13

Page 15

Handling the FOMA terminal, battery pack, adapter (and charger) and the UIM (general information)

DANGER

Use only DoCoMo-certified battery packs, adapters (and chargers) with the FOMA terminal.

Use of non-specified items could cause the FOMA terminal, battery pack or other devices to leak, overheat, rupture, catch fire or malfunction.

Battery pack: D06 Desktop holder: D09 Rear cover: D11 FOMA AC adapter: 01 FOMA DC adapter: 01 FOMA battery adapter: 01 In-car holder: 01

･For additional items related to the compatible products, contact the nearest DoCoMo Shop.

Do not attempt to disassemble or remodel. In addition, do not attempt to solder.

Attempting to do so will lead to an accident, such as a fire, injury, or electrical shock and damage the equipment. Doing so may also cause the battery pack to leak, overheat, rupture, or ignite.

Do not use or leave in a place near fire or heaters. Also avoid a high-temper ature place exposed to direct sunlight or a car under the scorching sun.

Otherwise, your equipment will get deformed or troubled. The battery pack may leak, overheat, rupture, or ignite. Other possible pro blems include a reducti on in perfor mance and li fe. Som etimes, the casing will partly get heated, resulting in an extremely high temperature to get you burnt.

Do not expose to water.

The equipment may overheat, cause electric shock, fire, damage or injury if exposed to water, pet urine or other liquids. Do not use the equipment in locations where it could get wet.

WARNING

Contents/Cautions

Quick Search/

SAFETY PRECAUTIONS

Be sure to turn off the FOMA terminal before entering a place such as a gas station that is subject to flammable gases. Do not charge in such a place. Charging could cause fire.

When using Osaifu-Keitai inside a gas station, make sure to turn off the FOMA terminal in advance. (If IC Card Lock is set, cancel the lock and then turn the power off.)

Do not place the battery pack, FOMA terminal, adapter (and charger) or UIM in the microwave oven, high-pressure cooker or other cooking appliances.

Doing so could cause the battery pack to leak, overheat, rupture or ignite, and could damage the circuitry of the FOMA terminal and adapter (and charger), causing overheat, smoke or fire.

Do not expose to strong shocks by dropping or throwing.

Doing so could cause the battery pack to leak, overheat, rupture or ignite, and damage the equipment, resulting in fire.

Do not let the recharging terminal and external device terminal touch any conductive material, such as a piece of metal or lead. Also do not put any conductive material into the recharging terminal and external device terminal.

The battery can short-circuit, causing fire and damage.

If there is anything wrong (such as strange odor, heat generation, color change, deformation, or the like) during use, battery charge or storage, you should take the following steps immediately.

1. Remove the power plug from the outlet.

2. Turn off the FOMA terminal.

3. Remove the battery pack from the FOMA terminal.

Continuing to use the equipment without taking these steps will cause it to overheat, rupture, or ignite or cause the battery pack to leak.

Page 16

Contents/Cautions

Quick Search/

CAUTION

SAFETY PRECAUTIONS

Handling the FOMA terminal

When a child uses the FOMA terminal, first be sure an experienced adult teaches proper usage methods and techniques. Observe the child to determine that they are using the FOMA terminal correctly.

Failure to do so could result in injury.

Keep out of the reach of small children.

The components can be accidentally swallowed, resulting in injury.

Do not place on an unstable or tilted surface.

Doing so could cause the equipment to slide off, possibly causing personal injury or damaging the equipment.

Do not store in locations subject to high temperature and humidity or excessive dust.

Doing so could damage the equipment.

The temperature of the FOMA terminal, battery pack or adapter (and charger) may become high when charging the battery, recording/playing a video, or

using videophone, i-mode or i-

If you touch the part with a high temperature directly for a long period of time, redness, i tchiness, rash, etc. may arise in your skin depending on your constitution or condition. Be especially careful when you use the FOMA terminal connected to an adapter (and charger) continuously for a prolonged period.

ppli repeatedly or for a long period of time.

WARNING

Turn off the FOMA terminal inside an aircraft, hospital or other location where use of mobile phones is prohibited.

The FOMA terminal may interfere with the correct functioning of electronic equipment. If the automatic power on function is used, cancel the setting and turn the power off. Observe any regulations posted in medical facilities. If you have done prohibition acts such as using the FOMA terminal inside an aircraft, you may be punished as stipulated by law.

Turn off the FOMA terminal in the vicinity of electronic equipment that relies on highprecision control or faint signals.

The FOMA terminal may interfere with the correct functioning of such electronic equipment.

･ Examples: hearing aids, implanted

cardiac pacemakers, implanted defibrillators, other medical devices, fire alarms, automatic doors and other automatically controlled equipment. Users of such medical equipments should check with the electronic equipment or device manufacturer with respect to the effect of electromagnetic interference.

Do not place the FOMA terminal in a breast or inner pocket if you are carrying or using electronic medical equipment.

The FOMA terminal could cause any medical equipment in its vicinity to malfunction.

People with weak hearts should take care with respect to setting the incoming vibrator and ring volume.

The FOMA terminal may interfere hearts.

Page 17

Do not aim the infrared port at eyes and attempt to transmit.

Eyes could be affected. Aiming at other infrared devices and transmitting could cause other devices to malfunction.

When you talk under handsfree settings (with the speakerphone function), be sure to keep a distance between FOMA terminal and your ear.

Failure to do so could cause the hearing loss.

Do not place the FOMA terminal in an area over an air bag or in an air bag deployment area such as on a dashboard in a vehicle.

If the air bag inflates, the FOMA terminal may hit you and injury and damage to itself could result.

Do not use the FOMA terminal while driving.

From November 1, 2004, using mobile phones while driving is set as the object of penal regulations. Even if you use the handsfree device, park the car in a safe place before using the phone. Use Public mode or Voice Mail Service while driving.

Do not turn on the compact light toward eyes at close range.

Taking a look at the light directly affects eyes damage. He or she may be blinded by it and injury could result.

If you hear thunder while using the FOMA terminal outdoors, immediately turn the power off and move to a safe location.

Use of the phone in such a situation could expose you to lightning strikes or electric shock.

CAUTION

Rarely, some FOMA terminal users may develop itching, skin irritation or eczema. If such a condition occurs, stop using the FOMA terminal immediately and seek medical attention.

Metal is used in the following components:

Part Material

One-push open button, b, C Chromium plating Speed Selector (except the Enter key in the center) Aluminum*

*1 Although painted, the skin may be touched if it separates.

Do not swing the FOMA terminal around by the strap.

Doing so could cause injury to yourself or a third party or damage the phone.

Use in certain makes of cars may affect onboard electronic equipment.

Continued use under such conditions could cause unsafe driving. Do not use the FOMA terminal in such a case.

Do not allow water or other liquids, pieces of metal or other foreign material to enter into the UIM slot and a miniSD memory card slot of the FOMA terminal.

Doing so could cause fire, electric shock, or damage to the phone.

Do not bring magnetic cards near the FOMA terminal.

Magnetic data stored on bank cards, credit cards, telephone cards, and floppy disks may be corrupted or lost.

Contents/Cautions

Quick Search/

SAFETY PRECAUTIONS

Handling the battery pack

■ Check the battery type indicated on the battery pack label.

Indication Battery type

Li-ion Lithium ion battery

Page 18

Contents/Cautions

Quick Search/

DANGER

SAFETY PRECAUTIONS

If electrolyte from the battery pack gets in your eyes, do not rub; instead, rinse immediately with copious amounts of clean water and seek medical attention.

Doing so could cause the loss of vision.

Do not attach metallic materials such as wire to the port. Do not carry or store the battery pack together with a necklace or other metallic items.

Doing so could cause the battery pack to leak, overheat, rupture or catch fire.

Do not pierce the battery pack with nails, hammer on it or step on it.

Doing so could cause the battery pack to leak, overheat, rupture or catch fire.

Do not throw the battery pack into a fire.

Doing so could cause the battery pack to leak, overheat, rupture or catch fire.

When you attach the battery pack to the FOMA terminal, never attempt to forcefully insert, because it should slide in easily and fit correctly. Check the direction of the battery pack and try again.

Doing so could cause the battery pack to leak, overheat, rupture or catch fire.

WARNING

Should any electrolyte from the battery pack come into contact with your skin or clothing, immediately stop using the battery and rinse with clean water.

Failure to do so could ca use ski n injur ies.

If the battery pack leaks or emits strange odors, immediately stop using it, and always keep away from sources of fire.

Failure to do so could cause the battery liquid to catch fire, and the battery pack itself to rupture.

Stop charging if it is not possible to fully charge the battery pack within the specified time.

Failure to do so could cause the battery pack to leak, overheat, rupture or catch fire.

CAUTION

Do not dispose of the battery pack with other regular household waste.

Failure to properly dispose of the battery pack in an environmentally sensitive manner could cause the battery pack to catch fire and damage the environment. Use adhesive tape to cover the terminal of battery pack when it is no longer used and bring it to a Do CoMo Shop af ter th e insu la ti on. Alternatively, you can also dispose of the batte ry pack in accor dan ce with l ocal regula ti ons.

Page 19

Handling optional devices (AC adapter/DC adapter/desktop holder/in-car holder)

WARNING

Contents/Cautions

Quick Search/

Use care not to short circuit the recharging terminal when the adapter (and charger) is connected to a wall outlet or cigarette lighter socket. Do not touch the recharging terminal with your hands or fingers, or some other part of the body.

Doing so could cause fire, equipment failure, electric shock or other injury.

Do not use th

e AC adapter and desktop holder in bathrooms or other potentially high humidity locations.

Doing so could cause electric shock.

Never use the adapter (and charger) when it has a damaged power cord.

Failure to do so could result in electric shock, overheat or fire.

If the adapter (and charger) or holder is exposed to water or other liquid, immediately disconnect the power plug from the wall outlet or cigarette lighter socket.

Failure to do so could result in electric shock, smoke or fire.

Be sure the power plug is free of dust.

Failure to do so could cause the equipment to catch fire.

Do not touch the adapter (and charger) cord or wall outlet with wet hands.

Doing so could cause electric shock.

When the adapter (and charger) is not to be used for a prolonged period, disconnect the power plug from the wall outlet.

Failure to do so could result in electric shock, fire, or equipment failure.

When connected to a wall outlet, make sure that the AC adapter does not come into contact with metallic straps or other metal objects and the plug is properly seated.

Failure to do so could result in electric shock, short circuit, or fire.

Use the designated power source and correct voltage.

Use of incorrect voltage could cause fire or equipment failure. When using the FOMA terminal overseas, use t he FOMA domestic/overseas AC adapter 0 1.

AC adapter: 100 V AC FOMA domestic/overseas AC adapter:

(Always connect to the outlet for in ternal household use.)

DC adapter: 12 V DC, 24 V DC

100 V to 240 V AC

(specific for negative ground vehicle)

SAFETY PRECAUTIONS

During charging, place the adapter (and charger) and desktop holder in a stable location. Do not cover or wrap the adapter (and charger) and desktop holder with a cloth or blanket, etc.

Using the equipment under such conditions could cause the FOMA terminal to be detached from the holder, or cause a heat buildup that leads to fire or equipment failure.

Do not touch the FOMA termin al and AC/DC adapter when hearing thunder.

Contact with the FOMA terminal and adapter could cause you lightning strikes or electric shock.

Use only the specified fuse for the DC adapter.

Use of the incorrect fuse could cause fire or equipment failure. Check the instruction manual for details of the correct fuse to use.

The DC adapter is for use with negative ground cars. Do not use it with positive ground cars.

Doing so could result in fire.

Page 20

Contents/Cautions

Quick Search/

CAUTION

SAFETY PRECAUTIONS

Handling the UIM (FOMA card)

Handling the FOMA terminal in the vicinity of medical devices

The information given below conforms to the guidelines set forth by the Electromagnetic Compatibility Conference regarding the protection of electronic medical equipment from radio waves emitted by mobile phone units.

Disconnect the power plug from the wall outlet or cigarette lighter socket before beginning any maintenance.

Failure to do so could cause electric shock.

Do not place heavy objects on the adapter (and charger) cord or power cord.

Doing so could cause electric shock or fire.

CAUTION

Take care when removing the UIM (the IC).

Failure to do so could cause injury to hand and fingers.

WARNING

Disconnect the adapter (and charger) from the wall outle t or cigarette lighter socket by pulling the adapter, not the adapter (and charger) cord or the power cord.

Pulling the cord could damage the cord, resulting in electric shock or fire.

Turn off the FOMA terminal on packed trains or in crowded places as someone with an implanted cardiac pacemaker or implanted defibrillator may be nearby.

The electromagnetic waves emitted by your phone could affect the function of an implanted cardiac pacemaker or implanted defibrillator.

When inside a medical institution, always remember the following guidelines:

Never take the FOMA terminal inside an operating room, intensive care unit (ICU) or coronary

･

care unit (CCU).

･Always turn off the FOMA terminal in hospital wards. ･Even in the lobby and other areas, always turn off the FOMA terminal when electronic medical

equipment is nearby.

･Follow the directives of the medical institut ion. There may be speci fic regulations as to it ems that

are prohibited or use of which is restricted.

･If you are using the automatic power on function, cancel the setting and turn off the power.

If you have an implanted cardiac pacemaker or implanted defibrillator, keep your FOMA terminal at least 22 cm away from it.

The electromagnetic waves emitted by your phone could affect the function of an implanted cardiac pacemaker or implanted defibrillator.

If you are using electronic medical equipment other than implanted cardiac pacemakers or implanted defibrillators at your home or outside the confines of a medical institution, be sure to check with the manufacturer about possible adverse effects caused by electromagnetic interference.

The electromagnetic waves emitted by your phone could affect the function of electronic medical equipment.

Page 21

Handling instructions

General

●Do not get the components wet.

The FOMA terminal, battery pack, adapter (and charger) and UIM are not waterproof. Avoid using the components in a bathroom or other high humidity areas or locations exposed to rain. If you carry the components, sweat could cause internal corrosion that leads to equipment failure. As a result of investigation, if component failure is found to be water-related, repair is not covered by the warranty and may not be able to be performed. In such a case, should it be found to be possible to repair the unit, you will be billed for all repairs.

●Clean the components with a soft dry cloth (such as a lens cloth).

• The FOMA terminal display may have a special coating on it so that the color LCD provides a clear view. Rubbing the display strongly with a dry cloth for cleaning could damage the display. Handle with care and clean the display with a soft dry cloth (such as a lens cloth). Also note that leaving the display with dirt or moisture attached could cause spots or remove the coating on it.

• Using alcohol, thinner, benzene or detergents could cause the printed text to fade or disappear, or the equipment to become discolored.

●Occasionally clean the terminals with a dry cotton swab.

Dirty terminals could cause intermittent contact that could interrupt the flow of power to the unit. Such a situation also causes insufficient charging. Use a dry cloth or cotton swab to clean the terminal.

●Do not place the components near an air conditioner vent.

Sudden changes in temperature could cause condensation, leading to corrosion insid e the compone nts and equipment failure.

●Do not place the F O MA terminal in locations where it could be exposed to excessive pressure.

Do not place it in a bag together with many other things or in your pocket when you sit down as this could exert pressure on the LCD or damage the internal boards, resulting in equipment fa ilure. Damage arising from such causes is not covered by the warranty.

●Carefully read the instruction manuals supplied with the battery pack and adapter (and charger) before use.

Contents/Cautions

Quick Search/

Handling instructions

FOMA terminal

●Avoid extremely high or low temperatures.

Use in an environment with a temperature of 5 to 35 °C and relative humidity of 45 to 85 %.

●If the FOMA terminal is used near a radio, television or general subscriber phone, it could affect such equipment. Use the phone as far away from such equipment as possible.

●With regard to data stored in the FOMA terminal, keep it separately in a memo, etc. so as not to permanently lose important data.

NTT DoCoMo cannot be held responsible in any way for the loss of stored data.

●Do not put the FOMA terminal in your back pocket and sit on it. Avoid putting the phone in the bottom of a bag, etc. where it is subject to excessive pressure.

Damage may result.

●Do not close the FO MA terminal with the strap held in side.

Malfunction or damage may result.

●It is normal for the FOMA terminal to become warm during using or recharging. You can continue to use it while warm.

●Do not aim the camera directly at the sun and leave it .

Elements may be discolored or baked.

●The FOMA terminal is compatible with Omakase Lock (☛P159)．

Omakase Lock is a service that locks FOMA terminal at the request from the subscriber. Note that the FOMA terminal is locked when a request is made by the subscriber even if the subscriber is not the user of FOMA terminal.

Page 22

Contents/Cautions

Quick Search/

Handling instructions

Battery pack

●The battery pack will gradually wear out.

Battery life also depends on how you use the battery pack; you know it is time to replace it when the usage time is very short even though you fully charge it. The specified battery pack can be purchased separately.

●Recharge the battery pack in locations where the ambient temperature is between 5 °C and 35 °C.

●When using for the first time or after a long period of non-use, be sure to fully charge the battery pack

before use.

●The time of use provided by the battery pack depends on the ambient conditions and the condition of the battery pack itself.

●Depending on usage, the battery pack may swell slightl y as it n ears th e end o f its life , but th is will no t cause a problem.

●Do not expose to the direct sunlight and high temperature. Please keep your battery in an airy and cool place.

When you do not use your phone for a long period of time, remove the battery pack from the FOMA terminal with the battery used up, put into the packing plastic bag or other container, and keep it.

Adapter (and charger)

●Recharge the battery pack in a location where the ambient temperature is between 5 °C and 35 °C.

●Do not recharge in the following locations:

• Locations that are subject to high humidity, dust or excessive vibration

• Near general subscriber phones, TVs or radios

●It is normal for t he adapter (and charger) to become warm during recharging. You can continue charging with a warm adapter.

●When the battery pack is recharged using the DC adapter, always keep the car engine running .

Failure to do so could cause the car battery to run down more quickly than normal.

●When an outlet with falling prevention mechanism is used, check the instruction manual for the outlet before use.

●Do not expose to the strong shock and deform the recharging terminal.

Giving the strong shock on an adapter can cause damage.

UIM (FOMA card)

●Do not use excessiv e force to remove the UIM.

●Do not place an excessive load on the UIM when inserting it into the terminal.

●The UIM becomes warm during use. This is normal and not a cause for concern.

●Note that any card failures resulting from inserting the UIM in an IC card reader/writer not designated

by NTT DoCoMo are the responsibility of the customer.

●Make sure that the ICs are kept clean.

●Clean the UIM with a soft dry cloth (such as a lens cloth).

●It is recommended that users maintain data stored on the UIM in some other form.

If the data should be erased, NTT DoCoMo assumes no responsibility for the loss of any data.

●The UIMs that are no longer used should be returned to a DoCoMo Shop for environmental protection.

●Avoid extremely high or low temperature.

●Take care not to damage, touch, or short-circuit the ICs to prevent them from losing their data or from

malfunctioning.

●Take care not to drop the UIM or give shock to the UIM to prevent it from malfunctioning.

●Do not bend the UIM and place heavy stuff on it to avoid a failure.

Page 23

Camera

If you should use the FOMA terminal to make a public nuisance, you might be punished under the laws and bylaws such as Japan’s nuisance prevention ordinance.

Please be considerate of the privacy of individuals around you when taking and sending images using camera-equipped mobile phones.

About intellectual property rights

Copyrights and portrait rights

Except in cases where reproduction and quoting for private use is sanctioned under copyright laws, the reproduction, alteration and public transmission of such content as text, images, music or software for which another party owns the copyrights, whether accomplished by using this product to photograph or record that content or by downloading it from Internet websites, is prohibited without the permission of the owner. Taking photographs or recordings of such events as performances and exhibitions may be prohibited even for purposes of private use. In addition, if you use this product to take another person’s photograph without their permission, or display such a photograph without their permission on an Internet website and make that content public to an indeterminate number of people, you may be in violation of portrait rights.

Trademarks

Contents/Cautions

Quick Search/

About intellectual property rights

Company names and trade names used in thi s manual are the trademarks or registered trademarks of their respective companies .

･ “FOMA”, “mova”, “i-motion”, “i-mode”, “i-

“i-anime”, “DoPa”, “mopera”, “mopera U”, “WORLD CALL”, “WORLD WING”, “Short Mail”, “QUICKCAST”, “Chaku-motion”, “D eco-mail”, “V-Live”, “i-area”, “pake-hodai”, “Chara-den”, “i-αppli DX”, “Dual Network”, “ToruCa”, “visualnet”, “i-channel”, “Push Talk”, “PushTalkPlus”, “iD”, “DCMX”, “FirstPass”, “sigmarion”, “Security Scan”, “musea”, ”Public mode”, “トクだねニュース便” and “My DoCoMo”, and FOMA, i-mode, i-αppli and DCMX logos are trademarks or registered trademarks of NTT DoCoMo.

ppli”, “i-αppli search”, “i-motion mail”, “i-shot”, “i-melody”,

･ “キャッチホン (Call Waiting)” is a registered trademark of Nippon Telegraph and Telephone Corporation. ･ The toll-free service name and the toll-free s ervice logo mark are trademarks of NTT Co mmunications

Corporation.

