OWNER’S GUIDE
MODEL
3203
Congratulations
Congratulations on the purchase of your state-of-the-art security system. Reading this owner’s guide prior to using your system will help maxi­mize the use of your system and its many features. For more informa­tion please visit the below website:
http://www.viper.com – For general and additional guide infor­mation.
For any additional questions please contact your authorized Directed dealer or contact Directed at 1-800-753-0600.
What you get
Welcome to the best generation of vehicle security. Your system con­tains everything you need.
Responder LE remote controls 1-way companion remote controls This owner’s guides Quick reference cards Warranty cards
AUX AUX
Owner’s
Guide
Quick
Reference Card
Warranty
Card
G3203V 2009-11
Important information
Your Warranty
Your system comes with a warranty. Please make sure you receive the warranty registration card and proof of purchase from your dealer indicating the product was installed by an authorized Directed dealer. Your product warranty must be validated within 10 days of purchase. You can validate it online at www.prodregister.com/directed or com- plete and return the warranty registration card.
Quick Reference Card
Carry this card with you to reference your system’s many features.
Replacement Remote Controls
If additional remote controls are desired, please see your authorized dealer or visit us at www.directedstore.com to order. Part numbers are: 7251V for Responder LE 2-way remote control and 7153V for the 1-way companion remote control.
Contents
Getting Started .................................................................................................... 3
Keys to using this manual ...................................................................... 3
Responder LE 2-Way ...........................................................................................4
Using your System ............................................................................................... 6
Commands and Confirmations .............................................................. 6
Performing Commands ......................................................................... 6
Remote Control Command table ............................................................ 7
Basic Commands (Direct Access) ..........................................................................8
Arm ................................................................................................... 8
Disarm ............................................................................................... 8
Remote Start /AUX1/AUX4 .................................................................. 9
AUX/Trunk .......................................................................................... 9
Advanced Commands: (Level 1) .........................................................................10
Silent Arm ......................................................................................... 10
AUX 1 .............................................................................................. 10
Advanced Commands: (Level 2) .........................................................................11
Sensor Bypass ................................................................................... 11
Remote Valet .................................................................................... 11
AUX 2 .............................................................................................. 12
Arm Status ........................................................................................ 12
Advanced Commands: (Level 3) .........................................................................13
Sensor Silent Arm* ............................................................................ 13
AUX 3 .............................................................................................. 13
Advanced Commands: (Level 4) .........................................................................14
Full Silent Arm* ................................................................................. 14
AUX 4 .............................................................................................. 14
Remote Control Configuration ............................................................................15
Remote Programming ......................................................................... 15
Pairing a 1-way or 2-way remote control ............................................. 15
Remote Features ............................................................................... 16
Car 2 ............................................................................................... 18
Remote Beep ..................................................................................... 19
Sensor Adjust .................................................................................... 19
Alarm Features .................................................................................................20
Normal Arm Protection ....................................................................... 20
Sensor Silent Arm protection ............................................................... 20
Full Silent Arm Protection .................................................................... 21
Sensor Warn-away ........................................................................... 21
Full Trigger ........................................................................................ 21
Emergency Override .......................................................................... 21
Trigger Zone Fault Report.................................................................... 22
Alarm Report ..................................................................................... 22
Nuisance Prevention (NPC) ................................................................. 23
Remote and System Operations ..........................................................................24
Passive Arming* ................................................................................ 24
Auto Re-arming* ................................................................................ 24
Valet Mode ....................................................................................... 25
Power Save ....................................................................................... 25
Rapid Resume ................................................................................... 25
Automatic Remote Updates ................................................................. 25
Out of Range .................................................................................... 26
No Remote Output ............................................................................. 26
Car Select ......................................................................................... 26
Vehicle Recovery System (VRS) ............................................................ 27
System Expansion Options .................................................................................28
Battery Information ............................................................................................30
Low Battery ....................................................................................... 30
Battery Life ........................................................................................ 30
Battery Disposal ................................................................................ 32
Glossary of Terms .............................................................................................. 33
Government Regulations .................................................................................... 34
Additional Information ....................................................................................... 35
Interference ....................................................................................... 35
Upgrades ......................................................................................... 35
Water/Heat Resistance ...................................................................... 35
Limited lifetime consumer warranty ..................................................................... 36
Getting Started
Keys to using this manual
Specific actions (in bold type) and style conventions are used consis­tently throughout this manual, they are as follows:
Press: s implies pushing in and releasing a button. Hold: s is used after “press” actions when a button needs to be
held in position for an extended period of time, typically several seconds. Italicizeds words denote section/sub headings in this guide and can be located through the table of contents. An asterisk (*) when used after a word or phrase denotes that s additional details can be found in related sections usually noted at the bottom of the page or end of the section. Ghost LED’s are identified by the command/function button they s are associated with.
© 2009 Directed Electronics. All rights reserved.
3
Responder LE 2-Way
Internal
Antenna
Transmit
LED
Ghost
LED’s
AUX
Feature Description
Internal Antenna Used for transmitting and receiving* information
Command Buttons (4) Used to perform arming, disarming, and auxiliary channel
commands.
