Dimplex MINICUBE-B, MINICUBE-RED User Manual

MINI CUBE

AUS/NZ

08/51232/0 Issue 3

1

205

330

370

1

3

2

II

2

I

IMPORTANT : THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND RETAINED FOR FUTURE REFERENCE

Important Safety Advice

When using electrical appliances, basic
precautions should be followed to reduce

the risk of re, electric shock, and injury to

persons, including the following:
If the appliance is damaged, check

immediately with the supplier before

installation and operation.
Do not use this appliance in the immediate

surroundings of a bath, shower or swimming
pool.

Do not use outdoors.
This appliance must not be located

immediately above or below a xed socket
outlet or connection box.

WARNING : The appliance carries

the Warning Symbol indicating that it
must not be covered or has a Do not
cover label. Do not cover or obstruct
in any way the heat outlet grille located
underneath the appliance, overheating will
result if the appliance is accidentally covered.

Do not place material or garments on the
appliance, or obstruct the air circulation

around the appliance, for instance by

curtains or furniture, as this could cause

overheating and a re risk.
In the event of a fault unplug the heater.

Unplug the appliance when not required

for long periods.The supply cord must be

placed on the right hand side of the heater

away from the heat outlet underneath the

appliance.

This appliance can be used by children
aged from 8 years and above and persons
with reduced physical, sensory or mental
capabilities or lack of experience and
knowledge if they have been given
supervision or instruction concerning use of
the appliance in a safe way and understand
the hazards involved. Children shall not
play with the appliance. Cleaning and user
maintaince shall not be made by Children
without supervision.

Children of less than 3 years should be
kept away unless continuously supervised.
Children aged from 3 years and less than 8
years shall only switch on/off the appliance
provided that it has been placed or installed

in its intended normal operating position

and they have been given supervision or

instruction concerning use of the appliance

in a safe way and understanding the hazards
involved. Children aged from 3 years and
less than 8 years shall not plug in, regulate

and clean the appliance or perform user
maintaince.

The appliance must be positioned so that
the plug is accessible.

If the supply cord is damaged it must be
replaced by the manufacturer or service
agent or similarly qualied person in order
to avoid a hazard.

CAUTION: In order to avoid a hazard due to
inadvertent resetting of the thermal cut-out,

this appliance must not be supplied through

an external switching device, such as a timer,
or connected to a circuit that is regularly
switched on and off by the utility.

CAUTION - Some parts of this product can
become very hot and cause burns. Particular
attention has to be given where children and
vulnerable people are present.

This instruction can be found at

www.Dimplex.co.uk

General

Unpack the heater carefully and retain the packaging for possible future
use, in the event of moving or returning the re to your supplier.

These models are designed to be free standing and are normally

positioned against a wall.

The re incorporates a ame effect, which can be used with or without
heating, so that the comforting effect may be enjoyed at any time of
the year. Using the ame effect on its own requires very little electricity.

A choice of 750W or 1500W heat output is provided by the fan heater,

which is located at the bottom of the unit.
Before connecting the heater check that the supply voltage is the same

as that stated on the heater.

Please note: Used in an environment where background noise is very
low, it may be possible to hear a sound which is related to the operation
of the ame effect. This is normal and should not be a cause for concern.

Electrical connection

WARNING – THIS APPLIANCE MUST BE EARTHED.

This heater must be used on an AC ~ supply only and the voltage marked
on the heater must correspond to the supply voltage.

Before switching on, please read the safety warnings and operating

Instructions.

Controls - see Fig. 2

Three switches provide a choice of heat settings. A switch is in the ON

position when the side with the markings on (i.e. I, I, or II) is pushed in.

Switch 1 (I) Controls the electricity supply to the heater and

the ame effect.

Note: This switch must be in the ON (I) position
for heater to operate with or without heat.

Switch 2 (I) Provides 750W heat output
Switch 3 (II) Provides 1500W heat output with switch 2 in the

ON positon also.

Thermal Safety Cut-out

A thermal safety cut-out is incorporated in the heater to prevent damage
due to overheating. This can happen if the heat outlet was restricted
in any way. The heater will switch on once the obstruction has been
removed and the heater has cooled. If the cut-out continues to operate
intermittently, the heater should be switched off and a service agent

contacted.

Maintenance

WARNING: ALWAYS DISCONNECT FROM THE POWER SUPPLY
BEFORE ATTEMPTING ANY MAINTENANCE.

Light Emitting Diode

This re is tted with LED (Light Emitting Diode) bulbs in place of
traditional incandescent bulbs. These generate the same light levels as
traditional bulbs, but use a fraction of the energy consumed.

Recycling

For electrical products sold within the European

Community.

At the end of the electrical product’s useful life it should

not be disposed of with household waste. Please recycle
where facilities exist. Check with your Local Authority or
retailer for recycling advice in your country.

Cleaning

WARNING – ALWAYS DISCONNECT FROM THE POWER SUPPLY
BEFORE CLEANING THE HEATER.

For general cleaning use a soft clean duster – never use abrasive
cleaners. The glass viewing screen should be cleaned carefully with a
soft cloth. DO NOT use proprietary glass cleaners.

To remove any accumulation of dust or uff the soft brush attachment of
a vacuum cleaner should occasionally be used to clean the outlet grille

of the fan heater.

After Sales Service

Your product is guaranteed for two years from the date

of purchase. Within this period, we undertake to repair or

exchange this product free of charge (excluding transducer
discs & subject to availability) provided it has been installed

and operated in accordance with these instructions. Your

rights under this guarantee are additional to your statutory
rights, which in turn are not affected by this guarantee.

Should you require after sales information or assistance
with this product please go to www.dimplex.com.au in

Australia or www.dimplex.co.nz in New Zealand and
select “Contact”.

Please retain your receipt as proof of purchase.

The product complies with the European Safety Standards EN60335-2-30 and the European Standard Electromagnetic Compatibility (EMC) EN55014, EN60555-2 and EN60555-3. These

cover the essential requirements of EEC Directives 2006/95/EC and 2004/108/EC

Glen Dimplex Australia Pty Ltd Glen Dimplex New Zealand Ltd

Unit1, 21 Lionel Road, 38 Harris Road,

Mount Waverley VIC 3149 East Tamaki, Auckland 2013,

Australia New Zealand

PH: 1300 556 816 PH: 09 274 8265
Fax: [phone] Fax: [phone]
Email: [e-mail] Email: [e-mail]

Web: www.dimplex.com.au Web: www.dimplex.co.nz
