Arrow 5

OOwwnneerr’’ss GGuuiiddee

limited lifetime consumer warranty

Directed Electronics, Inc. ("Directed") promises to the original purchaser to repair or replace with a comparable reconditioned model any Directed unit (hereafter the "unit"), excluding without limitation the siren, the remote transmitters, the associated sensors and accessories, which proves to be defective in workmanship or material under reasonable use during the lifetime of the vehicle provided the following conditions are met: the unit was professionally installed and serviced by an authorized Directed dealer; the unit will be professionally reinstalled in the vehicle in which it was originally installed by an authorized Directed dealer; and the unit is returned to Directed, shipping prepaid with a legible copy of the bill of sale or other dated proof of purchase bearing the following information: consumer's name, telephone number and address; the authorized dealers name, telephone number and address; complete product description, including accessories; the year, make and model of the vehicle; vehicle license number and vehicle identification number. All components other than the unit, including without limitation the siren, the remote transmitters and the associated sensors and accessories, carry a one-year warranty from the date of purchase of the same. This warranty is non-transferable and is automatically void if: the original purchaser has not completed the warranty card and mailed it within ten (10) days of the date of purchase to the address listed on the card; the unit's date code or serial number is defaced, missing or altered; the unit has been modified or used in a manner contrary to its intended purpose; the unit has been damaged by accident, unreasonable use, neglect, improper service, installation or other causes not arising out of defects in materials or construction. The warranty does not cover damage to the unit caused by installation or removal of the unit. Directed, in its sole discretion, will determine what constitutes excessive damage and may refuse the return of any unit with excessive damage. TO THE MAXIMUM EXTENT ALLOWED BY LAW, ALL WARRANTIES, INCLUDING BUT NOT LIMITED TO EXPRESS WARRANTY, IMPLIED WARRANTY, WARRANTY OF MERCHANTABILITY, FITNESS FOR PARTICULAR PURPOSE AND WARRANTY OF NON-INFRINGEMENT OF INTELLECTUAL PROPERTY, ARE EXPRESSLY EXCLUDED; AND DIRECTED NEITHER ASSUMES NOR AUTHORIZES ANY PERSON OR ENTITY TO ASSUME FOR IT ANY DUTY, OBLIGATION OR LIABILITY IN CONNECTION WITH ITS PRODUCTS. DIRECTED DISCLAIMS AND HAS ABSOLUTELY NO LIABILITY FOR ANY AND ALL ACTS OF THIRD PARTIES INCLUDING ITS AUTHORIZED DEALERS OR INSTALLERS. DIRECTED SECURITY SYSTEMS, INCLUDING THIS UNIT, ARE DETERRENTS AGAINST POSSIBLE THEFT. DIRECTED IS NOT OFFERING A GUARANTEE OR INSURANCE AGAINST VANDALISM, DAMAGE OR THEFT OF THE AUTOMOBILE, ITS PARTS OR CONTENTS; AND HEREBY EXPRESSLY DISCLAIMS ANY LIABILITY WHATSOEVER, INCLUDING WITHOUT LIMITATION, LIABILITY FOR THEFT, DAMAGE AND/OR VANDALISM. THIS WARRANTY DOES NOT COVER LABOR COSTS FOR MAINTENANCE, REMOVAL OR REINSTALLATION OF THE UNIT OR ANY CONSEQUENTIAL DAMAGES OF ANY KIND. IN THE EVENT OF A CLAIM OR A DISPUTE INVOLVING DIRECTED OR ITS SUBSIDIARY, THE PROPER VENUE SHALL BE SAN DIEGO COUNTY IN THE STATE OF CALIFORNIA. CALIFORNIA STATE LAWS AND APPLICABLE FEDERAL LAWS SHALL APPLY AND GOVERN THE DISPUTE. THE MAXIMUM RECOVERY UNDER ANY CLAIM AGAINST DIRECTED SHALL BE STRICTLY LIMITED TO THE AUTHORIZED DIRECTED DEALER'S PURCHASE PRICE OF THE UNIT. DIRECTED SHALL NOT BE RESPONSIBLE FOR ANY DAMAGES WHATSOEVER, INCLUDING BUT NOT LIMITED TO, ANY CONSEQUENTIAL DAMAGES, INCIDENTAL DAMAGES, DAMAGES FOR THE LOSS OF TIME, LOSS OF EARNINGS, COMMERCIAL