Function Button Used to access function levels for commands, configuration
menus for programming, and car selection.
Ghost LED’s ** Each button has an associated LED next to it that are active
during related operations. These LED’s are labeled respec­tively as:
arm LED, disarm LED, rs/aux LED, aux LED, and
Command
Buttons
Function
Button
LED
* 2-way communication is only applicable to the Responder LE
remote control
** Term denotes that these LED’s are only visible when on (Ghost
LED’s are only applicable to the Responder LE remote control).
4
© 2009 Directed Electronics. All rights reserved.
Control Center
Control Center Button
Control Center LED
The control center, typically located on the upper part of the front windshield sends and receives commands or messages to and from your system. It consists of:
The In-vehicle system antenna, for 2 way communication. s The control center LED, as a visual indicator of the system’s sta-s tus. The control center button, for placing the system into valet mode* s and to perform the emergency override** operation.
* See Remote and System Operations section for details. ** See
Alarm Features for details.
© 2009 Directed Electronics. All rights reserved.
5
Using your System
Commands and Confirmations
Commands, basic or advanced, are used to activate system features and are performed by pressing one of the command buttons. Ba­sic commands control the most often used security features while ad­vanced commands control more specialized features.
Confirmations for basic or advanced commands are indicated first by siren chirps and parking light flashes, and then by illuminated Ghost LED’s and beeps or tones on the remote control. A description of each feature confirmation is found in the Basic Commands and Advanced Commands sections.
Performing Commands
Perform basic commands by pressing a command button (Ghost LED’s are off). Perform advanced commands by first accessing Levels 1-4 using the
button and then by pressing a command button while within a
Level (Levels are indicated by illuminated ghost LED’s after pressing
button).
Advanced Command example: Silent Arm
Press1. the
LED turns on. Press2. the silent arm command. The Arm LED will illuminate to confirm when the silent arm mes-3. sage from the system is received.
button once to access function level 1, the
button while the LED is still on to perform the
6
© 2009 Directed Electronics. All rights reserved.
Remote Control Command table
Direct Access
Level
Button
Arm/Lock
(Panic)
Disarm/Unlock Silent Disarm Remote Valet Car Finder
Remote Start*/
Aux 1/4**
Aux/Trunk AUX 1 AUX 2 AUX 3 AUX 4
AUX
x 1
LEVEL 1
Silent Arm Sensor
LEVEL 2
Bypass
x 2
x 3
LEVEL 3
Sensor Silent
Arm
x 4
LEVEL 4
Full Silent
Arm
Advance Level,
Change Car
(3 sec), Enter
programming
(8 sec)
Arm
Status ***
* Available only with optional remote start module installation ** This button can command either aux 1 or aux 4 if turned on by
an authorized Directed dealer.
*** Not available for the 1-way companion remote control.
© 2009 Directed Electronics. All rights reserved.
7
Basic Commands (Direct Access)
No ghost LED’s on
Arm
Press and release
The alarm arms, doors lock (if connected), and the siren chirps and parking lights flash once. The arm LED and beeps play to confirm. If valet mode* is on, the doors lock and the arm LED, tone plays. Exit valet mode to arm the alarm normally.
If a trigger zone fault is detected the siren chirps once again and the remote will emit a trigger zone fault report**, the arm LED, a fault tone plays.
To Arm and Panic
Press and hold
The alarm arms (or locks in valet) and, after 2 seconds, sounds
the siren and flashes the parking lights. The ghost LED’s flash and
siren tones play to confirm. Press the
output.
or button to stop the
Disarm
Press and release
LED and a fault
LED and
The alarm disarms, doors unlock (if connected), and the siren chirps and parking lights flash twice. The disarm LED and beeps play to confirm. If valet mode* is on, the doors unlock and the disarm LED,
LED and fault tones play.
8
© 2009 Directed Electronics. All rights reserved.
An alarm report** will replace the disarm output if the alarm was trig­gered; the siren will chirp 4 or 5 times, and the disarm LED,
LED
and 4 or 5 fault tones play to alert of the report.
Remote Start /AUX1/AUX4
Press and release
Remote Start***
Activates (or if on, deactivates) the remote starter. The engine and parking lights turn on or off accordingly. The rs/aux LED and on tones play, or the rs/aux LED and off tones play to confirm.
AUX1/AUX4****
Activates (or if on, deactivates) the aux 1or aux 4 output. The aux LED and on tones or off tones play to confirm.
AUX/Trunk
Press and hold AUX
The Trunk opens (if connected) when this button is pressed for 2 sec­onds. The Aux LED and tones play to confirm.
* See Remote and System Operations for details. ** See Alarm Features for details.
*** Available only with optional Remote Start module installation. **** This feature must be turned on by an authorized Directed dealer.
© 2009 Directed Electronics. All rights reserved.
