Distech Controls EC-BOS-6AX Mounting And Wiring Instructions

EC-BOS-6

MOUNTING AND WIRING INSTRUCTIONS

This document covers the mounting and wiring of the EC-BOS-6AX series controller. It assumes that you are an engineer, technician, or service person who is performing control system installation. Instructions in this document apply to the following products:

Models

Models Description

ModelsModels

EC-BOS-6

Description

DescriptionDescription

EC-BOS-6AX base unit controller, powered by (either):

EC-NPB-PWR DIN-mountable 24V power module

EC-NPB-PWR-UN DIN-mountable 90-263VAC power module

EC-WPM-XX Wall-mount universal AC power adapter, with

different models available, where -XX is either:

-US, -EU, or -UK (vary by AC wall plug).

Note Not covered in this document is the Niagara

software installation and configuration required for a fully functioning unit. This includes setting host IP address and password, serial port configuration, and other parameters. Refer to the EC-BOSAX Install and Startup Guide for this information.

In addition, the mounting and wiring of EC-BOS-6AX expansion options are covered in separate documents. See sections “About Expansion Options,” page 8, and “Related Documentation,” page 18.

These are the main topics included in this document:

• Preparation, page 2

• Precautions, page 4

• Mounting, page 5

• Board Layout, page 7

• About Expansion Options, page 8

• Wiring Details, page 11

• Power Up and Initial Checkout, page 16

Also included in this document are several appendixes, as follows:

• Using Status LEDs, page 19

• Maintaining the EC-BOS-6

• Replacement Parts, page 21

• Certifications, page 24

• Declaration of Conformity, page 25

, page 20

Information and specifications published here are current as of the date of publication of this document. Distech Controls, Inc. reserves the right to change or modify specifications without prior notice. The latest product specifications can be found by contacting our corporate headquarters. Products or features con-

tained herein may be covered by one or more U.S. or foreign patents. LON and LONWORKS are registered trademarks of the Echelon Corp. NiagaraAX Framework is a trademark of Tridium Inc. © 2008 Distech Controls, Inc.

EC-BOS-6AX Mounting and Wiring Instructions Part Number: 05DI-HIBS6AX-10 Revised: February 2008

Preparation

Included in this Package

Preparation

Unpack the EC-BOS-6AX and power module (either EC-NPB-PWR, EC-NPB-PWR-UN or EC-WPM-XX) and inspect the contents of the packages for damaged or missing components. If damaged, notify the appropriate carrier at once and return any damaged components for immediate repair or replacement. See “Federal

Communications Commission (FCC)” on page 24.

• Included in this Package

• Material and Tools Required

Included in this Package

Included in this package you should find the following items:

• a EC-BOS-6

• These EC-BOS-6

• a packing slip, which lists the factory settings for IP address, machine name, and host logon.

• a hardware bag containing the following items:

–

A grounding wire, with quick-disconnect 0.187” female connector.

• a power module (if ordered), which is required for operation.

The power module can be one of the following:

–

EC-NPB-PWR: 24Vac in-line, DIN-mount capable, with grounding wire, or

–

EC-NPB-PWR-UN: 90-263Vac, DIN-mount capable, with grounding wire

–

EC-WPM-XX: External wall-mount power adapter (input: 90–254Vac, 50–60 Hz, output: 15Vdc, 1A)

base controller.

Mounting and Wiring Instructions, Part Number: 05DI-HIBS6AX-10

where XX varies by the AC wall plug (for installation locale): EC-WPM-US (U.S. or Japan installations) EC-WPM-EU (European installations, type “C” plug) EC-WPM-UK (United Kingdom installations, type “B” plug)

Material and Tools Required

The following supplies and tools may be required for installation:

• DIN rail, type NS35/7.5 (35mm x 7.5mm) and DIN rail end-clips (stop clips), recommended for any

installation that includes a power module and/or optional I/O modules.

Note Length of DIN rail is determined by the number of optional DIN-mounted options.

See Figure 1 on page 6 for more details.

• If using an EC-NPB-PWR power module, either one of the following:

–

UL listed, Class 2, 24Vac transformer, rated at minimum of 8.5VA to 20VA. Note that a dedicated transformer is required (cannot also power additional equipment).

–

24Vdc power supply, capable of supplying at least 1A (24W).

• If using an EC-NPB-PWR-UN power module, the following:

–

UL listed, Class 2, 90-263Vac transformer, rated at 40VA. Note that a dedicated transformer is required (cannot also power additional equipment).

Revised: February 2008 Part Number: 05DI-HIBS6AX-10

EC-BOS-6AX Mounting and Wiring Instructions

Preparation

Material and Tools Required

• Suitable screws and screwdriver for mounting DIN rail, or if DIN rail not used, for mounting bases of

EC-BOS-6AX controller and power module (if used).

• #2 phillips screwdriver: used to install and remove optional communications modules.

• Small flat-blade screwdriver: used for mounting or removing the EC-BOS-6

making wiring connections to RS-485 connector, and optionally LON® connectors.

from DIN rail, also for

EC-BOS-6AX Mounting and Wiring Instructions Part Number: 05DI-HIBS6AX-10 Revised: February 2008

Precautions

Safety Precautions

Precautions

This document uses the following warning and caution conventions:

Caution Cautions remind the reader to be careful. They alert readers to situations where there is a chance

that the reader might perform an action that cannot be undone, might receive unexpected results, or might lose data. Cautions contain an explanation of why the action is potentially problematic.

Warning Warnings alert the reader to proceed with extreme care. They alert readers to situations where there

is a chance that the reader might do something that can result in personal injury or equipment damage. Warnings contain an explanation of why the action is potentially dangerous.

Safety Precautions

The following items are warnings of a general nature relating to the installation and start-up of the EC-BOS-6AX controller. Be sure to heed these warnings to prevent personal injury or equipment damage.

Warning • Depending on power module used, the circuit powering the EC-BOS-6

or 24Vdc (if using EC-NPB-PWR), 90 to 263Vac at 50/60Hz (if using EC-NPB-PWR-UN) or from 100–240Vac at 50/60 Hz (if using EC-WPM-XX). Disconnect power before installation or servicing to prevent electrical shock or equipment damage.

• Make all connections in accordance with national and local electrical codes. Use copper

conductors only.

• To reduce the risk of fire or electrical shock, install in a controlled environment relatively free

of contaminants.

