DMW 240, 440, R400 Operation Manual

Frozen Beverage Dispenser

Models 240, 440, R400

Operations Manual

2124 0 F o ster R o a d Bui l ding 4 A , Sp r i n g, T e x a s 773 8 8

281-67 7 - 6 7 00 | w w w.d r i n k ma ch i n e wor k s . c om

DMW Dispense r O p erations M anual 2

All information contained in this publication is proprietary property of Drink

Machine Works LLC. Any reproduction or use of these instructions, drawings,

or photographs without the written permission of an officer of Drink Machine

Works LLC is forbidden.

Copyright 2019, Drink Machine Works LLC

All rights reserved. Printed in the United States of America.

DMW Dispense r O p erations M anual 3

Legal Notice

Drin k M a chin e W o rks, L L C m a k es n o w a rrant y or r ep r e s enta t i o n eith e r
exp r e s s e d or i m p l ie d o f a ny k i n d r e g ard i n g t his m a t eria l , i n clud i n g , but n o t
limit e d t o, t h e i mpl i e d w ar r a n t i es o f i t s q u a l i t y, p e r f o rman c e , mark e t a b i lity ,
and f i t n e ss f o r a pa rt i c u l ar p u r p ose. Dri n k Machi n e Work s , L L C s h a ll n o t b e
liabl e f o r e r r o r s con t a i n ed h e r e i n o r f o r inci d e n tal c o n s equ e n t i a l da m a g e s in
conn e c t i on wi t h t h e f u r n i shin g , p erf o r m a n ce, o r u se o f t h i s m a t e r i a l.

This d o c u men t c o n ta i n s p rop r i e t a ry in f o rmati o n w hich i s pr o t e c t ed b y
cop y r i g h t wi t h a l l ri g h t s r e s e r v ed. U n d er t h e C opy r i g h t La w s , n o p a r t o f th i s
docum e n t ma y b e p hot o c o p i e d , rep r o d u c ed, o r t ransl a t e d in t o a n oth e r
langu a g e with o u t the p r i or w r i t t e n c o n s ent o f D r i n k Ma c h i n e Wo r k s , LLC. Th e
info r m a t i on c o n t a ined i n thi s d o cumen t i s subj e c t to c h a n g e w i t h out n o t i ce.

DRINK MACHI N E WORKS, L LC

Limited Warranty

Drink M a chi n e W ork s , L L C w a r r ant s t o Ori g i n al Pu r c h a ser/ U s e r the Dri n k
Machi n e W ork s froz e n b ever a g e d isp e n s er f r o m t h e da t e of i n v o i ce t o b e fr e e
from d e f e cts i n f acto r y w ork m a n s h ip o r m a teri a l s as f o l low s :

A) O r i g i nal C o m p res s o r

B) O r i g i nal P a r t s

C) Li m i ted L a b o r

Drink M a chi n e W o rks a g re e s t o per f o r m ful l l abor w a r r ant y a t n o c h a r g e fo r
servi c e s on O r i g in a l P u r chas e r / U ser ’ s b eve r a g e d isp e n s er c on t i n gent u p on:

1) O r i g i nal P u r c h as e r / U s er p e r f o rms o r d i nary c l eani n g a n d m a i n tenan c e on a
regul a r basi s a s des c r i bed i n the O p erati o n s Manu a l a n d a s o u tli n e d .

2) O r i g i nal P u r c h as e r / U s er p r o v i des p r o p er p o w e r , 12 0 - v o l t , 2 0 - a m p,
dedi c a t e d ci r c u i t an d p rope r v e n ti l a t i on a s d e s cri b e d i n t h e Ope r a t i o n s
Manual . Ori g i n al Pu r c h a ser/U s e r und e r s t ands t h a t fa i l ure t o p r o vid e t h e
prop e r p ower a n d vent i l ati o n w i ll v o i d th e w a rrant y a s set f o r t h h e r e i n.

