411R Series
Owner's Guide
i
©
2000 Directed Electronics, Inc.
i
Limited Lifetime
Consumer Warranty
For a period of one calendar year from the date of purchase of this auto-security
device, Directed Electronics, Inc. promises to the ORIGINAL PURCHASER to repair or
replace (with a comparable reconditioned model), free of cost, any electronic control
module which proves to be defective in workmanship or material under normal use,
SO LONG AS THE SYSTEM WAS SOLD, INSTALLED, AND SERVICED BY A PROFESSIONAL
AUTO INSTALLER, AND REMAINS IN THE CAR IN WHICH THE SYSTEM WAS ORIGINALLY
INSTALLED. If warranty service is necessary you must have a clear copy of your sales
receipt containing all of the information shown on the following page.
After the first calendar year, from the date of purchase of this auto-security device,
Directed Electronics, Inc., promises to the ORIGINAL PURCHASER to repair or replace
(with a comparable reconditioned model) any electronic control module which proves
to be defective in workmanship or material under normal use FOR A CHARGE OF
$45.00, SO LONG AS THE SYSTEM WAS SOLD, INSTALLED, AND SERVICED BY A PROFESSIONAL AUTO INSTALLER, AND REMAINS IN THE CAR IN WHICH THE SYSTEM WAS
ORIGINALLY INSTALLED. If warranty service is necessary you must have a clear copy
of your sales receipt containing all of the information shown on the following page.
This warranty contains the entire agreement relating to warranty and supersedes all
previous and contemporaneous representations or understandings, whether written or
oral. IN ANY EVENT, DEI IS NOT LIABLE FOR THE THEFT OF THE VEHICLE AND/OR ITS
CONTENTS.
This warranty is void if the product has been damaged by accident, unreasonable use,
neglect, improper service or other causes not arising out of defects in materials or
construction. This warranty is nontransferable and does not apply to any unit that
has been modified or used in a manner contrary to its intended purpose and does not
cover batteries. The unit in question must be returned to the manufacturer, postage
prepaid. This warranty d
oes not cover labor costs for the removal, diagnosis, troubleshooting or reinstallation of the unit. For service on an out-of-warranty product a
flat rate fee by model is charged. Contact your authorized dealer to obtain the service charge for your unit.
These systems are a deterrent against possible theft. Directed Electronics, Inc. is not
offering a guarantee or insuring against the theft of the automobile or its contents
and disclaims any liability for the theft of the vehicle and/or its contents. Directed
Electronics does not authorize any person to create for it any other obligation or liability in connection with this security system.
ii
©
2000 Directed Electronics, Inc.
ii
TO THE MAXIMUM EXTENT ALLOWED BY LAW, ANY AND ALL WARRANTIES ARE EXCLUDED BY THE MANUFACTURER AND EACH ENTITY PARTICIPATING IN THE STREAM OF COMMERCE THEREWITH. THIS EXCLUSION INCLUDES BUT IS NOT LIMITED TO THE EXCLUSION OF ANY AND ALL WARRANTY OF MERCHANTABILITY AND/OR ANY AND ALL WARRANTY OF FITNESS FOR A PARTICULAR PURPOSE AND/OR ANY AND ALL WARRANTY OF
NON-INFRINGEMENT OF PATENTS, IN THE UNITED STATES OF AMERICA AND/OR
ABROAD. NEITHER THE MANUFACTURER OR ANY ENTITIES CONNECTED THEREWITH
SHALL BE RESPONSIBLE OR LIABLE FOR ANY DAMAGES WHATSOEVER, INCLUDING BUT
NOT LIMITED TO ANY CONSEQUENTIAL DAMAGES, INCIDENTAL DAMAGES, TOWING,
REPAIR, REPLACEMENT, DAMAGES FOR LOSS OF TIME, LOSS OF EARNINGS, COMMERCIAL
LOSS, LOSS OF ECONOMIC OPPORTUNITY AND THE LIKE. NOTWITHSTANDING THE
ABOVE, MANUFACTURER DOES OFFER A LIMITED WARRANTY TO REPLACE OR REPAIR
THE CONTROL MODULE AS DESCRIBED ABOVE. Some states do not allow limitations on
how long an implied warranty will last or the exclusion or limitation of incidental or
consequential damages. This warranty gives you specific legal rights, and you may
also have other rights which vary from state to state.
IMPORTANT NOTE:
This product warranty is automatically void if its date code or serial number is
defaced, missing, or altered. This warranty will not be valid unless you have completed the warranty card and mailed it to Directed Electronics, Inc. within 10 days
after purchase to the address listed on the warranty registration card.
