Model No. 2034CL-MAV
(&2034CL-MAV-T)
300 CLIP INSTANT ACCESS SYSTEM
Sony DP Protocol
for SONY MAV-555 Video Servers
Note: Supports up to 4 Video Server Channels
1
1
USER MANUAL
2034CL-MAV, 300 Clip Fast Access System, for Sony MAV-555
TABLE OF CONTENTS
1. REVISION HISTORY 4
GETTING STARTED . . . 5
2. SYSTEM DESCRIPTION 5
DEFINITIONS 5
3. SYSTEM INSTALLATION 6
a. ST300-S/SM, VTR/DDR CONTROLLER 6
b. SHOTBOX 6
4. VIDEO SERVER SETUP 7
5. LOAD AND LEARN EXISTING CLIPS 7
6. LEARN 8
a. LEARN ON THE ST300 8
b. LEARN ON THE SHOTBOX 8
7. RECALL 8
a. RECALL ON THE ST300 8
b. RECALL ON THE SHOTBOX 8
8. SET RECORD DURATION 9
9. CREATE NEW CLIPS 9
10. SETTING THE IN (OUT) POINT 10
a. MARKING THE IN (OUT) POINT 10
b. VIEW THE IN (OUT) POINT 10
c. CLEARING AN IN (OUT) POINT 10
11. ENTER PREROLL VALUE 10
12. TRIMMING
13. LOOPING A CLIP 11
CLIPS 11
ADVANCED FEATURES . . . 12
14. SHOTBOX
15. VIEW CONTENT OF CUE POINTS 12
16. SHOTKEY MAPPING TO SHOTLIST LOCATIONS 12
17. TRANSFERRING
a. TRANSMIT CUELIST FUNCTION 13
b. RECEIVE CUELIST FUNCTION. 14
2
2
2034CL-MAV, 300 Clip Fast Access System, for Sony MAV-555
CONTROL SWITCHES 12
CUELIST 13
REFERENCE . . . 15
SETUP MENU 15
18.
19. FUNCTION
TABLE 17
20. SPECIFICATIONS 18
ST300 18
ST420 (SHOTBOX) 19
21. TROUBLESHOOTING 20
ST420 TROUBLESHOOTING 20
22. KEY LAYOUT 21
23. DNF CONTROLS LIMITED WARRANTY 22
Manual Version ……………..………………………. 1.6 101105
Document No............…................ 2034CL-MAV User Manual
3
3
2034CL-MAV, 300 Clip Fast Access System, for Sony MAV-555
1. REVISION HISTORY
092203 Rev. 1.1 Company header information revised.
110403 Rev. 1.2 Added DNF Controls Limited Warranty.
Updated Receive Cue List & Transmit Cue List Function description.
121003 Rev. 1.3 Reformatted.
Revised TRIMMING CLIPS Section.
Added Video Sync, Video Standard, Recall M e nu Opt i o ns.
020504 Rev. 1.4 Added note to cover and System Description: Supports up to 4 Video
Server Channels.
011105 Rev. 1.5 Added Key Layout.
4
4
2034CL-MAV, 300 Clip Fast Access System, for Sony MAV-555
Getting Started . . .
2. SYSTEM DESCRIPTION
The 300 Clip Instant Access System consists of the ST300-SSM VTR Controller and Shotlist
Software. The Video Server must support SONY DP Protocol.
The ST300 controls up to 4 video channels individually or ganged.
SHOTLIST provides instant access to existing video clips stored on SONY-MAV.
The SHOTLIST contains up to 300 CLIP IDs, stored in non-volatile memory in the ST300.
Any clip in the SHOTLIST can be quickly loaded by simply entering the associated 3-digit
number of its location, then pressing [LOAD]. Press [PLAY] to play the clip. Press [RECUE] to
recue to the beginning of the clip or to the “recalled” time if defined.
DEFINITIONS
Throughout this document, the MAV-555 will be referred to as “Video Server.”
The ST300-S/SM is referred to as the ST300.
The ST420 is referred to as the SHOTBOX.