3) O r i g i nal P u r c h as e r / U s er ag r e e s and u nder s t a n d s th a t d a mag e s c ause d t o
the d i s p ens e r a s a r e s u l t of o p e rat or , a g ent, o r cust o m e r negl i genc e s h a ll
not b e c o ver e d b y th e w a rrant y as s e t forth h erei n . Expen d a b l e pa r t s are
excl u d e d fro m t h e w a r r a n ty a s s et f o r t h her e i n . Su c h p arts s h a l l i n c l ude, b u t
not b e l im i t e d t o re a r s eals , O- ri n g s, fi l t ers, g a s k ets , l i ght b u l bs, s i g n s,
merch a n d i si n g m a teri a l s, and m a t eri a l s and/ o r t ools n e ede d t o p e r form
servi c e .

DMW Dispense r O p erations M anual 4

Orig i n a l Pu r c h a s er/ U s e r und e r s t a n ds t h a t the w a rrant y s e t f o r t h h erei n d oes
not a p p l y to d a m a ge t o the di s p ense r o ccurri n g in t r a n sit, o r d a mag e c a u sed
by un a u t h ori z e d alt e r a t i ons , f i r e, a c c i dent s , a rtifi c i all y g e n erat e d e l ect r i c a l
curr e n t s , Act s o f Go d , m i su s e o r abu s e , or b y a n y ot h e r cau s e w h a ts o e v e r
othe r t h a n d e f e c t s i n f a c tory w o r kman s h i p or m a t erial . F u rth e r , the
war ra n t y do e s n o t ap p l y t o da m a g es f o r l oss o f p r odu c t s , ref r i g e rant,
prop e r t y , or l o s s of i n come o r p rofi t s d u e t o th e m a l fun c t i oni n g o f th e
disp e n s e r, n o r t o t r a n s p orta t i o n (sh i p p i ng) , o r co s t s t o an d f r om f a c t o ry o r
repa i r c ente r , o r sp e c i a l cha r g es of s t a te s a l e s or o t h er ta x e s. Dri n k Machi n e
Work s L L C r e s e r v es t h e rig h t t o exch a n g e th e d i spen s e r wi t h a n equi v a l ent
or up g r a d ed d i s p ens e r i n ord e r t o p r o v i d e O r i g i nal P u r chas e r / U ser w i t h th e
maxi m u m servi c e val u e a n d t o m i nim i z e down t i me fo r O rigi n a l
Purch a s er/Us e r . The w a r r ant y f o r th e d i spens e r i s non - tra n s f era b l e and
appl i e s to O r i g i nal P u rcha s e r / U ser .

All d e c i sion s r egar d i n g th e e x i st en c e of d e f e c t s in m a t eri a l o r wo r k m a n shi p
or o t h e r cau s e s s h al l b e mad e b y D r i nk M a c h i ne W o r k s, L L C . an d s h al l b e
bin d i n g upon t h e pa rt i e s .

The f o r e g oin g l i mi t e d w a rran t y sh a l l not b e enl a r g e d or a f f e cted b y , and n o
lia b i l i ty o r o b l i g a t i on sha l l aris e f r om, Drin k M a chi n e W ork s , L L C . r e n deri n g
of t e c h n i cal o r oth e r a d vic e , o r of s e r v i ce .

All t e c h n i ca l i nq u i r i e s to o u r fac t o r y must b e acc o m p a n i ed b y you r u n i t s e r i a l
numb e r .

The s e r i al n u m b e r i s l ocat ed on t h e rea r o f the u n i t on t h e dat a p l at e and
engr a v e d on t h e u ppe r r i ght s i d e of t h e d isp e n s er.

DMW Dispense r O p erations M anual 5

Table of Contents

Introduction:

Legal Notice ................................................................................................. 3

Limited Warranty ......................................................................................... 3

Preliminary Inspection .................................................................................. 6

Installation Guidelines .................................................................................. 6

LID Safety Switch ........................................................................................ 7

SETUP AND OPERATION ............................................................................ 8

Initial Startup Instructions ............................................................................ 8

Parts, Assembly, and Lubrication ................................................................. 10

Faucet Assembly ......................................................................................... 11

Beater Bar Assembly ................................................................................... 12

Thickness and Consistency .......................................................................... 13

Maintenance Schedule ................................................................................. 13

CLEANING AND SANITIZING PROCEDURES ............................................ 15

Cleaning Equipment and Supplies ................................................................ 15

DMW Dispense r O p erations M anual 6

Preliminary Inspection

As s o o n a s th e D ri n k M a chi n e W orks u n i t i s d el i v e r ed, U n p a ck th e u n i t a n d
insp e c t a l l c o m p on e n t s to en s u r e tha t t he eq u i p ment h a s not b e en da m a g ed
in t r a n s i t.

