Dixon 700 User Manual

TABLE OF CONTENTS

P-11408

I. OWNER INFORMATION

Warranty Information -------------------------------------------- ||

Specifications------------------------------------------------------- |||

II. SAFETY

Accident Patterns ------------------------------------------------------1

Safety Instructions and Recommendation -----------------------1

Safety Interlock Systems ---------------------------------------------3

III. START UP AND OPERATION

Checklist Before Operation -------------------------------------------3

Control Locations-----------------------------------------------------------4

Operation ----------------------------------------------------------------- 4

Mowing Recommendations------------------------------------------- 6

VI. MAINTENANCE

Maintenance Schedule ------------------------------------------------6

Maintenance Instructions -------------------------------------------- 7

Leveling the Deck-------------------------------------------------------10

Raising and Lowering Deck for Servicing ------------------------11

Trouble Shooting Checklist ------------------------------------------13

Wiring Schematic--------------------------------------------------------15

(2/99)

DIXON LIMITED WARRANTY POLICY - HYDRO-GEAR MODELS

SEE DEALER FOR DETAILS

n P-11408

WARRANTY: Dixon Commercial Warranty term is for a period of one (1) year from date of purchase or 400 hours of use, whichever
occurs first. Mowers used for residential homeowner applications (used only at owner's primary place of residence) are warranted for
two (2) years from date of purchase or 400 hours of use, whichever occurs first. DIXON ZTR MOWERS ARE WARRANTED AGAINST
DEFECTS IN MATERIALS AND WORKMANSHIP AND PROVIDES FOR REPLACEMENT OR REPAIR OF PARTS INCLUDING
LABOR COSTS. THIS WARRANTY IS SUBJECT TO THE FOLLOWING CONDITIONS AND LIMITATIONS:

1. Warranty applies only to original retail purchaser of new and unused mower and accessories.

2. All Dixon warranty must be accomplished by authorized Dixon dealers and in accordance with Dixon warranty policy and
allowances. All warranty claims must be approved by Dixon Industries, Inc.

3. Battery warranty. Limited to 90 days from date of purchase.

4. Accessories Warranty (Grass Catchers, Snow Blades, Tie Rakes, Covers, etc.): Limited to 90 days from date of purchase.

5. Warranty does not apply to damage in transit or incidents of misuse, negligence, accidents, or alteration. The use of parts or
components other than those supplied by Dixon Industries, Inc. VOIDS ALL WARRANTY.

6. The following items are not covered by this warranty policy:

(a) Pick up and delivery charges for transportation of mower to and from an Authorized Dixon Dealer's place of business.
(b) Routine maintenance or adjustments.
(c) Belts / chains / sprockets / cutting blades.
(d) Engines - All engines used on Dixon ZTR mowers are warranted by each individual engine manufacturer.

(e) Any cost or expense of providing substitute equipment while repair work is being performed on a warranted mower.

7. There is no other express warranty. Implied warranties, including those of merchantability and fitness for a particular

purpose, are limited to the dame duration of the express warranty, and to the extent permitted by law and all implied

warranties are excluded. Liabilities for consequential damages under any and all warranties are excluded.

WARRANTY VALIDATION: At the time of sale, selling dealer must review each portion of this warranty document, complete the
information section below, secure customer's signature and send copy to Dixon Industries, Inc.

/

(2/99)

P-11408 (2/99)

ACCIDENT PATTERNS TO AVOID

I. CONTACT WITH THE ROTATING

BLADE -- This accident usually
happens when the operator is clearing
the discharge chute of grass, (especially
when the grass is wet), or when the
operator adjusts the machine without
turning it off and waiting for the blades
to completely stop.

II. PROPELLED OBJECTS - Sticks,

rocks, wires, and other objects can be
propelled out through the discharge chute or
from under the mower housing. Bystanders
are particularly vulnerable.

III. GRASS CATCHER OR GUARD - The

mower shall not be operated without either
the entire grass catcher or guard

IV. OVERTURNING - This happens when riding

mowers are used on steep slopes,
embankments or hills. The operator in
these cases can come in contact with the
blades or sustain injuries during a

V. MOWER RUNNING OVER THE

VICTIM ~ This usually happens when a
riding mower is driven in reverse. The
accident victims are most often young
children whom, unseen by the operator of
the mower, were in the area being

in place.

fall.

mowed.

SAFETY INSTRUCTIONS AND

RECOMMENDATIONS

1. PEOPLE WHO OPERATE, SERVICE,

OR ARE OTHERWISE ASSOCIATED

with the Zero Turning Radius Mower
should be trained in its proper use and
warned of its dangers. Before operating,
adjusting, or servicing the Zero Turning
Radius Mower they should read and
understand this entire manual and the
engine owner's manual.

2. AVOID CONTACT WITH MOVING
PARTS. Keep hands and feet from
under mowing deck and away from
blades at all times. Turn engine (motor)
off if you must unclog the chute.

3. AVOID HILLS AND SLOPES. Use

.extreme caution when mowing up or
down slopes. NEVER mow across the
face of a slope. If a slope must be
ascended, back up the slope; drive
forward when descending. Reduce ~
speed and use caution to start, stop and
maneuver. To prevent loss of control on a
slope avoid sharp turns, sudden changes
in direction, and sudden stops and starts.

4. DISENGAGE POWER TO MOWER

BEFORE BACKING UP. Do not mow
in reverse unless ABSOLUTELY
necessary and then only after turning
around and observing the entire area
behind the mower. Go slowly. Most
"running over victim" accidents occur in
reverse.

5. BEGINNING OPERATORS SHOULD
LEARN HOW TO STEER the Zero
Turning Radius Mower before
attempting to mow. Start with slow
engine speed and drive without the
blades engaged in an open area until
comfortable with the machine.

