Directed Electronics 12.2X User Manual

MMooddeell 1122..22XX
OOwwnneerrss GGuuiiddee
3
© 2006 directed electronics
lliimmiitteedd lliiffeettiimmee ccoonnssuummeerr wwaarrrraannttyy
Directed Electronics ("Directed") promises to the original purchaser to repair or replace with a comparable reconditioned model any Directed unit (hereafter the "unit"), exclud­ing without limitation the siren, the remote transmitters, the associated sensors and acces­sories, which proves to be defective in workmanship or material under reasonable use dur­ing the lifetime of the vehicle provided the following conditions are met: the unit was pro­fessionally installed and serviced by an authorized Directed dealer; the unit will be pro­fessionally reinstalled in the vehicle in which it was originally installed by an authorized Directed dealer; and the unit is returned to Directed, shipping prepaid with a legible copy of the bill of sale or other dated proof of purchase bearing the following information: con­sumer's name, telephone number and address; the authorized dealers name, telephone number and address; complete product description, including accessories; the year, make and model of the vehicle; vehicle license number and vehicle identification number. All components other than the unit, including without limitation the siren, the remote trans­mitters and the associated sensors and accessories, carry a one-year warranty from the date of purchase of the same. This warranty is non-transferable and is automatically void if: the original purchaser has not completed the warranty card and mailed it within ten (10) days of the date of purchase to the address listed on the card; the unit's date code or serial num­ber is defaced, missing or altered; the unit has been modified or used in a manner con­trary to its intended purpose; the unit has been damaged by accident, unreasonable use, neglect, improper service, installation or other causes not arising out of defects in materi­als or construction. The warranty does not cover damage to the unit caused by installa­tion or removal of the unit. Directed, in its sole discretion, will determine what consti­tutes excessive damage and may refuse the return of any unit with excessive damage. TO THE MAXIMUM EXTENT ALLOWED BY LAW, ALL WARRANTIES, INCLUD­ING BUT NOT LIMITED TO EXPRESS WARRANTY, IMPLIED WARRANTY, WARRANTY OF MERCHANTABILITY, FITNESS FOR PARTICULAR PURPOSE AND WARRANTY OF NON-INFRINGEMENT OF INTELLECTUAL PROPERTY, ARE EXPRESSLY EXCLUDED; AND DIRECTED NEITHER ASSUMES NOR AUTHORIZES ANY PERSON OR ENTITY TO ASSUME FOR IT ANY DUTY, OBLIGATION OR LIABILITY IN CONNECTION WITH ITS PRODUCTS. DIRECTED DISCLAIMS AND HAS ABSOLUTELY NO LIABILITY FOR ANY AND ALL ACTS OF THIRD PARTIES INCLUDING ITS AUTHORIZED DEAL­ERS OR INSTALLERS. DIRECTED SECURITY SYSTEMS, INCLUDING THIS UNIT, ARE DETERRENTS AGAINST POSSIBLE THEFT. DIRECTED IS NOT OFFERING A GUARANTEE OR INSURANCE AGAINST VANDALISM, DAM­AGE OR THEFT OF THE AUTOMOBILE, ITS PARTS OR CONTENTS; AND HEREBY EXPRESSLY DISCLAIMS ANY LIABILITY WHATSOEVER, INCLUD­ING WITHOUT LIMITATION, LIABILITY FOR THEFT, DAMAGE AND/OR VANDALISM. THIS WARRANTY DOES NOT COVER LABOR COSTS FOR MAINTENANCE, REMOVAL OR REINSTALLATION OF THE UNIT OR ANY
4
© 2006 directed electronics
CONSEQUENTIAL DAMAGES OF ANY KIND. IN THE EVENT OF A CLAIM OR A DISPUTE INVOLVING DIRECTED OR ITS SUBSIDIARY, THE PROPER VENUE SHALL BE SAN DIEGO COUNTY IN THE STATE OF CALIFORNIA. CALIFORNIA STATE LAWS AND APPLICABLE FEDERAL LAWS SHALL APPLY AND GOVERN THE DISPUTE. THE MAXIMUM RECOVERY UNDER ANY CLAIM AGAINST DIRECTED SHALL BE STRICTLY LIMITED TO THE AUTHORIZED DIRECTED DEALER'S PURCHASE PRICE OF THE UNIT. DIRECTED SHALL NOT BE RESPONSIBLE FOR ANY DAMAGES WHATSOEV­ER, INCLUDING BUT NOT LIMITED TO, ANY CONSEQUENTIAL DAMAGES, INCIDENTAL DAMAGES, DAMAGES FOR THE LOSS OF TIME, LOSS OF EARNINGS, COMMERCIAL LOSS, LOSS OF ECONOMIC OPPORTUNITY AND THE LIKE. NOTWITHSTANDING THE ABOVE, THE MANUFACTURER DOES OFFER A LIMITED WARRANTY TO REPLACE OR REPAIR THE CON­TROL MODULE AS DESCRIBED ABOVE. Some states do not allow limitations on how long an implied warranty will last or the exclusion or limitation of incidental or con­sequential damages. This warranty gives you specific legal rights and you may also have other rights that vary from State to State.