NOTE : If an y d a m ag e i s app a r e n t , i n f o r m th e c a rri e r i m m edi a t e l y. D r i n k
Machi n e W ork s assu m e s n o r e s p o n sib i l i ty f o r a n y pr o d u c t af t e r i t l e a v e s th e
manu f a c t u re r a n d cann o t a ssi st w i th d a m a g e cl a i m s su b m i t ted t o t he c a r rier.
Damag e c l ai m s m u st b e f i led d i r ectl y wi t h t h e f r e i g ht c a r r i er .

Installation Guidelines

Befo r e u n pac k i n g and i n s t all i n g the u n i t, ma k e s u re t h a t the i n s t all a t i on
surf a c e i s s o l i d and w i ll s u p p o rt th e f u l l w e i ght o f t h e m a c h i ne an d m i xt u r e .
When f u l ly o p e r a tio n a l , th e t o t a l w e i g ht o f a d ou bl e - f l a vor u n i t i s
appr o x i m a tel y 2 6 5 l b . C h oo s e a h igh l y v i si b l e and a c c e ssi b l e lo c a t i o n to
disp l a y the u n i t . Th e DMW d i spen s e r i s d e s i g ned t o b e vi s u a ll y a p p eali n g a n d
is a m a j o r c o n t r i but o r t o cu s t o m er att r a ction a n d sal e s .

IMPO R T A N T : Pl a c e ea c h u n it o n i ts o w n 2 0 - a m p , 12 0 - vol t d e d i ca t e d
brea k e r . Do n o t atte m p t t o u s e t h e ma c h i ne o n a sha r e d b rea k e r . In
addi t i o n , m a k e sure t h a t th e p o wer s u p p ly r e q u i remen t s show n o n th e
nam ep l a t e mat c h t he l o c a l p o w e r supp l y requi r e m ents .

DMW d i s p ens e r s a re a i r - co o l e d uni t s t h a t r e q u ir e a deq u a t e ai r s p ace
clea r a n c e awa y f rom a n y a dja c e n t wal l or equ i p m ent . M a k e su r e t h at t h e
locati o n you c h o ose p r o v i d e s a d equa t e s p a ce f o r air c i r cul a t i o n arou n d t h e
uni t .

NOTE : A voi d l o cati n g t h e u n i t in a n y area w h e re h eat f r om di r e c t sunl i g ht,
cooki n g faci l i ties , o r oth e r s o u rc e s m a y el e v a t e th e t e m pe r a t u r e.

NOTE : The t o p c ov e r m u st b e p l aced o n the d i s p en s e r t o s t a r t t he m a c h ine
and a c t i vate t h e be a t e r b ars .

DMW Dispense r O p erations M anual 7

LID Safety Switch

Your D M W di s p e n ser w i ll b e e qui p p e d wi t h a stan d a rd sa f e t y fea t u r e that
prev e n t s th e u n i t fr o m f u nct i o n i ng w h e n th e h o p per l i d i s r e m o ved. T h i s
featu r e m eet s U n d erw ri t e rs La b o r ato r y ( U L) r e q u i rem e n t t hat s e e ks t o
prot e c t opera t o r s fr o m a c cid e n t a l i n j u r y . N o t e t h e l o c a ti o n o f t he d r i v e
moto r k i ll s w i t ch i n the p i c t u re b e l o w.

CAUT I O N : D o n o t ta m p e r wit h o r di s a b l e the d r i ve m o t o r ki l l s w i tch .
Seri o u s i nj u r y m ay r e s u l t .

