Directed Electronics 1601 User Manual

Model 1601
Security and Remote Start
Owner’s Guide
© 2008 Directed Electronics, Vista, CA
G5102P 2008-06
Contents
Government regulations .....................................................................................5
Warning! Safety first .........................................................................................7
What is included .............................................................................................10
Important information ......................................................................................10
1-way remote .................................................................................................13
Using the system .............................................................................................18
Using the remote start ......................................................................................25
Safety features ...............................................................................................32
Disabling the remote start system ..............................................................32
Diagnostics ....................................................................................................33
Owner recognition .........................................................................................37
Rapid resume logic ..........................................................................................37
Power saver mode...........................................................................................38
Programming options .......................................................................................39
Security & convenience expansions ...................................................................41
Glossary of terms ............................................................................................43
Quick reference guide .....................................................................................45
Notes ............................................................................................................47
Limited lifetime consumer warranty ....................................................................49
5
© 2008 Directed Electronics. All rights reserved.
Government regulations
This device complies with Part 15 of FCC rules. Operation is subject to the fol­lowing two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesirable operation.
This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential instal­lation. This equipment generates and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television, which can be determined by turning the equipment OFF and ON, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
• Consult the dealer or an experienced radio / TV technician for help.
To satisfy FCC RF exposure compliance requirements, this device should be used
in hand-held, hand operated configurations only. The device and its antenna must maintain a separation distance of 20 cm or more from the person’s body,
except for the hand and wrists, to satisfy RF exposure compliance. This device
is designed to be used in a person’s hands and its operating configurations do
not support normal transmissions while it is carried in pockets or holsters next to
a persons’ body.
This device complies with the Industry Canada Radio Standards Specification
6
© 2008 Directed Electronics. All rights reserved.
RSS 210. Its use is authorized only on a no-interference, no-protection basis; in other words, this device must not be used if it is determined that it causes harm­ful interference to services authorized by IC. In addition, the user of this device must accept any radio interference that may be received, even if this interference could affect the operation of the device.
WARNING!
Changes or modications not expressly approved by the party re-
sponsible for compliance could void the user’s authority to operate this device.
7
© 2008 Directed Electronics. All rights reserved.
Warning! Safety first
The following safety warnings must be observed at all times:
Due to the complexity of this system, installation of this product must only be
performed by an authorized Directed dealer.
When properly installed, this system can start the vehicle via a command signal from the remote control transmitter. Therefore, never operate the system in an enclosed area or partially enclosed area without ventilation (such as a garage). When parking in an enclosed or partially enclosed area or when having the vehicle serviced, the remote start system must be disabled using the installed toggle switch. It is the user’s sole responsibility to properly handle and keep out of reach from children all remote control transmitters to assure that the system does not unintentionally remote start the vehicle. THE USER MUST INSTALL A
CARBON MONOXIDE DETECTOR IN OR ABOUT THE LIVING AREA ADJA­CENT TO THE VEHICLE. ALL DOORS LEADING FROM ADJACENT LIVING AREAS TO THE ENCLOSED OR PARTIALLY ENCLOSED VEHICLE STORAGE
AREA MUST AT ALL TIMES REMAIN CLOSED. These precautions are the sole responsibility of the user.
Remote starters on manual transmission vehicles operate differently than those with automatic transmission
because you must leave your car in neutral. You
must read this Owner’s Guide to familiarize yourself with the proper procedures
regarding manual transmission remote starters. If you have any questions, ask your installer or contact Directed at 1-800-753-0600.
Before remote starting a manual transmission vehicle, be sure to:
Leave the vehicle in neutral and be sure no one is standing in front or •
behind the vehicle.
Only remote start on a flat surface•
Have the parking brake fully engaged•
8
© 2008 Directed Electronics. All rights reserved.
WARNING!
It is the responsibility of the owner to ensure the parking/emergen-
cy brake properly functions. Failure to do so can result in personal injury or prop-
erty damage. We recommend the owner have the parking / emergency brake
system inspected and adjusted by a qualified automotive shop bi-annually.
