Directed Electronics 600 ESP User Manual
Model 600 ESP
Owner's Guide
i
©
1999 Directed Electronics, Inc.
Limited Lifetime
Consumer Warranty
Directed Electronics, Inc. ("DEI®") promises to the original purchaser to repair or
replace with a comparable reconditioned model any DEI unit (hereafter the "unit"),
excluding without limitation the siren, the remote transmitters, the associated
sensors and accessories, which proves to be defective in workmanship or material
under reasonable use during the lifetime of the vehicle provided the following conditions are met: the unit was professionally installed and serviced by an authorized
DEI dealer; the unit will be professionally reinstalled in the vehicle in which it was
originally installed by an authorized DEI dealer; and the unit is returned to DEI, shipping prepaid with a legible copy of the bill of sale or other dated proof of purchase
bearing the following information: consumer's name, telephone number and address;
the authorized dealers name, telephone number and address; complete product
description, including accessories; the year, make and model of the vehicle; vehicle
license number and vehicle identification number. All components other than the
unit, including without limitation the siren, the remote transmitters and the associated sensors and accessories, carry a one-year warranty from the date of purchase of
the same. This warranty is non-transferable and is automatically void if: the original
purchaser has not completed the warranty card and mailed it within ten (10) days of
the date of purchase to the address listed on the card; the unit's date code or serial
number is defaced, missing or altered; the unit has been modified or used in a
manner contrary to its intended purpose; the unit has been damaged by accident,
unreasonable use, neglect, improper service, installation or other causes not arising
out of defects in materials or construction. The warranty does not cover damage to
the unit caused by installation or removal of the unit. DEI, in its sole discretion, will
determine what constitutes excessive damage and may refuse the return of any unit
with excessive damage. TO THE MAXIMUM EXTENT ALLOWED BY LAW, ALL WAR-
RANTIES, INCLUDING BUT NOT LIMITED TO EXPRESS WARRANTY, IMPLIED
WARRANTY, WARRANTY OF MERCHANTABILITY, FITNESS FOR PARTICULAR PURPOSE
AND WARRANTY OF NON-INFRINGEMENT OF INTELLECTUAL PROPERTY, ARE
EXPRESSLY EXCLUDED; AND DEI NEITHER ASSUMES NOR AUTHORIZES ANY PERSON
OR ENTITY TO ASSUME FOR IT ANY DUTY, OBLIGATION OR LIABILITY IN CONNECTION WITH ITS PRODUCTS. DEI DISCLAIMS AND HAS ABSOLUTELY NO LIABILITY
FOR ANY AND ALL ACTS OF THIRD PARTIES INCLUDING ITS AUTHORIZED DEALERS
OR INSTALLERS. DEI SECURITY SYSTEMS, INCLUDING THIS UNIT, ARE DETERRENTS
AGAINST POSSIBLE THEFT. DEI IS NOT OFFERING A GUARANTEE OR INSURANCE
AGAINST VANDALISM, DAMAGE OR THEFT OF THE AUTOMOBILE, ITS PARTS OR CONTENTS; AND HEREBY EXPRESSLY DISCLAIMS ANY LIABILITY WHATSOEVER,