"6. KNOW HOW TO STOP QUICKLY.

Know the location and operation of
every control, especially how to brake
and how to disengage the mower
blades.

7. DO NOT MOVE STEERING CONTROL
LEVERS

from forward position to
reverse position rapidly. The speed
and/or direction of travel is affected
instantly by movement of the Steering
Control Levers.

several minutes after running. Always
make sure the gas cap is in place.

15. DO NOT SMOKE AROUND THE

or the gasoline storage container. Gasoline
fumes can easily

ignite.

MOWER

8. DO NOT ALLOW CHILDREN TO

OPERATE MOWER. Do not allow

others who have not had instruction to
operate mower.

9. ALWAYS TURN ENGINE OFF AND

REMOVE KEY before leaving the mower to
prevent children and inexperienced operators
from starting the engine. Never leave the
mower unattended with engine running.
Always wait for all moving parts and all sounds
to stop before leaving operator's seat.

10. WEAR STURDY, ROUGH-SOLED

WORK SHOES AND CLOSE-FITTING
SLACKS AND SHIRTS. Never operate

mower in bare feet, sandals or sneakers.

11. NEVER CARRY PASSENGERS.

12. KNOW THE AREA YOU ARE TO

MOW. Watch for hidden danger such
roots, sticks, holes, bumps, and drop-offs, etc.
Before mowing, pick
mowed.

Sharp and hard objects can be

up all debris in area to be

propelled at a high speed and can act
shrapnel. Walk through tall grass BEFORE
MOWING to make sure there are no hidden
dangers. Mow higher than desired in tall grass
to expose any hidden objects and/or
obstacles, clean the area, and then mow to the
desired

height.

as rocks,

like

16. KEEP GASOLINE IN A WELL-

VENTILATED AREA away from your

living
quarters and in tightly-capped safety cans.
Never store mower with gasoline in the tank
inside a building where fumes may reach
open flame or

spark.

17. DISENGAGE BLADES, STOP ENGINE

AND REMOVE IGNITION KEY before

servicing. Be sure all moving parts and all
sounds have stopped. Let engine cool and
disconnect the spark plugs so the engine
cannot start by accident. A SLIGHT
ROTATION OF THE BLADES COULD
START THE

ENGINE.

18. KEEP ALL NUTS, BOLTS, AND

SCREWS TIGHT

to be sure equipment is
in safe working condition, especially blade
mounting bolts.

19. VEHICLE SHOULD BE STOPPED

AND INSPECTED FOR DAMAGE after

striking a foreign object and the damage
should be repaired before restarting and
operating the equipment. Stop immediately
and check for damage or loose parts if
mower should start

20. DISENGAGE BLADES BEFORE

DRIVING ACROSS WALKS or

projecting objects.

vibrating.

any

13. NEVER REFUEL A MOWER

INDOORS.

Allow the engine time to cool
before refueling. Unseen vapors may be
ignited by a spark. Always clean up spilled
gasoline. Never run the engine indoors in a
garage or any other closed building. Allow
engine to cool before storing in any enclosure.
The engine exhaust and gasoline fumes are
dangerous.

14. NEVER REMOVE THE FUEL CAP or

add gasoline to a running or hot engine that
has not been allowed to cool for

21 KEEP SAFETY DEVICES AND

GUARDS IN PLACE. If any of the
switches become inoperable, have them
repaired immediately.

22. DO NOT STEP OR STAND ON THE

MOWER HOUSING.

the foot deck.

23. WATCH OUT FOR TRAFFIC near

Stop or stand only

roadways and when crossing roads.

24. DO NOT USE MOWER WHEN GRASS IS

2

WET OR SLIPPERY.

safety

on

P-11408 (2/99)

25. MOW ONLY DURING DAYLIGHT.

All

Models

3

P-11408

26. THIS MACHINE IS NOT MEANT FOR
HIGHWAY OR STREET USE. It is not

a recreational vehicle and it should not
be operated as such.

27. ALWAYS DISENGAGE THE MOWER

BLADE CLUTCH when transporting.

SAFETY INTERLOCK SYSTEM

Your Zero Turning Radius Mower is equipped
with switches interlocked for your safety.

CHECKLIST BEFORE OPERATION

1. Make sure fuel tank is full. Use regular
unleaded gasoline (see engine owner's
manual for more details).

1. The mower blades must be disengaged
before engine will start.

2. The Steering Control Levers must be in
the neutral "OUT" position before the
engine will start.

3. The engine will stop if the mower blade

clutch is engaged when the operator
leaves the driver's seat.

4. The engine will stop if the Steering Control

Levers are not in the neutral

"OUT"
position when the operator leaves the
driver's seat.

5. The engine will stop if the brake is
"SET" and the Steering Control Levers
are moved to the "IN" position.

6. The engine will stop if the brake is
"SET" and the mower blade clutch is
engaged.

2. Make sure dirt and foreign matter is
kept out of gas tank. Use a clean funnel and
gas can.

3. Do not mix oil with gasoline.

4. Do not use white, high test or premium
gasoline. Do not use de-icers, carburetor
cleaners, or other such

additives.

5. Check the crankcase oil level. Make sure the
engine is off. The mower should be parked
on a level area. Do not overfill. (See your
engine manual for

more detailed instruction.)

6. Check the hydrostatic transmission oil level.

(See "Maintenance" section of this

7. Check battery fluid level.

8. Inspect V-belts.

9. Check tire pressure:

Model

Front tires Rear tires
12psi

12psi

manual.)

10. Make sure underside of mower deck is
of grass.

free

11. Make sure mower blades are sharp and
secured tightly.

(2/99)
