Model No. 2034CL-O-PBIO
(& 2034CL-O-T)
300 CLIP INSTANT ACCESS SYSTEM
Odetics Protocol
With Peripheral Bus Interface Option
VERSION 3.1 SOFTWARE
User Manual
1 2034CL-O, Vs. 3.1, 300 Clip Instant Access System, Odetics Protocol,
PBIO Option
TABLE OF CONTENTS
REVISION
GETTING STARTED . . . 5
1. SYSTEM DESCRIPTION 5
2. SYSTEM INSTALLATION 6
3. VIDEO SERVER SETUP 9
4. LOAD
6. VIEW
1. LEARN A CLIP OR CLIP COMBINATION 10
8. RECALL A CLIP OR CLIP COMBINATION 12
9. RECUE THE CURRENTLY LOADED CLIP 13
10. PLAY CLIP 13
11. LOOP CLIP 13
12. TRIGGER 14
13. SETTING THE IN (OUT) POINTS 15
14. CREATE CUE POINT LABELS 15
15. BVW MODE 16
16. LEARN A CLIP OR CLIP COMBINATION (BVW MODE) 17
HISTORY 4
A CLIP 9
THE CLIP ID OF THE CURRENTLY LOADED CLIP 10
ADVANCED FEATURES . . . 18
17. CREATING A CLIP 18
18. CAPTURE FUNCTION 18
19. VIEW SHOTBOX SHOTKEY ASSIGNMENTS 19
20. SHOTBOX SHOTKEY MAPS 20
21. SHOTBOX
CONTROL SWITCHES 20
22. CLEAR SINGLE CUEPOINT 20
23. TRANSFER CUE LIST 21
REFERENCE . . . 23
24. SETUP MENU 23
25. FUNCTION
TABLE 26
26. SPECIFICATIONS 28
27. TROUBLESHOOTING 30
28. KEY LAYOUT 31
29. DNF
CONTROLS LIMITED WARRANTY 32
2 2034CL-O, Vs. 3.1, 300 Clip Instant Access System, Odetics Protocol,
PBIO Option
Manual Version.........….….........….……......................... 1.71 060607
Document ID....................... 2034CL-O-PBIO_Vs.3.1_User_Manual
3 2034CL-O, Vs. 3.1, 300 Clip Instant Access System, Odetics Protocol,
PBIO Option
REVISION HISTORY
122702 Rev. 1.1 Corrected LOOP CLIP section.
050103 Rev. 1.2 Added Parity Setup to PBIO initialization.
Corrected Connection Diagram.
070903 Rev. 1.3 Added Play Clip, BVW Mode section.
Added Gang and Autorecue setup to Setup Menu section.
110403 Rev. 1.4 Added DNF Controls Limited Warranty.
Updated Receive Cue List & Transmit Cue List Function description.
012204 Rev. 1.5 Changed Key Layout.
080304 Rev. 1.6 Added LEARN A CLIP OR CLIP COMBINATION (BVW MODE)
section.
101404 Rev. 1.7 Updated Section CREATING A CLIP.
060607 Rev. 1.7 1 Added Clip Label function.
4 2034CL-O, Vs. 3.1, 300 Clip Instant Access System, Odetics Protocol,
PBIO Option
Getting Started . . .
1. SYSTEM DESCRIPTION
The 300 Clip Instant Access System consists of the ST300-SSM VTR Controller, STS420
Shotbox, and Shotlist Software.
The Video Server must support Odetics Broadcast Protocol.
SHOTLIST provides fast access to existing video clips stored on Grass Valley Group PROFILE,
Leitch VR or other DDR, VDR, Video Servers supporting Odetics Broadcast Protocol.
The SHOTLIST can contain up to 300 CLIP IDs, stored in non-volatile memory in the ST300.
Remotely view the CLIP IDs that exist in the Video Server under control. Desired clips can be
MARKED into the SHOTLIST at a single location or at multiple locations.
Any clip in the SHOTLIST can be quickly loaded by simply entering the associated 3-digit
number of its location, then pressing [LOAD]. Press [PLAY] to play the clip. Press [RECUE] to
recue to the beginning of the clip or to the “recalled” time if defined.
The PERIPHERAL BUS INTERFACE Option for the ST300 VTR Controller is special software
in the ST300. With this Option, the ST300 has 4 Peripheral Device Addresses, one for each VTR
that it controls. This allows the production switcher to control any and all VTRs connected to the
ST300.
Upon receipt of the Learn command from the production switcher, the ST300 saves the CLIP IDs
of the currently loaded clips, the current time of each clip, the VTRs they are loaded on and the
current GANG mode into the appropriate Cue Point.
When the Recall command is received, the ST300 loads the “Learned” Clips onto the “Learned”
VTRs, cues the Clip to the “Learned” time, then restores the “Learned” GANG mode.
Learn & Recall may also be done directly from the ST300 without the production switcher.
The Trigger function on the production switcher puts the selected VTRs into Play, Stop, Recue or
other available modes.
DEFINITIONS
Throughout this document VTR, DDR, VDR & Video Server will be referred to collectively
as “Video Server.”
The ST300-S/SM as the ST300.
The ST420 SHOTBOX is referred to as “SHOTBOX.”
“SHOTKEY” refers to the 1-30 switches on the SHOTBOX.
Words surrounded by brackets, for example, [ENTER], are keys on the ST300 or the
SHOTBOX. [XXX] + [XXX] means hold the two keys down simultaneously.
