Directed Electronics SMARTSTART 3000 User Manual

3000

OOwwnneerr’’ss GGuuiiddee

limited lifetime consumer warranty

For a period of one calendar year from the date of purchase of this auto-security device, Directed Electronics promises to the ORIGINAL PURCHASER to repair or replace (with a comparable reconditioned model), free of cost, any electronic control module which proves to be defective in workmanship or material under normal use, SO LONG AS THE SYSTEM WAS SOLD, INSTALLED, AND SERVICED BY A PROFESSIONAL AUTO INSTALLER, AND REMAINS IN THE CAR IN WHICH THE SYSTEM WAS ORIGINALLY INSTALLED. If warranty service is necessary you must have a clear copy of your sales receipt containing all of the information shown on the following page.

After the first calendar year, from the date of purchase of this auto-security device, Directed Electronics promises to the ORIGINAL PURCHASER to repair or replace (with a comparable reconditioned model) any electronic control module which proves to be defective in workmanship or material under normal use FOR A CHARGE OF $45.00, SO LONG AS THE SYSTEM WAS SOLD, INSTALLED, AND SERVICED BY A PROFESSIONAL AUTO INSTALLER, AND REMAINS IN THE CAR IN WHICH THE SYSTEM WAS ORIGINALLY INSTALLED. If warranty service is necessary you must have a clear copy of your sales receipt containing all of the information shown on the following page.

This warranty contains the entire agreement relating to warranty and supersedes all previous and contemporaneous representations or understandings, whether written or oral. IN ANY EVENT, DIRECTED ELECTRONICS IS NOT LIABLE FOR THE THEFT OF THE VEHICLE AND/OR ITS CONTENTS. This warranty is void if the product has been damaged by accident, unreasonable use, neglect, improper service or other causes not arising out of defects in materials or construction. This warranty is nontransferable and does not apply to any unit that has been modified or used in a manner contrary to its intended purpose and does not cover batteries. The unit in question must be returned to the manufacturer, postage prepaid. This warranty does not cover labor costs for the removal, diagnosis, troubleshooting or reinstallation of the unit. For service on an out-of-warranty product a flat rate fee by model is charged. Contact your authorized dealer to obtain the service charge for your unit.

These systems are a deterrent against possible theft. Directed Electronics is not offering a guarantee or insuring against the theft of the automobile or its contents and disclaims any liability for the theft of the vehicle and/or its contents. Directed Electronics does not authorize any person to create for it any other obligation or liability in connection with this security system.

TO THE MAXIMUM EXTENT ALLOWED BY LAW, ANY AND ALL WARRANTIES ARE EXCLUDED BY THE MANUFACTURER AND EACH ENTITY PARTICIPATING IN THE STREAM OF COMMERCE THEREWITH. THIS EXCLUSION INCLUDES BUT IS NOT LIMITED TO THE EXCLUSION OF ANY AND ALL WARRANTY OF MERCHANTABILITY AND/OR ANY AND ALL WARRANTY OF FITNESS FOR A PARTICULAR PURPOSE AND/OR ANY AND ALL WARRANTY OF NON-INFRINGEMENT OF PATENTS, IN THE UNITED STATES OF AMERICA AND/OR ABROAD. NEITHER THE MANUFACTURER OR ANY ENTITIES CONNECTED THEREWITH SHALL BE RESPONSIBLE OR LIABLE FOR ANY DAMAGES WHATSOEVER, INCLUDING BUT NOT LIMITED TO ANY CONSEQUENTIAL DAMAGES, INCIDENTAL DAMAGES, TOWING, REPAIR, REPLACEMENT, DAMAGES FOR LOSS

OF TIME, LOSS OF EARNINGS, COMMERCIAL LOSS, LOSS OF ECONOMIC OPPORTUNITY AND THE LIKE. NOTWITHSTANDING THE ABOVE, MANUFACTURER DOES OFFER A LIMITED WARRANTY TO REPLACE OR REPAIR THE CONTROL MODULE AS DESCRIBED ABOVE. Some states do not allow limitations on how long an implied warranty will last or the exclusion or limitation of incidental or consequential damages. This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.

IMPORTANT NOTE:

This product warranty is automatically void if its date code or serial number is defaced, missing, or altered. This warranty will not be valid unless you have completed the warranty card and mailed it to Directed Electronics within 10 days after purchase to the address listed on the warranty registration card.

