Dimplex LAGsu Assembly Instructions Manual

08/51850/0 ISS 1

In keeping with our policy of continuous product development, we reserve the right to make changes without notice.

LAGUNA SURROUND

LAGsu

ASSEMBLY INSTRUCTIONS

1

x4

CONTENTS

1 X BASE
1 X LH SIDE
1 X RH SIDE
1 X BASE INFILL
1 X LH SIDE INFILL
1 X RH SIDE INFILL
1 X TOP INFILL
1 X TOP PANEL
4 X WING BOLTS
4 X GLASS STUDS
20 X THREADED STUDS
24 X WASHERS
20 X WING NUTS
1 X GLASS SHELF LARGE
1 x GLASS SHELF SMALL

Note: For service removal of the fi rebox, fi rstly remove this glass shelf.

3

x4

x2

2

5

4

Optional Support•

x6

x4

7

6

x4

After Sales Service

Your product is guaranteed for one year from the date of purchase.
Within this period, we undertake to repair or exchange this product free of charge (excluding lamps or
batteries and subject to availibility) provided it has been installed and operated in accordance with these
instructions.
Your rights under this guarantee are additional to your statutory rights, which in turn are not affect by this
guarantee.
Should you require after sales service you should contact our customer services help desk on 0844 879

3588. It would assist us if you can quote the model number, series, date of purchase and the nature of the
fault at the time of your call. The customer services helpdesk will also be able to advise you should you
need to purchase any spares.
Please do not return any faullty product to us in the fi rst instance as this may result in loss or damge and
delay in providing you with a staisfactory service.
Please retain your receipt as proof of purchase.

SERVICE

Contact your local dealer for service or warranty information.

RECYCLING

For electrical products sold in the European Community.
At the end of the electrical product’s useful life it should not be disposed of with household waste.
Please recycle where facilities exist. Check with your Local Authority or retailer for recycling
advice in your country.

The product complies with the European Safety Standard EN60335-2-30 and the
European Standard for Electromagnetic Compatibility (EMC) EN55014, EN61000
and EN50366 which cover the essential requirements of EEC Directives 2006/95
and 2004/108.
