Dimplex Montclair, Stamford Owner's Manual

08/51835/0 Issue 1

The product complies with the European Safety Standards EN60335-2-30 and the European S tandard Electromagnetic Compatibility (EMC)
EN55014, EN60555-2 and EN60555-3. These cover the essential requirements of EEC Directives 2006/95/EC and 2004/108/EC.

UK

Stamford

Montclair

1

2

3

4

123

Note: Graphic shows Stamford
Cast Fret, Montclair Fret is
removed in the same manner as
the Stamford Fret, see paragrapgh
titled “Fixing” for details.

Model Dim A
Montclair 150
Stamford 195

O

I

II

I

IMPORTANT: THESE INSTRUCTIONS SHOULD BE READ CAREFULL Y AND RET AINED FOR FUTURE REFERENCE

General

Unpack the heater carefully and retain the packaging for possible future
use, in the event of moving or returning the fire to your supplier.

The fire incorporates a flame effect, which can be used with or without
heating, so that the comforting effect may be enjoyed at any time of the
year. Using the flame effect on its own only requires little electricity.

Before connecting the heater check that the supply voltage is the same
as that stated on the heater.

Please note: Used in an environment where background noise is very
low, it may be possible to hear a sound which is related to the operation
of the flame effect. This is normal and should not be a cause for concern.

Electrical connection

WARNING – THIS APPLIANCE MUST BE EARTHED
This heater must be used on an AC ~ supply only and the voltage marked

on the heater must correspond to the supply voltage.
Before switching on, please read the safety warnings and operating

instructions.

Fixing - see Fig. 1,3 & 4.

It is recommended the appliance be securely fixed via the fixing holes
on the base.
The product should be located in its intended position and the fret and

fuel bed remove to allow access to the fixing holes.
To remove the fret and fuel bed from the fire, grip the fret and lift it up and

then out away from the fire, place this somewhere safe, next remove the
3 fixing screws from the fuel bed and slide it away from the fire.(See Fig.
4, shown Stamford Fret option).

The 2 fixing holes should then be marked and pilot holes drilled if required,
screw fix the fire into position and then refit the fret and fuel bed in
reverse of above.

The Montclair fret removes in the same manner as the Stamford fret.

Manual Controls - see Fig. 2

Three switches provide a choice of heat setting. Each switch is activated
when the bottom half of the switch is pushed in.

Switch 1 Controls the electricity supply to the heater.

Note: This switch must be in the ON position for the heater
to operate with or without heat.

Switch 2 Provides 950 W heat output.
Switch 3 Provides 1900 W output when used in conjunction with switch2

Thermal Safety Cut-out

A thermal safety cut-out is incorporated in the heater to prevent damage
due to overheating. This can happen if the heat outlet was restricted in
any way. The heater will switch on once the obstruction has been removed
and the heater has cooled. If the cut-out continues to operate intermittently,
the heater should be switched off and a service agent contacted.

Maintenance

WARNING: AL W AYS DISCONNECT FROM THE POWER SUPPL Y BEFORE
ATTEMPTING ANY MAINTENANCE.

Light Emitting Diode

This fire is fitted with LED (Light Emitting Diode) bulbs in place of
conventional bulbs . These generate the same light levels as conventional
bulbs, but use a fraction of the energy consumed. These LED bulbs are
maintenance free and will not require replacing during the life of the
product.

UK

Important Safety Advice

When using electrical appliances, basic precautions should
always be followed to reduce the risk of fire, electrical
shock and injury to persons, including the following:
If the appliance is damaged, check with the supplier before
installation and operation.
Do not use outdoors.

Do not use in the immediate surroundings of a bath,
shower or swimming pool.

Do not locate the appliance immediately below a fixed
socket outlet or connection box.

The appliance carries the W arning DO NOT COVER,
indicating that it must not be covered.

This appliance can be used by children aged form 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the
hazards involved. Children shall not play with the
appliance. Cleaning and user maintenance shall not be
made by Children without supervision.

Children of less than 3 years should be kept away unless
continuously supervised. Children aged from 3 years and
less than 8 years shall only switch on/off the appliance
provided that it has been placed or installed in its intended
normal operating position and they have been given
supervision or instruction concerning use of the appliance
in a safe way and understanding the hazards involved.
Children aged from 3 years and less than 8 years shall not
plug in, regulate and clean the appliance or perform user
maintenance.