Make sure you have all of the following information from your dealer:

A clear copy of the sales receipt, showing the following:

Date of purchase

Your full name and address

Authorised dealer's company name and address

Type of alarm installed

Year, make, model and colour of the vehicle

Vehicle registration number

Vehicle identification number

All security options installed on vehicle

Installation receipts

trademarks and copyrights

Bitwriter®, Clifford®, Code-Hopping®, Directed®, Doubleguard®, ESP®, FailSafe®, Ghost Switch™, Learn Routine

™

, Nite-Lite®, Nuisance Prevention

Circuitry, NPC®, Revenger®, Silent Mode™, Soft

Chirp

, Stealth Coding™, Stinger®, Valet®, Vehicle Recovery SystemTM, VRS®, and Warn Away

are all Trademarks or Registered Trademarks of Directed Electronics.

limited lifetime consumer

warranty . . . . . . . . . . . . . . . . . . . . .i

trademarks and copyrights . . . . .ii

table of contents . . . . . . . . . . . . .1

what is included . . . . . . . . . . . . . .2

important information . . . . . . . . .2

your warranty . . . . . . . . . . . . .3

remote configurations . . . . . . . . .4

standard configuration for

in-key 2-button remote . . . . . .5

standard configuration for

3-button remote . . . . . . . . . . .5

using your system . . . . . . . . . . . . .6

arming . . . . . . . . . . . . . . . . . . .6

disarming . . . . . . . . . . . . . . . . .8

disarming without a remote . . .8

auto-immobilisation . . . . . . . . .9

remote siren silencing . . . . . . .9

remote chirp muting

(3-button remote only) . . . . . .10

remote sensor disable . . . . . .11

remote start sensor bypass . . .11

auxiliary channel bypass . . . . .12

valet mode . . . . . . . . . . . . . . .12

remote valet mode . . . . . . . . .13

instant auto-arming bypass . .14

nuisance prevention® circuitry14

multiple event total recall . . . .15

battery back-up siren . . . . . . . . .15

diagnostics . . . . . . . . . . . . . . . . . .16

arming diagnostics . . . . . . . . .16

disarming diagnostics . . . . . . .17

arm/disarm diagnostic chart . .17

table of zones . . . . . . . . . . . .18

high frequency . . . . . . . . . . . . . .19

rapid resume logic . . . . . . . . . . .19

power saver mode . . . . . . . . . . .20

system sensors and adjustments 20

programming options . . . . . . . .21

manual programming

instructions . . . . . . . . . . . . . .22

user selectable features . . . . .24

user selectable features

descriptions - column one . . .24

user selectable features

descriptions - column two . . .26

user selectable features

descriptions - column three . .27

pin programming . . . . . . . . . .29

glossary of terms . . . . . . . . . . . . .31

security & convenience

expansions . . . . . . . . . . . . . . . . . .32

quick reference guide . . . . . . . .33

table of contents

what is included

One control module/siren with built-in Tilt sensor and 24 pin main wiring harness (attached)

One Mini-Blue status LED

One 2-button Valet switch

One in-key 2-button remote

One 3-button remote

Two Merlin decal’s

This Owner’s Guide

Warranty Card

important information

Congratulations on the purchase of your state-of-the-art motorcycle

security system. It has been designed to provide years of trouble-free

operation. This system must be installed by an authorised dealer.

Installation of this product by anyone other than an authorised dealer

voids the warranty. As verification of authorization, all authorised deal-

ers are provided with preprinted dealer certificates.

In order to maximize the use of this system, please review this owner's

guide carefully prior to using your system. You can print additional or

replacement copies of this owner’s guide by accessing the Directed

website at www.directed.com.

nnoottee::

Your system MUST be installed by an Authorised dealer in accordance with the instructions we supply them. The Merlin 3000 system is designed to be installed on any 12-volt, negative ground motorcycle or moped.

system maintenance

The system requires no specific maintenance. The batteries in your

remotes will last approximately one year under normal use. Your 3-but-

ton remote is powered by a miniature 3V lithium battery (CR2032). Your

in-key 2-button remote is powered by a 12V miniature battery (type

27A).

your warranty

It is necessary to retain your sales receipt, which reflects that the prod-

uct was installed by an authorised dealer. For full details regarding your

warranty coverage, please refer to the consumer warranty section of

this guide.

nnoottee::

Other than the remote controls, this system has no user-service-

able parts. Your authorized dealer can correct any system wiring problems and, if needed, can return any malfunctioning component to Directed Electronics for repair/replacement under the terms of the Limited Lifetime Warranty printed at the beginning of this guide.

remote configurations

The 3000 system has an in-key 2-button remote control and a 3-button

remote control. Two additional Merlin remote controls can be added.

IN-KEY 2-BUTTON REMOTE CONTROL

FRONT REAR

LED

ACCESSORY

RM/DISARM/PANIC

3-BUTTON REMOTE CONTROL

LED

RM/DISARM/PANIC

ACCESSORY

SILENT ARM/DISARM

remote functions

This system uses computer-based code learning to learn the remote buttons. This makes it possible to assign any remote button to any system function. The remotes initially come programmed with standard configuration. The buttons in all of the instructions in this manual correspond to a standard configuration remote.

standard configuration for in-key 2-button remote

Button

The arming, disarming, and panic functions are controlled by this button.

