DiyTracker MT-18 User's Manual Installation And Operating Instructions

REAL TIME GPS TRACKING AND MONITORING SYSTEM
It’s LIVE
Vehicle Tracking
Anytime,
Anywhere
REAL TIME
User’s Guide
Installation and Operating Instructions
All rights reserved. ©2011 DIY TRACKER
Contents
2
CONTENTS
INTRODUCTION 3
HARDWARE AND ACCESSORIES 4
INSTALLATION PROCESS 5
WIRING DIAGRAM 6
TESTING AND TROUBLESHOOTING 8
WARRANTY AND DISCLAIMER 9
All rights reserved. ©2011 DIY TRACKER
Introduction
Before Installing
This guide covers the installation of the DiyTrack device to ensure a safe and functional install of the unit by either a Professional or novice installer Prior to the installation process, thoroughly review this guide and adhere to the following:
- Use only a Digital or Analog Volt Meter - DO NOT USE TEST LIGHT!
- Check for possible installation locations for the tracker unit prior to permanent installation.
- Make sure that the installation process does not cause damage to any motorcycle hose, electrical loom, or cause physical damage to the motorcycle
- Make note of the unit mobile and serial numbers prior to installation.
- Prior to installing this device, disconnect the motorcycle battery
- Make sure the device and all associated cables are securely mounted and do not impede any of the motorcycles’s controls.
- Ensure all connections are properly soldered and insulated, all un-used cables must be properly insulated.
- Use high quality electrical tape and shrink tubing were necessary
motorcycle
panel disassembly, and any other mechanical aspects of the motorcycle
Thank you for purchasing our “DiyTracker”
Each unit has been manufactored to the highest quality to ensure reliability and ease of use.
GPS Fundamentals
All GPS Trackers require a SIM card
To get the location data from the GPS tracking unit to a users computer some transmission channel is required. Don’t panic it will not cost a “premium” The Tracker uses GPRS and only sends a very small amount of data.
Your Tracker is already tted with a Pre -Paid Simcard.
3
There is a minimum of 24 operational GPS satellites at all times. The satellites, operated by the U.S. Air Force, orbit the earth every 12 hours. Each GPS satellite transmits data that indicates its location and the current time. All GPS satellites synchronize operations so that these repeating signals are transmitted at the same instant. The signals, moving at the speed of light, arrive at a GPS receiver
determined by determining the amount of time it takes for their signals to reach the receiver. When the receiver determines the distance to at least four GPS satellites, it can by triangulation, calculate its position in three dimensions.
To ensure the GPS unit receives enough satellite signals at an acceptable signal strength, it must be mounted so that it has a
clear view of the sky. In hidden locations, such as under the fairing or seat, it is important to keep any metal interference as far as
While GPS data collection has improved in ease and speed, some obstacles remain. Solid or dense objects can block GPS signals.
Wet trees with heavy branches and leaves can mask or attenuate GPS signals. Mountains and buildings can block satellite transmission.
users should be aware of obvious multipath environments.
possible from the top portion (map picture) of the GPS unit so that the most accurate position can be calculated.
All rights reserved. ©2011 DIY TRACKER
Hardware & Accessories
Contents of the Box
1. DiyTrack TellMe Tracking Unit
2. Cable Harness
3. Relay
Tools Needed for Installation
• Metric and standard socket set
Wire strippers
• Digital Multimeter
• Screwdriver set
• Pliers
• Electrical tape
• Side cutters, wire cutters
Terminal crimpers
• Flashlight
• Soldering iron and solder
WARNING
It is highly recommended that a Digital Multimeter be used when probing
electrical systems on a motorcycle to prevent damage to factory components.
4
Correct wire/cable joining method
Solder and insulate all connections. (Crimping should be avoided wherever possible.)
All rights reserved. ©2011 DIY TRACKER
Installation Process
Installing and Mounting the GPS Unit
Solder and insulate all connections (Crimping should be avoided wherever possible)
WARNING
5
the satellites will degrade the signal and reduce the overall performance.
The TellMe unit can be installed in any type of motorcycle. The unit should be mounted
so it will not be exposed to or get damaged from people or objects.