5 2034CL-O, Vs. 3.1, 300 Clip Instant Access System, Odetics Protocol,
PBIO Option
2. SYSTEM INSTALLATION
a. SHOTBOX
1) Plug one end of a standard 9-pin, RS422 serial cable, into the
OUTPUT connector on the rear of the SHOTBOX. Plug the other end
of the cable into the AUX connector on the rear of the ST300.
2) Connect the Ault Model #SW300 POWER SUPPLY into the POWER
connector on the rear of the SHOTBOX. Plug the Power Supply into an outlet,
90 VAC – 240 VAC.
b. ST300-S/SM, VTR/DDR CONTROLLER
1) Plug one end of a 9-conductor, RS422 serial cable into the VTR 1 (2 or 3)
connector on the rear of the ST300. Plug the other end of the cable into the
REMOTE connector on the Video Server.
2) Connect the supplied POWER SUPPLY, APX#4108, into the POWER
connector on the rear of the ST300. Plug the Power Supply into an outlet, 90
VAC – 240 VAC.
3) Check SETUP MENU prior to using the ST300 to confirm proper Record mode
and other User settable modes.
4) Select CONTROL MODE = ODETICS.
(See menu description.)
6 2034CL-O, Vs. 3.1, 300 Clip Instant Access System, Odetics Protocol,
PBIO Option
c. PRODUCTION SWITCHER
1) Connect a RS422, 9-pin serial cable to the VTR4 connector on the rear of the
ST300, using the supplied Turnaround Adapter. Connect the other end of the
cable to the Peripheral Bus Connector on the production switcher.
(Communication Format- 38.4K, 8,1)
2) To select a Production Switcher type (Default = Grass Valley Group).
a) Press [MENU] and turn the Wheel until “SWITCHER” is displayed.
b) Press softkeys to select between Sony and GVG.
c) Press [ESC] at anytime to exit MENU mode.
3) The ST300 has 4 Peripheral Device Addresses, one for each VTR that it
controls.
To set the Device Address for each VTR:
a) Press [MENU] and turn the wheel until “Peripheral Address” is
displayed.
b) Press VTR[1], VTR[2] or VTR[3] to select a VTR.
c) Assign a Peripheral Device Address for that VTR, from 0 to 23, by
entering the desired address using the numeric keypad.
OR
Press [DEL] to turn off the device.
d) Select the next VTR and assign a Peripheral Device Address for it.
e) When done, press [ESC] to exit MENU mode.
4) Select Parity to match the Parity of the Production Switcher.
a) Press [MENU] and turn the wheel un til “PARITY” is displayed.
b) Press softkeys to select Odd, Even or None. The Parity must match
Production Switcher’s parity.
c) Press [ESC] to exit Menu Mode.
5) Enable PBIO.
Press [PBIO] key. The LED above the key turns ON when PBIO is enabled. It
is OFF when it is disabled.
Installation is complete.
7 2034CL-O, Vs. 3.1, 300 Clip Instant Access System, Odetics Protocol,
PBIO Option
8 2034CL-O, Vs. 3.1, 300 Clip Instant Access System, Odetics Protocol,
PBIO Option
3. VIDEO SERVER SETUP
a. Select ODETICS Broadcast communications protocol on the VIDEO SERVER to be
controlled.
b. Assign a serial port on the VIDEO SERVER through which the ST300 will control the
server.
NOTES: The VIDEO SERVER may not support LTC or VITC time modes in ODETICS
Broadcast mode. The ST300 will default to Tape Time if a non-supported time mode is selected
on the ST300.
The Grass Valley Group PROFILE does not
(LTC or VITC) in ODETICS Protocol. Tape Time mode (TM) must be selected on the ST300.
In ODETICS Broadcast mode, the VIDEO SERVER may O
ASSEMBLE record modes may be disabled.
Setup is complete.
4. LOAD A CLIP
Only available in Odetics Control Mode.
a. Select a VTR by pressing VTR[1], VTR[2], or VTR[3].
b. Press [CLIP LIST] to view the list of CLIP IDs that are resident on the Video Server.
The CLIP LIST indicator will turn on.
c. Press [LOAD] to create and load a new clip.
(Creating a clip is described in the CREATING A CLIP section.)
OR
Turn the Wheel to view the existing CLIP IDs on the video server.
Turn the Wheel clockwise to scroll forward, or counter-clockwise to scroll backward,
through the list of available CLIPs. Backward scrolling is limited to the last 10 CLIP IDs
viewed.
OR
Manually enter a CLIP ID using the ST300 numeric keypad, or PC keyboard (if KBIO
option).
OR
Manually enter a Clip ID using the Qwerty keyboard on SHOTBOX.
support search to a time location using Timecode
NLY allow Full Record. INSERT and
9 2034CL-O, Vs. 3.1, 300 Clip Instant Access System, Odetics Protocol,
PBIO Option
d. Press [LOAD] to load the selected CLIP ID for playout.
e. Locate the clip to the desired IN time. Press [IN] to mark the IN time.
f. Locate the clip to the desired OUT time. Press [OUT] to mark the OUT time.
g. Repeat steps a. – f. until clips are loaded into the desired VTRs.
h. Set the GANG mode, if required.
6. VIEW THE CLIP ID OF THE CURRENTLY LOADED
CLIP
Press [SHIFT] + [LOAD]. The bottom line will show the name of the loaded clip.
1. LEARN A CLIP OR CLIP COMBINATION
a. LEARN ON THE PRODUCTION SWITCHER
1) On ST300, Load a clip(s) on the desired VTR(s). (See “LOAD A CLIP”
section.) (Only for Odetics Control Mode.)
2) Select and enable the Peripheral Device Addresses for the ST300.