･ Microsoft

, Windows®, Windows Media® and DirectX® are registered trademarks of Microsoft Corporation in

the US and other countries.

･ Java and all Java-related trademarks are t rademarks or registered trademarks of Sun Microsystems,

Inc. in the US and other countries.

･ Powered by JBlend

JBlend and all JBlend-based trademarks and logos are trademarks or registered trademarks of Aplix Corporation in Japan and other countries.

･ “Multitask” is a registered trademark of NEC Corporation. ･ＦｅｌｉＣａ is a registered trademark of Sony Corporation. ･ is a registered trademark of FeliCa Networks Inc. ･ This product contains NetFront of ACCESS CO., LTD. to provide Internet function.

Page 24

Contents/Cautions

Quick Search/

About intellectual property rights

･ Contains Macromedia

Flash® Player technology by Macromedia, Inc. Copyright© 1995-2006 Macromedia, Inc. All rights reserved. Macromedia, Flash, and Macromedia F lash are trademarks or registered trademarks of Macromedia, Inc. in the US and other countries.

･ McAfee and VirusScan are registered trademarks or trademarks of McAfee, Inc. and/or its affiliates in

･ QR code is a registered trademark of DENSO WAVE INCORPORATED. ･ Contains Adobe Reader of Adobe Systems Incorporated.

Copyright© 2006 Adobe Systems Incorporated. All rights reserved. Patents pending. Adobe, the Adobe logo and Reader are either registered trademarks or trademarks of Adobe Systems Incorporated. Adobe and Reader are trademarks or registered trademarks of Adobe Systems Incorporated in the US and other countries.

･ miniSD ･ Powered By Mascot Capsule

and are tradema rks of the SD Card Association.

/Micro3D Edition

Mascot Capsule® is a registered trademark of HI CORPORATION.

･ “BeatJam” is copy-protected material of Justsystem Corporation. Copyrights and other rights related to

“BeatJam” belong to Justsystem Corporation and other respective o w ners of those rights.

･ “BeatJam”, “ATOK” and “APOT” (Advanced Prediction Optimization Technology) are registered

trademarks of Justsystem Corporation.

･ G-GUIDE, G-GUIDE MOBILE and the logos associated wit h G-GUIDE are registered

trademarks of Gemstar-TV Guide International, Inc. and/or its affiliates in Japan.

･ QuickTime is a registered trademark of Apple Computer, Inc. in the US and other countries. ･ “Privacy Mode” is a registered trademark of FUJITSU. ･

This product includes software licensed from Symbian Software Ltd. ‘Symbian’, ‘Symbian OS’ and other associate d Sy mb ian marks are all trademarks of Symbian Software Ltd. ©1998-2006 Symbian Software Ltd. All rights reserved.

･ Intel and Pentium are trademarks or registered trademarks of Intel Corporation or its subsidiaries in

the United States and other countries.

･ In addition to the above, company names and trade names used in this manual are the trademarks or

registered trademarks of their respective companies.

Note: The miniSD memory card is not included in the bundle and needs to be purchased. ☛P331

Page 25

Other rights and responsibilities

･ＦｅｌｉＣａ is a contactless IC card technology deve loped by Sony Corporation. ･ “Edy” is a brand of the prepaid type electronic money service provided by bitWallet, Inc.

･ This product is licensed based on MPEG-4 Vi sual Patent Po rtfoli o Licen se. The us e of MPEG- 4 Video

Codec function is allowed for personal and nonprofit use only in the following cases:

・Recording videos that conform to MPEG-4 Visual Standard (hereinafter referred to as MPEG-4 Video) ・Playing MPEG-4 Videos recorded personally by consumers not engaged in profit activities ・Playing MPEG-4 Videos obtained fr om the provider licensed from MPEG LA

For further utilizing such as promotion, in-house use or profit-making business, please contact MPEG LA, LLC in the US.

･ Licensed by QUALCOMM Incorporated under one or more of the following United States Patents and/

or their counterparts in other nations:

4,901,307 5,600,754 5,267,261 5,506,865 5,710,784 5,504,773 5,416,797 5,568,483 5,228,054 5,778,338 5,109,390 5,490,165 5,414,796 5,544,196 5,535,239 5,101,501 5,659,569 5,337,338 5,267,262 5,511,073 5,056,109 5,657,420

･ This product contains a module developed by the Independent JPEG Group. ･ “Meikyo Mobile Japanese Dictionary”, “G-M obile English-Japanese Dictio nary” and “G-Mobile

Japanese-English Dictionary” are copyrighted works of TAISHUKAN Publishing Co., Ltd.

･ In this manual, each OS (Japanese version) is written for short as follows:

・Windows XP is the abbreviation for Microsoft® Windows® XP Professional operating system or

Microsoft® Windows® XP Home Edition operating system.

・Windows 2000 is the abbreviation for Microsoft® Windows® 2000 Professional operating system. ・Windows Me is the abbreviation for Micr osoft® Windows® Millennium Edition operating system. ・Windows 98 is the abbreviation for Microsoft® Windows® 98 operating system. ・Windows 98SE is the abbreviation for Microsoft® Windows® 98 operating system SECOND EDITION. ・Windows NT Server is the abbreviation for Microsoft® Windows NT® Server Network operating

system Version 4.0.

・It may describe like Windows XP, 2000, Me, 98 in parallel. ・Windows 98 and Windows 98SE are described as Windows 98 in all.

Contents/Cautions

Quick Search/

About intellectual property rights

Page 26

Contents/Cautions

Quick Search/

Basic package and optional accessories

Basic package

Basic package and optional accessories

(including the written

FOMA D902iS

Instruction manual (this book)

CD-ROM for FOMA

D902iS warranty and the rear cover D11)

Manual

Quick Reference Manual ☛P476

BeatJamサポートガイド (BeatJam Support Guide) BeatJam音楽転送クイックガイド (BeatJam Quick Manual for music data transfer)(separately bound)

BeatJamサポートガイド

BeatJam音楽転送クイックガイド

The PDF version of “Manual for Data Communication” is contai ned.

Motion Smoothy 2

簡易操作ガイド

(Simple User’s Manual for Motion Smoothy 2) (attached)

MotionSmoothy2 簡易操作ガイド

Optional accessories

FOMA AC adapter 01 (including the written warranty and the instruction manual)

Desktop holder D09 (including the instruction manual)

Battery pack D06 (including the instruction manual)

･ Other optional accessories ☛P444

Page 27

Before Using D902iS

Names and functions of parts .........................................................................26

Reading the display .................................................... ..................... .................29

Selecting the menu ...........................................................................................32

Number of saved, registered and protected items in D902iS .......................38

Using the UIM (FOMA card) .............................................................................38

Attaching/removing the battery pack .............................................................41

Charging the battery of FOMA terminal ..........................................................42

Checking the remaining battery level .................................... Battery Level 45

Turning the power on/off ..................................................... Power ON/ O F F 45

Switching to English display ............................................ Select Language 46

Setting the date and time ......................................... Date and Time Setting 47

Notifying your phone number to the other party ..... Caller ID Notification 48

Checking your own phone number ........................................ Own Num ber 48

Page 28

Before Using D902iS

uv wx

Names and functions of parts

c d

l m n

a Earpiece

The other party’s voice comes out of here.

b Display ☛P29 c mMenu/upper left soft/Silent Mode key

Use this key to display menus, perform the operation shown in the upper left part of the guide row, set/cancel Silent Mode, etc.

d tStart videophone/scroll/lower left soft key

Use this key to make/answer videophone calls, scroll mail or site display by a page, switch between upper/lower cases when entering characters, perform the operation shown in the lower left part of the guide row, etc.

Start voice call/speakerphone/character key

Use this key to make/answer voice calls, turn on/ off the speakerphone function, use the focus lock function of Camera, switch input modes when entering characters, etc.

f c i-channel/Clear key

Use this key to display the channel list, delete characters, return to the previous screen, set/ cancel Self Mode, etc. On the idisplay, press this key to start i-

ppli standby

ppli.

g Dial keys (0 to 9), (, #

Dial keys

Used to enter phone numbers and text and to select menu items.

( /Public mode (Driving mode) key

Use this key to enter “ ”, set/cancel Public mode (Driving mode), etc.

##/Silent Mode/line-feed key

Use this key to enter “＃”, set/cancel Silent Mode, start a new line when entering characters, etc.

rts

B C

Size (mm)

: 110 (H) x 49 (W) x 19.9 (D)

(when closed)

Weight (g)

: Approx. 124 (with battery pack)

Switches between the standard mode and the macro mode while shooting with the out-camera.

h Microphone

Picks up your voice.

i Infrared data port ☛P347

Exchange data via infrared communication.

j In-camera ☛P89, P172

Used to shoot yourself with Camera or Movie Camera and send your image during a videophone call.

Speed Selector

･You can rotate the Speed Selector to operate it.

☛P28

oEnter key

Use this key to perform the selected operation, activate Focus Mode, start ikey Shortcut, etc.

uData Box/↑ key

Use this key to display the Data Box menu, activate Camera with the in-camera on, move the cursor upward, adjust volume, etc.

di-mode/i-

Use this key to display the i-mode menu or ifolder list, move the cursor downward, adjust volume, etc.

lReceived Calls/←(previous) key

Use this key to display the received call history, switch between pages, move the cursor leftwa rd, set/cancel Privacy Mode, etc.

rRedial/→(next) key

Use this key to display the redial data, switch between pages, move the cursor rightward, set/ cancel IC Card Lock etc.

ppli/↓key

ppli set for One-

ppli

Note: The miniSD memory card is not included in the bundle and needs to be purchased. ☛P331

Page 29

l pPhonebook/schedule/upper right soft key

Use this key to display the phonebook or schedules, perform the operation shown in the upper right part of the guide row, etc.

Mail/scroll/lower right soft key

Use this key to display the Mail menu, compose new mail, scroll mail or site display by a page, perform the operation shown in the lower right part of the guide row, etc.

n fPower/End/Hold key

Use this key to turn the power on/off, end calls or functions in operation, place incoming calls on hold, cancel Secret Mode, switch displaying/not displaying the custom standby display, etc.

o Charging terminals

Used when charging FOMA terminal in the desktop holder (optional).

activate Camera and shoot images, stop ring alert/ alarm, switch between the normal display and anti-peeping display (Only View) of the mail view screen, etc.

･ C has 2 positions: half press and full press for

shooting images with auto focus, so the feel of pressing this key is different from other keys.

D One-push open button

Use this button to open FOMA terminal.

E Keylock switch ☛P164

Use this key to set/cancel Key Lock.

Connecting to earphone/microphone set with switch

p External connection terminals ☛P43, P342

Used to connect various optional accessories.

q FeliCa mark

The mark means that a piece of IC card is mounted. Use IC card functions by placing the FeliCa mark over the reader/writer. The IC card cannot be detached.

r Compact light ☛P89, P177, P182

Used during the out-camera use. It lights or flashes in red when shooting still image s or videos (however, when the compact lig ht is turned on f or shooting, the red light may be difficult to see ).

s Out-camera ☛P89, P172

Used to shoot people or landscape with Camera or Movie Camera and send these images during a videophone call.

t Antenna (built-in)

Take care not to cover the built-in antenna with your hand so that you can use FOMA terminal on better conditions.

u Rear cover v miniSD memory card sl ot ☛P335

Insert the miniSD memory card in this slot to use i t.

･ You can plug in a flat type earphone/microphone set

with switch (optional) and use it. Using the earphone jack converter adapter P001 (optional) allows you to use an existing earphone/microphone set.

Opening/closing FOMA terminal

To open FOMA terminal, press the one-push open button. To close it, slide the front face (with the display) downward.

One-push open button

Open

w Lens cover ☛P173 x Strap opening y Speaker

Ring alert and other sounds come out of here. When the speakerphone function is used, the other party’s voice comes out.

z Earphone/microphone jack

Used to connect a flat type earphone/microphone set with switch (optional).

A gPushTalk button ☛P97

Use this button to display the PushTalk phonebook or make/answer PushTalk calls and speak during PushTalk. Also, use this key to turn on/off the auto focus function of Camera.

B bTASK key

Use this key during Multiaccess or Multitask.

C CAnswer Machine/shutter key

Use this key to display the Answer Machine/Voice Memo menu, start Quick Record Message,

･Operations such as accessing the screen to

reply to mail or to edit schedules or notes are made easily by opening FOMA terminal. ☛P242,P371, P384

･FOMA terminal allows you to make calls without

opening it. You can also answer an incoming call by opening FOMA terminal and end or put on hold the call by closing it. ☛P65

･Please note that if you open the terminal by

force without pressing the one-push open button or open and close it violently, it will cause

the damage of the terminal.

*1 Lights or flashes when a call or mail is received, FOMA terminal is opened/closed, the Speed Selector is

rotated, during shooting with the camera, etc. The lighting pattern and color can be set (☛P148). Also, it flashes when there is new information (☛P149), and lights in red during charging.

Before Using D902iS Names and functions of parts

Page 30

Before Using D902iS

Using the Speed Selector

You can rotate the Speed Selector as well as press o and O to operate it. The operation performed by rotating the Speed Selector varies by the screen.

Operating on the standby display

One of the following operations is available by rotating the Speed Selector:

Operation Description Page

Names and functions of parts

Executing a function Displays the menu, the phonebook list or the calendar screen of Scheduler,

Switching images on the standby display

according to Speed Selector Setting. You can also set to execute no function. Switches images on the standby display when Change image is set to Speed selector in

Random Display Image.

Operating on a screen other than the standby display

Depending on the screen, the same operation as pre ssing % or & is avai lab le . Rota ti ng th e Sp ee d Select or moves the highlighted item or scrolls t he screen accor ding to how much th e Speed Select or is ro tated. Th is allows you to operate quickly. As the rotating direction, Clockwise or Anticlockwise can be set in Speed Selector Setting.

Direction setting Moving / scrolling operation

List screen List screen View screen Character entry

Clockwise

P28

P138

screen

Anticlockwise

Highlights an item

Highlights a pictogram

Scrolls Moves the cursor

･You can adjust the ring volume by rotating the Seed Selector while receiving a voice/videophone/PushTalk

call. Also, rotating during a voice/PushTalk call adjusts the volume of other party’s voice.

･You can zoom in and out by rotating the Speed Selector on the shooting screen of Camera/Movie Camera or

videophone talking screen.

･In entry fields for date/time and number, rotating the Speed Selector increases and decreases values.

However, this operation is unavailable in some entry fields.

INFORMATION

● In the following cases, no operation is performed by rotating the Speed Selector but pressing % or & is enabled:

･Displaying sites by shortcuts on the dial input screen ･ Using Calculator ･Moving the cursor, frame or stamp while editing still image ･ The display is off

● If Speed selector is set to ON in Light Alert Setting, the Enter key lights/flashes when the Speed Selector is rotated.

Setting the Speed Selector Speed Selector Setting

Set the rotating operation of the Speed Selector.

Default Speed selector: ON Direction: Clockwise Use at stand-by disp: Menu

m889

Note: The miniSD memory card is not included in the bundle and needs to be purchased. ☛P331

Page 31

Select each item to set

Speed selector：Set whether to enable th e r otating operation of the Speed Selector. When OFF is set, the

Direction： Set the rotating direction of the Speed Selector. Select Clockwise or Anticlockwise. Use at stand-by disp：

rotating operation is disabled, and Direction and Use at stand-by disp cannot be set.

Select the function to be executed when the Speed Selector is rotated on the standby display.

･When Menu is set, the menu is displayed. ･When Phonebook is set, the phonebook list is displayed. ･When Scheduler is set, the calendar screen of Scheduler is displayed. ･When OFF is set, no function will be executed.

Press p

･When Change image is set to Speed selector in Random Display Image, if you set Use at stand-by disp to

other than OFF, a confirmation screen appears. Select Yes to change the setting.

INFORMATION

● Even if Speed selector is set to OFF, some i-

● Even if Speed selector is set to ON and Speed selector in Settings (for i-

be operated by rotating the Speed Selector.

● When adjusting the volume, zooming in and out or increasing and decreasing values, the setting for Direction is

disabled. In this case, rotating the Speed Selector to the right increases the volume/display magnification/value and rotating to the left decreases it. In addition, the setting for Direction is disabled for some i-

ppli may be operated by rotating the Speed Selector.

ppli) is set to other than OFF, some i-αppli cannot

ppli.

Reading the display

The description of icons displ ayed at the top or the bottom of the displ ay are shown below:

a - m

Date, day of the week and time

n o - y

Received i-channel information

When you use i-channel, if Show ticker is set to Yes in Ticker Setting, the received i-channel information is displayed as ticker on the standby display. ☛P292

a : Battery level ☛P45 b : Received signal level ☛P46

: Out of service area ☛P46 : Self Mode is set ☛P160

: During data transfer ☛P332, P347

In the miniSD mode ☛P342 Data link software in progress ☛P444

c : In i-mode communication (during

i-mode connection) ☛P200

: In i-mode communication (during

packet communication) ☛P214, P239

d : During infrared communication ☛P347

Infrared remote control function in operation ☛P351

: Key Lock is set (in gray when Key Lock

is temporarily released) ☛P164

e : Speakerphone function in operation

☛P51

: Connecting to USB handsfree

compatible equipment ☛P62

：Total call cost exceeds the maximum

limit ☛P383

f ：Accessing the phonebook on the

network (PushTalkPlus) ☛P96

：During PushTalk calls ☛

: i-mode Mail and Message R/F storage

P96

space is full in the Center *2 ☛P240, P214

Before Using D902iS Reading the display

Page 32

Before Using D902iS

Reading the display

: i-mode Mail or Message R/F storage

space is full in the Center ☛P240, P214

: Both i-mode Mail and Message R/F exist

unreceived in the Center ☛P240, P214

: i-mode Mail or Message R/F exists

unreceived in the Center ☛P240, P214

g : Unread i-mode Mail or SMS storage

space is full and also SMS storage space is full on UIM ☛P266

: Unread i-mode Mail or SMS storage

space is full ☛P240, P266

: SMS full on UIM ☛P266 : Unread i-mode Mail and SMS exist

☛P239,

: Unread i-mode Mail exists ☛P239 : Unread SMS exists ☛P265

(blue/red)

: Unread Message R exists/unread

P265

Message R storage space is full ☛P214

i/(green/red)

: Unread Message F exists/unread

Message F storage space is full ☛P214

j : i-αppli running ☛P273

: i-

ppli standby display on ☛P139

: Starting i-

ppli from the i-αppli standby

display ☛P284

: i-

ppli DX running ☛P273

: i-

ppli DX standby display on ☛P139

: Starting i-

ppli from the i-αppli DX

standby display ☛P284

k : Displaying SSL page, using i-αppli

downloaded from SSL pages and in

l : Secret Mode is set ☛P165 m : i-αppli Auto Start failed ☛P283

n : Focus Mode icon ☛P37 o : General silent mode is set ☛P134

: Personalized silent mode is set ☛P135

p : Call alert volume is set to silent ☛P68

: Vibrator for incoming voice call is set

☛P133

: Call alert volume is set to silent and

vibrator for incoming voice call is set ☛P68, P133

q : Public mode (Driving mode) is set

☛P73

r : Answer Machine is set ☛P75

: Recorded messages full ☛P75

s : Connecting to external device via the

FOMA USB cable (optional) ☛P94

t /

: Effective Speed Selector keys in Focus

Mode ☛P37

u : miniSD memory card inserted ☛P335 v : Reading the UIM ☛P45

: IC Card Lock is set ☛P300

w : PIM Lock is set ☛P160

: Keypad Dial Lock is set ☛P161

x : Alarm Clock is set ☛P368

: Schedule alarm is set ☛P371 : Alarm Clock and schedule alarm are

set simultaneously ☛P368, P371

y : Software Update reserved ☛P460

/ (succeeded/failed)

: Result of auto-update of the latest

pattern definition ☛P462

SSL communication with i-αppli ☛P201 Displaying TLS/SSL page ☛P305

: Auto-send mail failed exists ☛P238 : Auto-send mail exists ☛P238

*1 The current highest priority item is displayed. These icons are listed in the order of priority from the top. *2 Displayed when the storage space for either i-mode Mail or Message R/F is full and also unreceived mail/messages

exist.

Reading the guide row

Operations that can be executed by pressing m, t, o, p and a are displayed in the guide row.

Example

Guide row for the mail composition screen

The display positions and the keys correspond as shown in the figure. In

Guide

this manual, the operations displayed in the guide row are explained using

row

the corresponding keys (mtopa). The operations displayed in the guide row differ depending on the screen.

･ on the guide row corresponds to O of the Speed Selector (it may

be different depending on the function, site or Internet web page in use).

Note: The miniSD memory card is not included in the bundle and needs to be purchased. ☛P331

Page 33

Reading the task bar

The icon for the function (task) in progress is displayed on the task bar (up to 9 icons). You can confirm functions being used and run. In addition, when receiving mails/messages, the reception result is scrolled.

