Directed Electronics D600, D800 User Manual

models
D600 D800
OWNER’S MANUAL
22
© 2005 Directed Electronics, Inc. all rights reserved
TABLE OF CONTENTS
Congratulations for choosing a Directed Audio power amplifier from Directed Electronics, the industry leader in high quality automotive security and audio equipment since 1990.
Directed Audio power amplifiers continue to set new standards of perfor­mance, reliability, and affordability in the mobile electronics industry.
Featuring high-efficiency MOSFET power supplies, flexible on-board crossovers, and state of the art audio design, Directed Audio power amplifiers will excite and delight the mobile sound
enthusiast with years of high-quality audio reproduction.
Directed Audio power amplifiers come with a two-year limited warranty if installed by an authorized Directed dealer. If not installed by an authorized dealer, Directed Audio power amplifiers are covered by a one-year, parts-and­labor limited warranty.
Be sure to retain your original sales receipt and refer to the warranty section of this guide for full details about your coverage.
Limited Two-year Consumer Warranty . . . . . . . . . . . . . . . . . . . . . . . . . .3
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Installation Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Front Panel Connections/Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Rear Panel Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Speaker Wiring Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Parallel Synced Gain Connections/Settings . . . . . . . . . . . . . . . . . . . . .11
Crossover Settings and Gain Adjustment . . . . . . . . . . . . . . . . . . . . . . .12
LED Tube Installation (Optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
CEA Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
LIMITED TWO-YEAR CONSUMER WARRANTY
33
© 2005 Directed Electronics, Inc. all rights reserved
Directed Electronics, Inc. promises to the original purchaser, to replace this product should it prove to be defective in workman­ship or material under normal use, for a period of two years from the date of purchase by the dealer as indicated by the date code marking of the product PROVIDED the product was installed by an authorized Directed dealer. During this two ­year period, there will be no charge for this replacement PROVIDED the unit is returned to Directed, shipping pre-paid. If the unit is installed by anyone other than an autho­rized Directed dealer, the warranty period will be one year from the date of purchase by the dealer as indicated by the date code marking of the product. During this one-year period there will be no charge for this replacement PROVIDED the unit is returned to Directed, shipping pre-paid. This warranty is non-transferable and does not apply to any unit that has been modified or used in a manner contrary to its intended purpose, and does not cover damage to the unit caused by installation or removal of the unit. This warranty is void if the product has been damaged by accident or unreasonable use, neglect, improper service or other causes not arising out of defects in materials or construction. ALL WARRANTIES INCLUDING
BUT NOT LIMITED TO EXPRESS WARRANTY, IMPLIED WARRANTY, WARRANTY OF MERCHANTABILITY, FITNESS FOR PARTICULAR PURPOSE, AND
WARRANTY OF NON-INFRINGEMENT OF INTELLECTUAL PROPERTY ARE EXPRESSLY EXCLUDED TO THE MAXIMUM EXTENT ALLOWED BY LAW, AND DIRECTED NEITHER ASSUMES NOR AUTHORIZES ANY PERSON TO ASSUME FOR IT ANY LIABILITY IN CONNECTION WITH THE SALE OF THE PRODUCT. DIRECTED HAS ABSOLUTELY NO LIABILITY FOR ANY AND ALL ACTS OF THIRD PARTIES INCLUDING ITS AUTHORIZED DEALERS OR INSTALLERS. Unit must be returned to
Directed, postage pre-paid, with: consumer’s name, telephone number, and address, authorized dealer’s name and address, and product description. IN ORDER FOR THIS
WARRANTY TO BE VALID, YOUR UNIT MUST BE SHIPPED WITH PROOF OF INSTALLATION BY AN AUTHORIZED DIRECTED DEALER. ALL UNITS RECEIVED BY DIRECTED FOR WARRANTY REPAIR WITHOUT PROOF OF DIRECTED DEALER INSTALLATION WILL BE COVERED BY THE LIMITED ONE-YEAR PARTS AND LABOR WARRANTY. Note: This warranty does not
cover labor costs for the removal and rein­stallation of the unit. BY PURCHASING
THIS PRODUCT, THE CONSUMER AGREES AND CONSENTS THAT ALL DISPUTES BETWEEN THE CONSUMER AND Directed SHALL BE RESOLVED IN ACCORDANCE WITH CALIFORNIA LAWS IN SAN DIEGO COUNTY, CALIFORNIA.
44
© 2005 Directed Electronics, Inc. all rights reserved
High-powered car audio
systems may produce sound pressure levels that exceed the threshold at which hearing loss may result.
They may also impair a driver’s ability to hear traffic sounds or emergency vehi­cles. Use common sense and practice safe listening habits when listening to or adjusting your audio system.
WARNING
FEATURES
Super-efficient Class D PWM design
runs much cooler than conventional amps.