3) Do a LEARN to the desired REGISTER.
The ST300 will: LEARN (save) the VTR number, loaded CLIP ID and current
IN and OUT time into the REGISTER number in the ST300.
In BVW mode, the clip ID is not learned.
b. LEARN ON THE SHOTBOX
1) Load clip(s) on the desired VTRs. (See “LOAD A CLIP” section.)
(Only in Odetics Control Mode.)
2) Press [LEARN]. The LEARN indicator will turn on.
3) Select the desired BANK and ShotKey.
4) Press [LEARN] to exit at anytime.
NOTE: The [LEARN] key toggles LEARN mode on/off.
The controller will: LEARN (save) the VTR Number (1,2,3), loaded CLIP ID and
current IN and OUT time to the selected Cue Point.
In BVW mode, the clip ID is not learned.
10 2034CL-O, Vs. 3.1, 300 Clip Instant Access System, Odetics Protocol,
PBIO Option
c. LEARN ON THE ST300
1) Load a clip(s) on the desired VTR(s). (See “LOAD A CLIP” section.)
(Only in Odetics Control Mode.)
2) Select the desired Cue Point by pressing [NEXT CUE], [LAST CUE] or by
manually entering the Cue Point using the numeric keypad.
The selected Cue Point number is shown on the bottom line of the display.
3) Press [SHIFT] + [MARK] to start the LEARN.
The first line of the display will show “Select VTRs:”
The second line of the display will show “Mark-Lrn, ESC-cancel.”
4) Press VTR[1], VTR[2] or VTR[3] to select the VTR to be learned into the
current Cue Point.
If the VTRs are ganged, select one VTR that is part of the Gang. The rest of the
Gang will learn automatically.
5) Press [MARK] to co mplete the LEARN.
OR
Press [ESC] to exit without LEARNING.
The ST300 will: LEARN (save) the VTR Number (1,2,3), loaded CLIP ID and
current IN & OUT time to the selected Cue Point.
In BVW mode, the Clip ID is not learned.
11 2034CL-O, Vs. 3.1, 300 Clip Instant Access System, Odetics Protocol,
PBIO Option
8. RECALL A CLIP OR CLIP COMBINATION
a. RECALL ON THE PRODUCTION SWITCHER
RECALL the desired REGISTER NUMBER.
The ST300 will automatically load the Learned clips on the Learned VTRs, cue the clips
to the Learned time, then set the Learned GANG mode.
In BVW mode, Clips are not loaded, the video is positioned to learned IN point.
b. RECALL ON THE SHOTBOX
1) Select the desired Bank.
2) Press the desired shotkey.
The ST300 will automatically load the learned clips on the learned VTRs, cue
the clips to the Learned time, then set the Learned Gang Mode.
In BVW mode, Clips are not loaded, the video is positioned to learned IN point.
c. RECALL ON THE ST300
1) Select the desired Cue Point by pressing [NEXT CUE], [LAST CUE] or
by manually entering the Cue Point using the numeric keypad.
The selected Cue Point number is shown on the bottom line of the display.
2) Press [LOAD] on the ST300.
The ST300 will automatically load the Learned clips on the Learned VTRs, cue
the clips to the Learned time, then set the Learned GANG mode. If RECALL
MODE in the Setup Menu is set to REDIR, and a cue point contains only one
clip, then the clip will be REDIRECTED to load on the currently selected VTR,
not the Learned VTR.
In BVW mode, Clips are not loaded, the video is positioned to learned IN point.
12 2034CL-O, Vs. 3.1, 300 Clip Instant Access System, Odetics Protocol,
PBIO Option
9. RECUE THE CURRENTLY LOADED CLIP
Press [RECUE]. If an IN Point is marked (the IN indicator is on), the clip will RECUE to the IN
Point.
If the IN point is not marked, the clip will RECUE to the start of the clip.
OR
Press [SHIFT] + [RECUE].
a. Enter the desired time to search to using the ST300’s numeric keypad.
b. Press [ENTER] to search to the entered time.
OR
Press [ESC] to exit without searching.
10. PLAY CLIP
a. Load a clip from Cliplist or Recall a learned clip.
b. Mark IN (OUT) points if desired. (See Section 13, “SETTING THE IN (OUT)
POINTS.”)
c. Press [PLAY].
The clip will play from the current point to the OUT point or, if no OUT point is marked,
to the end of the clip.
If Autorecue Option is ON (see Setup Menu), the clip will recue to the IN point (or the
beginning of the clip) once the OUT point (or the end of the clip) is reached.
11. LOOP CLIP
Only available in Odetics Control Mode.
a. LOAD a clip from CLIPLIST or RECALL a learned clip.
b. Press [LOOP ENABLE] to a load ed clip. The LOOP ENABLE indicator will turn on.
The second line of the display will show “Looping clip . . .”
c. Press [STOP] to stop the loop play.
If the clip ID ends with an asterisk (“*”), it will automatically loop when either [LOOP
ENABLE] or [PLAY] is pressed.
13 2034CL-O, Vs. 3.1, 300 Clip Instant Access System, Odetics Protocol,
PBIO Option
12. TRIGGER
The operator fires a trigger using either the Timeline or Run function on the production switcher.
The ST300 puts the Video Server into the following modes based upon the trigger value:
GRASS VALLEY GROUP VALUES
Trigger Value Mode
0 Play
1 Recue to beginning of clip
2 Slo-mo using ST300 Wheel Preset or T-Bar Speed
3 Reverse Play
4 Still Frame
5 Loop
6 Record
7 or greater Play
SONY VALUES
Trigger Value Mode
0 Recue to beginning of clip
1 Play
2 Slo-mo using ST300 Wheel Preset or T-Bar Speed
3 Reverse Play
4 Still Frame
5 Loop
6 Record
7 or greater Play
To control more than one VTR, enable the Peripheral Device Address for the required VTRs. The
Trigger will be sent to the enabled devices.