This product may be covered by a Guaranteed Protection Plan ("GPP"). See your autho­rized Directed dealer for details of the plan or call Directed Customer Service at 1-800­876-0800. Directed security systems, including this unit, are deterrents against possible theft. Directed is not offering a guarantee or insurance against vandalism, damage or theft of the automobile, its parts or contents; and hereby expressly disclaims any liability what­soever, including without limitation, liability for theft, damage and/or vandalism. Directed does not and has not authorized any person or entity to create for it any other obligation, promise, duty or obligation in connection with this security system.
Make sure you have all of the following information from your dealer:
A clear copy of the sales receipt, showing the following:
Date of purchaseYour full name and addressAuthorized dealer's company name and addressType of alarm installedYear, make, model and color of the automobileAutomobile license numberVehicle identification numberAll security options installed on automobileInstallation receipts
5
© 2006 directed electronics
ttaabbllee ooff ccoonntteennttss
lliimmiitteedd lliiffeettiimmee ccoonnssuummeerr wwaarrrraannttyy .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 33
22--wwaayy rreemmoottee ccoonnttrrooll ddiiaaggrraamm .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .
. .. .. .. .. .. .. .. .. .. .. .. .. .. 77
ssttaannddaarrdd rreemmoottee ccoonnffiigguurraattiioonnss .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 88
wwhhaatt iiss iinncclluuddeedd.. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .
. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 99
iimmppoorrttaanntt iinnffoorrmmaattiioonn.. .. .. ..
.. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 99
system maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
fcc/id notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
rreeppllaac
ceemmeenntt rreemmoottee ccoonnttrroollss .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 1111
22--wwaayy rreemmoottee ccoonnttrrooll ffuunnccttiioonnss .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 1122
standard configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
rreemmoottee ooppeerraattiioonn .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. ..
.. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 1155
system signal paging features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
out of range notification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
pprrooggrraammmmiinngg 22--wwaayy rreemmoottee .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 1177
uussiinngg yyoouurr ssyysstteemm .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 1188
active arming. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
passive arming. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
multi-level security arming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
disarming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
disarming without a transmitter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
dome light control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
silent mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
panic mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
valet mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
one-time bypass. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
nuisance prevention® circuitry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
aauuxxiilliiaarryy
oouuttppuuttss ((ooppttiioonnss)) .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .
. .. .. .. 2299
sshhoocckk sseennssoorr aaddjjuussttmmeenntt .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 3300
enter shock sensor adjustment mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
adjusting the shock sensor setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
exit shock sensor adjustment mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
reset shock sensor to default setting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
ddiiaaggnnoossttiiccss .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .
. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 3322
arming diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
disarming diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
table of zones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
6
© 2006 directed electronics
interpreting zone diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
oowwnneerr rreeccooggnniittiioonn .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. ..
.. .. .. .. .. .. .. .. .. .. 3377
rraappiidd rreessuummee llooggiicc .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 3377
ppoowweerr ssaavveerr mmooddee .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 3388
pprrooggrraammmmiinngg .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 3399
iinnssttaallllaattiioonn ooppttiioonnss .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 4422
vveehhiiccllee rreeccoovveerryy ssyysstteemm ((vvrrss®®)) .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 4422
arming the vrs® . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
vrs® triggered sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
disarming the vrs® . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
pprrooggrraammmmiinngg ooppttiioonnss .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 4466
sseeccuurriittyy && ccoonnvveenniieennccee eexxppaannssiioonnss .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 4488
gglloossssaarryy ooff tteerrmmss .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 5511
qquuiicckk rreeffeerreennccee gguuiiddee .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 5533
7
© 2006 directed electronics
22--wwaayy rreemmoottee ccoonnttrrooll ddiiaaggrraamm
1. Arm/Disarm Indicator (Orange)
2. Receive/Transmit Indicator (Green)
3. Auxiliary Indicator (Yellow)
4. Siren Indicator (Red)
5. Arm Button
6. Disarm Button
7. Panic Button
8. Auxiliary Channel Button
9. Battery Door
1-800-274-0200
RPN 488V/P/X
2(66) CODES
FCC ID: EZSDEI487
2
3
1
5
8
4
6
7
9
8
© 2006 directed electronics
ssttaannddaarrdd rreemmoottee ccoonnffiigguurraattiioonnss
controls the
LLoocckkAArrmm//PPaanniicc OOnn//PPaanniicc OOffff
function.