Words surrounded by brackets, for example, [ENTER], are keys on the ST300 or the
SHOTBOX. [XXX] + [XXX] means hold the two keys down simultaneously.
“Softkeys” are the row of keys directly below the display that perform multiple functions in
MENU and other modes.
5
5
2034CL-MAV, 300 Clip Fast Access System, for Sony MAV-555
3. SYSTEM INSTALLATION
a. ST300-S/SM, VTR/DDR CONTROLLER
1) Plug one end of a 9-conductor, RS422 serial cable into the 9-pin connector
(VTR 1, 2, 3 or 4) on the rear of the ST300. Plug the other end of the cable into
the 9-pin remote connector on the Video Server.
2) Connect the +5, +12, -12 VDC POWER SUPPLY into the POWER connector
on the rear of the ST300. Plug the Power Supply into an outlet, 90 VAC – 240
VAC.
3) Check SETUP MENU prior to using the ST300 to confirm proper Record mode
and other User settable modes.
b. SHOTBOX
1) Plug one end of a standard 9-pin, RS422 serial cable, into the OUTPUT
connector, 9-pin female, on the rear of the SHOTBOX. Plug the other end of
the cable into the 9-pin connector, AUX, on the rear of the ST300.
2) Connect the 5 VDC, 1Amp POWER SUPPLY into the POWER connector on
the rear of the SHOTBOX. Plug the Power Supply into an outlet, 90 VAC – 240
VAC.
Installation is complete.
6
6
2034CL-MAV, 300 Clip Fast Access System, for Sony MAV-555
4. VIDEO SERVER SETUP
On the MAV Unit:
a. The SONY MAV unit must have the following or higher software versions: V1.1
b. Clips loaded from the front panel of the MAV will not be Learned or displayed on the
ST300 or the SHOTBOX.
c. Crash and Lockout are the only RECORD modes supported.
5. LOAD AND LEARN EXISTING CLIPS
a. Select VTR. You must be connected to the Player port to load existing clips.
b. Press [CLIP LIST]. The CLIP LIST indicator will turn on.
The display prompts: “WHEEL-scroll files, ENTER- enter file ID”
c. Turn the Wheel. The top line of the display will show “CLIP ID.”
The bottom line of the display will show “xxxxxxxxxxxxxxxxxxxx:”
Where “xxxxxxxxxxxxxxxxxxxx” is the 20 character CLIP ID. (CLIP IDs can contain
up to 24 characters. The ST300 is capable of displaying a maximum of 20 characters. If
a CLIP ID has more than 19 characters, the last character is a “Δ.)
d. Turn the wheel to scroll through the list of available CLIPs.
OR
Type in an alphabetical ID using the “qwerty” keyboard on the SHOTBOX.
OR
Enter a numeric file ID using the numeric keypad on the ST300.
e. Press [LOAD] to load the desired clip.
f. Locate the clip to the desired IN time.
g. Press [ESC] at anytime to exit CLIP LIST.
7
7
2034CL-MAV, 300 Clip Fast Access System, for Sony MAV-555
6. LEARN
a. LEARN ON THE ST300
1) LOAD a clip on the ST300 as described above.
2) Set IN and OUT points if desired.
3) Select the desired Cue Point by pressing [NEXT CUE], [LAST CUE], or by
manually entering the Cue Point using the numeric keypad.
The selected Cue Point number is shown on the bottom line of the display.
4) Press [SHIFT] + [MARK] to initiate the LEARN.
The display will show:
5) Press the VTR key desired: [1], [2], [3].
6) Press [MARK] and the ST300 will: LEARN (save) the VTR Number (1,2,3),
loaded CLIP ID and current IN time to the selected Cue Point.
b. LEARN ON THE SHOTBOX
1) Press [LEARN]. The LEARN indicator will turn on.
2) Select the desired BANK and ShotKey.
3) Press [LEARN] to exit at anytime.
NOTE: The [LEARN] key toggles LEARN mode on/off.