• This device is only intended for use as a monitoring and control device. To prevent data loss or

equipment damage, do not use it for any other purpose.

is 24Vac at 50/60 Hz

Static Discharge Precautions

Static charges produce voltages high enough to damage electronic components. The microprocessors and associated circuitry within a EC-BOS-6AX controller are sensitive to static discharge. Follow these precautions when installing, servicing, or operating the system:

Caution • Work in a static-free area.

• Discharge any static electricity you may have accumulated. Discharge static electricity by

touching a known, securely grounded object.

•

Do not handle the printed circuit board (PCB) without proper protection against static discharge. Use a wrist strap when handling PCBs. The wrist strap clamp must be secured to earth ground.

Revised: February 2008 Part Number: 05DI-HIBS6AX-10

EC-BOS-6AX Mounting and Wiring Instructions

Mounting

Environmental Requirements

Mounting

Mount the EC-BOS-6AX controller in a location that allows clearance for wiring, servicing, and module removal. Additional mounting information applies, as follows:

• Environmental Requirements

• Physical Mounting

Environmental Requirements

Note the following requirements for the EC-BOS-6AX mounting location:

• This product is intended for indoor use only. Do not expose the unit to ambient conditions outside of the

range of 0ºC (32º F) to 50ºC (122º F) and relative humidity outside the range 5% to 95% non-condensing (pollution degree 1).

• If mounting inside an enclosure, that enclosure should be designed to keep the unit within its required

operating range considering a 20-watt dissipation by the controller. This is especially important if the controller is mounted inside an enclosure with other heat producing equipment.

• Do not mount the unit:

–

in an area where excessive moisture, corrosive fumes, or explosive vapors are present.

–

where vibration or shock is likely to occur.

–

in a location subject to electrical noise. This includes the proximity of large electrical contractors, electrical machinery, welding equipment, and spark igniters.

Physical Mounting

The following information applies about physically mounting the unit.

• You can mount the EC-BOS-6

mounting.

• Mounting on a 35mm wide DIN rail is recommended. The EC-BOS-6

slot and locking clip, as does the power module and the I/O expansion modules. Mounting on a DIN rail ensures accurate alignment of connectors between all modules.

• If DIN rail mounting is impractical, you can use screws in mounting tabs on the EC-BOS-6

end-connected accessory (EC-NPB-PWR, etc.). Tab dimensions are on page 26 of this document.

The following procedure provides step-by-step DIN rail mounting instructions for the EC-BOS-6AX.

Note Mount the EC-BOS-6

Procedure 1 To mount on DIN rail

Step 1

Step 2

Securely install the DIN rail using at least two screws, near both ends of the rail.

Position the EC-BOS-6AX on the rail, tilting to hook DIN rail tabs over one edge of the DIN rail (Figure 1on page 6).

Step 3

Use a screwdriver to pry down the plastic locking clip, and push down and in on the EC-BOS-6AX, to force the locking clip to snap over the other edge of the DIN rail.

in any orientation. It it not necessary to remove the cover before

unit base has a molded DIN rail

prior to mounting any accessory items (24V power module, etc.).

, then in any

Step 4

EC-BOS-6AX Mounting and Wiring Instructions Part Number: 05DI-HIBS6AX-10 Revised: February 2008

Mount any accessory item onto the DIN rail in the same manner.

Physical Mounting

Mounting on DIN Rail Removing from DIN Rail

EC-BOS-6

345 mm (13.58”)

162 mm (6.38”)

104 mm

(4.1”)

162 mm (6.38”)

EC-NPB-PWR

Install DIN rail End Clip (Stop Clip) at both ends of final assembly.

DIN rail End Clip

DIN Rail End Clip

EC-NPB-PWR

263 mm (10.35”)

509 mm (20.04”)

427 mm (16.81”)

591 mm (23.27”)

52 mm (2.05”)

EC-BOS-6

181 mm (7.13”)

IO-16 (1)

IO-16 (2)

IO-16 (3)

IO-16 (4)

EC-NPB-PWR

IO-16

Up to four (4) EC-NetAX IO-16 modules are supported.

NOTE: If installing EC-NetAX IO-16 modules and using the EC-NPB-PWR or EC-NPM-PWR-UN power supply module, the power supply module installs at the end of the chain.

Mounting

Step 5

Step 6

Step 7

Slide the accessory along the DIN rail to connect its 20-position plug into the EC-BOS-6

Repeat this for all accessories, until all are mounted on the DIN rail and firmly connected to each other.

To keep the final assembly together, secure at both ends with DIN rail end-clips provided by the DIN rail vendor. This also prevents the assembly from sliding on the DIN rail. See Figure 1 below.

Figure 1 EC-BOS-6AX and accessory mounting details.

Revised: February 2008 Part Number: 05DI-HIBS6AX-10

EC-BOS-6AX Mounting and Wiring Instructions

Board Layout

BATTERY

Option Slot 2

Option Slot 1

Battery Bracket (on top of option cards, if any)

Option Slot Connectors

Status LEDs (visible with cover on):

LAN2

LAN1

BEAT

STATUS

20 Pin Connector

(I/O and Power Modules)

Secondary

Ethernet

(RJ-45)

LAN2

(top

board)

RS-232

(DB-9) COM1

Primary

Ethernet

(RJ-45)

LAN1

(top

board)

RS-485

(3-pos.)

COM2

(bottom

board)

Barrel power connector for wall mounted power module (EC-WPM-XX).

Earth Ground

Spade Lug

COM 1

COM 2

Serial port LEDs on bottom board, remove cover to see:

Mode Jumper (for serial shell access)

EC-BOS-6AX Battery Connector (see Figure 6 on page 17)

Removing and Replacing the Cover

You must remove the EC-BOS-6AX cover to connect the battery (new unit) or to replace the battery, and to install any option boards. The cover snaps onto the base with four plastic tabs (two on each end).

To remove the cover, press in the four tabs on both ends of the unit, and lift the cover off.

Note If accessory modules are plugged into the EC-BOS-6

, you may need to slide them away from the unit

to get to the cover tabs.

To replace the cover, orient it so the cutout area for comm ports is correct, then push inwards to snap in place.

Board Layout

Figure 2 shows the location of LEDs, option slots, and other features of the EC-BOS-6AX with cover removed.

For a side view of communications ports and other features, see Figure 5 on page 15.

Figure 2 EC-BOS-6AX board layout details.

EC-BOS-6AX Mounting and Wiring Instructions Part Number: 05DI-HIBS6AX-10 Revised: February 2008

About Expansion Options

About Option Cards

About Expansion Options

The EC-BOS-6AX provides for field-installable expansion with two kinds of options:

• Option cards—Install on connectors inside the EC-BOS-6

• Accessory modules—To “chain” onto the EC-BOS-6

Modules” below.

