Directed Electronics OHDW17.2 User Manual

17” (16:9) Overhead Video Monitor/DVD Player

MODEL OHDW17.2

OWNER’S GUIDE

INSTALLATION GUIDE

NON-TRANSFERABLE LIMITED ONE YEAR CONSUMER WARRANTY

Directed Electronics (Directed) promises to the original purchaser that the new automotive video monitor and/or source unit(s) (the Product) that is purchased and installed from a Directed authorized dealer more than ninety (90) days after the purchase of a new vehicle are warranted for a period of one (1) year from date of purchase of the Product.

Directed promises to the original purchaser that all video accessories will be free from defects in materials and workmanship under normal use and condition for a period of ninety (90) days after the date of purchase. A sales receipt and/or warranty registration card is required to provide proof of date of purchase of the Product or accessories.

Should the Product be determined defective during the applicable warranty period, the defect(s) will be repaired or replaced with a new or reconditioned part(s), at Directed’s option. To obtain warranty service, the Product must be returned to a Directed authorized dealer along with proof of purchase and installation.

Note: This warranty does not cover labor costs for the removal and reinstallation of the Product. IN ORDER FOR THIS WARRANTY TO BE VALID, YOUR PRODUCT MUST BE SHIPPED WITH PROOF OF PURCHASE AND INSTALLATION BY AN AUTHORIZED DIRECTED DEALER. ALL PRODUCTS RECEIVED BY DIRECTED FOR WARRANTY REPAIR WITHOUT PROOF OF DIRECTED DEALER INSTALLATION WILL BE DENIED.

This warranty is non-transferable and does not apply to any Product that has been modified or used in a manner contrary to its intended purpose, and does not cover damage to the Product caused by installation or removal of the Product. This warranty is VOID if the product has not been purchased from an authorized Directed dealer or has been damaged by accident or unreasonable use, negligence, acts of God, neglect, improper service or other causes not arising out of defect in materials or construction. This warranty does not cover the elimination of externally generated static or noise, or the correction of antenna problems or weak television reception, damage to tapes, video games, software, camcorders, discs, speakers, accessories or vehicle electrical systems, cosmetic damage or damage due to negligence, misuse, abuse, failure to follow operating instructions, accidental spills or customer applied cleaners, damage due to environmental causes such as floods, airborne fallout, chemicals, salt, hail, windstorms, lightning or extreme temperatures, damage due to accidents, road hazards, fire, theft, loss or vandalism, damage due to improper connection to equipment of another manufacturer, modification of existing equipment, damage caused by faulty media or the cleaning of components, or Product which has been opened or tampered with for any reason or which has been damaged due to alteration or service performed by anyone other than Directed Electronics.

ALL WARRANTIES INCLUDING BUT NOT LIMITED TO EXPRESS WARRANTY, IMPLIED WARRANTY, WARRANTY OF MERCHANTABILITY, FITNESS FOR PARTICULAR PURPOSE, AND WARRANTY OF NON-INFRINGEMENT OF INTELLECTUAL PROPERTY ARE EXPRESSLY EXCLUDED TO THE MAXIMUM EXTENT ALLOWED BY LAW, AND DIRECTED NEITHER ASSUMES NOR AUTHORIZES ANY PERSON TO ASSUME FOR IT ANY LIABILITY IN CONNECTION WITH THE SALE OF THE PRODUCT. DIRECTED HAS ABSOLUTELY NO LIABILITY FOR ANY AND ALL ACTS OF THIRD PARTIES INCLUDING ITS LICENSED DEALERS OR INSTALLERS. IN NO EVENT WILL DIRECTED ELECTRONICS, INC. BE LIABLE FOR ANY INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES (INCLUDING LOSS OF PROFITS), BY PURCHASING THIS PRODUCT, THE CONSUMER AGREES AND CONSENTS THAT ALL DISPUTES BETWEEN THE CONSUMER AND DIRECTED SHALL BE RESOLVED IN ACCORDANCE WITH CALIFORNIA LAWS IN SAN DIEGO COUNTY, CALIFORNIA.

Some states do not allow limitation on how long an implied warranty lasts. In such states, the limitations or exclusions of this Limited Warranty may not apply. Some states do not allow the exclusion or limitation of incidental or consequential damages. In such states, the exclusion or limitation of this Limited Warranty may not apply to you.This Limited Warranty gives you specific legal rights, and you may have other rights which vary from state to state.

