Remote Start Keyless Entry
Model 1.3X
Owner’s Guide
© 2011 Directed Electronics, Vista, CA
G4202X 2011-03
Contents
Government regulations .................................................................................... iii
Warning! Safety first .........................................................................................v
What’s included ................................................................................................1
Important information ........................................................................................1
Your warranty...........................................................................................1
Replacement remote controls ......................................................................1
Responder LE 2- way remote ...............................................................................2
1- way companion remote ..................................................................................3
Transmitter configuration ............................................................................4
Control Center ..................................................................................................5
Basic commands ...............................................................................................6
Lock .......................................................................................................6
Unlock .....................................................................................................6
Remote Start .............................................................................................6
AUX .......................................................................................................6
Function shift ............................................................................................7
Advanced commands: function level 1 .................................................................8
Silent lock ................................................................................................8
Silent unlock .............................................................................................8
Runtime reset ............................................................................................8
Aux 1 ......................................................................................................8
Cabin temperature ....................................................................................8
Advanced commands: function level 2 ................................................................9
Valet mode ..............................................................................................9
Timer mode ..............................................................................................9
Aux 2 ......................................................................................................9
Lock status ...............................................................................................9
Advanced commands: function level 3 ...............................................................10
Car finder ..............................................................................................10
Smart start .............................................................................................10
Aux 3 ....................................................................................................10
Runtime check ........................................................................................10
Advanced commands: function level 4 ...............................................................11
Rear defogger ........................................................................................11
Aux 4 ....................................................................................................11
Out of range notification ..................................................................................12
System maintenance ........................................................................................12
Low battery indicator ..............................................................................13
Configuring your remote ..................................................................................14
Programming .........................................................................................16
Multi-car control capability .......................................................................17
© 2011 Directed Electronics. All rights reserved.
i
Using your system ...........................................................................................19
Locking the vehicle ..................................................................................19
Unlocking the vehicle ..............................................................................19
Valet mode ...........................................................................................20
Panic Mode ...........................................................................................21
Overriding the optional Starter kill ............................................................21
Using the remote start ......................................................................................22
Manual transmission vehicles ...................................................................24
Timer mode ............................................................................................25
Turbo timer mode ....................................................................................26
Smart start activation ...............................................................................27
Low runtime alert ....................................................................................28
Cabin temperature ..................................................................................28
Turning on the rear defogger ....................................................................29
Pit Stop mode ........................................................................................29
Safety features ................................................................................................30
Optional starter anti-grind circuitry ............................................................30
Disabling the remote start system ..............................................................30
Remote Start Safe-lock .............................................................................30
Diagnostics ....................................................................................................31
Locking ..................................................................................................31
Unlocking ..............................................................................................31
Remote start ...........................................................................................31
Owner recognition ..........................................................................................32
Rapid resume logic ..........................................................................................32
Power saver mode...........................................................................................32
Programming options .......................................................................................33
Convenience expansions ..................................................................................34
Glossary of terms ............................................................................................35
Quick reference guide .....................................................................................37
Limited lifetime consumer warranty ....................................................................40
ii
© 2011 Directed Electronics. All rights reserved.
Government regulations
This device complies with Part 15 of FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference
that may cause undesirable operation.
This equipment has been tested and found to comply with the limits for a
class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates and can radiate radio frequency energy and, if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television,
which can be determined by turning the equipment Off and ON, the user is
encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which
the receiver is connected.
• Consult the dealer or an experienced radio / TV technician for help.
To satisfy FCC RF exposure compliance requirements, this device should be used
in hand-held, hand operated configurations only. The device and its antenna
must maintain a separation distance of 20 cm or more from the person’s body,
except for the hand and wrists, to satisfy RF exposure compliance. This device
is designed to be used in a person’s hands and its operating configurations do
not support normal transmissions while it is carried in pockets or holsters next to
a persons’ body.
© 2011 Directed Electronics. All rights reserved.
iii
This device complies with the Industry Canada Radio Standards Specification
RSS 210. Its use is authorized only on a no-interference, no-protection basis;
in other words, this device must not be used if it is determined that it causes
harmful interference to services authorized by IC. In addition, the user of this
device must accept any radio interference that may be received, even if this
interference could affect the operation of the device.
Warning:
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate this device.
iv
© 2011 Directed Electronics. All rights reserved.
Warning! Safety first
The following safety warnings must be observed at all times:
Due to the complexity of this system, installation of this product must only be
performed by an authorized Directed dealer.
When properly installed, this system can start the vehicle via a command
signal from the remote control transmitter. Therefore, never operate the system
in an enclosed area or partially enclosed area without ventilation (such as a
garage). When parking in an enclosed or partially enclosed area or when
having the vehicle serviced, the remote start system must be disabled using the
installed toggle switch. It is the user’s sole responsibility to properly handle and
keep out of reach from children all remote control transmitters to assure that the
system does not unintentionally remote start the vehicle. THE USER MUST INSTALL A CARBON MONOXIDE DETECTOR IN OR ABOUT THE LIVING AREA
ADJACENT TO THE VEHICLE. ALL DOORS LEADING FROM ADJACENT
LIVING AREAS TO THE ENCLOSED OR PARTIALLY ENCLOSED VEHICLE
STORAGE AREA MUST AT ALL TIMES REMAIN CLOSED. These precautions
are the sole responsibility of the user.
Remote starters on manual transmission vehicles operate differently than those
with automatic transmission because you must leave your car in neutral. You
must read this Owner’s Guide to familiarize yourself with the proper procedures regarding manual transmission remote starters. If you have any questions,
ask your installer or contact Directed at 1-800-753-0600.
Before remote starting a manual transmission vehicle, be sure to:
• Leave the vehicle in neutral and be sure no one is standing in front or
behind the vehicle.
• Only remote start on a flat surface
• Have the parking brake fully engaged
Warning! It is the responsibility of the owner to ensure the parking/emergency
brake properly functions. Failure to do so can result in personal injury or property damage. We recommend the owner have the parking/emergency brake
system inspected and adjusted by a qualified automotive shop biannually.
© 2011 Directed Electronics. All rights reserved.
v
Use of this product in a manner contrary to its intended mode of operation
may result in property damage, personal injury, or death. (1) Never remotely
start the vehicle with the vehicle in gear, and (2) Never remotely start the
vehicle with the keys in the ignition. The user must also have the neutral safety
feature of the vehicle periodically checked, wherein the vehicle must not
remotely start while the car is in gear. This testing should be performed by an
authorized Directed dealer in accordance with the Safety Check outlined in
the product installation guide. If the vehicle starts in gear, cease remote start
operation immediately and consult with the authorized Directed dealer to fix
the problem.