To ensure the GPS unit receives enough satellite signals at an acceptable signal strength, it must be
mounted so that it has a clear view of the sky. In hidden locations, such as under the fairing or seat,
it is important to keep any metal interference as far as possible from the top portion of the GPS unit
so that the most accurate position can be calculated. Ensure the “gps Antenna area” is “face up” towards the sky
Any metal objects between the GPS Antenna Sensing Area and
Wiring Diagram
6
Solder and insulate all connections (Crimping should be avoided wherever possible)
WARNING
GND
A. Connec t the Brown wire/c able to the yell ow wire/ cable ( 86) of the relay B. Connect the white wire/cabl e (85 ) of the relay to a c onstant 12/2 4v sou rce C. Cut the positi ve wi re of the igniti on coil / fuel pump / sol enoid etc D. Connect the gree n wire of the relay (30) to one end of the positive wire that you c ut E. Connect the green wire of the rel ay (8 7a) to one end of the posi tive wi re that you cut
Power cut relay (Optional conn ection)
This connect ion is to re motely i mmobili se yo ur bike. Please be cautious if installing this optio nal immobiliser functi on as large curr ents are carried w hen s tarting the motorcycle and we woul d hate for y ou to have an u nplan ned motorcycl e sto p due to an installation failure.
86
85
87a
30
Relay
GND
+12 /24v
Bl ue
B lack
Red
Ye llow
Brown
Ign itio n C oil Fue l Pu mp Sol enoi d
Pan ic B utto n
All rights reserved. ©2011 DIY TRACK
86
85
87a
30
+12 /24v
B
A
C
D
E
Relay
All rights reserved. ©2011 DIY TRACKER
Installation Process
12/24v Power/Positive Connection (Red Wire)
Securely attach the wiring harness to the Tracking unit
Disconnect the negative terminal from the motorcycle battery to prevent a possible transient voltage surge
that will damage your traking unit. Please note warranty does not cover damage from transient voltage surge.
Switched Ignition 12/24v Connection (Yellow Wire )
The Yellow must be connected to a switched 12/24v source from the motorcycle.
Locate the Yellow wire found on the wire harness supplied with your Tracking unit.
Optional Connection
How to Find (+) 12/24v Ignition with a Multi Meter
1. Set your meter to DCV or DC voltage
2. Attach the (-) negative probe of the meter to the chassis ground
Your meter should read (+) 0v
4. Turn the ignition key to the “ON” position. If your meter reads (+)12/24VDC go to the next step, if not probe another wire.
5. Now turn the key to the start position. The meter display should stay steady (+) 12/24v, not dropping by more than a few tenths of a volt. If it drops close to or all the way to (0) zero, go back to step 3, If it stays steady at (+) 12/24v you have the ignition wire.
Ground Connection (Black Wire)
Re-connect the negative terminal to the vehicle battery and proceed to the next step
Solder and insulate all connections (Crimping should be avoided wherever possible)
WARNING
7
12-24V DC Power Connection (Red Wire)
Locate the Red wire found on the wiring harness. The red wire must be connected to a constant 12 volt source from the motorcycle to power the tracker unit.
It’s important that the12 volt power source maintains 12 volts at all times.
Locate the Black wire found on the wiring harness The black wire must be connected to the negative terminal of the motor cycle battery.
All rights reserved. ©2011 DIY TRACKER
Testing & Troubleshooting
8
After the TellMe tracking unit has been powered on for atleast 5 minutes, dial the tracker simcard mobile number that is inserted in your tracking unit. Let it “ring” 3 times then hang up. Now send the following SMS to the simcard mobile number that is inserted in your tracking unit:
*1234*P#
Please note the above SMS must be sent exactly like the example and all letters must be UPPER CASE
If the ITellMe tracking unit has been correctly installed and the GPS antenna has successfully fixed onto the satellites, then you will receice a SMS text message back from the TellMe tracking unit containing a “clickable” google map link showing you the current location of your motorcycle.
SYMPTOM CAUSES
Unit Does Not Power-up Power is not connected to the unit. With a Digital Volt
Meter, measure the voltage at the input to the unit. A positive voltage should be measured on the + terminal of the unit when measuring between the + terminal and the - terminal or chassis ground. This voltage should also measure 12/24v. Correct the wiring to assure the correct polarity and the correct voltage level.
Unit Does Not Find Cellular Service
The main cause of this is poor signal strength due to shielding. Move the motorcycle outside the building ,
after 5min re-apply power to the unit.
Unit Does Not Receive a GPS Signal The cause is that the GPS receiver is not locking into
the satellites. The main cause is due to the unit not receiving the signal from the satellites. Make sure that the unit “face up”is facing towards the sky. If it is, then move the motorcycle outside of any building/garage to allow the GPS unit to have a clear view of the sky.
If no GPS fix has been acquired by the time the tests are complete, then verify that the TellMe tracking unit has been installed correctly and that there is NO metal blocking the signal between the GPS antenna and the sky and that motorcycle is outside.
All rights reserved. ©2011 DIY TRACKER
Warranty & Disclaimer
9
Diy-Track warrants, to parties purchasing Diy-Track equipment directly from Diy-Track
i.e., to its authorized distributors and to no other parties, that for 12 months following the date of purchase,
Diy-Track equipment will be free of defects in materials and workmanship when installed, operated, maintained,
and serviced in strict accordance with
Diy-Track and, if applicable, the manufacturer’s requirements.
