Directed Electronics Clifford RS2.1 Owner's Manual

MMooddeell RRSS22..11

➤

OOwwnneerr’’ss GGuuiiddee

i

© 2005 directed electronics—all rights reserved

lliimmiitteedd lliiffeettiimmee ccoonnssuummeerr wwaarrrraannttyy

Directed Electronics ("Directed") promises to the original purchaser to repair or replace
with a comparable reconditioned model any Directed unit (hereafter the "unit"), exclud­ing without limitation the siren, the remote transmitters, the associated sensors and acces­sories, which proves to be defective in workmanship or material under reasonable use dur­ing the lifetime of the vehicle provided the following conditions are met: the unit was pro­fessionally installed and serviced by an authorized Directed dealer; the unit will be pro­fessionally reinstalled in the vehicle in which it was originally installed by an authorized
Directed dealer; and the unit is returned to Directed, shipping prepaid with a legible copy
of the bill of sale or other dated proof of purchase bearing the following information: con­sumer's name, telephone number and address; the authorized dealers name, telephone
number and address; complete product description, including accessories; the year, make
and model of the vehicle; vehicle license number and vehicle identification number. All
components other than the unit, including without limitation the siren, the remote trans­mitters and the associated sensors and accessories, carry a one-year warranty from the date
of purchase of the same. This warranty is non-transferable and is automatically void if: the
original purchaser has not completed the warranty card and mailed it within ten (10) days
of the date of purchase to the address listed on the card; the unit's date code or serial num­ber is defaced, missing or altered; the unit has been modified or used in a manner con­trary to its intended purpose; the unit has been damaged by accident, unreasonable use,
neglect, improper service, installation or other causes not arising out of defects in materi­als or construction. The warranty does not cover damage to the unit caused by installa­tion or removal of the unit. Directed, in its sole discretion, will determine what consti­tutes excessive damage and may refuse the return of any unit with excessive damage. TO
THE MAXIMUM EXTENT ALLOWED BY LAW, ALL WARRANTIES, INCLUD­ING BUT NOT LIMITED TO EXPRESS WARRANTY, IMPLIED WARRANTY,
WARRANTY OF MERCHANTABILITY, FITNESS FOR PARTICULAR PURPOSE
AND WARRANTY OF NON-INFRINGEMENT OF INTELLECTUAL PROPERTY,
ARE EXPRESSLY EXCLUDED; AND DIRECTED NEITHER ASSUMES NOR
AUTHORIZES ANY PERSON OR ENTITY TO ASSUME FOR IT ANY DUTY,
OBLIGATION OR LIABILITY IN CONNECTION WITH ITS PRODUCTS.
DIRECTED DISCLAIMS AND HAS ABSOLUTELY NO LIABILITY FOR ANY
AND ALL ACTS OF THIRD PARTIES INCLUDING ITS AUTHORIZED DEAL­ERS OR INSTALLERS. DIRECTED SECURITY SYSTEMS, INCLUDING THIS
UNIT, ARE DETERRENTS AGAINST POSSIBLE THEFT. DIRECTED IS NOT
OFFERING A GUARANTEE OR INSURANCE AGAINST VANDALISM, DAM­AGE OR THEFT OF THE AUTOMOBILE, ITS PARTS OR CONTENTS; AND
HEREBY EXPRESSLY DISCLAIMS ANY LIABILITY WHATSOEVER, INCLUD­ING WITHOUT LIMITATION, LIABILITY FOR THEFT, DAMAGE AND/OR
VANDALISM. THIS WARRANTY DOES NOT COVER LABOR COSTS FOR
MAINTENANCE, REMOVAL OR REINSTALLATION OF THE UNIT OR ANY

ii

© 2005 directed electronics—all rights reserved

CONSEQUENTIAL DAMAGES OF ANY KIND. IN THE EVENT OF A CLAIM
OR A DISPUTE INVOLVING DIRECTED OR ITS SUBSIDIARY, THE PROPER
VENUE SHALL BE SAN DIEGO COUNTY IN THE STATE OF CALIFORNIA.
CALIFORNIA STATE LAWS AND APPLICABLE FEDERAL LAWS SHALL APPLY
AND GOVERN THE DISPUTE. THE MAXIMUM RECOVERY UNDER ANY
CLAIM AGAINST DIRECTED SHALL BE STRICTLY LIMITED TO THE
AUTHORIZED DIRECTED DEALER'S PURCHASE PRICE OF THE UNIT.
DIRECTED SHALL NOT BE RESPONSIBLE FOR ANY DAMAGES WHATSOEV­ER, INCLUDING BUT NOT LIMITED TO, ANY CONSEQUENTIAL DAMAGES,
INCIDENTAL DAMAGES, DAMAGES FOR THE LOSS OF TIME, LOSS OF
EARNINGS, COMMERCIAL LOSS, LOSS OF ECONOMIC OPPORTUNITY
AND THE LIKE. NOTWITHSTANDING THE ABOVE, THE MANUFACTURER
DOES OFFER A LIMITED WARRANTY TO REPLACE OR REPAIR THE CON­TROL MODULE AS DESCRIBED ABOVE. Some states do not allow limitations on
how long an implied warranty will last or the exclusion or limitation of incidental or con­sequential damages. This warranty gives you specific legal rights and you may also have
other rights that vary from State to State.

This product may be covered by a Guaranteed Protection Plan ("GPP"). See your autho­rized Directed dealer for details of the plan or call Directed Customer Service at 1-800­876-0800. Directed security systems, including this unit, are deterrents against possible
theft. Directed is not offering a guarantee or insurance against vandalism, damage or theft
of the automobile, its parts or contents; and hereby expressly disclaims any liability what­soever, including without limitation, liability for theft, damage and/or vandalism.
Directed does not and has not authorized any person or entity to create for it any other
obligation, promise, duty or obligation in connection with this security system.

Make sure you have all of the following information from your dealer:

A clear copy of the sales receipt, showing the following:

➤ Date of purchase
➤ Your full name and address
➤ Authorized dealer's company name and address
➤ Type of alarm installed
➤ Year, make, model and color of the automobile
➤ Automobile license number
➤ Vehicle identification number
➤ All security options installed on automobile
➤ Installation receipts

1

© 2005 directed electronics—all rights reserved

ttaabbllee ooff ccoonntteennttss

lliimmiitteedd lliiffeettiimmee ccoonnssuummeerr wwaarrrraannttyy.. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. ii

ssttaannddaarrdd ttrraannssmmiitttteerr ccoonnffiigguurraattiioonn .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .

. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 33

wwhhaatt iiss iinncclluuddeedd .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .

. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 44

iimmppoorrttaanntt iinnffoorrmmaattiioonn .. .. .. .. .. .. .. .. .. .. ..

.. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 44

system maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

your warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

fcc/id notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

caution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

ttrraannssmmiitttteerr ffuunnccttiioon

nss .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 66

standard configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

uussiinngg yyoouurr ssyysstteemm .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. ..

.. .. .. .. .. .. .. .. .. .. .. .. .. 88

warning! safety first . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

active arming. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

passive arming. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

multi-level security arming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

arming while driving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

disarming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

high security disarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

disarming without a transmitter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

silent mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

panic mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

valet mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

remote start. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

rear defogger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

valet take-over . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

short-run/turbo . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

timer/temperature mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

ssaaffeettyy ffeeaattuurreess.. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .

. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 2222

starter anti-grind circuitry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

disabling the remote start system. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

over and under rev protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

shut down inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

nuisance prevention® circuitry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

ddiiaaggnnoossttiiccss .. .. .. .. .. .. .. .. .. .. .. .. .. .. .

. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 2255

arming diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

disarming diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

system status chirps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

table of zones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

interpreting zone diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

ccooddee hhooppppi

inngg .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. ..

.. .. .. .. .. .. 2288

2

© 2005 directed electronics—all rights reserved

hhiigghh ffrreeqquueennccyy .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 2299

oowwnneerr rreeccooggnniittiioonn .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .

. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 2299

rraappiidd rreessuummee llooggiicc .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. ..

.. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 3300

ppoowweerr ssaavveerr mmooddee .. .. .. .. .. ..

.. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 3300

pprrooggrraam

mmmiinngg ooppttiioonnss .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 3311

sseeccuurriittyy && ccoonnvveenniieennccee eexxppaannssiioonnss .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .

. .. .. .. .. .. .. .. .. .. .. 3344

gglloossssaarryy ooff tteerrmmss .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .

. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 3366

3

© 2005 directed electronics—all rights reserved

ssttaannddaarrdd ttrraannssmmiitttteerr ccoonnffiigguurraattiioonn

controls the

AArrmm

and

PPaanniicc

On/Off function.

controls the

DDiissaarrmm

and

PPaanniicc

Off function.

controls

SSiilleenntt MMooddee™™

and

AAuuxxiilliiaarryy

channel 22output.

controls the

RReemmoottee SSttaarrtt

function.

and pressed together control the

TTiimmeerr

mode.

and pressed together control

TTuurrbboo//SShhoorrtt RRuun

n

.

and pressed together control channel 44output.

and pressed together control channel 5 output.

and and pressed together control the rear

defogger.

4

© 2005 directed electronics—all rights reserved

and pressed together control channel 6 output.

wwhhaatt iiss iinncclluuddeedd

➤ A control module

➤ An XR+ receiver/antenna

➤ Two four-button transmitters

➤ A Stinger™ DoubleGuard

®

two-stage shock sensor

➤ A Revenger™ Soft Chirp™ six-tone programmable siren

➤ A red status LED indicator light

➤ A push-button Valet button

➤ Your warranty registration

➤ A shut-down toggle switch

iimmppoorrttaanntt iinnffoorrmmaattiioonn

Congratulations on the purchase of your combination remote

start alarm system. Due to the complexity of this system, it must

be installed by an authorized dealer only. Installation of this

product by anyone other than an authorized dealer voids the

warranty. All dealers are provided with a preprinted dealer certifi-

cate to verify authorization.

By carefully reading this Owner's Guide prior to using your

system, you will maximize the use of this system and its features.

You can print additional or replacement copies of this manual by

5

© 2005 directed electronics—all rights reserved

accessing our web site at www.directed.com.

6

© 2005 directed electronics—all rights reserved

system maintenance

The system requires no specific maintenance. Your remote is

powered by a small, lightweight 3-volt lithium battery that will

last approximately one year under normal use. When the battery

begins to weaken, operating range will be reduced and the LED

on the remote will dim.

your warranty

Your warranty registration must be completely filled out and

returned within 10 days of purchase. Your product warranty

will not be validated if your warranty registration is not returned.

Make sure you receive the warranty registration from your dealer.

It is also necessary to keep your proof of purchase, which reflects

that the product was installed by an authorized dealer.

fcc/id notice

This device complies with Part 15 of FCC rules. Operation is

subject to the following two conditions: (1) This device may not

cause harmful interference, and (2) This device must accept any

interference received, including interference that may cause

undesirable operation.

Changes or modifications not expressly approved by the party

responsible for compliance could void the user's authority to

operate this device.

➜

➜

➜

7

© 2005 directed electronics—all rights reserved

caution

This product is designed for fuel injected, automatic transmission

vehicles only. Use of this product in a standard transmission

vehicle is dangerous and contrary the product's intended use.

ttrraannssmmiitttteerr ffuunnccttiioonnss

The receiver uses a computer-based Learn Routine to learn the

transmitter buttons. This makes it possible to assign any remote

transmitter button to any receiver function. The transmitter

initially comes programmed with Standard Configuration, but

may also be customized by an authorized dealer. The buttons in

all of the instructions in this manual correspond to a Standard

Configuration transmitter.

standard configuration

Button

The arming and panic functions are controlled by pressing this

button for one second.

Button

The disarming function is controlled by pressing this button for

one second.

Button

Silent Mode™ and an optional auxiliary function are controlled

by this button. (Silent Mode works by pressing this button for

➜

➜

8

© 2005 directed electronics—all rights reserved

less than one second before arming or disarming. An optional

auxiliary function, such as trunk release, can be controlled by

pressing this button for 1.5 seconds.)

The auxiliary output controls __________________________.

Button

The remote start function of your system is controlled by

pressing this button twice within 3 seconds.

and Buttons

An optional auxiliary convenience or expansion function that

you have added to your system can be activated by pressing these

buttons simultaneously.

