Table of Contents
Table of Contents
Product Overview.............................................................. |
4 |
Package Contents......................................................................... |
4 |
System Requirements.................................................................. |
5 |
Introduction.................................................................................... |
6 |
Features............................................................................................ |
8 |
Hardware Overview...................................................................... |
9 |
Connections............................................................................ |
9 |
LEDs.......................................................................................... |
10 |
WPS Button............................................................................ |
11 |
Installation........................................................................ |
12 |
Wireless Installation Considerations.................................... |
13 |
Configuration................................................................... |
14 |
First Time Setup........................................................................... |
14 |
Web-based Configuration Utility........................................... |
19 |
Wireless Setup Wizard............................................................... |
20 |
Manual Configuration............................................................... |
21 |
Wireless Setup...................................................................... |
21 |
LAN Settings.......................................................................... |
23 |
Static IP............................................................................... |
24 |
Advanced....................................................................................... |
25 |
Advanced Wireless.............................................................. |
25 |
Maintenance................................................................................. |
26 |
Admin...................................................................................... |
26 |
System..................................................................................... |
27 |
Language Pack..................................................................... |
28 |
Firmware................................................................................. |
28 |
Time.......................................................................................... |
29 |
Status............................................................................................... |
30 |
Device Info............................................................................. |
30 |
Logs.......................................................................................... |
31 |
Statistics.................................................................................. |
32 |
Help.................................................................................................. |
33 |
Wireless Security.............................................................. |
34 |
What is WPA?................................................................................. |
35 |
Configure WPA/WPA2 Personal.............................................. |
36 |
Connect to a Wireless Network....................................... |
37 |
Using Windows® XP..................................................................... |
37 |
Configure WPA-PSK.................................................................... |
38 |
Using Windows Vista® ................................................................ |
40 |
Configure WPA-PSK.................................................................... |
42 |
Using Windows® 7........................................................................ |
43 |
Configure WPS...................................................................... |
46 |
Troubleshooting............................................................... |
50 |
Wireless Basics.................................................................. |
54 |
What is Wireless?......................................................................... |
55 |
Tips................................................................................................... |
57 |
Wireless Modes............................................................................ |
58 |
Networking Basics............................................................ |
59 |
Check your IP address................................................................ |
59 |
Statically Assign an IP address................................................ |
60 |
D-Link DAP-1513 User Manual |
2 |
Table of Contents |
|
Technical Specifications................................................... |
61 |
Contacting Technical Support......................................... |
62 |
Warranty........................................................................... |
63 |
Registration...................................................................... |
69 |
D-Link DAP-1513 User Manual |
3 |
Section 1 - Product Overview
Product Overview
Package Contents
DAP-1513 Wireless N Dual Band MediaBridge®
Ethernet Cable
Power Adapter
CD-ROM with Manual
Note: Using a power supply with a different voltage rating than the one included with the DAP-1513 will cause damage and void the warranty for this product.
D-Link DAP-1513 User Manual |
4 |
Section 1 - Product Overview
System Requirements
Network Requirements |
• An Ethernet-based Network |
• IEEE 802.11n/g wireless access point or wireless router |
|
|
• 10/100 Ethernet |
|
|
|
Computer with the following: |
|
• Windows®, Macintosh, or Linux-based operating system |
|
• An installed Ethernet adapter |
|
Browser Requirements: |
Web-based Configuration |
• Internet Explorer® 6.0 and higher |
Utility Requirements |
• Mozilla Firefox 3.0 and higher |
|
• Google™ Chrome 2.0 and higher |
|
• Apple Safari 3.0 and higher |
|
Windows® Users: Make sure you have the latest version of Java installed. |
|
Visit www.java.com to download the latest version. |
|
|
D-Link DAP-1513 User Manual |
5 |
Section 1 - Product Overview
Introduction
D-Link, an industry leader in networking, introduces the new D-Link DAP-1513 Wireless N Dual Band MediaBridge®. With the ability to transfer files with a maximum wireless signal rate of up to 300Mbps*, the DAP-1513 gives you high-speed wireless network access for your home or office.