9
Advanced Commands: (Level 1)
Press and release the button 1 time. The LED illuminates indicat- ing Level 1 Note: The transmit LED on the 1-way remote will flash in groups of 1 to indicate level 1.
Silent Arm
Press and release
The alarm arms, doors lock (if connected), and the parking lights flash once. The arm LED turns on to confirm. valet mode* or trigger zone fault report** messages may be received.
Silent Disarm
Press and release
The alarm disarms, doors unlock (if connected), and the parking lights flash twice. The disarm LED turns on to confirm. The silent disarm out­put may be replaced by the alarm report**.
AUX 1
Press and release AUX
Activates (or if on, deactivates) the aux 1 output. The aux LED and on tones or off tones play to confirm.
* See Remote and System Operations section for details. ** See Alarm Features for details.
10
© 2009 Directed Electronics. All rights reserved.
Advanced Commands: (Level 2)
Press and release the button 2 times. The and aux LED’s illumi- nate indicating Level 2 Note: The transmit LED on the 1-way remote will flash in groups of 2 to indicate level 2.
Sensor Bypass
Press and release
Performing the sensor bypass command will incrementally bypass sen­sor operations and be confirmed as follows:
Warn-away Bypass:s The parking lights flash 2 times. The arm LED, 1 beep and 1 fault tone play to confirm. Sensors will be activated for full trigger levels of impact only. Warn-away & Full Trigger Bypass:s The parking lights flash 3 times. The arm LED, 1 beep and 2 fault tones play to confirm. Sensors will not be activated for any level of impact. Sensor Bypass Off:s The parking lights flash 1 time. The arm LED and 1 beep play to confirm. Sensors are fully operational.
Sensor bypass can only be performed when the system
Note
is armed. The alert when performing sensor bypass when the system is disarmed. Perform arm command any time to turn sensor bypass off.
LED and a long fault tone plays as an
Remote Valet
Press and release
Enters (or if on, exits) valet mode. The control center LED turns on and
© 2009 Directed Electronics. All rights reserved.
11
off accordingly. The disarm LED and valet beeps play (1 for on, 2 for off) to confirm.
AUX 2
Press and release AUX
Activates (or if on, deactivates) the aux 2 output. The aux LED and on tones or off tones play to confirm.
Arm Status
Press and hold the button
The remote will generate an output to display the systems arm status since its last update message or command operation. It will report status via ghost LED’s, beeps, and tones as described in this section for arm, disarm, valet mode arm, valet mode disarm, sensor silent arm, full silent arm.
12
© 2009 Directed Electronics. All rights reserved.
Advanced Commands: (Level 3)
Press and release the button 3 times. The , aux and rs/aux LED’s illuminate indicating Level 3. Note: The transmit LED on the 1-way remote will flash in groups of 3 to indicate level 3.
Sensor Silent Arm*
Press and release
The alarm arms, doors lock, and the siren chirps and parking lights flash 3 times. The arm LED, 1 beep and 3 fault tones play to con­firm.
Car finder
Press and release
The siren emits one long chirp and the parking lights flash for 10 sec­onds. The disarm LED and 1 beep play to confirm. The parking light flashes stop if armed or disarmed while car finder is in progress.
AUX 3
Press and release AUX
Activates (or if on, deactivates) the aux 3 output. The aux LED and on tones or off tones play to confirm.
* See Alarm Features for more details.
© 2009 Directed Electronics. All rights reserved.
13
Advanced Commands: (Level 4)
Press and release the button 4 times. The , aux, rs/aux and disarm LED’s illuminate indicating Level 4 Note: The transmit LED on the 1-way remote will flash in groups of 4 to indicate level 4.
Full Silent Arm*
Press and release
The alarm arms, doors lock, and the siren chirps and parking lights flash 4 times. The arm LED, 1 beep and 4 fault tones play to con­firm.
AUX 4
Press and release AUX
Activates (or if on, deactivates) the aux 4 output. The aux LED and on tones or off tones play to confirm.
* See Alarm Features for more details.
14
© 2009 Directed Electronics. All rights reserved.
Remote Control Configuration
Remote Programming
The Responder LE and 1-way companion remote controls have opera­tions that can be configured to a user’s personal preferences. The fol­lowing instruction will direct you through the available programming options for both remote controls.
To enter programming, press and hold the the remote emits one long beep and the transmit LED turns on to indi­cate the main menu is accessed.
To exit programming or go back to a previous menu, press and re­lease the back and when programming is exited the transmit LED turns off.
Note: The 1-way remote does not emit any confirmation beeps.
button. 1 short and 1 long beep is emitted for each step
button for 8 seconds,
Pairing a 1-way or 2-way remote control
Note: The remote control may or may not emit sounds during this operation.
Prepare the vehicle
Open1. a door. Turn2. the ignition On. Press3. and release then press and hold the control center button.
The control center LED flashes and siren chirps one time to con­firm the system is prepared.
Release4. the button and proceed below.
Note: Begin pairing within 60 seconds or the system will exit (indi-
cated by a long siren chirp) and need to be prepared again.