Some states do not allow the exclusion or limitation of incidental or consequential damages. In such states, the exclusion or limitations of this Limited Warranty may not apply to you. This Limited Warranty gives you specific legal rights and you may have other rights which vary from state to state.

Table of Contents

Non-Transferable Limited One Year Consumer Warranty . . . . . . . . . . . . . . . . . . .2

Safety Instructions and Cautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Welcome . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

What’s Included . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Important . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

When Cleaning the Vehicle .............................................................................6

While Driving ...............................................................................................6

When Parked ................................................................................................7

Proper Use ...................................................................................................7

Disc Handling and Cleaning ............................................................................7

Repairs........................................................................................................7

Radio/TV Tuner Use .......................................................................................7

Installation..................................................................................................7

Picture Quality..............................................................................................8

Important Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

FCC Notice ...................................................................................................8

Your Warranty ...............................................................................................8

Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Monitor .......................................................................................................9

DVD—Mounted............................................................................................10

DVD—UnMounted........................................................................................12

DVD—Memory Card Mounting ........................................................................13

DVD Player—Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

DVD Player—Removal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

Setting the Screen Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

Remote Control Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

Remote Buttons ..........................................................................................16

IR Remote Feedthrough................................................................................17

Battery Replacement....................................................................................18

Precautions ................................................................................................18

Loading and Unloading Discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

Loading Disc...............................................................................................18

Unloading Disc............................................................................................19

Operating the Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

Open/Close the Display Monitor.....................................................................20

Power Up/Down the Display Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

P (Picture-In-Picture/Split Screen).................................................................21

Source (Mode) ............................................................................................21

Menu (Console Menu)...................................................................................22

Door Light On/Off .......................................................................................22

Courtesy Light On/Off ..................................................................................22

Basic Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

DVD Playback..............................................................................................23

Play/Pause (DVD/MP3/CD) ............................................................................24

Stop (DVD/MP3/CD).....................................................................................24

Selecting a Track or Chapter..........................................................................25

MP3 and JPEG Playback on CD or Memory Card ................................................25

Playback Programming .................................................................................26

Advanced Playback (DVD/MP3/CD) .................................................................27

Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28

Accessing Setup Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28

System Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

1. TV System .............................................................................................29

2. Screen Saver..........................................................................................29

3. TV Type.................................................................................................30

4. Password...............................................................................................30

5. Rating (Parental Settings)........................................................................30

6. Default .................................................................................................31

7. Exit ......................................................................................................31

Language Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31

1. OSD Language........................................................................................31

2. Audio Lang............................................................................................31

3. Subtitle Lang.........................................................................................32

4. Menu Lang.............................................................................................32

Installation Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32

Precautions ................................................................................................32

Electrical Connections ..................................................................................33

Signal Connection........................................................................................34

Typical Wiring Diagram.................................................................................35

Installation Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36

System Wiring Diagram Example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41

Safety Instructions and Cautions

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS EQUIP-

MENT TO RAIN OR MOISTURE. TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK AND ANNOYING INTERFERENCE, USE ONLY THE INCLUDED HARDWARE.

THIS MONITOR IS ONLY DESIGNED FOR REAR SEAT PASSENGER VIEWING AND IS NOT INTENDED FOR VIEWING BY THE DRIVER WHILE THE VEHICLE IS IN MOTION. SUCH USE MAY DISTRACT THE DRIVER OR INTERFERE WITH THE SAFE OPERATION OF THE VEHICLE, AND MAY ALSO VIOLATE STATE LAW.

DIRECTED ELECTRONICS DISCLAIMS ANY LIABILITY FOR ANY BODILY INJURY, INCLUDING FATALITIES, OR PROPERTY DAMAGE THAT MAY RESULT FROM ANY IMPROPER OR UNINTENDED USES OF THIS PRODUCT.

SHOULD THE LCD PANEL BREAK OR LEAK FLUID, AVOID ALL CONTACT WITH THE UNIT. IF YOU SHOULD COME IN CONTACT WITH THE LEAKED FLUID, WASH THE AFFECTED AREA THOROUGHLY WITH WATER AND SEEK IMMEDIATE MEDICAL ATTENTION.

DO NOT CLOSE THE LCD SCREEN IF A MEMORY CARD HAS BEEN INSERTED INTO THE DVD PLAYER. THIS CAN CAUSE THE LCD PANEL TO BREAK OR LEAK FLUID (SEE ABOVE WARNING). REMOVE MEMORY CARD(S) BEFORE CLOSING SCREEN.

