DMC Analog Resistive Touchscreen ATP/AST Series, ATP Series, AST Series Product Specifications
Analog Resistive Touchscreen
ATP/AST Series Product Specifications
DER-S0080A 2 Rev. 12©1999 - 2011 DMC Co., Ltd.
ATP/AST Series Product Specifications
Table of Contents
1. Product Specifications...........................................................................................................................3
1-1. Product Applicable .............................................................................................................................3
1-2. Structure.............................................................................................................................................3
1-3. Environmental Specifications .............................................................................................................3
1-4. Mechanical Characteristics ................................................................................................................3
1-5. Electrical Characteristics ....................................................................................................................3
1-6. Appearance ........................................................................................................................................4
2. Testing Regulation.................................................................................................................................. 5
2-1. Testing Regulation..............................................................................................................................5
2-2. Environmental Specifications .............................................................................................................5
2-3. Mechanical Characteristics ................................................................................................................5
2-4. Electrical Characteristics ....................................................................................................................6
2-5. Appearance ........................................................................................................................................6
3. Reliability Condition...............................................................................................................................7
3-1. Temperature Condition .......................................................................................................................7
4. Recommended Connector .....................................................................................................................7
4-1. Recommended Connector .................................................................................................................7
5. Handling Notes........................................................................................................................................8
5-1. Precautions ........................................................................................................................................ 8
5-2. Handling Notes...................................................................................................................................8
5-3. Construction Notes.............................................................................................................................8
5-4. Electrical & Software Notice ...............................................................................................................8
5-5. Mounting Notes ..................................................................................................................................9
6. Warranty ................................................................................................................................................ 10
6-1. Warranty Period ............................................................................................................................... 10
6-2. Warranty Target................................................................................................................................ 10
6-3. Warranty Exceptions ........................................................................................................................ 10
6-4. Tools.................................................................................................................................................10
6-5. Changes........................................................................................................................................... 10
6-6. RoHS Compliance……………………………......................................................................................11
7. Revision history....................................................................................................................................11
DER-S0080A 3 Rev. 12©1999 - 2011 DMC Co., Ltd.
ATP/AST Series Product Specifications
1. Product Specifications
1-1. Product Applicable
§ This specification is applied to the analog resistive touchscreen: ATP/AST Series.
1-2. Structure
§ Dimensions, structure, and shape are referred on the drawing attached.
1-3. Environmental Specifications
Specification Value
Operating Temperature -20°C to 70°C (no condensation)
Operating Humidity
-20°C to 60°C Less than 90%RH (no condensation)
Exceeding 60°C 133.8g/m
3
(no condensation)
Storage Temperature -40°C to 80°C (no condensation)
Storage Humidity
-40°C to 60°C Less than 95%RH (no condensation)
Exceeding 60°C 142.9g/m3 (no condensation)
Chemical Resistance
(top surface)
Toluene, Tricholoroethylene, Athetone, Alcohol,
Gasoline, Machine Oil, Ammonia, Glass Cleaner,
Mayonnaise, Ketchup, Wine, Salad Oil, Vinegar, Lipstick, etc.
1-4. Mechanical Characteristics
Specification Value
Activation Force 0.05N to 0.8N
Input (finger) 10,000,000 hits
Operating Life
Character Input (pen) 100,000 characters
Light Transmittance Over 80% (typical value at full wavelength)
Surface Hardness Over 2H (by JIS pencil hardness)
1-5. Electrical Characteristics
Specification Value
Maximum Voltage DC6V
Top Electrode 100mA
Bottom Electrode 100mA
Maximum Current
Between the Top and Bottom 0.5mA
Linearity
Under ±2% (Under ±1% (typical value))
Top Electrode
Less than 1kΩ
Terminal Resistance
Bottom Electrode
Less than 1kΩ
Neighboring Terminals
Over 20MΩ at 25V
Insulation Resistance
Active Area Electrodes
Over 20MΩ at 25V
Chattering Less than 10msec at ON/OFF.
DER-S0080A 4 Rev. 12©1999 - 2011 DMC Co., Ltd.
ATP/AST Series Product Specifications
1-6. Appearance
§ Scratch, dust (W = width, L = length, D = average diameter = (longest + shortest) /2)
Item Width (mm) Length (mm) Acceptable Numbers Total
0.1≥W>0.05 4≥L 1pcs in φ30mm
0.05≥W>0.03 10≥L 2pcs in φ20mm
Linear(Scratch/Dust)
Over 0.1mm in
diameter refer to the
Circular.
0.03≥W 20≥L
Acceptable
0.4≥D>0.3 *1
1pcs in viewing area *1
0.3≥D>0.2 2pcs in φ30mm
Circular
(Scratch/Dust)
0.2≥D
Acceptable
Within 5pcs
/panel
Applied only in the Active Area. Scratches or dusts in the outside of the Active Area are acceptable unless the
electrical characteristics are affected.
*1 Applied to the size of 14 inches or more.
§ Dirt
Acceptable if not noticeable on a black mat.
§ Tip, crack (t = glass thickness) (applicable only for the glass)
Item Size (mm) Acceptable Numbers
X
≤3
Y
≤3
Corner
Z
≤t
2pcs
/panel
X
≤5
Y
≤3
Side
Z
≤t
2pcs
/side
Crack Not acceptable
X
Y
Z
Z
X
Y