Press VTR:
MARK-Lrn ESC-Cancel
7. RECALL
a. RECALL ON THE ST300
1) Select the desired Cue Point by pressing [NEXT CUE], [LAST CUE],
2) Press [LOAD] on the ST300.
b. RECALL ON THE SHOTBOX
Select the desired Cue Point by pressing the bank and the switch key.
8
8
2034CL-MAV, 300 Clip Fast Access System, for Sony MAV-555
or by manually entering the Cue Point using the numeric keypad.
The selected Cue Point number is shown on the bottom line of the display.
8. SET RECORD DURATION
NOTE: Set Record duration BEFORE creating a new clip, not before going into record.
a. Press [SHIFT] + [RECORD]. The first line of the display shows current record
duration. The second line of the display prompts “Enter record length.”
b. Enter the desir e d reco rd len gth using numeric keypad.
c. Press [ENTER] to save the entered time and exit.
OR
Press [ESC] to exit without saving.
Default record duration is 30 minutes.
9. CREATE NEW CLIPS
a. Select VTR. You must be connected to the Recorder port on MAV-555.
b. Press [CLIP LIST]. The CLIP LIST indicator will turn on.
The display will show “Enter new file name.”
c. Enter a CLIP ID (up to 8 characters) using the numeric keypad OR the SHOTBOX
“qwerty” keyboard.
d. Press [LOAD] to create the selected CLIP ID.
OR
Press [ESC] to exit at anytime.
NOTE: The only functions available for new clips are RECORD and STOP. In order to playback
a newly recorded clip, you must reload it on a Player port.
9
9
2034CL-MAV, 300 Clip Fast Access System, for Sony MAV-555
10. SETTING THE IN (OUT) POINT
a. MARKING THE IN (OUT) POINT
1) Locate the clip to the desired IN (OUT) time.
2) Press [IN] ([OUT]).
The IN (OUT) indicator turns on.
b. VIEW THE IN (OUT) POINT
1) When the IN (OUT) indicator is on, press [IN] ([OUT]) to view the existing IN
(OUT) Point.
2) While viewing the IN (OUT) Point:
Press [MARK] to overwrite the saved time with the current time.
Press [RECUE] to search to the IN (OUT) point.
Press [SHIFT] + [IN] ([OUT]) to manually enter a new IN (OUT) time.
Press [ENTER] to save the entered time or [ESC] to exit without saving.
NOTE: When manually entering IN and OUT points, they are always marked based on
tape time, not LTC, no matter what time mode is selected.
c. CLEARING AN IN (OUT) POINT
Press and hold [DEL] then press and release [IN] ([OUT]).
The IN (OUT) indicator turns off.
11. ENTER PREROLL VALUE
a. Press [MENU] and turn the wheel to “Enter PREROLL:”
b. Enter the desir e d preroll value using the ST300’s numeric keypad.
c. Press [ENTER] to save the entered value OR [ESC] to exit without saving.
0
110
2034CL-MAV, 300 Clip Fast Access System, for Sony MAV-555
12. TRIMMING CLIPS
a. LOAD a clip that you want to trim.
b. Mark IN and OUT points as described above.
c. Press [SHIFT] + [CLIP LIST]. The display prompts “Enter new file name.”
d. Enter ne w fi l e name (up to 8 characters) using the numeric keypad.
e. Press [ENTER] or [LOAD] to save the new CLIP ID.
OR
Press [ESC] to exit without saving.
If the saving is successful, the new clip is created. The beginning of the clip is the marked IN
point, the end of the clip is the OUT point. You can load the new clip using the CLIP LIST
function. Upon saving the new clip, marked IN and OUT points are cleared.
NOTE: Do not create trimmed clips with a duration of less than 18 frames.
13. LOOPING A CLIP
a. Press [LOOP ENABLE]. The indicator turns on.
b. The clip is now in the loop mode. Pressing [PLAY], [SLOMO], [FFWD], etc. will
cause the clip to play to the end and wrap around to the beginning.
c. To return to normal mode, press [LOOP ENABLE]. The indicator will turn off
1
111
2034CL-MAV, 300 Clip Fast Access System, for Sony MAV-555
Advanced Features . . .