© 2009 Directed Electronics. All rights reserved.
15
Prepare the remote control
Select the desired car 1 (default) or car 2 operation before proceed­ing.
Press1. and hold the
button of the remote control for 8 seconds until the transmit LED turns on, and then release it (If programmed to operate two systems, ignore the Transmit LED flashes at 3 sec­onds). Press2. and hold the
button until the transmit LED flashes off
and on three times. Press3. and hold the
button until the siren emits one long chirp
to confirm Pairing. Note: 2-way remote controls MUST also emit a sequence of chimes to confirm pairing is successful. If not heard, make sure the system is still prepared and repeat step 3 until successful.
Remote Features
Press the button to access the remote operation features, 2 trans- mit LED flashes and 2 beeps indicate the remote features menu is accessed. Press the buttons indicated in the tables below to set the feature option.
Responder LE
The ghost LED’s next to the button indicate the feature settings.
Feature Button
Keypad Lock
Remote Beeps
Car 2
LED on LED off LED Flash LED Double
Press
Auto Off
Beeps On Beeps Off Triggers
only
Car 2 On Car 2 Off
Flash
16
© 2009 Directed Electronics. All rights reserved.
Feature Button
Page Mode
LED on LED off LED Flash LED Double
Press
Paging On Paging Off Power
AUX
Save1
Flash
Power Save 2
1-way companion remote control
The 1-way remote will flash the transmit LED to indicate the setting.
Feature Button Press LED on LED off
Keypad Lock
Auto Off
No function
Car 2
No function No function
Car 2 On Car 2 Off
Keypad Lock
Options: Off, Auto
When off, the buttons do not lock and always perform a command when pressed. When set to auto, the remote buttons lock after a 20 second lapse between buttons presses to prevent unintentional opera­tions. If a button is pressed when locked the play as an alert. To unlock the buttons, press the
button followed by the button.
The ghost LEDs flash and tones play to confirm unlocking.
Note: When the 1-way remote keypad is locked, the remote control appears to be non-operational. It will not transmit a command or il­luminate the transmit LED and needs to be unlocked to resume normal operation.
© 2009 Directed Electronics. All rights reserved.
LED and a fault tone
17
Auto unlocking
After turning the ignition off, a message to the Responder LE will unlock the keypad buttons until the next command is performed. If auto unlocking is not desired this message can be turned off by an authorized Directed dealer.
Page Mode
Options: Power Save 1, Power Save 2, On, Off
Paging is how the Responder LE remote monitors your system’s mes­sages. Power save extends battery life by turning paging off after 72 hours if the remote control is not used during this period. Just press any button to resume system monitoring. Power save 2 is for maximum bat­tery life and will monitor the system only when remote start has been activated. Caution: Use only with an optional remote start module connected. Alarm trigger messages will not be received when remote start is off. When set to on it wakes up every few seconds to listen for pages from the system. When set to off it does not wake up to receive alarm trigger pages.
Note: When off, responses are still received when a command is performed but alarm trigger pages will not be received.
Car 2
Options: Off, On
The Responder LE and 1-way companion remote controls can control two systems independently. When set to off, the car select feature is not available. When set to on the car select feature is enabled. See Car Select (under Remote and System Operations) for details on using a remote with 2 systems.
18
© 2009 Directed Electronics. All rights reserved.
Remote Beep
Options: On, Off, Triggers Only
The Responder LE will emit a beep as confirmation of button presses and command responses. When set to off, beeps are not emitted for any operations except programming. For triggers only, beeps will only be emitted for full trigger messages.
Sensor Adjust
The button is used for sensor adjustment, to avoid unintended alarm triggers; it is recommended that an authorized Directed dealer performs all sensor adjustments.
© 2009 Directed Electronics. All rights reserved.
19
Alarm Features
Normal Arm Protection
Control center LED: The control center LED flashes as a visual indicator that your vehicle’s security system is active.
Starter Kill: The Failsafe starter kill relay prevents the engine from starting
May require additional parts and installation
Note
Sensor triggers: The onboard shock sensor can distinguish minor im-
pacts from major impacts to the vehicle exterior. Minor impacts cause the system to emit a Warn-away output by chirping the siren and flashing the parking lights for 3 seconds. Major impacts caused for example by a forcible entry attempt, results in a Full Trigger output. The siren sounds and the parking lights flash for 30 seconds or longer. Full Triggers send a message to the remote control.
Point of entry triggers: Opening the hood or trunk causes a Full Trig­ger output, while opening a Door or turning on the Ignition causes the the siren to chirp 3 seconds before beginning the Full Trigger output. This 3 second delay allows time to disarm and silence the siren in case of accidental trigger. The Full Trigger message is still sent to the remote.
Sensor Silent Arm protection
Sensor Warn-away and Sensor Full Trigger activations only send mes­sages to the Responder LE remote control, while the parking light flash and siren outputs are defeated. Point of entry triggers will activate the parking light flash, siren, and send messages normally.
20
© 2009 Directed Electronics. All rights reserved.
