DIRECTV®
Universal Remote Control
User Guide
2
CONTENTS
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Features and Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Key Charts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Installing Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Controlling Your DIRECTV
®
Receiver. . . . . . . . . . . . . . . . . . . . . . . . . 7
Setting Up Your DIRECTV Remote . . . . . . . . . . . . . . . . . . . . . . 7
Onscreen Remote Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Controlling Your TV. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Setting Up the TV Input Key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Deactivating the TV Input Select Key . . . . . . . . . . . . . . . . . . . 9
Controlling Other Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Searching for TV, AV1 or AV2 Codes . . . . . . . . . . . . . . . . . . . . . . . . .10
Verifying the Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Changing Volume Lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Locking Volume to AV1, AV2 or TV . . . . . . . . . . . . . . . . . . . . .11
Activating and Deactivating the RF Transmitter . . . . . . . . . . . . . . . 12
Activating the RF Transmitter. . . . . . . . . . . . . . . . . . . . . . . . . 12
Deactivating the RF Transmitter . . . . . . . . . . . . . . . . . . . . . .12
Restoring Factory Default Settings . . . . . . . . . . . . . . . . . . . . . . . . . 13
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
DIRECTV Setup Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Setup Codes for DIRECTV
®
Receivers. . . . . . . . . . . . . . . . . . 14
Setup Codes for DIRECTV HD Receivers. . . . . . . . . . . . . . . . . 14
Setup Codes for DIRECTV
®
DVRs. . . . . . . . . . . . . . . . . . . . . . 15
Setup Codes, Other Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Setup Codes for TVs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Setup Codes for TVs (DLP) . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Setup Codes for TVs (Plasma) . . . . . . . . . . . . . . . . . . . . . . . .26
Setup Codes for TV/DVD Combos . . . . . . . . . . . . . . . . . . . . . . 28
Setup Codes for TV/VCR Combos . . . . . . . . . . . . . . . . . . . . . . 29
Setup Codes for VCRs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Setup Codes for PVRs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41
Setup Codes for DVD Players . . . . . . . . . . . . . . . . . . . . . . . . . 36
Setup Codes for Audio Receivers. . . . . . . . . . . . . . . . . . . . . . 42
Setup Codes for Audio Amplifiers. . . . . . . . . . . . . . . . . . . . . . 45
Repair or Replacement Policy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Additional Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Compliance with FCC Rules and Regulations. . . . . . . . . . . . . . . . . . 47
3
INTRODUCTION
Congratulations! You now have an exclusive DIRECTV®
Universal Remote Control that will contro l four
components, including a DIRECTV Receiv er, TV, and two
stereo or video components (f or exampl e, a DVD, stereo, or
second TV). Moreover, its sophisticated technology allows
you to consolidate the clutter of your original remote
controls in to one easy-to-use unit that's packed with
features such as:
• Four-position MODE slide switch for easy component
selection
• Code library for popular video and stereo compo nents
• Code search to help program control of older or discontinue d components
• Memor y protection to ensure you will not have to reprogram the remote when the batteries are replaced
Before using your DIRECTV U ni v er sal Remo te Co n tr ol, y o u
may need to program it to operate with your particular
component. Please follow the instructions detailed in this
guide to set up your DIRECTV U niv ersal R emote Co n trol so
you can start enjoying its features.
4
FEATURES AND FUNCTIONS
Key Charts
Press this key… To…
Slide the MODE switch to the DIRECTV, AV1,
AV2 or TV positions to select the com po nen t
you want t o contro l. A green LED under
each switch position indicates the
component being controlled.
Press TV INPUT to select the available inputs
on your TV.
NOTE: Additional setu p is required to
activate the TV INPUT key. (See
instructions on page 9.)
Press FORMAT to cycle through the
resolution and screen formats. Each press
of the key cycles to the next available
format and /or r esol utio n. (N o t a vailab le on
all DIRECTV
®
Receivers. )
Press PWR to turn the selected component
on or off.
Press TV POWER ON/OFF to turn the TV and
DIRECTV Receiver on or off.
(NOTE: These keys are only active a fter the
remote has been setup for your TV. See
page 8.)
Use these keys to control your DIRECTV
DVR or your VCR, DVD, or CD/DVD player.
On a DIRECTV DVR, enables one-
touch record for any selected program.
Jum ps back 6 seco nds and p la y s video
from that location.
Jumps ahead in a recording.
Use GUIDE to display the DIRECTV
Program Guide.
Press ACTIVE to access special features,
services, and the DIRECTV Information
channel.
5
Press LIST to display y our TO DO list of
programs. (Not available on all DIRECTV
®
Receivers.)
Press EXIT to exit menu screens and the
Program Guide and return to live TV.
Press SELECT to choose highlighted items
in menu screens or the Program Guide.
Use the ARROW keys to move around in the
Program Guide and menu screens.
Press BACK to return to the previously
displayed screen.
Press MENU to display the Quick Menu in
DIRECTV mode, or other me nu f or an other
selected device.
Use INFO to display current channel and
program information when watching live
TV or in the Guide.
Press YELLOW in full-screen TV to cycle
through alternate audio tracks
Press BLUE in full-screen TV to displa y the
Mini-Guide.
Press RED in the Guide to jump 12 hours
back.
Press GREEN in the Guide to jump 12 hours
forward.
Other functions vary–look for onscreen
hints or refer to your DIRECTV
®
Receiver's
user guide. (Not available on all DIRECTV
Receivers.)
Press VOL to raise or lower the sound
volume. The volume key is only active
when the remote is set up for your TV.
Press this key… To…
6
While watching TV, press CHANS (or
CHAN
T) to select the next higher (or
lower) channel.
While in the DIRECTV
Program Guide or
menu, press PAGE+ (or PAGE-) to page up
(or down) through available channels in
the Guide.
Press MUTE to turn the sound off or back
on.
Press PREV to return to the last channel
viewed.
Press the number keys to dir ectly enter a
channel number (e.g. 207) while watching
TV or in the Guide.
Press DASH to separate main and subchannel numbers.
Press ENTER to activate number e nt ries
quickly.
Press this key… To…
7
INSTALLING BATTERIES
1. On the back of the remote control, push d own on the
door (as shown), slide the battery cover off, and
remove the used batteries.
2. Obtain two (2) new AA alkaline batteries. Matc h their
+and - marks to the + and - marks in the battery
case, then insert them.
3. Slide the cover back on until battery door clicks into
place.
CONTROLLING YOUR DIRECTV® RECEIVER
The DIRECTV® Universal Remote Control comes
programmed to work with most DIRECTV Receivers.
Should the remote control not work with your DIRECTV
Receiver, y ou will need to set up the remote control b y
performing the following steps.
Setting Up Your DIRECTV Remote
1. Locate the DIRECTV Receiver's brand and model
number (on the back or bottom panel) and write it in
the spaces below.
BRAND:
......................................................................
MODEL: ......................................................................
8
2. Locate the 5-digit code for your DIRECTV® Receive r.
(See page 14.)
3. Power on the DIRECTV Receiver.
4. Slide the MODE switch to the DIRECTV p o s ition.
5. Press and hold the MUTE and SELECT keys unti l the
green ligh t unde r the DIRECTV position flashes twice,
then release both keys.
6. Using the number keys, enter the 5-digit code. If
performed correctly, the green light under the
DIRECTV position flashes twice.
7. Aim the remote at your DIRECTV Receiver and press
the PWR key once. The DIRECTV Receiver should
turnoff; if it does not, repeat steps 3 and 4, trying each
code for your brand un til you find the correct code.
8. For future referenc e, write down the working code for
your DIRECTV Receiver in the blocks below:
ONSCREEN REMOTE SETUP
Once your remote is setup to work with your DIRECTV
Receiver, you can set it up for your other equipment using
the steps detailed on the following pages, or you can set it
up onscreen by pr essing MENU, the n SELECT on Settings,
Setup in the Quick Menu, then selecting Remote from the
left menu.
CONTROLLING YOUR TV
Once yo u have succe ssfully set up your DIRECTV R emote
to operate your DIRECTV Receiver, you can set it up to
control your TV. We recommend you use the on-screen
steps described on page 8, but you can also use the
manual method below:
1. Turn on the TV.
NOTE
: Please read steps 2-5 completely before proceed-
ing. Highlight or write down the codes and component you wish to set up before moving on to
step 2.
2. Locate the 5-digit code for your TV. (See “Setup
Codes for TVs” on page15.)
3. Slide the MODE switch to the TV position.
4. Pres s an d h o l d th e MUTE and SELECT keys at the same
time until the green light under the TV position
flashes twice, then release both keys.
5. Using the n um ber keys enter the 5-digit code for your
brand of TV. If performed correctly, the green light
under TV flashed twice.
6. Aim the remote at your TV and press the PWR key
once. Your TV shou ld turn off. If it does not turn off,
repeat steps 3 and 4, trying each code for your brand
until you find the correct code.