Make sure you have all of the following information from your dealer:
A clear copy of the sales receipt, showing the following:
■ Date of purchase
■ Your full name and address
■ Authorized dealer's company name and address
■ Type of system installed
■ Year, make, model and color of the automobile
■ Automobile license number
■ Vehicle identification number
■ All security options installed on automobile
■ Installation receipts
1
©
2000 Directed Electronics, Inc.
Table of Contents
Limited Lifetime Consumer Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . i
Standard Configuration Transmitter Diagram. . . . . . . . . . . . . . . . . . . . . . . . . 2
What Is Included . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Important Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
System Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Your Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
FCC/ID Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Transmitter Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Standard Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Using Your System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Locking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Unlocking. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Panic Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Code Hopping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
High Frequency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Programming Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Security & Convenience Expansions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Glossary of Terms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Quick Reference Guide (Removable) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
2
©
2000 Directed Electronics, Inc.
Standard Configuration
3
©
2000 Directed Electronics, Inc.
What is Included
■ The control module
■ A pair of two-button transmitters
■ The red status LED indicator light
■ A push-button Valet
®
switch
■ Your warranty card
Important Information
Congratulations on the purchase of this system. It has been
designed to provide years of trouble-free operation. By carefully
reading this guide prior to using your system, you will maximize
the use of this product and its features. Additional or replacement
copies of this manual may be obtained by logging on to DEI’s web-
site at www.directed.com.
This system has been designed to provide years of trouble-free op-
eration. The system requires no specific maintenance. Your remote
control is powered by a miniature 12V battery, type GP23A, that
will last approximately one year under normal use. When the bat-
tery weakens, operating range will be reduced and the LED on the
remote will dim.
System Maintenance
4
©
2000 Directed Electronics, Inc.
Your warranty card must be returned and the barcode serial num-
ber must not be removed. If the warranty card is not returned, no
warranty will be honored on your unit. It is also necessary to keep
your proof of purchase, which reflects that the product was
installed by an authorized dealer. Make sure you receive the war-
ranty card from your dealer.
This device complies with Part 15 of FCC rules. Operation is subject
to the following two conditions: (1) This device may not cause
harmful interference, and (2) This device must accept any interfer-
ence received, including interference that may cause undesired op-
eration.
Caution: Changes or modifications not expressly approved by the
party responsible for compliance could void the user's authority to
operate this device.
FCC/ID Notice
Your Warranty
5
©
2000 Directed Electronics, Inc.
Transmitter Functions
This system is programmable, making it possible to assign any trans-
mitter button to any specific receiver function. The remote initially
comes programmed with Standard Configuration, but may also be
customized by an authorized dealer. The buttons in all of the instruc-
tions in this manual correspond to a Standard Configuration remote.
Button
Locking and Panic Mode activation are controlled by this button.
Pressing it for one second will lock the doors, while pressing it for
1.5 seconds will activate Panic Mode.
Button
Unlocking, Panic Mode deactivation and an optional auxiliary
function are controlled by this button. Pressing it for one second
will unlock the doors. This button is also used to stop Panic Mode
at any time. Additionally, an optional auxiliary function can be
controlled by pressing and holding it for 1.5 seconds. This auxil-
iary output controls ____________________________.
Buttons and
An optional auxiliary function that you have added to your system
can be activated by pressing these buttons simultaneously.
This auxiliary output controls_____________________________.
NOTE: If using an optional four-button remote, the Standard
Configuration may be assigned to buttons III and IV of the transmitter.
Standard Configuration
6
©
2000 Directed Electronics, Inc.
Using Your System
Pressing for one second will lock the doors. The red LED will
begin to flash once per second and the parking lights will flash
once. Pressing again within 10 seconds of locking the system
will not lock the doors again, but it will flash the parking lights
and honk the horn once, confirming that the system is locked.
After 10 seconds, the system can be locked again, as usual.
NOTE: You must use your transmitter to lock the vehicle in order to be
able to unlock the system with your transmitter. If you have not used
the transmitter to lock the vehicle doors (i.e. the vehicle has been locked
using the lock/unlock switch) the transmitter cannot be used to unlock the
doors.
To unlock the driver’s door (or all vehicles doors, depending on if
your vehicle has driver’s door unlock), press for one second.
The parking lights will flash twice and the red LED will go out. If
pressing the first time did not unlock all doors, press
again within 10 seconds to unlock the remaining passenger doors
and the parking lights will flash twice. Pressing a third time
within 10 seconds will flash the parking lights and honk the horn
twice, confirming that the system has been unlocked. After 10
seconds, the system can be unlocked again, as usual.
NOTE: If the system has been locked with the remote, you must use the
remote to unlock the system.
Unlocking
Locking
7
©
2000 Directed Electronics, Inc.
If you are threatened in or near your vehicle, you can attract
attention by triggering the system with your remote! Just press
and hold for 1.5 seconds, and you will enter Panic Mode. The
horn will honk and the parking lights will flash for 30 seconds. To
stop Panic Mode at any time, press on the remote.
NOTE: In order for Panic Mode to function, the vehicle’s horn (or optional siren) must be connected.
Code Hopping
™
The receiver and transmitter use mathematical formulas called
algorithms to change their codes each time the transmitter is used.