Full Silent Arm Protection
Sensor Warn-away, Sensor Full Trigger and Point of Entry activations will only send messages to the Responder LE remote control, with park­ing light flash and siren outputs defeated.
Sensor Warn-away
When the system sensors detect a Warn-away trigger the siren chirps and parking lights flash for 3 seconds. No messages are sent to the Responder LE remote control for Warn-away triggers.
Full Trigger
An alarm Full Trigger will sound the siren and flash the parking lights for 30 seconds while sending a Full Trigger message to the remote control. The ghost LED’s flash and siren tones play for 30 seconds followed by an alert that consists of 1 long beep per minute for 10 minutes. To stop the output and alert, press a command button to perform a command, or Press the
button.
Emergency Override
The following procedure disarms the system when a programmed re­mote is not available. Number of presses__________
Turn1. the ignition On. Press2. the control button on the Control Center the correct
number of times (the default is 1 press). After a few seconds the siren output ceases and the system 3. is disarmed.
As a precaution, if programmed for Passive Arming or Auto
Note
re-arming the system should be placed into Valet Mode until a remote is available .
© 2009 Directed Electronics. All rights reserved.
21
Trigger Zone Fault Report
When armed by remote command the system runs a status check of the alarm trigger zones. Faulty zones (usually caused by dome light delay or open trunk) are bypassed and reported via the control center LED and remote, while all other trigger zones remain active and are monitored to protect the vehicle. Should a faulty zone self correct (dome light turns off) it becomes active and is then monitored normally. The siren chirps once again a few seconds following the arming chirps as an audible alert, the control center LED flashes in groups to indicate the zone number.
Alarm Report
If the alarm was triggered while armed, it will be reported when the alarm is disarmed via the remote control, siren chirps, parking light and control center LED flashes. The siren chirps 4 times (or 5 times if NPC On*), the parking lights flash 3 times, and the control center LED flashes in groups to indicate the last two zones that were triggered (see Table of Zones). The report output will repeat for each disarm operation until the ignition is turned on.
* See Nuisance Prevention (NPC) for more details.
22
© 2009 Directed Electronics. All rights reserved.
Table of Zones
Zone # (led flashes) Zone Name
1 Trunk
2 Shock Sensor
3 Door
4 Sensor 2
5 Ignition
6 Hood
7 Sensor 3
Nuisance Prevention (NPC)
NPC monitors all alarm zones and, if any are triggered excessively, bypasses them until corrected. If a point of entry (trunk, hood, door) is left open following a forced entry, it is bypassed. It becomes active again only after being closed. Bypassed sensors automatically reset after one hour and after the ve­hicle is driven. Disarming then re-arming the alarm does not reset bypassed sensors.
© 2009 Directed Electronics. All rights reserved.
23
Remote and System Operations
Passive Arming*
Park and exit the vehicle, after the doors are closed the Passive arming countdown begins. The control center LED flashes quickly and upon reaching 20 seconds the siren then chirps once. At 30 seconds the system arms itself. Anytime before the system arms you can re-enter the vehicle or open the trunk to load or unload items and, after closing passive arming resumes. To stay secure in case of accidental disarming of the system, if a door is not opened within 30 seconds the system re-arms itself and locks the doors.
Auto Re-arming*
Auto re-arm ensures the vehicle stays protected if it is not entered after disarming by remote control. After disarming by remote, the alarm automatically re-arms itself (and locks the doors if programmed on) in 30 seconds. Open any point of entry to stop the re-arm until the next disarm by remote.
Onetime Bypass*
Turn the ignition on for one to three seconds and then off. The siren chirps once to confirm one-time bypass is enabled. One-time bypass can be used to temporarily bypass the Passive arm­ing operation for one cycle. It also bypasses the comfort closure and auxiliary channel outputs programmed to activate when arming. After the next disarm all operations return to normal.
* These features must be turned on by an authorized Directed dealer.
24
© 2009 Directed Electronics. All rights reserved.
Valet Mode
Valet mode can be entered and exited by performing the remote valet command or manually using the vehicle key and the control button. When entered, the alarm functions are defeated while the conve­nience features still operate normally. Arm and disarm commands lock and unlock the doors. The Responder LE emits the arm in valet and disarm in valet output as described for arm and disarm in the Basic Commands section.
Use the following steps to manually enter and exit valet mode:
Turn1. the ignition switch on and then off Immediately 2. press and release the control button once The control center LED turns on when entering and off when exit-3. ing.
Power Save
To reduce power consumption the control center LED modifies its out­put if the vehicle is parked for an extended period. If armed, the flashing is reduced after 24 hours. When valet mode is on the control center LED will turn off after1 hour and will reset each time the ignition is turned off.
Rapid Resume
If power is ever disconnected by a mechanic or thief, the system will resume the state it was in at the time of disconnection, when power is reconnected.
Automatic Remote Updates
The system sends a silent message to all remote controls after any major action has occurred. When the remote receives this message it updates the arm status.
© 2009 Directed Electronics. All rights reserved.