The auxiliary output controls __________________________.

and Buttons

An optional auxiliary convenience or expansion function that

you have added to your system can be activated by pressing these

buttons simultaneously.

The auxiliary output controls __________________________.

and Buttons

The remote start timer mode is controlled by pressing these

buttons simultaneously.

and Buttons

The short-run turbo mode is activated when these buttons are

pressed simultaneously.

9

© 2005 directed electronics—all rights reserved

and and Buttons

When simultaneously pressed these buttons control the rear

window defogger during remote starting.

and Buttons

An optional auxiliary convenience or expansion function that

you have added to your system can be activated by pressing these

buttons simultaneously.

The auxiliary output controls __________________________.

uussiinngg yyoouurr ssyysstteemm

warning! safety first

The following safety warnings must be observed at all times:

➤ Due to the complexity of this system, installation of this

product must only be performed by an authorized Directed

dealer.

➤ When properly installed, this system can start the vehicle via

a command signal from the remote control transmitter.

Therefore, never operate the system in an enclosed area or

partially enclosed area without ventilation (such as a garage).

When parking in an enclosed or partially enclosed area or

when having the vehicle serviced, the remote start system

must be disabled using the installed toggle switch. It is the

user's sole responsibility to properly handle and keep out of

➜

10

© 2005 directed electronics—all rights reserved

reach from children all remote control transmitters to assure

that the system does not unintentionally remote start the

vehicle.

TTHHEE UUSSEERR MMUUSSTT IINNSSTTAALLLL AA CCAARRBBOONN

MMOONNOOXXIIDDEE DDEETTEECCTTOORR IINN OORR AABBOOUUTT TTHHEE

LLIIVVIINNGG AARREEAA AADDJJAACCEENNTT TTOO TTHHEE VVEEHHIIC

CLLEE.. AALLLL

DDOOOORRSS LLEEAADDIINNGG FFRROOMM AADDJJAACCEENNTT LLIIVVIINNGG AARREEAASS

TTOO TTHHEE EENNCCLLOOSSEEDD OORR PPAARRTTIIAALLLLYY EENNCCLLOOSSEEDD

VVEEHHIICCLLEE SSTTOORRA

AGGEE AARREEAA MMUUSSTT AATT AALLLL TTIIMMEESS

RREEMMAAIINN CCLLOOSSEEDD..

These precautions are the sole respon-

sibility of the user.

➤ Use of this product in a manner contrary to its intended

mode of operation may result in property damage, personal

injury, or death. (1) Never remotely start the vehicle with the

vehicle in gear, and (2) Never remotely start the vehicle with

the keys in the ignition. The user must also have the neutral

safety feature of the vehicle periodically checked, wherein the

vehicle must not remotely start while the car is in gear. This

testing should be performed by an authorized Directed dealer

in accordance with the Safety Check outlined in the product

installation guide. If the vehicle starts in gear, cease remote

start operation immediately and consult with the authorized

Directed dealer to fix the problem.

➤ After the remote start module has been installed, contact

your authorized dealer to have him or her test the remote

start module by performing the Safety Check outlined in the

product installation guide. If the vehicle starts when

performing the Neutral Safety Shutdown Circuit test, the

11

© 2005 directed electronics—all rights reserved

remote start unit has not been properly installed. The remote

start module must be removed or the installer must properly

reinstall the remote start system so that the vehicle does not

start in gear. All installations must be performed by an autho-

rized Directed dealer.

OOPPEERRAATTIIOONN OOFF TTHHEE RREEMMOOTTEE

SSTTAARRTT MMOODDUULLEE IIFF TTHHEE VVEEHHIICCLLEE SSTTAARRTTSS IINN GGEEAARR

IISS CCOONNTTRRAARRYY TTOO IITTSS IINNTTEENNDDEEDD MMOOD

DEE OOFF OOPPEERR--

AATTIIOONN.. OOPPEERRAATTIINNGG TTHHEE RREEMMOOTTEE SSTTAARRTT SSYYSSTTEEMM

UUNNDDEERR TTHHEESSEE CCOONNDDIITTIIOONNSS MMAAYY RREESSUULLTT IINN

PPRROOPPEERRTTYY DDA

AMMAAGGEE OORR PPEERRSSOONNAALL IINNJJUURRYY.. YYOOUU

MMUUSSTT IIMMMMEEDDIIAATTEELLYY CCEEAASSEE TTHHEE UUSSEE OOFF TTHHEE

UUNNIITT AANNDD SSEEEEKK TTHHEE AASSSSIISSTTAANNCCEE OOFF A

ANN AAUUTTHHOO--

RRIIZZEEDD DDIIRREECCTTEEDD DDEEAALLEERR TTOO RREEPPAAIIRR OORR

DDIISSCCOONNNNEECCTT TTHHEE IINNSSTTAALLLLEEDD RREEMMOOTTEE SSTTAARRTT

MMOODDUULLEE.. DDIIRREECCTTEEDD WWI

ILLLL NNOOTT BBEE HHEELLDD

RREESSPPOONNSSIIBBLLEE OORR PPAAYY FFOORR IINNSSTTAALLLLAATTIIOONN OORR

RREEIINNSSTTAALLLLAATTIIOONN CCOOSSTTSS..

active arming

You can arm the system by pressing of your transmitter for

one second. When the system arms, you will hear a short siren

sound, or chirp, and see the parking lights flash once. If the power

door locks are controlled by the system, the doors will also lock.

While the system is armed, the status LED will flash approximately

once per second, indicating that the system is actively protecting

your vehicle. If you hear a second chirp after arming and note that

the status LED is flashing in groups, see the Diagnostics Section of

this guide. This extra chirp is called Bypass Notification.

➜

12

© 2005 directed electronics—all rights reserved

passive arming

The system can be programmed to arm itself automatically (called

passive arming). If the system is programmed for passive arming, it

will automatically arm 30 seconds after the ignition is turned off

and the system detects that you have left the vehicle by opening and

closing a door. Whenever the system is in its 30-second passive

arming countdown, the status LED will flash twice as fast as it does

when the system is armed. At the 20-second point of the count-

down, the siren will chirp to indicate that the system is about to

arm. At the 30-second point, the parking lights will flash to indicate

that the system is armed.