LOSS, LOSS OF ECONOMIC OPPORTUNITY AND THE LIKE. NOTWITHSTANDING THE ABOVE, THE MANUFACTURER DOES OFFER A LIMITED WARRANTY TO REPLACE OR REPAIR THE CONTROL MODULE AS DESCRIBED ABOVE. Some states do not allow limitations on how long an implied warranty will last or the exclusion or limitation of incidental or consequential damages. This warranty gives you specific legal rights and you may also have other rights that vary from State to State.

This product may be covered by a Guaranteed Protection Plan ("GPP"). See your authorized Directed dealer for details of the plan or call Directed Customer Service at 1-800-876-0800. Directed security systems, including this unit, are deterrents against possible theft. Directed is not offering a guarantee or insurance against vandalism, damage or theft of the automobile, its parts or contents; and hereby expressly disclaims any liability whatsoever, including without limitation, liability for theft, damage and/or vandalism. Directed does not and has not authorized any person or entity to create for it any other obligation, promise, duty or obligation in connection with this security system.

Make sure you have all of the following information from your dealer:

A clear copy of the sales receipt, showing the following:

Date of purchase

Your full name and address

Authorized dealer's company name and address

Type of alarm installed

Year, make, model and color of the automobile

Automobile license number

Vehicle identification number

All security options installed on automobile

Installation receipts

trademarks and copyrights

Bitwriter™, Clifford®, Code-Hopping™, Directed®, Doubleguard®, ESP™, FailSafe®, Ghost Switch™, Learn Routine

™

, Nite-Lite®, Nuisance Prevention Circuitry®, NPC®, Revenger®, Silent Mode™, Soft

Chirp

, Stealth Coding™, Stinger®, Valet®, Vehicle Recovery System®, VRS®, and Warn Away

are all Trademarks or Registered Trademarks of Directed Electronics, Inc.

iimmppoorrttaanntt!!

Please note that this manual was intended for US consumers

and therefore includes American phrases or words.

