SPLIT.CONVERTER
User's Manual
Version 2.0
page 2 of 24
SPLIT.CONVERTER Manual - Version 2.0
Copyright
All rights reserved. Permission to reprint or electronically reproduce any document or graphic in whole or in part for any reason is expressly prohibited, unless prior written consent is obtained from the DirectOut GmbH. All trademarks and registered trademarks belong to their respective owners. It cannot be guaranteed that all product names, products, trademarks, requisitions, regulations, guidelines, specifications and norms are free from trade mark rights of third parties. All entries in this document have been thoroughly checked; however no guarantee for correctness can be given. DirectOut GmbH cannot be held responsible for any misleading or incorrect information provided throughout this manual. DirectOut GmbH reserves the right to change specifications at any time without notice. DirectOut Technologies® is a registered trademark of the DirectOut GmbH.
© DirectOut GmbH, 2017
page 3 of 24
SPLIT.CONVERTER Manual - Version 2.0
Table of contents
About This Manual 5
How to Use This Manual ............................................................................... 5
Conventions .................................................................................................. 5
CHAPTER 1: Overview 6
Introduction ................................................................................................... 6
Feature Summary .......................................................................................... 6
How it works ................................................................................................. 6
Applications ................................................................................................... 7
CHAPTER 2: Legal issues & facts 8
Before Installing This Device ......................................................................... 8
Defective Parts/Modules ............................................................................. 8
First Aid (in case of electric shock) ................................................................ 9
Updates ....................................................................................................... 10
Conditions of Warranty ............................................................................... 10
Intended Operation .................................................................................... 10
Conformity & Certificates ........................................................................... 11
Contact ........................................................................................................ 11
Contents ...................................................................................................... 12
CHAPTER 3: Installation 13
Installing the Device .................................................................................... 13
CHAPTER 4: Operation 16
Global Control .............................................................................................. 16
Connecting MADI ....................................................................................... 17
Signal Routing ............................................................................................. 18
CHAPTER 5: Troubleshooting and Maintenance 20
Troubleshooting ........................................................................................... 20
Maintenance ................................................................................................ 20
CHAPTER 6: Technical Data 21
Index 22
page 4 of 24
SPLIT.CONVERTER Manual - Version 2.0
This page is left blank intentionally.
page 5 of 24
SPLIT.CONVERTER Manual - Version 2.0
About This Manual
About This Manual
How to Use This Manual
This manual guides you through the installation and operation of the device. Use the Table of Contents at the beginning of the manual or Index Directory at the end of the document to locate help on a particular topic. You can access more information and latest news by visiting on the DirectOut website at
www.directout.eu.
Conventions
The following symbols are used to draw your attention to:
TIPS!
indicate useful hints and shortcuts.
NOTES!
are used for important points of clarification or cross references.
WARNINGS!
alert you when an action should always be observed.
This document relates to:
• SPLIT.CONVERTER (BNC / SC)
• SPLIT.CONVERTER optical (SC / SC)
page 6 of 24 SPLIT.CONVERTER Manual - Version 2.0
CHAPTER 1: Overview
CHAPTER 1: Overview
Introduction
The SPLIT.CONVERTER is a combined MADI format converter and signal splitter with four MADI ports.
With one RU height, two redundant power supplies and a straightforward source selector it allows for instantaneous conversion or distribution of MADI signals.
Feature Summary
MADI Ports 2 x SC-Socket multi/single-mode &
2 x coaxial BNC connector, 75 Ω (BNC/SC) or 4 x SC-Socket multi/single-mode (SC/SC)
MADI Formats 56/64 channel, 48k/96k Frame, S/MUX 2/4
Sample Rates 32 kHz up to 192 kHz
Power Supply This device is equipped with two wide range power
supplies (84 V to 264 V AC / 47 Hz to 63 Hz / safety class 1)
How it works
Using the rotary input selector for each port, any output can be fed from any input. All ports are independent from each other, allowing the SPLIT.CONVERTER to route and convert up to four asynchronous MADI streams simultaneously.
The signal routing is bittransparent and operates without any delays. All common sample rates and MADI formats are supported, and will pass through the unit without modifi cation. It is therefore also possible to convert and route proprietary data formats.
page 7 of 24
SPLIT.CONVERTER Manual - Version 2.0
CHAPTER 1: Overview
Applications
SPLIT.CONVERTER can be used to convert MADI signals in “mixed environments” or for distribution of MADI signals.
Typical applications include:
• Switching converter units between control rooms
• Redundancy splitting/switching (manually) during recording or live sound applications.
• Splitting signals for live events (FOH, monitoring, recording)
• Conversion between optical and coaxial connections to link devices
• Conversion between single-mode and multi-mode
• ...