LID Safety Switch

DMW Dispense r O p erations M anual 8

SETUP AND OPERATION

Initial Startup Instructions

To u s e t h e di s p e n se r f o r th e f i r st
tim e o r t o r e s t a rt th e u n it a f t e r
clean i n g , ob s e r ve th e f oll o w i n g
proc e d u r es:

1. R e m o v e th e d i spen s e r l i d s and
set t h e m asi d e .

2. M a k e sur e t h at a l l cont r o l
swit c h e s are i n t he c ente r p o s i ti o n
(OFF )

3. P o u r prod u c t in t o t he h o p p ers.

4. P l a c e th e l i d s o n the m a c h i ne .

5. T e s t the c o n t rol s w i tch i n t h e
CLEA N p o siti o n .

NOTE : W ith t h e con t r o l s set i n t he
CLEA N p osit i o n , th e d r i ve m o t or
turn s t h e b e a t e r ba r a n d the
comp r e s s or r e m a i ns o f f .

6. P l a c e th e c o n trol s w itch i n th e
AUTO p o siti o n . Al l o w t h e u n i t t o
run i n F R EEZ E m ode u n t i l th e
comp r e s s or st o p s .

7. S a m p l e t h e p r od u c t f or t a s t e
and t h i c k nes s .

8. I f n e cess a r y , us e t h e thi c k n e ss
adjus t m e n t sc r e w to a d j u st t h e

mach i n e for o p t i mal p r o d u ct
thi c k n e s s . Th e p rodu c t s h ould b e
slush y — n eit h e r as t h i n as j u i c e,
nor a s t h ick a s i ce c r e a m.

NOTE : C H I LL i s a n ext e n d e d
defr o s t m od e t h a t al l o w s the u n i t
to r e m a i n un a t t e n ded f o r m or e
than 1 2 h ou r s . It w i l l m a i n tain t h e
produ c t a t a r e f rige r a t e d
temp e r a t u re. T h i s m o d e is en e r gy
effi c i e n t and r e t ain s t h e p r o d u ct
freshn e s s.

NOTE : Y o u r di s p e n ser w i l l be
equi p p e d wit h a l o w - l evel i n dicat o r
lig h t . Desi g n e d to a c t i vat e t h e li g h t
when p r o duct i n t he h o p pe r f a l l s
belo w a cert a i n lev e l . H owe v e r ,
addi n g m i x b e f o re th e l i gh t g o e s
off wi l l i n c r e a se pr o d u c t ion a n d th e
rec o v e r y rat e o f you r u n i t.

9. Wh e n t h e r e s u l ts o f a l l t e s t s a nd
check s a re s a t i s f act o r y , the u n i t i s
read y f o r op e r a t i on.

10. P e r f orm a f i nal c h eck, r e t u rn
the s w i t c h es t o AU T O , and w i pe
down t h e out s i d e of t h e uni t .

Low Level Indicator
Light

DMW Dispense r O p erations M anual 9

OFF POSITION

AUTO POSITION

CLEAN POSITION

CHILL MODE

DMW Dispense r O p erations M anual 10

Parts, Assembly, and Lubrication

The D r i nk Ma c h i ne W o r k s u n i t is sh i p p ed f u l ly as s e m b led a n d is r e a d y f o r
ini t i a l start u p and o p e rati o n . The f o l l ow i n g i nst ru c t i ons p r o vid e s t ep -by-st ep
gui d a n c e for t r o u bl e s h o otin g a n d mai n t enanc e p roc ed u r e s un d e r n orm a l
opera t i o n con d i t ion s .

1. Lu b r i cate t h e b e a t e r bar s h aft t h orou g h l y.

IMP O R T A N T: F a i l ur e t o l ub r i c a t e p a r t s
resul t s i n d a m a g e t o t h e ma c h i n e. P e t r o Gel
or o t h e r sani t a r y lu b r i cant s a r e
rec o m m e n ded f o r m achi n e l ub r i c a t ion .

2. In s e r t th e s h a ft i n t o t he w h i t e r e a r s eal
moun t i n the b a c k o f t h e cyl i nder.

3. Li g h t l y p u s h and r o t a te th e shaft u n t i l i t
full y e n gage s t h e d r i v e coup l i ng i n t h e r e a r
of th e c y l i n d e r .