limited lifetime consumer

warranty . . . . . . . . . . . . . . . . . . . . .i

trademarks and copyrights . . . . .ii

table of contents . . . . . . . . . . . . .1

what is included . . . . . . . . . . . . . .2

important information . . . . . . . . .3

your warranty . . . . . . . . . . . . .3

fcc/id notice . . . . . . . . . . . . . . .4

transmitter functions . . . . . . . . . .5

standard configuration . . . . . . .5

using your system . . . . . . . . . . . . .6

arming . . . . . . . . . . . . . . . . . . .6

disarming . . . . . . . . . . . . . . . . .7

disarming without a transmitter8

remote siren silencing . . . . . . .8

transmitter chirp muting . . . . .8

transmitter sensor disable . . . .9

intellistart and smartwindows

sensor bypass . . . . . . . . . . . . . .9

auxiliary channel bypass . . . . .10

panic mode with smart door

locking . . . . . . . . . . . . . . . . . .10

valet mode . . . . . . . . . . . . . . .10

transmitter valet mode . . . . . .11

battery saver mode . . . . . . . .12

low battery warning . . . . . . .12

instant auto-arming bypass . .12

multiple event total recall . . . .13

false alarm control technology

(FACT II) . . . . . . . . . . . . . . . . .13

select siren sounds . . . . . . . . . . .14

diagnostics . . . . . . . . . . . . . . . . . .15

arming diagnostics . . . . . . . . .15

disarming diagnostics . . . . . . .16

arm/disarm diagnostic chart . .16

table of zones . . . . . . . . . . . .16

anti-code grabbing (ACG) . . . . .17

high frequency . . . . . . . . . . . . . .18

smart power up II . . . . . . . . . . . .18

power saver mode . . . . . . . . . . .18

programming options . . . . . . . .19

manual programming

instructions . . . . . . . . . . . . . .20

user selectable features . . . . .22

user selectable features

descriptions - column one . . .22

user selectable features

descriptions - column two . . .24

user selectable features

descriptions - column three . .26

pin programming . . . . . . . . . .28

glossary of terms . . . . . . . . . . . . .29

security & convenience

expansions . . . . . . . . . . . . . . . . . .31

health check . . . . . . . . . . . . . . . .33

table of contents

transmitter configurations

what is included

Arrow 5 control module and harness

Two three-button transmitters

XHF antenna/receiver with harness

Pre-wired blue status LED

PlainView 2 Valet switch

504C dual-stage shock sensor with harness

514C neo-siren

Presentation pack

Quick reference card

Two window decal's

Arm/Disarm

Button

Accessory

Output Button

Optional Accessory Channel Button

important information

Congratulations on the purchase of your state-of-the-art vehicle

security system. It has been designed to provide years of trouble-free

operation. This system must be installed by an authorized dealer.

Installation of this product by anyone other than an authorized dealer

voids the warranty. As verification of authorization, all authorized deal-

ers are provided with preprinted dealer certificates.

In order to maximize the use of this system, please review this owner's

guide carefully prior to using your system. You can print additional or

replacement copies of this owner’s guide by accessing the Clifford web-

site at www.clifford.com.

system maintenance

The system requires no specific maintenance. Your transmitter is pow-

ered by a miniature 3V lithium battery (CR2032) that will last approxi-

mately one year under normal use. When the battery weakens, operat-

ing range will be reduced and the system will provide a low battery

warning chirps indication when disarming.

your warranty

Your warranty registration must be completely filled out and returned within 10 days of purchase. Your product warranty will not be validated if your warranty registration is not returned. Make sure you receive the warranty registration from your dealer. It is also necessary to keep your proof of purchase, which reflects that the product was installed by an authorized dealer.

fcc/id notice

This device complies with Part 15 of FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesirable operation.

Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this device.

Directed Electronics, Inc.

DRW-396

Tested to Comply

with FCC Standards

transmitter functions

This system uses computer-based code learning to learn the transmitter buttons. This makes it possible to assign any transmitter button to any system function. The transmitter initially comes programmed with standard configuration, but may also be customized using the CliffNet Wizard PC program. The buttons in all of the instructions in this manual correspond to a standard configuration transmitter.

standard configuration

Button

The arming, disarming, and panic function are controlled by this button.

Button

The trunk release or accessory output is controlled by this button.

Button

An optional accessory convenience or expansion function that you have

added to your system can be activated by pressing this button.

and Buttons

When pressed together, these buttons control silent arm and disarm.

and Buttons

When pressed together, these buttons disable the 504C shock sensor.

and Buttons

When pressed together, these buttons control the remote valet.

using your system

The buttons used in the instructions in this manual correspond to the

standard transmitter configuration. If your transmitter has been custom

configured, the icons on your transmitter buttons may not correspond

to the indicated functions.

arming

You can activate, or arm, the system by pressing on your trans-

mitter for one second. When the system arms, you will hear two short

siren sounds, or chirps, and see the parking lights flash twice. The LED

will begin to flash steadily. If the vehicle’s power door locks have been

connected to the system, the doors will lock.

While the system is armed, the LED status indicator will flash approxi-

mately once per second showing that the system is actively protecting

your vehicle. If you hear more than two chirps when arming, refer to

the Diagnostics section of this guide. These extra chirps confirm a mal-

function autobypass.