If
Diy-Track equipment fails because of a defect in materials or workmanship within the warranty period, Diy-Track will, at its sole option and at no charge, repair or replace it. Diy-Track agreement to repair using new or reconditioned parts or replace with a comparable new
or reconditioned
Diy-Track unit is the exclusive remedy with respect to Diy-Track Equipment found
to be defective in materials or workmanship; this remedy will not be deemed to have failed of its essential purpose so long as Diy-Track is willing and able to repair or replace the defective unit as provided above or, at
Diy-Track sole option, to refund the purchase price paid.
Parties purchasing
Diy-Track equipment from a distributor are referred to the distributor with respect
to any product claims they may have.
THE FOREGOING WARRANTY IS LIMITED AND IS THE ONLY WARRANTY OFFERED. DIY-TRACK MAKES NO OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, WITHOUT LIMITATION, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, TITLE, NON-INFRINGEMENT, AND NON-OBSOLESCENCE. THE FOREGOING WARRANTY FURTHERMORE DOES NOT COVER DIY-TRACK DEVICES THAT (A) HAVE BEEN IMPROPERLY INSTALLED, MAINTAINED, OR SERVICED; (B) HAVE BEEN TAMPERED WITH OR DEFACED; OR (C) HAVE BEEN SUBJECTED TO ABUSE
(D)TRANSIENT VOLTAGE SURGE OR A HOSTILE OPERATING ENVIRONMENT.
No Warranty – Services
ALL SERVICES ASSOCIATED WITH DIY-TRACK DEVICES INCLUDING, WITHOUT LIMITATION, NETWORK CONNECTIONS ENABLED BY DIY-TRACK, ARE PROVIDED STRICTLY AS-IS, WITHOUT WARRANTY OF ANY KIND INCLUDING, WITHOUT LIMITATION WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, TITLE, NON-INFRINGEMENT, NON-OBSOLESCENCE, NON-INTERRUPTION, AND FREEDOM FROM ERROR.
IN THE EVENT OF A CLAIM UNDER THIS WARRANTY THE RECEIPT/PROOF OF PURCHASE MUST BE PRODUCED TOGETHER WITH THIS WARRANTY.
Model Number:__________________________________________
Date of Purchase:_________________________________________
Place of Purchase:_________________________________________
The use of a GPS vehicle tracking device to track a person without their permission could be illegal or result in a legal action against
you, even if you own the vehicle. Tracking another person or their property is usually illegal without their permission and/or a warrant. You should seek legal advice before using any GPS vehicle tracking device as the regulations vary from country to country
We are not responsible for acts or omissions of any other service provider, for information provided through the equipment, for
use of or installation of Diy-Track products unless caused
by the sole and gross negligence of Diy-Track
Disclaimer
Warranty
SMS Commands
Example text reply:
356823032252491 Lat:+ 50.723855 Lon: -3.531958 Speed:1.11KM/H
http://maps.google.com/maps?q=+50.723855,-3.531958
Clickable link
The authorised number will receive an SMS with the location co-ordinates of the vehicle and a clickable Google Maps link. perfect for tracking on a cell phone with internet availability.
*1234*P#
Please note:
Send SMS:
The SMS must be sent exactly like the above example with NO spaces and all
*1234*A
The alarm alert numbers will receive SMS alerts such as panic alert and accident alert
A total of 3 mobile numbers can be programmed into the tracking unit to receive alerts
Replace
[mobilenumber]
with your own mobile numbers.
44mobilenumber*B44mobilenumber *C44mobilenumber
#
*1234*A44721273167*B44789292882*C44843623686#
The mobile numbers “ 0721273167 and 0789292882 and 0843623686 will now be the authorised numbers
Please note:
Example SMS:
The SMS must be sent exactly like the above example with NO spaces and all
Setting alarm alert numbers
Get Co-ordinates with Gmaps link
The Accident alert numbers will receive an SMS should the motorcycle be in an accident.
*1234*GON#
Please note:
The SMS must be sent exactly like the above example with NO spaces and
*1234*GOFF#
Activate Accident Alert
All rights reserved. ©2011 DIY TRACK
10
All rights reserved. ©2011 DIY TRACKER
SMS Commands
To immobilise the motorcycle :
*1234*stop#
Please note:
Send SMS:
The SMS must be sent exactly like the above example with NO spaces.
If the relay is installed (see page 7) then an alert number can send SMS commands to the TellMe unit to immobilise the motorcycle.
To restore power to the the motorcycle :
*1234*K#
Send SMS:
Immobilize the bike
Please note : The SMS must be sent exactly like the above example with NO spaces
*1234*GMT+0000#
SMS:
Set Local Time
11
