QUADRUPLE 2-INPUT NAND GATES

Description

The 74LV00A provides provides four independent 2-input NAND

gates with standard push-pull outputs. The device is designed for

operation with a power supply range of 2.0V to 5.5V.

The inputs are tolerant to 5.5V allowing this device to be used in a

mixed voltage environment. The device is fully specified for partial

power down applications using I

output preventing damaging current backflow when the device is

powered down.

The gates perform the Boolean function:

B

or B

Y 

NEW PRODUCT

Y 

OFF

. The I

circuitry disables the

OFF

Features

 Wide Supply Voltage Range from 2.0V to 5.5V

 Sinks or sources 12mA at V

 CMOS low power consumption

 I

Supports Partial -Power Down Operation

OFF

 Inputs or Outputs accept up to 5.5V

 Inputs can be driven by 3.3V or 5V allowing for voltage

translation applications.

 Schmitt Trigger Action at All Inputs

 ESD Protection Tested per JESD 22

 Exceeds 200-V Machine Model (A115)

 Exceeds 2000-V Human Body Model (A114)

 Exceeds 1000-V Charged Device Model (C101)

 Latch-Up Exceeds 100mA per JESD 78, Class I

 Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2)

 Halogen and Antimony Free. “Green” Device (Note 3)

Notes: 1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant.

2. See http://www.diodes.com/quality/lead_free.html for more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free, "Green" and Lead-free.

3. Halogen- and Antimony-free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and <1000ppm antimony compounds.

74LV00A

Document number: DS35657 Rev. 1 - 2

= 4.5V

CC

Click for Ordering Information

www.diodes.com

Pin Assignments

Applications

 General Purpose Logic

 Power Down Signal Isolation

 Wide array of products such as:

 PCs, networking, notebooks, ultrabooks, netbooks

 Computer peripherals, hard drives, CD/DVD ROM

 TV, DVD, DVR, set top box

1 of 9

74LV00A

October 2013

Pin Descriptions

Pin Number Pin Name Description

1 1A Data Input

2 1B Data Input

3 1Y Data Output

4 2A Data Input

5 2B Data Input

6 2Y Data Output

7 GND Ground

8 3Y Data Output

9 3A Data Input

10 3B Data Input

11 4Y Data Output

12 4A Data Input

NEW PRODUCT

13 4B Data Input

14

Function Table

74LV00A

Logic Diagram

V

CC

Supply Voltage

Inputs Output

A B Y

H H L

L X H

X L H

Absolute Maximum Ratings (Note 4) (@T

Symbol

ESD HBM Human Body Model ESD Protection 2 kV

ESD CDM

ESD MM

VCC

VI

IIK Input Clamp Current VI < 0V

IOK Output Clamp Current VO < -0V

IO

ICC

I

GND

TJ

T

STG

P

TOT

Note: 4. Stresses beyond the absolute maximum may result in immediate failure or reduced reliability. These are stress values and device operation should be within recommend values.

Charged Device Model ESD Protection 1 kV

Machine Model ESD Protection 200 V

Supply Voltage Range -0.5 to +7.0 V

Input Voltage Range note 4 -0.5 to +7.0 V

Continuous Output Current - 0.5V < V

Continuous Current Through V

Continuous Current Through GND -50 mA

Operating Junction Temperature -40 to +150 °C

Storage Temperature -65 to +150 °C

Total Power Dissipation 500 mW

= +25°C, unless otherwise specified.)

A

Parameter Rating Unit

-20 mA

-50 mA

±25 mA

50 mA

CC

+0.5V

O VCC

74LV00A

Document number: DS35657 Rev. 1 - 2

2 of 9

www.diodes.com

October 2013

Recommended Operating Conditions (Note 5) (@T

Symbol Parameter Conditions Min Max Unit

VCC

VI

VO

IOH

IOL

NEW PRODUCT

Δt/ΔV

TA

Note: 5. Unused inputs should be held at VCC or Ground.