After the remote start module has been installed, contact your authorized
dealer to have him or her test the remote start module by performing the Safety
Check outlined in the product installation guide. If the vehicle starts when
performing the Neutral Safety Shutdown Circuit test, the remote start unit has
not been properly installed. The remote start module must be removed or the
installer must properly reinstall the remote start system so that the vehicle does
not start in gear. All installations must be performed by an authorized Directed
dealer.
OPERATION OF THE REMOTE START MODULE IF THE VEHICLE STARTS IN
GEAR IS CONTRARY TO ITS INTENDED MODE OF OPERATION. OPERATING THE REMOTE START SYSTEM UNDER THESE CONDITIONS MAY
RESULT IN PROPERTY DAMAGE OR PERSONAL INJURY. YOU MUST IMMEDIATELY CEASE THE USE OF THE UNIT AND SEEK THE ASSISTANCE OF AN
AUTHORIZED Directed DEALER TO REPAIR OR DISCONNECT THE INSTALLED
REMOTE START MODULE. DIRECTED WILL NOT BE HELD RESPONSIBLE OR
PAY FOR INSTALLATION OR REINSTALLATION COSTS.
This product is designed for fuel injected vehicles only. Use of this product in a
standard transmission vehicle must be in strict accordance with this guide.
This product should not be installed in any convertible vehicles, soft, or hard
top with a manual transmission. Installation in such vehicles may pose certain
risk.
vi
© 2011 Directed Electronics. All rights reserved.
What’s included
• One five-button/2- way Supercode Responder LE remote control
• One five-button/1- way Supercode remote
• The control module (installed out-of-sight)
• Control Center with integrated status LED and Control button
• A remote start defeat toggle switch
• Window decals
• Your warranty registration
Important information
Congratulations on the purchase of your state-of-the-art remote start and keyless
entry system. Due to the complexity of this system, it must be installed by an
authorized dealer only. Installation of this product by anyone other than an authorized dealer voids the warranty. All dealers are provided with a preprinted
dealer certificate to verify authorization.
By carefully reading this Owner’s Guide prior to using your system, you will
maximize the use of this system and its features. You can print additional or
replacement copies of this manual by accessing our web site at
www.directed.com.
➢ Your warranty
Your Responder LE system comes with a warranty. Please make sure you
receive the warranty registration card and proof of purchase from your dealer
indicating the product was installed by an authorized Directed dealer. Your
product warranty must be validated within 10 days of purchase. You can
validate it online at
the warranty registration card.
www.prodregister.com/directed
or complete and return
➢ Replacement remote controls
Your system comes with one Responder LE remote control (P/N 7251X) and
one remote control (P/N 7152X). If additional remotes are desired, please
see your authorized dealer or visit www.directedstore.com to order.
© 2011 Directed Electronics. All rights reserved.
1
Responder LE 2- way remote
531;
,&$
)&&,'(=6'(,
%$77(5<&5
8
1
2
3
4
5
6
9
7
AUX
3
2
8
7
Feature
Description
1 Lock button Press for one second to lock.
2 Unlock button Press for one second to unlock.
3 Remote start
button
4 Auxiliary
button
5 Function
button
Press for one second to activate remote
start.
Press and hold for 1.5 second to activate
optional trunk release.
Allows access to programming and
modifies operation of the other buttons.
6 Label Back of remote has label to identify the
7 Battery Door Remove to access batteries when
8 Transmit indicator
9 LED indicators Flashes to indicate function confirmation
Note: If Keypad Lock is On, press
2
remote as 2- way or 1- way.
necessary. For more detail, see Page13.
and then press
© 2011 Directed Electronics. All rights reserved.
to unlock.
1-way companion remote
531;
,&$
)&&,'(=6'(,
%$77(5<&5
1
2
3
4
5
6
1
2
3
4
5
531;
,&$
)&&,'(=6'(,
%$77(5<&5
7
6
7
AUX
AUX
Note: See call-out table for 2- way remote.
© 2011 Directed Electronics. All rights reserved.
3
➢ Transmitter configuration
A U X
A U X
A U X
A U X
A U X
A U X
Basic
Advanced Commands
Commands
Button
Level
Direct Access
Function
Level 1
x 1
Function
Level 2
x 2
Lock Silent Lock
Unlock Silent Unlock Valet Mode Car Finder
Remote Start Reset Runtime Timer Mode Smart Start Rear
Trunk Release AUX 1 AUX 2 AUX 3 AUX 4
AUX
*
Function
Shift**
Cabin Temp.
Request**
(2- way only)
Lock
Status**
(2- way
Runtime
Check**
(2- way only)
only)
*Used to access function levels for Advanced Commands
(
with multiplier in third row implies button presses)
** Must be pressed and held to access state
Function
Level 3
x 3
Function
Level 4
x 4
Defogger
4
© 2011 Directed Electronics. All rights reserved.
Control Center
The Control Center, typically located on the upper part of the front windshield
sends and receives commands or messages to and from your system. It consists
of:
• The In-vehicle system antenna, for 2- way communication to the system.
• The Status LED, as a visual indicator of the system’s status.
• The Control button, for placing the system into Valet Mode and to per-
form the Emergency Override operation.
Control Button
LED
© 2011 Directed Electronics. All rights reserved.
5
Basic commands
Lock
Command
Feedback
:
Notes
:
Unlock
Command
Feedback
: Unlock LED turns on and remote beeps twice.
Notes
:
Remote
Start
Command
Feedback
:
Notes
Remote Start
AUX
AUX
:
Command
Feedback
: The AUX LED turns on and AUX activation tone
Notes
: This is an optional feature. See your authorized Di-
:
Press one time to Lock
Lock LED turns on with 1 beep.
Press/hold for 1.5 seconds to Lock the system and
then activate the Panic output*
:
Press one time to Unlock
: Press one time to activate Remote Start
Remote Start LED turns on, remote start tones.
: Press and hold for 1.5 seconds to activate the Trunk
Release.
sounds.
rected dealer for details.
6
© 2011 Directed Electronics. All rights reserved.
Function
A U X
shift
Command
Feedback
Function Shift
Notes
Feedback is available on the 2- way remote only.
*Horn honk is an optional feature. The panic and horn honk feature is available when this option is installed.
Pressing more than one button simultaneously generates an error tone and the
Function LED turns on, and all other LEDs flash.
: Press 1 to 4 times. ( See Function shift table.)
: LED indicators turn on (according to the feature com-
mand)
: Each Press then release, shifts the function of the com-
mand button.
© 2011 Directed Electronics. All rights reserved.