9
7. Slide the MODE switch to the DIRECTV position. Press
TV POWER. Your TV should turn on.
8. For future referenc e, write down the working code for
your TV in the blocks below:
SETTING UP THE TV INPUT KEY
Once you have setup the DIRECTV® Remote control for
your T V, you can activate the TV INPUT key so you can
change the “source”—the piece of equipm ent whose signal
is displayed on your TV:
1. Slide the MODE switch to the TV position.
2. Press and hold the MUTE and SELECT keys unti l the
green light under the TV position flashes twice, then
release both keys.
3. Us ing the number keys enter 9-6-0. (The green light
under the TV position flashes twice.)
You now can change the input for your TV.
Deactivating the TV Input Select Key
If you want to deactivate the TV INPUT key, repeat steps 1
through 3 from the previous section; the green light will
blink 4 times. Pressing the TV INPUT key will now do
nothing.
CONTROLLING OTHER COMPONENTS
The AV1 and AV2 switch positions can be setup to control a
VCR, DVD, STEREO, second DIRECTV Receiver or second
TV. We recommen d you use the onscreen steps
described on page 8, but you can also use the manual
method below:
1. Turn on the component you wish to control (e.g. your
DVD Player).
2. Locate the 5-digit code for your component. (See
“Setup Codes, Other Devices” starting on page 15.)
3. Slide the MODE switch to the AV1 (or AV2) position.
4. Pres s an d h o l d th e MUTE and SELECT keys at the same
time until th e green light under AV1 (or AV2) flashes
twice, then release both keys.
5. Using the NUMBER keys, enter the 5-d igit code for the
brand of component being set up. If performed
correctly, the green light under the se lected position
flashes twice.
6. Aim the remote at your co mponen t and pr ess the PWR
key once. The component shou ld turn off; i f it does
not, repeat steps 3 and 4, trying each code for your
brand until you find the correct cod e.
10
7. Repeat steps 1 through 6 to set up a new component
under AV2 (or AV1).
8. For future reference write down the working code for
the component(s) set up under AV1 and AV2 below:
AV1:
COMPONENT: ___________________
AV2:
COMPONENT:___________________
SEARCHING FOR TV, AV1 OR AV2 CODES
If you were unable to find the code for your brand of TV or
componen t, you can try a code search. This process may
take up to 30 minutes.
1. Turn on the TV or component. Insert a tape or di sk if
applicable.
2. Slide the MODE switch to the TV, AV1 or AV2 position,
as desired.
3. Pres s an d h o l d th e MUTE and SELECT keys at the same
time until the green light under the selected switch
position flashes twice, then rel ease both keys.
4. Enter 9-9-1 followed by one of the following fourdigits:
5. Press PWR, or other functions (e.g. PLAY for VCR) you
want to use.
6. Point the remot e at the TV or compon ent and press
CHAN
S. Repeatedly press CHANS until the TV or
component turns off or performs the action you
selected in step 5.
NOTE: Every time CHAN
S is pressed the remo te
advances to the next code and power is transmitted to the component.
COMPONENT TYPE COMPONENT ID #
Satellite 0
TV 1
VCR/DVD/PVR 2
Stereo 3
11
7. Use the CHANT key to step back a code.
8. When the TV or component turns off turns off or
performs the action you selected in step 5, stop
pressing the CHAN
S key. Then, press and release the
SELECT key.
NOTE: If the light flashes 3 times before the TV or com-
ponent responds, you've cy cled through all
codes and the c ode y ou n eed is no t a vailab le. Yo u
must use the remote that came with your TV or
component.
Verifying the Codes
Once you have set up the DIRECTV® Univer sal Remote
Control using the above steps, use the following
instructions to find out the 5-digit code to which your
component responded:
1. Slide the MODE switch to the appropriate position.
2. Pres s an d h o l d th e MUTE and SELECT keys at the same
time until the green light under the selected switch
position flashes twice, then rel ease both keys.
3. Enter 9-9-0. (The green light under the selected
switch position flashes twice.)
4. To view the first digit in the code, Press and release
then number 1 key. Wait three seconds, and c ount the
number of times the green light flashes. Write this
number down in the leftmost TV, AV1 or AV2 code
box found on page 10.
5. Repeat step 4 four more times for the remaining
digits; i.e., press number 2 for the second digit, 3 for
the third di git, 4 for the fourth digit and 5 for the final
digit.
CHANGING VOLUME LOCK
Depending on how you set up y our remote, the VOL and
MUTE may control the volume only on your TV, regardless
of the position of the MODE switch. This remote can be set
up so that the VOL and MUTE keys work only with the
comp onent selected by the MODE s witch. To enable this
feature, perform the following steps:
1. Press and hold the MUTE and SELECT keys unti l the
green ligh t unde r the DIRECTV position flashes twice,
then release both keys.
2. Using the number keys, enter 9-9-3. (The green light
will flash twice after the 3.)
3. Press and release the VOL+ key. (The green light
flashes 4 times.)
Now t he VOL and MUTE keys will work only for the
comp onent selected by the MODE switch position.
Locking Volume to AV1, AV2 or TV
1. Slide the MODE switch to the AV1, AV2 or TV position to
lock the volume.
2. Press and hold the MUTE and SELECT keys unti l the
green light under th e selected s witch flas hes twice an d
release both keys.
12
3. Using the number keys, enter 9-9-3. (The green light
flashes twice.)
4. Press and release the SELECT key. (The green light
flashes twice.)
NOTE: DIRECTV
®
Receivers don’t have volume control,
so the remote will not allow the user to lock vo lume to the DIRECTV mode.
ACTIVATING AND DEACTIVATING THE RF
TRANSMITTER
Your DIRECTV Remote Con trol features RF (radio
frequency) capability. When you activate the RF feature of
your remote control, you can control your DIRECTV
Receiver from anywhere in your home. You do not need to
be within the line of sight of your receiver to con trol it.
NOTE: Not all DIREC TV Receivers are RF-capable. Also,
some RF-capable DIRECTV Receivers include integrated
RF antennas an d do not require an external antenna. If
your receiver requires the external RF antenna, before
activating the RF transmitter, locate the RF antenna
included with your remote control and insert it into the RF
remote antenna coaxial connector on the back of your
DIRECTV Receiver.
Activating the RF Transmitter
To activate the RF transmitter on your DIRECTV Remote
Control, perform the following steps:
1. Locate the 12 digit Receiver ID (RID) number of your
DIRECTV Receiver. You can find the RID number on
the back panel of your receiver, or inside the CAM
access door next to the reset button.
2. Write down the last six digits of the RID number.
3. Slide the mode switch to DIRECTV, AV1, or AV2.
4. Press and hold the MUTE and SELECT keys unti l the
green light under the selected swit ch flashes twice an d
release both keys.
5. Using the number keys, enter 9 6 1. (The green light
flashes twice.)
6. Press and release
CHANS. (The green light flashes
twice.)
7. Using the NUMBER keys, enter the last six digits of the
RID number. (See step 2 above.)
8. Press and release the SELECT key. (The green light
flashes twice.)
Deactivating the RF Transmitter
To deactivate the RF transmitter on your DIRECTV Remote
Control, perform the following steps:
1. Slide the mode switch to DIRECTV, AV1, or AV2.
2. Press and hold the MUTE and SELECT keys unti l the
green light under the selected swit ch flashes twice an d
release both keys.
3. Using the number keys, enter 9 6 1. (The green light
flashes twice.)
13
4. Press and release CHANT. (The green light flashes
twice.)
The RF transmitter on your remote control is now
deactivated. To reactivate the RF transmitter, See
“Activating the RF T ransmitter ” abo ve.
RESTORING FACTORY DEFAULT SETTINGS
To reset all the functions of the remote control to the
factory defaults (the original, out-of -the- box settings),
follow these steps:
1. Pres s an d h o l d th e MUTE and SELECT keys at the same
time until the green light flashes twice, then release
both keys.
2. Using the number keys, enter 9-8-1. (The green light
flashes 4 times.)
TROUBLESHOOTING
PROBLEM: Light at the top of the remote blinks when you
press a key, but the component does not respond.
SOLUTION 1: Try replacing the batteries (see page 7).
SOLUTION 2: Make sur e you are aiming the DIRECTV
®
Uni versal Remote Contro l at your home entertainment
component an d that you are within 15 f eet of the
component you are trying to control.
PROBLEM: The DIRECTV Universal Remote Control does
not co ntrol c omponent or commands ar e not recognized
properly.
SOLUTION: Try all listed co des for the device brand being
set up. Make sure all components can be operated with an
infrared remote control.
PROBLEM: TV/VCR combo does not respond properly.
SOLUTION: Us e the VCR codes for your bran d. So m e co m bo
units may require both a TV code and a VCR code for full
operation (see page 8).