･While entering characters, the input mode is displayed on the task bar. ☛P405

Task bar (when schedule calendar is displayed during a voice call)

Before Using D902iS

: Voice call / : Videophone (64K/32K) : Switching voice/videophone

call : Ending call : Videophone call through

external device : Adjusting volume using

Multitask : PushTalk : 64K data communication / : Originating/communicating/

sending/receiving packet via

USB : Mail : Receiving i-mode Mail/

Message R/F : Receiving SMS : Chat Mail : Message R/F : Check i-mode Message/SMS : i-mode/i-channel

Reading the list screen

Example

The setting screen for Color Scheme

: i-mode Bookmark/Internet

Connection/Screen Memo/

i-mode Shortcut : i-αppli : ToruCa : Full Browser : My Picture (Image) : i-motion : Melody : Chara-den : My Document : Camera : Movie Camera : Sound Recorder : Bar Code Reader : Music Player : Phonebook : Received Calls : Redial : Answer Machine/Voice Memo : Own Number : Timer : Alarm Clock set/alarm

sounding : Scheduler : Schedule alarm sounding

The number of the currently displayed page and the total number of pages (when a list extends over multiple pages)

indicates that other selectable items exist above and below the highlighted item.

･ Press % to move the cursor. ･ If you press d on the last item of the page, the next page appears, and if you press

on the first item of the page, the previous page appears.

: Notepad : Calculator

: Dictionaries

: Data exchanging with

external device

: Setting reception method for

infrared communication/

saving to INBOX / (dark blue/gray) : Accessing/waiting for access

to the miniSD memory card / (dark blue/gray) : In the miniSD mode

(communication possible)/

(USB cable unconnected/no

miniSD memory card inserted) / (dark blue/gray) : Setting/holding each function : Software Update activated : Software Update notified : Update Definition activated/

version display : Setting each network service

: Accessing Data Center

: Displaying communication

log with Data Center

indicates that selectable items exist over multiple pages.

･ Press & to switch between pages.

･ You cannot switch between pages on the icon selection screen, etc.

･ Color names are for information purpose only.

Reading the display

INFORMATION

● Note that the following cases may occur due to the characteristics of liquid crystal display (LCD) and they are not

defects in FOMA terminal.

･ FOMA terminal display is manufactured by taking advantage of highly advanced technology but some dots may be

always or never lit.

･ When the battery pack is removed from FOMA terminal with the power turned on, residual images may remain for

some time. Remove the battery pack with the power turned off.

Page 34

Before Using D902iS

Selecting the menu

･When a screen has been displayed for a certain time, if you change it to another screen by performing some

operations, residual images of the previous screen may remain.

Selecting the menu

In addition to the normal menu, the simple menu which offers popular features is provided. In the simple menu, the menu items are displayed in large letters. Also, you can create your original menu (Custom Menu ☛P376).

Display format for the normal menu and the custom menu

Animation in the normal menu is set by default. Select from the following types (Menu Setting ☛P146). The following screens are examples of the normal menu displayed when Style Theme is set to Platinum.

List view

*1 Available only for the normal menu

● When the menu display fo rmat is set t o Animation, a subsequent operation may not be performe d until the animation stops.

Tile display 3D display Animation*

Switching to the simple menu

Switch to Japanese display before performing these operations.

Press a

The normal menu is displayed.

･ When the custom menu is displayed: p

The simple menu is displayed.

Page 35

■ Switching to the normal menu: ma on the standby display

･To switch to the custom menu: m

on the standby display

Functions available on the simple menu

Some menus cannot be accessed from the simple menu.

でんわ電話帳検索

Menu item Shortcut Menu item Shortcut

電話帳登録リダイヤル着信履歴伝言メモ一覧自局番号

メール受信メール

送信メール未送信メール新規メールｉモード問合せ

カメラカメラ

マイピクチャ待受画面設定

ｉモードｉMenu

Bookmark ラストURL

m11 m12 m13 m14 m15

m16 m0

m21 m22 m23 m24 m25 m31 m32 m33 m41 m42 m43

ｉモード画面メモ

ｉチャネル一覧テロップ表示設定

ｉアプリソフト一覧

待受画面設定

データ BOX

ｉアプリ設定マイピクチャｉモーションメロディキャラ電

マイドキュメント設定／ステーショナリー

音／バイブ

ディスプレイ

目覚まし

電卓

伝言メモ設定

情報表示／リセット

留守番電話

m44 m45 m46 m51 m52 m53 m61 m62 m63 m64 m65 m71 m72 m73 m74 m75 m76 m77

When the simple menu is set

● During calling or talking, you can see how to adjust the volume of other party’s voice.

● Enter a phone number to see the operation to be performed subsequently.

● In standby display, ente r the phone book No. ( 1 to 9) t o see th e registered n ames and ph one numbers. K ey

operations for making voice calls/videophone calls are also shown. During voice calls, you can also press m, select

ダイヤル入力

● The characters in the redials, received calls, phonebook list/group list, member list/group list of the PushTalk phonebook, mail view screen, site, screen memo, me ssage text ent ry screen and char acter entry screen (full-screen entry) are displayed in large font. When the simple menu is set, the font size cannot be changed.

(Dial) and enter a phonebook number to see the same information.

Before Using D902iS

Selecting the menu

INFORMATION

● You cannot switch FOMA terminal to the simple menu when English display is set in Select Language. Also, when you

choose the simple menu, the setting for Select Language is not available.

● Even if you selected the simple menu, when you insert the UIM for which English display is specified as language, the

menu will change to the normal one.

Selecting functions from the menu

Select menu items by the dial keys (Shortcut operations). Also, use the Speed Selector to select menu items.

･In this manual, the operation procedure is explained mainly in shortcut operations of the normal menu. ･When any lock function is set or the UIM is not inserted, some functions are disabled. The disabled

functions are indicated by or dimmed. However, if the menu di splay format is set to Animation, a message appears when menu items for the disable functions are selected.

Page 36

Before Using D902iS

Selecting menu items with the dial keys (Shortcut operations)

Each menu item has a number (item number) and can be selected by pressing the corresponding key.

Example

Selecting the menu

Executing Phonebook new entry from the normal menu

Press m42

The phonebook registration screen is displayed.

When several shortcuts are available

When there are multiple shortcut operations using the normal menu, the shortc ut operations other than described in the operating procedure are shown at the far right of the title in the body text.

Example

ly called numbers Redial

and PushTalk calls that you made as dialed calls (Redial). When the other

ial by simple operation.

When the number exceeds 30, the oldest one is deleted chronologically.

For redialing

Selecting menu items with the Speed Selector

Example

Executing Phonebook new entry from the normal menu (Type1 of animation display)

Menu 46

Press m to show the menu, then press 4 and 6 to show the redial list.

･! means pressing a, and ? means pressing d.

O to highlight Phonebook & Logs z o

･ In case of the animation display, the opera tions of O differ depending on the animation design.

O to highlight Phonebook new entry z Press o

The phonebook registration screen is displayed.

･ Highlighting the desired menu item in other than the animation display shows

the description of the item’s function.

･ In case of the animation display, in the guide row is not displayed.

Page 37

Selecting menu items (List view)

Before Using D902iS

Menu item that has been highlighted

Menu item that cannot be selected (dimmed)

Lower-level menu exists.

Selecting menu items (Tile display)

Press O to highlight a menu item and press o.

･ You can also select an item by the dial key for the item number. ･ To return to the previous menu: c

When Type1 is set

Selecting menu items (3D display)

Press & to bring the desired item to the front of the ic on r ing and pre s s o.

･ Press % to move the the icon at the rear to the front. ･ You can also select an item by the dial key for the item number. Check the item

numbers in the tile display or list view menu.

Press % to highlight a menu item and press o or r.

･You can also select an item by the dial key for the

item number.

･To return to the previous menu: l or c

Selecting the menu

Selecting menu items (Simple menu)

to highlight a menu item and press o or r.

Press

･ You can also select an item by the dial key for the item number. ･ To return to the previous menu: l or c

Returning to the standby display or previous screen

：Returns to the standby display.

：Returns to the previous screen.

Page 38

Before Using D902iS

Selecting functions from the submenu

When MENU is displayed at the upper left of the guide row, you can use the submenu to perform various operations.

Selecting the menu

Example

Setting each item on the screen

Selecting Yes or No on the confirmation screen

Displaying the Redial submenu

m in the redial list

Item that has been highlighted

Lower-level menu exists.

Shows that a submenu exists.

% to highlight a submenu item z Press o or r

･ You can select an item by the dial key for t he ite m number. Even for the same fu nction, th e item numbers

may differ depending on the screen.

･ To return to the previous menu: l or c ･ To close the submenu: m

% to highlight Yes or No z Press o

･ For some functions, items other than Yes or No may appear.

Selecting an item from the pulldown menu

% to highlight an it em

o to display the pulldown menu z % to highlight an item

Press o

･You can select an item by the dial key for the item number.

Pulldown menu

Page 39

Selecting an item from the check box

% to highlight a check box z Press o

The check box changes from to , and is selected.

･Select the selected item ( ) to cancel the selection ( ). ･Depending on the function, you can select/cancel all items by pressing m. ･You can select an item by the dial key for the item number.

Before Using D902iS

Displaying information quickly Focus Mode

When the icons such as or are displayed on the standby display, you can quickly display the information.

o z & to highlight an icon such as or

Press o

The screen corresponding to the selected icon is displayed.

: The received call list is displayed, letting you check the date and time, the calle r in form ation, etc . : The recorded message list is displayed, letting you play the recorded messages. : The confirmation screen for playing voice mail messages is displayed, letting you play the

messages. : The received mail folder list is displayed, letting you check unread mail. : The folder list of ToruCa is displayed and unread ToruCa can be checked.

/ (succeeded/failed):

The data of the latest pattern definition updated automatically can be checked. ☛P462 : The setting for USB Mode Setting while the FOMA USB cable (optional) is connected can be

checked. ☛P342

･The number of stored items is displayed at the right of each icon. ･To cancel Focus Mode: c or f ･When , or is displayed: o z % to highlight the icon

Missed call (unanswered call) exists. Unplayed recorded message exists. Voice mail message exists. Unread received mail exists. Unread ToruCa exists. Data of the latest pattern definition updated automatically exists. ( , ) Effective Speed Selector keys Being connected to external device via the FOMA USB cable (optional) ( ) The color of the highlighted icon changes.

Selecting the menu

INFORMATION

● When you highlight an icon and hold down c for over a second, the icon temporarily disappears from the screen. It

reappears when new information is stored or the number of stored items changes by viewing information, etc. For the icon indicating voice mail messages, however, a confirmation screen appears asking whether to clear the icon. Select Yes to clear it temporarily.

Page 40

Before Using D902iS

Number of saved, registered and protected items in D902iS

Type

Mail Received mail*

Sent mail*

Number of saved, registered and protected items in D902iS

Unsent mail*

Template* SMS in the UIM* Message R* Message F*

Bookmark i-mode 100

Full Browser 100

Screen memo*

Maximum number of

saved/registered

items

1,000 500 i-αppli*

200 100 Image* 200 100 Melody* 100

100 50

50 25

100 50

Maximum number

of protected

items

−

Type

PDF data*

Video/i-motion/sound recorded with Sound

Recorder* Chara-den*

ToruCa*

Maximum number of

saved/registered

items

100 100

1,000

500 100

100

100 50

*1 Depending on the size of data, the actual number of items that can be saved and registered may be fewer. *2 The total number of i-mode Mail and SMS. *3 The total number of sent and received SMS. The number of delivery report is not included.

*4 Up to 5 items of Message i-

saved. Depending on the i-

ppli (as part of the 100 items, maximum number of i-αppli that can be saved) can be

ppli size, the actual number of items that can be saved may be fewer.

INFORMATION

● Because the data saved in FOMA terminal may be lost due to failure, repair or other handlings of FOMA terminal, it is

recommended that you maintain a separate record of the important data in FOMA terminal. Please note that we are not responsible for any lost data.

● Depending on the function, the displayed size of data in FOMA terminal may differ slightly.

● It is recommended that you save the data stored in FOMA terminal such as mail, bookmarks, images, melodies or video/

i-motion to the miniSD memory card. Exchangeable data ☛P336

● If you have a PC, you can use the FOMA D series data link software contained in the attached CD-ROM and the FOMA

USB cable (optional) to transfer and save the data such as mail, bookmarks, images, melodies, video/i-motion to your PC.

Maximum number

of protected

items

−

Using the UIM (FOMA card)

Use the UIM (FOMA card) to store your phon e number and other information. Insert the UIM into FOMA terminal to use it.

･For details on handling the UIM, refer to the UIM manual.

Inserting/removing the UIM

Use your FOMA terminal with the UIM inserted. If the UIM is not inserted in your FOMA terminal, first insert it.

･Before inserting or removing the UIM, turn the power off and remove the rear cover and battery pack.

Attaching/removing the rear cover and battery pack ☛P41

･Insert or remove the UIM with FOMA terminal closed using both hands.

Note: The miniSD memory card is not included in the bundle and needs to be purchased. ☛P331

Page 41

Inserting the card

Before Using D902iS

Tray is pulled out until it stops.

Slot tray

Cut corner

UIM

Removing the card

aPull out the UIM slot tray.

･ The operations are the same as a to b in

“Inserting the card”.

bRemove the UIM by sliding it out.

Cut corner

UIM slot cover

aRemove the rear cover and then

the battery pack. ☛P41

bPull out the UIM slot tray.

Place your finger on the slot cover and slide it out until the slot tray stops.

cInsert the UIM into the slot with

the IC side of the card facing down.

dLift the slot cover until its bottom

is even with the slot tray.

Align the cut corner of the slot tray to the cut corner of the UIM.

ePush the slot tray in until it

stops.

fReattach the battery pack and

then the rear cover. ☛P41

When the UIM slot tray is removed

Insert the UIM slot tray and push the tray straight in.

● Remove the UIM before replacing the slot tray.

Using the UIM (FOMA card)

INFORMATION

● Insert or remove the UIM carefully as forcing it may damage the card.

● Carefully handle the removed UIM so that it does not become lost.

● When attaching the battery pack, make sure that the UIM slot is in place. If not, you cannot attach the battery pack.

Forcibly attaching the battery pack may damage the UIM or the UIM slot.

● When pushing the UIM slot in, make sure that the UIM is properly placed in the slot and the lid is flat. Forcibly pushing

the slot into FOMA terminal may cause an operation error.

UIM security codes

The PIN1 and PIN2 codes are used for the UIM. Both codes are set to “0000” at the time of subscription to the FOMA service. You can change this to any code (4 to 8 digits). ☛P156

UIM operation restriction function

FOMA terminal is provided with the UIM operation restriction function for protecting your data and files.

･When the data or files downloaded from sites or t he data attached to mail are saved in FOMA terminal with

the UIM inserted, the UIM operation restriction function is automatically set to these data or files.

Page 42

Before Using D902iS

･If the UIM is replaced by another UIM or is removed from FOMA termin al, the data or files with the UIM

operation restriction function set cannot be displayed or played.

･The data or files with the UIM operation restrictio n function set cannot be copied/moved to the miniSD

memory card or cannot be exchanged by infrared communication. However, i-motion compatible with Movable Contents can be moved to the miniSD memory card.

･The data which is subject to the restriction is as follows:

・Screen memo ・Message R/F ・Image inserted in Deco-mail or signature ・File attached to i-mode Mail ・i-

ppli (including the i-αppli standby display) ・i-motion

Using the UIM (FOMA card)

・Image (including animation and Flash movie) ・Chara-den ・Melody ・PDF data ・Recorded message for videophone call ・Movie memo ・Image of ToruCa (details) ・Data compatible with Movable Contents

･For i-

ppli with the UIM operation restriction set, the following operations are disabled wh en the UIM is

replaced by another UIM or is removed from FOMA terminal:

・Start ・Displaying the detail information of i- ・Operation settings for i- ・Changing the auto start function ・Setting the i-

ppli ・Auto start

ppli standby display

・Upgrade

INFORMATION

● When the data with the UIM operation restriction function enabled is set for the standby display, call image or ring tone,

the image and sound settings return to the default if the UIM is replaced by another UIM or is removed from FOMA terminal. In this case, the image and sound that are actually displayed/generated may differ from the settings. Inserting the UIM that was used when the data was downloaded cancels the operation restriction of the data and restores the original settings. (Note that the setting may be canceled if the data was used for Random Display Image.)

● The UIM operation restriction function is not set to the data obtained via infrared communication, the miniSD memory

card or data link software or to the still images or videos taken with the built-in camera. The UIM operation restriction may not be set to some mail templates such as the one containing only text.

● When the UIM is inserted in other i-channel compatible terminals, the i-channel information is not displayed as ticker on

the standby display. After that, if the information is updated automatically or if you press c on the standby display to display the channel list, the latest information is received and then displayed as ticker on the standby display.

● When the UIM is not inserted, the i-channel information is not displayed as ticker on the standby display.

ppli

The settings saved into the UIM

The following settings are saved into the UIM. If the UIM is replaced, the settings saved in the new UIM become available.

･Font type, storage period in the SMS Center, SMSC, address, type of number set in SMS Setting ･DoCoMo certificate and user certificate set in Certificate Setting ･My phone number of Own Number ･Select Language ･ The PIN1/PIN2 code of the UIM and PIN1 Code ON/OFF

Functional differences between the UIM types

There are 2 types of the UIM: green and blue. The functions differ depending on the type as shown below:

Number of digits of a phone number that can be registered in the UIM phonebook

Certificate Download for using FirstPass

WORLD WING service Available Unavailable P41 Service Dialing Number Calling DoCoMo for Repairs and DoCoMo

Note: The miniSD memory card is not included in the bundle and needs to be purchased. ☛P331

Item UIM (green) UIM (blue) Page

Up to 26 digits Up to 20 digits P110

Available Unavailable P217

for General Inquiries (

Center) available

DoCoMo Information

Unavailable P396

Page 43

WORLD WING

WORLD WING is the DoCoMo FOMA international roaming service. By taking out the UIM (green) from the FOMA terminal you normally use and inserting it into a FOMA terminal supporting the service or an overseas mobile phone (W-CDMA or GSM handset), you can make/receive calls in foreign countries with your own mobile phone number.

You can use WORLD WING without subscription.

● If you have not contracted WORLD WING for the FOMA service in the contract before August 31, 2005, a separate subscription is required to use WORLD WING.

● This service cannot be used with some billing plans.

Attaching/removing the battery pack

･Turn the power off before attaching or removing the battery pack. Also, attach or remove it with FOMA

terminal closed using both hands.

･Be careful not to touch the camera lens. ･Use the specified battery pack D06.

Attaching the battery pack

Press here.

aRemove the rear cover.

While pressing the top of the rear co ver with your thumb, slide it in the direction of the arrow until it is removed.

Before Using D902iS

Attaching/removing the battery pack

Removing the battery pack

bWith the surface with the DoCoMo logo and the

recycle mark of battery pack facing up, insert the battery pack into FOMA terminal at the angle as shown in the figure.

Do not force the battery pack terminals into FOMA terminal. Doing so could damage these terminals or the body connector.

cPush the battery pack in. dPlace the rear cover plate so that it can slide

about 2 mm on FOMA terminal.

eSlide the rear cover in the direction of the arrow

pushing its center by fingers so that FOMA terminal and the rear cover do not gap.

Failure to follow the correct procedure could damage the rear cover.

aRemove the rear cover. bLift the projection part of the battery pack and

remove it.

Page 44

Before Using D902iS

INFORMATION

● The FOMA terminal display uses an active LCD. Due to the characteristics of active LCD, residual images or crossbar

may remain for a while when the battery pack is attached or removed. This is not a fault of FOMA terminal.

Charging the battery of FOMA terminal

When the battery level is low, charge the battery.

･The battery level icon shows how much charge remains in the battery. ☛P45

Charging time and operation time on full charge (estimates)

Charging time Continuous call time Continuous standby time

Approx.

120 minutes

During a voice call: Approx. 170 minutes During a videophone call: Approx. 90 minutes

While standing still: Approx. 550 hours While moving: Approx. 380 hours

･ Continuous call time is an estimate of call time for FOMA terminal when it can send or receive signal s

normally.

･ Continuous standb y time is a n estima te of op erat ion t ime of FOMA termi nal w hen it is clos ed a nd ab le

to receive signals normally. The call/standby time may be redu ced to about half, depending on the amount of charge in the battery, th e function settings, the ambient temperature and signal conditions (radio waves do not or hardly reach). Using i-mode communication reduces the call (communication)/ standby time. Even if you do not make a call or use i-mode, the call (communication)/standby time will be reduced by composing i-mode Mail, or starting downloaded i-αppli software or the i-αppli standby display.

･ Continuous standby time (while standing still) is the average operation tim e of FOMA terminal when it

is standing still, closed and able to receive signals normally.

･ Continuous standby time (while moving) is the average operation time of FOMA terminal that is

standing still, moving and outside the service area when it is closed and able to receive signals normally.

･ Alternatively, if you perform data communication or Multiaccess, use Camera or play video/i-motion

(including music data), the call (communication)/standby time will be reduced.

Starting/ending charging and other items to note

The battery pack can be charged regardless of whether FOMA terminal is turned on or off. However, charging takes longer with the power turned on.

･ When charging starts, the Enter key lights in red.

When FOMA terminal is turned on, the charge alert sounds and the battery level icon blinks.