14. SHOTBOX CONTROL SWITCHES
a. [PLAY]: Plays out the selected clip.
b. [RECUE]: Returns to the beginning of the clip.
c. [STOP]: Stops playout of the clip.
15. VIEW CONTENT OF CUE POINTS
a. Press [VIEW]. The VIEW indicator turns on.
b. Press the switch for which you would like to see the content.
c. The switch turns RED and the content (CLIP ID) of the corresponding Cue Point is
displayed on a virtual display.
For Example:
Note: All the remaining switches are not illuminated.
d. Release the keys to return to normal operation.
VTR 1
Clip 23
VTR 2
Clip 13
VTR 3
Clip 77
VTR 4
No
Assignment
16. SHOTKEY MAPPING TO SHOTLIST LOCATIONS
The SWITCHES on the SHOTBOX access the SHOTLIST locations as follows:
BANK 0, SWITCHES 1 Î 30 access SHOTLIST locations 001 Î 030.
BANK 1, SWITCHES 1 Î 30 access SHOTLIST locations 101 Î 130.
BANK 2, SWITCHES 1 Î 30 access SHOTLIST locations 201 Î 230.
BANK 3, SWITCHES 1 Î 30 access SHOTLIST locations 301 Î 330.
BANK 4, SWITCHES 1 Î 50 access SHOTLIST locations 401 Î 430.
BANK 5, SWITCHES 1 Î 30 access SHOTLIST locations 501 Î 530.
BANK 6, SWITCHES 1 Î 30 access SHOTLIST locations 601 Î 630.
BANK 7, SWITCHES 1 Î 30 access SHOTLIST locations 701 Î 730.
2
112
2034CL-MAV, 300 Clip Fast Access System, for Sony MAV-555
17. TRANSFERRING CUELIST
a. TRANSMIT CUELIST FUNCTION
The TRANSMIT CUELIST function allows you to transmit your list of Cue Points to a
PC, using the provided utility software on the PC, or to another ST300. Transfer to a PC
requires OpSuite 3.0 software, which runs on a Windows-based computer. Contact DNF
Controls for more information.
1) TO TRANSMIT CUE POINTS TO THE ST300
a) Connect the VTR4 connector on the rear of the ST300 to the VTR4
connector of the receiving ST300 using an RS422 9-pin cable with TX
and RX lines crossed.
(A “turnaround” cable)
b) Press [MENU].
c) Scroll the wheel until “Transmit CUE List? YES=Enter, Exit=ESC” is
displayed.
d) Press [ENTER] to start transmitting.
The Display shows “Waiting to transmit” on the first line.
e) When the Receiver is ready, transfer starts automatically.
The Display now shows “Transmitting cuelist.”
f) After the transfer is over the display shows “Transfer is over” for one
second then shows “Waiting to transmit” again.
g) Connect another ST300 to transmit the list again.
OR
Press [ESC] twice to exit the MENU mode.
2) TO TRANSMIT CUE POINTS TO THE PC
a) Connect the VTR4 connector on the back of the ST300 to one of the
COM ports on the PC using a RS422 to RS232 adapter.
b) Repeat steps b-g of the TRANSMIT CUE POINTS to the ST300
section.
3
113
2034CL-MAV, 300 Clip Fast Access System, for Sony MAV-555
b. RECEIVE CUELIST FUNCTION.
The RECEIVE CUELIST function allows you to receive your list of Cue Points from a
PC or from another ST300. Transfer to a PC requires OpSuite 3.0 software, which runs
on a Windows-based computer. Contact DNF Controls for more information.
1) To Receive Cue Points from the ST300
a) Connect the VTR4 connector on the back of the ST300 from the VTR4
connector of the transmitting ST300 using RS422 9-pin cable with TX
and RX lines crossed.
(A “Turnaround” Cable)
b) Press [MENU].
c) Scroll the wheel until “Receive CUE List? YES=Enter, Exit=ESC” is
displayed.
d) Press [ENTER] from start receiving.
