PDU620
6A ULTRA-FAST RECOVERY RECTIFIER
PowerDIä5
Features
Glass Passivated Die Construction
·
Ultra-Fast Recovery Time for High Efficiency
·
High Maximum Junction Temperature
·
High Forward Surge Current Capability
·
For Use in Low Voltage, High Frequency Inverters, Free
·
Wheeling, and Polarity Protection Applications
Lead Free Finish, RoHS Compliant (Note 1)
·
"Green" Molding Compound (No Br, Sb)
·
Qualified to AEC-Q101 Standards for High Reliability
·
NEW PRODUCT
TOP VIEW
Maximum Ratings
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
RMS Reverse Voltage
Average Rectified Output Current (See also figure 4)
Non-Repetitive Peak Forward Surge Current
8.3ms Single half sine-wave Superimposed on Rated Load
@ TA= 25°C unless otherwise specified
Characteristic Symbol
Mechanical Data
Case: PowerDIä5
·
Case Material: Molded Plastic, “Green” Molding
·
Compound. UL Flammability Classification Rating 94V-0
Moisture sensitivity: Level 1 per J-STD-020C
·
Terminals: Finish – Matte Tin annealed over Copper
·
leadframe. Solderable per MIL-STD-202, Method 208
Polarity: See Diagram on Page 4
·
Marking: See Page 3
·
Weight: 0.096 grams (approx.)
·
BOTTOM VIEW
Value
V
RRM
V
RWM
V
V
R(RMS)
I
FSM
R
I
O
200 V
141 V
6A
150 A
e
3
Unit
Thermal Characteristics
Characteristic Symbol Typ Max Unit
Thermal Resistance Junction to Soldering Point
Thermal Resistance Junction to Ambient Air (Note 2) T
Thermal Resistance Junction to Ambient Air (Note 3) T
Thermal Resistance Junction to Ambient Air (Note 4) T
Operating Temperature Range
Storage Temperature Range
Notes: 1. RoHS revision 13.2.2003. Glass and High Temperature Solder Exemptions Applied, see
2. FR-4 PCB, 2 oz. Copper, minimum recommended pad layout per http://www.diodes.com/datasheets/ap02001.pdf.
3. Polymide PCB, 2 oz. Copper, minimum recommended pad layout per http://www.diodes.com/datasheets/ap02001.pdf.
4. Polymide PCB, 2 oz. Copper. Cathode pad dimensions 9.4mm x 7.2mm. Anode pad dimensions 2.7mm x 1.6mm.
= 25°C
A
= 25°C
A
= 25°C
A
DS30760 Rev. 2 - 2 1 of 4 PDU620
PowerDI is a trademark of Diodes Incorporated. www.diodes.com ã Diodes Incorporated
R
qJS
R
qJA
R
qJA
R
qJA
T
j
T
STG
EU Directive Annex Notes 5 and 7
¾ 1.5 °C/W
95 ¾°C/W
60 ¾°C/W
40 ¾°C/W
-65 to +175 °C
-65 to +175 °C
.

Electrical Characteristics
@ TA= 25°C unless otherwise specified
Characteristic Symbol
Minimum Reverse Breakdown Voltage (Note 5)
Maximum Forward Voltage
Maximum Reverse Leakage Current (Note 5)
Maximum Reverse Recovery Time
Notes: 5. Short duration test pulse used to minimize self-heating effect.
NEW PRODUCT
T = 150°C
j
0.2
T = 175°C
j
0.4
T = -65°C
j
0.6
0.8
T = 125°C
j
T = 85°C
j
T = 25°C
j
1
F
I , INSTANTANEOUS FORWARD CURRENT (A)
10
1
100m
10m
1m
0
1.2
V
1.4
(BR)R
V
FM
I
RM
t
rr
Value Unit
200 V
0.940
0.860
0.975
0.895
5
500
25 ns
1,000
100
10
1
0.1
0.01
0.001
0
mA
Test Condition
= 5mA
I
R
= 6A, TS= 25°C
I
F
= 6A, TS= 150°C
I
F
V
= 8A, TS= 25°C
I
F
= 8A, TS= 150°C
I
F
= 25°C, VR= 200V
T
S
= 100°C, VR= 200V
T
S
I
= 0.5A, IR= 1.0A
F
= 0.25A (See figure 7)
I
RR
T = 175°C
j
T = 125°C
40
80
j
T = 150°C
j
T = 85°C
j
T = 25°C
j
120
T = -65°C
j
160
200
V , INSTANTANEOUS REVERSE VOLTAGE (V)
V , INSTANTANEOUS FORWARD VOLTAGE (V)
F
.1 Typical Forward Characteristics
Fi
400
350
f=1MHz
7.5
300
250
4.5
200
TAL CAPACITANCE (pF)
T
C,T
150
100
50
RWARD CURRENT (A)
F
I,DCF
1.5
0
0
10
V , REVERSE VOLTAGE (V)
R
20
30
Fig. 3 Typical Total Capacitance vs. Reverse Voltag
R
Fig. 2 Typical Reverse Characteristics
6
Note 4
Note 3
3
Note 2
0
0
25
50
75
T , AMBIENT TEMPERATURE (°C)
A
100
125
150
175
Fig. 4 DC Forward Current Derating
DS30760 Rev. 2 - 2 2 of 4 PDU620
PowerDI is a trademark of Diodes Incorporated. www.diodes.com

4.5
250
I
PK
I
AV
= 1 (DC)
Note 2
200
LTAGE (V)
150
3
100
NEW PRODUCT
1.5
F
P , FORWARD POWER DISSIPATION (W)
0
0
(+)
R
50
V , DC REVERSE V
0
1
(-)
3
2
I , FORWARD CURRENT (A)
F
. 5 Forward Power Dissipation
Fi
50V DC
Approx
5
4
Device
Under
Te st
6
Oscilloscope
(Note 1)
8
7
9
10
(-)
Pulse
Generator
(Note 2)
(+)
0
T , DERATED AMBIENT TEMPERATURE (°C)
+0.5A
0A
-0.25A
-1.0A
50
A
Fig. 6 Operating Temperature Derating
t
rr
Set time base for 50/100 ns/cm
100
150
200
Fig. 7 Reverse RecoveryTime Characteristic and Test Circuit
Ordering Information
Notes: 6. For Packaging Details, go to our website at http://www.diodes.com/datasheets/ap02007.pdf.
Device
PDU620-13
(Note 6)
Packaging Shipping
PowerDI
ä
5 5000/Tape & Reel
Marking Information
U620
YYWWK
DS30760 Rev. 2 - 2 3 of 4 PDU620
PowerDI is a trademark of Diodes Incorporated. www.diodes.com
U620 = Product type marking code
= Manufacturers’ code marking
YYWW = Date code marking
YY = Last digit of year ex: 06 for 2006
WW = Week code 01 to 52
K = Factory Designator

Package Outline Dimensions
NEW PRODUCT
D
b2
L1
E
L1
e
b1
W
b1
LEFT PIN
RIGHT PIN
Note: Pins Left & Right must
be electrically connected
at the printed circuit board.
b1
D
D2
b2
L
E2
L1
e
b1
A
A2
E1
A2
E
BOTTOMSIDE
HEAT SINK
PowerDIä5
A
A2
b1
b2
D
D2
E
e
E1
E2
L
L1
W
Min Max
1.05 1.15
0.33 0.43
0.80 0.99
1.70 1.88
3.90 4.05
3.05 NOM
6.40 6.60
1.84 NOM
5.30 5.45
3.55 NOM
0.75 0.95
0.50 0.65
1.20 1.50
Dim
All Dimensions in mm