OR
GANG the required VTRs on the ST300. Refer to the Function Table for GANG instructions.
Enable the Peripheral Device Address for one of the GANGed VTRs. The Trigger will be sent to
the enabled VTR. The other VTRs in the GANG will perform the same action.
14 2034CL-O, Vs. 3.1, 300 Clip Instant Access System, Odetics Protocol,
PBIO Option
13. SETTING THE IN (OUT) POINTS
a. MARKING THE IN (OUT) POINTS
1) Locate the clip to the desired IN (OUT) time.
2) Press [IN] ([OUT]) to set the IN (OUT) Point. The IN (OUT) indicator will
turn on.
The display will show “IN (OUT) xx:xx:xx:xx” where xx:xx:xx:xx is the saved
time.
b. ENTERING THE IN (OUT) POINTS
1) Press [SHIFT] + [IN] ([OUT]) to manually enter a new IN (OUT) time.
2) Press [ENTER] to save the entered time or press [ESC] to exit without saving.
OR
Press [RECUE] to search to viewed point.
c. VIEWING THE IN (OUT) POINTS
When the IN (OUT) indicator is on,
press [IN] ([OUT]) to view the existing IN (OUT) Point.
d. CLEARING THE IN (OUT) POINTS
Press and hold [DEL], then press and release [IN] ([OUT]).
The IN (OUT) indicator goes off.
14. CREATE CUE POINT LABELS
Use LABEL mode to assign meaningful names to cue points. Rather than viewing cryptic CLIP
IDS on the Shotkeys, LABEL provides a faster and easier method to select cue points.
ON THE ST300
a. Select cue point to label.
b. Press the [SHIFT] + [CLIPLIST]
c. Manually enter a label, up to 12 characters in length, using the numeric keypad,
ST420 Shotbox QWERTY Keyboard, or PC keyboard. (KBIO OPTION)
d. Press the [LOAD] shotkey on the Shotbox to assign the entered label to the
selected cue point
OR
[ENTER] on the ST300
OR
[ENTER) on the PC Keyboard (KBIO OPTION)
OR
[ESC] to exit without save
NOTE: Labels are saved in non-volatile memory in the ST300, not in the Shotbox. They are not
saved in the video server.
15 2034CL-O, Vs. 3.1, 300 Clip Instant Access System, Odetics Protocol,
PBIO Option
15. BVW MODE
If you wish to control a tape machine or a DDR with the 2034CL-O system, select control
MODE=BVW (see Setup Menu section). In this mode, the media is accessed by timecode, not by
clip names. The cuepoints in BVW mode consist only of IN point, OUT point and Gang
information.
The following functions are not available in BVW mode:
- View Clip ID
- Recue Clip
- Loop Clip
- Capture
- Create Clip
All other functions work as described in the manual.
16 2034CL-O, Vs. 3.1, 300 Clip Instant Access System, Odetics Protocol,
PBIO Option
16. LEARN A CLIP OR CLIP COMBINATION (BVW
MODE)
a. Select the desired Cue Point by pressing [NEXT CUE], [LAST CUE], or by manually
entering the Cue Point using the numeric keypad.
The selected Cue Point number is shown on the bottom line of the display.
b. Locate the clip to the desired IN time. Press [IN] to mark the IN time.
c. Locate the clip to the desired OUT time. Press [OUT] to mark the OUT time.
d. Press [SHIFT] + [MARK] to start the LEARN.
The first line of the display will show “Select VTRs:”
The second line of the display will show “Mark-Lrn, ESC-cancel.”
e. Press VTR[1], VTR[2], VTR[3] or VTR[4] to select the VTR to be learned into the
current Cue Point.
If the VTRs are ganged, select one VTR that is part of the Gang. The rest of the Gang
will learn automatically.
f. Press [MARK] to complete the LEARN.
OR
Press [ESC] to exit without LEARNING.
The ST300 will: LEARN (save) the VTR number (1,2,3,4) and current IN & OUT time
to the selected Cue Point.
17 2034CL-O, Vs. 3.1, 300 Clip Instant Access System, Odetics Protocol,
PBIO Option
Advanced Features . . .
17. CREATING A CLIP
Only available in Odetics Control Mode.
a. Press [CLIP LIST]. The display will show “CREATE NEW CLIP.”
b. Press [LOAD]. The display will show the default CLIP ID.
c. Press [ENTER] to accept the default CLIP ID.
OR
Enter an ID wi th a maximum of 8 characters using the SHOTBOX’s Qwerty.
NOTE: For numbers on the SHOTBOX keyboard, use bank keys 0-9.
OR
Enter a numeric ID with a maximum of 8 characters using the ST300’s numeric keypad.
d. Press [ENTER] on the ST300 to create the selected CLIP ID.
e. If the selected CLIP ID already exists, a warning message will be displayed. To load the
existing clip, press [ENTER]. Press [ESC] to exit without loading the existing clip.
18. CAPTURE FUNCTION
Only available in Odetics Control Mode.
The CAPTURE function allows source material from a VTR to be easily and quickly recorded
into the VIDEO SERVER. A CLIP ID is also created.
VTR1 is always the Recorder (the VIDEO SERVER).
Select VTR[2] or VTR[3] as the source VTR. Any RS422, SONY protocol compatible VTR can
be used.