PROBLEM: CHAN
S, CHANT, and PREV do not work for
your RCA TV.
SOLUTION: Due to RC A design for c ertain models (1983-
1987), only the original remote co ntrol will operate these
functions.
PROBLEM: Changing channels does not work properly.
SOLUTION: If original remote control required pressing
ENTER to change channels, press ENTER on the DIRECTV
Universal remote control after entering a channel number.
PROBLEM: Remote control does not turn on Sony or Sharp
TV/VCR Combo.
SOLUTION: For po w er o n, these p r od ucts r equire setting up
TV codes on the remote control. For Sony, use TV code
10000 and VCR code 20032. For Sharp, use TV code 10093
and VCR code 20048. (See “Controlling Other
Components” on page9.)
14
DIRECTV SETUP CODES
Setup Codes for DIRECTV® Receivers
Setup Codes for DIRECTV HD Receivers
DIRECTV all models 00001, 00002
Hughes Network Systems (most
models)
00749
Hughes Network Systems
models GAEB0, GAEB0A, GCB0,
GCEB0A, HBH-SA, HAH-SA
01749
GE models GRD33G2A and
GRD33G3A, GRD122GW
00566
Philips models DSX5500 and
DSX5400
00099
Proscan m od els PRD8630A and
PRD8650B
00566
RCA models DRD102RW,
DRD203 RW, DRD301RA,
DRD302RA, DRD303RA,
DRD403RA, DRD703RA,
DRD502RB, DRD 503RB,
DRD505RB, DRD515RB,
DRD523 RB, and DRD 705RB
00566
DRD440 RE, DRD460RE,
DRD480RE,DRD430RG,
DRD431RG, DRD450RG,
DRD451RG,
DRD485RG,DRD486RG,
DRD430RGA, DRD450RGA,
DRD485RGA, DRD435RH,
DRD455 RH, and DR D486R H
00392
Samsung model SIR-S60W 01109
Samsung models SIR-S70, SIR-
S75, SIR-S300W, and SIRS310W
01108
Sony models (All models except
TiVo and Ultimate TV)
01639
DIRECTV all models 00001, 00002
Hitachi model 61HDX98B 00819
HNS models HIRD-E8, HTL - HD 01750
LG model LSS-3200A,
HTL-HD
01750
Mitsubishi model SR-HD5 01749, 00749
Philips model DSHD800R 01749
Proscan model PSHD105 00392
RCA models DTC-100, DTC-210 00392
Samsung model SIR-TS360 01609
Samsung models SIR-TS160 01276
15
Setup Codes for DIRECTV
®
DVRs
SETUP CODES, OTHER DEVICES
Setup Codes for TVs
Sony models SAT-HD100, 200,
300
01639
Toshiba models DST-3000,
DST-3100, DW65X91
01749, 01285
Zenith models DTV1080, HDSAT520
01856
DIRECTV all models 00 00 1, 00 002
HNS models SD-DVR80, SD-
DV40, SD-DVR120,
HDVR2, GXCEBOT, GXCEBOTD
01442
Philips models DSR704,
DSR708, DSR6000,
DSR600R, DRS700/17
01142, 01442
RCA models DWD490RE,
DWD496RG
01392
RCA models DVR39, 40, 80, 120 01442
Sony model SAT-T60 00639
Sony model SAT-W60 01640
Samsung models SIR-S4040R,
SIR-S4080R, SIR-S4120R
01442
3M 11616
A-Mark 10003
Abex 10032
Accurian 11803
Action 10873
Admiral 10093, 10463
Advent 10761, 10783, 10815, 10817,
10842, 11933
Adventura 10046
Aiko 10092, 11579
Aiwa 10701
Akai 10812, 10 702, 10030, 10098,
10672, 11207, 11675, 11676,
11688, 11689, 11690, 11692,
11693, 11903, 11935
Akura 10264
Alaron 10179, 10183, 10216, 10208,
10208
Albatron 10700, 1084 3
Alfide 10672
Ambassador 10177
America Action 10180
Ampro 10751
16
Amstrad 10412
Anam 10 18 0, 10 00 4, 100 09, 10068
Anam National 10055, 10161
AOC 10030, 10003, 10019, 10052,
10137, 10185, 11365
Apex Digital 10748, 10879, 10765, 10767,
10890, 11217, 11943
Archer 10003
Astar 11531, 11548
Audinac 10180, 10391
Audiovox 10451, 10180, 10092, 10003,
10623, 10710, 10802, 10846,
10875, 11284, 11937, 11951,
11952
Aventura 10171
Axion 11937
Bang & Olufsen 11620
Barco 10556
Baysonic 10180
Baur 10010, 10535
Belcor 10019
Bell & Howell 10154, 10016
BenQ 11032, 11212, 11315
Blue Sky 10556, 11254
Blaupunkt 10535
Boigle 11696
Boxlight 10752
BPL 10208
Bradford 10180
Brillian 11007, 11255, 11257, 11258
Brockwood 10019
Broksonic 10236, 10463, 10003, 10642,
11911, 11929, 11935, 11938
Byd:sign 11309, 11311
Cadia 11283
Candle 10030, 10046, 10056, 10186
Carnivale 10030
Carver 10054, 10170
Casio 11205
CCE 10037, 10217, 10329
Celebrity 10000
Celera 10765
Champion 11362
Changhong 10765
Cinego 11986
Cineral 10451, 10092
17
Citizen 10060, 1003 0, 100 92, 10039,
10046, 10056, 10186, 10280,
11928, 11935
Clairtone 10185
Clarion 10180
Commercial Solutions 11447, 10047
Concerto 10056
Contec 10180, 10157, 10158, 10185
Craig 10180, 10161
Crosley 10054
Crown 10180, 10039, 10672, 11446
Crown Mustan g 10672
Curtis Mathes 10047, 10054, 10154, 10451,
10093, 10060, 10702, 10030,
10145, 10166, 11919, 11347,
11147, 10747, 10466, 10056,
10039, 10016
CXC 10180
CyberHome 10794
Cytron 11326
Daewoo 10451, 10092, 11661, 10019,
10039, 10066, 10067, 10091,
10623, 10661, 10672, 11928
Daytron 10019
De Graaf 10208
Dell 11080, 11178, 11264, 11403
Delta 11369
Denon 10145, 10511
Denstar 10628
Diamond Vision 11996, 11997
Digital Projection Inc. 11482
Dumont 10017, 10019, 10070
Durabrand 10463, 10180, 10178, 10171,
11034, 10003
Dwin 10720, 10774
Dynatech 10049
Ectec 10391
Electroband 10000, 10185
Electrograph 11623, 11755
Electrohome 1046 3, 10 38 1, 103 89, 10409
Elektra 10017, 11661
Emerson 10154, 10236, 10463, 10180,
10178, 10171, 11963, 11944,
11929, 11928, 11911, 11394,
10623, 10282, 10280, 10270,
10185, 10183, 10182, 10181,
10179, 10177, 10158, 10039,
10038, 10019
Emprex 11422, 11546
18
Envision 10030, 1081 3, 11365
Epson 10833, 10840, 11122, 11290
Erres 10012
ESA 10812, 10171, 11944, 11963
Ferguson 10005
Fidelity 10082
Finlandia 10208
Finlux 10070, 10105
Fisher 10154, 10159, 10208
FlexVision 10710
Frontech 10264
Fujitsu 10179, 10186, 10683 , 10809 ,
10853
Funai 10180, 10171, 10179, 11271,
11904, 11963
Futuretech 10180, 10264
Gateway 11001, 11002, 11003 , 110 04 ,
11755, 11756
GE 11447, 10047, 10051, 10451,
10178, 11922, 11919, 11917,
11347, 10747, 10282, 10279,
10251, 10174, 10138, 10135,
10055, 10029, 10027, 10021
Gibralter 10017, 1003 0, 10019
Go Video 10886
GoldStar 10178, 10030, 100 01 , 100 02,
10019, 10032, 10106, 10409,
11926
Goodmans 10360
Gradiente 10053, 10056, 10170, 10392,
11804
Granada 10208, 10339
Grundig 10037, 10195, 10672, 100 70 ,
10535
Grunpy 10180, 10179
H & B 11366
Haier 11034, 10768
Hallmark 10178
Hannspree 11348, 11351, 11352
Hantarex 11338
HCM 10412
Harley Davidson 10043, 10179, 11904
Harman/Kardon 10054, 10078
Harvard 10180, 10068
Havermy 10093
Helios 10865
Hello Kitty 10451
19
Hewlett Packard 11088, 11089, 11101, 11494,
11502, 11642
Himitsu 10180, 10628, 10779
Hisense 10748
Hitachi 11145, 10145, 11960, 11904 ,
11445, 11345, 11045, 10797,
10583, 10577, 10413, 10409,