High-speed MOSFET switching
power supply.
High-current complimentary Class D
MOSFET outputs stable into one ohm loads. (D600 stable into two ohm load.)
Thermal, DC offset, reverse polarity,
and short circuit protection with status LED.
Continuously variable 12dB/
octave low-pass crossover.
Switchable subsonic filter,
24dB/octave .
Switchable 8 dB bass EQ function.
Switchable 180° phase inversion.
Remote subwoofer level control
function.
Variable input sensitivity optimizes
match with different signal sources.
Chrome-plated wire terminals and
RCA connectors ensure maximum signal transfer.
Rugged 2-piece heatsink and cover.
Unity gain pass-through RCA jacks.
55
© 2005 Directed Electronics, Inc. all rights reserved
INSTALLATION GUIDELINES
1. Please read this owner’s manual
carefully before installing this ampli­fier.
2. Disconnect the battery ground
terminal prior to making any elec­trical connections.
3. Check for any hazards or obstruc-
tions such as gas tanks, fuel or brake lines, and wiring harnesses before mounting the amplifier.
4. Pick a mounting location that will
provide adequate access and venti­lation and protect the amplifier from heat, moisture, and dirt.
5. Avoid sharp metal areas when
routing cables to the amplifier, and run RCA cables away from the power cables and other potentially noisy car harnesses.
6. The amplifier should be grounded
with a short, heavy gauge wire connected directly to the car at a bare metal surface, preferably scraped body sheet metal. Do not use factory ground locations, seat bolts, or brackets that are spot welded.
7. Always fuse your power connection
within 8 to 10 inches of the battery
terminal. Use a fuse or circuit breaker rated slightly more than the on-board fuse(s) of the amplifier(s). The gauge of power wire used should take into account the total current draw of the system, and the length of wire used. IASCA and other auto sound competition organizations have charts available for this; you can also find a chart in the MECP study guide. Minimum wire gauge recom­mendations for the individual ampli­fiers are listed on the specification page. Always use the same gauge wire for the amplifier ground that you use for the power wire. Be sure to examine the battery ground cable of the vehicle, and if neces­sary, upgrade it by adding an addi­tional ground wire that is the same gauge as the amplifier’s power wire. Remember, the amplifier can only deliver its rated output when it is not current limited by the power and ground supply wires.
8. This amplifier is designed to drive a speaker load that measures from 1 to 4 ohms (D600 2 to 4 ohms). Keep in mind that heat is the long­term enemy of automotive elec-
66
© 2005 Directed Electronics, Inc. all rights reserved
1.
RRCCAA IInnppuutt JJaacckkss --
Accepts line level outputs from head units or signal processors at voltages between 150mV and 7.5 volts.
2.
RRCCAA LLiinnee OOuuttppuutt JJaacckkss --
These pass through RCA jacks can be used to send the input signal to a second amplifier.
3.
GGaaiinn CCoonnttrrooll --
Controls the ampli­fier’s sensitivity and is used to match the input level of the ampli­fier to the output level of the signal source.
4.
SSuubbssoonniicc SSwwiittcchh --
The subsonic filter attenuates frequencies below 30Hz by 24dB per octave.
5.
BBaassss EEQQ SSwwi
ittcchh --
Adds 8dB of bass boost to the subwoofer when selected.
6.
RReemmoottee
- Controls the subwoofer amplifier gain, from a remote loca­tion for ease of adjustment during listening.
WWaarrnniinngg::
DO NOT connect a level control knob from other manufacturers to the Remote Sub Level Control of any Directed amplifier. Even though the connectors fit properly, the control knob and connector pin positions may be different and the amplifier will be damaged.
7.
LLPPFF CCoonnttrrooll --
Controls low pass filter
cutoff from 30Hz to 250Hz.
8.
PPhhaassee SSwwiittcchh --
0° or 180° selec­table for switching the phase output to the woofer.
FRONT PANEL CONNECTIONS/CONTROLS
tronics and the lower your speaker load, the more heat is generated. For low impedance speaker applica­tions or restricted ventilation instal­lations, an external cooling fan may be advisable.
9. Battery and ground connections to the vehicle should be made with crimped ring terminals of the appro­priate size (surface area is what counts); soldering the terminals after crimping is also recom­mended.
10. Due to the high-frequency MOSFET switching power supply, filtering the power cable is not generally required (remember that the amp can’t deliver full output if the power supply is restricted). Proper grounding of the signal source is mandatory for the amplifier to reach its performance peak. If the RCA inputs are not grounded adequately via the signal source, electrical noise from the vehicle may be picked up in the system.
77
© 2005 Directed Electronics, Inc. all rights reserved
9.