About Option Cards

The EC-BOS-6AX has two (2) option slots for custom option cards designed for use with the EC-BOS-6AX. Each slot has a 30-pin connector on the EC-BOS-6AX base board. See Figure 2 on page 7.

base unit. See “About Option Cards” below.

’s 20-pin connector. See “About Accessory

Warning Power to the EC-BOS-6

must be OFF when installing or removing option cards, or damage will occur! Also, you must be very careful to plug an option card into its connector properly (pins aligned).

Option cards typically provide additional communications features, such as the following available models (with others still in development) listed below in Table 1.

Table 1 EC-BOS-6AX option cards.

Model

Model Description

ModelModel

EC-NPB-LON FTT-10A LON (LONWORKS®)

EC-NPB-MDM 56Kbps Auto-dial/Auto-answer

Description Notes

DescriptionDescription

adapter with a 2-position removable screw-terminal connector plug.

Modem with one RJ-11 connector for phone line.

Notes

NotesNotes

Up to 2 LON option cards may be installed.

• If one LON option, it operates as LON1, regardless of slot.

• If two LON options, LON1 is Option slot 1, LON2 is Option slot 2.

Maximum of one. Does not have own UART. Must be installed in Option Slot 1, where it operates as COM1. This disables the RS-232 base serial port (DB-9 connector) on the EC-BOS-6

Note: If an EC-NPB-MDM is installed, and the “mode jumper” (see

Figure 2) is put in “Serial Shell” position, the EC-BOS-6

port becomes active immediately following a reboot. This allows an RS-232 connection to the “serial shell” for debugging purposes. To re-enable the modem, you must put the mode jumper back in the “Normal” position, and reboot again.

during normal operation.

base RS-232

Mounting Option Cards

For complete details, see the mounting & wiring instructions document that accompany the specific option card. The following procedure provides a basic set of steps.

Procedure 2 Mounting option cards on a EC-BOS-6AX.

Step 1

Step 2

Step 3

Step 4

Remove power from the EC-BOS-6

Remove the cover. See “Removing and Replacing the Cover,” page 7.

Remove the battery and bracket assembly by taking out the four screws holding it in place, setting the screws aside for later. Unplug the battery from the connector on the EC-BOS-6AX.

Remove the blanking end plate for the slot you are installing the option card into. (Retain the blanking plate in case the option card must be removed at a later date.)

—see the previous Warning.

EC-BOS-6AX Mounting and Wiring Instructions

Revised: February 2008 Part Number: 05DI-HIBS6AX-10

About Expansion Options

About Accessory Modules

Step 5

Carefully insert the pins of the option card into the socket of the appropriate option card slot. The mounting holes on the option board should line up with the standoffs on the base board. If they do not, the connector is not properly aligned. Press until the option card is completely seated.

Step 6

Step 7

Step 8

Place the custom end plate that came with the option card over the connector(s) of the option card.

Plug the battery connector plug into the battery connector on the EC-BOS-6AX.

Set the battery and bracket assembly back over the option card slots, with the mounting holes aligned with the standoffs.

Step 9

Place the four screws through the battery bracket, end plates, and into the standoffs on the EC-BOS-6AX base board. Hand tighten these screws.

Step 10

Replace the cover.

About Accessory Modules

The EC-BOS-6AX has a 20-pin, right-angle, Euro-DIN connector that accepts custom-built accessory modules. The connector provides power and signal lines to any connected modules, and is located on the end of the EC-BOS-6AX opposite to the option cards.

Warning • Power to the EC-BOS-6

for all LED activity to stop (all LEDs to be off).

• Also, do not connect live voltages to the inputs or outputs of an I/O module (EC-Net

EC-NetAX IO-34) while it is in an “un-powered state” before plugging the module into an EC-BOS-6AX.

• Otherwise, damage to the I/O module and/or the EC-BOS-6

must be OFF when inserting or unplugging accessory modules. Wait

IO-16 or

controller may result!

Each accessory module has a DIN-mount base, and provides two (2) 20-pin connectors that allow you to “chain” multiple accessories (see Procedure 1 on page 5). Table 2 lists the currently available accessory modules.

Table 2 EC-BOS-6AX accessory modules.

Model

Model Description

ModelModel

EC-NPB-PWR DIN-mountable, 24V isolated power

EC-NPB-PWR-UN DIN-mountable, 90-263V isolated

EC-BOS-6AX Mounting and Wiring Instructions Part Number: 05DI-HIBS6AX-10 Revised: February 2008

Description Notes

DescriptionDescription

module, used to power EC-BOS-6AX from a dedicated, external, Class-2, 24Vac transformer or a 24Vdc power supply.

power module, used to power EC-BOS-6AX from a dedicated, external, Class-2, 90 to 263Vac transformer.

Notes

NotesNotes

• Wiring is covered in this document, see “EC-NPB-PWR,” page

12 or “EC-NPB-PWR-UN,” page 13.

• Only one EC-NPB-PWR/EC-NPB-PWR-UN per EC-BOS-6

• Do not install if using EC-WPM-XX.

About Accessory Modules

Table 2 EC-BOS-6AX accessory modules.

Model

Model Description

ModelModel

EC-NetAX IO-16 DIN-mountable, 16 points I/O module,

EC-NetAX IO-34 DIN-mountable, combined 34 points

Description Notes

DescriptionDescription

used to provide I/O points as noted.

I/O with 24V isolated power module, used to provide I/O points as well as power EC-BOS-6AX from a dedicated, external, Class-2, 24Vac transformer or a 24Vdc power supply.

About Expansion Options

Notes

NotesNotes

Provides the following I/O points:

• 8 - Universal Inputs (UIs).

• 4 - Digital Outputs (DOs), SPST-relay type.

• 4 - Analog Outputs, 0-10Vdc type.

Up to four (maximum) IO-16 accessory modules are supported.

Wiring is covered in a sperate document, see the EC-NetAX IO-16 Installation and Configuration Instructions.

Only one EC-NetAX IO-34 per EC-BOS-6AX. Provides the following I/O points:

• 16- Universal Inputs (UIs).

• 10- Digital Outputs (DOs), SPST-relay type.

• 8- Analog Outputs, 0-10Vdc type.

Up to two additional IO-16 accessory modules can be used. Do not power the IO-34 if using an EC-WPM-XX.

Wiring is covered in a sperate document, see the EC-NetAX IO-34 Installation and Configuration Instructions.