Charging: Blinks

(

Charged: Lights

・The battery level icon differs depending on the color of FOMA terminal. You can also change it. ☛P147 ・If the Enter key does not light in red at the start of chargi ng or it flash es in r ed, cha rg ing i s unsucce ssfu l. The

battery may not be charged when the temperature of FOMA terminal is high. Stop any function in progress and confirm that the temperature is low before chargi ng again. If the bat tery pack still canno t be charged even aft er charging again, contact “Repairs” on the back of t his manu al.

Icon Enter key Meaning

)

Charging: Lights in red Charged: Goes off

Charging normally.

･ When charging is completed, the Enter key goes off.

When FOMA terminal is turned on, the charge alert sounds and the battery level icon lights.

･ If the battery level icon blinks, charging is not completed. ･ You can set the charge alert not to sound. ☛P134

Page 45

･ Do not charge the battery for an extended period (longer than a full day) with FOMA terminal turned

on. FOMA terminal uses power so the adapter continues charging until FOMA terminal is unplugged from the adapter. In such a case, the AC or DC adapter charges again but when FOMA terminal is removed in the middle of charging , the following could occur:

・Low battery level ・Message appears indicating that the battery runs down. ・FOMA terminal is operational for a short time.

･ If the battery is fully charged, connecting FOMA terminal to the AC or DC adapter may not start

charging.

･ If you use FOMA terminal while charging the battery for an extended period with the AC or DC adapter

connected, the battery may not be charged temporarily by temperature rise.

･ Insert or remove the connector to/from FOMA terminal slowly and firmly without forcing it. When

removing it, be sure to press the release buttons on both sides of the connector and pull it out. Forcibly pulling it could cause equipment failure.

･ Insert or remove the AC adapter connector straight to/from FOMA terminal.

Battery pack life

The battery pack is a consumable part and will gradually wear out. Each time it is charged, it will accept slightly less charge than the previous time. When the battery charge lasts only ha lf as long as when it was new, replace it with a new one. The battery pack life is about 1 year. This life may be shorter depending on the frequency of use.

･FOMA terminal uses a lithium ion battery containing valuable materials that should be recycled. To protect

the environment, return used batte ries to an NTT DoCoMo service co unter, NTT D oCoMo agent or recycl ing center.

･Please take the following precautions when recycling batteries:

・Attach a piece of adhesive tape on the terminals of used battery packs ・Do not disassemble or modify battery packs

Li-ion

Before Using D902iS

Charging the battery of FOMA terminal

Charging from a wall outlet

Use the FOMA AC adapter 01 (optional) to charge the battery. Also it can be used with the desktop holder D09 (optional). You can charge the battery with FOMA terminal either closed or open.

･The battery pack can only be charged when it is attached to FOMA terminal. ･For details, refer to the manuals for the AC adapter and t he desktop holder.

■ Charging the battery with the AC adapter alone

Power plug

100 V AC outlet

aUnfold the power plug from the AC

adapter and plug it into a 100 V AC outlet.

bOpen the external connection

terminal cap of FOMA terminal.

cInsert the AC adapter connector in

firmly until it clicks.

dCheck that charging starts.

Check that the Enter key lights in red. When charging is completed, remove

Enter key

Release button

Connector ( up)

AC adapter

the AC adapter connector from F O MA terminal while pressing the release buttons on both sides of the connector, and unplug the AC adapter from the outlet. Then, close the terminal cap.

Page 46

Before Using D902iS

Charging the battery of FOMA terminal

■ Charging the battery in the desktop holder

100 V AC outlet

Power plug

aUnfold the power plug from the AC

adapter and plug it into a 100 V AC outlet.

bInsert the AC adapter connector in

Enter key

the desktop holder until it clicks.

cAlong with the desktop holder,

Connector ( up)

Desktop holder

AC adapter

insert FOMA terminal at the angle as shown in the figure.

dCheck that charging starts.

Check that the Enter key lights in red. When charging is completed, remove FOMA terminal from the desktop holder by tilting it to the front while holding the desktop holder by hand.

･ When inserting FOMA terminal into the desktop holder, be careful not to put a strap in the holder. ･ When FOMA terminal is not inserted firmly or it leans, the battery is not charged normally. Insert

FOMA terminal until it is locked certainly.

Charging in a car

Use the FOMA DC adapter 01 (optional) to charge the battery in a car. It can be used with negative ground cars (both 12 V and 24 V).

･For details, refer to the DC adapter manual.

aInsert the cigare tte lighter plug of the DC adapter i n to the cigarette lighter socket of the car. bTurn off the power of FOMA te rminal and open the external connection terminal cap. cInsert the DC adapter connector firmly until it clicks. dCheck that charging starts.

When charging is completed, remove the DC adapter connector from FOMA terminal while pressing the release buttons on both sides of the connector, and remove the cigarette lighter plug from the cigarette lighter socket. Then, close the terminal cap.

Cigarette lighter plug

Enter key

Connector ( up)

Release button

Cigarette lighter socket

DC adapter

INFORMATION

● If you charge FOMA terminal with the car engine off, the car battery may be discharged. Charge the battery when the

car engine is running.

● When not charging, remove the DC adapter from the cigarette lighter socket.

● The DC adapter fuses (2A) are consumable items. New fuses are available at automotive supply stores.

Page 47

Checking the remaining battery level Battery Level

The display indicates an estimate of the remaining battery level in 3 levels.

(Level 3): Amply charged (Level 2): Charging decreased

Battery level icon

Checking the remaining battery level by sound and display

m843

(Level 3)

(Level 1): Recharging recommended

･The battery level icon differs depending on the color of FOMA terminal. You

can also change it. ☛P147

(Level 2)

(Level 1)

The remaining battery level is displayed. The confirmation sound rings by the sound set in Keypad Sound.

Before Using D902iS

Battery Level

Sounds 3 times.

Sounds twice.

Sounds once.

When the battery almost runs down

A message appears or a low battery alert sounds to indicate that the battery level is low. Charging the battery stops the low battery alert. To stop it immediately, press f.

･In standby, a message indicating low battery appears. The message disappears by pressing o, c or

f, but aft er a pe ri od of t im e , it re appears and the low bat tery al ert soun ds. At this t ime, al l the icons o n the

top of the screen blink and after approximately 1 minute, the power turns off automatically.

･During a call, the low ba ttery alert sounds from the earpiece and a message indicating low battery appears.

The message disappears by pressing o, c or f. When approximately 20 seconds elapse after th e low battery alert is heard, the call is cut off and the standby display reappears. Then, after approximately 1 minute, the power turns off automatically.

Setting the low battery alert not to sound Low Battery Alert

Default ON

m81165

Press 2

･To set the alert: 1

INFORMATION

● When the battery almost runs down during a call, even if OFF is set, the low battery alert sounds from the earpiece.

Turning the power on/off Power ON/OFF

･When FOMA terminal is turned on for the first time, a confirmation screen is displayed asking whether to

perform Software Update. Note that the battery needs to be charged enoug h wh en performing. Please be sure to refer to “Updating software” before performing. ☛P457

Page 48

Before Using D902iS

Select Language

Turning the power on

Hold down f for over 2 seconds

The wake-up screen appears and then the standby display is displayed. Displaying the wake-up screen may take some time.

Battery level icon

Received

signal level

Icon Received

signal level

Strong Weak Outside the service area

and where radio waves are hard to reach

･If the date and time have not been set, a message indicating that

Date/day/time

The standby image is displayed.

is displayed. When FOMA terminal receives the time informatio n and the time is automatically corrected, the message disappears. Press o to set the date and time manually.

･If no UIM is inserted, a message indicating that insertion of the

UIM is required is displayed. Turn the power off, insert the UIM and then turn the power back on.

･The following items can be changed:

is indicated while reading the UIM and

disappears when reading is completed.

・Standby image ☛P136 ・Battery level icon ☛P147 ・Time display format ☛P151

Turning the power off

Hold down f for over 2 seconds

INFORMATION

● When you turn on the power of FOMA terminal after replacing t he UIM (except when Omakase Lock (Remot e Lock) is set),

entry of the 4 to 8-digit terminal security code is required. After entering the correct PIN1 code, the standby display appears. If a wrong terminal security code is entered 5 times consecutively, the power is turned off (can be turned on again).

● Calls may be cut off even when is indicated and you are not moving.

● When PIN1 Code ON/OFF is set to ON, entry of the PIN1 code is required.

● When Reset Call Cost is set to ON, entry of the PIN2 code is required.

● When Normal use of Display light time in Display Light Setting is set to other than Always, if you do not press any keys for

about 90 seconds, the display disappears. This also applies during a voice call. If there is any key operation* rotating the Speed Selector) or an incoming call, the display appears again.

･The display does not disappear in following cases: during a videophone call, when the shooting screen of Camera/

Movie Camera is displayed, while shooting, while charging with AC adapter connected of Display light time set to Always on, or while executing the function for which Display light time is set to Always on.

*1 Pressing dial keys does not enter numbers, except during a call.

(except

Switching to English display Select Language

Default Japanese

m8272

Press 2

･ To switch to Japanese display: 1

INFORMATION

● The setting is saved in the UIM.

Note: The miniSD memory card is not included in the bundle and needs to be purchased. ☛P331

Page 49

Setting the date and time Date and Time Setting

The time setting can be performed in 2 ways: obtaining the time information from DoCoMo network to adjust the time setting of FOMA terminal, or manually entering the current time to the terminal.

Default Auto time adjust: ON Offset: +,00h00m

m851

Select each item to set

･When you set Auto time adjust to ON, Offset can be set. Date and Time cannot

be set.

Before Using D902iS

Date and Time Setting

Auto time adjust ：Set whether to perform the automatic time correction.

Offset ：Specify the amount of time advance (+) or delay (-) so that your terminal's clock

Date, Time ：Set the date and time.

･The entered numbers can also be increased or decreased with %. Also, highlight the number with &

to change to enter it.

Press p

･ To enter the date and time manually, set Auto time adjust to OFF.

advances from/delays to the time obtained for a given length of time.

･ Enter the time between 00h00m and 23h59m. ･ Prefix 0 if the hour and/or minute is a single digit (0 to 9).

･ Enter the year by the last 2 digits of the year. From January 1, 2000 to December 31,

2050 can be set.

･ Enter the time in the 24-hour clock (00h00m to 23h59m). ･ Prefix 0 if the month, date, hour and/or minute is a single digit (0 to 9).

When the automatic time correction is set

The automatic time correction takes place when the UIM is inserted and you turn the power on in a location where radio waves reach.

･The automatic time correction sometimes causes a time error of several seconds. In addition, it may fail to

correct the time depending on the radio wave condition.

･If the time information is received while i- ･When Auto time adjust is set to ON, the time may not be corrected for a while. To enable the automatic time

correction, turn the power off and then on.

･When no UIM is inserted or FOMA terminal is out of the service area, the automat ic time correction is not

performed even if you turn the power off and then on.

INFORMATION

● You cannot use the following functions when the date and time are not set:

･ Auto Power ON/OFF ･ Alarm Clock ･ Certificate Download ☛P217 ･ i-

ppli auto start ☛P282 ･ i-αppli DX ☛P270 ･ Flash movie which uses the date and time setting

･ Scheduler (including data transfer and display of data on the miniSD memory card) ･ Downloading and playing i-motion with replay restrictions set ☛P321 ･ Software Update ･Update Definition ･ SSL communication (authentication) ･ Random Display Image (when Chang image is set to other than Open slide or Speed selector)

● If the date and time are not set, the date and time are not recorded for the following functions and “----/--/--” or

“----------------” is displayed. A number to segmentalize (segmental number) may be appended.

ppli is running, the time may not be corrected depending on the i-αppli.

Page 50

Before Using D902iS

Caller ID Notification

･Redial/Received Calls ･Answer Machine/Voice Memo ･ Notepad ･Date and time of still image/video shot with the camera ☛P174 ･Date and time of sent mail/unsent mail ☛P248 ･ Date and time of sound recorded with Sound Recorder ☛P352 ･Date and time of the last reset of call duration/call cost ･Date and time in the file name of data scanned by Bar Code Reader ☛P193 ･Date and time of downloaded i- ･Date and time of saved/registered still image, melody, Chara-den, i-motion or mail template ☛P344, P237

● The set time is retained even when the battery pack is replaced, but may be reset if the battery pack is removed for an

extended period. In that case, set the date and time again.

● When Reset Call Cost is set to ON, entry of the terminal security code is required.

ppli (detail information) ☛P274 ･ Date and time of receiving ToruCa ☛P297

Notifying your phone number to the other party Caller ID Notification

Set FOMA terminal to send your phone number (caller ID) to be displayed on the other party’s pho ne every time you make a call.

･The caller ID is your important information. Carefully consider whether to send your caller ID. ･The caller ID is displayed only when the other party’s phone can display the caller ID. ･Caller ID Notification cannot be set outside the service area. Set in a location with good radio reception. ･For details, see “Network Services User’s Guide”.

m8951

･ To check the current setting: m8952 z Select Yes

Enter the network security code z Press 1

･ The network security code entered is masked with “ ･ To hide the caller ID: 2

INFORMATION

● You can also use the following ways to show/hide the caller ID.

･Setting to show/hide the caller ID for each phonebook entry ☛P121 ･Setting to show/hide the caller ID when making a call ☛P57, P58

● If you hear a guidance requesting your caller ID when you make a call, call back after setting to send caller ID.

● When setting/operating multiple caller ID notification methods at the same time, the caller ID is notified in the following

priority. However, the setting of showing/hiding the caller ID shown on the display may be different from the actual setting.

When you set the caller ID notification method in Call Option when making a call ☛P58

When “186”/“184” is appended before the other party’s phone number

When Caller ID Setting is set to a phonebook entry

When Caller ID Notification is set

● Set Caller ID Notification for PushTalk calls in PT Caller ID Notification.

＊

”.

Menu 48

Checking your own phone number Own Number

Check your phone number (My phone number), name, mail address, etc.

Default My phone number: subscribed phone number Other than that: not recorded

Press m0

･ The phone number of the UIM inserted in FOMA terminal is displayed for My phone number. ･ To check your i-mode Mail address: d1 to display iMenu → Select ENGLISH → dOptions →

aMail Settings → Confirm Mail Address

INFORMATION

● To check your phone number during a call: b0

Page 51

Making/Receiving Calls

Making calls

Making calls ......................................................................................................50

Switching from a voice call to a videophone call ..........................................53

Setting Chaku-moji ...................................................................... Chaku-moji 54

Calling back previously called numbers ........................................... Redial 56

Setting whether to send your phone number for each call

...................................................................................................... 186/184 Call 57

Making calls by setting the conditions .......................................Call Option 58

Using international calls ........................................................ WORLD CALL 58

Making a call by specifying a sub-address ............................ Sub Address 60

Setting the alarm indicating reconnection of interrupted call

............................................................................................. Reconnect Alarm 61

Suppressing ambient noises to improve the call quality

.............................................................................................. Noise Reduction 61

Talking without using hands in a car ............................... In-car Handsfree 62

Receiving calls

Receiving calls ..................................................................................................62

Receiving a call by switching from a voice call to a videophone call .........64

Enabling use of dial keys to answer a call ...................... Any Key Answer 65

Setting to start talking by opening FOMA terminal .............. Open Answer 65

Disconnecting/continuing/holding a call by closing FOMA terminal

.................................................................................................... Close Setting 65

Using Received Calls ........................................................... Received Calls 66

Adjusting the volume of the other party’s voice during a call

.................................................................................................. Listen Volume 68

Adjusting the volume of ring alerts and other sounds emitted from FOMA

terminal ................................................................................... Adjust Volume 68

Setting for incoming voice/videophone/PushTalk calls

.................................................. Call Alert/Videophone Alert/PushTalk Alert 70

Setting the priority screen for incoming calls during a call or packet

communication ............................................................ Priority Comm Mode 70

When you can/could not answer a call

Putting incoming calls on hold when you cannot answer right away

......................................................................................... Response and Hold 71

Setting the response hold guidance .................................. Status Message 72

Setting the on-hold tone ........................................................ On-hold Tone 72

Using Public mode (Driving mode) ............... Public mode (Driving mode) 73

Using Public mode (power off) ........................................................................74

Allowing the caller to leave message when you cannot answer the call

.............................................................................................. Answer Machine 75

Page 52

Making calls

Making/Receiving Calls

Making calls

The operations common to voice call s and videophone calls are explaine d here.

･Do not cover the built-in antenna with your hands during a call.

Enter the phone number

Calling general subscriber phones

Calling mobile phones 090 - XXXX - XXXX, 080 - XXXX - XXXX Calling PHS phones 070 - XXXX - XXXX

･ Up to 80 digits can be entered. However, only 24 digits are displayed. ･ To correct the phone number: c ･ To return to the standby display: c (for over a second)

You will hear a dial tone. You can start talking when the call is answered.

･ If the phone of the other party is busy, you will hear a busy signal. Press f

to end the call and call again later. You can call back quickly using Redial.

･ If the power of the other party’s mobile phone or PHS is turn ed off or the other

party is in an area where radio waves are hard to reach, a guidance informs that the connection is unavailable.

Always include the area code even when calling from the same city.

Press f when you finish the call

･ To end the call by closing FOMA terminal, change the setting in Close Setting .

INFORMATION

● You can also make a call in order of Step 2, Step 1. A voice call will be made automatically about 5 seconds after you

have pressed n and entered the phone number.

● If a guidance requesting your caller ID is heard w hen a call is made, cal l again after setting F OMA terminal to send cal ler

ID.

● When you subscribe to the Multi Number service, you can call after selecting a registered multi-number. ☛P397

Page 53

Putting calls on hold while talking On-hold

Putting the call on hold while talking allows you to talk without the other party hearing your voice.

･Callers are charged for the time spent on hold.

Press o during a call

Flashes

The call is put on hold and a guidance (on-hold tone) is played. For videophone calls, the onhold image is displayed on your and the other party’s terminals.

On-hold image

Making/Receiving Calls

Making calls

Voice call on hold

Videophone call

on hold

･Press o or n while a voice call is on hold to cancel the hold. ･Press o while a videophone call is on hold to cancel the hold and send the image that has been sent

before the hold. Press t or n to cancel the hold and send your image to the other party and press a to cancel the hold and send a substitute image.

･To put the call on hold by closing FOMA terminal, change the setting in Close Sett i ng.

Using the speakerphone function

You can make a call allowing the other party’s voice to be heard through the speaker.

Enter the phone number z Hold down n for over a second

･To make a videophone call: Enter the phone number z t

If Speakerphone is set to OFF in Videopho ne Settings, press t for over a second.

･When you make a videophone call , the sp ea kerpho ne f unc ti on i s autom at ical ly tu rned o n. To make a

videophone call without turning on the speakerp ho ne fun ct ion , chang e t he sett i ng in Vid eo pho ne Set tin gs.

･You can turn on/off th e speakerphone function by pressing n while dialing or calling, and by pressing

a or n during a call.

･ is displayed at the top of the display while the speakerphone function is on. ･The operation is the same as when operating from the list of th e phonebook, redials, received calls,

recorded messages and voice memos.

･To make a PushTalk call: Enter the phone number z g (for over a second) ･When you make a PushTalk call with FOMA terminal closed, the speakerphone function is automatically

turned on.

■ Adjusting the speakerphone volume: % during a voice call z O to adjust the volume

･ During a videophone call: m0 z ･ The setting is retained even after the call is ended, and is also reflected to the volume of playback

sound for recorded videophone call messages.

to adjust the volume

INFORMATION

● When the speakerphone function is turned on, the volume may suddenly increase and damage your ears, so use it with

FOMA terminal away from your ears.

● If a call is hard to hear with a large amount of noise around you or the other party, turn off the speakerphone function.

● Talk to FOMA terminal within about 30 cm.

● When a flat type earphone/microphone set with switch (optional) or the In-Car Hands-Free Kit 01 (optional) is connected

to FOMA terminal, use the connected device to communicate.

● The speakerphone function can be used even when Silent Mode is on.

Page 54

Making/Receiving Calls

Making calls

Operations available from the submenu during a voice call

Submenu item Description Page

Switch to V-phone

Received calls

Redial

Set time

Reconnect alarm*

Quality alarm*

Terminal close

Dial up

Listen volume

*1 The setting can be changed while an alarm is sounding. It becomes effective when the alarm is stopped.

Switches from a voice call to a videophone call. P53 Displays received calls. P66 Displays redials. P56 Sets the date and time. P47

Allows setting an alarm indicating reconnection of a call under improved signal quality which has been cut off due to poor signal quality.

Sets whether to sound an alarm when your call is about to be cut off due to poor signal quality.

Sets the operations (whether the call is disconnected, continued or held) when FOMA terminal is closed during a call.

Allows making a call to another party during a call using Call Waiting Service. P393 Adjusts the earpiece volume. P68

P61

P134

P65

･The following key operations are available during a call:

: Adjust the volume

・

: Activate Camera

・

・l: Display received call s ・r: Display redials ・p: Start the phonebook

・C (for over a second): Record the other party’s voice (Talking Voice Memo)

Entering pauses or timed pauses

Pauses and timed pauses are available only for voice calls.

