V
ternal Schematic
Features
• Fast Switching Speed
• Ultra-Small Surface Mount Package
• For General Purpose Switching Applications
• Two “BAV70” Circuits In One Package
• Lead Free/RoHS Compliant (Note 1)
• "Green" Device (Note 2)
ADVANCE INFORMATION
Top View
SOT563
Bottom View
BAV70D
SURFACE MOUNT SWITCHING DIODE ARRAY
Mechanical Data
• Case: SOT563
• Case Material: Molded Plastic, “Green” Molding Compound.
UL Flammability Classification Rating 94V-0
• Moisture Sensitivity: Level 1 per J-STD-020
• Terminals: Matte Tin Finish annealed over Copper Alloy
leadframe (Lead Free Plating). Solderable per MIL-STD-202,
Method 208
• Orientation: See Diagram
• Weight: 0.003 grams (approximate)
C
A1 A
In
1
Top View
A
A
2
2
C
2
1
Ordering Information (Note 3)
Part Number Case Packaging
BAV70DV-7 SOT563 3000/Tape & Reel
Notes: 1. No purposefully added lead.
2. Diodes Inc.'s "Green" policy can be found on our website at http://www.diodes.com.
3. For packaging details, go to our website at http://www.diodes.com.
Marking Information
Date Code Key
Year 2011 2012 2013 2014 2015 2016 2017
Code Y Z A B C D E
Month Jan Feb Mar Apr May Jun Jul Aug Sep Oct Nov Dec
Code 1 2 3 4 5 6 7 8 9 O N D
BXA
YM
BXA = Product Type Marking Code
YM = Date Code Marking
Y = Year (ex: Y = 2011)
M = Month (ex: 9 = September)
BAV70DV
Document number: DS35311 Rev. 4 - 2
1 of 4
www.diodes.com
January 2012
© Diodes Incorporated
V
)
θ
(BR)
P
P
OWER
PAT
O
T
T
O
U
O
RWAR
C
U
R
R
T
Maximum Ratings @T
= 25°C unless otherwise specified
A
Characteristic Symbol Value Unit
Non-Repetitive Peak Reverse Voltage
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
RMS Reverse Voltage
Forward Continuous Current (Note 4)
Average Rectified Output Current (Note 4)
Non-Repetitive Peak Forward Surge Current @ t = 1.0μs
@ t = 1.0s
Thermal Characteristics
Characteristic Symbol Value Unit
Power Dissipation (Note 4)
Thermal Resistance Junction to Ambient Air (Note 4)
Operating and Storage Temperature Range
V
T
V
RM
V
RRM
V
RWM
V
R(RMS
I
FM
I
O
I
FSM
P
R
, T
J
R
D
JA
STG
BAV70D
100 V
75 V
53 V
300 mA
150 mA
2.0
1.0
A
200 mW
625 °C/W
-65 to +150
°C
Electrical Characteristics @T
ADVANCE INFORMATION
= 25°C unless otherwise specified
A
Characteristic Symbol Min Max Unit Test Condition
Reverse Breakdown Voltage (Note 5)
Forward Voltage
Reverse Current (Note 5)
Total Capacitance
Reverse Recovery Time
Notes: 4. Device mounted on FR-4 PCB, 1 inch x 0.85 inch x 0.062 inch; pad layout as shown on Diodes Inc. suggested pad layout document AP02001, which can
be found on our website at http://www.diodes.com.
5. Short duration pulse test used to minimize self-heating effect.
V
V
⎯
F
I
⎯
R
C
⎯
T
t
⎯
rr
250
75
R
⎯
0.715
0.855
1.0
1.25
2.5
50
30
25
2.0 pF
4.0 ns
V
IF = 2.5μA
= 1.0mA
I
F
= 10mA
I
F
V
I
= 50mA
F
= 150mA
I
F
V
μA
μA
μA
nA
R
V
R
V
R
V
R
VR = 0, f = 1.0MHz
= IR = 10mA,
I
F
I
rr
= 75V
= 75V, TJ = 150°C
= 25V, TJ = 150°C
= 20V
= 0.1 x IR, RL = 100Ω
1,000
(mA)
200
Note 4
EN
100
N (mW)
I
150
D
10
DISSI
S F
100
,
D
50
0
0125175
25 10050 75 150
T , AMBIENT TEMPERATURE ( C)
A
°
Fig. 1 Power Derating Curve, Total Package
1
ANE
0.1
AN
0.01
F
I , INS
0 0.2 0.4 0.6 0.8 1.0 1.2
V , INSTANTANEOUS FORWARD VOLTAGE (V)
F
Fig. 2 Typical Forward Characteristics, Per Element
BAV70DV
Document number: DS35311 Rev. 4 - 2
2 of 4
www.diodes.com
January 2012
© Diodes Incorporated
V
TANT
O
US R
R
C
U
R
RENT
C, TOT
CAPACITAN
C
(µA)
SE
EVE
ANE
0.001
R
I, INS
0.0001
100
10
1
0.1
0.01
020406080100
V , INSTANTANEOUS REVERSE VOLT AGE (V)
R
Fig. 3 Typical Reverse Characteristics, Per Element
Package Outline Dimensions
ADVANCE INFORMATION
K
Suggested Pad Layout
G
Z
Y
BAV70D
1.60
1.50
E (pF)
1.40
AL
1.30
T
1.20
110100
Fig. 4 T otal Capacitance vs. Reverse Voltage, Per Element
A
B
C
D
G
M
H
C2
X
C2
L
Dimensions Value (in mm)
Z 2.2
C1
G 1.2
X 0.375
Y 0.5
C1 1.7
C2 0.5
V , DC REVERSE VOLT AGE (V)
R
Dim Min Max Typ
SOT563
A 0.15 0.30 0.20
B 1.10 1.25 1.20
C 1.55 1.70 1.60
D - - 0.50
G 0.90 1.10 1.00
H 1.50 1.70 1.60
K 0.55 0.60 0.60
L 0.10 0.30 0.20
M 0.10 0.18 0.11
All Dimensions in mm
BAV70DV
Document number: DS35311 Rev. 4 - 2
3 of 4
www.diodes.com
January 2012
© Diodes Incorporated
V