LLEEDD//FFAANN CCoonnnneeccttoorr --
Allows connec-
tion of an
ooppttiioonnaall
LED light bar or
ooppttiioonnaall
cooling fan for the amplifier.
10.
SSttaattuuss LLEEDD
- Will illuminate GREEN
to indicate the amplifier is on and
operating normally, and will be illu­minated RED if the amplifier shuts down due to short circuit, DC offset, or overheating detected by on­board protection circuitry.
D600/D800
1
2
4
5
6
7
8
9
10
11
FIGURE 1—AMPLIFIER CONNECTIONS/CONTROLS D600/D800 FRONT
FIGURE 2—LED/FAN HARNESS
BLACK
BLUE
BLACK
RED
­TO LED s
+
­TO FAN
+
1.
FFuusseess --
These fuses protect the amplifier against internal electrical damage and are meant to protect the amplifier only. All other power connections should be fused at the source.
The D600 uses 1-40A fuse, the D800 uses 2-25A fuses.
2.
((++)) 1122 VVoolltt PPoowweerr
- Connect this terminal through a FUSE or CIRCUIT BREAKER to the positive terminal of the vehicle battery or the positive terminal of an isolated audio system battery.
WWAARRNNIINNGG::
Always protect this power wire by installing a fuse or circuit breaker of the appropriate size within 12 inches of the battery terminal connection.
2.
RReemmoottee TTuurrnn OOnn
- This terminal turns on the amplifier when (+) 12 volt is applied to it. Connect it to the remote turn on lead of the head unit or signal source.
2.
GGrroouunndd --
Connect this terminal directly to the sheet metal chassis of the vehicle, using the shortest wire necessary to make this connection. Always use wire of the same gauge or larger than the (+) 12 volt power wire. The chassis connection point should be scraped free of paint and dirt. Use only quality crimped and/or soldered connectors at both ends of this wire. DO NOT connect this terminal directly to the vehicle battery ground terminal or any other factory ground points.
3.
SSppeeaakkeerr TTeerrmmiinnaallss
- Connect subwoofers to these terminals. (Refer to the
Speaker Wiring
Diagrams
section of this guide.)
REAR PANEL CONNECTIONS
88
© 2005 Directed Electronics, Inc. all rights reserved
99
© 2005 Directed Electronics, Inc. all rights reserved
D600
D800
1
2
3
FIGURE 3—AMPLIFIER CONNECTIONS - REAR
1100
© 2005 Directed Electronics, Inc. all rights reserved
SPEAKER WIRING DIAGRAMS
Single subwoofer connection (top view)
Two subwoofer connection (top view)
NNOOTTEE::
The dual + and -- sub-out terminals of the D600/D800 are paralleled internally and the combined load impedance should be taken into consideration when connecting multiple subwoofers.
1111
© 2005 Directed Electronics, Inc. all rights reserved
Refer to figure 5 for wiring details.
1.
IInnppuutt SSiiggnnaall
- Connect these RCA
jacks as described in the
Front Panel
Connection
section of this guide.
2.
SSllaavvee//MMaasstteerr SSwwiittcchh
Set the slave/master switch
on the master amplifier to the MASTER position.
Set the slave/master switch
on the slave amplifier to the SLAVE position.
Setting the slave/master
switch on both amplifiers will auto­matically set the I/O RCA jack configuration according to each amplifier’s slave or master designa­tion.
NNOOTTEE::
One master amplifier can control up to three slave amplifiers in this combination. Multiple identical master/slave combinations can be added to any given system.
3.
PPhhaassee SSwwiittcchh --
Set the phase switches of all synced amps to the same position (all at 0° or all at 180°).
4. In order to achieve safe, optimal perfor­mance, the LPF, Bass EQ, and Subsonic Filter controls on all synced amps must be set to the same position.
5.
SSiiggnnaall CCoonnnneeccttiioonn
- Connect an RCA cable between the OUT RCA jack of the master amplifier and the SLAVE IN RCA jack of the slave amplifier as shown in the Figure 5.
6.
SSuubbwwooooffeerr SSppeeaakkeerr CCoonnnneeccttiioonn
- In this amplifier combination each amplifiers must drive its own sepa­rate subwoofer(s). Connect the speaker terminals of each amplifier to any combination of one or more subwoofers that results in nominal impedance between one and four ohms (D600—2 to 4 ohms). Make sure that each amplifier sees the same speaker impedance.
WWAARRNNIINNGG::
The amplifier’s gain control is bypassed completely in SLAVE mode. Do
NNOOTT
move the MASTER/SLAVE switch to SLAVE position when the amplifier is connected and playing. Do
NNOOTT
connect any signal source to the amplifier in SLAVE mode that exceeds 200mV.