The security system also can be programmed to arm itself

automatically (called passive arming). If the system is programmed for

passive arming, it will automatically arm 30 seconds after the ignition

is turned off and the system sees you leave the vehicle by opening and

closing a door. Whenever the system is in its 30-second passive-arming

countdown. The siren will chirp twice and the lights will flash twice five

seconds after the last door has been closed. The system is not actually

armed at that point. The system arms and the doors lock (if connected

and programmed for passive locking) at 30 seconds, but the siren will

not chirp. The early chirps provide you with a 25-second warning prior

to arming.

When armed, your vehicle is protected as follows:

The LED will flash as a visible theft deterrent.

Light impacts will trigger the Warning Zone signal. When triggered, the siren will chirp for a few seconds.

Heavy impacts will trigger the system. The triggered sequence is 30, 60, or 90 seconds of constant siren chirping and flashing parking lights.

If a protected entry (d20.0rs57o hood0, ortrunkg) isopen(ed, the ys-g)]TJT*0.7527 Tw[(ems williammeiaterly trigger the sir)17.7(en(and flasr the parking)]TJT*8 Tw lights.)Tj/TT1 1 Tf7.8 0 0 7.8 171.6362.55821 Tm0.50196 g0 Tc<007a>Tj/F1 1 Tf10.4 0 0 10.4 195360.60842 Tm0 g-0.0001 Tc010738 Tw[(Theoptiognaliamobilizger pr)17.7ev ensr the vehicl’s nstrete fprmg

disarming without a transmitter

This feature allows you to disarm the system without the transmitter

should it be lost, damaged, or disabled. In order to disarm without a

transmitter, you must have the vehicle’s ignition key, know where the

PlainView 2 Valet switch is located, and have the PIN code. Be sure to

check with the installer for the location of the PlainView 2 Valet switch

and instructions for entering the PIN code. Turn the ignition On and

then press the button twice (factory PIN default setting) and the

button once to disarm without a transmitter.

remote siren silencing

This system offers remote siren silencing. Remote siren silencing is a fea-

ture that makes it possible to silence and reset the system when it is

triggering without disarming the system. If the system is triggered and

the siren has been sounding, press on the transmitter to stop the

trigger and return the unit to the armed state. The system will not dis-

arm, but rather reset. This prevents you from disabling the system

should you wish to silence it without visually checking the vehicle. After

resetting the system, press again to disarm the system.

transmitter chirp muting

To temporarily turn off the arm or disarm chirps, use transmitter chirp

muting. Simply press and simultaneously on the trans-

mitter, and the confirmation chirp(s) will be eliminated for that one op-

eration only. The parking lights will flash to confirm the arm/disarm

command. If you want the arm/disarm chirps turned off permanently,

please refer to the User-Selectable Features section of this guide.

transmitter sensor disable

To temporarily disable a sensor input, arm the system, press the

and simultaneously. The lights will flash four times and all warn

away trigger zones three and eight are bypassed. Press the buttons

again; the lights flash four times and both warn away and full trigger

zones three and eight are bypassed until the system is disarmed. This

can be performed anytime the system is armed.

1. Arm the system.

2. Using the transmitter, bypass the sensor.

3. The lights will flash four times; all warn away zones are now bypassed.

4. Transmit the sensor bypass channel again.

5. The lights will flash four more times; the sensor warn away and full trigger zones are now bypassed.

6. The sensor zones will reset when disarmed.

intellistart and smartwindows sensor bypass

When the system sees a command to start the vehicle via the

Intellistart, it bypasses zones three, seven, and eight, and will continue

bypass these zones until the remote start shuts down. Zone four will

bypass for 5 seconds from the time it remote starts and again for 5 sec-

onds after remote start shut down.

When the system sees a SmartWindows command for up or down

operation, the unit will automatically bypass zones three and eight until

the windows complete their operation.