EC-BOS-6AX Mounting and Wiring Instructions

Revised: February 2008 Part Number: 05DI-HIBS6AX-10

Wiring Details

Grounding

Wiring Details

See Figure 2 on page 7 to locate connectors and other components on the EC-BOS-6AX controller.

Make connections to the EC-BOSAX in the following order.

1. Install any option boards (LON, RS-485, or modem) in option slots 1 and 2. See “Mounting Option

Cards,” page 8 for a general procedure. For complete details, refer to the specific mounting and wiring

guide that shipped with the option board.

2. Connect supplied earth grounding wires (with spade connector) from the earth ground lug on the

EC-BOS-6AX and any accessory modules (if used) to a nearby earth grounding point. See “Grounding” below for details.

3. Prepare power wiring (leave the unit powered off). See “Power Wiring” for details.

4. Connect communications cables. See “Communications Wiring,” page 14 for ports available on the

EC-BOS-6AX base unit. For ports on any installed option board (LON, RS-485, modem) see the specific mounting and wiring guide for any additional details.

5. If I/O accessory modules are installed, connect I/O wiring. Refer to the appropriate mounting and wiring

guide for complete details.

6. Connect the backup battery to the EC-BOS-6

“Power Up and Initial Checkout,” page 16.

battery connector, and apply power to the unit. See

Grounding

An earth ground spade lug (0.187") is provided on the base of the EC-BOS-6AX for connection to earth ground. For maximum protection from electrostatic discharge or other forms of EMI, connect the supplied earth grounding wire to this lug and a nearby earth ground (see Figure 3 on page 13). Keep this wire as short as possible.

Power is provided for EC-BOS-6AX plug-in accessory modules through the 20-pin accessory connectors. However, you should also connect the earth ground spade lug of each accessory module to ground in the same manner.

Power Wiring

The EC-BOS-6AX must be powered by an approved 15 Vdc power source. This can be either1 an external wall mount AC adapter (EC-WPM-XX) or the DIN-mount power module (EC-NPB-PWR/-UN). The EC-BOS-6AX controller does not include an on/off switch. To apply power, plug in the power connector to either the EC-BOS-6AX (if EC-WPM-XX) or the EC-NPB-PWR/-UN.

The EC-BOS-6AX controller does not include an on/off switch. To apply power, you either:

• if EC-WPM-XX, plug in the power connector to the EC-BOS-6

• if EC-NPB-PWR, plug in its 2-position power connector.

• if EC-NPB-PWR-UN, energize the AC circuit (90-263Vac) wired to that module.

1. In some markets, a fourth power option is available: an EC-NetAX IO-34 accessory module, which is a combination of the EC-NPB-PWR module and two EC-NetAX IO-16 modules (plus two extra relays). Please refer to its mounting and wiring instructions document for more details. For general information on accessory modules, see “About Accessory

Modules,” page 9.

EC-BOS-6AX Mounting and Wiring Instructions Part Number: 05DI-HIBS6AX-10 Revised: February 2008

Wiring Details

Power Wiring

Caution Do not connect both the EC-WPM-XX and EC-NPB-PWR/-UN supplies at the same time, or

equipment damage may result.

If desired, you can use the wall mount EC-WPM-XX in your office (to initially commission the EC-BOS-6AX), and then install the EC-BOS-6AX at the job using an EC-NPB-PWR/-UN module. The following sections provide more details:

• EC-WPM-XX (Wall Power Modules)

• EC-NPB-PWR (24Vac-powered in-line module)

• EC-NPB-PWR-UN (90-263Vac powered in-line module)

EC-WPM-XX

All models of wall power modules (US, EU, UK) are self-contained, isolated, switching power supplies designed to plug into a standard building power receptacle of appropriate voltage. To supply power to the EC-BOS-6AX, you then simply plug the barrel connector plug from the EC-WPM-XX into the barrel power connector on the EC-BOS-6AX base board (see Figure 5 on page 15).

Caution Do not plug the barrel connector plug from the EC-WPM-XX into the EC-BOS-6

until all other

mounting and wiring is completed. See “Power Up and Initial Checkout,” page 16.

EC-NPB-PWR

Using the EC-NPB-PWR module lets you power the EC-BOS-6AX from a dedicated Class 2, 24Vac transformer, or from a 24Vdc power supply. If installing EC-NetAX IO-16 modules, the EC-NPB-PWR installs as tghe last (end) module in the chain. See

Note If powering from the transformer, do not power any other equipment with it. Otherwise, conducted noise

problems may result. Also, do not ground either side of the transformer’s secondary.

Located at the bottom of the power module is a 2-position power connector, and an earth ground spade lug, as shown in Figure 3.

EC-BOS-6AX Mounting and Wiring Instructions

Revised: February 2008 Part Number: 05DI-HIBS6AX-10

Wiring Details

–

Power Module (cover shown removed)

EC-BOS-6

24Vac

Line Voltage

(Mains)

Earth Ground

Dedicated 24Vac Transformer neither side of secondary tied to earth ground

24Vdc

24Vdc Power Supply

(Polarity Not Critical)

neither side tied to earth

Power Wiring

Figure 3 EC-NPB-PWR module wiring connections.

Connect the supplied earth ground wire to a nearby earth ground point. Unplug the power connector plug from the module and make connections to it as shown in Figure 3.

Caution Do not plug 24V power into the EC-NPB-PWR (reinsert connector plug) until all other mounting

and wiring is completed. See “Power Up and Initial Checkout,” page 16.

Power consumption depends on installed accessories and option boards, and may vary from:

• EC-BOS-6

with EC-NPB-PWR alone: Approximately 8.5VA (AC) or 8.5W (DC)

with EC-NPB-PWR and four (4) EC-NetAX IO-16 modules, plus option boards: up to 20VA

(AC) or 20W (DC)

EC-NPB-PWR-UN

The EC-NPB-PWR-UN module lets you power the EC-BOS-6AX (and if installed, EC-NetAX IO-16 modules) from AC line power, with a universal input range from 90-263Vac. If installing EC-NetAX IO-16 modules, the EC-NPB-PWR-UN installs as the last (end) module in the chain. See Figure 1 on page 6.

Warning • A 120Vac or 240Vac circuit powers the EC-NPB-PWR-UN. Disconnect power

circuit before installation to prevent electrical shock of equipment damage.

• Make all connections in accordance with national and local electrical codes. Use copper

conductors only.

• Do not exceed the 30W capacity of EC-NPB-PWR-UN by powered devices.