5. Fi t t h e O - r i ng i n t o t he g r o o ve o f t h e
facep l a t e.

6. In s t a l l t h e facep l a te a s f o l low s :

a. Ali g n t he fa c e p l ate b u s h i ng w i th th e

shaft o f the b e a t er b a r .

b. Slide t h e f a cepl a t e ov e r t h e fo u r stud s .

IMPO R T A N T : D o N O T lu b r i cate t h e
facep l a t e O- r i n g. T h e f acep l a t e sh o u l d fi t
snugl y t o th e c y l i n d e r w i thou t s l i p p a g e.

c. Tigh t e n the f a c epla t e b y e v e n l y tu r n i ng

all f o u r fac e p l ate k n o b s cl o c k w i se .

NOTE : T i g h ten t h e fa c e p l ate k n o b s ON L Y b y
hand. D o not o v erti g h t e n the k n obs.

DMW Dispense r O p erations M anual 11

Faucet Assembly

Compl e t e the f o l low i n g step s t o ass e m b l e th e f a u ce t.

1. L u b r i cat e t h e pl u n g e r O - ring t h o roug h l y .

2. S l i de th e s p rin g o n t o th e p l ung e r s h aft .

3. I n s e r t th e p l ung e r i nto t h e fauc e t b ody.

NOTE : L u bri c a t e th e p l u nger O -ri n g wit h P e t ro G e l or ot h e r sani t a ry
lub r i c a n t i f t h e plu n g e r d o e s n ot sl i de sm o o t h l y.

4. P u s h th e t h r e aded e n d of t h e fau c e t p lun g e r t hrou g h t he s m a l l hol e on
the f r o n t of t h e fauc e t b ody .

5. S c r e w th e b l a ck f a u c et kn o b onto t h e as s e m b l y.

NOTE : T i g h ten f a u cet p a r t s b y h a n d ON L Y . Do n o t o verti g h t en p a r t s.

6. S c r e w th e f a u cet o n t o t h e fac ep l a t e u n t i l i t i s tig h t . M ak e s u r e tha t t h e
exi t h o l e of t h e fau c e t f ac es d o wn.

DMW Dispense r O p erations M anual 12

Beater Bar Assembly

Ass em b l e the b e a ter b a r as f o l l ows:

1. S l i de th e s c rap e r b l ad e s p r i ng o n t o
the s c r a p er b l a d e ro d .

2. W h i l e hol d i ng th e s pri n g o n th e
scrape r b l a de r o d , hook t h e la r g e end o f
the s p r i ng a r o u n d th e b e a t er b a r fram e
and i n s e rt i t i n to th e f ront m o u n ti n g h ole.

3. R o t a t e th e s c rap e r b l ad e u n t il i t
poin t s s t rai g h t up.

4. P u s h th e s c r a p er b l a d e r o d i nto t h e
front m o u nti n g h ole u n t i l t h e s p ri n g is
comp r e s s ed.

5. I n s e r t th e o p p os i t e end o f t h e r o d i nto
the r e a r moun t i n g h o l e .

NOTE : T o di s a s s embl e t h e b e a t e r ba r ,
rev e r s e S t ep s 1 t hrou g h 5 .

DMW Dispense r O p erations M anual 13

Thickness and Consistency

Produ c t t hi c k n e s s is c o n trol l e d wit h a n e l e ctron i c sma r t l ogi c s ystem .

To I N C R E ASE t h i c kne s s : t u r n t he c o n t rol s c r e w ge n t l y tu r n C L OCK W I S E .

To DE C R E ASE t h i c kn e s s : t u r n the c o n trol s c r e w g e n t l y tu r n

COUN T E R C LOCK W I S E.

Maintenance Schedule

Perf o r m regul a r main t e n a n ce p r o c edur e s a ccord i n g to t h e S tand a r d Ope r a t i ng
Proc e d u r es l i s t e d i n T a b l e b e l o w.