INCLUDING WITHOUT LIMITATION, LIABILITY FOR THEFT, DAMAGE AND/OR VAN-
ii
©
1999 Directed Electronics, Inc.
DALISM. THIS WARRANTY DOES NOT COVER LABOR COSTS FOR MAINTENANCE,
REMOVAL OR REINSTALLATION OF THE UNIT OR ANY CONSEQUENTIAL DAMAGES OF
ANY KIND. IN THE EVENT OF A CLAIM OR A DISPUTE INVOLVING DEI OR ITS SUBSIDIARY, THE PROPER VENUE SHALL BE SAN DIEGO COUNTY IN THE STATE OF
CALIFORNIA. CALIFORNIA STATE LAWS AND APPLICABLE FEDERAL LAWS SHALL
APPLY AND GOVERN THE DISPUTE. THE MAXIMUM RECOVERY UNDER ANY CLAIM
AGAINST DEI SHALL BE STRICTLY LIMITED TO THE AUTHORIZED DEI DEALER'S PURCHASE PRICE OF THE UNIT. DEI SHALL NOT BE RESPONSIBLE FOR ANY DAMAGES
WHATSOEVER, INCLUDING BUT NOT LIMITED TO, ANY CONSEQUENTIAL DAMAGES,
INCIDENTAL DAMAGES, DAMAGES FOR THE LOSS OF TIME, LOSS OF EARNINGS,
COMMERCIAL LOSS, LOSS OF ECONOMIC OPPORTUNITY AND THE LIKE. NOTWITHSTANDING THE ABOVE, THE MANUFACTURER DOES OFFER A LIMITED WARRANTY TO
REPLACE OR REPAIR THE CONTROL MODULE AS DESCRIBED ABOVE. Some states do
not allow limitations on how long an implied warranty will last or the exclusion or
limitation of incidental or consequential damages. This warranty gives you specific
legal rights and you may also have other rights that vary from State to State.
This product may be covered by a Guaranteed Protection Plan ("GPP"). See your
authorized DEI dealer for details of the plan or call DEI Customer Service at 1-800876-0800. DEI security systems, including this unit, are deterrents against possible
theft. DEI is not offering a guarantee or insurance against vandalism, damage or theft
of the automobile, its parts or contents; and hereby expressly disclaims any liability
whatsoever, including without limitation, liability for theft, damage and/or vandalism.
DEI does not and has not authorized any person or entity to create for it any other
obligation, promise, duty or obligation in connection with this security system.
Make sure you have all of the following information from your dealer:
A clear copy of the sales receipt, showing the following:
■ Date of purchase
■ Your full name and address
■ Authorized dealer's company name and address
■ Type of alarm installed
■ Year, make, model and color of the automobile
■ Automobile license number
■ Vehicle identification number
■ All security options installed on automobile
■ Installation receipts
1
©
1999 Directed Electronics, Inc.
Table of Contents
Limited Lifetime Consumer Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . i
Standard Transmitter Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
What Is Included . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Important Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
System Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Your Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
FCC/ID Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Transmitter Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Standard Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Using Your System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Arming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Multi-Level Security Arming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Arming While Driving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Disarming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
High Security Disarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Disarming Without a Transmitter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Silent Mode
™
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Panic Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Valet
®
Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Remote Valet
®
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Nuisance Prevention
®
Circuitry. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Arming Diagnostics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Disarming Diagnostics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Table of Zones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Code-Hopping
™
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
High Frequency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Owner Recognition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Rapid Resume Logic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Power Saver Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Programming Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Installation Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Vehicle Recovery System (VRS®) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Arming the VRS
®
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
VRS
®
Triggered Sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Disarming the VRS
®
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Glossary Of Terms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Security & Convenience Expansions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Quick Reference Guide (Removable) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
2
©
1999 Directed Electronics, Inc.
Standard Transmitter
Configuration
controls the Arm function.
controls the Disarm function.
controls Silent Mode™and an Auxiliary Output.
controls the Panic function.
and pressed simultaneously control an Auxiliary Output.
3
©
1999 Directed Electronics, Inc.
What is Included
■ 3-Channel Receiver
■ A pair of four-button transmitters
■ A Stinger
®
Doubleguard®dual-output shock sensor
■ The Revenger
®
Soft Chirp®six-tone programmable siren
■ The red status LED indicator light
■ A push-button Valet
®
switch
■ Your warranty card
■ Failsafe
®
Starter Kill ready circuitry (may require additional
labor)
Important Information
Congratulations on the purchase of your state-of-the-art vehicle
security system. This system has been designed to provide years of
trouble-free operation. Due to the complexity of this system, it
must be installed by an authorized dealer only. Installation of this
product by anyone other than an authorized dealer voids the war-
ranty. All dealers are provided with preprinted dealer certificates to
verify that they are authorized.
This owner’s guide should help you to get the most out of your sys-
tem. Please take the time to read it prior to using the system.
