Docomo AQUOS PHONE Technical Guide Technical Manual

SH-06D

INSTRUCTION MANUAL

’12.2

Thank you for purchasing “SH-06D”.

Introduction

Be sure to read this manual before and during
use to ensure proper operation.

Using the handset

The handset supports W-CDMA, GSM/GPRS and

Wireless LAN System.

Because the handset relies on radio signals, it

cannot be used in places with no signal (such as
tunnels, underground or in buildings), in places with
a weak signal or outside the FOMA service area.
You may not use the handset in the upper floors of a
building even with no obstructions in sight. There
may also be times when the signal is strong and you
are not moving but the call is interrupted.

Because the handset uses electrical signals, it is

possible for a third party to listen in on a
conversation. However, since the W-CDMA and
GSM/GPRS systems automatically apply privacy to
every call, a third party that tries to listen in only
hears static.

The handset converts conversations into a digital

signal and sends it to the other party over the radio.
If the signal cannot be reconverted properly by such
as moving to an area with a wea k signal, the voice
may not be heard correctly.

Keep a separate memo and note information (e.g.

the phonebook, calendar, memo, voice memo,
answering memo) stored in the handset. DOCOMO
shall not be liable for any loss of content due to a
failure, repair, upgrade or other handling of the
handset.

As with PCs, some user-installed applications etc.

may disrupt the stability of your handset
performance or unexpectedly transmit information
via the Internet causing improper use of your
location information and personal information stored
in the handset. Therefore, verify the supplier and
operating conditions of the applications to be used
before using them.

It is recommended to save the important data to the

microSD Card.

The handset supports the FOMA Plus-Area and the

FOMA HIGH-SPEED area.

Unlocking SIM lock

The handset can unlock the SIM lock. Unlock the SIM
lock to use non-DOCOMO SIM cards.

SIM lock can be unlocked at a docomo Shop.
Commission is incurred separately for unlocking SIM

lock.

When using non-DOCOMO SIM card, some

services and functions are unavailable. DOCOMO
shall not be liable for guaranteeing operation of the
handset.

For details on unlocking SIM lock, refer to DOCOMO

website.

Checking operation method

 Quick Start Guide (Basic package) (in Japanese

only)

This guide describes operations of basic functions.

 User’s Manual (Application of the handset) (in

Japanese only)

This manual describes detailed guidance and
operations of functions.
In the home screen, [R]/[Instruction Manual]
･ To display help: z/[ヘルプ] (Help)

 User’s Manual (in PDF format)

This manual describes detailed guidance and
operations of functions.
Download from the DOCOMO website

(http://www.nttdocomo.co.jp/english/support/trouble/

manual/download/index.html)
※ The URL and contents of this manual are subject

to change without prior notice.

Basic package

SH-06D
(warranty and
Back Cover SH61)

microSDHC Card
(16 GB) (sample)
(includes user’s guide)

microSDHC Card is

inserted to the
handset by default.

Desktop Holder SH38
(includes warranty)

FOMA charger micro
USB adapter SH01

Earphone Plug Cable
(with Antenna) SH01

Battery Pack SH31

microUSB cable for
PC (sample)
(includes user’s guide)

Quick Start Guide
(in Japanese only)

The screens and illustrations in this manual

are shown as examples. The actual screens
and illustrations may differ.

The explanations in this manual are based on

the case when the home application is
docomo Palette UI. If you change the home
application, operation procedures etc. may be
different from the explanations of this manual.

Note that “SH-06D” is referred to as “handset”

in this manual.

This manual refers to microSD Card or

microSDHC Card as “microSD Card” or
“microSD”.

Reproduction of this manual in part or in whole

is prohibited.

The contents of this manual are subject to

change without prior notice.

For details on other optional parts nP. 156

Contents/Precautions

1

Contents

Basic package . . . . . . . . . . . . . . . . . . . . . . . . . 1

Notes on using the handset. . . . . . . . . . . . . . . 4

Precautions (ALWAYS FOLLOW THESE

DIRECTIONS) . . . . . . . . . . . . . . . . . . . . . . . . . 6

Handling precautions . . . . . . . . . . . . . . . . . . . 17

Waterproof/Dust-proof . . . . . . . . . . . . . . . . . . 22

Call/Network Services

Making a call . . . . . . . . . . . . . . . . . . . . . . . . .64

Receiving a call . . . . . . . . . . . . . . . . . . . . . . .66

Operation during a call . . . . . . . . . . . . . . . . . . 67

Outgoing/Incoming call history. . . . . . . . . . . .67

Phonebook. . . . . . . . . . . . . . . . . . . . . . . . . . .68

Available network services . . . . . . . . . . . . . . .72

Before Using the Handset

Part names and functions . . . . . . . . . . . . . . . 27

docomo mini UIM card . . . . . . . . . . . . . . . . . . 29

microSD Card . . . . . . . . . . . . . . . . . . . . . . . . 30

Battery pack . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Charging . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Turning power ON/OFF . . . . . . . . . . . . . . . . . 36

Basic operation . . . . . . . . . . . . . . . . . . . . . . . 37

Changing screen display to English. . . . . . . . 40

Initial setting . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Screen display/icons . . . . . . . . . . . . . . . . . . . 45

Character entry . . . . . . . . . . . . . . . . . . . . . . . 49

docomo Palette UI

Home screen . . . . . . . . . . . . . . . . . . . . . . . . . 55

Application screen . . . . . . . . . . . . . . . . . . . . . 57

Searching applications. . . . . . . . . . . . . . . . . . 63

Switching displays of the application

screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

Information on home applications . . . . . . . . . 63

Contents/Precautions

2

Various Settings

Setting menu . . . . . . . . . . . . . . . . . . . . . . . . . 79

Profile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

Energy saving settings . . . . . . . . . . . . . . . . . .80

docomo service . . . . . . . . . . . . . . . . . . . . . . . 81

Wireless & networks. . . . . . . . . . . . . . . . . . . . 81

Call settings . . . . . . . . . . . . . . . . . . . . . . . . . . 82

Sound settings . . . . . . . . . . . . . . . . . . . . . . . .82

Display settings . . . . . . . . . . . . . . . . . . . . . . . 83

USB connection . . . . . . . . . . . . . . . . . . . . . . .84

Location & security . . . . . . . . . . . . . . . . . . . . .85

Lock/Security . . . . . . . . . . . . . . . . . . . . . . . . . 86

Applications . . . . . . . . . . . . . . . . . . . . . . . . . .88

Accounts & synchronization. . . . . . . . . . . . . . 89

Privacy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .89

microSD & phone storage . . . . . . . . . . . . . . . 89

Language & keyboard . . . . . . . . . . . . . . . . . .90

Voice input & output . . . . . . . . . . . . . . . . . . . .90

Accessibility . . . . . . . . . . . . . . . . . . . . . . . . . . 90

Pedometer setting . . . . . . . . . . . . . . . . . . . . .90

Date & time . . . . . . . . . . . . . . . . . . . . . . . . . .92

About phone. . . . . . . . . . . . . . . . . . . . . . . . . .92

Mail/Internet

sp-mode mail . . . . . . . . . . . . . . . . . . . . . . . . . 93

SMS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93

Email . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95

Gmail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98

Early warning “Area Mail” . . . . . . . . . . . . . . 101

Browser . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102

File Management

Contents manager . . . . . . . . . . . . . . . . . . . . 105

Infrared communication . . . . . . . . . . . . . . . . 106

iC communication . . . . . . . . . . . . . . . . . . . . 107

®

Bluetooth

External connector device . . . . . . . . . . . . . .112

Cooperating with Blu-ray Disc recorder . . . . 114

Home network settings . . . . . . . . . . . . . . . . 114

VPN (Virtual Private Network) . . . . . . . . . . . 115

function . . . . . . . . . . . . . . . . . . . 108

Applications

Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116

Camera reader. . . . . . . . . . . . . . . . . . . . . . . 120

Picture (3D-capable) . . . . . . . . . . . . . . . . . . 123

Music player. . . . . . . . . . . . . . . . . . . . . . . . . 124

Market . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126

GPS/Navigation . . . . . . . . . . . . . . . . . . . . . . 127

Talk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130

1Seg . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131

Mobacas . . . . . . . . . . . . . . . . . . . . . . . . . . . 138

YouTube . . . . . . . . . . . . . . . . . . . . . . . . . . . 141

Osaifu-Keitai . . . . . . . . . . . . . . . . . . . . . . . . 141

Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 144

Schedule . . . . . . . . . . . . . . . . . . . . . . . . . . . 146

Memo. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 147

Calculator . . . . . . . . . . . . . . . . . . . . . . . . . . . 147

microSD backup . . . . . . . . . . . . . . . . . . . . . .147

iD設定アプリ (iD setting appli). . . . . . . . . . .149

Smart Familink . . . . . . . . . . . . . . . . . . . . . . . 149

International Roaming

Outline of international roaming (WORLD

WING) . . . . . . . . . . . . . . . . . . . . . . . . . . . . .150

Available services overseas . . . . . . . . . . . . .150

Before use overseas . . . . . . . . . . . . . . . . . .151

Settings to use overseas . . . . . . . . . . . . . . .152

Making/Receiving a call in your country of

stay . . . . . . . . . . . . . . . . . . . . . . . . . . . .153

Setting international roaming . . . . . . . . .155

Appendix/Index

Introduction of options and related

devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 156

Troubleshooting (FAQ). . . . . . . . . . . . . . . . .156

Warranty and After-Sales Service . . . . . . . .162

Updating software . . . . . . . . . . . . . . . . . . . . 164

OS version upgrade . . . . . . . . . . . . . . . . . . . 171

Main specifications . . . . . . . . . . . . . . . . . . . .172

Specific Absorption Rate (SAR) of Mobile

Phone. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .175

Export Administration Regulations . . . . . . . .178

Intellectual Property Right . . . . . . . . . . . . . .178

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 183

Contents/Precautions

3

Notes on using the handset

The handset does not support i-mode

functions (connection to i-mode site
(broadcast), i-appli, etc.).

Google applications and its service contents

are subject to change without prior notice.

The handset automatically performs

communication for some functions, for
example, to synchronize data, check the latest
software version or maintain connection with
the server. Also, making a communication
with large-volume data such as downloading
applications or watching videos will lead to
higher packet communication charges.
Subscription to flat-rate packet communication
services is highly recommended.

Subscription to sp-mode is required to use

Wi-Fi tethering.

Packet communication charges when using

Wi-Fi tethering differ according to your
payment plans. Subscription to flat-rate
packet communication services is highly
recommended.

Since Mobacas is a service that collaborates

with communications, packet communication
charges are incurred when using this service.
Subscription to flat-rate packet communication
services is recommended.

For details on usage fees to use, refer to the

following site.

(http://www.nttdocomo.co.jp/) (in Japanese

only)

The handset does not support Public mode

(Drive mode).

Setting the handset to the manner mode does

not mute sounds (camera shutter sound, etc.)
other than the ring tone, operation sound, and
various notification sounds.

Software in the handset can be updated to

up-to-date status (nP. 164).

For details on software version of your

handset nP. 92

In the home screen, [R]/[Settings]/[Profile]

to check your phone number (own number).

New functions may be added to the handset,

the operation method may change, etc. by
upgrading the OS version. Check the
DOCOMO website for the latest information of
additions and changes.

If the OS is upgraded, some applications that

used in the previous OS version may not be
available or some unintended bugs may
occur.

Contents/Precautions

4

Capacity of microSD Card or the handset is

nearly full, applications in use may not work
properly. In that case, delete saved data.

Secure the security of the handset by setting

Screen lock in case you lose it (nP. 85).

Read the terms of use of Google Inc. for

details on Google services. Also, read each
terms of use for details on other web services.

If your handset is lost, change your password

for each account using a PC to prevent other
persons from using Twitter, mixi, and Google
services such as Google Talk, Gmail and
Android Market.

The handset does not support providers other

than mopera U, Business mopera Internet
(URL restriction) and sp-mode.

It is recommended that microSD Card be

inserted to use the handset. Some data such
as images shot with the camera cannot be
saved and some data cannot be sent and
received using infrared communication or
Bluetooth connection without microSD Card.

Contents/Precautions

5

Precautions (ALWAYS FOLLOW THESE DIRECTIONS)

Before use, read these “Precautions” carefully

and use your handset properly.
Keep this manual in a safe place for future
reference.

These precautions contain information intended

to prevent bodily injury to the user and to
surrounding people, as well as damage to
property, and must be observed at all times.

The following symbols indicate the different
degrees of injury or damage that may occur if
information provided is not observed and the
handset is used improperly.

This symbol
indicates that “death
or serious bodily

Danger

Warning

Caution

injury may directly
and immediately
result from improper
use”.

This symbol
indicates that “death
or serious bodily
injury may result
from improper use”.

This symbol
indicates that “minor
injury and/or
property damage
may result from
improper use”.

The following symbols indicate specific
directions.

Indicates a prohibited action.

Indicates not to disassemble the
device.

Indicates not to handle the device
with wet hands.

Indicates not to use the device
near water or get it wet.

Indicates that instructions
specified are compulsory (must
be followed).

Indicates that the power cord must
be unplugged from the outlet.

Contents/Precautions

6

“Precautions” is explained in the following

Danger

Warning

seven sections.

Handling the handset, battery pack, adapters

(including charger micro USB adapter), desktop
holder, docomo mini UIM card and earphone

plug cable (with antenna) (general) . . . . . . . P. 7

Handling the handset . . . . . . . . . . . . . . . . . . P. 8

Handling battery pack . . . . . . . . . . . . . . . . . P. 11

Handling adapters (including charger micro USB

adapter) and desktop holder . . . . . . . . . . . . P. 12

Handling docomo mini UIM card . . . . . . . . . P. 13

Handling near electronic medical equipment

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 13

Viewing 3D images . . . . . . . . . . . . . . . . . . . P. 14

Handling the handset, battery
pack, adapters (including
charger micro USB adapter),
desktop holder, docomo mini
UIM card and earphone plug
cable (with antenna) (general)

Do not use, store or leave the
equipment in locations subject to
high temperatures (near a fire or
heating unit, in a kotatsu, under
direct sunlight, inside a vehicle on a

May cause fires, burns or bodily injury.

hot day, etc.).

Do not place the equipment inside
cooking appliances such as
microwave ovens or pressure

May cause fires, burns, bodily injury or electric shock.

May cause fires, burns, bodily injury or electric shock.

May cause fires, burns, bodily injury or electric shock.
Refer to the following for details on waterproofness.
n“Waterproof/Dust-proof” on P. 22

May cause fires, burns, bodily injury or electric shock.

May cause fires, burns, bodily injury or electric shock.

May cause fires, burns, bodily injury or electric shock.

cookers.

Do not attempt to disassemble or
modify the equipment.

Do not get the equipment wet with
water, drinking water, pet urine, etc.

Use only the battery packs and
adapters (including charger micro
USB adapter) specified by NTT
DOCOMO for use with the handset.

Do not subject the equipment to
strong force or impacts or throw it.

Do not allow conductive materials
(such as metal objects and pencil
lead) to come into contact with the
charger terminal or external
connector terminal. In addition, do
not insert such objects.

Contents/Precautions

7

Do not cover or wrap the equipment

Caution

Warning

with bedding, etc. when using or

May cause fires or burns.

May cause a gas explosion or fire.
To use Osaifu-Keitai in locations such as gas stations,
be sure to turn off the power in advance (If the
Osaifu-Keitai lock setting is activated, disable the lo ck
before turning off the power).

May cause fires, burns, bodily injury or electric shock.

charging.

Be sure to turn off the handset and
not to charge the battery in locations
such as gas stations where
flammable gas is generated.

If you notice anything unusual, such
as an unusual odor, overheating,
discoloration or deformation during
use, charging or storage,
immediately follow the instructions
below.
Unplug the power cord from the

outlet or cigarette lighter socket.

Turn off the handset.
Remove the battery pack from the

handset.

If being used by a child, have a
guardian teach him/her the proper
handling procedures. In addition,
check that the child is using the

May result in bodily injury.

A young child may swallow the equipment or suffer
other bodily injury.

The handset, battery pack or adapters (including
charger micro USB adapter) may become warm if 1Seg
etc. is used for a long time while charging.
Touching high temperature areas for a prolonged
period of time may cause skin irritations, itchiness or
low-temperature burns in some people.

equipment as directed.

Keep the equipment out of the reach
of young children.

Be very careful when using the
handset connected to adapters
(including charger micro USB
adapter) repeatedly or for long
periods of time.

Handling the handset

Do not leave the equipment on
unstable surfaces, such as on a

May fall and cause injury.

May cause fires, burns or electric shock.

8

wobbly table or sloped surface.

Do not store the equipment in
locations that are subject to
humidity, dust or high temperatures.

Contents/Precautions

Do not aim the infrared port towards
the eyes.

May cause eye injury.

Do not aim the infrared port towards
home electric appliances with an
infrared device during infrared

May interfere with the operation of infrared devices and
cause an accident.

communication.

Do not point the illuminated light

Mobile light

directly at someone’s eyes.
Especially when you shoot still
pictures or moving pictures of young
children, keep 1 m or more distance

Do not use Mobile light near people’s faces. Eyesight
may be temporarily affected leading to accidents.
Precautions:
The
the light over the safety level for eyes when operations
such as undirected adjustments are intentionally made.
Therefore, do not disassemble the handset.

from them.

mobile

light source used for this product may emit

EN60825-1:1994 A1:2002 & A2:2001

CLASS1
LED Product

CAUTION:

Use of controls, adjustments or performance of
procedure other than those specified herein may result
in hazardous radiation exposure. As the emission level
from Mobile light LED used in this product is harmful to
the eyes, do not attempt to disassemble the cabinet.
Servicing is limited to qualified servicing station only.

Do not allow water or other liquids,
metal, flammable material or other
foreign objects to enter the docomo
mini UIM card or microSD Card slot

May cause fires, burns, bodily injury or electric shock.

on the handset.

Do not shine the light at anyone
driving a car or other vehicles.

May prevent a driver from driving safely and cause a
traffic accident.

Turn off the handset in areas where
the use of mobile phones is
prohibited, such as in aircraft or

May interfere with the operation of electronic devices
and electronic medical equipment.
Follow the instructions given by the respective medical
facilities regarding the use of mobile phones on their
premises.
Actions such as using a mobile phone aboard aircraft
are prohibited and punishable by law.
However, follow the instructions on use of the handset
given by the airline if the handset can be used aboard
aircraft by setting the handset such as setting it not to
emit radio wave.

hospitals.

Keep the handset away from the ears
during a call in which hands-free is set
or while the ring tone is ringing.
When you attach the earphone/
microphone, etc. to the handset to
play games, music, etc., do not make

Excessive high volume may damage your hearing.
Also, it may prevent you from hearing ambient sounds
and cause an accident.

Earphone Signal Level

The maximum output voltage for the music player
function, measured in accordance with EN 50332-2, is
23 mV.

May have harmful effects on your heart.

the volume too loud.

If you have a weak heart, take extra
precautions when setting functions
such as the vibrator and ring tone
volume for incoming calls.

Contents/Precautions

9

If you are using electronic medical

Caution

equipment, contact the respective
manufacturer or dealer to check
whether the operation of the

May interfere with the operation of electronic medical
equipment, etc.

equipment is affected by signals.

Turn off the handset near high-precision
electronic devices or devices that use

May interfere with the operation of electronic devices.

Take particular care with the following devices

Hearing aids, implanted cardiac pacemakers, implanted
cardioverter-defibrillators or other electronic medical
equipment. Fire alarms, auto matic doors, and other
equipment controlled by electronic signals. If you use
an implanted cardiac pacemaker, implanted
cardioverter-defibrillator or other electronic medical
equipment, contact the respe ctive manufacturer or
dealer to check whether the operation of the equipment
is affected by signals.

The surface of the display is covered by a protective
film while the surface of the camera lens is covered by a
plastic panel so as to minimize the possibility of glass
scattering. However, touching the broken or exposed
parts may cause injury.

weak electronic signals.

If the display part or camera lens is
damaged, be careful of broken glass
and the exposed inside of the handset.

Do not swing the handset by its
antenna, strap, etc.

May hit you or others around you, resulting in bodily injury.

Do not use a damaged handset.

May cause fires, burns, bodily injury or electric shock.

Contents/Precautions

10

For using a motion sensor and
geomagnetic sensor, check the safety
around, hold the handset and do not

May cause injury etc.

May result in loss of eyesight and harm to your skin.
If the liquid comes into contact with your eyes or mouth,
immediately rinse your eyes or mouth with clean water
and see a doctor.
If the liquid comes into contact with your skin or clothes,
immediately wipe it off with alcohol, and wash with
water and soap.

Using the equipment with the film removed may
damage the display and cause bodily injury.

May interfere with the operation of electronic equipment
in some vehicle models. In such cases, stop using the
handset.

For details on materials of each part n“Material list”
on P. 15

swing them more than necessary.

If the display is broken and the liquid
crystal then leaks, do not get the
liquid on your skin (face, hands, etc.).

The surface of the display is covered
with a protective film for ensuring
the security against any damages
caused by the handset being
dropped or receiving a strong
impact etc. Do not remove the film
forcibly or damage it.

If you use the handset in a vehicle,
contact the vehicle manufacturer or
dealer to check whether the
operation of the vehicle is affected
by signals.

Use of the handset may cause skin
irritations such as itchiness, rashes
or eczema in some people. If this
occurs, immediately stop using the
handset and seek medical treatment.

Look at the display in a well-lit place,

Danger

Warning

Caution

keeping a certain distance from the

Otherwise, eyesight may be weakened.

screen.

Handling battery pack

Check the type of battery using the information
printed on the battery pack label.

Label Battery type

Li-ion00 Lithium-ion

Do not touch terminals with metallic
objects such as wires. In addition,
do not carry or store the battery

The battery pack may catch fire, explode, overheat or leak.

The battery pack may catch fire, explode, overheat or leak.

The battery pack may catch fire, explode, overheat or leak.

The battery pack may catch fire, explode, overheat or leak.

pack with metallic necklaces, etc.

Check that the battery pack is facing
the correct direction before you
attach it to the handset. If you are
having difficulty fitting the battery
pack to the handset, do not use
excessive pressure to force the
battery into place.

Do not throw the battery pack into a
fire.

Do not puncture, hit with a hammer
or step on the battery pack.

If the battery fluid, etc. comes into
contact with your eyes, do not rub
your eyes but immediately rinse
your eyes with clean water. Then

May result in loss of eyesight.

The battery pack may catch fire, explode, overheat or leak.

The battery fluid is flammable and could ignite, causing
a fire or explosion.

The battery pack may catch fire, explode, overheat or leak.

May cause fires or damage to the environment. Place
tape over the terminals to insulate unnecessary battery
packs, and take them to a docomo Shop, retailer or
institution that handles used batteries in your area.

The battery pack may catch fire, explode, overheat or leak.

seek prompt medical treatment.

If any trouble such as a deformation
or scratches caused by dropping the
battery pack is found, never use it.

If the battery pack leaks or emits an
unusual odor, immediately stop
using it and move it away from any
naked flames or fire.

Do not allow a pet to bite the battery
pack.

Do not dispose of used battery
packs in ordinary garbage.

Do not use or charge a wet battery
pack.

Contents/Precautions

11

If the battery fluid, etc. leaks, do not

Warning

get the liquid on your skin (face,

May result in loss of eyesight and harm to your skin.
If the liquid comes into contact with your eyes, mouth,
skin or clothes, immediately rinse them with clean
water.
If the liquid, etc. comes into contact with your eyes or
mouth, see a doctor immediately after rinsing your eyes
or mouth.

hands, etc.).

Handling adapters (including
charger micro USB adapter)
and desktop holder

Do not use if the cord of the adapter
(including charger micro USB

May cause fires, burns or electric shock.

May cause fires, burns or electric shock.

May cause fires, burns or electric shock.

May cause electric shock.

12

adapter) is damaged.

Never use the AC adapter or the
desktop holder in humid locations
such as a bathroom.

The DC adapter should only be used
in negative grounded vehicles.
Never use it in positive grounded
vehicles.

Do not touch adapters (including
charger micro USB adapter) if you
hear thunder.

Contents/Precautions

Take care not to short-circuit the
charger terminal when connected to an
outlet or cigarette lighter socket. Also,
take care not to allow any part of your
body (hands, fingers, etc.) to come into

May cause fires, burns or electric shock.

May cause fires, burns or electric shock.

May cause fires, burns or electric shock.

May cause fires, burns or electric shock.

Using the incorrect voltage may cause fire, burns or
electric shock.
AC adapter: 100V AC
DC adapter: 12/24V DC (for negative grounded
vehicles only)
AC adapter available overseas: 100 to 240V AC
(Connect only with a household AC outlet)

May cause fires, burns or electric shock. Refer to the
respective manuals for information on the correct fuse
specifications.

contact with the charger terminal.

Do not place heavy objects on the
cord of the adapter (including
charger micro USB adapter).

When plugging/unplugging the AC
adapter into/from the outlet, do not
allow metallic straps or other
metallic objects to come into contact
with the prongs of the plug.

Do not handle the cord of the
adapters (including charger micro
USB adapter), the desktop holder or
the outlet with wet hands.

Always use the specified power
supply and voltage.
When using overseas, use the AC
adapter that is available overseas.

If the fuse in the DC adapter blows,
always replace it with a fuse of the
specified type.

Wipe off any dust on the power plug.

Caution

Caution

Warning

May cause fires, burns or electric shock.

Fully plug the AC adapter into the
outlet.

May cause fires, burns or electric shock.

Always grasp the adapters when
unplugging the power plug from the
outlet or cigarette lighter socket. Do
not forcibly pull by the cord of the
adapter (including charger micro USB

May cause fires, burns or electric shock.

May cause fires, burns or electric shock.

May cause fires, burns or electric shock.

May cause fires, burns or electric shock.

May hit you or others around you, resulting in bodily
injury.

adapter).

Unplug the power plug from the
outlet or cigarette lighter socket
when not using for a long time.

Should water or other liquids enter
the equipment, remove the power
plug from the outlet or cigarette
lighter socket immediately.

Always unplug the power plug from
the outlet or cigarette lighter socket
before cleaning the equipment.

Do not swing the desktop holder by
its antenna etc.

Handling docomo mini UIM card

Be careful with the cutting surface
when detaching the docomo mini

May cause bodily injury.

UIM card.

Handling near electronic
medical equipment

The precautions detailed here conform to the
guidelines drawn up by the Electromagnetic
Compatibility Conference Japan, regarding the
protection of electronic medical equipment
from signals emitted by mobile phones.

Observe the following in hospitals or
other medical facilities.

Do not take your handset into operating rooms, ICUs

(Intensive Care Units) or CCUs (Coronary Care
Units).

Turn off your handset inside hospital wards.
Turn off your handset even when you are in an area

outside hospital wards, such as a hospital lobby,
since electronic medical equipment may be in use
nearby.

Where a medical facility has specific instructions

prohibiting the carrying and use of mobile phones,
observe those instructions strictly.

Contents/Precautions

13

Turn off your handset in crowded

Caution

places such as rush-hour trains in
case somebody nearby is using an
implanted cardiac pacemaker or

Electromagnetic signals may have harmful effects on
the operation of implanted cardiac pacemakers and
implanted cardioverter-defibrillators.

Electromagnetic signals may have harmful effects on
the operation of the electronic medical equipment.

Electromagnetic signals may have harmful effects on
the operation of electronic medical equipment.

implanted cardioverter-defibrillator.

If you have electronic medical
equipment such as an implanted
cardiac pacemaker or an implanted
cardioverter-defibrillator, always
carry or use your handset at least 22
cm away from your implant.

Patients receiving medical treatment
away from a hospital or medical
facility (e.g. home treatment) who are
using electronic medical equipment
other than implanted cardiac
pacemakers or implanted
cardioverter defibrillators should
consult the respective manufacturers
for information regarding the effects
of signals on the equipment.

Viewing 3D images

Do not view 3D images if you have
suffered from a photosensitivity
disease or have a heart disease, or if
you are in bad shape, sleep-deprived,

May cause an increase in symptoms.

14

tired or under the influence of alcohol.

Contents/Precautions

When you see a double image or
have difficulty in perceiving the
stereoscopic effect while viewing 3D
images, stop using the 3D

May cause eyestrain.

May cause sick feelings. Take a rest properly.
Be extra careful to use in the environment that tends to
shake the screen such as a train or a vehicle.

When a child views 3D images, he/she may get sick
suddenly, since it is difficult to notice a reaction such as
fatigue or discomfort.
When a child views 3D images, his/her parents should
supervise and monitor whether he/she feels eyestrain.

Viewing for a long time may cause eyestrain.

May cause eyestrain.
When viewing 3D images, hold the handset in front of
your face and keep it approximately 30 cm away. A
floating image or image which has depth appears.

functionality.

When you experience trouble such
as fatigue or discomfort (sickness
that is similar to carsickness) while
viewing 3D images, stop using the
3D functionality.

Viewing 3D images is intended for
use by children aged 7 years or
older.

When viewing 3D images, take a
break every 30 minutes.

When viewing 3D images, hold the
screen in front of your face and
view.

Material list

Handset/Back cover/Battery pack

Part

Display side

Surrounding section of
display side

Upper part of display side

Sides

Operation key

Surrounding section of
operation key

Side key

1Seg/Mobacas antenna SUS/UV coating

Metal section of 1Seg/
Mobacas antenna

Brace of 1Seg/Mobacas
antenna

Charger terminal SUS/Gold plating

Power supply terminal SUS/Gold plating

External connector
terminal

External connector
terminal cover

Gasket of external
connector terminal cover

Material/Surface

treatment

Reinforced glass/
Shatterproof sheet of
surface

PA resin/UV coating for
surface, Discontinuous
deposition

PMMA resin

PA resin/UV coating for
surface

PC resin/UV coating for
surface

PC resin

PC resin/UV coating for
surface

Low alloy steel

SUS/Ni plating

Copper alloy/Gold
plating over Pd-Ni

PC resin/UV coating for
surface, Discontinuous
deposition

Silicone rubber

Part

Camera/Infrared port panel

Mobile light PC resin

Surrounding section of
mobile light

Inside back cover PA resin

Speaker Polyester

Surrounding section of
speaker

Jack sheet PET

Upper section of docomo
mini UIM card tray

Resin section of docomo
mini UIM card tray

Metal section of docomo
mini UIM card tray

microSD Card slot SUS

FOMA antenna

Battery terminal
connector

Battery terminal

Battery storage side PET/SUS

Screw

Back cover

Material/Surface

PMMA resin/UV coating

PMMA resin

Polyolefin

Glass epoxy board/Gold
plating

LCP

SUS/Ni plating

LDS resin/Gold plating,
UV coating for surface

LCP

Free-cutting brass/Ni
base, Gold plating

Steel/Ni plating, Black
Ni plating, Trivalent
chromate, Passivation
coating

Handset color White:
ABS resin/UV coating
Handset color Magenta
Red, Blue Black: ABS
resin/Soft touch coating

treatment

Contents/Precautions

15

Part

Gasket of back cover Silicone rubber

Battery lid spacer PC resin

Battery pack PC resin/Spark erosion

Battery pack terminal
section

Material/Surface

treatment

Copper alloy/Full
surface Ni with plating
base, Gold plating

Desktop holder

Part

Main body ABS/Surface texturing

Tab POM

Switch

Lever POM

Charger terminal

Power supply terminal

1Seg/Mobacas antenna SUS

Tip of 1Seg/Mobacas
antenna

Brace of 1Seg/Mobacas
antenna

Connector terminal C5210R/Gold plating

Screw SWCH/Black Ni plating

Stopper

Material/Surface

treatment

POM

C2200W/Ni plating,
Gold plating

C2200W/Ni plating,
Gold plating

PC resin

Cadmium-free brass

Foamed polyurethane/
Silicone resin

FOMA charger micro USB adapter SH01

Part

Connector section TPE

Contents/Precautions

16

Material/Surface

treatment

Part

Cord section TPE

Connector section on
handset side (Metal
section)

Connector section on AC
adapter side (Terminal)

Connector section on
AC adapter side
(Surrounding section of
terminal)

Connector section on
handset side (Terminal)

Connector section on
handset side (Surrounding
section of terminal)

Material/Surface

treatment

SUS

Corson alloy/Gold
plating

PPS

Phosphor bronze/Gold
plating

PA66

Earphone Plug Cable (with Antenna) SH01

Part

Cord section

Earphone/Microphone
terminal

Earphone/Microphone
terminal (Metal section)

Connector section Olefin system elastomer

Connector section
(Metal section)

Connector section
(Terminal)

Connector section
(Surrounding section of
terminal)

Latch STS304

Material/Surface

treatment

Styrene system elastomer

Olefin system elastomer

Gold plating

STS304

Gold plating

PPA

Handling precautions

General notes

SH-06D is waterproof/dust-proof, however,

do not allow water to seep or dust to get in
the handset and do not allow accessories or
optional parts to get wet or do not allow dust
to adhere.

The battery pack, adapter (including charger micro
USB adapter), desktop holder, docomo mini UIM
card and earphone plug cable (with antenna) are not
waterproof/dust-proof. Do not use in humid or
steamy areas such as bathrooms and avoid
exposing to rain and other forms of moisture. If the
handset is carried close to the skin, perspiration may
cause internal components to corrode and result in
malfunction. Note that if a problem is found to be
due to moisture, the handset and parts are not
covered by warranty and in some cases may be
irreparable. Even when repairs are possible, repair
charges will be incurred, since the damage is not
covered by warranty.

