MODEL: GDC-AC9RW / GDC-AC9RCS

GDC-AC9RCW / GDC-AC12RW
GDC-AC12RB / GDC-AC12RCB

GDC-AC12RCW

INSTRUCTIONS FOR USE

PORTABLE AIR CONDITIONER

1

VERY IMPORTANT！

Do not install and use your portable air conditioner
unit before carefully reading this instruction manual.
Please retain this manual for product warranty and
future reference

CAUTION！

1." DO NOT BLOCK VENTILATION "! Please make sure the inlet and outlet
ventilation is not blocked at all times.

2. Operate this unit on a horizontal surface to avoid water leakage.

3. Do not operate this unit in an explosive or corrosive atmosphere.

4. Operate this unit in an ambient of 32 degree centigrade or less when the unit is

in the cooling function.

Contrarily, when the unit is in the heating function, the

ambient temperature is less 23 degree centigrade

5. Clean the air filter periodically to enjoy the most efficient cooling.

6. When the unit is turned off, please wait at least 3 minutes before restarting it.

This is to prevent the compressor from being damaged.

7. This unit needs at least 10 Amps of electricity to have its compressor operational.

Please do not use any extension cords with this unit.

8. This unit is for indoor operation only.

9. Make sure the adjustable air vent is open, and also the exhaust pipe and drain pipe are

removed and extended to the closest window before using.

10.When the supply cord is damaged, it must be replaced by the manufacturer, its

service agent or similarly qualified persons in order to avoid hazard.

11.The batteries must be removed from the appliance before it is scrapped and

that they are disposed of safely.

12. This appliance is not intended for use by persons (including children) with reduced

physical, sensory or mental capabilities, or lack experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety.

13. Children should be supervised to ensure that they do not play with the appliance.

2

CONGRATULATIONS ON YOUR
SELECTION OF A QUALITY
PORT ABLE AIR CONDITIONER

PORT ABLE AIR CONDITIONER

Y our Air Conditioner has been designed and manufactured to the
highest standards of modern engineering.
One of its many features is a remote control device which allows you
to control all functions conveniently.

- Moves easily from room to room on easy glide castors

- No installation required-just plug into any household 10 Amp
power outlet

- Refrigerated air system designed to cool instantlywhenever
you want it

- Heated air system design heats instantly whenever
you want it

- Dehumidified filtered air cycle for improved breathing
conditions due to the powerful dehumidification
process

-If the remote control function is not required, your one touch
electronic pad provides easy to identify manual operation

-24 hour programmable timer that can be used with either the air
conditioning or dehumidification setting

-Unique sleep control function

-220-240 Volt 50Hz operation

-1.6 meter cord with plug

3

UNPA CKING INSTRUCTIONS

1. Place the unit in the correct upright position before unpacking.

2. Cut the two packing straps.

3. Slide the carton in an upwards motion and it will release from the base.

4. Grip the carry handles located on either side of the unit and carefully lift until it slides
out of the foam base.

CONTENTS

1 / Air control unit
2 / 1-remote control unit
3/ Window kit

4

NAMES OF THE PARTS

1. T ack switch

2. Display screen

3. Adjustable air vent

4. Joint tube

5. Exhaust tube

6. Drain hose

7. Cool inlet

8. Cool Air filter

9. Hot inlet

10. Drain pipe

11. Hot air filter

5

TACK SWITCH & DESCRIPTION OF FUNCTION

1. POWER KEY Press to turn unit "ON" or "OFF".

2. FUNCTION Press this key to select refrigeration, heat or dehumidification.

( heating function just for model number

GDC-AC9RCS/ GDC-AC9RCW/ GDC-AC12RCB/

GDC-AC12RCW)

3. TEMPERATURE REGULATION KEY (UP)

This key raises the preset temperature by 1℃ each time it is pressed to a maximum of 30℃

4. TEMPERATURE REGULATION KEY (DOWN)

This key lowers the preset temperature by 1℃ each time it is pressed to a minimum of 15
℃ or 17℃( For GDC-AC9RW/ GDC-AC12RW/GDC-AC12RB, the minimum is 15℃, for

GDC-AC9RCS/GDC-AC9RCW/GDC-AC12RCB/GDC-AC12RCW,

the minimum is 17℃)

※ In normal conditions, the temperature data which appears on the panel is the ambient

temperature, not the temperature which is set by the user. When the user has adjusted
and set the temperature to his requirement, the data on the panel will return to the

ambient temperature 5 seconds later.
The ambient temperature will descend or change according to the temperature which is
set by the user, but the temperature descendant time and speed will depend on the
environment and space where the model is.
For example, if the ambient temperature is too hot or the room is too large, the speed for the
temperature descent is absolutely slow, and the cooling ef ficiency will be poor as well.