25
Out of Range
Each time a command is performed the Responder LE will expect a command confirmation from the system. If a command confirmation is not received the plays as an alert.
and transmit LED’s flash and a long fault tone
No Remote Output
Occasionally when a command is performed the remote may not generate a command confirmation output or out of range output. This indicates that the system received the command but it was an incom­plete command (e.g. aux button pressed too short to activate the trunk release) or it was an illegal message (e.g. the command was cor­rupted due to local RF interference). These are temporary normal func­tions of the system and remote, perform the command again within 10 seconds to return to normal operation.
Car Select
Car 2 must first be turned on (See Remote Control Configuration sec­tion to turn on).
Press1. and hold the the transmit LED and beeps once or twice to indicate the selected car is 1 or 2. Release2. the LED and beeps continue to perform car select. Once the car is selected a command can be performed by pressing one of the command buttons.
Note: The 1-way remote does not emit any indication beeps. The transmit LED flashes once or twice to indicate car one or car two.
button for 3 seconds. The remote flashes
button, then press and release while the transmit
26
© 2009 Directed Electronics. All rights reserved.
Vehicle Recovery System (VRS)
In case your vehicle is stolen or carjacked, VRS sounds the siren and flashes the parking lights to persuade the thief to abandon the vehicle, and when the ignition is turned off, activates the starter kill to prevent the engine from restarting.
To arm VRS, perform the silent arm command while driving, or while the ignition is turned on. The siren chirps and parking lights flash once to confirm arming. The arm LED and beeps play to confirm arming.
If valet mode is on, the before arming VRS.
Once armed, VRS triggers if any door is opened then closed while the ignition remains on, and if the vehicle is parked while armed, VRS triggers when driving resumes. See trigger description below.
When triggered, the control center LED begins flashing after fifteen seconds. Within 45 seconds perform the silent arm command to dis­arm VRS. If not disarmed, the siren begins chirping for 60 seconds and then becomes a constant siren blast with flashing parking lights for several minutes. This output will continue and be repeated each time the ignition is turned on until VRS is disarmed.
To disarm, perform the silent disarm command anytime before VRS has been triggered, or within one minute after it has triggered and be­fore the siren begins to chirp. If not disarmed before the siren begins to chirp, the emergency override procedure must be used to disarm VRS.
LED and fault tone plays, exit valet mode
© 2009 Directed Electronics. All rights reserved.
27
System Expansion Options
Controlling Two Vehicles (Car Select)
The Responder LE and 1way companion remote can control systems in two different vehicles saving the need for multiple remote controls. This feature also allows for customized system configurations on each vehicle that has more than one driver. See following Owner Recogni- tion for details.
Owner Recognition
The system can be configured to recognize the remote used when disarming and change selected features to match the remote users preferences. Memory seat adjustment, siren chirps, passive arming, remote button auto unlocking, alarm output duration can all be custom set for each remote user at the time of installation.
Comfort Closure
Comfort closure emulates turning the key in the door cylinder or hold­ing the lock button of an OEM keyless entry. It will automatically close the windows and sunroof on vehicles with this type of OEM conve­nience feature.
Alarm Output Duration
The length of time the siren sounds can be adjusted from 1 to 180 seconds at the time of installation.
Arming and Warn-away Chirp Control
The system arm, disarm and sensor warn-away chirps can be config­ured for those that prefer a custom silent alarm operation.
28
© 2009 Directed Electronics. All rights reserved.
Driver Door Priority Unlocking
The door unlocking operation can be configured to emulate an OEM style of driver priority unlocking for added security during disarming.
© 2009 Directed Electronics. All rights reserved.
29
Battery Information
The Responder LE remote is powered by 2 batteries (PN CR-2016) and the 1-way companion remote by 1 battery (PN CR-2032), that can be purchased at most retailers. When the battery begins to weak­en, the operating range will be reduced. The information and precau­tions in this section can help maximize your battery’s life and usage in providing your Responder LE and 1-way companion remote controls with many years of trouble free operation.
Low Battery
After a command is performed the Responder LE and 1way com­panion remote controls check their battery level and, when the level requires attention, will begin generating alerts. Once the alerts begin, the remote controls will remain operational for several days but the battery/batteries should be replaced at the earliest opportunity or failure to control the system may occur.
Low Battery Alerts
When disarming the system using a remote with a low battery the siren will emit one additional chirp as an alert. If confirmation chirps are programmed off, the system will still emit one chirp as an alert when disarming. After performing a command, several beeps play on the Responder LE remote to indicate the battery/ batteries need replacing.
Battery Life
The Responder LE remote control has many features that make it one of the most unique remote controls on the market today. The default fea­ture settings provide for excellent battery life. However, to maximize this battery life, the following suggestions will help:
30
© 2009 Directed Electronics. All rights reserved.
Turn Paging off: The remote will not wake up to check for mes-s sages with paging off in the setup remote menu. Note: The remote will not receive trigger messages from the sys­tem. Turn Beeps off: The button beeps can be turned off in the setup s remote menu. The command beeps still play normally.