7
Advanced commands: function level 1
A U
X
A U
X
A U
X
A U
X
A U
X
A U
X
Silent lock
Command
Feedback: Lock LED turns on.
Notes
Silent unlock
Command
Feedback: Unlock LED turns on.
Notes
Runtime reset
Command
Feedback: Remote start on tones sound, all LEDs light up to indicate start
Notes
Aux 1
Command
Feedback: The Aux LED turns on, activation tone sounds.
Notes
: Press
one- time and then press
.
: Locks the system without horn honks*
: Press
one- time and then press
.
: Unlocks the system without horn honks*
: Press
one-time and then
.
time has been restored.
: Re-starts the runtime counter if remote start is active. If the re-
mote start is not active, the 2- way remote responds with error
tone. (see Page 23)
: Press
one time and then press AUX .
: This is an optional feature. See your authorized Directed
dealer for details.
Cabin temperature
Command
Feedback: Cabin temperature is displayed on the remote.
Notes
*Horn honk is an optional feature.
8
: Press
one time, then Hold for 1.5 seconds .
: LED lights turn on to indicate a range. (See Page 28)
© 2011 Directed Electronics. All rights reserved.
Advanced commands: function level 2
A U
X
A U
X
A U
X
A U
X
A U
X
Valet mode
Command
Feedback: Remote beeps 1 to 2 times when entering or exiting Valet Mode
Notes: To enter or exit Valet mode, even if Locked. When entering Valet
Timer mode
Command
Feedback: Remote start LED turns on, with 1 beep when enabled and 2
Notes
Aux 2
: Press
two-times and then
.
and unlock LED turns on.
Mode the remote beeps one-time. When exiting Valet Mode
the remote beeps two-times.
: Press
two-times and then
.
beeps for disabled.
: Enables or disables the remote start timer mode. (see Page
25)
Command
Feedback
: Press
two times and then press AUX.
: The Aux LED turns on, and Aux activation sounds.
Notes: This is an optional feature. See your authorized Directed dealer
for details.
Lock status
Command: Press
Feedback
: Lock or Unlock LED on 2- way remote lights up to display
if the system is in locked or unlocked mode.
© 2011 Directed Electronics. All rights reserved.
two-times and then hold for 1.5 seconds.
9
Advanced commands: function level 3
A U
X
A U
X
A U
X
A U
X
AUX
A U
X
Car finder
Command
: Press
three-times and then
.
Feedback: The remote emits 1 short beep, the vehicle emits 1 long horn
honk*, and the parking lights flash 10 times.
Notes
: Lock/Unlock cancels the parking light flashes.
Smart start
Command
Feedback: Remote start LED turns on, with1 beep for enable or 2 beeps for
Notes
: Press
three-times and then press
.
disable.
: Enables or disables the Smart Start feature. (see Page 27)
Aux 3
Command
Feedback: The AUX LED turns on, Aux activation tone sounds
Notes
: Press
three times and then press
.
: This is an optional feature. See your authorized Directed dealer
for details.
Runtime check
Command
Feedback: Remote start On tones sound.
Notes
: Press
three times, and then Hold for 1.5 seconds.
: Runtime remaining is displayed via LEDs. (See Page 23) If re-
mote start is not active the 2- way responds with an error tone.
10
© 2011 Directed Electronics. All rights reserved.
Advanced commands: function level 4
A U
X
A U
X
A U
X
Rear defogger
Command
: Press
four times, and then
. (after remote start is on.)
Feedback: Remote start LED turns on, 1 beep.
Notes: Manually turns on the defogger when remote start is on. If re-
mote start is not active the 2- way responds with an error tone.
This is an optional feature. See your authorized Directed dealer
for details.
Aux 4
Command
Feedback: The AUX LED turns on, Aux activation tone sounds
Notes
: Press
four times and then press AUX .
: This is an optional feature. See your authorized Directed dealer
for details.
© 2011 Directed Electronics. All rights reserved.
11
Out of range notification
If a command is issued from the remote, but the remote is beyond the range
of the vehicle to receive the command, the remote will respond with an out-of
range notification. If this occurs, the transmit indicator on the remote flashes
rapidly, the key LED turns on, and the remote emits the error tone sounds.
Since conditions will vary in different areas (i.e.: Weather, RF interference, etc)
range may be affected and require you to be closer to the vehicle for successful transmission.
System maintenance
The system requires no specific maintenance. The 2- way remote uses two
CR2016 cell batteries and the1- way remote uses one CR2032 cell battery.
When the battery begins to weaken, the operating range is reduced.
12
© 2011 Directed Electronics. All rights reserved.
Low battery indicator
+
1-800-274-0200
RPN 7152P
IC: 1513A-7152
FCC ID:EZSDEI7152
BATTERY: CR2032
Battery
Cover
Battery
Tray
Latch
Battery
Clip
Rear View
+
+
Battery
Cover
Battery
Clip
1 2
Side View Rear View
1
2
Rear View
1
2
When the batteries are low, the 2- way remote emits two groups of beeps,
the LED flashes, and additional horn honks are emitted when unlocking. It
is time to change the batteries. When the battery is low on the 1- way remote
the only indication is additional horn honks emitted when unlocking.
Note: Horn honk is an optional feature.
Battery Replacement
1. Slide the battery cover up by applying
equal pressure at its top and bottom (the
arrow on the cover indicates the direction),
remove the cover from the remote control
housing.
2. Gently pry up on the battery to remove
it from the holder. Insert a new battery into
the holder and under the clip with the positive (+) side up. Replace the battery cover.
The remote control is now ready for use.
© 2011 Directed Electronics. All rights reserved.
13
Configuring your remote
The Responder LE 2- way and 1- way remote controls have menus for programming the remote to the system, and for configuring the remote control user
features. Before you start make sure the keypad is unlocked. (See Button Auto
Lock )
Button Auto Lock
When On, the remote control buttons lock if more than 20 seconds lapses
between button presses. If a button is pressed when locked, a fault tone is
emitted.
To unlock remote buttons:
Press the
confirm.
Button Auto Unlocking
After turning the ignition off, the remote unlocks the buttons until the next command is performed. If you do not want Auto Unlocking, it can be turned off by
an authorized Directed Dealer.
Button press beep On/Off
Turns On/Off the beeps from the remote when a button is pressed.
Car 2 On or Off
Turns On/Off the Car 2 operation from the remote.
Paging* On or Off, Power Save and Power Save 2
The Responder LE remote monitors your system's messages via Paging.
* This option is not available with the 1- way companion remote.
button followed by the
button. The remote plays a tone to
When Paging is On the remote wakes up every few seconds to detect pages
from the system. When Off the remote does not wake up to receive pages
from the system.