Use the transport function keys to control the source VTR. Each source VTR has its own set of
IN and OUT points.
a. ENTER PREROLL VALUE
1) Press [MENU] and turn the Wheel to “Enter PREROLL:”
2) Enter the desired preroll value using the ST300’s numeric keypad.
3) Press [ENTER] to save the entered value.
OR
Press [ESC] to exit without saving.
18 2034CL-O, Vs. 3.1, 300 Clip Instant Access System, Odetics Protocol,
PBIO Option
b. EXECUTE CAPTURE FUNCTION
1) Press VTR[2] or VTR[3] to select the source VTR.
2) Set IN and OUT points as described in “SETTING THE IN (OUT) POINTS”
section on the source VTR.
3) Press [SHIFT] + [RECORD]. Th e display will prompt you for a CLIP ID. A
default CLIP ID will be shown.
4) Press [LOAD] to accept the default CLIP ID.
OR
Enter a name with a maximum of 8 characters using the SHOTBOX
Qwerty keyboard.
OR
Use [NEXT CUE], [LAST CUE] and Wheel to edit the CLIP ID. Use
the [NEXT CUE] and [LAST CUE] keys to position the cursor. Turn
the Wheel to select the desired letter.
OR
Manually enter a numeric ID using the numeric keypad.
Press [LOAD] to accept the CLIP ID. The ST300 will create the new
CLIP ID on the Video Server.
The Source VTR will preroll to the IN Point, then play. At the source VTR’s IN
point, the RECORDER will go into record.
At the Source VTR’s OUT point, the RECORDER will terminate record, postroll for 2 seconds, then stop.
The Source VTR will search to the OUT point and stop. The OUT point will be
cleared. The IN indicator will stay on. The OUT indicator will turn off.
19. VIEW SHOTBOX SHOTKEY ASSIGNMENTS
a. Press and hold [VIEW]. The VIEW indicator comes on.
b. Press and hold the desired shotkey.
c. The switch turns RED and the content (CLIP ID) is displayed on a virtual display.
For Example:
NOTE: All the remaining switches are not illuminated.
d. Release the keys to return to normal operation.
19 2034CL-O, Vs. 3.1, 300 Clip Instant Access System, Odetics Protocol,
PBIO Option
VTR 1
Clip 23
VTR 2
Clip 13
VTR 3
Clip 77
VTR 4
No Assignment
20. SHOTBOX SHOTKEY MAPS
The SWITCHES on the SHOTBOX access the SHOTLIST locations as follows:
BANK 0, SWITCHES 1 Î 30 access Cue Points 001 Î 030 and e-mem registers 1 - 30.
BANK 1, SWITCHES 1 Î 30 access Cue Points 101 Î 130 and e-mem registers 31 - 60.
BANK 2, SWITCHES 1 Î 30 access Cue Points 201 Î 230 and e-mem registers 61 - 90.
BANK 3, SWITCHES 1 Î 09 access Cue Points 301 Î 309 and e-mem registers 91 - 99.
MARK 3, SWITCHES 10 Î 30 access Cue Points 310 - 330
BANK 4, SWITCHES 1 Î 50 access Cue Points 401 Î 430.
BANK 5, SWITCHES 1 Î 30 access Cue Points 501 Î 530.
BANK 6, SWITCHES 1 Î 30 access Cue Points 601 Î 630.
BANK 7, SWITCHES 1 Î 30 access Cue Points 701 Î 730.
BANK 8, SWITCHES 1 Î 30 access Cue Points 801 Î 830.
BANK 9, SWITCHES 1 Î 30 access Cue Points 901 Î 930.
21. SHOTBOX CONTROL SWITCHES
a. [PLAY]: Plays out the selected clip.
b. [RECUE]: Returns to the beginning of the clip.
d. [STOP]: Stops playout of the clip.
e. [SHIFT] + [SHOTKEY]: Clears the contents of the pressed shotkey.
22. CLEAR SINGLE CUEPOINT
On the Shotbox, press [SHIFT] + the Shotkey, the content of which you wish to clear.
The Shotkey becomes blank, the corresponding cuepoint is cleared.
20 2034CL-O, Vs. 3.1, 300 Clip Instant Access System, Odetics Protocol,
PBIO Option
23. TRANSFER CUE LIST
a. TRANSMIT CUE LIST FUNCTION
The TRANSMIT CUE LIST function allows you to transmit your list of Cue Points to a
PC, using the provided utility software on the PC, or to another ST300. Transfer to a PC
requires OpSuite 3.0 software, which runs on a Windows-based computer. Contact DNF
Controls for more information.
1) To Transmit Cue Points to Another ST300:
a) Connect the VTR4 connector on the rear of the ST300 to the VTR4
connector of the receiving ST300 using an RS422 9-pin cable with TX
and RX lines crossed. (A “turnaround” cable.)
b) Press [MENU].
c) Scroll the Wheel until “Tran s mit CUE list? YES=Enter, Exit=ESC” is
displayed.
d) Press [ENTER] to start transmitting. The Display shows “Waiting to
transmit” on the first line.
e) When the Receiver is ready, transfer starts automatically. The Display
now shows “Transmitting cuelist.”
f) After the transfer is over, the display shows “Transfer is over” for one
second and then shows “Waiting to transmit” again.
g) Connect another ST300 to transmit the list again.
OR
Press [ESC] twice to exit the MENU mode.
2) To Transmit Cue Points to a PC:
a) Connect the VTR4 connector on the back of the ST300 to one of the
COM ports on the PC using a RS422 to RS232 adapter.
b) Repeat steps b) thru g) of “To Transmit Cue Points to Another
ST300” section.