When armed your vehicle is protected as follows:

➤ Light impacts trigger the Warn Away

®

signal. When trig-

gered, the siren chirps and the parking lights flash for a few

seconds.

➤ Heavy impacts trip a Triggered Sequence. The sequence

consists of the siren sounding continuously and the parking

lights flashing for a pre-programmed period, which can

range in duration from 1 to 180 seconds.

➤ If a door is opened, the system will immediately start

chirping the siren and flashing the parking lights. Three

seconds later, the siren output changes to a continuous blast.

This progressive response gives you time to disarm the sys-

note: If any protected entry point (such as a door or a
switch-protected trunk or hood) is open, the system will
not passively arm (unless forced passive arming is pro­grammed on. See Programming Options section).

➜

13

© 2005 directed electronics—all rights reserved

tem with your transmitter if you inadvertently open the door

while the system is armed, while still providing instant re-

sponse (even if the door is immediately closed).

➤ Turning on the ignition key will trip the same progressive re-

sponse as opening a door.

➤ The optional starter kill prevents the vehicle’s starter from

cranking.

multi-level security arming

Multi-Level Security Arming allows you to select which of the

system's inputs or sensors will be active and which will be

bypassed when the system is armed. (See

Table of Zones

section

of this guide.) Pressing (only in Standard Configuration)

again within five seconds of arming the system will activate the

Multi-Level Security feature. Each time is pressed again, a

different security level is selected. The different security levels are

selected as follows:

➤ Press once: The siren chirps once. The system is armed.

➤ Press a second time within five seconds: The siren chirps

twice followed by a long chirp. Zone 2 is now bypassed.

➤ Press a third time within five seconds: The siren chirps

three times followed by a long chirp. Zone 4 is now bypassed.

➤ Press a fourth time within five seconds: The siren chirps four

times followed by a long chirp. Zones 2 and 4 are now bypassed.

➤ Press a fifth time within five seconds: The siren chirps

five times followed by a long chirp. All input zones, except

the ignition, are now bypassed.

➜

14

© 2005 directed electronics—all rights reserved

arming while driving

Your security system can be armed while driving the vehicle!

Simply press on the transmitter for two seconds while the

vehicle is running. The siren will chirp once to indicate that the

security system is armed, and then once more to indicate that the

ignition is on. The system will not respond to any input except

the door triggers, and the starter kill relay (if installed) will not be

activated. Once you have arrived at your destination, the system

will disarm when the ignition is turned off. The siren will chirp

twice and the LED will then stop flashing. The system can also

be disarmed at any time by pressing

..

disarming

To disarm the security system, press . You will hear two

chirps, and the parking lights will flash twice. If the power locks

are controlled by the system, the doors will also unlock. The siren

chirping either four or five times when disarming indicates

Tamper Alert, which is described in the Diagnostics Section of

this guide.

high security disarm

This security system offers High Security Disarm. High Security

➜

➜

➜

note: Multi-Level Security Arming only applies to a sin­gle arming cycle. Once the system is disarmed and then
re-armed, all the zones will be active again.

15

© 2005 directed electronics—all rights reserved

Disarm is a feature that makes it possible to silence and reset the

system while it is triggering, without disarming the system. If the

system is triggered and the siren has been sounding for longer

than six seconds, pressing on the remote transmitter will

stop the trigger and return the unit to the armed state. The

system will not disarm, but rather reset. This prevents you from

disabling the system should you wish to disarm it without visu-

ally checking the vehicle. Pressing after resetting the system

will disarm the system; pressing this button during the first six

seconds of the triggered sequence will disarm the security system

immediately. The six second timer is provided for your conve-

nience, in case the system is accidentally triggered.

disarming without a transmitter

If your remote transmitter is lost or damaged, you can manually

disarm your vehicle security system. To disarm the system

without a transmitter, you must have the vehicle's ignition key

and know where the Valet

®

switch is located. Be sure to check

with your installer at the time of installation for both the loca-

tion and the preset response (1-5 presses) of the Valet

®

switch.

➜

16

© 2005 directed electronics—all rights reserved

To disarm the security system,

turn the ignition to the ON posi-

tion. Press the Valet button the

preset number of times (one to

five times) within 15 seconds.

After five seconds, the system will

disarm. If the system does not

disarm, you may have waited too

long; turn the ignition off and on and try again.

Location of Valet Button_________________________________

Number of Presses_____________________________________

silent mode

To temporarily turn off the arm or disarm chirps, use Silent

Mode™. Simply press for less than one second before

arming or disarming, and the confirmation chirp(s) will be elim-

inated for that one operation only. If you want the arm/disarm

chirps turned off permanently, your dealer can do this for you.

note: The Warn Away® response to lighter impacts is
bypassed if the system is armed using Silent Mode. This
ensures that no chirps will be emitted by the siren in an
area you want chirp-free. The system is still fully capable
of triggering. Only the Warn Away® response is
bypassed.

➜

important! The Valet button can be programmed to
respond to 1-5 presses for the disarm function. You must
check with the installer to verify the programming for
your individual unit.

DRW-35

17

© 2005 directed electronics—all rights reserved

panic mode

If you are threatened in or near your vehicle, you can attract

attention by triggering the system with your transmitter. Just

press for two seconds, and you will enter Panic Mode. The

siren will sound and the parking lights will flash for the

programmed siren duration. To stop Panic Mode at any time,

press on the remote transmitter again.

valet mode

You can prevent your security system from automatically arming

and triggering by using Valet Mode. This is very useful when

washing the vehicle or having it serviced. In Valet Mode, the

security system will not arm, even with the remote transmitter,

but all convenience functions (door locks, trunk release, etc.) will

continue to work normally.

To enter or exit Valet Mode:

1. Turn the ignition on.

2. Turn the ignition off.

3. Press and release the Valet

button within 10 seconds.

The status LED will light solidly if you are entering Valet Mode,

and it will go out if you are exiting Valet Mode.