10279, 10227, 10173, 10151,
10097, 10095, 10056, 10038,
10032, 10016, 10105
HP 11088, 11089, 11101, 11494,
11502, 11642
Humax 11501
Hyundai 10 84 9, 11 21 9, 112 94
Hypson 10264
ICE 10264
Intervision 10264
iLo 11286, 11603, 11684, 11990
Infinity 10054
InFocus 10752, 11164, 11430, 11516
Initial 11603, 11990
Innova 10037
Insignia 10171, 11204, 11326, 11517,
11564, 11641, 11963, 12002
Inteq 10017
IRT 10 45 1, 11 661, 10628, 10698
IX 10877
Janeil 10046
JBL 10054
JCB 10000
Jensen 10761, 10050, 10815, 10817,
11299, 11933
JVC 10463, 10053, 10036, 10069,
10160, 10169, 10182, 10731,
11253, 11302, 11923, 10094
Kamp 10216
Kawasho 10158, 1021 6, 103 08
Kaypani 10052
KDS 11498
KEC 10180
Ken Brown 11321
Kenwood 10 03 0, 10019
Kioto 10054, 10706, 10556, 10785
KLH 10765, 10767, 11962
Kloss 10024, 10046, 10078
KMC 10106
Konka 10628, 10632, 10638 , 107 03 ,
10707, 11939, 11940
20
Kost 11 26 2, 11 483
Kreisen 10876
KTV 10180, 10030, 10039, 10183,
10185, 10217, 10280
Leyco 10264
Local India TV 10208
LG 11265, 10178, 10030, 100 56 ,
10442, 10700, 10823, 10829,
10856, 11178, 11325, 11423,
11758, 11993
Lloyd's 11904
Loewe 10136, 10512
Logik 10016
Luxman 10056
LXI 10047, 10054, 10154, 10156,
10178, 10148, 10747
M & S 10054
MAG 11498
Magnasonic 11928
Magnavox 11454, 10054, 10030, 10706,
11990, 11963, 11944, 11931,
11904, 11525, 11365, 11254,
11198, 10802, 10386, 10230,
10187, 10186, 10179, 10096,
10036, 10028, 10024, 10020
M Electronic 1010 5
Manesth 10264
Matsui 10208
Mediator 10012
Metz 10535
Minerva 10070, 10535
Minoka 10412
Mitsubishi 10535
Majestic 10015, 10016
Marantz 10054, 10030, 10037, 10444,
10704, 10854, 10855, 11154,
11398
Matsushita 10250, 10650
Maxent 10762, 11211, 11755, 11757
Megapower 10700
Megatron 10178, 10 14 5, 100 03
MEI 10185
Memorex 10154, 10463, 10150, 10178,
10016, 10106, 10179, 10877,
11911, 11926
Mercury 10001
MGA 10150, 10178, 10030, 10019,
10155
Micro 11436
21
Midland 10047, 10 01 7, 100 51 , 100 32 ,
10039, 10135, 10747
Mintek 11603, 11990
Minutz 10021
Mitsubishi 10093, 11250, 10150, 10178,
11917, 11550, 11522, 11392,
11151, 10868, 10836, 10358,
10331, 10155, 10098, 10019,
10014
Monivision 10700, 10843
Motorola 10093, 10055, 10835
Moxell 10835
MTC 10060, 10 03 0, 100 19 , 100 49 ,
10056, 10091, 10185, 10216
Multitech 10180, 10049, 10217
NAD 10 15 6, 10 17 8, 100 37 , 100 56 ,
10866, 11156
Nakamichi 11493
NEC 10030, 10019, 10036, 10056,
10170, 10434, 10497, 10882,
11398, 11704
Netsat 10037
NetTV 10762, 11755
Neovia 11338
Nikkai 10264
Nikko 10178, 10030, 10092, 10317
Niko 11581, 11618
Nisato 10391
Noblex 10154, 10430
Norcent 10748, 1082 4, 110 89 , 113 65 ,
11589, 11590, 11591
Norwood Micro 11286, 11296, 11303
Noshi 10018
NTC 10092
Olevia 11144, 11240, 11331, 11610
Olympus 11342
Onwa 10180
Optimus 10 15 4, 10 25 0, 101 66, 10650
Optoma 10887, 11622, 11674
Optonica 10093, 10165
Orion 10236, 10463, 11463, 10179,
11911, 11929
Osaki 10264, 10412
Otto Versand 10010, 10535
Panasonic 10250, 10051, 11947, 11946,
11941, 11919, 11510, 11480,
11410, 11310, 11291, 10650,
10375, 10338, 10226, 10162,
10055
22
Panama 10264
Penney 10047, 10156, 10051, 10060 ,
10178, 10030, 11926, 11919,
11347, 10747, 10309, 10149,
10138, 10135, 10110, 10039,
10032, 10027, 10021, 10019,
10018, 10003, 10002
Petters 11523
Philco 10054, 10463, 10030, 10145,
11661, 10019, 10020, 10028,
10096, 10302, 10786, 11029,
11911
Philips 11454, 10 05 4, 100 37, 10556,
10690, 11154, 11483, 11961,
10012, 10013
Phonola 10012, 10013
Protech 10264
Pye 10012
Pilot 10030, 10019, 10039
Pioneer 10166, 10 03 8, 101 72, 10679,
10866, 11260, 11398
Planar 11496
Polaroid 10765, 1086 5, 11262, 11276,
11314, 11316, 11326, 11327,
11328, 11341, 11498, 11523,
11991, 11992
Portland 1009 2, 10 01 9, 100 39
Prima 10761, 1078 3, 10815, 10817,
11933
Princeton 10700, 10717
Prism 10051
Proscan 11447, 10047, 10747, 11347,
11922
Proton 10178, 10 00 3, 100 31 , 100 52,
10466
Protron 11320, 11323
Proview 10835, 1140 1, 114 98
Pulsar 10017, 10019
Quasar 10250, 10051, 10055, 10165,
10219, 10650, 11919
Quelle 10010, 10070, 10535
RadioShack 1004 7, 10154, 10180, 10178,
10030, 10019, 10032, 10039,
10056, 10165, 10409, 10747,
11904
23
RCA 11 44 7, 10 047, 10060, 12002,
11958, 11953, 11948, 11922,
11919, 11917, 11547, 11347,
11247, 11147, 11047, 10747,
10679, 10618, 10278, 10174,
10135, 10090, 10038, 10029,
10019, 10018
Realistic 10154, 10180, 10178, 10030,
10019, 10032, 10039, 10056,
10165
Radiola 10012
RBM 10070
Rex 10264
Roadstar 10264
Rhapsody 1018 3, 10185, 10216
Runco 10017, 10 03 0, 102 51 , 104 97 ,
10603, 11292, 11397, 11398,
11628, 11629, 11638, 11639,
11679
Sampo 1003 0, 10 03 2, 100 39 , 100 52 ,
10100, 10110, 10762, 11755
Samsung 10060, 1081 2, 107 02 , 10178 ,
10030, 11959, 11903, 11575,
11395, 11312, 11249, 11060,
10814, 10766, 10618, 10482,
10427, 10408, 10329, 10056,
10037, 10032, 10019, 10264
Samsux 10039
Sansei 10451
Sansui 10463, 11409, 11904, 11911,
11929, 11935
Sanyo 10154, 10088, 10107, 10146,
10159, 10232, 10484, 10799,
10893, 11142, 10208, 10339
Saisho 10264
SBR 10012, 10013
Schneider 10013
Sceptre 10878, 11217, 11360, 11599
Scimitsu 10019
Scotch 10178
Scott 10236, 1018 0, 101 78, 10019,
10179, 10309
Sears 10047, 10054, 10154, 10156,
10178, 10171, 11926, 11904,
11007, 10747, 10281, 10179,
10168, 10159, 10149, 10148,
10146, 10056, 10015
Semivox 10180
Semp 10156, 11356
SEG 10264
24
SEI 10010
Sharp 10093, 10039, 101 53 , 101 57 ,
10165, 10220, 10281, 10386,
10398, 10491, 10688, 10689,
10818, 10851, 11602, 11917,
11393
Sheng Chia 10093
Sherwood 11399
Shogun 10019
Signature 10016
Signet 11262
Siemens 10535
Sinudyne 10010
SIM2 Multimedia 11297
Simpson 10186, 10187
SKY 10037
Sony 11100, 10000, 10011, 10080,
10111, 10273, 10353, 10505,
10810, 10834, 11317, 11685,
11904, 11925, 10010
Soundesign 10180, 10178, 10179, 10186
Sova 11320, 11952
Soyo 11520
Sonitron 10208
Sonolor 10208
Space Tek 11696
Spectricon 10003, 10 13 7
Spectroniq 11498
Squareview 10171
SSS 10180, 1001 9
Starlite 10180
Studio Experience 10843
Superscan 10093, 10864
Supre-Macy 10046
Supreme 10000
SVA 10748, 10587, 10768, 10865,
10870, 10871, 10872
Sylvania 10054, 10030, 10171, 10020,
10028, 10065, 10096, 10381,
11271, 11314, 11394, 11931,
11944, 11963
Symphonic 10180, 10171, 11904, 11944
Syntax 11144, 11240, 113 31
Tandy 10093
