DNF Controls ST100-CP User Manual

12843 Foothill Blvd. Suite C
Sylmar, California 91342
V: 818.898.3380
F: 818.898.3360
[e-mail]

MODEL No. ST100-CP

CONTROL PANEL PROTOCOL

User Manual

Table of Contents

1. REVISION HISTORY 3

2. COMMUNICATION DATA FORMAT 3

3. ELECTRICAL INTERFACE 3

4. COMMUNICATIONS PROTOCOL 4

5. COMMANDS 5

6. DNF CONTROLS LIMITED WARRANTY 6

Manual Version: ………………………………….. 2.2 092005

Document ID: ……………..…….. ST100-CP_User_Manual.doc

SSTT110000--CCPP UUsseerr MMaannuuaall

PPaaggee 22 ooff 66

1. REVISION HISTORY

010504 Rev. 2.1 Company header information revised.
Added DNF Controls Limited Warranty.

092005 Rev. 2.2 Correct interface connector signal flow.

2. COMMUNICATION DATA FORMAT

Baud Rate = 38400
Data = 8 bits
Parity = ODD
Stop = 1

3. ELECTRICAL INTERFACE

RS422 Serial Connector RS232 Serial Connector
9-Pin D-Type, Female 9-Pin D-Type, Female

Pin # 1 Frame Ground
2 Transmit A Î Receive Data Í
3 Receive B Í Transmit Data Î
4 Transmit Common
5 Spare Ground
6 Receive Common
7 Transmit B Î
8 Receive A Í
9 Frame Ground

SSTT110000--CCPP UUsseerr MMaannuuaall

PPaaggee 33 ooff 66

4. COMMUNICATIONS PROTOCOL

The Control System (CS) will initiate ALL communications with the ST100 except as noted
below. The ST100 will respond to CS commands within 20 milliseconds after complete receipt of
a command.

The ST100 will transmit data to the CS, without CS initiation, under the following three (3)
conditions:

a) Upon completion of Power Up of the ST100, it will transmit ASCII "P" + 00H. No

response from the CS is expected.

b) Upon detection of a key press or key release, the ST100 will transmit the current state of

the key switches - ASCII "S" + Data Byte. No response from the CS is expected. See
Switch Data Byte Chart below.

c) Upon detection of Shuttle Wheel motion, the ST100 will transmit ASCII "W" + ASCII

"Z" for clockwise motion, or ASCII "W" + ASCII "z" for counter-clockwise motion. No
response from the CS is expected.

SSTT110000--CCPP UUsseerr MMaannuuaall

PPaaggee 44 ooff 66

5. COMMANDS

These commands are transmitted by the CS to the ST100. The ST100 will respond with ACK (40H), NAK
(80H) or the appropriate Status information.

LED ON/OFF: ASCII "L" + MSB LED Data Byte + LSB LED Byte
(See LED Data Byte Chart)

The ST100 will respond with ACK (40H) or NAK (80H). The LED Data Bytes
will determine the ON/OFF state of each LED.

KEYBOARD QUERY: ASCII "K"

The ST100 will respond with NAK (80H) or ASCII "K" + Switch Data Byte.
The Switch Data Byte represents the current status of the keypad. See Switch
Data Byte Chart below.

MESSAGE DISPLAY: ASCII "D" + ROW + 16 Character Message
ROW: "1" = top row of the display
"2" = bottom row of the display

16-Character Message will consist of 16 printable ASCII characters. The
message MUST contain 16 characters.

The ST100 will respond with ACK (40H) or NAK (80H).

SWITCH DATA BYTE: Pressed = 1 Not Pressed (Released)=0
Bit7= Switch #7 (Shift Key)
Bit6= Always 0
Bit5= Switch #6
Bit4= Switch #5
Bit3= Switch #4
Bit2= Switch #3
Bit1= Switch #2
Bit0= Switch #1

LED DATA BYTE: LED ON= 1 LED OFF= 0

Bit7= Don't Care
Bit6= Don't Care
Bit5= LED #6
Bit4= LED #5
Bit3= LED #4
Bit2= LED #3
Bit1= LED #2
Bit0= LED #1

MSB:

SSTT110000--CCPP UUsseerr MMaannuuaall

PPaaggee 55 ooff 66

6. DNF CONTROLS LIMITED WARRANTY

DNF Controls warrants its product to be free from defects in material and workmanship for a period of one
(1) year from the date of sale to the original purchaser from DNF Controls.

In order to enforce the rights under this warranty, the customer must first contact DNF’s Customer Support
Department to afford the opportunity of identifying and fixing the problem without sending the unit in for
repair. If DNF’s Customer Support Department cannot fix the problem, the customer will be issued a
Returned Merchandise Authorization number (RMA). The customer will then ship the defective product
prepaid to DNF Controls with the RMA number clearly indicated on the customer’s shipping document.
The merchandise is to be shipped to:

DNF Controls
12843 Foothill Blvd., Suite C
Sylmar, CA 91342
USA

Failure to obtain a proper RMA number prior to returning the product may result in the return not being
accepted, or in a charge for the required repair.

DNF Controls, at its option, will repair or replace the defective unit. DNF Controls will return the unit
prepaid to the customer. The method of shipment is at the discretion of DNF Controls, principally UPS
Ground for shipments within the United States of America. Shipments to international customers will be
sent via air. Should a customer require the product to be returned in a more expeditious manner, the return
shipment will be billed to their freight account.

This warranty will be considered null and void if accident, misuse, abuse, improper line voltage, fire, water,
lightning or other acts of God damaged the product. All repair parts are to be supplied by DNF Controls,
either directly or through its authorized dealer network. Similarly, any repair work not performed by either
DNF Controls or its authorized dealer may void the warranty.

After the warranty period has expired, DN F C ont r ol s offers repair services at prices listed in the DNF
Controls Price List. DNF Controls reserves the right to refuse repair of any unit outside the warranty
period that is deemed non-repairable.

DNF Controls shall not be liable for direct, indirect, incidental, consequential or other types of damage
resulting from the use of the product.

# # #