To enter or exit Valet Mode using the transmitter:

1. Open any vehicle door.

2. Press .

➜

➜

DRW-35

18

© 2005 directed electronics—all rights reserved

3. Press .

4. Press again.

The status LED will light solidly if you are entering Valet Mode,

and it will go out if you are exiting Valet Mode.

remote start

This feature allows you to remotely start and run your vehicle for

a programmable period of time. This makes it possible to warm

up the engine, as well as adjust the interior temperature of the ve-

hicle with the climate control system. If interior heating or

cooling is desired, the climate controls must be preset, and the

fan blower must be set to the desired level prior to remote starting

the vehicle.

To remote start the vehicle:

1. Press on the transmitter twice within 3 seconds.

2. The parking lights will flash to confirm that the vehicle will

attempt to start.

3. In gasoline vehicles, the engine will start 4 seconds after the

parking lights flash. In diesel vehicles, the engine will start

when the WAIT-TO-START indicator on the vehicle's dash

goes out or the programmed delay has ended.

iimmppoorrttaanntt!!

(1) Never remote start your vehicle when the
keys are in the ignition, except when performing Valet
Take-Over, and (2) Never start the vehicle if it is not in
either PARK or NEUTRAL.

➜

19

© 2005 directed electronics—all rights reserved

4. Once the vehicle has started, it will run for the pre-program-

med period of time (either 12, 24, or 60 minutes - see

Programming Options section of this guide) or until a shut-

down input is triggered.

When you are ready to drive the vehicle:

1. Insert the ignition key and turn

it to the ON (not START) posi-

tion.

2. Press the brake pedal.

While the vehicle is running during remote start operation, the

system will monitor the vehicle and will automatically shut down

the engine if the system receives any of the following shut-down

inputs:

➤ The brake pedal is pressed.

➤ The hood is opened.

➤ The shutdown toggle switch is put into the OFF position.

➤ The pre-programmed run time (12, 24, or 60 minutes) has

elapsed.

➤ Transmitter buttons is pressed twice within 3 seconds.

note: If the brake pedal is pressed before the key is in the
ON position, the engine will shut down.

iimmppoorrttaanntt!!

It is unsafe to operate a vehicle’s motor in a
garage or other closed off area. Breathing the exhaust
from the vehicle is hazardous to your health. Never acti­vate the remote start in an enclosed space.

20

© 2005 directed electronics—all rights reserved

rear defogger

To turn the rear defogger output OFF:

1. Simultaneously press & release the + + buttons

on the remote control.

2. The lights will flash 2 times.

3. The rear defogger output will no longer activate when the

vehicle is remote started.

To turn the rear defogger output ON:

1. Simultaneously press & release the + + buttons

on the remote control.

2. The lights will flash 3 times.

3. The rear defogger output will once again activate when the

vehicle is remote started.

note: If the temperature is greater than 55° F at the time
of remote start activation, the rear defogger will not acti­vate for that start.

note: If the remote start is on the lights will turn off then
flash 3-times before returning to their normal output and
the defogger output will activate as programmed.

note: If the remote start is on the parking lights will turn
off then flash 2-times before returning to their normal
output and the defogger output, if active, will cease.

➜

21

© 2005 directed electronics—all rights reserved

valet take-over

The Valet Take-Over feature allows the vehicle to remain running

after the key has been removed from the ignition. This feature is

useful for occasions when you wish to exit and lock the vehicle

for short periods of time, but would like to leave the motor

running and the climate controls on.

To perform Valet Take-Over:

1. Before turning off the engine, press and release twice

within 3 seconds on the transmitter (or press and release the

optional momentary switch). Then wait five seconds.

2. Turn the ignition key to the OFF position. (The engine will

stay running.)

3. The engine will run until the pre-programmed time elapses

or a shut-down input is received. (See the previous

Remote

Start

section for a complete list of shut-down inputs.)

short-run/turbo

Short run turbo mode keeps the engine running after arriving at

you destination for a programmable period of 1, 3, 5 or 10

minutes. This allows the system’s timer to conveniently cool

down the turbo after you have left the vehicle.

➜

note: This feature will not work if the brake pedal is
being pressed.

➜

22

© 2005 directed electronics—all rights reserved

To activate:

1. Park the vehicle and set parking brake.

2. Remove your foot from the brake pedal and leave the engine

running.

3. Press and release the and buttons at the same time.

4. The lights will flash to indicate the remote start has entered

short run turbo mode.

5. Turn off the key, the engine will keep running.

6. Exit and secure the vehicle.

7. The engine will turn off after the programmed run time.

timer/temperature mode

By pressing the remote and buttons the parking

lights will flash 4 times and then start the vehicle and run for the

set duration in timer mode. The remote start can be shut off by

the transmitter by pressing the remote start button and

remain in timer mode, but if any other shut down zones or the

ignition becomes active the timer mode will cancel.

1. Press Timer mode buttons.

2. The vehicle will confirm with 4 parking light flashes.

3. A 1-second delay will start.

➜

23

© 2005 directed electronics—all rights reserved

4. The system will start the car and will run for the specified

duration, unless shut down by the remote start button . If

shut down with the remote start button the

system will remain in timer mode.

5. The system will start every 3 hours until canceled by the

brake, hood, or neutral safety shut-down wires.

To exit timer mode, turn the ignition switch on any time the

engine is running. The parking lights will flash 4 times, indi-

cating timer mode has been exited.

If the system is set up to start in temperature mode, the vehicle

will start at the specified elapsed time but only if the temperature

is less than 0 degrees Fahrenheit.

ssaaffeettyy ffeeaattuurreess

This system has several important safety features to ensure proper

operation of the motor and prevent accidental damage to the

engine or its components.

note: The low temperature start operation will automat­ically exit after 18 hours..

important

!!

Timer Mode should be used only in
open areas. Never start and run the vehicle in an
enclosed space such as a garage or carport.

24

© 2005 directed electronics—all rights reserved

starter anti-grind circuitry

Whenever the vehicle is remote started, advanced anti-grind

circuitry prevents the starter from engaging, even if the key is

turned to the start position. This prevents damage to the starter

motor if the key is turned to the start position during remote start

operation.

disabling the remote start system

This feature allows your system's remote start unit to be

temporarily disabled to prevent the vehicle from being remote

started accidentally. This feature is useful if the vehicle is being

serviced or stored in an enclosed area. To disable the remote start,

move the shutdown toggle switch to the OFF position. The

switch can be installed in a location of your choice. Check with

your installer for recommended locations.