Clean only with a soft and dry cloth (such as

the type used for eyeglasses).

･ Forceful rubbing of the LCD with a dry cloth may

scratch its surface.

･ Note also that LCD coating may stain if moisture

or soiling is left on the surface for a long period.

･ Never use chemicals such as alcohol, thinners,

benzene or detergents, as these agents may
erase the printing on the handset or cause
discoloration.

Occasionally clean terminals with a dry

cotton swab, etc.

Dirty terminals may result in poor connections and
loss of power. Keep the terminal clean with a dry
cotton swab, etc.
Be careful with the terminal while cleaning it.

Do not place the handset near an air

conditioning vent.

Condensation formed due to rapid changes in
temperature may cause internal corrosion and lead
to a malfunction.

Do not apply excessive force to the handset

and battery pack when using them.

Carrying the handset in a tightly packed bag or
sitting on the handset in your pocket may cause
damage to the display, other internal components or
battery pack or result in a malfunction.
Keeping an external connector device plugged into
the external connector terminal (earphone/
microphone terminal) may cause damage to the
connector or result in a malfunction.

Do not rub or scratch the display with metal,

etc.

May scratch the handset and cause malfunction or
damage.

Read the respective manuals or user’s

guides supplied with the battery pack and
adapters (including charger micro USB
adapter) carefully.

Notes about the handset

Do not forcefully press the surface of the touch
panel or operate with a pointed object such as
a fingernail, ballpoint pen, pin, etc.

May damage the touch panel.

Avoid using the handset in extremely high or

low temperatures.

Use the handset within the range of a temperature
between 5°C and 40°C (for temperatures of 36°C or
higher, such as in a room with a bath, limit usage to
a short period of time) and a humidity between 45%
and 85%.

Contents/Precautions

17

Using the handset close to landline phones,
TVs or radios may have harmful effects on
the operation of such equipment. Move as far
away as possible from such items before use.

Keep a separate memo noting information

stored in the handset.

DOCOMO shall not be liable for an y loss of content.

Do not drop or otherwise subject the handset

to severe impact.

May damage the handset and cause a malfunction.

When connecting an external connector

device to the external connector terminal
(earphone/microphone terminal), do not put
it in obliquely and do not pull it while it is
plugged in.

May damage the handset and cause a malfunction.

The handset becomes warm during use or

charging but this is not a malfunction.

Do not leave the camera in direct sunlight.

May cause discoloration or burn-in.

Use the handset with the external connector

terminal cover closed.

Dust, water, etc. may get in and cause a
malfunction.

Do not use the handset without the back

cover.

May detach the battery pack or cause a malfunction
or damage.

While using a microSD Card, do not remove

the card or turn off the handset.

May cause data loss or a malfunction.

Never place a magnetic card near the

handset.

The stored magnetic data in cash cards, credit
cards, telephone cards, floppy disks, etc. may be
erased.

Never place magnetized items near the

handset.

Putting highly magnetized items closer may cause
an error.

Contents/Precautions

18

Notes about the battery pack

The battery pack is a consumable product.

Though usage time varies with use, change the
battery if the battery level is extremely low even after
being fully charged. Purchase a specified new
battery pack.

Charge battery in areas where ambient
temperature is between 5°C and 35°C.

The usage time for a battery pack depends

on the usage and deterioration of battery
pack.

Depending on usage, the battery pack may

swell as it approaches the end of its service
life, but this will not cause problems.

Note the following when the battery pack is

stored.

 Storage with the battery pack fully charged

(immediately after charging is completed)

 Storage with no battery level (cannot turn the

main body on)
May lower the performance or shorten the life of the
battery pack.
Approximately 40% is recommended as the battery
level for storage.

Notes about adapters (including
charger micro USB adapter)

Charge the battery in areas where the

ambient temperature is between 5°C and
35°C.

Do not charge the battery pack in the

following locations.

 Areas with high humidity or dust, or in areas

exposed to strong vibrations

 Close to landline phones, TVs, radios, etc.

Adapters (including charger micro USB

adapter) may become warm during charging
but this is not a malfunction.

Do not use the DC adapter to charge the

① ②

③

④

battery when the car engine is not running.

May cause the car battery to run down.

When using an outlet with a feature to

prevent the plug from being removed
accidentally, follow the instructions in the
outlet user’s guide.

Do not subject to strong force or impacts.

Also, do not disfigure the charger terminals.

May cause a malfunction.

Notes about docomo mini UIM
card

Do not apply unnecessary force when

inserting/removing the docomo mini UIM
card.

Customer is responsible for malfunctions

arising from inserting docomo mini UIM card
into a different IC card reader/writer.

Always keep IC area clean.
Clean only with a soft and dry cloth (such as

the type used for eyeglasses).

Keep a separate memo and note information

stored in the docomo mini UIM card.

DOCOMO shall not be liable for an y loss of content.

To protect the environment, please take any

unneeded docomo mini UIM cards to a
docomo Shop or retailer.

Do not damage, touch haphazardly or

short-circuit the IC.

May cause data loss or a malfunction.

Do not drop or otherwise subject the

docomo mini UIM card to severe impact.

May cause a malfunction.

Never bend the docomo mini UIM card or

place heavy objects on it.

May cause a malfunction.

Do not insert the docomo mini UIM card to

the handset with a label or sticker attached
on the card.

May cause a malfunction.

Notes on using Bluetooth
function

The handset supports the security function

that meets the Bluetooth specification for
security during communication using
Bluetooth functions. However, the security
may not be sufficient depending on the
configuration. Take care of the security while
making communication using Bluetooth
function.

Even if any leak of data or information

occurs while making communication using
Bluetooth function, DOCOMO shall not be
liable for any loss of content.

Radio frequencies

The radio frequencies the Bluetooth function
of the handset uses are as follows.

① 2.4: This radio equipment uses the 2.4 GHz

band.

② FH: The modulation system is the FH-SS system.
③ 1: The estimated coverage distance is 10 m or

less.
④ : All radio frequencies between 2400

MHz and 2483.5 MHz are used and the

frequencies for mobile object identifiers shall not

be avoided.

Contents/Precautions

19

Cautions on using Bluetooth devices

Bluetooth operates at radio frequencies
assigned to the in-house radio stations for
a mobile object identifier that have to be
licensed and is used in production lines of
a factory, specific unlicensed low power
radio stations, and amateur radio stations
(hereafter, referred to “another radio
station”) in addition to industrial, scientific,
medical devices or home electric
appliances such as microwave ovens.

1. Before using the handset, make sure that
“another radio station” is not operating
nearby.

2. If radio interference between the handset
and “another radio station” occurs,
avoid interference by moving
immediately to another place or “turning
off the power”.

3. Contact the number listed in “General
Inquiries” on the back of this manual for
further details.

Wireless LAN

Do not use wireless LAN near magnetic devices
such as electric appliances or AV/OA devices or in
radio waves.
･ Magnetism or radio waves may increase noises or

disable communications (especially when using a
microwave oven).