The DAP-1513 is Wi-Fi IEEE 802.11n compliant, meaning that it can connect and interoperate with other 802.11n compatible wireless client devices. The DAP-1513 is also backwards compatible with 802.11b/g and offers dual band support for 802.11a. With its Setup Wizard, the DAP-1513 ensures that you will be up and running on a wireless network in just a matter of minutes.
The DAP-1513 features Wi-Fi Protected Access (WPA-PSK/WPA2-PSK) to provide an enhanced level of security for wireless data communications. The DAP-1513 also includes additional security features to keep your wireless connection safe from unauthorized access.
• Actual data throughput will vary. Network conditions and environmental factors, including volume of network traffic, building materials and construction, and network overhead, lower actual data throughput rate.
D-Link DAP-1513 User Manual |
6 |
Section 1 - Product Overview
TOTAL PERFORMANCE
Combines award winning access point features and 802.11n wireless technology to provide the best wireless performance.
TOTAL SECURITY
The most complete set of security features including WPA/WPA2 encryption to protect your network against outside intruders.
TOTAL COVERAGE
Provides greater wireless signal rates even at farther distances for best-in-class home coverage.
ULTIMATE PERFORMANCE
The D-Link Wireless N Dual Band MediaBridge® (DAP-1513) is an 802.11n compliant device that delivers real world performance of up to 650% faster than an 802.11g wireless connection (also faster than a 100Mbps wired Ethernet connection). Create a secure wireless network to share photos, files, music, video, printers, and network storage throughout your home. Connect the DAP-1513 to router and share your high-speed Internet access with everyone on the network. In addition, this Range Extender includes a Quality of Service (QoS) engine that keeps digital phone calls (VoIP) and online gaming smooth and responsive, providing a better Internet experience.
TOTAL NETWORK SECURITY
The DAP-1513 supports all of the latest wireless security features to prevent unauthorized access, be it from over the wireless network or from the Internet. Support for WPA and WPA2 standards ensure that you’ll be able to use the best possible encryption method, regardless of your client devices.
* Maximum wireless signal rate derived from IEEE Standard 802.11g and 802.11n specifications. Actual data throughput will vary. Network conditions and environmental factors, including volume of network traffic, building materials and construction, and network overhead, lower actual data throughput rate. Environmental conditions will adversely affect wireless signal range.
D-Link DAP-1513 User Manual |
7 |
Section 1 - Product Overview
Features
•FasterWireless Networking - The DAP-1513 provides up to 300Mbps* wireless connection with other 802.11n wireless devices. This capability allows users to participate in real-time activities online, such as video streaming, online gaming, and real-time audio.
•Compatible with IEEE 802.11g Devices - The DAP-1513 is still fully compatible with the 802.11g standards, so it can connect with existing 802.11g PCI, USB, and Cardbus adapters.
•WPS PBC - (Wi-Fi Protected Setup Push Button Configuration) Push Button Configuration is a button that can be pressed to add the device to an existing network or to create a new network. A virtual button can be used on the utility while a physical button is placed on the side of the device.
This easy setup method allows you to form a secured wireless link between the DAP-1513 and another WPS enabled device. A PC is no longer needed to log into the Web-based interface.
•WPS PIN - (Wi-Fi Protected Setup Personal Identification Number ) A PIN is a unique number that can be used to add the access point to an existing network or to create a new network. The default PIN may be printed on the bottom of the access point. For extra security, a new PIN can be generated. You can restore the default PIN at any time. Only the Administrator (“admin” account) can change or reset the PIN.
•User-friendly Setup Wizard - Through its easy-to-use Web-based user interface, the DAP-1513 lets you control what information is accessible to those on the wireless network, whether from the Internet or from your company’s server. Configure your access point to your specific settings within minutes.