Example

Calling to “03XXXXXXXXP12345” (P=Entered pause)

When you press o after the call is connected, the numbers after the pause are dialed.

Entering a pause “P”

A pause (P) is used for sending messages to beepers*, operating the answering system at home, reserving tickets, etc. At the point the pause (P) is entered, the dial digits are separat ed and tone signals (DTMF) are se nt.

Hold down ( for over a second

･ You cannot make a call if a pause is entered at the beginning of the phone number.

Entering a timed pause “T”

A timed pause (T) is used to dial outside line numbers with extensions. Enter “T” between the outside line and extension numbers to dial the extension number after a set number of seconds following the outside line number.

Page 55

Hold down # for over a second

･Timed pauses can be entered in succession. ･Each timed pause is followed by a second interval. ･You cannot make a call if a timed pause is entered at the beginning of the phone number.

INFORMATION

● Tone signals (DTMF) may not be received depending on the receiving device.

● You cannot make a call to another party by putting the current call on hold and entering a pause (P) or timed pause (T).

● When it is necessary to send tone signals (DTMF) following voice prompts as in making ticket reservations, the

speakerphone function is useful. In this case, input tone signals (DTMF) after turning on the speakerphone function.

Switching from a voice call to a videophone call

You can switch to a videophone call by operating from the submenu during a voice call when the other party’s terminal can switch calls. Switching can be performed only from the terminal which made the voice call.

･This operation can be performed between the terminals that support switching between voice call/

videophone call.

･To switch to a videophone call, the other party needs to set Indication ON of Notify Switchable Mode in

advance. ☛P93

m1 during a voice call z Select Yes

Making/Receiving Calls

Switching from a voice call to a videophone call

･A guidance informing that the call is being switched is played dur ing switching. ･Select No to return to the voice call talking screen. ･When Speakerphone is set to ON in Videophone Settings, the speakerphone functi on is automatically

turned on when the call is switched to a videophone call.

INFORMATION

● During packet communication, disconnect the packet communication and switch to a videophone call.

● When the other party is during packet communication, the call cannot be switched to a videophone call.

● While talking on the phone using Call Waiting Service, you cannot switch the call to a videophone call.

● It takes about 5 seconds to switch. In addition, it may take longer to switch depending on radio wave conditions.

● Depending on radio wave conditions, a voice call and videophone call may not be switched and the call my be

disconnected.

● A second call received while switching calls is rejected.

● The speakerphone function is turned on/off every time a voice call and videophone call are switched.

● The settings (such as switching the cameras or selecting the frame) during a videophone call are canceled every time a

voice call and videophone call are switched.

● According to the call duration of a voice call and videophone call, the call charges are added up, respectively.

● The call is not charged while Switching... is displayed.

● Switching from a videophone call to a voice call ☛P82

* From January 2001, the DoCoMo display beeper name has changed to “QUICKCAST”.

Page 56

Making/Receiving Calls

■

Chaku-moji

Setting Chaku-moji Chaku-moji

You can have a message (Chaku-moji) displayed on the incoming screen of the other party’s terminal for outgoing voice/videophone calls, letting him/her know what the matter is in advance. Also, whether to display Chaku-moji for incoming calls with Chaku-moji can be set.

･ Supporting models: 902iS series ･ Senders are charged, but receivers are not charged. ･ Received Chaku-moji is registered in the received call history.

Chaku-moji is displayed on the incoming screen of the other party’s terminal. When the call is answered, the Chaku-moji is cleared.

Editing and setting for Chaku-moji messages

Creating a Chaku-moji message

･Up to 10 messages can be registered.

m8941

Select <New message>

Enter a Chaku-moji message (up to 10 one-byte or two-byte characters)

･ Kanji, hiragana, katakana, alphabetic and numeric char acters, symbols, and pictograms can be entered.

Press p

･ When you have edited a reg ister ed Chaku-moji message , a con firmati on scree n a ppears asking whet her

to register it. Select Yes to overwrite.

Using the sent message history:

a m1 b Select a Chaku-moji message

■ Deleting:

a Highlight a Chaku-moji message z m2

･ To delete all: m3

b Select Yes

Page 57

Making the Chaku-moji reception setting Message Display Setting

Default Only with Caller ID

m8942

Press any of 1 to 4

Display all ：Displays all Chaku-moji. Hide all ：Hides Chaku-moji. Only from stored No.：Displays Chaku-moji only from a party registered in the phonebook. Only with Caller ID ：Displays Chaku-moji only from a party with the caller ID.

Making a call by attaching a Chaku-moji message

･Up to 10 messages can be recorded in t he sent message history. When the number of recorded messages

exceeds 10, they are deleted, oldest first.

Enter the phone number z m4

Select Chaku-moji field z Select a Chaku-moji message

■ Canceling Chaku-moji:

■ Creating/editing a message: 2 z Create a Chaku-moji message

･ Follow the procedure from Step 2 in “Creating a Chaku-moji message”.

☛P54

■ Selecting a registered message: 3 z Select a Chaku-moji message

■ Selecting from the sent message history: 4 z Select a Chaku-moji

message

Making/Receiving Calls

Chaku-moji

m z Select Yes

･When the Chaku-moji is received by the other party’s terminal, Transmission completed is displayed and

transmission fee is charged.

･When the Chaku-moji is sent to an incompatible terminal or is not received due to Message Display

Setting of the other party’s terminal, Transmission failed is displayed and transmission fee is not charged.

INFORMATION

● PushTalk does not support Chaku-moji.

● If the receiver is in one of the following cases, the sent Chaku-moji is not received and the call is not recorded in the

received call history of the receiver’s terminal. In addition, the transmission result is not displayed on the sender’s screen. In this case, transmission fee is not charged.

･ Outside the service area or the terminal is turned off ･ In Public mode (Driving mode) ･ When the response time of Answer Machine is set to 0 second, etc.

● Even when Chaku-moji is received, the transmission result may not be displayed on the sender’s screen depending on

radio wave conditions. In this case, the sender is charged for the transmission.

● When a call with Chaku-moji is received within th e delay time set in Mut e Ring Time Setting, the Chaku-moji is displa yed

and the call is registered in the received call history. In this case, the sender is charged for the transmission.

● You cannot send or receive Chaku-moji when using FOMA terminal overseas.

Page 58

Making/Receiving Calls

Redial

Menu 46

Calling back previously called numbers Redial

This function records the calls and PushTalk calls that you made as dialed calls (Redial). When the other party is busy, etc., you can redial by simple op eration.

･Up to 30 calls are recorded. When the number exceeds 30 , the oldest one is deleted chronologically.

r z Highlight a party in the redial list

Phone number, name*1 or group name*2 is displayed.

：Call with caller ID set to show in Call Option ：Call with caller ID set to hide in Call Option

Image* Date and time of dialing to the highlighted party PushTalk type or name of the multi-number selected in Call Option* PushTalk type

：PushTalk call (one party) ：PushTalk call (more than one party) ：PushTalk call using PushTalkPlus (one party) ☛P96 ：PushTalk call using PushTalkPlus (more than one party) ☛P96

Phone number

：Videophone call ：PushTalk call No icon: Voice call

*1 When the phone number is registered in the phonebook (while not in Secret Mode, the phone number is

displayed if it is registered in a phonebook entry with Secret Attribute) *2 When a PushTalk call was made to a group (the first member’s name for a PushTalk call to multiple parties) *3 When the image is registered in the phonebook (the first member’s image for a PushTalk call to multiple parties) *4 When you subscribe to the Multi Number service (the name of the basic number or additional number used when

you dialed)

：International call

･ To switch between the redial/received call lists: p ･ To display the list of PushTalk call parties: Highlight a PushTalk redial z o ･ You can also perform the following operations such as phonebook registration from the list of PushTalk

call parties.

■ Registering an entry in the phonebook:

a Highlight a redial z m1

･To add to an existing phonebook entry: m2 ･For a PushTalk call to multiple parties, select the party.

b 1 or 2 z Register the name or address ☛P107, P110

･To add to an existing phonebook entry: 1 or 2 z Select the party z Edit the data ☛P118

■ Registering an entry in the PushTalk phonebook: Highlight a redial z m3 z Select Yes

･ The party cannot be registered if not regi stered in the FOMA terminal phonebook.

･ For a PushTalk call to multiple parties, press m3, select the party, press p and then select Yes.

■ Registering entries in a group in the PushTalk phonebook:

When you made a PushTalk call to multiple parties who are registered in the PushTalk phonebook, you

can register these parties as a PushTalk group from the redial data.

a Highlight a redial z m4

b Enter a group name z p

■ Composing SMS: Highlight a redial z a (for over a second)

The SMS composition screen with the redial phone number specified as the address is displayed.

･ If the redial phone number is saved in the phonebook together with mail addresses, pressing a

displays the i-mode Mail composition screen with the first mail addre ss specified as the address. If not, the i-mode Mail composition screen is displayed with the redial phone number specified as the address.

･ For PushTalk redial, the above applies when there is only one party.

Page 59

Press n (for voice call) or t (for videophone call)

･To make a PushTalk call: g ･To make a call with the same call type as the highlighted redial: o

・For a 32K videophone call, the call is made at 64K when redialing.

INFORMATION

● You can make calls by setting conditions. ☛P58

● When you switch between a voice call and videophone call during a call, the call type (voice call/videophone call) that

was specified when you dialed will be recorded in the redial data.

● When the date and time have not been set, the date and time are not recorded in the redial data.

● When voice/videophone calls are made to the same number, only the most recent call is recorded for each caller ID

preference: show, hide or no setting. When a PushTalk call is made to the same number, the call is recorded as a separate record.

● Selecting a multi-number registered for Multi Number ☛P397

Deleting redials Delete Redial

Highlight a redial z m61

･To delete all: m62 ･You can also perform the same operation from the list of PushTalk call parties.

Select Yes

Setting whether to send your phone number for each call 186/184 Call

Making/Receiving Calls

186/184 Call

Set whether to make your phone number (caller ID) to be displayed on the other party’s phone when you make a call.

･The caller ID is your important information. Carefully consider whether to send your caller ID. ･The caller ID is displayed only when the other party’s pho ne can display caller ID.

Making calls by adding “186”/“184” to the phone numbers

Prefix a specific number to the beginning of the phone number when you make a call.

■ Showing your caller ID: 186 z Enter the phone number z n (for voice call) or t

(for videophone call)

■ Hiding your caller ID: 184 z Enter the phone number z n (for voice call) or t

(for videophone call)

INFORMATION

● If a guidance requesting your caller ID is heard when you make a call, call again by adding “186”.

● For international calls, the caller ID may not be notified depending on the phone company that handles a call even if

“186” is added.

● When making a call by adding “186”/“184” to the other party’s phone number, the phone number with “186”/“184” added

is recorded in the redial data.

● Caller ID notification priority ☛P48

Page 60

Making/Receiving Calls

Call Option

Making calls by setting the conditions Call Option

This function allows you to create or select Chaku-moji, se le ct a multi-number, select the call type, show/hide your caller ID, and append a prefix or international code for each voice/videophone call.

･When calling to a PushTalk group, you can set only the call type and whether to show/hide your caller ID.

Enter the phone number z m4

■ Making an international call: Enter the country code z phone number z m4

･ For international calls, dial without 0 when the area code begins with 0 (when calling to a general

subscriber phone and other phones in Italy, you need to dial 0).

Select each item to set the dialing conditions

Chaku-moji：Create or select the Chaku-moji message to be sent to the other party. ☛P55 Multi-No ：Select the number to be notified to the other party from the basic number or additional

Call type ：Select from Voice call, 64K V.phone, 32K V.phone or PushTalk.

Caller ID ：Set to show/hide caller ID.

Prefix ：Select the number (prefix) to be appended before the phone number.

International Call：

m z Select Yes

A call is made by the settings.

･ When you select 64K V.phone or 32K V.phone in Call type, press t and select Yes to select Chara-den to

be displayed during a videophone call.

numbers. ☛P397

･When PushTalk is selected, only Caller ID can be set. ･Caller ID notification priority ☛P48, Caller ID notification priority for PushTalk ☛ P103 ･Prefix ☛P60

Select the name of international code.

･Int’l Dial Setting ☛P59

INFORMATION

● In the redial list, received call list, recorded message list, voice memo list, details screen of Own Number, member list/

group list of the PushTalk phonebook, or member list for schedule, press m and select Call option.

● In the FOMA terminal phonebook list/details screen or the UIM phonebook list/details screen, highlight a phone number,

press m and select Mail/Call option → Call option.

● For international calls, the caller ID may not be notified depending on the phone company that handles a call even when

Notify is selected for Caller ID.

Using international calls WORLD CALL

DoCoMo international call service “WORLD CALL”

･The international call service “WORLD CALL” is available for DoCoMo mobile phones. ･How to call

009130 z 010 z Enter the country code z area code z phone number z n

･ The above phone number can be registered in the FOMA terminal phonebook. ･ When the area code begins with “0”, dial without “0” (when calling to a general subscriber phone and

other phones in Italy, you need to dial “0”).

Page 61

･You can call to approximately 220 countries and regions around the world. ･WORLD CALL charges are added to the FOMA service charges every month. ･No subscription charges or monthly fee is required.

・You were subscribed to “WORLD CALL” as one of standard services at the time of subscription to the

FOMA service (unless you request not to subscribe to it).

･Changes in international call dialing procedure

MY LINE service is not applicable to mobile phone communications, including WORLD CALL service. However, along with the introduction of MY L INE service, t he dialing p rocedure for internat ional calls using a mobile phone was changed. Consequently, the previous dialing procedure (without prefi x “010”) no longer be used.

･Contact “General Inquiries” on the back of this manual for details.

・To use international call services other than the DoCoMo service, contact each carrier for details.

･This service cannot be used with some billing plans.

“International videophone” calls to parties using specific overseas 3G mobile phone terminals can be made by dialing as described above and placing a call in the videophone mode.

･For the countries and overseas carriers you can connect to, visit the DoCoMo website. ･The image of the other party displayed on FOMA terminal may be distorted or connection may not be established

depending on the terminal at the other end of the international videophone line.

Using “WORLD CALL” by simplified dialing Int’l Dial Setting

When the auto assist setting is set to Auto assist ON in this sett ing, entering “+” when you make an international call automatically adds the preset internat ional code t o the phone n umber. This all ows you to make internatio nal calls easily.

･If you dial by prefixing “+” to the country code of Japan “81”, the international code is not added.

Setting the auto assist setting

Default Auto assist ON

Making/Receiving Calls

WORLD CALL

m86731

Press 1

･To cancel the setting: 2

Registering an international code

･Up to 3 international codes can be registered.

Default Name: World Call Prefix: 009130010

m86732

Highlight <Not recorded> z m2

Enter a name (up to 16 one-byte or 8 two-byte characters) z Enter a code (up to 10

digits) z p

Press p

Page 62

Making/Receiving Calls

Sub Address

Setting the international code

Select the international code that will be added automatically when “+” is entered.

m86732

■ Confirming the registered information: Highlight an item z m1

■ Editing: Highlight an item z m2 z Edit the data

･ You can also edit by pressing p on the confirmation screen of registered inf ormation. Follow the

procedure from Step 3 in “Registering an international code”. ☛P59

■ Deleting: Highlight an item z m3 z Select Yes

･ You cannot delete the international code that is automatically added.

Select an item

Press p

Making a call easily by using Int’l Dial Setting

0 (for over a second) z Enter the country code z phone number z n z Select

Yes

Setting numbers other than “WORLD CALL” Prefix

By registering the number (prefix) to add to the beginn ing of the pho ne number in advance , you can add a prefix after entering the phone number to make an international call easily.

･The default setting is “009130010” for DoCoMo’s international calls.

Default 009130010

m8672

Select Prefix1 to 3 field z Enter a number

･ Up to 3 numbers in total and up to 10 digits for each number can be entered. ･ Do not include a pause or timed pause in the number (prefix). If you set a prefix containing a pause or

timed pause, you cannot add the prefix when making a call.

･ “009130010” can be changed.

Press p

Making a call by specifying a sub-address Sub Address

Specify a sub-address to call a specific phone or communication device.

･This setting is also used to select the contents in a video delivery service, “V-Live”.

Page 63

Enabling use of a sub address

Default ON

m8674

Press 1

･To cancel the setting: 2

Making a call by specifying a sub-address

Enter the phone number z ( z Enter the sub-address

Press n (for voice call) or t (for videophone call)

･The sub-address needs to be set on the other party’s phone or communication device.

INFORMATION

● Even when Sub Address is ON, if “ ” is entered after entering a pause, timed pause or “#”, it is not recognized as a

sub-address delimiter and sent as tone signals (DTMF) containing “ ”.

Making/Receiving Calls

Reconnect Alarm

Setting the alarm indicating reconnection of interrupted call

Set an alarm that is heard at the time of reconnecting a voice call, videophone call or PushTalk call interrupted due to poor sign al cond itions i n a tu nnel or behind a build ing wh en sign al co ndition s improv e.

･The other party hears no sound while signals are disrupted. ･The time until the call is reconnected depends on line use or signal conditions. (The approximate time is a

maximum of 10 seconds.)

･Note that the call is charged for the time until the call is reconnected (up to 10 seconds). ･The call may be cut off before the alarm sounds depending on line use or signal conditions.

Default High alarm

m81164 z Press any of 1 to 3

Reconnect Alarm

Suppressing ambient noises to improve the call quality Noise Reduction

By suppressing ambient noises during a call, the other party can hear your voice clearly and you can also hear the other party’s vo ice clearly.

･It is recommended that this function usually be set to ON.

Default ON

m8681

Press 1

･To cancel the setting: 2

Page 64

Making/Receiving Calls

In-car Handsfree

Talking without using hands in a car In-car Handsfree

You can make and receive voice calls from a handsfree compatible device by connecting FOMA terminal via USB to such device as the In-Car Hands-Free Kit 01 (optional) or car navigation system.

･For operations of handsf ree devices, re fer to th e instructio n manual for each handsf ree device. Note that th e

FOMA In-Car Hands-Free Cable 01 (optional) is required to use the In-Car Hands-Free Kit 01 (optional).

INFORMATION

● The display and ring tone for incoming calls follow the FOMA terminal settings.

● If the setting is made to play sounds from a handsfree device, the ring tone sounds from a handsfree device regardless

of whether Silent Mode is on or of the ring tone settings on FOMA terminal.

● The operation during incoming calls in Public mode (Driving mode) follows the Public mode (Driving mode) settings.

● If a videophone call is made with a handsfree device using the phonebook or redial data, the communication speed set

by the handsfree device is used. If it is not set, the videophone call is made at fixed 64K.

● When a videophone call is made/received with a handsfree device, a substitute image is sent to the other party.

● The operation during incoming calls when Answer Machine is set follows the Answer Machine settings.

● If the setting is made to play sounds from FOMA terminal, the operation when FOMA terminal is closed during a call

follows Close Setting. If the setting is made to play sounds from a handsfree device, the call continues even if FOMA terminal is closed, regardless of Close Setting.

Receiving calls

The operations common to voice call s and videophone calls are explaine d here.

･For voice calls, calls can also be answered by pre ssing 0 to 9, (, o r # other than n (Any Key

Answer). ☛P65

A call is received

The ring tone sounds, the display light turns on and the Enter key lights/flashes.

･ To put the call on hold (Response and Hold): f

Press f when you finish the call

･ To end the call by closing FOMA terminal, change the setting in Close Setting .

You can talk. The call duration is displayed.

･ To put the call on hold (On-hold): o ･ To turn on the speakerphone function: a or n ･ You can also answer the call by opening FOMA terminal. ☛P65

Page 65

Display information

The caller’s phone number, name, image and/or video/i-mo tion wil l b e di splayed on th e screen a ccording to t he dialing condition of the caller and the FOMA terminal settings. You can set FOMA terminal not to display the name or phone number. ☛P144

■ When the caller has notified caller ID

If the caller’s phone number is not registered in your phonebook, the phone number is displayed. Also, the image set in Call Alert or Videophone Alert is displayed.

If the caller’s phone number is already registered in your phonebook, the name and phone number are displayed. When Contact Image is set to ON, the image or video/i-motion set in the phonebook is also displayed. ☛P143

■ When the caller has not notified caller ID

The reason why no caller ID is sent is displayed.

Reason for no

caller ID

User unset The caller selected not to send the caller ID. Payphone The call was made from a payphone, etc. Not supported The call was made from a party who cannot send caller ID, such

as a call from overseas or from a general subscriber phone via forwarding service (however, caller ID may be displayed depending on the phone company that handles a call).

Description

Making/Receiving Calls

Receiving calls

When a voice call arrives, the incoming operation or image set in Anonymous Caller is prioritized. When a videophone call comes in, the incoming image set in Videophone Alert is prioritized.

■ When a call with Chaku-moji is received

Chaku-moji is displayed, according to Message Display Setting. When you answer the call, the Chaku-moji is cleared.

･ Received Chaku-moji is registered in the received call history.

Page 66

Making/Receiving Calls

Operations available from the submenu while receiving a voice call

When you set Arrival call act to Answer, the same operations ar e ava ilable from the submenu when there is another incoming voice call during a call.