controls the
UUnnlloocckkDDiissaarrmm//PPaanniicc OOffff
function.
controls
SSiilleenntt MMooddee
and an
AAuuxxiilliiaarryy OOuuttppuutt ((22))
.
controls the
PPaanniic
c OOnn//OOffff
function (hold for 2-seconds).
and pressed together control an
AAuuxxiilliiaarryy OOuuttppuutt ((33))
.
and pressed together control an
AAuuxxiilliiaarryy OOuuttppuutt ((44))
.
and pressed together control an
AAuuxxiilliiaarryy OOuuttppuutt ((55))
.
and pressed together control an
AAuuxxiilliiaarryy OOuuttppuutt ((66))
.
9
© 2006 directed electronics
wwhhaatt iiss iinncclluuddeedd
One control module
One four-button LED 2-way transmitter, 488XD
One four-button transmitter, 7141X
Wire harnesses
Dual diode harness
The 514N six-tone programmable siren
The in-vehicle status LED indicator light
A push-button Valet switch
Your warranty registration
Failsafe
®
Starter Kill ready circuitry
(may require additional labor)
548T transceiver/antenna
iimmppoorrttaanntt iinnffoorrmmaattiioonn
Congratulations on the purchase of your state-of-the-art vehicle
security system. This system has been designed to provide years
of trouble-free operation. Due to the complexity of this system,
it must be installed by an authorized dealer only. Installation of
this product by anyone other than an authorized dealer voids the
warranty. All dealers are provided with preprinted dealer certifi-
cates to verify that they are authorized.
This owner’s guide should help you to get the most out of your
system. Please take the time to read it prior to using the system.
note: On both remotes the panic button is the same color.
10
© 2006 directed electronics
system maintenance
This system needs no specific maintenance beyond 2-way
remote control battery replacement. The 2-way remote is
powered by a 1.5V AAA battery. The 1-way remote is powered
by a pair of 3V CR2016 batteries.
Low Battery Notification
If the battery is low (and this feature is programmed On) the 2-
way remote will emit 2 long beeps 5-seconds after a transmission
is completed. The 2 long beeps will repeat every 25 seconds up
to 3 times (or until a 2-way remote button is pressed).
Battery Replacement
Gently pull the end of the battery door away from the top of the
remote control then slide the door up to expose the battery and
remove the expired battery. Place the new battery into the
remote control observing the correct polarity. When power is
returned the remote control will light all icons and generate
melodies (representing all beeper tones).
your warranty
Your warranty registration must be returned and the bar code
serial number must not be removed. If the warranty registration
is not returned, you do not have a warranty. It is also necessary
to keep your proof of purchase, which reflects that the product
was installed by an authorized dealer. Make sure that you receive
the warranty registration from your dealer.
11
© 2006 directed electronics
fcc/id notice
This device complies with Part 15 of FCC rules. Operation is
subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) This device must accept any
interference received, including interference that may cause
undesirable operation.
Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to
operate this device.
rreeppllaacceemmeenntt rreemmoottee ccoonnttrroollss
You can purchase replacement remote controls from your
Authorized Dealer or on-line at the following web site:
www.directedstore.com
Once you receive your new remote control, please refer to
instructions included on the remote packaging.
3201 Series
12
© 2006 directed electronics
22--wwaayy rreemmoottee ccoonnttrrooll ffuunnccttiioonnss
The 2-way remote control buttons are used to send commands
to the system. The descriptions below reflect the standard config-
uration for this system. The buttons can be custom configured
for the user’s specific needs by the installer.
standard configuration
Button
The arming function is controlled by pressing this button for
one second.
Button
The disarming function is controlled by pressing this button for
one second.