Button

An optional accessory convenience or expansion function that you have

added to your system can be activated by pressing this button.

and Buttons

When pressed together, these buttons disable the on-board control

module tilt sensor and any optionally installed sensors.

standard configuration for 3-button remote

Button

The arming, disarming, and panic functions are controlled by this button.

Button

An optional accessory convenience or expansion function that you have

added to your system can be activated by pressing this button.

Button

Silent arm and disarm is controlled by this button.

and Buttons

When pressed together, these buttons disable the on-board control

module tilt sensor and any optionally installed sensors.

and Buttons

Remotely enters or exits Valet.

using your system

The buttons used in the instructions in this manual correspond to the

standard remote configuration. If your remote has been custom con-

figured, the icons on your remote buttons may not correspond to the

indicated functions.

arming

You can activate, or arm, the system by pressing on your remote

for one second. When the system arms, you will hear one short siren

sound, or chirp, and see the parking lights flash once. The LED will illu-

minate steadily.

While the system is armed, the LED status indicator will flash approximately once per second showing that the system is actively protecting your vehicle. If you hear more than one chirp when arming, refer to the Diagnostics section of this guide. These extra chirps confirm a malfunction autobypass.

The security system also can be programmed to arm itself automatically without a remote (called passive arming). If the system is programmed for passive arming, it will automatically arm 30-seconds after the ignition is turned off. Whenever the system is in its 30-second passive-arming countdown, the siren will chirp once and the lights will flash once five seconds after countdown has commenced. This is indicated by the rapid flash from the status LED. The system is not actually armed at that point. The system arms after the 30-second countdown has elapsed, but the siren will not chirp. The early chirps provide you with a 25-second warning prior to arming.

When armed, your vehicle is protected as follows:

The LED will flash as a visible theft deterrent.

If the tilt sensor detects the motorcycle is being moved in an attempt to steal it, the system will immediately trigger the siren and flash the indicator lights.

This sensor is capable of independently learning the bike’s initial angles of vertical and horizontal inclination each time it is parked, ensuring the most accurate tilt (vertical and horizontal) sensing possible.

If a protected switch is opened, the system will immediately trigger the siren and flash the indicator lights.

The immobiliser prevents the motorcycle’s engine from starting.

nnoottee::

If one of the zone 4 or 5 switch inputs is active or the ignition is on, the system will not passively arm. Additionally, if one of these switches is activated or the ignition is turned on, the countdown will cease, then begin again when the input is removed.

disarming

To disarm the system, press . You will hear two chirps and the

parking lights will flash twice. If the siren chirps four times when disarm-

ing, refer to the Diagnostics section of this guide. This is called Tamper

Alert. If the siren is active (sounding) when the system is disarmed you

will hear three chirps but the system is not disarmed. (Refer to the

Remote Siren Silencing section of this guide.) However, if the alarm com-

pletes the full trigger cycle when disarmed you will hear four chirps.

disarming without a remote

This feature allows you to disarm the system without the remote should

it be lost, damaged, or disabled. In order to disarm without a remote,

you must have the motorcycle’s ignition key, know where the Valet

switch is located, and have the PIN code. Be sure to check with the

installer for the location of the Valet switch.

Turn the ignition On and then enter the PIN code as given in the fol-

lowing example to disarm without a remote.

1. Find the preset PIN code given in this manual.

FOR EXAMPLE: To disarm first enter a PIN code of 4301.

2. Turn the ignition On.

3. Press four times.

4. Then once. This enters the digit 4.

5. Then three times.

6. Then once. This enters the digit 3.

7. Then once. This enters a 0 as there was not a previous digit entered with .

8. Then once.

9. Then once. This enters the final digit 1.

auto-immobilisation

Immobiliser circuits automatically activate after 30-seconds.

Auto-immobilisation sequence:

1. Turn ignition off or disarm alarm.

2. After 30-seconds the systems Immobilisation circuits activate and engage the starter and engine interrupts.

3. LED flashes at ½ normal speed.

Disarm the system when immobilised:

Use one of the following methods to turn off auto-immobilisation.

Turn ignition on and press the button of the transmitter.

Arm the alarm and then disarm the alarm.

Turn the ignition on and enter the system Valet/PIN code.

remote siren silencing

Remote siren silencing is a feature that makes it possible to silence and

reset the system when it is triggering without disarming the system. If

the system is triggered and the siren is sounding, press on the

remote to stop the trigger and return the unit to the armed state. The

system will not disarm, but rather reset. This prevents you from dis-

abling the system should you wish to silence it without visually check-

ing the vehicle. After resetting the system, press again to disarm

the system.