Submenu item Description

aCall Rejection bVoice Mail cCall Forwarding

* 1 Valid when you use Voice Mail Service. * 2 Valid when you use Call Forwarding Service and have set a forwarding phone number.

Disconnects the call (the caller does not pay for the call). Connects the incoming call to the Voice Mail Service Center. Forwards the incoming call to the forwarding phone number.

･C (for over a second): Answer by Answer Machine (Quick Record Message)

Receiving a call by switching from a voice call to a videophone call

･C: Stop the r in g al e r t/vibrator ･% : Adjust the ring volume

When you hear beeps (call waiting ring tone) during a voice call

If you subscribe to Voice Mail, Call Waiting or Call Forwarding Service, you will hear beeps (call waiting ring tone) when you receive another incoming call while talking and the following operations can be performed:

Service Operation Page

Voice Mail Service Call Waiting Service Puts the current call on hold and answers the second call. P393 Call Forwarding Service

*1 This service can be operated from the submenu when you set Arrival call act to Answer and activate it in Se t arrival act.

Connects the second call to the Voice Mail Service Center. P392

Forwards the second call to the forwarding phone number. P394

･If you do not subscribe to Call Waiting Service, you cannot answer the call even if you hear beeps.

INFORMATION

● When a call forwarded from FOMA terminal arrives, the phone number from which it was forwarded is displayed if it is

not registered in the phonebook. If it is registered, the name is displayed. However, the phone number or name may not be displayed depending on the forwarding source.

● Even if video/i-motion is set as the incoming image in the phonebook or in Call Alert, it is not played and the first frame

of the video/i-motion is displayed when there is an incoming voice call during a voice call.

● When you receive an international call, a plus sign (+) appears at the beginning of the caller ID.

● For calls received from callers not registered in the phonebook , you can reject calls, or se t the ring tone or vibrator r inger

action not to start immediately. ☛P168, P167

● Call rejection can be set for some parties registered in the phonebook. ☛P165

Receiving a call by switching from a voice call to a videophone call

･The switching operation can be performed only from the terminal which made the voice call. It cannot be

performed from the terminal which received the voice call.

･To receive the request of switching to a videophone call, set Indica tion ON of Notify Switch able Mode. ☛P93

Page 67

Receive the request of switching to a videophone call during a voice call

･A guidance informing that the call is being switche d

is played during switching.

Making/Receiving Calls

Select Yes

The call is switched to a videophone call and your self image is sent to the other party.

･To send the substitute image: Select No ･When you select Yes, your self image is sent for t he first time.

Enabling use of dial keys to answer a call Any Key Answer

Allows you to answer a call by pressing 0 to 9, (, or # other than n.

･This function is available for voice calls and PushTalk calls. However, it is unavailab le when re ce ivi ng a call

while talking.

Default ON

m864

Press 1

･To cancel the setting: 2

Setting to start talking by opening FOMA terminal Open Answer

･This function is available only for voice calls (available even while Key Lock is on).

Default OFF

m8675

Press 1

･To cancel the setting: 2

Any Key Answer

Disconnecting/continuing/holding a call by closing FOMA terminal Close Setting

･This function does not operate during 64K data communication or packet communication. ･You can end a PushTalk call by closing FOMA terminal. Use PushTalk Close Setting to set it.

Default Continue

m8682

Page 68

Press any of 1 to 3

Making/Receiving Calls

End the call：Ends the call. Continue ：Continues the call. On hold ：Puts the call on hold. The other party hears a guidance (on-hold tone).

INFORMATION

● When On hold is set, the operations are as follows:

･If you close FOMA terminal during a videophone call while sending a still image or your image with frame on it, the still

image or frame will be canceled after the hold is released.

･If you close FOMA terminal while sending tone signals (DTMF), the call is continued. ･If you close FOMA terminal while switching between a voice call and videophone call, the call is continued.

● When you close FOMA terminal during a call using a flat type earphone/microphone set with switch (optional) or other

Received Calls

handsfree devices (available in market), the call continues regardless of this function’s setting if the settings is made to play sounds from the connected device. Even if you remove the flat type earphone/microphone set with swit ch (optional) or handsfree device in this state, the call will continue.

● When you close FOMA terminal while recording a message, the recording is continued regardless of this setting.

● This setting applies when you close FOMA terminal while recording a talking voice memo/movie memo. When On hold

is set, the contents which were being recorded by just before putting on hold are saved.

Using Received Calls Received Calls

The calls and PushTalk calls that you received, and unanswered calls (missed calls) are recorded in memory. Recorded messages are also inc luded in the list.

･Up to 30 calls are recorded. When the number exceeds 30 , the oldest one is deleted chronologically.

Menu 45

Example

Making a call from the received call history

l z Highlight a received call in the list

Phone number, name*1 or reason for no caller ID (☛P63) is displayed.

Image* Date and time of receiving from the highlighted party (and the ringing time for missed calls)

PushTalk type or name of the multi-number used*

: PushTalk call (one party) : PushTalk call (more than one party) : PushTalk call using PushTalkPlus (one party) ☛P96 : PushTalk call using PushTalkPlus (more than one party) ☛P96

Phone number or reason for no ca ller ID Chaku-moji

: Videophone call : PushTalk call : 64K data communication No icon: Voice call : International call

Received call status (with Chaku-moji/without Chaku-moji)

/No icon: Answered / : Missed cal l (checked) / : Missed call (unchecked)

/ : Recorded message / : Recorded message (deleted)

*1 When the phone number is registered in the phonebook *2 When the image is registered in the phonebook (the first member’s image for a PushTalk call to multiple parties) *3 When you subscribe to the Multi Number service (the name of the basic number or additional number used by

the received call)

･ To switch between the received call/redial lists: p ･ To display the list of PushTalk call parties: Highlight a received PushTalk call z o ･ You can also perform the following operations such as phonebook registration from the list of PushTalk

call parties.

Page 69

■ Registering an entry in the phonebook:

a Highlight a received call z m1

･ To add to an existing phonebook entry: m2 ･ For a PushTalk call to multiple parties, select the party.

b 1 or 2 z Register the name or address ☛ P107, P110

･ To add to an existing phonebook entry: 1 or 2 z Select the party z Edit the data ☛P118

■ Registering an entry in the PushTalk phonebook: Highlight a received call z m3 z Select Yes

･ The party cannot be registered if not registered in the FOMA terminal phonebook. ･ For a PushTalk call to multiple parties, press m3, select the party, press p and then select Yes.

■ Registering entries in a group in the PushTalk phonebook:

When you received a PushTalk call made to multiple parties who are registered in the PushTalk phonebook, you can register these parties as a PushTalk group from the received call history.

a Highlight a received call z m4 b Enter a group name z p

■ Composing SMS: Highlight a received call z a (for over a second)

The SMS composition screen with the phone number of the received call specified as the address appears.

･ If the phone number of the received call is registered in the phonebook t ogether with mail addresses,

pressing a displays the i-mode Mail composition screen with the first mail address specified as the address. If not, i-mode Mail mail composition screen is displayed with the phone number of the received call specified as the address.

･ For received PushTalk call, the above applies when there is only one party.

Press n (for voice call) or t (for videophone call)

･To make a call with the same call type as the highlighted received call: o ･To make a PushTalk call: g ･When you make a call from the received call with Chaku-moji, the Chaku-moji is not attached.

Making/Receiving Calls

Received Calls

Unanswered calls including PushTalk calls (missed calls)

(with the number of missed calls) is indicated and the call is recorded in the received call history. ☛P37

･When there is a missed call from an unkno wn phone number, the ringing time enables you t o check whether

the call is a malicious call (One-Ring Call, etc.) made for the sole purpose of leaving the phone number in the received call history.

INFORMATION

● Press m71 in the received call list to display all the calls including the missed calls of which ringing times are

shorter than the delay time set in Mute Ring Time Setting. To hide such short ringing calls, press m72.

● You can make calls by setting conditions. ☛P58

● If only missed calls of which ringing times are shorter than the delay time set in Mute Ring Time Setting are recorded as

received calls, pressing l on the standby display displays a confirmation screen asking whether to display missed calls. When Yes is selected, such short ringing calls are displayed.

● When the date and time have not been set, the date and time are not recorded in the received call history.

● Calls received from callers using dial-in services in such as office may display different numbers from the caller’s dial-in

number.

● When you switch between voice call and videophone call during a call, the call type (voice call/videophone call) that was

specified when you received it will be recorded in the received call history.

● When Keypad Dial Lock or PIM Lock is set, the numbers stored in the received call history up to that point are deleted.

However, the calls received after that are recorded in the received call history, and a call can be made using the received call history during PIM Lock.

● Selecting a multi-number registered for Multi Number ☛P397

Page 70

Making/Receiving Calls

Listen Volume

Deleting received calls Delete Received Calls

Highlight a received call z m61

･ To delete all: m62 ･ You can also perform the same operation from the list of PushTalk call parties.

Select Yes

Adjusting the volume of the other party’s voice during a call Listen Volume

The volume of the other party’s voice can be adjusted from level 1 (lowest volume) to level 6 (highest volume).

･The volume changed while talking is retained even after the call is ended. ･The set volume is retained even if the power is turned off.

Default Level 4

% during a call z O to adjust the volume

The volume is set automatically by pressing o or waiting for a while after you stop key operations.

･ To turn up the volume: u or r ･ To turn down the volume: d or l ･ To adjust the volume during a videophone call: m0 z O to adjust the volume

INFORMATION

● How to adjust the earpiece volume in standby, and the sounds to which the earpiece volume applies ☛P69

Adjusting the volume of ring alerts and other sounds emitted from FOMA terminal

Adjust the volume of call, mail an d Mes sage R /F ri ng al er ts; al arm cl ock; sc hedu le al arm; i-αppli sound; and the sound that plays when receiving ToruCa.

･The volume can be adjusted in 7 levels, from silent to level 1 to level 6 (the volume of Movie ringtone can

also be adjusted in 7 levels). You can also set STEPTONE (the volume changes into silent → level 1→ level 6 about every 3 seconds) in standby.

Adjust Volume

Adjusting the volume of call ring alerts while receiving a call

･The ring volume changed while receiving a call is reset to the original volume when the call is ended.

% while receiving a call z O to adjust the volume

The volume is set automatically by pressing o or waiting for a while after you stop key operations.

･ To turn up the volume: u or r ･ To turn down the volume: d or l

...

→

Page 71

INFORMATION

● To stop the ring alert and vibrator: C while receiving a call

● If STEPTONE is set for the call alert volume, the volume will be changed from level 6 when you adjust it while receiving

a call.

Adjusting the volume of ring alerts and other sounds in standby

･Listen volume cannot be set to silent. ･Listen volume, i- ･The ring volume changed while in standby is retained even if the power is turned off.

Default Level 4 (all)

m812

1 to 3, 5 or 6

■ Adjusting the volume of alarm clock: 41

■ Adjusting the volume of schedule alarm: 42

Call alert volume ：Adjusts the ring volume for voice calls, videophone calls and PushTalk calls.

Mail/Msg alert vol.：Adjusts the ring volume for mails, chat mails and Message R/Fs. Listen volume ：Adjusts the earpiece volume during a voice call, videophone call and PushTalk call.

Alarm clock sound：Adjusts the volume of the alarm clock that will be used when the volume is set to

Schedule reminder：Adjusts the volume of the schedule alarm (including alarm and alarm in advance).

iToruCa receive alert：Adjusts the volume of the sound that plays when receiving ToruCa. This setting is

ppli effect sound, and ToruCa receive alert cannot be set to STEPTONE.

The set volume also applies to the following sounds: Timer alarm, alarm for Call Cost Limit, sound indicating the battery level, and playback sound of melodies attached to mail

The set volume also applies to the following sounds: Keypad sound, sound of rotating the Speed Selector, and playback sound of voice call messages and voice memos

Terminal setting on the Set sound screen of Alarm Clock.

ppli effect sound ：Adjusts the volume of the effect sound for i-αppli.

reflected to the setting of ToruCa Setting.

Making/Receiving Calls

Adjust Volume

O to adjust the volume z Press o

･To set to STEPTONE: ･To set to silent:

INFORMATION

● is indicated on the standby display when Call alert volume is set to silent. If the vibrator for incoming voice calls is set

at the same time, is indicated.

or r when the volume is level 6

or l when the volume is level 1

Page 72

Making/Receiving Calls

Call Alert/Videophone Alert/PushTalk Alert

Setting for incoming vo ice/v ideop hone /Push Talk calls

･The settings of this function are reflected to the settings of Sound Setting, Vibrator Setting and Light Alert

Setting. The setting of Show image is reflected to the sett ings of In co ming Call an d V ideop hone Receiving of Mail/Call Image.

･For PushTalk Alert, Show image cannot be set.

Default Ring alert: Melody/Vivaldism (Call Alert), Melody/電話・メロディ A(Phone, melody A) (Videophone Alert),

Melody/電話・メロディ B(Phone, melody B) (PushTalk Alert) Show image: Standard image Vibrate alert: OFF Light alert: Flash/Sky (Call Alert), Flash/Lime (Videophone Alert), Flash/Peach (PushTalk Alert)

Example

Setting operations when receiving a voice call

m862

■ Setting operations when receiving a videophone call: m8712

■ Setting operations when receiving a PushTalk call: m8721

Select each item to set

Ring alert ：Sets a ring alert for incoming calls.

･ When OFF is selected, no ring alert emits. ･ When Melody or Movie ringtone is selected, select a melody or video/i-motion file.

Show image：Sets an image displayed for incoming calls.

･ When Select image is selected, select Select image (from List images) to set an image. ･ When i-motion is selected, se lect a video/i-motion file from the folder list. If the folder list is

not displayed, select Select image (from List images). Vibrate alert：Sets the vibration for incoming calls. Light alert ：Sets the lighting pattern and color of the Enter key for incoming calls.

･ Playing and checking a melody or video/i-motion file when selecting ☛P129

Press p

Call Alert/Videophone Alert/PushTalk Alert

INFORMATION

● Setting Created animation for the image displays the first frame.

● When the video/i-motion with sound only (i-motion without image such as singer’s vocals) is set for Ring alert, if Show

image is reset to the video/i-motion with image only or Flash movie, the ring alert sounds by Vivaldism for voice call or by

電話・メロディ

● Some video/i-motion may be unable to be set for the image. Also, the video/i-motion with sound cannot be set.

● Even when you set Sync melody for Vibrate alert or Light alert, the vibrator or lighting may not be activated depending on

the melody.

● For PushTalk Alert, only the video/i-motion with sound only can be set for the ring alert.

Setting the priority screen for incoming calls during a call or packet communication

This function allows you to select the voice call or packet communication screen to be given priority when a packet communication (or voice) call is received during a voice (or packet communication) call.

･The screen change caused by this function does not interrupt the call or packet communicat ion.

Default No Set Up

m8671

A for videophone call.

Priority Comm Mode

Page 73

Press any of 1 to 3

No Set Up：Displays the screen for the latest incoming call/communication without setting the priority. Voice call：Displays the voice call talking screen by priority. Packet ：Displays the incoming packet communication screen by priority.

• When a voice call is received during i-mode packet communication, you can press b and display the Switch Task menu to answer the call.

･When there is incoming packet communication in i-mode, the voice call talking screen is displayed by

priority regardless of this setting.

Screen display

The following screen is displayed depending on the setting for Priority Comm Mode:

Setting

No Set Up Voice call talking screen Incoming voice call screen Voice call Packet Incoming packet communication screen Screen displayed during i-mode communication

*1 The screen displayed for incoming calls depends on the setting for Arrival call act. ☛P396 *2 Packet communication in modes other than i-mode does not include receiving of i-mode Mail, SMS and

Message R/F.

*3 Packet communication in modes other than i-mo de cannot be receiv ed during i-mode c ommunicat ion. ☛P439

When you can/could not answer a call

Incoming packet communication (other than

i-mode) during voice call*

Incoming voice call during packet

communication*

Making/Receiving Calls

Response and Hold

Putting incoming calls on hold when you cannot answer right away

Response and Hold

･Callers are charged for the time spent on hold.

f while receiving a call

Incoming voice

call on hold

Press n when you are ready to answer the call

･For a voice call, you can answer the call also by opening FOMA termin al. ☛P65

Incoming videophone

call on hold

The incoming call is put on hold (Response and Hold). The other party hears the response hold guidance. For videophone calls, the response hold image is displayed on your and the other party’s terminals.

･Press t or n for a videophone call. Press a to send the substitute image (☛P 92) to the other

party.

･If f is pressed or the other party hangs up during Response and Hold, the call is ended.

INFORMATION

● When you use Voice Mail Service or Call Forwarding Service, you can switch to Voice Mail or Call Forwarding by

pressing m and selecting Voice Mail (V-phone answerphone for videophone call) or Call Forwarding while receiving a call.

Page 74

Making/Receiving Calls

ill

Setting the response hold guidance Status Message

You can record your own voice as response hold guidance.

･One guidance of up to about 10 seconds long can be recorded. ･While a voice or videophone call is during Response and Hold, the guid ance set by this function is played.

Default Standard

Example

Status Message

2 3

INFORMATION

● If you delete the recorded guidance, the default guidance is restored.

● If Standard is set, the guidance “I cannot answer the phone right now. Please wait or call back later (in Japanese)” is

played for the other party during Response and Hold.

Setting a recorded guidance

m81161

Select On-hold tone field z 2

･ To reset to the default guidance: 1 z Go to Step 4

Select Record in Edit message field z Speak a response hold guidance after a tone (beep)

Indication of the allowable recording time

Press p

ecording w

･ An end tone (beep) sounds in about 10 seconds

from the start of recording.

･ To stop the recording: o ･ To check the recorded guidance: Select Play ･ Record cannot be selected when a recorded

guidance has already been registered. Select Delete, select Yes and record after deleting the recorded guidance.

start after a message is displayed.

Setting the on-hold tone On-hold Tone

･While a voice or videophone call is during On-hold, the melody set by this function is played.

Default 保留音・ボイス(On-hold tone, voice)

m81162

Press 2 or 3

･ To reset to the default melody: 1 ･ To play a melody: Highlight a melody z p

INFORMATION

● The volume of the on-hold tone cannot be changed.

● The 3D sound compatible melody set as on-hold tone may be heard deteriorated to the other party.

Page 75

Using Public mode (Driving mode) Public mode (Driving mode)

Public mode is an automatic answering service considering etiquette in highly public places. When Public mode is activated and a ca ll is received, a guidance is played and informs the caller that the called party is driving or in an area (train, bus, movie theater, etc.) where use of the phone should be refrained and cannot answer th e call. Then the call is disconnected.

･Public mode can be activated/canceled only in standby (including when

displayed on the screen).

･Even in Public mode you can make calls as normal. ･This function cannot be used during data communication.

Activating Public mode (Driving mode)

Hold down ( for over a second

Public mode is activated and appears. When a call is received, a guidance is played saying “The person you are cal ling is current ly driving or in a n area where cellphone should not be used. Please try again later”.

･When Silent Mode is activated at the same time, Public mode takes precedence.

■ Canceling: ( (for over a second)

■ When Public mode (Driving mode) is activated

No ring tone plays when your FOMA terminal receives a call. appears on the screen and the call is recorded in the received call history. The caller hears a guidance informing that you are driving or in an area where use of the mobile phone should be refrained and the call is then ended.

･An incoming PushTalk call is not answered, and Connection failed. is displayed on the caller’s screen. In

case of the PushTalk call with 3 or more parties, the connected members are notified that you are driving.

■ Operation when receiving calls in Public mode (Driving mode) with network service activated

Service Receiving voice calls Receiving videophone calls

Voice Mail Service

Call Forwarding Service

Call Waiting Service

Nuisance Call Blocking Service

Caller ID Request Service

*1 As of May 2006, the call is disconnected without being connected to the Voice Mail Service Center.

The caller hears the Public mode guida nce and the call is then connected to the Voice Mail Service Center.

The caller hears the Public mode guida nce and the call is then forwarded to the specified destination. Whether the caller hears the guidance or not depends on the setting for Call Forwarding Service. When the guidance is on, the Public mode guidance is played. When the guidance is off, no guidance is played.

The caller hears the Public mode guida nce and the call is then disconnected.

If registered as nuisance call er, the caller hears a guidance indicating that the call cannot be connected and the call is then disconnected.

･The caller who has not notified the caller ID

hears a guidance requesting caller ID and the call is then disconnected.

･The caller who has notified the caller ID

hears the Public mode guidance and the call is then disconnected.

The call is connected to the Voice Mail Service Center without the Public mode video guidance.*

The call is forwarded to the specified destination without the Public mode video guidance. If the destination party uses the phone not compatible with videophone, the call is disconnected.

The caller sees the Public mode video guidance and the call is then disconnected.

If registered as nuisance caller, the caller sees a video guidance indicating that the call cannot be connected and the call is then disconnected.

･ The caller who has not notified the caller ID

･ The caller who has notified the caller ID sees

圏外

(outside service area) is

sees a video guidance requesting caller ID and the call is then disconnected.

the Public mode video guidance and the call is then disconnected.