4
©
1999 Directed Electronics, Inc.
The system requires no specific maintenance. Your remote control
is powered by a small, lightweight 3-volt lithium battery that will
last approximately one year under normal use. When the battery
weakens, operating range will be reduced and the LED on the
remote will dim.
Your warranty card must be returned and the bar code serial num-
ber must not be removed. If the warranty card is not returned, you
do not have a warranty. It is also necessary to keep your proof of
purchase, which reflects that the product was installed by an au-
thorized dealer. Make sure that you receive the warranty card from
your dealer.
This device complies with Part 15 of FCC rules. Operation is sub-
ject to the following two conditions: (1) This device may not cause
harmful interference, and (2) This device must accept any interfer-
ence received, including interference that may cause undesired
operation.
Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to oper-
ate this device.
FCC/ID Notice
Your Warranty
System Maintenance
5
©
1999 Directed Electronics, Inc.
Transmitter Functions
The receiver uses a computer-based Learn Routine to learn the
remote transmitter buttons. This makes it possible to assign any
transmitter button to any receiver function. The transmitter ini-
tially comes programmed with Standard Configuration, but may
also be customized by an authorized dealer. The buttons in all of
the instructions in this manual correspond to a Standard
Configuration transmitter.
The standard configuration is how the transmitters come pro-
grammed initially. If you would like a custom configuration, con-
tact your dealer.
Button
The arming function is controlled by pressing .
Button
The disarming function is controlled by pressing .
Button
Silent Mode
™
and an optional auxiliary function are controlled by
. (Silent Mode works by pressing for less than one sec-
ond before arming or disarming. An optional auxiliary function,
such as trunk release, can be controlled by pressing for 1.5
seconds.)
The auxiliary output controls _____________________________.
Standard Configuration
6
©
1999 Directed Electronics, Inc.
Button
The panic feature is controlled by pressing for 1 second.
and Buttons
An optional auxiliary convenience or expansion function that you
have added to your system can be activated by pressing and
simultaneously.
The auxiliary output controls _____________________________.
Using Your System
The receiver uses a computer-based Learn Routine to learn the
transmitter buttons. This makes it possible to assign any trans-
mitter button to any receiver function. The transmitter initially
comes programmed with Standard Configuration, but may also be cus-
tomized by an authorized dealer. The buttons in all of the instruc-
tions in this manual correspond to a Standard Configuration trans-
mitter.
You can activate, or arm, the system by pressing of your trans-
mitter for one second. When the system arms, you will hear a short
siren sound, or chirp, and the parking lights will flash once. If the
power door locks have been connected to the system, the doors
will lock.
Arming
7
©
1999 Directed Electronics, Inc.
While the security system is armed, the status LED will flash
approximately once per second, indicating that the system is
actively protecting your vehicle. If you hear a second chirp after
arming the system, and see the status LED flashing in groups, refer
to the Diagnostics section of this guide. This extra chirp is called
Bypass Notification.
The system also can be programmed to arm itself automatically
(called passive arming). If the system is programmed for passive
arming, it will automatically arm 30 seconds after the ignition is
turned off and the system "sees" you leave the vehicle by opening
and closing a door. Whenever the system is in its 30-second pas-
sive-arming countdown, the status LED will flash twice as fast as
it does when the system is armed. The siren will chirp one time 20
seconds after the last door has been closed. The system is not
actually armed at that point. The system arms and the doors lock
(if connected and programmed for passive locking) at the 30 sec-
ond mark, but the siren will not chirp. The early chirp provides you
with a 10-second warning prior to arming.
NOTE: If any protected entry point (such as a door or a switch-protected
trunk or hood) is open, the system will not passively arm (unless forced
passive arming is programmed on.) See Programming Options section of
this guide. Additionally, each time a sensor is triggered during the arming countdown, the 30-second countdown starts over.
When armed, your vehicle is protected as follows:
■ Light impacts will trigger the Warn Away
®
signal. When trig-
gered, the siren will chirp and the parking lights will flash for
a few seconds.
Loading...