21 2034CL-O, Vs. 3.1, 300 Clip Instant Access System, Odetics Protocol,
PBIO Option
b. RECEIVE CUE LIST FUNCTION
The RECEIVE CUELIST function allows you to receive a list of Cue Points from a PC
or from another ST300. Transfer to a PC requires OpSuite 3.0 software, which runs on a
Windows-based computer. Contact DNF Controls for more information.
1) To Receive Cue Points From Another ST300
a) Connect the VTR4 connector on the back of the ST300 from the VTR4
connector of the transmitting ST300 using RS422 9-pin cable with TX
and RX lines crossed.
(A “Turnaround” Cable)
b) Press [MENU].
c) Scroll the Wheel until “Receive CUE List? YES=Enter, Exit=ESC” is
displayed.
d) Press [ENTER] to start receiving.
The Display shows “Waiting to receive” on the first line.
e) When the Transmitter is ready, transfer starts automatically.
The Display now shows “Receiving cuelist.”
f) After the transfer is over the display shows “Done-Success! Press any
key…”
g) Press any key. The display shows “Receive cuelist?” message.
h) Press [ESC] to exit the MENU mode.
2) To Receive Cue Points From the PC
a) Connect the VTR4 connector on the back of the ST300 to one of the
COM ports on the PC using RS422 to RS232 adapter.
b) Repeat steps b) – h) of “To Receive Cue Points From Another
ST300” section.
22 2034CL-O, Vs. 3.1, 300 Clip Instant Access System, Odetics Protocol,
PBIO Option
Reference . . .
24. SETUP MENU
Press [MENU]. The MENU indicator will turn on.
Turn the Wheel to select item to change.
Press [MENU] OR use the Softkeys to change the desired mode for that option.
Turn the Wheel at anytime to select another item.
Press [ESC] at anytime to exit SETUP MENU. The MENU indicator will turn off.
MENU MODES
RECORD
WIND
MODE
SLOMO
(Turning Wheel Clockwise)
Press Softkey to select the desired record mode:
Assemble, Insert, Lockout or Crash (Full).
Press Softkey to select:
HOLD (fast wind is maintained only while key is depressed).
OR
LATCH (fast wind is initiated and maintained with momentary key press).
Select fast wind speed (03.9X, etc.) by pressing Softkey.
ST300 display shows
(Non T-Bar version):
ST300 display shows
(T-Bar version):
Press Softkey [TBAR] (or [WHEEL]) to toggle between T-BAR and WHEEL.
NOTE - The T-BAR has a fixed speed range of 0 Æ +200 with a detent at +100% play speed.
For Wheel only
Press Softkey [SPDRANGE] to select SLOMO speed ranges:
Press Softkey to select 0 Æ +200 OR –100 Æ +200.
Press Softkey [BACK] to return to SLOMO MENU.
Press [ESC] to exit SETUP MENU.
OR turn the Wheel to select another item.
(Continued on next page.)
:
SLOMO with: WHEEL
SpdRange Preset
SLOMO with: TBAR
Wheel SpdRange Preset
23 2034CL-O, Vs. 3.1, 300 Clip Instant Access System, Odetics Protocol,
PBIO Option
GANG MODE
For Wheel only
:
Press Softkey [PRSET] to select the SLOMO Preset Speed Mode.
Press Softkey [UPDATE].
When exiting SLOMO mode, the last used speed is saved in the Preset Speed register.
OR
Press Softkey [STATIC].
The Preset Speed register is NOT updated when exiting SLOMO mode.
It is only changed by [SHIFT] + [SLOMO] (PRESET SLOMO).
Press Softkey to select PERMANENT GANG (described in the FUNCTION Table) or
TEMPORARY GANG.
In TEMPORARY mode, press and hold the VTR key that you want to read status from, then press
the VTR#s of those VTRs that you want to include in the gang. Release the keys. The LED on the
monitored VTR blinks, all other VTRs in the gang stay on constantly. To break the temporary gang,
press any VTR# key.
ST300
SETUP
ST300 SETUP
Clear Cues SetDefault
Press Softkey beneath ClearCues to clear all Cue Points to 00:00:00:00.
Press Softkey [YES] when asked “Are You Sure?”
Press Softkey beneath SetDefault to set ST300 to default settings.
Press Softkey [YES] when asked “Are You Sure?”
IMPORTANT NOTE: Please set these items during initial installation.
DISPLAY
SOFTWARE
VERSION
The version number and date for the currently installed software is displayed. For example:
2034CL-O V3.1
072400
SYNC
Set to ON if black burst is supplied to the Ref Video connector on the rear panel. Set to OFF if no
blackburst is supplied.
AUTO RECUE If Set to [ON] the video automatically recues back to the IN point (or to the beginning of the clip if
there is no IN point) after the playout reaches OUT point (or the end of the clip).
RECORD
Press Softkey to select single button or 2-button record.
RECORD = [REC] Only.
OR
[REC] + [PLAY].
RECALL MODE Press [NORMAL] or [REDIR] (redirect).
NORMAL The cue point will load on the learned VTR.
REDIR When one and only one clip is learned into a Cue Point, the Clip will be REDIRECTED to load on
the currently selected VTR.
24 2034CL-O, Vs. 3.1, 300 Clip Instant Access System, Odetics Protocol,
PBIO Option
PBIO ADDRESS
SWITCHER TYPE
Press VTR key to select the VTR to which to assign a PBIO address.
Display shows:
Enter address number desired on numeric keypad.
Repeat for all VTRs assigned.
Select your switcher type.