14
© 2011 Directed Electronics. All rights reserved.
Power Save extends battery life by turning Paging Off after 72 hours if the
remote control is not used during this period. Press any button to resume system
monitoring.
Power Save 2 is for maximum battery life and will monitor the system only
when remote start has been activated.
Important: When Power Save 2 is on, the optional Factory Alarm trigger messages are not received when remote start is off. (See Convenience Expansions)
© 2011 Directed Electronics. All rights reserved.
15
➢ Programming
A U
X
AUX
AUX
A U
X
To enter:
Hold
the
button for 8 seconds, the remote emits one long beep
and the transmit LED turns on, the programming main menu has been accessed. If Car 2 mode is on, ignore the car select at 3 seconds.
Remote Features menu
Press
and
release
the button, 2 LED flashes and beeps indicate the remote
features menu is accessed and can be set.
Press
buttons indicated below 1beep and flash turns the feature on, 2 beeps and 2 flashes turns the feature
off.
The paging feature for the 2- way remote has four options: LED On, LED Off,
LED flashing or LED flashing in groups of two.
• Keypad Lock: Press to turn On/Off.
• Remote Beeps: Press to turn Off.
• Car 2: Press
to turn On/Off.
• Paging (2- way remote only): Press AUX to change.
To save and exit,
press
and
release
the
button and then press and hold for
1.5 seconds. 1 short and 1 long beep is emitted and the transmit LED turns off
when programming is exited.
Remote Pairing
Remote pairing is a process where the Responder LE remote, and the in-vehicle
system learn the other's encrypted identification, securing communication
between the two from intruders.
Note: Remotes are pre-programmed from the factory.
How to Remote Pair
Make sure the remote control is set for the desired Car 1 or Car 2 operation
for the system it is to be paired with.
16
© 2011 Directed Electronics. All rights reserved.
Placing the system into the remote pair mode:
AUX
AUX
1. Turn the ignition to the On position.
2. Press, release, then press and hold the Control button (on the Control
Center).
3. The Control Center LED begins to flash and the horn honks once to
confirm the system is in Pair mode, the Control button can be released.
The system will stay in Pair mode for 60 seconds or until the ignition is
turned off. The horn will emit one short and one long honk when it exits
remote pair mode.
Placing the remote into the remote pair mode:
1. Press and hold the button for 8 seconds. If the transmit LED flashes at
3 seconds, disregard and continue to hold.
2. Wait for the Transmit LED to light solid. Release the button.
3. Press the
button for 1 second. The transmit LED flashes 3 times.
4. Within 5 seconds, press the button.
5. The vehicle horn honks. You have now successfully learned the remote to
the vehicle remote start system.
6. Press the button two times to exit learn routine on the remote. The
transmit LED turns off and exit.
➢ Multi-car control capability
You can use the Responder LE 2- way and 1- way companion remote control
system for two cars, with full command capability for both vehicles.
While holding a command button and transmitting, the amber LED at the
top of the remote control flashes in groups to indicate which car is being
controlled.
• Car 1: 1 flash
• Car 2: 2 flashes
© 2011 Directed Electronics. All rights reserved.
17
To change the Car to be operated:
3
2
Press/hold the button for 3 seconds or until the remote beeps and the
and/or
ates.
• Car 1: 1 beep and Lock LED on
• Car 2: 2 beeps and Lock & Unlock LEDs on
Note: Using the 1- way companion remote, the amber LED flashes and beeps
once for Car 1. The amber LED flashes and beeps twice for Car 2.
To change Car while the LEDs are On:
1. Press and release the button. The LEDs will change to indicate the car
2. After you select the car number, press any command button to oper-
LEDs turn on. This indicates which car the remote currently oper-
that can be operated.
ate the features. The selected car remains selected until the setting is
changed.
18
© 2011 Directed Electronics. All rights reserved.
Using your system
➢ Locking the vehicle
To lock the vehicle, press the button on the remote control.
The horn in the vehicle honks one-time, and the parking lights flash one-time. If
the power door locks are connected, the doors lock and the optional Failsafe
Starter Kill activates. The system automatically checks for errors when it locks.
The 2- way remote beeps one-time and then flashes the LED indicator to
confirm locking. If no lock confirmation is received, the remote emits the out-ofrange signal.
If errors are found when locking:
If the door is open when you lock the vehicle, the horn honks once and the
parking lights flash. The horn then honks a second time to indicate that the
door is open and the LED on the Control Center flashes in groups of three. The
2- way remote control sounds a short “error” tone, and the LED indicators next
to the and buttons flash. Note: The optional horn honk and door input
must be installed for this feature to work.
Locking without the honk (Silent Lock)
Press the button on the remote one-time, and then press the button. The
vehicle locks without the confirmation honk. The parking lights flash one-time.
The 2- way remote flashes the LED to confirm locking. If no lock confirmation is received, the 2- way remote emits the out-of-range signal.
Note: When locking in valet mode, the 2- way remote generates a single error
tone, and the
and LEDs light up.
➢ Unlocking the vehicle
Press the button one time. The vehicle horn honks two-times and the parking lights flash. The 2- way remote beeps two-times and the LED indicator flashes. If locked the doors unlock and the optional Failsafe Starter Kill
deactivates. If no unlock confirmation is received, the 2- way remote emits the
out-of-range signal.
© 2011 Directed Electronics. All rights reserved.
19
UnLocking without the honk (Silent Unlock)
3
2
3
2
3
2
Press the button on the remote one-time, and then press the
vehicle unlocks without the confirmation honk. The parking lights flash twotimes. The 2- way remote flashes the
confirmation is received, the 2- way remote emits the out-of-range signal.
When unlocking in valet mode with the 2- way remote, the remote generates
two error tones and the
and LEDs light up.
LED to confirm unlocking. If no unlock
button. The
➢ Valet mode
You can prevent your system from automatically activating the Failsafe® Starter
Kill. When the system is in Valet mode, the feature is disabled. The doors
do not automatically lock. This is useful when washing or having the vehicle
serviced.
To enter or exit valet mode with the Control button:
1. Turn the ignition key on and then off.
2. At anytime during the next 10 seconds, press and
release the Control button on the Control Center.
The LED turns on solid when you enter Valet®
Mode, and turns off when you exit Valet Mode.
To enter or exit Valet mode with the remote control:
Press two times, and then to set the system in Valet Mode. Repeat the
process to take the system out of Valet Mode.
The Control Center LED turns on solid when in Valet Mode and turns off when
exiting Valet Mode.
20
© 2011 Directed Electronics. All rights reserved.
