REV. DESCRIPTION DATE PCN INT'L

00 FIRST ISSUE FEB. 14, 2018 15112 I.I.

FIG. 1

FIG. 2

CORRUGATE BOX

SUPPLIER IN THE SER

DRAWING 7121700000

SUITABLE

FINAL PACK

DIMENSIONS AS

PROVIDED BY

CARTON LABEL

SEE TABLE AND

NOTES:

SEE TABLE FOR PART NUMBERS AND SKU'S1. BILL OF MATERIAL: AS NOTED ON THIS DRAWING.2. PACKAGING MUST BY ABLE TO PASS SIMULATED 3A I.S.T.A. TEST. 3. ROCKS SHOULD NOT SPILL OUT OF THE PACKAGING. GROUP SKU'S:4. CDFI1000-BLKRCK, 2 OF CDFI500-BLKRCK, CDFI1000-RVRCK, 2 OF CDFI500-RVRCK

ROCK MEDIA SET SEE TABLE MATERIAL: NATURAL ROCKS ROCKS TO BE FREE OF DUST. PLACE ROCKS IN SUITABLE PLASTIC BAG, NOT SHOWN.

9601980200 CDFI500-RVRCK RIVER ROCK FIG. 2 5.2KG / 11.5 LBS 7121700200 355x158x81

9601980100 CDFI500-BLKRCK BLACK ROCK FIG. 1 5.4KG / 11.9 LBS 7121700100 355x158x81

ROCK'S WEIGHT

P/N SKU DESCRIPTION ROCK SPEC

ROCK'S WEIGHT

+/-0.1

CARTON LABEL REF. PACK DIM.

UNLESS OTHERWISE SPECIFIED

No sharp edges on all pa rts.

ALL DIM. IN MILLIMETERS DO NOT SCALE FLAT IS FOR REFERENCE ONLY TOLERANCES: X.XX 0.15 X.X 0.8 X 3 HOLES: 0.15 ANGLES: 2

C THIS SYMBOL REPRESENTS A CONTROL DIMENSION. CONTROL DIMENSIONS ARE CONSIDERED TO BE A GOOD INDICATOR OF WHETHER A MANUFACTURING PROCESS IS IN CONTROL. THESE DIM. MUST HAVE A MIN. Cpk OF 1.33 FOR A SAMPLE 31 CONSECUTIVE PIECES.

MATERIAL:

FINISH:

WHERE USED:

DR BY:

CHK'D:

SCALE:

This drawing and the design of this article represented herein, are the exclusive property of Dimplex North America Limited and are provided strictly on a confidential basis. The drawing and design shall be used only for the purposes for which they have been provided and shall not be produced, reproduced, altered, used, published or disclosed to others without the prior written consent of Dimplex North America Limited.

AS NOTED

NOTED

CDFI500...

I.I.

FEB. 9, 2018

I.I.

FEB. 9, 2018

1:4

DATE

TITLE:

DWG NO.:

9601980000

ACCESSORY, ROCK MEDIA

SHEET:

1 OF 1

REV.:

SIZE:
