AM7115MZTL - EDGE
Marke: Dino-Lite
Artikelnummer: AM7115MZTL
Short Description
5 Megapixel resolution
Robust metal housing
10-140x magnification
Long working distance
Flexible LED Control (FLC)
Beschreibung
With the use of the latest, cutting-edge optics, a brand new 5 megapixel sensor and
several special features such as Flexible LED Control (FLC) and full aluminum body, the
Dino-Lite AM7115MZTL is a marvel of technology and the best choice for the highdemanding professional. The Dino-Lite AM7115MZTL offers superb image quality and
color reproduction in a robust, compact and appealing housing.
The AM7115MZTL is part of the Long Working Distance (LWD) range and with its
Long Working Distance and magnification range from 10 – 140x, it is suitable for a wide
range of applications where extra distance to the object or a larger field of view is
required.
The extra working distance and larger field of view make this model an ideal solution for
tasks such as repair, rework or assembly or for working with bulky or fragile objects that
cannot be touched. Because of the built-in polarization filter this model is ideal when
working with shiny or reflective objects such as metal, plastic, glass, jewelry, electronics,
etc.
The main features of the AM7115MZTL are:
• 5 Megapixel Edge sensor
• Long Working Distance (LWD)
• 10-140x magnification
• Integrated polarizer
• Aluminum housing
• Flexible LED Control (FLC)
• Extensive measurement functions
• Calibration
• Exchangeable front caps
• And more...
Working distance/field of view/depth of field
MAGNIFICATI
ON RATE
Listed values
may differ
slightly
10 234.5 39.0 31.2 12
20 112.5 19.5 15.6 4.5
30 72.5 13.0 10.4 3.1
40 54.5 9.8 7.8 1.8
WORKING
DISTANCE*
* Without front
cap
FIELD OF
VIEW(X)
FIELD OF
VIEW(Y)
DEPTH OF
FIELD
Unit = mm
50 43.5 7.8 6.2 1.2
60 37.5 6.5 5.2 0.9
70 33.7 5.6 4.5 0.6
80 31.3 4.9 3.9 0.5
90 29.9 4.3 3.5 0.37
100 29.2 3.9 3.1 0.28
110 29.1 3.5 2.8 0.22
120 29.3 3.3 2.6 0.17
130 29.8 3.0 2.4 0.12
140 30.5 2.8 2.2 0.09
Spezifikation
Lighting
Light/ LED type White
Number of LEDs 8
LED on/off switchable: Yes
Infrared filter IR cut-filter >650 nm
Diffuser available Yes (N3C-D included)
Emission filter No
Polarizer Yes, linear
Optics
Magnification 10-140x
Macro zoom No
Working distance Long
Lens type Glass with anti-reflection coating
Sensor
Sensor type CMOS
Resolution 5 Megapixel (2592x1944)
Maximum frame rate 30 fps
Compatibility
Interface USB 2.0
Operating system Windows 7, 8, 10 & 11, MacOS 10.9 and up
Included software DinoCapture 2.0 (Windows), DinoXcope (Mac
OS)
Supported image formats
(Windows)
Supported video formats
(Windows)
Supported image formats
(MacOS)
Supported video formats
BMP, GIF, PNG, JPG, TIF, RAS, PNM, TGA,
PCX, MNG, WBMP, JP2, JPC, PGX
WMV, FLV, SWF
JPEG, PNG
MOV (max 1.3MP)
(MacOS)
Imaging standards DirectShow, UVC
Wifi Wireless-ready, requires the WF-10 WiFi streamer
(optional)
Housing
Housing material Metal housing
Magnification lock Yes
Dimensions 10.5cm (L) x 3.2cm (D)
Weight 135gr
Cable length 1.8m
Features
Special feature Flexible LED Control (FLC)
Measurement Yes
Calibration Yes
Microtouch sensor Yes
ESD safe Yes
Information
Package contents Microscope, carry pouch, software CD, calibration
target, user manual, N3C-O- Open cap, N3C-C-
Closed cap, N3C-D- diffuser cap, N3C-E-
extension cap, N3C-L- Long cap, N3C-S- Side
light cap
Warranty information 2 years European warranty
Regulatory approval CE, FCC, ROHS
Price range €900,00 - €1100,00
