Dingtek A300 User Manual

GPS Vehicle Tracker A300

User manual

Version V1.3
Date:2012-09-05

Beijing Dinghengtai Technology Co., Ltd. Tel:[phone]

http://www.dingtek.com E-mail: [e-mail]

Room 605, Building Botai B, Nanhudongyuan 122, Chaoyang District, Beijing, China 100102 Page

1

Index

Query function................................................................................................................. 3

Settings............................................................................................................................. 3

Control............................................................................................................................... 5

Alarm.................................................................................................................................. 6

Other...................................................................................................................................7

wire diagram.....................................................................................................................8

Beijing Dinghengtai Technology Co., Ltd. Tel:[phone]

http://www.dingtek.com E-mail: [e-mail]

Room 605, Building Botai B, Nanhudongyuan 122, Chaoyang District, Beijing, China 100102 Page

2

Query function

1, Position query

After received position query instructions, the terminal would returns the current position of
the vehicle information. Location information include: time, latitude, longitude, speed, position,
orientation marks, vehicles and terminal state, etc.

2, Parameters status query

After received the parameter states query instructions,the terminal would return to the
current state of the vehicle information. State information include: position information,
vehicle state, terminal state, set parameters, mileages etc.

3, Version query

After received the version query instructions,the terminal would return the current version of
vehicle information. Version query include:terminal model, terminal chip types, software
version, software release time.

Settings

1, Fixed time/ set times to return position information settings

Set designated vehicles according to the fixed time/times to send the location information to the
center through UDP.

This instruction request the terminal use interval as the time interval, return location
information, up to 65535 times positioning information.

2, Fixed time return location information’s time interval settings

This settings include return the location information’s time interval when the car power on
and off.

When the car power on, the time interval of the return location information, the factory default
is 30 seconds.
When the car power off, the time interval of the return location information, the factory default
is 0 seconds.

*If the car power off, the return location information’s time interval is 0 seconds, whatever the
car is power on and off, the return location information’s time interval according to the car
power on time interval.

If the car power off, the return location information’s time interval >o seconds, the terminal
would return the location time interval according to the car power on and off separately.