･ When used near TV, radio, etc., reception

interference may occur or channels on the TV
screen may be disturbed.

･ If there are multiple wireless LAN access points

nearby and the same channel is used, search may
not work correctly.

Radio frequencies

The radio frequencies the WLAN-installed
devices use are indicated on the battery
storage section of the main body of the
handset. The following are the descriptions:

Notes about wireless LAN
(WLAN)

Wireless LAN (WLAN) uses radio waves to

communicate information. Therefore, it has
an advantage of freely connecting to the LAN
within the service area. On the other hand, if
security setting is not set, it is possible for a
malicious third party to intercept the
communication contents or hack. It is
recommended to set security setting at your
own risk and judgement.

Contents/Precautions

20

① 2.4: This radio equipment uses the 2400 MHz

band.

② DS: The modulation system is the DS-SS

system.

③ OF: The modulation system is the OFDM system.
④ 4: The estimated coverage distance is 40 m or

less.

⑤ : All radio frequencies

between 2400 MHz and 2483.5 MHz are used
and the frequencies for mobile object identifiers

shall not be avoided.
Available channels for the handset’s wireless LAN
are between 1 to 13. Note that other channel access
points cannot be connected.
Available channels vary depending on the country.
For use in an aircraft, contact the airline beforehand.

There are restrictions on the use of wireless LAN in
some countries or regions such as France. If you
intend to use wireless LAN overseas, check the local
laws and regulations beforehand.

Cautions on using 2.4 GHz devices

WLAN-installed devices operate at radio
frequencies assigned to the in-house radio
stations for a mobile object identifier (radio
stations requiring a license) used in
production lines of a factory, specific
unlicensed low power radio stations (radio
stations requiring no license), and amateur
radio stations (radio stations requiring a
license) in addition to industrial, scientific,
medical devices or home electric
appliances such as microwave ovens.

1. Before using this device, make sure that
the in-house radio stations for a mobile
object identifier, specific unlicensed low
power radio stations and amateur radio
stations are not operating nearby.

2. If the device causes harmful radio
interference to the in-house radio
stations for a mobile object identifier,
immediately change the radio frequency
or stop use, and contact the number
listed in “General Inquiries” on the back
of this manual for crosstalk avoidance,
etc. (e.g. partition setup).

3. If the device causes radio interference to
specific unlicensed low power radio
stations for a mobile object identifier or
amateur radio stations, contact the
number listed in “General Inquiries” on
the back of this manual for further
details.

FeliCa reader/writer

The FeliCa reader/writer function in the

handset uses weak electric waves in the
handling of which does not require a license
of radio station.

The frequency in use is the 13.56 MHz band.

When another reader/writer is being used
nearby, keep enough distance from it. Make
sure that there is no radio station using the
same frequency band in the nearby area.

Caution

Never use the handset that is modified.

Using a modified device violates the Radio
Law.

The handset has acquired the certification of
conformity with technical regulations for the
specified radio station based on the Radio Law, and
the “Technical Conformity Mark ” is printed on the
model nameplate of the handset as a proof. If the
screws of handset are removed and a modification is
given to the inside, the certification of conformity
with technical regulations will become invalid. Never
use the handset without the valid certification. Doing
so violates the Radio Law.

Be careful when using the handset while

driving a motor vehicle.

Using a mobile phone in hand while driving is
regarded as a punishable act.
However, the punishment has no application in
some cases such as when rescuing sick and injured
people or maintaining public safety.

Use the FeliCa reader/writer function only in

Japan.

The FeliCa reader/writer function in the handset
conforms to the domestic radio wave standards.
Using the function overseas may result in
punishment.

Contents/Precautions

21

Never change the basic software improperly.

This may be regarded as a conversion of software
and repairs may be refused.

Be careful not to connect the handset to PC

using the microUSB cable for PC (sample) in
areas where the use of mobile phones is
prohibited.

Power may turn on automatically.

Viewing 3D images

There are individual differences in how

people perceive 3D images.

Keep the display parallel to your eyes when

watching 3D images.

Waterproof/Dust-proof

SH-06D is waterproof to IPX5
standards, and dust-proof to IP5X
the external connector terminal cover is
securely closed as well as the back cover is
attached.

*1 IPX5 means that phone keeps functioning after

being subjected to a jet flow (approximately

12.5 liters/min) discharged from a nozzle (inner

diameter: 6.3 mm), from all directions
(approximately 3 m from the handset) for 3
minutes or more.

*2 IPX7 means that SH-06D phone keeps

functioning after it is slowly submerged to depth
of 1 m in static tap water at room temperature,
left there for approximately 30 minutes and
then taken out.

*3 IP5X means the level of dust protection. Phone

keeps functioning in safety after it is left in the
device containing dust (diameter: 75 μm or
smaller) for 8 hours, agitated and then taken
out.

*1

and IPX7*2

*3

standards if

What you can do with
waterproof/dust-proof of
SH-06D

You can call without using an umbrella in the rain

(for rainfall of approximately 20 mm per hour).

You can rinse off dirt from the handset. Wash the

handset with low-pressure water flow (6 liters/
min or lower and tap water at room temperature
(between 5°C and 35°C)), holding it
approximately 10 cm below faucet or shower
head. Wash by using only your hands, not a
brush or sponge, with the back cover attached,
and the external connector terminal cover held in
position. Drain the handset before use
(nP. 25).

You can use the handset at a poolside. Do not

throw water in a swimming pool on the handset
or soak the handset in the water of a swimming
pool.

You can use the handset in a bathroom. Do not

soak the handset in the bathtub.

Things to keep in mind

To maintain waterproof/dust-proof
performance, check the followings.

Securely close the external connector terminal

cover and the back cover. Be careful not to apply
excessive force on the rubber gasket when
opening and closing them.

Make sure that the external connector terminal

cover and the back cover are completely closed
without floating.

Contents/Precautions

22

To maintain waterproof/dust-proof performance,

the handset has the external connector terminal
cover and the back cover that allow you to close
securely. May cause injuries to your nails or
fingers if you try to open them forcibly.

Opening external connector terminal
cover

Hook your finger into the slot to open.

Slot

Closing external connector terminal
cover

Push and close securely in the direction of the
arrow so that gaps are not left between the handset
and the external connector terminal cover.

Removing back cover

Securely hold the surrounding

1

section of camera, put fingers on
the center of the back cover and
hook the tip of a finger under the
concave portion of the back cover
to remove

Concave portion

Attaching back cover

Confirm the direction of the back

1

cover, adjust it to the direction of
the handset and press the
surrounding section (shaded
section) of the back cover securely
to attach

: Make sure there is no space between the

back cover and the handset.

Contents/Precautions

23

Securely close the back cover. If not closed

securely, the back cover may come off and the
battery pack may fall out due to vibration. May
damage the waterproof/dust-proof performance
and allow water to seep or dust to get in.