Location of Shutdown Switch____________________________

over and under rev protection

The system monitors the engine speed and will automatically

shut the engine off if the RPMs rise above or fall below the

programmed levels. This feature prevents damage to the motor

due to fuel delivery system failures or other problems which may

cause the engine to race.

note: The system uses a wire connected to the vehicle to
sense engine speed. This wire must be connected in order
for over and under rev protection to work.

➜

➜

➜

25

© 2005 directed electronics—all rights reserved

shut down inputs

This security system uses several inputs to shut down the remote

start operation of the motor or prevent remote start if certain

inputs are active. The two most important are hood and brake

inputs. The hood input will prevent the motor from starting, as

well as shut it down, any time the hood is opened. The brake

pedal will shut down the motor at any time during remote start

operation, as well as preventing the remote start from activating

while it is being pressed.

nuisance prevention®circuitry

Your system has Directed’s Nuisance Prevention®Circuitry

(NPC). It prevents annoying repetitive trigger sequences due to

faulty door pin switches or environmental conditions such as

thunder, jackhammers, airport noise, etc.

Example

If the alarm triggers three times within a 60-minute period and

each time the same sensor or switch triggers the alarm, NPC will

interpret those triggers as false alarms. After the third trigger,

NPC ignores, or bypasses, that sensor or switch (along with any

other sensors or switches sharing the same zone) for 60 minutes.

If the bypassed sensor tries to trigger the security system while it

is being bypassed, the 60-minute bypass period will start over.

This ensures that a sensor that is continually being triggered will

remain bypassed.

➜

➜

26

© 2005 directed electronics—all rights reserved

The vehicle doors are protected by NPC differently. If your secu-

rity system is triggered by an open door for three full cycles, the

system will bypass the doors until the trigger ceases.

ddiiaaggnnoossttiiccss

The microprocessor at the heart of your system is constantly

monitoring all of the switches and sensors connected to it. It is

designed to detect any faulty switches and sensors and prevents

them from disabling the entire system. The microprocessor will

also record and report any triggers that occurred during your

absence. Refer to the

System Status Chirps

and

Table of Zones

sections of this guide for diagnostic information.

arming diagnostics

If the security system is armed at the same time that an input is

active (such as a door opening or sensor triggering), you will hear

one siren chirp to indicate arming and a second siren chirp to

indicate Bypass Notification. A Bypass Notification chirp means

that the security system ignores the input that was active when

➜

note: Arming and disarming the system does not reset
this function! The only ways to reset a bypassed zone are
for it to not trigger for 60 minutes, or to turn on the igni­tion. If testing your system, it is important to remember
that the NPC programming can cause zones to be
bypassed and appear to stop working. If five chirps are
heard when disarming, NPC has been engaged. If you
wish to clear the NPC memory, turn the ignition on.

27

© 2005 directed electronics—all rights reserved

the system was armed, until that input ceases. Three seconds

after that input ceases, the security system will resume normal

monitoring. For example, if your vehicle has an interior light exit

delay and you arm your security system before the interior light

turns off, you may hear a second Bypass Notification chirp.

Once the light turns off, however, the security system resumes

normal monitoring.

disarming diagnostics

Extra chirps that are heard when disarming the system are the

Tamper Alert. If four chirps are heard when disarming the

system, then the security system was triggered in your absence. If

five chirps are heard when disarming the system, a zone was trig-

gered so many times that the Nuisance Protection

®

Circuitry has

bypassed that zone. In either case, the status LED will indicate

which zone was involved (see

Table of Zones

section). The secu-

rity system will retain this information in its memory and chirp

four or five times each time it is disarmed, until the next time

that the ignition is turned on.

system status chirps

The siren will chirp when arming/disarming the system. The

pattern of chirps will audibly report the system’s status as

described below.

➜

➜

note: Bypass Notification does not occur when the sys­tem is in Silent Mode or if the notification chirps have
been programmed off by the installer.

28

© 2005 directed electronics—all rights reserved

table of zones

A zone is represented by the number of LED flashes used by the

system to identify a particular type of input. Standard input

assignments are listed in the following table, along with spaces to

write in any optional sensors or switches that have been installed.

ZZOONNEE

(Number of

DDEEAALLEERR--IINNSSTTAALLLLEEDD

LED Flashes)

DDEESSCCRRIIPPTTIIOONN OOPPTTIIOONNSS

11

Trunk Pin

22

Instant trigger - a heavier impact
detected by the shock sensor

33

Door switch trigger

44

Instant trigger - for optional
sensors

55

Ignition trigger

66

Hood Pin

➜

Action Number of Chirps Description

Arm 1 System armed

Arm 1 (3-second delay), 1 System armed with

Bypass Notification

Disarm 2 System disarmed

Disarm 4 System disarmed with

Tamper Alert

Disarm 5 System disarmed NPC

active

29

© 2005 directed electronics—all rights reserved

interpreting zone diagnostics

Warn Away responses are not reported by arming or disarming

diagnostics. If you receive a Bypass notification when arming or

a Tamper Alert notification when disarming, look at the LED.

Active or triggered zones will be indicated by a pattern of blinks

by the LED.

Example

If zone 3 was active or triggered, the LED will blink three times

with a two-second pause. Then it will blink three times again,

and repeat until the ignition is turned on.

ccooddee hhooppppiinngg

The receiver and transmitters use a mathematical formula called

an algorithm to change their code each time the transmitter is

used. This technology has been developed to increase the secu-

rity of the unit. The control unit knows what the next codes should

be. This helps to keep the transmitter “in sync” with the control

unit even if you use the remote control out of range of the

vehicle. However, if the remote has been pressed many times out

of range of the vehicle, or the battery has been removed, it may fall

note: Your system stores the last two triggered zones in
memory. If your system has been triggered but the LED
has been reset by turning on the ignition, your dealer can
still recall the last two zones that were triggered. Contact
your dealer for details.

➜

30

© 2005 directed electronics—all rights reserved

out of sync with the control unit and fail to operate the system.

To re-sync the remote simply press several times within

range of the vehicle. The alarm will automatically re-sync and

respond to the transmitters normally.

hhiigghh ffrreeqquueennccyy

Your system transmits and receives at 434 MHz. This provides a

cleaner spectrum with less interference and a more stable signal.