Dail y

Fil l t h e d i sp e n s e r & c y c l e t he b e v e r a g e
Wipe d o w n t he f r o n t o f the d i s p e nse r
Defro s t - Mid ni g h t unt i l o p e ni n g t i m e

Weekl y

Clean - fol l o w pr o c e d u r es f o r w eekl y c l ean i n g

Month l y

Deep C l e a n - f oll o w c l eani n g i nst r u c t i on s l i sted i n
Opera t i on Man u a l .
Insp e c t t h e u n i t for l e a k s.
Insp e c t t h e O - r i ngs a n d seal s for d e f o rmat i o n s or
tear s .
Lubri c a t e as n e e d ed.
Insp e c t t h e b e a ter b a r a ssemb l y and b l ade s h a r p n es s

Eve r y S i x Mon t h s

Repl a c e the O - r i ng s a n d ch e c k t he f a u cet, p l unge r ,
rear s e a l , an d f a cep l a t e.

Adjustment Screws
TOP – Left side
Bottom – Right side

DMW Dispense r O p erations M anual 14

Drink M a chi n e W o rks d i sp e n s e rs a r e d esi g n e d to w i t h stand r i gorou s u s e.
When o p erated a n d s e r v i c ed a s s p eci f i e d , th e d i spen s e r wil l p r ovid e m a n y
year s o f trou b l e -f r e e ope ra t i o n .

CAUT I O N : Pow e r f ail u r e s and s u r g es m a y d ama g e y our m a c h i ne. W h en y o u
susp e c t p ot en t i a l l y d a m a gin g con d i t i ons i n y our a r e a , tu r n o ff th e p ower t o
the u n i t unti l t he d a n g e r pa s s e s.

CAUT I O N : NEV E R a ttemp t t o fr e e z e pl a i n wate r o r any m i xtu r e c o n tai n i ng
artifi c i al s w e e t ene r i n a D r i nk M a c h ine W o rks d i spen s e r . In a d d i ti o n , p ouri n g
extr e m e l y h o t w a t er ( 1 2 0ºF o r h ott e r ) i nt o t h e cyl i n der w i l l c au s e
irre v e r s i bl e e q u i pm e n t d ama g e . Dam a g e cau s e d b y i m p r o p er u s e i s n o t
cove r e d u nde r w a rran t y .

WAR N I N G : When i n stal l i ng, cl e a n i ng, a d j usti n g , or o p e r a ti n g t h is m a c h i ne ,
do n o t p l ace a n y bo d y p a rt o r o t her o b j e ct i n t o t h e hop p e r whi l e t h e ma c h i ne
is i n o p erati o n . Doi n g so can c a u se s e r i ous i n j u ry.

DMW Dispense r O p erations M anual 15

CLEANING AND SANITIZING PROCEDURES

For p r o p er o p e r a t i on , e q u ipm e n t l ong e v i ty, a n d enhan c e d cu st o m e r
sati s f a c t i on , i t is i m p ortan t t o pe r f o r m al l r e comm e n d ed cl e a n i n g an d
sani t i z ing p r o c edur e s f or th e Dri n k Mach i n e Work s Uni t . B a sic c l e ani n g
proc e d u r es sh o u l d b e p e rfor m e d w ee k l y and d e e p cle a n i n g pr o c e d u re s s h o u ld
be p e r f o r med m o n t hl y .

NOTE : T he f o l l owi n g w e ekl y c l eani n g p roc e d u r es en s u r e com p l i ance w i t h
NSF I n t e rnati o n a l ( N S F ) sani t i zi n g r e q u i rem e n t s f o r t h e Dri n k M a chi n e W orks
syst e m . F ai l u r e t o f o l l ow th e p r oced u r e affe c t s the p r o d uct q u a l it y , d a mag e s
the d i s p ense r , a n d v o i d s th e w a rran t y .

