Dimplex GDDEYS40 Instruction Manual

– 1 –
40L DEHUMIDIFIER AND AIR PURIFIER
INSTRUCTION MANUAL
GDDEYS40
Dehumidifies a large home and purifies air
– 2 –
Safety and usage notices 5
Components 9
Control panel 10
Display screen 11
Setting Timer 12
Dehumification instructions 13
Automatic dehumification 13
Continuous dehumification 13
Clothes drying 13
Emptying the tank and drainage 14
Air purification and filters 16
Ventilation 16
Air purification function 16
Inserting a filter 17
Filter information 18
Maintenance 19
Self-cleaning mode 20
Troubleshooting 21
Technical specifications 22
– 4 –
Before operating this appliance, please read this instruction manual carefully. Please also keep for future reference.
– 5 –
SAFETY AND USAGE NOTICES
The power supply for this appliance is 220­240V~ If the voltage is 10% higher or lower than the normal voltage, the appliance will not operate. It is suggested that a voltage stabilizer be equipped.
The working range of this appliance is between 5-32oC, outside of these temperatures the appliance will not operate normally. However the optimum working temperature is between 16-32oC. The unit will dehumidifiy between 30%-85% relative humidity.
Technical Specifications
Please position the appliance on a flat and stable surface to reduce vibration and noise.
Please do not position your appliance near flames or heating appliances.
Please do not use the appliance if plug or electrical cord is damaged.
Multi-socket plug adapters are not recommended for use with this appliance.
Usage
Please do not immerse the appliance in water.
– 6 –
SAFETY AND USAGE NOTICES
The appliance is designed for domestic use only, not for commercial purposes.
Please do not use aerosols or other flammable substances near the appliance.
Please do not place anything on top of the appliance.
Please do not tilt the appliance when in use.
Please do not use sharp objects on the appliance to prevent scratching.
Usage
Please do not knot, or fold the power cord, also ensure the power cord is free from tangle and nothing is place on top of it while in operation.
Please do not hang anything over the air outlet, by doing this you will reduce the dehumidification capacity and increase the noise.
Please do not put the automatic drainage pipe directly in the cold outdoors.
– 7 –
When operating the appliance, please keep a clearance of 50cm above and over 30cm surrounding. Please refer to the following figure.
Please keep windows closed when appliance is in use.
Please do not direct your appliance towards plants or pets for long periods of time.
Please do not operate in direct sunlight, this will influence the dehumidification capacity.
SAFETY AND USAGE NOTICES
Usage
– 8 –
SAFETY AND USAGE NOTICES
If the unit is faulty (e.g., burning smells, smoke detected), please turn off the appliance and unplug it, then contact a qualified service agent for maintenance.
If the appliance is not to be used, or is to be stored for a period of time, please activate the self-cleaning function, which will dry the internal components of the appliance and prevent mildew growth.
If the power cord is damaged, it must be replaced by a qualified electrician, service agent or similarly qualified persons in order to avoid malfunction.
This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, unless they have are supervised or given instruction concerning use of the appliance by a person responsible for their safety. Children should be supervised at all times.
Please do not hose down the appliance.
Maintenance and Storage
Repairs are to be done by a qualified electrician or service agent.
Please unplug the appliance when not in use for long periods of time.
Please do not use chemical solvents (e.g., benzene, gasoline, alcohol,etc.) to clean the appliance. Instead, use warm soapy water.