Enjoy a phenomenal increase in range, even in areas with high

radio interference.

oowwnneerr rreeccooggnniittiioonn

Owner Recognition is a revolutionary new feature available only

from Directed. Using a Directed Bitwriter

®

, hand-held program-

ming tool, your dealer can program many of the system settings.

The programmer makes it possible to program different settings

for each transmitter that is used with the system. Then, whenev-

er a specific transmitter is used, the system will recall the settings

assigned to that transmitter. Owner Recognition lets up to four

users of the system have different settings that meet their specific

needs. It is almost like having four separate alarms in your

vehicle, one for each user.

31

© 2005 directed electronics—all rights reserved

rraappiidd rreessuummee llooggiicc

This Directed system will store its current state to non-volatile

memory. If power is lost and then reconnected the system will

recall the stored state from memory. This means if the unit is in

Valet Mode and the battery is disconnected for any reason, such

as servicing the car, when the battery is reconnected the unit will

still be in Valet Mode. This applies to all states of the system

including arm, disarm, and Valet Mode.

ppoowweerr ssaavveerr mmooddee

Your system will automatically enter Power Saver Mode while

armed or in Valet Mode, after a period of time in which no oper-

ation has been performed. This lowers the current draw on the

vehicle's battery. Power Saver Mode takes over under the

following conditions:

➤ Power Saver when the system is armed: After the system has

been armed for 24 hours the LED will flash at half its

normal rate, decreasing the system's current draw.

➤ Power Saver in Valet Mode: When the system enters Valet

note: Owner Recognition cannot be programmed with­out a Bitwriter

®

and the necessary software. Check with

your dealer for more information.

32

© 2005 directed electronics—all rights reserved

Mode the LED illuminates steadily. If the vehicle is not used

(ignition is not turned on) for a one hour period while the

system is in Valet Mode, the LED will shut off. If the system

remains in Valet Mode, the LED will come back on the next

time the ignition is turned on and then back off.

pprrooggrraammmmiinngg ooppttiioonnss

Programming options control your system's normal, operational

set-up. Most options do not require additional parts, but some

may require installation labor.

The following is a list of the programmable options, with the

factory settings in Bold.

➤

AAccttiivvee

arming (transmitter only) or passive arming (auto-

matic arming 30 seconds after the last door has been closed).

➤ Arming/disarming siren chirps

oonn

or off.

➤ The ignition controlled door lock feature

oonn

or off: When

this feature is programmed on, the doors will lock three

seconds after the ignition is turned on, and unlock when the

ignition is turned off. If your installer is programming the

security system with the Directed Bitwriter

®

, ignition lock

and unlock are independent features that can be

programmed separately.

➤ Passive door locking (with passive arming) or

aaccttiivvee ddoooorr

lloocckkiinngg

(only when arming with the transmitter). Passive

locking allows the vehicle's doors to lock when the security

33

© 2005 directed electronics—all rights reserved

system passively arms (after the 30-second countdown). This

feature only works if passive arming has been programmed.

➤ Panic mode

eennaabblleedd

/disabled when the ignition is turned

on. (Some states have laws against sirens sounding in moving

cars.)

➤ Forced passive arming

oonn

or off. If your security system is

programmed for passive arming and the forced passive

arming feature has been programmed on, the system will

passively arm after one hour, even if a protected entry has

been left open. Forced passive arming ensures that the

system will be armed if a door has accidentally been left ajar

when leaving the vehicle.

➤ Full trigger response

3300

or 60 seconds: This determines how

long the full triggered sequence lasts. Some states have laws

regulating how long a security system can sound before it is

considered a nuisance. If your installer is programming the

security system with the Directed Bitwriter

®

, the full trig-

gered response can be programmed for any duration ranging

from 1 to 180 seconds.

➤ Automatic Engine Disable (AED) on or

ooffff

. The purpose of

this feature is to protect the vehicle from being stolen at all

times, regardless of whether or not the alarm is armed. If

note: When the system passively arms after one hour, the
entry point that has been left open, and anything con­nected to the same zone, is bypassed and cannot trigger
the system. However, the remaining inputs to the system
are fully operational.

34

© 2005 directed electronics—all rights reserved

AED is programmed on, the starter of the vehicle will be

disabled 30 seconds after the ignition is turned off. Once the

key is turned off, the LED will flash slowly (one-half its

normal armed rate) to indicate the AED arming cycle.

Thirty seconds later, the starter will be disabled. To start the

car, it will be necessary to disarm the system with the trans-

mitter. It is also possible to disarm the AED feature by

turning the ignition key to the RUN position and pressing

the Valet button the programmed number of times. AED is

also disabled when the system is in Valet mode.

➤ Siren tones and chirp volume. The output of the Revenger

™

Soft Chirp™siren consists of six different tones in sequence.

Any of these tones can be eliminated by a dealer, resulting in a

unique, easily identifiable siren sound. The chirps can be either

full volume or

66 ddeecciibbeellss qquuiieetteerr

than the full alarm blast.

➤ 12, 24, or 60 minute run time. your system can be

programmed to allow the vehicle to run for 12, 24, or 60

minutes when remote started. Can be set up to minute

increments by your installer.

➤ 3, 6, 9, or 12 minute timer mode run time. Your system can

be programmed to allow the vehicle to run for 3, 6, 9, or 12

minutes when remote started in timer mode. Can be set up

to 16 minutes by your installer.

note: This feature will only function if the FailSafe

®

Starter Kill relay has been installed.

35

© 2005 directed electronics—all rights reserved

➤ While the remote start system is running the engine, the

parking lights of the vehicle can

ffllaasshh oonn aanndd ooffff

or come on

and light steadily.

➤ Comfort closure is a programming option which closes the

vehicle’s windows after remote locking.

sseeccuurriittyy && ccoonnvveenniieennccee eexxppaannssiioonnss

Listed below are some of the many expansion options available.

Please consult your dealer for a complete explanation of all the

options available to you.

Audio Sensor:

Metal on glass, glass cracking, and breaking

glass produce distinctive acoustic signatures. The 506T audio

sensor uses a microphone to pick up sounds, then analyzes them

with proprietary acoustic software to determine if the glass has

been struck.