6

5. L.E.D. DISPLAY Indicates the temperature or the time setting. After any time set

the display will return to the preset temperature automatically.

6. SPEED Press to select either LOW, MEDIUM, HIGH or AUTO fan speed.

If "AUTO" is selected, the unit operates at maximum cooling
capacity when the room temperature less the set temperature
is above 2℃.
When the room temperature less the set temperature is below
2℃, the unit operates at middle cooling capacity.
When the room temperature equal the set temperature, the
unit operates at minimum capacity.
If "HIGH" is selected, the unit operates at maximum cooling

capacity no matter what the setting temperature is . The
"MEDIUM" OR “LOW" comes to the same.

7. PROGRAMMABLE Programmable timer ON/OFF key.
TIMER TIMER-ON: The timer-on is used to turn on the unit automati-

cally after the set time is over.

(Timer-on key is correspond to the functional indicator light)

1. Press the "TIMER" key at stand-by status to set the time.
Choose the function desired(refrigeration, heat or
dehumidification.)

2. Once the set hour has come to an end, the unit will turn on
automatically.

3. Press the "POWER" key before time out, the setting time will

be cancelled and the unit will turn on.

TIMER-OFF: The timer-off is used to turn off the unit automati-

cally after the setting time is over.

Error Display
E1: Indicates open circuit or short circuit in room temperature sensor.
E2: Indicates open circuit or short circuit in pipe temperature sensor.
E7: Indicates the water is full inside.
Please contact a authorized service centre if any of the above error messages are shown.

7

8. SLEEP CONTROL When setting the "sleep comfort" mode please ensure that you
FUNCTION then set the number of hours required and press the timer

button till those hours are indicated on the L.E.D display. After
setting the hours the L.E.D. display will automatically return to
the current pre-set temperature. To increase this setting press
the "UP" button for each press, the temperature will be increased
by 1℃. Likewise to set for a lower temperature, press the button
indicating “DOWN”, and for each press the temperature will be
decreased by 1℃.

During the course of this cycle, to ensure maximum sleep
comfort. the micro-processor memory will raise the pre-set
temperature 0.5℃ each half hour to a maximum of 2℃ over two
hours and then maintain that temperature for the balance of the
time set.

The portable air conditioner is fitted with a 3 minutes compressor
delay protection circuit which simply means that the compressor
requires 3 minutes to start. From either being switched on, or
when changing from “dehumidify” to any air conditioning cycle
chosen.

9.”E7” When the unit warns of full water, please unplug the water

stopper at the back of the unit and then lean the unit to drain the
water out. Then the unit can be restarted. If the E7 is presented
again, please find a specialized person to repair.

GDC-AC9RCS/GDC-AC9RCW/GDC-AC12RCB/GDC-AC12RCW with heating
function

Note: Heating function does not operate if the ambient temperature is over 23

℃.

8

REMOTE CONTROL FUNCTION

1. POWER

2. FUNC

3. TIMER

4. AUTO

5. HI

6. MID

7. LOW

8. SLEEP

9. TEMP.

Stop/Start switch
Function “MODE” selector
Hourly programming

A

utomatic fan speed
High fan speed
Medium fan speed
Low fan speed
Night operation selector
Tem

p

erature selecto

r

9

INSTALLATION

Install the portable air conditioner in a flat and spacious location where
the air inlets and outlets will not be blocked. A minimum clearance of
40cm from a wall or other obstacles should be kept (as below picture).
The appliance should not be used in the laundry.

NOTICE

This unit can evaporate the condensation and flow out through the
exhaust hose automatically when the unit is in the cooling function.
Contrarily when the unit is in heating function and the water level reaches
the detected level, it will begin to pump for sixty seconds. After sixty
seconds of pump function, if the water level is still on the detected level,
the unit will stop working and present "E7" warning. Then after three
seconds of relieving malfunction, the unit will rework automatically.
Please make sure that the rubber cap is locked on the drain hose, and
also the exhaust pipe and the drain pipe to be extended to the closest
window when the unit is running.

10

MAINTENANCE

PLEASE DISCONNECT THE POWER CORD BEFORE.

AIR FILTER

The air filter located on both sides of the unit can be removed, simply by
pulling the frame in an upward motion.

CONDENSER/EVAPORATOR

Use a brush attachment with a vacuum cleaner.