Button
Silent Mode™ and an optional auxiliary function are controlled
by pressing this button. (Silent Mode works by pressing this
button for less than one second before arming or disarming. An
optional auxiliary function, such as trunk release, can be
controlled by pressing this button for 1.5 seconds.)
The auxiliary output controls __________________________.
Button
The panic feature is controlled by pressing this button for
approximately two seconds.
13
© 2006 directed electronics
and Buttons
An optional auxiliary convenience or expansion function that
you have added to your system can be activated by pressing these
buttons simultaneously.
The auxiliary output controls_________________________.
and Buttons
An optional auxiliary convenience or expansion function that
you have added to your system can be activated by pressing these
buttons simultaneously.
The auxiliary output controls_________________________.
and Buttons
An optional auxiliary convenience or expansion function that
you have added to your system can be activated by pressing these
buttons simultaneously.
The auxiliary output controls_________________________.
and Buttons
An optional auxiliary convenience or expansion function that
you have added to your system can be activated by pressing these
buttons simultaneously.
The auxiliary output controls_________________________.
14
© 2006 directed electronics
ttrraannssmmiitttteerr ffuunnccttiioonnss
This system uses a computer-based learn routine to learn the
transmitter buttons. This makes it possible to assign any trans-
mitter button to any system function. The transmitter initially
comes programmed with Standard Configuration, but may also
be customized by an authorized dealer. The buttons in all of the
instructions in this manual correspond to a Standard
Configuration transmitter.
15
© 2006 directed electronics
rreemmoottee ooppeerraattiioonn
The system operates at 434 MHz and incorporates Directed’s propri-
etary out-board technology transceiver. The high frequency combined
with Binary Data communication achieves superior range with two-
way communication.
system signal paging features
A page is the signal the control module sends to the remote control
as confirmation of receipt of a command or alarm system status.
When the remote control receives a page it will generate a page
notification to the user (notifications are audible beeps) and the
LED Icons will display the current system status.
Command Page
When a command (arm/disarm, or auxiliary channel) from the
remote control is sent and received, the system will send a
command page back to confirm receipt.
Alarm Page
If the alarm system is triggered while armed, an Alarm Page will
be sent to the remote control. When the remote receives an
Alarm Page, the LED icons will display the alarm system status
information and the remote control will generate beeps.
An Alarm Page alert is a series of 10 or 4 rapid beeps and the Red
LED will illuminate. This will repeat every 60 seconds to alert
the user that the alarm system was triggered and will continue
16
© 2006 directed electronics
until the alarm page is cleared.
If the shock sensor or optional sensor has triggered the alarm the
remote will display the alarm page with 6 Red LED flashes and
10 rapid beeps.
If the trunk, door, ignition, or hood triggered the alarm the
remote will display the alarm page with the Red LED illumi-
nating for 3-seconds and 4 rapid beeps (repeated 5 times)
Page Recognition (Acknowledgement)
To clear a page alert/notification, quickly press any button on
the remote control. This can be performed at any time during or
after the page notification has occurred.
The remote control will not send a command to the system at
this time; it will only clear future repeats of the page notification.
The next time a button is pressed on the remote control it will
send a command to the system.
out of range notification
If a command is issued from the remote, but the remote is
beyond the range of the vehicle to receive the command, the
remote responds with 3 sets of 2 quick beeps and the Green LED
will flash 6-times.
17
© 2006 directed electronics
pprrooggrraammmmiinngg 22--wwaayy rreemmoottee
To enter programming mode
Press and hold all four remote control buttons simultaneously
until one long beep is heard. Programming mode is now entered.
Beeps On/Off
Press to select beeps On/Off. One beep is notification beeps
On, Two beeps is notification beeps Off. The notification beeps
are programmed On from the factory and can be programmed
Off if they are not desired. When programmed Off the remote
will only flash the LEDs as notification of a command page or
an alarm page.
2-Way LED Remote battery low notification
Press to select low battery notification On/Off. One beep is
low battery notification On. Two beeps is low battery notifica-
tion Off. The Low battery Beeps are programmed On from the
factory and can be programmed Off if they are not desired.
When programmed Off the remote will not give any notification
that the battery charge level in the remote is low.
Page notification
The remote control can be programmed to notify the user of a
page (audibly beeping if the vehicle’s status changes, e.g. door
unlocked, engine started, vehicle violation, etc.). On the 2-way
LED remote press to select page On/Off. One beep is page
On, Two beeps is page Off. When programmed off the remote will
not give any notification that a page was received from the vehicle.
Loading...
+ 37 hidden pages