Scheme
A
Inputs
B C D
A
Outputs
B
C
D
page 8 of 24
SPLIT.CONVERTER Manual - Version 2.0
CHAPTER 2: Legal issues & facts
CHAPTER 2: Legal issues & facts
Before Installing This Device
WARNING!
Please read and observe all of the following notes before installing this product:
• Check the hardware device for transport damage.
• Any devices showing signs of mechanical damage or damage from the spillage of liquids must not be connected to the mains supply, or disconnected from the mains immediately by pulling out the power lead.
• All devices must be grounded. The device is grounded through its IEC power connections.
• All devices must be connected to the mains using the three-cord power leads supplied with the system. Only supply electrical interfaces with the voltages and signals described in these instructions.
• Do not use the device at extreme temperatures. Proper operation can only be guaranteed between temperatures of 5ºC and 45ºC and a maximum relative humidity of 80%, non-condensing.
• The cabinet of the device will heat up. Do not place the device close to heating sources (e.g. heaters). Observe the environmental conditions.
Defective Parts/Modules
WARNING!
This device contains no user-serviceable parts. Therefore do not open the device. In the event of a hardware defect, please send the device to your DirectOut representative together with a detailed description of the fault. We would like to remind you to please check carefully whether the failure is caused by erroneous configuration, operation or connection before sending parts for repair.
page 9 of 24
SPLIT.CONVERTER Manual - Version 2.0
CHAPTER 2: Legal issues & facts
First Aid (in case of electric shock)
WARNING!
• Do not touch the person or his/her clothing before power is turned off, otherwise you risk sustaining an electric shock yourself.
• Separate the person as quickly as possible from the electric power source as follows:
- Switch off the equipment.
- Unplug or disconnect the mains cable.
• Move the person away from the power source by using dry insulating material (such as wood or plastic).
• If the person is unconscious:
- Check their pulse and reanimate if their respiration is poor.
- Lay the body down and turn it to one side. Call for a doctor immediately.
• Having sustained an electric shock, always consult a doctor.
page 10 of 24
SPLIT.CONVERTER Manual - Version 2.0
CHAPTER 2: Legal issues & facts
Updates
DirectOut products are continually in development, and therefore the information in this manual may be superseded by new releases. To access the latest documentation, please visit the DirectOut website:
www.directout.eu.
WARNING!
No compensation can be claimed for damages caused by operation of this unit other than for the intended use described above. Consecutive damages are also excluded explicitly. The general terms and conditions of business of DirectOut GmbH are applied.
Conditions of Warranty
This unit has been designed and examined carefully by the manufacturer and complies with actual norms and directives. Warranty is granted by DirectOut GmbH over the period of two years for all components that are essential for proper and intended operation of the device. The date of purchase is applied for this period. Consumable parts (e.g. battery) are excluded from warranty claims.
WARNING!
All claims of warranty will expire once the device has been opened or modified, or if instructions and warnings were ignored. For warranty claims please contact the dealer where your device was acquired.
Intended Operation
The SPLIT.CONVERTER is designed for the conversion and distribution of MADI signals (AES10) and other signals which meet the electrical specifications of MADI.
page 11 of 24
SPLIT.CONVERTER Manual - Version 2.0
CHAPTER 2: Legal issues & facts
Conformity & Certificates
CE
This device complies with the basic requests of applicable EU guidelines. The appropriate procedure for approval has been carried out.
RoHS
(Restriction of the use of certain Hazardous Substances) This device was constructed fulfilling the directive on the restriction of the use of certain hazardous substances in electrical and electronic equipment 2002/95/EC.
WEEE
(Directive on Waste Electrical and Electronic Equipment) Due to the directive 2002/96/EC for waste disposal this device must be recycled. For correct recycling please dispatch the device to: DirectOut GmbH, Leipziger Str. 32 09648 Mittweida Germany Only stamped parcels will be accepted! WEEE-Reg.-No. DE 64879540
Contact
DirectOut GmbH Leipziger Str. 32, 09648 Mittweida, Germany Phone: +49 (0)3727 5665-100 Fax: +49 (0)3727 5665-101 Mail: sales@directout.eu
www.directout.eu
page 12 of 24 SPLIT.CONVERTER Manual - Version 2.0
CHAPTER 2: Legal issues & facts
Single-Mode / Multi-Mode
The SC ports are multi-mode as default. It is possible to equip the device with single-mode SC ports. The housing of single-mode ports is colored blue.