Making/Receiving Calls

Public mode (Driving mode)

Page 76

INFORMATION

Making/Receiving Calls

● In Public mode, the following sounds are disabled. In addition, the vibrator does not operate or the Enter key does not

light/flash for incoming calls/mails, etc.

･Ring tone ･Alarm clock ･ Schedule alarm ･ Timer alarm ･i-

ppli sound ･ Charge alert ･ Alarm for Call Cost Limit*

･The sound that plays when data is obtained by holding the FeliCa mark over a reader/writer*

*1 Even if Alert for Call Cost Limit is set to ON and an alarm is set, a message is not displayed. *2 When IC card light in Light Alert Setting is set to ON or Light alert in ToruCa Setting is set to ON, the Enter key

flashes.

● Even in Public mode, the following sounds are played:

･Low battery alert

･Keypad sound ･Speed Selector sound ･ Shutter sound ･Lens cover sound ･ Slide sound

● In Public mode, the i-channel information does not scroll on the standby display.

Using Public mode (power off)

● In Public mode, Chaku-moji is not displayed.

● Even if a mail or Message R/F is received, the receiving screen and r eception result screen are not displayed. But, when

Check i-mode Message is performed, these screens are displayed. If a mail or Message R/F is received at this time, the receiving screen is displayed and the reception result is updated when receiving is completed.

● When FOMA terminal is turned off or you are outside the service area, the caller hears a guidance informing out-of-

service area instead of the Public mode guidance.

● Making emergency calls (110, 119 or 118) in Public mode cancels Public mode. However, it is not canceled when

emergency calls are made using videophone.

Using Public mode (power off)

Public mode (power off) is an automatic answering service considering etiquettes in highly public places. When Public mode (power off) is set and then a call is received with FOMA terminal switched off, a guidance is played and informs the caller that the called party is in an area (hospital, airplane, priority seat area on a train, etc) where the phone should be turned off and cannot answer the call. Then the call is disconnected.

Activating Public mode (power off)

(25251 z Press n

Public mode (power off) is set. (There will be no change on the standby display.) When you subsequently turn the power off, Public mode (power off) is activated. In Public mode (power off) if a call is received with FOMA terminal off, a guidance is played saying “The person you are calling is currently in an area where use is prohibited. Please try again later”.

■ Canceling: (25250 z n

■ Checking the setting: (25259 z n

■ When Public mode (power off) is activated

The setting is retained until Public mode (power off) is canceled by dialing “ 25250”. The setting is not canceled by turning the power on. The Public mode (power off) guidance is played even in locations outside the service area or where radio waves are hard to reach. The caller hears a guidance informing that you are in an area where the phone should be turned off and the call is then ended.

･An incoming PushTalk call is not answered, and Connection failed. is displayed on the caller’s screen. In

case of the PushTalk call with 3 or more parties, the connected members are notified that you are not connected.

Page 77

■ Operation when receiving calls in Public mode (power off) with network service activated

Service Receiving voice calls Receiving videophone calls

Voice Mail Service

Call Forwarding Service

Nuisance Call Blocking Service

Caller ID Request Service

*1 As of May 2006, the call is disconnected without being connected to the Voice Mail Service Center.

The caller hears the Public mode (power off) guidance and the call is then connected to the Voice Mail Service Center.

The caller hears the Public mode (power off) guidance and the call is then forwarded to the specified destination. Whether the caller hears the guidance or not depends on the setting for Call Forwarding Service. When the guidance is on, the Public mode guidance is played. When the guidance is off, no guidance is played.

If registered as nuisance caller, the caller hears a guidance indicating that the call cannot be connected and the call is then disconnected.

･

The caller who has not notified the caller ID hears a guidance requesting caller ID and the call is then disconnected.

･

The caller who has notified the c aller ID hears the Public mode (power off) guidance and the call is then disconnected.

The call is connected to the Voice Mail Service Center without the Public mode (power off) video guidance.*

The call is forwarded to the specified de stination without the Public mode (power off) video guidance. If the destination party uses the phone not compatible with videophone, the call is disconnected.

If registered as nuisance caller, the caller sees a video guidance indicating that the call cannot be connected and the call is then disconnected.

･

The caller who has not notified the caller ID sees a video guidance requesting caller ID and the call is then disconnected.

･

The caller who has notified the caller ID sees the Public mode (power off) video guidance and the call is then disconnected.

Making/Receiving Calls

Answer Machine

Allowing the caller to leave message when you cannot answer the c all

Answer Machine

By setting Answer Machine, you can play the greeting message and record the caller’s message when you cannot answer the call.

･Up to 4 messages can be recorded for voice/videophone calls in total, a maximum of about 30 seconds for

each.

･For voice calls, the caller’s voice is recorded. For videophone calls, the caller’s voice and image are

recorded.

･The recording date and time and the phone number are also recorded. However, when the date and time

have not been set or the phone number is not notified, they are not recorded.

･You can set the time interval between the reception of the call and the start of the greeting. ･The greeting in your own voice can be recorded. ･Incoming PushTalk calls cannot be answered by Answer Machine. ･It is advisable that the contents of r ecorded messages be separately written down in a notebook, etc.

Recorded data may be lost due to failure, repair, change of model or other handlings of FOMA terminal. If the data should be erased, DoCoMo assumes no responsibility for the loss of any data.

Menu 4711

Setting Answer Machine

Default Deactivate

Press C11

appears on the standby display.

■ Canceling: C12

Page 78

Making/Receiving Calls

Replying with Quick Record Message

When Answer Machine has not been set to start, you can activate this function only once by holding down C for over a second while receiving a call. This operation does not set Answer Machine to start.

･For incoming PushTalk calls, you cannot activate Quick Record Message.

INFORMATION

● When the number of recorded messages reaches 4, is indicated on the standby display. The icon does not

disappear even if Answer Machine is canceled.

● If there are already 4 recorded messages, Answer Machine cannot be set. If you attempt to activate Quick Record

Message by holding down C for over a second while receiving a call, the warning tone (rapid beeps) sounds and the

Answer Machine

ring tone keeps sounding. Delete unnecessary recorded messages and set again.

Receiving a call while Answer Machine is set

A call is received

After the ring tone sounds according to Greeting Response Time, the greeting message screen is displayed.

･ When the greeting message is set to Preinstalled, the caller hears the guidance “I cannot answer the

phone right now, please leave your name and message after the beep (in Japa nese)”. Set Personalized to play a recorded guidance.

Recording the caller’s message starts

Recording a voice call

message

Indication of the allowable recording time

Recording a videophone

call message

･A beep announces the caller the

start and end of the recording. And when about 25 seconds have elapsed since the start of recording, rapid beeps sound to indicate that the end of recording is approaching.

When the recording is completed, the call is disconnected

(with the number of recorded messages) is indicated.

INFORMATION

● When FOMA terminal is turned off or outside the service area, Answer Machine does not operate. Use Voice Mail

Service (pay service).

● Answer Machine does not operate and the ring tone keeps sounding when 4 messages have already been recorded. If

Voice Mail Service or Call Forwarding Service is activated, each service starts its operation.

● Public mode (Driving mode) takes precedence over Answer Machine. In Public mode (Driving mode), Answer Machine

does not operate.

● The recording may be disrupted or the screen may be distorted if the signal conditions are poor.

● Another call received while playing the greeting or recording a message is rejected and playing or recording continues.

If you are subscribing to Voice Mail Service, Call Forwarding Service or Call Waiting Service, the rejected incoming call is recorded in the received call history.

● You can answer a call even while playing the greeting or recording a message. Press n to answer a voice call. For a

videophone call, press n or t to answer by sending your image or a to answer by sending the substitute image. For a voice call, you can also answer the call by opening FOMA terminal. ☛P65 If the message is being recorded at this time, the contents before answering the call will not be recorded.

Page 79

Menu 4713

Setting the response time until the greeting starts Greeting Response Time

Default 008 Sec.

C13

Enter the response time (0 to 120 seconds)

･To increase or decrease the entered values: %

INFORMATION

● When Auto Answer (with a flat type earphone/microphone set with switch (optional) connected), Voice Mail Service or

Call Forwarding Service and this function are set simultaneously, the priority depends on the ringing times set for each service and function. To give priority to Answer Machine, the response time for this function should be set shorter than the ringing times set for Auto Answer, Voice Mail Service and Call Forwarding Service. Note that Answer Machine may not be given priority depending on the signal conditions. In this case, answer a call with Quick Record Message.

● The delayed time of Auto Answer and the response time of Answer Machine cannot be set to the same time period.

Menu 4714

Setting the greeting message Greeting Message Setting

You can record your own voice as greeting message.

･One greeting of up to about 10 seconds long can be recorded.

Default Preinstalled

Making/Receiving Calls

Answer Machine

Example

1 2

3 4

INFORMATION

● If you delete the recorded greeting, the default greeting is restored.

Setting a recorded greeting

C14

Select Greeting message field z 2

･To reset to the default greeting: 1 z Go to Step 4

Select Record in Edit message field z Speak a greeting message after a tone (beep)

･The operation procedure is the same as when recording the response hold guidance. ☛P72

Press p

Page 80

Making/Receiving Calls

Answer Machine

Playing recorded messages

You can play or delete recorded messages from the list.

･Unplayed recorded messages, if any, can be played quickly from the standby display. ☛P37

Select a recorded message to play

Indication of the playing time

Playing a voice call

message

On the recorded message list screen, the recording date and time and the caller’s phone number appear.

: Voice call message (unplayed) : Videophone call message (unplayed) : Voice call message (played) : Videophone call message (played)

･ If the caller’s phone number is notified, it is displayed. If not, the reason for no

caller ID is displayed. If the notified caller’s phone number is registered in the phonebook, the name is displayed.

･ When you subscribe to the Multi Number service, the name of basi c number or

additional number used by a received call is also displayed.

･ During playback, the following operations are available:

：Adjust volume

% n：Speakerphone on/off (for voice call messages only)

■ Deleting:

a Highlight a recorded message z m21

･ To delete all: m22

b Select Yes

■ Registering an entry in the phonebook:

a Highlight a recorded message z m4

･ To add to an existing phonebook entry: m5

b 1 or 2 z Register the name or address ☛P107, P110

･ To add to an existing phonebook entry: 1 or 2 z Select the party

z Edit the data ☛P118

■ Making a call: Highlight a recorded message z n (for voice call) or

t (for videophone call)

･ You can make calls by setting conditions. ☛P58

：Stop

Menu 472

Select whether to delete the played recorded message

･ To delete the recorded message: Select Yes

Page 81

Making/Receiving Videophone Calls

Videophone ....................................................................................................... 80

Making videophone calls .................................................................................80

Receiving videophone calls .............................................................................83

Using Chara-den ...............................................................................................85

Setting images to be sent to the other party ..................................................86

Customizing the display settings during a videophone call ........................90

Changing the videophone settings ........................... Videophone Settings 90

Setting of switching between a voice call and videophone call

.................................................................................. Notify Switchable Mode 93

Setting how incoming videophone calls are handled during i-mode

................................................................................. Data Session Arrival Act 93

Using the videophone by connecting with an external device

................................................................................................ External Device 94

Page 82

Making/Receiving Videophone Calls

Videophone

The videophone function is available between terminals that support DoCoMo’s videophone. By using the videophone, you can talk on the phone while looking ea ch other imag es. It is also possible to display a still image, substitute image, Chara-den, etc. instead of your self image.

DoCoMo videophone specifications are compliant with “3G-324M*1 that has been standardized by the international standard 3GPP*

*1 3G-324M…An international standard for the 3rd generation mob ile videophone *2 3GPP (3rd Generation Partnership Project)…Area standardizat i on organization established to develop the

standard technology specification for the 3rd generation mobile communications systems (IMT-2000).

･ The following 2 communication speeds are provided for the videophone:

・64K: Connects at communication speed of 64 kbps. ・32K: Connects at communication speed of 32 kbps.

Videophone

Screen display during a videophone call

”. Note that the connection with videophones of different specifications cannot be established.

Main screen Image of the other party is displayed by default.

Communication

speed Speakerphone

function Sub screen Your image is displayed by default.

Zoom to : Normal to 2x (in-camera)

Status : Sending your self image

Action mode : Action : Action of parts Scene mode/

effect Compact light No icon: Turn light off : Turn light on

Quality of

outgoing image Sound/image

sending and receiving status

Macro mode No icon: Off : On (out-camera)

k l Videophone/voice

call switching

m Call duration Displayed in the HH:MM:SS format

: 64K : 32K

: On No icon: Off

to : Normal to 16x (out-camera)

: Sending the camera-off image : Sending Chara-den : Sending a frame : Sending a still image : On-hold : On Response and Hold : Recording a message : Recording a movie memo

: Full auto, etc.

The icons for other modes/effects ☛P87

No icon: Normal : Prefer image quality

: Prefer motion speed : Sending and receiving sound : Sending and receiving image

: Sending and receiving sound/image

No icon: Switching is not available. : Switching is available.

Making videophone calls

･International videophone calls are available by using the DoCoMo’s international call service “WORLD

CALL”. ☛P58

Enter the phone number

･ Entering method is the same as for voice calls.

Page 83

Your image is displayed while being connected.

･If the phone of the other party is busy, you will hear a busy signal. The

message, Busy. or Connection failed. is displayed on the screen. Press f to end the call and call again later. You can call back quickly by using Redial.

･Pressing t while being connected sends the substitute image set in Image

Setting. When the substitute image is set to Chara-den, Chara-den may not be displayed. If this happens, the default image for the substitute image setting is sent to the other party. ☛P92

･Charging begins when Connected to videophone. is displayed.

Talk with the other party

The other party’s voice comes out of the speaker (Speakerphone function).

･To put the call on hold: o ･To turn on/off the speakerphone function: a or n ･Depending on the other party’s settings, the substitute image may be

displayed.

･To disable turning on the speakerphone function automatically, change the

setting in Videophone Settings.

Press f when you finish the call

･To end the videophone call by closing FOMA terminal, change the setting in Cl ose Setting.

INFORMATION

● You can also make a videophone call by performing in order of Steps 2, Step 1. When t is pressed and the phone

number is entered, a videophone call is made automatically after about 5 seconds.

● You can make videophone calls by attaching Chaku-moji. ☛P55

● You can make videophone calls by setting conditions. ☛P58

● When Speakerphone is set to ON in Videophone Settings and Silent Mode is active, if you make a videophone call, a

confirmation screen appears asking whether to switch to the speakerphone call. Select Yes or No.

● If a videophone call cannot be made, one of the following message is displayed on the screen and then the standby

display returns. Note that the displayed message may not reflect the status of the other party’s terminal correctly, depending on the type of the terminal and/or the network service used by the other party.

Message Description

Check number, then redial. You dialed the phone number not used. Busy. The other party is busy.* Out of service area/power off. The other party is outside the service area or the other party’s terminal is turned off. Set Caller ID to ON. This message is displayed in case connecting without notifying the caller ID (when

accessing to V-Live or visualnet).

Redial using voice call. This message is displayed when the other party sets Call Forwarding Service and the

forwarding destination is the terminal which is not compatible with videophone.*

Busy with packet transmission. The other party is in packet communication. Connection failed. Set Caller ID Notification to Notify and dial again.

･ The message may appear in cases other than the above.

*1 The message may also appear when the other party is in packet communication, depending on his/her terminal. *2 As of May 2006, the message may also appear when the other party has activated Voice Mail Service.

Making/Receiving Videophone Calls

Making videophone calls

Page 84

Making/Receiving Videophone Calls

● If a videophone call made is not connected, redialing is automatically performed as described below:

Call type 64K ON 64K → 32K → Voice call

32K ON 32K → Voice call

● When there is an incoming call while dialing a videophone call or redialing, the dialing may be interrupted and the ring

tone may sound.

● Even if sending/receiving the voice or image is aborted and (voice only) or (image only) is displayed during

a videophone call, the call may be continued as it is.

● When you talk on a videophone call while a flat type earphone/microphone set with switch (optional) is connected, the

voice sounds from the connected earphone/microphone regardless of the setting of Speakerphone in Videophone

Making videophone calls

Settings.

● Please note that digital communication charges apply for videophone calls instead of voice call charges even if the

substitute image or Chara-den is used.

● Videophone at 32K is intended for connection with devices such as PHS with which videophone calls at 64K may not be

available depending on the network condition. When a videophone call is made at 64K, the call type is automatically switched to 32K when redialing if the communication environment of the other party is found to be 32K area. When ON is set for Auto redial as voice in Videophone Settings, redialing at 32K is also given priority. ☛P90

Auto redial as

voice setting

OFF 64K → 32K → Disconnection

OFF 32K → Disconnection

Redialing operation

When a videophone call is made by specifying a multinumber, redialing will be made with the specified number. When a videophone call with Chaku-moji is made, redialing will be made with the same Chaku-moji attached. If redialing as voice call occurs, voice call charges ap ply.

･Even if a call is made at 32K, the charge is the same as digital communication charges at 64K.

● If a videophone call is made to emergency calls (110, 119 or 118) from FOMA terminal while Auto redial as voice is set to

ON in Videophone Settings, the call automatically switches to a voice call.

Switching from a videophone call to a voice call

You can switch to a voice call by operating from the submenu during a videophone call when the other party’s terminal can switch calls. Switching can be performed only from the terminal which made the videophone call.

･This operation can be perf ormed bet ween the te rmina ls that supp ort switchi ng between voice call/videop hone

call.

･To switch to a voice call, the other party needs to set Indication ON of Notify Switchable Mode in advance.

☛P93

m1 during a videophone call z Select Yes

･ A guidance informing that the call is being switched is played during switching. ･ Select No to return to the videophone talking screen.

INFORMATION

● For precautions when switching between a voice call and videophone call, see INFORMATION in “Switching from a

voice call to a videophone call”. ☛P53

● Switching from a voice call to a videophone call ☛P53

Page 85

Transmitting tone signals (DTMF) Send DTMF

You can input tone signals (DTMF) while sending your self image ( ), the camera-off image ( ) or Charaden ( ).

･Tone signals may not be received depending on the receiver’s device.

m9 during a call z Enter with dial keys

The entered number is displayed and the tone signals (DTMF) are transmitted.

･To cancel transmitting tone signals (DTMF): c ･The tone signals (DTMF) are transmitted by pressing dial keys without pressing m9 while your self

image or the camera-off image is being sent.

･When the tone signals (DTMF) are transmitted, the set frame and still image are canceled. ･Because tone signals (DTMF) are transmitted using dial keys, you cannot use dial keys to make actions

while sending Chara-den.

Receiving videophone calls

･You cannot receive a videophone call by pressing the keys other than t, n or a (Any Key Answer is

unavailable).

A call is received

The ring tone sounds, the display light turns on and the Enter key lights/flashes.

･The caller’s phone number, name, i mage or video/i- motion will be displayed on

the screen according to the caller’s dialing condition or your FOMA terminal settings. When a call with Chaku-moji is received, Chaku-mo ji is di splayed. ☛P63

･To put the incoming call on hold: f

Making/Receiving Videophone Calls

Receiving videophone calls

t or n

Your image is displayed while being connected.

■ Receiving a videophone call with the substitute image: a

The substitute image is sent to the ot her party when the videophone call is connected.

･ Even when Chara-den is set as the substitute image, Chara-den may not

be displayed. If this happens, the default image for the substitute image setting is sent to the other party.

Page 86

Making/Receiving Videophone Calls

Talk with the other party

The other party’s voice comes out of the speaker (Speakerphone function).

･ To put the call on hold: o ･ To turn on/off the speakerphone function: a or n ･ Depending on the other party’s settings, the substitute image may be

displayed.

･ To disable turning on the speakerphone function automatically, change the

setting in Videophone Settings.

Press f when you finish the call

Receiving videophone calls

･ To end the videophone call by closing FOMA terminal, change the setting in Close Setting.

Operations available from the submenu while receiving a videophone call

Submenu item Description

Call Rejection Disconnects the call (the caller does not pay for the call).

V-phone answerphone

Call Forwarding*

*1 Valid when you use Voice Mail Service (The service is not available as of May 2006). *2 Valid when you use Call Forwarding Service and the forwarding phone number has been set.

Connects the incoming call to the Voice Mail Service Center. Forwards the incoming call to the forwarding phone number.

･You can operate FOMA terminal with the following keys while receiving a call:

・C (for over a second): Record a message (Quick Record Message) ・C: Stop the ring alert/vibrator ・%: Adju st th e ri ng volum e

INFORMATION

● When Speakerphone is set to ON in Videophone Settings and Silent Mode is active, if you receive a videophone call,

a confirmation screen appears asking whether to switch to the speakerphone call. Select Yes or No.

● When a videophone call arrives while a flat type earphone/microphone set with switch (optional) is connected, the voice

sounds from the connected earphone/microphone regardless of the setting for Speakerphone in Videophone Settings.

● When a videophone call arrives, it is not connected if the forwarding destination is not set to a videophone terminal

compliant with the 3G-324M even if Call Forwarding Service is activated. Check the specifications of the forwarding destination when setting it.

● Changing the operation for incoming videophone calls ☛P70

Page 87

Receiving a call by switching from a videophone call to a voice call

･The switching operation can be performed only from the terminal which made the videophone ca ll. It cannot

be performed from the terminal which received the videophone call.