D-Link DAP-1513 User Manual |
8 |
Section 1 - Product Overview
Hardware Overview
Connections
1
2
3
1LAN Ports (1-4) Connect 10/100 Ethernet devices such as computers, switches, and hubs.
2Power Receptor Receptor for the supplied power adapter.
3 |
Reset Button |
Hold the reset button for at least 6 seconds to reset the device back to the factory default |
|
settings. All the LEDs will turn on for 2 second and then begin the reboot process. |
|||
|
|
D-Link DAP-1513 User Manual |
9 |
Section 1 - Product Overview
Hardware Overview
LEDs
1
2
1 |
Power LED |
A solid green light indicates a proper connection to the power supply. |
|
|
|
2 |
Wireless LED |
A blinking green light indicates the wireless function is working. The light will blink fast during |
data transmission and when WPS is associating. The light will be off during device reboot or |
||
|
|
if the wireless radio is disabled. |
D-Link DAP-1513 User Manual |
10 |
Section 1 - Product Overview
Hardware Overview
WPS Button
1
1 |
WPS Button |
Press to start the WPS process. You will have 120 seconds to start the WPS process on |
|
another wireless device . |
|||
|
|
||
|
|
|
D-Link DAP-1513 User Manual |
11 |
Section 2 - Installation
Installation
In the Wireless Client mode, the DAP-1513 acts as a wireless network adapter for your Ethernet-enabled device (such as a game console or a TV set-top box). Connect your Ethernet-enabled device to the AP using an Ethernet cable. The AP Client mode can support multiple wired clients.
If you are going to connect several Ethernet-enabled devices to your DAP-1513, connect the LAN port of the DAP-1513 to an Ethernet switch, then connect your devices to this switch.
Example: Connect a gaming console using an Ethernet cable to the DAP-1513. The unit is set to Wireless bridge which will wirelessly connect to a wireless router on your network.
Gaming Console
Internet |
Modem |
Router |
DAP-1513 |
D-Link DAP-1513 User Manual |
12 |
Section 2 - Installation
Wireless Installation Considerations
The D-Link wireless access point lets you access your network using a wireless connection from virtually anywhere within the operating range of your wireless network. Keep in mind, however, that the number, thickness and location of walls, ceilings, or other objects that the wireless signals must pass through, may limit the range. Typical ranges vary depending on the types of materials and background RF (radio frequency) noise in your home or business. The key to maximizing wireless range is to follow these basic guidelines:
1.Keep the number of walls and ceilings between the D-Link access point and other network devices to a minimum. Each wall or ceiling can reduce your adapter’s range from 3-90 feet (1-30 meters.) Position your devices so that the number of walls or ceilings is minimized.
2.Be aware of the direct line between network devices. A wall that is 1.5 feet thick (.5 meters), at a 45-degree angle appears to be almost 3 feet (1 meter) thick. At a 2-degree angle it looks over 42 feet (14 meters) thick! Position devices so that the signal will travel straight through a wall or ceiling (instead of at an angle) for better reception.
3.Building Materials make a difference. A solid metal door or aluminum studs may have a negative effect on range. Try to position access points, wireless access points, and computers so that the signal passes through drywall or open doorways. Materials and objects such as glass, steel, metal, walls with insulation, water (fish tanks), mirrors, file cabinets, brick, and concrete will degrade your wireless signal.
4.Keep your product away (at least 3-6 feet or 1-2 meters) from electrical devices or appliances that generate RF noise.
5.If you are using 2.4GHz cordless phones or X-10 (wireless products such as ceiling fans, lights, and home security systems), your wireless connection may degrade dramatically or drop completely. Make sure your 2.4GHz phone base is as far away from your wireless devices as possible. The base transmits a signal even if the phone is not in use.
D-Link DAP-1513 User Manual |
13 |
Section 3 - Configuration
Configuration
This section will show you how to configure your new D-Link wireless access point using the web-based configuration utility.