Electrical Characteristics (@T

Supply Voltage — 2.0 5.5 V

Input Voltage — 0 5.5 V

Output Voltage — 0

High-Level Output Current

Low-Level Output Current

Input Transition Rise or Fall Rate

Operating Free-Air Temperature

= +25°C, unless otherwise specified.)

A

74LV00A

= +25°C, unless otherwise specified.)

A

VCC

2.0V — -50 mA

2.3V to 2.7V — -2 μA

3.0V to 3.6V — -6 mA

4.5V to 5.5V — -12 mA

2.0V — 50 μA

2.3V to 2.7V — 2 mA

3.0V to 3.6V — 6 mA

4.5V to 5.5V — 12 mA

2.3V to 2.7V — 200

3.0V to 3.6V — 100

4.5V to 5.5V — 20

— -40 +125 °C

V

ns/V

T

= -40°C to +85°C TA = -40°C to +125°C

Symbol Parameter

High-Level Input

VIH

Voltage

Low-Level Input

VIL

Voltage

High-Level

VOH

Output Voltage

Low-Level

VOL

Output Voltage

Power Down

I

OFF

Leakage Current

Input Current

II

Supply Current

ICC

Test Conditions

— 2.0V

— 2.3V to 2.7V

— 3.0V to 3.6V

— 4.5V to 5.5V

— 2.0V — 0.5 — 0.5

— 2.3V to 2.7V —

— 3.0V to 3.6V —

— 4.5V to 5.5V —

= -50μA

I

OH

IOH = -2mA

IOH = -6mA

IOH = -12mA

= 50μA

I

OL

IOL = 2mA

IOL = 6mA

IOL = 12mA

VI or VO = 0 to 5.5V

V

= GND or 5.5V

I

V

= GND or VCC

I

= 0

O

V

CC

2.0V to 5.5V

2.3V 2.0 — 2.0 —

3.0V 2.48 — 2.48 —

4.5V 3.8 — 3.8 —

2.0V to 5.5V — 0.1 — 0.1

2.3V — 0.4 — 0.4

3.0V — 0.44 — 0.44

4.5V — 0.55 — 0.55

0V — 5 — 5 μA

0 to 5.5V — ±1 — ±1 μA

5.5V — 20 — 20 μA

A

Min Max Min Max

1.5 — 1.5 —

V

X 0.7

CC

V

X 0.7

CC

V

X 0.7

CC

VCC-0.1

V

CC

—

X 0.3

—

VCC X 0.7

—

VCC-0.1

Unit

—

— —

VCC X 0.3

—

V

—

V

74LV00A

Document number: DS35657 Rev. 1 - 2

3 of 9

www.diodes.com

October 2013

Switching Characteristics

74LV00A

Symbol Parameter

tPD

Propagation

Delay A

N

to YN

Operating Characteristics

TA = +25°C

Parameter

NEW PRODUCT

Cpd

Power Dissipation

Capacitance per Gate

Noise Characteristics

VCC = 3V, CL = 50pF, TA = +25°C

Symbol Parameter Min Typ Max Unit

V

Quiet output, maximum dynamic VOL

OL(p)

V

Quiet output, minimum dynamic VOL

OL(V)

V

Quiet output, minimum dynamic VOH

OH(V)

V

IH(D)

V

IL(D)