Cleaning Equipment and Supplies

To p e r f o rm f u l l cl e a n i ng a n d s ani t i z ing p r o c edur e s
for th e D rin k M a chi n e W ork s U nit , y o u w i l l need
the f o l l owin g e q ui p m e n t and s u p p li e s :

• two 2 - o z pa c k a g es o f S t era - S h een®

sani t i z er and c l ean e r (o r e q u i val e n t )

• one 5 - g a l s a n i t izi n g c o n tai n e r or b u c k et f o r

drai n i ng and s a ni t i z i n g th e d i sp e n s e r

• clean t o wel s

1. P l a c e co n t r ol sw i t c h es t o t h e CL E A N posi t i on 30
min u t e s befo r e c l ea n i n g.

2. P u l l fau c e t p lu n g e r , empt y a l l p rodu c t i nto a n
open c o n tai n e r a n d D I S CARD .

WARN I N G : P r oduc t r e m ov ed cann o t b e r e - u sed i n
the d i s p ense r !

3. P l a c e co n t r ol s w i t c h es t o t h e O F F p osi t i o n.

4. P o u r 2.5 g a l l on s o f cool ( 6 0- 8 0 F ) ri n s e wa t e r
int o t h e hopp e r pe r s i de .

5. W i t h a cl e a n to w e l , w i p e the h o p p er c l e a n o f
any b u i l du p o f p rod u c t or d e b r i s .

WARN I N G : DO N O T in s e r t fin g e r i nsi d e t he i n l e t
hole o f t h e h o p p er.

6. P l a c e th e lids o n mach i n e .

7. Pl a c e the c o n t rol s w i tch e s t o th e C L EAN p o s i ti o n
and a g i t ate f o r 2 minu t e s , then s w i tch t o the O F F
posi t i on.

8. D r a i n an d d i spos e o f all r i n se w a t e r. ( R epea t i f
nec e s s a ry, t o r emov e d e b ris)

DMW Dispense r O p erations M anual 16

9. Di s s o l ve o n e 2 oz p a cket o f S tera -Sh e e n Gree n L a bel
in 2 g a l l o n s o f hot ( 1 0 0 o F) w a t er .

11. P o u r th e s a n iti z i n g sol u t i on i n t o t h e h o p p e r and
clean t h e hop p e r , l e v el p r o b es, a n d i nl e t h ole w i t h a
clean t o wel .

12. P l a c e c o n t rol s w i tch es t o CL E A N posi t i on, p u t l id s on
mach i n e and a g i t a te f o r at l e a st 4 m i nut e s .

WARN I N G : En s u r e t hat N O D rin k s c a n b e s e r ved at t h i s
tim e

13. P l a c e c o n t r ol s w i tches t o O F F p o s i t i on a n d drai n a l l
sol u t i o n .

14. R e m o v e f a c e p l at e b y turn i n g th e f o u r kn o b s i n a
count e r - clo c k w i se d i r e ction u n ti l t hey a r e rem o v e d from
the s t u d s.

15. P u l l th e f a c eplat e a way f r o m th e f r o nt of t h e ma c h i ne
and p u l l t h e b e a ter b a r t o r e m ov e f r om t h e cyli n d e r .

(Beat e r B ar m a y be h ard t o r e mov e d u e t o p r evio u s
lubr i c a n t )

16. Un s c rew t h e f au c e t a ssem b l y from t h e f a c epl a t e a nd
disa s s e m ble t h e fau c e t bod y b y u nsc r e w in g t h e b la c k
knob f r o m th e p l ung e r . (R e f e r to F a u cet A s s e mbl y f o r
help )

17. Di s a ssem b l e the b e a t er b a r . ( R e f er t o
Beat e r B a r A s s e m b l y f or h el p )

18. W a s h all r e m ove d p a r ts ( i n c l udi n g d rip
tray) i n wa rm ( 1 00* F ) sani t i z ing s o l u ti on a n d
all o w t o ai r d r y.

20. R e a s semb l e t he d i s p e nser w ith a l l p a r t s .
(Ref e r t o Pa r t s , As s e m b ly a n d Lub ri c a t ion f o r
help )

21. R e f i ll t h e d i sp en s e r w i t h pr od u c t .

22. P l a c e th e l i ds o n m achi n e and s e t c o n t r ol s w i t ches t o AU T O p osi t i on.