Use of this product in a manner contrary to its intended mode of operation may result in property damage, personal injury, or death. (1) Never remotely start the vehicle with the vehicle in gear, and (2) Never remotely start the vehicle with the keys in the ignition. The user must also have the neutral safety feature of the vehicle periodically checked, wherein the vehicle must not remotely start while the car is in gear. This testing should be performed by an authorized Directed dealer in accordance with the Safety Check outlined in the product installation guide. If the vehicle starts in gear, cease remote start operation immediately and
consult with the authorized Directed dealer to x the problem.
After the remote start module has been installed, contact your authorized dealer to have him or her test the remote start module by performing the Safety Check outlined in the product installation guide. If the vehicle starts when performing the Neutral Safety Shutdown Circuit test, the remote start unit has not been properly installed. The remote start module must be removed or the installer must properly reinstall the remote start system so that the vehicle does not start in gear. All installations must be performed by an authorized Directed dealer.
OPERATION OF THE REMOTE START MODULE IF THE VEHICLE STARTS IN GEAR IS CONTRARY TO ITS INTENDED MODE OF OPERATION. OPERAT­ING THE REMOTE START SYSTEM UNDER THESE CONDITIONS MAY RESULT IN PROPERTY DAMAGE OR PERSONAL INJURY. YOU MUST IMMEDIATELY
CEASE THE USE OF THE UNIT AND SEEK THE ASSISTANCE OF AN AU­THORIZED Directed DEALER TO REPAIR OR DISCONNECT THE INSTALLED REMOTE START MODULE. DIRECTED WILL NOT BE HELD RESPONSIBLE OR PAY FOR INSTALLATION OR REINSTALLATION COSTS.
9
© 2008 Directed Electronics. All rights reserved.
This product is designed for fuel injected vehicles only. Use of this product in a standard transmission vehicle must be in strict accordance with this guide.
This product should not be installed in any convertible vehicles, soft or hard top with a manual transmission. Installation in such vehicles may pose certain risk.
10
© 2008 Directed Electronics. All rights reserved.
What is included
Two five-button remote controls•
The control module with Stinger™ DoubleGuard® two-stage •
shock sensor
Control center with integrated status LED and Valet override •
switch
Revenger™Soft Chirp™six-tone siren•
A remote start defeat toggle switch•
Window decals•
Your warranty registration•
Important information
Congratulations on the purchase of your state-of-the-art remote start and
alarm system. Due to the complexity of this system, it must be installed
by an authorized dealer only. Installation of this product by anyone other than an authorized dealer voids the warranty. All dealers are provided with a preprinted dealer certificate to verify authorization.
By carefully reading this Owner’s Guide prior to using your system, you will maximize the use of this system and its features. You can print
additional or replacement copies of this manual by accessing our web site at
www.directed.com
.
➤ Your warranty
Your warranty registration must be completely filled out and returned within 10 days of purchase. Your product warranty will not be validat­ed if your warranty registration is not returned. Make sure you receive the warranty registration from your dealer. It is also necessary to keep your proof of purchase, which reflects that the product was installed by an authorized dealer.
11
© 2008 Directed Electronics. All rights reserved.
➤ Replacement remotes
Your system comes with two Responder remote controls (P/N 7153P).
If additional remotes are desired, please see your authorized dealer or visit
www.directedstore.com
to order.
➤ System maintenance
The system requires no specific maintenance. Your One way remote is powered by small coin cell lightweight 3-volt lithium battery that will
last approximately one year under normal use. The remote uses one
CR2032 cell battery. When the battery begins to weaken, the operat­ing range will be reduced.
➤ Low battery indicator
When the batteries are low the alarm then emits an additional chirp upon disarming of the alarm to let you know its time to change the remote battery.
Note:
The Arm/Disarm chirps should be programmed ON for the
alarm to emit any additional chirps during disarm. Ask your authorized dealer if you have any questions.
➤ Battery Replacement
Slide the door up to expose the battery beneath the holder. Remove the expired battery. Place the new battery into the remote control. When
power is returned the remote control is ready for use.