Contents
The contents of your SPLIT.CONVERTER package should include:
• 1 x SPLIT.CONVERTER (19’’, 1 RU)
• 2 x power chord
• 2 x fixing unit for power plug
• 1 x User's Manual
Two different MADI I/O confi gurations are available:
2 x SC-Socket & 2 x BNC coaxial (Version BNC / SC)
4 x SC-Socket (Version SC / SC, 'optical')
multi-mode single-mode
page 13 of 24SPLIT.CONVERTER Manual - Version 2.0
CHAPTER 3: Installation
Retain the protective cap if the optical port is unused. This will protect against soiling which can lead to malfunction.
Avoid damage from condensation by waiting for the device to adapt to the environmental temperature. Proper operation can only be guaranteed between temperatures of 5ºC and 45ºC and a maximum relative humidity of 80%, non­condensing. Ensure that the unit has suffi cient air circulation for cooling.
CHAPTER 3: Installation
Installing the Device
1. Open the packaging and check that the contents have been delivered
complete and undamaged.
2. Fix the device in a 19’’ frame with four screws, or place it on a non-slip
horizontal surface.
WARNING!
3. Remove the protective cap from the optical MADI port(s) before use.
BNC / SC Version SC / SC Version
(Version BNC / SC)
(Version SC / SC)
NOTE
BNC / SC Version SC / SC Version
page 14 of 24 SPLIT.CONVERTER Manual - Version 2.0
CHAPTER 3: Installation
This device may operate with only one power supply. To provide power supply redundancy, it is recommended to connect both PSU1 and PSU 2 to independent power supplies with separate fuses.
This device must be connected to the mains using the three-cord power leads supplied with the system. Only supply the voltages and signals indicated (84 V – 264 V).
Keep any packaging in order to protect the device should it need to be dispatched for service.
4. Connect the signal cables for the MADI signals to the device.
5. Using the power cord provided connect the PSU to a matching power supply.
WARNING
NOTE
6. Turn on the power switch and check the status of PSUs on the front panel:
TIP
page 15 of 24
SPLIT.CONVERTER Manual - Version 2.0
CHAPTER 3: Installation
This page is left blank intentionally.
page 16 of 24 SPLIT.CONVERTER Manual - Version 2.0
CHAPTER 4: Operation
The green LEDs (PSU 1 & PSU 2) indicate that a working power supply is connected to the power supply unit. Note that an unlit LED does not guarantee that the device is free of voltage. To ensure that the device is completely disconnected from mains voltage, the power chords must be disconnected.
CHAPTER 4: Operation
Global Control
The control on the right of the front panel indicates the power supply. Power switches are on the back panel:
PSU 1 & PSU 2 (rear) 2 Switches
Enable / disable power supply.
PSU 1 & PSU 2 (rear) C13 socket
Connect the power supply here (84 - 264 V AC).
PSU 1 & PSU 2 (front) 2 LEDs (green): indicate the status of both
power supply units
LED OFF = Power supply inactive LED ON = Power supply active
NOTE
page 17 of 24SPLIT.CONVERTER Manual - Version 2.0
CHAPTER 4: Operation
Connecting MADI
The MADI ports are used for transmission of 64 audio channels (AES10). Two different MADI I/O confi gurations are available:
Version BNC / SC
Version SC / SC
PORT A OUT
SC socket (optical)
MADI output (64 ch), connect for MADI output signal here
PORT A IN
SC socket (optical)
MADI input (64 ch), connect MADI input signal here
PORT B OUT
SC socket (optical)
MADI output (64 ch), connect for MADI output signal here
PORT B IN
SC socket (optical)
MADI input (64 ch), connect MADI input signal here
PORT C OUT
BNC socket (coaxial), 75 Ω or SC socket (optical) MADI output (64 ch), connect for MADI output signal here
PORT C IN
BNC socket (coaxial), 75 Ω or SC socket (optical) MADI input (64 ch), connect MADI input signal here
PORT D OUT
BNC socket (coaxial), 75 Ω or SC socket (optical) MADI output (64 ch), connect for MADI output signal here
PORT D IN
BNC socket (coaxial), 75 Ω or SC socket (optical) MADI input (64 ch), connect MADI input signal here
NOTE
SC Ports may be equipped with multi-mode or single-mode modules. Mixed combinations offer the comfortable conversion between multi-mode and single­mode I/Os. See „Examples“ on page 19.
page 18 of 24 SPLIT.CONVERTER Manual - Version 2.0
CHAPTER 4: Operation
Signal Routing
All four MADI input signals are fed to a routing matrix where they can be distributed to any output. This allows the SPLIT.CONVERTER to convert and distribute MADI signals:
PORT A (ABCD)
Encoder
Turn the rotary control to the desired position to select the desired input source for output A.
PORT B (ABCD)
Encoder
Turn the rotary control to the desired position to select the desired input source for output B.
PORT C (ABCD)
Encoder
Turn the rotary control to the desired position to select the desired input source for output C.
PORT D (ABCD)
Encoder
Turn the rotary control to the desired position to select the desired input source for output D.