Backup Battery:

The 520T keeps the system armed, triggers the

alarm and keeps the starter interrupt active if main battery is dis-

connected.

Hood Lock:

Prevents the vehicle’s hood from being opened

without a key, keeping thieves away from the system’s siren, the

battery connections, and other components under the hood.

Field Disturbance Sensor:

An invisible dome of coverage is estab-

lished by installing the 508D “radar” sensor. Your system can

react to any intrusions into this field with the full triggered

36

© 2005 directed electronics—all rights reserved

sequence.

Power Locks:

This system offers lock outputs that can control

some manufacturers' power door lock systems. For other

systems, additional parts may be required.

Power Trunk Release:

The accessory output of the system can op-

erate a factory power release for the vehicle’s trunk or hatch.

Although the on-board relay can control most power trunk re-

leases, sometimes an optional relay is required. If the factory

release is not power-activated, Directed

®

's 522T trunk release

solenoid can often be added.

Power Window Control:

Automatic power window control is pro-

vided with the 529T and 530T systems. These can operate

power windows, and can roll them up automatically when the

system is armed, roll them down, or both up and down.

Mobile Video:

This system is compatible with Directed Video’s

MCB1000 Multi-Channel Controller, featuring on-screen secu-

rity system programming and zone trigger information.

37

© 2005 directed electronics—all rights reserved

gglloossssaarryy ooff tteerrmmss

Control Unit:

The “brain” of your system. Usually hidden under-

neath the dash area of the vehicle. The control unit houses the

microprocessor which monitors your vehicle and controls all

system functions.

Fault-Proof Starter Interrupt:

An automatic switch controlled by

your system that prevents the vehicle’s starter from cranking

whenever the system is armed. The vehicle is never prevented

from cranking when the system is disarmed, in Valet Mode, or if

the starter interrupt switch itself fails. Your system has feature-

ready circuitry for the starter interrupt, however installation may

require additional labor.

Input:

A physical connection to the system. An input can be

provided by a sensor, pinswitch or by existing systems in the

vehicle, such as ignition or courtesy lights.

LED:

A red light mounted at a discretionary location inside the

vehicle. It is used to indicate the status of your system.

Shock Sensor:

This system has a dual zone shock sensor. This

sensor is mounted in the vehicle and designed to pick up impacts

to the vehicle or glass.

Transmitter:

A hand-held, remote control which operates the

various functions of your system.

38

© 2005 directed electronics—all rights reserved

Trigger or Triggered Sequence:

This is what happens when the

alarm “goes off” or “trips.” The triggered sequence of your

system consists of the siren sounding and parking lights flashing

for the programmed duration.

Valet button:

A small push button mounted at a discretionary

location inside the vehicle. It is used to override the starter inter-

rupt when a transmitter is lost or damaged, or to enter or exit

Valet Mode.

Warning Zone Response:

Lighter impacts to the vehicle will

generate the Warning Zone response. It consists of several

seconds of siren chirps and parking light flashes.

Zone:

A zone is a separate input that the alarm can recognize as

unique. Each input to the system is connected to a particular

zone. Often two or more inputs may share the same zone.

39

© 2005 directed electronics—all rights reserved

QUICK REFERENCE GUIDE

Arming

■ To arm, press . When the system arms, you will hear a short chirp, and
the parking lights will flash once.

Arming while driving

■ To arm the system while driving, press on your transmitter while the
vehicle is running. The system will chirp once and then once more to indi­cate that the ignition is on.

Disarming

■ To disarm, press . You will hear two chirps, and the parking lights will
flash twice.

High security disarm

■ For high security disarm, press on your transmitter and the siren will stop
sounding. To completely disarm the security system, press again and the
system will chirp 4 or 5 times (reporting the trigger).

Disarming without a transmitter

■ Turn on the ignition. Press the Valet button within 15 seconds. The system
should now disarm. If it does not, you may have waited too long, so turn the
ignition off and on and try again.

Silent Mode

™

■ Pressing briefly before arming or disarming will eliminate the confir-
mation chirp(s) for that one operation only.

Panic Mode

■ Press for 2 seconds, and you will enter Panic Mode. The siren will sound
and the parking lights will flash for 30 seconds. To stop Panic Mode at any
time, press on the transmitter again.

To remote start the vehicle

■ Press twice within 3 seconds. The parking lights will turn on (if
connected) and the vehicle will start and run for the programmed period of
time.

To disable the remote start system

■ To disable the remote start, move the shutdown toggle switch to the OFF
position.

Location of Valet button_________________________________
Number of Valet button pulses for disarming_______________

CCuutt aalloonngg ddootttteedd lliinnee aanndd ffoolldd ffoorr aa qquuiicckk aanndd eeaassyy rreeffeerreennccee ttoo kkeeeepp iinn yyoouurr ppuurrssee oorr wwaalllleett..

✂

✂

40

© 2005 directed electronics—all rights reserved

CCuutt aalloonngg ddootttteedd lliinnee aanndd ffoolldd ffoorr aa qquuiicckk aanndd eeaassyy rreeffeerreennccee ttoo kkeeeepp iinn yyoouurr ppuurrssee oorr wwaalllleett..

✂

✂

RReeaarr WWiinnddooww DDeeffooggggeerr

■ Press the , , and buttons simultaneously to turn the

defogger on or off when remote starting. When a remote start is initi­ated, the parking lights will flash 2-times if the defogger is set to off,
and will flash 3-times if the defogger is set to on.

41

© 2005 directed electronics—all rights reserved

The company behind this system is Directed Electronics

Since its inception, Directed Electronics has had one purpose, to provide consumers with
the finest vehicle security and car stereo products and accessories available. The recipient of
nearly 100 patents and Innovations Awards in the field of advanced electronic
technology, Directed is ISO 9001 registered.

Quality Directed Electronics products are sold and serviced throughout North America
and around the world.

Call

((880000)) 227744--00220000

for more information about our products and services.

Vista, CA 92081

www.directed.com

© 2005 Directed Electronics—All rights reserved

G919563 07-05

Directed Electronics is committed to delivering world class quality products

and services that excite and delight our customers.