The Display shows “Waiting to receive” on the first line.
e) When the Transmitter is ready, transfer starts automatically.
The Display now shows “Receiving cuelist.”
f) After the transfer is over the display shows “Done-Success! Press any
key…”
g) Press any key. The display shows “Receive cuelist?” message.
h) Press [ESC] to exit the MENU mode.
2) To Receive Cue Points from the PC
a) Connect the VTR4 conn ector on the back of the ST300 to one of the
COM ports on the PC using RS422 to RS232 adapter
b) Repeat steps b-h of the RECEIVE CUE POINTS from the ST300
section.
4
114
2034CL-MAV, 300 Clip Fast Access System, for Sony MAV-555
Reference . . .
18. SETUP MENU
Press [MENU]. The MENU indicator will turn on.
Turn the Wheel to select item to change.
Press [MENU] OR use the Softkeys to change the desired mode for that option.
Turn the Wheel at anytime to select another item.
Press [ESC] at anytime to exit SETUP MENU. The MENU indicator will turn off.
MENU MODES
RECORD
WIND MODE
SLOMO
(Turning Wheel Clockwise)
Press [MENU] to select the desired record mode: Crash (Full) or Lockout.
Press [HOLD]. (Fast wind is maintained only while key is depressed).
OR
[LATCH]. (Fast wind is initiated and maintained with momentary key press).
Select fast wind speed (3.9 to 23.7) by pressing Softkey below SPD.
ST300 display shows:
(Non T-Bar version)
ST300 display shows:
(T-Bar versions)
Press Softkey [TBAR] (or [WHEEL]) to toggle between them.
NOTE: The T-BAR has a fixed speed range of 0 Æ +200 with a detent at +100 %
play speed.
For Wheel only:
Press Softkey [SPDRANGE] to select SLOMO speed ranges:
Press Softkey to select: 0 Æ +200 OR -100 Æ +200.
Press Softkey [BACK] to return to SLOMO MENU.
Press [ESC] to exit OR turn the Wheel to select another item.
For Wheel only:
Press Softkey [PRSET] to select the SLOMO Preset Speed Mode.
Press Softkey [UPDATE] when exiting SLOMO mode. The last used speed is
saved in the Preset Speed register.
Press Softkey [STATIC].
The Preset Speed register is NOT updated when exiting SLOMO mode.
It is only changed by [SHIFT] + [SLOMO] (PRESET SLOMO).
SLOMO with: WHEEL
SpdRange Preset
SLOMO with: TBAR
Wheel Speed Preset
5
115
2034CL-MAV, 300 Clip Fast Access System, for Sony MAV-555
ST300 SETUP
DISPLAY
SOFTWARE
VERSION
SYNC
VIDEO
STANDARD
RECALL MODE
RECORD
TRANSMIT
CUELIST
RECEIVE
CUELIST
ST300 SETUP
Clear Cues SetDefault
Press Softkey beneath ClearCues to clear all Cue Points to 00:00:00:00.
Press Softkey [YES] when asked “Are You Sure?”
Press Softkey beneath SetDefault to set ST300 to default settings.
Press Softkey [YES] when asked “Are You Sure?”
The version number for the currently installed software is displayed.
Set to ON if black burst is supplied to the Ref Video connector on the rear panel.
Set to OFF if no blackburst is supplied.
Sets Video Standard option to NTSC when [NTSC] is pressed.
OR
Sets Video Standard option to PAL when [PAL] is pressed.
Press [NORMAL] or [REDIR] (redirect).
NORMAL –
The cue point will load on the learned VTR.
REDIR –
When one and only one clip is learned into a Cue Point, the Clip will be
REDIRECTED to load on the currently selected VTR.
Press Softkey to select single-button or 2-button rec or d.
RECORD = [REC] Only OR [REC] + [PLAY].
Transmit cuelist to another ST300 or to a PC.
Receive cuelist from another ST300 or PC.
6
116
2034CL-MAV, 300 Clip Fast Access System, for Sony MAV-555
19. FUNCTION TABLE
Function
GOTO ENTERED
TIME
FFWD
JOG [JOG] Select JOG mode and enable Wheel.