Responder LE Battery Replacement
Rear View
1 2
Battery
Cover
Battery
Clip
1. Slide the battery cover up by ap­plying equal pressure at its top and bottom (the arrow on the cover indi­cates the direction), remove the cover from the remote control housing.
+
2. Gently pry up on the battery (or batteries) to remove it from the holder.
Insert a new battery (or batteries) into the holder and under the clip with the positive (+) side up. Replace the battery cover. The remote control is now ready for use.
1-way Battery Replacement
Using a small 1. flathead screwdriver, insert into slot located at the bottom of the keypad and carefully pry the front of the unit open.
© 2009 Directed Electronics. All rights reserved.
31
Turn both the unit 2. front and circuit board over, remove battery from clip and replace while observing the correct po­larity.
With the front and circuit board still turned over, turn back portion 3. of unit onto both parts, reposition all parts and snap together.
Battery Disposal
Directed Electronics cares about the environment. If you need to dispose of the battery, please do so in accordance with your municipal requirements for battery disposal.
+
+
32
© 2009 Directed Electronics. All rights reserved.
Glossary of Terms
Document Terminology
Control Module The “brain” of your system. Usually hidden underneath the
dash area of the vehicle. It houses the microprocessor which monitors your vehicle and controls all of the system’s func­tions.
Responder LE (2-way Remote Control)
Companion Remote (1-way Remote Con­trol)
Control Center The control center contains the system’s radio-frequency anten-
Control Center LED A light used to indicate the status of your system. It is located
Control Center Button A small push button located on your system’s control center.
A hand-held, remote control which operates the various func­tions of your system and receives messages and pages from the system.
A hand-held, remote control which operates the various func­tions of your system but does not provide message display.
na, the control center button and LED. For maximum remote­control range, the control center is usually located at the top of the windshield, centered near the rear-view mirror.
on your system’s control center.
It is used to override (disarm) the alarm when a remote is not available or to enter or exit valet mode.
© 2009 Directed Electronics. All rights reserved.
33
Government Regulations
This device complies with Part 15 of FCC rules. Operation is subject to the fol­lowing two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesirable operation.
This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates and can radiate radio frequency en­ergy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television, which can be determined by turning the equipment OFF and ON, the user is encouraged to try to correct the interference by one or more of the following measures:
s2EORIENTORRELOCATETHERECEIVINGANTENNA s)NCREASETHESEPARATIONBETWEENTHEEQUIPMENTANDRECEIVER s#ONNECTTHEEQUIPMENTINTOANOUTLETONACIRCUITDIFFERENTFROMTHATTOWHICH
the receiver is connected.
s#ONSULTTHEDEALERORANEXPERIENCEDRADIO46TECHNICIANFORHELP
This device complies with the Industry Canada Radio Standards Specification RSS 210. Its use is authorized only on a no-interference, no-protection basis; in other words, this device must not be used if it is determined that it causes harmful interference to services authorized by IC. In addition, the user of this device must accept any radio interference that may be received, even if this interference could affect the operation of the device.
WARNING! Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this de­vice.
34
© 2009 Directed Electronics. All rights reserved.
Additional Information
Interference
All radio devices are subject to interference which could affect proper performance.
Upgrades
Any upgrades to this product must be performed by an authorized Directed dealer. Do not attempt to perform any unauthorized modifica­tions to this product.
Water/Heat Resistance
This product is not designed to be water and/or heat-resistant. Please take care to keep this product dry and away from heat sources. Any damage from water or heat will void the warranty.
© 2009 Directed Electronics. All rights reserved.
35
Limited lifetime consumer warranty
Directed Electronics. (“Directed”) promises to the original purchaser to repair or replace (at Directed’s election) with a comparable reconditioned model any Directed unit (hereaf­ter the “unit”), excluding without limitation the siren, the remote transmitters, the associated sensors and accessories, which proves to be defective in workmanship or material under reasonable use during the lifetime of the vehicle provided the following conditions are met: the unit was purchased from an authorized Directed dealer, the unit was profession­ally installed and serviced by an authorized Directed dealer; the unit will be professionally reinstalled in the vehicle in which it was originally installed by an authorized Directed dealer; and the unit is returned to Directed, shipping prepaid with a legible copy of the bill of sale or other dated proof of purchase bearing the following information: consumer’s name, telephone number and address; the authorized dealers name, telephone number and address; complete product description, including accessories; the year, make and model of the vehicle; vehicle license number and vehicle identification number. All com­ponents other than the unit, including without limitation the siren, the remote transmitters and the associated sensors and accessories, carry a one-year warranty from the date of purchase of the same. ALL PRODUCTS RECEIVED BY DIRECTED FOR WARRANTY REPAIR WITHOUT PROOF OF PURCHASE WILL BE DENIED. This warranty is non-transferable and is automatically void if: the original purchaser has not completed the warranty card and mailed it within ten (10) days from the date of purchase to the address listed on the card; the unit’s date code or serial number is defaced, missing or altered; the unit has been modified or used in a manner contrary to its intended purpose; the unit has been damaged by accident, unreasonable use, neglect, improper service, installation or other causes not arising out of defects in materials or construction. The warranty does not cover damage to the unit caused by installation or removal of the unit. Directed, in its sole discretion, will determine what constitutes excessive damage and may refuse the return of any unit with excessive damage.