➢ Panic Mode
If you are threatened in or near your vehicle, you can attract attention by triggering the system with your remote. This feature is only available if the optional
horn honk is connected.
• Press button on the remote for 2 seconds, to enter Panic Mode. The
horn honks and the parking lights flash for 30 seconds.
• To stop Panic Mode at any time:
Press again.
➢ Overriding the optional Starter kill
To bypass the optional Starter kill without a remote control:
Use the button on the Control Center (see diagram below) to bypass the
system. You can bypass the system only if you have the vehicle key.
To check proper operation:
1. While the vehicle is locked, open the door. Immediately insert the key
into the ignition and turn it to the Run or On position. (all the indicators in
the dash turn on)
2. Press and release the Control button one time. The LED on the Control
Center will stop flashing and the optional Starter kill is bypassed. You
can now start the vehicle with the key.
Note: The override feature allows you to select a specific number of presses
needed to disable the system. If the override button has been programmed to
a new number of presses by your authorized dealer, that number should be
indicated below.
Override button presses ________
© 2011 Directed Electronics. All rights reserved.
21
Using the remote start
A U
X
Read this user guide, including the Warnings section at the beginning of the
guide before using the remote start. Ensure that the vehicle is parked in an
open area, not in a garage. To use your remote start to pre-warm or pre-cool
your vehicle, remember to set the climate controls to the desired settings before
shutting off the engine.
➢ Remote starting your vehicle
• Press the
button on the remote control. The vehicle parking
lights flash.
• On the 2- way remote, the Remote Start LED flashes and ascending
Remote Start tone plays.
The preset remote start run time is 12 minutes. This can be changed to
between 1 and 60 minutes (see your authorized Directed dealer for programming changes).
Points to remember
If the hood is open or if the brake pedal is pressed, the vehicle will not remote
start. The remote start shuts down:
• When the brake pedal is pressed
• The hood is opened
• When the remote start command is sent again from a remote control
• When runtime expires
22
© 2011 Directed Electronics. All rights reserved.
➢ Runtime check
To check the amount of runtime remaining:
After the vehicle is remote started, press the button on the 2-way three-times,
and then hold until the remote beeps, and then release. The LEDs light up to
indicate how much time is remaining.
100% runtime remaining
75% runtime remaining
50% runtime remaining
25% runtime remaining
When the remote
start and Function
LEDs are blinking,
there is less than
three minutes of
runtime left.
AUX
© 2011 Directed Electronics. All rights reserved.
23
➢ Manual transmission vehicles
When installed into a manual transmission vehicle, the system requires that the
MTS mode is properly set when parking. If MTS mode is not properly set or is
defeated after being properly set the system will not start the engine.
1. With the engine running,
ning. For Pit Stop or Turbo Timer mode (to leave the engine running after
arming)
open
the driver door.
2.
Release
the foot brake (if pressed during Step 1), or
the foot brake anytime. As long as the engine is running there is no time
limit to perform this step.
3. Within 20 seconds of foot brake release,
on the remote, after 20 seconds return to Step 2 (For Turbo Timer Mode,
press the optional dash mounted activation button, or send the Timer
Mode command from the Advanced Start menu).
4. The vehicle lights flash 5 times to confirm MTS mode enable and the
remote start activates the ignition outputs.
5.
Turn
Off and
running.
6.
Exit
the vehicle,
7. The engine turns off after a few seconds. If the door is opened in Step 3
then the engine continues to run.
You can now remote start the vehicle. If a door is opened before the next
remote start activation, the system will not remote start the vehicle.
To drive your automatic or manual transmission vehicle after it has been remote
started:
1. Get in without stepping on the brake.
2. Insert the ignition key and turn it to the On position.
3. Now, step on the brake. The remote start turns off.
The vehicle is ready to drive.
remove
set
the parking brake and leave the engine run-
press
and
press
any command button
the key from the ignition switch, the engine remains
close
all the doors and
lock
the system.
release
24
© 2011 Directed Electronics. All rights reserved.
➢ Timer mode
A U
X
A U
X
This unit can be programmed to start and run the engine every three hours, for
a maximum of six cycles. The engine will run for the programmed run time and
then shut down. After three hours, the system will restart the engine.
Note: This feature works only when the system has been locked with the
remote.
Important:
Never start and run the vehicle in an enclosed space such
as a garage or carport.
To activate timer mode with an automatic transmission:
Timer Mode should be used in open areas only.
1. Press
twice and then press
.
2. The parking lights quickly flash four times to confirm timer mode entry.
(The vehicle will not remote start at this point.)
3. The vehicle begins the timer mode sequence.
To activate timer mode with a manual transmission:
1. Enter the MTS mode.
2. Exit the vehicle and lock the system.
3. Enter the timer mode. The parking lights quickly flash 4 times to confirm
entry into timer mode (vehicle will not remote start at this point).
The vehicle begins the timer mode sequence.
Timer Mode is exited automatically after the sixth run cycle. The parking lights
slowly flash 4 times when exiting timer mode.
To exit timer mode with the transmitter:
• Press the button twice and then press
. The parking lights flash
slow four times to confirm timer mode is exited.
© 2011 Directed Electronics. All rights reserved.
25
To exit timer mode without the transmitter:
A U
X
A U
X
1. Make sure the remote start system is not operating the engine.
2. Turn the ignition on. Timer Mode is exited and the parking lights flash
slowly four times.
Note:
Your authorized Directed dealer using the Bitwriter® programming tool
can change the amount of times the remote start activates, and change the
intervals between activations in timer mode.
➢ Turbo timer mode*
Turbo timer mode keeps the engine running after arriving at your destination
for a programmable period of 1, 3, 5 or 10 minutes. This allows the system’s
timer to conveniently cool down the turbo after you have left the vehicle. Turbo
timer mode can be activated by the remote or optional dash mounted activation button.
To activate turbo timer mode with automatic transmission:
1. While the vehicle is running, press button 2-times, and then press
button. Or you can press the optional dash mounted activation button
one time. The vehicle lights turn on and the remote start activates the ignition outputs. The parking lights flash one-time confirming that the remote
start is activated.
2. Turn Off the ignition. The car remains running.
3. Exit the vehicle and Lock the system. The vehicle remains running for the
programmed run time.
*Must be turned on by an authorized Directed dealer.
To activate turbo timer mode with a manual transmission:
Perform the manual transmission procedure (See Page 24) with the door open.
Transmit the timer mode feature by pressing
two-times, and then press
Or press the optional dash mounted activation button one time. The lights turn
on and the remote start activates the ignition.
26
© 2011 Directed Electronics. All rights reserved.
.
After exiting the vehicle, lock the system. The vehicle remains running for the
A U
X
A U
X
programmed runtime. (The remote start feature is still enabled).