LAST CUE [LAST CUE] Step to the previous Cue Point Location.
NEXT CUE [NEXT CUE] Step to the next Cue Point Location.
RECORD [REC] Places VTR into the Record mode selected by RECORD
[SHIFT] + [RECUE] Search the VTR to the manually entered time.
[FFWD] Press and HOLD to shuttle. Release key to stop. Set WIND
Key Press Description
Use the ST300 numeric keypad. Press [ENTER] or
[RECUE].
Speed in MENU.
MODE in the SETUP MENU. Press [RECORD] or
[RECORD] + [PLAY].
REWIND
SHUTTLE [SHUTTLE] Select SHUTTLE mode and enable Wheel.
SLOMO
SLO-MO SPEED
PRESET
STOP [STOP] Press once to STILL frame VTR.
GANG VTRs
TIME MODE
SELECT
LOOP CLIP
[RWD] Press and HOLD to shuttle. Release key to stop. Set WIND
Speed in MENU.
[SLOMO] Press [SLOMO] to slo-mo the VTR. Turn the wheel (or move
the T-Bar if available) to change the play speed. Press
[SLOMO] to STILL frame
OR press any transport key to exit SLOMO.
[SHIFT] + [SLOMO] For WHEEL ONLY: Press [SHIFT] + [SLOMO] to preset the
slo-mo speed. Turn wheel to select desired speed. Press
[ESC] or any transport key to exit.
Press again to put VTR into STOP mode.
[SHIFT] + [VTR#1]
OR
[SHIFT] + [VTR#2]
OR
[SHIFT] + [VTR#3]
OR
[SHIFT] + [VTR#4]
[TIME MODE] Press to toggle between Timecode (TC), VITC (VT) or Tape
[LOOP ENABLE] Press to loop a clip.
Press VTR keys to include in the gang. Press [ESC] to escape
gang setup mode.
Flashing LED indicates VTR being monitored fo r status.
Timer (TM) display modes.
7
117
2034CL-MAV, 300 Clip Fast Access System, for Sony MAV-555
20. SPECIFICATIONS
ST300
Power: 90 VAC to 265 VAC adapter supplied with IEC connector
Size: (approx.) (L” x W” x H”) 12” x 6” x 1.5” (front) 3.0” (rear)
Weight: 4 lbs.
Rear Panel Connectors: VTR1, VTR2, VTR3, VTR4......... ... . All DB 9F
GPI..................................................... DBF15F
Power..................................................DB9M
Aux .....................................................DB9F
Display: Easy to read 2-line, back-lit LCD display
(User adjustable contrast)
Jog/Shuttle Wheel: With mechanical detents
Optional “T”-bar: Slo-mo 0-200% of Play Speed
RS422 SERIAL CONNECTOR
9-Pin D-Type, Female
Pin # 1 Frame Ground 6 Receive Common
2 Receive A Í 7 Receive B Í
3 Transmit B Î 8 Transmit A Î
4 Transmit Common 9 Frame Ground
5 Spare
POWER CONNECTOR
9-Pin D-Type, Male
Pin # 1 +5v DC 6 +5 VDC
2 +5v DC 7 Ground
3 Ground 8 Ground
4 +12 VDC 9 Ground
5 –12 VDC
AUX PORT RS422 SERIAL CONNECTOR
9-Pin D-Type, Female
Pin # 1 Frame Ground 6 Transmit Common
2 Receive AÍ 7 Receive B Í
3 Transmit B Î 8 Transmit A Î
4 Receive Common 9 Frame Ground
5 Spare
8
118
2034CL-MAV, 300 Clip Fast Access System, for Sony MAV-555
GPI IN/OUT CONNECTOR
15-Pin D-Type, Female (DB15F)
Pin # Description Function Pin # Description Function
1 GPI 1 Out 9 GPI 1 In Play
2 GPI 2 Out 10 GPI 2 In Stop
3 GPI 3 Out 11 GPI 3 In Recue
4 GPI 4 Out 12 GPI 4 In Next Cue
5 GPI 5 Out 13 GPI 5 In Last Cue
6 GPI 6 Out 14 GPI 6 In Recall
7 GPI 7 Out 15 GPI 7 In
8 Ground
ST420 (SHOTBOX)
Power: 90 VAC to 265 VAC adapter supplied with IEC connector
Size (approx.): (L” x W” x H”) 12 ” x 7 1/4”” x 1 1/2” (front) 3 5/8” (rear)
Weight : 5.5 lbs.