■

During operation, if the unit should over-heat or malfunction, switch off the unit and see your

dealer. Do not disassemble the unit as there are no user-serviceable parts in this unit and the war-

ranty will be voided.

■

Should there be a need to replace a blown fuse, turn off the unit and disconnect all power to

the player. Use only the correct rating fuse to avoid electrical damage to the unit.

■

Only operate the monitor as described in this guide. Attempts to use or modify this monitor

contrary to the descriptions in this guide may cause damage and void the warranty.

■

Extremes in temperature can cause abnormal display operation. This monitor has an optimal

operating temperature range between 32–120 degrees Fahrenheit. If the vehicle interior is outside

this range, do NOT operate the monitor until the temperature is within its operating range.

■

Exposure to moisture or dust can cause harmful damage to the internal electronics. Do not

mount near cup holders or in areas where spills may occur.

■

This monitor is designed for use in vehicles with standard (-) 12 volt ground electrical systems.

■

Do not operate for an extended period of time without the engine running or the vehicle’s bat-

tery voltage may drop to levels precluding engine starting.

■

Do not drop the LCD panel or subject it to direct impact. This will damage the panel and/or

the back light element.

■

When operating the unit, avoid contact with the LCD panel.

■

Prevent metal or foreign objects being locked between the LCD screen and the enclosure.

Foreign objects may impair smooth running of the disc and may cause electrical problems.

■

Keep unit away from equipment with strong magnets such as large loudspeakers.

■

To prevent malfunction, do not play discs other than the ones listed below: DVD audio discs, CD-

ROMs, JPEGs, MP3s and DVDs with region numbers other than this player's region number.

Welcome

Thank you for your purchase of Directed’s Overhead Monitor with integrated DVD. Prior to operating

this unit, please fully read this instruction manual and retain it for future reference.

What’s Included

The following items are included with your purchase:

Important

WHEN CLEANING THE VEHICLE

Do not spray this unit with water or cleaning solutions. Moisture and the chemicals found in cleaning

fluids could damage the consoles finish and interior electronics. A soft damp, lens cleaning cloth

should be used to wipe the screen. Do NOT use any type of scouring pad, abrasive cleaners, or solvents.

WHILE DRIVING

This unit is intended for use in the rear seat area only. It is illegal in some jurisdictions to install the

unit in a location that would allow the driver to view it while driving.

z Monitor with DVD Player z Power Harness (2)

z A/V Switch Box z DIN Cable

z (2) Headphones (HP200) z Domelight Harness

z Remote Control z Mounting Trim Gasket

z Mounting Plate (with 6 screws) z A/V Cable for DVD Player

z AC/DC Adapter for DVD Player

WHEN PARKED

The screen is easily visible when deployed. Always close the screen when parking for an extended

period of time to avoid potential theft or extended exposure to direct sunlight.

PROPER USE

Do not touch the screen. Do not pull or hang from the fold down monitor door.

DISC HANDLING AND CLEANING

Always handle the discs by the edge. Never touch the shiny side of the discs, as this can impair prop-

er playback.

Mount and dismount the discs with care not to damage or scratch the shiny side of the disc. This

will cause playback faults.

Do not expose the discs to direct sunlight.

After playing, store the disc back in its case.

To clean the disc, use a clean soft lint-free cloth and wipe the disc from the center out. Do not wipe

with a circular motion. Do not use any solvents.

REPAIRS

If the monitor stops working for any reason, discontinue use immediately and consult with your

retailer about any necessary repairs.

RADIO/TV TUNER USE

When the unit is used in conjunction with a Radio/TV tuner, please assure that the receiver is man-

ufactured to receive television broadcast signals that are transmitted via terrestrial radio waves.

Reception quality will change and vary according to vehicle location and weather conditions.

INSTALLATION

Avoid installing the monitor at a location, where it will be under direct sunlight or a hot air vent.

The operating temperature of the unit is from 32–120°F (0–50°C). Install the unit at a dry location,

where it is away from condensation.

Use only the correct size fasteners and cables during installation. Failure to do so may cause a

mechanical or electrical failure and create a fire hazard. The installation should be done by an

authorized Directed dealer.

NOTE: If the internal temperature of the vehicle is higher than the normal operating

temperature, please allow the vehicle to cool down (or warm up) prior to operating the unit.

PICTURE QUALITY

The picture quality of this LCD unit depends strictly on its installed location. To achieve the best

picture quality, adjust the brightness control or viewing angle of the unit until the optimum view-

ing is achieved.