PARALLEL SYNCED GAIN CONNECTIONS/SETTINGS
1122
© 2005 Directed Electronics, Inc. all rights reserved
CROSSOVER SETTINGS AND GAIN ADJUSTMENT
Your Directed Audio power amplifier needs to be adjusted carefully to achieve maximum performance. These are some guidelines to follow when fine­tuning the amplifier.
Because this amplifier is only
designed for subwoofer applica­tions, the low-pass crossover is active at all times. The crossover point is adjustable to allow more precise system operation.
Try and keep the setting low
enough to prevent image smearing (you should not be able to hear male voices from the subwoofer) but not so low as to create a gap between the subwoofer and the mid-bass/midrange speakers. It will be to your advantage to spend some extra time with this adjust­ment, listening to familiar music or system set-up discs to achieve the kind of musical reproduction that you prefer.
The gain adjustment allows you to
set proper signal match for clean, quiet amplifier operation. Start by playing some music you are familiar with. With the gain adjust­ment on the amplifier in the middle of its rotation, bring up the volume on your head unit to the 3/4 volume setting or until you start to
hear distortion or clipping. If you hear distortion before you reach the 3/4 volume setting of your head unit, reduce the gain setting on the amplifier and start to raise the head unit volume again. When you can listen to the music at or slightly above 3/4 on your head unit without audible distortion, slowly raise the gain of the amplifier until distortion is heard, then back off the gain until the distortion is not audible. This setting will allow you to reach full output with all but the quietest of source material, while avoiding excessive noise in the system.
For systems using the Remote Sub
Level Adjustment, increase the subwoofer gain on the amplifier by 25% and set the Remote Sub Level knob to the center position after making all system gain and filter adjustments. This will give the Remote Sub Level Control a wider range of adjustment to the subwoofer output.
You should take into consideration
the effect that gain adjustment has on system frequency response and staging. Again, plan on spending some time with music that you know getting the gain and
1133
© 2005 Directed Electronics, Inc. all rights reserved
CEA SPECIFICATIONS
DD660000 Power Output: 180 Watts RMS x 1 at 4 ohms and <
1% THD+N
Signal to Noise Ratio: -60 dBA (reference 1 Watt into 4 ohms)
Additional Power: 300 Watts RMS x 1 at 2 ohms and <
1% THD+N
DD880000 Power Output: 200 Watts RMS x 1 at 4 ohms and <
1% THD+N
Signal to Noise Ratio: -60 dBA (reference 1 Watt into 4 ohms)
Additional Power: 400 Watts RMS x 1 at 1 ohm and <
1% THD+N
LED TUBE INSTALLATION (OPTIONAL)
This Directed Audio amplifier has been designed with a custom heat sink that can accommodate two (optional—not supplied) LED tubes.
Follow the installation instructions provided with the LED tubes.
Directed Amplifier—LED Cross Reference Chart
Directed Part Number Directed Model Directed LED Model
45095 D600 DIRW9L 45100 D800 DIRW9L
Use the following cross reference chart to select the proper length LED tube for use with your Directed Audio amplifier.
crossover settings the way you like. Test discs and analyzers may help with this process, but in the end it's
your ears that count --listen to the music!
1144
© 2005 Directed Electronics, Inc. all rights reserved
SPECIFICATIONS
DD660000 DD880000
Maximum Watts 600W 800W RMS continuous Power
1
300W 300W
RMS continuous Power
2
N/A 400W Frequency Response 20-250Hz 20-250Hz Damping Factor 50 50 Variable Low Pass Crossover
12dB slope
30-250Hz 30-250Hz
Subsonic Filter Yes Yes Bass Boost Yes Yes Input Impedance 20K 20K Input Sensitivity 150mV/7.5V 150mV/7.5V Output Load 2 ohms 1 ohms Fusing 1 x 40A 2 x 25A Illuminated LED Driver Yes Yes External Fan Driver Yes Yes Pass Through RCA Jacks Yes Yes
1. RMS continuous power driven into 2 ohms from 20 to 250Hz @ 14.4VDC with less than 1% THD+N.
2. RMS continuous power driven into 1 ohms from 20 to 250Hz @ 14.4VDC with less than 1% THD+N.
The company behind this system is Directed Electronics, Inc. Since
its inception, Directed has had one purpose, to provide customers with the finest
vehicle security, car stereo products, rear seat entertainment, and accessories avail-
able. The recipient of more than 20 patents in the field of advanced electronic tech-
nology, Directed is ISO 9001 registered.
Directed® is committed to delivering world-class quality products and services that excite and delight our customers.
Directed Electronics, Inc.
Vista, California 92081
www.directed.com
Quality Directed products are sold and serviced throughout North America and around the world
Call 800 274 0200 for more information about our products and services
© 2005 Directed Electronics, Inc. - All rights reserved - G45095.100 06-05