The back cover may be damaged if it is inserted

or removed forcibly. Be careful not to apply
excessive force on it.

To maintain waterproof/dust-proof

performance, replacement of parts is required
every 2 years regardless of whether the
handset appears normal or abnormal.
DOCOMO replaces the parts as a chargeable
service. Bring the handset to a repair center
that DOCOMO specifies.

Precautions

When your hands or the handset are wet, do not

attach/remove the back cover or open/close the
external connector terminal cover.

Contents/Precautions

24

Close the external connector terminal cover and

the back cover securely. Even a fine obstacle
(one hair, one grain of sand, tiny fiber, etc.) put
between contact surfaces may allow water to
seep or dust to get in.

If the handset gets wet with water or other liquids

with the external connector terminal cover or the
back cover opened, the liquid may get inside the
terminal causing electric shocks or malfunction.
Stop using the handset, turn off the power,
remove the battery pack and contact a repair
center that DOCOMO specifies.
The rubber gaskets of the external connector
terminal cover and the back cover play an
important role in maintaining waterproof/
dust-proof performance. Do not remove or scratch
them. Also, prevent dust from adhering to them.
If the rubber gasket of the external connector
terminal cover or the back cover is damaged or
deformed, replace it at a repair center that
DOCOMO specifies.

Do not insert sharp objects through external

connector terminal cover and back cover gaps. It
causes damage to the rubber gasket and allow
water to seep or dust to get in.

If the back cover is damaged, replace it. Water

may seep inside from a damaged section
causing troubles such as electric shocks or
corrosion of the battery.

Do not use the handset underwater (including

key operations). May cause malfunction.

Do not apply water flow stronger than allowed

(nP. 22) (over 6 liters/min). May cause
malfunction though SH-06D provides waterproof
performance of IPX5.
Do not let the handset get wet with liquids other than
water at room temperature (between 5°C and 35°C).
Do not wash the handset in a washing machine, etc.
To prevent condensation, do not bring the handset
from a cold place to a bathroom, etc. without
letting the handset warmed to room temperature.

Do not expose the handset to extreme humidity for
long periods. Avoid prolonged use in bathrooms.

Never soak the handset in hot spring water or

water containing soap, detergent or bath powder.
Do not soak the handset in hot water, use it in a
sauna or apply hot air (from a hair dryer, etc.) to it.

Do not soak the handset in seawater.
Do not put the handset directly on sand/dirt.
Do not leave the handset wet. In cold places,

water may freeze and cause malfunction.

The handset does not float on water.
Do not let the handset fall. It may become

scratched and cause the waterproof/dust-proof
performance to degrade.
Do not leave water on the mouthpiece, earpiece
or speaker. Such water may interfere with talking.

Accessories and optional parts are not

waterproof/dust-proof. When the handset is
placed on the accompanying desktop holder, do
not use it in rooms where water is regularly in
use such as bathroom, shower room, kitchen,
lavatory, etc. even if the AC adapter is not
connected to it.

Soap/Detergent/
Bath powder

Seawater Swimming pool

DOCOMO does not guarantee actual operations
under all states. Malfunctions deemed to be
caused by inappropriate operation by the
customer are not covered by the warranty.

Draining water when the
handset gets wet

When the handset is wet, water may flow out
after wiping it off. Drain the water following the
steps below.

Wipe the handset surface with dry

1

and clean cloth, etc.

: If a strap is attached, dry the strap well.

Shake the handset approximately

2

20 times, securely holding it, until
there is no more water splattering

Hot spring Sand/Dirt

Contents/Precautions

25

To drain water off the speaker,
shake the handset with the
speaker turned up

Softly press dry and clean cloth,

3

etc. against the handset to wipe off
water remaining in the mouthpiece,
earpiece, speaker or keys

: Pat the opening with cloth to remove water

because there may be any water remaining
in the grooves of each part.

Wipe off water drained from the

4

handset with dry and clean cloth,
etc.

: Water, if any, remaining in the main body

may ooze up after wiping off.

Charging

Accessories and optional parts are not
waterproof/dust-proof. Check the followings
before and after charging.

Make sure that the handset is not wet. If the

handset is wet or after the handset is wet,
adequately drain it and wipe off water with dry
and clean cloth, etc. before placing in the
desktop holder or opening the external connector
terminal cover.

When the external connector terminal cover is

opened for charging, close the cover securely
after charging. It is recommended that the
desktop holder be used for charging to prevent
water from seeping inside and dust from getting
in from the external connector terminal.

Never try to charge the battery pack when the

handset is wet.

Do not touch the AC adapter or the desktop

holder with your wet hands. May cause electric
shock.

Do not use AC adapters or desktop holders in a

place subject to water. Do not use the AC
adapter or desktop holder in rooms which water
is regularly in use such as bathroom, shower
room, kitchen, lavatory, etc. May cause fire or
electric shock.

Contents/Precautions

26

Before Using the Handset

Part names and functions

Before Using the Handset

27

Using earphone/microphone

Earphone/
Microphone
plug

Earphone/
Microphone
terminal

Connector
section

Earphone Plug Cable
(with Antenna) SH01

Open external
connector
terminal cover

If you use an earphone/microphone which is not
compatible with the external connector terminal,
connect the handset to the commercially
available earphone/microphone with the
accompanying Earphone Plug Cable (with
Antenna) SH01 before use.
For compatible earphones/microphones, refer

to the following website.

(http://k-tai.sharp.co.jp/support/d/sh-06d/

peripherals.html#!/earphone_support) (in
Japanese only)

1 Sub camera
2 Charger terminal

Use for charging with the accompanying

desktop holder.

3 Power supply terminal

Use for supplying radio waves of Mobacas

from the desktop holder.

4 Display/Touch panel
5 Strap hole
6 Earpiece

Before Using the Handset

28

7 Proximity sensor/Brightness sensor

The proximity sensor detects the distance to

the face and prevents inadvertent operation of
touch panel during a call.

The brightness sensor detects the brightness

of the surrounding area and adjusts the
brightness of the backlight.

8 Incoming/Charging lamp

The lamp will illuminate/flash according to the

function being used and situation.

9 Mouthpiece/Microphone
a z: Menu key

Displays available functions (menus) in a

screen.

b |: Home key

Displays the main page of the home screen.

c {: Back key

Returns to the previous screen.

d Main camera
e Mobile light
f H: Power key

Use to turn the power on/off, etc.
Use to set/disable the sleep mode.

g x/y: Volume UP/DOWN key

Adjusts the volume in each function.

h FOMA antenna
i External connector terminal
j Infrared port
k a mark

IC card is contained (It cannot be removed).

l microSD Card slot
m docomo mini UIM card slot
n 1Seg/Mobacas antenna
o Back cover
p Speaker

Ring tone, music, etc. can be heard from

here.

The other party’s voice can be heard from

here during a hands-free call.

*2

*1