Important Information

FCC NOTICE

This device complies with Part 15 of FCC rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and (2) this device must accept any interfer-

ence received, including interference that may cause undesirable operation.

Changes or modifications not expressly approved by the party responsible for compliance could void

the user's authority to operate this device.

YOUR WARRANTY

Your warranty registration must be completely filled out and returned within 10 days of purchase.

Your product warranty will not be validated if your warranty registration is not returned. Make sure

you receive the warranty registration from your dealer. It is also necessary to keep your proof of pur-

chase, which reflects that the product was installed by an authorized dealer.

Controls

MONITOR

1. COURTESY LIGHT—Activate this switch to "ON/OFF" to activate the dome lights on the

monitor.

2. DOOR LIGHT On/Off—Engage this switch to have the door open switch activate

the dome lights.

3. IR Transmitter/Receiver—Infrared transmitter and receiver which transmits the audio to the

headphones and receives commands from the remote control.

4. OPEN/CLOSE—The latch to open or close the LCD screen.

5. PICTURE—Each press of this button activates the Picture-In-Picture (PIP), split screen,

or normal feature.

6. SOURCE—Selects the source to be used for the monitor (DVD, AV1, or AV2). This button

will select the source for PIP or split screen mode, if PIP or split screen are active.

7. MODE—Selects Full, Normal, Wide, or Zoom video presentation. It will select 4:3 or 16:9

for PIP video presentation, if PIP is active.

8. MENU—Used to set FM Frequency, Brightness, Contrast, Saturation, Hue, or Reset (menu

parameters). The menu will exit if no action is taken within a few seconds.

57 9 11

123 468 10

9. UP Button—Used in conjunction with the button to scroll up (or increase) the

menu setting.

10. DOWN Button—Used in conjunction with the button to scroll down (or decrease)

the menu setting.

11. POWER—Power On/Off button.

DVD—MOUNTED

The illustration below shows the DVD player mounted in a typical LCD monitor.

1. LOCK/UNLOCK—To dock or undock the DVD player.

2. OPEN—Press this button to open the access door to mount or dismount a disc.

3. AUDIO—Each press of this button accesses each audio track recorded on the DVD (multiple lan-

gauges, commentary, etc.)

4. MENU—Displays the menu on the DVD. Use the Up, Down, Left, and Right buttons to scroll

through the available selections. Use the Enter button to select.

5. UP—

6. DOWN—





1713

7. LEFT—

8. RIGHT—

9. ENTER

10. PLAY/PAUSE—When pressed pauses the playback until pressed again.

11. STOP—Halts playback. If the Play button is pressed the playback will continue from where

stopped. If the Stop button is pressed twice, playback will now start from the beginning.

WARNING: DO NOT CLOSE THE LCD SCREEN IF A MEMORY CARD HAS BEEN INSERTED INTO THE DVD PLAYER. THIS CAN CAUSE THE LCD SCREEN TO BREAK OR LEAK FLUID. IF YOU SHOULD COME IN CONTACT WITH LEAKED FLUID, WASH THE AFFECTED AREA THOROUGHLY WITH WATER AND SEEK IMMEDIATE MEDICAL ATTENTION. REMOVE ALL MEMORY CARDS BEFORE CLOSING THE LCD SCREEN.

12. MS Card—Memory Stick, allows playback of music, photographs, movies, etc.

13. SD Card—Secure Digital, allows playback of music, photographs, movies, etc.

NOTE: To read from a memory card, there must not be a DVD or CD in the playerplayer

and the player door must be closed. Only 1 memory card can be inserted into the player at a time.

* These buttons are used to navigate through the menus on the screen and then use the Enter but-

ton to select the option.

DVD—UNMOUNTED

The illustration below shows the side of the DVD player when removed from the LCD monitor.

1. Electrical connector—This connector provides the electrical interface when mounted in the LCD

monitor.

2. VOL Control—Controls the volume to the phone jack output.

3. PHONE Jack—An optional headphone set can be connected here.

4. A/V OUT Jack—Audio/video output jack.

5. DC 12V Jack—Input power.

6. IR Receiver—For receiving commands from the remote control.

VOL PHONE A/V OUT

DC 12V

12345 6

DVD—MEMORY CARD MOUNTING

Ensure that the memory cards are mounted with the logo side of the memory cards oriented with the

arrows as shown below (towards the DVD drive):

Secure Digital

Logo

Side

DVD

drive

Logo

Side

Memory Stick

+ 29 hidden pages