Do not use this appliance in series with a thermal control,
a program controller, a timer or any other device that
switches on the heat automatically, since a fire risk exists
when the appliance is accidentally covered or displaced.
This appliance is not equipped with a device to control the
room temperature. Do not use this appliance in small
rooms when they are occupied by persons not capable of
leaving the room on their own, unless constant supervision
is provided.
Ensure that furniture, curtains or other combustible
material are positioned no closer than 1 metre from the
appliance.
In the event of a fault unplug the appliance.
Unplug the appliance when not required for long periods.

Although this appliance complies with safety standards, we
do not recommend its use on deep pile carpets or on long
hair type of rugs.
The appliance must be positioned so that the plug is
accessible.
If the supply cord is damaged it must be replaced by the
manufacturer or service agent or a similarly qualified
person in order to avoid a hazard.
Keep the supply cord away from the front of the appliance.
Warning: In order to avoid overheating, do not cover the
appliance. Do not place material or garments on the
appliance, or obstruct the air circulation around the
appliance, for instance by curtains or furniture, as this
could cause overheating and a fire risk.
Warning: In order to avoid a hazard due to inadvertent
resetting of the thermal cut-out, this appliance must not be
supplied through an external switching device, such as a
timer, or connected to a circuit that is regularly switched
on and off by the utility.
CAUTION - Some parts of this product can become very
hot and cause burns. Particular attention has to be given
where children and vulnerable people are present.

This instruction can be found at WWW.DIMPLEX.CO.UK

UK

IMPORTANT: THESE INSTRUCTIONS SHOULD BE READ CAREFULL Y AND RET AINED FOR FUTURE REFERENCE

Dimplex
A Division of GDC Group Ltd
Millbrook House
GrangeDrive
HedgeEnd
Southampton
Hampshire.SO30 2DF

TEL: [phone]
FAX: [phone]
WEBSITE: www.dimplex.co.uk

Republic of Ireland Tel. [phone]

[c] GDC Group Ltd,
All rights reserved. Material contained in this publication may not be reproduced in whole or in part, without prior permission in writing of GDC Group Ltd.

Maintenance

WARNING: AL W AYS DISCONNECT FROM THE POWER SUPPL Y BEFORE
ATTEMPTING ANY MAINTENANCE.

Light Emitting Diode

This fire is fitted with LED (Light Emitting Diode) bulbs in place of
conventional bulbs . These generate the same light levels as conventional
bulbs, but use a fraction of the energy consumed. These LED bulbs are
maintenance – free and will not require replacing during the life of the
product.

Cleaning

WARNING – ALWAYS DISCONNECT FROM THE POWER SUPPLY
BEFORE CLEANING THE HEATER.

For general cleaning use a soft clean duster – never use abrasive
cleaners. The glass viewing screen should be cleaned carefully with a
soft cloth. DO NOT use proprietary glass cleaners.

To remove any accumulation of dust or fluff the soft brush attachment of
a vacuum cleaner should occasionally be used to clean the outlet grille of
the fan heater.

Three switches provide a choice of heat setting. Each switch is activated
when the bottom half of the switch is pushed in.

Recycling

For electrical products sold within the European Community .
At the end of the electrical products useful life it should not

be disposed of with household waste. Please recycle
where facilities exist. Check with your Local Authority or
retailer for recycling advice in your country.

After Sales Service

Your product is guaranteed for one year from the date of purchase.
Within this period, we undertake to repair or exchange this product free

of charge (excluding lamps & subject to availability) provided it has been
installed and operated in accordance with these instructions.

Your rights under this guarantee are additional to your statutory rights,
which in turn are not affected by this guarantee.

Should you require after sales information or assistance with this product,
please contact 0844 879 8588 (UK) or 01 842 4833 (R.O.I.)

Please retain your receipt as proof of purchase.

The product complies with the European Safety Standards EN60335-2-30 and the European Standard Electromagnetic Compatibility (EMC) EN55014, EN60555-2 and
EN60555-3. These cover the essential requirements of EEC Directives 2006/95/EC and 2004/108/EC
