Ditek DTK-FPK2 Specsheet

DTK-FPK2

Fire Alarm System Power And Dialer Surge Protection

Fire Protection Kits from DITEK are
designed for commercial alarm
professionals specializing in fire
detection systems. The FPK2 provides
premium AC power and dialer protection
in a convenient kit.

The DTK-120SRD provides maximum
critical load protection, with EMI/RFI
filtering and Dry Contacts for remote
notification of surge protection status.
The two MRJ31XSCPWP Telco surge
protectors provide protection for dual
dialer circuits.

General Product Specifications

Product Description

DTK-FPK2

- 120SRD Series Installation AC Surge Protector

- Multi-stage protection, in series with the electrical supply for maximum protection

- 54,000 A peak surge current capacity, 20A max operating current

- Provides AC power protection for alarm power supply at alarm panel

- Suitable for use on circuit breakers rated at 10kA AIC

- MRJ31XSCPWP

- Modular RJ31X connection

- Protects against over-voltage and over-current events

- Patch cord included

Warranty (All Products): 10 Year Limited Warranty

Note: See DTK-120SRD and DTK-MRJ31XSCPWP datasheets for individual

product specifications.

One DITEK Center
1720 Starkey Road
Largo, FL 33771

1-800-753-2345 Direct: 727-812-5000

Technical Support: 1-888-472-6100

www.ditekcorp.com

Doc. Number: SPS-100040-001 Rev 6 10/13

©2013 DITEK Corp.

Specification Subject to Change