You can still remote start the vehicle after the turbo timer has timed out and
shut Off the vehicle. For safety reasons, if a door is opened (while the system
is Locked or Unlocked) while you are away, the remote start exits the manual
transmission mode and will not remote start until the MTS sequence is reinitiated.
➢ Smart start activation
Smart Start uses the hours and cycles settings used in Timer Mode, in addition
to temperature or voltage, to automatically start the engine. Activation begins
the countdown timer. When the timer expires the vehicle interior temperature
is checked and, if it exceeds the temperature or voltage thresholds the engine
starts. When the Remote start runtime expires the engine shuts off and the
countdown timer restarts. Smart Start is exited after the final start.
Note: This feature works only when the system has been locked with the
remote.
The factory setting for temperature high is 100º, and the low is 0º (F). The
voltage setting is 10.5v. These settings can be adjusted, or turned off by your
authorized Directed dealer using the Bitwriter.
To activate Smart Start mode:
• Press the button on the remote 3 times and then press the
button.
The parking lights flash 5 times fast to confirm the remote is in Smart Start
mode.
To activate Smart Start mode with a manual transmission:
1. Enter the MTS procedure.
2. Exit the vehicle and press the button on the remote (the vehicle shuts
down when locking).
3. Press the button on the remote 3 times and then press the
button.
The parking lights flash 5 times fast to confirm the remote is in Smart Start
mode.
© 2011 Directed Electronics. All rights reserved.
27
Use one of the below methods to exit Smart Start mode:
• Perform the same steps you followed to activate Smart Start mode
• Turn the ignition On
• Press the brake pedal
The parking lights flash 5 times slowly to confirm the remote has exited Smart
Start mode.
➢ Low runtime alert
During remote start a message is sent three minutes before and then again at
one minute before the engine turns off. The 2- way remote plays tones as an
alert to reset the runtime if desired.
➢ Cabin temperature
Using the Responder LE you have the ability to check the temperature inside the
vehicle.
Press the button one-time, and then press and hold until the remote beeps,
and then release. The LEDs light up indicating the temperature range of the
vehicle.
95˚F and above
76˚F to 95˚F
56˚F to 75˚F
32˚F to 55˚F
32˚F and below
AUX
28
© 2011 Directed Electronics. All rights reserved.
➢ Turning on the rear defogger
A U
X
A U
X
The rear defogger (if connected) is programmed to automatically activate
when remote start is turned on. If the interior cabin temperature is above 55˚ F
the defogger will not activate.
To manually activate the rear defogger after remote start is on:
• Press four times, and then press
. The parking lights flash 3 times
to confirm the defogger activation.
During the next remote start activation, the defogger activation resumes
normally.
➢ Pit Stop mode
The Pit Stop mode feature allows the vehicle to remain running after the key
has been removed from the ignition. This feature is useful for occasions when
you want to exit and lock the vehicle for short periods of time, but would like
to leave the motor running and the climate controls on.
To perform Pit Stop mode:
1. Before turning Off the engine, press and release the
transmitter.
The parking lights flash one time to confirm that Pit Stop mode has been
initiated, then wait a few seconds.
2. Turn the ignition key to the Off position (The engine remains running).
3. Exit the vehicle and lock the system with the remote.
The engine runs until the pre-programmed time elapses or a shut-down
input is received.
Note: To use Pit Stop mode with a manual transmission, open the door when
going into MTS mode. The parking lights flash five-times to confirm entry into
Pit Stop mode. After you exit the vehicle you can lock the system with the
remote and the car remains running. If the vehicle shuts down when locking,
then the unit did not enter the Pit Stop mode.
button on the
© 2011 Directed Electronics. All rights reserved.
29
Safety features
This system has several important safety features to ensure proper operation of
the motor and prevent accidental damage to the engine or its components.
➢ Optional starter anti-grind circuitry
Whenever the vehicle is remote started, advanced anti-grind circuitry prevents
the starter from engaging, even if the key is turned to the start position. This
prevents damage to the starter motor if the key is turned to the start position
during remote start operation.
Note: Anti-grind circuitry only works when the remote start system is operating
the motor and the optional Failsafe® Starter Kill relay is installed.
➢ Disabling the remote start system
This feature allows the remote start unit to be temporarily disabled to prevent
the vehicle from being remote started accidentally. This feature is useful when
the vehicle is being serviced or stored in an enclosed area.
To disable the remote start, move the shutdown toggle switch to the Off position. Check with your installer for the location of the shutdown switch.
Location of Shutdown Switch____________________________
➢ Remote Start Safe-lock
Remote start safe-lock makes sure the doors are locked when Remote Start is
activated and after it is deactivated, even if they are unlocked when remote
start is activated. Door locks may require additional parts and labor.
30
© 2011 Directed Electronics. All rights reserved.
Diagnostics
The microprocessor at the heart of the system is constantly monitoring the
switches that are connected to the main unit.
➢ Locking
If the system is locked at the same time that the door input is active, you will
hear one horn honk to indicate locking, and then a second horn honk to
indicate Bypass Notification.
Note: Bypass Notification does not occur if the optional horn and door input
is not installed or when the system is in Silent Mode or if the notification honks
have been programmed Off by the installer.
➢ Unlocking
Extra honks when unlocking the system is a notification that the battery in the
remote is low and needs to be replaced.
Important:
stalled.
➢ Remote start
This system can provide you with information to indicate what the problem is
when using the remote start. When the remote start is activated and fails to
engage, count the parking light flashes to determine the problem. The parking
lights will flash between 5 - 8 times to indicate what caused the no start situation.
• 5ashes:brakewireisactive
• 6ashes:hoodpinisactive
• 7ashes:manualtransmissionmodeisenabledandnotinitialized
• 8ashes:neutralsafetywirehasnogroundortheremotestart
defeat toggle switch is off.
The optional horn honk feature must be in-
Keep a record of the number of flashes, to assist your authorized Directed
dealer when taking the vehicle in for service.
© 2011 Directed Electronics. All rights reserved.
31
Owner recognition
Owner recognition lets up to four users of the system have unique settings to
meet their specific needs. It is almost like having four separate systems in your
vehicle, one for each user. This feature is only available to authorized dealers
using the Bitwriter programming tool.
Rapid resume logic
This Directed system will store its current state to non-volatile memory. If power
is lost and then reconnected the system will recall the stored state from memory.
For example, if the unit is in Valet Mode and the battery is disconnected for
any reason, such as servicing the car, when the battery is reconnected the unit
is still in Valet Mode. This applies to all states of the system including lock or
unlock.