GVG = Grass Valley Group (default) or Sony.
For Philips DD35 with PBus, use GVG.
PBIO Address = 00
Enter 00-23
PARITY
ENTER
PREROLL
RECORD
DELAY
CONTROL
MODE
SELECT
TRANSMIT
CUELIST
RECEIVE
CUELIST
Select Parity type Switcher is putting out on the PBUS:
ODD, EVEN or NONE
Enter the desired preroll value using the ST300’s numeric keypad.
Turn wheel to save the entered value OR press [ESC] to exit without saving.
Enter up to 99 frames record delay (used in Capture Function).
Typical value is 3 frames.
Select Control mode Odetics\BVW.
Have Odetics selected for video server control and clip access.
Have BVW selected to access media by timecode.
Transmit Cuelist to another ST300 or to a PC.
See Section: “Transfer Cue List.”
Receive Cuelist from another ST300 or a PC.
See Section: “Transfer Cue List.”
25 2034CL-O, Vs. 3.1, 300 Clip Instant Access System, Odetics Protocol,
PBIO Option
25. FUNCTION TABLE
FUNCTION
KEY PRESS DESCRIPTION
GOTO
ENTERED
TIME
GANG
FFWD
JOG
Label clip
LAST CUE
NEXT CUE
[SHIFT] + [RECUE]
[SHIFT]+[VTR #1]
OR
[SHIFT]+[VTR #2]
OR
[SHIFT]+[VTR #3]
[FFWD]
[JOG]
[SHIFT] + [CLIPLIST]
[LAST CUE]
[NEXT CUE]
Search the VTR to the manually entered time.
Use the ST300 numeric keypad.
To manually enter the desired time press [ENTER] or [RECUE].
NOTE: G
time search.
Individually press the VTR keys to be included in the gang; the LED
above the key will turn on. Press the VTR key again to remove from
gang; the LED above the key will turn off. Press [ESC] to exit.
The VTR LEDs that are on show the gang.
The flashing LED shows which VTR is currently selected.
Press and HOLD to FFWD. Release key to stop. Set WIND Speed in
MENU.
Select JOG mode and enable Wheel.
Enter clip label on shotbox keyboard or optional PC keyboard.
Step to the previous Cue Point Location.
Step to the next Cue Point Location.
RASS VALLEY GROUP Profile does not support TC or VITC
RECORD
REWIND
SHUTTLE
SLOMO
SLO-MO
SPEED
PRESET
STOP
TIME MODE
SELECT
LOOP CLIP
[REC]
[RWD]
[SHUTTLE]
[SLOMO] Press [SLOMO] to slo-mo the VTR. Turn the Wheel (or move the T-
[SHIFT] + [SLOMO] For WHEEL ONLY: Press [SHIFT] + [SLOMO] to preset the slo-mo
[STOP]
[TIME MODE]
[LOOP ENABLE]
Places VTR into the Record mode selected by RECORD MODE in the
SETUP MENU. Press [RECORD] or [RECORD] + [PLAY].
Press and HOLD to REWIND. Release key to stop. Set WIND Speed
in MENU.
Select SHUTTLE mode and enable Wheel.
Bar, if available) to change the play speed.
Press [SLOMO] to STILL frame
OR press any transport key to exit SLOMO.
speed. Turn the Wheel to select desired speed.
Press [ESC] or any transport key to exit.
Press once to STILL frame VTR.
Press again to put VTR into STOP mode.
Press to toggle between Timecode (TC), VITC (VT) or Tape Timer
(TM) display modes.
Press to loop a whole clip or a part between IN and OUT points (if
marked).
26 2034CL-O, Vs. 3.1, 300 Clip Instant Access System, Odetics Protocol,
PBIO Option
PBIO
ENABLE/
DISABLE
PLAY
PLAY TO
THE END OF
THE CLIP
ALIGN
GANGED
CHANNELS
[PBIO]
[PLAY]
[SHIFT] + [PLAY]
[SHIFT] + [STOP]
Toggle the key to enable/disable PBus commands.
If the LED is on, PBIO is enabled.
If the LED is OFF, PBIO is disabled.
Plays the clip.
If the OUT point is set, stops at the OUT point.
If no OUT point is set, plays to the end of the clip.
If the clip ends with “*”, loops the clip.
Plays to the end of the clip.
Disregards the OUT point and the “*”.
Re-establishes the initial offset between ganged channels.
27 2034CL-O, Vs. 3.1, 300 Clip Instant Access System, Odetics Protocol,
PBIO Option
26. SPECIFICATIONS
a. ST300
Power: 90 VAC to 265 VAC adapter supplied with IEC connector
Size: (L” x W” x H”) 12” x 6” x 1.5” (front) 3.0” (rear)
Weight: 4 lbs.
Rear Panel Connectors: VTR1, VTR2, VTR3, VTR4 (All DB9F)
GPI (DBF15F)
Power (DB9M)
Aux (DB9F)
Reference Video (BNC)
Display: Easy to read 2-line, back-lit LCD display
Jog/Shuttle Wheel: With mechanical detents.