Tatung 10003, 1004 9, 100 55 , 103 96 ,
11101, 11285, 11286, 11287,
11288, 11361, 11756
Teac 10264, 10412
25
Telefunken 10005
Technics 10250, 10051
Technol Ace 10179
Technovox 10007
Techview 10847, 12004
Techwood 10051, 10003, 10056
Teco 11040
Teknika 10054, 10 18 0, 101 50 , 100 60 ,
10092, 10016, 10019, 10039,
10056, 10175, 10179, 10186,
10312, 10322
Telefunken 10702, 10056, 10074
Tera 10031
Thomas 11904
Thomson 10209, 10210
TMK 10178, 10056, 10177
TNCi 10017
Tophouse 10180
Toshiba 10154, 11256, 10156, 10093,
11265, 10060, 11356, 11369,
11524, 11635, 11656, 11704,
11918, 11935, 11936, 11945,
12006, 11343, 11325, 11306,
11164, 11156, 10845, 10832,
10822, 10650, 10149, 10036,
10070
Tosonic 10185
Totevision 10039
Trical 10157
TVS 10463
Ultra 10391, 11323
Universal 10027
Universum 10105, 10264, 10535, 11337
US Logic 11286, 11303
Vector Research 10030
VEOS 11007
Victor 10053
Video Concepts 10098
Vidikron 10054, 10242, 11292, 11302,
11397, 11398, 11628, 11629,
11633
Vidtech 10178, 10019, 10036
Viewsonic 10797, 10857, 10864, 10885,
11330, 11342, 11578, 11627,
11640, 11755
Viking 10046, 10 312
Viore 11207
Visart 11336
26
Setup Codes for TVs (DLP)
Setup Codes for TVs (Plasma)
Vizio 10864, 10885, 11499, 11756,
11758
Wards 10054, 10178, 10030 , 111 56 ,
10866, 10202, 10179, 10174,
10165, 10111, 10096, 10080,
10056, 10029, 10028, 10027,
10021, 10020, 10019, 10016
Waycon 10156
Westing house 10885, 10889, 10890, 11282,
11577
White Westinghouse 10463, 10623
WinBook 11381
Wyse 11365
Yamaha 10030, 10019, 10769 , 107 97 ,
10833, 10839, 11526
Yoko 10264
Zenith 10017, 10463, 112 65 , 101 78 ,
10092, 10016, 11904, 11911,
11929
Zonda 10003, 10698, 10779
Hewlett Packard 11494
HP 11494
LG 11265
Magnavox 11525
Mitsubishi 11250
Optoma 10887
Panasonic 11291
RCA 11447
Samsung 10812, 1106 0, 113 12
SVA 10872
Toshiba 11265, 11306
Vizio 11499
Akai 10812, 11207, 11675, 116 88,
11690
Albatron 10843
BenQ 11032
Byd:sign 11311
Daewoo 10451, 10661
Dell 11264
Delta 11369
Electrograph 11623, 11755
ESA 10812
Fujitsu 10186, 10683, 10809, 10853
Funai 11271
27
Gatewa y 11001, 11002, 11003, 11004,
11755, 11756
H & B 11366
Helios 10865
Hewlett Packard 11089, 11502
Hitachi 10797
HP 11089, 11502
iLo 11684
Insignia 11564
JVC 10731
LG 10178, 10056, 10829, 10856,
11423, 11758
Marantz 10704, 11398
Maxe nt 11755, 11757
Mitsubishi 10836
Monivision 10843
Motorola 10835
Moxell 10835
Nakamichi 11493
NEC 11398, 11704
NetTV 11755
Norcent 10824, 11089, 11590
Norwood Micro 11303
Panasonic 10250, 10650, 11480
Philips 10690
Pioneer 10679, 11260, 11398
Polaroid 10865, 11276, 11327, 11328
Proview 10835
Runco 11398, 11679
Sampo 11755
Samsung 10812, 11312
Sharp 10093
Sony 10000, 10810, 11317
Studio Experience 10843
SVA 10865
Sylvania 11271, 11394
Tatung 11101, 11285, 11287 , 11288,
11756
Toshiba 10650, 11704
US Logic 11303
Viewsonic 10797, 11755
Viore 11207
Vizio 11756, 11758
Yamaha 10797
Zenith 10178
28
Setup Codes for TV/DVD Combos
Controlled by the TV
Setup Codes for TV/DVD Combos
Controlled by the DVD
Accurian 11803
Advent 11933
Akai 11675, 11935
Apex Digital 11943
Audiovox 11937, 11951, 11952
Axion 11937
Boigle 11696
Broksonic 11935
Cinego 11986
Citizen 11935
Diamond Vision 11997
Emerson 11394, 11963
ESA 11963
Funai 11963
Hitachi 11960
iLo 11990
Initial 11990
Insignia 11963, 12002
Jensen 11933
KLH 11962
Konka 11939, 11940
LG 11993
Magna vox 11963, 11990
Mintek 11990
Panasonic 11941
Philips 11961
Polaroid 11991
Prima 11933
RCA 11948, 11958, 12002
Samsung 11903
Sansui 11935
Sova 11952
Sylvania 11394, 11963
Techview 12004
Toshiba 11635, 11935, 12006
Advent 21016
Akai 20695
Apex Digital 20830
Audiovox 21071, 21121, 21122
Axion 21071
Broksonic 20695
Cinego 21399
29
Setup Codes for TV/VCR Combos
Controlled by the TV
Citizen 20695
Diamond Vision 21610
Emerson 20675, 21268
ESA 21268
Funai 21268
Go Vision 21071
Hitachi 21247
iLo 21472
Initial 21472
Insignia 21013, 21268
Jensen 21016
KLH 21261
Konka 20719, 20720
LG 21526
Magna vox 21268, 21472
Mintek 21472
Naxa 21473
Panasonic 21490
Philips 20854, 21260
Polaroid 21480
Prima 21016
RCA 21013, 21022, 21193
Samsung 20899
Sansui 20695
Sova 21122
Sylvania 20675, 21268
Toshiba 20695
America Action 10180
Audiovox 10180
Broksonic 11911, 11929
Citizen 11928
Curtis Mathes 11919
Daewoo 11928
Emerson 10236, 11911, 11928, 11929
Funai 11904
GE 11 91 7, 11 919, 11922
GoldStar 11926
Gradiente 11804
Harley Davidso n 11904
Hitachi 11904
JVC 11923
Lloyd's 11904
Magnasonic 11928
Magnavox 11904, 11931
30
Setup Codes for TV/VCR Combos
Controlled by the VCR
Memorex 11926
Mitsubishi 11917
Orion 11911, 11929
Panasonic 11919
Penney 11919, 11926
Quasar 11919
RadioShack 11904
RCA 11917, 11919, 11922
Samsung 11959
Sansui 11904, 11911, 11929
Sears 11904, 11926
Sony 11904, 11925
Sylvania 11931
Symphonic 11904
Thomas 11904
Toshiba 11918, 11936
Zenith 1190 4, 11 91 1, 11 929
America Action 20278
Audiovox 20278
Broksonic 20002, 20479, 21479
Citizen 21278
Colt 20072
Curtis Mathes 21035
Daewoo 20637, 21278
Emerson 20002, 20479, 20593, 21278,
21479
Funai 20000
GE 20240, 20807, 21035, 21060
GoldStar 21237
Gradiente 21137
Harley Davidson 20000
Hitachi 20000
LG 21037
Lloyd's 20000
Magnasonic 20593, 21278
Magnavox 20000, 20593, 21781
Magnin 20240
Memorex 20162, 21037, 21162, 21237,
21262
MGA 20240
Mitsubishi 20807
Optimus 20162, 20593, 21162, 21262
Orion 20002, 20479, 21479
Panasonic 20162, 21035, 21162, 21262
31
Setup Codes for VCRs
Penney 20240, 21035, 21237
Philco 20479
Quasar 20162, 21035, 21162
RadioShack 20000, 21037
RCA 20240, 20807, 21035, 21060
Samsung 20432, 21014
Sansui 20000, 20479, 21479
Sanyo 20240
Sears 20000, 21237
Sony 20000, 21232
Sylvania 21781
Symphonic 20000, 20593
Thomas 20000
Toshiba 20845, 21145
White Westinghouse 20637
Zenith 20000, 20479, 20637, 21479
ABS 21972
Admiral 20048, 20209
Adventura 20000
Aiko 20278
Aiwa 20037, 20000, 20124, 20307
Akai 20041, 20061, 20106
Alienware 21972
Allegro 21137
America Action 20278
American High 20035
Asha 20240
Audiovox 20037, 20278
Bang & Olufsen 21697
Beaumark 20240
Bell & Howell 20104
Blaupunkt 20006, 20003
Broksonic 20184, 20121, 20209, 200 02 ,
20295, 20348, 20479, 21479
Calix 20037
Canon 20035, 20102
Capehart 20020
Carver 20081
CCE 20072, 20278
Cineral 20278
CineVision 21137
Citizen 20037, 20278, 21278
Colt 20072