Power saver mode
Your system will automatically enter Power Saver Mode while locked or in
Valet Mode, after a period of time in which no operation has been performed.
This lowers the current draw on the vehicle’s battery. Power Saver Mode takes
over under the following conditions:
Power Saver when the system is locked: After the system has been Locked for
24 hours the status LED on the Control Center flashes at half its normal rate,
decreasing the system’s current draw.
Power Saver in Valet Mode: When the system enters Valet Mode the Status
LED on the Control Center illuminates steadily. If the vehicle is not used (ignition
is not turned on) for a one-hour period while the system is in Valet Mode, the
status LED shuts Off. If the system remains in Valet Mode, the LED comes back
on the next time the ignition is turned On, and then Off.
32
© 2011 Directed Electronics. All rights reserved.
Programming options
Your system has many custom programmable options. Some may require installation labor. Ask your authorized dealer for details.
The following is a list of the programmable options, with the factory settings in
Bold.
• Active locking (remote only) passive locking, the system automatically
locks the doors 30-seconds after the last door is closed; or Auto Re-lock
automatically re-locks the doors 60 seconds after unlocking (if no door is
opened).
• Locking/Unlocking with horn honk confirmations On or Off.
• Ignition controlled door lock feature On or Off: When this feature is pro-
grammed on, the doors lock three seconds after the ignition is turned on,
and unlock when the ignition is turned Off. The ignition lock and unlock
are independent features that can be programmed separately.
• Panic mode enabled/disabled when the ignition is turned on or com-
pletely turned Off.
• Comfort closure is a programming option which closes the vehicle’s
windows after remote locking. Note: Comfort closure can only be used
on cars that have the capability of closing the windows (and on some
cars the sunroof as well) with the key cylinder in the door.
• Auto re-locking On/Off, ensures the vehicle stays locked if it is not
entered after unlocking by remote control. After unlocking by remote, the
system automatically re-locks locks the doors in 30 seconds. Open any
point of entry to stop the re-lock until the next unlock by remote.
• One-time Bypass On/Off, can be used to temporarily bypass the Passive
locking operation for one cycle. It also bypasses the comfort closure and
auxiliary channel outputs programmed to activate when locking. After the
next unlock all operations return to normal.
Turn the ignition On for one to three seconds and then Off. The horn
honks once to confirm one-time bypass is enabled.
© 2011 Directed Electronics. All rights reserved.
33
Convenience expansions
Listed below are some of the expansion options available. Please consult your
dealer for a complete explanation of all the options available to you.
Power Trunk Release: The accessory output of the system can operate a factory power release for the vehicle’s trunk or hatch. Sometimes an optional relay
is required. If the factory release is not power-activated, Directed®’s 522T
trunk release solenoid can often be added.
Power Window Control: Automatic power window control is provided with
the 529T and 530T systems. These can operate power windows, and can roll
them up automatically when the system is Locked, roll them down, or both up
and down.
Driver Door Priority Unlocking: The door unlocking operation can be configured to emulate an OEM style of driver priority unlocking for added security
during disarming.
Auxiliary Channels: The Auxiliary Channel outputs can be used to activate
many of the convenience features found in today’s vehicles. The installer can
tell you if any the features listed below are compatible with your vehicle.
• Trunk Release
• Windows open/close
• Left Sliding door open/close
• Right Sliding door open/close
• Rear Hatch open/close
• Sunroof open/close
• Audio System on/off
• Headlights on/off
34
© 2011 Directed Electronics. All rights reserved.
Glossary of terms
Control Center: The Control Center contains the system’s radio-frequency
antenna, the Control button, and the Status LED. For maximum remote-control
range, the Control Center is usually located at the top of the windshield,
centered near the rear-view mirror.
Control Module: The “brain” of your system. Usually hidden underneath the
dash area of the vehicle. It houses the microprocessor which monitors your
vehicle and controls all of the system's functions.
Failsafe® Starter Kill (if equipped): An automatic switch controlled by the
system which prevents the vehicle’s starter from cranking whenever the system
is locked. The vehicle is never prevented from cranking when the system is
unlocked in Valet® Mode, or should the Starter Kill switch fail. Your system
is ready for this feature, however installation of this feature may require additional labor.
Input: Any physical connection to the system. An input can be provided by
existing systems in the vehicle, such as ignition or courtesy lights.
In-vehicle status LED: A light used to indicate the status of your system. It is
located on your systems Control Center.
MTS: Manual transmission start. Procedure required for using the remote start
in a vehicle with a manual transmission.
RF: Radio frequency
Control Button: A small push button switch located on your systems Control
Center. It is used to override the starter interrupt when a remote is lost or damaged, or to enter or exit Valet Mode.
© 2011 Directed Electronics. All rights reserved.
35
Quick reference guide
3
2
3
2
• Locking
To lock press for one second. The doors lock.
The LED on the Control Center flashes and the horn honks one time. (if
connected). The parking lights flash once to confirm locking.
• Unlocking
To unlock press
two times. LED on the Control Center stops flashing. The parking lights
flash two times to confirm unlocking.
• Bypassing the optional Starter Kill without a remote
Turn on the ignition. Press and release the Control button within 15
seconds.
The system should now bypass. If it does not, you may have waited too
long or pressed the button incorrect number of times.
Number of Control button presses for disabling__________________
• Silent Lock
Press one-time and then press . The doors lock. The LED on the
Control Center flashes and the parking lights flash once to confirm locking.
Cut along the dotted line and fold to keep in purse or wallet for a quick and easy reference.
• Silent UnLock
Press one-time and then press
the parking lights flash twice to confirm unlocking.
. The doors unlock, and the horn honks (if connected)
for one-second. The doors unlock
✂
© 2011 Directed Electronics. All rights reserved.
37
• Remote Start
A U
X
A U
X
3
2
A U
X
Press
. The parking lights turns on (if connected). The vehicle starts
and runs for the programmed duration.
• Rear Defogger
Press four-times, and then press
(only after remote start is on.)
The parking lights flash 3 times confirming activation of the defogger
output. This is an optional feature.
• To disable the remote start system
Move the shutdown toggle switch to the Off position.
Location of Shutdown Toggle Switch___________________
• Valet Mode
Press two-times and then
. The LED on the Control Center comes
on solid to indicate the system is in valet. The same sequence on the
remote can be used to exit valet made. The LED turns off when valet
mode is exited.
• Pit Stop mode
1. Before turning Off the engine, press and release the
Then wait a few seconds.
2. Turn the ignition key to the Off position.
3. Exit the vehicle and lock the doors with the remote.
The engine will remain running until the programmed time elapses
or a shut-down input is received.
38
© 2011 Directed Electronics. All rights reserved.
button.