Power inpur connections are made to the terminals on the circuit board (cover removal is required). An earth ground connection must be made to the grounding lug using the supplied earth wire. See Figure 4 on page 14.

Disconnect power to this

Disconnect powerDisconnect power

EC-BOS-6AX Mounting and Wiring Instructions Part Number: 05DI-HIBS6AX-10 Revised: February 2008

Communications Wiring

Remove cover

EC-BOS-6AX or EC-NetAX

IO-16

120 or 240Vac

50-60Hz

Single Phase

Earth Ground

Note: The 6-pin connector of the EC-NPB-PWR-UN is not used with an EC-BOS-6AX series controller.

6-pin connector not used

L N

Line

Neutral

AC Input

Figure 4 EC-NPB-PWR-UN module wiring connections.

Wiring Details

Procedure 3 Wiring EC-NPB-PWR-UN input power and earth ground

Step 1

Step 2

Remove power from the AC circuit being wired to the EC-NPB-PWR-UN - see previous warning.

Remove the EC-NPB-PWR-UN cover. To do this, press in the four tabs on both ends of the unit and lift the cover off.

Step 3

If the EC-BOS-6AX or EC-NetAX IO-16 accessory module is plugged into the unit, you may need to slide it away to get to the cover tabs.

Step 4

Step 5

Step 6

Connect the supplied earth grounding wire to a nearby grounding point. See Figure 4.

Make AC circuit connections line (mains) and neutral to the terminals labeled “INPUT PWR”.

Replace the cover on the EC-NPB-PWR-UN. Make sure all modules in the mounted assembly are firmly connected together and secured.

Caution Do not energize the AC circuit wired to the EC-NPB-PWR-UN until all other EC-BOS-6

mounting and wiring is completed. See “Power Up and Initial Checkout,” page 16

Communications Wiring

Connect communications wiring to the EC-BOS-6AX using ports on the bottom of the unit (Figure 5), which include:

• Ethernet

• Serial

EC-BOS-6AX Mounting and Wiring Instructions

Revised: February 2008 Part Number: 05DI-HIBS6AX-10

Wiring Details

Battery in bracket (on top of option cards, if any)

EC-BOSAX Battery

20 Pin Connector

(Power Modules)

Ethernet (RJ-45)

LAN 2

RS-232

(DB-9) COM1

Primary Ethernet (RJ-45)

LAN 1

RS-485 (3-pos.)

COM2

Earth Ground

Spade Lug

Barrel power connector for EC-WPM-XX

Option Slot area (Slot #1 this side)

s + –

Communications Wiring

Note Prior to connecting cables, provide strain relief for them to prevent damage to the controller.

Figure 5 EC-BOS-6AX bottom side (cover removed).

Ethernet

Two, female 10/100-Mbit Ethernet connections are provided on the EC-BOS-6AX. These are RJ-45 connectors labeled LAN2 and LAN1. Use a standard Ethernet patch cable for connecting to a hub or Ethernet switch. An activity LED for each Ethernet port is visible, and are labeled “LAN2” and “LAN1” on the cover.

The factory-default IP address for LAN1 on an EC-BOS-6AX is 192.168.1.12n, where the last numeral n in the address matches the EC-BOS-6AX’s serial number, and subnet mask is 255.255.255.0. By default, LAN2 on an EC-BOS-6AX is disabled. Refer to the EC-BOSAX Install and Startup Guide for details on changing IP address.

Note Typically, you only use LAN1 (primary port), unless you have a specific application for isolating a

driver’s network traffic to a separate LAN, using LAN2. Do not use LAN2 as the primary port.

Serial

There are two serial ports on the EC-BOS-6AX base unit. Each has a UART capable of operation up to 115,200 baud. At the bottom of the board (see Figure 5), the left port is an RS-232 port using an DB-9 plug (male) connector. To the right of this is a two-wire with shield, isolated RS-485 port, using a screw-terminal connector plug.

Note A green “receive” LED and yellow “transmit” LED are provided for each serial port. These LEDs are

located on the bottom board, on the opposite side of the serial connectors (see Figure 2 on page 7). These LEDs are labeled on the board (COM1, COM2) and are not visible with the cover on.

RS-232—An RS-232 serial port using a male DB-9 connector always operates as COM1. You can use standard DB-9 serial cables with this port. The EC-BOS-6AX is a serial DTE device, such another DTE device (PC, for example) requires a “null modem” cable. If connecting the EC-BOS-6AX to a DCE device (modem, for example), a straight-through cable is used. Table 3 provides standard serial DB-9 pinouts.

EC-BOS-6AX Mounting and Wiring Instructions Part Number: 05DI-HIBS6AX-10 Revised: February 2008

Power Up and Initial Checkout

DB-9 Plug (male)

3-position connector (male)

–

Communications Wiring

Note If a modem option card (EC-NPB-MDM) is installed, this port becomes disabled—except if rebooted

with the mode jumper (see Figure 2 on page 7) in the “Serial Shell” position.

Table 3 Serial port (RS-232 and RS-485) pinouts.

Base RS-232 DB-9 Port (COM1)

Base RS-232 DB-9 Port (COM1) Base RS-485 Port (COM2)

Base RS-232 DB-9 Port (COM1)Base RS-232 DB-9 Port (COM1)

Pinout References

Pinout References Signal

Pinout References Pinout References

DCD Data carrier detect 1

RXD Receive data 2

TXD Transmit data 3

DTR Data terminal ready 4

GND Ground 5

DSR Data set ready 6

RTS Request to send 7

CTS Clear to send 8

not used on the EC-BOS-6

Signal DB-9 Plug Pin

SignalSignal

DB-9 Plug Pin Pinouts

DB-9 Plug PinDB-9 Plug Pin

Base RS-485 Port (COM2)

Base RS-485 Port (COM2)Base RS-485 Port (COM2)

Pinouts

PinoutsPinouts

RS-485—An RS-485, optically isolated port uses a 3-position, screw terminal connector and always operates as COM2. Wire to this connector with shielded 18-22AWG wiring (refer to the TIA/EIA-485 standard). As shown in Table 3, the screw terminals (from left-to-right) are shield, plus (+), and minus (–).

USB—A single USB port is on the top of the board.

Note The USB port is for future use.

Power Up and Initial Checkout

Ensure power wiring to the EC-BOS-6AX is ready—see the “Power Wiring” section on page 11. Refer to

Figure 2 on page 7 for the locations of the EC-BOS-6AX battery connector, status LEDs and barrel power

connector (for EC-WPM-XX only). Refer to Figure 3 on page 13 for location of the power connector on the EC-NPB-PWR/-UN power module.