Craig 20037, 20047, 20240, 20072,
20271
32
Curtis Mathes 20060, 20035, 20162, 20041,
20760, 21035
Cybernex 20240
CyberPower 21972
Daewoo 20045, 20278, 20020, 205 61 ,
20637, 21137, 21278
Daytron 20020
Dell 21972
Denon 20042
DirecTV 20739, 21989
Durabrand 20039, 20038
Dynatech 20000
Electrohome 20037
Electrophonic 20037
Emerex 20032
Emerson 20037, 20184, 20000, 20121,
20043, 20209, 20002, 20278,
20068, 20061, 20036, 20208,
20212, 20295, 20479, 20561,
20593, 20637, 21278, 21479,
21593
ESA 21137
Fisher 20047, 20104, 20054 , 200 66
Fuji 20 03 5, 20 03 3
Funai 20000, 20593, 21 593
Garrard 20000
Gateway 21972
GE 20 06 0, 20 03 5, 20240, 20065,
20202, 20760, 20761, 20807,
21035, 21060
Go Video 20432, 20526, 20614, 206 43 ,
21137, 21873
GoldStar 20037, 20 03 8, 21 137, 21237
Gradiente 20 00 0, 20 00 8, 21137
Grundig 20195
Harley Davidso n 20000
Harman/Kardon 20081, 20038, 20075
Harwood 20072, 20068
Headquarter 20046
Hewlett Packard 21972
HI-Q 20047
Hitachi 20000, 20 04 2, 20 041 , 200 65 ,
20089, 20105, 20166
Howard Computers 21972
HP 21972
Hughes Network Systems 20042, 20739
Humax 20739, 21797, 21988
Hush 21972
33
iBUYPOWER 21972
Jensen 20041
JVC 20067, 20 04 1, 20 008 , 20206
KEC 20037, 20278
Kenwood 20067, 20041, 20038
Kioto 20348
KLH 20072
Kodak 20035, 20037
LG 20037, 21037, 21137, 21786
Linksys 21972
Lloyd's 20000, 20208
Logik 20072
LXI 20037
Magnasonic 20593, 2127 8
Magnavox 20035, 20039, 20081, 20000,
20149, 20110, 20563, 20593,
21593, 21781
Magnin 20240
Marantz 20035, 20081
Marta 20037
Matsushita 20 03 5, 20 16 2, 21162
Media Center PC 21972
MEI 20035
Memorex 20035, 20162, 20037, 200 48 ,
20039, 20047, 20240, 20000,
20104, 20209, 20046, 20307,
20348, 20479, 21037, 21162,
21237, 21262
MGA 20240, 20043, 20061
MGN Technology 20240
Microsoft 21972
Mind 21972
Minolta 20042, 20105
Mitsubishi 20067, 20 04 3, 20 061 , 200 75 ,
20173, 20807, 21795
Motorola 20035, 2004 8
MTC 20240, 20000
Multitech 20000, 20072
NEC 20104, 20067, 20041, 20038,
20040
Nikko 20037
Nikon 20034
Niveus Media 21972
Noblex 20240
Northgate 21972
Olympus 20035
Optimus 21062, 20162, 20037, 20048,
20104, 20432, 20593, 21048,
21162, 21262
Optonica 20062
Orion 20184, 20209, 20002, 20295,
20479, 21479
Panasonic 21062, 20035, 20162, 20077,
20102, 20225, 20614, 20616,
21035, 21162, 21262, 21807
Penney 20035, 20037, 20240, 20042,
20038, 20040, 20054, 21035,
21237
Pentax 20042, 20065, 20105
Philco 20035, 20209, 20479, 20561
Philips 20035, 20081, 20062, 20110,
20618, 20739, 21081, 21181,
21818
Pilot 20037
Pioneer 20067, 21337, 21803
Polk Audio 20081
Portland 20020
Presidian 21593
Profitr onic 20240
Proscan 20060, 20202, 20760, 20761,
21060
Protec 20072
Pulsar 20039
Quarter 20046
Quartz 20046
Quasar 20035, 20162, 20077, 21035,
21162
RadioShack 20000, 21037
Radix 20037
Randex 20037
RCA 20060, 20240, 20042, 20149,
20065, 20077, 20105, 20106,
20202, 20760, 20761, 20807,
20880, 21035, 21060, 21989
Realistic 20035, 20037, 20048, 20047,
20000, 20104, 20046, 20062,
20066
ReplayTV 20614, 20616
Ricavision 21972
Ricoh 20034
Rio 21137
Runco 20039
Salora 20075
35
Samsung 2024 0, 20 04 5, 20 432 , 207 39 ,
21014
Samtron 20643
Sanky 20048, 20039
Sansui 20000, 20067, 20209, 20041,
20271, 20479, 21479
Sanyo 20047, 20240, 20104 , 20046
Scott 20184, 20045, 20121, 20043,
20210, 20212
Sears 20035, 20037, 20047, 200 00,
20042, 20104, 20046, 20054,
20066, 20105, 21237
Semp 20045
Sharp 20048, 20062, 20807, 20848,
21875
Shintom 20072
Shogun 20240
Singer 20072
SKY 22032
Sky Brazil 22032
Sonic Blue 20614, 20616, 21137
Sony 20035, 20032, 20033, 20000 ,
20034, 20636, 21032, 21232,
21886, 21972
Stack 9 21972
STS 20042
Sylvania 20035, 20081, 20 000 , 200 43 ,
20110, 20593, 21593, 21781
Symphonic 20000, 20593, 21593
Systemax 21972
Tagar Systems 21972
Tatung 20041
Teac 20000, 20041
Technics 20035, 20162
Teknika 20035, 20037, 20000
Thomas 20000
Tivo 20618, 20636, 20 739 , 213 37 ,
21996
TMK 20240, 20036, 20208
Toshiba 20045, 20043, 20066 , 202 10 ,
20212, 20366, 20845, 21008,
21145, 21972, 21988, 21996
Totevision 20037, 20 24 0
Touch 21972
UEC 22032
UltimateTV 21989
Unitech 20240
Vector 20045
36
Setup Codes for DVD Players
Vector Research 20038, 20040
Video Concepts 20045, 20040, 20061
Videomagic 20037
Videosonic 20240
Viewsonic 21972
Villain 20000
Voodoo 21972
Wards 20060, 20035, 20048, 20047,
20081, 20240, 20000, 20042,
20072, 20149, 20062, 20212,
20760
White Westinghouse 20 20 9, 20 072, 20637
XR-1000 20035, 2000 0, 20 072
Yamaha 20038
Zenith 2003 9, 20 03 3, 20 000 , 202 09 ,
20034, 20479, 20637, 21137,
21139, 21479
ZT Group 21972
Accurian 2107 2, 21416
Adcom 21094
Advent 21016
Aiwa 20641
Akai 20695, 20770, 20899, 21089
Alco 20790
Allegro 20869
Amoisonic 20764
Amphion Media Works 20872, 21245
AMW 20872, 21245
Apex Digital 20672, 20 71 7, 20 755 , 207 94 ,
20795, 20796, 20797, 20830,
21004, 21020, 21056, 21061,
21100
Arrgo 21023
Aspire Digital 21168, 21407
Astar 21 48 9, 21 67 8, 21679
Audiologic 20736
Audiovox 20790, 21041, 21071, 21072,
21121, 21122
Axion 21071, 21072
B & K 20655, 20662
Bang & Olufsen 21696
BBK 21224
Bel Canto Design 21571
Blaupunkt 20717
Blue Parade 20571
Bose 22023
37
Broksonic 20695, 20868, 21419
Buffalo 21882
Cambridge Soundworks 20690
Cary Audio Design 21477
Casio 20512
CAVS 21057
Centrios 21577
Cinea 20831
Cinego 21399
Cinematrix 21052
CineVision 2087 6, 20 833, 20869, 21483
Citizen 20695, 21277
Clatronic 20788
Coby 20778, 20852, 21086, 21107,
21165, 21177, 21351
Craig 20831
Curtis Mathes 21087
CyberHome 20816, 20874, 21023, 21024,
21117, 21129, 21502, 21537
D-Link 21881
Daewoo 20784, 20705, 20770, 208 33 ,
20869, 21169, 21172, 21234,
21242, 21441, 21443
Denon 20490, 20634
Desay 21407, 21455
Diamond Vision 21316, 21609, 21 610
DigitalMax 21738
Digix Media 21272
Disney 20675, 21270
Dual 21068, 21085
Durabrand 21127
DVD2000 20521
Emerson 20591, 20675, 20821, 21268
Encore 21374
Enterprise 20591
ESA 20821, 2126 8, 21 443
Fisher 20670, 21919
Funai 20675, 21268, 21 334
Gateway 21073, 21077, 21158, 21194
GE 20 52 2, 20 81 5, 20717
Genica 20750
Go Video 20744, 20715, 20741, 207 83 ,
20833, 20869, 21044, 21075,
21099, 21144, 21148, 21158,
21304, 21443, 21483, 21730
Go Vision 21071, 21072
GoldStar 20741
GPX 20699, 20769
38
Gradiente 20651
Greenhill 20717
Grundig 20705