Optional “T”-bar: Slo-mo 0-200% of Play Speed
VTR RS422 SERIAL CONNECTOR
9-Pin D-Type, Female
Pin # 1 Frame Ground 6 Receive Common
2 Receive A Í 7 Receive B Í
3 Transmit B Î 8 Transmit A Î
4 Transmit Common 9 Frame Ground
5 Spare
POWER CONNECTOR
9-Pin D-Type, Male
Pin # 1 +5v DC 6 +5 VDC
2 +5v DC 7 Ground
3 Ground 8 Ground
4 +12 VDC 9 Ground
5 –12 VDC
AUX PORT RS422 SERIAL CONNECTOR
9-Pin D-Type, Female
Pin # 1 Frame Ground 6 Receive Common
2 Receive A Í 7 Receive B Í
3 Transmit B Î 8 Transmit A Î
4 Receive Common 9 Frame Ground
5 Spare
(T-Bar unit is 12.6” wide)
(User adjustable contrast)
28 2034CL-O, Vs. 3.1, 300 Clip Instant Access System, Odetics Protocol,
PBIO Option
GPI IN/OUT CONNECTOR
15-Pin D-Type, Female (DB15F)
Pin # Description Function Pin # Description Function
1 GPI 1 Out 9 GPI 1 In Play
2 GPI 2 Out 10 GPI 2 In Stop
3 GPI 3 Out 11 GPI 3 In Recue
4 GPI 4 Out 12 GPI 4 In Next Cue
5 GPI 5 Out 13 GPI 5 In Last Cue
6 GPI 6 Out 14 GPI 6 In Recall
7 GPI 7 Out 15 GPI 7 In
8 Ground
b. ST420 (SHOTBOX)
Power: +5v DC @ 4A, +12v DC @ 1.0A, -12v DC @ 0.6A
90 VAC to 265 VAC adapter supplied with IEC connector
Size: [L” x W” x H”] 11.5” x 6.5” x 1.75” (front) 3.5” (rear)
Weight: 4 lbs.
Rear Panel Connectors: Power: ……... DB9M
OUTPUT: … DB9F
RS422 SERIAL CONNECTOR
9-Pin D-Type, Female
Pin # 1 Frame Ground 6 Transmit Common
2 Transmit A Î 7 Transmit B Î
3 Receive B Í 8 Receive A Í
4 Receive Common 9 Frame Ground
5 Spare
POWER CONNECTOR
9-Pin D-Type, Male
Pin # 1 +5v DC 6 +5 VDC
2 +5v DC 7 Ground
3 Ground 8 Ground
4 +12 VDC 9 Ground
5 –12 VDC
29 2034CL-O, Vs. 3.1, 300 Clip Instant Access System, Odetics Protocol,
PBIO Option
c. TURNAROUND ADAPTER
Convert CONTROLLER PORT Î DEVICE PORT
9-Pin D-Type, Female 9-Pin D-Type, Male
1 Frame Ground 1 Frame Ground
2 Receive A Í 2 Transmit A Î
3 Transmit B Î 3 Receive B Í
4 Transmit Common 4 Transmit Common
5 No Connection 5 No Connection
6 Receive Common 6 Receive Common
7 Receive B Í 7 Transmit B Î
8 Transmit A Î 8 Receive A Í
9 Frame Ground 9 Frame Ground
27. TROUBLESHOOTING
ST420 TROUBLESHOOTING
a. All keys are RED - no communication with ST300.
b. All keys are dark - no communication between the ST300 and the Video Server.
c. The version of the ST420 must comply in the software version with the ST300 it is
connected to.
To determine the software version of the ST420 do the following:
1) Press [SHIFT] + [STOP] + [PLAY].
The key that displays the current version is RED.
2) The ST420 displays:
“SELECT ST300 [V2.1 or V2.0] or [V3.0 or V4.0].”
Press [V3.0 or V4.0] key for proper Shotbox setup.
30 2034CL-O, Vs. 3.1, 300 Clip Instant Access System, Odetics Protocol,
PBIO Option
28. KEY LAYOUT
31 2034CL-O, Vs. 3.1, 300 Clip Instant Access System, Odetics Protocol,
PBIO Option
29. DNF CONTROLS LIMITED WARRANTY
DNF Controls warrants its product to be free from defects in material and workmanship for a period of one
(1) year from the date of sale to the original purchaser from DNF Controls.
In order to enforce the rights under this warranty, the customer must first contact DNF’s Customer Support
Department to afford the opportunity of identifying and fixing the problem without sending the unit in for
repair. If DNF’s Customer Support Department cannot fix the problem, the customer will be issued a
Returned Merchandise Authorization number (RMA). The customer will then ship the defective product
prepaid to DNF Controls with the RMA number clearly indicated on the customer’s shipping document.
The merchandise is to be shipped to:
DNF Controls
12843 Foothill Blvd., Suite C
Sylmar, CA 91342
USA
Failure to obtain a proper RMA number prior to returning the product may result in the return not being
accepted, or in a charge for the required repair.
DNF Controls, at its option, will repair or replace the defective unit. DNF Controls will return the unit
prepaid to the customer. The method of shipment is at the discretion of DNF Controls, principally UPS
Ground for shipments within the United States of America. Shipments to international customers will be
sent via air. Should a customer require the product to be returned in a more expeditious manner, the return
shipment will be billed to their freight account.
This warranty will be considered null and void if accident, misuse, abuse, improper line voltage, fire,
water, lightning or other acts of God damaged the product. All repair parts are to be supplied by DNF
Controls, either directly or through its authorized dealer network. Similarly, any repair work not
performed by either DNF Controls or its authorized dealer may void the warranty.
After the warranty period has expired, DNF Controls offers repair services at prices listed in the DNF
Controls Price List. DNF Controls reserves the right to refuse repair of any unit outside the warranty
period that is deemed non-repairable.
DNF Controls shall not be liable for direct, indirect, incidental, consequential or other types of damage
resulting from the use of the product.
# # #
32 2034CL-O, Vs. 3.1, 300 Clip Instant Access System, Odetics Protocol,
PBIO Option
Loading...