Rear Panel Connectors: Power...................DB9M
OUTPUT .............DB9F
Aux......….............DB9F
Display: LCD on each key
POWER CONNECTOR
9-Pin D-Type, Male
Pin # 1 +5v DC 6 No Connection
2 +5v DC 7 Ground
3 Ground 8 Ground
4 No Connection 9 Ground
5 No Connection
AUX PORT RS422 SERIAL CONNECTOR
9-Pin D-Type, Female
Pin # 1 Frame Ground 6 Transmit Common
2 Receive A Í 7 Receive B Í
3 Transmit B Î 8 Transmit A Î
4 Receive Common 9 Frame Ground
5 Spare
9
119
2034CL-MAV, 300 Clip Fast Access System, for Sony MAV-555
21. TROUBLESHOOTING
ST420 TROUBLESHOOTING
a. All keys are RED - no communication with ST300.
b. All keys are dark - No communication between the ST300 and the Video Server.
c. The version of the ST420 must comply in the software version with the ST300 it is
connected to.
To determine the software version of the ST420 do the following:
a. Press [SHIFT] + [STOP] + [PLAY].
The key that displays the current version is RED.
b. The ST420 displays:
“SELECT ST300 V2.1 or V2.0 or V3.0.”
Press the key for the software version of ST300 you are using. Please refer to the ST300 to
determine the Version if needed.
0
220
2034CL-MAV, 300 Clip Fast Access System, for Sony MAV-555
22. KEY LAYOUT
1
221
2034CL-MAV, 300 Clip Fast Access System, for Sony MAV-555
23. DNF CONTROLS LIMITED WARRANTY
DNF Controls warrants its product to be free from defects in material and workmanship for a period of one
(1) year from the date of sale to the original purchaser from DNF Controls.
In order to enforce the rights under this warranty, the customer must first contact DNF’s Customer Support
Department to afford the opportunity of identifying and fixing the pr oblem without sending the unit in for
repair. If DNF’s Customer Support Department cannot fix the problem, the customer will be issued a
Returned Merchandise Authorization number (RMA). The customer will then ship the defective product
prepaid to DNF Controls with the RMA number clearly indicated on the customer’s shipping document.
The merchandise is to be shipped to:
DNF Controls
12843 Foothill Blvd., Suite C
Sylmar, CA 91342
USA
Failure to obtain a proper RMA number prior to returning the product may result in the return not being
accepted, or in a charge for the required repair.
DNF Controls, at its option, will repair or replace the defective unit. DNF Controls will return the unit
prepaid to the customer. The method of shipment is at the discretion of DNF Controls, principally UPS
Ground for shipments within the United States of America. Shipments to international customers will be
sent via air. Should a customer require the product to be returned in a more expeditious manner, the return
shipment will be billed to their freight account.
This warranty will be considered null and void if accident, misuse, abuse, improper line voltage, fire, water,
lightning or other acts of God damaged the product. All repair parts are to be supplied by DNF Controls,
either directly or through its authorized dealer network. Similarly, any repair work not performed by either
DNF Controls or its authorized dealer may void the warranty.
After the warranty period has expired, DNF Controls offers repair services at prices listed in the DNF
Controls Price List. DNF Controls reserves the right to refuse repair of any unit outside the warranty
period that is deemed non-repairable.
DNF Controls shall not be liable for direct, indirect, incidental, consequential or other types of damage
resulting from the use of the product.
# # #
2
222
2034CL-MAV, 300 Clip Fast Access System, for Sony MAV-555
Loading...