Following all mounting and wiring, perform the following:

Procedure 4 Initial power up and checkout

Step 1

Step 2

Connect the Backup Battery.

Apply Power.

Step 3

Check the Status LEDs.

EC-BOS-6AX Mounting and Wiring Instructions

Revised: February 2008 Part Number: 05DI-HIBS6AX-10

Power Up and Initial Checkout

Battery Connector

Battery Assembly

Connect the Backup Battery

With the cover removed from the EC-BOS-6AX (see “Removing and Replacing the Cover,” page 7), locate the red and black wires coming from the backup battery, with 2-position connector plug. Insert the plug into the battery connector on the bottom board (below option slot 2 area), as shown in Figure 6.

Figure 6 Backup battery connector on EC-BOS-6AX bottom board.

The connector is keyed—you cannot insert it incorrectly. The red (positive) connection should be the furthest from the two 30-pin option board connectors. For more battery details, see “About the Battery,” page 18.

Apply Power

Apply power to the EC-BOS-6AX by plugging in the power plug into either the EC-BOS-6AX (if wall mount AC adapter EC-WPM-XX) or the 24V-powered EC-NPB-PWR module. If powering using the line-voltage input EC-NPB-PWR-UN power supply module, energize the 90-263Vac circuit wired to the EC-NPB-PWR-UN module.

Caution Do not connect both the EC-WPM-XX and EC-NPB-PWR/EC-NPB-PWR-UN supplies at the same

time, or equipment damage may result, or a power outage may go unrecognized.

Check the Status LEDs

When power is applied, the green LED labeled “STATUS” will light. This indicates that the system is OK and that power is applied. Once the EC-BOS-6AX boots, the yellow “BEAT” (heartbeat) LED will begin blinking, with a typical rate of about 1 Hz. Blinking should begin within 30 seconds after power is applied.

If after applying power, the STATUS LED goes out, or if the BEAT LED comes on (steady) and stays lit longer than two minutes, contact Systems Engineering for technical assistance. See also the “Using Status LEDs” section on page 19.

EC-BOS-6AX Mounting and Wiring Instructions Part Number: 05DI-HIBS6AX-10 Revised: February 2008

Using Status LEDs

Ethernet Ports

Using Status LEDs

The EC-BOS-6AX controller includes several LEDs that can help determine the status of the unit. They are located in two places: the top of the controller (visible through the cover), and for serial ports, on the bottom board (only with cover removed). From left-to-right these LEDs include:

• Ethernet Ports

• Heartbeat

• Status

• Serial Ports

Refer to Figure 2 on page 7 for the exact locations of status LEDs on the EC-BOS-6AX controller.

Ethernet Ports

Each Ethernet port (“LAN2”, “LAN1”) has one green LED, visible on the top cover.

A “LANx” LED indicates activity on that port as follows:

• Off—No Ethernet link is made

• On—Ethernet link is present, but no activity on the LAN

• Blinking—Ethernet link is present with data activity on the LAN.

Heartbeat

The “BEAT” LED is located to the right of the Ethernet status LEDs, and is yellow. Under normal operation, this LED should blink about once per second. If the heartbeat LED stays on constantly, does not light, or blinks very fast (more than once per second), contact System Engineering for technical support.

Caution During boot-up, the heartbeat LED blinks in a 90% on - 10% off pattern. Do not remove power

during this time or data loss may result (I/O module’s firmware upgrade may be in progress.

Status

The “STATUS” LED is located to the right of the heartbeat (“BEAT”) LED, and is green. This LED provides a CPU machine status check, and should remain lit whenever the EC-BOS-6AX is powered. If the STATUS LED does not light while power is applied, contact System Engineering for technical support.

Serial Ports

LEDs for the two serial ports are located on the EC-BOS-6AX’s bottom board, on the opposite side of the RS-232 and RS-485 ports (see Figure 2 on page 7). Labels “COM1” and “COM2” correspond to the software configuration of the COM ports. LEDs show the transmit and receive activity for the serial ports and optional modem.

Note You must remove the cover to the serial port LEDs. See “Removing and Replacing the Cover,” page 7.

• The yellow transmit LED indicates that the EC-BOS-6

is sending data out the serial port over a

communications line to a connected device.

EC-BOS-6AX Mounting and Wiring Instructions Part Number: 05DI-HIBS6AX-10 Revised: February 2008

Cleaning

Maintaining the EC-BOS-6

• The green receive LED indicates that the EC-BOS-6

is receiving data from a connected device.

These LEDs provide a fixed on-time when data is detected on the port. If these LEDs are on constantly, this indicates a problem with the communications channel, such as a shorted wire or reversed wiring.

Maintaining the EC-BOS-6

This section provides information on the following topics:

• Cleaning

• Required Battery Maintenance

• Replacement Parts

• Replacing the base assembly Federal Communications Commission (FCC)

Cleaning

If dust or metal filings are present inside the unit, clean with vacuum or compressed air. Otherwise, no cleaning inside the unit is required. Optionally, if the cover becomes dirty, you can wipe it with a damp cloth and mild detergent.

Required Battery Maintenance

Battery life expectancy is a function of its discharge cycles (the number of discharges and their depth) and the ambient temperature of the battery during normal operation. In most applications, the battery should see relatively few discharges. Therefore, ambient temperature has more to do with determining the life expectancy of the battery than does any other factor. If the EC-BOS-6AX is installed in a conditioned space, the battery should provide dependable service for approximately three years (average). In an environment where the operating temperature is higher (that is, 50ºC or 122ºF), you should only expect the battery to last approximately one year.

The NiMH battery in the EC-BOS-6AX controller is fully discharged when factory shipped. Additionally, NiMH batteries lose charge over time if not kept trickle-charged (for more details, see “About the Battery,” page 18). Therefore, even a new unit (or replacement battery) will require up to 18 hours of powered operation before it can provide reliable backup power (is at full charge).

The EC-BOS-6AX monitors the battery and periodically loads the battery to test its ability to maintain battery-backed functions. Investigate any battery trouble message, and check the battery connections to the unit. Replace the battery as required. To order a new battery, see the “Standard Replacement Parts” section on page 22.

Replacing the Battery

A replacement battery is a complete assembly, that is a battery pack pre-attached to a battery bracket. See

Figure 6 on page 17.