NOTE
• The ports are independent from each other, the MADI signals are not required to be in sync to each other.
• The routing is bit transparent and works without delay, even proprietary adaptions of MADI will pass through the unit in their native state.
• All common sample rates (up to 192 kHz) and MADI formats (48k/96k frame, 56/64 channels) are supported.
page 19 of 24SPLIT.CONVERTER Manual - Version 2.0
CHAPTER 4: Operation
Examples
Format conversion of four MADI signals (coaxial < > optical)
Signal distribution of one MADI signal (4 x optical, '1:4')
Format conversion of four MADI signals (single mode <> multi-mode)
Signal C Signal D Signal A Signal B
Signal A Signal A Signal A Signal A
Signal C Signal D Signal A Signal B
page 20 of 24
SPLIT.CONVERTER Manual - Version 2.0
CHAPTER 5: Troubleshooting and Maintenance
Troubleshooting
To identify a possible defect with the device please consult the following table. If the fault cannot be resolved using these instructions, please contact your local DirectOut representative or visit support.directout.eu.
Maintenance
To clean the device, use a soft, dry cloth. To protect the surface, avoid using cleaning agents.
The device should be disconnected from the power supply during the cleaning process.
CHAPTER 5: Troubleshooting and Maintenance
Issue Possible reason Solution
Device doesn’t work.
Power supply is broken.
Check that the power supply switch is on, that the device is connected to the power supply and that the socket is working. Defective fuses must be exchanged by qualified service personal only.
Optical port does not work.
Optic is dirty. Use an air supply to carefully remove any
dust. Never use objects for cleaning.
No signal at the output port.
Connections (input / output) are mixed up.
Check the connections and change the cables if necessary. Check the routing matrix.
No signal at the output port.
Signal cable defective. Exchange the signal cable.
MADI signal at the input is not stable.
Signal source is defective or bad signal condition (Jitter > 1 ns) - e.g. due to exceeded length or bad screening attenuation of signal cable.
Change the source or use appropriate cables (75 Ω, screening attenuation better than 85 dB.)
Output port does not transmit the desired signal.
Wrong input selected. Change the input using the rotary control
on the front panel.
NOTE
page 21 of 24
SPLIT.CONVERTER Manual - Version 2.0
CHAPTER 6: Technical Data
CHAPTER 6: Technical Data
Dimensions
• Width 19’’ (483 mm)
• Height 1 RU (44.5 mm)
• Depth 10’’ (254 mm)
Weight
• about 3.4 kg
Power Consumption
• 25 W
Power Supply
• 84 V - 264 V AC / 47 Hz - 63 Hz / Safety class 1
Fuses
• Fuse 250 V - 2 A (slow-blow) – 2 fuses per power supply
Environmental Conditions
• Operating temperature +5°C up to +45°C
• Relative humidity: 10% - 80%, non condensing
MADI Port - (Version BNC/SC)
• 2 x BNC socket (1 x input / 1 x output)
• Impedance: 75 Ω
• 0.3 V up to 0.6 V (peak to peak)
MADI Port - (Version BNC/SC or SC/SC)
• 2 x or 4 x SC socket FDDI (input / output)
• ISO/IEC 9314-3
• Wave length: 1310 nm
• Multi mode 62.5/125 µm or 50/125 µm
• optional: single mode 9/125 µm
Sample Rate
• 32 kHz to 192 kHz
MADI Format (I/O)
• 48k Frame, 96k Frame
• 56 channel, 64 channel
• S/MUX 2/4
page 22 of 24
SPLIT.CONVERTER Manual - Version 2.0
Index
Index
B
Bit-transparent ......................................... 18
C
Compatibility seeBit-transparent Conformity & Certificates
CE ........................................................ 11
RoHS ................................................... 11
WEEE .................................................. 11
Contact .................................................... 11
Contents .................................................. 12
Conventions ............................................... 5
D
Defective Parts/Modules ........................... 8
Dimensions .............................................. 21
E
Environmental Conditions .................. 13, 21
F
Feature Summary ...................................... 6
First Aid ..................................................... 9
Fuses ....................................................... 21
I
Intended Operation .................................. 10
S
Sample Rate ............................................ 21
Signal Routing
Examples ............................................. 19
Single-/Multi-mode .................................. 12
Support .................................................... 20
T
Technical Data .......................................... 21
Troubleshooting ....................................... 20
U
Updates ................................................... 10
W
Warranty .................................................. 10
page 23 of 24
SPLIT.CONVERTER Manual - Version 2.0
Notes
DirectOut GmbH T: +49-3727-5665-100
F: +49-3727-5665-101 www.directout.eu
Leipziger Strasse 32 09648 Mittweida Germany
Loading...