CABINET

Wipe with a damp cloth and polish with a soft cloth.

11

To remove the air filter, please follow the arrow direction and push the

filter lightly. Then take out the filter for cleaning.

POWER SUPPLY

(1) Confirm the correct power.
(2) Insert the plug into the outlet firmly.

In case of a dangerous leak, prevent the AC cord from scarri ng.

(3) Don’t pull the power wire by force because it will cause damage to

the power wire.

PLACE FOR USE

(1) Because the machine exerts hot air, please don’t operate it in a narrow

place.

(2) In case of dangerous leak, don’t work the machine in a humid place.

(3) Don’t place the machine in a sunlit corner oth erwise the colors soon fade

out of the machine.

12

HELPFUL HINTS

The unit is fitted with a special thermal cut off device.
When selecting the refrigerating function, The unit should operate in
room temperatures between 17-32℃, and when selecting heating
function, the room temperature must less than 23℃ and above 7℃.
Please ensure the unit is not placed against objects which will
obstruct air intake e.g. furniture or curtains as this will affect it's
performance drastically.
Do not place the unit in direct sunlight, as this may cause the unit to
overheat and turn off.

EXHAUST PIPE AND DRAIN PIPE

● To remove exhaust pipe, press slightly and pull away from the unit.

● Picture indicates the removal of the exhaust pipe.

● Made sure the exhaust pipe and the drain pipe to be extended to the

closest window.

13

TROUBLE SHOOTING

Never try to repair or dismantle the air conditioner unit yourself. Incompetent repairs
result in loss of warranty and can endanger the user and the property.

Problem Cause Solution

No power supply. Connect to a functioning outlet

and switch on.

The alarm light is on. Empty the internal water

container.

The air
conditioner does
not function.

Timer function is active. Deactivate TIMER function.

In direct sunlight. Close curtains.
Windows or doors open,

many people or a heat
source in the room.

Close doors and windows, place
an extra air conditioner.

Dirty filter Clean the filter(s).
Air inlet or air outlet blocked. Remove the blockage.

The air
conditioner does
not seem to
perform.

Room temperature lower
than the selected value.

Change temperature selection.

The unit is noisy. Unit is not level. Place on an even, solid surface

(less vibrations.)

The compressor
does not work.

The overheat protection is
probably activated.

Wait 30 minutes until the
temperature has decreased, then
turn the unit on again.

Distance too long.
Remote control signal not

detected by the control
panel.

Make sure the remote control is
correctly aimed at the control
panel.

The remote
control does not
function.

The batteries are drained Replace the batteries.

To correct prob lems not mentioned in the table and/or if the recommended solutions fail
to solve the problem, please contact an authorized service centre.

14

SPECIFICATIONS

Model No. GDC-AC9RW GDC-AC12RW / GDC-AC12RB
Power Source 220-240V~ 50Hz AC 220-240V~ 50Hz AC
Power Consumption 1080W 1452W
Max Power 1250W 1480W
Cooling Capacity 2600W 3500W
Air Flow 400 M3/H 420 M3/H
De-humidifier
(30℃,80%)

1.6L/hr 2.5L/hr

Refrigerant R410A R410A
For room size up to 20 m

2

25 m2
Dimensions (mm) 476Wx358Dx840H 476Wx358Dx840H
Net Weight 28.5KG 29.5KG

Model No. GDC-AC9RCW/GDC-AC9RCS GDC-AC12RCW/GDC-AC12RCB
Power Source 220-240V~ 50Hz AC 220-240V~ 50Hz AC
Power Consumption

Cooling / Heating 1080W / 1245W

1452W / 1500W
Max Power
Cooling / Heating 1250W / 1350W

1480W / 1530W
Cooling Capacity 2600W 3500W
Heating Capacity 3000W 3700W
Air Flow 400 M

3

/H 420 M3/H
De-humidifier
(30℃,80%)

1.6L/hr 2.5L/hr

Refrigerant R410A R410A
For room size up to 20 m2 25 m2
Dimensions (mm) 476Wx358Dx840H 476Wx358Dx840H
Net Weight 29.5KG 30.5KG

15

Glen Dimplex Australasia Ltd Glen Dimplex Australia Pty Ltd

38 Harris Road, East Tamaki, 2/205 Abbotts Road,
Manukau, Auckland 2013 Dandenong sth 3175, Victoria,
New Zealand Australia
Ph: 0800 666 2824 Ph: 1300 556 816
Fx: 0800 112 020 Fx: 1800 058 900
