AF4915ZTL - Wired
Marke: Dino-Lite
Artikelnummer: AF4915ZTL
Short Description
1.3 Megapixel Edge sensor
Extended Depth of Field (EDOF)
Extended Dynamic Range (EDR)
Flexible LED Control (FLC)
Automatic Magnification Reading (AMR)
Beschreibung
The Dino-Lite AF4915ZTL is part of the Long Working Distance (LWD) series and
connects to your device via USB. The AF4915ZTL is Wireless-ready, but requires the
(optional) WF-20 to make it a fully wireless solution.
The AF4915ZTL is equipped with premium features such as Extended Depth of Field
(EDOF), Extended Dynamic Range (EDR), Flexible LED Control (FLC), integrated
polarizer, extensive measurement functionality and Automatic Magnification Reading
(AMR) for measurement-intensive applications.
The main features of the AF4915ZTL are:
• Wireless-ready, requires the WF-20 adapter (optional)
• 10-140x magnification
• 1.3 Megapixel Edge sensor
• Adjustable polarizer
• Extended Depth of Field (EDOF)
• Extended Dynamic Range (EDR)
• Automatic Magnification Reading (AMR)
• Flexible LED Control (FLC)
• And more...
(*EDOF/EDR only functions under Windows OS)
Working distance/field of view/depth of field
Magnification
Rate
Listed values
may differ
slightly
10 234.5 39.0 31.2 12
20 112.5 19.5 15.6 4.5
30 72.5 13.0 10.4 3.1
40 54.5 9.8 7.8 1.8
50 43.5 7.8 6.2 1.2
60 37.5 6.5 5.2 0.9
70 33.7 5.6 4.5 0.6
80 31.3 4.9 3.9 0.5
90 29.9 4.3 3.5 0.37
100 29.2 3.9 3.1 0.28
110 29.1 3.5 2.8 0.22
Working
Distance *
* Without front
cap
Field of View(x) Field of
View(y)
Depth of Field
Unit = mm
120 29.3 3.3 2.6 0.17
130 29.8 3.0 2.4 0.12
140 30.5 2.8 2.2 0.09
Spezifikation
Lighting
Light/ LED type White
Light/ LED type Wireless-ready, requires the WF-20 adapter
(optional)
Number of LEDs 8
LED on/off switchable: Yes
Infrared filter IR cut-filter >650 nm
Diffuser available Yes (N3C-D included)
Emission filter No
Polarizer Yes, linear
Optics
Magnification 10-140x
Macro zoom No
Working distance Long
Lens type Glass with anti-reflection coating
Sensor
Sensor type CMOS
Resolution 1.3 Megapixel (1280x1024)
Maximum frame rate 30 fps
Compatibility
Interface USB 2.0
Operating system Windows 7, 8, 10 & 11, MacOS 10.12 and up”
Included software DinoCapture 2.0 (Windows), DinoXcope (Mac
OS)
Supported image formats
(Windows)
Supported video formats
(Windows)
Supported image formats
(MacOS)
Supported video formats
(MacOS)
Imaging standards DirectShow, UVC
Housing
Housing material Composite/ plastic housing
Magnification lock Yes
BMP, GIF, PNG, JPG, TIF, RAS, PNM, TGA,
PCX, MNG, WBMP, JP2, JPC, PGX
WMV, FLV, SWF
JPEG, PNG
MOV
Dimensions 11.4cm (L) x 3.3cm (D)
Weight 111g
Cable length 1.8m
Features
Special feature Automatic Magnification Reading (AMR),
Extended Dynamic Range (EDR), Extended Depth
of Field (EDOF), Flexible LED Control (FLC)
Measurement Yes
Calibration Yes
Microtouch sensor Yes
ESD safe No
Information
Package contents Microscope, carry pouch, software CD, calibration
target, user manual, N3C-O- Open cap, N3C-C-
Closed cap, N3C-D- Diffuser cap, N3C-E-
Extension cap, N3C-L- Long cap, N3C-S- Side
light cap
Warranty information 2 years European warranty
Regulatory approval CE, FCC, ROHS
Price range €700,00 - €800,00