First Time Setup
When you first connect the DAP-1513 to your computer, the setup wizard will automatically launch.
Click Next to continue.
The DAP-1513 is in wireless bridge mode. Click Next to continue.
D-Link DAP-1513 User Manual |
14 |
Section 3 - Configuration
If you have a Wi-Fi Protected Setup (WPS)-enabled wireless router or access point, select WPS and click Next to continue.
If you want to manually enter the network settings, select Manual and click Next to continue. Skip to page 17.
For PBC (Push Button Configuration), skip to the next page.
Select PIN to connect your wireless device with WPS. You may click Generate New PIN to use a different PIN number. Click Connect to start the WPS scan.
Within 2 minutes, enter the PIN number into the other device you want to connect to.
D-Link DAP-1513 User Manual |
15 |
Section 3 - Configuration
Select PBC to use the Push Button Configuration to connect to your network. Click Connect to continue.
Note: In the future, you may press the WPS button located on the side of the DAP-1513 instead of running this wizard.
On the device you want to connect to, start the PBC process on the device. You will have 2 minutes to start the PBC process on both devices.
D-Link DAP-1513 User Manual |
16 |
Section 3 - Configuration
Select Manual configuration to setup your network manually.
Click Next to continue.
Enter the network name (SSID) of the network you want to connect to. If you do not know the exact name or would like to search for the wireless network, click Site Survey.
Find your access point from the list, click the radio button in the right column, and click Connect.
D-Link DAP-1513 User Manual |
17 |
Section 3 - Configuration
Click Next to continue.
Select the wireless security mode you would like to use.
If you select WPA or WPA2, enter the wireless security password. Click Next to complete the Setup Wizard.
The Setup Wizard is complete. Click Finish to reboot the device.
D-Link DAP-1513 User Manual |
18 |
Section 3 - Configuration
Web-based Configuration Utility
If you wish to change the default settings or optimize the performance of the DAP-1513, you may use the web-based configuration utility.
To access the configuration utility, open a web browser such as Internet Explorer and enter dlinkap or 192.168.0.50 in the address field.
Type Admin and then enter your password. Leave the password blank by default.
If you get a Page Cannot be Displayed error, please refer to the Troubleshooting section for assistance.
D-Link DAP-1513 User Manual |
19 |
Section 3 - Configuration
Wireless Setup Wizard
Click Launch Wireless Setup Wizard to configure your wireless bridge. Refer to the FirstTime Setup section for the Wireless Setup Wizard.
If you want to enter your settings without running the wizard, click Wireless Setup on the left side and skip to the next page.
D-Link DAP-1513 User Manual |
20 |
Section 3 - Configuration
Manual Configuration
Wireless Setup
Wireless Mode: Bridge Mode only.
Site Survey: Click Site Survey to display a list of wireless networks in your area. You may select the wireless access point to connect to.
Enable Wireless: Check the box to enable the wireless function. If you do not want to use wireless, uncheck the box to disable all the wireless functions. You may also set up a specific time range (schedule). Select a schedule from the drop-down menu or click Add New to create a new schedule.
Wireless Type: Select Infrastructure if connecting to an access point or wireless router, or select Ad-Hoc if connecting to another wireless client.
Wireless Network Enter the SSID of the access point or wireless router Name: you want to connect to. If you do not know for sure, click Site Survey and select it from the list, if available.
Wireless Channel: The channel will automatically change to the channel of the AP you are connected to.
802.11 Mode: Select the appropriate 802.11 mode based on the wireless clients in your network. The drop-down menu options are 802.11g Only, Mixed 802.11b/g, 802.11bOnly, 802.11nOnly, or Mixed802.11b/g/n.
Channel Width: Select the appropriate channel width between 20MHz or Auto 20/40MHz from the drop-down menu.
D-Link DAP-1513 User Manual |
21 |
Loading...