Caution Use only battery packs approved for use with the EC-BOS-6

To replace the battery, proceed as follows:

Revised: February 2008 Part Number: 05DI-HIBS6AX-10

EC-BOS-6AX Mounting and Wiring Instructions

Replacement Parts

Procedure 5 Replacing NiMH battery assembly on an EC-BOS-6AX.

Non-replaceable Parts

Step 1

Backup the EC-BOS-6AX controller’s configuration to your PC using the appropriate NiagaraAX software tool (for example, EC-NetAX Pro).

Step 2

Remove power from the EC-BOS-6AX. Wait for LED activity to stop - after several seconds, all LEDs on the EC-BOS-6AX should be off.

Step 3

Step 4

Remove the cover. See “Removing and Replacing the Cover,” page 7.

Remove the old battery and bracket assembly by taking out the four screws holding it in place, setting the screws aside for later. Unplug the battery from the connector on the EC-BOS-6AX.

Step 5

Plug the battery connector plug of the replacement battery into the battery connector on the EC-BOS-6AX.

Step 6

Set the replacement battery/bracket assembly back over the option card slots, with the mounting holes aligned with the standoffs.

Step 7

Place the four screws through the battery bracket, option cards blanking plates, and into the standoffs on the EC-BOS-6AX base board. Hand tighten these screws.

Step 8

Step 9

Replace the cover.

Restore power to the EC-BOS-6AX and verify normal operation.

Replacement Parts

Servicing the EC-BOS-6AX may call for replacement parts. There are three categories of parts:

• Non-replaceable Parts

• Standard Replacement Parts

• New Replacement Units

Non-replaceable Parts

Other than the parts listed in the replacement parts sections, there are no serviceable components on the base assembly.

Memory

Any addition, modification, or replacement of memory components requires software configuration and is not a field upgrade. For additional information on modifying the memory capacity of the EC-BOS-6AX, consult Distech Controls office for technical support

Fuse

The EC-BOS-6AX contains a non-user replaceable fuse, soldered on the circuit board. This fuse provides protection from internal shorts or connection to incorrect power supplies. If the fuse circuitry is suspect, contact Distech Controls office for technical support. See the “Federal Communications Commission (FCC)” section on page 24.

EC-BOS-6AX Mounting and Wiring Instructions Part Number: 05DI-HIBS6AX-10 Revised: February 2008

Replacing the base assembly

Standard Replacement Parts

Standard replacement parts are listed in Table 4 and can be ordered from stock without restriction. Standard replacement parts cannot be returned for credit and should be disposed of in an appropriate manner.

Table 4 Standard replacement parts.

Part Number

Part Number Description

Part NumberPart Number

10499 NiMH Battery Pack (with battery bracket)—see “Replacing the Battery,” page 20

10027 RS-485 connector plug, 3-position

Description

DescriptionDescription

Note Screws used for the EC-BOS-6

are standard #6-32 x 3/8" types, which you can obtain locally if lost.

New Replacement Units

To replace a faulty unit, order and install a new EC-BOS-6AX—please note that EC-BOSAX series products do not have special “field replacement units,” or FRUs, with separate part numbers.

If the faulty EC-BOS-6AX is still in warranty, you can receive credit by returning it to Distech Controls. Be sure to contact Distech Controls for a return authorization (RMA) number before shipping an item for return credit. See “Federal Communications Commission (FCC),” page 24, for more details.

Note Before ordering a new EC-BOS-6

, it is strongly recommended that you contact your normal technical

support resource to eliminate the possibility of a software issue or mis-configuration problem.

Replacing the base assembly

Caution Before handling circuit boards, discharge any accumulated static by touching the metal surface of

the EC-BOS-6AX. For details, see the “Static Discharge Precautions” section on page 4.

To replace the EC-BOS-6AX base assembly in the field, proceed as follows:

Procedure 6 Replacing a EC-BOS-6AX base assembly.

Step 1

Step 2

Using the appropriate NiagaraAX software tool, back up the EC-BOSAX’s configuration to your PC.

Remove power to the EC-BOS-6AX. The unit should power down automatically.

Note If I/O accessory modules are installed and any I/O points have voltage, turn the devices off or

disconnect power to them.

Step 3

Note positions of all communications and other wiring cables going to the EC-BOS-6AX, as well as all installed accessory modules (if they must be removed). If necessary, label connectors and accessory modules to avoid mis-connection later, after EC-BOS-6AX is replaced.

Revised: February 2008 Part Number: 05DI-HIBS6AX-10

EC-BOS-6AX Mounting and Wiring Instructions

Replacing the base assembly

New Replacement Units

Step 4

Step 5

Step 6

Unplug all Ethernet, serial, LON, and modem connectors from the EC-BOS-6AX, and unplug its earth ground wire.

If I/O accessory modules are installed:

–

If DIN rail mounting with DIN end-clips was used, you may be able to remove the DIN rail end clip that secures the EC-BOS-6AX end of the assembly and then slide the EC-BOS-6AX away from the rest of the assembly. Then you can remove the EC-BOS-6AX from the DIN rail (see Figure 1 on page 6), leaving the mounting and wiring of I/O modules untouched. In this case, after removing the EC-BOS-6AX from the DIN rail, skip ahead to Step 6.

–

If tab (screw) mounting was used instead of DIN rail mounting, or if a combination of DIN rail mounting and tab screws (into the EC-BOS-6AX’s “accessory side” tab holes, see last page), you will need to remove the accessory modules first, before removing the EC-BOS-6AX. In this case:

a. Making a careful note of all wiring terminations, unplug the I/O connector plugs and earth ground

wires from the installed I/O modules.

b. Remove the installed accessory modules, starting with the end module. Modules may be secured

by screws in mounting tabs or clipped to a DIN rail, or fastened by some sombinations. See

Figure 1 on page 6 for details on removal from (and mounting onto) the DIN rail.

c. Remove any screws fastening the EC-BOS-6

and remove it (see Figure 1 on page 6).

Remove the cover from the old EC-BOS-6AX (see “Removing and Replacing the Cover,” page 7). Note the position of installed option boards, if any. You must transfer them to the replacement EC-BOS-6AX.

Step 7

Step 8

Step 9

Step 10

Step 11

Step 12

Step 13

Step 14

Remove the option boards from the old EC-BOS-6AX and install them into the replacement EC-BOS-6AX, if applicable. See “Mounting Option Cards,” page 8, for more details.

Mount the replacement EC-BOS-6AX as it was previously, using the same DIN rail location and/or screws.

Reconnect/remount any removed accessory modules, being careful to replace in the same order, using the same DIN rail location and/or screws. Secure all accessory modules as done previously.