Cut along the dotted line and fold to keep in purse or wallet for a quick and easy reference.
✂
Limited lifetime consumer warranty
Directed Electronics. (“Directed”) promises to the original purchaser to repair or replace (at
Directed’s election) with a comparable reconditioned model any Directed unit (hereafter
the “unit”), excluding without limitation the siren, the remote transmitters, the associated
sensors and accessories, which proves to be defective in workmanship or material under
reasonable use during the lifetime of the vehicle provided the following conditions are met:
the unit was purchased from an authorized Directed dealer, the unit was professionally
installed and serviced by an authorized Directed dealer; the unit will be professionally
reinstalled in the vehicle in which it was originally installed by an authorized Directed
dealer; and the unit is returned to Directed, shipping prepaid with a legible copy of the
bill of sale or other dated proof of purchase bearing the following information: consumer’s
name, telephone number and address; the authorized dealers name, telephone number
and address; complete product description, including accessories; the year, make and
model of the vehicle; vehicle license number and vehicle identification number. All components other than the unit, including without limitation the siren, the remote transmitters
and the associated sensors and accessories, carry a one-year warranty from the date of
purchase of the same. ALL PRODUCTS RECEIVED BY DIRECTED FOR WARRANTY REPAIR
WITHOUT PROOF OF PURCHASE WILL BE DENIED. This warranty is non-transferable
and is automatically void if: the original purchaser has not completed the warranty card
and mailed it within ten (10) days from the date of purchase to the address listed on the
card; the unit’s date code or serial number is defaced, missing or altered; the unit has been
modified or used in a manner contrary to its intended purpose; the unit has been damaged
by accident, unreasonable use, neglect, improper service, installation or other causes not
arising out of defects in materials or construction. The warranty does not cover damage
to the unit caused by installation or removal of the unit. Directed, in its sole discretion, will
determine what constitutes excessive damage and may refuse the return of any unit with
excessive damage.
TO THE MAXIMUM EXTENT ALLOWED BY LAW, ALL WARRANTIES, INCLUDING
BUT NOT LIMITED TO EXPRESS WARRANTY, IMPLIED WARRANTY, WARRANTY OF
MERCHANTABILITY, FITNESS FOR PARTICULAR PURPOSE AND WARRANTY OF NONINFRINGEMENT OF INTELLECTUAL PROPERTY, ARE EXPRESSLY EXCLUDED; AND
DIRECTED NEITHER ASSUMES NOR AUTHORIZES ANY PERSON OR ENTITY TO ASSUME
FOR IT ANY DUTY, OBLIGATION OR LIABILITY IN CONNECTION WITH ITS PRODUCTS.
DIRECTED DISCLAIMS AND HAS ABSOLUTELY NO LIABILITY FOR ANY AND ALL ACTS
OF THIRD PARTIES INCLUDING ITS AUTHORIZED DEALERS OR INSTALLERS. DIRECTED
SECURITY SYSTEMS, INCLUDING THIS UNIT, ARE DETERRENTS AGAINST POSSIBLE
THEFT. DIRECTED IS NOT OFFERING A GUARANTEE OR INSURANCE AGAINST
VANDALISM, DAMAGE OR THEFT OF THE AUTOMOBILE, ITS PARTS OR CONTENTS;
AND HEREBY EXPRESSLY DISCLAIMS ANY LIABILITY WHATSOEVER, INCLUDING
40
© 2011 Directed Electronics. All rights reserved.
WITHOUT LIMITATION, LIABILITY FOR THEFT, DAMAGE AND/OR VANDALISM. THIS
WARRANTY DOES NOT COVER LABOR COSTS FOR MAINTENANCE, REMOVAL OR
REINSTALLATION OF THE UNIT OR ANY CONSEQUENTIAL DAMAGES OF ANY KIND.
IN THE EVENT OF A CLAIM OR A DISPUTE INVOLVING DIRECTED OR ITS SUBSIDIARY,
THE VENUE SHALL BE SAN DIEGO COUNTY IN THE STATE OF CALIFORNIA.
CALIFORNIA STATE LAWS AND APPLICABLE FEDERAL LAWS SHALL APPLY AND GOVERN
THE DISPUTE. THE MAXIMUM RECOVERY UNDER ANY CLAIM AGAINST DIRECTED
SHALL BE STRICTLY LIMITED TO THE AUTHORIZED DIRECTED DEALER’S PURCHASE
PRICE OF THE UNIT. DIRECTED SHALL NOT BE RESPONSIBLE FOR ANY DAMAGES
WHATSOEVER, INCLUDING BUT NOT LIMITED TO, ANY CONSEQUENTIAL DAMAGES,
INCIDENTAL DAMAGES, DAMAGE TO VEHICLE, DAMAGES FOR THE LOSS OF TIME,
LOSS OF EARNINGS, COMMERCIAL LOSS, LOSS OF ECONOMIC OPPORTUNITY
AND THE LIKE. NOTWITHSTANDING THE ABOVE, THE MANUFACTURER DOES OFFER
A LIMITED WARRANTY TO REPLACE OR REPAIR THE CONTROL MODULE SUBJECT TO
THE CONDITIONS AS DESCRIBED HEREIN. THIS WARRANTY IS VOID IF THE UNIT
HAS NOT BEEN PURCHASED FROM DIRECTED, OR AN AUTHORIZED DIRECTED
DEALER, OR IF THE UNIT HAS BEEN DAMAGED BY ACCIDENT, UNREASONABLE USE,
NEGLIGENCE, ACTS OF GOD, NEGLECT, IMPROPER SERVICE, OR OTHER CAUSES
NOT ARISING OUT OF DEFECT IN MATERIALS OR CONSTRUCTION.
Some states do not allow limitations on how long an implied warranty will last or the exclusion or limitation of incidental or consequential damages. This warranty gives you specific
legal rights and you may also have other rights that vary from State to State.
This warranty is only valid for sale of product(s) within the United States of America.
Product(s) sold outside of the United States of America are sold “AS-IS” and shall have NO
WARRANTY, express or implied. This product may be covered by a Guaranteed Protection
Plan (“GPP”). See your authorized Directed dealer for details of the plan or call Directed
Customer Service at 1-800-876-0800.
Make sure you have all of the following information from your authorized Directed
dealer:
A clear copy of the sales receipt, showing the following:
o Date of purchase
o Your full name and address
o Authorized dealer’s company name and address
o Type of alarm installed
o Year, make, model and color of the automobile
o Automobile license number
o Vehicle identification number
o All security options installed on automobile
o Installation receipts
920-0003 06-06
© 2011 Directed Electronics. All rights reserved.
41