･To receive the request of switching to a voice call, set Indication ON of Notify Switchable Mode in advance. ☛P93

Receive the request of switching to a voice call during a videophone call

The videophone call is switched to a voice call automatically.

･A guidance informing that the call is being switched is played during switching.

Using Chara-den

A character can be sent instead of your image when making a videophone call. The character can be moved by pressing dial keys during a videophone call. Some characters move their mouth in time with the sounds picked up by the microphone.

m321 during a call

Select a folder z Select Chara-den

©BVIG

Chara-den

Action list scrolls.

INFORMATION

● Some Chara-den has no actions.

･If you press dial keys while sending Chara-den as the substitute image, the

character performs the action correspondin g to the number of the keys. The following operations can also be performed:

0：Cancel action (：Display the action list

･Selecting an action moves the character.

( (for over a second):

Switch action modes (Action/Action of parts)

･The action list of Chara-den set by default ☛P425

Making/Receiving Videophone Calls

Using Chara-den

Page 88

Making/Receiving Videophone Calls

Setting images to be sent to the other party

You can change images and apply sp ecial effects to the image sent to the other party during a videophone call. Also, you can switch between the in-camera and the out-camera.

Switching the outgoing image between your self image and the substitute image

Press t during a call

©BVIG

The substitute image

Setting the quality of outgoing and incoming images

･Setting Prefer motion spd makes motions smoother in a little lower-definition image. ･Setting Prefer img qual makes motions a little slower in a higher-definition image.

Default Normal

･ Each press switches the image between your self imag e ( ) and the

substitute image ( or ). ☛P92

･ Even when Chara-den is set as the substitute image, Chara-de n may not be

displayed. If this happens, the default image for the substitut e image in Image Setting is sent to the other party. ☛P92

Example

Setting the quality of outgoing image

m71 during a call

･ Pressing & during a call also switches the quality of outgoing image.

■ Setting the quality of incoming image: m72 during a call

Press any of 1 to 3

Setting a frame on the outgoing image Frame

The frame can be set while sending your self image.

･Only the frame with the display size of 176 x 144 or smaller can be selected . As for downloaded frames,

only the frame with the display size of 176 x 144 can be selected.

m31 during a call

Page 89

Select a frame

･While the in-camera is used, the mirror image (left-right reversed image) is

displayed on the screen and the normal image (right directed image) is sent to the other party. While the out-camera is used, the same image as disp layed on the screen is sent to the other party.

･To cancel sending the frame: o while sending a frame ･Frames set by default ☛P424

Applying special effects to outgoing image Scene Mode/Effect

You can apply the following effects to outgoing images. These settings can be changed only while sending your self image.

Item Icon Item Icon Item Icon Item Icon

Full auto Night Letter Soft touch Sensitivity up Twilight Color reversal Mono tone (red) Super sensitivity up Surf&Snow Painting Mono tone (green) Adjust backlight Sport Woodcut Mono tone (blue) Spot photometry Pet Whiten Monochrome Scenery Gourmet Suntan Sepia

･For details ☛P187

Default Full auto

m21 during a call

Press any of 1 to 9, 0, ( or #

･Press

to switch the pages.

Making/Receiving Videophone Calls

Setting images to be sent to the other party

The effect currently applied

Adjusting the brightness/color density/flicker of outgoing image Camera Setting

You can adjust the brightness and color density in 5 levels. Also, you may be able to control the flicker of images, if it occurs, by making settings according to the power supply frequency in your area.

･This setting can be changed only while your self image is being sent. ･The brightness and color density may not be changed depending on the setting for Screen Mode/Effect. ･This setting is retained even after the call is finished. ･The flicker adjustment settings for Camera and Bar Code Reader will reflect changes in this setting.

Default Brightness: level 3 Density: level 3 Flicker adjustment: Auto

Page 90

Making/Receiving Videophone Calls

Setting images to be sent to the other party

m2 during a call z Select an item

■ Adjusting brightness and color density:

a 2 z Highlight Brightness slider z & b d to highlight Density slider z & z p

･ Your self image is displayed on the main screen while adjusting. You

can check the change of brightness or color density as you shift the slider’s position.

･ If you do nothing on the terminal for some time after changing the

slider’s position, the settings are not changed and the ta lking screen reappears.

■ Adjusting flicker: 3 z 1 to 3

Sending the still image/camera-off image

Select a still image or the image displayed as Camera off (camera-off image).

･This setting is not available while a frame is being sent. ☛P86 ･Only the still image that is 176 x 144 or smaller and is permitted to be output from FOMA terminal can be

set.

m3 during a call z Select an item

■ Sending the camera-off image: 3

･ When the camera-off image is set, the substitute image set in Image Setting is sent.

However, if Chara-den is set as the substitute image, the default image (camera-off image) is sent.

■ Sending a still image:

a 4 z Select a folder b Select a still image

･ To view a still image: Highlight a still image z p ･ To send the previous image: o while sending a still image

Switching display magnifications Zoom

･Available only while your self image is being sent.

Default normal ( )

Press % during a call

･ Each press of u switches the magnif ication of image as follows. Press d to switch in the reverse

order. In-camera : normal ( ) → 2x ( ) Out-camera: normal ( ) → 2x ( ) → 4x ( ) → 6x ( ) → 8x ( )

→ 10x ( ) → 12x ( ) → 16x ( )

INFORMATION

● Zooming will be canceled if you switch between the in-camera and out-camera.

Page 91

Switching the in-camera and out-camera

･Available only while your self image is being sent.

Default in-camera

Press m6 during a call

The image through the selected camera is sent.

･Each press switches between the in-camera and

out-camera.

･Even if you switch the cameras, the frame and the

brightness/color density/flicker settings of outgoing image are kept.

･Open the lens cover when switching to the out-

camera. If you close the lens cover while using the out-camera, the substitute image is sent to the other

In-camera selected Out-camera selected

party. If you open the lens cover while Open lens cover. is being displayed, your image is sent.

Switching the camera to the macro mode

You can switch to the macro mode and adjust the focus of the image when sending the image of an object about 7 to 11 cm away.

･You can switch the camera to the macro mode only while the out-camera is used.

Default Macro OFF

Press m4 during a call

･To turn off the macro mode: m4

Making/Receiving Videophone Calls

Setting images to be sent to the other party

INFORMATION

● If you switch to the in-camera in the macro mode, the camera returns to the normal mode.

Turning the compact light on

･You can switch the compact light on only while the out-camera is used. ･The compact light may go out temporarily when you perform some setting operations while talking.

Press m5 during a call

The compact light is turned on. If the light has been turned on, it goes out.

･Each press turns the compact light on ( ) and off (no icon).

Page 92

Making/Receiving Videophone Calls

Customizing the display settings during a videophone call

･The settings are retained even after the call is finished.

Switching between the main screen and sub screen

Default Main screen image: other party’s image Sub screen image: your self image

Press p during a call

･ Each press switches the images on the main screen and sub screen by turns.

Main screen: other party’s image Main screen: your self image Sub screen: your self image Sub screen: other party’s image

Customizing the display settings during a videophone call

Changing the main screen size

Default large

Hold down p for over a second during a call

･ Each press switches the screen size in the following order: large → standard → small → large → .

Setting the screen displayed during a call Videophone Settings during a call

Default Display setting: Both sides Sub screen: My side Screen size: Large Display light: Always on(normal)

m8 during a call

Select each item to set

･ For setting each item (Display setting, Sub screen, Screen size and Display light), follow Step 2 in “Changing

the videophone settings”. ☛P91

…

Press p

Changing the videophone settings Videophone Settings

Set the operation to be performed when a videophone call is not connected, the screen displayed during a videophone call, etc.

･The auto redial as voice function is provided to ensure access to the other party. By setting this function to

ON, a dialed videophone call will be automatically redialed as voice call if th e other pa rty’s ter minal does not support the videophone function or cannot rece ive the video phone cal l while using t he mova service through Dual Network Service. Redialing does not occur, however , if you call an ISDN-sync 64 kbps or PIAFS access point, or an ISDN videophone incompatible with 3G-324M (as of May 2006), or if you dial the wrong number. Note that some calls may require the call charge.

Default

Auto redial as voice: OFF Display setting: Both sides Sub screen: My side Screen size : Large Visual preference: Normal Display light: Always on(normal) Speakerphone: ON

m8713

Page 93

Select each item to set

Auto redial as voice：Sets whether to redial as voice call automatically when a videophone call is not connected. Display setting ：Specifies whether to display either your self image or the other party’s image or both

images during a videophone call.

･If you set other than Both sides, Sub screen cannot be set.

Sub screen ：Specifies whether to display your self image or the other party’s image on the sub

Screen size ：Sets the main screen view size. Visual preference ：Sets the quality of outgoing image. Display light ：Sets the display light during a videophone call.

screen during a videophone call.

･When Terminal settings is set, the setting of Display light time (Normal use) in Display

Light Setting (☛P144) applies.

Speakerphone ：Specifies whether to turn on the speakerphone function automatically once a videophone

Press p

call is connected.

INFORMATION

● Even when Auto redial as voice is set to ON, redialing may not be performed depending on the situation of the other party

or the network.

● When Auto redial as voice is set to ON, if you make a videophone call during a packet communication with a PC

connected, the call is redialed as voice call without connecting to a videophone call. During a voice call or 64K data communication, the call is not connected to a videophone call and redialing is not performed, either.

● If redialing as voice call occurs with Auto redial as voice set to ON, voice call charges apply instead of digital

communication charges.

● When Speakerphone is set to ON and Silent Mode is active, if you make a videophone call, a confirmation screen

appears asking whether to switch to the speakerphone call. Select Yes or No.

Making/Receiving Videophone Calls

Videophone Settings

Menu 8234

Setting the images to be displayed during a videophone call Image Setting

Change the images to be sent to the other party during a vi deop hone call su ch as the su bstit ut e image, a nswe r machine image, response hold image, on-hold image and movie memo image.

･You cannot set the following images:

・Still image with a size larger than 176 x 144 ・Animation and Created animation ・Still image in the format other than JPEG and GIF formats ・Image that is prohibited from being output from FOMA terminal

Page 94

Making/Receiving Videophone Calls

Setting the substitute image

Default Default Chara-den

m8715

1 z Select Image field

Chara-den

Videophone Settings

■ Setting other still images:

a 4 z Select Select image (from List images) z Select a folder b Select a still imag e

･To display a still image: Highlight a still image z p ･The selected image with the text message on it is displayed on the other party’s terminal.

Press p

INFORMATION

● If the Chara-den set as the substitute image is deleted, the substitute image is reset to Default Chara-den. If the still

image or the default Chara-den is deleted, the substitute image is reset to Default image.

©BVIG

■ Setting the default Chara-den: 1

Default Chara-den (ブンブン(Dimo)) is set.

■ Setting the default still image: 2

Default image (camera-off image) is set.

■ Setting other Chara-den:

a 3 z Select Select image (from List images) z Select

a folder

b Select Chara-den

･ To display Chara-den: Highlight Chara-den z p

Changing the answer machine/response hold/on-hold/movie memo images

Default Answer machine image, Response hold image, On-hold image, Movie memo image: Default

m8715

2 to 5

Select each item to set

In case of the answer

machine image

Press p

･ When Default is selected, the default image is set. ･ When Select image (from Image) is selected, select Select image (from List

images) to select an image.

･ The selected image with the text mes sage on it is di splayed on the other p arty’s

terminal.

Page 95

Making/Receiving Videophone Calls

Setting of switching between a voice call and videophone call

Set whether to notify the other party’s terminal that your terminal can switch between a voice call and a videophone call.

･You cannot change the setting during a voice call or videophone call. ･This setting cannot be made outside the service area. Operate the terminal in locations with good radio

wave condition.

Default Indication ON: active

m87171

■ Deactivating: m87172

■ Checking the current setting: m87173

Select Yes

Setting how incoming videophone calls are handled during i-mode

Videophone calls can be receiv ed during i-mode packet communication.

Default V.phone priority

m8714

Press any of 1 to 4

V.phone priority ：Receives a videophone call. When the call is answered, the current packet

Packet DL priority ：Rejects an incoming videophone call and continues the packet communication. V.phone answerphone：Connects an incoming videophone call to the Voice Mail Service Center.* Call forwarding ：Forwards an incoming videophone call to the forwarding phone number.

*1 The service is not available as of May 2006.

communication is disconnected.

Notify Switchable Mod e

Data Session Arrival Act

Notify Switchable Mode

INFORMATION

● Voice Mail Service and Call Forwarding Service are optional subscriber services. Without subscription, even if you set

V.phone answerphone or Call forwarding, the action of Packet DL priority takes place.

● If Voice Mail Service or Call Forwarding Service is activated and the ringing time for each service is set to 0 second,

either service starts its operation, regardless of this setting. Incoming calls are not registered in the received call history.

Page 96

Making/Receiving Videophone Calls

Using the videophone by connecting with an external device External Device

By connecting FOMA terminal to an exter nal device such as PC by the FOMA USB cabl e (option al), you can make and receive videophone calls from the external device. To use this function, install a videophone application in a dedicated external device or a PC, and prepare devices such as an earphone/microp hone or USB-compatible Web camera (available in market).

･This function is not available when FOMA terminal is not connected to an external device. ･Refer to the instruction manual of external devices fo r hardware requirements or setting/operating

instructions of videophone applications.

･The application called “ドコモテレビ電話ソフト 2005 (DoCoMo videophone software 2005)” that is

compatible with this function is available on the DoCoMo videophone software website. Visit the site below

External Device

and download it (visit the support website for details of the environment for usage on PC):

http://videophonesoft.nttdocomo.co.jp/

Default Terminal

Base station

FOMA videophone communication

m8716

Press 1 or 2

speed: 64K or 32K

FOMA

network

INFORMATION

● A videophone call cannot be made from an external device during a voice call.

● When you subscribe to Call Waiting Service, if a videophone call is received through an external device during a voice

call, it is recorded as a missed call in the received call history. The same applies when a voice call, videophone call or 64K data communication is received during a videophone call using an external device.

Page 97

PushTalk

What’s PushTalk? .............................................................................................96

Making PushTalk calls .....................................................................................96

Receiving PushTalk calls .................................................................................98

Registering entries into the PushTalk phonebook

.................................................................... PushTalk Phonebook New Entry 99

Making a PushTalk call by using the PushTalk phonebook .......................100

Deleting members from the PushTalk phonebook

........................................................................ Delete PushTalk Phonebook 102

Setting for incoming/outgoing PushTalk calls ............................................102

Page 98

音の設定

What’s PushTalk?

The PushTalk button (g) allows you to communicate with multiple people (up to 5 including yo urself) by simple operation. Press the PushTalk button for over a second to make access to the PushTalk phonebook, select the parties to talk to and press g. PushTalk communication fee is charged every time you press g and speak. Hold down g while you are speaking and the ot her parties only listen to you. On the screen, you can see who is speaking and the states of the other members. This function is very

PushTalk

useful when communicating within a group or delivering a brief message.

･Supporting models: 902i series, 902iS series and P702i

Talk between two persons

Talk among multiple persons

What’s PushTalk?

PushTalkPlus is a service in which you can communicate with up to 20 persons including you by using a phonebook on the network registered in advance. This service also provides some useful functions such as allowing you to check the member’s state. Note that the optional subscription is needed if you use PushTalkPlus.

● For details about how to operate PushTalkP l us, see the separately-provided booklet.

Making PushTalk calls

PushTalk communication screen

Member Name*1, phone number, or

User unset*2 is displayed.

*1 Displayed when the phone number is registered in the FOMA terminal phonebook (Name displays ☛P107). *2 When a caller makes a PushTalk call not notifying the caller ID, the members are indicated as User unset on receiver’s

*3 Displayed when no party is speaking. *4 Displayed when the speaking party cannot be identified. *5 Displayed when 3 or more parties are communicating.

Hello.

ReceiverCaller

Speak while holding down g.

PushTalkPlus

Member that is speaking now

Name*1, phone number, User unset*2, Myself, a blank*3, or *4 is displayed.

Group name (indicated only on the screen of the party who started group calling) The other party’s status

screens.

I’ll arrive

Callout

Receiver Receiver

: Calling the other party : Participating in PushTalk

: No response, PushTalk ended, or the other party’s terminal is outside service area

or turned off

: Public mode (Driving mode) set on the other party’s terminal

Receiver

soon.

ReceiverCaller

Speak while holding down g.

Page 99

Communicating on PushTalk

Enter the phone number

･Do the same as you enter a number for a voice call.

When the other party answers, the answering tone sounds and PushTalk starts.

･When you make a PushTalk call with FOMA terminal

closed, the speakerphone function is turned on.

PushTalk

PushTalk button

■ Making a call with the speakerphone function while FOMA terminal is open: g (for over a

second)

Communicate on PushTalk

･When a member answers while 3 or more parties are communicating, the connection tone sounds. ･When a member exits from PushTalk while 3 or more parties are communicating , the disconn ectio n tone

sounds.

■ Switching to the speakerphone function: a or n

■ Speaking:

a Hold down g and speak

･ When you press g, you hear the floor acquisition sound. ･ While another party is speaking, pressing g makes the floor acquisition failure sound and you

cannot speak.

b Release g when you finish speaking

･ When you release g, a tone sounds to indicate the end of floor acquisition. ･ When the limit of time for the floor acquisition approaches, a tone sounds to indicate the floor

acquisition is ending.

Press f when you end PushTalk

･To end a PushTalk call by closing the FOMA terminal, change the setting of PushTalk Close Setting .

INFORMATION

● You can make a PushTalk call from the FOMA terminal phonebook, UIM phonebook, redial data, received call history,

ppli, or scan result of Bar Code Reader. You can also make a PushTalk call from Phone To (AV Phone To) in mail,

isites, or ToruCa.

● You can make a PushTalk call by setting conditions. ☛P58

● You cannot make a PushTalk call during a voice call, videophone call or data communication. During PushTalk, you

cannot make a voice call or videophone call to a different party.

● When you make a PushTalk call during i-mode, i-mode is disconnected.

● When you make a PushTalk call when i-

● Speaking time with a single floor acquisition is limited. When the time limit arrives, the floor acquisition is canceled.

● If no party acquires the floor for a certain period of time, PushTalk ends.

● If you set Answer in PushTalk Arrival Act, a voice call coming in while you are speaking cancels the floor acquisition.

● You cannot call an emergency number (110, 119, or 118) during PushTalk.

ppli is running, i-αppli is suspended.

Making PushTalk calls

Operation during PushTalk

The following operations can be performed from the submenu. You can change the earpiece volume during PushTalk with %.

Page 100

Submenu item Description Page

Reconnect alarm*

Setting when folded Set whether to end PushTalk by closing FOMA terminal. P104

PushTalk arv. act Set the action against an incoming voice call during PushTalk. P103

*1 You can change this setting even while the alarm is sounding. The new setting takes effect after the alarm stops.

Set an alarm indicating reconnection of a PushTalk call under improved signal quality which has been cut off due to poor signal quality.

P61

PushTalk

Receiving PushTalk calls

An incoming PushTalk call is received

The PushTalk ring alert sounds, the display lights, and the Enter key lights or flashes.

Blinking

Phone number, name (when the phone number is registered in the FOMA terminal phonebook), or User unset*1 is displayed.

*1 When a caller makes a PushTalk call not notifying the caller ID, the members are indicated as User unset on

receiver’s screens.

g or n

You can answer the PushTalk call and Connected is notified to the other party.

indicates the caller.

･ Answering the PushTalk call while FOMA terminal is closed switches on the speakerphone function. ･ You can also answer a PushTalk call by pres si ng 0 to 9, (, or # (Any Key Answer). ☛P65 ･ Pressing f disconnects the call without answering it. For a group call, Disconnected is notified to the

connected members before disconnecting the call.

･ When PushTalk Auto Answer is set to ON, incoming PushTalk calls are automatically answered.

Your FOMA terminal is switched to the communication that uses the speakerphone functi on. In Silent Mode, however, the auto answering function does not work. Answer by pressing g or n (you can also answer by Any Key Answer).

Communicate on PushTalk

･ For details, follow Step 3 of “Communicating on PushTalk”. ☛P97

Press f when you end PushTalk

･ To end a PushTalk call by closing the FOMA terminal, change the setting of PushTalk Close Setting.

INFORMATION

● To stop the ring alert and vibrator: C while receiving a PushTalk call

● You cannot answer incoming PushTalk calls during a voice call. They are registered in the received call history.

● PushTalk calls cannot be received during a videophone call, v ideophone call throu gh an external devic e, data

communication, software update, or pattern definition update. The missed calls are not registered in the rec eived call histor y.

● If you receive a PushTalk call during i-mode, the action will be subject to the setting of i-mode Arrival Act: PT.

● i-mode cannot be used during PushTalk.

● Response and Hold is not possible for PushTalk. Pressing f disconnects the incoming call.

● Even if there is an incoming videophone call, PushTalk cal l or data communic ation during PushTa lk, you cannot answ er.

They are registered in the received call history.

● When no answer is received within the duration (in seconds) set in PushTalk Ring Time, the incoming PushTalk call is

terminated. In case of the PushTalk call with 3 or more parties, Disconnected is notified to the connected members.