Harman/Kardon 20582, 20702
Hitachi 20573, 20 66 4, 20 695 , 212 47 ,
21919
Hiteker 20672
Humax 21500, 21588
iLo 21348, 21472
Initial 20717, 21472
Innovative Technology 21542
Insignia 21013, 21268
Integra 20627
InterVideo 21124
IRT 20783
Jaton 21078
JBL 20702
Jensen 21016
JSI 21423
JVC 20558, 20 62 3, 20 867 , 21164 ,
21275, 21550, 21602, 21863
jWin 21049, 21051
Kawasaki 20790
Kenwood 20490, 20534, 20682, 20737
KLH 20717, 20790, 21020, 211 49 ,
21261
Konka 20711, 20 71 9, 20 720 , 207 21
Koss 20651, 20896, 21423
Kreisen 21421
Krell 21498
Lafayette 21369
Landel 20826
Lasonic 20798, 21173
Lenoxx 21076, 21127
Lexicon 20671
LG 20591, 20741, 20801, 20869,
21526
LiteOn 2105 8, 21 158, 21416, 21440,
21656, 21738
Loewe 20511, 20885
Magnavox 20503, 20539, 20646, 20675,
20821, 21268, 21472, 21506
Malata 20782, 21159
Marantz 20539
McIntosh 21273, 21373
Memorex 20695, 20831, 21270
Meridian 21497
Microsoft 205 22, 21708
39
Mintek 20839, 20717, 21472
Mitsubishi 21521, 20 52 1
MixSonic 21130
Momitsu 21082
NAD 20692, 20741
Nakamichi 21222
Naxa 21473
NEC 20785
Nesa 20717, 21603
NeuNeo 21454
Next Base 20826
NexxTech 21402
Norcent 21 00 3, 20 87 2, 21 107 , 212 65 ,
21457
Nova 21517, 21518, 21519
Onkyo 2050 3, 20 62 7, 20 792, 21417,
21418, 21612
Oppo 20575, 2122 4, 21 525
OptoMedia Electronics 20896
Oritron 20651
Panasonic 20490, 20 63 2, 20 703 , 213 62 ,
21462, 21490, 21762
Philco 20690, 20733, 20790 , 208 62 ,
21855, 22000
Philips 20 50 3, 20 539, 20646, 20671,
20675, 20854, 21260, 21267,
21340, 21354
Pioneer 20525, 20571, 20142, 20631,
20632, 21460, 21512, 22052
Polaroid 21020, 21061, 21086, 21245,
21316, 21478, 21480, 21482
Polk Audio 20539
Portland 20770
Presidian 20675, 21072, 21738
Prima 21016
Primare 21467
Princeton 20674
Proscan 20522
ProVisio n 20778
Qwestar 20651
RCA 20522, 20571, 20717, 20790,
20822, 21013, 21022, 21132,
21193, 21769
Recco 20698
Rio 20869, 22002
RJTech 21360
Rotel 20623, 20865, 21178
Rowa 20823
40
Sampo 20698, 20752, 21501
Samsung 2049 0, 20 57 3, 20 744 , 201 99 ,
20820, 20899, 21044, 21075
Sansui 20695
Sanyo 20670, 20695, 20873 , 21919
Seeltech 21338
Semp 20503
Sensory Science 21158
Sharp 20630, 20675, 20752, 21256
Sharper Image 21117
Sherwood 20633, 20770, 21043, 21077,
21889
Shinsonic 20533, 20839
Sigma Designs 20674
SilverCrest 21368
Sonic Blue 20869, 21099, 22002
Sony 20533, 21533, 20864, 21033 ,
21070, 21431, 21432, 21433,
21548, 21824, 21892, 22020,
22043
Sound Mobile 21298
Sova 21122
Sungale 21074, 21342, 21532
Superscan 20821
SVA 20860, 21105
Sylvania 20675, 20821, 21 268
Symphonic 20675, 20821
TAG McLaren 20894
Teac 20758, 20790, 20809
Technics 20490, 20703
Technosonic 20730
Techwood 20692
Terapin 21031, 21053, 21166
Theta Digital 20571
Tivo 21503, 21512
Toshiba 20503, 20695, 21045 , 211 54 ,
21503, 21510, 21515, 21588,
21769, 21854
Tredex 2079 9, 20 80 0, 20803, 20804
TYT 20705
Urban Concepts 20503
US Logic 20839
Valor 21298
Venturer 20790
Vialta 21509
Viewmage 21374
Vizio 21064, 21226
Vocopro 21027, 21360
41
Setup Codes for PVRs
Wintel 21131
Xbox 20522, 21708
Xwave 21001
Yamaha 20490, 20 539, 20545
Zenith 2050 3, 20 59 1, 20 741 , 208 69
Zoece 21265
ABS 21972
Alienware 21972
CyberPower 21972
Dell 21972
DirecTV 20739, 21989
Gateway 21972
Go Video 20614, 21873
Hewlett Packard 21972
Howard Computers 21972
HP 21972
Hughes Network Systems 20739
Humax 20739, 21797, 21988
Hush 21972
iBUYPOWER 21972
LG 21786
Linksys 21972
Media Center PC 21972
Microsoft 21972
Mind 21972
Mitsubishi 21795
Niveus Media 21972
Northgate 21972
Panasonic 20614, 20616, 21807
Philips 2061 8, 20 73 9, 218 18
Pioneer 21337, 21803
RCA 20880, 21989
ReplayTV 20614, 20616
Samsung 20739
Sharp 21875
SKY 22032
Sonic Blue 20614, 2061 6
Sony 20636, 21886, 21972
Stack 9 21972
Systemax 21972
Tagar Systems 21972
Tivo 20618, 20636, 20739, 21337
Toshiba 21008, 21972, 21988, 21996
Touch 21972
42
Setup Codes for Audio Receivers
UEC 22032
UltimateTV 21989
Viewsonic 21972
Voodoo 21972
ZT Group 21972
ADC 30531
Aiwa 31405, 3015 8, 30 18 9, 301 21 ,
30405, 31089, 31243, 31321,
31347, 31388, 31641
Akai 31512
Alco 31390
Amphion Media Works 31563, 31615
AMW 31563, 31615
Anam 31609, 31074
Apex Digital 31257, 31430, 31774
Arcam 31120, 31212, 31978, 32022
Audiophase 31387
Audiotronic 31189
Audiovox 31390, 31627
B & K 30701, 30820, 30840
Bang & Olufsen 30799, 31196
BK 30702
Bose 31229, 30639, 31 25 3, 316 29 ,
31841, 31933
Brix 31602
Cambridge Soundworks 31370, 31477
Capetronic 30531
Carver 31 18 9, 30189, 30042, 31089
Casio 30195
Clarinette 30195
Classic 31352
Coby 31263, 31 38 9
Criterion 31420
Curtis 30797
Curtis Mathes 30080
Daewoo 31178, 31250
Dell 31383
Delphi 31414
Denon 31360, 3000 4, 31 10 4, 311 42 ,
31311, 31434
Emerson 30255
Fisher 30042, 31 80 1
Garrard 30281, 30286, 3046 3, 307 44
Gateway 31517
GE 31379
43
Glory Horse 31263
Go Video 31532
GPX 30744, 31299
Harman/Kardon 30110, 30189, 30891, 31304,
31306
Hewlett Packard 31181
Hitachi 31273, 31801
Hitech 30744
Initial 31426
Insignia 31030, 31893
Integra 30135, 3129 8, 31 32 0
JBL 30110, 30281, 31 30 6
JVC 30074, 30286, 30464, 31199,
31263, 31282, 31374, 31495,
31560, 31643, 31811, 31871
Kenwood 31313, 31570, 31569, 300 27 ,
31916, 31670, 31262, 31261,
31052, 31032, 31027, 30569,
30337, 30314, 30313, 30239,
30186, 30077, 30042
Kioto 30797
KLH 31390, 3141 2, 31 42 8
Koss 30255, 30744, 31366, 31497
Lasonic 31798
Lenoxx 31437
LG 31293, 31524
Linn 30189
Liquid Video 31497
Lloyd's 30195
LXI 30181, 30744
Magnavox 31189, 31269, 30189, 30195 ,
30391, 30531, 31089, 31514
Marantz 31189, 31269, 30039, 30189,
31089, 31289
MCS 30039, 30346
Mitsubishi 31393
Modulaire 30195
Musicmagic 31089
NAD 30320, 30845
Nakamichi 30097, 30876, 31236, 31555
Norcent 31389
Nova 31389
NTDE Geniesom 30744
Onkyo 30135, 30380, 30842, 31298,
31320, 31531, 31805
44
Optimus 31023, 30042, 30080, 301 81 ,
30186, 30286, 30531, 30670,
30738, 30744, 30797, 30801,
31074
Orient Power 30744
Oritron 31366, 31497
Panasonic 31308, 31518, 30039, 30309,
30367, 30763, 31275, 31288,
31316, 31350, 31363, 31509,
31548, 31633, 31763, 31764
Penney 30195
Philco 31390, 31 56 2, 31 83 8
Philips 31189, 31269, 30189, 30391,
31089, 31120, 31266, 31268,
31283, 31365, 31368
Pioneer 31023, 30014, 30080, 301 50 ,
30244, 30289, 30531, 30630,
31123, 31343, 31384
Polaroid 31508