This Code Hopping technology has been developed to increase the
security of the unit. By following this set code sequence, the
receiver and transmitter stay synchronized, even if the transmitter
is used out of range of the vehicle. If, however, the transmitter is
pressed many times out of range, or the battery is removed, the
transmitter may get temporarily out of sync and fail to operate the
system. To resynchronize the transmitter, simply press several
times within range of the vehicle. The system will automatically
resynchronize and the transmitter will respond normally.
Panic Mode
8
©
2000 Directed Electronics, Inc.
High Frequency
Your system transmits and receives at 434 MHz. This provides a
cleaner spectrum with less interference and a more stable signal.
Enjoy a phenomenal increase in range, even in areas with high
radio interference.
Programming Options
Programming options control what your system does during normal
operation, and require few or no additional parts. However, some
options may require additional installation labor. The following is
a list of the program settings, with the factory settings in bold:
■ Ignition-controlled door locks can be turned on or off. When
turned on, the doors will lock three seconds after the ignition
is turned on and unlock when the ignition is turned off.
■ There is an ignition-controlled panic sequence that can be
programmed on or off. If this feature is programmed on, Panic
Mode will initiate whenever the ignition is turned on while
the system is locked. To turn off this panic sequence, simply
press .
9
©
2000 Directed Electronics, Inc.
Security & Convenience
Expansions
Here we have listed only some of the many expansion options
available. Please consult your dealer for a complete explanation of
all the options available to you.
Domelight Supervision: If installed, the domelight will illuminate
for 30 seconds each time the system is unlocked using the trans-
mitter. This is useful for seeing inside the vehicle at night prior to
entering it.
Valet
®
Start System: For the ultimate in convenience, the Valet
®
Start System can start your vehicle, monitor engine functions, and
power your climate control system with a push of a button! Over-
rev protection, open-hood lockout, brake-pedal shutoff, and auto-
matic timer shutoff are all included. (Only for fuel-injected, auto-
matic-transmission vehicles.)
Power Window Control: Power window control is provided with
the 529T or 530T systems. The 529T system will roll up two win-
dows automatically when the system is locked, or roll two windows
down. The 530T can roll two windows both up and down. The 530T
also provides one touch switch operation.
Power Trunk Release: This expansion option allows you to oper-
ate a factory power release for the vehicle's trunk or hatch. If the
factory release is not power-activated, DEI's 522T trunk-release
solenoid can often be added.
10
©
2000 Directed Electronics, Inc.
Glossary of Terms
Control Unit: The “brain” of your system. Usually hidden under-
neath the dash area of the vehicle. It houses the microprocessor
which monitors your vehicle and controls all of the system func-
tions.
LED: Red light mounted somewhere in the vehicle. It is used to
indicate the status of your system.
Transmitter: Hand-held, remote control which operates the vari-
ous functions of your system.
Valet
®
Switch: A small push button switch mounted somewhere
inside the vehicle that is used by the installer for programming the
system. It can also be used to override certain expansion options
that have been added to your system. Consult your dealer for details.
11
©
2000 Directed Electronics, Inc.
Notes
12
©
2000 Directed Electronics, Inc.
Notes
13
©
2000 Directed Electronics, Inc.
QUICK REFERENCE GUIDE:
To lock using your transmitter
■ Pressing for one second will lock the doors. The red LED will begin
to flash once per second and the parking lights will flash once to confirm locking of the doors. Pressing again within 10 seconds of locking the system will not lock the doors again, but it will flash the parking lights and honk the horn once, confirming that the system is locked.
After 10 seconds, the system can be locked again, as usual.
To unlock using your transmitter
■ To unlock the driver’s door (or all vehicles doors, depending on if your
vehicle has driver’s door unlock), press for one second. The parking lights will flash twice and the red LED will go out. If pressing
the first time did not unlock all vehicle doors, press it again within 10
seconds to unlock the remaining passenger doors and the parking lights
will flash twice. Pressing a third time within 10 seconds will flash
the parking lights and honk the horn twice, confirming that the system
has been unlocked. After 10 seconds, the system can be unlocked again,
as usual.
To activate panic mode
■ Press and hold down for 1.5 seconds.
To exit panic mode
■ Press .
Cut along dotted line and fold for a quick and easy reference to keep in your purse or wallet.
✂✂
✂✂
The company behind this system is Directed Electronics, Inc.
Since its inception, DEI® has had one purpose, to provide consumers with the finest
vehicle security and car stereo products and accessories available. The recipient of
more than 20 patents in the field of advanced electronic technology, DEI is ISO 9001
registered.
Quality Directed Electronics products are sold and serviced throughout North America
and around the world.
Call (800) 274-0200 for more information about our products and services.
Vista, CA 92083
www.directed.com
© 2000 Directed Electronics, Inc. - All rights reserved
G411R 3/00
DEI is committed to delivering on time, the best products we know how to provide,
and to constantly work with our customers and vendors to improve our products, quality, delivery and customer friendly features.
®
Loading...