High Level dynamic input voltage 2.31 — — V

Low Level dynamic input voltage — — 0.99 V

Test

Conditions

Figure 1

C

= 15pF

L

Figure 1

C

= 50pF

L

= +25°C

T

V

CC

2.5V ± 0.2V — 7.1 12.9 1 15 1 16

3.3V ± 0.3V — 5 7.9 1 9.5 1 10.5

5.0V ± 0.5V — 3.6 5.5 1 6.5 1 7.5

2.5V ± 0.2V — 9.6 16.6 1 20 1 21

3.3V ± 0.3V — 6.9 11.4 1 13 1 14

5.0V ± 0.5V — 4.9 7.5 1 8.5 1 9.5

Test

Conditions

F = 10 MHz

C

= 50pF

L

V

CC

3.3V 9.5

5.0V 11

A

Min Typ Max Min Max Min Max

Typ Unit

-40°C to +85°C -40°C to +125°C

pF

— 0.2 0.8 V

— -0.1 -0.8 V

— 3.1 — V

Unit

ns

Package Characteristics

Symbol Parameter Test Conditions

Ci

Input Capacitance

Vi = V

CC

74LV00A

Document number: DS35657 Rev. 1 - 2

– or GND

4 of 9

www.diodes.com

V

CC

2.0 to 5.5V — 3.3 10 pF

Min Typ Max Unit

October 2013

Parameter Measurement Information

NEW PRODUCT

VCC

2.0V to 5.5V

VI t

V

CC

Inputs

r/tf

<3ns

74LV00A

VM C

VCC/2

L

15pF or 50pF

Voltage Waveform

Pulse Duration

Notes: A. Includes test lead and test apparatus capacitance. B. All pulses are supplied at pulse repetition rate ≤ 10MHz C. Inputs are measured separately one transition per measurement

D. t

PLH

and t

are the same as t

PHL

PD

Figure 1 Load Circuit and Voltage Waveforms

74LV00A

Document number: DS35657 Rev. 1 - 2

5 of 9

www.diodes.com

Voltage Waveform

Propagation Delay Times

Inverting and Non Inverting Outputs

October 2013

Ordering Information

Device Package Code

74LV00AS14-13 S14

74LV00AT14-13 T14

Note: 6. The taping orientation and tape details can be found at http://www.diodes.com/datasheets/ap02007.pdf

Packaging

(Note 6)

SO-14 2500/Tape & Reel -13

TSSOP-14 2500/Tape & Reel -13

Quantity Part Number Suffix

NEW PRODUCT

Marking Information

13” Tape and Reel

74LV00A

(1) SO14, TSSOP14

Part Number Package

74LV00AS14 SO-14

74LV00AT14 TSSOP-14

74LV00A

Document number: DS35657 Rev. 1 - 2

6 of 9

www.diodes.com

October 2013

Package Outline Dimensions (All Dimensions in mm)

Please see AP02002 at http://www.diodes.com/datasheets/ap02002.pdf for latest version.

Package Type: SO-14

Gauge Plane

NEW PRODUCT

B

Package Type: TSSOP-14

H

E

7

°

(

4

x

D

)

e

A2

A1

A

L

Detail “A”

Pin# 1 Indent

B

L

G

K

A

a

1

D

C

F1

F

Detail ‘A’

5 2

.

0

2

a

Gauge Plane Seating Plane

Detail ‘A’

74LV00A

SO-14

Dim Min Max

A 1.47 1.73

A1 0.10 0.25



A2 1.45 Typ

B 0.33 0.51 D 8.53 8.74 E 3.80 3.99 e 1.27 Typ H 5.80 6.20 L 0.38 1.27

0 8



All Dimensions in mm

TSSOP-14

Dim Min Max

a1 7° (4X) a2

0

A 4.9 5.10 B 4.30 4.50 C



D 0.8 1.05 F 1.00 Typ

F1 0.45 0.75

G 0.65 Typ K 0.19 0.30 L 6.40 Typ

All Dimensions in mm

8°

1.2

74LV00A

Document number: DS35657 Rev. 1 - 2

7 of 9

www.diodes.com

October 2013

Suggested Pad Layout

Please see AP02001 at http://www.diodes.com/datasheets/ap02001.pdf for the latest version.

Package Type: SO-14

X

C2

C1

Y

NEW PRODUCT

Package Type: TSSOP-14

X

C2

Y

C1

Dimensions Value (in mm)

X 0.60

Y 1.50 C1 5.4 C2 1.27

Dimensions Value (in mm)

X 0.45

Y 1.45 C1 5.9 C2 0.65

74LV00A

Document number: DS35657 Rev. 1 - 2

8 of 9

www.diodes.com

October 2013