Reconnect the earth ground wires to the EC-BOS-6AX grounding lug and any installed accessory modules.

Reconnect any Ethernet, serial, and modem connectors to the EC-BOS-6AX and any installed accessory modules.

If using I/O modules, and any of your I/O points have voltage, turn the devices back on or reconnect power to them.

Restore power to the EC-BOS-6AX. It should boot up as a new unit (see “Check the Status LEDs,” page 17).

Using the NiagaraAX platform tools, re-commission the EC-BOS-6AX, and install the saved station database. For more details, see the EC-BOSAX Install and Startup Guide.

EC-BOS-6AX Mounting and Wiring Instructions Part Number: 05DI-HIBS6AX-10 Revised: February 2008

Certifications

Federal Communications Commission (FCC)

Certifications

Federal Communications Commission (FCC)

This equipment generates, uses, and can radiate radio frequency energy, and if not installed and used in accordance with the instruction manual, may cause interference with radio communications. It has been tested and found to comply with the limits for a Class A computing device pursuant to Subpart J of Part 15 of FCC Rules, which are designed to provide reasonable protection against such interference when operated in a commercial environment. Operation of this equipment in a residential area may cause interference, in which case, users at their own expense will be required to take whatever measures may be required to correct the interference. Any unauthorized modification of this equipment may result in the revocation of the owner's authority to continue its operation.

Canadian Department of Communications (DOC)

Note This Class A digital apparatus meets all requirements of the Canadian Interference-Causing Equipment

Regulations.

Note Cet appareil numérique de la classe A respecte toutes les exigences du Règlement canadien sur le

matèriel pouvant causer des interfèrences.

EC-BOS-6AX Mounting and Wiring Instructions

Revised: February 2008 Part Number: 05DI-HIBS6AX-10

Declaration of Conformity

EC-BOS-6

Application of Council Directive:

Application of Council Directive:Application of Council Directive:

Manufacturer’s Name:

Manufacturer’s Name:Manufacturer’s Name:

Manufacturer’s Address:

Manufacturer’s Address:Manufacturer’s Address:

Product Model Number:

Product Model Number:Product Model Number:

Type of Equipment:

Type of Equipment:Type of Equipment:

EMC Standards Applied:

EMC Standards Applied:EMC Standards Applied:

89/336/EEC, 92/31/EEC, 73/23/EEC, 93/68/EEC

Distech Controls, Inc.

4005-B Matte Boulevard Brossard, Quebec J4Y 2P4 Canada

EC-BOS-6AX, with the following: EC-NPB-PWR, EC-NPM-PWR-UN, EC-NPB-LON, EC-NPB-MDM

Information Technology Equipment

Standard

EN 61000-6-4

EN 61000-6-2 and EN 61000-6-1, as defined below

EN50081-2 Generic Emission Standard for residential, commercial,

CISPR 11 Limits of Radio Disturbance - Radiated Emissions

IEC 61000-4-2 E.S.D PASS Criteria A

IEC 61000-4-3 Radiated Field Immunity PASS Criteria A

IEC 61000-4-4

IEC 61000-4-5

IEC 61000-4-6

EN 61000-3-2

EN 61000-3-3

IEC 61000-4-11

IEC 61010-10-1: 90 +A1:92 + A2:95

Description

Electro-Magnetic Compatibility Emissions Generic

Electro-Magnetic Compatibility Immunity Complies, as

and light industrial environment

Limits of Radio Disturbance - Conducted Emissions

Electrical Fast Transient Immunity (Signal Ports) Electrical Fast Transient Immunity (AC Power)

Surge Immunity

Conducted Immunity

Harmonic Current

Quasi-Stationary Harmonics Test, Voltage Fluctuation and Flicker

Voltage Dips Voltage Interrupts

Safety requirement for electrical equipment for measurement, control and laboratory use

Criteria Met

Complies

documented below

PASS Class A PASS Class A

PASS Criteria A PASS Criteria A

PASS Criteria A

PASS

PASS Criteria A PASS Criteria A

PASS

EC-BOS-6AX Mounting and Wiring Instructions Part Number: 05DI-HIBS6AX-10 Revised: February 2008

Tab Mounting Dimensions

DIN mounting is recommended over tab mounting.

Note: Electronic and printed versions of this guide may not show the dimensions to scale.

95.25mm (3.75”)

170.66mm (6.719”)

63.50mm (2.50”)

101.6mm (4.00”)

4.32mm Dia.

(0.170”)

EC-BOS-6

63.50mm (2.50”)

EC-NetAX IO-16 or

EC-NPM-PWR or

EC-NPB-PWR-UN

88.55mm (3.48”)

82.55mm (3.25”)

Tip: If mounting accessory modules, future removal/replacement of the EC-BOSAX is simplified if you do not install screws in the “accessory module side” tabs of the EC-BOSAX (see above).

EC-BOS-6

EC-NetAX IO-16 or

EC-NPM-PWR or

EC-NPB-PWR-UN

Distance between center of tabs from one unit to another unit.

Accessory

module

side tabs

170.66mm (6.719”)

EC-NetAX

IO-16

82.55mm (3.25”)

Distech Controls Inc.

4005-B Boul. Matte Brossard, QC J4Y 2P4 Tel.: 1-800-404-0043 (North America) Tel.: 1-450-444-9898 (International)

05DI-HIBS6AX-10

Distech Controls EC-BOS-6AX Mounting And Wiring Instructions

Specifications and Main Features

Frequently Asked Questions

User Manual

Preparation

Included in this Package

Material and Tools Required

Precautions

Safety Precautions

Static Discharge Precautions

Mounting

Environmental Requirements

Physical Mounting

Board Layout

Removing and Replacing the Cover

About Expansion Options

About Option Cards

Mounting Option Cards

About Accessory Modules

Wiring Details

Grounding

Power Wiring

EC-WPM-XX

EC-NPB-PWR

EC-NPB-PWR-UN

Communications Wiring

RS-232

Ethernet

Serial

Power Up and Initial Checkout

Connect the Backup Battery

Apply Power

Check the Status LEDs

Related Documentation

About the Battery

Using Status LEDs

Ethernet Ports

Heartbeat

Status

Serial Ports

Cleaning

Required Battery Maintenance

Replacing the Battery

Replacement Parts

Non-replaceable Parts

Memory

Fuse

Replacing the base assembly

Standard Replacement Parts

New Replacement Units

Certifications

Federal Communications Commission (FCC)

Canadian Department of Communications (DOC)

Declaration of Conformity

Tab Mounting Dimensions