Polk Audio 30189, 31289, 31 41 4
Proscan 31254
Quasar 30039
RadioShack 30744, 31263
RCA 31023, 31609, 31 25 4, 300 54 ,
30080, 30346, 30530, 30531,
31074, 31123, 31154, 31390,
31511
Realistic 30181, 30195
Recco 30797
Regent 31437
Rio 31383, 31869
Rotel 30793
Saba 31519
Samsung 30286, 31199, 31295, 31500
Sansui 30189, 30 193, 30346, 31089
Sanyo 30801, 31251, 31469, 31801
Semivox 30255
Sharp 30186, 3128 6, 31361, 31386
Sharper Image 30797, 31263, 31410, 31556
Sherwood 30491, 30502, 3107 7, 314 23 ,
31517, 31653, 31905
Shinsonic 31426
Sirius 31602, 31627, 31811, 31987
Sonic 30281
Sonic Blue 31383, 31532, 31869
45
Setup Codes for Audio Amplifiers
Sony 31058, 31441, 31258, 31759,
31622, 30158, 31958, 31858,
31822, 31758, 31658, 30168,
31558, 31547, 31529, 31503,
31458, 31442, 30474, 31406,
31382, 31371, 31367, 31358,
31349, 31131, 31158
Soundesign 30670
Starlight 30797
Stereophonics 31023
Sunfire 31313, 30313, 30314, 31052
Sylvania 30797
Teac 30463, 31074, 31390, 31528
Technics 3130 8, 31 518, 30039, 30309,
30763, 31309
Techwood 30281
Thorens 31189
Toshiba 31788
Venturer 31390
Victor 30074
Wards 30158, 30189, 30014, 30054,
30080
XM 31406, 31414
Yamaha 30176, 30082, 30186, 30376,
31176, 31276, 31331, 31375,
31376, 31476
Yorx 30195
Zenith 30281, 30744, 30857, 31293,
31524
Accuphase 30382
Acurus 30765
Adcom 30577, 31100
Aiwa 30406
AudioSource 30011
Arcam 30641
Bel Canto Design 31583
Bose 30674
Carver 30269
Classe 31461, 31462
Curtis Mathes 30300
Denon 30160
Durabrand 31561, 31566
Elan 30647
GE 30078
Harman/Kardon 30892
46
JVC 30331
Kenwood 30356
Left Coast 30892
Lenoxx 31561, 31566
Lexicon 31802
Linn 30269
Luxman 30165
Magnavox 30269
Marantz 30892, 30321, 30269
Mark Levinson 31483
McIntosh 30251
Nakamichi 30321
NEC 30264
Optimus 30395, 30300, 30823
Panasonic 30308, 30521
Parasound 30246
Philips 30892, 30269, 30641
Pioneer 30013, 30300, 30823
Polk Audio 30892, 30269
RCA 30300, 30823
Realistic 30395
Regent 31568
Sansui 30321
Sharp 31432
Shure 30264
Sony 30689, 30220, 30815, 31126
Soundesign 30078, 30211
Technics 30308, 30521
Victor 30331
Wards 30078, 30013, 30211
Xantech 32658, 32659
Yamaha 30354, 30133, 30143, 30504
REPAIR OR REPLACEMENT POLICY
If the DIRECT V® Universal Remote Control does not function properly,
DIRECTV wi ll, at our sole di scretion, repair or replace the DIRECTV Universal
Remote Control, provided that:
THE DIRECTV UNIVERSAL REMOTE CONTROL IS PROVIDED ON AN AS-IS,
AS-AVAILABLE BASIS, SOLELY FOR YOUR NON-COMMERCIAL,
RESIDENTIAL USE. DIRECTV DOES NOT MAKE ANY REP R ESENTATIONS
OR WARRANTIES OF ANY KIND, WHETHER STATUTORY, EXPRESS OR
IMPLIED, REGARDING THE DIRECTV UNIVERSAL REMOTE CONTROL,
INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY,
NONINFRINGEMENT OR FITNESS FOR A PARTICULAR PURPOSE OR
IMPLIED WARRANTIES ARISING FROM A COURSE OF DEALING OR
COURSE OF PERFORMANCE. DIRECTV E XPRESSLY DISCLAIMS ANY
REPRESENTATION OR WARRANTY THAT THE DIRECTV UNIVERSAL
REMOTE CONTRO L WILL BE ERR O R FREE. NO O RAL AD VICE OR WRITTEN
INFORMATION GIVEN BY DIRECTV, ITS EMPLOYEES, AND LICENSORS OR
THE LIKE SHALL CREATE A WARRANTY; NOR SHALL CUSTOMER RELY ON
ANY SUCH INFORMATION OR ADVICE.
UNDER NO CIRCUMSTANCES, INCLUDING NEGLIGENCE, SHALL DIREC TV
OR ANYONE ELSE INVOLVED IN ADMINISTERING, DISTRIBUTING, OR
PROVIDING THE DIRE CTV UNIVERSAL R EMOTE CONTR O L BE LIABLE FO R
ANY INDIRECT, INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES,
INCLUDING, WITHOUT LIMITATION, LOSS OF REVENUES OR INABILITY
TO USE THE DIRECTV UNIVERSAL REMOTE CONTROL, MISTAKE S ,
OMISSIONS, IN TERRUPTIONS, DEFECTS, FAILURE OF PERFORMANCE,
EVEN IF DIRECTV HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH
LOSSES.
Becaus e some states do not all ow the exclusion or limitation of liability for
consequential or incidental damages, in such states, DIRECTV’s liability is
limited to the greatest extent permitted by law.
ADDITIONAL INFORMATION
This product does not have any user-serviceable par ts.Opening the case, except
for the battery cover, may cause permanent damage to your DIRECTV Universal
Remote Control.
For help via the Internet, visit us at: DIRECTV.com
Or ask for technical support at: 1-800-531-5000
Copyright 2006 by DIRECTV, Inc. No part of this publication may be
reproduced, transmitted, transcribed, stored in any retrieval system, or
translated t o any language, in any form or b y any means, electro n ic, mec hani cal,
magnetic, optical, manual, or other wise, without prior wr itten permission of
DIRECTV, Inc.
DIRECTV and the Cyclone Design logo are registered trademarks of DIRECTV,
Inc.
M2983 C for use with the URC2983 DIRECTV Universal Remote Control.
04/07
COMPLIANCE WITH FCC RULES AND
REGULATIONS
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency
energy and if not used in accordance with the instructions, may
cause harmful interference to radio communications.
a. You are a custome r of D IRECTV and y o ur ac c o un t is in good stand ing; and
b. The problem with the DIRECTV Universal R emote Contr ol was not caused
by abuse, mishandling, alteration, accident, failure to follow operating,
maintenance or enviro nmental instructions set forth in this U ser Guide, or
service performed by someone other than DIRECTV.
48
However, there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful
interference to radio or television reception, the user is encouraged to try to correct the interference by one or more of the following measures:
• Increase or decrease the separation between the eq uipment
and receiver.
• Consult the dealer or an experienced remote control/ TV tech-
nician for help.
This equipment has been verified to comply with the limits for a
Class B computing device, pursuant to FCC Rules. The user is
cautioned that changes and modifications made to the equipment
without the approval of manufacturer could void the user's
authority to operate this equipment.
FCC Authorization Label
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions:
1. This device may not cause harmful interference.
2 This device must accept any interference received, including
interference that may cause undesired operation.
Responsible Party:
DIRECTV, Inc.
2230 E. Imperial Hwy.
El Segundo, CA 90245
1-800-531-5000
FCC ID #: MG3 2481
Loading...
