Diodes DFLS160 User Manual

Features

• Guard Ring Die Construction for Transient Protection

• Low Power Loss, High Efficiency

• Patented Interlocking Clip Design for High Surge Current

Capacity

• Qualified to AEC-Q101 Standards for High Reliability

• Lead Free Finish, RoHS Compliant (Note 1)

• Green Molding Compound (No Br, Sb)

DFLS160

1.0A SURFACE MOUNT SCHOTTKY BARRIER RECTIFIER

POWERDI

Mechanical Data

• Case: POWERDI®123

• Case Material: Molded Plastic, “Green” Molding Compound.

UL Flammability Classification Rating 94V-0

• Moisture Sensitivity: Level 1 per J-STD-020

• Terminal Connections: Cathode Band

• Terminals: Finish – Matte Tin annealed over Copper

leadframe. Solderable per MIL-STD-202 Method 208

• Weight: 0.01 grams (approximate)

POWERDI®123

Top View

®

123

Ordering Information (Note 2)

Part Number Case Packaging

DFLS160-7 POWERDI®123 3000/Tape & Reel

Notes: 1. EU Directive 2002/95/EC (RoHS). All applicable RoHS exemptions applied, see EU Directive 2002/95/EC Annex Notes

2. For packaging details, go to our website at http://www.diodes.com.

Marking Information

Date Code Key

Year 2004 2005 2006 2007 2008 2009 2010 2011 2012 2013 2014 2015 2016 2017

Code R S T U V W X Y Z A B C D E

Month Jan Feb Mar Apr May Jun Jul Aug Sep Oct Nov Dec

Code 1 2 3 4 5 6 7 8 9 O N D

POWERDI is a registered trademark of Diodes Incorporated.

F17

DFLS160

Document number: DS30548 Rev. 7 - 2

F17 = Product Type Marking Code
YM = Date Code Marking
Y = Year (ex: R = 2004)

YM

M = Month (ex: 9 = September)

1 of 4

www.diodes.com

December 2011

© Diodes Incorporated

)

)

θ

θ

θ

(BR)

Maximum Ratings @T

= 25°C unless otherwise specified

A

Single phase, half wave, 60Hz, resistive or inductive load.
For capacitance load, derate current by 20%.

Characteristic Symbol Value Unit

Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage

RMS Reverse Voltage
Average Forward Current
Non-Repetitive Peak Forward Surge Current 8.3ms

single half sine-wave superimposed on rated load

Thermal Characteristics

Characteristic Symbol Typ Max Unit

Thermal Resistance Junction to Soldering Point (Note 3)
Thermal Resistance Junction to Ambient (Note 4)
Typical Thermal Resistance (Note 7)
Operating and Storage Temperature Range

T

V
V

V

I

R
R
R

, T

J

RRM
RWM

V

R

R(RMS

F(AV

I

FSM

JS
JA

JC

STG

DFLS160

⎯

125

⎯

60 V

42 V

1.0 A
50 A

6
⎯
18

-65 to +150

°C/W
°C/W
°C/W

°C

Electrical Characteristics @T

= 25°C unless otherwise specified

A

Characteristic Symbol Min Typ Max Unit Test Condition

Reverse Breakdown Voltage (Note 5)
Forward Voltage
Leakage Current (Note 5)
Total Capacitance

Notes: 3. Theoretical R

4. Device mounted on Polymide substrate, 1" x 1" 2oz copper double-sided PC board with minimum recommended pad layout, which can be found on our
website at http://www.diodes.com.

5. Short duration pulse test to minimize self-heating effect

6. Part mounted on 50.8mm*50.8mm GETEK board with 25.4mm*25.4mm copper pad,25% anode,75% cathode. T

7. Part mounted on FR-4 board with 1.8mm X 2.5mm cathode and 1.8mm X 1.2mm anode, 1 oz. copper pads. T

calculated from the top center of the die straight down to the PCB/cathode tab solder junction.

θJS

V

R

V

⎯ ⎯

F

I

⎯ ⎯

R

C

⎯

T

60

⎯ ⎯

0.50 V

0.1 mA

67

⎯

V

IR = 0.2mA
IF = 1.0A
VR = 60V, TA = 25°C

pF

VR = 10V, f = 1.0MHz

= 25°C

A

A = 25°C

100

10

1

0.1

100,000

10,000

1,000

100

10

1

T = 125 C

°

A

T = 150 C

A

T = 25C

A

°

T = 100 C

°

A

°

0.1

0.01

0.01

T = -65C

°

A

0.001

F

I , INSTANTANEOUS FORWARD CURRENT (A)

0.001
0

V , INSTANT ANEOUS FORW ARD VOLTAGE (V)

F

0.5 1.0 1.5

Fig. 1 Typical Forward Characte r istics

R

I , INSTANT ANEOUS REVERSE CURRENT (µA)

0.0001
52030405060

V , INSTANTANEOUS REVERSE VOLTAGE (V)

R

Fig. 2 Typical Reverse Characteristics