TO THE MAXIMUM EXTENT ALLOWED BY LAW, ALL WARRANTIES, INCLUDING BUT NOT LIMITED TO EXPRESS WARRANTY, IMPLIED WARRANTY, WARRANTY OF MERCHANTABILITY, FITNESS FOR PARTICULAR PURPOSE AND WARRANTY OF NON-INFRINGEMENT OF INTELLECTUAL PROPERTY, ARE EXPRESSLY EXCLUDED; AND DIRECTED NEITHER ASSUMES NOR AUTHORIZES ANY PERSON OR ENTITY TO ASSUME FOR IT ANY DUTY, OBLIGATION OR LIABILITY IN CONNECTION WITH ITS PRODUCTS. DIRECTED DISCLAIMS AND HAS ABSOLUTELY NO LIABILITY FOR ANY AND ALL ACTS OF THIRD PARTIES INCLUDING ITS AUTHORIZED DEALERS OR INSTALLERS. DIRECTED SECURITY SYSTEMS, INCLUDING THIS UNIT, ARE DETERRENTS AGAINST POSSIBLE THEFT. DIRECTED IS NOT OFFERING A GUARANTEE OR INSURANCE AGAINST VANDALISM, DAMAGE OR THEFT OF THE AUTOMOBILE, ITS PARTS OR CONTENTS; AND HEREBY EXPRESSLY DISCLAIMS ANY
36
© 2009 Directed Electronics. All rights reserved.
LIABILITY WHATSOEVER, INCLUDING WITHOUT LIMITATION, LIABILITY FOR THEFT, DAMAGE AND/OR VANDALISM. THIS WARRANTY DOES NOT COVER LABOR COSTS FOR MAINTENANCE, REMOVAL OR REINSTALLATION OF THE UNIT OR ANY CONSEQUENTIAL DAMAGES OF ANY KIND. IN THE EVENT OF A CLAIM OR A DISPUTE INVOLVING DIRECTED OR ITS SUBSIDIARY, THE VENUE SHALL BE SAN DIEGO COUNTY IN THE STATE OF CALIFORNIA. CALIFORNIA STATE LAWS AND APPLICABLE FEDERAL LAWS SHALL APPLY AND GOVERN THE DISPUTE. THE MAXIMUM RECOVERY UNDER ANY CLAIM AGAINST DIRECTED SHALL BE STRICTLY LIMITED TO THE AUTHORIZED DIRECTED DEALER’S PURCHASE PRICE OF THE UNIT. DIRECTED SHALL NOT BE RESPONSIBLE FOR ANY DAMAGES WHATSOEVER, INCLUDING BUT NOT LIMITED TO, ANY CONSEQUENTIAL DAMAGES, INCIDENTAL DAMAGES, DAMAGE TO VEHICLE, DAMAGES FOR THE LOSS OF TIME, LOSS OF EARNINGS, COMMERCIAL LOSS, LOSS OF ECONOMIC OPPORTUNITY AND THE LIKE. NOTWITHSTANDING THE ABOVE, THE MANUFACTURER DOES OFFER A LIMITED WARRANTY TO REPLACE OR REPAIR THE CONTROL MODULE SUBJECT TO THE CONDITIONS AS DESCRIBED HEREIN. THIS WARRANTY IS VOID IF THE UNIT HAS NOT BEEN PURCHASED FROM DIRECTED, OR AN AUTHORIZED DIRECTED DEALER, OR IF THE UNIT HAS BEEN DAMAGED BY ACCIDENT, UNREASONABLE USE, NEGLIGENCE, ACTS OF GOD, NEGLECT, IMPROPER SERVICE, OR OTHER CAUSES NOT ARISING OUT OF DEFECT IN MATERIALS OR CONSTRUCTION.
Some states do not allow limitations on how long an implied warranty will last or the exclusion or limitation of incidental or consequential damages. This warranty gives you specific legal rights and you may also have other rights that vary from State to State. This warranty is only valid for sale of product(s) within the United States of America. Product(s) sold outside of the United States of America are sold “AS-IS” and shall have NO WARRANTY, express or implied. This product may be covered by a Guaranteed Protection Plan (“GPP”). See your authorized Directed dealer for details of the plan or call Directed Customer Service at 1-800-876-0800. Make sure you have all of the following information from your authorized Directed dealer:
A clear copy of the sales receipt, showing the following:
Date of purchases Your full name and addresss Authorized dealer’s company name and addresss Type of alarm installeds Year, make, model and color of the automobiles Automobile license numbers Vehicle identification numbers All security options installed on automobiles Installation receiptss
920-0003 06-06
Loading...