➤ Two Car Operation
You can use the remote control system for two cars with full command capability for both vehicles.
12
© 2008 Directed Electronics. All rights reserved.
To change the car selection:
Press and hold the •
AU X
button until the amber light blinks once or twice indicating current vehicle. one blink & beep = car 1. Two blinks & beeps = car 2 To scroll from one car to the other press the •
AU X
button again. After selecting the car, operation of other features can resume. The se­lected car remains selected until this setting is changed.
13
© 2008 Directed Electronics. All rights reserved.
1-way remote
1
3
4
5
6
2
A U X
8
7
1
2
3
4
5
6

531;
,&$
)&&,'(=6'(,
%$77(5<&5
7
8
7
8
1
2
3
4
5
6
Feature
Description
1
Transmit indicator
2
Lock button Press for one second to arm.
3
Unlock button Press for one second to disarm.
4
Remote start button
Press for one second to activate remote start.
5
Auxiliary button
Press and hold for 1.5 second to activate trunk release.
6
Function button
Allows access to programming and modifies operation of the other buttons.
7
Label Back of remote has label to identify the
remote as 2-way or 1-way
8
Battery Door Remove to access batteries when neces-
sary.
Note:
If Keypad Lock is On, press
AU X
and then press
to exit.
14
© 2008 Directed Electronics. All rights reserved.
➤ Transmitter configuration
Button
Level
Direct Access
AU X
x 1
AU X
x 2
AU X
x 3
AU X
x 4
Arm/Lock
(Panic)
Silent Arm Sensor
Bypass **
Silent Alarm
Sensors †
Silent Alarm
All Zones †
Disarm/Unlock
(Panic)
Silent Disarm Valet On/
Off
Car Finder
Starter
On/Off
Reset
Runtime
Timer Mode
On/Off
Smart Start
On/Off
Defogger
On
A U X
Trunk Release
(Red/White)
AUX 1 AUX 2 AUX 3 ***
A U X
Advance Level
Change Car
(3s) Enter
programming
(8s) *
Request
Temperature
* †
Runtime
Remaining
* †
Event His-
tory Report
* †
*
AU X
button must be pressed and
held
to access state ** System must be in ARMED mode to access this feature *** System must be in remote start mode to access this feature † Only applicable when upgrading to two way remote
Note:
Pressing more than one button simultaneously generates an Error
tone and the LED flashes.
15
© 2008 Directed Electronics. All rights reserved.
➤ Feature List:
Arm
Command
:
Press one time to Arm
Notes
:
Press/hold for 1.5 seconds to Arm the system and then
activate the Panic output
Disarm
Command
:
Press one time to Disarm
Remote Start
Command
:
Press one time to activate Remote Start
A U X
Aux (trunk)
Command
:
Press one time to
open Trunk
A U X
Function shift
Command
: Press 1 to 4 times. ( See Function shift table)
Notes
: Each Press then release, shifts the function of the com-
mand button.
Silent arm
Command
: Press
AU X
one- time and then press
Notes
: Arms the system without chirps
Silent disarm
Command
: Press
AU X
one- time and then press
.
Notes
: Disarms the system without chirps
16
© 2008 Directed Electronics. All rights reserved.
Runtime reset
Command
: Press
AU X
one-time and then
A UX
.
Notes
: Re-starts the remote start runtime counter if remote start is
active.
Aux 1
Command
: Press
AU X
one time and then press
A UX
.
Notes
: This is an optional feature. See your sales rep/installer
for details.
Aux 2
Command
: Press
AU X
two times and then press
A UX
.
Notes
: This is an optional feature. See your sales rep/installer
for details.
Aux 3
Command
: Press
AU X
three times and then press
A UX
.
Notes
: This is an optional feature. See your sales rep/installer
for details.
Sensor Bypass
Command
: Press
AU X
two- times and then
Notes
: Available when armed only: bypasses warn triggers.
Send again to bypass Warn & Full Trigger; Send again to turn bypass off and monitor sensors normally. For more information, see Modified Arming Modes.
Valet mode
Command
: Press
AU X
two-times and then
.
